Open AccessArticle

Head Pose Estimation on Top of Haar-Like Face Detection: A Study Using the Kinect Sensor

by Anwar Saeed, Ayoub Al-Hamadi and Ahmed Ghoneim

Sensors 2015, 15(9), 20945-20966; https://doi.org/10.3390/s150920945 - 26 Aug 2015

Cited by 25 | Viewed by 14061

Abstract

Head pose estimation is a crucial initial task for human face analysis, which is employed in several computer vision systems, such as: facial expression recognition, head gesture recognition, yawn detection, etc. In this work, we propose a frame-based approach to estimate the head [...] Read more.

Head pose estimation is a crucial initial task for human face analysis, which is employed in several computer vision systems, such as: facial expression recognition, head gesture recognition, yawn detection, etc. In this work, we propose a frame-based approach to estimate the head pose on top of the Viola and Jones (VJ) Haar-like face detector. Several appearance and depth-based feature types are employed for the pose estimation, where comparisons between them in terms of accuracy and speed are presented. It is clearly shown through this work that using the depth data, we improve the accuracy of the head pose estimation. Additionally, we can spot positive detections, faces in profile views detected by the frontal model, that are wrongly cropped due to background disturbances. We introduce a new depth-based feature descriptor that provides competitive estimation results with a lower computation time. Evaluation on a benchmark Kinect database shows that the histogram of oriented gradients and the developed depth-based features are more distinctive for the head pose estimation, where they compare favorably to the current state-of-the-art approaches. Using a concatenation of the aforementioned feature types, we achieved a head pose estimation with average errors not exceeding 5:1; 4:6; 4:2 for pitch, yaw and roll angles, respectively. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

23 pages, 2065 KiB

Open AccessArticle

Cost-Effective Hyperspectral Transmissometers for Oceanographic Applications: Performance Analysis

by Marta Ramírez-Pérez, Rüdiger Röttgers, Elena Torrecilla and Jaume Piera

Sensors 2015, 15(9), 20967-20989; https://doi.org/10.3390/s150920967 - 26 Aug 2015

Cited by 11 | Viewed by 6631

Abstract

The recent development of inexpensive, compact hyperspectral transmissometers broadens the research capabilities of oceanographic applications. These developments have been achieved by incorporating technologies such as micro-spectrometers as detectors as well as light emitting diodes (LEDs) as light sources. In this study, we evaluate [...] Read more.

The recent development of inexpensive, compact hyperspectral transmissometers broadens the research capabilities of oceanographic applications. These developments have been achieved by incorporating technologies such as micro-spectrometers as detectors as well as light emitting diodes (LEDs) as light sources. In this study, we evaluate the performance of the new commercial LED-based hyperspectral transmissometer VIPER (TriOS GmbH, Rastede, Germany), which combines different LEDs to emulate the visible light spectrum, aiming at the determination of attenuation coefficients in coastal environments. For this purpose, experimental uncertainties related to the instrument stability, the effect of ambient light and derived temperature, and salinity correction factors are analyzed. Our results identify some issues related to the thermal management of the LEDs and the contamination of ambient light. Furthermore, the performance of VIPER is validated against other transmissometers through simultaneous field measurements. It is demonstrated that VIPER provides a compact and cost-effective alternative for beam attenuation measurements in coastal waters, but it requires the consideration of several optimizations. Full article

(This article belongs to the Section Remote Sensors)

► Show Figures

Figure 1

26 pages, 1186 KiB

Open AccessArticle

Development of a Conductivity Sensor for Monitoring Groundwater Resources to Optimize Water Management in Smart City Environments

by Lorena Parra, Sandra Sendra, Jaime Lloret and Ignacio Bosch

Sensors 2015, 15(9), 20990-21015; https://doi.org/10.3390/s150920990 - 26 Aug 2015

Cited by 78 | Viewed by 10744

Abstract

The main aim of smart cities is to achieve the sustainable use of resources. In order to make the correct use of resources, an accurate monitoring and management is needed. In some places, like underground aquifers, access for monitoring can be difficult, therefore [...] Read more.

The main aim of smart cities is to achieve the sustainable use of resources. In order to make the correct use of resources, an accurate monitoring and management is needed. In some places, like underground aquifers, access for monitoring can be difficult, therefore the use of sensors can be a good solution. Groundwater is very important as a water resource. Just in the USA, aquifers represent the water source for 50% of the population. However, aquifers are endangered due to the contamination. One of the most important parameters to monitor in groundwater is the salinity, as high salinity levels indicate groundwater salinization. In this paper, we present a specific sensor for monitoring groundwater salinization. The sensor is able to measure the electric conductivity of water, which is directly related to the water salinization. The sensor, which is composed of two copper coils, measures the magnetic field alterations due to the presence of electric charges in the water. Different salinities of the water generate different alterations. Our sensor has undergone several tests in order to obtain a conductivity sensor with enough accuracy. First, several prototypes are tested and are compared with the purpose of choosing the best combination of coils. After the best prototype was selected, it was calibrated using up to 30 different samples. Our conductivity sensor presents an operational range from 0.585 mS/cm to 73.8 mS/cm, which is wide enough to cover the typical range of water salinities. With this work, we have demonstrated that it is feasible to measure water conductivity using solenoid coils and that this is a low cost application for groundwater monitoring. Full article

(This article belongs to the Special Issue Sensors and Smart Cities)

► Show Figures

Figure 1

17 pages, 1879 KiB

Open AccessArticle

Recognizing Banknote Fitness with a Visible Light One Dimensional Line Image Sensor

by Tuyen Danh Pham, Young Ho Park, Seung Yong Kwon, Dat Tien Nguyen, Husan Vokhidov, Kang Ryoung Park, Dae Sik Jeong and Sungsoo Yoon

Sensors 2015, 15(9), 21016-21032; https://doi.org/10.3390/s150921016 - 27 Aug 2015

Cited by 13 | Viewed by 5602

Abstract

In general, dirty banknotes that have creases or soiled surfaces should be replaced by new banknotes, whereas clean banknotes should be recirculated. Therefore, the accurate classification of banknote fitness when sorting paper currency is an important and challenging task. Most previous research has [...] Read more.

In general, dirty banknotes that have creases or soiled surfaces should be replaced by new banknotes, whereas clean banknotes should be recirculated. Therefore, the accurate classification of banknote fitness when sorting paper currency is an important and challenging task. Most previous research has focused on sensors that used visible, infrared, and ultraviolet light. Furthermore, there was little previous research on the fitness classification for Indian paper currency. Therefore, we propose a new method for classifying the fitness of Indian banknotes, with a one-dimensional line image sensor that uses only visible light. The fitness of banknotes is usually determined by various factors such as soiling, creases, and tears, etc. although we just consider banknote soiling in our research. This research is novel in the following four ways: first, there has been little research conducted on fitness classification for the Indian Rupee using visible-light images. Second, the classification is conducted based on the features extracted from the regions of interest (ROIs), which contain little texture. Third, 1-level discrete wavelet transformation (DWT) is used to extract the features for discriminating between fit and unfit banknotes. Fourth, the optimal DWT features that represent the fitness and unfitness of banknotes are selected based on linear regression analysis with ground-truth data measured by densitometer. In addition, the selected features are used as the inputs to a support vector machine (SVM) for the final classification of banknote fitness. Experimental results showed that our method outperforms other methods. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

21 pages, 1328 KiB

Open AccessArticle

A Combination of Genetic Algorithm and Particle Swarm Optimization for Vehicle Routing Problem with Time Windows

by Sheng-Hua Xu, Ji-Ping Liu, Fu-Hao Zhang, Liang Wang and Li-Jian Sun

Sensors 2015, 15(9), 21033-21053; https://doi.org/10.3390/s150921033 - 27 Aug 2015

Cited by 54 | Viewed by 8180

Abstract

A combination of genetic algorithm and particle swarm optimization (PSO) for vehicle routing problems with time windows (VRPTW) is proposed in this paper. The improvements of the proposed algorithm include: using the particle real number encoding method to decode the route to alleviate [...] Read more.

A combination of genetic algorithm and particle swarm optimization (PSO) for vehicle routing problems with time windows (VRPTW) is proposed in this paper. The improvements of the proposed algorithm include: using the particle real number encoding method to decode the route to alleviate the computation burden, applying a linear decreasing function based on the number of the iterations to provide balance between global and local exploration abilities, and integrating with the crossover operator of genetic algorithm to avoid the premature convergence and the local minimum. The experimental results show that the proposed algorithm is not only more efficient and competitive with other published results but can also obtain more optimal solutions for solving the VRPTW issue. One new well-known solution for this benchmark problem is also outlined in the following. Full article

► Show Figures

Figure 1

21 pages, 7193 KiB

Open AccessArticle

Saliency-Guided Detection of Unknown Objects in RGB-D Indoor Scenes

by Jiatong Bao, Yunyi Jia, Yu Cheng and Ning Xi

Sensors 2015, 15(9), 21054-21074; https://doi.org/10.3390/s150921054 - 27 Aug 2015

Cited by 22 | Viewed by 8934

Abstract

This paper studies the problem of detecting unknown objects within indoor environments in an active and natural manner. The visual saliency scheme utilizing both color and depth cues is proposed to arouse the interests of the machine system for detecting unknown objects at [...] Read more.

This paper studies the problem of detecting unknown objects within indoor environments in an active and natural manner. The visual saliency scheme utilizing both color and depth cues is proposed to arouse the interests of the machine system for detecting unknown objects at salient positions in a 3D scene. The 3D points at the salient positions are selected as seed points for generating object hypotheses using the 3D shape. We perform multi-class labeling on a Markov random field (MRF) over the voxels of the 3D scene, combining cues from object hypotheses and 3D shape. The results from MRF are further refined by merging the labeled objects, which are spatially connected and have high correlation between color histograms. Quantitative and qualitative evaluations on two benchmark RGB-D datasets illustrate the advantages of the proposed method. The experiments of object detection and manipulation performed on a mobile manipulator validate its effectiveness and practicability in robotic applications. Full article

(This article belongs to the Special Issue Sensors for Indoor Mapping and Navigation)

► Show Figures

Figure 1

24 pages, 639 KiB

Open AccessArticle

Online Doppler Effect Elimination Based on Unequal Time Interval Sampling for Wayside Acoustic Bearing Fault Detecting System

by Kesai Ouyang, Siliang Lu, Shangbin Zhang, Haibin Zhang, Qingbo He and Fanrang Kong

Sensors 2015, 15(9), 21075-21098; https://doi.org/10.3390/s150921075 - 27 Aug 2015

Cited by 9 | Viewed by 5770

Abstract

The railway occupies a fairly important position in transportation due to its high speed and strong transportation capability. As a consequence, it is a key issue to guarantee continuous running and transportation safety of trains. Meanwhile, time consumption of the diagnosis procedure is [...] Read more.

The railway occupies a fairly important position in transportation due to its high speed and strong transportation capability. As a consequence, it is a key issue to guarantee continuous running and transportation safety of trains. Meanwhile, time consumption of the diagnosis procedure is of extreme importance for the detecting system. However, most of the current adopted techniques in the wayside acoustic defective bearing detector system (ADBD) are offline strategies, which means that the signal is analyzed after the sampling process. This would result in unavoidable time latency. Besides, the acquired acoustic signal would be corrupted by the Doppler effect because of high relative speed between the train and the data acquisition system (DAS). Thus, it is difficult to effectively diagnose the bearing defects immediately. In this paper, a new strategy called online Doppler effect elimination (ODEE) is proposed to remove the Doppler distortion online by the introduced unequal interval sampling scheme. The steps of proposed strategy are as follows: The essential parameters are acquired in advance. Then, the introduced unequal time interval sampling strategy is used to restore the Doppler distortion signal, and the amplitude of the signal is demodulated as well. Thus, the restored Doppler-free signal is obtained online. The proposed ODEE method has been employed in simulation analysis. Ultimately, the ODEE method is implemented in the embedded system for fault diagnosis of the train bearing. The results are in good accordance with the bearing defects, which verifies the good performance of the proposed strategy. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

15 pages, 779 KiB

Open AccessArticle

Off-Grid DOA Estimation Using Alternating Block Coordinate Descent in Compressed Sensing

by Weijian Si, Xinggen Qu and Zhiyu Qu

Sensors 2015, 15(9), 21099-21113; https://doi.org/10.3390/s150921099 - 27 Aug 2015

Cited by 7 | Viewed by 4768

Abstract

This paper presents a novel off-grid direction of arrival (DOA) estimation method to achieve the superior performance in compressed sensing (CS), in which DOA estimation problem is cast as a sparse reconstruction. By minimizing the mixed k-l norm, the proposed method [...] Read more.

This paper presents a novel off-grid direction of arrival (DOA) estimation method to achieve the superior performance in compressed sensing (CS), in which DOA estimation problem is cast as a sparse reconstruction. By minimizing the mixed k-l norm, the proposed method can reconstruct the sparse source and estimate grid error caused by mismatch. An iterative process that minimizes the mixed k-l norm alternately over two sparse vectors is employed so that the nonconvex problem is solved by alternating convex optimization. In order to yield the better reconstruction properties, the block sparse source is exploited for off-grid DOA estimation. A block selection criterion is engaged to reduce the computational complexity. In addition, the proposed method is proved to have the global convergence. Simulation results show that the proposed method has the superior performance in comparisons to existing methods. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

20 pages, 2303 KiB

Open AccessArticle

Embedded Vision Sensor Network for Planogram Maintenance in Retail Environments

by Emanuele Frontoni, Adriano Mancini and Primo Zingaretti

Sensors 2015, 15(9), 21114-21133; https://doi.org/10.3390/s150921114 - 27 Aug 2015

Cited by 18 | Viewed by 11025

Abstract

A planogram is a detailed visual map that establishes the position of the products in a retail store. It is designed to supply the best location of a product for suppliers to support an innovative merchandising approach, to increase sales and profits and [...] Read more.

A planogram is a detailed visual map that establishes the position of the products in a retail store. It is designed to supply the best location of a product for suppliers to support an innovative merchandising approach, to increase sales and profits and to better manage the shelves. Deviating from the planogram defeats the purpose of any of these goals, and maintaining the integrity of the planogram becomes a fundamental aspect in retail operations. We propose an embedded system, mainly based on a smart camera, able to detect and to investigate the most important parameters in a retail store by identifying the differences with respect to an “approved” planogram. We propose a new solution that allows concentrating all the surveys and the useful measures on a limited number of devices in communication among them. These devices are simple, low cost and ready for immediate installation, providing an affordable and scalable solution to the problem of planogram maintenance. Moreover, over an Internet of Things (IoT) cloud-based architecture, the system supplies many additional data that are not concerning the planogram, e.g., out-of-shelf events, promptly notified through SMS and/or mail. The application of this project allows the realization of highly integrated systems, which are economical, complete and easy to use for a large number of users. Experimental results have proven that the system can efficiently calculate the deviation from a normal situation by comparing the base planogram image with the images grabbed. Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

Figure 1

19 pages, 1101 KiB

Open AccessArticle

Multi-Sensor Detection with Particle Swarm Optimization for Time-Frequency Coded Cooperative WSNs Based on MC-CDMA for Underground Coal Mines

by Jingjing Xu, Wei Yang, Linyuan Zhang, Ruisong Han and Xiaotao Shao

Sensors 2015, 15(9), 21134-21152; https://doi.org/10.3390/s150921134 - 27 Aug 2015

Cited by 10 | Viewed by 5294

Abstract

In this paper, a wireless sensor network (WSN) technology adapted to underground channel conditions is developed, which has important theoretical and practical value for safety monitoring in underground coal mines. According to the characteristics that the space, time and frequency resources of underground [...] Read more.

In this paper, a wireless sensor network (WSN) technology adapted to underground channel conditions is developed, which has important theoretical and practical value for safety monitoring in underground coal mines. According to the characteristics that the space, time and frequency resources of underground tunnel are open, it is proposed to constitute wireless sensor nodes based on multicarrier code division multiple access (MC-CDMA) to make full use of these resources. To improve the wireless transmission performance of source sensor nodes, it is also proposed to utilize cooperative sensors with good channel conditions from the sink node to assist source sensors with poor channel conditions. Moreover, the total power of the source sensor and its cooperative sensors is allocated on the basis of their channel conditions to increase the energy efficiency of the WSN. To solve the problem that multiple access interference (MAI) arises when multiple source sensors transmit monitoring information simultaneously, a kind of multi-sensor detection (MSD) algorithm with particle swarm optimization (PSO), namely D-PSO, is proposed for the time-frequency coded cooperative MC-CDMA WSN. Simulation results show that the average bit error rate (BER) performance of the proposed WSN in an underground coal mine is improved significantly by using wireless sensor nodes based on MC-CDMA, adopting time-frequency coded cooperative transmission and D-PSO algorithm with particle swarm optimization. Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

Figure 1

16 pages, 1715 KiB

Open AccessArticle

Enhanced Dibutyl Phthalate Sensing Performance of a Quartz Crystal Microbalance Coated with Au-Decorated ZnO Porous Microspheres

by Kaihuan Zhang, Guokang Fan, Ruifen Hu and Guang Li

Sensors 2015, 15(9), 21153-21168; https://doi.org/10.3390/s150921153 - 27 Aug 2015

Cited by 18 | Viewed by 6577

Abstract

Noble metals addition on nanostructured metal oxides is an attractive way to enhance gas sensing properties. Herein, hierarchical zinc oxide (ZnO) porous microspheres decorated with cubic gold particles (Au particles) were synthesized using a facile hydrothermal method. The as-prepared Au-decorated ZnO was then [...] Read more.

Noble metals addition on nanostructured metal oxides is an attractive way to enhance gas sensing properties. Herein, hierarchical zinc oxide (ZnO) porous microspheres decorated with cubic gold particles (Au particles) were synthesized using a facile hydrothermal method. The as-prepared Au-decorated ZnO was then utilized as the sensing film of a gas sensor based on a quartz crystal microbalance (QCM). This fabricated sensor was applied to detect dibutyl phthalate (DBP), which is a widely used plasticizer, and its coating load was optimized. When tested at room temperature, the sensor exhibited a high sensitivity of 38.10 Hz/ppb to DBP in a low concentration range from 2 ppb to 30 ppb and the calculated theoretical detection limit is below 1 ppb. It maintains good repeatability as well as long-term stability. Compared with the undecorated ZnO based QCM, the Au-decorated one achieved a 1.62-time enhancement in sensitivity to DBP, and the selectivity was also improved. According to the experimental results, Au-functionalized ZnO porous microspheres displayed superior sensing performance towards DBP, indicating its potential use in monitoring plasticizers in the gaseous state. Moreover, Au decoration of porous metal oxide nanostructures is proved to be an effective approach for enhancing the gas sensing properties and the corresponding mechanism was investigated. Full article

(This article belongs to the Special Issue Gas Sensors—Designs and Applications)

► Show Figures

Figure 1

27 pages, 2615 KiB

Open AccessArticle

Stochastic Resonance in an Underdamped System with Pinning Potential for Weak Signal Detection

by Haibin Zhang, Qingbo He and Fanrang Kong

Sensors 2015, 15(9), 21169-21195; https://doi.org/10.3390/s150921169 - 28 Aug 2015

Cited by 41 | Viewed by 7875

Abstract

Stochastic resonance (SR) has been proved to be an effective approach for weak sensor signal detection. This study presents a new weak signal detection method based on a SR in an underdamped system, which consists of a pinning potential model. The model was [...] Read more.

Stochastic resonance (SR) has been proved to be an effective approach for weak sensor signal detection. This study presents a new weak signal detection method based on a SR in an underdamped system, which consists of a pinning potential model. The model was firstly discovered from magnetic domain wall (DW) in ferromagnetic strips. We analyze the principle of the proposed underdamped pinning SR (UPSR) system, the detailed numerical simulation and system performance. We also propose the strategy of selecting the proper damping factor and other system parameters to match a weak signal, input noise and to generate the highest output signal-to-noise ratio (SNR). Finally, we have verified its effectiveness with both simulated and experimental input signals. Results indicate that the UPSR performs better in weak signal detection than the conventional SR (CSR) with merits of higher output SNR, better anti-noise and frequency response capability. Besides, the system can be designed accurately and efficiently owing to the sensibility of parameters and potential diversity. The features also weaken the limitation of small parameters on SR system. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

8 pages, 1212 KiB

Open AccessArticle

A CSRR-Fed SIW Cavity-Backed Fractal Patch Antenna for Wireless Energy Harvesting and Communication

by Hailin Cao, Fen Jiang, Jiujiu Liu, Wenbin Cai, Mingchun Tang, Xiaoheng Tan and Shizhong Yang

Sensors 2015, 15(9), 21196-21203; https://doi.org/10.3390/s150921196 - 28 Aug 2015

Cited by 7 | Viewed by 8516

Abstract

This paper presents a novel compact dual-band and dual-polarized complementary split-ring resonator (CSRR)-fed substrate-integrated waveguide (SIW) cavity-backed fractal patch antenna for wireless energy harvesting and communication. The proposed antenna is composed of a Giuseppe Peano fractal radiation patch with a backed SIW cavity. [...] Read more.

This paper presents a novel compact dual-band and dual-polarized complementary split-ring resonator (CSRR)-fed substrate-integrated waveguide (SIW) cavity-backed fractal patch antenna for wireless energy harvesting and communication. The proposed antenna is composed of a Giuseppe Peano fractal radiation patch with a backed SIW cavity. To enhance the bandwidth and minimize the dimensions, the CSRR structure is designed to feed the Giuseppe Peano fractal patch orthogonally. A prototype of the proposed antenna is simulated, fabricated and measured. The proposed antenna exhibits good directionality and high cross-polarization level with especially compact size. Full article

(This article belongs to the Section Remote Sensors)

► Show Figures

Figure 1

15 pages, 661 KiB

Open AccessArticle

vitisFlower^®: Development and Testing of a Novel Android-Smartphone Application for Assessing the Number of Grapevine Flowers per Inflorescence Using Artificial Vision Techniques

by Arturo Aquino, Borja Millan, Daniel Gaston, María-Paz Diago and Javier Tardaguila

Sensors 2015, 15(9), 21204-21218; https://doi.org/10.3390/s150921204 - 28 Aug 2015

Cited by 51 | Viewed by 9340

Abstract

Grapevine flowering and fruit set greatly determine crop yield. This paper presents a new smartphone application for automatically counting, non-invasively and directly in the vineyard, the flower number in grapevine inflorescence photos by implementing artificial vision techniques. The application, called vitisFlower^®, [...] Read more.

Grapevine flowering and fruit set greatly determine crop yield. This paper presents a new smartphone application for automatically counting, non-invasively and directly in the vineyard, the flower number in grapevine inflorescence photos by implementing artificial vision techniques. The application, called vitisFlower^®, firstly guides the user to appropriately take an inflorescence photo using the smartphone’s camera. Then, by means of image analysis, the flowers in the image are detected and counted. vitisFlower^® has been developed for Android devices and uses the OpenCV libraries to maximize computational efficiency. The application was tested on 140 inflorescence images of 11 grapevine varieties taken with two different devices. On average, more than 84% of flowers in the captures were found, with a precision exceeding 94%. Additionally, the application’s efficiency on four different devices covering a wide range of the market’s spectrum was also studied. The results of this benchmarking study showed significant differences among devices, although indicating that the application is efficiently usable even with low-range devices. vitisFlower is one of the first applications for viticulture that is currently freely available on Google Play. Full article

(This article belongs to the Section Remote Sensors)

► Show Figures

Figure 1

20 pages, 1255 KiB

Open AccessArticle

Inferring Human Activity in Mobile Devices by Computing Multiple Contexts

by Ruizhi Chen, Tianxing Chu, Keqiang Liu, Jingbin Liu and Yuwei Chen

Sensors 2015, 15(9), 21219-21238; https://doi.org/10.3390/s150921219 - 28 Aug 2015

Cited by 21 | Viewed by 6317

Abstract

This paper introduces a framework for inferring human activities in mobile devices by computing spatial contexts, temporal contexts, spatiotemporal contexts, and user contexts. A spatial context is a significant location that is defined as a geofence, which can be a node associated with [...] Read more.

This paper introduces a framework for inferring human activities in mobile devices by computing spatial contexts, temporal contexts, spatiotemporal contexts, and user contexts. A spatial context is a significant location that is defined as a geofence, which can be a node associated with a circle, or a polygon; a temporal context contains time-related information that can be e.g., a local time tag, a time difference between geographical locations, or a timespan; a spatiotemporal context is defined as a dwelling length at a particular spatial context; and a user context includes user-related information that can be the user’s mobility contexts, environmental contexts, psychological contexts or social contexts. Using the measurements of the built-in sensors and radio signals in mobile devices, we can snapshot a contextual tuple for every second including aforementioned contexts. Giving a contextual tuple, the framework evaluates the posteriori probability of each candidate activity in real-time using a Naïve Bayes classifier. A large dataset containing 710,436 contextual tuples has been recorded for one week from an experiment carried out at Texas A&M University Corpus Christi with three participants. The test results demonstrate that the multi-context solution significantly outperforms the spatial-context-only solution. A classification accuracy of 61.7% is achieved for the spatial-context-only solution, while 88.8% is achieved for the multi-context solution. Full article

(This article belongs to the Section Remote Sensors)

► Show Figures

Figure 1

15 pages, 1479 KiB

Open AccessArticle

Development of a Small-Sized, Flexible, and Insertable Fiber-Optic Radiation Sensor for Gamma-Ray Spectroscopy

by Wook Jae Yoo, Sang Hun Shin, Dong Eun Lee, Kyoung Won Jang, Seunghyun Cho and Bongsoo Lee

Sensors 2015, 15(9), 21265-21279; https://doi.org/10.3390/s150921265 - 28 Aug 2015

Cited by 19 | Viewed by 13050

Abstract

We fabricated a small-sized, flexible, and insertable fiber-optic radiation sensor (FORS) that is composed of a sensing probe, a plastic optical fiber (POF), a photomultiplier tube (PMT)-amplifier system, and a multichannel analyzer (MCA) to obtain the energy spectra of radioactive isotopes. As an [...] Read more.

We fabricated a small-sized, flexible, and insertable fiber-optic radiation sensor (FORS) that is composed of a sensing probe, a plastic optical fiber (POF), a photomultiplier tube (PMT)-amplifier system, and a multichannel analyzer (MCA) to obtain the energy spectra of radioactive isotopes. As an inorganic scintillator for gamma-ray spectroscopy, a cerium-doped lutetium yttrium orthosilicate (LYSO:Ce) crystal was used and two solid-disc type radioactive isotopes with the same dimensions, cesium-137 (Cs-137) and cobalt-60 (Co-60), were used as gamma-ray emitters. We first determined the length of the LYSO:Ce crystal considering the absorption of charged particle energy and measured the gamma-ray energy spectra using the FORS. The experimental results demonstrated that the proposed FORS can be used to discriminate species of radioactive isotopes by measuring their inherent energy spectra, even when gamma-ray emitters are mixed. The relationship between the measured photon counts of the FORS and the radioactivity of Cs-137 was subsequently obtained. The amount of scintillating light generated from the FORS increased by increasing the radioactivity of Cs-137. Finally, the performance of the fabricated FORS according to the length and diameter of the POF was also evaluated. Based on the results of this study, it is anticipated that a novel FORS can be developed to accurately measure the gamma-ray energy spectrum in inaccessible locations such as narrow areas and holes. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

14 pages, 1194 KiB

Open AccessArticle

A Ratiometric Wavelength Measurement Based on a Silicon-on-Insulator Directional Coupler Integrated Device

by Pengfei Wang, Agus Muhamad Hatta, Haoyu Zhao, Jie Zheng, Gerald Farrell and Gilberto Brambilla

Sensors 2015, 15(9), 21280-21293; https://doi.org/10.3390/s150921280 - 28 Aug 2015

Cited by 6 | Viewed by 7501

Abstract

A ratiometric wavelength measurement based on a Silicon-on-Insulator (SOI) integrated device is proposed and designed, which consists of directional couplers acting as two edge filters with opposite spectral responses. The optimal separation distance between two parallel silicon waveguides and the interaction length of [...] Read more.

A ratiometric wavelength measurement based on a Silicon-on-Insulator (SOI) integrated device is proposed and designed, which consists of directional couplers acting as two edge filters with opposite spectral responses. The optimal separation distance between two parallel silicon waveguides and the interaction length of the directional coupler are designed to meet the desired spectral response by using local supermodes. The wavelength discrimination ability of the designed ratiometric structure is demonstrated by a beam propagation method numerically and then is verified experimentally. The experimental results have shown a general agreement with the theoretical models. The ratiometric wavelength system demonstrates a resolution of better than 50 pm at a wavelength around 1550 nm with ease of assembly and calibration. Full article

(This article belongs to the Special Issue Silicon Based Optical Sensors)

► Show Figures

Figure 1

21 pages, 3389 KiB

Open AccessArticle

Knowledge-Based Query Construction Using the CDSS Knowledge Base for Efficient Evidence Retrieval

by Muhammad Afzal, Maqbool Hussain, Taqdir Ali, Jamil Hussain, Wajahat Ali Khan, Sungyoung Lee and Byeong Ho Kang

Sensors 2015, 15(9), 21294-21314; https://doi.org/10.3390/s150921294 - 28 Aug 2015

Cited by 13 | Viewed by 9823

Abstract

Finding appropriate evidence to support clinical practices is always challenging, and the construction of a query to retrieve such evidence is a fundamental step. Typically, evidence is found using manual or semi-automatic methods, which are time-consuming and sometimes make it difficult to construct [...] Read more.

Finding appropriate evidence to support clinical practices is always challenging, and the construction of a query to retrieve such evidence is a fundamental step. Typically, evidence is found using manual or semi-automatic methods, which are time-consuming and sometimes make it difficult to construct knowledge-based complex queries. To overcome the difficulty in constructing knowledge-based complex queries, we utilized the knowledge base (KB) of the clinical decision support system (CDSS), which has the potential to provide sufficient contextual information. To automatically construct knowledge-based complex queries, we designed methods to parse rule structure in KB of CDSS in order to determine an executable path and extract the terms by parsing the control structures and logic connectives used in the logic. The automatically constructed knowledge-based complex queries were executed on the PubMed search service to evaluate the results on the reduction of retrieved citations with high relevance. The average number of citations was reduced from 56,249 citations to 330 citations with the knowledge-based query construction approach, and relevance increased from 1 term to 6 terms on average. The ability to automatically retrieve relevant evidence maximizes efficiency for clinicians in terms of time, based on feedback collected from clinicians. This approach is generally useful in evidence-based medicine, especially in ambient assisted living environments where automation is highly important. Full article

(This article belongs to the Special Issue Select Papers from UCAmI & IWAAL 2014 – The 8th International Conference on Ubiquitous Computing and Ambient Intelligence & the 6th International Workshop on Ambient Assisted Living (UCAmI & IWAAL 2014: Pervasive Sensing Solutions))

► Show Figures

Graphical abstract

12 pages, 2393 KiB

Open AccessArticle

Field Test of a Remote Multi-Path CLaDS Methane Sensor

by Genevieve Plant, Michal Nikodem, Phil Mulhall, Ruth K. Varner, David Sonnenfroh and Gerard Wysocki

Sensors 2015, 15(9), 21315-21326; https://doi.org/10.3390/s150921315 - 28 Aug 2015

Cited by 26 | Viewed by 6507

Abstract

Existing technologies for quantifying methane emissions are often limited to single point sensors, making large area environmental observations challenging. We demonstrate the operation of a remote, multi-path system using Chirped Laser Dispersion Spectroscopy (CLaDS) for quantification of atmospheric methane concentrations over extended areas, [...] Read more.

Existing technologies for quantifying methane emissions are often limited to single point sensors, making large area environmental observations challenging. We demonstrate the operation of a remote, multi-path system using Chirped Laser Dispersion Spectroscopy (CLaDS) for quantification of atmospheric methane concentrations over extended areas, a technology that shows potential for monitoring emissions from wetlands. Full article

(This article belongs to the Special Issue Chemical Sensors based on In Situ Spectroscopy)

► Show Figures

Graphical abstract

23 pages, 963 KiB

Open AccessArticle

Generalized Parameter-Adjusted Stochastic Resonance of Duffing Oscillator and Its Application to Weak-Signal Detection

by Zhi-Hui Lai and Yong-Gang Leng

Sensors 2015, 15(9), 21327-21349; https://doi.org/10.3390/s150921327 - 28 Aug 2015

Cited by 50 | Viewed by 6273

Abstract

A two-dimensional Duffing oscillator which can produce stochastic resonance (SR) is studied in this paper. We introduce its SR mechanism and present a generalized parameter-adjusted SR (GPASR) model of this oscillator for the necessity of parameter adjustments. The Kramers rate is chosen as [...] Read more.

A two-dimensional Duffing oscillator which can produce stochastic resonance (SR) is studied in this paper. We introduce its SR mechanism and present a generalized parameter-adjusted SR (GPASR) model of this oscillator for the necessity of parameter adjustments. The Kramers rate is chosen as the theoretical basis to establish a judgmental function for judging the occurrence of SR in this model; and to analyze and summarize the parameter-adjusted rules under unmatched signal amplitude, frequency, and/or noise-intensity. Furthermore, we propose the weak-signal detection approach based on this GPASR model. Finally, we employ two practical examples to demonstrate the feasibility of the proposed approach in practical engineering application. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

27 pages, 537 KiB

Open AccessArticle

Efficient, Decentralized Detection of Qualitative Spatial Events in a Dynamic Scalar Field

by Myeong-Hun Jeong and Matt Duckham

Sensors 2015, 15(9), 21350-21376; https://doi.org/10.3390/s150921350 - 28 Aug 2015

Viewed by 5368

Abstract

This paper describes an efficient, decentralized algorithm to monitor qualitative spatial events in a dynamic scalar field. The events of interest involve changes to the critical points (i.e., peak, pits and passes) and edges of the surface network derived from the field. Four [...] Read more.

This paper describes an efficient, decentralized algorithm to monitor qualitative spatial events in a dynamic scalar field. The events of interest involve changes to the critical points (i.e., peak, pits and passes) and edges of the surface network derived from the field. Four fundamental types of event (appearance, disappearance, movement and switch) are defined. Our algorithm is designed to rely purely on qualitative information about the neighborhoods of nodes in the sensor network and does not require information about nodes’ coordinate positions. Experimental investigations confirm that our algorithm is efficient, with O(n) overall communication complexity (where n is the number of nodes in the sensor network), an even load balance and low operational latency. The accuracy of event detection is comparable to established centralized algorithms for the identification of critical points of a surface network. Our algorithm is relevant to a broad range of environmental monitoring applications of sensor networks. Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

Figure 1

17 pages, 3175 KiB

Open AccessArticle

Received Signal Strength Database Interpolation by Kriging for a Wi-Fi Indoor Positioning System

by Shau-Shiun Jan, Shuo-Ju Yeh and Ya-Wen Liu

Sensors 2015, 15(9), 21377-21393; https://doi.org/10.3390/s150921377 - 28 Aug 2015

Cited by 64 | Viewed by 7900

Abstract

The main approach for a Wi-Fi indoor positioning system is based on the received signal strength (RSS) measurements, and the fingerprinting method is utilized to determine the user position by matching the RSS values with the pre-surveyed RSS database. To build a RSS [...] Read more.

The main approach for a Wi-Fi indoor positioning system is based on the received signal strength (RSS) measurements, and the fingerprinting method is utilized to determine the user position by matching the RSS values with the pre-surveyed RSS database. To build a RSS fingerprint database is essential for an RSS based indoor positioning system, and building such a RSS fingerprint database requires lots of time and effort. As the range of the indoor environment becomes larger, labor is increased. To provide better indoor positioning services and to reduce the labor required for the establishment of the positioning system at the same time, an indoor positioning system with an appropriate spatial interpolation method is needed. In addition, the advantage of the RSS approach is that the signal strength decays as the transmission distance increases, and this signal propagation characteristic is applied to an interpolated database with the Kriging algorithm in this paper. Using the distribution of reference points (RPs) at measured points, the signal propagation model of the Wi-Fi access point (AP) in the building can be built and expressed as a function. The function, as the spatial structure of the environment, can create the RSS database quickly in different indoor environments. Thus, in this paper, a Wi-Fi indoor positioning system based on the Kriging fingerprinting method is developed. As shown in the experiment results, with a 72.2% probability, the error of the extended RSS database with Kriging is less than 3 dBm compared to the surveyed RSS database. Importantly, the positioning error of the developed Wi-Fi indoor positioning system with Kriging is reduced by 17.9% in average than that without Kriging. Full article

(This article belongs to the Special Issue Sensors for Indoor Mapping and Navigation)

► Show Figures

Figure 1

13 pages, 2263 KiB

Open AccessArticle

Transferring Data from Smartwatch to Smartphone through Mechanical Wave Propagation

by Seung-Chan Kim and Soo-Chul Lim

Sensors 2015, 15(9), 21394-21406; https://doi.org/10.3390/s150921394 - 28 Aug 2015

Cited by 5 | Viewed by 6296

Abstract

Inspired by the mechanisms of bone conduction transmission, we present a novel sensor and actuation system that enables a smartwatch to securely communicate with a peripheral touch device, such as a smartphone. Our system regards hand structures as a mechanical waveguide that transmits [...] Read more.

Inspired by the mechanisms of bone conduction transmission, we present a novel sensor and actuation system that enables a smartwatch to securely communicate with a peripheral touch device, such as a smartphone. Our system regards hand structures as a mechanical waveguide that transmits particular signals through mechanical waves. As a signal, we used high-frequency vibrations (18.0–20.0 kHz) so that users cannot sense the signals either tactually or audibly. To this end, we adopted a commercial surface transducer, which is originally developed as a bone-conduction actuator, for mechanical signal generation. At the receiver side, a piezoelement was adopted for picking up the transferred mechanical signals. Experimental results have shown that the proposed system can successfully transfer data using mechanical waves. We also validate dual-frequency actuations under which high-frequency signals (18.0–20.0 kHz) are generated along with low-frequency (up to 250 Hz) haptic vibrations. The proposed method has advantages in terms of security in that it does not reveal the signals outside the body, meaning that it is not possible for attackers to eavesdrop on the signals. To further illustrate the possible application spaces, we conclude with explorations of the proposed approach. Full article

(This article belongs to the Section Biosensors)

► Show Figures

Figure 1

20 pages, 1906 KiB

Open AccessArticle

Illumination and Reflectance Estimation with its Application in Foreground Detection

by Gang Jun Tu, Henrik Karstoft, Lene Juul Pedersen and Erik Jørgensen

Sensors 2015, 15(9), 21407-21426; https://doi.org/10.3390/s150921407 - 28 Aug 2015

Cited by 21 | Viewed by 6368

Abstract

In this paper, we introduce a novel approach to estimate the illumination and reflectance of an image. The approach is based on illumination-reflectance model and wavelet theory. We use a homomorphic wavelet filter (HWF) and define a wavelet quotient image (WQI) model based [...] Read more.

In this paper, we introduce a novel approach to estimate the illumination and reflectance of an image. The approach is based on illumination-reflectance model and wavelet theory. We use a homomorphic wavelet filter (HWF) and define a wavelet quotient image (WQI) model based on dyadic wavelet transform. The illumination and reflectance components are estimated by using HWF and WQI, respectively. Based on the illumination and reflectance estimation we develop an algorithm to segment sows in grayscale video recordings which are captured in complex farrowing pens. Experimental results demonstrate that the algorithm can be applied to detect the domestic animals in complex environments such as light changes, motionless foreground objects and dynamic background. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

22 pages, 312 KiB

Open AccessArticle

Optimized ECC Implementation for Secure Communication between Heterogeneous IoT Devices

by Leandro Marin, Marcin Piotr Pawlowski and Antonio Jara

Sensors 2015, 15(9), 21478-21499; https://doi.org/10.3390/s150921478 - 28 Aug 2015

Cited by 55 | Viewed by 8850

Abstract

The Internet of Things is integrating information systems, places, users and billions of constrained devices into one global network. This network requires secure and private means of communications. The building blocks of the Internet of Things are devices manufactured by various producers and [...] Read more.

The Internet of Things is integrating information systems, places, users and billions of constrained devices into one global network. This network requires secure and private means of communications. The building blocks of the Internet of Things are devices manufactured by various producers and are designed to fulfil different needs. There would be no common hardware platform that could be applied in every scenario. In such a heterogeneous environment, there is a strong need for the optimization of interoperable security. We present optimized elliptic curve Cryptography algorithms that address the security issues in the heterogeneous IoT networks. We have combined cryptographic algorithms for the NXP/Jennic 5148- and MSP430-based IoT devices and used them to created novel key negotiation protocol. Full article

(This article belongs to the Special Issue Select Papers from UCAmI & IWAAL 2014 – The 8th International Conference on Ubiquitous Computing and Ambient Intelligence & the 6th International Workshop on Ambient Assisted Living (UCAmI & IWAAL 2014: Pervasive Sensing Solutions))

► Show Figures

Figure 1

18 pages, 1643 KiB

Open AccessArticle

Mach-Zehnder Interferometer Biochemical Sensor Based on Silicon-on-Insulator Rib Waveguide with Large Cross Section

by Dengpeng Yuan, Ying Dong, Yujin Liu and Tianjian Li

Sensors 2015, 15(9), 21500-21517; https://doi.org/10.3390/s150921500 - 28 Aug 2015

Cited by 55 | Viewed by 16222

Abstract

A high-sensitivity Mach-Zehnder interferometer (MZI) biochemical sensing platform based on Silicon-in-insulator (SOI) rib waveguide with large cross section is proposed in this paper. Based on the analyses of the evanescent field intensity, the mode polarization and cross section dimensions of the SOI rib [...] Read more.

A high-sensitivity Mach-Zehnder interferometer (MZI) biochemical sensing platform based on Silicon-in-insulator (SOI) rib waveguide with large cross section is proposed in this paper. Based on the analyses of the evanescent field intensity, the mode polarization and cross section dimensions of the SOI rib waveguide are optimized through finite difference method (FDM) simulation. To realize high-resolution MZI read-out configuration based on the SOI rib waveguide, medium-filled trenches are employed and their performances are simulated through two-dimensional finite-difference-time domain (2D-FDTD) method. With the fundamental EH-polarized mode of the SOI rib waveguide with a total rib height of 10 μm, an outside rib height of 5 μm and a rib width of 2.5 μm at the operating wavelength of 1550 nm, when the length of the sensitive window in the MZI configuration is 10 mm, a homogeneous sensitivity of 7296.6%/refractive index unit (RIU) is obtained. Supposing the resolutions of the photoelectric detectors connected to the output ports are 0.2%, the MZI sensor can achieve a detection limit of 2.74 × 10⁻⁶ RIU. Due to high coupling efficiency of SOI rib waveguide with large cross section with standard single-mode glass optical fiber, the proposed MZI sensing platform can be conveniently integrated with optical fiber communication systems and (opto-) electronic systems, and therefore has the potential to realize remote sensing, in situ real-time detecting, and possible applications in the internet of things. Full article

(This article belongs to the Special Issue Micro-Optical Sensors)

► Show Figures

Figure 1

19 pages, 6081 KiB

Open AccessArticle

Heading Estimation for Indoor Pedestrian Navigation Using a Smartphone in the Pocket

by Zhi-An Deng, Guofeng Wang, Ying Hu and Di Wu

Sensors 2015, 15(9), 21518-21536; https://doi.org/10.3390/s150921518 - 28 Aug 2015

Cited by 113 | Viewed by 9337

Abstract

Heading estimation is a central problem for indoor pedestrian navigation using the pervasively available smartphone. For smartphones placed in a pocket, one of the most popular device positions, the essential challenges in heading estimation are the changing device coordinate system and the severe [...] Read more.

Heading estimation is a central problem for indoor pedestrian navigation using the pervasively available smartphone. For smartphones placed in a pocket, one of the most popular device positions, the essential challenges in heading estimation are the changing device coordinate system and the severe indoor magnetic perturbations. To address these challenges, we propose a novel heading estimation approach based on a rotation matrix and principal component analysis (PCA). Firstly, through a related rotation matrix, we project the acceleration signals into a reference coordinate system (RCS), where a more accurate estimation of the horizontal plane of the acceleration signal is obtained. Then, we utilize PCA over the horizontal plane of acceleration signals for local walking direction extraction. Finally, in order to translate the local walking direction into the global one, we develop a calibration process without requiring noisy compass readings. Besides, a turn detection algorithm is proposed to improve the heading estimation accuracy. Experimental results show that our approach outperforms the traditional uDirect and PCA-based approaches in terms of accuracy and feasibility. Full article

(This article belongs to the Special Issue Sensors for Indoor Mapping and Navigation)

► Show Figures

Figure 1

17 pages, 1837 KiB

Open AccessArticle

A Dynamic Navigation Model for Unmanned Aircraft Systems and an Application to Autonomous Front-On Environmental Sensing and Photography Using Low-Cost Sensor Systems

by Andrew James Cooper, Chelsea Anne Redman, David Mark Stoneham, Luis Felipe Gonzalez and Victor Kwesi Etse

Sensors 2015, 15(9), 21537-21553; https://doi.org/10.3390/s150921537 - 28 Aug 2015

Cited by 11 | Viewed by 6183

Abstract

This paper presents an unmanned aircraft system (UAS) that uses a probabilistic model for autonomous front-on environmental sensing or photography of a target. The system is based on low-cost and readily-available sensor systems in dynamic environments and with the general intent of improving [...] Read more.

This paper presents an unmanned aircraft system (UAS) that uses a probabilistic model for autonomous front-on environmental sensing or photography of a target. The system is based on low-cost and readily-available sensor systems in dynamic environments and with the general intent of improving the capabilities of dynamic waypoint-based navigation systems for a low-cost UAS. The behavioural dynamics of target movement for the design of a Kalman filter and Markov model-based prediction algorithm are included. Geometrical concepts and the Haversine formula are applied to the maximum likelihood case in order to make a prediction regarding a future state of a target, thus delivering a new waypoint for autonomous navigation. The results of the application to aerial filming with low-cost UAS are presented, achieving the desired goal of maintained front-on perspective without significant constraint to the route or pace of target movement. Full article

(This article belongs to the Section Remote Sensors)

► Show Figures

Figure 1

13 pages, 11797 KiB

Open AccessArticle

0.5 V and 0.43 pJ/bit Capacitive Sensor Interface for Passive Wireless Sensor Systems

by Andoni Beriain, Iñigo Gutierrez, Hector Solar and Roc Berenguer

Sensors 2015, 15(9), 21554-21566; https://doi.org/10.3390/s150921554 - 28 Aug 2015

Cited by 8 | Viewed by 4950

Abstract

This paper presents an ultra low-power and low-voltage pulse-width modulation based ratiometric capacitive sensor interface. The interface was designed and fabricated in a standard 90 nm CMOS 1P9M technology. The measurements show an effective resolution of 10 bits using 0.5 V of supply [...] Read more.

This paper presents an ultra low-power and low-voltage pulse-width modulation based ratiometric capacitive sensor interface. The interface was designed and fabricated in a standard 90 nm CMOS 1P9M technology. The measurements show an effective resolution of 10 bits using 0.5 V of supply voltage. The active occupied area is only 0.0045 mm2 and the Figure of Merit (FOM), which takes into account the energy required per conversion bit, is 0.43 pJ/bit. Furthermore, the results show low sensitivity to PVT variations due to the proposed ratiometric architecture. In addition, the sensor interface was connected to a commercial pressure transducer and the measurements of the resulting complete pressure sensor show a FOM of 0.226 pJ/bit with an effective linear resolution of 7.64 bits. The results validate the use of the proposed interface as part of a pressure sensor, and its low-power and low-voltage characteristics make it suitable for wireless sensor networks and low power consumer electronics. Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

Figure 1

14 pages, 3305 KiB

Open AccessArticle

Low-Actuation Voltage MEMS Digital-to-Analog Converter with Parylene Spring Structures

by Cheng-Wen Ma, Fu-Wei Lee, Hsin-Hung Liao, Wen-Cheng Kuo and Yao-Joe Yang

Sensors 2015, 15(9), 21567-21580; https://doi.org/10.3390/s150921567 - 28 Aug 2015

Cited by 4 | Viewed by 4915

Abstract

We propose an electrostatically-actuated microelectromechanical digital-to-analog converter (M-DAC) device with low actuation voltage. The spring structures of the silicon-based M-DAC device were monolithically fabricated using parylene-C. Because the Young’s modulus of parylene-C is considerably lower than that of silicon, the electrostatic microactuators in [...] Read more.

We propose an electrostatically-actuated microelectromechanical digital-to-analog converter (M-DAC) device with low actuation voltage. The spring structures of the silicon-based M-DAC device were monolithically fabricated using parylene-C. Because the Young’s modulus of parylene-C is considerably lower than that of silicon, the electrostatic microactuators in the proposed device require much lower actuation voltages. The actuation voltage of the proposed M-DAC device is approximately 6 V, which is less than one half of the actuation voltages of a previously reported M-DAC equipped with electrostatic microactuators. The measured total displacement of the proposed three-bit M-DAC is nearly 504 nm, and the motion step is approximately 72 nm. Furthermore, we demonstrated that the M-DAC can be employed as a mirror platform with discrete displacement output for a noncontact surface profiling system. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

32 pages, 4980 KiB

Open AccessArticle

Adaptive Correlation Space Adjusted Open-Loop Tracking Approach for Vehicle Positioning with Global Navigation Satellite System in Urban Areas

by Hang Ruan, Jian Li, Lei Zhang and Teng Long

Sensors 2015, 15(9), 21581-21612; https://doi.org/10.3390/s150921581 - 28 Aug 2015

Cited by 9 | Viewed by 4964

Abstract

For vehicle positioning with Global Navigation Satellite System (GNSS) in urban areas, open-loop tracking shows better performance because of its high sensitivity and superior robustness against multipath. However, no previous study has focused on the effects of the code search grid size on [...] Read more.

For vehicle positioning with Global Navigation Satellite System (GNSS) in urban areas, open-loop tracking shows better performance because of its high sensitivity and superior robustness against multipath. However, no previous study has focused on the effects of the code search grid size on the code phase measurement accuracy of open-loop tracking. Traditional open-loop tracking methods are performed by the batch correlators with fixed correlation space. The code search grid size, which is the correlation space, is a constant empirical value and the code phase measuring accuracy will be largely degraded due to the improper grid size, especially when the signal carrier-to-noise density ratio (C/N₀) varies. In this study, the Adaptive Correlation Space Adjusted Open-Loop Tracking Approach (ACSA-OLTA) is proposed to improve the code phase measurement dependent pseudo range accuracy. In ACSA-OLTA, the correlation space is adjusted according to the signal C/N₀. The novel Equivalent Weighted Pseudo Range Error (EWPRE) is raised to obtain the optimal code search grid sizes for different C/N₀. The code phase measuring errors of different measurement calculation methods are analyzed for the first time. The measurement calculation strategy of ACSA-OLTA is derived from the analysis to further improve the accuracy but reduce the correlator consumption. Performance simulation and real tests confirm that the pseudo range and positioning accuracy of ASCA-OLTA are better than the traditional open-loop tracking methods in the usual scenarios of urban area. Full article

(This article belongs to the Section Remote Sensors)

► Show Figures

Figure 1

24 pages, 2341 KiB

Open AccessArticle

A Probabilistic Feature Map-Based Localization System Using a Monocular Camera

by Hyungjin Kim, Donghwa Lee, Taekjun Oh, Hyun-Taek Choi and Hyun Myung

Sensors 2015, 15(9), 21636-21659; https://doi.org/10.3390/s150921636 - 31 Aug 2015

Cited by 17 | Viewed by 7833

Abstract

Image-based localization is one of the most widely researched localization techniques in the robotics and computer vision communities. As enormous image data sets are provided through the Internet, many studies on estimating a location with a pre-built image-based 3D map have been conducted. [...] Read more.

Image-based localization is one of the most widely researched localization techniques in the robotics and computer vision communities. As enormous image data sets are provided through the Internet, many studies on estimating a location with a pre-built image-based 3D map have been conducted. Most research groups use numerous image data sets that contain sufficient features. In contrast, this paper focuses on image-based localization in the case of insufficient images and features. A more accurate localization method is proposed based on a probabilistic map using 3D-to-2D matching correspondences between a map and a query image. The probabilistic feature map is generated in advance by probabilistic modeling of the sensor system as well as the uncertainties of camera poses. Using the conventional PnP algorithm, an initial camera pose is estimated on the probabilistic feature map. The proposed algorithm is optimized from the initial pose by minimizing Mahalanobis distance errors between features from the query image and the map to improve accuracy. To verify that the localization accuracy is improved, the proposed algorithm is compared with the conventional algorithm in a simulation and realenvironments Full article

(This article belongs to the Special Issue Sensors for Indoor Mapping and Navigation)

► Show Figures

Figure 1

13 pages, 2464 KiB

Open AccessArticle

Unmasking of Olive Oil Adulteration Via a Multi-Sensor Platform

by Marco Santonico, Simone Grasso, Francesco Genova, Alessandro Zompanti, Francesca Romana Parente and Giorgio Pennazza

Sensors 2015, 15(9), 21660-21672; https://doi.org/10.3390/s150921660 - 31 Aug 2015

Cited by 22 | Viewed by 6394

Abstract

Methods for the chemical and sensorial evaluation of olive oil are frequently changed and tuned to oppose the increasingly sophisticated frauds. Although a plethora of promising alternatives has been developed, chromatographic techniques remain the more reliable yet, even at the expense of their [...] Read more.

Methods for the chemical and sensorial evaluation of olive oil are frequently changed and tuned to oppose the increasingly sophisticated frauds. Although a plethora of promising alternatives has been developed, chromatographic techniques remain the more reliable yet, even at the expense of their related execution time and costs. In perspective of a continuous increment in the number of the analyses as a result of the global market, more rapid and effective methods to guarantee the safety of the olive oil trade are required. In this study, a novel artificial sensorial system, based on gas and liquid analysis, has been employed to deal with olive oil genuineness and authenticity issues. Despite these sensors having been widely used in the field of food science, the innovative electronic interface of the device is able to provide a higher reproducibility and sensitivity of the analysis. The multi-parametric platform demonstrated the capability to evaluate the organoleptic properties of extra-virgin olive oils as well as to highlight the presence of adulterants at blending concentrations usually not detectable through other methods. Full article

(This article belongs to the Special Issue Sensors for Food Safety and Quality)

► Show Figures

Figure 1

14 pages, 1820 KiB

Open AccessArticle

Structural Stability Monitoring of a Physical Model Test on an Underground Cavern Group during Deep Excavations Using FBG Sensors

by Yong Li, Hanpeng Wang, Weishen Zhu, Shucai Li and Jian Liu

Sensors 2015, 15(9), 21696-21709; https://doi.org/10.3390/s150921696 - 31 Aug 2015

Cited by 25 | Viewed by 6631

Abstract

Fiber Bragg Grating (FBG) sensors are comprehensively recognized as a structural stability monitoring device for all kinds of geo-materials by either embedding into or bonding onto the structural entities. The physical model in geotechnical engineering, which could accurately simulate the construction processes and [...] Read more.

Fiber Bragg Grating (FBG) sensors are comprehensively recognized as a structural stability monitoring device for all kinds of geo-materials by either embedding into or bonding onto the structural entities. The physical model in geotechnical engineering, which could accurately simulate the construction processes and the effects on the stability of underground caverns on the basis of satisfying the similarity principles, is an actual physical entity. Using a physical model test of underground caverns in Shuangjiangkou Hydropower Station, FBG sensors were used to determine how to model the small displacements of some key monitoring points in the large-scale physical model during excavation. In the process of building the test specimen, it is most successful to embed FBG sensors in the physical model through making an opening and adding some quick-set silicon. The experimental results show that the FBG sensor has higher measuring accuracy than other conventional sensors like electrical resistance strain gages and extensometers. The experimental results are also in good agreement with the numerical simulation results. In conclusion, FBG sensors could effectively measure small displacements of monitoring points in the whole process of the physical model test. The experimental results reveal the deformation and failure characteristics of the surrounding rock mass and make some guidance for the in situ engineering construction. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

14 pages, 1328 KiB

Open AccessArticle

Time-Resolved Synchronous Fluorescence for Biomedical Diagnosis

by Xiaofeng Zhang, Andrew Fales and Tuan Vo-Dinh

Sensors 2015, 15(9), 21746-21759; https://doi.org/10.3390/s150921746 - 31 Aug 2015

Cited by 10 | Viewed by 8696

Abstract

This article presents our most recent advances in synchronous fluorescence (SF) methodology for biomedical diagnostics. The SF method is characterized by simultaneously scanning both the excitation and emission wavelengths while keeping a constant wavelength interval between them. Compared to conventional fluorescence spectroscopy, the [...] Read more.

This article presents our most recent advances in synchronous fluorescence (SF) methodology for biomedical diagnostics. The SF method is characterized by simultaneously scanning both the excitation and emission wavelengths while keeping a constant wavelength interval between them. Compared to conventional fluorescence spectroscopy, the SF method simplifies the emission spectrum while enabling greater selectivity, and has been successfully used to detect subtle differences in the fluorescence emission signatures of biochemical species in cells and tissues. The SF method can be used in imaging to analyze dysplastic cells in vitro and tissue in vivo. Based on the SF method, here we demonstrate the feasibility of a time-resolved synchronous fluorescence (TRSF) method, which incorporates the intrinsic fluorescent decay characteristics of the fluorophores. Our prototype TRSF system has clearly shown its advantage in spectro-temporal separation of the fluorophores that were otherwise difficult to spectrally separate in SF spectroscopy. We envision that our previously-tested SF imaging and the newly-developed TRSF methods will combine their proven diagnostic potentials in cancer diagnosis to further improve the efficacy of SF-based biomedical diagnostics. Full article

(This article belongs to the Special Issue Imaging: Sensors and Technologies)

► Show Figures

Figure 1

25 pages, 2455 KiB

Open AccessArticle

Developing Mixed Reality Educational Applications: The Virtual Touch Toolkit

by Juan Mateu, María José Lasala and Xavier Alamán

Sensors 2015, 15(9), 21760-21784; https://doi.org/10.3390/s150921760 - 31 Aug 2015

Cited by 30 | Viewed by 8858

Abstract

In this paper, we present Virtual Touch, a toolkit that allows the development of educational activities through a mixed reality environment such that, using various tangible elements, the interconnection of a virtual world with the real world is enabled. The main goal of [...] Read more.

In this paper, we present Virtual Touch, a toolkit that allows the development of educational activities through a mixed reality environment such that, using various tangible elements, the interconnection of a virtual world with the real world is enabled. The main goal of Virtual Touch is to facilitate the installation, configuration and programming of different types of technologies, abstracting the creator of educational applications from the technical details involving the use of tangible interfaces and virtual worlds. Therefore, it is specially designed to enable teachers to themselves create educational activities for their students in a simple way, taking into account that teachers generally lack advanced knowledge in computer programming and electronics. The toolkit has been used to develop various educational applications that have been tested in two secondary education high schools in Spain. Full article

(This article belongs to the Special Issue Select Papers from UCAmI & IWAAL 2014 – The 8th International Conference on Ubiquitous Computing and Ambient Intelligence & the 6th International Workshop on Ambient Assisted Living (UCAmI & IWAAL 2014: Pervasive Sensing Solutions))

► Show Figures

Figure 1

22 pages, 3392 KiB

Open AccessArticle

Numerical Modeling and Experimental Validation by Calorimetric Detection of Energetic Materials Using Thermal Bimorph Microcantilever Array: A Case Study on Sensing Vapors of Volatile Organic Compounds (VOCs)

by Seok-Won Kang, Joe Fragala and Debjyoti Banerjee

Sensors 2015, 15(9), 21785-21806; https://doi.org/10.3390/s150921785 - 31 Aug 2015

Cited by 4 | Viewed by 7651

Abstract

Bi-layer (Au-Si₃N₄) microcantilevers fabricated in an array were used to detect vapors of energetic materials such as explosives under ambient conditions. The changes in the bending response of each thermal bimorph (i.e., microcantilever) with changes in actuation [...] Read more.

Bi-layer (Au-Si₃N₄) microcantilevers fabricated in an array were used to detect vapors of energetic materials such as explosives under ambient conditions. The changes in the bending response of each thermal bimorph (i.e., microcantilever) with changes in actuation currents were experimentally monitored by measuring the angle of the reflected ray from a laser source used to illuminate the gold nanocoating on the surface of silicon nitride microcantilevers in the absence and presence of a designated combustible species. Experiments were performed to determine the signature response of this nano-calorimeter platform for each explosive material considered for this study. Numerical modeling was performed to predict the bending response of the microcantilevers for various explosive materials, species concentrations, and actuation currents. The experimental validation of the numerical predictions demonstrated that in the presence of different explosive or combustible materials, the microcantilevers exhibited unique trends in their bending responses with increasing values of the actuation current. Full article

(This article belongs to the Special Issue Gas Sensors—Designs and Applications)

► Show Figures

Graphical abstract

17 pages, 984 KiB

Open AccessArticle

Initial Alignment of Large Azimuth Misalignment Angles in SINS Based on Adaptive UPF

by Jin Sun, Xiao-Su Xu, Yi-Ting Liu, Tao Zhang and Yao Li

Sensors 2015, 15(9), 21807-21823; https://doi.org/10.3390/s150921807 - 31 Aug 2015

Cited by 38 | Viewed by 6288

Abstract

The case of large azimuth misalignment angles in a strapdown inertial navigation system (SINS) is analyzed, and a method of using the adaptive UPF for the initial alignment is proposed. The filter is based on the idea of a strong tracking filter; through [...] Read more.

The case of large azimuth misalignment angles in a strapdown inertial navigation system (SINS) is analyzed, and a method of using the adaptive UPF for the initial alignment is proposed. The filter is based on the idea of a strong tracking filter; through the introduction of the attenuation memory factor to effectively enhance the corrections of the current information residual error on the system, it reduces the influence on the system due to the system simplification, and the uncertainty of noise statistical properties to a certain extent; meanwhile, the UPF particle degradation phenomenon is better overcome. Finally, two kinds of non-linear filters, UPF and adaptive UPF, are adopted in the initial alignment of large azimuth misalignment angles in SINS, and the filtering effects of the two kinds of nonlinear filter on the initial alignment were compared by simulation and turntable experiments. The simulation and turntable experiment results show that the speed and precision of the initial alignment using adaptive UPF for a large azimuth misalignment angle in SINS under the circumstance that the statistical properties of the system noise are certain or not have been improved to some extent. Full article

(This article belongs to the Special Issue Inertial Sensors and Systems)

► Show Figures

Figure 1

20 pages, 766 KiB

Open AccessArticle

An Improved WiFi Indoor Positioning Algorithm by Weighted Fusion

by Rui Ma, Qiang Guo, Changzhen Hu and Jingfeng Xue

Sensors 2015, 15(9), 21824-21843; https://doi.org/10.3390/s150921824 - 31 Aug 2015

Cited by 128 | Viewed by 11796

Abstract

The rapid development of mobile Internet has offered the opportunity for WiFi indoor positioning to come under the spotlight due to its low cost. However, nowadays the accuracy of WiFi indoor positioning cannot meet the demands of practical applications. To solve this problem, [...] Read more.

The rapid development of mobile Internet has offered the opportunity for WiFi indoor positioning to come under the spotlight due to its low cost. However, nowadays the accuracy of WiFi indoor positioning cannot meet the demands of practical applications. To solve this problem, this paper proposes an improved WiFi indoor positioning algorithm by weighted fusion. The proposed algorithm is based on traditional location fingerprinting algorithms and consists of two stages: the offline acquisition and the online positioning. The offline acquisition process selects optimal parameters to complete the signal acquisition, and it forms a database of fingerprints by error classification and handling. To further improve the accuracy of positioning, the online positioning process first uses a pre-match method to select the candidate fingerprints to shorten the positioning time. After that, it uses the improved Euclidean distance and the improved joint probability to calculate two intermediate results, and further calculates the final result from these two intermediate results by weighted fusion. The improved Euclidean distance introduces the standard deviation of WiFi signal strength to smooth the WiFi signal fluctuation and the improved joint probability introduces the logarithmic calculation to reduce the difference between probability values. Comparing the proposed algorithm, the Euclidean distance based WKNN algorithm and the joint probability algorithm, the experimental results indicate that the proposed algorithm has higher positioning accuracy. Full article

(This article belongs to the Special Issue Sensors for Indoor Mapping and Navigation)

► Show Figures

Figure 1

13 pages, 1002 KiB

Open AccessArticle

An Insertable Passive LC Pressure Sensor Based on an Alumina Ceramic for In Situ Pressure Sensing in High-Temperature Environments

by Jijun Xiong, Chen Li, Pinggang Jia, Xiaoyong Chen, Wendong Zhang, Jun Liu, Chenyang Xue and Qiulin Tan

Sensors 2015, 15(9), 21844-21856; https://doi.org/10.3390/s150921844 - 31 Aug 2015

Cited by 12 | Viewed by 6565

Abstract

Pressure measurements in high-temperature applications, including compressors, turbines, and others, have become increasingly critical. This paper proposes an implantable passive LC pressure sensor based on an alumina ceramic material for in situ pressure sensing in high-temperature environments. The inductance and capacitance elements of [...] Read more.

Pressure measurements in high-temperature applications, including compressors, turbines, and others, have become increasingly critical. This paper proposes an implantable passive LC pressure sensor based on an alumina ceramic material for in situ pressure sensing in high-temperature environments. The inductance and capacitance elements of the sensor were designed independently and separated by a thermally insulating material, which is conducive to reducing the influence of the temperature on the inductance element and improving the quality factor of the sensor. In addition, the sensor was fabricated using thick film integrated technology from high-temperature materials that ensure stable operation of the sensor in high-temperature environments. Experimental results showed that the sensor accurately monitored pressures from 0 bar to 2 bar at temperatures up to 800 °C. The sensitivity, linearity, repeatability error, and hysteretic error of the sensor were 0.225 MHz/bar, 95.3%, 5.5%, and 6.2%, respectively. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

19 pages, 933 KiB

Open AccessArticle

Multi-Sensor Data Fusion Using a Relevance Vector Machine Based on an Ant Colony for Gearbox Fault Detection

by Zhiwen Liu, Wei Guo, Zhangchun Tang and Yongqiang Chen

Sensors 2015, 15(9), 21857-21875; https://doi.org/10.3390/s150921857 - 31 Aug 2015

Cited by 39 | Viewed by 6584

Abstract

Sensors play an important role in the modern manufacturing and industrial processes. Their reliability is vital to ensure reliable and accurate information for condition based maintenance. For the gearbox, the critical machine component in the rotating machinery, the vibration signals collected by sensors [...] Read more.

Sensors play an important role in the modern manufacturing and industrial processes. Their reliability is vital to ensure reliable and accurate information for condition based maintenance. For the gearbox, the critical machine component in the rotating machinery, the vibration signals collected by sensors are usually noisy. At the same time, the fault detection results based on the vibration signals from a single sensor may be unreliable and unstable. To solve this problem, this paper proposes an intelligent multi-sensor data fusion method using the relevance vector machine (RVM) based on an ant colony optimization algorithm (ACO-RVM) for gearboxes’ fault detection. RVM is a sparse probability model based on support vector machine (SVM). RVM not only has higher detection accuracy, but also better real-time accuracy compared with SVM. The ACO algorithm is used to determine kernel parameters of RVM. Moreover, the ensemble empirical mode decomposition (EEMD) is applied to preprocess the raw vibration signals to eliminate the influence caused by noise and other unrelated signals. The distance evaluation technique (DET) is employed to select dominant features as input of the ACO-RVM, so that the redundancy and inference in a large amount of features can be removed. Two gearboxes are used to demonstrate the performance of the proposed method. The experimental results show that the ACO-RVM has higher fault detection accuracy than the RVM with normal the cross-validation (CV). Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

22 pages, 647 KiB

Open AccessArticle

Field Balancing and Harmonic Vibration Suppression in Rigid AMB-Rotor Systems with Rotor Imbalances and Sensor Runout

by Xiangbo Xu and Shao Chen

Sensors 2015, 15(9), 21876-21897; https://doi.org/10.3390/s150921876 - 31 Aug 2015

Cited by 29 | Viewed by 7381

Abstract

Harmonic vibrations of high-speed rotors in momentum exchange devices are primary disturbances for attitude control of spacecraft. Active magnetic bearings (AMBs), offering the ability to control the AMB-rotor dynamic behaviors, are preferred in high-precision and micro-vibration applications, such as high-solution Earth observation satellites. [...] Read more.

Harmonic vibrations of high-speed rotors in momentum exchange devices are primary disturbances for attitude control of spacecraft. Active magnetic bearings (AMBs), offering the ability to control the AMB-rotor dynamic behaviors, are preferred in high-precision and micro-vibration applications, such as high-solution Earth observation satellites. However, undesirable harmonic displacements, currents, and vibrations also occur in the AMB-rotor system owing to the mixed rotor imbalances and sensor runout. To compensate the rotor imbalances and to suppress the harmonic vibrations, two control methods are presented. Firstly, a four degrees-of-freedom AMB-rotor model with the static imbalance, dynamic imbalance, and the sensor runout are described. Next, a synchronous current reduction approach with a variable-phase notch feedback is proposed, so that the rotor imbalances can be identified on-line through the analysis of the synchronous displacement relationships of the geometric, inertial, and rotational axes of the rotor. Then, the identified rotor imbalances, which can be represented at two prescribed balancing planes of the rotor, are compensated by discrete add-on weights whose masses are calculated in the vector form. Finally, a repetitive control algorithm is utilized to suppress the residual harmonic vibrations. The proposed field balancing and harmonic vibration suppression strategies are verified by simulations and experiments performed on a control moment gyro test rig with a rigid AMB-rotor system. Compared with existing methods, the proposed strategies do not require trial weights or an accurate model of the AMB-rotor system. Moreover, the harmonic displacements, currents, and vibrations can be well-attenuated simultaneously. Full article

(This article belongs to the Special Issue Inertial Sensors and Systems)

► Show Figures

Figure 1

33 pages, 3770 KiB

Open AccessArticle

Human Age Estimation Method Robust to Camera Sensor and/or Face Movement

by Dat Tien Nguyen, So Ra Cho, Tuyen Danh Pham and Kang Ryoung Park

Sensors 2015, 15(9), 21898-21930; https://doi.org/10.3390/s150921898 - 31 Aug 2015

Cited by 16 | Viewed by 11500

Abstract

Human age can be employed in many useful real-life applications, such as customer service systems, automatic vending machines, entertainment, etc. In order to obtain age information, image-based age estimation systems have been developed using information from the human face. However, limitations exist for [...] Read more.

Human age can be employed in many useful real-life applications, such as customer service systems, automatic vending machines, entertainment, etc. In order to obtain age information, image-based age estimation systems have been developed using information from the human face. However, limitations exist for current age estimation systems because of the various factors of camera motion and optical blurring, facial expressions, gender, etc. Motion blurring can usually be presented on face images by the movement of the camera sensor and/or the movement of the face during image acquisition. Therefore, the facial feature in captured images can be transformed according to the amount of motion, which causes performance degradation of age estimation systems. In this paper, the problem caused by motion blurring is addressed and its solution is proposed in order to make age estimation systems robust to the effects of motion blurring. Experiment results show that our method is more efficient for enhancing age estimation performance compared with systems that do not employ our method. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

26 pages, 8792 KiB

Open AccessArticle

A Framework for Applying Point Clouds Grabbed by Multi-Beam LIDAR in Perceiving the Driving Environment

by Jian Liu, Huawei Liang, Zhiling Wang and Xiangcheng Chen

Sensors 2015, 15(9), 21931-21956; https://doi.org/10.3390/s150921931 - 31 Aug 2015

Cited by 18 | Viewed by 6969

Abstract

The quick and accurate understanding of the ambient environment, which is composed of road curbs, vehicles, pedestrians, etc., is critical for developing intelligent vehicles. The road elements included in this work are road curbs and dynamic road obstacles that directly affect the [...] Read more.

The quick and accurate understanding of the ambient environment, which is composed of road curbs, vehicles, pedestrians, etc., is critical for developing intelligent vehicles. The road elements included in this work are road curbs and dynamic road obstacles that directly affect the drivable area. A framework for the online modeling of the driving environment using a multi-beam LIDAR, i.e., a Velodyne HDL-64E LIDAR, which describes the 3D environment in the form of a point cloud, is reported in this article. First, ground segmentation is performed via multi-feature extraction of the raw data grabbed by the Velodyne LIDAR to satisfy the requirement of online environment modeling. Curbs and dynamic road obstacles are detected and tracked in different manners. Curves are fitted for curb points, and points are clustered into bundles whose form and kinematics parameters are calculated. The Kalman filter is used to track dynamic obstacles, whereas the snake model is employed for curbs. Results indicate that the proposed framework is robust under various environments and satisfies the requirements for online processing. Full article

(This article belongs to the Special Issue Sensors in New Road Vehicles)

► Show Figures

Figure 1

14 pages, 1152 KiB

Open AccessArticle

A Long Distance Phase-Sensitive Optical Time Domain Reflectometer with Simple Structure and High Locating Accuracy

by Yi Shi, Hao Feng and Zhoumo Zeng

Sensors 2015, 15(9), 21957-21970; https://doi.org/10.3390/s150921957 - 2 Sep 2015

Cited by 48 | Viewed by 8101

Abstract

A phase-sensitive optical time domain reflectometer (Φ-OTDR) can be used for pipeline security. However, the sensing distance (less than 20 km) of traditional Φ-OTDR is too short for the needs of typical oil and gas pipeline monitoring applications (30–50 km). A simple structure [...] Read more.

A phase-sensitive optical time domain reflectometer (Φ-OTDR) can be used for pipeline security. However, the sensing distance (less than 20 km) of traditional Φ-OTDR is too short for the needs of typical oil and gas pipeline monitoring applications (30–50 km). A simple structure Φ-OTDR system utilizing long pulse, balanced amplified detector and heterodyne detection is proposed in this paper and the sensing range is thereby increased to 60 km. Through analyzing the sensing principle of Φ-OTDR, a novel locating strategy is proposed to maintain the locating accuracy at a few meters when a long pulse (5 µs) is used. The increased pulse width deteriorates the time series of each sensing point seriously. In order to eliminate the deterioration, a data processing technique combining wavelet and empirical mode decomposition is applied in this system. The experiment results show that the sensing distance can be increased to 60 km and the locating accuracy is maintained at 6.8 m. Full article

(This article belongs to the Special Issue Silicon Based Optical Sensors)

► Show Figures

Figure 1

18 pages, 1170 KiB

Open AccessArticle

Microwave-Based Oxidation State and Soot Loading Determination on Gasoline Particulate Filters with Three-Way Catalyst Coating for Homogenously Operated Gasoline Engines

by Markus Dietrich, Christoph Jahn, Peter Lanzerath and Ralf Moos

Sensors 2015, 15(9), 21971-21988; https://doi.org/10.3390/s150921971 - 2 Sep 2015

Cited by 19 | Viewed by 6451

Abstract

Recently, a novel method emerged to determine the oxygen storage degree of three way catalysts (TWC) by a microwave-based method. Up to now, this method has been investigated only in lab-scale reactors or under steady state conditions. This work expands those initial studies. [...] Read more.

Recently, a novel method emerged to determine the oxygen storage degree of three way catalysts (TWC) by a microwave-based method. Up to now, this method has been investigated only in lab-scale reactors or under steady state conditions. This work expands those initial studies. A TWC-coated gasoline particulate filter was investigated in a dynamic engine test bench simulating a typical European driving cycle (NEDC). It could be shown that both the oxygen storage degree and the soot loading can be monitored directly, but not simultaneously due to their competitive effects. Under normal driving conditions, no soot accumulation was observed, related to the low raw emissions and the catalytic coating of the filter. For the first time, the quality factor of the cavity resonator in addition to the resonance frequency was used, with the benefit of less cross sensitivity to inconstant temperature and water. Therefore, a temperature dependent calibration of the microwave signal was created and applied to monitor the oxidation state in transient driving cycles. The microwave measurement mirrors the oxidation state determined by lambda probes and can be highly beneficial in start-stop phases (where lambda-probes do not work) and to determine the oxygen storage capacity (OSC) without unnecessary emissions. Full article

(This article belongs to the Section Chemical Sensors)

► Show Figures

Figure 1

14 pages, 1094 KiB

Open AccessArticle

Investigating the Potential of Using the Spatial and Spectral Information of Multispectral LiDAR for Object Classification

by Wei Gong, Jia Sun, Shuo Shi, Jian Yang, Lin Du, Bo Zhu and Shalei Song

Sensors 2015, 15(9), 21989-22002; https://doi.org/10.3390/s150921989 - 2 Sep 2015

Cited by 51 | Viewed by 6020

Abstract

The abilities of multispectral LiDAR (MSL) as a new high-potential active instrument for remote sensing have not been fully revealed. This study demonstrates the potential of using the spectral and spatial features derived from a novel MSL to discriminate surface objects. Data acquired [...] Read more.

The abilities of multispectral LiDAR (MSL) as a new high-potential active instrument for remote sensing have not been fully revealed. This study demonstrates the potential of using the spectral and spatial features derived from a novel MSL to discriminate surface objects. Data acquired with the MSL include distance information and the intensities of four wavelengths at 556, 670, 700, and 780 nm channels. A support vector machine was used to classify diverse objects in the experimental scene into seven types: wall, ceramic pots, Cactaceae, carton, plastic foam block, and healthy and dead leaves of E. aureum. Different features were used during classification to compare the performance of different detection systems. The spectral backscattered reflectance of one wavelength and distance represented the features from an equivalent single-wavelength LiDAR system; reflectance of the four wavelengths represented the features from an equivalent multispectral image with four bands. Results showed that the overall accuracy of using MSL data was as high as 88.7%, this value was 9.8%–39.2% higher than those obtained using a single-wavelength LiDAR, and 4.2% higher than for multispectral image. Full article

(This article belongs to the Section Remote Sensors)

► Show Figures

Figure 1

46 pages, 8988 KiB

Open AccessArticle

Inspection of Pole-Like Structures Using a Visual-Inertial Aided VTOL Platform with Shared Autonomy

by Inkyu Sa, Stefan Hrabar and Peter Corke

Sensors 2015, 15(9), 22003-22048; https://doi.org/10.3390/s150922003 - 2 Sep 2015

Cited by 21 | Viewed by 8714

Abstract

This paper presents an algorithm and a system for vertical infrastructure inspection using a vertical take-off and landing (VTOL) unmanned aerial vehicle and shared autonomy. Inspecting vertical structures such as light and power distribution poles is a difficult task that is time-consuming, dangerous [...] Read more.

This paper presents an algorithm and a system for vertical infrastructure inspection using a vertical take-off and landing (VTOL) unmanned aerial vehicle and shared autonomy. Inspecting vertical structures such as light and power distribution poles is a difficult task that is time-consuming, dangerous and expensive. Recently, micro VTOL platforms (i.e., quad-, hexa- and octa-rotors) have been rapidly gaining interest in research, military and even public domains. The unmanned, low-cost and VTOL properties of these platforms make them ideal for situations where inspection would otherwise be time-consuming and/or hazardous to humans. There are, however, challenges involved with developing such an inspection system, for example flying in close proximity to a target while maintaining a fixed stand-off distance from it, being immune to wind gusts and exchanging useful information with the remote user. To overcome these challenges, we require accurate and high-update rate state estimation and high performance controllers to be implemented onboard the vehicle. Ease of control and a live video feed are required for the human operator. We demonstrate a VTOL platform that can operate at close-quarters, whilst maintaining a safe stand-off distance and rejecting environmental disturbances. Two approaches are presented: Position-Based Visual Servoing (PBVS) using an Extended Kalman Filter (EKF) and estimator-free Image-Based Visual Servoing (IBVS). Both use monocular visual, inertia, and sonar data, allowing the approaches to be applied for indoor or GPS-impaired environments. We extensively compare the performances of PBVS and IBVS in terms of accuracy, robustness and computational costs. Results from simulations Sensors 2015, 15 22004 and indoor/outdoor (day and night) flight experiments demonstrate the system is able to successfully inspect and circumnavigate a vertical pole. Full article

(This article belongs to the Special Issue UAV Sensors for Environmental Monitoring)

► Show Figures

Figure 1

11 pages, 2203 KiB

Open AccessArticle

Flip Chip Bonding of a Quartz MEMS-Based Vibrating Beam Accelerometer

by Jinxing Liang, Liyuan Zhang, Ling Wang, Yuan Dong and Toshitsugu Ueda

Sensors 2015, 15(9), 22049-22059; https://doi.org/10.3390/s150922049 - 2 Sep 2015

Cited by 21 | Viewed by 8845

Abstract

In this study, a novel method to assemble a micro-accelerometer by a flip chip bonding technique is proposed and demonstrated. Both the main two parts of the accelerometer, a double-ended tuning fork and a base-proof mass structure, are fabricated using a quartz wet [...] Read more.

In this study, a novel method to assemble a micro-accelerometer by a flip chip bonding technique is proposed and demonstrated. Both the main two parts of the accelerometer, a double-ended tuning fork and a base-proof mass structure, are fabricated using a quartz wet etching process on Z cut quartz wafers with a thickness of 100 μm and 300 μm, respectively. The finite element method is used to simulate the vibration mode and optimize the sensing element structure. Taking advantage of self-alignment function of the flip chip bonding process, the two parts were precisely bonded at the desired joint position via AuSn solder. Experimental demonstrations were performed on a maximum scale of 4 × 8 mm² chip, and high sensitivity up to 9.55 Hz/g with a DETF resonator and a Q value of 5000 in air was achieved. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

29 pages, 3260 KiB

Open AccessArticle

Energy-Efficient Crowdsensing of Human Mobility and Signal Levels in Cellular Networks

by Paweł Foremski, Michał Gorawski, Krzysztof Grochla and Konrad Polys

Sensors 2015, 15(9), 22060-22088; https://doi.org/10.3390/s150922060 - 2 Sep 2015

Cited by 21 | Viewed by 6851

Abstract

The paper presents a practical application of the crowdsensing idea to measure human mobility and signal coverage in cellular networks. Currently, virtually everyone is carrying a mobile phone, which may be used as a sensor to gather research data by measuring, e.g., human [...] Read more.

The paper presents a practical application of the crowdsensing idea to measure human mobility and signal coverage in cellular networks. Currently, virtually everyone is carrying a mobile phone, which may be used as a sensor to gather research data by measuring, e.g., human mobility and radio signal levels. However, many users are unwilling to participate in crowdsensing experiments. This work begins with the analysis of the barriers for engaging people in crowdsensing. A survey showed that people who agree to participate in crowdsensing expect a minimum impact on their battery lifetime and phone usage habits. To address these requirements, this paper proposes an application for measuring the location and signal strength data based on energy-efficient GPS tracking, which allows one to perform the measurements of human mobility and radio signal levels with minimum energy utilization and without any engagement of the user. The method described combines measurements from the accelerometer with effective management of the GPS to monitor the user mobility with the decrease in battery lifetime by approximately 20%. To show the applicability of the proposed platform, the sample results of signal level distribution and coverage maps gathered for an LTE network and representing human mobility are shown. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

23 pages, 4383 KiB

Open AccessArticle

Universal Capacitance Model for Real-Time Biomass in Cell Culture

by Viktor Konakovsky, Ali Civan Yagtu, Christoph Clemens, Markus Michael Müller, Martina Berger, Stefan Schlatter and Christoph Herwig

Sensors 2015, 15(9), 22128-22150; https://doi.org/10.3390/s150922128 - 2 Sep 2015

Cited by 29 | Viewed by 8521

Abstract

Capacitance probes have the potential to revolutionize bioprocess control due to their safe and robust use and ability to detect even the smallest capacitors in the form of biological cells. Several techniques have evolved to model biomass statistically, however, there are problems with [...] Read more.

Capacitance probes have the potential to revolutionize bioprocess control due to their safe and robust use and ability to detect even the smallest capacitors in the form of biological cells. Several techniques have evolved to model biomass statistically, however, there are problems with model transfer between cell lines and process conditions. Errors of transferred models in the declining phase of the culture range for linear models around +100% or worse, causing unnecessary delays with test runs during bioprocess development. The goal of this work was to develop one single universal model which can be adapted by considering a potentially mechanistic factor to estimate biomass in yet untested clones and scales. The novelty of this work is a methodology to select sensitive frequencies to build a statistical model which can be shared among fermentations with an error between 9% and 38% (mean error around 20%) for the whole process, including the declining phase. A simple linear factor was found to be responsible for the transferability of biomass models between cell lines, indicating a link to their phenotype or physiology. Full article

(This article belongs to the Special Issue Sensors for Bioprocess Monitoring and Control)

► Show Figures

Graphical abstract

16 pages, 1547 KiB

Open AccessArticle

Smartphone-Based Bioelectrical Impedance Analysis Devices for Daily Obesity Management

by Ahyoung Choi, Justin Younghyun Kim, Seongwook Jo, Jae Hwan Jee, Steven B. Heymsfield, Yusuf A. Bhagat, Insoo Kim and Jaegeol Cho

Sensors 2015, 15(9), 22151-22166; https://doi.org/10.3390/s150922151 - 2 Sep 2015

Cited by 31 | Viewed by 14030

Abstract

Current bioelectric impedance analysis (BIA) systems are often large, cumbersome devices which require strict electrode placement on the user, thus inhibiting mobile capabilities. In this work, we developed a handheld BIA device that measures impedance from multiple frequencies (5 kHz~200 kHz) with four [...] Read more.

Current bioelectric impedance analysis (BIA) systems are often large, cumbersome devices which require strict electrode placement on the user, thus inhibiting mobile capabilities. In this work, we developed a handheld BIA device that measures impedance from multiple frequencies (5 kHz~200 kHz) with four contact electrodes and evaluated the BIA device against standard body composition analysis systems: a dual-energy X-ray absorptiometry (DXA) system (GE Lunar Prodigy, GE Healthcare, Buckinghamshire, UK) and a whole-body BIA system (InBody S10, InBody, Co. Ltd, Seoul, Korea). In the study, 568 healthy participants, varying widely in body mass index, age, and gender, were recruited at two research centers: the Samsung Medical Center (SMC) in South Korea and the Pennington Biomedical Research Center (PBRC) in the United States. From the measured impedance data, we analyzed individual body fat and skeletal muscle mass by applying linear regression analysis against target reference data. Results indicated strong correlations of impedance measurements between the prototype pathways and corresponding InBody S10 electrical pathways (R = 0.93, p < 0.0001). Additionally, body fat estimates from DXA did not yield significant differences (p > 0.728 (paired t-test), DXA mean body fat 29.45 ± 10.77 kg, estimated body fat 29.52 ± 12.53 kg). Thus, this portable BIA system shows a promising ability to estimate an individual’s body composition that is comparable to large stationary BIA systems. Full article

(This article belongs to the Special Issue Smartphone-Based Sensors for Non-Invasive Physiological Monitoring)

► Show Figures

Figure 1

25 pages, 1655 KiB

Open AccessArticle

A New Reassigned Spectrogram Method in Interference Detection for GNSS Receivers

by Kewen Sun, Tian Jin and Dongkai Yang

Sensors 2015, 15(9), 22167-22191; https://doi.org/10.3390/s150922167 - 2 Sep 2015

Cited by 18 | Viewed by 5606

Abstract

Interference detection is very important for Global Navigation Satellite System (GNSS) receivers. Current work on interference detection in GNSS receivers has mainly focused on time-frequency (TF) analysis techniques, such as spectrogram and Wigner–Ville distribution (WVD), where the spectrogram approach presents the TF resolution [...] Read more.

Interference detection is very important for Global Navigation Satellite System (GNSS) receivers. Current work on interference detection in GNSS receivers has mainly focused on time-frequency (TF) analysis techniques, such as spectrogram and Wigner–Ville distribution (WVD), where the spectrogram approach presents the TF resolution trade-off problem, since the analysis window is used, and the WVD method suffers from the very serious cross-term problem, due to its quadratic TF distribution nature. In order to solve the cross-term problem and to preserve good TF resolution in the TF plane at the same time, in this paper, a new TF distribution by using a reassigned spectrogram has been proposed in interference detection for GNSS receivers. This proposed reassigned spectrogram method efficiently combines the elimination of the cross-term provided by the spectrogram itself according to its inherent nature and the improvement of the TF aggregation property achieved by the reassignment method. Moreover, a notch filter has been adopted in interference mitigation for GNSS receivers, where receiver operating characteristics (ROCs) are used as metrics for the characterization of interference mitigation performance. The proposed interference detection method by using a reassigned spectrogram is evaluated by experiments on GPS L1 signals in the disturbing scenarios in comparison to the state-of-the-art TF analysis approaches. The analysis results show that the proposed interference detection technique effectively overcomes the cross-term problem and also keeps good TF localization properties, which has been proven to be valid and effective to enhance the interference Sensors 2015, 15 22168 detection performance; in addition, the adoption of the notch filter in interference mitigation has shown a significant acquisition performance improvement in terms of ROC curves for GNSS receivers in jamming environments. Full article

(This article belongs to the Section Remote Sensors)

► Show Figures

Figure 1

17 pages, 2662 KiB

Open AccessArticle

Simulations of Interdigitated Electrode Interactions with Gold Nanoparticles for Impedance-Based Biosensing Applications

by Scott MacKay, Peter Hermansen, David Wishart and Jie Chen

Sensors 2015, 15(9), 22192-22208; https://doi.org/10.3390/s150922192 - 2 Sep 2015

Cited by 61 | Viewed by 11430

Abstract

In this paper, we describe a point-of-care biosensor design. The uniqueness of our design is in its capability for detecting a wide variety of target biomolecules and the simplicity of nanoparticle enhanced electrical detection. The electrical properties of interdigitated electrodes (IDEs) and the [...] Read more.

In this paper, we describe a point-of-care biosensor design. The uniqueness of our design is in its capability for detecting a wide variety of target biomolecules and the simplicity of nanoparticle enhanced electrical detection. The electrical properties of interdigitated electrodes (IDEs) and the mechanism for gold nanoparticle-enhanced impedance-based biosensor systems based on these electrodes are simulated using COMSOL Multiphysics software. Understanding these properties and how they can be affected is vital in designing effective biosensor devices. Simulations were used to show electrical screening develop over time for IDEs in a salt solution, as well as the electric field between individual digits of electrodes. Using these simulations, it was observed that gold nanoparticles bound closely to IDEs can lower the electric field magnitude between the digits of the electrode. The simulations are also shown to be a useful design tool in optimizing sensor function. Various different conditions, such as electrode dimensions and background ion concentrations, are shown to have a significant impact on the simulations. Full article

(This article belongs to the Section Biosensors)

► Show Figures

Graphical abstract

15 pages, 1942 KiB

Open AccessArticle

Multi-Wavelength Based Optical Density Sensor for Autonomous Monitoring of Microalgae

by Fei Jia, Murat Kacira and Kimberly L. Ogden

Sensors 2015, 15(9), 22234-22248; https://doi.org/10.3390/s150922234 - 2 Sep 2015

Cited by 49 | Viewed by 12336

Abstract

A multi-wavelength based optical density sensor unit was designed, developed, and evaluated to monitor microalgae growth in real time. The system consisted of five main components including: (1) laser diode modules as light sources; (2) photodiodes as detectors; (3) driver circuit; (4) flow [...] Read more.

A multi-wavelength based optical density sensor unit was designed, developed, and evaluated to monitor microalgae growth in real time. The system consisted of five main components including: (1) laser diode modules as light sources; (2) photodiodes as detectors; (3) driver circuit; (4) flow cell; and (5) sensor housing temperature controller. The sensor unit was designed to be integrated into any microalgae culture system for both real time and non-real time optical density measurements and algae growth monitoring applications. It was shown that the sensor unit was capable of monitoring the dynamics and physiological changes of the microalgae culture in real-time. Algae biomass concentration was accurately estimated with optical density measurements at 650, 685 and 780 nm wavelengths used by the sensor unit. The sensor unit was able to monitor cell concentration as high as 1.05 g·L⁻¹ (1.51 × 10⁸ cells·mL⁻¹) during the culture growth without any sample preparation for the measurements. Since high cell concentrations do not need to be diluted using the sensor unit, the system has the potential to be used in industrial microalgae cultivation systems for real time monitoring and control applications that can lead to improved resource use efficiency. Full article

(This article belongs to the Special Issue Micro-Optical Sensors)

► Show Figures

Figure 1

17 pages, 1160 KiB

Open AccessArticle

RB Particle Filter Time Synchronization Algorithm Based on the DPM Model

by Chunsheng Guo, Jia Shen, Yao Sun and Na Ying

Sensors 2015, 15(9), 22249-22265; https://doi.org/10.3390/s150922249 - 3 Sep 2015

Cited by 6 | Viewed by 5005

Abstract

Time synchronization is essential for node localization, target tracking, data fusion, and various other Wireless Sensor Network (WSN) applications. To improve the estimation accuracy of continuous clock offset and skew of mobile nodes in WSNs, we propose a novel time synchronization algorithm, the [...] Read more.

Time synchronization is essential for node localization, target tracking, data fusion, and various other Wireless Sensor Network (WSN) applications. To improve the estimation accuracy of continuous clock offset and skew of mobile nodes in WSNs, we propose a novel time synchronization algorithm, the Rao-Blackwellised (RB) particle filter time synchronization algorithm based on the Dirichlet process mixture (DPM) model. In a state-space equation with a linear substructure, state variables are divided into linear and non-linear variables by the RB particle filter algorithm. These two variables can be estimated using Kalman filter and particle filter, respectively, which improves the computational efficiency more so than if only the particle filter was used. In addition, the DPM model is used to describe the distribution of non-deterministic delays and to automatically adjust the number of Gaussian mixture model components based on the observational data. This improves the estimation accuracy of clock offset and skew, which allows achieving the time synchronization. The time synchronization performance of this algorithm is also validated by computer simulations and experimental measurements. The results show that the proposed algorithm has a higher time synchronization precision than traditional time synchronization algorithms. Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

Figure 1

25 pages, 507 KiB

Open AccessArticle

Energy-Efficient Transmissions for Remote Wireless Sensor Networks: An Integrated HAP/Satellite Architecture for Emergency Scenarios

by Feihong Dong, Hongjun Li, Xiangwu Gong, Quan Liu and Jingchao Wang

Sensors 2015, 15(9), 22266-22290; https://doi.org/10.3390/s150922266 - 3 Sep 2015

Cited by 31 | Viewed by 6833

Abstract

A typical application scenario of remote wireless sensor networks (WSNs) is identified as an emergency scenario. One of the greatest design challenges for communications in emergency scenarios is energy-efficient transmission, due to scarce electrical energy in large-scale natural and man-made disasters. Integrated high [...] Read more.

A typical application scenario of remote wireless sensor networks (WSNs) is identified as an emergency scenario. One of the greatest design challenges for communications in emergency scenarios is energy-efficient transmission, due to scarce electrical energy in large-scale natural and man-made disasters. Integrated high altitude platform (HAP)/satellite networks are expected to optimally meet emergency communication requirements. In this paper, a novel integrated HAP/satellite (IHS) architecture is proposed, and three segments of the architecture are investigated in detail. The concept of link-state advertisement (LSA) is designed in a slow flat Rician fading channel. The LSA is received and processed by the terminal to estimate the link state information, which can significantly reduce the energy consumption at the terminal end. Furthermore, the transmission power requirements of the HAPs and terminals are derived using the gradient descent and differential equation methods. The energy consumption is modeled at both the source and system level. An innovative and adaptive algorithm is given for the energy-efficient path selection. The simulation results validate the effectiveness of the proposed adaptive algorithm. It is shown that the proposed adaptive algorithm can significantly improve energy efficiency when combined with the LSA and the energy consumption estimation. Full article

(This article belongs to the Special Issue Towards Energy-Neutral WSN Architectures: Energy Harvesting and Other Enabling Technologies)

► Show Figures

Figure 1

13 pages, 2337 KiB

Open AccessArticle

An Apta-Biosensor for Colon Cancer Diagnostics

by Mojgan Ahmadzadeh Raji, Ghasem Amoabediny, Parviz Tajik, Morteza Hosseini and Ebrahim Ghafar-Zadeh

Sensors 2015, 15(9), 22291-22303; https://doi.org/10.3390/s150922291 - 3 Sep 2015

Cited by 21 | Viewed by 8436

Abstract

This paper reports the design and implementation of an aptasensor using a modified KCHA10a aptamer. This aptasensor consists of a functionalized electrodes using various materials including 11-mercaptoandecanoic acid (11-MUA) and modified KCHA10a aptamer. The HCT 116, HT 29 and HEp-2 cell lines are [...] Read more.

This paper reports the design and implementation of an aptasensor using a modified KCHA10a aptamer. This aptasensor consists of a functionalized electrodes using various materials including 11-mercaptoandecanoic acid (11-MUA) and modified KCHA10a aptamer. The HCT 116, HT 29 and HEp-2 cell lines are used in this study to demonstrate the functionality of aptasensor for colon cancer detection purposes. Flow cytometry, fluorescence microscopy and electrochemical cyclic voltammetry are used to verify the binding between the target cells and aptamer. The limit of detection (LOD) of this aptasensor is equal to seven cancer cells. Based on the experimental results, the proposed sensor can be employed for point-of-care cancer disease diagnostics. Full article

(This article belongs to the Special Issue Label-Free Sensing)

► Show Figures

Figure 1

21 pages, 5307 KiB

Open AccessArticle

Step Response Characteristics of Polymer/Ceramic Pressure-Sensitive Paint

by Anshuman Pandey and James W. Gregory

Sensors 2015, 15(9), 22304-22324; https://doi.org/10.3390/s150922304 - 3 Sep 2015

Cited by 28 | Viewed by 6988

Abstract

Experiments and numerical simulations have been used in this work to understand the step response characteristics of Polymer/Ceramic Pressure-Sensitive Paint (PC-PSP). A recently developed analytical model describing the essential physics in PC-PSP quenching kinetics is used, which includes the effect of both diffusion [...] Read more.

Experiments and numerical simulations have been used in this work to understand the step response characteristics of Polymer/Ceramic Pressure-Sensitive Paint (PC-PSP). A recently developed analytical model describing the essential physics in PC-PSP quenching kinetics is used, which includes the effect of both diffusion time scale and luminescent lifetime on the net response of PC-PSP. Step response simulations using this model enables an understanding of the effects of parameters, such as the diffusion coefficient of O₂ in the polymer/ceramic coating, attenuation of excitation light, ambient luminescent lifetime, sensitivity, and the magnitude and direction of pressure change on the observed response time scales of PC-PSP. It was found that higher diffusion coefficient and greater light attenuation lead to faster response, whereas longer ambient lifetime and larger sensitivity lead to slower response characteristics. Due to the inherent non-linearity of the Stern-Volmer equation, response functions also change with magnitude and direction of the pressure change. Experimental results from a shock tube are presented where the effects of varying the roughness, pressure jump magnitude and luminophore probe have been studied. Model parameters have been varied to obtain a good fit to experimental results and this optimized model is then used to obtain the response time for a step decrease in pressure, an estimate of which is currently not obtainable from experiments. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

18 pages, 898 KiB

Open AccessArticle

Novel X-ray Communication Based XNAV Augmentation Method Using X-ray Detectors

by Shibin Song, Luping Xu, Hua Zhang and Yuanjie Bai

Sensors 2015, 15(9), 22325-22342; https://doi.org/10.3390/s150922325 - 3 Sep 2015

Cited by 16 | Viewed by 5505

Abstract

The further development of X-ray pulsar-based NAVigation (XNAV) is hindered by its lack of accuracy, so accuracy improvement has become a critical issue for XNAV. In this paper, an XNAV augmentation method which utilizes both pulsar observation and X-ray ranging observation for navigation [...] Read more.

The further development of X-ray pulsar-based NAVigation (XNAV) is hindered by its lack of accuracy, so accuracy improvement has become a critical issue for XNAV. In this paper, an XNAV augmentation method which utilizes both pulsar observation and X-ray ranging observation for navigation filtering is proposed to deal with this issue. As a newly emerged concept, X-ray communication (XCOM) shows great potential in space exploration. X-ray ranging, derived from XCOM, could achieve high accuracy in range measurement, which could provide accurate information for XNAV. For the proposed method, the measurement models of pulsar observation and range measurement observation are established, and a Kalman filtering algorithm based on the observations and orbit dynamics is proposed to estimate the position and velocity of a spacecraft. A performance comparison of the proposed method with the traditional pulsar observation method is conducted by numerical experiments. Besides, the parameters that influence the performance of the proposed method, such as the pulsar observation time, the SNR of the ranging signal, etc., are analyzed and evaluated by numerical experiments. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

21 pages, 3159 KiB

Open AccessArticle

Electrochemical Interrogation of G3-Poly(propylene thiophenoimine) Dendritic Star Polymer in Phenanthrene Sensing

by Hlamulo R. Makelane, Oluwakemi Tovide, Christopher E. Sunday, Tesfaye Waryo and Emmanuel I. Iwuoha

Sensors 2015, 15(9), 22343-22363; https://doi.org/10.3390/s150922343 - 3 Sep 2015

Cited by 14 | Viewed by 5491

Abstract

A novel dendritic star-copolymer, generation 3 poly(propylene thiophenoimine) (G3PPT)-co-poly(3-hexylthiophene) (P3HT) star co-polymer on gold electrode (i.e., Au|G3PPT-co-P3HT) was used as a sensor system for the determination of phenanthrene (PHE). The G3PPT-co-P3HT star co-polymer was synthesized via in situ electrochemical co-polymerization of [...] Read more.

A novel dendritic star-copolymer, generation 3 poly(propylene thiophenoimine) (G3PPT)-co-poly(3-hexylthiophene) (P3HT) star co-polymer on gold electrode (i.e., Au|G3PPT-co-P3HT) was used as a sensor system for the determination of phenanthrene (PHE). The G3PPT-co-P3HT star co-polymer was synthesized via in situ electrochemical co-polymerization of generation 3 poly (propylene thiophenoimine) and poly (3-hexylthiophene) on gold electrode. 1HNMR spectroscopy was used to determine the regioregularity of the polymer composites, whereas Fourier transform infrared spectroscopy and scanning electron microscopy were used to study their structural and morphological properties. Au|G3PPT-co-P3HT in the absence of PHE, exhibited reversible electrochemistry attributable to the oligo (thiophene) ‘pendants’ of the dendrimer. PHE produced an increase in the voltammetric signals (anodic currents) due to its oxidation on the dendritic material to produce catalytic current, thereby suggesting the suitability of the Au|G3PPT-co-P3HT electrode as a PHE sensor. The electrocatalysis of PHE was made possible by the rigid and planar oligo-P3HT species (formed upon the oxidation of the oligo (thiophene) pendants of the star-copolymer), which allowed the efficient capture (binding) and detection (electrocatalytic oxidation) of PHE molecules. Full article

(This article belongs to the Section Chemical Sensors)

► Show Figures

Figure 1

14 pages, 843 KiB

Open AccessArticle

Handling Neighbor Discovery and Rendezvous Consistency with Weighted Quorum-Based Approach

by Chung-Ming Own, Zhaopeng Meng and Kehan Liu

Sensors 2015, 15(9), 22364-22377; https://doi.org/10.3390/s150922364 - 3 Sep 2015

Cited by 17 | Viewed by 5663

Abstract

Neighbor discovery and the power of sensors play an important role in the formation of Wireless Sensor Networks (WSNs) and mobile networks. Many asynchronous protocols based on wake-up time scheduling have been proposed to enable neighbor discovery among neighboring nodes for the energy [...] Read more.

Neighbor discovery and the power of sensors play an important role in the formation of Wireless Sensor Networks (WSNs) and mobile networks. Many asynchronous protocols based on wake-up time scheduling have been proposed to enable neighbor discovery among neighboring nodes for the energy saving, especially in the difficulty of clock synchronization. However, existing researches are divided two parts with the neighbor-discovery methods, one is the quorum-based protocols and the other is co-primality based protocols. Their distinction is on the arrangements of time slots, the former uses the quorums in the matrix, the latter adopts the numerical analysis. In our study, we propose the weighted heuristic quorum system (WQS), which is based on the quorum algorithm to eliminate redundant paths of active slots. We demonstrate the specification of our system: fewer active slots are required, the referring rate is balanced, and remaining power is considered particularly when a device maintains rendezvous with discovered neighbors. The evaluation results showed that our proposed method can effectively reschedule the active slots and save the computing time of the network system. Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

Figure 1

23 pages, 1462 KiB

Open AccessArticle

Towards Low Energy Atrial Defibrillation

by Philip Walsh, Vivek Kodoth, David McEneaney, Paola Rodrigues, Jose Velasquez, Niall Waterman and Omar Escalona

Sensors 2015, 15(9), 22378-22400; https://doi.org/10.3390/s150922378 - 3 Sep 2015

Cited by 5 | Viewed by 7081

Abstract

A wireless powered implantable atrial defibrillator consisting of a battery driven hand-held radio frequency (RF) power transmitter (ex vivo) and a passive (battery free) implantable power receiver (in vivo) that enables measurement of the intracardiac impedance (ICI) during internal [...] Read more.

A wireless powered implantable atrial defibrillator consisting of a battery driven hand-held radio frequency (RF) power transmitter (ex vivo) and a passive (battery free) implantable power receiver (in vivo) that enables measurement of the intracardiac impedance (ICI) during internal atrial defibrillation is reported. The architecture is designed to operate in two modes: Cardiac sense mode (power-up, measure the impedance of the cardiac substrate and communicate data to the ex vivo power transmitter) and cardiac shock mode (delivery of a synchronised very low tilt rectilinear electrical shock waveform). An initial prototype was implemented and tested. In low-power (sense) mode, >5 W was delivered across a 2.5 cm air-skin gap to facilitate measurement of the impedance of the cardiac substrate. In high-power (shock) mode, >180 W (delivered as a 12 ms monophasic very-low-tilt-rectilinear (M-VLTR) or as a 12 ms biphasic very-low-tilt-rectilinear (B-VLTR) chronosymmetric (6ms/6ms) amplitude asymmetric (negative phase at 50% magnitude) shock was reliably and repeatedly delivered across the same interface; with >47% DC-to-DC (direct current to direct current) power transfer efficiency at a switching frequency of 185 kHz achieved. In an initial trial of the RF architecture developed, 30 patients with AF were randomised to therapy with an RF generated M-VLTR or B-VLTR shock using a step-up voltage protocol (50–300 V). Mean energy for successful cardioversion was 8.51 J ± 3.16 J. Subsequent analysis revealed that all patients who cardioverted exhibited a significant decrease in ICI between the first and third shocks (5.00 Ω (SD(σ) = 1.62 Ω), p < 0.01) while spectral analysis across frequency also revealed a significant variation in the impedance-amplitude-spectrum-area (IAMSA) within the same patient group (|∆(IAMSA_S1-IAMSA_S3)[1 Hz − 20 kHz] = 20.82 Ω-Hz (SD(σ) = 10.77 Ω-Hz), p < 0.01); both trends being absent in all patients that failed to cardiovert. Efficient transcutaneous power transfer and sensing of ICI during cardioversion are evidenced as key to the advancement of low-energy atrial defibrillation. Full article

(This article belongs to the Special Issue Power Schemes for Biosensors and Biomedical Devices)

► Show Figures

Figure 1

18 pages, 781 KiB

Open AccessArticle

ISAR Imaging of Maneuvering Targets Based on the Modified Discrete Polynomial-Phase Transform

by Yong Wang, Ali Cherif Abdelkader, Bin Zhao and Jinxiang Wang

Sensors 2015, 15(9), 22401-22418; https://doi.org/10.3390/s150922401 - 3 Sep 2015

Cited by 27 | Viewed by 5519

Abstract

Inverse synthetic aperture radar (ISAR) imaging of a maneuvering target is a challenging task in the field of radar signal processing. The azimuth echo can be characterized as a multi-component polynomial phase signal (PPS) after the translational compensation, and the high quality ISAR [...] Read more.

Inverse synthetic aperture radar (ISAR) imaging of a maneuvering target is a challenging task in the field of radar signal processing. The azimuth echo can be characterized as a multi-component polynomial phase signal (PPS) after the translational compensation, and the high quality ISAR images can be obtained by the parameters estimation of it combined with the Range-Instantaneous-Doppler (RID) technique. In this paper, a novel parameters estimation algorithm of the multi-component PPS with order three (cubic phase signal-CPS) based on the modified discrete polynomial-phase transform (MDPT) is proposed, and the corresponding new ISAR imaging algorithm is presented consequently. This algorithm is efficient and accurate to generate a focused ISAR image, and the results of real data demonstrate the effectiveness of it. Full article

(This article belongs to the Section Remote Sensors)

► Show Figures

Figure 1

20 pages, 500 KiB

Open AccessArticle

EPPS: Efficient and Privacy-Preserving Personal Health Information Sharing in Mobile Healthcare Social Networks

by Shunrong Jiang, Xiaoyan Zhu and Liangmin Wang

Sensors 2015, 15(9), 22419-22438; https://doi.org/10.3390/s150922419 - 3 Sep 2015

Cited by 25 | Viewed by 7377

Abstract

Mobile healthcare social networks (MHSNs) have emerged as a promising next-generation healthcare system, which will significantly improve the quality of life. However, there are many security and privacy concerns before personal health information (PHI) is shared with other parities. To ensure patients’ full [...] Read more.

Mobile healthcare social networks (MHSNs) have emerged as a promising next-generation healthcare system, which will significantly improve the quality of life. However, there are many security and privacy concerns before personal health information (PHI) is shared with other parities. To ensure patients’ full control over their PHI, we propose a fine-grained and scalable data access control scheme based on attribute-based encryption (ABE). Besides, policies themselves for PHI sharing may be sensitive and may reveal information about underlying PHI or about data owners or recipients. In our scheme, we let each attribute contain an attribute name and its value and adopt the Bloom filter to efficiently check attributes before decryption. Thus, the data privacy and policy privacy can be preserved in our proposed scheme. Moreover, considering the fact that the computational cost grows with the complexity of the access policy and the limitation of the resource and energy in a smart phone, we outsource ABE decryption to the cloud while preventing the cloud from learning anything about the content and access policy. The security and performance analysis is carried out to demonstrate that our proposed scheme can achieve fine-grained access policies for PHI sharing in MHSNs. Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

Figure 1

12 pages, 1102 KiB

Open AccessArticle

Analysis of a Lipid/Polymer Membrane for Bitterness Sensing with a Preconditioning Process

by Rui Yatabe, Junpei Noda, Yusuke Tahara, Yoshinobu Naito, Hidekazu Ikezaki and Kiyoshi Toko

Sensors 2015, 15(9), 22439-22450; https://doi.org/10.3390/s150922439 - 4 Sep 2015

Cited by 19 | Viewed by 6848

Abstract

It is possible to evaluate the taste of foods or medicines using a taste sensor. The taste sensor converts information on taste into an electrical signal using several lipid/polymer membranes. A lipid/polymer membrane for bitterness sensing can evaluate aftertaste after immersion in monosodium [...] Read more.

It is possible to evaluate the taste of foods or medicines using a taste sensor. The taste sensor converts information on taste into an electrical signal using several lipid/polymer membranes. A lipid/polymer membrane for bitterness sensing can evaluate aftertaste after immersion in monosodium glutamate (MSG), which is called “preconditioning”. However, we have not yet analyzed the change in the surface structure of the membrane as a result of preconditioning. Thus, we analyzed the change in the surface by performing contact angle and surface zeta potential measurements, Fourier transform infrared spectroscopy (FTIR), X-ray photon spectroscopy (XPS) and gas cluster ion beam time-of-flight secondary ion mass spectrometry (GCIB-TOF-SIMS). After preconditioning, the concentrations of MSG and tetradodecylammonium bromide (TDAB), contained in the lipid membrane were found to be higher in the surface region than in the bulk region. The effect of preconditioning was revealed by the above analysis methods. Full article

(This article belongs to the Special Issue Sensors for Food Safety and Quality)

► Show Figures

Figure 1

22 pages, 6427 KiB

Open AccessArticle

Improved Leg Tracking Considering Gait Phase and Spline-Based Interpolation during Turning Motion in Walk Tests

by Ayanori Yorozu, Toshiki Moriguchi and Masaki Takahashi

Sensors 2015, 15(9), 22451-22472; https://doi.org/10.3390/s150922451 - 4 Sep 2015

Cited by 32 | Viewed by 8111

Abstract

Falling is a common problem in the growing elderly population, and fall-risk assessment systems are needed for community-based fall prevention programs. In particular, the timed up and go test (TUG) is the clinical test most often used to evaluate elderly individual ambulatory ability [...] Read more.

Falling is a common problem in the growing elderly population, and fall-risk assessment systems are needed for community-based fall prevention programs. In particular, the timed up and go test (TUG) is the clinical test most often used to evaluate elderly individual ambulatory ability in many clinical institutions or local communities. This study presents an improved leg tracking method using a laser range sensor (LRS) for a gait measurement system to evaluate the motor function in walk tests, such as the TUG. The system tracks both legs and measures the trajectory of both legs. However, both legs might be close to each other, and one leg might be hidden from the sensor. This is especially the case during the turning motion in the TUG, where the time that a leg is hidden from the LRS is longer than that during straight walking and the moving direction rapidly changes. These situations are likely to lead to false tracking and deteriorate the measurement accuracy of the leg positions. To solve these problems, a novel data association considering gait phase and a Catmull–Rom spline-based interpolation during the occlusion are proposed. From the experimental results with young people, we confirm that the proposed methods can reduce the chances of false tracking. In addition, we verify the measurement accuracy of the leg trajectory compared to a three-dimensional motion analysis system (VICON). Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

17 pages, 1802 KiB

Open AccessArticle

Effects of Nanowire Length and Surface Roughness on the Electrochemical Sensor Properties of Nafion-Free, Vertically Aligned Pt Nanowire Array Electrodes

by Zhiyang Li, Calvin Leung, Fan Gao and Zhiyong Gu

Sensors 2015, 15(9), 22473-22489; https://doi.org/10.3390/s150922473 - 4 Sep 2015

Cited by 32 | Viewed by 9202

Abstract

In this paper, vertically aligned Pt nanowire arrays (PtNWA) with different lengths and surface roughnesses were fabricated and their electrochemical performance toward hydrogen peroxide (H₂O₂) detection was studied. The nanowire arrays were synthesized by electroplating Pt in nanopores of [...] Read more.

In this paper, vertically aligned Pt nanowire arrays (PtNWA) with different lengths and surface roughnesses were fabricated and their electrochemical performance toward hydrogen peroxide (H₂O₂) detection was studied. The nanowire arrays were synthesized by electroplating Pt in nanopores of anodic aluminum oxide (AAO) template. Different parameters, such as current density and deposition time, were precisely controlled to synthesize nanowires with different surface roughnesses and various lengths from 3 μm to 12 μm. The PtNWA electrodes showed better performance than the conventional electrodes modified by Pt nanowires randomly dispersed on the electrode surface. The results indicate that both the length and surface roughness can affect the sensing performance of vertically aligned Pt nanowire array electrodes. Generally, longer nanowires with rougher surfaces showed better electrochemical sensing performance. The 12 μm rough surface PtNWA presented the largest sensitivity (654 μA·mM⁻¹·cm⁻²) among all the nanowires studied, and showed a limit of detection of 2.4 μM. The 12 μm rough surface PtNWA electrode also showed good anti-interference property from chemicals that are typically present in the biological samples such as ascorbic, uric acid, citric acid, and glucose. The sensing performance in real samples (river water) was tested and good recovery was observed. These Nafion-free, vertically aligned Pt nanowires with surface roughness control show great promise as versatile electrochemical sensors and biosensors. Full article

(This article belongs to the Special Issue Electrochemical Sensors and Biosensors: From Bench-Top to Point-of-Care)

► Show Figures

Graphical abstract

19 pages, 1645 KiB

Open AccessArticle

Carbon Nanomaterials Based Electrochemical Sensors/Biosensors for the Sensitive Detection of Pharmaceutical and Biological Compounds

by Bal-Ram Adhikari, Maduraiveeran Govindhan and Aicheng Chen

Sensors 2015, 15(9), 22490-22508; https://doi.org/10.3390/s150922490 - 4 Sep 2015

Cited by 153 | Viewed by 12277

Abstract

Electrochemical sensors and biosensors have attracted considerable attention for the sensitive detection of a variety of biological and pharmaceutical compounds. Since the discovery of carbon-based nanomaterials, including carbon nanotubes, C₆₀ and graphene, they have garnered tremendous interest for their potential in the [...] Read more.

Electrochemical sensors and biosensors have attracted considerable attention for the sensitive detection of a variety of biological and pharmaceutical compounds. Since the discovery of carbon-based nanomaterials, including carbon nanotubes, C₆₀ and graphene, they have garnered tremendous interest for their potential in the design of high-performance electrochemical sensor platforms due to their exceptional thermal, mechanical, electronic, and catalytic properties. Carbon nanomaterial-based electrochemical sensors have been employed for the detection of various analytes with rapid electron transfer kinetics. This feature article focuses on the recent design and use of carbon nanomaterials, primarily single-walled carbon nanotubes (SWCNTs), reduced graphene oxide (rGO), SWCNTs-rGO, Au nanoparticle-rGO nanocomposites, and buckypaper as sensing materials for the electrochemical detection of some representative biological and pharmaceutical compounds such as methylglyoxal, acetaminophen, valacyclovir, β-nicotinamide adenine dinucleotide hydrate (NADH), and glucose. Furthermore, the electrochemical performance of SWCNTs, rGO, and SWCNT-rGO for the detection of acetaminophen and valacyclovir was comparatively studied, revealing that SWCNT-rGO nanocomposites possess excellent electrocatalytic activity in comparison to individual SWCNT and rGO platforms. The sensitive, reliable and rapid analysis of critical disease biomarkers and globally emerging pharmaceutical compounds at carbon nanomaterials based electrochemical sensor platforms may enable an extensive range of applications in preemptive medical diagnostics. Full article

(This article belongs to the Special Issue Electrochemical Sensors and Biosensors: From Bench-Top to Point-of-Care)

► Show Figures

Graphical abstract

21 pages, 1934 KiB

Open AccessArticle

A 181 GOPS AKAZE Accelerator Employing Discrete-Time Cellular Neural Networks for Real-Time Feature Extraction

by Guangli Jiang, Leibo Liu, Wenping Zhu, Shouyi Yin and Shaojun Wei

Sensors 2015, 15(9), 22509-22529; https://doi.org/10.3390/s150922509 - 4 Sep 2015

Cited by 4 | Viewed by 6670

Abstract

This paper proposes a real-time feature extraction VLSI architecture for high-resolution images based on the accelerated KAZE algorithm. Firstly, a new system architecture is proposed. It increases the system throughput, provides flexibility in image resolution, and offers trade-offs between speed and scaling robustness. [...] Read more.

This paper proposes a real-time feature extraction VLSI architecture for high-resolution images based on the accelerated KAZE algorithm. Firstly, a new system architecture is proposed. It increases the system throughput, provides flexibility in image resolution, and offers trade-offs between speed and scaling robustness. The architecture consists of a two-dimensional pipeline array that fully utilizes computational similarities in octaves. Secondly, a substructure (block-serial discrete-time cellular neural network) that can realize a nonlinear filter is proposed. This structure decreases the memory demand through the removal of data dependency. Thirdly, a hardware-friendly descriptor is introduced in order to overcome the hardware design bottleneck through the polar sample pattern; a simplified method to realize rotation invariance is also presented. Finally, the proposed architecture is designed in TSMC 65 nm CMOS technology. The experimental results show a performance of 127 fps in full HD resolution at 200 MHz frequency. The peak performance reaches 181 GOPS and the throughput is double the speed of other state-of-the-art architectures. Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

Figure 1

17 pages, 4227 KiB

Open AccessArticle

Design and Realization of a Three Degrees of Freedom Displacement Measurement System Composed of Hall Sensors Based on Magnetic Field Fitting by an Elliptic Function

by Bo Zhao, Lei Wang and Jiu-Bin Tan

Sensors 2015, 15(9), 22530-22546; https://doi.org/10.3390/s150922530 - 8 Sep 2015

Cited by 13 | Viewed by 6597

Abstract

This paper presents the design and realization of a three degrees of freedom (DOFs) displacement measurement system composed of Hall sensors, which is built for the XYθz displacement measurement of the short stroke stage of the reticle stage of lithography. The measurement [...] Read more.

This paper presents the design and realization of a three degrees of freedom (DOFs) displacement measurement system composed of Hall sensors, which is built for the XYθz displacement measurement of the short stroke stage of the reticle stage of lithography. The measurement system consists of three pairs of permanent magnets mounted on the same plane on the short stroke stage along the Y, Y, X directions, and three single axis Hall sensors correspondingly mounted on the frame of the reticle stage. The emphasis is placed on the decoupling and magnetic field fitting of the three DOFs measurement system. The model of the measurement system is illustrated, and the XY positions and θ_Z rotation of the short stroke stage can be obtained by decoupling the sensor outputs. A magnetic field fitting by an elliptic function-based compensation method is proposed. The practical field intensity of a permanent magnet at a certain plane height can be substituted for the output voltage of a Hall sensors, which can be expressed by the elliptic function through experimental data as the crucial issue to calculate the three DOFs displacement. Experimental results of the Hall sensor displacement measurement system are presented to validate the proposed three DOFs measurement system. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

14 pages, 1533 KiB

Open AccessCommunication

Aptameric Recognition-Modulated Electroactivity of Poly(4-Styrenesolfonic Acid)-Doped Polyaniline Films for Single-Shot Detection of Tetrodotoxin

by Gertrude Fomo, Tesfaye T. Waryo, Christopher E. Sunday, Abd A. Baleg, Priscilla G. Baker and Emmanuel I. Iwuoha

Sensors 2015, 15(9), 22547-22560; https://doi.org/10.3390/s150922547 - 8 Sep 2015

Cited by 29 | Viewed by 7719

Abstract

The work being reported is the first electrochemical sensor for tetrodotoxin (TTX). It was developed on a glassy carbon electrodes (C) that was modified with poly(4-styrenesolfonic acid)-doped polyaniline film (PANI/PSSA). An amine-end functionalized TTX-binding aptamer, 5′-NH₂-AAAAATTTCACACGGGTGCCTCGGCTGTCC-3′ (NH₂-Apt), was grafted [...] Read more.

The work being reported is the first electrochemical sensor for tetrodotoxin (TTX). It was developed on a glassy carbon electrodes (C) that was modified with poly(4-styrenesolfonic acid)-doped polyaniline film (PANI/PSSA). An amine-end functionalized TTX-binding aptamer, 5′-NH₂-AAAAATTTCACACGGGTGCCTCGGCTGTCC-3′ (NH₂-Apt), was grafted via covalent glutaraldehyde (glu) cross-linking. The resulting aptasensor (C//PANI⁺/PSSA-glu-NH_2-Apt) was interrogated by cyclic voltammetry (CV) and electrochemical impedance spectroscopy (EIS) in sodium acetate buffer (NaOAc, pH 4.8) before and after 30 min incubation in standard TTX solutions. Both CV and EIS results confirmed that the binding of the analyte to the immobilized aptamer modulated the electrochemical properties of the sensor: particularly the charge transfer resistance (R_ct) of the PANI⁺/PSSA film, which served as a signal reporter. Based on the R_ct calibration curve of the TTX aptasensor, the values of the dynamic linear range (DLR), sensitivity and limit of detection (LOD) of the sensor were determined to be 0.23–1.07 ng·mL⁻¹ TTX, 134.88 ± 11.42 Ω·ng·mL⁻¹ and 0.199 ng·mL⁻¹, respectively. Further studies are being planned to improve the DLR as well as to evaluate selectivity and matrix effects in real samples. Full article

(This article belongs to the Section Biosensors)

► Show Figures

Figure 1

26 pages, 12381 KiB

Open AccessArticle

Segmentation of White Blood Cells through Nucleus Mark Watershed Operations and Mean Shift Clustering

by Zhi Liu, Jing Liu, Xiaoyan Xiao, Hui Yuan, Xiaomei Li, Jun Chang and Chengyun Zheng

Sensors 2015, 15(9), 22561-22586; https://doi.org/10.3390/s150922561 - 8 Sep 2015

Cited by 62 | Viewed by 8631

Abstract

This paper presents a novel method for segmentation of white blood cells (WBCs) in peripheral blood and bone marrow images under different lights through mean shift clustering, color space conversion and nucleus mark watershed operation (NMWO). The proposed method focuses on obtaining seed [...] Read more.

This paper presents a novel method for segmentation of white blood cells (WBCs) in peripheral blood and bone marrow images under different lights through mean shift clustering, color space conversion and nucleus mark watershed operation (NMWO). The proposed method focuses on obtaining seed points. First, color space transformation and image enhancement techniques are used to obtain nucleus groups as inside seeds. Second, mean shift clustering, selection of the C channel component in the CMYK model, and illumination intensity adjustment are employed to acquire WBCs as outside seeds. Third, the seeds and NMWO are employed to precisely determine WBCs and solve the cell adhesion problem. Morphological operations are further used to improve segmentation accuracy. Experimental results demonstrate that the algorithm exhibits higher segmentation accuracy and robustness compared with traditional methods. Full article

(This article belongs to the Section Biosensors)

► Show Figures

Figure 1

29 pages, 1054 KiB

Open AccessArticle

Revisiting Gaussian Process Regression Modeling for Localization in Wireless Sensor Networks

by Philipp Richter and Manuel Toledano-Ayala

Sensors 2015, 15(9), 22587-22615; https://doi.org/10.3390/s150922587 - 8 Sep 2015

Cited by 37 | Viewed by 8181

Abstract

Signal strength-based positioning in wireless sensor networks is a key technology for seamless, ubiquitous localization, especially in areas where Global Navigation Satellite System (GNSS) signals propagate poorly. To enable wireless local area network (WLAN) location fingerprinting in larger areas while maintaining accuracy, methods [...] Read more.

Signal strength-based positioning in wireless sensor networks is a key technology for seamless, ubiquitous localization, especially in areas where Global Navigation Satellite System (GNSS) signals propagate poorly. To enable wireless local area network (WLAN) location fingerprinting in larger areas while maintaining accuracy, methods to reduce the effort of radio map creation must be consolidated and automatized. Gaussian process regression has been applied to overcome this issue, also with auspicious results, but the fit of the model was never thoroughly assessed. Instead, most studies trained a readily available model, relying on the zero mean and squared exponential covariance function, without further scrutinization. This paper studies the Gaussian process regression model selection for WLAN fingerprinting in indoor and outdoor environments. We train several models for indoor/outdoor- and combined areas; we evaluate them quantitatively and compare them by means of adequate model measures, hence assessing the fit of these models directly. To illuminate the quality of the model fit, the residuals of the proposed model are investigated, as well. Comparative experiments on the positioning performance verify and conclude the model selection. In this way, we show that the standard model is not the most appropriate, discuss alternatives and present our best candidate. Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

Graphical abstract

30 pages, 819 KiB

Open AccessArticle

Energy-Efficient Integration of Continuous Context Sensing and Prediction into Smartwatches

by Reza Rawassizadeh, Martin Tomitsch, Manouchehr Nourizadeh, Elaheh Momeni, Aaron Peery, Liudmila Ulanova and Michael Pazzani

Sensors 2015, 15(9), 22616-22645; https://doi.org/10.3390/s150922616 - 8 Sep 2015

Cited by 52 | Viewed by 11200

Abstract

As the availability and use of wearables increases, they are becoming a promising platform for context sensing and context analysis. Smartwatches are a particularly interesting platform for this purpose, as they offer salient advantages, such as their proximity to the human body. However, [...] Read more.

As the availability and use of wearables increases, they are becoming a promising platform for context sensing and context analysis. Smartwatches are a particularly interesting platform for this purpose, as they offer salient advantages, such as their proximity to the human body. However, they also have limitations associated with their small form factor, such as processing power and battery life, which makes it difficult to simply transfer smartphone-based context sensing and prediction models to smartwatches. In this paper, we introduce an energy-efficient, generic, integrated framework for continuous context sensing and prediction on smartwatches. Our work extends previous approaches for context sensing and prediction on wrist-mounted wearables that perform predictive analytics outside the device. We offer a generic sensing module and a novel energy-efficient, on-device prediction module that is based on a semantic abstraction approach to convert sensor data into meaningful information objects, similar to human perception of a behavior. Through six evaluations, we analyze the energy efficiency of our framework modules, identify the optimal file structure for data access and demonstrate an increase in accuracy of prediction through our semantic abstraction method. The proposed framework is hardware independent and can serve as a reference model for implementing context sensing and prediction on small wearable devices beyond smartwatches, such as body-mounted cameras. Full article

(This article belongs to the Section State-of-the-Art Sensors Technologies)

► Show Figures

Figure 1

14 pages, 888 KiB

Open AccessArticle

Affinity Propagation Clustering of Measurements for Multiple Extended Target Tracking

by Tao Zhang and Renbiao Wu

Sensors 2015, 15(9), 22646-22659; https://doi.org/10.3390/s150922646 - 8 Sep 2015

Cited by 15 | Viewed by 4864

Abstract

More measurements are generated by the target per observation interval, when the target is detected by a high resolution sensor, or there are more measurement sources on the target surface. Such a target is referred to as an extended target. The probability hypothesis [...] Read more.

More measurements are generated by the target per observation interval, when the target is detected by a high resolution sensor, or there are more measurement sources on the target surface. Such a target is referred to as an extended target. The probability hypothesis density filter is considered an efficient method for tracking multiple extended targets. However, the crucial problem of how to accurately and effectively partition the measurements of multiple extended targets remains unsolved. In this paper, affinity propagation clustering is introduced into measurement partitioning for extended target tracking, and the elliptical gating technique is used to remove the clutter measurements, which makes the affinity propagation clustering capable of partitioning the measurement in a densely cluttered environment with high accuracy. The Gaussian mixture probability hypothesis density filter is implemented for multiple extended target tracking. Numerical results are presented to demonstrate the performance of the proposed algorithm, which provides improved performance, while obviously reducing the computational complexity. Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

Figure 1

12 pages, 1587 KiB

Open AccessArticle

High-Temperature Dielectric Properties of Aluminum Nitride Ceramic for Wireless Passive Sensing Applications

by Jun Liu, Yukun Yuan, Zhong Ren, Qiulin Tan and Jijun Xiong

Sensors 2015, 15(9), 22660-22671; https://doi.org/10.3390/s150922660 - 8 Sep 2015

Cited by 20 | Viewed by 8682

Abstract

The accurate characterization of the temperature-dependent permittivity of aluminum nitride (AlN) ceramic is quite critical to the application of wireless passive sensors for harsh environments. Since the change of the temperature-dependent permittivity will vary the ceramic-based capacitance, which can be converted into the [...] Read more.

The accurate characterization of the temperature-dependent permittivity of aluminum nitride (AlN) ceramic is quite critical to the application of wireless passive sensors for harsh environments. Since the change of the temperature-dependent permittivity will vary the ceramic-based capacitance, which can be converted into the change of the resonant frequency, an LC resonator, based on AlN ceramic, is prepared by the thick film technology. The dielectric properties of AlN ceramic are measured by the wireless coupling method, and discussed within the temperature range of 12 °C (room temperature) to 600 °C. The results show that the extracted relative permittivity of ceramic at room temperature is 2.3% higher than the nominal value of 9, and increases from 9.21 to 10.79, and the quality factor Q is decreased from 29.77 at room temperature to 3.61 at 600 °C within the temperature range. Full article

(This article belongs to the Special Issue Sensors for Harsh Environments)

► Show Figures

Figure 1

20 pages, 1492 KiB

Open AccessArticle

Novel PCR Assays Complement Laser Biosensor-Based Method and Facilitate Listeria Species Detection from Food

by Kwang-Pyo Kim, Atul K. Singh, Xingjian Bai, Lena Leprun and Arun K. Bhunia

Sensors 2015, 15(9), 22672-22691; https://doi.org/10.3390/s150922672 - 8 Sep 2015

Cited by 12 | Viewed by 6647

Abstract

The goal of this study was to develop the Listeria species-specific PCR assays based on a house-keeping gene (lmo1634) encoding alcohol acetaldehyde dehydrogenase (Aad), previously designated as Listeria adhesion protein (LAP), and compare results with a label-free light scattering sensor, BARDOT [...] Read more.

The goal of this study was to develop the Listeria species-specific PCR assays based on a house-keeping gene (lmo1634) encoding alcohol acetaldehyde dehydrogenase (Aad), previously designated as Listeria adhesion protein (LAP), and compare results with a label-free light scattering sensor, BARDOT (bacterial rapid detection using optical scattering technology). PCR primer sets targeting the lap genes from the species of Listeria sensu stricto were designed and tested with 47 Listeria and 8 non-Listeria strains. The resulting PCR primer sets detected either all species of Listeria sensu stricto or individual L. innocua, L. ivanovii and L. seeligeri, L. welshimeri, and L. marthii without producing any amplified products from other bacteria tested. The PCR assays with Listeria sensu stricto-specific primers also successfully detected all species of Listeria sensu stricto and/or Listeria innocua from mixed culture-inoculated food samples, and each bacterium in food was verified by using the light scattering sensor that generated unique scatter signature for each species of Listeria tested. The PCR assays based on the house-keeping gene aad (lap) can be used for detection of either all species of Listeria sensu stricto or certain individual Listeria species in a mixture from food with a detection limit of about 10⁴ CFU/mL. Full article

(This article belongs to the Special Issue Sensors for Food Safety and Quality)

► Show Figures

Graphical abstract

13 pages, 1734 KiB

Open AccessArticle

Design and Application of a High Sensitivity Piezoresistive Pressure Sensor for Low Pressure Conditions

by Huiyang Yu and Jianqiu Huang

Sensors 2015, 15(9), 22692-22704; https://doi.org/10.3390/s150922692 - 8 Sep 2015

Cited by 48 | Viewed by 7397

Abstract

In this paper, a pressure sensor for low pressure detection (0.5 kPa–40 kPa) is proposed. In one structure (No. 1), the silicon membrane is partly etched to form a crossed beam on its top for stress concentration. An aluminum layer is also deposited [...] Read more.

In this paper, a pressure sensor for low pressure detection (0.5 kPa–40 kPa) is proposed. In one structure (No. 1), the silicon membrane is partly etched to form a crossed beam on its top for stress concentration. An aluminum layer is also deposited as part of the beam. Four piezoresistors are fabricated. Two are located at the two ends of the beam. The other two are located at the membrane periphery. Four piezoresistors connect into a Wheatstone bridge. To demonstrate the stress concentrate effect of this structure, two other structures were designed and fabricated. One is a flat membrane structure (No. 2), the other is a structure with the aluminum beam, but without etched silicon (No. 3). The measurement results of these three structures show that the No.1 structure has the highest sensitivity, which is about 3.8 times that of the No. 2 structure and 2.7 times that of the No. 3 structure. They also show that the residual stress in the beam has some backside effect on the sensor performance. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

19 pages, 6393 KiB

Open AccessArticle

A Simplified, Light Emitting Diode (LED) Based, Modular System to be Used for the Rapid Evaluation of Fruit and Vegetable Quality: Development and Validation on Dye Solutions

by Raffaele Civelli, Valentina Giovenzana, Roberto Beghi, Ezio Naldi, Riccardo Guidetti and Roberto Oberti

Sensors 2015, 15(9), 22705-22723; https://doi.org/10.3390/s150922705 - 8 Sep 2015

Cited by 31 | Viewed by 5681

Abstract

NIR spectroscopy has proven to be one of the most efficient and ready to transfer tools to monitor product’s quality. Portable VIS/NIR instruments are particularly versatile and suitable for field use to monitor the ripening process or quality parameters. The aim of this [...] Read more.

NIR spectroscopy has proven to be one of the most efficient and ready to transfer tools to monitor product’s quality. Portable VIS/NIR instruments are particularly versatile and suitable for field use to monitor the ripening process or quality parameters. The aim of this work is to develop and evaluate a new simplified optoelectronic system for potential measurements on fruit and vegetables directly in the field. The development, characterization and validation of an operative prototype is discussed. LED technology was chosen for the design, and spectral acquisition at four specific wavelengths (630, 690, 750 and 850 nm) was proposed. Nevertheless, attention was given to the modularity and versatility of the system. Indeed, the possibility to change the light sources module with other wavelengths allows one to adapt the use of the same device for different foreseeable applications and objectives, e.g., ripeness evaluation, detection of particular diseases and disorders, chemical and physical property prediction, shelf life analysis, as well as for different natures of products (berry, leaf or liquid). Validation tests on blue dye water solutions have shown the capability of the system of discriminating low levels of reflectance, with a repeatability characterized by a standard deviation proportional to the measured intensity and in general limited to 2%–4%. Full article

(This article belongs to the Special Issue Optical Sensors for Chemical, Biological and Industrial Applications)

► Show Figures

Graphical abstract

13 pages, 6392 KiB

Open AccessArticle

New Opportunities in Mid-Infrared Emission Control

by Peter Geiser

Sensors 2015, 15(9), 22724-22736; https://doi.org/10.3390/s150922724 - 9 Sep 2015

Cited by 27 | Viewed by 9882

Abstract

Tunable laser absorption spectroscopy (TLAS) has been well accepted as a preferred measurement technique for many industrial applications in recent years, especially for in situ applications. Previously, mainly near-infrared lasers have been used in TLAS sensors. The advent of compact mid-infrared light sources, [...] Read more.

Tunable laser absorption spectroscopy (TLAS) has been well accepted as a preferred measurement technique for many industrial applications in recent years, especially for in situ applications. Previously, mainly near-infrared lasers have been used in TLAS sensors. The advent of compact mid-infrared light sources, like quantum cascade lasers and interband cascade lasers, has made it possible to detect gases with better sensitivity by utilizing fundamental absorption bands and to measure species that do not have any absorption lines in the near-infrared spectral region. This technological advancement has allowed developing new sensors for gases, such as nitric oxide and sulfur dioxide, for industrial applications. Detection limits of better than 1 ppm·m for nitric oxide and better than 10 ppm·m for sulfur dioxide are demonstrated in field experiments. Full article

(This article belongs to the Special Issue Chemical Sensors based on In Situ Spectroscopy)

► Show Figures

Figure 1

13 pages, 1472 KiB

Open AccessArticle

Development of Ionic Liquid Modified Disposable Graphite Electrodes for Label-Free Electrochemical Detection of DNA Hybridization Related to Microcystis spp.

by Ceren Sengiz, Gulsah Congur and Arzum Erdem

Sensors 2015, 15(9), 22737-22749; https://doi.org/10.3390/s150922737 - 9 Sep 2015

Cited by 20 | Viewed by 6251

Abstract

In this present study, ionic liquid (1-butyl-3-methylimidazolium hexafluorophosphate (IL)) modified pencil graphite electrode (IL-PGEs) was developed for electrochemical monitoring of DNA hybridization related to Microcystis spp. (MYC). The characterization of IL-PGEs was performed using microscopic and electrochemical techniques. DNA hybridization related to MYC [...] Read more.

In this present study, ionic liquid (1-butyl-3-methylimidazolium hexafluorophosphate (IL)) modified pencil graphite electrode (IL-PGEs) was developed for electrochemical monitoring of DNA hybridization related to Microcystis spp. (MYC). The characterization of IL-PGEs was performed using microscopic and electrochemical techniques. DNA hybridization related to MYC was then explored at the surface of IL-PGEs using differential pulse voltammetry (DPV) technique. After the experimental parameters were optimized, the sequence-selective DNA hybridization related to MYC was performed in the case of hybridization between MYC probe and its complementary DNA target, noncomplementary (NC) or mismatched DNA sequence (MM), or and in the presence of mixture of DNA target: NC (1:1) and DNA target: MM (1:1). Full article

(This article belongs to the Special Issue Electrochemical Sensors and Biosensors: From Bench-Top to Point-of-Care)

► Show Figures

Graphical abstract

26 pages, 3007 KiB

Open AccessArticle

An Improved Method of Parameter Identification and Damage Detection in Beam Structures under Flexural Vibration Using Wavelet Multi-Resolution Analysis

by Seyed Alireza Ravanfar, Hashim Abdul Razak, Zubaidah Ismail and Hooman Monajemi

Sensors 2015, 15(9), 22750-22775; https://doi.org/10.3390/s150922750 - 9 Sep 2015

Cited by 15 | Viewed by 5917

Abstract

This paper reports on a two-step approach for optimally determining the location and severity of damage in beam structures under flexural vibration. The first step focuses on damage location detection. This is done by defining the damage index called relative wavelet packet entropy [...] Read more.

This paper reports on a two-step approach for optimally determining the location and severity of damage in beam structures under flexural vibration. The first step focuses on damage location detection. This is done by defining the damage index called relative wavelet packet entropy (RWPE). The damage severities of the model in terms of loss of stiffness are assessed in the second step using the inverse solution of equations of motion of a structural system in the wavelet domain. For this purpose, the connection coefficient of the scaling function to convert the equations of motion in the time domain into the wavelet domain is applied. Subsequently, the dominant components based on the relative energies of the wavelet packet transform (WPT) components of the acceleration responses are defined. To obtain the best estimation of the stiffness parameters of the model, the least squares error minimization is used iteratively over the dominant components. Then, the severity of the damage is evaluated by comparing the stiffness parameters of the identified model before and after the occurrence of damage. The numerical and experimental results demonstrate that the proposed method is robust and effective for the determination of damage location and accurate estimation of the loss in stiffness due to damage. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Graphical abstract

22 pages, 4390 KiB

Open AccessArticle

A Wireless Optogenetic Headstage with Multichannel Electrophysiological Recording Capability

by Gabriel Gagnon-Turcotte, Alireza Avakh Kisomi, Reza Ameli, Charles-Olivier Dufresne Camaro, Yoan LeChasseur, Jean-Luc Néron, Paul Brule Bareil, Paul Fortier, Cyril Bories, Yves De Koninck and Benoit Gosselin

Sensors 2015, 15(9), 22776-22797; https://doi.org/10.3390/s150922776 - 9 Sep 2015

Cited by 37 | Viewed by 10409

Abstract

We present a small and lightweight fully wireless optogenetic headstage capable of optical neural stimulation and electrophysiological recording. The headstage is suitable for conducting experiments with small transgenic rodents, and features two implantable fiber-coupled light-emitting diode (LED) and two electrophysiological recording channels. This [...] Read more.

We present a small and lightweight fully wireless optogenetic headstage capable of optical neural stimulation and electrophysiological recording. The headstage is suitable for conducting experiments with small transgenic rodents, and features two implantable fiber-coupled light-emitting diode (LED) and two electrophysiological recording channels. This system is powered by a small lithium-ion battery and is entirely built using low-cost commercial off-the-shelf components for better flexibility, reduced development time and lower cost. Light stimulation uses customizable stimulation patterns of varying frequency and duty cycle. The optical power that is sourced from the LED is delivered to target light-sensitive neurons using implantable optical fibers, which provide a measured optical power density of 70 mW/mm² at the tip. The headstage is using a novel foldable rigid-flex printed circuit board design, which results into a lightweight and compact device. Recording experiments performed in the cerebral cortex of transgenic ChR2 mice under anesthetized conditions show that the proposed headstage can trigger neuronal activity using optical stimulation, while recording microvolt amplitude electrophysiological signals. Full article

(This article belongs to the Special Issue Miniaturized Wireless Biosensors)

► Show Figures

Figure 1

13 pages, 1161 KiB

Open AccessArticle

A New Trans-Tympanic Microphone Approach for Fully Implantable Hearing Devices

by Seong Tak Woo, Dong Ho Shin, Hyung-Gyu Lim, Ki-Woong Seong, Peter Gottlieb, Sunil Puria, Kyu-Yup Lee and Jin-Ho Cho

Sensors 2015, 15(9), 22798-22810; https://doi.org/10.3390/s150922798 - 9 Sep 2015

Cited by 13 | Viewed by 10919

Abstract

Fully implantable hearing devices (FIHDs) have been developed as a new technology to overcome the disadvantages of conventional acoustic hearing aids. The implantable microphones currently used in FIHDs, however, have difficulty achieving high sensitivity to environmental sounds, low sensitivity to body noise, and [...] Read more.

Fully implantable hearing devices (FIHDs) have been developed as a new technology to overcome the disadvantages of conventional acoustic hearing aids. The implantable microphones currently used in FIHDs, however, have difficulty achieving high sensitivity to environmental sounds, low sensitivity to body noise, and ease of implantation. In general, implantable microphones may be placed under the skin in the temporal bone region of the skull. In this situation, body noise picked up during mastication and touching can be significant, and the layer of skin and hair can both attenuate and distort sounds. The new approach presently proposed is a microphone implanted at the tympanic membrane. This method increases the microphone’s sensitivity by utilizing the pinna’s directionally dependent sound collection capabilities and the natural resonances of the ear canal. The sensitivity and insertion loss of this microphone were measured in human cadaveric specimens in the 0.1 to 16 kHz frequency range. In addition, the maximum stable gain due to feedback between the trans-tympanic microphone and a round-window-drive transducer, was measured. The results confirmed in situ high-performance capabilities of the proposed trans-tympanic microphone. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

15 pages, 1397 KiB

Open AccessArticle

Geometric Parameters Estimation and Calibration in Cone-Beam Micro-CT

by Jintao Zhao, Xiaodong Hu, Jing Zou and Xiaotang Hu

Sensors 2015, 15(9), 22811-22825; https://doi.org/10.3390/s150922811 - 9 Sep 2015

Cited by 24 | Viewed by 9236

Abstract

The quality of Computed Tomography (CT) images crucially depends on the precise knowledge of the scanner geometry. Therefore, it is necessary to estimate and calibrate the misalignments before image acquisition. In this paper, a Two-Piece-Ball (TPB) phantom is used to estimate a set [...] Read more.

The quality of Computed Tomography (CT) images crucially depends on the precise knowledge of the scanner geometry. Therefore, it is necessary to estimate and calibrate the misalignments before image acquisition. In this paper, a Two-Piece-Ball (TPB) phantom is used to estimate a set of parameters that describe the geometry of a cone-beam CT system. Only multiple projections of the TPB phantom at one position are required, which can avoid the rotation errors when acquiring multi-angle projections. Also, a corresponding algorithm is derived. The performance of the method is evaluated through simulation and experimental data. The results demonstrated that the proposed method is valid and easy to implement. Furthermore, the experimental results from the Micro-CT system demonstrate the ability to reduce artifacts and improve image quality through geometric parameter calibration. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

28 pages, 4614 KiB

Open AccessArticle

Push-Broom-Type Very High-Resolution Satellite Sensor Data Correction Using Combined Wavelet-Fourier and Multiscale Non-Local Means Filtering

by Wonseok Kang, Soohwan Yu, Doochun Seo, Jaeheon Jeong and Joonki Paik

Sensors 2015, 15(9), 22826-22853; https://doi.org/10.3390/s150922826 - 10 Sep 2015

Cited by 16 | Viewed by 6428

Abstract

In very high-resolution (VHR) push-broom-type satellite sensor data, both destriping and denoising methods have become chronic problems and attracted major research advances in the remote sensing fields. Since the estimation of the original image from a noisy input is an ill-posed problem, a [...] Read more.

In very high-resolution (VHR) push-broom-type satellite sensor data, both destriping and denoising methods have become chronic problems and attracted major research advances in the remote sensing fields. Since the estimation of the original image from a noisy input is an ill-posed problem, a simple noise removal algorithm cannot preserve the radiometric integrity of satellite data. To solve these problems, we present a novel method to correct VHR data acquired by a push-broom-type sensor by combining wavelet-Fourier and multiscale non-local means (NLM) filters. After the wavelet-Fourier filter separates the stripe noise from the mixed noise in the wavelet low- and selected high-frequency sub-bands, random noise is removed using the multiscale NLM filter in both low- and high-frequency sub-bands without loss of image detail. The performance of the proposed method is compared to various existing methods on a set of push-broom-type sensor data acquired by Korean Multi-Purpose Satellite 3 (KOMPSAT-3) with severe stripe and random noise, and the results of the proposed method show significantly improved enhancement results over existing state-of-the-art methods in terms of both qualitative and quantitative assessments. Full article

(This article belongs to the Section Remote Sensors)

► Show Figures

Figure 1

20 pages, 1443 KiB

Open AccessArticle

Vision-Aided RAIM: A New Method for GPS Integrity Monitoring in Approach and Landing Phase

by Li Fu, Jun Zhang, Rui Li, Xianbin Cao and Jinling Wang

Sensors 2015, 15(9), 22854-22873; https://doi.org/10.3390/s150922854 - 10 Sep 2015

Cited by 30 | Viewed by 10047

Abstract

In the 1980s, Global Positioning System (GPS) receiver autonomous integrity monitoring (RAIM) was proposed to provide the integrity of a navigation system by checking the consistency of GPS measurements. However, during the approach and landing phase of a flight path, where there is [...] Read more.

In the 1980s, Global Positioning System (GPS) receiver autonomous integrity monitoring (RAIM) was proposed to provide the integrity of a navigation system by checking the consistency of GPS measurements. However, during the approach and landing phase of a flight path, where there is often low GPS visibility conditions, the performance of the existing RAIM method may not meet the stringent aviation requirements for availability and integrity due to insufficient observations. To solve this problem, a new RAIM method, named vision-aided RAIM (VA-RAIM), is proposed for GPS integrity monitoring in the approach and landing phase. By introducing landmarks as pseudo-satellites, the VA-RAIM enriches the navigation observations to improve the performance of RAIM. In the method, a computer vision system photographs and matches these landmarks to obtain additional measurements for navigation. Nevertheless, the challenging issue is that such additional measurements may suffer from vision errors. To ensure the reliability of the vision measurements, a GPS-based calibration algorithm is presented to reduce the time-invariant part of the vision errors. Then, the calibrated vision measurements are integrated with the GPS observations for integrity monitoring. Simulation results show that the VA-RAIM outperforms the conventional RAIM with a higher level of availability and fault detection rate. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

25 pages, 1397 KiB

Open AccessArticle

Urban Automation Networks: Current and Emerging Solutions for Sensed Data Collection and Actuation in Smart Cities

by Carles Gomez and Josep Paradells

Sensors 2015, 15(9), 22874-22898; https://doi.org/10.3390/s150922874 - 10 Sep 2015

Cited by 34 | Viewed by 8424

Abstract

Urban Automation Networks (UANs) are being deployed worldwide in order to enable Smart City applications. Given the crucial role of UANs, as well as their diversity, it is critically important to assess their properties and trade-offs. This article introduces the requirements and challenges [...] Read more.

Urban Automation Networks (UANs) are being deployed worldwide in order to enable Smart City applications. Given the crucial role of UANs, as well as their diversity, it is critically important to assess their properties and trade-offs. This article introduces the requirements and challenges for UANs, characterizes the main current and emerging UAN paradigms, provides guidelines for their design and/or choice, and comparatively examines their performance in terms of a variety of parameters including coverage, power consumption, latency, standardization status and economic cost. Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

Graphical abstract

15 pages, 1400 KiB

Open AccessArticle

A Mathematical Model of the Thermo-Anemometric Flowmeter

by Igor Korobiichuk, Olena Bezvesilna, Andriі Ilchenko, Valentina Shadura, Michał Nowicki and Roman Szewczyk

Sensors 2015, 15(9), 22899-22913; https://doi.org/10.3390/s150922899 - 11 Sep 2015

Cited by 36 | Viewed by 8421

Abstract

A thermo-anemometric flowmeter design and the principles of its work are presented in the article. A mathematical model of the temperature field in a stream of biofuel is proposed. This model allows one to determine the fuel consumption with high accuracy. Numerical modeling [...] Read more.

A thermo-anemometric flowmeter design and the principles of its work are presented in the article. A mathematical model of the temperature field in a stream of biofuel is proposed. This model allows one to determine the fuel consumption with high accuracy. Numerical modeling of the heater heat balance in the fuel flow of a thermo-anemometric flowmeter is conducted and the results are analyzed. Methods for increasing the measurement speed and accuracy of a thermo-anemometric flowmeter are proposed. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Graphical abstract

15 pages, 1571 KiB

Open AccessArticle

An Electrochemical Impedance Spectroscopy-Based Technique to Identify and Quantify Fermentable Sugars in Pineapple Waste Valorization for Bioethanol Production

by Claudia Conesa, Eduardo García-Breijo, Edwin Loeff, Lucía Seguí, Pedro Fito and Nicolás Laguarda-Miró

Sensors 2015, 15(9), 22941-22955; https://doi.org/10.3390/s150922941 - 11 Sep 2015

Cited by 16 | Viewed by 6262

Abstract

Electrochemical Impedance Spectroscopy (EIS) has been used to develop a methodology able to identify and quantify fermentable sugars present in the enzymatic hydrolysis phase of second-generation bioethanol production from pineapple waste. Thus, a low-cost non-destructive system consisting of a stainless double needle electrode [...] Read more.

Electrochemical Impedance Spectroscopy (EIS) has been used to develop a methodology able to identify and quantify fermentable sugars present in the enzymatic hydrolysis phase of second-generation bioethanol production from pineapple waste. Thus, a low-cost non-destructive system consisting of a stainless double needle electrode associated to an electronic equipment that allows the implementation of EIS was developed. In order to validate the system, different concentrations of glucose, fructose and sucrose were added to the pineapple waste and analyzed both individually and in combination. Next, statistical data treatment enabled the design of specific Artificial Neural Networks-based mathematical models for each one of the studied sugars and their respective combinations. The obtained prediction models are robust and reliable and they are considered statistically valid (CCR% > 93.443%). These results allow us to introduce this EIS-based technique as an easy, fast, non-destructive, and in-situ alternative to the traditional laboratory methods for enzymatic hydrolysis monitoring. Full article

(This article belongs to the Section Biosensors)

► Show Figures

Figure 1

14 pages, 4451 KiB

Open AccessArticle

Evaluating Sentinel-2 for Lakeshore Habitat Mapping Based on Airborne Hyperspectral Data

by Dimitris Stratoulias, Heiko Balzter, Olga Sykioti, András Zlinszky and Viktor R. Tóth

Sensors 2015, 15(9), 22956-22969; https://doi.org/10.3390/s150922956 - 11 Sep 2015

Cited by 42 | Viewed by 7066

Abstract

Monitoring of lakeshore ecosystems requires fine-scale information to account for the high biodiversity typically encountered in the land-water ecotone. Sentinel-2 is a satellite with high spatial and spectral resolution and improved revisiting frequency and is expected to have significant potential for habitat mapping [...] Read more.

Monitoring of lakeshore ecosystems requires fine-scale information to account for the high biodiversity typically encountered in the land-water ecotone. Sentinel-2 is a satellite with high spatial and spectral resolution and improved revisiting frequency and is expected to have significant potential for habitat mapping and classification of complex lakeshore ecosystems. In this context, investigations of the capabilities of Sentinel-2 in regard to the spatial and spectral dimensions are needed to assess its potential and the quality of the expected output. This study presents the first simulation of the high spatial resolution (i.e., 10 m and 20 m) bands of Sentinel-2 for lakeshore mapping, based on the satellite’s Spectral Response Function and hyperspectral airborne data collected over Lake Balaton, Hungary in August 2010. A comparison of supervised classifications of the simulated products is presented and the information loss from spectral aggregation and spatial upscaling in the context of lakeshore vegetation classification is discussed. We conclude that Sentinel-2 imagery has a strong potential for monitoring fine-scale habitats, such as reed beds. Full article

(This article belongs to the Section Remote Sensors)

► Show Figures

Figure 1

34 pages, 5839 KiB

Open AccessArticle

Map as a Service: A Framework for Visualising and Maximising Information Return from Multi-ModalWireless Sensor Networks

by Mohammad Hammoudeh, Robert Newman, Christopher Dennett, Sarah Mount and Omar Aldabbas

Sensors 2015, 15(9), 22970-23003; https://doi.org/10.3390/s150922970 - 11 Sep 2015

Cited by 43 | Viewed by 6083

Abstract

This paper presents a distributed information extraction and visualisation service, called the mapping service, for maximising information return from large-scale wireless sensor networks. Such a service would greatly simplify the production of higher-level, information-rich, representations suitable for informing other network services and [...] Read more.

This paper presents a distributed information extraction and visualisation service, called the mapping service, for maximising information return from large-scale wireless sensor networks. Such a service would greatly simplify the production of higher-level, information-rich, representations suitable for informing other network services and the delivery of field information visualisations. The mapping service utilises a blend of inductive and deductive models to map sense data accurately using externally available knowledge. It utilises the special characteristics of the application domain to render visualisations in a map format that are a precise reflection of the concrete reality. This service is suitable for visualising an arbitrary number of sense modalities. It is capable of visualising from multiple independent types of the sense data to overcome the limitations of generating visualisations from a single type of sense modality. Furthermore, the mapping service responds dynamically to changes in the environmental conditions, which may affect the visualisation performance by continuously updating the application domain model in a distributed manner. Finally, a distributed self-adaptation function is proposed with the goal of saving more power and generating more accurate data visualisation. We conduct comprehensive experimentation to evaluate the performance of our mapping service and show that it achieves low communication overhead, produces maps of high fidelity, and further minimises the mapping predictive error dynamically through integrating the application domain model in the mapping service. Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

Figure 1

16 pages, 964 KiB

Open AccessArticle

New Fast Fall Detection Method Based on Spatio-Temporal Context Tracking of Head by Using Depth Images

by Lei Yang, Yanyun Ren, Huosheng Hu and Bo Tian

Sensors 2015, 15(9), 23004-23019; https://doi.org/10.3390/s150923004 - 11 Sep 2015

Cited by 68 | Viewed by 6853

Abstract

In order to deal with the problem of projection occurring in fall detection with two-dimensional (2D) grey or color images, this paper proposed a robust fall detection method based on spatio-temporal context tracking over three-dimensional (3D) depth images that are captured by the [...] Read more.

In order to deal with the problem of projection occurring in fall detection with two-dimensional (2D) grey or color images, this paper proposed a robust fall detection method based on spatio-temporal context tracking over three-dimensional (3D) depth images that are captured by the Kinect sensor. In the pre-processing procedure, the parameters of the Single-Gauss-Model (SGM) are estimated and the coefficients of the floor plane equation are extracted from the background images. Once human subject appears in the scene, the silhouette is extracted by SGM and the foreground coefficient of ellipses is used to determine the head position. The dense spatio-temporal context (STC) algorithm is then applied to track the head position and the distance from the head to floor plane is calculated in every following frame of the depth image. When the distance is lower than an adaptive threshold, the centroid height of the human will be used as the second judgment criteria to decide whether a fall incident happened. Lastly, four groups of experiments with different falling directions are performed. Experimental results show that the proposed method can detect fall incidents that occurred in different orientations, and they only need a low computation complexity. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

30 pages, 609 KiB

Open AccessArticle

Optimization and Control of Cyber-Physical Vehicle Systems

by Justin M. Bradley and Ella M. Atkins

Sensors 2015, 15(9), 23020-23049; https://doi.org/10.3390/s150923020 - 11 Sep 2015

Cited by 90 | Viewed by 14542

Abstract

A cyber-physical system (CPS) is composed of tightly-integrated computation, communication and physical elements. Medical devices, buildings, mobile devices, robots, transportation and energy systems can benefit from CPS co-design and optimization techniques. Cyber-physical vehicle systems (CPVSs) are rapidly advancing due to progress in real-time [...] Read more.

A cyber-physical system (CPS) is composed of tightly-integrated computation, communication and physical elements. Medical devices, buildings, mobile devices, robots, transportation and energy systems can benefit from CPS co-design and optimization techniques. Cyber-physical vehicle systems (CPVSs) are rapidly advancing due to progress in real-time computing, control and artificial intelligence. Multidisciplinary or multi-objective design optimization maximizes CPS efficiency, capability and safety, while online regulation enables the vehicle to be responsive to disturbances, modeling errors and uncertainties. CPVS optimization occurs at design-time and at run-time. This paper surveys the run-time cooperative optimization or co-optimization of cyber and physical systems, which have historically been considered separately. A run-time CPVS is also cooperatively regulated or co-regulated when cyber and physical resources are utilized in a manner that is responsive to both cyber and physical system requirements. This paper surveys research that considers both cyber and physical resources in co-optimization and co-regulation schemes with applications to mobile robotic and vehicle systems. Time-varying sampling patterns, sensor scheduling, anytime control, feedback scheduling, task and motion planning and resource sharing are examined. Full article

(This article belongs to the Special Issue Cyber-Physical Systems)

► Show Figures

Figure 1

21 pages, 1292 KiB

Open AccessArticle

Deep Coupled Integration of CSAC and GNSS for Robust PNT

by Lin Ma, Zheng You, Bin Li, Bin Zhou and Runqi Han

Sensors 2015, 15(9), 23050-23070; https://doi.org/10.3390/s150923050 - 11 Sep 2015

Cited by 14 | Viewed by 6050

Abstract

Global navigation satellite systems (GNSS) are the most widely used positioning, navigation, and timing (PNT) technology. However, a GNSS cannot provide effective PNT services in physical blocks, such as in a natural canyon, canyon city, underground, underwater, and indoors. With the development of [...] Read more.

Global navigation satellite systems (GNSS) are the most widely used positioning, navigation, and timing (PNT) technology. However, a GNSS cannot provide effective PNT services in physical blocks, such as in a natural canyon, canyon city, underground, underwater, and indoors. With the development of micro-electromechanical system (MEMS) technology, the chip scale atomic clock (CSAC) gradually matures, and performance is constantly improved. A deep coupled integration of CSAC and GNSS is explored in this thesis to enhance PNT robustness. “Clock coasting” of CSAC provides time synchronized with GNSS and optimizes navigation equations. However, errors of clock coasting increase over time and can be corrected by GNSS time, which is stable but noisy. In this paper, weighted linear optimal estimation algorithm is used for CSAC-aided GNSS, while Kalman filter is used for GNSS-corrected CSAC. Simulations of the model are conducted, and field tests are carried out. Dilution of precision can be improved by integration. Integration is more accurate than traditional GNSS. When only three satellites are visible, the integration still works, whereas the traditional method fails. The deep coupled integration of CSAC and GNSS can improve the accuracy, reliability, and availability of PNT. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

24 pages, 2469 KiB

Open AccessArticle

Aircraft Detection in High-Resolution SAR Images Based on a Gradient Textural Saliency Map

by Yihua Tan, Qingyun Li, Yansheng Li and Jinwen Tian

Sensors 2015, 15(9), 23071-23094; https://doi.org/10.3390/s150923071 - 11 Sep 2015

Cited by 45 | Viewed by 7244

Abstract

This paper proposes a new automatic and adaptive aircraft target detection algorithm in high-resolution synthetic aperture radar (SAR) images of airport. The proposed method is based on gradient textural saliency map under the contextual cues of apron area. Firstly, the candidate regions with [...] Read more.

This paper proposes a new automatic and adaptive aircraft target detection algorithm in high-resolution synthetic aperture radar (SAR) images of airport. The proposed method is based on gradient textural saliency map under the contextual cues of apron area. Firstly, the candidate regions with the possible existence of airport are detected from the apron area. Secondly, directional local gradient distribution detector is used to obtain a gradient textural saliency map in the favor of the candidate regions. In addition, the final targets will be detected by segmenting the saliency map using CFAR-type algorithm. The real high-resolution airborne SAR image data is used to verify the proposed algorithm. The results demonstrate that this algorithm can detect aircraft targets quickly and accurately, and decrease the false alarm rate. Full article

(This article belongs to the Section Remote Sensors)

► Show Figures

Figure 1

15 pages, 2047 KiB

Open AccessArticle

Pre-Processing Effect on the Accuracy of Event-Based Activity Segmentation and Classification through Inertial Sensors

by Benish Fida, Ivan Bernabucci, Daniele Bibbo, Silvia Conforto and Maurizio Schmid

Sensors 2015, 15(9), 23095-23109; https://doi.org/10.3390/s150923095 - 11 Sep 2015

Cited by 30 | Viewed by 7880

Abstract

Inertial sensors are increasingly being used to recognize and classify physical activities in a variety of applications. For monitoring and fitness applications, it is crucial to develop methods able to segment each activity cycle, e.g., a gait cycle, so that the successive classification [...] Read more.

Inertial sensors are increasingly being used to recognize and classify physical activities in a variety of applications. For monitoring and fitness applications, it is crucial to develop methods able to segment each activity cycle, e.g., a gait cycle, so that the successive classification step may be more accurate. To increase detection accuracy, pre-processing is often used, with a concurrent increase in computational cost. In this paper, the effect of pre-processing operations on the detection and classification of locomotion activities was investigated, to check whether the presence of pre-processing significantly contributes to an increase in accuracy. The pre-processing stages evaluated in this study were inclination correction and de-noising. Level walking, step ascending, descending and running were monitored by using a shank-mounted inertial sensor. Raw and filtered segments, obtained from a modified version of a rule-based gait detection algorithm optimized for sequential processing, were processed to extract time and frequency-based features for physical activity classification through a support vector machine classifier. The proposed method accurately detected >99% gait cycles from raw data and produced >98% accuracy on these segmented gait cycles. Pre-processing did not substantially increase classification accuracy, thus highlighting the possibility of reducing the amount of pre-processing for real-time applications. Full article

(This article belongs to the Special Issue Smartphone-Based Sensors for Non-Invasive Physiological Monitoring)

► Show Figures

Figure 1

16 pages, 1376 KiB

Open AccessArticle

Improving the Detection Limit in a Capillary Raman System for In Situ Gas Analysis by Means of Fluorescence Reduction

by Simone Rupp, Andreas Off, Hendrik Seitz-Moskaliuk, Timothy M. James and Helmut H. Telle

Sensors 2015, 15(9), 23110-23125; https://doi.org/10.3390/s150923110 - 11 Sep 2015

Cited by 19 | Viewed by 8563

Abstract

Raman spectroscopy for low-pressure or trace gas analysis is rather challenging, in particular in process control applications requiring trace detection and real-time response; in general, enhancement techniques are required. One possible enhancement approach which enjoys increasing popularity makes use of an internally-reflective capillary [...] Read more.

Raman spectroscopy for low-pressure or trace gas analysis is rather challenging, in particular in process control applications requiring trace detection and real-time response; in general, enhancement techniques are required. One possible enhancement approach which enjoys increasing popularity makes use of an internally-reflective capillary as the gas cell. However, in the majority of cases, such capillary systems were often limited in their achievable sensitivity by a significant fluorescence background, which is generated as a consequence of interactions between the laser light and optical glass components in the setup. In order to understand and counteract these problems we have investigated a range of fluorescence-reducing measures, including the rearrangement of optical elements, and the replacement of glass components—including the capillary itself—by metal alternatives. These studies now have led to a capillary setup in which fluorescence is practically eliminated and substantial signal enhancement over standard Raman setups is achieved. With this improved (prototype) setup, detection limits of well below 1 mbar could be obtained in sub-second acquisition times, demonstrating the potential of capillary Raman spectroscopy for real-time, in situ gas sensing and process control applications, down to trace level concentrations. Full article

(This article belongs to the Special Issue Chemical Sensors based on In Situ Spectroscopy)

► Show Figures

Figure 1

19 pages, 623 KiB

Open AccessArticle

Temperature and Humidity Sensor Powered by an Individual Microbial Fuel Cell in a Power Management System

by Qi Zheng, Lei Xiong, Bing Mo, Weihong Lu, Suki Kim and Zhenyu Wang

Sensors 2015, 15(9), 23126-23144; https://doi.org/10.3390/s150923126 - 11 Sep 2015

Cited by 26 | Viewed by 9978

Abstract

Microbial fuel cells (MFCs) are of increasing interest as bioelectrochemical systems for decomposing organic materials and converting chemical energy into electricity. The main challenge for this technology is that the low power and voltage of the devices restricts the use of MFCs in [...] Read more.

Microbial fuel cells (MFCs) are of increasing interest as bioelectrochemical systems for decomposing organic materials and converting chemical energy into electricity. The main challenge for this technology is that the low power and voltage of the devices restricts the use of MFCs in practical applications. In this paper, a power management system (PMS) is developed to store the energy and export an increased voltage. The designed PMS successfully increases the low voltage generated by an individual MFC to a high potential of 5 V, capable of driving a wireless temperature and humidity sensor based on nRF24L01 data transmission modules. With the PMS, MFCs can intermittently power the sensor for data transmission to a remote receiver. It is concluded that even an individual MFC can supply the energy required to power the sensor and telemetry system with the designed PMS. The presented PMS can be widely used for unmanned environmental monitoring such as wild rivers, lakes, and adjacent water areas, and offers promise for further advances in MFC technology. Full article

(This article belongs to the Special Issue Power Schemes for Biosensors and Biomedical Devices)

► Show Figures

Figure 1

23 pages, 910 KiB

Open AccessArticle

Butterfly Encryption Scheme for Resource-Constrained Wireless Networks

by Raghav V. Sampangi and Srinivas Sampalli

Sensors 2015, 15(9), 23145-23167; https://doi.org/10.3390/s150923145 - 15 Sep 2015

Cited by 10 | Viewed by 6359

Abstract

Resource-constrained wireless networks are emerging networks such as Radio Frequency Identification (RFID) and Wireless Body Area Networks (WBAN) that might have restrictions on the available resources and the computations that can be performed. These emerging technologies are increasing in popularity, particularly in defence, [...] Read more.

Resource-constrained wireless networks are emerging networks such as Radio Frequency Identification (RFID) and Wireless Body Area Networks (WBAN) that might have restrictions on the available resources and the computations that can be performed. These emerging technologies are increasing in popularity, particularly in defence, anti-counterfeiting, logistics and medical applications, and in consumer applications with growing popularity of the Internet of Things. With communication over wireless channels, it is essential to focus attention on securing data. In this paper, we present an encryption scheme called Butterfly encryption scheme. We first discuss a seed update mechanism for pseudorandom number generators (PRNG), and employ this technique to generate keys and authentication parameters for resource-constrained wireless networks. Our scheme is lightweight, as in it requires less resource when implemented and offers high security through increased unpredictability, owing to continuously changing parameters. Our work focuses on accomplishing high security through simplicity and reuse. We evaluate our encryption scheme using simulation, key similarity assessment, key sequence randomness assessment, protocol analysis and security analysis. Full article

(This article belongs to the Special Issue Identification, Information & Knowledge in the Internet of Things)

► Show Figures

Figure 1

20 pages, 459 KiB

Open AccessArticle

Performance Evaluation of Smartphone Inertial Sensors Measurement for Range of Motion

by Quentin Mourcou, Anthony Fleury, Céline Franco, Frédéric Klopcic and Nicolas Vuillerme

Sensors 2015, 15(9), 23168-23187; https://doi.org/10.3390/s150923168 - 15 Sep 2015

Cited by 93 | Viewed by 9553

Abstract

Over the years, smartphones have become tools for scientific and clinical research. They can, for instance, be used to assess range of motion and joint angle measurement. In this paper, our aim was to determine if smartphones are reliable and accurate enough for [...] Read more.

Over the years, smartphones have become tools for scientific and clinical research. They can, for instance, be used to assess range of motion and joint angle measurement. In this paper, our aim was to determine if smartphones are reliable and accurate enough for clinical motion research. This work proposes an evaluation of different smartphone sensors performance and different manufacturer algorithm performances with the comparison to the gold standard, an industrial robotic arm with an actual standard use inertial motion unit in clinical measurement, an Xsens product. Both dynamic and static protocols were used to perform these comparisons. Root Mean Square (RMS) mean values results for static protocol are under 0.3° for the different smartphones. RMS mean values results for dynamic protocol are more prone to bias induced by Euler angle representation. Statistical results prove that there are no filter effect on results for both protocols and no hardware effect. Smartphones performance can be compared to the Xsens gold standard for clinical research. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

17 pages, 1686 KiB

Open AccessArticle

ISAR Imaging Based on the Wideband Hyperbolic Frequency-ModulationWaveform

by Wei Zhou, Chun-mao Yeh, Kan Jin, Jian Yang and Yao-bin Lu

Sensors 2015, 15(9), 23188-23204; https://doi.org/10.3390/s150923188 - 15 Sep 2015

Cited by 13 | Viewed by 5827

Abstract

The hyperbolic frequency-modulated (HFM) waveform has an inherent Doppler-invariant property. It is more conducive than the conventional linear frequency-modulated (LFM) waveform to high speed moving target imaging. In order to apply the HFM waveform to existing inverse synthetic aperture radar (ISAR) imaging systems, [...] Read more.

The hyperbolic frequency-modulated (HFM) waveform has an inherent Doppler-invariant property. It is more conducive than the conventional linear frequency-modulated (LFM) waveform to high speed moving target imaging. In order to apply the HFM waveform to existing inverse synthetic aperture radar (ISAR) imaging systems, a new pulse compression algorithm is proposed. First, the received HFM echoes are demodulated with the transmitted signal, which is called “decurve” in this paper. By this operation, the bandwidth of the demodulated echoes is effectively reduced and can be processed by the existing narrow-band receiver. Then, the phase of the decurved HFM echoes is analyzed, and thus, the pulse compression is accomplished by space-variant phase compensation. In addition, the space-variant phase compensation is realized by resampling and fast Fourier transform (FFT) with high computational efficiency. Finally, numerical results illustrate the effectiveness of the proposed method. Full article

(This article belongs to the Section Remote Sensors)

► Show Figures

Figure 1

13 pages, 1901 KiB

Open AccessArticle

Capacitive Micromachined Ultrasonic Transducers (CMUTs) for Underwater Imaging Applications

by Jinlong Song, Chenyang Xue, Changde He, Rui Zhang, Linfeng Mu, Juan Cui, Jing Miao, Yuan Liu and Wendong Zhang

Sensors 2015, 15(9), 23205-23217; https://doi.org/10.3390/s150923205 - 15 Sep 2015

Cited by 32 | Viewed by 8684

Abstract

A capacitive micromachined ultrasonic transducer structure for use in underwater imaging is designed, fabricated and tested in this paper. In this structure, a silicon dioxide insulation layer is inserted between the top electrodes and the vibration membrane to prevent ohmic contact. The capacitance-voltage [...] Read more.

A capacitive micromachined ultrasonic transducer structure for use in underwater imaging is designed, fabricated and tested in this paper. In this structure, a silicon dioxide insulation layer is inserted between the top electrodes and the vibration membrane to prevent ohmic contact. The capacitance-voltage (C-V) characteristic curve shows that the transducer offers suitable levels of hysteresis and repeatability performance. The −6 dB center frequency is 540 kHz and the transducer has a bandwidth of 840 kHz for a relative bandwidth of 155%. Underwater pressure of 143.43 Pa is achieved 1 m away from the capacitive micromachined ultrasonic transducer under 20 excitation. Two-dimensional underwater ultrasonic imaging, which is able to prove that a rectangular object is present underwater, is achieved. The results presented here indicate that our work will be highly beneficial for the establishment of an underwater ultrasonic imaging system. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

31 pages, 711 KiB

Open AccessArticle

Adaptive Data Gathering in Mobile Sensor Networks Using Speedy Mobile Elements

by Yongxuan Lai, Jinshan Xie, Ziyu Lin, Tian Wang and Minghong Liao

Sensors 2015, 15(9), 23218-23248; https://doi.org/10.3390/s150923218 - 15 Sep 2015

Cited by 24 | Viewed by 5981

Abstract

Data gathering is a key operator for applications in wireless sensor networks; yet it is also a challenging problem in mobile sensor networks when considering that all nodes are mobile and the communications among them are opportunistic. This paper proposes an efficient data [...] Read more.

Data gathering is a key operator for applications in wireless sensor networks; yet it is also a challenging problem in mobile sensor networks when considering that all nodes are mobile and the communications among them are opportunistic. This paper proposes an efficient data gathering scheme called ADG that adopts speedy mobile elements as the mobile data collector and takes advantage of the movement patterns of the network. ADG first extracts the network meta-data at initial epochs, and calculates a set of proxy nodes based on the meta-data. Data gathering is then mapped into the Proxy node Time Slot Allocation (PTSA) problem that schedules the time slots and orders, according to which the data collector could gather the maximal amount of data within a limited period. Finally, the collector follows the schedule and picks up the sensed data from the proxy nodes through one hop of message transmissions. ADG learns the period when nodes are relatively stationary, so that the collector is able to pick up the data from them during the limited data gathering period. Moreover, proxy nodes and data gathering points could also be timely updated so that the collector could adapt to the change of node movements. Extensive experimental results show that the proposed scheme outperforms other data gathering schemes on the cost of message transmissions and the data gathering rate, especially under the constraint of limited data gathering period. Full article

(This article belongs to the Special Issue Towards Energy-Neutral WSN Architectures: Energy Harvesting and Other Enabling Technologies)

► Show Figures

Figure 1

13 pages, 3581 KiB

Open AccessArticle

A Palladium-Tin Modified Microband Electrode Array for Nitrate Determination

by Yexiang Fu, Chao Bian, Jian Kuang, Jinfen Wang, Jianhua Tong and Shanhong Xia

Sensors 2015, 15(9), 23249-23261; https://doi.org/10.3390/s150923249 - 15 Sep 2015

Cited by 23 | Viewed by 6054

Abstract

A microband electrode array modified with palladium-tin bimetallic composite has been developed for nitrate determination. The microband electrode array was fabricated by Micro Electro-Mechanical System (MEMS) technique. Palladium and tin were electrodeposited successively on the electrode, forming a double-layer structure. The effect of [...] Read more.

A microband electrode array modified with palladium-tin bimetallic composite has been developed for nitrate determination. The microband electrode array was fabricated by Micro Electro-Mechanical System (MEMS) technique. Palladium and tin were electrodeposited successively on the electrode, forming a double-layer structure. The effect of the Pd-Sn composite was investigated and its enhancement of catalytic activity and lifetime was revealed. The Pd-Sn modified electrode showed good linearity (R² = 0.998) from 1 mg/L to 20 mg/L for nitrate determination with a sensitivity of 398 μA/(mg∙L⁻¹∙cm²). The electrode exhibited a satisfying analytical performance after 60 days of storage, indicating a long lifetime. Good repeatability was also displayed by the Pd-Sn modified electrodes. The results provided an option for nitrate determination in water. Full article

(This article belongs to the Special Issue Electrochemical Sensors and Biosensors: From Bench-Top to Point-of-Care)

► Show Figures

Figure 1

24 pages, 2283 KiB

Open AccessArticle

Workload Model Based Dynamic Adaptation of Social Internet of Vehicles

by Kazi Masudul Alam, Mukesh Saini and Abdulmotaleb El Saddik

Sensors 2015, 15(9), 23262-23285; https://doi.org/10.3390/s150923262 - 15 Sep 2015

Cited by 29 | Viewed by 7198

Abstract

Social Internet of Things (SIoT) has gained much interest among different research groups in recent times. As a key member of a smart city, the vehicular domain of SIoT (SIoV) is also undergoing steep development. In the SIoV, vehicles work as sensor-hub to [...] Read more.

Social Internet of Things (SIoT) has gained much interest among different research groups in recent times. As a key member of a smart city, the vehicular domain of SIoT (SIoV) is also undergoing steep development. In the SIoV, vehicles work as sensor-hub to capture surrounding information using the in-vehicle and Smartphone sensors and later publish them for the consumers. A cloud centric cyber-physical system better describes the SIoV model where physical sensing-actuation process affects the cloud based service sharing or computation in a feedback loop or vice versa. The cyber based social relationship abstraction enables distributed, easily navigable and scalable peer-to-peer communication among the SIoV subsystems. These cyber-physical interactions involve a huge amount of data and it is difficult to form a real instance of the system to test the feasibility of SIoV applications. In this paper, we propose an analytical model to measure the workloads of various subsystems involved in the SIoV process. We present the basic model which is further extended to incorporate complex scenarios. We provide extensive simulation results for different parameter settings of the SIoV system. The findings of the analyses are further used to design example adaptation strategies for the SIoV subsystems which would foster deployment of intelligent transport systems. Full article

(This article belongs to the Special Issue Cyber-Physical Systems)

► Show Figures

Figure 1

17 pages, 1424 KiB

Open AccessArticle

INS/GPS/LiDAR Integrated Navigation System for Urban and Indoor Environments Using Hybrid Scan Matching Algorithm

by Yanbin Gao, Shifei Liu, Mohamed M. Atia and Aboelmagd Noureldin

Sensors 2015, 15(9), 23286-23302; https://doi.org/10.3390/s150923286 - 15 Sep 2015

Cited by 153 | Viewed by 13708

Abstract

This paper takes advantage of the complementary characteristics of Global Positioning System (GPS) and Light Detection and Ranging (LiDAR) to provide periodic corrections to Inertial Navigation System (INS) alternatively in different environmental conditions. In open sky, where GPS signals are available and LiDAR [...] Read more.

This paper takes advantage of the complementary characteristics of Global Positioning System (GPS) and Light Detection and Ranging (LiDAR) to provide periodic corrections to Inertial Navigation System (INS) alternatively in different environmental conditions. In open sky, where GPS signals are available and LiDAR measurements are sparse, GPS is integrated with INS. Meanwhile, in confined outdoor environments and indoors, where GPS is unreliable or unavailable and LiDAR measurements are rich, LiDAR replaces GPS to integrate with INS. This paper also proposes an innovative hybrid scan matching algorithm that combines the feature-based scan matching method and Iterative Closest Point (ICP) based scan matching method. The algorithm can work and transit between two modes depending on the number of matched line features over two scans, thus achieving efficiency and robustness concurrently. Two integration schemes of INS and LiDAR with hybrid scan matching algorithm are implemented and compared. Real experiments are performed on an Unmanned Ground Vehicle (UGV) for both outdoor and indoor environments. Experimental results show that the multi-sensor integrated system can remain sub-meter navigation accuracy during the whole trajectory. Full article

(This article belongs to the Special Issue Sensors for Indoor Mapping and Navigation)

► Show Figures

Figure 1

22 pages, 5474 KiB

Open AccessArticle

A Novel Phonology- and Radical-Coded Chinese Sign Language Recognition Framework Using Accelerometer and Surface Electromyography Sensors

by Juan Cheng, Xun Chen, Aiping Liu and Hu Peng

Sensors 2015, 15(9), 23303-23324; https://doi.org/10.3390/s150923303 - 15 Sep 2015

Cited by 44 | Viewed by 8361

Abstract

Sign language recognition (SLR) is an important communication tool between the deaf and the external world. It is highly necessary to develop a worldwide continuous and large-vocabulary-scale SLR system for practical usage. In this paper, we propose a novel phonology- and radical-coded Chinese [...] Read more.

Sign language recognition (SLR) is an important communication tool between the deaf and the external world. It is highly necessary to develop a worldwide continuous and large-vocabulary-scale SLR system for practical usage. In this paper, we propose a novel phonology- and radical-coded Chinese SLR framework to demonstrate the feasibility of continuous SLR using accelerometer (ACC) and surface electromyography (sEMG) sensors. The continuous Chinese characters, consisting of coded sign gestures, are first segmented into active segments using EMG signals by means of moving average algorithm. Then, features of each component are extracted from both ACC and sEMG signals of active segments (i.e., palm orientation represented by the mean and variance of ACC signals, hand movement represented by the fixed-point ACC sequence, and hand shape represented by both the mean absolute value (MAV) and autoregressive model coefficients (ARs)). Afterwards, palm orientation is first classified, distinguishing “Palm Downward” sign gestures from “Palm Inward” ones. Only the “Palm Inward” gestures are sent for further hand movement and hand shape recognition by dynamic time warping (DTW) algorithm and hidden Markov models (HMM) respectively. Finally, component recognition results are integrated to identify one certain coded gesture. Experimental results demonstrate that the proposed SLR framework with a vocabulary scale of 223 characters can achieve an averaged recognition accuracy of 96.01% ± 0.83% for coded gesture recognition tasks and 92.73% ± 1.47% for character recognition tasks. Besides, it demonstrats that sEMG signals are rather consistent for a given hand shape independent of hand movements. Hence, the number of training samples will not be significantly increased when the vocabulary scale increases, since not only the number of the completely new proposed coded gestures is constant and limited, but also the transition movement which connects successive signs needs no training samples to model even though the same coded gesture performed in different characters. This work opens up a possible new way to realize a practical Chinese SLR system. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

16 pages, 1239 KiB

Open AccessArticle

Investigation and Optimization of the Performance of an Air-Coil Sensor with a Differential Structure Suited to Helicopter TEM Exploration

by Chen Chen, Fei Liu, Jun Lin and Yanzhang Wang

Sensors 2015, 15(9), 23325-23340; https://doi.org/10.3390/s150923325 - 15 Sep 2015

Cited by 18 | Viewed by 6291

Abstract

An air-coil sensor (ACS) is a type of induction magnetometer used as a transducer to measure the variations of a magnetic field. This device is widely applied in helicopter transient electromagnetic method (TEM) exploration. Most helicopter TEM explorations generate common-mode noise and require [...] Read more.

An air-coil sensor (ACS) is a type of induction magnetometer used as a transducer to measure the variations of a magnetic field. This device is widely applied in helicopter transient electromagnetic method (TEM) exploration. Most helicopter TEM explorations generate common-mode noise and require extreme ACS specifications, both of which inevitably challenge geophysical explorations. This study proposes a differential air-core coil combined with a differential pre-amplifier to reduce the common-mode noise induced in exploration surveys. To satisfy the stringent performance requirements, including the geometric parameters and electrical specifications, the physical calculations in theory and the equivalent schematic of an ACS with noise location are investigated, respectively. The theory calculation and experimental result for the optimized ACS are then compared on the basis of a differential structure. Correspondingly, an ACS is constructed with a mass, resultant effective area, 3 dB bandwidth, signal-to-noise ratio, and normalized equivalent input noise of 2.5 kg, 5.5 m² (diameter is 0.5 m), 71 kHz, 20 (the varying magnetic field strength is 1 nT/s), and 5.43 nV/m², respectively. These data are superior to those of the traditional induction sensor 3D-3. Finally, a field experiment is performed with a fabricated sensor to show a valid measurement of the time-varying magnetic field of a helicopter TEM system based on the designed ACS. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

20 pages, 1585 KiB

Open AccessArticle

CCTV Coverage Index Based on Surveillance Resolution and Its Evaluation Using 3D Spatial Analysis

by Kyoungah Choi and Impyeong Lee

Sensors 2015, 15(9), 23341-23360; https://doi.org/10.3390/s150923341 - 16 Sep 2015

Cited by 10 | Viewed by 11213

Abstract

We propose a novel approach to evaluating how effectively a closed circuit television (CCTV) system can monitor a targeted area. With 3D models of the target area and the camera parameters of the CCTV system, the approach produces surveillance coverage index, which [...] Read more.

We propose a novel approach to evaluating how effectively a closed circuit television (CCTV) system can monitor a targeted area. With 3D models of the target area and the camera parameters of the CCTV system, the approach produces surveillance coverage index, which is newly defined in this study as a quantitative measure for surveillance performance. This index indicates the proportion of the space being monitored with a sufficient resolution to the entire space of the target area. It is determined by computing surveillance resolution at every position and orientation, which indicates how closely a specific object can be monitored with a CCTV system. We present full mathematical derivation for the resolution, which depends on the location and orientation of the object as well as the geometric model of a camera. With the proposed approach, we quantitatively evaluated the surveillance coverage of a CCTV system in an underground parking area. Our evaluation process provided various quantitative-analysis results, compelling us to examine the design of the CCTV system prior to its installation and understand the surveillance capability of an existing CCTV system. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

15 pages, 786 KiB

Open AccessArticle

A Self-Adaptive Behavior-Aware Recruitment Scheme for Participatory Sensing

by Yuanyuan Zeng and Deshi Li

Sensors 2015, 15(9), 23361-23375; https://doi.org/10.3390/s150923361 - 16 Sep 2015

Cited by 8 | Viewed by 4747

Abstract

Participatory sensing services utilizing the abundant social participants with sensor-enabled handheld smart device resources are gaining high interest nowadays. One of the challenges faced is the recruitment of participants by fully utilizing their daily activity behavior with self-adaptiveness toward the realistic application scenarios. [...] Read more.

Participatory sensing services utilizing the abundant social participants with sensor-enabled handheld smart device resources are gaining high interest nowadays. One of the challenges faced is the recruitment of participants by fully utilizing their daily activity behavior with self-adaptiveness toward the realistic application scenarios. In the paper, we propose a self-adaptive behavior-aware recruitment scheme for participatory sensing. People are assumed to join the sensing tasks along with their daily activity without pre-defined ground truth or any instructions. The scheme is proposed to model the tempo-spatial behavior and data quality rating to select participants for participatory sensing campaign. Based on this, the recruitment is formulated as a linear programming problem by considering tempo-spatial coverage, data quality, and budget. The scheme enables one to check and adjust the recruitment strategy adaptively according to application scenarios. The evaluations show that our scheme provides efficient sensing performance as stability, low-cost, tempo-spatial correlation and self-adaptiveness. Full article

(This article belongs to the Special Issue Mobile Sensor Computing: Theory and Applications)

► Show Figures

Figure 1

26 pages, 3121 KiB

Open AccessArticle

Dual-Stack Single-Radio Communication Architecture for UAV Acting As a Mobile Node to Collect Data in WSNs

by Ali Sayyed, Gustavo Medeiros De Araújo, João Paulo Bodanese and Leandro Buss Becker

Sensors 2015, 15(9), 23376-23401; https://doi.org/10.3390/s150923376 - 16 Sep 2015

Cited by 21 | Viewed by 7212

Abstract

The use of mobile nodes to collect data in a Wireless Sensor Network (WSN) has gained special attention over the last years. Some researchers explore the use of Unmanned Aerial Vehicles (UAVs) as mobile node for such data-collection purposes. Analyzing these works, it [...] Read more.

The use of mobile nodes to collect data in a Wireless Sensor Network (WSN) has gained special attention over the last years. Some researchers explore the use of Unmanned Aerial Vehicles (UAVs) as mobile node for such data-collection purposes. Analyzing these works, it is apparent that mobile nodes used in such scenarios are typically equipped with at least two different radio interfaces. The present work presents a Dual-Stack Single-Radio Communication Architecture (DSSRCA), which allows a UAV to communicate in a bidirectional manner with a WSN and a Sink node. The proposed architecture was specifically designed to support different network QoS requirements, such as best-effort and more reliable communications, attending both UAV-to-WSN and UAV-to-Sink communications needs. DSSRCA was implemented and tested on a real UAV, as detailed in this paper. This paper also includes a simulation analysis that addresses bandwidth consumption in an environmental monitoring application scenario. It includes an analysis of the data gathering rate that can be achieved considering different UAV flight speeds. Obtained results show the viability of using a single radio transmitter for collecting data from the WSN and forwarding such data to the Sink node. Full article

(This article belongs to the Special Issue UAV Sensors for Environmental Monitoring)

► Show Figures

Graphical abstract

16 pages, 1177 KiB

Open AccessArticle

Wearable Sensing of In-Ear Pressure for Heart Rate Monitoring with a Piezoelectric Sensor

by Jang-Ho Park, Dae-Geun Jang, Jung Wook Park and Se-Kyoung Youm

Sensors 2015, 15(9), 23402-23417; https://doi.org/10.3390/s150923402 - 16 Sep 2015

Cited by 87 | Viewed by 17675

Abstract

In this study, we developed a novel heart rate (HR) monitoring approach in which we measure the pressure variance of the surface of the ear canal. A scissor-shaped apparatus equipped with a piezoelectric film sensor and a hardware circuit module was designed for [...] Read more.

In this study, we developed a novel heart rate (HR) monitoring approach in which we measure the pressure variance of the surface of the ear canal. A scissor-shaped apparatus equipped with a piezoelectric film sensor and a hardware circuit module was designed for high wearability and to obtain stable measurement. In the proposed device, the film sensor converts in-ear pulse waves (EPW) into electrical current, and the circuit module enhances the EPW and suppresses noise. A real-time algorithm embedded in the circuit module performs morphological conversions to make the EPW more distinct and knowledge-based rules are used to detect EPW peaks. In a clinical experiment conducted using a reference electrocardiogram (ECG) device, EPW and ECG were concurrently recorded from 58 healthy subjects. The EPW intervals between successive peaks and their corresponding ECG intervals were then compared to each other. Promising results were obtained from the samples, specifically, a sensitivity of 97.25%, positive predictive value of 97.17%, and mean absolute difference of 0.62. Thus, highly accurate HR was obtained from in-ear pressure variance. Consequently, we believe that our proposed approach could be used to monitor vital signs and also utilized in diverse applications in the near future. Full article

(This article belongs to the Special Issue Noninvasive Biomedical Sensors)

► Show Figures

Figure 1

13 pages, 1865 KiB

Open AccessArticle

A Simple, Low-Cost Platform for Real-Time Isothermal Nucleic Acid Amplification

by Pascal Craw, Ruth E. Mackay, Angel Naveenathayalan, Chris Hudson, Manoharanehru Branavan, S. Tariq Sadiq and Wamadeva Balachandran

Sensors 2015, 15(9), 23418-23430; https://doi.org/10.3390/s150923418 - 16 Sep 2015

Cited by 22 | Viewed by 8699

Abstract

Advances in microfluidics and the introduction of isothermal nucleic acid amplification assays have resulted in a range of solutions for nucleic acid amplification tests suited for point of care and field use. However, miniaturisation of instrumentation for such assays has not seen such [...] Read more.

Advances in microfluidics and the introduction of isothermal nucleic acid amplification assays have resulted in a range of solutions for nucleic acid amplification tests suited for point of care and field use. However, miniaturisation of instrumentation for such assays has not seen such rapid advances and fluorescence based assays still depend on complex, bulky and expensive optics such as fluorescence microscopes, photomultiplier tubes and sensitive lens assemblies. In this work we demonstrate a robust, low cost platform for isothermal nucleic acid amplification on a microfluidic device. Using easily obtainable materials and commercial off-the-shelf components, we show real time fluorescence detection using a low cost photodiode and operational amplifier without need for lenses. Temperature regulation on the device is achieved using a heater fabricated with standard printed circuit board fabrication methods. These facile construction methods allow fabrications at a cost compatible with widespread deployment to resource poor settings. Full article

(This article belongs to the Section Biosensors)

► Show Figures

Figure 1

28 pages, 1758 KiB

Open AccessArticle

Kullback-Leibler Divergence-Based Differential Evolution Markov Chain Filter for Global Localization of Mobile Robots

by Fernando Martín, Luis Moreno, Santiago Garrido and Dolores Blanco

Sensors 2015, 15(9), 23431-23458; https://doi.org/10.3390/s150923431 - 16 Sep 2015

Cited by 10 | Viewed by 5893

Abstract

One of the most important skills desired for a mobile robot is the ability to obtain its own location even in challenging environments. The information provided by the sensing system is used here to solve the global localization problem. In our previous work, [...] Read more.

One of the most important skills desired for a mobile robot is the ability to obtain its own location even in challenging environments. The information provided by the sensing system is used here to solve the global localization problem. In our previous work, we designed different algorithms founded on evolutionary strategies in order to solve the aforementioned task. The latest developments are presented in this paper. The engine of the localization module is a combination of the Markov chain Monte Carlo sampling technique and the Differential Evolution method, which results in a particle filter based on the minimization of a fitness function. The robot’s pose is estimated from a set of possible locations weighted by a cost value. The measurements of the perceptive sensors are used together with the predicted ones in a known map to define a cost function to optimize. Although most localization methods rely on quadratic fitness functions, the sensed information is processed asymmetrically in this filter. The Kullback-Leibler divergence is the basis of a cost function that makes it possible to deal with different types of occlusions. The algorithm performance has been checked in a real map. The results are excellent in environments with dynamic and unmodeled obstacles, a fact that causes occlusions in the sensing area. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

18 pages, 1139 KiB

Open AccessArticle

Scalable Microfabrication Procedures for Adhesive-Integrated Flexible and Stretchable Electronic Sensors

by Dae Y. Kang, Yun-Soung Kim, Gladys Ornelas, Mridu Sinha, Keerthiga Naidu and Todd P. Coleman

Sensors 2015, 15(9), 23459-23476; https://doi.org/10.3390/s150923459 - 16 Sep 2015

Cited by 37 | Viewed by 12876

Abstract

New classes of ultrathin flexible and stretchable devices have changed the way modern electronics are designed to interact with their target systems. Though more and more novel technologies surface and steer the way we think about future electronics, there exists an unmet need [...] Read more.

New classes of ultrathin flexible and stretchable devices have changed the way modern electronics are designed to interact with their target systems. Though more and more novel technologies surface and steer the way we think about future electronics, there exists an unmet need in regards to optimizing the fabrication procedures for these devices so that large-scale industrial translation is realistic. This article presents an unconventional approach for facile microfabrication and processing of adhesive-peeled (AP) flexible sensors. By assembling AP sensors on a weakly-adhering substrate in an inverted fashion, we demonstrate a procedure with 50% reduced end-to-end processing time that achieves greater levels of fabrication yield. The methodology is used to demonstrate the fabrication of electrical and mechanical flexible and stretchable AP sensors that are peeled-off their carrier substrates by consumer adhesives. In using this approach, we outline the manner by which adhesion is maintained and buckling is reduced for gold film processing on polydimethylsiloxane substrates. In addition, we demonstrate the compatibility of our methodology with large-scale post-processing using a roll-to-roll approach. Full article

(This article belongs to the Special Issue Wearable Sensors)

► Show Figures

Graphical abstract

19 pages, 1431 KiB

Open AccessArticle

An SINS/GNSS Ground Vehicle Gravimetry Test Based on SGA-WZ02

by Ruihang Yu, Shaokun Cai, Meiping Wu, Juliang Cao and Kaidong Zhang

Sensors 2015, 15(9), 23477-23495; https://doi.org/10.3390/s150923477 - 16 Sep 2015

Cited by 21 | Viewed by 7027

Abstract

In March 2015, a ground vehicle gravimetry test was implemented in eastern Changsha to assess the repeatability and accuracy of ground vehicle SINS/GNSS gravimeter—SGA-WZ02. The gravity system developed by NUDT consisted of a Strapdown Inertial Navigation System (SINS), a Global Navigation Satellite System [...] Read more.

In March 2015, a ground vehicle gravimetry test was implemented in eastern Changsha to assess the repeatability and accuracy of ground vehicle SINS/GNSS gravimeter—SGA-WZ02. The gravity system developed by NUDT consisted of a Strapdown Inertial Navigation System (SINS), a Global Navigation Satellite System (GNSS) remote station on test vehicle, a GNSS static master station on the ground, and a data logging subsystem. A south-north profile of 35 km along the highway in eastern Changsha was chosen and four repeated available measure lines were obtained. The average speed of a vehicle is 40 km/h. To assess the external ground gravity disturbances, precise ground gravity data was built by CG-5 precise gravimeter as the reference. Under relative smooth conditions, internal accuracy among repeated lines shows an average agreement at the level of 1.86 mGal for half wavelengths about 1.1 km, and 1.22 mGal for 1.7 km. The root-mean-square (RMS) of difference between calculated gravity data and reference data is about 2.27 mGal/1.1 km, and 1.74 mGal/1.7 km. Not all of the noises caused by vehicle itself and experiments environments were eliminated in the primary results. By means of selecting reasonable filters and improving the GNSS observation conditions, further developments in ground vehicle gravimetry are promising. Full article

(This article belongs to the Special Issue Inertial Sensors and Systems)

► Show Figures

Figure 1

18 pages, 4977 KiB

Open AccessArticle

A Fixed-Pattern Noise Correction Method Based on Gray Value Compensation for TDI CMOS Image Sensor

by Zhenwang Liu, Jiangtao Xu, Xinlei Wang, Kaiming Nie and Weimin Jin

Sensors 2015, 15(9), 23496-23513; https://doi.org/10.3390/s150923496 - 16 Sep 2015

Cited by 18 | Viewed by 12503

Abstract

In order to eliminate the fixed-pattern noise (FPN) in the output image of time-delay-integration CMOS image sensor (TDI-CIS), a FPN correction method based on gray value compensation is proposed. One hundred images are first captured under uniform illumination. Then, row FPN (RFPN) and [...] Read more.

In order to eliminate the fixed-pattern noise (FPN) in the output image of time-delay-integration CMOS image sensor (TDI-CIS), a FPN correction method based on gray value compensation is proposed. One hundred images are first captured under uniform illumination. Then, row FPN (RFPN) and column FPN (CFPN) are estimated based on the row-mean vector and column-mean vector of all collected images, respectively. Finally, RFPN are corrected by adding the estimated RFPN gray value to the original gray values of pixels in the corresponding row, and CFPN are corrected by subtracting the estimated CFPN gray value from the original gray values of pixels in the corresponding column. Experimental results based on a 128-stage TDI-CIS show that, after correcting the FPN in the image captured under uniform illumination with the proposed method, the standard-deviation of row-mean vector decreases from 5.6798 to 0.4214 LSB, and the standard-deviation of column-mean vector decreases from 15.2080 to 13.4623 LSB. Both kinds of FPN in the real images captured by TDI-CIS are eliminated effectively with the proposed method. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

22 pages, 2610 KiB

Open AccessArticle

Application of a Terrestrial LIDAR System for Elevation Mapping in Terra Nova Bay, Antarctica

by Hyoungsig Cho, Seunghwan Hong, Sangmin Kim, Hyokeun Park, Ilsuk Park and Hong-Gyoo Sohn

Sensors 2015, 15(9), 23514-23535; https://doi.org/10.3390/s150923514 - 16 Sep 2015

Cited by 7 | Viewed by 5983

Abstract

A terrestrial Light Detection and Ranging (LIDAR) system has high productivity and accuracy for topographic mapping, but the harsh conditions of Antarctica make LIDAR operation difficult. Low temperatures cause malfunctioning of the LIDAR system, and unpredictable strong winds can deteriorate data quality by [...] Read more.

A terrestrial Light Detection and Ranging (LIDAR) system has high productivity and accuracy for topographic mapping, but the harsh conditions of Antarctica make LIDAR operation difficult. Low temperatures cause malfunctioning of the LIDAR system, and unpredictable strong winds can deteriorate data quality by irregularly shaking co-registration targets. For stable and efficient LIDAR operation in Antarctica, this study proposes and demonstrates the following practical solutions: (1) a lagging cover with a heating pack to maintain the temperature of the terrestrial LIDAR system; (2) co-registration using square planar targets and two-step point-merging methods based on extracted feature points and the Iterative Closest Point (ICP) algorithm; and (3) a georeferencing module consisting of an artificial target and a Global Navigation Satellite System (GNSS) receiver. The solutions were used to produce a topographic map for construction of the Jang Bogo Research Station in Terra Nova Bay, Antarctica. Co-registration and georeferencing precision reached 5 and 45 mm, respectively, and the accuracy of the Digital Elevation Model (DEM) generated from the LIDAR scanning data was ±27.7 cm. Full article

(This article belongs to the Section Remote Sensors)

► Show Figures

Figure 1

18 pages, 516 KiB

Open AccessArticle

A Robust Wireless Sensor Network Localization Algorithm in Mixed LOS/NLOS Scenario

by Bing Li, Wei Cui and Bin Wang

Sensors 2015, 15(9), 23536-23553; https://doi.org/10.3390/s150923536 - 16 Sep 2015

Cited by 33 | Viewed by 5695

Abstract

Localization algorithms based on received signal strength indication (RSSI) are widely used in the field of target localization due to its advantages of convenient application and independent from hardware devices. Unfortunately, the RSSI values are susceptible to fluctuate under the influence of non-line-of-sight [...] Read more.

Localization algorithms based on received signal strength indication (RSSI) are widely used in the field of target localization due to its advantages of convenient application and independent from hardware devices. Unfortunately, the RSSI values are susceptible to fluctuate under the influence of non-line-of-sight (NLOS) in indoor space. Existing algorithms often produce unreliable estimated distances, leading to low accuracy and low effectiveness in indoor target localization. Moreover, these approaches require extra prior knowledge about the propagation model. As such, we focus on the problem of localization in mixed LOS/NLOS scenario and propose a novel localization algorithm: Gaussian mixed model based non-metric Multidimensional (GMDS). In GMDS, the RSSI is estimated using a Gaussian mixed model (GMM). The dissimilarity matrix is built to generate relative coordinates of nodes by a multi-dimensional scaling (MDS) approach. Finally, based on the anchor nodes’ actual coordinates and target’s relative coordinates, the target’s actual coordinates can be computed via coordinate transformation. Our algorithm could perform localization estimation well without being provided with prior knowledge. The experimental verification shows that GMDS effectively reduces NLOS error and is of higher accuracy in indoor mixed LOS/NLOS localization and still remains effective when we extend single NLOS to multiple NLOS. Full article

(This article belongs to the Special Issue Integrated Intelligent Sensory Systems with Self-x Capabilities)

► Show Figures

Figure 1

18 pages, 1257 KiB

Open AccessArticle

Time Reversal Acoustic Communication Using Filtered Multitone Modulation

by Lin Sun, Baowei Chen, Haisen Li, Tian Zhou and Ruo Li

Sensors 2015, 15(9), 23554-23571; https://doi.org/10.3390/s150923554 - 17 Sep 2015

Cited by 11 | Viewed by 5458

Abstract

The multipath spread in underwater acoustic channels is severe and, therefore, when the symbol rate of the time reversal (TR) acoustic communication using single-carrier (SC) modulation is high, the large intersymbol interference (ISI) span caused by multipath reduces the performance of the TR [...] Read more.

The multipath spread in underwater acoustic channels is severe and, therefore, when the symbol rate of the time reversal (TR) acoustic communication using single-carrier (SC) modulation is high, the large intersymbol interference (ISI) span caused by multipath reduces the performance of the TR process and needs to be removed using the long adaptive equalizer as the post-processor. In this paper, a TR acoustic communication method using filtered multitone (FMT) modulation is proposed in order to reduce the residual ISI in the processed signal using TR. In the proposed method, FMT modulation is exploited to modulate information symbols onto separate subcarriers with high spectral containment and TR technique, as well as adaptive equalization is adopted at the receiver to suppress ISI and noise. The performance of the proposed method is assessed through simulation and real data from a trial in an experimental pool. The proposed method was compared with the TR acoustic communication using SC modulation with the same spectral efficiency. Results demonstrate that the proposed method can improve the performance of the TR process and reduce the computational complexity of adaptive equalization for post-process. Full article

(This article belongs to the Special Issue Mobile Sensor Computing: Theory and Applications)

► Show Figures

Figure 1

17 pages, 4254 KiB

Open AccessArticle

A Wireless Multi-Sensor Dielectric Impedance Spectroscopy Platform

by Seyed Alireza Ghaffari, William-O. Caron, Mathilde Loubier, Maxime Rioux, Jeff Viens, Benoit Gosselin and Younes Messaddeq

Sensors 2015, 15(9), 23572-23588; https://doi.org/10.3390/s150923572 - 17 Sep 2015

Cited by 9 | Viewed by 8592

Abstract

This paper describes the development of a low-cost, miniaturized, multiplexed, and connected platform for dielectric impedance spectroscopy (DIS), designed for in situ measurements and adapted to wireless network architectures. The platform has been tested and used as a DIS sensor node on ZigBee [...] Read more.

This paper describes the development of a low-cost, miniaturized, multiplexed, and connected platform for dielectric impedance spectroscopy (DIS), designed for in situ measurements and adapted to wireless network architectures. The platform has been tested and used as a DIS sensor node on ZigBee mesh and was able to interface up to three DIS sensors at the same time and relay the information through the network for data analysis and storage. The system is built from low-cost commercial microelectronics components, performs dielectric spectroscopy ranging from 5 kHz to 100 kHz, and benefits from an on-the-fly calibration system that makes sensor calibration easy. The paper describes the microelectronics design, the Nyquist impedance response, the measurement sensitivity and accuracy, and the testing of the platform for in situ dielectric impedance spectroscopy applications pertaining to fertilizer sensing, water quality sensing, and touch sensing. Full article

(This article belongs to the Special Issue Chemical Sensors based on In Situ Spectroscopy)

► Show Figures

Figure 1

29 pages, 603 KiB

Open AccessArticle

Novel Kalman Filter Algorithm for Statistical Monitoring of Extensive Landscapes with Synoptic Sensor Data

by Raymond L. Czaplewski

Sensors 2015, 15(9), 23589-23617; https://doi.org/10.3390/s150923589 - 17 Sep 2015

Cited by 4 | Viewed by 3984

Abstract

Wall-to-wall remotely sensed data are increasingly available to monitor landscape dynamics over large geographic areas. However, statistical monitoring programs that use post-stratification cannot fully utilize those sensor data. The Kalman filter (KF) is an alternative statistical estimator. I develop a new KF algorithm [...] Read more.

Wall-to-wall remotely sensed data are increasingly available to monitor landscape dynamics over large geographic areas. However, statistical monitoring programs that use post-stratification cannot fully utilize those sensor data. The Kalman filter (KF) is an alternative statistical estimator. I develop a new KF algorithm that is numerically robust with large numbers of study variables and auxiliary sensor variables. A National Forest Inventory (NFI) illustrates application within an official statistics program. Practical recommendations regarding remote sensing and statistical issues are offered. This algorithm has the potential to increase the value of synoptic sensor data for statistical monitoring of large geographic areas. Full article

(This article belongs to the Section Remote Sensors)

► Show Figures

Graphical abstract

22 pages, 1092 KiB

Open AccessArticle

Relative Orientation and Position Detections Based on an RGB-D Sensor and Dynamic Cooperation Strategies for Jumping Sensor Nodes Recycling

by Jun Zhang, Xi Yang, Guang-Ming Song, Tian-Yuan Chen and Yong Zhang

Sensors 2015, 15(9), 23618-23639; https://doi.org/10.3390/s150923618 - 17 Sep 2015

Cited by 3 | Viewed by 4737

Abstract

This paper presents relative orientation and position detection methods for jumping sensor nodes (JSNs) recycling. The methods are based on motion captures of the JSNs by an RGB-D sensor mounted on a carrier robot and the dynamic cooperation between the carrier and the [...] Read more.

This paper presents relative orientation and position detection methods for jumping sensor nodes (JSNs) recycling. The methods are based on motion captures of the JSNs by an RGB-D sensor mounted on a carrier robot and the dynamic cooperation between the carrier and the JSNs. A disc-like label with two different colored sides is mounted on the top of the JSNs. The RGB-D sensor can detect the motion of the label to calculate the orientations and positions of the JSNs and the carrier relative to each other. After the orientations and positions have been detected, the JSNs jump into a cabin mounted on the carrier in dynamic cooperation with the carrier for recycling. The performances of the proposed methods are tested with a prototype system. The results show that the carrier can detect a JSN from up to 2 m away and sense its relative orientation and position successfully. The errors of the JSN’s orientation and position detections relative to the carrier could be reduced to the values smaller than 1° and 1 cm, respectively, by using the dynamic cooperation strategies. The proposed methods in this paper could also be used for other kinds of mobile sensor nodes and multi-robot systems. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

13 pages, 3009 KiB

Open AccessArticle

Design and Simulation Test of an Open D-Dot Voltage Sensor

by Yunjie Bai, Jingang Wang, Gang Wei and Yongming Yang

Sensors 2015, 15(9), 23640-23652; https://doi.org/10.3390/s150923640 - 17 Sep 2015

Cited by 15 | Viewed by 6438

Abstract

Nowadays, sensor development focuses on miniaturization and non-contact measurement. According to the D-dot principle, a D-dot voltage sensor with a new structure was designed based on the differential D-dot sensor with a symmetrical structure, called an asymmetric open D-dot voltage sensor. It is [...] Read more.

Nowadays, sensor development focuses on miniaturization and non-contact measurement. According to the D-dot principle, a D-dot voltage sensor with a new structure was designed based on the differential D-dot sensor with a symmetrical structure, called an asymmetric open D-dot voltage sensor. It is easier to install. The electric field distribution of the sensor was analyzed through Ansoft Maxwell and an open D-dot voltage sensor was designed. This open D-voltage sensor is characteristic of accessible insulating strength and small electric field distortion. The steady and transient performance test under 10 kV-voltage reported satisfying performances of the designed open D-dot voltage sensor. It conforms to requirements for a smart grid measuring sensor in intelligence, miniaturization and facilitation. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

14 pages, 868 KiB

Open AccessArticle

Cuffless and Continuous Blood Pressure Estimation from the Heart Sound Signals

by Rong-Chao Peng, Wen-Rong Yan, Ning-Ling Zhang, Wan-Hua Lin, Xiao-Lin Zhou and Yuan-Ting Zhang

Sensors 2015, 15(9), 23653-23666; https://doi.org/10.3390/s150923653 - 17 Sep 2015

Cited by 42 | Viewed by 9493

Abstract

Cardiovascular disease, like hypertension, is one of the top killers of human life and early detection of cardiovascular disease is of great importance. However, traditional medical devices are often bulky and expensive, and unsuitable for home healthcare. In this paper, we proposed an [...] Read more.

Cardiovascular disease, like hypertension, is one of the top killers of human life and early detection of cardiovascular disease is of great importance. However, traditional medical devices are often bulky and expensive, and unsuitable for home healthcare. In this paper, we proposed an easy and inexpensive technique to estimate continuous blood pressure from the heart sound signals acquired by the microphone of a smartphone. A cold-pressor experiment was performed in 32 healthy subjects, with a smartphone to acquire heart sound signals and with a commercial device to measure continuous blood pressure. The Fourier spectrum of the second heart sound and the blood pressure were regressed using a support vector machine, and the accuracy of the regression was evaluated using 10-fold cross-validation. Statistical analysis showed that the mean correlation coefficients between the predicted values from the regression model and the measured values from the commercial device were 0.707, 0.712, and 0.748 for systolic, diastolic, and mean blood pressure, respectively, and that the mean errors were less than 5 mmHg, with standard deviations less than 8 mmHg. These results suggest that this technique is of potential use for cuffless and continuous blood pressure monitoring and it has promising application in home healthcare services. Full article

(This article belongs to the Special Issue Smartphone-Based Sensors for Non-Invasive Physiological Monitoring)

► Show Figures

Figure 1

17 pages, 3148 KiB

Open AccessArticle

Commercial Motion Sensor Based Low-Cost and Convenient Interactive Treadmill

by Jonghyun Kim, Andrew Gravunder and Hyung-Soon Park

Sensors 2015, 15(9), 23667-23683; https://doi.org/10.3390/s150923667 - 17 Sep 2015

Cited by 16 | Viewed by 7295

Abstract

Interactive treadmills were developed to improve the simulation of overground walking when compared to conventional treadmills. However, currently available interactive treadmills are expensive and inconvenient, which limits their use. We propose a low-cost and convenient version of the interactive treadmill that does not [...] Read more.

Interactive treadmills were developed to improve the simulation of overground walking when compared to conventional treadmills. However, currently available interactive treadmills are expensive and inconvenient, which limits their use. We propose a low-cost and convenient version of the interactive treadmill that does not require expensive equipment and a complicated setup. As a substitute for high-cost sensors, such as motion capture systems, a low-cost motion sensor was used to recognize the subject’s intention for speed changing. Moreover, the sensor enables the subject to make a convenient and safe stop using gesture recognition. For further cost reduction, the novel interactive treadmill was based on an inexpensive treadmill platform and a novel high-level speed control scheme was applied to maximize performance for simulating overground walking. Pilot tests with ten healthy subjects were conducted and results demonstrated that the proposed treadmill achieves similar performance to a typical, costly, interactive treadmill that contains a motion capture system and an instrumented treadmill, while providing a convenient and safe method for stopping. Full article

(This article belongs to the Special Issue Integrated Intelligent Sensory Systems with Self-x Capabilities)

► Show Figures

Figure 1

22 pages, 2611 KiB

Open AccessArticle

Error Model and Compensation of Bell-Shaped Vibratory Gyro

by Zhong Su, Ning Liu and Qing Li

Sensors 2015, 15(9), 23684-23705; https://doi.org/10.3390/s150923684 - 17 Sep 2015

Cited by 6 | Viewed by 5626

Abstract

A bell-shaped vibratory angular velocity gyro (BVG), inspired by the Chinese traditional bell, is a type of axisymmetric shell resonator gyroscope. This paper focuses on development of an error model and compensation of the BVG. A dynamic equation is firstly established, based on [...] Read more.

A bell-shaped vibratory angular velocity gyro (BVG), inspired by the Chinese traditional bell, is a type of axisymmetric shell resonator gyroscope. This paper focuses on development of an error model and compensation of the BVG. A dynamic equation is firstly established, based on a study of the BVG working mechanism. This equation is then used to evaluate the relationship between the angular rate output signal and bell-shaped resonator character, analyze the influence of the main error sources and set up an error model for the BVG. The error sources are classified from the error propagation characteristics, and the compensation method is presented based on the error model. Finally, using the error model and compensation method, the BVG is calibrated experimentally including rough compensation, temperature and bias compensation, scale factor compensation and noise filter. The experimentally obtained bias instability is from 20.5°/h to 4.7°/h, the random walk is from 2.8°/h^1/2 to 0.7°/h^1/2 and the nonlinearity is from 0.2% to 0.03%. Based on the error compensation, it is shown that there is a good linear relationship between the sensing signal and the angular velocity, suggesting that the BVG is a good candidate for the field of low and medium rotational speed measurement. Full article

(This article belongs to the Special Issue Inertial Sensors and Systems)

► Show Figures

Figure 1

21 pages, 785 KiB

Open AccessArticle

A Novel Component Carrier Configuration and Switching Scheme for Real-Time Traffic in a Cognitive-Radio-Based Spectrum Aggregation System

by Yunhai Fu, Lin Ma and Yubin Xu

Sensors 2015, 15(9), 23706-23726; https://doi.org/10.3390/s150923706 - 17 Sep 2015

Cited by 3 | Viewed by 3991

Abstract

In spectrum aggregation (SA), two or more component carriers (CCs) of different bandwidths in different bands can be aggregated to support a wider transmission bandwidth. The scheduling delay is the most important design constraint for the broadband wireless trunking (BWT) system, especially in [...] Read more.

In spectrum aggregation (SA), two or more component carriers (CCs) of different bandwidths in different bands can be aggregated to support a wider transmission bandwidth. The scheduling delay is the most important design constraint for the broadband wireless trunking (BWT) system, especially in the cognitive radio (CR) condition. The current resource scheduling schemes for spectrum aggregation become questionable and are not suitable for meeting the challenge of the delay requirement. Consequently, the authors propose a novel component carrier configuration and switching scheme for real-time traffic (RT-CCCS) to satisfy the delay requirement in the CR-based SA system. In this work, the authors consider a sensor-network-assisted CR network. The authors first introduce a resource scheduling structure for SA in the CR condition. Then the proposed scheme is analyzed in detail. Finally, simulations are carried out to verify the analysis on the proposed scheme. Simulation results prove that our proposed scheme can satisfy the delay requirement in the CR-based SA system. Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

Figure 1

18 pages, 671 KiB

Open AccessArticle

Automatic Spiral Analysis for Objective Assessment of Motor Symptoms in Parkinson’s Disease

by Mevludin Memedi, Aleksander Sadikov, Vida Groznik, Jure Žabkar, Martin Možina, Filip Bergquist, Anders Johansson, Dietrich Haubenberger and Dag Nyholm

Sensors 2015, 15(9), 23727-23744; https://doi.org/10.3390/s150923727 - 17 Sep 2015

Cited by 53 | Viewed by 9315

Abstract

A challenge for the clinical management of advanced Parkinson’s disease (PD) patients is the emergence of fluctuations in motor performance, which represents a significant source of disability during activities of daily living of the patients. There is a lack of objective measurement of [...] Read more.

A challenge for the clinical management of advanced Parkinson’s disease (PD) patients is the emergence of fluctuations in motor performance, which represents a significant source of disability during activities of daily living of the patients. There is a lack of objective measurement of treatment effects for in-clinic and at-home use that can provide an overview of the treatment response. The objective of this paper was to develop a method for objective quantification of advanced PD motor symptoms related to off episodes and peak dose dyskinesia, using spiral data gathered by a touch screen telemetry device. More specifically, the aim was to objectively characterize motor symptoms (bradykinesia and dyskinesia), to help in automating the process of visual interpretation of movement anomalies in spirals as rated by movement disorder specialists. Digitized upper limb movement data of 65 advanced PD patients and 10 healthy (HE) subjects were recorded as they performed spiral drawing tasks on a touch screen device in their home environment settings. Several spatiotemporal features were extracted from the time series and used as inputs to machine learning methods. The methods were validated against ratings on animated spirals scored by four movement disorder specialists who visually assessed a set of kinematic features and the motor symptom. The ability of the method to discriminate between PD patients and HE subjects and the test-retest reliability of the computed scores were also evaluated. Computed scores correlated well with mean visual ratings of individual kinematic features. The best performing classifier (Multilayer Perceptron) classified the motor symptom (bradykinesia or dyskinesia) with an accuracy of 84% and area under the receiver operating characteristics curve of 0.86 in relation to visual classifications of the raters. In addition, the method provided high discriminating power when distinguishing between PD patients and HE subjects as well as had good test-retest reliability. This study demonstrated the potential of using digital spiral analysis for objective quantification of PD-specific and/or treatment-induced motor symptoms. Full article

(This article belongs to the Special Issue Smartphone-Based Sensors for Non-Invasive Physiological Monitoring)

► Show Figures

Figure 1

18 pages, 1375 KiB

Open AccessArticle

Large-Scale Wireless Temperature Monitoring System for Liquefied Petroleum Gas Storage Tanks

by Guangwen Fan, Yu Shen, Xiaowei Hao, Zongming Yuan and Zhi Zhou

Sensors 2015, 15(9), 23745-23762; https://doi.org/10.3390/s150923745 - 18 Sep 2015

Cited by 15 | Viewed by 8356

Abstract

Temperature distribution is a critical indicator of the health condition for Liquefied Petroleum Gas (LPG) storage tanks. In this paper, we present a large-scale wireless temperature monitoring system to evaluate the safety of LPG storage tanks. The system includes wireless sensors networks, high [...] Read more.

Temperature distribution is a critical indicator of the health condition for Liquefied Petroleum Gas (LPG) storage tanks. In this paper, we present a large-scale wireless temperature monitoring system to evaluate the safety of LPG storage tanks. The system includes wireless sensors networks, high temperature fiber-optic sensors, and monitoring software. Finally, a case study on real-world LPG storage tanks proves the feasibility of the system. The unique features of wireless transmission, automatic data acquisition and management, local and remote access make the developed system a good alternative for temperature monitoring of LPG storage tanks in practical applications. Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

Figure 1

25 pages, 958 KiB

Open AccessArticle

Block-Based Connected-Component Labeling Algorithm Using Binary Decision Trees

by Wan-Yu Chang, Chung-Cheng Chiu and Jia-Horng Yang

Sensors 2015, 15(9), 23763-23787; https://doi.org/10.3390/s150923763 - 18 Sep 2015

Cited by 32 | Viewed by 6326

Abstract

In this paper, we propose a fast labeling algorithm based on block-based concepts. Because the number of memory access points directly affects the time consumption of the labeling algorithms, the aim of the proposed algorithm is to minimize neighborhood operations. Our algorithm utilizes [...] Read more.

In this paper, we propose a fast labeling algorithm based on block-based concepts. Because the number of memory access points directly affects the time consumption of the labeling algorithms, the aim of the proposed algorithm is to minimize neighborhood operations. Our algorithm utilizes a block-based view and correlates a raster scan to select the necessary pixels generated by a block-based scan mask. We analyze the advantages of a sequential raster scan for the block-based scan mask, and integrate the block-connected relationships using two different procedures with binary decision trees to reduce unnecessary memory access. This greatly simplifies the pixel locations of the block-based scan mask. Furthermore, our algorithm significantly reduces the number of leaf nodes and depth levels required in the binary decision tree. We analyze the labeling performance of the proposed algorithm alongside that of other labeling algorithms using high-resolution images and foreground images. The experimental results from synthetic and real image datasets demonstrate that the proposed algorithm is faster than other methods. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

17 pages, 890 KiB

Open AccessArticle

A Dedicated Genetic Algorithm for Localization of Moving Magnetic Objects

by Roger Alimi, Eyal Weiss, Tsuriel Ram-Cohen, Nir Geron and Idan Yogev

Sensors 2015, 15(9), 23788-23804; https://doi.org/10.3390/s150923788 - 18 Sep 2015

Cited by 19 | Viewed by 5148

Abstract

A dedicated Genetic Algorithm (GA) has been developed to localize the trajectory of ferromagnetic moving objects within a bounded perimeter. Localization of moving ferromagnetic objects is an important tool because it can be employed in situations when the object is [...] Read more.

A dedicated Genetic Algorithm (GA) has been developed to localize the trajectory of ferromagnetic moving objects within a bounded perimeter. Localization of moving ferromagnetic objects is an important tool because it can be employed in situations when the object is obscured. This work is innovative for two main reasons: first, the GA has been tuned to provide an accurate and fast solution to the inverse magnetic field equations problem. Second, the algorithm has been successfully tested using real-life experimental data. Very accurate trajectory localization estimations were obtained over a wide range of scenarios. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

42 pages, 4896 KiB

Open AccessArticle

Vision-Based Detection and Distance Estimation of Micro Unmanned Aerial Vehicles

by Fatih Gökçe, Göktürk Üçoluk, Erol Şahin and Sinan Kalkan

Sensors 2015, 15(9), 23805-23846; https://doi.org/10.3390/s150923805 - 18 Sep 2015

Cited by 107 | Viewed by 14524

Abstract

Detection and distance estimation of micro unmanned aerial vehicles (mUAVs) is crucial for (i) the detection of intruder mUAVs in protected environments; (ii) sense and avoid purposes on mUAVs or on other aerial vehicles and (iii) multi-mUAV control scenarios, such as environmental monitoring, [...] Read more.

Detection and distance estimation of micro unmanned aerial vehicles (mUAVs) is crucial for (i) the detection of intruder mUAVs in protected environments; (ii) sense and avoid purposes on mUAVs or on other aerial vehicles and (iii) multi-mUAV control scenarios, such as environmental monitoring, surveillance and exploration. In this article, we evaluate vision algorithms as alternatives for detection and distance estimation of mUAVs, since other sensing modalities entail certain limitations on the environment or on the distance. For this purpose, we test Haar-like features, histogram of gradients (HOG) and local binary patterns (LBP) using cascades of boosted classifiers. Cascaded boosted classifiers allow fast processing by performing detection tests at multiple stages, where only candidates passing earlier simple stages are processed at the preceding more complex stages. We also integrate a distance estimation method with our system utilizing geometric cues with support vector regressors. We evaluated each method on indoor and outdoor videos that are collected in a systematic way and also on videos having motion blur. Our experiments show that, using boosted cascaded classifiers with LBP, near real-time detection and distance estimation of mUAVs are possible in about 60 ms indoors (1032 × 778 resolution) and 150 ms outdoors (1280 × 720 resolution) per frame, with a detection rate of 0.96 F-score. However, the cascaded classifiers using Haar-like features lead to better distance estimation since they can position the bounding boxes on mUAVs more accurately. On the other hand, our time analysis yields that the cascaded classifiers using HOG train and run faster than the other algorithms. Full article

(This article belongs to the Special Issue UAV Sensors for Environmental Monitoring)

► Show Figures

Graphical abstract

21 pages, 12609 KiB

Open AccessArticle

Camera on Vessel: A Camera-Based System to Measure Change in Water Volume in a Drinking Glass

by Idowu Ayoola, Wei Chen and Loe Feijs

Sensors 2015, 15(9), 23847-23867; https://doi.org/10.3390/s150923847 - 18 Sep 2015

Cited by 4 | Viewed by 6202

Abstract

A major problem related to chronic health is patients’ “compliance” with new lifestyle changes, medical prescriptions, recommendations, or restrictions. Heart-failure and hemodialysis patients are usually placed on fluid restrictions due to their hemodynamic status. A holistic approach to managing fluid imbalance will incorporate [...] Read more.

A major problem related to chronic health is patients’ “compliance” with new lifestyle changes, medical prescriptions, recommendations, or restrictions. Heart-failure and hemodialysis patients are usually placed on fluid restrictions due to their hemodynamic status. A holistic approach to managing fluid imbalance will incorporate the monitoring of salt-water intake, body-fluid retention, and fluid excretion in order to provide effective intervention at an early stage. Such an approach creates a need to develop a smart device that can monitor the drinking activities of the patient. This paper employs an empirical approach to infer the real water level in a conically shapped glass and the volume difference due to changes in water level. The method uses a low-resolution miniaturized camera to obtain images using an Arduino microcontroller. The images are processed in MATLAB. Conventional segmentation techniques (such as a Sobel filter to obtain a binary image) are applied to extract the level gradient, and an ellipsoidal fitting helps to estimate the size of the cup. The fitting (using least-squares criterion) between derived measurements in pixel and the real measurements shows a low covariance between the estimated measurement and the mean. The correlation between the estimated results to ground truth produced a variation of 3% from the mean. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

18 pages, 1169 KiB

Open AccessArticle

“Stable-on-the-Table” Biosensors: Hemoglobin-Poly (Acrylic Acid) Nanogel BioElectrodes with High Thermal Stability and Enhanced Electroactivity

by Ananta Ghimire, Omkar V. Zore, Vindya K. Thilakarathne, Victoria A. Briand, Patrick J. Lenehan, Yu Lei, Rajeswari M. Kasi and Challa V. Kumar

Sensors 2015, 15(9), 23868-23885; https://doi.org/10.3390/s150923868 - 18 Sep 2015

Cited by 14 | Viewed by 6539

Abstract

In our efforts toward producing environmentally responsible but highly stable bioelectrodes with high electroactivities, we report here a simple, inexpensive, autoclavable high sensitivity biosensor based on enzyme-polymer nanogels. Met-hemoglobin (Hb) is stabilized by wrapping it in high molecular weight poly(acrylic acid) (PAA, M [...] Read more.

In our efforts toward producing environmentally responsible but highly stable bioelectrodes with high electroactivities, we report here a simple, inexpensive, autoclavable high sensitivity biosensor based on enzyme-polymer nanogels. Met-hemoglobin (Hb) is stabilized by wrapping it in high molecular weight poly(acrylic acid) (PAA, M_W 450k), and the resulting nanogels abbreviated as Hb-PAA-450k, withstood exposure to high temperatures for extended periods under steam sterilization conditions (122 °C, 10 min, 17–20 psi) without loss of Hb structure or its peroxidase-like activities. The bioelectrodes prepared by coating Hb-PAA-450k nanogels on glassy carbon showed well-defined quasi-reversible redox peaks at −0.279 and −0.334 V in cyclic voltammetry (CV) and retained >95% electroactivity after storing for 14 days at room temperature. Similarly, the bioelectrode showed ~90% retention in electrochemical properties after autoclaving under steam sterilization conditions. The ultra stable bioelectrode was used to detect hydrogen peroxide and demonstrated an excellent detection limit of 0.5 μM, the best among the Hb-based electrochemical biosensors. This is the first electrochemical demonstration of steam-sterilizable, storable, modular bioelectrode that undergoes reversible-thermal denaturation and retains electroactivity for protein based electrochemical applications. Full article

(This article belongs to the Special Issue Microbial and Enzymatic Biosensors)

► Show Figures

Figure 1

17 pages, 800 KiB

Open AccessArticle

Enhanced Viability of Endothelial Colony Forming Cells in Fibrin Microbeads for Sensor Vascularization

by Jarel K. Gandhi, Lada Zivkovic, John P. Fisher, Mervin C. Yoder and Eric M. Brey

Sensors 2015, 15(9), 23886-23902; https://doi.org/10.3390/s150923886 - 18 Sep 2015

Cited by 8 | Viewed by 6465

Abstract

Enhanced vascularization at sensor interfaces can improve long-term function. Fibrin, a natural polymer, has shown promise as a biomaterial for sensor coating due to its ability to sustain endothelial cell growth and promote local vascularization. However, the culture of cells, particularly endothelial cells [...] Read more.

Enhanced vascularization at sensor interfaces can improve long-term function. Fibrin, a natural polymer, has shown promise as a biomaterial for sensor coating due to its ability to sustain endothelial cell growth and promote local vascularization. However, the culture of cells, particularly endothelial cells (EC), within 3D scaffolds for more than a few days is challenging due to rapid loss of EC viability. In this manuscript, a robust method for developing fibrin microbead scaffolds for long-term culture of encapsulated ECs is described. Fibrin microbeads are formed using sodium alginate as a structural template. The size, swelling and structural properties of the microbeads were varied with needle gauge and composition and concentration of the pre-gel solution. Endothelial colony-forming cells (ECFCs) were suspended in the fibrin beads and cultured within a perfusion bioreactor system. The perfusion bioreactor enhanced ECFCs viability and genome stability in fibrin beads relative to static culture. Perfusion bioreactors enable 3D culture of ECs within fibrin beads for potential application as a sensor coating. Full article

(This article belongs to the Special Issue Novel Biomaterials and Sensors for Tissue Engineering)

► Show Figures

Figure 1

24 pages, 20637 KiB

Open AccessArticle

Multi-Stage Feature Selection by Using Genetic Algorithms for Fault Diagnosis in Gearboxes Based on Vibration Signal

by Mariela Cerrada, René Vinicio Sánchez, Diego Cabrera, Grover Zurita and Chuan Li

Sensors 2015, 15(9), 23903-23926; https://doi.org/10.3390/s150923903 - 18 Sep 2015

Cited by 88 | Viewed by 11493

Abstract

There are growing demands for condition-based monitoring of gearboxes, and techniques to improve the reliability, effectiveness and accuracy for fault diagnosis are considered valuable contributions. Feature selection is still an important aspect in machine learning-based diagnosis in order to reach good performance in [...] Read more.

There are growing demands for condition-based monitoring of gearboxes, and techniques to improve the reliability, effectiveness and accuracy for fault diagnosis are considered valuable contributions. Feature selection is still an important aspect in machine learning-based diagnosis in order to reach good performance in the diagnosis system. The main aim of this research is to propose a multi-stage feature selection mechanism for selecting the best set of condition parameters on the time, frequency and time-frequency domains, which are extracted from vibration signals for fault diagnosis purposes in gearboxes. The selection is based on genetic algorithms, proposing in each stage a new subset of the best features regarding the classifier performance in a supervised environment. The selected features are augmented at each stage and used as input for a neural network classifier in the next step, while a new subset of feature candidates is treated by the selection process. As a result, the inherent exploration and exploitation of the genetic algorithms for finding the best solutions of the selection problem are locally focused. The Sensors 2015, 15 23904 approach is tested on a dataset from a real test bed with several fault classes under different running conditions of load and velocity. The model performance for diagnosis is over 98%. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Graphical abstract

26 pages, 1570 KiB

Open AccessArticle

Active Low Intrusion Hybrid Monitor for Wireless Sensor Networks

by Marlon Navia, Jose C. Campelo, Alberto Bonastre, Rafael Ors, Juan V. Capella and Juan J. Serrano

Sensors 2015, 15(9), 23927-23952; https://doi.org/10.3390/s150923927 - 18 Sep 2015

Cited by 6 | Viewed by 5201

Abstract

Several systems have been proposed to monitor wireless sensor networks (WSN). These systems may be active (causing a high degree of intrusion) or passive (low observability inside the nodes). This paper presents the implementation of an active hybrid (hardware and software) monitor with [...] Read more.

Several systems have been proposed to monitor wireless sensor networks (WSN). These systems may be active (causing a high degree of intrusion) or passive (low observability inside the nodes). This paper presents the implementation of an active hybrid (hardware and software) monitor with low intrusion. It is based on the addition to the sensor node of a monitor node (hardware part) which, through a standard interface, is able to receive the monitoring information sent by a piece of software executed in the sensor node. The intrusion on time, code, and energy caused in the sensor nodes by the monitor is evaluated as a function of data size and the interface used. Then different interfaces, commonly available in sensor nodes, are evaluated: serial transmission (USART), serial peripheral interface (SPI), and parallel. The proposed hybrid monitor provides highly detailed information, barely disturbed by the measurement tool (interference), about the behavior of the WSN that may be used to evaluate many properties such as performance, dependability, security, etc. Monitor nodes are self-powered and may be removed after the monitoring campaign to be reused in other campaigns and/or WSNs. No other hardware-independent monitoring platforms with such low interference have been found in the literature. Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

Graphical abstract

30 pages, 1058 KiB

Open AccessArticle

An Adaptive Low-Cost GNSS/MEMS-IMU Tightly-Coupled Integration System with Aiding Measurement in a GNSS Signal-Challenged Environment

by Qifan Zhou, Hai Zhang, You Li and Zheng Li

Sensors 2015, 15(9), 23953-23982; https://doi.org/10.3390/s150923953 - 18 Sep 2015

Cited by 24 | Viewed by 6764

Abstract

The main aim of this paper is to develop a low-cost GNSS/MEMS-IMU tightly-coupled integration system with aiding information that can provide reliable position solutions when the GNSS signal is challenged such that less than four satellites are visible in a harsh environment. To [...] Read more.

The main aim of this paper is to develop a low-cost GNSS/MEMS-IMU tightly-coupled integration system with aiding information that can provide reliable position solutions when the GNSS signal is challenged such that less than four satellites are visible in a harsh environment. To achieve this goal, we introduce an adaptive tightly-coupled integration system with height and heading aiding (ATCA). This approach adopts a novel redundant measurement noise estimation method for an adaptive Kalman filter application and also augments external measurements in the filter to aid the position solutions, as well as uses different filters to deal with various situations. On the one hand, the adaptive Kalman filter makes use of the redundant measurement system’s difference sequence to estimate and tune noise variance instead of employing a traditional innovation sequence to avoid coupling with the state vector error. On the other hand, this method uses the external height and heading angle as auxiliary references and establishes a model for the measurement equation in the filter. In the meantime, it also changes the effective filter online based on the number of tracked satellites. These measures have increasingly enhanced the position constraints and the system observability, improved the computational efficiency and have led to a good result. Both simulated and practical experiments have been carried out, and the results demonstrate that the proposed method is effective at limiting the system errors when there are less than four visible satellites, providing a satisfactory navigation solution. Full article

(This article belongs to the Section Remote Sensors)

► Show Figures

Figure 1

19 pages, 2550 KiB

Open AccessArticle

How Angular Velocity Features and Different Gyroscope Noise Types Interact and Determine Orientation Estimation Accuracy

by Ilaria Pasciuto, Gabriele Ligorio, Elena Bergamini, Giuseppe Vannozzi, Angelo Maria Sabatini and Aurelio Cappozzo

Sensors 2015, 15(9), 23983-24001; https://doi.org/10.3390/s150923983 - 18 Sep 2015

Cited by 53 | Viewed by 7962

Abstract

In human movement analysis, 3D body segment orientation can be obtained through the numerical integration of gyroscope signals. These signals, however, are affected by errors that, for the case of micro-electro-mechanical systems, are mainly due to: constant bias, scale factor, white noise, and [...] Read more.

In human movement analysis, 3D body segment orientation can be obtained through the numerical integration of gyroscope signals. These signals, however, are affected by errors that, for the case of micro-electro-mechanical systems, are mainly due to: constant bias, scale factor, white noise, and bias instability. The aim of this study is to assess how the orientation estimation accuracy is affected by each of these disturbances, and whether it is influenced by the angular velocity magnitude and 3D distribution across the gyroscope axes. Reference angular velocity signals, either constant or representative of human walking, were corrupted with each of the four noise types within a simulation framework. The magnitude of the angular velocity affected the error in the orientation estimation due to each noise type, except for the white noise. Additionally, the error caused by the constant bias was also influenced by the angular velocity 3D distribution. As the orientation error depends not only on the noise itself but also on the signal it is applied to, different sensor placements could enhance or mitigate the error due to each disturbance, and special attention must be paid in providing and interpreting measures of accuracy for orientation estimation algorithms. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Graphical abstract

24 pages, 1579 KiB

Open AccessArticle

Generating Daily Synthetic Landsat Imagery by Combining Landsat and MODIS Data

by Mingquan Wu, Wenjiang Huang, Zheng Niu and Changyao Wang

Sensors 2015, 15(9), 24002-24025; https://doi.org/10.3390/s150924002 - 18 Sep 2015

Cited by 70 | Viewed by 5870

Abstract

Owing to low temporal resolution and cloud interference, there is a shortage of high spatial resolution remote sensing data. To address this problem, this study introduces a modified spatial and temporal data fusion approach (MSTDFA) to generate daily synthetic Landsat imagery. This algorithm [...] Read more.

Owing to low temporal resolution and cloud interference, there is a shortage of high spatial resolution remote sensing data. To address this problem, this study introduces a modified spatial and temporal data fusion approach (MSTDFA) to generate daily synthetic Landsat imagery. This algorithm was designed to avoid the limitations of the conditional spatial temporal data fusion approach (STDFA) including the constant window for disaggregation and the sensor difference. An adaptive window size selection method is proposed in this study to select the best window size and moving steps for the disaggregation of coarse pixels. The linear regression method is used to remove the influence of differences in sensor systems using disaggregated mean coarse reflectance by testing and validation in two study areas located in Xinjiang Province, China. The results show that the MSTDFA algorithm can generate daily synthetic Landsat imagery with a high correlation coefficient (R) ranged from 0.646 to 0.986 between synthetic images and the actual observations. We further show that MSTDFA can be applied to 250 m 16-day MODIS MOD13Q1 products and the Landsat Normalized Different Vegetation Index (NDVI) data by generating a synthetic NDVI image highly similar to actual Landsat NDVI observation with a high R of 0.97. Full article

(This article belongs to the Section Remote Sensors)

► Show Figures

Figure 1

28 pages, 728 KiB

Open AccessArticle

Energy Efficient Medium Access Control Protocol for Clustered Wireless Sensor Networks with Adaptive Cross-Layer Scheduling

by Maria Sefuba, Tom Walingo and Fambirai Takawira

Sensors 2015, 15(9), 24026-24053; https://doi.org/10.3390/s150924026 - 18 Sep 2015

Cited by 6 | Viewed by 5638

Abstract

This paper presents an Energy Efficient Medium Access Control (MAC) protocol for clustered wireless sensor networks that aims to improve energy efficiency and delay performance. The proposed protocol employs an adaptive cross-layer intra-cluster scheduling and an inter-cluster relay selection diversity. The scheduling is [...] Read more.

This paper presents an Energy Efficient Medium Access Control (MAC) protocol for clustered wireless sensor networks that aims to improve energy efficiency and delay performance. The proposed protocol employs an adaptive cross-layer intra-cluster scheduling and an inter-cluster relay selection diversity. The scheduling is based on available data packets and remaining energy level of the source node (SN). This helps to minimize idle listening on nodes without data to transmit as well as reducing control packet overhead. The relay selection diversity is carried out between clusters, by the cluster head (CH), and the base station (BS). The diversity helps to improve network reliability and prolong the network lifetime. Relay selection is determined based on the communication distance, the remaining energy and the channel quality indicator (CQI) for the relay cluster head (RCH). An analytical framework for energy consumption and transmission delay for the proposed MAC protocol is presented in this work. The performance of the proposed MAC protocol is evaluated based on transmission delay, energy consumption, and network lifetime. The results obtained indicate that the proposed MAC protocol provides improved performance than traditional cluster based MAC protocols. Full article

(This article belongs to the Special Issue Towards Energy-Neutral WSN Architectures: Energy Harvesting and Other Enabling Technologies)

► Show Figures

Figure 1

33 pages, 2404 KiB

Open AccessArticle

A User-Centric Knowledge Creation Model in a Web of Object-Enabled Internet of Things Environment

by Muhammad Golam Kibria, Sheik Mohammad Mostakim Fattah, Kwanghyeon Jeong, Ilyoung Chong and Youn-Kwae Jeong

Sensors 2015, 15(9), 24054-24086; https://doi.org/10.3390/s150924054 - 18 Sep 2015

Cited by 24 | Viewed by 7510

Abstract

User-centric service features in a Web of Object-enabled Internet of Things environment can be provided by using a semantic ontology that classifies and integrates objects on the World Wide Web as well as shares and merges context-aware information and accumulated knowledge. The semantic [...] Read more.

User-centric service features in a Web of Object-enabled Internet of Things environment can be provided by using a semantic ontology that classifies and integrates objects on the World Wide Web as well as shares and merges context-aware information and accumulated knowledge. The semantic ontology is applied on a Web of Object platform to virtualize the real world physical devices and information to form virtual objects that represent the features and capabilities of devices in the virtual world. Detailed information and functionalities of multiple virtual objects are combined with service rules to form composite virtual objects that offer context-aware knowledge-based services, where context awareness plays an important role in enabling automatic modification of the system to reconfigure the services based on the context. Converting the raw data into meaningful information and connecting the information to form the knowledge and storing and reusing the objects in the knowledge base can both be expressed by semantic ontology. In this paper, a knowledge creation model that synchronizes a service logistic model and a virtual world knowledge model on a Web of Object platform has been proposed. To realize the context-aware knowledge-based service creation and execution, a conceptual semantic ontology model has been developed and a prototype has been implemented for a use case scenario of emergency service. Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

Graphical abstract

22 pages, 1036 KiB

Open AccessArticle

Three-Component Decomposition Based on Stokes Vector for Compact Polarimetric SAR

by Hanning Wang, Zhimin Zhou, John Turnbull, Qian Song and Feng Qi

Sensors 2015, 15(9), 24087-24108; https://doi.org/10.3390/s150924087 - 18 Sep 2015

Cited by 12 | Viewed by 5619

Abstract

In this paper, a three-component decomposition algorithm is proposed for processing compact polarimetric SAR images. By using the correspondence between the covariance matrix and the Stokes vector, three-component scattering models for CTLR and DCP modes are established. The explicit expression of decomposition results [...] Read more.

In this paper, a three-component decomposition algorithm is proposed for processing compact polarimetric SAR images. By using the correspondence between the covariance matrix and the Stokes vector, three-component scattering models for CTLR and DCP modes are established. The explicit expression of decomposition results is then derived by setting the contribution of volume scattering as a free parameter. The degree of depolarization is taken as the upper bound of the free parameter, for the constraint that the weighting factor of each scattering component should be nonnegative. Several methods are investigated to estimate the free parameter suitable for decomposition. The feasibility of this algorithm is validated by AIRSAR data over San Francisco and RADARSAT-2 data over Flevoland. Full article

(This article belongs to the Section Remote Sensors)

► Show Figures

Figure 1

16 pages, 1258 KiB

Open AccessArticle

Inline Measurement of Particle Concentrations in Multicomponent Suspensions using Ultrasonic Sensor and Least Squares Support Vector Machines

by Xiaobin Zhan, Shulan Jiang, Yili Yang, Jian Liang, Tielin Shi and Xiwen Li

Sensors 2015, 15(9), 24109-24124; https://doi.org/10.3390/s150924109 - 18 Sep 2015

Cited by 14 | Viewed by 6417

Abstract

This paper proposes an ultrasonic measurement system based on least squares support vector machines (LS-SVM) for inline measurement of particle concentrations in multicomponent suspensions. Firstly, the ultrasonic signals are analyzed and processed, and the optimal feature subset that contributes to the best model [...] Read more.

This paper proposes an ultrasonic measurement system based on least squares support vector machines (LS-SVM) for inline measurement of particle concentrations in multicomponent suspensions. Firstly, the ultrasonic signals are analyzed and processed, and the optimal feature subset that contributes to the best model performance is selected based on the importance of features. Secondly, the LS-SVM model is tuned, trained and tested with different feature subsets to obtain the optimal model. In addition, a comparison is made between the partial least square (PLS) model and the LS-SVM model. Finally, the optimal LS-SVM model with the optimal feature subset is applied to inline measurement of particle concentrations in the mixing process. The results show that the proposed method is reliable and accurate for inline measuring the particle concentrations in multicomponent suspensions and the measurement accuracy is sufficiently high for industrial application. Furthermore, the proposed method is applicable to the modeling of the nonlinear system dynamically and provides a feasible way to monitor industrial processes. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

18 pages, 2003 KiB

Open AccessArticle

Self-Adaptive Strategy Based on Fuzzy Control Systems for Improving Performance in Wireless Sensors Networks

by Vicente Hernández Díaz, José-Fernán Martínez, Néstor Lucas Martínez and Raúl M. Del Toro

Sensors 2015, 15(9), 24125-24142; https://doi.org/10.3390/s150924125 - 18 Sep 2015

Cited by 8 | Viewed by 6908

Abstract

The solutions to cope with new challenges that societies have to face nowadays involve providing smarter daily systems. To achieve this, technology has to evolve and leverage physical systems automatic interactions, with less human intervention. Technological paradigms like Internet of Things (IoT) and [...] Read more.

The solutions to cope with new challenges that societies have to face nowadays involve providing smarter daily systems. To achieve this, technology has to evolve and leverage physical systems automatic interactions, with less human intervention. Technological paradigms like Internet of Things (IoT) and Cyber-Physical Systems (CPS) are providing reference models, architectures, approaches and tools that are to support cross-domain solutions. Thus, CPS based solutions will be applied in different application domains like e-Health, Smart Grid, Smart Transportation and so on, to assure the expected response from a complex system that relies on the smooth interaction and cooperation of diverse networked physical systems. The Wireless Sensors Networks (WSN) are a well-known wireless technology that are part of large CPS. The WSN aims at monitoring a physical system, object, (e.g., the environmental condition of a cargo container), and relaying data to the targeted processing element. The WSN communication reliability, as well as a restrained energy consumption, are expected features in a WSN. This paper shows the results obtained in a real WSN deployment, based on SunSPOT nodes, which carries out a fuzzy based control strategy to improve energy consumption while keeping communication reliability and computational resources usage among boundaries. Full article

(This article belongs to the Special Issue Cyber-Physical Systems)

► Show Figures

Graphical abstract

35 pages, 888 KiB

Open AccessArticle

Evaluation of Content-Matched Range Monitoring Queries over Moving Objects in Mobile Computing Environments

by HaRim Jung, MoonBae Song, Hee Yong Youn and Ung Mo Kim

Sensors 2015, 15(9), 24143-24177; https://doi.org/10.3390/s150924143 - 18 Sep 2015

Cited by 7 | Viewed by 5540

Abstract

A content-matched (CM) rangemonitoring query overmoving objects continually retrieves the moving objects (i) whose non-spatial attribute values are matched to given non-spatial query values; and (ii) that are currently located within a given spatial query range. In this paper, we propose a new [...] Read more.

A content-matched (CM) rangemonitoring query overmoving objects continually retrieves the moving objects (i) whose non-spatial attribute values are matched to given non-spatial query values; and (ii) that are currently located within a given spatial query range. In this paper, we propose a new query indexing structure, called the group-aware query region tree (GQR-tree) for efficient evaluation of CMrange monitoring queries. The primary role of the GQR-tree is to help the server leverage the computational capabilities of moving objects in order to improve the system performance in terms of the wireless communication cost and server workload. Through a series of comprehensive simulations, we verify the superiority of the GQR-tree method over the existing methods. Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

Figure 1

13 pages, 635 KiB

Open AccessArticle

Continuous-Wave Stimulated Emission Depletion Microscope for Imaging Actin Cytoskeleton in Fixed and Live Cells

by Bhanu Neupane, Tao Jin, Liliana F. Mellor, Elizabeth G. Loboa, Frances S. Ligler and Gufeng Wang

Sensors 2015, 15(9), 24178-24190; https://doi.org/10.3390/s150924178 - 18 Sep 2015

Cited by 11 | Viewed by 6993

Abstract

Stimulated emission depletion (STED) microscopy provides a new opportunity to study fine sub-cellular structures and highly dynamic cellular processes, which are challenging to observe using conventional optical microscopy. Using actin as an example, we explored the feasibility of using a continuous wave (CW)-STED [...] Read more.

Stimulated emission depletion (STED) microscopy provides a new opportunity to study fine sub-cellular structures and highly dynamic cellular processes, which are challenging to observe using conventional optical microscopy. Using actin as an example, we explored the feasibility of using a continuous wave (CW)-STED microscope to study the fine structure and dynamics in fixed and live cells. Actin plays an important role in cellular processes, whose functioning involves dynamic formation and reorganization of fine structures of actin filaments. Frequently used confocal fluorescence and STED microscopy dyes were employed to image fixed PC-12 cells (dyed with phalloidin- fluorescein isothiocyante) and live rat chondrosarcoma cells (RCS) transfected with actin-green fluorescent protein (GFP). Compared to conventional confocal fluorescence microscopy, CW-STED microscopy shows improved spatial resolution in both fixed and live cells. We were able to monitor cell morphology changes continuously; however, the number of repetitive analyses were limited primarily by the dyes used in these experiments and could be improved with the use of dyes less susceptible to photobleaching. In conclusion, CW-STED may disclose new information for biological systems with a proper characteristic length scale. The challenges of using CW-STED microscopy to study cell structures are discussed. Full article

(This article belongs to the Special Issue Fluorescent Probes for Intracellular Imaging and Super Resolution Microscopy)

► Show Figures

Graphical abstract

23 pages, 4194 KiB

Open AccessArticle

A Self-Adaptive Dynamic Recognition Model for Fatigue Driving Based on Multi-Source Information and Two Levels of Fusion

by Wei Sun, Xiaorui Zhang, Srinivas Peeta, Xiaozheng He, Yongfu Li and Senlai Zhu

Sensors 2015, 15(9), 24191-24213; https://doi.org/10.3390/s150924191 - 18 Sep 2015

Cited by 26 | Viewed by 6115

Abstract

To improve the effectiveness and robustness of fatigue driving recognition, a self-adaptive dynamic recognition model is proposed that incorporates information from multiple sources and involves two sequential levels of fusion, constructed at the feature level and the decision level. Compared with existing models, [...] Read more.

To improve the effectiveness and robustness of fatigue driving recognition, a self-adaptive dynamic recognition model is proposed that incorporates information from multiple sources and involves two sequential levels of fusion, constructed at the feature level and the decision level. Compared with existing models, the proposed model introduces a dynamic basic probability assignment (BPA) to the decision-level fusion such that the weight of each feature source can change dynamically with the real-time fatigue feature measurements. Further, the proposed model can combine the fatigue state at the previous time step in the decision-level fusion to improve the robustness of the fatigue driving recognition. An improved correction strategy of the BPA is also proposed to accommodate the decision conflict caused by external disturbances. Results from field experiments demonstrate that the effectiveness and robustness of the proposed model are better than those of models based on a single fatigue feature and/or single-source information fusion, especially when the most effective fatigue features are used in the proposed model. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Graphical abstract

16 pages, 3384 KiB

Open AccessArticle

A Fiber Bragg Grating Sensing Based Triaxial Vibration Sensor

by Tianliang Li, Yuegang Tan, Yi Liu, Yongzhi Qu, Mingyao Liu and Zude Zhou

Sensors 2015, 15(9), 24214-24229; https://doi.org/10.3390/s150924214 - 18 Sep 2015

Cited by 28 | Viewed by 7176

Abstract

A fiber Bragg grating (FBG) sensing based triaxial vibration sensor has been presented in this paper. The optical fiber is directly employed as elastomer, and the triaxial vibration of a measured body can be obtained by two pairs of FBGs. A model of [...] Read more.

A fiber Bragg grating (FBG) sensing based triaxial vibration sensor has been presented in this paper. The optical fiber is directly employed as elastomer, and the triaxial vibration of a measured body can be obtained by two pairs of FBGs. A model of a triaxial vibration sensor as well as decoupling principles of triaxial vibration and experimental analyses are proposed. Experimental results show that: sensitivities of 86.9 pm/g, 971.8 pm/g and 154.7 pm/g for each orthogonal sensitive direction with linearity are separately 3.64%, 1.50% and 3.01%. The flat frequency ranges reside in 20–200 Hz, 3–20 Hz and 4–50 Hz, respectively; in addition, the resonant frequencies are separately 700 Hz, 40 Hz and 110 Hz in the x/y/z direction. When the sensor is excited in a single direction vibration, the outputs of sensor in the other two directions are consistent with the outputs in the non-working state. Therefore, it is effectively demonstrated that it can be used for three-dimensional vibration measurement. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

27 pages, 716 KiB

Open AccessArticle

Cell Selection Game for Densely-Deployed Sensor and Mobile Devices In 5G Networks Integrating Heterogeneous Cells and the Internet of Things

by Lusheng Wang, Yamei Wang, Zhizhong Ding and Xiumin Wang

Sensors 2015, 15(9), 24230-24256; https://doi.org/10.3390/s150924230 - 18 Sep 2015

Cited by 13 | Viewed by 6721

Abstract

With the rapid development of wireless networking technologies, the Internet of Things and heterogeneous cellular networks (HCNs) tend to be integrated to form a promising wireless network paradigm for 5G. Hyper-dense sensor and mobile devices will be deployed under the coverage of heterogeneous [...] Read more.

With the rapid development of wireless networking technologies, the Internet of Things and heterogeneous cellular networks (HCNs) tend to be integrated to form a promising wireless network paradigm for 5G. Hyper-dense sensor and mobile devices will be deployed under the coverage of heterogeneous cells, so that each of them could freely select any available cell covering it and compete for resource with others selecting the same cell, forming a cell selection (CS) game between these devices. Since different types of cells usually share the same portion of the spectrum, devices selecting overlapped cells can experience severe inter-cell interference (ICI). In this article, we study the CS game among a large amount of densely-deployed sensor and mobile devices for their uplink transmissions in a two-tier HCN. ICI is embedded with the traditional congestion game (TCG), forming a congestion game with ICI (CGI) and a congestion game with capacity (CGC). For the three games above, we theoretically find the circular boundaries between the devices selecting the macrocell and those selecting the picocells, indicated by the pure strategy Nash equilibria (PSNE). Meanwhile, through a number of simulations with different picocell radii and different path loss exponents, the collapse of the PSNE impacted by severe ICI (i.e., a large number of picocell devices change their CS preferences to the macrocell) is profoundly revealed, and the collapse points are identified. Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

Figure 1

12 pages, 743 KiB

Open AccessArticle

A Lateral Differential Resonant Pressure Microsensor Based on SOI-Glass Wafer-Level Vacuum Packaging

by Bo Xie, Yonghao Xing, Yanshuang Wang, Jian Chen, Deyong Chen and Junbo Wang

Sensors 2015, 15(9), 24257-24268; https://doi.org/10.3390/s150924257 - 21 Sep 2015

Cited by 26 | Viewed by 6512

Abstract

This paper presents the fabrication and characterization of a resonant pressure microsensor based on SOI-glass wafer-level vacuum packaging. The SOI-based pressure microsensor consists of a pressure-sensitive diaphragm at the handle layer and two lateral resonators (electrostatic excitation and capacitive detection) on the device [...] Read more.

This paper presents the fabrication and characterization of a resonant pressure microsensor based on SOI-glass wafer-level vacuum packaging. The SOI-based pressure microsensor consists of a pressure-sensitive diaphragm at the handle layer and two lateral resonators (electrostatic excitation and capacitive detection) on the device layer as a differential setup. The resonators were vacuum packaged with a glass cap using anodic bonding and the wire interconnection was realized using a mask-free electrochemical etching approach by selectively patterning an Au film on highly topographic surfaces. The fabricated resonant pressure microsensor with dual resonators was characterized in a systematic manner, producing a quality factor higher than 10,000 (~6 months), a sensitivity of about 166 Hz/kPa and a reduced nonlinear error of 0.033% F.S. Based on the differential output, the sensitivity was increased to two times and the temperature-caused frequency drift was decreased to 25%. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

28 pages, 2431 KiB

Open AccessArticle

An Enhanced Error Model for EKF-Based Tightly-Coupled Integration of GPS and Land Vehicle’s Motion Sensors

by Tashfeen B. Karamat, Mohamed M. Atia and Aboelmagd Noureldin

Sensors 2015, 15(9), 24269-24296; https://doi.org/10.3390/s150924269 - 22 Sep 2015

Cited by 17 | Viewed by 7190

Abstract

Reduced inertial sensor systems (RISS) have been introduced by many researchers as a low-cost, low-complexity sensor assembly that can be integrated with GPS to provide a robust integrated navigation system for land vehicles. In earlier works, the developed error models were simplified based [...] Read more.

Reduced inertial sensor systems (RISS) have been introduced by many researchers as a low-cost, low-complexity sensor assembly that can be integrated with GPS to provide a robust integrated navigation system for land vehicles. In earlier works, the developed error models were simplified based on the assumption that the vehicle is mostly moving on a flat horizontal plane. Another limitation is the simplified estimation of the horizontal tilt angles, which is based on simple averaging of the accelerometers’ measurements without modelling their errors or tilt angle errors. In this paper, a new error model is developed for RISS that accounts for the effect of tilt angle errors and the accelerometer’s errors. Additionally, it also includes important terms in the system dynamic error model, which were ignored during the linearization process in earlier works. An augmented extended Kalman filter (EKF) is designed to incorporate tilt angle errors and transversal accelerometer errors. The new error model and the augmented EKF design are developed in a tightly-coupled RISS/GPS integrated navigation system. The proposed system was tested on real trajectories’ data under degraded GPS environments, and the results were compared to earlier works on RISS/GPS systems. The findings demonstrated that the proposed enhanced system introduced significant improvements in navigational performance. Full article

(This article belongs to the Special Issue Advances on Resources Management for Multi-Platform Infrastructures)

► Show Figures

Figure 1

21 pages, 2311 KiB

Open AccessArticle

Leveraging Two Kinect Sensors for Accurate Full-Body Motion Capture

by Zhiquan Gao, Yao Yu, Yu Zhou and Sidan Du

Sensors 2015, 15(9), 24297-24317; https://doi.org/10.3390/s150924297 - 22 Sep 2015

Cited by 38 | Viewed by 9307

Abstract

Accurate motion capture plays an important role in sports analysis, the medical field and virtual reality. Current methods for motion capture often suffer from occlusions, which limits the accuracy of their pose estimation. In this paper, we propose a complete system to measure [...] Read more.

Accurate motion capture plays an important role in sports analysis, the medical field and virtual reality. Current methods for motion capture often suffer from occlusions, which limits the accuracy of their pose estimation. In this paper, we propose a complete system to measure the pose parameters of the human body accurately. Different from previous monocular depth camera systems, we leverage two Kinect sensors to acquire more information about human movements, which ensures that we can still get an accurate estimation even when significant occlusion occurs. Because human motion is temporally constant, we adopt a learning analysis to mine the temporal information across the posture variations. Using this information, we estimate human pose parameters accurately, regardless of rapid movement. Our experimental results show that our system can perform an accurate pose estimation of the human body with the constraint of information from the temporal domain. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

25 pages, 1630 KiB

Open AccessArticle

Measurement and Evaluation of the Gas Density and Viscosity of Pure Gases and Mixtures Using a Micro-Cantilever Beam

by Anastasios Badarlis, Axel Pfau and Anestis Kalfas

Sensors 2015, 15(9), 24318-24342; https://doi.org/10.3390/s150924318 - 22 Sep 2015

Cited by 24 | Viewed by 8731

Abstract

Measurement of gas density and viscosity was conducted using a micro-cantilever beam. In parallel, the validity of the proposed modeling approach was evaluated. This study also aimed to widen the database of the gases on which the model development of the micro-cantilever beams [...] Read more.

Measurement of gas density and viscosity was conducted using a micro-cantilever beam. In parallel, the validity of the proposed modeling approach was evaluated. This study also aimed to widen the database of the gases on which the model development of the micro-cantilever beams is based. The density and viscosity of gases are orders of magnitude lower than liquids. For this reason, the use of a very sensitive sensor is essential. In this study, a micro-cantilever beam from the field of atomic force microscopy was used. Although the current cantilever was designed to work with thermal activation, in the current investigation, it was activated with an electromagnetic force. The deflection of the cantilever beam was detected by an integrated piezo-resistive sensor. Six pure gases and sixteen mixtures of them in ambient conditions were investigated. The outcome of the investigation showed that the current cantilever beam had a sensitivity of 240 Hz/(kg/m³), while the accuracy of the determined gas density and viscosity in ambient conditions reached ±1.5% and ±2.0%, respectively. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

31 pages, 1104 KiB

Open AccessArticle

Implementation and Evaluation of Four Interoperable Open Standards for the Internet of Things

by Mohammad Ali Jazayeri, Steve H. L. Liang and Chih-Yuan Huang

Sensors 2015, 15(9), 24343-24373; https://doi.org/10.3390/s150924343 - 22 Sep 2015

Cited by 36 | Viewed by 9684

Abstract

Recently, researchers are focusing on a new use of the Internet called the Internet of Things (IoT), in which enabled electronic devices can be remotely accessed over the Internet. As the realization of IoT concept is still in its early stages, manufacturers of [...] Read more.

Recently, researchers are focusing on a new use of the Internet called the Internet of Things (IoT), in which enabled electronic devices can be remotely accessed over the Internet. As the realization of IoT concept is still in its early stages, manufacturers of Internet-connected devices and IoT web service providers are defining their proprietary protocols based on their targeted applications. Consequently, IoT becomes heterogeneous in terms of hardware capabilities and communication protocols. Addressing these heterogeneities by following open standards is a necessary step to communicate with various IoT devices. In this research, we assess the feasibility of applying existing open standards on resource-constrained IoT devices. The standard protocols developed in this research are OGC PUCK over Bluetooth, TinySOS, SOS over CoAP, and OGC SensorThings API. We believe that by hosting open standard protocols on IoT devices, not only do the devices become self-describable, self-contained, and interoperable, but innovative applications can also be easily developed with standardized interfaces. In addition, we use memory consumption, request message size, response message size, and response latency to benchmark the efficiency of the implemented protocols. In all, this research presents and evaluates standard-based solutions to better understand the feasibility of applying existing standards to the IoT vision. Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

Graphical abstract

12 pages, 537 KiB

Open AccessArticle

Configuration Analysis of the ERS Points in Large-Volume Metrology System

by Zhangjun Jin, Cijun Yu, Jiangxiong Li and Yinglin Ke

Sensors 2015, 15(9), 24397-24408; https://doi.org/10.3390/s150924397 - 22 Sep 2015

Cited by 35 | Viewed by 6648

Abstract

In aircraft assembly, multiple laser trackers are used simultaneously to measure large-scale aircraft components. To combine the independent measurements, the transformation matrices between the laser trackers’ coordinate systems and the assembly coordinate system are calculated, by measuring the enhanced referring system (ERS) points. [...] Read more.

In aircraft assembly, multiple laser trackers are used simultaneously to measure large-scale aircraft components. To combine the independent measurements, the transformation matrices between the laser trackers’ coordinate systems and the assembly coordinate system are calculated, by measuring the enhanced referring system (ERS) points. This article aims to understand the influence of the configuration of the ERS points that affect the transformation matrix errors, and then optimize the deployment of the ERS points to reduce the transformation matrix errors. To optimize the deployment of the ERS points, an explicit model is derived to estimate the transformation matrix errors. The estimation model is verified by the experiment implemented in the factory floor. Based on the proposed model, a group of sensitivity coefficients are derived to evaluate the quality of the configuration of the ERS points, and then several typical configurations of the ERS points are analyzed in detail with the sensitivity coefficients. Finally general guidance is established to instruct the deployment of the ERS points in the aspects of the layout, the volume size and the number of the ERS points, as well as the position and orientation of the assembly coordinate system. Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

Figure 1

19 pages, 1293 KiB

Open AccessArticle

Toward Epileptic Brain Region Detection Based on Magnetic Nanoparticle Patterning

by Maysam Z. Pedram, Amir Shamloo, Aria Alasty and Ebrahim Ghafar-Zadeh

Sensors 2015, 15(9), 24409-24427; https://doi.org/10.3390/s150924409 - 22 Sep 2015

Cited by 21 | Viewed by 6280

Abstract

Resection of the epilepsy foci is the best treatment for more than 15% of epileptic patients or 50% of patients who are refractory to all forms of medical treatment. Accurate mapping of the locations of epileptic neuronal networks can result in the complete [...] Read more.

Resection of the epilepsy foci is the best treatment for more than 15% of epileptic patients or 50% of patients who are refractory to all forms of medical treatment. Accurate mapping of the locations of epileptic neuronal networks can result in the complete resection of epileptic foci. Even though currently electroencephalography is the best technique for mapping the epileptic focus, it cannot define the boundary of epilepsy that accurately. Herein we put forward a new accurate brain mapping technique using superparamagnetic nanoparticles (SPMNs). The main hypothesis in this new approach is the creation of super-paramagnetic aggregates in the epileptic foci due to high electrical and magnetic activities. These aggregates may improve tissue contrast of magnetic resonance imaging (MRI) that results in improving the resection of epileptic foci. In this paper, we present the mathematical models before discussing the simulation results. Furthermore, we mimic the aggregation of SPMNs in a weak magnetic field using a low-cost microfabricated device. Based on these results, the SPMNs may play a crucial role in diagnostic epilepsy and the subsequent treatment of this disease. Full article

(This article belongs to the Special Issue Inorganic Nanoparticles as Biomedical Probes)

► Show Figures

Figure 1

17 pages, 827 KiB

Open AccessArticle

Optimizing the De-Noise Neural Network Model for GPS Time-Series Monitoring of Structures

by Mosbeh R. Kaloop and Jong Wan Hu

Sensors 2015, 15(9), 24428-24444; https://doi.org/10.3390/s150924428 - 22 Sep 2015

Cited by 13 | Viewed by 6971

Abstract

The Global Positioning System (GPS) is recently used widely in structures and other applications. Notwithstanding, the GPS accuracy still suffers from the errors afflicting the measurements, particularly the short-period displacement of structural components. Previously, the multi filter method is utilized to remove the [...] Read more.

The Global Positioning System (GPS) is recently used widely in structures and other applications. Notwithstanding, the GPS accuracy still suffers from the errors afflicting the measurements, particularly the short-period displacement of structural components. Previously, the multi filter method is utilized to remove the displacement errors. This paper aims at using a novel application for the neural network prediction models to improve the GPS monitoring time series data. Four prediction models for the learning algorithms are applied and used with neural network solutions: back-propagation, Cascade-forward back-propagation, adaptive filter and extended Kalman filter, to estimate which model can be recommended. The noise simulation and bridge’s short-period GPS of the monitoring displacement component of one Hz sampling frequency are used to validate the four models and the previous method. The results show that the Adaptive neural networks filter is suggested for de-noising the observations, specifically for the GPS displacement components of structures. Also, this model is expected to have significant influence on the design of structures in the low frequency responses and measurements’ contents. Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

Figure 1

13 pages, 1253 KiB

Open AccessArticle

Using LDR as Sensing Element for an External Fuzzy Controller Applied in Photovoltaic Pumping Systems with Variable-Speed Drives

by Geraldo Neves De A. Maranhão, Alaan Ubaiara Brito, Anderson Marques Leal, Jéssica Kelly Silva Fonseca and Wilson Negrão Macêdo

Sensors 2015, 15(9), 24445-24457; https://doi.org/10.3390/s150924445 - 22 Sep 2015

Cited by 8 | Viewed by 8094

Abstract

In the present paper, a fuzzy controller applied to a Variable-Speed Drive (VSD) for use in Photovoltaic Pumping Systems (PVPS) is proposed. The fuzzy logic system (FLS) used is embedded in a microcontroller and corresponds to a proportional-derivative controller. A Light-Dependent Resistor (LDR) [...] Read more.

In the present paper, a fuzzy controller applied to a Variable-Speed Drive (VSD) for use in Photovoltaic Pumping Systems (PVPS) is proposed. The fuzzy logic system (FLS) used is embedded in a microcontroller and corresponds to a proportional-derivative controller. A Light-Dependent Resistor (LDR) is used to measure, approximately, the irradiance incident on the PV array. Experimental tests are executed using an Arduino board. The experimental results show that the fuzzy controller is capable of operating the system continuously throughout the day and controlling the direct current (DC) voltage level in the VSD with a good performance. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Graphical abstract

21 pages, 1804 KiB

Open AccessArticle

Techniques for Updating Pedestrian Network Data Including Facilities and Obstructions Information for Transportation of Vulnerable People

by Seula Park, Yoonsik Bang and Kiyun Yu

Sensors 2015, 15(9), 24466-24486; https://doi.org/10.3390/s150924466 - 23 Sep 2015

Cited by 8 | Viewed by 5053

Abstract

Demand for a Pedestrian Navigation Service (PNS) is on the rise. To provide a PNS for the transportation of vulnerable people, more detailed information of pedestrian facilities and obstructions should be included in Pedestrian Network Data (PND) used for PNS. Such data can [...] Read more.

Demand for a Pedestrian Navigation Service (PNS) is on the rise. To provide a PNS for the transportation of vulnerable people, more detailed information of pedestrian facilities and obstructions should be included in Pedestrian Network Data (PND) used for PNS. Such data can be constructed efficiently by collecting GPS trajectories and integrating them with the existing PND. However, these two kinds of data have geometric differences and topological inconsistencies that need to be addressed. In this paper, we provide a methodology for integrating pedestrian facilities and obstructions information with an existing PND. At first we extracted the significant points from user-collected GPS trajectory by identifying the geometric difference index and attributes of each point. Then the extracted points were used to make an initial solution of the matching between the trajectory and the PND. Two geometrical algorithms were proposed and applied to reduce two kinds of errors in the matching: on dual lines and on intersections. Using the final solution for the matching, we reconstructed the node/link structure of PND including the facilities and obstructions information. Finally, performance was assessed with a test site and 79.2% of the collected data were correctly integrated with the PND. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

27 pages, 8250 KiB

Open AccessArticle

Sea-Based Infrared Scene Interpretation by Background Type Classification and Coastal Region Detection for Small Target Detection

by Sungho Kim

Sensors 2015, 15(9), 24487-24513; https://doi.org/10.3390/s150924487 - 23 Sep 2015

Cited by 16 | Viewed by 10386

Abstract

Sea-based infrared search and track (IRST) is important for homeland security by detecting missiles and asymmetric boats. This paper proposes a novel scheme to interpret various infrared scenes by classifying the infrared background types and detecting the coastal regions in omni-directional images. The [...] Read more.

Sea-based infrared search and track (IRST) is important for homeland security by detecting missiles and asymmetric boats. This paper proposes a novel scheme to interpret various infrared scenes by classifying the infrared background types and detecting the coastal regions in omni-directional images. The background type or region-selective small infrared target detector should be deployed to maximize the detection rate and to minimize the number of false alarms. A spatial filter-based small target detector is suitable for identifying stationary incoming targets in remote sea areas with sky only. Many false detections can occur if there is an image sector containing a coastal region, due to ground clutter and the difficulty in finding true targets using the same spatial filter-based detector. A temporal filter-based detector was used to handle these problems. Therefore, the scene type and coastal region information is critical to the success of IRST in real-world applications. In this paper, the infrared scene type was determined using the relationships between the sensor line-of-sight (LOS) and a horizontal line in an image. The proposed coastal region detector can be activated if the background type of the probing sector is determined to be a coastal region. Coastal regions can be detected by fusing the region map and curve map. The experimental results on real infrared images highlight the feasibility of the proposed sea-based scene interpretation. In addition, the effects of the proposed scheme were analyzed further by applying region-adaptive small target detection. Full article

(This article belongs to the Special Issue Infrared and THz Sensing and Imaging)

► Show Figures

Figure 1

16 pages, 720 KiB

Open AccessArticle

Validation of Inter-Subject Training for Hidden Markov Models Applied to Gait Phase Detection in Children with Cerebral Palsy

by Juri Taborri, Emilia Scalona, Eduardo Palermo, Stefano Rossi and Paolo Cappa

Sensors 2015, 15(9), 24514-24529; https://doi.org/10.3390/s150924514 - 23 Sep 2015

Cited by 63 | Viewed by 7730

Abstract

Gait-phase recognition is a necessary functionality to drive robotic rehabilitation devices for lower limbs. Hidden Markov Models (HMMs) represent a viable solution, but they need subject-specific training, making data processing very time-consuming. Here, we validated an inter-subject procedure to avoid the intra-subject one [...] Read more.

Gait-phase recognition is a necessary functionality to drive robotic rehabilitation devices for lower limbs. Hidden Markov Models (HMMs) represent a viable solution, but they need subject-specific training, making data processing very time-consuming. Here, we validated an inter-subject procedure to avoid the intra-subject one in two, four and six gait-phase models in pediatric subjects. The inter-subject procedure consists in the identification of a standardized parameter set to adapt the model to measurements. We tested the inter-subject procedure both on scalar and distributed classifiers. Ten healthy children and ten hemiplegic children, each equipped with two Inertial Measurement Units placed on shank and foot, were recruited. The sagittal component of angular velocity was recorded by gyroscopes while subjects performed four walking trials on a treadmill. The goodness of classifiers was evaluated with the Receiver Operating Characteristic. The results provided a goodness from good to optimum for all examined classifiers (0 < G < 0.6), with the best performance for the distributed classifier in two-phase recognition (G = 0.02). Differences were found among gait partitioning models, while no differences were found between training procedures with the exception of the shank classifier. Our results raise the possibility of avoiding subject-specific training in HMM for gait-phase recognition and its implementation to control exoskeletons for the pediatric population. Full article

(This article belongs to the Special Issue Sensor Systems for Motion Capture and Interpretation)

► Show Figures

Figure 1

23 pages, 3496 KiB

Open AccessArticle

Research on the Sensing Performance of the Tuning Fork-Probe as a Micro Interaction Sensor

by Fengli Gao and Xide Li

Sensors 2015, 15(9), 24530-24552; https://doi.org/10.3390/s150924530 - 23 Sep 2015

Cited by 12 | Viewed by 5982

Abstract

The shear force position system has been widely used in scanning near-field optical microscopy (SNOM) and recently extended into the force sensing area. The dynamic properties of a tuning fork (TF), the core component of this system, directly determine the sensing performance of [...] Read more.

The shear force position system has been widely used in scanning near-field optical microscopy (SNOM) and recently extended into the force sensing area. The dynamic properties of a tuning fork (TF), the core component of this system, directly determine the sensing performance of the shear positioning system. Here, we combine experimental results and finite element method (FEM) analysis to investigate the dynamic behavior of the TF probe assembled structure (TF-probe). Results from experiments under varying atmospheric pressures illustrate that the oscillation amplitude of the TF-probe is linearly related to the quality factor, suggesting that decreasing the pressure will dramatically increase the quality factor. The results from FEM analysis reveal the influences of various parameters on the resonant performance of the TF-probe. We compared numerical results of the frequency spectrum with the experimental data collected by our recently developed laser Doppler vibrometer system. Then, we investigated the parameters affecting spatial resolution of the SNOM and the dynamic response of the TF-probe under longitudinal and transverse interactions. It is found that the interactions in transverse direction is much more sensitive than that in the longitudinal direction. Finally, the TF-probe was used to measure the friction coefficient of a silica–silica interface. Full article

(This article belongs to the Section State-of-the-Art Sensors Technologies)

► Show Figures

Figure 1

20 pages, 892 KiB

Open AccessArticle

Wireless Power Transfer for Autonomous Wearable Neurotransmitter Sensors

by Cuong M. Nguyen, Pavan Kumar Kota, Minh Q. Nguyen, Souvik Dubey, Smitha Rao, Jeffrey Mays and J.-C. Chiao

Sensors 2015, 15(9), 24553-24572; https://doi.org/10.3390/s150924553 - 23 Sep 2015

Cited by 22 | Viewed by 8378

Abstract

In this paper, we report a power management system for autonomous and real-time monitoring of the neurotransmitter L-glutamate (L-Glu). A low-power, low-noise, and high-gain recording module was designed to acquire signal from an implantable flexible L-Glu sensor fabricated by micro-electro-mechanical system (MEMS)-based processes. [...] Read more.

In this paper, we report a power management system for autonomous and real-time monitoring of the neurotransmitter L-glutamate (L-Glu). A low-power, low-noise, and high-gain recording module was designed to acquire signal from an implantable flexible L-Glu sensor fabricated by micro-electro-mechanical system (MEMS)-based processes. The wearable recording module was wirelessly powered through inductive coupling transmitter antennas. Lateral and angular misalignments of the receiver antennas were resolved by using a multi-transmitter antenna configuration. The effective coverage, over which the recording module functioned properly, was improved with the use of in-phase transmitter antennas. Experimental results showed that the recording system was capable of operating continuously at distances of 4 cm, 7 cm and 10 cm. The wireless power management system reduced the weight of the recording module, eliminated human intervention and enabled animal experimentation for extended durations. Full article

(This article belongs to the Special Issue Power Schemes for Biosensors and Biomedical Devices)

► Show Figures

Graphical abstract

12 pages, 705 KiB

Open AccessArticle

Effect of Electrode Configuration on Nitric Oxide Gas Sensor Behavior

by Ling Cui and Erica P. Murray

Sensors 2015, 15(9), 24573-24584; https://doi.org/10.3390/s150924573 - 23 Sep 2015

Cited by 7 | Viewed by 6799

Abstract

The influence of electrode configuration on the impedancemetric response of nitric oxide (NO) gas sensors was investigated for solid electrochemical cells [Au/yttria-stabilized zirconia (YSZ)/Au)]. Fabrication of the sensors was carried out at 1050 °C in order to establish a porous YSZ electrolyte that [...] Read more.

The influence of electrode configuration on the impedancemetric response of nitric oxide (NO) gas sensors was investigated for solid electrochemical cells [Au/yttria-stabilized zirconia (YSZ)/Au)]. Fabrication of the sensors was carried out at 1050 °C in order to establish a porous YSZ electrolyte that enabled gas diffusion. Two electrode configurations were studied where Au wire electrodes were either embedded within or wrapped around the YSZ electrolyte. The electrical response of the sensors was collected via impedance spectroscopy under various operating conditions where gas concentrations ranged from 0 to 100 ppm NO and 1%–18% O₂ at temperatures varying from 600 to 700 °C. Gas diffusion appeared to be a rate-limiting mechanism in sensors where the electrode configuration resulted in longer diffusion pathways. The temperature dependence of the NO sensors studied was independent of the electrode configuration. Analysis of the impedance data, along with equivalent circuit modeling indicated the electrode configuration of the sensor effected gas and ionic transport pathways, capacitance behavior, and NO sensitivity. Full article

(This article belongs to the Special Issue Gas Sensors—Designs and Applications)

► Show Figures

Graphical abstract

10 pages, 807 KiB

Open AccessArticle

Location Dependence of Mass Sensitivity for Acoustic Wave Devices

by Kewei Zhang, Yuesheng Chai and Z.-Y. Cheng

Sensors 2015, 15(9), 24585-24594; https://doi.org/10.3390/s150924585 - 23 Sep 2015

Cited by 5 | Viewed by 4566

Abstract

It is introduced that the mass sensitivity (S_m) of an acoustic wave (AW) device with a concentrated mass can be simply determined using its mode shape function: the S_m is proportional to the square of its mode shape. By [...] Read more.

It is introduced that the mass sensitivity (S_m) of an acoustic wave (AW) device with a concentrated mass can be simply determined using its mode shape function: the S_m is proportional to the square of its mode shape. By using the S_m of an AW device with a uniform mass, which is known for almost all AW devices, the S_m of an AW device with a concentrated mass at different locations can be determined. The method is confirmed by numerical simulation for one type of AW device and the results from two other types of AW devices. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

20 pages, 2020 KiB

Open AccessArticle

Integrated WiFi/PDR/Smartphone Using an Unscented Kalman Filter Algorithm for 3D Indoor Localization

by Guoliang Chen, Xiaolin Meng, Yunjia Wang, Yanzhe Zhang, Peng Tian and Huachao Yang

Sensors 2015, 15(9), 24595-24614; https://doi.org/10.3390/s150924595 - 23 Sep 2015

Cited by 123 | Viewed by 12162

Abstract

Because of the high calculation cost and poor performance of a traditional planar map when dealing with complicated indoor geographic information, a WiFi fingerprint indoor positioning system cannot be widely employed on a smartphone platform. By making full use of the hardware sensors [...] Read more.

Because of the high calculation cost and poor performance of a traditional planar map when dealing with complicated indoor geographic information, a WiFi fingerprint indoor positioning system cannot be widely employed on a smartphone platform. By making full use of the hardware sensors embedded in the smartphone, this study proposes an integrated approach to a three-dimensional (3D) indoor positioning system. First, an improved K-means clustering method is adopted to reduce the fingerprint database retrieval time and enhance positioning efficiency. Next, with the mobile phone’s acceleration sensor, a new step counting method based on auto-correlation analysis is proposed to achieve cell phone inertial navigation positioning. Furthermore, the integration of WiFi positioning with Pedestrian Dead Reckoning (PDR) obtains higher positional accuracy with the help of the Unscented Kalman Filter algorithm. Finally, a hybrid 3D positioning system based on Unity 3D, which can carry out real-time positioning for targets in 3D scenes, is designed for the fluent operation of mobile terminals. Full article

(This article belongs to the Special Issue Sensors for Indoor Mapping and Navigation)

► Show Figures

Figure 1

29 pages, 11865 KiB

Open AccessArticle

A New Approach for Combining Time-of-Flight and RGB Cameras Based on Depth-Dependent Planar Projective Transformations

by Carlota Salinas, Roemi Fernández, Héctor Montes and Manuel Armada

Sensors 2015, 15(9), 24615-24643; https://doi.org/10.3390/s150924615 - 23 Sep 2015

Cited by 15 | Viewed by 6873

Abstract

Image registration for sensor fusion is a valuable technique to acquire 3D and colour information for a scene. Nevertheless, this process normally relies on feature-matching techniques, which is a drawback for combining sensors that are not able to deliver common features. The combination [...] Read more.

Image registration for sensor fusion is a valuable technique to acquire 3D and colour information for a scene. Nevertheless, this process normally relies on feature-matching techniques, which is a drawback for combining sensors that are not able to deliver common features. The combination of ToF and RGB cameras is an instance that problem. Typically, the fusion of these sensors is based on the extrinsic parameter computation of the coordinate transformation between the two cameras. This leads to a loss of colour information because of the low resolution of the ToF camera, and sophisticated algorithms are required to minimize this issue. This work proposes a method for sensor registration with non-common features and that avoids the loss of colour information. The depth information is used as a virtual feature for estimating a depth-dependent homography lookup table (Hlut). The homographies are computed within sets of ground control points of 104 images. Since the distance from the control points to the ToF camera are known, the working distance of each element on the Hlut is estimated. Finally, two series of experimental tests have been carried out in order to validate the capabilities of the proposed method. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

18 pages, 1230 KiB

Open AccessArticle

A Location Method Using Sensor Arrays for Continuous Gas Leakage in Integrally Stiffened Plates Based on the Acoustic Characteristics of the Stiffener

by Xu Bian, Yibo Li, Hao Feng, Jiaqiang Wang, Lei Qi and Shijiu Jin

Sensors 2015, 15(9), 24644-24661; https://doi.org/10.3390/s150924644 - 23 Sep 2015

Cited by 17 | Viewed by 6094

Abstract

This paper proposes a continuous leakage location method based on the ultrasonic array sensor, which is specific to continuous gas leakage in a pressure container with an integral stiffener. This method collects the ultrasonic signals generated from the leakage hole through the piezoelectric [...] Read more.

This paper proposes a continuous leakage location method based on the ultrasonic array sensor, which is specific to continuous gas leakage in a pressure container with an integral stiffener. This method collects the ultrasonic signals generated from the leakage hole through the piezoelectric ultrasonic sensor array, and analyzes the space-time correlation of every collected signal in the array. Meanwhile, it combines with the method of frequency compensation and superposition in time domain (SITD), based on the acoustic characteristics of the stiffener, to obtain a high-accuracy location result on the stiffener wall. According to the experimental results, the method successfully solves the orientation problem concerning continuous ultrasonic signals generated from leakage sources, and acquires high accuracy location information on the leakage source using a combination of multiple sets of orienting results. The mean value of location absolute error is 13.51 mm on the one-square-meter plate with an integral stiffener (4 mm width; 20 mm height; 197 mm spacing), and the maximum location absolute error is generally within a ±25 mm interval. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

19 pages, 1439 KiB

Open AccessArticle

FRET-Based Nanobiosensors for Imaging Intracellular Ca²⁺ and H⁺ Microdomains

by Alsu I. Zamaleeva, Guillaume Despras, Camilla Luccardini, Mayeul Collot, Michel De Waard, Martin Oheim, Jean-Maurice Mallet and Anne Feltz

Sensors 2015, 15(9), 24662-24680; https://doi.org/10.3390/s150924662 - 23 Sep 2015

Cited by 14 | Viewed by 8823

Abstract

Semiconductor nanocrystals (NCs) or quantum dots (QDs) are luminous point emitters increasingly being used to tag and track biomolecules in biological/biomedical imaging. However, their intracellular use as highlighters of single-molecule localization and nanobiosensors reporting ion microdomains changes has remained a major challenge. Here, [...] Read more.

Semiconductor nanocrystals (NCs) or quantum dots (QDs) are luminous point emitters increasingly being used to tag and track biomolecules in biological/biomedical imaging. However, their intracellular use as highlighters of single-molecule localization and nanobiosensors reporting ion microdomains changes has remained a major challenge. Here, we report the design, generation and validation of FRET-based nanobiosensors for detection of intracellular Ca²⁺ and H⁺ transients. Our sensors combine a commercially available CANdot^®565QD as an energy donor with, as an acceptor, our custom-synthesized red-emitting Ca²⁺ or H⁺ probes. These ‘Rubies’ are based on an extended rhodamine as a fluorophore and a phenol or BAPTA (1,2-bis(o-aminophenoxy)ethane-N,N,N′,N′-tetra-acetic acid) for H⁺ or Ca²⁺ sensing, respectively, and additionally bear a linker arm for conjugation. QDs were stably functionalized using the same SH/maleimide crosslink chemistry for all desired reactants. Mixing ion sensor and cell-penetrating peptides (that facilitate cytoplasmic delivery) at the desired stoichiometric ratio produced controlled multi-conjugated assemblies. Multiple acceptors on the same central donor allow up-concentrating the ion sensor on the QD surface to concentrations higher than those that could be achieved in free solution, increasing FRET efficiency and improving the signal. We validate these nanosensors for the detection of intracellular Ca²⁺ and pH transients using live-cell fluorescence imaging. Full article

(This article belongs to the Special Issue FRET Biosensors)

► Show Figures

Figure 1

Review

Jump to: Research, Other

26 pages, 2621 KiB

Open AccessReview

Enhanced Vibrational Spectroscopies as Tools for Small Molecule Biosensing

by Souhir Boujday, Marc Lamy de la Chapelle, Johannes Srajer and Wolfgang Knoll

Sensors 2015, 15(9), 21239-21264; https://doi.org/10.3390/s150921239 - 28 Aug 2015

Cited by 30 | Viewed by 9751

Abstract

In this short summary we summarize some of the latest developments in vibrational spectroscopic tools applied for the sensing of (small) molecules and biomolecules in a label-free mode of operation. We first introduce various concepts for the enhancement of InfraRed spectroscopic techniques, including [...] Read more.

In this short summary we summarize some of the latest developments in vibrational spectroscopic tools applied for the sensing of (small) molecules and biomolecules in a label-free mode of operation. We first introduce various concepts for the enhancement of InfraRed spectroscopic techniques, including the principles of Attenuated Total Reflection InfraRed (ATR-IR), (phase-modulated) InfraRed Reflection Absorption Spectroscopy (IRRAS/PM-IRRAS), and Surface Enhanced Infrared Reflection Absorption Spectroscopy (SEIRAS). Particular attention is put on the use of novel nanostructured substrates that allow for the excitation of propagating and localized surface plasmon modes aimed at operating additional enhancement mechanisms. This is then be complemented by the description of the latest development in Surface- and Tip-Enhanced Raman Spectroscopies, again with an emphasis on the detection of small molecules or bioanalytes. Full article

(This article belongs to the Special Issue Advances in Optical Biosensors)

► Show Figures

Figure 1

51 pages, 2087 KiB

Open AccessReview

Biomedical Probes Based on Inorganic Nanoparticles for Electrochemical and Optical Spectroscopy Applications

by Abdulhadee Yakoh, Chanika Pinyorospathum, Weena Siangproh and Orawon Chailapakul

Sensors 2015, 15(9), 21427-21477; https://doi.org/10.3390/s150921427 - 28 Aug 2015

Cited by 24 | Viewed by 12094

Abstract

Inorganic nanoparticles usually provide novel and unique physical properties as their size approaches nanometer scale dimensions. The unique physical and optical properties of nanoparticles may lead to applications in a variety of areas, including biomedical detection. Therefore, current research is now increasingly focused [...] Read more.

Inorganic nanoparticles usually provide novel and unique physical properties as their size approaches nanometer scale dimensions. The unique physical and optical properties of nanoparticles may lead to applications in a variety of areas, including biomedical detection. Therefore, current research is now increasingly focused on the use of the high surface-to-volume ratios of nanoparticles to fabricate superb chemical- or biosensors for various detection applications. This article highlights various kinds of inorganic nanoparticles, including metal nanoparticles, magnetic nanoparticles, nanocomposites, and semiconductor nanoparticles that can be perceived as useful materials for biomedical probes and points to the outstanding results arising from their use in such probes. The progress in the use of inorganic nanoparticle-based electrochemical, colorimetric and spectrophotometric detection in recent applications, especially bioanalysis, and the main functions of inorganic nanoparticles in detection are reviewed. The article begins with a conceptual discussion of nanoparticles according to types, followed by numerous applications to analytes including biomolecules, disease markers, and pharmaceutical substances. Most of the references cited herein, dating from 2010 to 2015, generally mention one or more of the following characteristics: a low detection limit, good signal amplification and simultaneous detection capabilities. Full article

(This article belongs to the Special Issue Inorganic Nanoparticles as Biomedical Probes)

► Show Figures

Figure 1

23 pages, 4856 KiB

Open AccessReview

Label-Free Biosensor Imaging on Photonic Crystal Surfaces

by Yue Zhuo and Brian T. Cunningham

Sensors 2015, 15(9), 21613-21635; https://doi.org/10.3390/s150921613 - 28 Aug 2015

Cited by 68 | Viewed by 10208

Abstract

We review the development and application of nanostructured photonic crystal surfaces and a hyperspectral reflectance imaging detection instrument which, when used together, represent a new form of optical microscopy that enables label-free, quantitative, and kinetic monitoring of biomaterial interaction with substrate surfaces. Photonic [...] Read more.

We review the development and application of nanostructured photonic crystal surfaces and a hyperspectral reflectance imaging detection instrument which, when used together, represent a new form of optical microscopy that enables label-free, quantitative, and kinetic monitoring of biomaterial interaction with substrate surfaces. Photonic Crystal Enhanced Microscopy (PCEM) has been used to detect broad classes of materials which include dielectric nanoparticles, metal plasmonic nanoparticles, biomolecular layers, and live cells. Because PCEM does not require cytotoxic stains or photobleachable fluorescent dyes, it is especially useful for monitoring the long-term interactions of cells with extracellular matrix surfaces. PCEM is only sensitive to the attachment of cell components within ~200 nm of the photonic crystal surface, which may correspond to the region of most interest for adhesion processes that involve stem cell differentiation, chemotaxis, and metastasis. PCEM has also demonstrated sufficient sensitivity for sensing nanoparticle contrast agents that are roughly the same size as protein molecules, which may enable applications in “digital” diagnostics with single molecule sensing resolution. We will review PCEM’s development history, operating principles, nanostructure design, and imaging modalities that enable tracking of optical scatterers, emitters, absorbers, and centers of dielectric permittivity. Full article

(This article belongs to the Special Issue Label-Free Sensing)

► Show Figures

Figure 1

36 pages, 1548 KiB

Open AccessReview

Technologies for Assessment of Motor Disorders in Parkinson’s Disease: A Review

by Qi Wei Oung, Hariharan Muthusamy, Hoi Leong Lee, Shafriza Nisha Basah, Sazali Yaacob, Mohamed Sarillee and Chia Hau Lee

Sensors 2015, 15(9), 21710-21745; https://doi.org/10.3390/s150921710 - 31 Aug 2015

Cited by 62 | Viewed by 13069

Abstract

Parkinson’s Disease (PD) is characterized as the commonest neurodegenerative illness that gradually degenerates the central nervous system. The goal of this review is to come out with a summary of the recent progress of numerous forms of sensors and systems that are related [...] Read more.

Parkinson’s Disease (PD) is characterized as the commonest neurodegenerative illness that gradually degenerates the central nervous system. The goal of this review is to come out with a summary of the recent progress of numerous forms of sensors and systems that are related to diagnosis of PD in the past decades. The paper reviews the substantial researches on the application of technological tools (objective techniques) in the PD field applying different types of sensors proposed by previous researchers. In addition, this also includes the use of clinical tools (subjective techniques) for PD assessments, for instance, patient self-reports, patient diaries and the international gold standard reference scale, Unified Parkinson Disease Rating Scale (UPDRS). Comparative studies and critical descriptions of these approaches have been highlighted in this paper, giving an insight on the current state of the art. It is followed by explaining the merits of the multiple sensor fusion platform compared to single sensor platform for better monitoring progression of PD, and ends with thoughts about the future direction towards the need of multimodal sensor integration platform for the assessment of PD. Full article

(This article belongs to the Special Issue Wearable Sensors)

► Show Figures

Figure 1

39 pages, 806 KiB

Open AccessReview

Inertial Sensor-Based Gait Recognition: A Review

by Sebastijan Sprager and Matjaz B. Juric

Sensors 2015, 15(9), 22089-22127; https://doi.org/10.3390/s150922089 - 2 Sep 2015

Cited by 286 | Viewed by 15277

Abstract

With the recent development of microelectromechanical systems (MEMS), inertial sensors have become widely used in the research of wearable gait analysis due to several factors, such as being easy-to-use and low-cost. Considering the fact that each individual has a unique way of walking, [...] Read more.

With the recent development of microelectromechanical systems (MEMS), inertial sensors have become widely used in the research of wearable gait analysis due to several factors, such as being easy-to-use and low-cost. Considering the fact that each individual has a unique way of walking, inertial sensors can be applied to the problem of gait recognition where assessed gait can be interpreted as a biometric trait. Thus, inertial sensor-based gait recognition has a great potential to play an important role in many security-related applications. Since inertial sensors are included in smart devices that are nowadays present at every step, inertial sensor-based gait recognition has become very attractive and emerging field of research that has provided many interesting discoveries recently. This paper provides a thorough and systematic review of current state-of-the-art in this field of research. Review procedure has revealed that the latest advanced inertial sensor-based gait recognition approaches are able to sufficiently recognise the users when relying on inertial data obtained during gait by single commercially available smart device in controlled circumstances, including fixed placement and small variations in gait. Furthermore, these approaches have also revealed considerable breakthrough by realistic use in uncontrolled circumstances, showing great potential for their further development and wide applicability. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

25 pages, 1845 KiB

Open AccessReview

Real-Time QoS Routing Protocols in Wireless Multimedia Sensor Networks: Study and Analysis

by Adwan Alanazi and Khaled Elleithy

Sensors 2015, 15(9), 22209-22233; https://doi.org/10.3390/s150922209 - 2 Sep 2015

Cited by 57 | Viewed by 10416

Abstract

Many routing protocols have been proposed for wireless sensor networks. These routing protocols are almost always based on energy efficiency. However, recent advances in complementary metal-oxide semiconductor (CMOS) cameras and small microphones have led to the development of Wireless Multimedia Sensor Networks (WMSN) [...] Read more.

Many routing protocols have been proposed for wireless sensor networks. These routing protocols are almost always based on energy efficiency. However, recent advances in complementary metal-oxide semiconductor (CMOS) cameras and small microphones have led to the development of Wireless Multimedia Sensor Networks (WMSN) as a class of wireless sensor networks which pose additional challenges. The transmission of imaging and video data needs routing protocols with both energy efficiency and Quality of Service (QoS) characteristics in order to guarantee the efficient use of the sensor nodes and effective access to the collected data. Also, with integration of real time applications in Wireless Senor Networks (WSNs), the use of QoS routing protocols is not only becoming a significant topic, but is also gaining the attention of researchers. In designing an efficient QoS routing protocol, the reliability and guarantee of end-to-end delay are critical events while conserving energy. Thus, considerable research has been focused on designing energy efficient and robust QoS routing protocols. In this paper, we present a state of the art research work based on real-time QoS routing protocols for WMSNs that have already been proposed. This paper categorizes the real-time QoS routing protocols into probabilistic and deterministic protocols. In addition, both categories are classified into soft and hard real time protocols by highlighting the QoS issues including the limitations and features of each protocol. Furthermore, we have compared the performance of mobility-aware query based real-time QoS routing protocols from each category using Network Simulator-2 (NS2). This paper also focuses on the design challenges and future research directions as well as highlights the characteristics of each QoS routing protocol. Full article

(This article belongs to the Special Issue Mobile Sensor Computing: Theory and Applications)

► Show Figures

Figure 1

27 pages, 3602 KiB

Open AccessReview

Piezotronic Effect: An Emerging Mechanism for Sensing Applications

by Kory Jenkins, Vu Nguyen, Ren Zhu and Rusen Yang

Sensors 2015, 15(9), 22914-22940; https://doi.org/10.3390/s150922914 - 11 Sep 2015

Cited by 68 | Viewed by 10533

Abstract

Strain-induced polarization charges in a piezoelectric semiconductor effectively modulate the band structure near the interface and charge carrier transport. Fundamental investigation of the piezotronic effect has attracted broad interest, and various sensing applications have been demonstrated. This brief review discusses the fundamentals of [...] Read more.

Strain-induced polarization charges in a piezoelectric semiconductor effectively modulate the band structure near the interface and charge carrier transport. Fundamental investigation of the piezotronic effect has attracted broad interest, and various sensing applications have been demonstrated. This brief review discusses the fundamentals of the piezotronic effect, followed by a review highlighting important applications for strain sensors, pressure sensors, chemical sensors, photodetectors, humidity sensors and temperature sensors. Finally, the review offers some perspectives and outlook for this new field of multi-functional sensing enabled by the piezotronic effect. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Graphical abstract

23 pages, 1476 KiB

Open AccessReview

Recent Progress in Fluorescent Imaging Probes

by Yen Leng Pak, K. M. K. Swamy and Juyoung Yoon

Sensors 2015, 15(9), 24374-24396; https://doi.org/10.3390/s150924374 - 22 Sep 2015

Cited by 109 | Viewed by 13144

Abstract

Due to the simplicity and low detection limit, especially the bioimaging ability for cells, fluorescence probes serve as unique detection methods. With the aid of molecular recognition and specific organic reactions, research on fluorescent imaging probes has blossomed during the last decade. Especially, [...] Read more.

Due to the simplicity and low detection limit, especially the bioimaging ability for cells, fluorescence probes serve as unique detection methods. With the aid of molecular recognition and specific organic reactions, research on fluorescent imaging probes has blossomed during the last decade. Especially, reaction based fluorescent probes have been proven to be highly selective for specific analytes. This review highlights our recent progress on fluorescent imaging probes for biologically important species, such as biothiols, reactive oxygen species, reactive nitrogen species, metal ions including Zn²⁺, Hg²⁺, Cu²⁺ and Au³⁺, and anions including cyanide and adenosine triphosphate (ATP). Full article

(This article belongs to the Special Issue Fluorescent Probes for Intracellular Imaging and Super Resolution Microscopy)

► Show Figures

Graphical abstract

Other

Jump to: Research, Review

23 pages, 7307 KiB

Open AccessConference Report

GNSS Signal Tracking Performance Improvement for Highly Dynamic Receivers by Gyroscopic Mounting Crystal Oscillator

by Maryam Abedi, Tian Jin and Kewen Sun

Sensors 2015, 15(9), 21673-21695; https://doi.org/10.3390/s150921673 - 31 Aug 2015

Cited by 1 | Viewed by 5496

Abstract

In this paper, the efficiency of the gyroscopic mounting method is studied for a highly dynamic GNSS receiver’s reference oscillator for reducing signal loss. Analyses are performed separately in two phases, atmospheric and upper atmospheric flights. Results show that the proposed mounting reduces [...] Read more.

In this paper, the efficiency of the gyroscopic mounting method is studied for a highly dynamic GNSS receiver’s reference oscillator for reducing signal loss. Analyses are performed separately in two phases, atmospheric and upper atmospheric flights. Results show that the proposed mounting reduces signal loss, especially in parts of the trajectory where its probability is the highest. This reduction effect appears especially for crystal oscillators with a low elevation angle g-sensitivity vector. The gyroscopic mounting influences frequency deviation or jitter caused by dynamic loads on replica carrier and affects the frequency locked loop (FLL) as the dominant tracking loop in highly dynamic GNSS receivers. In terms of steady-state load, the proposed mounting mostly reduces the frequency deviation below the one-sigma threshold of FLL (1σ_FLL). The mounting method can also reduce the frequency jitter caused by sinusoidal vibrations and reduces the probability of signal loss in parts of the trajectory where the other error sources accompany this vibration load. In the case of random vibration, which is the main disturbance source of FLL, gyroscopic mounting is even able to suppress the disturbances greater than the three-sigma threshold of FLL (3σ_FLL). In this way, signal tracking performance can be improved by the gyroscopic mounting method for highly dynamic GNSS receivers. Full article

(This article belongs to the Special Issue Sensors for Harsh-Environment Applications)

► Show Figures

Graphical abstract

8 pages, 214 KiB

Open AccessConference Report

4th International Symposium on Sensor Science (I3S2015): Conference Report

by Peter Seitz, Debbie G. Senesky, Michael J. Schöning, Peter C. Hauser, Roland Moser, Hans Peter Herzig, Assefa M. Melesse, Patricia A. Broderick and Patrick Thomas Eugster

Sensors 2015, 15(9), 24458-24465; https://doi.org/10.3390/s150924458 - 23 Sep 2015

Viewed by 6174

Abstract

An international scientific conference was sponsored by the journal Sensors under the patronage of the University of Basel. The 4th edition of the International Symposium on Sensor Science (I3S2015) ran from 13 to 15 July 2015 in Basel, Switzerland. It comprised five plenary [...] Read more.

An international scientific conference was sponsored by the journal Sensors under the patronage of the University of Basel. The 4th edition of the International Symposium on Sensor Science (I3S2015) ran from 13 to 15 July 2015 in Basel, Switzerland. It comprised five plenary sessions and one morning with three parallel sessions. The conference covered the most exciting aspects and the latest developments in sensor science. The conference dinner took place on the second evening of the conference. The I3S2015 brought together 170 participants from 40 different countries. [...] Full article

(This article belongs to the Special Issue I3S 2015 Selected Papers)

Journal Menu

Journal Browser

Sensors, Volume 15, Issue 9 (September 2015) – 183 articles , Pages 20945-24680

Research

Review

Other

Further Information

Guidelines

MDPI Initiatives

Follow MDPI
