An innovative solar monitoring system has been developed. The system aimed at measuring the main parameters and characteristics of solar plants; collecting, diagnosing and processing data. The system communicates with the inverters, electrometers, metrological equipment and additional components of the photovoltaic arrays. The developed and constructed long working system is built on special data collecting technologies. At the generating plants, a special data logger BBbox is installed. The new monitoring system has been used to follow 65 solar plants in the Czech Republic and elsewhere for 175 MWp. As an example, we have selected 13 PV plants in this paper that are at least seven years old. The monitoring system contributes to quality management of plants, and it also provides data for scientific purposes. Production of electricity in the built PV plants reflects the expected values according to internationally used software PVGIS (version 5) during the previous seven years of operation. A comparison of important system parameters clearly shows the new solutions and benefits of the new Solarmon-2.0 monitoring system. Secured communications will increase data protection. A higher frequency of data saving allows higher accuracy of the mathematical models. Full article

In this study, pristine palygorskite powders were used as the inhibition materials to suppress the explosion of methane-air premixed gas for the first time. The composition, porosity and pyrolysis characteristics of the powders were tested by X-ray diffraction (XRD), energy dispersive spectrometry (EDS), N₂ adsorption-desorption and Thermogravimetry-differential scanning calorimetry (TG-DSC) techniques. The effects of pristine palygorskite powders concentration on the explosion pressure and the average velocity of flame propagation of the 9.5% methane-air premixed gas were tested by a 20 L spherical explosion system and a 5 L pipeline explosion system. The results indicated the pristine palygorskite powders possess a considerable suppression property on methane explosion. When the mass concentration of pristine palygorskite powders was 0.20 g·L⁻¹, the max-pressure of methane explosion was decreased by 23.9%. The methane explosion flame propagation velocity was inhibited obviously. Owing to the excellent inhibitory performance and the advantage of low-cost and environmental harmlessness, pristine palygorskite powders are potential new materials for the application on gas explosion suppression. Full article

Power systems are the most complex systems that have been created by men in history. To operate such systems in a stable mode, several control loops are needed. Voltage frequency plays a vital role in power systems which need to be properly controlled. To this end, primary and secondary frequency control loops are used to control the frequency of the voltage in power systems. Secondary frequency control, which is called Load Frequency Control (LFC), is responsible for maintaining the frequency in a desirable level after a disturbance. Likewise, the power exchanges between different control areas are controlled by LFC approaches. In recent decades, many control approaches have been suggested for LFC in power systems. This paper presents a comprehensive literature survey on the topic of LFC. In this survey, the used LFC models for diverse configurations of power systems are firstly investigated and classified for both conventional and future smart power systems. Furthermore, the proposed control strategies for LFC are studied and categorized into different control groups. The paper concludes with highlighting the research gaps and presenting some new research directions in the field of LFC. Full article

Demand response (DR) is an effective solution used to maintain the reliability of power systems. Although numerous demand bidding models were designed to balance the demand and supply of electricity, these works focused on optimizing the DR supply curve of aggregator and the associated clearing prices. Limited researches were done to investigate the interaction between each aggregator and its customers to ensure the delivery of promised load curtailments. In this paper, a closed demand bidding model is envisioned to bridge the aforementioned gap by facilitating the internal DR trading between the aggregator and its large contract customers. The customers can submit their own bid as a pairs of bidding price and quantity of load curtailment in hourly basis when demand bidding is needed. A purchase optimization scheme is then designed to minimize the total bidding purchase cost. Given the presence of various load curtailment constraints, the demand bidding model considered is highly nonlinear. A modified genetic algorithm incorporated with efficient encoding scheme and adaptive bid declination strategy is therefore proposed to solve this problem effectively. Extensive simulation shows that the proposed purchase optimization scheme can minimize the total cost of demand bidding and it is computationally feasible for real applications. Full article

In microgrid, the grid-connected inverter current with the LCL (inductor-capacitor-inductor) output filter is amplified at certain frequencies. Using virtual resistor damping method can help suppress the amplification. By choosing an appropriate virtual resistor value, the model of the inverter current control loop is simplified as a 2^nd-order lowpass filter. Based on such simplified model, this paper proposes a design method of reference current compensation controller, which does not require decomposition of harmonic components. With the reference compensation, the inverter output current control precision is improved obviously. The simulation and experimental results verify the accuracy of the inverter simplified model and effectiveness of the reference compensation design method. Full article

This paper has two aims. The first is to develop a robust hierarchical tracking controller for the DC/DC Buck-Boost–inverter–DC motor system. This controller considers a high level control for the inverter–DC motor subsystems and a low level control for the DC/DC Buck-Boost converter subsystem. Such controls solve the tracking task associated with the angular velocity of the motor shaft and the output voltage of the converter, respectively, via the differential flatness approach. The second aim is to present a comparison of the robust hierarchical controller to a passive controller. This, with the purpose of showing that performance achieved with the hierarchical controller proposed in this paper, is better than the one achieved with the passive controller. Both controllers are experimentally implemented on a prototype of the DC/DC Buck-Boost–inverter–DC motor system by using Matlab-Simulink along with the DS1104 board from dSPACE. According to experimental results, the proposal in the present paper achieves a better performance than the passive controller. Full article

This article studies the challenges of Thai energy-from-waste (EFW) development from an institutional perspective. Policy capacity, described as conditions for effective policy development and implementation, of the main government organizations involved in EFW development under the Alternative Energy Development Plan (AEDP) 2015 is examined. Adopting the variables used under the institutional analytical and development (IAD) approach, we modified the analytical framework for policy capacity by categorizing factors contributing to policy capacity into elements (skills, resources, and process) that affect the decisions and actions of actors of government organizations. Then, the results from the in-depth interview were interpreted through a modified analytical framework to examine policy capacity at the organizational and systemic level of government organizations involved in EFW development. We believe that a modified analytical framework for policy capacity is compatible with the IAD approach and can facilitate the utilization of policy capacity for further analysis under the IAD approach. Moreover, the modified framework can encourage a better understanding of current policy capacity and its impacts on other organizations, since an organization values its own policy capacity and others’ policy capacity differently. Consequently, this understanding can benefit the improvement of cooperation among Thai government organizations involved in EFW development. Full article

Regional protection based on multisource information of a regional power network depends on communication technology. A partition strategy considering communication constraints and implementation techniques must be considered to realize the regional protection of a large power grid. This paper aims at examining the technical requirements of rapid and reliable regional protection, considering the number of hops as the factor affecting communication between secondary substations and primary substations, and combining this with the equalization of substations. Then, a primary substation selection model of regional protection based on an exhaustive method is proposed using the Floyd–Warshall algorithm (an algorithm for finding shortest paths in a weighted graph). The partition model is further established according to the multifactors that affect the communication delay time for regional protection. Focusing on the N-1 channel fault in the preset region after the formation of the subregions, this paper analyzes the circuitous process of information in an interrupt channel and considers the influence of communication delay time to further improve the partition strategy. Finally, this paper puts forward techniques for partition strategy implementation based on graph theory; an example analysis of an actual power network is also given, and the conclusions of multiple partitions of the same power network are compared and analyzed. Besides this, partition suggestions and theoretical guidance considering actual engineering demands are given. Full article

This paper develops a numerical model to study fracture network evolution during the nitrogen fracturing process in shale reservoirs. This model considers the differences of incompressible and compressible fluids, shear and tensile failure modes, shale heterogeneity, and the strength and permeability of both shale matrix and bedding planes through the coupling of mechanical-seepage-damage during fracturing fluid injection. The results show that nitrogen fracturing has a lower breakdown pressure and larger seepage zone than hydraulic fracturing under the same injection pressure. Tensile failure was identified as the major reason for the initiation and propagation of fractures. Ignoring the effect of bedding planes, the fracture initiation pressure, breakdown pressure, and fracturing effectiveness reached their maxima when the stress ratio is 1. Under the same strength ratio, the propagation path of the fractures was controlled by the stronger effect that was casused by the bedding angle and stress ratio. With increasing the strength ratio, the fracture number and shearing of the bedding plane increased significantly and the failure pattern changed from tensile-only mode to tensile-shear mode. These analyses indicated that the fracture network of bedding shale was typically induced by the combined impacts of stress ratio, bedding angle and strength ratio. Full article

The dendritic fin was introduced to improve the solid-liquid phase change in heat exchangers. A theoretical model of melting phase change in dendritic heat exchangers was developed and numerically simulated. The solid-liquid phase interface, liquid phase rate and dynamic temperature change in dendritic heat exchanger during melting process are investigated and compared with radial-fin heat exchanger. The results indicate that the dendritic fin is able to enhance the solid-liquid phase change in heat exchanger for latent thermal storage. The presence of dendritic fin leads to the formation of multiple independent PCM zones, so the heat can be quickly diffused from one point to across the surface along the metal fins, thereby making the PCM far away from heat sources melt earlier and faster. In addition, the dendritic structure makes the PCM temperature distribution more uniform over the entire zone inside heat exchangers due to high-efficient heat flow distribution of dendritic fins. As a result, the time required for the complete melting of the PCM in dendritic heat exchanger is shorter than that of the radial-fin heat exchanger. Full article

A small laboratory fluidized bed reactor is used to test the chemical reactivity of solid particles fluidized with a gas. The novelty of the system is that it can be used for testing any solid particles, and, in this work, oxygen carriers with Mn/Si oxide supported on TiO₂ are used to present the possibilities and layout of the laboratory system. The system is equipped with automatic valves that make it possible to rapidly change the gas conditions in the reactor. The setup facilitates solid particle testing using a sample of a few grams with gas-solid contact conditions relevant for a full-scale fluidized bed. With this small system, it is possible to mimic a section or a part of a larger system. It is also possible to test extreme conditions that can occur in a bigger unit. The system is designed for determining chemical reactivity in combustion, gasification, and reforming, but it can be used for investigating any type of gas-solid reaction in fluidized bed conditions. The setup presented here is one of the smallest possible devices that can be realized while maintaining fluidized bed conditions. Full article

The objective of this study was to numerically investigate the heat transfer characteristics of a 36V electronic control unit (ECU) system of an electric bicycle and to validate the experimental data. The temperatures of the ECU heatsink, seven metal-oxide-silicon field effect transistors (MOSFETs) and two capacitors of the 36V ECU system were numerically derived under variable operating conditions including power dissipation, thermal grease, ambient temperature and heatsink material, to analyze the heat transfer characteristics. When the thermal conductivity of the thermal grease increased from 0.01 W/m °C to 3.0 W/m° C, the temperatures of the seven MOSFETs and the two capacitors decreased by 51.245% and 3.58%, respectively. When the total power dissipation increased from 2.57 MW/m³ to 4.26 MW/m³, the temperatures of the ECU heatsink, seven MOSFETs and the two capacitors increased by 20.95%, 30.31% and 21.54%, respectively. Furthermore, increasing the ambient temperatures from 30 °C to 40 °C resulted in an increase in the temperatures of the ECU heatsink, MOSFET and capacitor by 24.75%, 9.93% and 22.04% respectively.. These numerically derived temperatures for the MOSFET and the ECU heatsink were validated with the experimental results within a range of 7.2% and 1.7%, respectively. This confirmed that the applied numerical model was valid. Full article

This study investigates numerically the effect of the two-phase nanofluid model due to natural convection within a square cavity along with the existence of a conducting solid block, and a corner heater using the finite difference method (FDM). The top horizontal wall is retained at a cold temperature that is fixed as constant, while the isothermal heater is positioned at the bottom left corner within the square cavity. The remaining fractions of the right vertical wall and the heated wall are set to be adiabatic. The water-based nanofluid, together with Al ${}_2$ O ${}_3$ nanoparticles, have been evaluated by determining the following parameters: the volume fraction of nanoparticles, thickness of solid block, Rayleigh number, and the solid block thermal conductivity. As a result, the comparative evaluation with outputs reported in publications and prior experimental works has pointed out exceptional agreement with the findings retrieved in this study. The experimental outcomes are graphically illustrated in terms of the average and local Nusselt numbers, isotherms, distribution of nanoparticles, and the streamlines. The findings indicate that an elevation of the thermal conductivity in blocks with a similar size successfully increases the transfer rate of heat, wherein the dominance of conduction has been observed. Full article

In recent years, the International Maritime Organization agreed on aiming to reduce shipping’s greenhouse gas emissions by 50% with respect to 2009 levels. Meanwhile, cruise ship tourism is growing at a fast pace, making the challenge of achieving this goal even harder. The complexity of the energy system of these ships makes them of particular interest from an energy systems perspective. To illustrate this, we analyzed the energy and exergy flow rates of a cruise ship sailing in the Baltic Sea based on measurements from one year of the ship’s operations. The energy analysis allows identifying propulsion as the main energy user (46% of the total) followed by heat (27%) and electric power (27%) generation; the exergy analysis allowed instead identifying the main inefficiencies of the system: while exergy is primarily destroyed in all processes involving combustion (76% of the total), the other main causes of exergy destruction are the turbochargers, the heat recovery steam generators, the steam heaters, the preheater in the accommodation heating systems, the sea water coolers, and the electric generators; the main exergy losses take place in the exhaust gas of the engines not equipped with heat recovery devices. The application of clustering of the ship’s operations based on the concept of typical operational days suggests that the use of five typical days provides a good approximation of the yearly ship’s operations and can hence be used for the design and optimization of the energy systems of the ship. Full article

The concept of a Self-Excited Induction Generator (SEIG) has introduced the concept of the placement of an induction machine for power generation in an isolated mode with external capacitance. The produced output voltage and generated frequency in an SEIG greatly depends on speed, load, and terminal capacitance. To maintain constant air-gap voltage against a varying speed and load, a corresponding supply of reactive power through capacitors is needed. The selection of the required capacitance while there is continuous variation of vital parameters needs a rigorous random-selection method. In this paper, an intelligent selection of suitable additional capacitance has been made by using the Fuzzy Logic Technique for a Three-Phase 5.0 HP SEIG. Additional capacitance in the range of 14.79–22.47 μF is compulsory under a varying load of 427−101 ohms, and additional capacitance in the range of 13.70–22.59 μF is essential for a varying speed of 1349 to 1672 RPM. With this promising result, we propose the implementation of this intelligent technique in place of analytical and standard methods for capacitance selection. Full article

The electric field distribution at the end of a large hydro-generator is highly nonuniform and prone to corona discharge, which damages the main insulation and significantly reduces the service life of the hydro-generator. In order to reduce the thickness of the main insulation and the physical size of a large hydro-generator, it is necessary to understand the distribution of the electric field at the end of its stator bar. In this paper, the stator bar at the end of a large generator is simulated using the finite element method to determine the distribution of the potential, electric field, and loss at the rated voltage, as well as to elucidate the differences between the linear corona protection, two-segment nonlinear corona protection, and three-segment nonlinear corona protection structures. The influences of the arc angle, length of each corona protection layer, intrinsic resistivity of the corona protection material, and nonlinear coefficient are also analyzed. The results manifest that the angle of the stator bar should be 22.5°, the difference in resistivity between the two adjacent corona protection coatings should not exceed two orders of magnitude, and the resistivity of the medium resistivity layer should be nearly 10⁶ Ω·m or 10⁷ Ω·m, for an optimal design of the corona protection structure. Full article

Recently, Low-Voltage DC (direct current) distribution systems have received high lights according to the expansion of DC generations and DC loads such as photovoltaics (PV) generations, electric vehicles (EVs), light emitting diodes (LEDs), computers, DC homes, etc. Low-Voltage DC distribution systems have optimistic perspectives since DC has various good aspects compared to alternating current (AC). However, ensuring safety of human and electric facility in Low-Voltage DC is not easy because of arc generation and difficulty of arc-extinguishing. This paper constructs a low-voltage DC circuit and studies the arc interruption that occurs when separating electrodes from where load currents flow. Also, arc extinguishers are experimented upon and analysed in various levels of source voltage and load currents conditions. Voltage and current characteristics for arc interruption are identified based on experimental results, and we establish the electric generation for arc interruption. Further, the voltage–current characteristics and the correlation of arc during arc duration time arc are verified, and the voltage–current equation and DC arc resistance model for the breaking arc are developed. Full article

Rechargeable Li metal batteries have attracted lots of attention because they can achieve high energy densities. However, the commercialization of rechargeable Li metal batteries is delayed because Li dendrites may be generated during the batteries’ electrochemical cycles, which may cause severe safety issues. In this research, a Li-B alloy is investigated as an anode for rechargeable batteries instead of Li metal. Results show that the Li-B alloy has better effects in suppressing the formation of dendritic lithium, reducing the interface impedance and improving the cycle performance. These effects may result from the unique structure of Li-B alloy, in which free lithium is embedded in the Li₇B₆ framework. These results suggest that Li-B alloy may be a promising anode material applicable in rechargeable lithium batteries. Full article

A numerical model is proposed to perform CFD simulations of biomass boilers working in different operating conditions and analyse the results with low computational effort. The model is based on steady fluxes that represent the biomass thermal conversion stages through the conservation of mass, energy, and chemical species in the packed bed region. The conversion reactions are combined with heat and mass transfer submodels that release the combustion products to the gas flow. The gas flow is calculated through classical finite volume techniques to model the transport and reaction phenomena. The overall process is calculated in a steady state with a fast, efficient, and reasonably accurate method, which allows the results to converge without long computation times. The modelling is applied to the simulation of a 30 kW domestic boiler, and the results are compared with experimental tests with reasonably good results for such a simple model. The model is also applied to study the effect of air enrichment in boiler performance and gas emissions. The boiler operation is simulated using different oxygen concentrations that range from 21% to 90% in the feeding air, and parameters such as the heat transferred, fume temperatures, and emissions of CO, CO₂, and NO_x are analysed. The results show that with a moderated air enrichment of 40% oxygen, the energy performance can be increased by 8%, CO emissions are noticeably reduced, and NO_x remains practically stable. Full article

Along with the emerging development of demand side management applications, it is still a challenge to exploit flexibility realistically to resolve or prevent specific geographical network issues due to limited situational awareness of the (unbalanced low-voltage) network as well as complex time dependent constraints. To overcome these problems, this paper presents a time-horizon three-phase grid-supportive demand side management methodology for low voltage networks by using a universal interface that is established between the demand side management application and the monitoring and network analysis tools of the network operator. Using time-horizon predictions of the system states that the probability of operational limit violations is identified. Since this analysis is computationally intensive, a data driven approach is adopted by using machine learning. Time-horizon flexibility is procured, which effectively prevents operation limit violation from occurring independent of the objective that the demand side management application has. A practical example featuring fair power sharing demonstrates the effectiveness of the presented method for resolving over-voltages and under-voltages. This is followed by conclusions and recommendations for future work. Full article

A single-phase grid-connected converter is considered in this paper in the presence of harmonic problems introduced non-linear loads. In order to compensate the harmonics caused by the loads, a local voltage support scheme is proposed. This is an added feature because its implementation is in parallel with a conventional current control method. Distinctively, the measurements of the grid or load current are not needed since the scheme is based on only local measurements. On top of a fundamental part for desired power injection, the converter output current comprises a harmonic part for compensation. Thus, the grid current harmonic distortion is minimized and the enhancement of the local voltage quality is achieved. A comprehensive model analysis indicates that the proposed strategy can help to attenuate harmonics of the local voltage without compromising on the quality of the fundamental current injection. Experimental results validate the effectiveness of the proposed control scheme. Moreover, the impact of grid frequency estimation error on the control strategy’s performance is quantified theoretically and experimentally. Full article

Dwellings built between 1945 and 1980 have the largest energy demand in the EU, which by 2009 represented 70% of the final energy use in buildings. A great portion of these dwellings have not been retrofitted and most of them were not built with any energy efficiency measures, since most of the energy regulations were implemented after the oil crisis in the 70s. To face this issue several actions were taken in the EU, among these, the implementation of Energy Performance Certification, which includes a Recommendation List of Measures (RLMs) to retrofit the property. The main objective of this study is to identify the weaknesses of the RLMs and to suggest changes to improve the quality and impact of this feature. The results indicate that to retrofit an existing building, the RLMs lack information for decision-making. The study suggests important barriers to overcome for achieving potential energy reductions in existing residential buildings, highlighting improvements to the recommendation content and its implementation. Full article

The emerging global wave energy industry has the potential to contribute to the world’s energy needs, but careful consideration of potential impacts to coastal processes in the form of an impact assessment is required for each new wave energy site. Methods for conducting a coastal processes impact assessment for wave energy arrays vary considerably in the scientific literature, particularly with respect to characterising the energy absorption of a wave energy converter (WEC) array in a wave model. In this paper, modelling methods used in the scientific literature to study wave farm impacts on coastal processes are reviewed, with the aim of determining modelling guidance for impact assessments. Effects on wave climate, beach morphology, and the surfing resource for coastal water users are considered. A novel parameterisation for the WEC array transmission coefficient is presented that, for the first time, uses the permitted power rating of the wave farm, which is usually well defined at the impact assessment stage, to estimate the maximum likely absorption of a permitted WEC array. A coastal processes impact assessment case study from a wave farm in south-west Ireland is used to illustrate the application of the reviewed methods, and demonstrates that using the new ‘rated power transmission coefficient’ rather than a WEC-derived transmission coefficient or complete energy absorption scenario can make the difference between significant and non-significant levels of coastal impacts being predicted. Full article

This paper describes a novel observation on partial discharges (PDs), which occur despite the absence of an applied voltage, within a chopped sequence. It was found that additional discharge pulses occur when a specimen is subjected to chopped sequences rather than a continuous sinusoid. The discharge pulses, called Partial Discharge Echoes (PDE), appeared in time intervals (where no voltage was being applied), immediately after the specimen had been exposed to a base waveform (e.g., sinusoidal) above a partial discharge inception level. The chopped timing is composed of a multiple series of packets consisting of base waveforms, with each packet being separated in time by a defined delay period. The presented experiments were performed on specimens with an embedded gaseous void, in thermosetting insulation and glass as a non-polar material, for comparison. Acquisition of the echo signal was performed in the phase-resolved mode, modifying the synchronization path and the settings. In contrast to continuous sinusoidal PD measurements, the chopped approach might provide a deeper insight into key PD phenomena, such as inception, propagation, time lag, post-discharge time decay, and effective surface area. Special focus was paid to the transition point between sinusoidal phase and the echo interval. The various scenarios of an echo mechanism, depending on the coincidence of remnant polarization field and the field accumulated on void walls, are discussed. Full article

Using active control methods for load mitigation in wind turbines could greatly reduce the cost of per kilowatt hour of wind power. In this work, the combined pitch and trailing edge flap control (CPFC) for load mitigation of wind turbines is investigated. The CPFC includes an individual pitch control (IPC) loop and a trailing edge flap control (TEFC) loop, which are combined by a load frequency division control algorithm. The IPC loop is mainly used to mitigate the low frequency loads, and the TEFC loop is mainly used to mitigate the high frequency loads. The CPFC adopts both an azimuth angle feed-forward and a loads feedback control strategy. The azimuth angle feed-forward control strategy should mitigate the asymmetrical loads caused by observable disturbances. and the loads feedback control strategy should decrease asymmetrical loads by closed loop control. A simulation is carried out on the joint platform of FAST and MATLAB. The simulation results show that the damage equivalent load (DEL) of blade root out-of-plane bending moment is reduced by 53.7% while using CPFC, compared to collective pitch control (CPC); and the standard deviation of blade tip out-of-plane deflection is reduced by 50.2% while using CPFC, compared to CPC. The results demonstrate that the CPFC can mitigate the fatigue loads of wind turbines as anticipated. Full article

EU energy policy is more and more promoting a resilient, efficient and sustainable energy system. Several agreements have been signed in the last few months that set ambitious goals in terms of energy efficiency and emission reductions and to reduce the energy consumption in buildings. These actions are expected to fulfill the goals negotiated at the Paris Agreement in 2015. The successful development of this ambitious energy policy needs to be supported by scientific knowledge: a huge effort must be made in order to develop more efficient energy conversion technologies based both on renewables and fossil fuels. Similarly, researchers are also expected to work on the integration of conventional and novel systems, also taking into account the needs for the management of the novel energy systems in terms of energy storage and devices management. Therefore, a multi-disciplinary approach is required in order to achieve these goals. To ensure that the scientists belonging to the different disciplines are aware of the scientific progress in the other research areas, specific Conferences are periodically organized. One of the most popular conferences in this area is the Sustainable Development of Energy, Water and Environment Systems (SDEWES) Series Conference. The 12th Sustainable Development of Energy, Water and Environment Systems Conference was recently held in Dubrovnik, Croatia. The present Special Issue of Energies, specifically dedicated to the 12th SDEWES Conference, is focused on five main fields: energy policy and energy efficiency in smart energy systems, polygeneration and district heating, advanced combustion techniques and fuels, biomass and building efficiency. Full article

Downwind rotors are a promising concept for multi-megawatt scale large wind turbines due to their advantages in safety and cost reduction. However, they have risks from impulsive loads when one of the blades passes across the tower wake, where the wind speed is lower and locally turbulent. Although the tower shadow effects on the tower loads have been discussed in former studies, there is currently no appropriate model for the blade-element and momentum theory so far. This study formulates the tower shadow effects on the tower load variation induced by blades using the lifting line theory, which does not require any empirical parameters. The method is verified via computational fluid dynamics for a 2 MW(megawatt), 3-bladed downwind turbine. The amplitude and the phase of the variation are shown to be accurate in outboard sections, where the rotor-tower clearance is large (>3.0 times of the tower diameter) and the ratio of the blade chord length is small (<0.5 times of the tower diameter), in both of rated and cut-out conditions. Full article

Extended exergy accounting (EEA) is a methodology which estimates the extended exergy cost (EEC) of a product or a service or the extended exergy efficiency (EEE) of a country or economic sector taking into account materials, energy, labour, capital, and environmental impact. The use of EEA results for policy or planning purposes has been hampered by: (1) the lack of data to quantify the EEC of most of the inputs, making it almost impossible to quantify the EEC of a product or service and (2) the lack of a conceptual framework to quantify in a consistent way the exergy of labour and capital. In this paper, we make a review of past studies to identify, synthesize, and discuss the different EEA methods. We identified 3 different EEA methods, that we further compare using the Portuguese Agriculture, Forestry, and Fishery (AFF) sector from 2000 to 2012. The equivalent exergies of labour and capital estimated for the AFF sector vary widely among the three EEA methodologies. We propose and test a new EEA methodology to estimate EEE which accounts for these fluxes in a more restricted scope but more consistently and that includes the Environmental Benefit (EB) that represents the capability of the forestry to capture carbon dioxide. Results show that the EEE of the Portuguese AFF sector has increased by 32% from 2000 to 2012. Full article

The objective of this study was to develop an optimal evaluation system for collocating photovoltaic (PV) modules and power conditioners by using the extension engineering method. The matter-element model and correlation functions of the extension theory were adopted as the basis of the proposed extension evaluation system, which was then used to develop a multilevel evaluation model for PV modules and PV power conditioners. The extension evaluation system was used to evaluate and test numerous PV modules and power conditioner products that are commonly employed and commercially available in Taiwan. First, a PV module matter-element model was established based on price, power temperature, size, and weight, and a PV power conditioner matter-element model was established based on input voltage range, maximum power point tracking (MPPT) voltage range, number of MPPT units, minimum operating voltage, and maximum input current. Second, the weighting values of the various characteristics in the extension method were determined according to numerous consideration factors of the PV modules and power conditioners. Finally, the values of the degree of correlation between numerous user preferences and the various PV modules and power conditioner brands were calculated using correlation functions to determine the key components of PV power generation systems (PV-PGSs) that corresponded to user preferences. The test results confirmed that the proposed extension evaluation system can determine the optimal collocation for the key components of the PV-PGSs under different user preference settings. Full article

The inter-turn short circuit is a common fault in the synchronous generator. This fault is not easily detected at early stage. However, with the development of the fault, it will pose a threat to the safe operation of the generator. To detect the inter-turn short circuit of rotor winding, the feasibility of identifying the stator branch characteristics of synchronous generator during inter-turn short circuit was analyzed. In this paper, an on-line fault identification method based on Volterra kernel identification is presented. This method uses the stator branch voltage and stator unbalance branch current collected from the generator as input and output signals of the series model. Recursive batch least squares method is applied to calculate the three kernels of Volterra series. When the generator is in normal state or fault state, the Volterra kernel will change accordingly. Through the identification of the time-domain kernel of the nonlinear transfer model, the inter-turn short circuit fault of the synchronous generator is diagnosed. The correctness and effectiveness of this method is verified by using the data of fault experimental synchronous generator. Full article

The model parameter identification based on real operation data is a means to accurately determine the simulation parameters of the microgrid, but the real operation data cannot guarantee the exact agreement with the required data for parameter identification, which has become an important restriction factor in the accurate simulation and analysis of the dynamics of the microgrid. This paper provides a method of modeling of microgrid based on data testing and parameter identification. In this paper, the method of parameter trajectory sensitivity is first introduced. Then, the data testing scheme for parameter identification is presented, and the parameter identification flow chart is given. Thirdly, a microgrid demonstration system in China is taken as an example, the important parameters of the distributed photovoltaic, direct-drive wind turbine and energy storage unit in the system are obtained by data testing and parameter identification, and in the end, the accuracy of the model is verified through the comparison of the simulation data and the test data of the microgrid during grid-connection/island switching process. The obtained microgrid model provides a base model for the analysis of the overall characteristics, such as the transient stability, as well as power quality of the microgrid. Full article

This paper presents a decision support model for negotiation portfolio optimization considering the participation of players in local markets (at the microgrid level) and in external markets, namely in regional markets, wholesale negotiations and negotiations of bilateral agreements. A local internal market model for microgrids is defined, and the connection between interconnected microgrids is based on nodal pricing to enable negotiations between nearby microgrids. The market environment considering the local market setting and the interaction between integrated microgrids is modeled using a multi-agent approach. Several multi-agent systems are used to model the electricity market environment, the interaction between small players at a microgrid scale, and to accommodate the decision support features. The integration of the proposed models in this multi-agent society and interaction between these distinct specific multi-agent systems enables modeling the system as a whole and thus testing and validating the impact of the method in the outcomes of the involved players. Results show that considering the several negotiation opportunities as complementary and making use of the most appropriate markets depending on the expected prices at each moment allows players to achieve more profitable results. Full article

The arrival time of a microseismic event is an important piece of information for microseismic monitoring. The accuracy and efficiency of arrival time identification is affected by many factors, such as the low signal-to-noise ratio (SNR) of the records, the vast amount of real-time monitoring records, and the abnormal situations of monitoring equipment. In order to eliminate the interference of these factors, we propose a method based on phase-only correlation (POC) to estimate the relative arrival times of microseismic events. The proposed method includes three main steps: (1) The SNR of the records is improved via time-frequency transform, which is used to obtain the time-frequency representation of each trace of a microseismic event. (2) The POC functions of all pairs of time-frequency representations are calculated. The peak value of the POC function indicates the similarity of the traces, and the peak position in the time lag axis indicates the relative arrival times between the traces. (3) Using the peak values as weighting coefficients of the linear equations, consistency processing is used to exclude any abnormal situations and obtain the optimal relative arrival times. We used synthetic data and field data to validate the proposed method. Comparing with Akaike information criterion (AIC) and cross-correlation, the proposed method is more robust at estimating the relative arrival time and excluding the influence of abnormal situations. Full article

Smart grids are robust, self-healing networks that allow bidirectional propagation of energy and information within the utility grid. This introduces a new type of energy user who consumes, produces, stores and shares energy with other grid users. Such a user is called a “prosumer.” Prosumers’ participation in the smart grid is critical for the sustainability and long-term efficiency of the energy sharing process. Thus, prosumer management has attracted increasing attention among researchers in recent years. This paper systematically examines the literature on prosumer community based smart grid by reviewing relevant literature published from 2009 to 2018 in reputed energy and technology journals. We specifically focus on two dimensions namely prosumer community groups and prosumer relationships. Based on the evaluated literature, we present eight propositions and thoroughly describe several future research directions. Full article

In this paper, a numerical model of the kinetic Monte Carlo (KMC) method has been developed to study the oxygen reduction reaction (ORR) that occurs inside the cathode catalyst layer (CCL). Firstly, a 3-D model of the CCL that consists of Pt and carbon spheres is built using the sphere packing method; secondly, an efficient procedure of the proton-oxygen reaction process is developed and simulated. In the proton-oxygen reaction process, all of the continuous movements of protons and oxygen are considered. The maximum reaction distance is determined to be 8 Å. The input pressures of protons and oxygen are represented by the number of spheres of the species. The value of the current density is calculated based on the amount of reaction during the interval time. Indications are that the results of the present model match reasonably well with the published results. A new way to apply the KMC method in the proton exchange membrane fuel cell (PEMFC) research field is developed in this paper. Full article

Electric power systems are experiencing relevant changes involving the growing penetration of distributed generation and energy storage systems, the introduction of electric vehicles, the management of responsive loads, the proposals for new energy markets and so on. Such an evolution is pushing a paradigm shift that is one of the most important challenges in power network design: the management must move from traditional planning and manual intervention to full “smartization” of medium and low voltage networks. Peculiarities and criticalities of future power distribution networks originate from the complexity of the system which includes both the physical aspects of electric networks and the cyber aspects, like data elaboration, feature extraction, communication, supervision and control; only fully integrated advanced monitoring systems can foster this transition towards network automation. The design and development of such future networks require distinct kinds of expertise in the industrial and information engineering fields. In this context, this paper provides a comprehensive review of current challenges and multidisciplinary interactions in the development of smart distribution networks. The aim of this paper is to discuss, in an integrated and organized manner, the state of the art while focusing on the need for interaction between different disciplines and highlighting how innovative and future-proof outcomes of both research and practice can only emerge from a coordinated design of all the layers in the smart distribution network architecture. Full article

A wide experimental database on indicated pressure diagrams measured on a turbocharged diesel engine, equipped with high and low pressure exhaust gas recirculation (EGR) circuits and a variable nozzle turbine (VNT), was processed to evaluate a large set of combustion parameters. Available data were referred to different tests in three part load operating conditions, focused on High Pressure EGR trade-off and the development of integrated control strategies for EGR and turbocharging systems aiming at NO_X and fuel consumption reduction. According to their definition, combustion parameters were derived from pressure diagrams, its first derivative and heat release curves. Their calculation allowed enlarging the information content of measured in-cylinder pressure diagrams. Several linear correlations were then defined, linking engine operating, energy and environmental quantities to combustion parameters, useful for the analysis and modeling of in-cylinder processes and engine behavior. The influence of testing conditions on these relationships was also analyzed, referring to the investigated operating modes and the adoption of open and closed loop scheme for VNT management. Finally, general correlations were defined, linking NO_X and soot emissions to selected quantities. Full article

The general method to suppress the axial force of the permanent magnet synchronous motor (PMSM) direct-drive turbine is to increase the number of balance devices, such as balance disks and special bearings, to counteract its influence, but this also leads to complex system structure and higher mechanical losses. Aiming to solve the above issue, this paper presents a novel PMSM structure with a conical-rotor (CR). Due to its adaptive equilibrium of axial force and simple structure of rotor with turbine, the CR-PMSM can help improve the system efficiency. Both surface-type and interior-type motors are analyzed, and the axial magnetic force of CR-PMSM is studied in detail. The 3-D finite-element method (FEM) is used to model and simulate the machine, and the magnetic-field distribution, axial magnetic force and driving performance are obtained. Also, the control rule of d-axis current is analyzed to achieve the adaptive equilibrium of axial force. A 2.0 kW, 6000 r/min prototype motor is fabricated and tested to validate the theory. Full article

In this paper, a Lyapunov-based method is used in order to determine the stability boundaries of the grid-connected voltage source converter (VSC). To do so, a state space model of the VSC is used to form the Lyapunov function of the system. Then, by using the eigenvalues of the Lyapunov function, the system stability boundaries will be determined. It is shown that the grid-connected VSC works in its stable mode when all of its Lyapunov function’s eigenvalues are positive. The proposed model validity is tested by time-domain simulation. Simulation results show that the method is credible in determining the stability margin of the grid-connected VSC. Full article

An experimental study has been conducted into the ignition and combustion processes of composite fuel droplets fed into a heated muffle furnace on a holder. Consistent patterns and characteristics of physical and chemical processes have been established for a group of fuel compositions: wet coal processing waste (a mixture of fine coals and water) 85% + municipal solid waste (wood, or plastic, or rubber) 10% + used oil 5%. Burning a coal-water slurry instead of dry coal dust is characterized by a positive environmental effect. Adding used oil to a coal-water slurry results in better energy performance characteristics of the composite fuel during combustion. Adding fine municipal solid waste (MSW) to the fuel composition makes it possible to effectively recover it by burning in boiler furnaces with energy performance characteristics of combustion and environmental characteristics of flue gases that are as good as those of composite fuel compositions without MSW. Sustainability of the composite fuel ignition process and complete burnout of liquid and solid combustible components have been determined. The values of the guaranteed ignition delay times for droplets with a size (diameter) of about 2 mm have been established for the composite fuel compositions under study in the ambient temperature range 600–1000 °C. The minimum values of ignition delay times are about 3 s, the maximum values are about 15 s under the near-threshold ignition conditions. The obtained findings enabled to elaborate the main elements of the strategy for combined recovery of industrial and municipal waste by burning it as part of composite fuels. Full article

We assess the possibility of using biochar and ash from plant biomass to fertilise giant miscanthus (Miscanthus x giganteus). The paper concerns the optimisation of the combination of fertiliser applications of the aforementioned materials in the context of the plant yield obtained. There was an increase in yield of 8–68% over the two years of research when compared with the control plots. It was found that the application of biochar, ash from biomass and a combination of the two at appropriate rates as a soil additive can substitute for classic mineral fertilisers and strengthen the ecological aspects of energy crop cultivation. The interpretation of the results obtained enabled the selection of optimum fertiliser applications, resulting in a significant increase in the yield of plants and an improvement in soil chemical properties. It was found that the highest yield of dry matter of giant miscanthus plants, after both the first and second year of cultivation, was obtained by applying the fertiliser containing ash at a rate of 1.5 t ha⁻¹, together with biocarbon and the combination of biochar and ash at a rate of 1.5 t ha⁻¹. Full article

Generally, two-third of a building’s energy is consumed by heating, ventilation and air-conditioning systems. One green alternative for conventional air conditioner systems is the implementation of passive cooling. Wing walls and windcatchers are two prominent passive cooling techniques which use wind as a renewable resource for cooling. However, in low wind speed regions and climates, the utilization of natural ventilation systems is accompanied by serious uncertainties. The performance of ventilation systems can be potentially enhanced by integrating windcatchers with wing walls. Since previous studies have not considered this integration, in the first part of this research the effect of this integration on the ventilation performance was assessed and the optimum angle was revealed. However, there is still gap of this combination; thus, in the second part, the impact of wing wall length on the indoor air quality factors was evaluated. This research implemented a Computational Fluid Dynamics (CFD) method to address the gap. The CFD simulation was successfully validated with experimental data from wind tunnel tests related to the previous part. Ten different lengths from 10 cm to 100 cm were analyzed and it was found that the increase in wing wall length leads to a gradual reduction in ventilation performance. Hence, the length does not have a considerable influence on the indoor air quality factors. However, the best performance was seen in 10 cm, that could provide 0.8 m/s for supply air velocity, 790 L/s for air flow rate, 39.5 1/h for air change rate, 107 s for mean age of air and 92% for air change effectiveness. Full article

The reforming of natural gas with steam and CO₂ is commonly referred to as mixed reforming and considered a promising route to utilize CO₂ in the production of synthetic fuels and base chemicals such as methanol. In the present study, the mixed reforming reaction is assessed regarding its potential to effectively utilize CO₂ in such processes based on simple thermodynamic models. Requirements for the mixed reforming reactions based on process considerations are defined. These are the avoidance of carbon formation in the reactor, high conversion of the valuable inlet streams CH₄ and CO₂ as well as a suitable syngas composition for subsequent synthesis. The syngas composition is evaluated based on the module $M=\left(z_{{\mathrm{H}}_2}-z_{{\mathrm{CO}}_2}\right)/\left(z_{{\mathrm{CO}}_2}+z_{\mathrm{CO}}\right),$ which should assume a value close to 2. A large number of different configurations regarding CO₂/H₂O/CH₄ at the reactor inlet, operating pressure and outlet temperature are simulated and evaluated according to the defined requirements. The results show that the actual potential of the mixed reforming reaction to utilize CO₂ as feedstock for fuels and methanol is limited to approximately 0.35 CO₂/CH₄, which is significantly lower than suggested in literature. At 900 °C and 7 bar at the reactor outlet, which is seen suitable for solar reforming, a ratio of H₂O/CH₄ of 1.4 can be set and the resulting value of M is 1.92 (CO₂/CO/H₂ = 0.07/0.4/1). Full article

Tests of the effects of uniaxial compression on the structural behavior of fractured coals were conducted. The structural behavior is different from the material behavior of intact samples and the discontinuous behavior based on the block theory. It is a macro response of continuous-discontinuous behavior in coal with varied fracture structure geometry, and includes the material behavior with cracking and contact behavior with sliding. The structural behavior is studied based on the complete stress-strain curve, the material parameters, i.e. elastic modulus, Poisson’s ratio, and compression strength, and the structural integrity parameters, i.e. longitudinal and shear wave velocity, and the physical parameter, i.e. density. All the parameters are compared with the different fracture patterns. Various types of parameter degradation damage are defined to describe the structural characteristics with the different fracture patterns. They shows the effective relation of damage with strength. Furthermore, the mechanisms of the structural modulus degradation, structural failure deformation, and structural strength evolution are discussed. The results show that the post-peak behavior can be defined as the structural behavior. With the structural formation-reloading failure cycle, the mutual conversion changes between structural geometry instability and stability, and the characteristics are stress drops or stress platforms generated by structural rebalance. It is pointed out that the post-peak unloading is a macro response of the structural geometry. It includes the recovery of elastic strain and structural resilience strain, and structural stress drop. Full article

Coal is among the most important energy sources, and gob-side entry retention by roof cutting (GERRC) is an innovative non-pillar mining technique that can effectively increase coal recovery rates and avoid coal wastage. To investigate the characteristics of mine strata pressure using the GERRC technique, a field case study under conditions involving a medium-thick coal seam and a compound roof was performed, and the mine strata behavior mechanisms were studied by theoretical analysis. Field monitoring shows that the distributions of the weighting step and strength along the longwall working face are asymmetrical. The periodic weighting length on the entry retaining side is longer than that on the other sides of the longwall working face, and the average increase is appropriately 4 m. Compared to the other sides of the longwall, on the entry retaining side, the periodic weighting strength is weaker, the average pressure is reduced by 2.1 MPa, and the peak pressure is reduced by 10.2 MPa. The lateral distance affected by roof cutting along the longwall is approximately 29.75 m, and the closer to the cutting slit, the more significant the roof cutting effect is. The retained entry becomes stable when it is more than 230 m behind the mining face, and the final cross section of the retained entry can meet the reuse demand of the next mining face. Theoretical analysis shows that the roof pressure mechanism in GERRC can be explained using cantilever beam theory. Within the area affected by roof cutting, the thickness of the immediate roof increases, and the suspension plate length of the roof immediately behind the longwall decreases. Then, the gangue pile in the goaf behind the longwall formed by the immediate roof’s collapse and expansion can support the main roof and other overlying strata much better. Therefore, the rotational breaking angle of the main roof is smaller, the periodic weighting step strength increases, and the periodic weighting decreases. According to the structural state of the surrounding rocks during the entire entry retaining process, the retained entry can be divided into coal support, dynamic pressure and stable entry areas. Full article

For an integrated liquefied air energy storage and electricity generation system, mathematical models of the liquefied air energy storage and electricity generation process are established using a thermodynamic theory. The effects of the outlet pressure of the compressor unit, the outlet pressure of the cryogenic pump, the heat exchanger effectiveness, the initial air temperature and pressure before throttling on the performances of the integrated liquefied air energy storage, and the electricity generation system are investigated, using the cycle efficiency and liquid air yield ratio as the evaluation indexes. The results show that if the compressor outlet pressure is raised, both the compression work and the expansion work increase, but because the expansion work increases more slowly, the cycle efficiency of the system gradually decreases. Increasing the cryogenic pump outlet pressure and heat exchanger effectiveness can significantly increase the cycle efficiency of the system; the higher the air pressure and the lower the air temperature before throttling, the greater the liquid air yield after expansion, and the higher the cycle efficiency. The theoretical analysis models and research results can provide a reference for the development of an integrated system of liquefied air energy storage and electricity production, as well as for the development of medium-capacity energy storage technology. Full article

Natural fractures (NFs) have been recognized as the dominant factors that increase hydraulic fracture complexity and reservoir productivity. However, the interactions between hydraulic and natural fractures are far from being fully understood. In this study, a two-dimensional numerical model based on the displacement discontinuity method (DDM) has been developed and used to investigate the interaction between hydraulic and pre-existing natural fractures. The inelastic deformation, e.g., stick, slip and separation, of the geologic discontinuities is captured by a special friction joint element called Mohr-Coulomb joint element. The dynamic stress transfer mechanisms between the two fracture systems and the possible location of secondary tensile fracture that reinitiates along the opposite sides of the NF are discussed. Furthermore, the model results are validated by a series of large tri-axial hydraulic fracture (HF) tests. Both experimental and numerical results showed that the displacements and stresses along the NFs are all in highly dynamic changes. When the HF is approaching the NF, the HF tip can exert remote compressional and shear stresses on the NF interface, which results in the debonding of the NF. The location and value of the evoked stress is a function of the far-field horizontal differential stress, inclination angle of the NF, and the net pressure used in fracturing. For a small approaching angle, the stress peak is located farther away from the intersection point, so an offset fracture is more likely to be generated. The cemented strength of the NF also has an important influence on the interaction mechanism. Weakly bonded NF surfaces increase the occurrence of a shear slippage, but for a moderate strength NF, the hybrid failure model with both tensile and shear failures, and conversion may appear. Full article

Permanent magnet synchronous motors (PMSMs) with inverters are widely used in electric vehicles (EVs). However, current harmonics caused by the nonlinearity of the inverter generate torque ripples and give rise to torsional vibration in the vehicle driveline. This paper proposes a new compensation method to suppress the torque ripples. This method extracts the 6th-order harmonic component online from the d-axis and q-axis currents with the approximate Fourier transform, and adopts a harmonic current PI regulator to calculate compensation voltage, which is added to the voltage reference to compensate the nonlinearity of the inverter. After correcting the current distortion and improving the motor torque smoothness, the torsional vibration of the driveline caused by the motor pulsating torque is reduced. According to the simulation results, the 6th-order of motor torque ripple and the torsional vibration response is reduced about 26–28%, which confirms the validity of the proposed strategy. The proposed method does not need any additional hardware and can be implemented broadly in PMSM drives. Full article

The partially shaded photovoltaic (PSPV) condition reduces the generated power and contributes to hot spot problems that may lead to breakdown of shaded modules. PSPV generates multiple peak, one global one and many other local peaks. Many efficient, accurate and reliable maximum power point tracker (MPPT) techniques are used to track the global peak instead of local peaks. The proposed technique is not limited to global peak tracking, but rather it is capable of tracking the sum of all peaks of the PV arrays using an interleaved boost converter (IBC). The proposed converter has been compared with the state of the art conventional control method that uses a conventional boost converter (CBC). The converters used in the two PSPV systems are interfaced with electric utility using a three-phase inverter. The simulation findings prove superiority of the PSPV with IBC compared to the one using CBC in terms of power quality, reliability, mismatch power loss, DC-link voltage stability, efficiency and flexibility. Also, IBC alleviates partial shading effects and extracts higher power compared to the one using CBC. The results have shown a remarkable increase in output generated power of a PSPV system for the three presented scenarios of partial shading by 61.6%, 30.3% and 13%, respectively, when CBC is replaced by IBC. Full article

In this paper, an intelligent sliding mode controlled voltage source inverter (VSI) is developed to achieve not only quick transient behavior, but satisfactory steady-state response. The presented approach combines the respective merits of a nonsingular fast terminal attractor (NFTA) as well as an adaptive neuro-fuzzy inference system (ANFIS). The NFTA allows no singularity and error states to be converged to the equilibrium within a finite time, while conventional sliding mode control (SMC) leads to long-term (infinite) convergent behavior. However, there is the likelihood of chattering or steady-state error occurring in NFTA due to the overestimation or underestimation of system uncertainty bound. The ANFIS with accurate estimation and the ease of implementation is employed in NFTA for suppressing the chatter or steady-state error so as to improve the system’s robustness against uncertain disturbances. Simulation results display that this described approach yields low distorted output wave shapes and quick transience in the presence of capacitor input rectifier loading as well as abrupt connection of linear loads. Experimental results conducted on a 1 kW VSI prototype with control algorithm implementation in Texas Instruments DSP (digital signal processor) support the theoretic analysis and reaffirm the robust performance of the developed VSI. Because the proposed VSI yields remarkable benefits over conventional terminal attractor VSIs on the basis of computational quickness and unsophisticated realization, the presented approach is a noteworthy referral to the designers of correlated VSI applications in future, such as DC (direct current) microgrids and AC (alternating current) microgrids, or even hybrid AC/DC microgrids. Full article

The current scenario of colorimetry shows a wide variety of different metrics which do not converge in the assessment of the color rendering of light sources. The limitations of the Color Rendering Index have promoted the emergence of new metrics, such as the Color Quality Scale. As in the case of the previous metric, these new concepts are based on the analysis of the deviation of different color samples in a color space, contrasting the results with those obtained with a light source reference, which can vary depending on the color temperature. Within this context, the Daylight Spectrum Index is proposed. This new concept aims to determine the affinity with daylighting of electric light sources, comparing the resulting spectral power distributions of the lamps studied and that observed under natural light. The affinity of an electric light source with daylighting allows for lower energy consumption due to the better performance of human vision. The new metric proposed is evaluated following the results obtained from 80 surveys, demonstrating the usefulness of this new concept in the quantification of color rendering of LED lamps and the affinity of electric light sources with daylighting. Full article

In this paper, three Vernier permanent-magnet (VPM) motor, namely the inner-rotor VPM (IR-VPM) motor, the outer-rotor VPM (OR-VPM) motor and the OR consequent-pole VPM (OR-CP-VPM) motor are proposed for the hybrid electric vehicle (HEV) applications. Owing to employment of toroidal-winding arrangement, the OR-VPM and the OR-CP-VPM motors can enjoy better material utilization and easier manufacturing process than its IR-VPM counterpart. Meanwhile the OR-CP-VPM motor can utilize the consequent-pole topology to minimize flux leakage that exists in conventional design. With the support of finite element method (FEM), the motor performances among the VPM motors and the profound interior permanent-magnet (IPM) motor can be compared quantitatively. Full article

Smart grid architecture is one of the difficult constructions in electrical power systems. The main feature is divided into three layers; the first layer is the power system level and operation, the second layer is the sensor and the communication devices, which collect the data, and the third layer is the microprocessor or the machine, which controls the whole operation. This hierarchy is working from the third layer towards first layer and vice versa. This paper introduces an eco unit commitment study, that scheduling both conventional power plants (three IEEE) thermal plants) as a dispatchable distributed generators, with renewable energy resources (wind, solar) as a stochastic distributed generating units; and plug-in electric vehicles (PEVs), which can be contributed either loads or generators relied on the charging timetable in a trustworthy unit commitment. The target of unit commitment study is to minimize the combined eco costs by integrating more augmented clean and renewable energy resource with the help of field programming gate array (FPGA) layer installation. A meta-heuristic algorithm, such as the Gravitational Search Algorithm (GSA), proves its accuracy and efficiency in reducing the incorporated cost function implicating costs of CO₂ emission by optimally integrating and scheduling stochastic resources and charging and discharging processes of PEVs with conventional resources power plants. The results obtained from GSA are compared with a conventional numerical technique, such as the Dynamic Programming (DP) algorithm. The feasibility to implement GSA on an appropriate hardware platform, such as FPGA, is also discussed. Full article

When wind turbine blades are icing, the output power of a wind turbine tends to reduce, thus informing the selection of two basic variables of wind speed and power. Then other features, such as the degree of power deviation from the power curve fitted by normal sample data, are extracted to build the model based on the random forest classifier with the confusion matrix for result assessment. The model indicates that it has high accuracy and good generalization ability verified with the data from the China Industrial Big Data Innovation Competition. This study looks at ice detection on wind turbine blades using supervisory control and data acquisition (SCADA) data and thereafter a model based on the random forest classifier is proposed. Compared with other classification models, the model based on the random forest classifier is more accurate and more efficient in terms of computing capabilities, making it more suitable for the practical application on ice detection. Full article

Aiming to address the serious problem of coal wall spalling in the triangular zone of the coal face end under high-intensity mining, this paper introduces inorganic cement grouting reinforcement technology for medium-depth holes based on the specific geological conditions of the Sihe coal mine in China. Firstly, the effects of different water-to-material ratios and various accelerators on setting time and uniaxial compressive strength (UCS) of grouting materials and consolidation coal are studied. The results show that the combination of 2% accelerator I, 0.3% accelerator II, and 3.0% accelerator III was the most effective. Then, FLAC3D numerical simulation software was used to analyze the distribution laws of the plastic zone, the lateral abutment pressure, and abutment stresses in the face ends during repeated mining. The results indicate that the zone within 25–65 m of the front of the coal face was initially affected by the front abutment pressure. In this area, the stress value decreased slowly and fracture development was relatively intense. Grouting with high pressure and a large flow rate should be used in this scenario as the industrial experiment results indicated that the proposed inorganic cement grouting reinforcement technology could effectively control coal wall spalling and provide technical support for safe and efficient mining. Full article

Temperature control of the lithium-ion pouch cells is crucial for smooth operation, longevity and enhanced safety in the battery-operated electric vehicles. Investigating the thermal behavior of lithium-ion pouch cells and optimizing the cooling performance are required to accomplish better performance, long life, and enhanced safety. In the present study, the cooling performance characteristics of 20 Ah lithium-ion pouch cell with cold plates along both surfaces are investigated by varying the inlet coolant mass flow rates and the inlet coolant temperatures. The inlet coolant mass flow rate is varied from 0.000833 kg/s to 0.003333 kg/s, and the inlet coolant temperature is varied from 5 °C to 35 °C. In addition, the effects of the cold plate geometry parameter on cooling performance of 20 Ah lithium-ion pouch cell are studied by varying the number of the channels from 4 to 10. The maximum temperature and difference between the maximum and the minimum temperatures are considered as important criteria for cooling performance evaluation of the 20 Ah lithium-ion pouch cell with cold plates along both surfaces. The cooling energy efficiency parameter (β) and the pressure drop for 20 Ah lithium-ion pouch cell with cold plates along both surfaces are also reported. The study shows that enhanced cooling energy efficiency is accompanied with low inlet coolant temperature, low inlet coolant mass flow rate, and a high number of the cooling channels. As a result, the temperature distribution, the pressure drop, and the cooling energy efficiency parameter (β) of the 20 Ah lithium-ion pouch cell with cold plates along both surfaces are provided, and could be applied for optimizing the cooling performances of the thermal management system for lithium-ion batteries in electric vehicles. Full article

This work is concerned with the use of the engine start module (ESM) ULTRA 31/900/24V ultracapacitor in specific hybrid systems consisting of a photovoltaic (PV) module, battery, and internal combustion engine (ICE). The test bench research on the ESM cooperating with the photovoltaic module to prevent its self-discharge has been tested, analyzed, and discussed. Moreover, the power distribution between electrochemical batteries and the ultracapacitor is shown. The potential application of the ultracapacitor connected with batteries for the start-up of an ICE engine is also presented. Furthermore, we analyze the possible application of the ultracapacitor plus battery system in heavy transport vehicles and buses. The main advantages and disadvantages of the system consisting of an ultracapacitor and a battery is presented along with the problem of self-discharge and the conditions of ultracapacitor and battery cooperation. This work also features the assumptions made for the conducted tests, selected accordingly for nominal current values of typical starter motors available on the market. Full article

Since thermal energy for residential applications is a relevant part of the entire energy demand, solar technologies could play an important role in decreasing fossil fuel consumption. A novel small parabolic trough collector matched with a storage system is developed to satisfy heating and required hot water demand for a single house. A new receiver concept is designed and a prototype is realized using two coaxial tubes (three spattered layers). A covering glass with vacuum inside completes the high tech design. Because of numerous innovations including the small size, a specific off-Sun measurement procedure is set up with the aim of evaluating the real thermal loss and direct heating of the absorber by Joule effect. A novel test procedure is proposed for the one-end absorber. The receiver performance results are reported under vacuum conditions and with air at ambient pressure. Full article

Solar collectors are very important to the photothermal utilization of solar energy in low-temperature conditions. In this paper, a solar collector comprising an oscillating heat pipe in a flat-plate structure is designed and studied experimentally. The thermal properties are studied in detail, and we finally obtain the startup temperature and the expression of the instantaneous efficiency with a relative error of 5%. The results show that the impact of inclination angles on the startup properties of the solar collector is significant to the thermal properties. The comparisons of the efficiency of the present design and similar products are also displayed and discussed, showing that an oscillating heat pipe collector in a flat-plate structure overcomes the low efficiency, high startup temperature and bad pressure resistance of conventional solar collectors. In addition, the thermal properties of the water heating system based on the novel collector were also tested, illustrating the differences between the solar irradiance and the water heating system. Some improvements (e.g., shell material and assembly method) were made in this system design process to increase the heat transfer efficiency and solve the corrosion and pressure resistance problems. Full article

A large number of permanent magnet synchronous motors (PMSMs) are used to drive coal conveyer belts in coal enterprises. Sensorless energy conservation control has important economic value for these enterprises. The key problem of sensorless energy conservation control for PMSMs is how to decompose the stator current through estimating the rotor position and speed accurately. Then a double closed loop control for stator current and speed is formed to make the stator current drive the motor as an entire torque current. In this paper, the proposed startup estimation algorithm can utilize the current model of PMSM as reference model to estimate the rotor speed and position in the startup stages. It is not dependent on the back electromotive force (EMF) which is used by the general estimation algorithm. However, the resistance will change with the temperature shift of stator windings, and these changes will cause the reference current model to be inaccurate and influence the rotor speed and position estimation precision. Thus, startup estimation algorithm switches to the proposed operation estimation algorithm which is based on the robust sliding mode theory and is not dependent on the motor parameters. The advantages of startup estimation algorithm and operation estimation algorithm are combined to form a hybrid observer. This hybrid observer realizes the accurate estimation of the rotor speed and position from start-up to operation. The stator current is precisely decomposed. The excitation current is controlled to 0. Meanwhile, the double closed-loop control of current and speed is achieved. The stator current is as entire torque current to drive motor. The closed-loop control, which is based on the proposed rotor position and speed estimation algorithm, achieve the most efficient conversion of electrical energy. Full article

With the ever-intensive utilization of distributed generators (DGs) and smart devices, distribution networks are evolving from a hierarchal structure to a distributed structure, which imposes significant challenges to network operators in system dispatch. A distributed energy-management method for a networked microgrid (NM) is proposed to coordinate a large number of DGs for maintaining secure and economic operations in the electricity-market environment. A second-order conic programming model is used to formulate the energy-management problem of an NM. Network decomposition was first carried out, and then a distributed solution for the established optimization model through invoking alternating-direction method of multipliers (ADMM). A modified IEEE 33-bus power system was finally utilized to demonstrate the performance of distributed energy management in an NM. Full article

A novel methodology based on the recent metaheuristic optimization algorithm Salp Swarm Algorithm (SSA) for locating and optimal sizing of renewable distributed generators (RDGs) and shunt capacitor banks (SCBs) on radial distribution networks (RDNs) is proposed. A multi-objective function index (MOFI) approach is used for assuring the power quality (PQ) through enhancing the voltage level in addition to minimizing the power losses of the system and the whole operating cost of the grid. The proposed methodology is tested via 33-Bus standard radial distribution networks at different scenarios to prove their validity and performance. The obtained results are compared with the Grasshopper Optimization Algorithm (GOA), and the hybrid Particle Swarm Optimization (PSO) and Gravitational Search Algorithm (PSOGSA). The SSA optimizer proved its superiority with high attitude and accuracy for solving the problems of RDGs’ and SCBs’ locations and capacities simultaneously. An Egyptian practical case study at different load levels via different scenarios including the control operation within 24 h is considered. Full article

Sustained casing pressure (SCP) in shale gas wells caused by cement sheath failure can have serious impacts on safe and efficient gas production. Considering the fact that horizontal wells are widely used for production from shale, the cementing quality and casing centricity is barely ensured in these wells. Among other indications, the casing eccentricity is identified very often in wells with SCP problems in the Sichuan field in China. Hence, the objective of this study is to analyze the effect of the casing eccentricity on the integrity of the cement sheath. To better understand stress distribution in eccentric cement sheaths, an analytical model is proposed in this paper. By comparing the results of this model with the one’s with centric casing, the impacts of the casing eccentricity on the integrity of the cement sheath is analyzed. During fracturing treatments, the casing eccentricity has a little effect on stress distribution in the cement sheath if the well is well cemented and bonded to the formation rock. However, on the contrary, the casing eccentricity may have serious effects on stress distribution if the cementing is done poorly. The debonding of casing–cement–formation interfaces can significantly increase the circumferential stress in the cement sheath. At the thin side of the cement sheath, the circumferential stress could be 2.5 times higher than the thick side. The offset magnitude of the casing eccentricity has little effect on the radial stress in the cement sheath but it can significantly increase the shear stress. We found that the risk of cement failure may be reduced by making the casing string more centralized, or increasing the thickness of the casing. The results provide insights for design practices which may lead to better integrity in shale gas wells. Full article

This report assesses the performance characteristics of a ramjet compression system in the application of a hypersonic vehicle. The vehicle is required to be self-powered and perform a complete flight profile using a combination of turbojet, ramjet and scramjet propulsion systems. The ramjet has been designed to operate between Mach 2.5 to Mach 5 conditions, allowing for start-up of the scramjet engine. Multiple designs, including varying ramp configurations and turbo-ramjet combinations, were investigated to evaluate their merits and limitations. Challenges arose with attempting to maintain sufficient pressure recoveries and favourable flow characteristics into the ramjet combustor. The results provide an engine inlet design capable of propelling the vehicle between the turbojet and scramjet phase of flight, allowing for the completion of its mission profile. Compromises in the design, however, had to be made in order to allow for optimisation of other propulsion systems including the scramjet nozzle and aerodynamics of the vehicle; it was concluded that these compromises were justified as the vehicle uses the ramjet engine for a minority of the flight profile as it transitions between low supersonic to hypersonic conditions. Full article

To improve the ionic conductivity and thermal stability of a polyethylene oxide (PEO)-ethylene carbonate (EC)-LiClO₄-based solid polymer electrolyte for lithium-ion batteries, polymethyl methacrylate (PMMA) and silica aerogel were incorporated into the PEO matrix. The effects of the PEO:PMMA molar ratio and the amount of silica aerogel on the structure of the PEO-PMMA-LiClO₄ solid polymer electrolyte were studied by X-ray diffraction, Fourier-transform infrared spectroscopy and alternating current (AC) impedance measurements. The solid polymer electrolyte with PEO:PMMA = 8:1 and 8 wt% silica aerogel exhibited the highest lithium-ion conductivity (1.35 × 10⁻⁴ S∙cm⁻¹ at 30 °C) and good mechanical stability. The enhanced amorphous character and high degree of dissociation of the LiClO₄ salt were responsible for the high lithium-ion conductivity observed. Silica aerogels with a high specific surface area and mesoporosity could thus play an important role in the development of solid polymer electrolytes with improved structure and stability. Full article

A hold-up time extension circuit (HTEC) is used to charge and discharge an auxiliary capacitor. This capacitor stores the energy required to extend the operation time of critical loads experiencing short duration failures (SDF) at the DC bus to which they are connected. This paper presents complete modeling and a control-wise approach to a parallel HTEC based on the bidirectional buck-boost converter, which operates in Boundary Conduction Mode (BCM) with a variable switching frequency. The circuit permanently regulates the voltage of the auxiliary capacitor as well as the voltage of the DC bus during SDF, which is uncommon in industrial versions of HTEC. Enforcing the operation in BCM allows a reduction in the size of the inductor in the converter without requiring additional control circuitry. The entire behavior of the proposed HTEC, in all its operation modes, was analyzed theoretically and validated using simulation and experimental results, showing the potential of the circuit to be used in real applications. Full article

To investigate problems involving wind turbines that easily occur but are hard to diagnose, this paper presents a wind turbine (WT) fault diagnosis algorithm based on a spectrogram and a convolutional neural network. First, the original data are sampled into a phonetic form. Then, the data are transformed into a spectrogram in the time-frequency domain. Finally, the data are sent into a convolutional neural network (CNN) model with batch regularization for training and testing. Experimental results show that the method is suitable for training a large number of samples and has good scalability. Compared with Back Propagation Neural Network (BPNN), Support Vector Machine (SVM), Extreme Learning Machine (ELM), and other fault diagnosis methods, the average diagnostic correctness rate is higher; so, the method can provide more accurate reference information for wind turbine fault diagnosis. Full article

This study investigated the optimal reaction conditions for biodiesel production from soursop (Annona muricata) seeds. A high oil yield of 29.6% (w/w) could be obtained from soursop seeds. Oil extracted from soursop seeds was then converted into biodiesel through two-step transesterification process. A highest biodiesel yield of 97.02% was achieved under optimal acid-catalyzed esterification conditions (temperature: 65 °C, 1% H₂SO₄, reaction time: 90 min, and a methanol:oil molar ratio: 10:1) and optimal alkali-catalyzed transesterification conditions (temperature: 65 °C, reaction time: 30 min, 0.6% NaOH, and a methanol:oil molar ratio: 8:1). The properties of soursop biodiesel were determined and most were found to meet the European standard EN 14214 and American Society for Testing and Materials standard D6751. This study suggests that soursop seed oil is a promising biodiesel feedstock and that soursop biodiesel is a viable alternative to petrodiesel. Full article

This paper predicted the vibroacoustic regularity of a high temperature superconducting (HTS) field-modulation double-stator (HTS-FMDS) machine with stationary seal for low-speed and direct-drive applications. The originality of this paper lies in that the spatial order and angular velocity of electromagnetic-force density of the HTS-FMDS machine were derived by using the analytical method. Moreover, the validity of the analytical solutions was verified by the finite element analysis (FEA) results. Then, the modal shapes and frequencies of the outer stator were obtained by using multiphysics coupling simulation. By transferring the electromagnetic force to the stator structural model, the regularity of electromagnetic vibration and noise of the HTS-FMDS machine were revealed. Full article

The magnetic geared motor, which has improved torque density because of the magnetic gearing effect, has been researched. However, its narrow operating region due to the operating mechanism by the magnetic gearing effect and field flux by the PM is a challenge that needs to be overcome. Whereas, the doubly fed magnetic geared motor (DFMGM) can extend the operating region because of the double stator and double winding structure with the individual frequency control of the current fed to the inner and outer windings. However, two rotating magnetic fields, which are produced by the inner and outer winding flux, exist at the air-gap, and the large numbers of space harmonic components of the modulated flux density are produced at the air-gaps. These space harmonic components, which are produced by the winding MMF, influence not only the back-EMF of the winding but also the performances of the operating torque. Besides, the inner and outer windings affect each other in the back-EMF, and its characteristics appears differently in the inner and outer windings. Thus, in this paper, the structure, operating strategy, and basic characteristics according to the frequency condition in the inner and outer windings are presented. Full article

When a fault occurs in a section or a component of a given power system, the malfunctioning of protective relays (PRs) and circuit breakers (CBs), and the false and missing alarms, may manifestly complicate the fault diagnosis procedure. It is necessary to develop a methodologically appropriate framework for this application. As a branch of stochastic programming, the well-developed chance-constrained programming approach provides an efficient way to solve programming problems fraught with uncertainties. In this work, a novel fault diagnosis analytic model is developed with the ability of accommodating the malfunctioning of PRs and CBs, as well as the false and/or missing alarms. The genetic algorithm combined with Monte Carlo simulations are then employed to solve the optimization model. The feasibility and efficiency of the developed model and method are verified by a real fault scenario in an actual power system. In addition, it is demonstrated by simulation results that the computation speed of the developed method meets the requirements for the on-line fault diagnosis of actual power systems. Full article

In this study, the production process of second-generation biodiesel from Australian native stone fruit have been optimised using response surface methodology via an alkali catalysed transesterification process. This process optimisation was performed varying three factors, each at three different levels. Methanol: oil molar ratio, catalyst concentration (wt %) and reaction temperature were the input factors in the optimisation process, while biodiesel yield was the key model output. Both 3D surface plots and 2D contour plots were developed using MINITAB 18 to predict optimum biodiesel yield. Gas chromatography (GC) and Fourier transform infrared (FTIR) analysis of the resulting biodiesel was also done for biodiesel characterisation. To predict biodiesel yield a quadratic model was created and it showed an R² of 0.98 indicating the satisfactory performance of the model. Maximum biodiesel yield of 95.8% was obtained at a methanol: oil molar ratio of 6:1, KOH catalyst concentration of 0.5 wt % and a reaction temperature of 55 °C. At these reaction conditions, the predicted biodiesel yield was 95.9%. These results demonstrate reliable prediction of the transesterification process by Response surface methodology (RSM). The results also show that the properties of the synthesised Australian native stone fruit biodiesel satisfactorily meet the ASTM D6751 and EN14214 standards. In addition, the fuel properties of Australian native stone fruit biodiesel were found to be similar to those of conventional diesel fuel. Thus, it can be said that Australian native stone fruit seed oil could be used as a potential second-generation biodiesel source as well as an alternative fuel in diesel engines. Full article

The continued growth in life sciences is being accompanied by the constantly rising demand for robotic systems. Today, bioscreening and high–throughput screening processes are well automated. In contrast, a deficit can be found in the area of analytical measurements with complex and frequently changing processes. Robots undertake not only transportation tasks, but also direct sample manipulation and subsequent analytical measurements. Due to their human-like structure, dual-arm robots perform such processes similar to human operation. Liquid handling is required to transfer chemicals, to prepare standard solutions, or to dilute samples. Two electronic pipettes with different volume ranges (5–200 µL and 50–1000 µL) were integrated into a dual–arm robotic system. The main focus in this publication is the software interface for alternating robot and pipette control as well as the high–level process control system. The performance using a dual–arm robot equipped with electronic pipettes and conventional manual pipettes was determined and compared. The automation system presented is the first integration of a dual-arm robot in analytical measurement processes. Conventional manual laboratory pipettes and electronic pipettes are simultaneously used for liquid-handling tasks. The software control system enables a flexible and user-friendly process generation. Full article

Fully rotary drilling is one of many useful technologies used for the exploitation of petroleum and geothermal resources, but fully rotating drill-strings are extremely complicated. Therefore, according to the Hamilton principle, a non-linear coupled bottom hole assembly (BHA)-bit-formation-wellbore model is proposed for BHAs with bent-housing positive displacement motor using the finite element method to investigate the dynamic behavior and steering ability under fully rotary drilling. The impact force, acceleration, axial loading, torque, and dynamic stress were simulated, and factors influencing the dynamic steering forces were investigated. The results indicate that the impact force, acceleration, axial loading, torque, and dynamic stress under fully rotary drilling are much higher than under conventional drilling. The numerical simulation and field test in well B confirmed that the rotation of the drill-string is conducive to the hold-on of the deviation angle. With the increase in the weight-on-bit, bend angle, and stabilizer height, the deflecting force on a drill bit increases. Conversely, with the increase in stabilizer diameter, the deflecting force on the drill bit decreases; the lower the deflecting force, the better the effectiveness of hold-on. With increasing deviation angle, the deflecting force on the drill bit first decreases and then increases. The present model can provide a theoretical basis for wellbore trajectory control and optimization design of BHA. Full article

This study investigates pollutant emissions and fuel consumption of six Euro VI hybrid-diesel public transport buses operating on different scheduled routes in a metropolitan urban road network. Portable emission measurement systems (PEMS) are used in measurements and results are compared to those obtained from a paired number of Euro V conventional buses of the same body type used as control over the same routes. The selected routes vary from urban to highway driving and the experimentation was conducted over the first half of 2015. The available emissions data correspond to a wide range of driving, operating, and ambient conditions. Fuel consumption, distance- and energy-based emission levels are derived and presented in a comparative manner. The effect of different factors, including speed, ambient temperature, and road grade on fuel consumption and emissions performance is investigated. Mean fuel consumption of hybrid buses was found 6.1% lower than conventional ones, from 20% lower up to 16% higher, over six routes tested in total. The mean route difference between the two technologies was not statistically significant. Air conditioning decreased consumption benefits of the hybrid buses. Decrease of the mean route speed from 15 km h⁻¹ tο 8 km h⁻¹ increased the hybrid buses consumption by 63%. Nitrogen oxides (NO_x) emissions of the Euro VI hybrid buses were 93 ± 5% lower than conventional Euro V ones. Nitrous oxide (N₂O) emissions from hybrid Euro VI buses made up 5.9% of total greenhouse gas emissions and largely offset carbon dioxide (CO₂) benefits. The results suggest that hybrid urban buses need to be assessed under realistic operation and environmental conditions to assess their true environmental and fuel consumption benefits. Full article

The accurate ab-initio modelling of prototypical and well-representative photo-active interfaces for candidate dye-sensitised solar cells is a challenging problem. To this end, using ab-initio molecular-dynamics (AIMD) simulation based on Density Functional Theory (DFT), the effects of explicit solvation by iodide-based, I⁻[bmim]⁺ room-temperature ionic liquids (RTILs) have been assessed on modelling a N719-chromophore sensitising dye adsorbed onto an anatase-titania (101) surface. In particular, the vibrational spectra for this model photo-active interface were calculated by means of Fourier transformed mass-weighted velocity autocorrelation functions. These were compared with experiment and against each other to gain an understanding of how using iodine-based RTILs as the electrolytic hole acceptor alters the dynamical properties of the widely-used N719 dye. The effect of Perdew-Burke-Ernzerhof (PBE) and Becke-Lee-Yang-Parr (BLYP) functionals on the vibrational spectra were assessed. PBE generally performed best in producing spectra which matched the typically expected experimental frequency modes. Full article

The conversion system is a major contributor to failure rates. These faults lead to time and cost consuming. Fault diagnosis capabilities pay as a solver to achieve a steady system. This paper presents a full analysis of permanent magnet synchronous generator wind system (PMSGWS) and proposes a special RMS voltage-based fault diagnosis method. The full analysis presents a comprehensive knowledge of faulty behaviors especially under arm current flowing or cutting off. Due to enough knowledge of faulty behaviors, the implementation of the detection method without threshold setting is contributed by the special RMS voltage. Its sample period is set longer than the time of the maximum pulse width ratio (MPR) and shorter than the fault show time of lower tube voltage. Due to this, the detection speed and robustness are achieved. By these simple settings for the fault diagnosis method, the faulty switch is detected in less than 1/4 of the period. Simulation and experimental results confirm the validity and feasibility of the new proposed fault detection method. Full article

The drilling fluid loss or lost circulation via fractures is one of the critical engineering problems in the development of deep oil and gas resources. The conventional treatment is to introduce granular lost circulation material (LCM) into the drilling fluid system to plug fractures. In this work, a method incorporating the fracture surface scanning technique and coupled Computational Fluid Dynamics-Discrete Element Method (CFD-DEM) numerical simulation is proposed for the first time to investigate how the LCM particles plug rough fractures. The rough fracture model is built utilizing a high resolution and high precision measurement system. The LCM particle transport and plugging process in rough fractures are captured in the CFD-DEM numerical simulations. The results show that the local fracture aperture has a significant influence on LCM particle transport and the distribution of the plugging zone. The drilling fluid loss rate will decrease, and the drilling fluid pressure will redistribute during the accumulation of LCM particles in the fracture. The fracture plugging efficiency of nonspherical LCM is improved as a result of formation of multi-particle bridges. This study provides a novel approach and important theoretical guidance to the investigation of LCM particle transport in rough fractures. Full article

Gas-fired power plants are environmentally friendly because of their high efficiency rates and low CO₂ emissions. On the other hand, the output power of renewable generators is stochastic, meaning that additional capacity must be held in reserve throughout the system. Gas-fired power plants are ideally suited to mitigate renewable uncertainties as they are more flexible and can easily be fired up in just a few minutes, and subsequently be shut down. Increased use of gas-fired power plants makes gas and electricity networks more dependent, so that adequacy in fuel supply of electricity network becomes a majority. However expansion planning of gas and electricity systems is accomplished by private gas and electricity companies, having no effective data exchange mechanism together. So there is a need to provide a model that coordinates the expansion planning of gas and electricity networks. On the other hand, expansion cost of either gas or electricity network and risk criteria of integrated energy system may have priority in decision-making process. With different challenging attributes, there is a gap in the literature to provide a model that takes into account the privacy of energy parties with a minimum data exchange, while considering different attributes in decision-making process. In this paper a multi-attribute decision-making (MADM) method for co-expansion planning of gas and electricity systems is introduced. The proposed MADM method supposes that a central entity as Ministry of Energy (ME) is responsible for coordinated expansion planning of gas and electricity networks, while taking into account the privacy of gas and electricity energy parties. Decision-making attributes are conflicting and the proposed method selects the best plan based on a compromise among the attributes. Different attributes including gas expansion cost (GEC), electricity expansion cost (EEC), minimum of maximum regret (MMR) and β-robustness (β_R) are considered to find the best plan with regard to the preferences of independent gas and electricity network operators. In this regard, two multi-attribute decision analysis methodologies are employed: analytical hierarchy process (AHP) is used as a simple way to weight and rank all the attributes objectively and find the relative importance of various plans, and the weighted sum method to provide a general composite index and finding the final appropriate plan. A real case study in the Khorasan province of Iran, which has a high penetration level of gas-consuming generation units (GCGU), is utilized to demonstrate the effectiveness of proposed MADM method. Results are compared with a Pareto optimal method to qualify the accuracy of proposed method. Full article

Air conditioning accounts for up to 50% of energy use in buildings. Increased air-conditioning-system installations not only increase total energy consumption but also raise peak load demand. Desiccant evaporative cooling systems use low-grade thermal energy, such as solar energy and waste heat, instead of electricity to provide thermal comfort. This system can potentially lead to significant energy saving, reduction in carbon emissions, and it has a low dew-point operation and large capacity range. Their light weight, simplicity of design, and close-to-atmospheric operation make them easy to maintain. This paper evaluates the applicability of this technology to the climatic conditions of Brisbane, Queensland, Australia, specifically for the residential sector. Given the subtropical climate of Brisbane, where humidity levels are not excessively high during cooling periods, the numerical study shows that such a system can be a potential alternative to conventional compression-based air-conditioning systems. Nevertheless, the installation of such a system in Brisbane’s climate zone requires careful design, proper selection of components, and a cheap heat source for regeneration. The paper also discusses the economy-cycle options for this system in such a climate and compares its effectiveness to natural ventilation. Full article

Multi-physical field sensing and machine learning have drawn great attention in various fields such as sensor networks, robotics, energy devices, smart buildings, intelligent system and so on. In this paper, we present a novel efficient method for thermal and energy management based on bimodal airflow-temperature sensing and reinforcement learning, which expedites an exploration process by self-learning and adjusts action policy only through actuators interacting with the environment, being free of the controlled object model and priori experiences. In general, training of reinforcement learning requires a large amount of data iterations, which takes a long time and is not suitable for real-time control. Here, we propose an approach to speed up the learning process by indicating the action adjustment direction. We adopt tailor-designed bimodal sensors to simultaneously detect airflow and temperature field, which provides comprehensive information for reinforcement learning. The proposed thermal and energy management incorporates bimodal parametric sensing with an improved actor-critic algorithm to realize self-learning control. Experiments of thermal and energy management in a multi-module integrated system validate the effectiveness of the proposed methodology, which demonstrate high efficiency, fast response, and good robustness in various control scenarios. The proposed methodology can be widely applied to thermal and energy management of diverse integrated systems. Full article

Slip boundary has an important influence on fluid flow, which is non-negligible in rock micro-fractures. In this paper, an improved pseudo-potential multi-relaxation-time (MRT) lattice Boltzmann method (LBM), which can achieve a large density ratio, is introduced to simulate the fluid flow in a micro-fracture. The model is tested to satisfy thermodynamic consistency and simulate Poiseuille flow in the case of large liquid-gas density ratio. The slip length is used as an index for evaluating the flow characteristics, and the effects of wall wettability, micro-fracture width, driving pressure and liquid-gas density ratio on the slip length are discussed. The results demonstrate that the slip length increases significantly with the increase of the wall contact angle in rock micro-fracture. And the liquid-gas density ratio has an important impact on the slip length, especially for the hydrophobic wall. Moreover, under the laminar flow regime the driving pressure and the micro-fracture width has little effect on the slip length. Full article

This study demonstrated the enhancement of biogenic coal conversion to methane in a bioelectrochemical anaerobic reactor with polarized electrodes. The electrode with 1.0 V polarization increased the methane yield of coal to 52.5 mL/g lignite, which is the highest value reported to the best of our knowledge. The electrode with 2.0 V polarization shortened the adaptation time for methane production from coal, although the methane yield was slightly less than that of the 1.0 V electrode. After the methane production from coal in the bioelectrochemical reactor, the hydrolysis product, soluble organic residue, was still above 3600 mg chemical oxygen demand (COD)/L. The hydrolysis product has a substrate inhibition effect and inhibited further conversion of coal to methane. The dilution of the hydrolysis product mitigates the substrate inhibition to methane production, and a 5.7-fold dilution inhibited the methane conversion rate by 50%. An additional methane yield of 55.3 mL/g lignite was obtained when the hydrolysis product was diluted 10-fold in the anaerobic toxicity test. The biogenic conversion of coal to methane was significantly improved by the polarization of the electrode in the bioelectrochemical anaerobic reactor, and the dilution of the hydrolysis product further improved the methane yield. Full article

Aerodynamic performance of a floating offshore wind turbine (FOWT) is significantly influenced by platform surging motions. Accurate prediction of the unsteady aerodynamic loads is imperative for determining the fatigue life, ultimate loads on key components such as FOWT rotor blades, gearbox and power converter. The current study examines the predictions of numerical codes by comparing with unsteady experimental results of a scaled floating wind turbine rotor. The influence of platform surge amplitude together with the tip speed ratio on the unsteady aerodynamic loading has been simulated through unsteady CFD. It is shown that the unsteady aerodynamic loads of FOWT are highly sensitive to the changes in frequency and amplitude of the platform motion. Also, the surging motion significantly influences the windmill operating state due to strong flow interaction between the rotating blades and generated blade-tip vortices. Almost in all frequencies and amplitudes, CFD, LR-BEM and LR-uBEM predictions of mean thrust shows a good correlation with experimental results. Full article

A comprehensive method is presented in this work to locate faults in distribution systems with distributed generators (DGs). A two-level model is developed for this purpose with both telecommunication and telemetering data employed, so as to make good use of fused information for attaining a more credible optimization solution under scenarios with alarm distortions of feeder terminal units (FTUs) or loss during communication. First, at the upper level, an analytic model is developed to search all potential faulted sections/candidates based on the telecommunication data. Then, on the lower level, a model is presented using the telemetering data to identify the most likely fault location from the candidates provided by the upper model. The essential features of the two-level diagnosis model are demonstrated through a number of case studies. Simulation results have shown that the proposed approach is capable of not only locating the faulted section(s) in a distribution system with DGs but also identifying false and/or missing alarms. Full article

Harnessing the power of vortices shed in the wake of bluff bodies is indeed a boon to society in the face of fuel crisis. This fact serves as an impetus to develop a device called a hydro vortex power generator (HVPG), comprised of an elastically mounted cylinder that is free to oscillate in the cross-flow (CF) direction even in a low velocity flow field. The oscillatory motions in turn can be converted to useful power. This paper addresses the influence of system characteristics viz. stiffness ratio (k*) and mass ratio (m*) on the maximum response amplitude of the elastically mounted cylinder. Computational fluid dynamics (CFD) simulations have been used here to solve a two way fluid–structure interaction (FSI) problem for predicting the trend of variation of the non-dimensional amplitude Y/D with reduced velocity U_r through a series of simulations. Maximum amplitude motions have been attributed to the lowest value of m* with U_r = 8. However, the maximum lift forces correspond to U_r = 4, providing strong design inputs as well as indicating the best operating conditions. The numerical results have been compared with those of field tests in an irrigation canal and have shown reasonable agreement. Full article

Geothermal energy development has increasingly been studied in recently decades because of its renewable and sustainable features. It can be divided into two categories: traditional geothermal (hydrothermal) systems and enhanced geothermal systems (EGS) based on the type of exploitation. The hot dry rock (HDR) in the EGS incorporates about 80% of all thermal energy, and its value is about 100–1000 times that of fossil energy. It is pivotal for geothermal wells to improve the flow conductivity of the HDR mass, enhance the communication area of natural fractures, and constitute the fracture network between injection and production wells by hydraulic treatments. While the wellbore temperature significantly decreases because of fracturing, fluid injection will induce additional thermal stresses in the cement sheath, which will aggravate its failure. Considering the radial nonuniform temperature change, this paper proposes a new thermal stress model for a casing-cement sheath-formation combined system for geothermal wells during fracturing based on elastic mechanics and thermodynamics theory. This model is solved by the Gaussian main elimination method. Based on the analytical model, the thermal stresses of cement sheath have been analyzed. The effects of the main influencing parameters on thermal stresses have also been investigated. Results show that the radial and axial tensile thermal stresses are both obviously larger than tangential tensile thermal stress. The maximum radial and axial thermal stresses always occur at the casing interface while the location of the maximum tangential thermal stress varies. Generally, thermal stresses are more likely to induce radial and axial micro cracks in the cement sheath, and the cement sheath will fail more easily at the casing interface in fracturing geothermal wells. For integrity protection of the cement sheath, a proper decrease of casing wall thickness, casing linear thermal expansion coefficient, cement sheath elasticity modulus, and an increase of the fracturing fluid temperature has been suggested. Full article

Fault Current Indicators (FCIs) with communication interfaces have been widely used in distribution systems to reduce fault-finding time. The effectiveness of a Fault Management System (FMS) composed of FCIs greatly depends on the performance of the communication network deployed by the FCIs and the failure rates of distribution systems. The conventional techniques only focus on the issues of optimal number and location of FCIs or communication network deployment individually; therefore, the effectiveness of an FMS cannot be assessed realistically. A systematic effectiveness assessment methodology for FMS considering the performance of the communication network deployed by the FCIs and the failure rates of distribution systems is vital and is investigated in this paper. A communication evaluation platform is designed in this paper and used to acquire the field measurements of communication parameters. The communication parameters, especially the Packet Success Rate (PSR), between two adjacent FCIs are measured, and the Probability Density Function (PDF) of the PSR can be built accordingly. The effectiveness of the FMS is then assessed by stochastic analysis considering the failure rates of the distribution system and PSR PDFs between two adjacent FCIs. Due to the characteristics of easy installation, maintenance, longer battery life, lower cost, and so on of ZigBee, the ZigBee-based FCI is mainly discussed in this paper. In order to efficiently find the communication route when a fault occurs, a fast communication route tracking method is also proposed in this paper and its feasibility is demonstrated in an actual distribution system. Experimental and simulation results demonstrate the validity of the proposed systematic effectiveness assessment methodology for an FMS composed of FCIs. The proposed assessment methodology can more realistically react to the actual conditions of the FMS and therefore save on installation time and costs. Full article

This study suggests a model to include a solar power system or photovoltaic system (PV) in the control of frequency by taking into account a percentage of the PV power production for back-up reserve. This is done by investigating two scenarios: PV contribution in (1) initial primary frequency control and (2) entire primary frequency control. As explained in section three, 10% power of the PV modules which receive more than 400 w/m² irradiation is allocated for the power reserve. The power generation of photovoltaic systems depends largely on weather conditions which makes their output power associated with some degree of uncertainty. For this reason, in this paper, a PV system is considered along with conventional hydro and thermal units and they are modeled in MATLAB/Simulink (version 9.3, MathWorks, Natick, MA, USA) with the purpose of exploring the behavior of the intended method. In the next phase, for further studies, this system is extended to multi-area power systems including gas turbines. The results of the simulation demonstrated that the photovoltaic involvement in the control of frequency can successfully amend the frequency of the overall network. Not only it can decrease the overshoot and undershoot of the frequency response, it has the ability to improve the settling time as well, which helps the system reach the steady state easily and in shorter time. Specifically, the overshoot has reached nearly zero in both one area and two area systems and undershoot has declined up to 60% and 50% in the one area and two-area system, respectively. Considering settling time, while it had a negligible improvement in the one area system, it showed a remarkable enhancement in the two-area system, which improved from about 25 s to 6 s by using the proposed method. Full article

Fracture aperture of a fractured reservoir can be affected by both matrix elasticity and fracture compressibility when the reservoir pressure decreases, namely stress sensitivity. An elasticity parameter coupling Young’s modulus and Poisson’s ratio was introduced to reflect this geomechanical behavior, and a new model incorporating geomechanics was developed to analyze the flow behavior of a horizontal well in a naturally fractured reservoir. Pressure solutions for two cases—uniform-flux and infinite-conductivity—were derived, respectively. For the uniform-flux case, the effect of dimensionless elasticity parameter on the pressure-drop profile becomes stronger with continuing production, and the profile may be like a bow. Nine flow regimes can be observed on the transient response of the infinite-conductivity case. Stress sensitivity mainly affects the late-flow period and a larger dimensionless elasticity parameter causes a greater pressure drop. Due to stress sensitivity, the pressure derivative curve exhibits an upward tendency in the pseudo-radial flow regime, and the slope is greater than “1” in the pseudo-steady flow regime. For KT-I formation in the North Truva field, its elasticity parameter decreases with the increase of Young’s modulus or Poisson’s ratio and ranges from 8 × 10⁻⁸ Pa⁻¹ to 1.1 × 10⁻⁷ Pa⁻¹. Meanwhile, the transient response of H519 has a slight negative correlation with Young’s modulus and Poisson’s ratio in the pseudo-steady flow regime. Full article

In lattice Boltzmann simulations, the widely used non-equilibrium extrapolation method for velocity and pressure boundary conditions can cause a constant mass leakage under certain circumstances, particularly when an external force field is imposed on the fluid domain. The non-equilibrium distribution function at the boundary uses a first-order extrapolation method on the corresponding data of adjacent fluid nodes. In addition, based on this extrapolation method, the macroscopic velocity and density at the boundary nodes are obtained. Therefore, the corresponding equilibrium component of the distribution function can be calculated explicitly. Regarding the no-slip wall boundary condition, we found that the mass leakage primarily results from the extrapolation scheme for the density term in the equilibrium component of the distribution function at the boundary node. In this study, a mass-conserved wall treatment method is developed to correct the existing density term for guaranteeing the conservation of mass. Several benchmark test cases were simulated and compared to prove the justification of the newly developed mass-conserved boundary condition, and the results show a good agreement with those in the existing literature. Full article

Using a pseudo-random sequence to encode the transmitted waveform can significantly improve the working efficiency and depth of detection of electromagnetic exploration. The selection of parameters of pseudo-random sequence plays an important role in correlation identification and noise suppression. A discrete cycle correlation identification method for extracting the earth impulse response is proposed. It can suppress the distortion in the early stage of the excitation field and the glitches of the cross correlation function by traditional method. This effectively improves the accuracy of correlation identification. The influence of the order and the cycles of m-series pseudo-random coding on its autocorrelation properties is studied. The numerical results show that, with the increase of the order of m-sequence, the maximum out-of-phase periodic autocorrelation function decreases rapidly. Therefore, it is very beneficial to achieve synchronization. The limited-cycle m-sequences have good autocorrelation properties. As the period of the m-sequence increases and the width of the symbol decreases, the overall autocorrelation becomes closer to the impact function. The discussion of the influence of symbol width and period of m-sequence on its frequency bandwidth and power spectral density shows that the narrower the symbol width, the wider its occupied band. The longer the period, the smaller the power spectral line spacing. The abilities of m-sequence to suppress DC (Direct-current) interference, Schumann frequency noise, and sine-wave noise are analyzed. Numerical results show that the m-sequence has excellent ability to suppress DC interference and Schumann frequency noise. However, for high-order harmonic noise, the correlation identification error appears severe oscillation in the middle and late stages of the impulse response. It indicates that the ability of m-sequence to suppress high-frequency sinusoidal noise is deteriorated. In practical applications, the parameters of the transmitted waveform should be reasonably selected in combination with factors including transmitter performance, hardware noise, and ambient noise level to achieve the best identification effect. Full article

Small modular nuclear reactors (SMRs) offer the promise of providing carbon-free electricity and heat to small islands or isolated electricity grids. However, the economic feasibility of SMRs is highly system-dependent and has not been studied in this context. We selected three case-study islands for such an evaluation: Jeju, Tasmania and Tenerife based on their system complexity. We generated 100,000 electricity-mix cases stochastically for each island and examined the system-level generation-cost changes by incrementing the average generation cost of SMRs from USD$60 to 200 MWh⁻¹. SMRs were found to be economically viable when average generation cost was <$100 MWh⁻¹ for Jeju and <$140 MWh⁻¹ for Tenerife. For Tasmania the situation was complex; hydroelectric power is an established competitor, but SMRs might be complementary in a future “battery of the nation” scenario where most of the island’s hydro capacity was exported to meet peak power demand on the mainland grid. The higher average generation cost of SMRs makes it difficult for them to compete economically with a fossil fuel/renewable mix in many contexts. However, we have demonstrated that SMRs can be an economically viable carbon-free option for a small island with a limited land area and high energy demand. Full article

Cavitation is an important issue in pumps and usually starts on the blade leading-edge. For fixed blades with constant rotational speeds and specific flow rates, the incident angle, which is between the flow direction and the blade installing direction, on the blade leading-edge plays the key role in the cavitation process. The leading-edge shape is crucial on the local flow separation, pressure distribution, and cavitation. Hence, the influence of the leading-edge shape on cavitation has been studied in the current work in a centrifugal pump impeller. The blunt, sharp, ellipse and round leading-edge cases were compared using numerical simulation and verified by experimental data. Results show different features of cavitation. The round and ellipse leading-edge impellers have higher inception cavitation coefficient. It was caused by the sudden pressure drop on leading-edge arc or elliptical arc. The sharp and blunt leading-edge impellers have a wide flow-separation region on leading-edge with a wide low-pressure region. This is because of the sudden turn in geometry on the leading-edge corner. Cavitation grew quickly after inception and caused rapid head-drop in the sharp and blunt leading-edge impellers. Results suggest the critical cavitation performance is dominated by the leading-edge low-pressure area while the inception cavitation is mostly affected by the minimum pressure value on the leading-edge. The critical cavitation performance can be evaluated by checking the leading-edge low-pressure area. The inception cavitation can be evaluated by checking the minimum pressure value on the leading-edge. These strategies can be used in the further leading-edge designs. Full article

With the increasing interaction between physical devices and communication components, the substation based on the IEC 61850 standard is a type of cyber–physical system. This paper proposes a reliability analysis method for substations with a cyber–physical interface matrix (CPIM). This method calculates the influences from both the physical device failures and the communication devices failures. Two indices, Probability of Load Curtailments and Expected Demand Not Supplied, are used in the reliability analysis. Given the simplified model of the practical substation based on the Chinese IEC 61850 standard, the results show that the substation system had a potential risk of cascading failure under the cyber–physical fusion trend, as the failure in cyber layer would increase the power loss of the whole system. The changing magnitude of Expected Demand Not Supplied increased significantly with increasing transmission delay rate of the process bus. Full article

In this paper enhanced control strategies for standalone microgrids based on solar photovoltaic systems (SVPAs) and diesel engine driven fixed speed synchronous generators, are presented. Single-phase d-q theory-based sliding mode controller for voltage source converter voltage source converter (VSC) is employed to mitigate harmonics, balance diesel generator (DG) current, and to inject the generated power by SVPA into local grid. To achieve fast dynamic response with zero steady-state error during transition, sliding mode controller for inner control loop is employed. To achieve maximum power point tracking (MPPT) from SVPA without using any MPPT method, a DC-DC buck boost converter supported by battery storage system is controlled using a new control strategy based on sliding mode control with boundary layer. In addition, modeling and detailed stability analysis are performed. The performance of the developed control strategies, are validate by simulation using MATLAB/Simulink and in real-time using hardware prototype. Full article

Previous multiphase pipe flow tests have mainly been conducted in horizontal and vertical pipes, with few tests conducted on multiphase pipe flow under different inclined angles. In this study, in light of mid–high yield and highly deviated wells in the Middle East and on the basis of existent multiphase flow pressure research on well bores, multiphase pipe flow tests were conducted under different inclined angles, liquid rates, and gas rates. A pressure prediction model based on Mukherjee model, but with new coefficients and higher accuracy for well bores in the study block, was obtained. It was verified that the newly built pressure drawdown prediction model tallies better with experimental data, with an error of only 11.3%. The effect of inclination, output, and gas rate on the flow pattern, liquid holdup, and friction in the course of multiphase flow were analyzed comprehensively, and six kinds of classical flow regime maps were verified with this model. The results showed that for annular and slug flow, the Mukherjee flow pattern map had a higher accuracy of 100% and 80–100%, respectively. For transition flow, Duns and Ros flow pattern map had a higher accuracy of 46–66%. Full article

Interest in designing more efficient and versatile ships comes from increasingly stringent regulations on emissions. In this context, a possible solution to overcome these limits may be the replacement of marine propulsion systems based on diesel engines with hybrid architectures. This paper provides a dynamic analysis of a hybrid marine propulsion system (HPS) consisting of an internal combustion engine and an electric engine coupled with a battery pack. A dynamic simulation of a daily working cycle was carried out based on a real load demand. The instantaneous behavior of each component was evaluated. A brief summary of the HPS performance, varying the battery pack capacity, was provided together with an estimation of its impact on the system efficiency. Referring to this last point, the adoption of a hybrid system has permitted a decrease in the specific consumption, on a given route, of about 2% with respect to the case where the propulsion is entrusted only to the diesel engine. Full article

Scouring has long been considered to be a major issue affecting the reliability of the monopile foundations of offshore wind turbines (OWTs) on sandy seabeds. To reduce the impact of scouring, several tons of rock/stone are usually placed around the foundations shortly after the installation of them. Such a measure is costly. Moreover, rock and stone may spread widely on the seabed during the long-term service period of OWTs. It has no doubt that recycling these rock and stone on the seabed is quite difficult in future decommission. For this reason, a new scour-countermeasure device (SEMCD) is proposed and studied in this paper. Considering that the major driver of scouring is horseshoe vortices around the monopile foundation, a hollow horn-like SEMCD with an arc surface profile is designed for weakening the horseshoe vortices. The SEMCD is made of either cement or other kinds of corrosion resistant materials. It is light in weight, and easy to install and decommission. In the paper, the working mechanism of the SEMCD is first explained. Then, its scouring mitigation effect (SME), i.e., its contribution to the reduction of horseshoe vortices and the mitigation of seabed erosion around the foundation, is studied through investigating its influences on down/up-flow and seabed shear stress. Finally, the optimal size of the SEMCD is discussed through investigating the impact of its size on the speeds of up and down flows and the shear stress on seabed surface. The calculation results have shown that the proposed SEMCD has great potential to prevent scouring and seabed erosion, so that it is of significance to improve the reliability of the monopile foundations of OWTs. Full article

Oil shale is a kind of high-combustion heat mineral, and its oxidation in mining and storage are worth studying. To investigate the low-temperature oxidation characteristics of oil shale, the temperature, CO, alkane and alkene gases were analyzed using a temperature-programmed device. The results showed that the temperature of oil shale underwent three oxidation stages, namely a slow low-temperature oxidation stage, a rapid temperature-increasing oxidation stage, and a steady temperature-increasing stage. The higher the air supply rate is, the higher the crossing point temperature is. Similar to coal, CO also underwent three stages, namely a slow low-temperature oxidation stage, a rapid oxidation stage, and a steady increase stage. However, unlike coal, alkane and alkene gases produced by oil shale underwent four stages. They all had a concentration reduction stage with the maximum drop of 24.20%. Statistical classification of inflection temperature of various gases as their concentrations change showed that the temperature of 140 °C is the key temperature for group reactions, and above the temperature of 140 °C, all alkane and alkene gases underwent the rapid concentration increase stage. Full article

High reactivity coke is beneficial for achieving low carbon emission blast furnace ironmaking. Therefore, the preparation of highly reactive ferro-coke has aroused widespread attention. However, the effects of the particle size of iron ore on the pyrolysis behaviour of a coal-iron ore briquette are still unclear. In this study, the effect of three particle sizes (0.50–1.00 mm, 0.25–0.50 mm and <0.74 mm) of iron ore on the thermal and kinetic behaviours of coal-iron ore briquettes were investigated by non-isothermal kinetic analysis. The results showed that the synergistic effect of iron ore and coal during coking mainly occurred during the later reaction stage (850–1100 °C) and smaller particle sizes of iron ore have a stronger synergistic effect. The addition of iron ore had little effect on T₀ (the initial temperature) and T_p (the temperature at the maximum conversion rate) of briquette pyrolysis, however itgreatly affected the conversion rate and T_f (the final temperature) of the briquettes. T₀ decreased with the decrease of iron ore particle sizes, while T_p and T_f showed opposite trends. After adding iron ore into the coal briquette, the reaction kinetics at all stages of the coal-iron ore briquettes changed. The weighted apparent activation energy of the caking coal (JM) briquette was 35.532 kJ/mol, which is lower than that of the coal-iron ore briquettes (38.703–55.627 kJ/mol). In addition, the weighted apparent activation energy gradually increased with decreasing iron ore particle sizes. Full article

As a result of the high efficiency of ice-melting and the small power supply capacity, DC ice-melting devices are widely used in relation to transmission lines in the power grid. However, it needs to consume reactive power when ice-melting, and voltage fluctuation of the substation may be caused when the demand for reactive power is large. It also generates a large number of 5th and 7th harmonics when ice-melting. In this paper, combined with the demand for ice-melting for transmission lines and the dynamic reactive power of substations, a low-harmonic DC ice-melting device capable of simultaneous reactive power compensation is studied. The function of ice-melting and reactive power compensation can be operated simultaneously and the rectifier’s main harmonics can be eliminated. The simulation and experimental research on the device was carried out in the 500 kV Chuanshan substation. The actual ice melting was carried out on the 500 kV Chuansu I line and took only 68 min to melt the ice. The 500 kV bus voltage had no negative deviation, and the positive deviation decreased from +3.09% to +1.57% within 24 h of testing. The results prove the feasibility of the proposed DC ice-melting device in this paper. Full article

The fuel cell based vehicles powertrain is an extensive system that comprises a fuel cell (FC) as the primary energy source, a set of power converters both unidirectional and bidirectional and batteries or supercapacitors as secondary energy sources. Its design is a complex task that affects the mass, volume, cost, efficiency and fuel economy of the vehicle. This paper describes a graphic and straightforward sizing of the secondary energy sources needed to fulfil the vehicle load requirements, as well as the set of equations related to the mass, cost and volume of each one of the power distribution subsystems. Moreover, this paper analysis ten different power distribution architectures to conclude which is the most suitable secondary energy source, the minimum sizing, cost, volume and weight, depending on the amount of power delivered by the fuel cell. Also, a 1.6 kW fuel cell based architecture is implemented and testing. The experimental results confirm the proposed methodology. Full article

Dual Y shift 30° six-phase motors are expected to be extensively applied in high-power yet energy-effective fields, and a harmonic-suppressing control strategy plays a vital role in extending their prominent features of low losses and ultra-quiet operation. Aiming at the suppression of harmonic voltages, this paper proposes a six-phase space vector pulse width modulation method based on an optimization model, namely OM-SVPWM. First, four adjacent large vectors are employed in each of 12 sectors on a fundamental sub-plane. Second, the optimization model is constructed to intelligently determine activation durations of the four vectors, where its objective function aims to minimize the synthesis result on a harmonic sub-plane, and its constraint condition is that the synthesis result on the fundamental sub-plane satisfies a reference vector. Finally, to meet the real-time requirement, optimum solutions are obtained by using general central path following algorithm (GCPFA). Simulation and experiment results prove that, the OM-SVPWM performs around 37% better than a state-of-the-art competitive SVPWM in terms of harmonics suppression, which promise the proposed OM-SVPWM conforms to the energy-effective direction in actual engineering applications. Full article

This study aims to present a novel proportional-integral-derivative-resonant law-based sliding mode current control strategy with online inductance estimator (PIDR-SMCC-OIE) for voltage source converter medium voltage direct current (VSC-MVDC) system converter stations under unbalanced grid voltage conditions. A generalized current reference calculation method, by which the ratio of the amplitude of the active power ripple to that of the reactive power ripple can be continuously controlled without current distortion is presented. A dynamic model of the current control errors in the positive sequence synchronous reference frame is developed, and a PIDR law-based sliding mode current controller is designed, where derivatives of the current references are obtained by simple algebraic operations. An OIE adopting the dynamic filtering method and gradient algorithm is proposed to further improve system robustness. In this OIE, the converter pole voltages are obtained by computation utilizing the gate signals of the switching devices and the DC bus voltage, so that no additional voltage sensors are needed. To verify effectiveness of the PIDR-SMCC-OIE strategy, simulation studies on a two-terminal VSC-MVDC system are conducted in PSCAD/EMTDC. The results show it can provide satisfactory performance over a wide range of operating conditions. Full article

Norton equivalent circuit is a commonly used model in estimating harmonic current emissions of harmonic sources. It however cannot reflect the mutual coupling relationships among voltage and current in different harmonic orders. This paper proposes a new method to identify parameters in a coupled harmonic admittance model. The proposed method is conducted using voltage and current measurements and is based on least square estimation technique. The effectiveness of the method is verified through time-domain simulations for a grid-connected converter and also through field data obtained from a ±800 kV converter station. The experimental results showed that the proposed method presents higher accuracy in terms of harmonic current emission estimation compared with three Norton-base methods. Full article

The recent increase in the use of permanent magnet rotor motors underlines the importance of designing a rotor with an interior permanent magnet (IPM) structure, high power, and high efficiency. This study analyzed the rotor shapes of IPM motors for electric vehicles. Five types of motor rotors for automobiles were analyzed, including two hybrid vehicles. In order to minimize the number of variables in the analysis, the size of the motor stators was fixed and only the rotor shapes were modified to compare torque, torque ripple, efficiency and back-electromotive voltage. When the motor properties were compared as a function of rotor shape, the rotor shape with the smallest magnet volume exhibited excellent results for torque, efficiency and torque ripple. Full article

Local ownership models have proven to be an important way to avoid local resistance to onshore wind turbines. As wind power expands into onshore and nearshore wind farms, such ownership models become of increasing importance, while also undergoing further development. This paper uses the Choice Awareness theory to examine some of the barriers connected to the implementation of these new ownership models and presents recommendations to overcome such barriers. Choice Awareness addresses societal aspects (discourse, socioeconomics, and public regulation) mainly related to implementing alternatives to existing technologies. For the theory to be able to embrace the complexity of the transition of the energy system more holistically, we explore and specify the organizational dimension of choice-eliminating mechanisms. Based on the case of an NGO’s attempt to bid for a tender for nearshore wind turbines, it is shown how the central administration prevents new innovative ownership models from entering the tender. A strong path dependency has led to a conscious or unconscious elimination of projects based on organizational structures that do not fit the definition of large energy companies. As a result of this, the paper makes three recommendations for policy changes with the aim to secure equal possibilities for actors involved in nearshore wind power tenders. Full article

The indirect calculation from acceleration of transversal displacement of the piston inside the body of a double effect linear hydraulic cylinder during its operating cycle is assessed. Currently an extensive effort exists in the improvement of the mechanical and electronic design of the highly sophisticated MEMS accelerometers. Nevertheless, the predictable presence of measurement errors in the current commercial accelerometers is the main origin of velocity and displacement measurement deviations during integration of the acceleration. A bond graph numerical simulation model of the electromechanical system has been developed in order to forecast the effect of several measurement errors in the use of low cost two axes accelerometers. The level of influence is assessed using quality indicators and visual signal evaluation, for both simulations and experimental results. The obtained displacements results are highly influenced by the diverse dynamic characteristics of each measuring axis. The small measuring errors of a simulated extremely high performance sensor generate only moderate effects in longitudinal displacement but deep deviations in the reconstruction of piston transversal movements. The bias error has been identified as the source of the higher deviations of displacement results; although, its consequences can be easily corrected. Full article

Today, buildings consume more than 40% of primary energy in and produce more than 36% of CO₂. So, an intelligent controller applied to the buildings for energy and comfort management could achieve significant reduction in energy consumption while improving occupant’s comfort. Conventional on/off controllers were only able to automate the tasks in building and were not well suited for energy optimization tasks. Therefore, building energy management has become a focal point in recent years, promising the development of various technologies for various scenarios. This paper deals with a state of the art review on recent developments in building energy management system (BEMS) and occupants comfort, focusing on three model types: white box, black box, and gray box models. Through a comparative study, this paper presents pros and cons of each model. Full article

Near-pace hypersonic flight has great potential in civil and military use due to its high speed and low cost. To optimize the design and improve the robustness, this paper focuses on the integrated guidance and control (IGC) design with nonlinear actuator dynamics in the terminal phase of hypersonic flight. Firstly, a nonlinear integrated guidance and control model is developed with saturated control surface deflection, and third-order actuator dynamics is considered. Secondly, a neural network is introduced using an extended state observer (ESO) design to estimate the complex model uncertainty, nonlinearity and disturbance. Thirdly, a command-filtered back-stepping controller is designed with flexible designed sliding surfaces to improve the terminal performance. In this process, hybrid command filters are implemented to avoid the influences of disturbances and repetitive derivation, meanwhile solving the problem of unknown control direction caused by nonlinear saturation. The stability of the closed-loop system is proved by the Lyapunov theory, and the controller parameters can be set according to the relevant remarks. Finally, a series of numerical simulations are presented to show the feasibility and validity of the proposed IGC scheme. Full article

High voltage direct current (HVDC) transmission is being widely implemented for long-distance electrical power transmission due to its specific benefits over high voltage alternating current (HVAC) transmission. Most transmission lines pass through forests. Around the HVDC lines, an arc to a nearby tree may be produced. Thus, there should be a minimum possible clearance distance between a live conductor and a nearby tree, named the minimum vegetation clearance distance (MVCD), to avoid short-circuiting. Measurement of minimum clearance distance between the conductor and trees is a significant challenge for a transmission system. In the case of HVAC transmission, a large amount of research has been undertaken in the form of the Gallet equation for the measurement of this distance, whereas for HVDC transmission no substantial work has been done. An equivalent AC voltage value can be derived from the DC voltage value in order to use the Gallet equation. This paper presents an experimental measurement technique for determining the MVCD at 500 kV to verify the results obtained from the Gallet equation in the case of DC voltage. Performing the experiment with a 500 kV DC line is not possible in the laboratory due to safety concerns. Therefore, an experiment up to 60 kV is conducted to measure the MVCD for DC voltage. The measured results achieved from the experiment are then extrapolated to calculate the MVCD at 500 kV. Full article

This paper is devoted to the influence of two types of electronic scavenger additives/compounds, namely, carbon tetrachloride (CCl₄) and methyl iodide, which is also called iodomethane (CH₃I), on the dielectric strength of transformer mineral oil. The tests are achieved in a sphere-sphere electrodes arrangement under AC voltage according to the IEC 60156 standard. The investigated additive concentrations range from 0 to 600 ppm. The verification of the conformity of the experimental results with normal and Weibull probabilistic distributions as well as the estimation of the breakdown voltage with risk probabilities of 1%, 10%, and 50% are also performed. It is shown that there is an optimum concentration of each type of electronic scavenger compound at which the dielectric strength of the mineral oil is significantly improved (i.e., it reaches a maximum value). This improvement is of 98% with 500 ppm of CH₃I and 93% with 200 ppm of CCl₄. It is also shown that the breakdown voltage values of all of the investigated samples with and without additives conform to a Weibull distribution but not to a normal distribution. The obtained results are discussed with regard to the possible mechanisms that may be responsible, particularly the two phases of inception and propagation of the streamers. Full article

In recent years, distributed generation (DG) has developed rapidly. Renewable energy, represented by wind energy and solar energy, has been widely studied and utilized. At present, most distributed generators follow the principle of “installation is forgetting” after they are connected to a distribution network. This principle limits the popularization and benefit of distributed generation to a great extent. In order to solve these problems, this paper presents a two-tier model for optimal allocation of distributed power sources in active distribution networks (ADN). The objective of upper level planning is to minimize the annual comprehensive cost of distribution networks, and the objective of lower level planning is to minimize the active power cut-off of distributed generation through active management mode. Taking into account the time series characteristics of load and distributed power output, the improved K-means clustering method is used to cluster wind power and the photovoltaic output in different scenarios to get the daily curves in typical scenarios, and a bilevel programming model of distributed generation based on multiscenario analysis is established under active management mode. The upper level programming model is solved by Quantum genetic algorithm (QGA), and the lower level programming model is solved by the primal dual interior point method (PDIPM). The rationality of the model and the effectiveness of the algorithm are verified by simulation and analysis of a 33-bus distribution network. Full article

State-of-the-art thermodynamic simulation of energy conversion processes requires proprietary software. This article is an attempt to refute this statement. Based on object-oriented programming a simulation and exergy analysis of a combined cycle gas turbine is carried out in a free and open-source framework. Relevant basics of a thermodynamic analysis with exergy-based methods and necessary fluid property models are explained. Thermodynamic models describe the component groups of a combined heat and power system. The procedure to transform a physical model into a Python-based simulation program is shown. The article contains a solving algorithm for a precise gas turbine model with sophisticated equations of state. As an example, a system analysis of a combined cycle gas turbine with district heating is presented. Herein, the gas turbine model is validated based on literature data. The exergy analysis identifies the thermodynamic inefficiencies. The results are graphically presented in a Grassmann chart. With a sensitivity analysis a thermodynamic optimization of the district heating system is discussed. Using the exergy destruction rate in heating condensers or the overall efficiency as the objective function yields to different results. Full article

The rapid increasing amount of produced water in the deep-water and ultra-deep-water fields, especially those at their later development stages, increases the risk of the occurrence of hydrates plugging. In order to prevent and remediate the hydrates risks, it is important to understand the hydrate formation, slurry flow, and plugging characteristics and mechanisms under high water cuts conditions. In this paper, experiments with high water cuts ranging from 60–100% were conducted using a high pressure flow loop with observation windows. The whole processes of the hydrate formation, slurry flow and plugging is visually seen and recorded, and has been discussed and explained in detail in this paper. Moreover, it is found that the increasing water cuts shorten the induction time, but increase the volume fraction of hydrates. As the water cuts increase, the flow time of the hydrate slurry decreases, which serves as a critical parameter for the safe operation of the pipeline. In addition, different hypothetical mechanisms have been proposed for the medium and high water cuts conditions. We believe that this research can provide theoretical support for the safe transportation of oil and gas development in the high water cut oilfield. Full article

After disasters, enhancing the resilience of power systems and restoring power systems rapidly can effectively reduce the economy damage and bad social impacts. Reasonable post-disaster restoration strategies are the most critical part of power system restoration work. This paper co-optimizes post-disaster damage repair and power system operation together to formulate the optimal repair route, the unit output and transmission switching plan. The power outage loss will be minimized, with possible small expense of damage repair and power system operation cost. The co-optimization model is formulated as a mixed integer second order cone program (MISOCP), while the AC-power-flow model, the complex power system restoration constraints and the changing processes of component available states are synthetically considered to make the model more realistic. Lagrange relaxation (LR) decomposes the model into the damage repair routing sub problem and the power system operation sub problem, which can be solved iteratively. An acceleration strategy is used to improve the solving efficiency. The proposed model and algorithm are validated by the IEEE 57-bus test system and the results indicate that the proposed model can realize the enhancement of resilience and the economic restoration of post-disaster power systems. Full article

Polyvinyl chloride (PVC) electric wires were subjected to dechlorination in subcritical water at three different temperatures in a high-pressure reactor. About 2.09, 73.08, and 95.96 wt % of chlorine in PVC wires was removed during dechlorination at 200 °C, 250 °C, and 300 °C, respectively. The solid residues were analyzed and characterized by thermogravimetry, at three different heating rates (5 °C, 10 °C, and 20 °C/min) in inert and oxidizing atmosphere. With the purpose of studying the emission of chlorinated pollutants, pyrolysis experiments at 850 °C were also performed in a laboratory-scale reactor with the dechlorinated materials, as well as with the original PVC electric wire. Polycyclic aromatic hydrocarbons (PAH) formation increased, but chlorobenzenes (ClBz) and chlorophenols (ClPh) formation decreased as the temperature of dechlorination increased; naphthalene was the most abundant PAH and monochlorobenzene and monochlorinated phenols (3-+4-) were the most abundant chlorinated compounds. Full article

Harmonic amplification for doubly-fed induction generator wind turbine systems (DFIG WTSs) will occur due to the existence of non-linear loads and reactive power compensation installation, and grid voltage and total grid current at the point of common coupling (PCC) will be distorted. An impedance model is established to analyze the interaction between DFIG WTS, non-linear loads and weak grids. Harmonic current impact factor and harmonic voltage impact factor is proposed to analyze the impact of harmonic current source on total grid current and voltage at the PCC with different control strategies. A virtual harmonic resistor and capacitor method is adopted to reduce the harmonic voltage. An impedance-based analysis method is adopted to analyze the stability of the DFIG system. To achieve optimal control of harmonic voltage and harmonic current, a coordination factor is proposed to adjust the dynamic allocation for harmonic voltage and harmonic current at PCC. The experimental results demonstrate the effectiveness of the proposed control strategy. Full article

As the cost of solar photovoltaic (PV) falls, their potential for transforming modern electricity generation increases. Solar PV provides a simpler way of producing clean and affordable energy, which makes it an attractive investment. Great investments in solar PV have occurred in industrialized countries, but government efforts to promote this technology have not been effective in nonindustrialized countries. Despite this, some of these countries may have a high solar PV potential, such as Colombia, where policies to encourage solar PV are only just starting to take place. Therefore, this paper proposes a simulation model to assess different policies—feed-in tariff, net metering, and capital subsidy—to promote solar PV investments in the Colombian residential sector. Policies are assessed considering the criteria of efficiency and effectiveness. Simulation results suggest that (i) net metering is the most efficient policy with a cost indicator of 20,298 USD/MW; (ii) feed-in tariff is the most effective policy as it reaches the highest level of avoided CO₂ emissions—4,792,823 million tons of CO₂—and a meaningful PV installed capacity of 7522 MW; (iii) capital subsidy is the least efficient policy as it has the highest cost indicator of 509,616 USD/MW. Full article

A maximum power point tracker (MPPT) should be designed to deal with various weather conditions, which are different from region to region. Customization is an important step for achieving the highest solar energy harvest. The latest development of modern machine learning provides the possibility to classify the weather types automatically and, consequently, assist localized MPPT design. In this study, a localized MPPT algorithm is developed, which is supported by a supervised weather-type classification system. Two classical machine learning technologies are employed and compared, namely, the support vector machine (SVM) and extreme learning machine (ELM). The simulation results show the outperformance of the proposed method in comparison with the traditional MPPT design. Full article

This paper presents three phase current reconstruction methods for a three-level neutral point clamped inverter (NPCI) by measuring the voltage of a shunt resistor placed in the neutral point of the inverter. In order to accurately acquire the phase currents from the shunt resister, the dwell time of the active voltage vectors need to exceed the minimum time. On the other hand, if the time of active voltage is shorter than the minimum time, the current measurement becomes impossible. In this paper, unmeasurable regions for current are classified into three areas. Area 1 is a region in which both phase currents can be measure. Therefore, it is not necessary to restore the current. In Area 2, only one phase current can be measured. Thus, an estimation or restoration method is needed to measure another phase current. In this paper, the current estimation method using an electrical model of the motor is proposed. Area 3 is the region in which both phase currents can not be measured. In this case, it is necessary to move the voltage vector to the current measurable area by injecting the voltage. In this paper, Area 3 is divided into 36 sectors to inject optimal voltage. The proposed methods have the advantages of high current measurement accuracy and low THD (total harmonic distortion). The effectiveness of the proposed methods are verified through experimental results. Full article

The pore structure of rocks can affect fluid migration and the remaining hydrocarbon distribution. To understand the impacts of the base-level cycle on the pore structure of mouth bar sand bodies in a continental rift lacustrine basin, the pore structure of the mouth bar sand bodies in the ZVC (ZV4 + ZV5) of the Guan195 area was studied using pressure-controlled mercury injection (PMI), casting sheet image and scanning electron microscopy (SEM). The results show that three types of pores exist in ZVC, including intergranular pores, dissolution pores, and micro fractures. The porosity is generally between 1.57% and 44.6%, with a mean value of 19.05%. The permeability is between 0.06 μm² and 3611 μm², with a mean value of 137.56 μm². The pore structure heterogeneity of a single mouth bar sand body in the early stage of the falling period of short-term base-level is stronger than that in the late stage. During the falling process of the middle-term base level, the pore structure heterogeneity of a late single mouth bar sand body is weaker than that of an early single mouth bar sand body. In the long-term base-level cycle, the pore structure heterogeneity of mouth bar sand bodies becomes weaker with the falling of the base-level. Full article

This paper proposes a novel bilateral zero-voltage switching (ZVS) bidirectional converter with synchronous rectification. By controlling the direction and timing of excessive current injection, the main power switches can achieve bilateral ZVS under various loads and output voltages. Compared with the common soft-switching power converter with only zero-voltage turn-on, the proposed bilateral ZVS bidirectional converter can achieve both zero-voltage switching on and off in every switching cycle. This feature can alleviate the output switching noise due to the controlled rising and falling slope of the switch voltage. Furthermore, the voltage slopes almost remain unchanged over a wide range of output voltages and load levels. The most important feature of bilateral ZVS is to reduce the output switching noise. Experimental results based on a 1 kW prototype are presented to demonstrate the performance of the proposed converter. From experimental results on the proposed scheme, the switching noise reduction is about 75%. Full article

Tight sandstone reservoirs are often produced by shutting in the well and inducing imbibition. However, by adopting current reservoir classifications, the heterogeneity of reservoirs cannot be properly treated. Based upon the analysis of the imbibition curves and mercury intrusion porosimetry tests, Chang-7 tight sandstone reservoirs were classified into three categories according to the newly proposed standards. Imbibition tests demonstrated that for the first category, imbibition and drainage occurred continuously and never reached the plateau within the experiment duration. It was suggested that a longer shut-in time favors the production of oil. For the second category, a steady state for imbibition was reached and a shut-in time as short as three days resulted in a high imbibition rate. For the third category, a plateau was reached for the first time and imbibition restarted until a steady state was reached. The average shut-in time for the third category was eight days. Compatibility between reservoir characteristics and a soaking development regime based upon the proposed classification methods effectively enhances the oil recovery efficiency of formations with distinct petrophysical properties. This provides insight into the classification methods of tight sandstone reservoirs. Full article
