Energies

2023

Jump to: 2022, 2021, 2020, 2019, 2018, 2017, 2016, 2015, 2014

22 pages, 3027 KiB

Open AccessArticle

Wind Farm Power Prediction Considering Layout and Wake Effect: Case Study of Saudi Arabia

by Khadijah Barashid, Amr Munshi and Ahmad Alhindi

Energies 2023, 16(2), 938; https://doi.org/10.3390/en16020938 - 13 Jan 2023

Cited by 6 | Viewed by 2241

Abstract

The world’s technological and economic advancements have led to a sharp increase in the demand for electrical energy. Saudi Arabia is experiencing rapid economic and demographic growth, which is resulting in higher energy needs. The limits of fossil fuel reserves and their disruption [...] Read more.

The world’s technological and economic advancements have led to a sharp increase in the demand for electrical energy. Saudi Arabia is experiencing rapid economic and demographic growth, which is resulting in higher energy needs. The limits of fossil fuel reserves and their disruption to the environment have motivated the pursuit of alternative energy options such as wind energy. In order to regulate the power system to maintain safe and dependable operation, projections of current and daily power generation are crucial. Thus, this work focuses on wind power prediction and the statistical analysis of wind characteristics using wind data from a meteorological station in Makkah, Saudi Arabia. The data were collected over four years from January 2015 to July 2018. More than twelve thousand data points were collected and analyzed. Layout and wake effect studies were carried out. Furthermore, the near wake length downstream from the rotor disc between 1 and 5 rotor diameters (1D to 5D) was taken into account. Five robust machine learning algorithms were implemented to estimate the potential wind power production from a wind farm in Makkah, Saudi Arabia. The relationship between the wind speed and power produced for each season was carefully studied. Due to the variability in the wind speeds, the power production fluctuated much more in the winter. The higher the wind speed, the more significant the difference in energy production between the five farm layouts, and vice versa, whereas at a low wind speed, there was no significant difference in the power production in all of the near wake lengths of the 1D to 5D rotor diameters downstream from the rotor disc. Among the utilized prediction models, the decision tree regression was found to have the best accuracy values in all four utilized evaluation metrics, with 0.994 in R-squared, 0.025 in MAE, 0.273 in MSE, and 0.522 in RMSE. The obtained results were satisfactory and provide support for the construction of several wind farms, producing hundreds of megawatts, in Saudi Arabia, particularly in the Makkah Region. Full article

► Show Figures

Figure 1

2022

Jump to: 2023, 2021, 2020, 2019, 2018, 2017, 2016, 2015, 2014

19 pages, 3260 KiB

Open AccessArticle

Detecting Wind Turbine Blade Icing with a Multiscale Long Short-Term Memory Network

by Xiao Wang, Zheng Zheng, Guoqian Jiang, Qun He and Ping Xie

Energies 2022, 15(8), 2864; https://doi.org/10.3390/en15082864 - 14 Apr 2022

Cited by 16 | Viewed by 2360

Abstract

Blade icing is one of the main problems of wind turbines installed in cold climate regions, resulting in increasing power generation loss and maintenance costs. Traditional blade icing detection methods greatly rely on dedicated sensors, such as vibration and acoustic emission sensors, which [...] Read more.

Blade icing is one of the main problems of wind turbines installed in cold climate regions, resulting in increasing power generation loss and maintenance costs. Traditional blade icing detection methods greatly rely on dedicated sensors, such as vibration and acoustic emission sensors, which require additional installation costs and even reduce reliability due to the degradation and failures of these sensors. To deal with this challenge, this paper aims to develop a cost-effective detection system based on the existing operation data collected from the supervisory control and data acquisition (SCADA) systems which are already equipped in large-scale wind turbines. Considering that SCADA data is essentially a multivariate time series with inherent non-stationary and multiscale temporal characteristics, a new wavelet-based multiscale long short-term memory network (WaveletLSTM) approach is proposed for wind turbine blade icing detection. The proposed method incorporates wavelet-based multiscale learning into the traditional LSTM architecture and can simultaneously learn global and local temporal features of multivariate SCADA signals, which improves fault detection ability. A real case study has shown that our proposed WaveletLSTM method achieved better detection performance than the existing methods. Full article

► Show Figures

Figure 1

2021

Jump to: 2023, 2022, 2020, 2019, 2018, 2017, 2016, 2015, 2014

19 pages, 3607 KiB

Open AccessArticle

Design and Implementation of an Intelligent Blade Pitch Control System and Stability Analysis for a Small Darrieus Vertical-Axis Wind Turbine

by Gebreel Abdalrahman, Mohamed A. Daoud, William W. Melek, Fue-Sang Lien and Eugene Yee

Energies 2022, 15(1), 235; https://doi.org/10.3390/en15010235 - 30 Dec 2021

Cited by 6 | Viewed by 3381

Abstract

A few studies have been conducted recently in order to improve the aerodynamic performance of Darrieus vertical-axis wind turbines with straight blades (H-type VAWTs). The blade pitch angle control is proposed to enhance the performance of H-type VAWTs. This paper aims to investigate [...] Read more.

A few studies have been conducted recently in order to improve the aerodynamic performance of Darrieus vertical-axis wind turbines with straight blades (H-type VAWTs). The blade pitch angle control is proposed to enhance the performance of H-type VAWTs. This paper aims to investigate the performance of an H-type VAWT in terms of its power output and self-starting capability using an intelligent blade pitch control strategy based on a multi-layer perceptron artificial neural network (MLP-ANN) method. The performance of the proposed blade pitch controller is investigated by adding a conventional controller (PID) to the MLP-ANN controller (i.e., a hybrid controller). The dynamics of an H-type VAWT is mathematically modeled in a nonlinear state space for the stability analysis in the sense of Lyapunov. The effectiveness of the proposed pitch control system is validated by building an H-type VAWT prototype model that is extensively tested outdoors under different conditions for both fixed and variable pitch angle configurations. Results demonstrated that the blade-pitching technique enhanced the power output of an H-type VAWT by approximately

22 %

. The hybrid controller that used a high percentage of the MLP-ANN controller achieved a better control performance by reducing the overshoot of the control response at high rotor speeds. Full article

► Show Figures

Figure 1

29 pages, 13232 KiB

Open AccessArticle

A Combined RMS Simulation Model for DFIG-Based and FSC-Based Wind Turbines and Its Initialization

by Farshid Goudarzi and Lutz Hofmann

Energies 2021, 14(23), 8048; https://doi.org/10.3390/en14238048 - 1 Dec 2021

Cited by 3 | Viewed by 2413

Abstract

Reconstructable dynamic simulation models of modern variable-speed wind turbines (WTs), which are integrable into any simulation software, are crucial to the scientists investigating the contribution of WTs to counteracting the current power system stability issues. The structural similarity between a doubly fed induction-generator-based [...] Read more.

Reconstructable dynamic simulation models of modern variable-speed wind turbines (WTs), which are integrable into any simulation software, are crucial to the scientists investigating the contribution of WTs to counteracting the current power system stability issues. The structural similarity between a doubly fed induction-generator-based (DFIG-based) WT model and a full-scale-convertor-based (FSC-based) WT model using induction generator offers the possibility of integrating them into a combined modular model with little effort and the same used parameter set. This article presents a combined root mean square (RMS) WT model, which contains a DFIG-based WT and a FSC-based WT using induction generator. The model is designed based on fundamental machine and converter equations and can be applied for classical network stability analyses. Furthermore, analogous well-performing initialization procedures for both DFIG-based and FSC-based WT models are also introduced. As an example, to demonstrate the performance of the WT model in frequency stability studies, the model is extended with a droop-based fast frequency response (FFR) controller and is implemented in a MATLAB-based RMS simulation tool. The results of the case studies confirmed a solid functionality of initialization procedures. Furthermore, they illustrate feasible and comparable general behavior of both WT models as well as their plausible responses in the event of a frequency drop in a 220 kV test system. Full article

► Show Figures

Figure 1

23 pages, 1851 KiB

Open AccessArticle

A Review of Life Extension Strategies for Offshore Wind Farms Using Techno-Economic Assessments

by Benjamin Pakenham, Anna Ermakova and Ali Mehmanparast

Energies 2021, 14(7), 1936; https://doi.org/10.3390/en14071936 - 31 Mar 2021

Cited by 39 | Viewed by 5712

Abstract

The aim of this study is to look into the current information surrounding decommissioning and life extension strategies in the offshore wind sector and critically assess them to make informed decisions upon completion of the initial design life in offshore wind farms. This [...] Read more.

The aim of this study is to look into the current information surrounding decommissioning and life extension strategies in the offshore wind sector and critically assess them to make informed decisions upon completion of the initial design life in offshore wind farms. This was done through a two-pronged approach by looking into the technical aspects through comprehensive discussions with industrial specialists in the field and also looking into similar but more mature industries such as the Offshore Oil and Gas sector. For the financial side of the assessment, a financial model was constructed to help portray a possible outcome to extend the life for a current offshore wind farm, using the existing data. By employing a techno-economic approach for critical assessment of life extension strategies, this study demonstrates the advantages and disadvantages of each strategy and looks to inform the offshore wind industry the best course of action for current wind farms, depending on their size and age. Full article

► Show Figures

Figure 1

2020

Jump to: 2023, 2022, 2021, 2019, 2018, 2017, 2016, 2015, 2014

32 pages, 10258 KiB

Open AccessArticle

Free and Forced Vibration Analysis of H-type and Hybrid Vertical-Axis Wind Turbines

by Minhui Tong, Weidong Zhu, Xiang Zhao, Meilin Yu, Kan Liu and Gang Li

Energies 2020, 13(24), 6747; https://doi.org/10.3390/en13246747 - 21 Dec 2020

Cited by 1 | Viewed by 2881

Abstract

Vertical-axis wind turbines (VAWTs) are compact and efficient and have become increasingly popular for wind energy harvesting. This paper mainly focuses on free and forced vibration analysis of two different types of VAWTs, i.e., an H-type VAWT and a new hybrid VAWT. The [...] Read more.

Vertical-axis wind turbines (VAWTs) are compact and efficient and have become increasingly popular for wind energy harvesting. This paper mainly focuses on free and forced vibration analysis of two different types of VAWTs, i.e., an H-type VAWT and a new hybrid VAWT. The H-type VAWT has a lower cost, while the hybrid VAWT has a better self-starting capability at a low wind velocity. Both of them can be used for wind energy harvesting. By using the assumed modes method, the two VAWTs are simplified by a single degree-of-freedom (SDOF) model. By utilizing the method of structural mechanics, a multi-degree-of-freedom (MDOF) model is developed for the two VAWTs and the turbines in them are reasonably simplified. Natural frequency analyses for the SDOF and MDOF models of the two VAWTs are conducted. A beam element model (BEM) of the two VAWTs is created to calculate their natural frequencies and mode shapes and to verify natural frequency results from the SDOF and MDOF models. By using the BEM of the two VAWTs, their amplitude-frequency responses are obtained from harmonic response analysis. To analyze forced vibrations of the two VAWTs, aerodynamic loads on the two VAWTs are obtained from computational fluid dynamics (CFD) simulation. By using solid element models of the two VAWTs, forced transient responses of the two VAWTs are calculated by using the aerodynamic loads from CFD simulation. Steady-state forced response amplitudes of the 1 m-mast hybrid VAWT are 23.8% and 20.5% smaller in X- and Y-directions than those of the 1 m-mast H-type VAWT, respectively. Frequency contents of the aerodynamic loads from CFD simulation are calculated, which confirm that they are periodic, and the power efficiency of the H-type VAWT is about 2.6% higher that of the hybrid VAWT. Full article

► Show Figures

Figure 1

20 pages, 2384 KiB

Open AccessArticle

A Novel Analytical Wake Model with a Cosine-Shaped Velocity Deficit

by Ziyu Zhang, Peng Huang and Haocheng Sun

Energies 2020, 13(13), 3353; https://doi.org/10.3390/en13133353 - 30 Jun 2020

Cited by 21 | Viewed by 3787

Abstract

A novel analytical model is proposed and validated in this paper to predict the velocity deficit in the wake downwind of a wind turbine. The model is derived by employing mass and momentum conservation and assuming a cosine-shaped distribution for the velocity deficit. [...] Read more.

A novel analytical model is proposed and validated in this paper to predict the velocity deficit in the wake downwind of a wind turbine. The model is derived by employing mass and momentum conservation and assuming a cosine-shaped distribution for the velocity deficit. In this model, a modified wake growth rate rather than a constant one is chosen to take into account the effects of the ambient turbulence and the mechanical turbulence generated. The model was tested against field observations, wind-tunnel measurements in different thrust operations and high-resolution large-eddy simulations (LES) for two aerodynamic roughness lengths. It was found that the normalized velocity deficit predicted by the proposed model shows good agreement with experimental and numerical data in terms of shape and magnitude in the far wake region (

x / d_{0} > 3

). Based on the proposed model, predictions from multiple views and at different locations are demonstrated to show the spatial distribution of streamwise velocity downwind of a wind turbine. The result shows that the model is suitable for predicting streamwise velocity fields and thus could provide some references for the selection of wind turbine spacing. Full article

► Show Figures

Figure 1

18 pages, 3898 KiB

Open AccessArticle

Application of the Feedback Linearization in Maximum Power Point Tracking Control for Hydraulic Wind Turbine

by Chao Ai, Wei Gao, Qinyu Hu, Yankang Zhang, Lijuan Chen, Jiawei Guo and Zengrui Han

Energies 2020, 13(6), 1529; https://doi.org/10.3390/en13061529 - 24 Mar 2020

Cited by 10 | Viewed by 3215

Abstract

Taking the hydraulic wind turbine as the research object, the method is studied to improve the utilization ratio of wind energy for hydraulic wind turbine, when the wind speed is lower than the rated wind speed. The hydraulic fixed displacement pump speed and [...] Read more.

Taking the hydraulic wind turbine as the research object, the method is studied to improve the utilization ratio of wind energy for hydraulic wind turbine, when the wind speed is lower than the rated wind speed. The hydraulic fixed displacement pump speed and generating power can be used as control output to realize the maximum power point tracking control. The characteristics of the maximum power point tracking control are analyzed for hydraulic wind turbine, and the hydraulic output power is taken as control output based on the comprehensive performance requirements. Because the hydraulic wind turbine is a strong multiplication nonlinear system, the system is globally linearized based the feedback linearization method, and the maximum power point tracking control law is obtained. The simulation and experiment results show that the system has good dynamic performance with the proposed control law. The control provides theoretical guidance for optimal power tracking control law application for hydraulic wind turbine. Full article

► Show Figures

Figure 1

2019

Jump to: 2023, 2022, 2021, 2020, 2018, 2017, 2016, 2015, 2014

19 pages, 3861 KiB

Open AccessArticle

Analysis on the Force and Life of Gearbox in Double-Rotor Wind Turbine

by Yaru Yang, Hua Li, Jin Yao, Wenxiang Gao and Haiyan Peng

Energies 2019, 12(21), 4220; https://doi.org/10.3390/en12214220 - 5 Nov 2019

Cited by 5 | Viewed by 3406

Abstract

In order to study the force and life of the key components in the gearbox of an existing double-rotor wind turbine, the design and structural parameters of the gearbox in the traditional National Renewable Energy Laboratory (NREL) 5 MW single-rotor wind turbine are [...] Read more.

In order to study the force and life of the key components in the gearbox of an existing double-rotor wind turbine, the design and structural parameters of the gearbox in the traditional National Renewable Energy Laboratory (NREL) 5 MW single-rotor wind turbine are adopted, and the fixed ring gear of the first planetary stage transmission is released to form a differential gearbox suitable for a double-rotor wind turbine with two inputs. The double input is used to connect the double rotor. Subsequently, the characteristics of the gearbox in a double-rotor wind turbine are discussed. On the basis of the constant rated power of the whole wind turbine, the total power is divided into two parts, which are allocated to the double rotors, then two rotational speeds of the two inputs are given according to different power ratios by complying with the matching principle of force and moment. Furthermore, the force acting on the pitch circle of the planet gear, as well as the force and life of the planet bearing of the two-stage planetary transmission are calculated and compared with a single-rotor wind turbine. The results show that the structural advantages of a double-rotor wind turbine can reduce the stress of key components of the gearbox and increase the life span of the planet bearing, thereby the life of the whole gearbox is improved and the downtime of the whole wind turbine is reduced. Full article

► Show Figures

Graphical abstract

14 pages, 2619 KiB

Open AccessArticle

AD/RANS Simulations of Wind Turbine Wake Flow Employing the RSM Turbulence Model: Impact of Isotropic and Anisotropic Inflow Conditions

by Linlin Tian, Yilei Song, Ning Zhao, Wenzhong Shen and Tongguang Wang

Energies 2019, 12(21), 4026; https://doi.org/10.3390/en12214026 - 23 Oct 2019

Cited by 6 | Viewed by 2579

Abstract

The Reynolds-averaged Navier–Stokes (RANS)-based generalized actuator disc method along with the Reynolds stress model (AD/RANS_RSM) is assessed for wind turbine wake simulation. The evaluation is based on validations with four sets of experiments for four horizontal-axis wind turbines with different geometrical characteristics operating [...] Read more.

The Reynolds-averaged Navier–Stokes (RANS)-based generalized actuator disc method along with the Reynolds stress model (AD/RANS_RSM) is assessed for wind turbine wake simulation. The evaluation is based on validations with four sets of experiments for four horizontal-axis wind turbines with different geometrical characteristics operating in a wide range of wind conditions. Additionally, sensitivity studies on inflow profiles (representing isotropic and anisotropic turbulence) for predicting wake effects are carried out. The focus is on the prediction of the evolution of wake flow in terms of wind velocity and turbulence intensity. Comparisons between the computational results and the measurements demonstrate that in the near and transition wake region with strong anisotropic turbulence, the AD/RANS_RSM methodology exhibits a reasonably good match with all the experimental data sets; however, in the far wake region that is characterized by isotropic turbulence, the AD/RANS_RSM predicts the wake velocity quite accurately but appears to over-estimate the wake turbulence level. While the introduction of the overall turbulence intensity is found to give an improved agreement with the experiments. The performed sensitivity study proves that the anisotropic inflow condition is recommended as the profile of choice to represent the incoming wind flow. Full article

► Show Figures

Figure 1

24 pages, 8124 KiB

Open AccessArticle

Design Optimization of a Multi-Megawatt Wind Turbine Blade with the NPU-MWA Airfoil Family

by Jianhua Xu, Zhonghua Han, Xiaochao Yan and Wenping Song

Energies 2019, 12(17), 3330; https://doi.org/10.3390/en12173330 - 29 Aug 2019

Cited by 14 | Viewed by 5511

Abstract

A new airfoil family, called NPU-MWA (Northwestern Polytechnical University Multi-megawatt Wind-turbine A-series) airfoils, was designed to improve both aerodynamic and structural performance, with the outboard airfoils being designed at high design lift coefficient and high Reynolds number, and the inboard airfoils being designed [...] Read more.

A new airfoil family, called NPU-MWA (Northwestern Polytechnical University Multi-megawatt Wind-turbine A-series) airfoils, was designed to improve both aerodynamic and structural performance, with the outboard airfoils being designed at high design lift coefficient and high Reynolds number, and the inboard airfoils being designed as flat-back airfoils. This article aims to design a multi-megawatt wind turbine blade in order to demonstrate the advantages of the NPU-MWA airfoils in improving wind energy capturing and structural weight reduction. The distributions of chord length and twist angle for a 5 MW wind turbine blade are optimized by a Kriging surrogate model-based optimizer, with aerodynamic performance being evaluated by blade element-momentum theory. The Reynolds-averaged Navier–Stokes equations solver was used to validate the improvement in aerodynamic performance. Results show that compared with an existing NREL (National Renewable Energy Laboratory) 5 MW blade, the maximum power coefficient of the optimized NPU 5 MW blade is larger, and the chord lengths at all span-wise sections are dramatically smaller, resulting in a significant structural weight reduction (9%). It is shown that the NPU-MWA airfoils feature excellent aerodynamic and structural performance for the design of multi-megawatt wind turbine blades. Full article

► Show Figures

Figure 1

19 pages, 4043 KiB

Open AccessArticle

Monitoring Wind Turbine Gearbox with Echo State Network Modeling and Dynamic Threshold Using SCADA Vibration Data

by Xin Wu, Hong Wang, Guoqian Jiang, Ping Xie and Xiaoli Li

Energies 2019, 12(6), 982; https://doi.org/10.3390/en12060982 - 13 Mar 2019

Cited by 14 | Viewed by 4015

Abstract

Health monitoring of wind turbine gearboxes has gained considerable attention as wind turbines become larger in size and move to more inaccessible locations. To improve the reliability, extend the lifetime of the turbines, and reduce the operation and maintenance cost caused by the [...] Read more.

Health monitoring of wind turbine gearboxes has gained considerable attention as wind turbines become larger in size and move to more inaccessible locations. To improve the reliability, extend the lifetime of the turbines, and reduce the operation and maintenance cost caused by the gearbox faults, data-driven condition motoring techniques have been widely investigated, where various sensor monitoring data (such as power, temperature, and pressure, etc.) have been modeled and analyzed. However, wind turbines often work in complex and dynamic operating conditions, such as variable speeds and loads, thus the traditional static monitoring method relying on a certain fixed threshold will lead to unsatisfactory monitoring performance, typically high false alarms and missed detections. To address this issue, this paper proposes a reliable monitoring model for wind turbine gearboxes based on echo state network (ESN) modeling and the dynamic threshold scheme, with a focus on supervisory control and data acquisition (SCADA) vibration data. The aim of the proposed approach is to build the turbine normal behavior model only using normal SCADA vibration data, and then to analyze the unseen SCADA vibration data to detect potential faults based on the model residual evaluation and the dynamic threshold setting. To better capture temporal information inherent in monitored sensor data, the echo state network (ESN) is used to model the complex vibration data due to its simple and fast training ability and powerful learning capability. Additionally, a dynamic threshold monitoring scheme with a sliding window technique is designed to determine dynamic control limits to address the issue of the low detection accuracy and poor adaptability caused by the traditional static monitoring methods. The effectiveness of the proposed monitoring method is verified using the collected SCADA vibration data from a wind farm located at Inner Mongolia in China. The results demonstrated that the proposed method can achieve improved detection accuracy and reliability compared with the traditional static threshold monitoring method. Full article

► Show Figures

Figure 1

31 pages, 14632 KiB

Open AccessArticle

Intelligent Control of Wind-Assisted PHEVs Smart Charging Station

by Syed Zulqadar Hassan, Tariq Kamal, Muhammad Hussnain Riaz, Syed Aamir Hussain Shah, Hina Gohar Ali, Muhammad Tanveer Riaz, Muhammad Sarmad, Amir Zahoor, Muhammad Abbas Khan and Julio Pascual Miqueleiz

Energies 2019, 12(5), 909; https://doi.org/10.3390/en12050909 - 8 Mar 2019

Cited by 19 | Viewed by 3785

Abstract

Two technology opportunities, integration of renewable energy sources and the electrification of vehicles are being encouraged to reduce dependency on fossil fuels and pollution problems. Nevertheless, the huge increase of plug-in hybrid electric vehicles (PHEVs) on roads will cause an additional load in [...] Read more.

Two technology opportunities, integration of renewable energy sources and the electrification of vehicles are being encouraged to reduce dependency on fossil fuels and pollution problems. Nevertheless, the huge increase of plug-in hybrid electric vehicles (PHEVs) on roads will cause an additional load in demand, especially at rush hours, and therefore, threatens the stability of existing power grids. Considering PHEV stay for several hours in the workplace, (i.e., university), this may provide an inimitable framework to charge PHEV from wind in the workplace. This paper introduces the possibility of introducing intelligent control of wind power and battery storage units as supplementary power sources for future PHEV charging demands during rush hours. The operation of the proposed algorithm is based on the priority levels of PHEVs charging, and fluctuations in DC link voltage levels due to the variation in wind speed. The priorities of PHEVs charging are developed according to their power requirements, maximum rating of distribution transformer and park duration of PHEVs in the workplace during wind speed. Various non-isolated proportional–integral controllers and improved intelligent fuzzy control are used to keep a minimum critical DC link voltage to permit the power conditioning system to operate a charging station uninterruptedly, even at low wind speed. The improved intelligent fuzzy controller also contributes to minimizing the stress on the DC bus and ensures quality output power. The performance of the proposed charging station is verified for the real PHEV under real-world record of wind speed. All the energy sources, electric charging station and their controllers are designed in MATLAB/Simulink. Finally, the feasibility of proposed charging station is checked experimentally in the laboratory. Full article

► Show Figures

Figure 1

16 pages, 7300 KiB

Open AccessArticle

Dynamic Behavior of Wind Turbine Generator Configurations during Ferroresonant Conditions

by Ajibola Akinrinde, Andrew Swanson and Remy Tiako

Energies 2019, 12(4), 639; https://doi.org/10.3390/en12040639 - 16 Feb 2019

Cited by 21 | Viewed by 4355

Abstract

In this paper the dynamic behavior of different wind turbine generator configurations including doubly fed induction generators (DFIG), squirrel cage induction generator (SCIG), wound rotor induction generator (WRIG), and permanent magnet synchronous generator (PMSG) under ferroresonant conditions of energization and de-energization was investigated [...] Read more.

In this paper the dynamic behavior of different wind turbine generator configurations including doubly fed induction generators (DFIG), squirrel cage induction generator (SCIG), wound rotor induction generator (WRIG), and permanent magnet synchronous generator (PMSG) under ferroresonant conditions of energization and de-energization was investigated using Simulink/MATLAB (version 2017B, MathWorks, Natick, MA, USA). The result showed that SCIG had the highest overvoltage of 10.1 PU during energization, followed by WRIG and PMSG, while the least was DFIG. During de-energization, PMSG had the highest overvoltage of 9.58 PU while WRIG had the least. Characterization of the ferroresonance was done using a phase plane diagram to identify the harmfulness of the ferroresonance existing in the system. It was observed that for most of the wind turbine configurations, a chaotic mode of ferroresonance exists for both energization and de-energization scenarios. Although overvoltage during energization for wind turbine generator configurations was higher than in the de-energization with an exception of PMSG, their phase plane diagrams showed that de-energization scenarios were more chaotic than energization scenarios. The study showed that WRIG was the least susceptible to ferroresonance while PMSG was the most susceptible to ferroresonance. Full article

► Show Figures

Figure 1

25 pages, 13470 KiB

Open AccessArticle

Effect of Tailing-Edge Thickness on Aerodynamic Noise for Wind Turbine Airfoil

by Xinkai Li, Ke Yang, Hao Hu, Xiaodong Wang and Shun Kang

Energies 2019, 12(2), 270; https://doi.org/10.3390/en12020270 - 16 Jan 2019

Cited by 10 | Viewed by 3752

Abstract

The influence of wind turbine airfoil trailing edge thickness on aerodynamics and aerodynamic noise characteristics was studied using the computational fluid dynamics (CFD)/ Ffowcs Williams–Hawkings (FW–H) method in the present work. First, the airfoil of a DU97-W-300-flatback airfoil was chosen as the research [...] Read more.

The influence of wind turbine airfoil trailing edge thickness on aerodynamics and aerodynamic noise characteristics was studied using the computational fluid dynamics (CFD)/ Ffowcs Williams–Hawkings (FW–H) method in the present work. First, the airfoil of a DU97-W-300-flatback airfoil was chosen as the research object, and numerical method validation was performed. Three kinds of turbulence calculation methods (unsteady Reynolds average Navier-Stokes (URANS), detached eddy simulation (DES), and large eddy simulation (LES)) were investigated in detail, and three sets of grid scales were used to study the impact of the airfoil on the aerodynamic noise. Secondly, the airfoil trailing edge thickness was changed, and the impact of trailing edge thickness on aerodynamics and aerodynamic noise was investigated. Results show that three kinds of turbulence calculation methods yield the same sound pressure frequency, and the magnitude of the sound pressure level (SPL) corresponding to the mean frequency is almost the same. The calculation of the SPL of the peak value and the experimental results can match well with each other, but the calculated core frequency is slightly lower than the experimental frequency. The results of URANS and DES are closer to each other with a changing trend of SPL, and the consequences of the DES calculation are closer to the experimental results. From the comparison of two airfoils, the blunt trailing edge (BTE) airfoil has higher lift and drag coefficients than the original airfoil. The basic frequency of lift coefficients of the BTE airfoil is less than that of the original airfoil. It is demonstrated that the trailing vortex shedding frequency of the original airfoil is higher than that of the BTE airfoil. At a small angle of attack (AOA), the distribution of SPL for the original airfoil exhibits low frequency characteristics, while, at high AOA, the wide frequency characteristic is presented. For the BTE airfoil, the distribution of SPL exhibits low frequency characteristics for the range of the AOA. The maximum AOA of SPL is 4° and the minimum AOA of SPL is 15°, while, for the original airfoil, the maximum AOA of SPL is 19°, and the minimum AOA is 8°. For most AOAs, the SPL of the BTE airfoil is larger than that of the original airfoil. Full article

► Show Figures

Figure 1

2018

Jump to: 2023, 2022, 2021, 2020, 2019, 2017, 2016, 2015, 2014

14 pages, 4114 KiB

Open AccessArticle

A Comparative Computational Fluid Dynamic Study on the Effects of Terrain Type on Hub-Height Wind Aerodynamic Properties

by Akintayo T. Abolude and Wen Zhou

Energies 2019, 12(1), 83; https://doi.org/10.3390/en12010083 - 28 Dec 2018

Cited by 5 | Viewed by 2890

Abstract

The increased adoption of wind power has generated global discourse in wind energy meteorology. Studies based on turbine performances show a deviation of actual output from power curve output, thereby yielding errors irrespective of the turbine site. Understanding the cause of these errors [...] Read more.

The increased adoption of wind power has generated global discourse in wind energy meteorology. Studies based on turbine performances show a deviation of actual output from power curve output, thereby yielding errors irrespective of the turbine site. Understanding the cause of these errors is essential for wind power optimization, thus necessitating investigation into site-specific effects on turbine performance and operation. Therefore, Computational Fluid Dynamics simulations of hub-height wind aerodynamic properties were conducted based on the k-ε turbulence closure model Reynolds Averaged Navier Stokes equations for three terrains. To isolate terrain-induced effects, the same 40 m above mean sea level wind climatology was imposed on all three terrains. For the four wind directions considered, turbulence intensity (TI) was least in the offshore terrain at about 5–7% but ranged considerably higher from 4–18% for the coastal and island terrain. TI on crests also increased significantly by up to 15% upstream of wind direction for the latter terrains. Inflow angle ranged from −15° to +15° in both coastal and island terrains but remained at <+1° in the offshore terrain. Hellman exponent increased from between factors of 2–4 in the other two terrains relative to that of the offshore terrain. Wind speed-up varied from about 1.06–1.13, accounting for a range of 17–30% difference in power output from a hypothetical operational 2 MW turbine output placed in the three different terrains. Turbine loading, fatigue, efficiency, and life cycle can also be impacted by the variations noted. While adopting a site-specific power curve may help minimize errors and losses, collecting these aerodynamic data alongside wind speed and direction is the future for wind power optimization under big data and machine learning. Full article

► Show Figures

Figure 1

18 pages, 9190 KiB

Open AccessArticle

Application of an Eddy Current-Tuned Mass Damper to Vibration Mitigation of Offshore Wind Turbines

by Jijian Lian, Yue Zhao, Chong Lian, Haijun Wang, Xiaofeng Dong, Qi Jiang, Huan Zhou and Junni Jiang

Energies 2018, 11(12), 3319; https://doi.org/10.3390/en11123319 - 28 Nov 2018

Cited by 29 | Viewed by 4825

Abstract

Offshore wind turbine (OWT) structures are highly sensitive to complex ambient excitations, especially extreme winds. To mitigate the vibrations of OWT structures under windstorm or typhoon conditions, a new eddy current with tuned mass damper (EC-TMD) system that combines the advantages of the [...] Read more.

Offshore wind turbine (OWT) structures are highly sensitive to complex ambient excitations, especially extreme winds. To mitigate the vibrations of OWT structures under windstorm or typhoon conditions, a new eddy current with tuned mass damper (EC-TMD) system that combines the advantages of the eddy current damper and the tuned mass damper is proposed to install at the top of them. In the present study, the electromagnetic theory is applied to estimate the damping feature of the eddy current within the EC-TMD system. Then, the effectiveness of the EC-TMD system for vibration mitigation is demonstrated by small-scale tests. Furthermore, the EC-TMD system is used to alleviate structural vibrations of the OWT supported by composite bucket foundations (CBF) under extreme winds at the Xiangshui Wind Farm of China. It is found that the damping of the EC-TMD system can be ideally treated as having linear viscous damping characteristics, which are influenced by the gaps between the permanent magnets and the conductive materials as well as the permanent magnet layouts. Meanwhile, the RMS values of displacements of the OWT structure can be mitigated by 16% to 28%, and the acceleration can also be reduced significantly. Therefore, the excellent vibration-reducing performance of the EC-TMD system is confirmed, which provides meaningful guidance for application in the practical engineering of OWTs. Full article

► Show Figures

Figure 1

22 pages, 6123 KiB

Open AccessArticle

Assessment of Wind Energy Potential as a Power Generation Source: A Case Study of Eight Selected Locations in Northern Cyprus

by Mohamad M. Alayat, Youssef Kassem and Hüseyin Çamur

Energies 2018, 11(10), 2697; https://doi.org/10.3390/en11102697 - 10 Oct 2018

Cited by 42 | Viewed by 4986

Abstract

This paper presents a techno-economic assessment of the wind power potential for eight locations distributed over the Northern part of Cyprus. The wind speed data were collected from the meteorological department located in Lefkoşa, Northern Cyprus.Ten distribution models were used to analyze the [...] Read more.

This paper presents a techno-economic assessment of the wind power potential for eight locations distributed over the Northern part of Cyprus. The wind speed data were collected from the meteorological department located in Lefkoşa, Northern Cyprus.Ten distribution models were used to analyze the wind speed characteristics and wind energy potential at the selected locations. The maximum-likelihood method was used for calculating the parameters of the distribution functions.The power law model is utilized to determine the mean wind speed at various heights. In addition, the wind power density for each location was estimated. Furthermore, the performances of different small-scale vertical axis 3–10 kW wind turbines were evaluated to find those that were suitable and efficient for power generation in the studied locations.The results showed that the annual mean wind speed in the regions is greater than 2 m/s at a height of 10 m. Moreover, it is indicated that Generalized Extreme Value distribution provided the best fit to the actual data for the regions of Lefkoşa, Ercan, Girne, Güzelyurt, and Dipkarpaz. However, the Log-Logistic, Weibull, and Gamma distributions gave a better fit to the actual data of Gazimağusa, YeniBoğaziçi, and Salamis, respectively. The Rayleigh distribution does not fit the actual data from all regions. Furthermore, the values of wind power densityat the areas studied ranged from 38.76 W/m² to 134.29 W/m² at a height of 50 m, which indicated that wind energy sources in these selected locations are classified as poor. Meanwhile, based on the wind analysis, small-scale wind turbine use can be suitable for generating electricity in the studied locations. Consequently, an Aeolos-V2 with a rating of 5 kW was found to be capable of producing the annual energy needs of an average household in Northern Cyprus. Full article

► Show Figures

Figure 1

18 pages, 6379 KiB

Open AccessArticle

Combined Blade-Element Momentum—Lifting Line Model for Variable Loads on Downwind Turbine Towers

by Shigeo Yoshida

Energies 2018, 11(10), 2521; https://doi.org/10.3390/en11102521 - 21 Sep 2018

Cited by 5 | Viewed by 3334

Abstract

Downwind rotors are a promising concept for multi-megawatt scale large wind turbines due to their advantages in safety and cost reduction. However, they have risks from impulsive loads when one of the blades passes across the tower wake, where the wind speed is [...] Read more.

Downwind rotors are a promising concept for multi-megawatt scale large wind turbines due to their advantages in safety and cost reduction. However, they have risks from impulsive loads when one of the blades passes across the tower wake, where the wind speed is lower and locally turbulent. Although the tower shadow effects on the tower loads have been discussed in former studies, there is currently no appropriate model for the blade-element and momentum theory so far. This study formulates the tower shadow effects on the tower load variation induced by blades using the lifting line theory, which does not require any empirical parameters. The method is verified via computational fluid dynamics for a 2 MW(megawatt), 3-bladed downwind turbine. The amplitude and the phase of the variation are shown to be accurate in outboard sections, where the rotor-tower clearance is large (>3.0 times of the tower diameter) and the ratio of the blade chord length is small (<0.5 times of the tower diameter), in both of rated and cut-out conditions. Full article

► Show Figures

Figure 1

16 pages, 5144 KiB

Open AccessArticle

Combined Pitch and Trailing Edge Flap Control for Load Mitigation of Wind Turbines

by Keshan He, Liangwen Qi, Liming Zheng and Yan Chen

Energies 2018, 11(10), 2519; https://doi.org/10.3390/en11102519 - 21 Sep 2018

Cited by 17 | Viewed by 3334

Abstract

Using active control methods for load mitigation in wind turbines could greatly reduce the cost of per kilowatt hour of wind power. In this work, the combined pitch and trailing edge flap control (CPFC) for load mitigation of wind turbines is investigated. The [...] Read more.

Using active control methods for load mitigation in wind turbines could greatly reduce the cost of per kilowatt hour of wind power. In this work, the combined pitch and trailing edge flap control (CPFC) for load mitigation of wind turbines is investigated. The CPFC includes an individual pitch control (IPC) loop and a trailing edge flap control (TEFC) loop, which are combined by a load frequency division control algorithm. The IPC loop is mainly used to mitigate the low frequency loads, and the TEFC loop is mainly used to mitigate the high frequency loads. The CPFC adopts both an azimuth angle feed-forward and a loads feedback control strategy. The azimuth angle feed-forward control strategy should mitigate the asymmetrical loads caused by observable disturbances. and the loads feedback control strategy should decrease asymmetrical loads by closed loop control. A simulation is carried out on the joint platform of FAST and MATLAB. The simulation results show that the damage equivalent load (DEL) of blade root out-of-plane bending moment is reduced by 53.7% while using CPFC, compared to collective pitch control (CPC); and the standard deviation of blade tip out-of-plane deflection is reduced by 50.2% while using CPFC, compared to CPC. The results demonstrate that the CPFC can mitigate the fatigue loads of wind turbines as anticipated. Full article

► Show Figures

Figure 1

13 pages, 2097 KiB

Open AccessArticle

Using Multiple Fidelity Numerical Models for Floating Offshore Wind Turbine Advanced Control Design

by Joannes Olondriz, Wei Yu, Josu Jugo, Frank Lemmer, Iker Elorza, Santiago Alonso-Quesada and Aron Pujana-Arrese

Energies 2018, 11(9), 2484; https://doi.org/10.3390/en11092484 - 18 Sep 2018

Cited by 5 | Viewed by 4551

Abstract

This paper summarises the tuning process of the Aerodynamic Platform Stabiliser control loop and its performance with Floating Offshore Wind Turbine model. Simplified Low-Order Wind turbine numerical models have been used for the system identification and control tuning process. Denmark Technical University’s 10 [...] Read more.

This paper summarises the tuning process of the Aerodynamic Platform Stabiliser control loop and its performance with Floating Offshore Wind Turbine model. Simplified Low-Order Wind turbine numerical models have been used for the system identification and control tuning process. Denmark Technical University’s 10 MW wind turbine model mounted on the TripleSpar platform concept was used for this study. Time-domain simulations were carried out in a fully coupled non-linear aero-hydro-elastic simulation tool FAST, in which wind and wave disturbances were modelled. This testing yielded significant improvements in the overall Floating Offshore Wind Turbine performance and load reduction, validating the control technique presented in this work. Full article

► Show Figures

Figure 1

13 pages, 4198 KiB

Open AccessArticle

Dimensional Analysis of Power Prediction of a Real-Scale Wind Turbine Based on Wind-Tunnel Torque Measurement of Small-Scaled Models

by Sutrisno, Sigit Iswahyudi and Setyawan Bekti Wibowo

Energies 2018, 11(9), 2374; https://doi.org/10.3390/en11092374 - 8 Sep 2018

Cited by 5 | Viewed by 4465

Abstract

A preliminary study of a horizontal-axis wind turbine (HAWT) design is carried out using a wind tunnel to obtain its aerodynamic characteristics. Utilization of data from the study to develop large-scale wind turbines requires further study. This paper aims to discuss the use [...] Read more.

A preliminary study of a horizontal-axis wind turbine (HAWT) design is carried out using a wind tunnel to obtain its aerodynamic characteristics. Utilization of data from the study to develop large-scale wind turbines requires further study. This paper aims to discuss the use of wind turbine data obtained the wind-tunnel measurements to estimate the characteristics of wind turbines that have field size. One should measure the torque of two small-scale turbines inside the wind tunnel. The first small-scale turbine has a radius of 0.14 m, and the radius of the second small turbine is 0.19 m. Torque measurement results from both turbines were analyzed using the Buckingham π theorem to obtain a correlation between torsion and diameter variations. The obtained correlation equation was used to estimate the field measurement of turbine power with a radius of 1.2 m. The resulting correlation equation can be applied to approximate the energy generated by the turbine using the size of the field well in the operating area and the tip-speed ratio (λ) of the turbine design. Full article

► Show Figures

Figure 1

33 pages, 7160 KiB

Open AccessArticle

Conceptual Synthesis of Speed Increasers for Wind Turbine Conversion Systems

by Radu Saulescu, Mircea Neagoe and Codruta Jaliu

Energies 2018, 11(9), 2257; https://doi.org/10.3390/en11092257 - 27 Aug 2018

Cited by 14 | Viewed by 3404

Abstract

Most wind turbines (WT) are of the single-rotor type, which means they are simple, reliable and durable, but unlikely to convert more than 40% of the available wind energy. Different solutions are proposed to minimize WT energy loss and improve performance, such as [...] Read more.

Most wind turbines (WT) are of the single-rotor type, which means they are simple, reliable and durable, but unlikely to convert more than 40% of the available wind energy. Different solutions are proposed to minimize WT energy loss and improve performance, such as the use of speed increasers, counter-rotating wind rotors or counter-rotating electric generators. Downsizing the design, saving weight and reducing the cost of WT conversion systems, while increasing their efficiency, have posed constant challenges to WT designers. Nevertheless, very little research in the field is concerned with, and partially recommends, the design of conversion systems. Therefore, the aim of this paper is to propose a specific algorithm for the conceptual synthesis of speed increasers integrated in WT conversion systems, starting with an inventory of all combinations of the main components of a conversion system that prove compatible for efficient functioning. The algorithm is structured in two sections: the first one includes a four-step approach to WT system design, while the second one follows a three-step procedure for identifying the speed increaser concept. Twenty-two variants of speed increasers are further generated and analyzed, four of which are innovative solutions proposed by the authors. The paper also provides guidelines for identifying the WT conversion system concept according to the circumstances of its application. Full article

► Show Figures

Figure 1

6 pages, 219 KiB

Open AccessArticle

An Analytical Model for the Regeneration of Wind after Exiting a Wind Farm

by Brian H. Fiedler

Energies 2018, 11(8), 2071; https://doi.org/10.3390/en11082071 - 8 Aug 2018

Viewed by 2961

Abstract

The simplest model for an atmospheric boundary layer assumes a uniform steady wind over a certain depth, of order 1 km, with the forces of friction, pressure gradient and Coriolis in balance. A linear model is here employed for the adjustment of wind [...] Read more.

The simplest model for an atmospheric boundary layer assumes a uniform steady wind over a certain depth, of order 1 km, with the forces of friction, pressure gradient and Coriolis in balance. A linear model is here employed for the adjustment of wind to this equilibrium, as the wake of a very wide wind farm. A length scale is predicted for the exponential adjustment to equilibrium. Calculation of this length scale is aided by knowledge of the angle for which the wind would normally cross the isobars in environmental conditions in the wake. Full article

15 pages, 1842 KiB

Open AccessArticle

Assessment and Performance Evaluation of a Wind Turbine Power Output

by Akintayo Temiloluwa Abolude and Wen Zhou

Energies 2018, 11(8), 1992; https://doi.org/10.3390/en11081992 - 1 Aug 2018

Cited by 15 | Viewed by 4473

Abstract

Estimation errors have constantly been a technology bother for wind power management, often time with deviations of actual power curve (APC) from the turbine power curve (TPC). Power output dispersion for an operational 800 kW turbine was analyzed using three averaging tine steps [...] Read more.

Estimation errors have constantly been a technology bother for wind power management, often time with deviations of actual power curve (APC) from the turbine power curve (TPC). Power output dispersion for an operational 800 kW turbine was analyzed using three averaging tine steps of 1-min, 5-min, and 15-min. The error between the APC and TPC in kWh was about 25% on average, irrespective of the time of the day, although higher magnitudes of error were observed during low wind speeds and poor wind conditions. The 15-min averaged time series proved more suitable for grid management and energy load scheduling, but the error margin was still a major concern. An effective power curve (EPC) based on the polynomial parametric wind turbine power curve modeling technique was calibrated using turbine and site-specific performance data. The EPC reduced estimation error to about 3% in the aforementioned time series during very good wind conditions. By integrating statistical wind speed forecasting methods and site-specific EPCs, wind power forecasting and management can be significantly improved without compromising grid stability. Full article

► Show Figures

Figure 1

15 pages, 7628 KiB

Open AccessArticle

Load Estimation of Offshore Wind Turbines

by Sang Lee, Matthew Churchfield, Frederick Driscoll, Senu Sirnivas, Jason Jonkman, Patrick Moriarty, Bjόrn Skaare, Finn Gunnar Nielsen and Erik Byklum

Energies 2018, 11(7), 1895; https://doi.org/10.3390/en11071895 - 20 Jul 2018

Cited by 16 | Viewed by 4765

Abstract

The influence of 3 MW Hywind-II wind turbine wakes from an upstream offshore floating wind turbine on a downstream turbine with a separation distance of seven rotor diameters was studied for a site in the Gulf of Maine. The turbines and the platforms [...] Read more.

The influence of 3 MW Hywind-II wind turbine wakes from an upstream offshore floating wind turbine on a downstream turbine with a separation distance of seven rotor diameters was studied for a site in the Gulf of Maine. The turbines and the platforms were subjected to atmospheric boundary layer flows. Various sensitivity studies on fatigue loads with respect to the positions of the downstream turbine were performed and validated with a large-eddy simulation tool. In particular, the effect of various lateral positions of the downstream turbine relative to the upstream turbine were considered using time-series turbine wake data generated from the large-eddy simulation tool which served as an input to an aero-elastic wind turbine model to assess the loads. The load response from the rotor, tower, and the floating platform for the downstream turbine were sensitive to the lateral offset positions where turbines that were partially exposed to upstream turbine wakes yielded significant increases in the cyclic load range. For the given set of lateral positions for the downstream turbine, the largest damage equivalent load occurred when the turbine was one rotor diameter to the left of the centerline, when looking upstream, which is the position of the turbine fully exposed to upstream turbine wake. On the other hand, the fatigue load on the downstream turbine placed on the right side of the position fully exposed to the upstream turbine wake, yielded lower stress due to the non-symmetric shape of the turbine wake. The configuration associated with the largest damage equivalent loads was further investigated in a large-eddy simulation, modeling both the upstream and downstream turbines. It was found that the energy spectra at the blade rotational frequency were a magnitude order higher for the downstream turbine, especially for surge, heave, pitch, and yaw motion of the platform. The increase of the damage equivalent load for the flapwise blade root moment was 45% compared to the upstream turbine, which can potentially reduce the turbine service life time. Full article

► Show Figures

Figure 1

14 pages, 6815 KiB

Open AccessArticle

Computational Fluid Dynamics Approach to Predict the Actual Wind Speed over Complex Terrain

by Takanori Uchida

Energies 2018, 11(7), 1694; https://doi.org/10.3390/en11071694 - 29 Jun 2018

Cited by 11 | Viewed by 4193

Abstract

This paper proposes a procedure for predicting the actual wind speed for flow over complex terrain with CFD. It converts a time-series of wind speed data acquired from field observations into a time-series data of actual scalar wind speed by using non-dimensional wind [...] Read more.

This paper proposes a procedure for predicting the actual wind speed for flow over complex terrain with CFD. It converts a time-series of wind speed data acquired from field observations into a time-series data of actual scalar wind speed by using non-dimensional wind speed parameters, which are determined beforehand with the use of CFD output. The accuracy and reproducibility of the prediction procedure were investigated by simulating the flow with CFD with the use of high spatial resolution (5 m) surface elevation data for the Noma Wind Park in Kagoshima Prefecture, Japan. The errors of the predicted average monthly wind speeds relative to the observed values were less than approximately 20%. Full article

► Show Figures

Figure 1

15 pages, 30637 KiB

Open AccessArticle

LES Investigation of Terrain-Induced Turbulence in Complex Terrain and Economic Effects of Wind Turbine Control

by Takanori Uchida

Energies 2018, 11(6), 1530; https://doi.org/10.3390/en11061530 - 12 Jun 2018

Cited by 14 | Viewed by 3993

Abstract

In the present study, numerical wind simulation was conducted by reproducing the realistic topography near wind turbine sites with high spatial resolutions and using the Large-Eddy Simulation (LES) technique. The topography near wind turbine sites serves as the origin of the terrain-induced turbulence. [...] Read more.

In the present study, numerical wind simulation was conducted by reproducing the realistic topography near wind turbine sites with high spatial resolutions and using the Large-Eddy Simulation (LES) technique. The topography near wind turbine sites serves as the origin of the terrain-induced turbulence. The obtained numerical simulation results showed that the terrain-induced turbulence is generated at a small terrain feature located upstream of the wind turbine. The generated terrain-induced turbulence affects the wind turbine directly. The wind speed and wind direction at the wind turbine site are significantly changed with time. In the present study, a combination of the series of wind simulation results and on-site operation experience led to a decision to adopt an “automatic shutdown program”. Here, an “automatic shutdown program” means the automatic suspension of wind turbine operation based on the wind speed and wind direction meeting the conditions associated with significant effects of terrain-induced turbulence at a wind turbine site. The adoption of the “automatic shutdown program” has successfully led to a large reduction in the number of occurrences of wind turbine damage, thus, creating major positive economic effects. Full article

► Show Figures

Figure 1

13 pages, 22838 KiB

Open AccessArticle

Computational Fluid Dynamics (CFD) Investigation of Wind Turbine Nacelle Separation Accident over Complex Terrain in Japan

by Takanori Uchida

Energies 2018, 11(6), 1485; https://doi.org/10.3390/en11061485 - 7 Jun 2018

Cited by 11 | Viewed by 5085

Abstract

We have developed an unsteady and non-linear wind synopsis simulator called RIAM-COMPACT (Research Institute for Applied Mechanics, Kyushu University, COMputational Prediction of Airflow over Complex Terrain) to simulate the airflow on a micro scale, i.e., a few tens of km or less. In [...] Read more.

We have developed an unsteady and non-linear wind synopsis simulator called RIAM-COMPACT (Research Institute for Applied Mechanics, Kyushu University, COMputational Prediction of Airflow over Complex Terrain) to simulate the airflow on a micro scale, i.e., a few tens of km or less. In RIAM-COMPACT, the large-eddy simulation (LES) has been adopted for turbulence modeling. LES is a technique in which the structures of relatively large eddies are directly simulated and smaller eddies are modeled using a sub-grid scale model. In the present study, we conducted numerical wind diagnoses for the Taikoyama Wind Farm nacelle separation accident in Japan. The simulation results suggest that all six wind turbines at Taikoyama Wind Farm are subject to significant influence from separated flow (terrain-induced turbulence) which is generated due to the topographic irregularities in the vicinity of the wind turbines. A proposal was also made on reconstruction of the wind farm. Full article

► Show Figures

Figure 1

15 pages, 3954 KiB

Open AccessArticle

Interaction of Wind Turbine Wakes under Various Atmospheric Conditions

by Sang Lee, Peter Vorobieff and Svetlana Poroseva

Energies 2018, 11(6), 1442; https://doi.org/10.3390/en11061442 - 4 Jun 2018

Cited by 7 | Viewed by 3628

Abstract

We present a numerical study of two utility-scale 5-MW turbines separated by seven rotor diameters. The effects of the atmospheric boundary layer flow on the turbine performance were assessed using large-eddy simulations. We found that the surface roughness and the atmospheric stability states [...] Read more.

We present a numerical study of two utility-scale 5-MW turbines separated by seven rotor diameters. The effects of the atmospheric boundary layer flow on the turbine performance were assessed using large-eddy simulations. We found that the surface roughness and the atmospheric stability states had a profound effect on the wake diffusion and the Reynolds stresses. In the upstream turbine case, high surface roughness increased the wind shear, accelerating the decay of the wake deficit and increasing the Reynolds stresses. Similarly, atmospheric instabilities significantly expedited the wake decay and the Reynolds stress increase due to updrafts of the thermal plumes. The turbulence from the upstream boundary layer flow combined with the turbine wake yielded higher Reynolds stresses for the downwind turbine, especially in the streamwise component. For the downstream turbine, diffusion of the wake deficits and the sharp peaks in the Reynolds stresses showed faster decay than the upwind case due to higher levels of turbulence. This provides a physical explanation for how turbine arrays or wind farms can operate more efficiently under unstable atmospheric conditions, as it is based on measurements collected in the field. Full article

► Show Figures

Figure 1

21 pages, 24785 KiB

Open AccessArticle

Experimental Investigation of Static Stall Hysteresis and 3-Dimensional Flow Structures for an NREL S826 Wing Section of Finite Span

by Hamid Sarlak, Ariane Frère, Robert Mikkelsen and Jens N. Sørensen

Energies 2018, 11(6), 1418; https://doi.org/10.3390/en11061418 - 1 Jun 2018

Cited by 9 | Viewed by 4828

Abstract

Flow characteristics of an S826 airfoil at different Reynolds numbers, ranging from 40,000–400,000 (based on airfoil chord length) and angles of attack from −10–25 degrees are thoroughly investigated in a low-speed wind tunnel. The airfoil’s lift and drag polars are first measured, and [...] Read more.

Flow characteristics of an S826 airfoil at different Reynolds numbers, ranging from 40,000–400,000 (based on airfoil chord length) and angles of attack from −10–25 degrees are thoroughly investigated in a low-speed wind tunnel. The airfoil’s lift and drag polars are first measured, and with a focus on pitching the airfoil in upstroke and downstroke orders, static stall hysteresis is identified in selected experiments at Reynolds numbers below 100,000 near the stall angle and subsequently investigated. Experiments using wire-generated free stream turbulence are conducted, and the hysteresis effects are shown to disappear when introducing a free stream turbulence of less than 2.5%. Further, spanwise flow is detected by comparing lift and drag values measured using both surface pressure integration at one cross section as well as integral force gauge measurement, and the surface oil flow visualization technique is subsequently used to study the 3D flow topologies formed on the airfoil. The formation of distinct stall cells on the suction side of the airfoil is observed at Reynolds numbers above 100,000 near the stall angle. By repeating the experiments, stall cells are proven to be reproduceable, although the identical geometries are necessarily not retained in abscence of surface impurities such as tapes. The effect of disturbances on the stall cells is investigated by utilizing roughness elements on the airfoil surface, and it is found that while such disturbances tend to change the shape of the stall cells, they do not contribute to the creation, nor destruction of the cells. Polar and visualisation measurements are also used to study flow separation, and it is observed that the separation location, as well as the laminar separation bubble, moves towards the leading edge when increasing the angle of attack. Full article

► Show Figures

Figure 1

18 pages, 10427 KiB

Open AccessArticle

Comparison of Shell and Solid Finite Element Models for the Static Certification Tests of a 43 m Wind Turbine Blade

by Mathijs Peeters, Gilberto Santo, Joris Degroote and Wim Van Paepegem

Energies 2018, 11(6), 1346; https://doi.org/10.3390/en11061346 - 25 May 2018

Cited by 28 | Viewed by 9287

Abstract

A commercial 43 m wind turbine blade was tested under static loads. During these tests, loads, displacements, and local strains were recorded. In this work, the blade was modeled using the finite element method. Both a segment of the spar structure and the [...] Read more.

A commercial 43 m wind turbine blade was tested under static loads. During these tests, loads, displacements, and local strains were recorded. In this work, the blade was modeled using the finite element method. Both a segment of the spar structure and the full-scale blade were modeled. In both cases, conventional outer mold layer shell and layered solid models were created by means of an in-house developed software tool. First, the boundary conditions and settings for modeling the tests were explored. Next, the behavior of a spar segment under different modeling methods was investigated. Finally, the full-scale blade tests were conducted. The resulting displacements and longitudinal and transverse strains were investigated. It was found that for the considered load case, the differences between the shell and solid models are limited. Thus, it is concluded that the shell representation is sufficiently accurate. Full article

► Show Figures

Figure 1

18 pages, 21558 KiB

Open AccessArticle

Comparative Study of the Aerodynamic Performance of the New MEXICO Rotor under Yaw Conditions

by Yaoru Qian, Zhenyu Zhang and Tongguang Wang

Energies 2018, 11(4), 833; https://doi.org/10.3390/en11040833 - 4 Apr 2018

Cited by 22 | Viewed by 4136

Abstract

The influence of yaw misalignment on the aerodynamic performance of the New MEXICO rotor is investigated using blade-resolved Computational Fluid Dynamics (CFD) approaches with three wind speeds considered at a fixed yaw angle of 30 degrees. The air-load predictions and near wake characteristics [...] Read more.

The influence of yaw misalignment on the aerodynamic performance of the New MEXICO rotor is investigated using blade-resolved Computational Fluid Dynamics (CFD) approaches with three wind speeds considered at a fixed yaw angle of 30 degrees. The air-load predictions and near wake characteristics from the numerical results are compared and discussed against the most recent wind tunnel test data. The nacelle impact, dynamic stall phenomenon and wake characteristics are analyzed, demonstrating the yaw effects and numerical issues raised from Reynolds-Averaged Navier Stokes (RANS) and Detached Eddy Simulation (DES) computations. Full article

► Show Figures

Figure 1

19 pages, 592 KiB

Open AccessArticle

Wind Turbine Condition Monitoring Strategy through Multiway PCA and Multivariate Inference

by Francesc Pozo, Yolanda Vidal and Óscar Salgado

Energies 2018, 11(4), 749; https://doi.org/10.3390/en11040749 - 26 Mar 2018

Cited by 45 | Viewed by 4954

Abstract

This article states a condition monitoring strategy for wind turbines using a statistical data-driven modeling approach by means of supervisory control and data acquisition (SCADA) data. Initially, a baseline data-based model is obtained from the healthy wind turbine by means of multiway principal [...] Read more.

This article states a condition monitoring strategy for wind turbines using a statistical data-driven modeling approach by means of supervisory control and data acquisition (SCADA) data. Initially, a baseline data-based model is obtained from the healthy wind turbine by means of multiway principal component analysis (MPCA). Then, when the wind turbine is monitorized, new data is acquired and projected into the baseline MPCA model space. The acquired SCADA data are treated as a random process given the random nature of the turbulent wind. The objective is to decide if the multivariate distribution that is obtained from the wind turbine to be analyzed (healthy or not) is related to the baseline one. To achieve this goal, a test for the equality of population means is performed. Finally, the results of the test can determine that the hypothesis is rejected (and the wind turbine is faulty) or that there is no evidence to suggest that the two means are different, so the wind turbine can be considered as healthy. The methodology is evaluated on a wind turbine fault detection benchmark that uses a 5 MW high-fidelity wind turbine model and a set of eight realistic fault scenarios. It is noteworthy that the results, for the presented methodology, show that for a wide range of significance,

α \in [1 %, 13 %]

, the percentage of correct decisions is kept at 100%; thus it is a promising tool for real-time wind turbine condition monitoring. Full article

► Show Figures

Graphical abstract

24 pages, 6515 KiB

Open AccessArticle

A New Analytical Wake Model for Yawed Wind Turbines

by Guo-Wei Qian and Takeshi Ishihara

Energies 2018, 11(3), 665; https://doi.org/10.3390/en11030665 - 15 Mar 2018

Cited by 103 | Viewed by 10024

Abstract

A new analytical wake model for wind turbines, considering ambient turbulence intensity, thrust coefficient and yaw angle effects, is proposed from numerical and analytical studies. First, eight simulations by the Reynolds Stress Model are conducted for different thrust coefficients, yaw angles and ambient [...] Read more.

A new analytical wake model for wind turbines, considering ambient turbulence intensity, thrust coefficient and yaw angle effects, is proposed from numerical and analytical studies. First, eight simulations by the Reynolds Stress Model are conducted for different thrust coefficients, yaw angles and ambient turbulence intensities. The wake deflection, mean velocity and turbulence intensity in the wakes are systematically investigated. A new wake deflection model is then proposed to analytically predict the wake center trajectory in the yawed condition. Finally, the effects of yaw angle are incorporated in the Gaussian-based wake model. The wake deflection, velocity deficit and added turbulence intensity in the wake predicted by the proposed model show good agreement with the numerical results. The model parameters are determined as the function of ambient turbulence intensity and thrust coefficient, which enables the model to have good applicability under various conditions. Full article

► Show Figures

Figure 1

26 pages, 3625 KiB

Open AccessArticle

Flow Control over the Blunt Trailing Edge of Wind Turbine Airfoils Using Circulation Control

by He-Yong Xu, Qing-Li Dong, Chen-Liang Qiao and Zheng-Yin Ye

Energies 2018, 11(3), 619; https://doi.org/10.3390/en11030619 - 10 Mar 2018

Cited by 12 | Viewed by 5717

Abstract

A new partial circulation control (PCC) method is implemented on the blunt trailing edge DU97-Flatback airfoil, and compared with the traditional full circulation control (FCC) based on numerical analysis. When the Coanda jet is deactivated, PCC has an attractive advantage over FCC, since [...] Read more.

A new partial circulation control (PCC) method is implemented on the blunt trailing edge DU97-Flatback airfoil, and compared with the traditional full circulation control (FCC) based on numerical analysis. When the Coanda jet is deactivated, PCC has an attractive advantage over FCC, since the design of PCC doesn’t degrade aerodynamic characteristics of the baseline flatback section, in contrast to FCC, which is important in practical use in case of failure of the circulation control system. When the Coanda jet is activated, PCC also outperforms FCC in several respects. PCC can produce much higher lift coefficients than FCC over the entire range of angles of attack as well as the entire range of jet momentum coefficients under investigation, but with slightly higher drag coefficients. The flow field of PCC is less complex than that of FCC, indicating less energy dissipation in the main flow and hence less power expenditure for the Coanda jet. The aerodynamic figure of merit (AFM) and control efficiency for circulation control are defined, and results show that PCC has much higher AFM and control efficiency than FCC. It is demonstrated that PCC outperforms FCC in terms of effectiveness, efficiency and reliability for flow control in the blunt trailing edge wind turbine application. Full article

► Show Figures

Figure 1

11 pages, 1531 KiB

Open AccessArticle

On the Evolution of the Integral Time Scale within Wind Farms

by Huiwen Liu, Imran Hayat, Yaqing Jin and Leonardo P. Chamorro

Energies 2018, 11(1), 93; https://doi.org/10.3390/en11010093 - 2 Jan 2018

Cited by 32 | Viewed by 5466

Abstract

A wind-tunnel investigation was carried out to characterize the spatial distribution of the integral time scale (

T^{u}

) within, and in the vicinity of, two model wind farms. The turbine arrays were placed over a rough wall and operated under high [...] Read more.

A wind-tunnel investigation was carried out to characterize the spatial distribution of the integral time scale (

T^{u}

) within, and in the vicinity of, two model wind farms. The turbine arrays were placed over a rough wall and operated under high turbulence. The two layouts consisted of aligned units distinguished only by the streamwise spacing (

{Δ x}_{_{T}}

) between the devices, set at five and ten rotor diameters

d_{T}

(or

S_{x} = Δ x_{_{T}} / d_{T} =

5 and 10). They shared the same spanwise spacing between turbines of 2.5

d_{T}

; this resulted in arrays of 8 × 3 and 5 × 3 horizontal-axis turbines. Hotwire anemometry was used to characterize the instantaneous velocity at various vertical and transverse locations along the central column of the wind farms. Results show that

T^{u}

was modulated by the wind farm layout. It was significantly reduced within the wind farms and right above them, where the internal boundary layer develops. The undisturbed levels above the wind farms were recovered only at ≈

d_{T} / 2

above the top tip. This quantity appeared to reach adjusted values starting the fifth row of turbines in the

S_{x} = 5

wind farm, and earlier in the

S_{x} = 10

counterpart. Within the adjusted zone, the distribution of

T^{u}

at hub height exhibited a negligible growth in the

S_{x} = 5

case; whereas it underwent a mild growth in the

S_{x} = 10

wind farm. In addition, the flow impinging the inner turbines exhibited

T^{u} / T_{i n c}^{u} < 1

, where

T_{i n c}^{u}

is the integral time scale of the overall incoming flow. Specifically,

T^{u} \to β T_{i n c}^{u}

at

z = z_{h u b}

, where

β < 1

within standard layouts of wind farms, in particular

β \approx 0.5

and 0.7 for

S_{x} = 5

and 10. Full article

► Show Figures

Figure 1

2017

Jump to: 2023, 2022, 2021, 2020, 2019, 2018, 2016, 2015, 2014

2529 KiB

Open AccessArticle

Machine Learning for Wind Turbine Blades Maintenance Management

by Alfredo Arcos Jiménez, Carlos Quiterio Gómez Muñoz and Fausto Pedro García Márquez

Energies 2018, 11(1), 13; https://doi.org/10.3390/en11010013 - 21 Dec 2017

Cited by 87 | Viewed by 9431

Abstract

Delamination in Wind Turbine Blades (WTB) is a common structural problem that can generate large costs. Delamination is the separation of layers of a composite material, which produces points of stress concentration. These points suffer greater traction and compression forces in working conditions, [...] Read more.

Delamination in Wind Turbine Blades (WTB) is a common structural problem that can generate large costs. Delamination is the separation of layers of a composite material, which produces points of stress concentration. These points suffer greater traction and compression forces in working conditions, and they can trigger cracks, and partial or total breakage of the blade. Early detection of delamination is crucial for the prevention of breakages and downtime. The main novelty presented in this paper has been to apply an approach for detecting and diagnosing the delamination WTB. The approach is based on signal processing of guided waves, and multiclass pattern recognition using machine learning. Delamination was induced in the WTB to check the accuracy of the approach. The signal is denoised by wavelet transform. The autoregressive Yule–Walker model is employed for feature extraction, and Akaike’s information criterion method for feature selection. The classifiers are quadratic discriminant analysis, k-nearest neighbors, decision trees, and neural network multilayer perceptron. The confusion matrix is employed to evaluate the classification, especially the receiver operating characteristic analysis by: recall, specificity, precision, and F-score. Full article

► Show Figures

Figure 1

23119 KiB

Open AccessEditor’s ChoiceArticle

Flow Adjustment Inside and Around Large Finite-Size Wind Farms

by Ka Ling Wu and Fernando Porté-Agel

Energies 2017, 10(12), 2164; https://doi.org/10.3390/en10122164 - 18 Dec 2017

Cited by 72 | Viewed by 10290

Abstract

In this study, large-eddy simulations are performed to investigate the flow inside and around large finite-size wind farms in conventionally-neutral atmospheric boundary layers. Special emphasis is placed on characterizing the different farm-induced flow regions, including the induction, entrance and development, fully-developed, exit and [...] Read more.

In this study, large-eddy simulations are performed to investigate the flow inside and around large finite-size wind farms in conventionally-neutral atmospheric boundary layers. Special emphasis is placed on characterizing the different farm-induced flow regions, including the induction, entrance and development, fully-developed, exit and farm wake regions. The wind farms extend 20 km in the streamwise direction and comprise 36 wind turbine rows arranged in aligned and staggered configurations. Results show that, under weak free-atmosphere stratification (

Γ = 1

K/km), the flow inside and above both wind farms, and thus the turbine power, do not reach the fully-developed regime even though the farm length is two orders of magnitude larger than the boundary layer height. In that case, the wind farm induction region, affected by flow blockage, extends upwind about 0.8 km and leads to a power reduction of 1.3% and 3% at the first row of turbines for the aligned and staggered layouts, respectively. The wind farm wake leads to velocity deficits at hub height of around 3.5% at a downwind distance of 10 km for both farm layouts. Under stronger stratification (

Γ = 5

K/km), the vertical deflection of the subcritical flow induced by the wind farm at its entrance and exit regions triggers standing gravity waves whose effects propagate upwind. They, in turn, induce a large decelerating induction region upwind of the farm leading edge, and an accelerating exit region upwind of the trailing edge, both extending about 7 km. As a result, the turbine power output in the entrance region decreases more than 35% with respect to the weakly stratified case. It increases downwind as the flow adjusts, reaching the fully-developed regime only for the staggered layout at a distance of about 8.5 km from the farm edge. The flow acceleration in the exit region leads to an increase of the turbine power with downwind distance in that region, and a relatively fast (compared with the weakly stratified case) recovery of the farm wake, which attains its inflow hub height speed at a downwind distance of 5 km. Full article

► Show Figures

Figure 1

Journal Menu

Journal Browser

Wind Turbines

Share This Topical Collection

Editors

Topical Collection Information

Related Special Issues

Published Papers (98 papers)

2023

Jump to: 2022, 2021, 2020, 2019, 2018, 2017, 2016, 2015, 2014

2022

Jump to: 2023, 2021, 2020, 2019, 2018, 2017, 2016, 2015, 2014

2021

Jump to: 2023, 2022, 2020, 2019, 2018, 2017, 2016, 2015, 2014

2020

Jump to: 2023, 2022, 2021, 2019, 2018, 2017, 2016, 2015, 2014

2019

Jump to: 2023, 2022, 2021, 2020, 2018, 2017, 2016, 2015, 2014

2018

Jump to: 2023, 2022, 2021, 2020, 2019, 2017, 2016, 2015, 2014

2017

Jump to: 2023, 2022, 2021, 2020, 2019, 2018, 2016, 2015, 2014
