Sensors

Research

Jump to: Review, Other

18 pages, 1161 KiB

Open AccessArticle

Lower Extremity Joint Angle Tracking with Wireless Ultrasonic Sensors during a Squat Exercise

by Yongbin Qi, Cheong Boon Soh, Erry Gunawan, Kay-Soon Low and Rijil Thomas

Sensors 2015, 15(5), 9610-9627; https://doi.org/10.3390/s150509610 - 23 Apr 2015

Cited by 13 | Viewed by 9189

Abstract

This paper presents an unrestrained measurement system based on a wearable wireless ultrasonic sensor network to track the lower extremity joint and trunk kinematics during a squat exercise with only one ultrasonic sensor attached to the trunk. The system consists of an ultrasound [...] Read more.

This paper presents an unrestrained measurement system based on a wearable wireless ultrasonic sensor network to track the lower extremity joint and trunk kinematics during a squat exercise with only one ultrasonic sensor attached to the trunk. The system consists of an ultrasound transmitter (mobile) and multiple receivers (anchors) whose positions are known. The proposed system measures the horizontal and vertical displacement, together with known joint constraints, to estimate joint flexion/extension angles using an inverse kinematic model based on the damped least-squares technique. The performance of the proposed ultrasonic measurement system was validated against a camera-based tracking system on eight healthy subjects performing a planar squat exercise. Joint angles estimated from the ultrasonic system showed a root mean square error (RMSE) of 2.85° ± 0.57° with the reference system. Statistical analysis indicated great agreements between these two systems with a Pearson’s correlation coefficient (PCC) value larger than 0.99 for all joint angles’ estimation. These results show that the proposed ultrasonic measurement system is useful for applications, such as rehabilitation and sports. Full article

(This article belongs to the Special Issue Ultrasonic Sensors and Transducers for Applications in Biology, Medicine and NDT)

► Show Figures

23 pages, 2142 KiB

Open AccessArticle

Angular Displacement and Velocity Sensors Based on Coplanar Waveguides (CPWs) Loaded with S-Shaped Split Ring Resonators (S-SRR)

by Jordi Naqui, Jan Coromina, Ali Karami-Horestani, Christophe Fumeaux and Ferran Martín

Sensors 2015, 15(5), 9628-9650; https://doi.org/10.3390/s150509628 - 23 Apr 2015

Cited by 128 | Viewed by 11820

Abstract

In this paper, angular displacement and angular velocity sensors based on coplanar waveguide (CPW) transmission lines and S-shaped split ring resonators (S-SRRs) are presented. The sensor consists of two parts, namely a CPW and an S-SRR, both lying on parallel planes. By this [...] Read more.

In this paper, angular displacement and angular velocity sensors based on coplanar waveguide (CPW) transmission lines and S-shaped split ring resonators (S-SRRs) are presented. The sensor consists of two parts, namely a CPW and an S-SRR, both lying on parallel planes. By this means, line-to-resonator magnetic coupling arises, the coupling level being dependent on the line-to-resonator relative angular orientation. The line-to-resonator coupling level is the key parameter responsible for modulating the amplitude of the frequency response seen between the CPW ports in the vicinity of the S-SRR fundamental resonance frequency. Specifically, an amplitude notch that can be visualized in the transmission coefficient is changed by the coupling strength, and it is characterized as the sensing variable. Thus, the relative angular orientation between the two parts is measured, when the S-SRR is attached to a rotating object. It follows that the rotation angle and speed can be inferred either by measuring the frequency response of the S-SRR-loaded line, or the response amplitude at a fixed frequency in the vicinity of resonance. It is in addition shown that the angular velocity can be accurately determined from the time-domain response of a carrier time-harmonic signal tuned at the S-SRR resonance frequency. The main advantage of the proposed device is its small size directly related to the small electrical size of the S-SRR, which allows for the design of compact angular displacement and velocity sensors at low frequencies. Despite the small size of the fabricated proof-of-concept prototype (electrically small structures do not usually reject signals efficiently), it exhibits good linearity (on a logarithmic scale), sensitivity and dynamic range. Full article

(This article belongs to the Special Issue Metamaterial-Inspired Sensors)

► Show Figures

Figure 1

15 pages, 10766 KiB

Open AccessArticle

Accuracy Analysis of a Multi-View Stereo Approach for Phenotyping of Tomato Plants at the Organ Level

by Johann Christian Rose, Stefan Paulus and Heiner Kuhlmann

Sensors 2015, 15(5), 9651-9665; https://doi.org/10.3390/s150509651 - 24 Apr 2015

Cited by 120 | Viewed by 10405

Abstract

Accessing a plant’s 3D geometry has become of significant importance for phenotyping during the last few years. Close-up laser scanning is an established method to acquire 3D plant shapes in real time with high detail, but it is stationary and has high investment [...] Read more.

Accessing a plant’s 3D geometry has become of significant importance for phenotyping during the last few years. Close-up laser scanning is an established method to acquire 3D plant shapes in real time with high detail, but it is stationary and has high investment costs. 3D reconstruction from images using structure from motion (SfM) and multi-view stereo (MVS) is a flexible cost-effective method, but requires post-processing procedures. The aim of this study is to evaluate the potential measuring accuracy of an SfM- and MVS-based photogrammetric method for the task of organ-level plant phenotyping. For this, reference data are provided by a high-accuracy close-up laser scanner. Using both methods, point clouds of several tomato plants were reconstructed at six following days. The parameters leaf area, main stem height and convex hull of the complete plant were extracted from the 3D point clouds and compared to the reference data regarding accuracy and correlation. These parameters were chosen regarding the demands of current phenotyping scenarios. The study shows that the photogrammetric approach is highly suitable for the presented monitoring scenario, yielding high correlations to the reference measurements. This cost-effective 3D reconstruction method depicts an alternative to an expensive laser scanner in the studied scenarios with potential for automated procedures. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

15 pages, 705 KiB

Open AccessArticle

Optical Fiber Nanotips Coated with Molecular Beacons for DNA Detection

by Ambra Giannetti, Andrea Barucci, Franco Cosi, Stefano Pelli, Sara Tombelli, Cosimo Trono and Francesco Baldini

Sensors 2015, 15(5), 9666-9680; https://doi.org/10.3390/s150509666 - 24 Apr 2015

Cited by 22 | Viewed by 7552

Abstract

Optical fiber sensors, thanks to their compactness, fast response and real-time measurements, have a large impact in the fields of life science research, drug discovery and medical diagnostics. In recent years, advances in nanotechnology have resulted in the development of nanotools, capable of [...] Read more.

Optical fiber sensors, thanks to their compactness, fast response and real-time measurements, have a large impact in the fields of life science research, drug discovery and medical diagnostics. In recent years, advances in nanotechnology have resulted in the development of nanotools, capable of entering the single cell, resulting in new nanobiosensors useful for the detection of biomolecules inside living cells. In this paper, we provide an application of a nanotip coupled with molecular beacons (MBs) for the detection of DNA. The MBs were characterized by hybridization studies with a complementary target to prove their functionality both free in solution and immobilized onto a solid support. The solid support chosen as substrate for the immobilization of the MBs was a 30 nm tapered tip of an optical fiber, fabricated by chemical etching. With this set-up promising results were obtained and a limit of detection (LOD) of 0.57 nM was reached, opening up the possibility of using the proposed nanotip to detect mRNAs inside the cytoplasm of living cells. Full article

(This article belongs to the Special Issue Smart Materials for Switchable Sensors)

► Show Figures

Figure 1

22 pages, 1370 KiB

Open AccessArticle

Analysis and Experimental Kinematics of a Skid-Steering Wheeled Robot Based on a Laser Scanner Sensor

by Tianmiao Wang, Yao Wu, Jianhong Liang, Chenhao Han, Jiao Chen and Qiteng Zhao

Sensors 2015, 15(5), 9681-9702; https://doi.org/10.3390/s150509681 - 24 Apr 2015

Cited by 63 | Viewed by 19486

Abstract

Skid-steering mobile robots are widely used because of their simple mechanism and robustness. However, due to the complex wheel-ground interactions and the kinematic constraints, it is a challenge to understand the kinematics and dynamics of such a robotic platform. In this paper, we [...] Read more.

Skid-steering mobile robots are widely used because of their simple mechanism and robustness. However, due to the complex wheel-ground interactions and the kinematic constraints, it is a challenge to understand the kinematics and dynamics of such a robotic platform. In this paper, we develop an analysis and experimental kinematic scheme for a skid-steering wheeled vehicle based-on a laser scanner sensor. The kinematics model is established based on the boundedness of the instantaneous centers of rotation (ICR) of treads on the 2D motion plane. The kinematic parameters (the ICR coefficient , the path curvature variable and robot speed ), including the effect of vehicle dynamics, are introduced to describe the kinematics model. Then, an exact but costly dynamic model is used and the simulation of this model’s stationary response for the vehicle shows a qualitative relationship for the specified parameters and . Moreover, the parameters of the kinematic model are determined based-on a laser scanner localization experimental analysis method with a skid-steering robotic platform, Pioneer P3-AT. The relationship between the ICR coefficient and two physical factors is studied, i.e., the radius of the path curvature and the robot speed . An empirical function-based relationship between the ICR coefficient of the robot and the path parameters is derived. To validate the obtained results, it is empirically demonstrated that the proposed kinematics model significantly improves the dead-reckoning performance of this skid–steering robot. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

38 pages, 530 KiB

Open AccessArticle

Routing and Scheduling Algorithms for WirelessHARTNetworks: A Survey

by Marcelo Nobre, Ivanovitch Silva and Luiz Affonso Guedes

Sensors 2015, 15(5), 9703-9740; https://doi.org/10.3390/s150509703 - 24 Apr 2015

Cited by 68 | Viewed by 10925

Abstract

Wireless communication is a trend nowadays for the industrial environment. A number of different technologies have emerged as solutions satisfying strict industrial requirements (e.g., WirelessHART, ISA100.11a, WIA-PA). As the industrial environment presents a vast range of applications, adopting an adequate solution for each [...] Read more.

Wireless communication is a trend nowadays for the industrial environment. A number of different technologies have emerged as solutions satisfying strict industrial requirements (e.g., WirelessHART, ISA100.11a, WIA-PA). As the industrial environment presents a vast range of applications, adopting an adequate solution for each case is vital to obtain good performance of the system. In this context, the routing and scheduling schemes associated with these technologies have a direct impact on important features, like latency and energy consumption. This situation has led to the development of a vast number of routing and scheduling schemes. In the present paper, we focus on the WirelessHART technology, emphasizing its most important routing and scheduling aspects in order to guide both end users and the developers of new algorithms. Furthermore, we provide a detailed literature review of the newest routing and scheduling techniques forWirelessHART, discussing each of their features. These routing algorithms have been evaluated in terms of their objectives, metrics, the usage of theWirelessHART structures and validation method. In addition, the scheduling algorithms were also evaluated by metrics, validation, objectives and, in addition, by multiple superframe support, as well as by the redundancy method used. Moreover, this paper briefly presents some insights into the main WirelessHART simulation modules available, in order to provide viable test platforms for the routing and scheduling algorithms. Finally, some open issues in WirelessHART routing and scheduling algorithms are discussed. Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

15 pages, 449 KiB

Open AccessArticle

Adaptive Control of the Packet Transmission Period with Solar Energy Harvesting Prediction in Wireless Sensor Networks

by Kideok Kwon, Jihoon Yang and Younghwan Yoo

Sensors 2015, 15(5), 9741-9755; https://doi.org/10.3390/s150509741 - 24 Apr 2015

Cited by 14 | Viewed by 6195

Abstract

A number of research works has studied packet scheduling policies in energy scavenging wireless sensor networks, based on the predicted amount of harvested energy. Most of them aim to achieve energy neutrality, which means that an embedded system can operate perpetually while meeting [...] Read more.

A number of research works has studied packet scheduling policies in energy scavenging wireless sensor networks, based on the predicted amount of harvested energy. Most of them aim to achieve energy neutrality, which means that an embedded system can operate perpetually while meeting application requirements. Unlike other renewable energy sources, solar energy has the feature of distinct periodicity in the amount of harvested energy over a day. Using this feature, this paper proposes a packet transmission control policy that can enhance the network performance while keeping sensor nodes alive. Furthermore, this paper suggests a novel solar energy prediction method that exploits the relation between cloudiness and solar radiation. The experimental results and analyses show that the proposed packet transmission policy outperforms others in terms of the deadline miss rate and data throughput. Furthermore, the proposed solar energy prediction method can predict more accurately than others by 6.92%. Full article

(This article belongs to the Special Issue Wireless Sensor Networks and the Internet of Things)

► Show Figures

17 pages, 2493 KiB

Open AccessArticle

Embedded Ultrasonic Transducers for Active and Passive Concrete Monitoring

by Ernst Niederleithinger, Julia Wolf, Frank Mielentz, Herbert Wiggenhauser and Stephan Pirskawetz

Sensors 2015, 15(5), 9756-9772; https://doi.org/10.3390/s150509756 - 27 Apr 2015

Cited by 69 | Viewed by 11939

Abstract

Recently developed new transducers for ultrasonic transmission, which can be embedded right into concrete, are now used for non-destructive permanent monitoring of concrete. They can be installed during construction or thereafter. Large volumes of concrete can be monitored for changes of material properties [...] Read more.

Recently developed new transducers for ultrasonic transmission, which can be embedded right into concrete, are now used for non-destructive permanent monitoring of concrete. They can be installed during construction or thereafter. Large volumes of concrete can be monitored for changes of material properties by a limited number of transducers. The transducer design, the main properties as well as installation procedures are presented. It is shown that compressional waves with a central frequency of 62 kHz are mainly generated around the transducer’s axis. The transducer can be used as a transmitter or receiver. Application examples demonstrate that the transducers can be used to monitor concrete conditions parameters (stress, temperature, …) as well as damages in an early state or the detection of acoustic events (e.g., crack opening). Besides application in civil engineering our setups can also be used for model studies in geosciences. Full article

(This article belongs to the Special Issue Novel Sensors for Non-Destructive Testing and Structural Health Monitoring)

► Show Figures

Figure 1

18 pages, 2857 KiB

Open AccessArticle

Tidal Volume Estimation Using the Blanket Fractal Dimension of the Tracheal Sounds Acquired by Smartphone

by Natasa Reljin, Bersain A. Reyes and Ki H. Chon

Sensors 2015, 15(5), 9773-9790; https://doi.org/10.3390/s150509773 - 27 Apr 2015

Cited by 21 | Viewed by 7882

Abstract

In this paper, we propose the use of blanket fractal dimension (BFD) to estimate the tidal volume from smartphone-acquired tracheal sounds. We collected tracheal sounds with a Samsung Galaxy S4 smartphone, from five (N = 5) healthy volunteers. Each volunteer performed the [...] Read more.

In this paper, we propose the use of blanket fractal dimension (BFD) to estimate the tidal volume from smartphone-acquired tracheal sounds. We collected tracheal sounds with a Samsung Galaxy S4 smartphone, from five (N = 5) healthy volunteers. Each volunteer performed the experiment six times; first to obtain linear and exponential fitting models, and then to fit new data onto the existing models. Thus, the total number of recordings was 30. The estimated volumes were compared to the true values, obtained with a Respitrace system, which was considered as a reference. Since Shannon entropy (SE) is frequently used as a feature in tracheal sound analyses, we estimated the tidal volume from the same sounds by using SE as well. The evaluation of the performed estimation, using BFD and SE methods, was quantified by the normalized root-mean-squared error (NRMSE). The results show that the BFD outperformed the SE (at least twice smaller NRMSE was obtained). The smallest NRMSE error of 15.877% ± 9.246% (mean ± standard deviation) was obtained with the BFD and exponential model. In addition, it was shown that the fitting curves calculated during the first day of experiments could be successfully used for at least the five following days. Full article

(This article belongs to the Special Issue Smartphone-Based Sensors for Non-Invasive Physiological Monitoring)

► Show Figures

Figure 1

24 pages, 6340 KiB

Open AccessArticle

Novel Monitoring Techniques for Characterizing Frictional Interfaces in the Laboratory

by Paul A. Selvadurai and Steven D. Glaser

Sensors 2015, 15(5), 9791-9814; https://doi.org/10.3390/s150509791 - 27 Apr 2015

Cited by 18 | Viewed by 6041

Abstract

A pressure-sensitive film was used to characterize the asperity contacts along a polymethyl methacrylate (PMMA) interface in the laboratory. The film has structural health monitoring (SHM) applications for flanges and other precision fittings and train rail condition monitoring. To calibrate the film, simple [...] Read more.

A pressure-sensitive film was used to characterize the asperity contacts along a polymethyl methacrylate (PMMA) interface in the laboratory. The film has structural health monitoring (SHM) applications for flanges and other precision fittings and train rail condition monitoring. To calibrate the film, simple spherical indentation tests were performed and validated against a finite element model (FEM) to compare normal stress profiles. Experimental measurements of the normal stress profiles were within −7.7% to 6.6% of the numerical calculations between 12 and 50 MPa asperity normal stress. The film also possessed the capability of quantifying surface roughness, an important parameter when examining wear and attrition in SHM applications. A high definition video camera supplied data for photometric analysis (i.e., the measure of visible light) of asperities along the PMMA-PMMA interface in a direct shear configuration, taking advantage of the transparent nature of the sample material. Normal stress over individual asperities, calculated with the pressure-sensitive film, was compared to the light intensity transmitted through the interface. We found that the luminous intensity transmitted through individual asperities linearly increased 0.05643 ± 0.0012 candelas for an increase of 1 MPa in normal stress between normal stresses ranging from 23 to 33 MPa. Full article

(This article belongs to the Special Issue Novel Sensors for Non-Destructive Testing and Structural Health Monitoring)

► Show Figures

12 pages, 3680 KiB

Open AccessArticle

A PDMS-Based 2-Axis Waterproof Scanner for Photoacoustic Microscopy

by Jin Young Kim, Changho Lee, Kyungjin Park, Geunbae Lim and Chulhong Kim

Sensors 2015, 15(5), 9815-9826; https://doi.org/10.3390/s150509815 - 27 Apr 2015

Cited by 36 | Viewed by 8539

Abstract

Optical-resolution photoacoustic microscopy (OR-PAM) is an imaging tool to provide in vivo optically sensitive images in biomedical research. To achieve a small size, fast imaging speed, wide scan range, and high signal-to-noise ratios (SNRs) in a water environment, we introduce a polydimethylsiloxane (PDMS)-based [...] Read more.

Optical-resolution photoacoustic microscopy (OR-PAM) is an imaging tool to provide in vivo optically sensitive images in biomedical research. To achieve a small size, fast imaging speed, wide scan range, and high signal-to-noise ratios (SNRs) in a water environment, we introduce a polydimethylsiloxane (PDMS)-based 2-axis scanner for a flexible and waterproof structure. The design, theoretical background, fabrication process and performance of the scanner are explained in details. The designed and fabricated scanner has dimensions of 15 × 15 × 15 mm along the X, Y and Z axes, respectively. The characteristics of the scanner are tested under DC and AC conditions. By pairing with electromagnetic forces, the maximum scanning angles in air and water are 18° and 13° along the X and Y axes, respectively. The measured resonance frequencies in air and water are 60 and 45 Hz along the X axis and 45 and 30 Hz along the Y axis, respectively. Finally, OR-PAM with high SNRs is demonstrated using the fabricated scanner, and the PA images of micro-patterned samples and microvasculatures of a mouse ear are successfully obtained with high-resolution and wide-field of view. OR-PAM equipped with the 2-axis PDMS based waterproof scanner has lateral and axial resolutions of 3.6 μm and 26 μm, respectively. This compact OR-PAM system could potentially and widely be used in preclinical and clinical applications. Full article

(This article belongs to the Special Issue Modeling, Testing and Reliability Issues in MEMS Engineering)

► Show Figures

Figure 1

27 pages, 1274 KiB

Open AccessArticle

A Self-Alignment Algorithm for SINS Based on Gravitational Apparent Motion and Sensor Data Denoising

by Yiting Liu, Xiaosu Xu, Xixiang Liu, Yiqing Yao, Liang Wu and Jin Sun

Sensors 2015, 15(5), 9827-9853; https://doi.org/10.3390/s150509827 - 27 Apr 2015

Cited by 24 | Viewed by 6718

Abstract

Initial alignment is always a key topic and difficult to achieve in an inertial navigation system (INS). In this paper a novel self-initial alignment algorithm is proposed using gravitational apparent motion vectors at three different moments and vector-operation. Simulation and analysis showed that [...] Read more.

Initial alignment is always a key topic and difficult to achieve in an inertial navigation system (INS). In this paper a novel self-initial alignment algorithm is proposed using gravitational apparent motion vectors at three different moments and vector-operation. Simulation and analysis showed that this method easily suffers from the random noise contained in accelerometer measurements which are used to construct apparent motion directly. Aiming to resolve this problem, an online sensor data denoising method based on a Kalman filter is proposed and a novel reconstruction method for apparent motion is designed to avoid the collinearity among vectors participating in the alignment solution. Simulation, turntable tests and vehicle tests indicate that the proposed alignment algorithm can fulfill initial alignment of strapdown INS (SINS) under both static and swinging conditions. The accuracy can either reach or approach the theoretical values determined by sensor precision under static or swinging conditions. Full article

(This article belongs to the Special Issue Inertial Sensors and Systems)

► Show Figures

Graphical abstract

16 pages, 2381 KiB

Open AccessArticle

Smartphone Applications with Sensors Used in a Tertiary Hospital—Current Status and Future Challenges

by Yu Rang Park, Yura Lee, Guna Lee, Jae Ho Lee and Soo-Yong Shin

Sensors 2015, 15(5), 9854-9869; https://doi.org/10.3390/s150509854 - 27 Apr 2015

Cited by 16 | Viewed by 9567

Abstract

Smartphones have been widely used recently to monitor heart rate and activity, since they have the necessary processing power, non-invasive and cost-effective sensors, and wireless communication capabilities. Consequently, healthcare applications (apps) using smartphone-based sensors have been highlighted for non-invasive physiological monitoring. In addition, [...] Read more.

Smartphones have been widely used recently to monitor heart rate and activity, since they have the necessary processing power, non-invasive and cost-effective sensors, and wireless communication capabilities. Consequently, healthcare applications (apps) using smartphone-based sensors have been highlighted for non-invasive physiological monitoring. In addition, several healthcare apps have received FDA clearance. However, in spite of their potential, healthcare apps with smartphone-based sensors are mostly used outside of hospitals and have not been widely adopted for patient care in hospitals until recently. In this paper, we describe the experience of using smartphone apps with sensors in a large medical center in Korea. Among >20 apps developed in our medical center, four were extensively analyzed (“My Cancer Diary”, “Point-of-Care HIV Check”, “Blood Culture” and “mAMIS”), since they use smartphone-based sensors such as the camera and barcode reader to enter data into the electronic health record system. By analyzing the usage patterns of these apps for data entry with sensors, the current limitations of smartphone-based sensors in a clinical setting, hurdles against adoption in the medical center, benefits of smartphone-based sensors and potential future research directions could be evaluated. Full article

(This article belongs to the Special Issue Smartphone-Based Sensors for Non-Invasive Physiological Monitoring)

► Show Figures

Figure 1

12 pages, 1340 KiB

Open AccessArticle

Reversible NO₂ Optical Fiber Chemical Sensor Based on LuPc₂ Using Simultaneous Transmission of UV and Visible Light

by Antonio Bueno, Driss Lahem, Christophe Caucheteur and Marc Debliquy

Sensors 2015, 15(5), 9870-9881; https://doi.org/10.3390/s150509870 - 27 Apr 2015

Cited by 13 | Viewed by 6381

Abstract

In this paper, an NO₂ optical fiber sensor is presented for pollution monitoring in road traffic applications. This sensor exploits the simultaneous transmission of visible light, as a measurement signal, and UV light, for the recovery of the NO₂ sensitive materials. [...] Read more.

In this paper, an NO₂ optical fiber sensor is presented for pollution monitoring in road traffic applications. This sensor exploits the simultaneous transmission of visible light, as a measurement signal, and UV light, for the recovery of the NO₂ sensitive materials. The sensor is based on a multimode fiber tip coated with a thin film of lutetium bisphthalocyanine (LuPc₂). The simultaneous injection of UV light through the fiber is an improvement on the previously developed NO₂ sensors and allows the simplification of the sensor head, rendering the external UV illumination of the film unnecessary. Coatings of different thicknesses were deposited on the optical fiber tips and the best performance was obtained for a 15 nm deposited thickness, with a sensitivity of 5.02 mV/ppm and a resolution of 0.2 ppb in the range 0–5 ppm. The response and recovery times are not dependent on thickness, meaning that NO₂ does not diffuse completely in the films. Full article

(This article belongs to the Special Issue Modern Technologies for Sensing Pollution in Air, Water, and Soil)

► Show Figures

Figure 1

17 pages, 1287 KiB

Open AccessArticle

Separation of Radio-Frequency Sources and Localization of Partial Discharges in Noisy Environments

by Guillermo Robles, José Manuel Fresno and Juan Manuel Martínez-Tarifa

Sensors 2015, 15(5), 9882-9898; https://doi.org/10.3390/s150509882 - 27 Apr 2015

Cited by 45 | Viewed by 6395

Abstract

The detection of partial discharges (PD) can help in early-warning detection systems to protect critical assets in power systems. The radio-frequency emission of these events can be measured with antennas even when the equipment is in service which reduces dramatically the maintenance costs [...] Read more.

The detection of partial discharges (PD) can help in early-warning detection systems to protect critical assets in power systems. The radio-frequency emission of these events can be measured with antennas even when the equipment is in service which reduces dramatically the maintenance costs and favours the implementation of condition-based monitoring systems. The drawback of these type of measurements is the difficulty of having a reference signal to study the events in a classical phase-resolved partial discharge pattern (PRPD). Therefore, in open-air substations and overhead lines where interferences from radio and TV broadcasting and mobile communications are important sources of noise and other pulsed interferences from rectifiers or inverters can be present, it is difficult to identify whether there is partial discharges activity or not. This paper proposes a robust method to separate the events captured with the antennas, identify which of them are partial discharges and localize the piece of equipment that is having problems. The separation is done with power ratio (PR) maps based on the spectral characteristics of the signal and the identification of the type of event is done localizing the source with an array of four antennas. Several classical methods to calculate the time differences of arrival (TDOA) of the emission to the antennas have been tested, and the localization is done using particle swarm optimization (PSO) to minimize a distance function. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

16 pages, 4698 KiB

Open AccessArticle

A Non-Contact Pulse Automatic Positioning Measurement System for Traditional Chinese Medicine

by Ying-Yun Chen, Rong-Seng Chang, Ko-Wen Jwo, Chung-Chi Hsu and Chu-Pang Tsao

Sensors 2015, 15(5), 9899-9914; https://doi.org/10.3390/s150509899 - 27 Apr 2015

Cited by 19 | Viewed by 11119

Abstract

This study is to construct a non-contact pulse automatic positioning measurement system for Traditional Chinese Medicine (TCM) using optical triangulation measurements. The system consists of a linear laser, a CMOS image sensor and image analysis software. The linear laser is projected on the [...] Read more.

This study is to construct a non-contact pulse automatic positioning measurement system for Traditional Chinese Medicine (TCM) using optical triangulation measurements. The system consists of a linear laser, a CMOS image sensor and image analysis software. The linear laser is projected on the pulse beat location on the wrists; the CMOS image sensor records the process and the software analyzes the images. The program mainly uses the optical centroid and fast Fourier transform (FFT) principles to calculate centroid changes (pulse amplitude changes) from the images taken by the CMOS image sensor. It returns the positions of cun, guan and chi pulses automatically in terms of the amplitudes and the signals are then transformed from the time domain (time-amplitude) into the frequency domain (frequency-amplitude) via FFT to obtain the waveforms and frequencies of the cun, guan and chi pulses. It successfully extracts the data from the TCM pulse reading and can be a medical aid system for TCM. Combining the advantages of optical measurement and computer automation, this system provides a non-contact, easy to operate, fast in detection and low-cost equipment design. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

14 pages, 1422 KiB

Open AccessArticle

A High-Resolution Demodulation Algorithm for FBG-FP Static-Strain Sensors Based on the Hilbert Transform and Cross Third-Order Cumulant

by Wenzhu Huang, Tengkun Zhen, Wentao Zhang, Fusheng Zhang and Fang Li

Sensors 2015, 15(5), 9928-9941; https://doi.org/10.3390/s150509928 - 27 Apr 2015

Cited by 10 | Viewed by 5821

Abstract

Static strain can be detected by measuring a cross-correlation of reflection spectra from two fiber Bragg gratings (FBGs). However, the static-strain measurement resolution is limited by the dominant Gaussian noise source when using this traditional method. This paper presents a novel static-strain demodulation [...] Read more.

Static strain can be detected by measuring a cross-correlation of reflection spectra from two fiber Bragg gratings (FBGs). However, the static-strain measurement resolution is limited by the dominant Gaussian noise source when using this traditional method. This paper presents a novel static-strain demodulation algorithm for FBG-based Fabry-Perot interferometers (FBG-FPs). The Hilbert transform is proposed for changing the Gaussian distribution of the two FBG-FPs’ reflection spectra, and a cross third-order cumulant is used to use the results of the Hilbert transform and get a group of noise-vanished signals which can be used to accurately calculate the wavelength difference of the two FBG-FPs. The benefit by these processes is that Gaussian noise in the spectra can be suppressed completely in theory and a higher resolution can be reached. In order to verify the precision and flexibility of this algorithm, a detailed theory model and a simulation analysis are given, and an experiment is implemented. As a result, a static-strain resolution of 0.9 nε under laboratory environment condition is achieved, showing a higher resolution than the traditional cross-correlation method. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

20 pages, 1580 KiB

Open AccessArticle

Daytime Land Surface Temperature Extraction from MODIS Thermal Infrared Data under Cirrus Clouds

by Xiwei Fan, Bo-Hui Tang, Hua Wu, Guangjian Yan and Zhao-Liang Li

Sensors 2015, 15(5), 9942-9961; https://doi.org/10.3390/s150509942 - 28 Apr 2015

Cited by 10 | Viewed by 5770

Abstract

Simulated data showed that cirrus clouds could lead to a maximum land surface temperature (LST) retrieval error of 11.0 K when using the generalized split-window (GSW) algorithm with a cirrus optical depth (COD) at 0.55 μm of 0.4 and in nadir [...] Read more.

Simulated data showed that cirrus clouds could lead to a maximum land surface temperature (LST) retrieval error of 11.0 K when using the generalized split-window (GSW) algorithm with a cirrus optical depth (COD) at 0.55 μm of 0.4 and in nadir view. A correction term in the COD linear function was added to the GSW algorithm to extend the GSW algorithm to cirrus cloudy conditions. The COD was acquired by a look up table of the isolated cirrus bidirectional reflectance at 0.55 μm. Additionally, the slope k of the linear function was expressed as a multiple linear model of the top of the atmospheric brightness temperatures of MODIS channels 31–34 and as the difference between split-window channel emissivities. The simulated data showed that the LST error could be reduced from 11.0 to 2.2 K. The sensitivity analysis indicated that the total errors from all the uncertainties of input parameters, extension algorithm accuracy, and GSW algorithm accuracy were less than 2.5 K in nadir view. Finally, the Great Lakes surface water temperatures measured by buoys showed that the retrieval accuracy of the GSW algorithm was improved by at least 1.5 K using the proposed extension algorithm for cirrus skies. Full article

(This article belongs to the Section Remote Sensors)

► Show Figures

Figure 1

24 pages, 911 KiB

Open AccessArticle

Beyond Where to How: A Machine Learning Approach for Sensing Mobility Contexts Using Smartphone Sensors

by Robert E. Guinness

Sensors 2015, 15(5), 9962-9985; https://doi.org/10.3390/s150509962 - 28 Apr 2015

Cited by 28 | Viewed by 8789

Abstract

This paper presents the results of research on the use of smartphone sensors (namely, GPS and accelerometers), geospatial information (points of interest, such as bus stops and train stations) and machine learning (ML) to sense mobility contexts. Our goal is to develop techniques [...] Read more.

This paper presents the results of research on the use of smartphone sensors (namely, GPS and accelerometers), geospatial information (points of interest, such as bus stops and train stations) and machine learning (ML) to sense mobility contexts. Our goal is to develop techniques to continuously and automatically detect a smartphone user’s mobility activities, including walking, running, driving and using a bus or train, in real-time or near-real-time (<5 s). We investigated a wide range of supervised learning techniques for classification, including decision trees (DT), support vector machines (SVM), naive Bayes classifiers (NB), Bayesian networks (BN), logistic regression (LR), artificial neural networks (ANN) and several instance-based classifiers (KStar, LWLand IBk). Applying ten-fold cross-validation, the best performers in terms of correct classification rate (i.e., recall) were DT (96.5%), BN (90.9%), LWL (95.5%) and KStar (95.6%). In particular, the DT-algorithm RandomForest exhibited the best overall performance. After a feature selection process for a subset of algorithms, the performance was improved slightly. Furthermore, after tuning the parameters of RandomForest, performance improved to above 97.5%. Lastly, we measured the computational complexity of the classifiers, in terms of central processing unit (CPU) time needed for classification, to provide a rough comparison between the algorithms in terms of battery usage requirements. As a result, the classifiers can be ranked from lowest to highest complexity (i.e., computational cost) as follows: SVM, ANN, LR, BN, DT, NB, IBk, LWL and KStar. The instance-based classifiers take considerably more computational time than the non-instance-based classifiers, whereas the slowest non-instance-based classifier (NB) required about five-times the amount of CPU time as the fastest classifier (SVM). The above results suggest that DT algorithms are excellent candidates for detecting mobility contexts in smartphones, both in terms of performance and computational complexity. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

18 pages, 2046 KiB

Open AccessArticle

A Sensorless Predictive Current Controlled Boost Converter by Using an EKF with Load Variation Effect Elimination Function

by Qiaoling Tong, Chen Chen, Qiao Zhang and Xuecheng Zou

Sensors 2015, 15(5), 9986-10003; https://doi.org/10.3390/s150509986 - 28 Apr 2015

Cited by 18 | Viewed by 6993

Abstract

To realize accurate current control for a boost converter, a precise measurement of the inductor current is required to achieve high resolution current regulating. Current sensors are widely used to measure the inductor current. However, the current sensors and their processing circuits significantly [...] Read more.

To realize accurate current control for a boost converter, a precise measurement of the inductor current is required to achieve high resolution current regulating. Current sensors are widely used to measure the inductor current. However, the current sensors and their processing circuits significantly contribute extra hardware cost, delay and noise to the system. They can also harm the system reliability. Therefore, current sensorless control techniques can bring cost effective and reliable solutions for various boost converter applications. According to the derived accurate model, which contains a number of parasitics, the boost converter is a nonlinear system. An Extended Kalman Filter (EKF) is proposed for inductor current estimation and output voltage filtering. With this approach, the system can have the same advantages as sensored current control mode. To implement EKF, the load value is necessary. However, the load may vary from time to time. This can lead to errors of current estimation and filtered output voltage. To solve this issue, a load variation elimination effect elimination (LVEE) module is added. In addition, a predictive average current controller is used to regulate the current. Compared with conventional voltage controlled system, the transient response is greatly improved since it only takes two switching cycles for the current to reach its reference. Finally, experimental results are presented to verify the stable operation and output tracking capability for large-signal transients of the proposed algorithm. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

22 pages, 1694 KiB

Open AccessArticle

MEMS Flow Sensors Based on Self-Heated aGe-Thermistors in a Wheatstone Bridge

by Almir Talic, Samir Cerimovic, Roman Beigelbeck, Franz Kohl, Thilo Sauter and Franz Keplinger

Sensors 2015, 15(5), 10004-10025; https://doi.org/10.3390/s150510004 - 28 Apr 2015

Cited by 19 | Viewed by 12092

Abstract

A thermal flow transduction method combining the advantages of calorimetric and hot-film transduction principles is developed and analyzed by Finite Element Method (FEM) simulations and confirmed experimentally. The analyses include electrothermal feedback effects of current driven NTC thermistors. Four thin-film germanium thermistors acting [...] Read more.

A thermal flow transduction method combining the advantages of calorimetric and hot-film transduction principles is developed and analyzed by Finite Element Method (FEM) simulations and confirmed experimentally. The analyses include electrothermal feedback effects of current driven NTC thermistors. Four thin-film germanium thermistors acting simultaneously as heat sources and as temperature sensors are embedded in a micromachined silicon-nitride membrane. These devices form a self-heated Wheatstone bridge that is unbalanced by convective cooling. The voltage across the bridge and the total dissipated power are exploited as output quantities. The used thin-film thermistors feature an extremely high temperature sensitivity. Combined with properly designed resistance values, a power demand in sub-1mW range enables efficient gas-flow transduction, as confirmed by measurements. Two sensor configurations with different arrangements of the membrane thermistors were examined experimentally. Moreover, we investigated the influence of different layouts on the rise time, the sensitivity, and the usable flow range by means of two-dimensional finite element simulations. The simulation results are in reasonable agreement with corresponding measurement data confirming the basic assumptions and modeling approach. Full article

(This article belongs to the Collection Modeling, Testing and Reliability Issues in MEMS Engineering)

► Show Figures

Figure 1

22 pages, 682 KiB

Open AccessArticle

A Multi-Agent Framework for Packet Routing in Wireless Sensor Networks

by Dayong Ye, Minjie Zhang and Yun Yang

Sensors 2015, 15(5), 10026-10047; https://doi.org/10.3390/s150510026 - 28 Apr 2015

Cited by 88 | Viewed by 6370

Abstract

Wireless sensor networks (WSNs) have been widely investigated in recent years. One of the fundamental issues in WSNs is packet routing, because in many application domains, packets have to be routed from source nodes to destination nodes as soon and as energy efficiently [...] Read more.

Wireless sensor networks (WSNs) have been widely investigated in recent years. One of the fundamental issues in WSNs is packet routing, because in many application domains, packets have to be routed from source nodes to destination nodes as soon and as energy efficiently as possible. To address this issue, a large number of routing approaches have been proposed. Although every existing routing approach has advantages, they also have some disadvantages. In this paper, a multi-agent framework is proposed that can assist existing routing approaches to improve their routing performance. This framework enables each sensor node to build a cooperative neighbour set based on past routing experience. Such cooperative neighbours, in turn, can help the sensor to effectively relay packets in the future. This framework is independent of existing routing approaches and can be used to assist many existing routing approaches. Simulation results demonstrate the good performance of this framework in terms of four metrics: average delivery latency, successful delivery ratio, number of live nodes and total sensing coverage. Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

11 pages, 1600 KiB

Open AccessArticle

A Resonant Pressure Microsensor Capable of Self-Temperature Compensation

by Yinan Li, Junbo Wang, Zhenyu Luo, Deyong Chen and Jian Chen

Sensors 2015, 15(5), 10048-10058; https://doi.org/10.3390/s150510048 - 29 Apr 2015

Cited by 40 | Viewed by 7794

Abstract

Resonant pressure microsensors are widely used in the fields of aerospace exploration and atmospheric pressure monitoring due to their advantages of quasi-digital output and long-term stability, which, however, requires the use of additional temperature sensors for temperature compensation. This paper presents a resonant [...] Read more.

Resonant pressure microsensors are widely used in the fields of aerospace exploration and atmospheric pressure monitoring due to their advantages of quasi-digital output and long-term stability, which, however, requires the use of additional temperature sensors for temperature compensation. This paper presents a resonant pressure microsensor capable of self-temperature compensation without the need for additional temperature sensors. Two doubly-clamped “H” type resonant beams were arranged on the pressure diaphragm, which functions as a differential output in response to pressure changes. Based on calibration of a group of intrinsic resonant frequencies at different pressure and temperature values, the functions with inputs of two resonant frequencies and outputs of temperature and pressure under measurement were obtained and thus the disturbance of temperature variations on resonant frequency shifts was properly addressed. Before compensation, the maximal errors of the measured pressure values were over 1.5% while after compensation, the errors were less than 0.01% of the full pressure scale (temperature range of −40 °C to 70 °C and pressure range of 50 kPa to 110 kPa). Full article

(This article belongs to the Collection Modeling, Testing and Reliability Issues in MEMS Engineering)

► Show Figures

Figure 1

15 pages, 1372 KiB

Open AccessArticle

Sensitive, Fast, and Specific Immunoassays for Methyltestosterone Detection

by Na Kong, Shanshan Song, Juan Peng, Liqiang Liu, Hua Kuang and Chuanlai Xu

Sensors 2015, 15(5), 10059-10073; https://doi.org/10.3390/s150510059 - 29 Apr 2015

Cited by 19 | Viewed by 6288

Abstract

An indirect competitive enzyme-linked immunosorbent assay (icELISA) and an immunochromatographic strip assay using a highly specific monoclonal antibody, were developed to detect methyltestosterone (MT) residues in animal feed. The optimized icELISA had a half-inhibition concentration value of 0.26 ng/mL and a limit of [...] Read more.

An indirect competitive enzyme-linked immunosorbent assay (icELISA) and an immunochromatographic strip assay using a highly specific monoclonal antibody, were developed to detect methyltestosterone (MT) residues in animal feed. The optimized icELISA had a half-inhibition concentration value of 0.26 ng/mL and a limit of detection value of 0.045 ng/mL. There was no cross-reactivity with eight analogues, revealing high specificity for MT. Based on icELISA results, the recovery rate of MT in animal feed was 82.4%–100.6%. The results were in accordance with those obtained by gas chromatography-mass spectrometry. The developed immunochromatographic strip assay, as the first report for MT detection, had a visual cut-off value of 1 ng/mL in PBS, 2.5 ng/g in fish feed, and 2.5 ng/g in pig feed. Therefore, these immunoassays are useful and fast tools for MT residue detection in animal feed. Full article

(This article belongs to the Special Issue Immunosensors 2014)

► Show Figures

Figure 1

14 pages, 1355 KiB

Open AccessArticle

A New Indoor Positioning System Architecture Using GPS Signals

by Rui Xu, Wu Chen, Ying Xu and Shengyue Ji

Sensors 2015, 15(5), 10074-10087; https://doi.org/10.3390/s150510074 - 29 Apr 2015

Cited by 78 | Viewed by 12481

Abstract

The pseudolite system is a good alternative for indoor positioning systems due to its large coverage area and accurate positioning solution. However, for common Global Positioning System (GPS) receivers, the pseudolite system requires some modifications of the user terminals. To solve the problem, [...] Read more.

The pseudolite system is a good alternative for indoor positioning systems due to its large coverage area and accurate positioning solution. However, for common Global Positioning System (GPS) receivers, the pseudolite system requires some modifications of the user terminals. To solve the problem, this paper proposes a new pseudolite-based indoor positioning system architecture. The main idea is to receive real-world GPS signals, repeat each satellite signal and transmit those using indoor transmitting antennas. The transmitted GPS-like signal can be processed (signal acquisition and tracking, navigation data decoding) by the general receiver and thus no hardware-level modification on the receiver is required. In addition, all Tx can be synchronized with each other since one single clock is used in Rx/Tx. The proposed system is simulated using a software GPS receiver. The simulation results show the indoor positioning system is able to provide high accurate horizontal positioning in both static and dynamic situations. Full article

(This article belongs to the Special Issue Sensors for Indoor Mapping and Navigation)

► Show Figures

Figure 1

12 pages, 2613 KiB

Open AccessArticle

Silver Nanoparticle-Enhanced Resonance Raman Sensor of Chromium(III) in Seawater Samples

by Nguyễn Hoàng Ly and Sang-Woo Joo

Sensors 2015, 15(5), 10088-10099; https://doi.org/10.3390/s150510088 - 29 Apr 2015

Cited by 19 | Viewed by 8473

Abstract

Tris(hydroxymethyl)aminomethane ethylenediaminetetraacetic acid (Tris-EDTA), upon binding Cr(III) in aqueous solutions at pH 8.0 on silver nanoparticles (AgNPs), was found to provide a sensitive and selective Raman marker band at ~563 cm⁻¹, which can be ascribed to the metal-N band. UV-Vis absorption [...] Read more.

Tris(hydroxymethyl)aminomethane ethylenediaminetetraacetic acid (Tris-EDTA), upon binding Cr(III) in aqueous solutions at pH 8.0 on silver nanoparticles (AgNPs), was found to provide a sensitive and selective Raman marker band at ~563 cm⁻¹, which can be ascribed to the metal-N band. UV-Vis absorption spectra also supported the aggregation and structural change of EDTA upon binding Cr(III). Only for Cr(III) concentrations above 500 nM, the band at ~563 cm⁻¹ become strongly intensified in the surface-enhanced Raman scattering spectra. This band, due to the metal-EDTA complex, was not observed in the case of 50 mM of K⁺, Cd²⁺, Mg²⁺, Ca²⁺, Mn²⁺, Co²⁺, Na⁺, Cu²⁺, NH₄⁺, Hg²⁺, Ni²⁺, Fe³⁺, Pb²⁺, Fe²⁺, and Zn²⁺ ions. Seawater samples containing K, Mg, Ca, and Na ion concentrations higher than 8 mM also showed the characteristic Raman band at ~563 cm⁻¹ above 500 nM, validating our method. Our approach may be useful in detecting real water samples by means of AgNPs and Raman spectroscopy. Full article

(This article belongs to the Section Chemical Sensors)

► Show Figures

Graphical abstract

18 pages, 286 KiB

Open AccessArticle

Unsupervised Classification of Surface Defects in Wire Rod Production Obtained by Eddy Current Sensors

by Sergio Saludes-Rodil, Enrique Baeyens and Carlos P. Rodríguez-Juan

Sensors 2015, 15(5), 10100-10117; https://doi.org/10.3390/s150510100 - 29 Apr 2015

Cited by 10 | Viewed by 7313

Abstract

An unsupervised approach to classify surface defects in wire rod manufacturing is developed in this paper. The defects are extracted from an eddy current signal and classified using a clustering technique that uses the dynamic time warping distance as the dissimilarity measure. The [...] Read more.

An unsupervised approach to classify surface defects in wire rod manufacturing is developed in this paper. The defects are extracted from an eddy current signal and classified using a clustering technique that uses the dynamic time warping distance as the dissimilarity measure. The new approach has been successfully tested using industrial data. It is shown that it outperforms other classification alternatives, such as the modified Fourier descriptors. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

28 pages, 3060 KiB

Open AccessArticle

Joint Infrared Target Recognition and Segmentation Using a Shape Manifold-Aware Level Set

by Liangjiang Yu, Guoliang Fan, Jiulu Gong and Joseph P. Havlicek

Sensors 2015, 15(5), 10118-10145; https://doi.org/10.3390/s150510118 - 29 Apr 2015

Cited by 12 | Viewed by 9924

Abstract

We propose new techniques for joint recognition, segmentation and pose estimation of infrared (IR) targets. The problem is formulated in a probabilistic level set framework where a shape constrained generative model is used to provide a multi-class and multi-view shape prior and where [...] Read more.

We propose new techniques for joint recognition, segmentation and pose estimation of infrared (IR) targets. The problem is formulated in a probabilistic level set framework where a shape constrained generative model is used to provide a multi-class and multi-view shape prior and where the shape model involves a couplet of view and identity manifolds (CVIM). A level set energy function is then iteratively optimized under the shape constraints provided by the CVIM. Since both the view and identity variables are expressed explicitly in the objective function, this approach naturally accomplishes recognition, segmentation and pose estimation as joint products of the optimization process. For realistic target chips, we solve the resulting multi-modal optimization problem by adopting a particle swarm optimization (PSO) algorithm and then improve the computational efficiency by implementing a gradient-boosted PSO (GB-PSO). Evaluation was performed using the Military Sensing Information Analysis Center (SENSIAC) ATR database, and experimental results show that both of the PSO algorithms reduce the cost of shape matching during CVIM-based shape inference. Particularly, GB-PSO outperforms other recent ATR algorithms, which require intensive shape matching, either explicitly (with pre-segmentation) or implicitly (without pre-segmentation). Full article

(This article belongs to the Special Issue Sensors in New Road Vehicles)

► Show Figures

20 pages, 1166 KiB

Open AccessArticle

A New MEMS Gyroscope Used for Single-Channel Damping

by Zengping Zhang, Wei Zhang, Fuxue Zhang and Biao Wang

Sensors 2015, 15(5), 10146-10165; https://doi.org/10.3390/s150510146 - 30 Apr 2015

Cited by 6 | Viewed by 7830

Abstract

The silicon micromechanical gyroscope, which will be introduced in this paper, represents a novel MEMS gyroscope concept. It is used for the damping of a single-channel control system of rotating aircraft. It differs from common MEMS gyroscopes in that does not have a [...] Read more.

The silicon micromechanical gyroscope, which will be introduced in this paper, represents a novel MEMS gyroscope concept. It is used for the damping of a single-channel control system of rotating aircraft. It differs from common MEMS gyroscopes in that does not have a drive structure, itself, and only has a sense structure. It is installed on a rotating aircraft, and utilizes the aircraft spin to make its sensing element obtain angular momentum. When the aircraft is subjected to an angular rotation, a periodic Coriolis force is induced in the direction orthogonal to both the angular momentum and the angular velocity input axis. This novel MEMS gyroscope can thus sense angular velocity inputs. The output sensing signal is exactly an amplitude-modulation signal. Its envelope is proportional to the input angular velocity, and the carrier frequency corresponds to the spin frequency of the rotating aircraft, so the MEMS gyroscope can not only sense the transverse angular rotation of an aircraft, but also automatically change the carrier frequency over the change of spin frequency, making it very suitable for the damping of a single-channel control system of a rotating aircraft. In this paper, the motion equation of the MEMS gyroscope has been derived. Then, an analysis has been carried to solve the motion equation and dynamic parameters. Finally, an experimental validation has been done based on a precision three axis rate table. The correlation coefficients between the tested data and the theoretical values are 0.9969, 0.9872 and 0.9842, respectively. These results demonstrate that both the design and sensing mechanism are correct. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

14 pages, 2155 KiB

Open AccessArticle

Infrared Thermal Imaging System on a Mobile Phone

by Fu-Feng Lee, Feng Chen and Jing Liu

Sensors 2015, 15(5), 10166-10179; https://doi.org/10.3390/s150510166 - 30 Apr 2015

Cited by 17 | Viewed by 11040

Abstract

A novel concept towards pervasively available low-cost infrared thermal imaging system lunched on a mobile phone (MTIS) was proposed and demonstrated in this article. Through digestion on the evolutional development of milestone technologies in the area, it can be found that the portable [...] Read more.

A novel concept towards pervasively available low-cost infrared thermal imaging system lunched on a mobile phone (MTIS) was proposed and demonstrated in this article. Through digestion on the evolutional development of milestone technologies in the area, it can be found that the portable and low-cost design would become the main stream of thermal imager for civilian purposes. As a representative trial towards this important goal, a MTIS consisting of a thermal infrared module (TIM) and mobile phone with embedded exclusive software (IRAPP) was presented. The basic strategy for the TIM construction is illustrated, including sensor adoption and optical specification. The user-oriented software was developed in the Android environment by considering its popularity and expandability. Computational algorithms with non-uniformity correction and scene-change detection are established to optimize the imaging quality and efficiency of TIM. The performance experiments and analysis indicated that the currently available detective distance for the MTIS is about 29 m. Furthermore, some family-targeted utilization enabled by MTIS was also outlined, such as sudden infant death syndrome (SIDS) prevention, etc. This work suggests a ubiquitous way of significantly extending thermal infrared image into rather wide areas especially health care in the coming time. Full article

(This article belongs to the Special Issue Smartphone-Based Sensors for Non-Invasive Physiological Monitoring)

► Show Figures

Figure 1

14 pages, 286 KiB

Open AccessArticle

Metal Oxide Gas Sensor Drift Compensation Using a Two-Dimensional Classifier Ensemble

by Hang Liu, Renzhi Chu and Zhenan Tang

Sensors 2015, 15(5), 10180-10193; https://doi.org/10.3390/s150510180 - 30 Apr 2015

Cited by 34 | Viewed by 6745

Abstract

Sensor drift is the most challenging problem in gas sensing at present. We propose a novel two-dimensional classifier ensemble strategy to solve the gas discrimination problem, regardless of the gas concentration, with high accuracy over extended periods of time. This strategy is appropriate [...] Read more.

Sensor drift is the most challenging problem in gas sensing at present. We propose a novel two-dimensional classifier ensemble strategy to solve the gas discrimination problem, regardless of the gas concentration, with high accuracy over extended periods of time. This strategy is appropriate for multi-class classifiers that consist of combinations of pairwise classifiers, such as support vector machines. We compare the performance of the strategy with those of competing methods in an experiment based on a public dataset that was compiled over a period of three years. The experimental results demonstrate that the two-dimensional ensemble outperforms the other methods considered. Furthermore, we propose a pre-aging process inspired by that applied to the sensors to improve the stability of the classifier ensemble. The experimental results demonstrate that the weight of each multi-class classifier model in the ensemble remains fairly static before and after the addition of new classifier models to the ensemble, when a pre-aging procedure is applied. Full article

(This article belongs to the Special Issue Gas Sensors—Designs and Applications)

► Show Figures

27 pages, 5519 KiB

Open AccessArticle

Mobile Robot Positioning with 433-MHz Wireless Motes with Varying Transmission Powers and a Particle Filter

by Adrian Canedo-Rodriguez, Jose Manuel Rodriguez, Victor Alvarez-Santos, Roberto Iglesias and Carlos V. Regueiro

Sensors 2015, 15(5), 10194-10220; https://doi.org/10.3390/s150510194 - 30 Apr 2015

Cited by 6 | Viewed by 6848

Abstract

In wireless positioning systems, the transmitter’s power is usually fixed. In this paper, we explore the use of varying transmission powers to increase the performance of a wireless localization system. To this extent, we have designed a robot positioning system based on wireless [...] Read more.

In wireless positioning systems, the transmitter’s power is usually fixed. In this paper, we explore the use of varying transmission powers to increase the performance of a wireless localization system. To this extent, we have designed a robot positioning system based on wireless motes. Our motes use an inexpensive, low-power sub-1-GHz system-on-chip (CC1110) working in the 433-MHz ISM band. Our localization algorithm is based on a particle filter and infers the robot position by: (1) comparing the power received with the expected one; and (2) integrating the robot displacement. We demonstrate that the use of transmitters that vary their transmission power over time improves the performance of the wireless positioning system significantly, with respect to a system that uses fixed power transmitters. This opens the door for applications where the robot can localize itself actively by requesting the transmitters to change their power in real time. Full article

(This article belongs to the Special Issue Sensors for Indoor Mapping and Navigation)

► Show Figures

34 pages, 1929 KiB

Open AccessArticle

A Data Acquisition Protocol for a Reactive Wireless Sensor Network Monitoring Application

by Femi A. Aderohunmu, Davide Brunelli, Jeremiah D. Deng and Martin K. Purvis

Sensors 2015, 15(5), 10221-10254; https://doi.org/10.3390/s150510221 - 30 Apr 2015

Cited by 17 | Viewed by 6375

Abstract

Limiting energy consumption is one of the primary aims for most real-world deployments of wireless sensor networks. Unfortunately, attempts to optimize energy efficiency are often in conflict with the demand for network reactiveness to transmit urgent messages. In this article, we propose SWIFTNET: [...] Read more.

Limiting energy consumption is one of the primary aims for most real-world deployments of wireless sensor networks. Unfortunately, attempts to optimize energy efficiency are often in conflict with the demand for network reactiveness to transmit urgent messages. In this article, we propose SWIFTNET: a reactive data acquisition scheme. It is built on the synergies arising from a combination of the data reduction methods and energy-efficient data compression schemes. Particularly, it combines compressed sensing, data prediction and adaptive sampling strategies. We show how this approach dramatically reduces the amount of unnecessary data transmission in the deployment for environmental monitoring and surveillance networks. SWIFTNET targets any monitoring applications that require high reactiveness with aggressive data collection and transmission. To test the performance of this method, we present a real-world testbed for a wildfire monitoring as a use-case. The results from our in-house deployment testbed of 15 nodes have proven to be favorable. On average, over 50% communication reduction when compared with a default adaptive prediction method is achieved without any loss in accuracy. In addition, SWIFTNET is able to guarantee reactiveness by adjusting the sampling interval from 5 min up to 15 s in our application domain. Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

16 pages, 1268 KiB

Open AccessArticle

A New Surface Plasmon Resonance Immunosensor for Triazine Pesticide Determination in Bovine Milk: A Comparison with Conventional Amperometric and Screen-Printed Immunodevices

by Mauro Tomassetti, Elisabetta Martini, Luigi Campanella, Gabriele Favero, Gabriella Sanzó and Franco Mazzei

Sensors 2015, 15(5), 10255-10270; https://doi.org/10.3390/s150510255 - 30 Apr 2015

Cited by 20 | Viewed by 7205

Abstract

A detailed comparison was made of the analytical features of a new Surface Plasmon Resonance (SPR) immunodevice for triazine pesticide determination with those of two other amperometric (conventional and screen-printed) immunosensors and the advantages and disadvantages of the SPR method were thoroughly investigated. [...] Read more.

A detailed comparison was made of the analytical features of a new Surface Plasmon Resonance (SPR) immunodevice for triazine pesticide determination with those of two other amperometric (conventional and screen-printed) immunosensors and the advantages and disadvantages of the SPR method were thoroughly investigated. For conventional amperometric and screen-printed devices, “competitive” assays were used; conversely, the SPR transduction technique allowed a “direct” measurement format to be used. As far as the main analytical data are concerned, the SPR method does not seem to offer substantial advantages. Nevertheless the measurement time is much shorter and the measurement itself much easier to perform. Lastly several applications and recovery tests were carried out on bovine milk samples, before and after spiking, to check for triazine pesticides in the samples, obtaining satisfactory results. Full article

(This article belongs to the Special Issue Immunosensors 2014)

► Show Figures

Graphical abstract

17 pages, 14464 KiB

Open AccessArticle

Unified Camera Tamper Detection Based on Edge and Object Information

by Gil-beom Lee, Myeong-jin Lee and Jongtae Lim

Sensors 2015, 15(5), 10315-10331; https://doi.org/10.3390/s150510315 - 4 May 2015

Cited by 6 | Viewed by 6489

Abstract

In this paper, a novel camera tamper detection algorithm is proposed to detect three types of tamper attacks: covered, moved and defocused. The edge disappearance rate is defined in order to measure the amount of edge pixels that disappear in the current frame [...] Read more.

In this paper, a novel camera tamper detection algorithm is proposed to detect three types of tamper attacks: covered, moved and defocused. The edge disappearance rate is defined in order to measure the amount of edge pixels that disappear in the current frame from the background frame while excluding edges in the foreground. Tamper attacks are detected if the difference between the edge disappearance rate and its temporal average is larger than an adaptive threshold reflecting the environmental conditions of the cameras. The performance of the proposed algorithm is evaluated for short video sequences with three types of tamper attacks and for 24-h video sequences without tamper attacks; the algorithm is shown to achieve acceptable levels of detection and false alarm rates for all types of tamper attacks in real environments. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

18 pages, 1759 KiB

Open AccessArticle

Novel Real-Time Diagnosis of the Freezing Process Using an Ultrasonic Transducer

by Yen-Hsiang Tseng, Chin-Chi Cheng, Hong-Ping Cheng and Dasheng Lee

Sensors 2015, 15(5), 10332-10349; https://doi.org/10.3390/s150510332 - 4 May 2015

Cited by 4 | Viewed by 5951

Abstract

The freezing stage governs several critical parameters of the freeze drying process and the quality of the resulting lyophilized products. This paper presents an integrated ultrasonic transducer (UT) in a stainless steel bottle and its application to real-time diagnostics of the water freezing [...] Read more.

The freezing stage governs several critical parameters of the freeze drying process and the quality of the resulting lyophilized products. This paper presents an integrated ultrasonic transducer (UT) in a stainless steel bottle and its application to real-time diagnostics of the water freezing process. The sensor was directly deposited onto the stainless steel bottle using a sol-gel spray technique. It could operate at temperature range from −100 to 400 °C and uses an ultrasonic pulse-echo technique. The progression of the freezing process, including water-in, freezing point and final phase change of water, were all clearly observed using ultrasound. The ultrasonic signals could indicate the three stages of the freezing process and evaluate the cooling and freezing periods under various processing conditions. The temperature was also adopted for evaluating the cooling and freezing periods. These periods increased with water volume and decreased with shelf temperature (i.e., speed of freezing). This study demonstrates the effectiveness of the ultrasonic sensor and technology for diagnosing and optimizing the process of water freezing to save energy. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

30 pages, 4895 KiB

Open AccessArticle

WSN- and IOT-Based Smart Homes and Their Extension to Smart Buildings

by Hemant Ghayvat, Subhas Mukhopadhyay, Xiang Gui and Nagender Suryadevara

Sensors 2015, 15(5), 10350-10379; https://doi.org/10.3390/s150510350 - 4 May 2015

Cited by 319 | Viewed by 26168

Abstract

Our research approach is to design and develop reliable, efficient, flexible, economical, real-time and realistic wellness sensor networks for smart home systems. The heterogeneous sensor and actuator nodes based on wireless networking technologies are deployed into the home environment. These nodes generate real-time [...] Read more.

Our research approach is to design and develop reliable, efficient, flexible, economical, real-time and realistic wellness sensor networks for smart home systems. The heterogeneous sensor and actuator nodes based on wireless networking technologies are deployed into the home environment. These nodes generate real-time data related to the object usage and movement inside the home, to forecast the wellness of an individual. Here, wellness stands for how efficiently someone stays fit in the home environment and performs his or her daily routine in order to live a long and healthy life. We initiate the research with the development of the smart home approach and implement it in different home conditions (different houses) to monitor the activity of an inhabitant for wellness detection. Additionally, our research extends the smart home system to smart buildings and models the design issues related to the smart building environment; these design issues are linked with system performance and reliability. This research paper also discusses and illustrates the possible mitigation to handle the ISM band interference and attenuation losses without compromising optimum system performance. Full article

(This article belongs to the Special Issue Wireless Sensor Networks and the Internet of Things)

► Show Figures

Figure 1

23 pages, 280 KiB

Open AccessArticle

Analyzing SystemC Designs: SystemC Analysis Approaches for Varying Applications

by Jannis Stoppe and Rolf Drechsler

Sensors 2015, 15(5), 10399-10421; https://doi.org/10.3390/s150510399 - 4 May 2015

Cited by 10 | Viewed by 6524

Abstract

The complexity of hardware designs is still increasing according to Moore’s law. With embedded systems being more and more intertwined and working together not only with each other, but also with their environments as cyber physical systems (CPSs), more streamlined development workflows are [...] Read more.

The complexity of hardware designs is still increasing according to Moore’s law. With embedded systems being more and more intertwined and working together not only with each other, but also with their environments as cyber physical systems (CPSs), more streamlined development workflows are employed to handle the increasing complexity during a system’s design phase. SystemC is a C++ library for the design of hardware/software systems, enabling the designer to quickly prototype, e.g., a distributed CPS without having to decide about particular implementation details (such as whether to implement a feature in hardware or in software) early in the design process. Thereby, this approach reduces the initial implementation’s complexity by offering an abstract layer with which to build a working prototype. However, as SystemC is based on C++, analyzing designs becomes a difficult task due to the complex language features that are available to the designer. Several fundamentally different approaches for analyzing SystemC designs have been suggested. This work illustrates several different SystemC analysis approaches, including their specific advantages and shortcomings, allowing designers to pick the right tools to assist them with a specific problem during the design of a system using SystemC. Full article

(This article belongs to the Special Issue Cyber-Physical Systems)

► Show Figures

13 pages, 2227 KiB

Open AccessArticle

Dynamic Response of Tapered Optical Multimode Fiber Coated with Carbon Nanotubes for Ethanol Sensing Application

by Arafat Shabaneh, Saad Girei, Punitha Arasu, Mohd Mahdi, Suraya Rashid, Suriati Paiman and Mohd Yaacob

Sensors 2015, 15(5), 10452-10464; https://doi.org/10.3390/s150510452 - 4 May 2015

Cited by 38 | Viewed by 8144

Abstract

Ethanol is a highly combustible chemical universally designed for biomedical applications. In this paper, optical sensing performance of tapered multimode fiber tip coated with carbon nanotube (CNT) thin film towards aqueous ethanol with different concentrations is investigated. The tapered optical multimode fiber tip [...] Read more.

Ethanol is a highly combustible chemical universally designed for biomedical applications. In this paper, optical sensing performance of tapered multimode fiber tip coated with carbon nanotube (CNT) thin film towards aqueous ethanol with different concentrations is investigated. The tapered optical multimode fiber tip is coated with CNT using drop-casting technique and is annealed at 70 °C to enhance the binding of the nanomaterial to the silica fiber tip. The optical fiber tip and the CNT sensing layer are micro-characterized using FESEM and Raman spectroscopy techniques. When the developed sensor was exposed to different concentrations of ethanol (5% to 80%), the sensor reflectance reduced proportionally. The developed sensors showed high sensitivity, repeatability and fast responses (<55 s) towards ethanol. Full article

(This article belongs to the Special Issue Micro-Optical Sensors)

► Show Figures

Graphical abstract

16 pages, 2689 KiB

Open AccessArticle

Towards a Dynamic Clamp for Neurochemical Modalities

by Catalina Maria Rivera, Hyuck-Jin Kwon, Ali Hashmi, Gan Yu, Jiheng Zhao, Jianlong Gao, Jie Xu, Wei Xue and Alexander G. Dimitrov

Sensors 2015, 15(5), 10465-10480; https://doi.org/10.3390/s150510465 - 4 May 2015

Cited by 5 | Viewed by 6246

Abstract

The classic dynamic clamp technique uses a real-time electrical interface between living cells and neural simulations in order to investigate hypotheses about neural function and structure. One of the acknowledged drawbacks of that technique is the limited control of the cells’ chemical microenvironment. [...] Read more.

The classic dynamic clamp technique uses a real-time electrical interface between living cells and neural simulations in order to investigate hypotheses about neural function and structure. One of the acknowledged drawbacks of that technique is the limited control of the cells’ chemical microenvironment. In this manuscript, we use a novel combination of nanosensor and microfluidic technology and microfluidic and neural simulations to add sensing and control of chemical concentrations to the dynamic clamp technique. Specifically, we use a microfluidic lab-on-a-chip to generate distinct chemical concentration gradients (ions or neuromodulators), to register the concentrations with embedded nanosensors and use the processed signals as an input to simulations of a neural cell. The ultimate goal of this project is to close the loop and provide sensor signals to the microfluidic lab-on-a-chip to mimic the interaction of the simulated cell with other cells in its chemical environment. Full article

(This article belongs to the Special Issue On-Chip Sensors)

► Show Figures

15 pages, 1295 KiB

Open AccessArticle

Enhanced Sensitive Love Wave Surface Acoustic Wave Sensor Designed for Immunoassay Formats

by Mihaela Puiu, Ana-Maria Gurban, Lucian Rotariu, Simona Brajnicov, Cristian Viespe and Camelia Bala

Sensors 2015, 15(5), 10511-10525; https://doi.org/10.3390/s150510511 - 5 May 2015

Cited by 34 | Viewed by 7823

Abstract

We report a Love wave surface acoustic wave (LW-SAW) immunosensor designed for the detection of high molecular weight targets in liquid samples, amenable also for low molecular targets in surface competition assays. We implemented a label-free interaction protocol similar to other surface plasmon [...] Read more.

We report a Love wave surface acoustic wave (LW-SAW) immunosensor designed for the detection of high molecular weight targets in liquid samples, amenable also for low molecular targets in surface competition assays. We implemented a label-free interaction protocol similar to other surface plasmon resonance bioassays having the advantage of requiring reduced time analysis. The fabricated LW-SAW sensor supports the detection of the target in the nanomolar range, and can be ultimately incorporated in portable devices, suitable for point-of-care testing (POCT) applications. Full article

(This article belongs to the Special Issue Acoustic Waveguide Sensors)

► Show Figures

Graphical abstract

21 pages, 294 KiB

Open AccessArticle

A Novel Square-Root Cubature Information Weighted Consensus Filter Algorithm for Multi-Target Tracking in Distributed Camera Networks

by Yanming Chen and Qingjie Zhao

Sensors 2015, 15(5), 10526-10546; https://doi.org/10.3390/s150510526 - 5 May 2015

Cited by 18 | Viewed by 5586

Abstract

This paper deals with the problem of multi-target tracking in a distributed camera network using the square-root cubature information filter (SCIF). SCIF is an efficient and robust nonlinear filter for multi-sensor data fusion. In camera networks, multiple cameras are arranged in a dispersed [...] Read more.

This paper deals with the problem of multi-target tracking in a distributed camera network using the square-root cubature information filter (SCIF). SCIF is an efficient and robust nonlinear filter for multi-sensor data fusion. In camera networks, multiple cameras are arranged in a dispersed manner to cover a large area, and the target may appear in the blind area due to the limited field of view (FOV). Besides, each camera might receive noisy measurements. To overcome these problems, this paper proposes a novel multi-target square-root cubature information weighted consensus filter (MTSCF), which reduces the effect of clutter or spurious measurements using joint probabilistic data association (JPDA) and proper weights on the information matrix and information vector. The simulation results show that the proposed algorithm can efficiently track multiple targets in camera networks and is obviously better in terms of accuracy and stability than conventional multi-target tracking algorithms. Full article

(This article belongs to the Special Issue Visual Sensor Networks)

► Show Figures

22 pages, 513 KiB

Open AccessArticle

A Novel Artificial Fish Swarm Algorithm for Recalibration of Fiber Optic Gyroscope Error Parameters

by Yanbin Gao, Lianwu Guan, Tingjun Wang and Yunlong Sun

Sensors 2015, 15(5), 10547-10568; https://doi.org/10.3390/s150510547 - 5 May 2015

Cited by 15 | Viewed by 6149

Abstract

The artificial fish swarm algorithm (AFSA) is one of the state-of-the-art swarm intelligent techniques, which is widely utilized for optimization purposes. Fiber optic gyroscope (FOG) error parameters such as scale factors, biases and misalignment errors are relatively unstable, especially with the environmental disturbances [...] Read more.

The artificial fish swarm algorithm (AFSA) is one of the state-of-the-art swarm intelligent techniques, which is widely utilized for optimization purposes. Fiber optic gyroscope (FOG) error parameters such as scale factors, biases and misalignment errors are relatively unstable, especially with the environmental disturbances and the aging of fiber coils. These uncalibrated error parameters are the main reasons that the precision of FOG-based strapdown inertial navigation system (SINS) degraded. This research is mainly on the application of a novel artificial fish swarm algorithm (NAFSA) on FOG error coefficients recalibration/identification. First, the NAFSA avoided the demerits (e.g., lack of using artificial fishes’ pervious experiences, lack of existing balance between exploration and exploitation, and high computational cost) of the standard AFSA during the optimization process. To solve these weak points, functional behaviors and the overall procedures of AFSA have been improved with some parameters eliminated and several supplementary parameters added. Second, a hybrid FOG error coefficients recalibration algorithm has been proposed based on NAFSA and Monte Carlo simulation (MCS) approaches. This combination leads to maximum utilization of the involved approaches for FOG error coefficients recalibration. After that, the NAFSA is verified with simulation and experiments and its priorities are compared with that of the conventional calibration method and optimal AFSA. Results demonstrate high efficiency of the NAFSA on FOG error coefficients recalibration. Full article

(This article belongs to the Special Issue Inertial Sensors and Systems)

► Show Figures

Figure 1

11 pages, 2450 KiB

Open AccessArticle

Sensor Node for Remote Monitoring of Waterborne Disease-Causing Bacteria

by Kyukwang Kim and Hyun Myung

Sensors 2015, 15(5), 10569-10579; https://doi.org/10.3390/s150510569 - 5 May 2015

Cited by 29 | Viewed by 10875

Abstract

A sensor node for sampling water and checking for the presence of harmful bacteria such as E. coli in water sources was developed in this research. A chromogenic enzyme substrate assay method was used to easily detect coliform bacteria by monitoring the color [...] Read more.

A sensor node for sampling water and checking for the presence of harmful bacteria such as E. coli in water sources was developed in this research. A chromogenic enzyme substrate assay method was used to easily detect coliform bacteria by monitoring the color change of the sampled water mixed with a reagent. Live webcam image streaming to the web browser of the end user with a Wi-Fi connected sensor node shows the water color changes in real time. The liquid can be manipulated on the web-based user interface, and also can be observed by webcam feeds. Image streaming and web console servers run on an embedded processor with an expansion board. The UART channel of the expansion board is connected to an external Arduino board and a motor driver to control self-priming water pumps to sample the water, mix the reagent, and remove the water sample after the test is completed. The sensor node can repeat water testing until the test reagent is depleted. The authors anticipate that the use of the sensor node developed in this research can decrease the cost and required labor for testing samples in a factory environment and checking the water quality of local water sources in developing countries. Full article

(This article belongs to the Special Issue Biosensors for Pathogen Detection)

► Show Figures

Figure 1

36 pages, 2047 KiB

Open AccessArticle

Robust Pedestrian Detection by Combining Visible and Thermal Infrared Cameras

by Ji Hoon Lee, Jong-Suk Choi, Eun Som Jeon, Yeong Gon Kim, Toan Thanh Le, Kwang Yong Shin, Hyeon Chang Lee and Kang Ryoung Park

Sensors 2015, 15(5), 10580-10615; https://doi.org/10.3390/s150510580 - 5 May 2015

Cited by 43 | Viewed by 9143

Abstract

With the development of intelligent surveillance systems, the need for accurate detection of pedestrians by cameras has increased. However, most of the previous studies use a single camera system, either a visible light or thermal camera, and their performances are affected by various [...] Read more.

With the development of intelligent surveillance systems, the need for accurate detection of pedestrians by cameras has increased. However, most of the previous studies use a single camera system, either a visible light or thermal camera, and their performances are affected by various factors such as shadow, illumination change, occlusion, and higher background temperatures. To overcome these problems, we propose a new method of detecting pedestrians using a dual camera system that combines visible light and thermal cameras, which are robust in various outdoor environments such as mornings, afternoons, night and rainy days. Our research is novel, compared to previous works, in the following four ways: First, we implement the dual camera system where the axes of visible light and thermal cameras are parallel in the horizontal direction. We obtain a geometric transform matrix that represents the relationship between these two camera axes. Second, two background images for visible light and thermal cameras are adaptively updated based on the pixel difference between an input thermal and pre-stored thermal background images. Third, by background subtraction of thermal image considering the temperature characteristics of background and size filtering with morphological operation, the candidates from whole image (CWI) in the thermal image is obtained. The positions of CWI (obtained by background subtraction and the procedures of shadow removal, morphological operation, size filtering, and filtering of the ratio of height to width) in the visible light image are projected on those in the thermal image by using the geometric transform matrix, and the searching regions for pedestrians are defined in the thermal image. Fourth, within these searching regions, the candidates from the searching image region (CSI) of pedestrians in the thermal image are detected. The final areas of pedestrians are located by combining the detected positions of the CWI and CSI of the thermal image based on OR operation. Experimental results showed that the average precision and recall of detecting pedestrians are 98.13% and 88.98%, respectively. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

15 pages, 2242 KiB

Open AccessArticle

Tracking Diurnal Variation in Photosynthetic Down-Regulation Using Low Cost Spectroscopic Instrumentation

by Martin Van Leeuwen, Robert L. Kremens and Jan Van Aardt

Sensors 2015, 15(5), 10616-10630; https://doi.org/10.3390/s150510616 - 5 May 2015

Cited by 7 | Viewed by 5027

Abstract

Photosynthetic light-use efficiency (LUE) has gained wide interest as an input to modeling forest gross primary productivity (GPP). The photochemical reflectance index (PRI) has been identified as a principle means to inform LUE-based models, using airborne and satellite-based observations of canopy reflectance. More [...] Read more.

Photosynthetic light-use efficiency (LUE) has gained wide interest as an input to modeling forest gross primary productivity (GPP). The photochemical reflectance index (PRI) has been identified as a principle means to inform LUE-based models, using airborne and satellite-based observations of canopy reflectance. More recently, low-cost electronics have become available with the potential to provide for dense in situ time-series measurements of PRI. A recent design makes use of interference filters to record light transmission within narrow wavebands. Uncertainty remains as to the dynamic range of these sensors and performance under low light conditions, the placement of the reference band, and methodology for reflectance calibration. This paper presents a low-cost sensor design and is tested in a laboratory set-up, as well in the field. The results demonstrate an excellent performance against a calibration standard (R² = 0.9999) and at low light conditions. Radiance measurements over vegetation demonstrate a reversible reduction in green reflectance that was, however, seen in both the reference and signal wavebands. Time-series field measurements of PRI in a Douglas-fir canopy showed a weak correlation with eddy-covariance-derived LUE and a significant decline in PRI over the season. Effects of light quality, bidirectional scattering effects, and possible sensor artifacts on PRI are discussed. Full article

(This article belongs to the Section Remote Sensors)

► Show Figures

Figure 1

19 pages, 1038 KiB

Open AccessArticle

Collaborative Localization and Location Verification in WSNs

by Chunyu Miao, Guoyong Dai, Kezhen Ying and Qingzhang Chen

Sensors 2015, 15(5), 10631-10649; https://doi.org/10.3390/s150510631 - 6 May 2015

Cited by 24 | Viewed by 5630

Abstract

Localization is one of the most important technologies in wireless sensor networks. A lightweight distributed node localization scheme is proposed by considering the limited computational capacity of WSNs. The proposed scheme introduces the virtual force model to determine the location by incremental refinement. [...] Read more.

Localization is one of the most important technologies in wireless sensor networks. A lightweight distributed node localization scheme is proposed by considering the limited computational capacity of WSNs. The proposed scheme introduces the virtual force model to determine the location by incremental refinement. Aiming at solving the drifting problem and malicious anchor problem, a location verification algorithm based on the virtual force mode is presented. In addition, an anchor promotion algorithm using the localization reliability model is proposed to re-locate the drifted nodes. Extended simulation experiments indicate that the localization algorithm has relatively high precision and the location verification algorithm has relatively high accuracy. The communication overhead of these algorithms is relative low, and the whole set of reliable localization methods is practical as well as comprehensive. Full article

(This article belongs to the Special Issue Cyber-Physical Systems)

► Show Figures

Figure 1

26 pages, 1606 KiB

Open AccessArticle

Intelligent Simultaneous Quantitative Online Analysis of Environmental Trace Heavy Metals with Total-Reflection X-Ray Fluorescence

by Junjie Ma, Yeyao Wang, Qi Yang, Yubing Liu and Ping Shi

Sensors 2015, 15(5), 10650-10675; https://doi.org/10.3390/s150510650 - 6 May 2015

Cited by 8 | Viewed by 5169

Abstract

Total-reflection X-ray fluorescence (TXRF) has achieved remarkable success with the advantages of simultaneous multi-element analysis capability, decreased background noise, no matrix effects, wide dynamic range, ease of operation, and potential of trace analysis. Simultaneous quantitative online analysis of trace heavy metals is urgently [...] Read more.

Total-reflection X-ray fluorescence (TXRF) has achieved remarkable success with the advantages of simultaneous multi-element analysis capability, decreased background noise, no matrix effects, wide dynamic range, ease of operation, and potential of trace analysis. Simultaneous quantitative online analysis of trace heavy metals is urgently required by dynamic environmental monitoring and management, and TXRF has potential in this application domain. However, it calls for an online analysis scheme based on TXRF as well as a robust and rapid quantification method, which have not been well explored yet. Besides, spectral overlapping and background effects may lead to loss of accuracy or even faulty results during practical quantitative TXRF analysis. This paper proposes an intelligent, multi-element quantification method according to the established online TXRF analysis platform. In the intelligent quantification method, collected characteristic curves of all existing elements and a pre-estimated background curve in the whole spectrum scope are used to approximate the measured spectrum. A novel hybrid algorithm, PSO-RBFN-SA, is designed to solve the curve-fitting problem, with offline global optimization and fast online computing. Experimental results verify that simultaneous quantification of trace heavy metals, including Cr, Mn, Fe, Co, Ni, Cu and Zn, is realized on the online TXRF analysis platform, and both high measurement precision and computational efficiency are obtained. Full article

(This article belongs to the Section Chemical Sensors)

► Show Figures

Figure 1

10 pages, 1271 KiB

Open AccessArticle

Classifying Step and Spin Turns Using Wireless Gyroscopes and Implications for Fall Risk Assessments

by Peter C. Fino, Christopher W. Frames and Thurmon E. Lockhart

Sensors 2015, 15(5), 10676-10685; https://doi.org/10.3390/s150510676 - 6 May 2015

Cited by 26 | Viewed by 6039

Abstract

Recent studies have reported a greater prevalence of spin turns, which are more unstable than step turns, in older adults compared to young adults in laboratory settings. Currently, turning strategies can only be identified through visual observation, either in-person or through video. This [...] Read more.

Recent studies have reported a greater prevalence of spin turns, which are more unstable than step turns, in older adults compared to young adults in laboratory settings. Currently, turning strategies can only be identified through visual observation, either in-person or through video. This paper presents two unique methods and their combination to remotely monitor turning behavior using three uniaxial gyroscopes. Five young adults performed 90° turns at slow, normal, and fast walking speeds around a variety of obstacles while instrumented with three IMUs (attached on the trunk, left and right shank). Raw data from 360 trials were analyzed. Compared to visual classification, the two IMU methods’ sensitivity/specificity to detecting spin turns were 76.1%/76.7% and 76.1%/84.4%, respectively. When the two methods were combined, the IMU had an overall 86.8% sensitivity and 92.2% specificity, with 89.4%/100% sensitivity/specificity at slow speeds. This combined method can be implemented into wireless fall prevention systems and used to identify increased use of spin turns. This method allows for longitudinal monitoring of turning strategies and allows researchers to test for potential associations between the frequency of spin turns and clinically relevant outcomes (e.g., falls) in non-laboratory settings. Full article

(This article belongs to the Special Issue Inertial Sensors and Systems)

► Show Figures

Figure 1

19 pages, 460 KiB

Open AccessArticle

A Label-Free Impedimetric DNA Sensor Based on a Nanoporous SnO₂ Film: Fabrication and Detection Performance

by Minh Hai Le, Carmen Jimenez, Eric Chainet and Valerie Stambouli

Sensors 2015, 15(5), 10686-10704; https://doi.org/10.3390/s150510686 - 6 May 2015

Cited by 26 | Viewed by 7506

Abstract

Nanoporous SnO₂ thin films were elaborated to serve as sensing electrodes for label-free DNA detection using electrochemical impedance spectroscopy (EIS). Films were deposited by an electrodeposition process (EDP). Then the non-Faradic EIS behaviour was thoroughly investigated during some different steps of functionalization [...] Read more.

Nanoporous SnO₂ thin films were elaborated to serve as sensing electrodes for label-free DNA detection using electrochemical impedance spectroscopy (EIS). Films were deposited by an electrodeposition process (EDP). Then the non-Faradic EIS behaviour was thoroughly investigated during some different steps of functionalization up to DNA hybridization. The results have shown a systematic decrease of the impedance upon DNA hybridization. The impedance decrease is attributed to an enhanced penetration of ionic species within the film volume. Besides, the comparison of impedance variations upon DNA hybridization between the liquid and vapour phase processes for organosilane (APTES) grafting on the nanoporous SnO₂ films showed that vapour-phase method is more efficient. This is due to the fact that the vapour is more effective than the solution in penetrating the nanopores of the films. As a result, the DNA sensors built from vapour-treated silane layer exhibit a higher sensitivity than those produced from liquid-treated silane, in the range of tested target DNA concentration going to 10 nM. Finally, the impedance and fluorescence response signals strongly depend on the types of target DNA molecules, demonstrating a high selectivity of the process on nanoporous SnO₂ films. Full article

(This article belongs to the Special Issue Label-Free Sensing)

► Show Figures

Graphical abstract

18 pages, 2445 KiB

Open AccessArticle

Development of an Ultrasonic Airflow Measurement Device for Ducted Air

by Andrew B. Raine, Nauman Aslam, Christopher P. Underwood and Sean Danaher

Sensors 2015, 15(5), 10705-10722; https://doi.org/10.3390/s150510705 - 6 May 2015

Cited by 45 | Viewed by 16068

Abstract

In this study, an in-duct ultrasonic airflow measurement device has been designed, developed and tested. The airflow measurement results for a small range of airflow velocities and temperatures show that the accuracy was better than 3.5% root mean square (RMS) when it was [...] Read more.

In this study, an in-duct ultrasonic airflow measurement device has been designed, developed and tested. The airflow measurement results for a small range of airflow velocities and temperatures show that the accuracy was better than 3.5% root mean square (RMS) when it was tested within a round or square duct compared to the in-line Venturi tube airflow meter used for reference. This proof of concept device has provided evidence that with further development it could be a low-cost alternative to pressure differential devices such as the orifice plate airflow meter for monitoring energy efficiency performance and reliability of ventilation systems. The design uses a number of techniques and design choices to provide solutions to lower the implementation cost of the device compared to traditional airflow meters. The design choices that were found to work well are the single sided transducer arrangement for a “V” shaped reflective path and the use of square wave transmitter pulses ending with the necessary 180° phase changed pulse train to suppress transducer ringing. The device is also designed so that it does not have to rely on high-speed analogue to digital converters (ADC) and intensive digital signal processing, so could be implemented using voltage comparators and low-cost microcontrollers. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

11 pages, 885 KiB

Open AccessArticle

Enantioselective Recognition of Chiral Carboxylic Acids by a β-Amino Acid and 1,10-Phenanthroline Based Chiral Fluorescent Sensor

by Yonghong Zhang, Fangzhi Hu, Bin Wang, Xiaomei Zhang and Chenjiang Liu

Sensors 2015, 15(5), 10723-10733; https://doi.org/10.3390/s150510723 - 6 May 2015

Cited by 11 | Viewed by 7330

Abstract

A novel chiral 1,10-phenanthroline-based fluorescent sensor was designed and synthesized from optical active β-amino acids. It used 1,10-phenanthroline moiety as a fluorescent signaling site and binding site, with optically active β-amino acids as a chiral barrier site. Notably, the optically active β-amino acids [...] Read more.

A novel chiral 1,10-phenanthroline-based fluorescent sensor was designed and synthesized from optical active β-amino acids. It used 1,10-phenanthroline moiety as a fluorescent signaling site and binding site, with optically active β-amino acids as a chiral barrier site. Notably, the optically active β-amino acids were obtained by a Lewis base catalyzed hydrosilylation of β-enamino esters according to our former work. The chiral sensor has been used to conduct the enantioselective recognition of chiral mono and dicarboxylic acids derivatives. Using this fluorescent sensor, a moderate “turn-off” fluorescence-diminishment response towards enantiomer of tartaric acids, and proline was observed. It found that l-enantiomers quench the chiral fluorescence sensor more efficiently than d-enantiomers due to the absolute configuration of the β-amino acid. Full article

(This article belongs to the Section Chemical Sensors)

► Show Figures

Graphical abstract

19 pages, 1019 KiB

Open AccessArticle

Accuracy of a Custom Physical Activity and Knee Angle Measurement Sensor System for Patients with Neuromuscular Disorders and Gait Abnormalities

by Frank Feldhege, Anett Mau-Moeller, Tobias Lindner, Albert Hein, Andreas Markschies, Uwe Klaus Zettl and Rainer Bader

Sensors 2015, 15(5), 10734-10752; https://doi.org/10.3390/s150510734 - 6 May 2015

Cited by 31 | Viewed by 9347

Abstract

Long-term assessment of ambulatory behavior and joint motion are valuable tools for the evaluation of therapy effectiveness in patients with neuromuscular disorders and gait abnormalities. Even though there are several tools available to quantify ambulatory behavior in a home environment, reliable measurement of [...] Read more.

Long-term assessment of ambulatory behavior and joint motion are valuable tools for the evaluation of therapy effectiveness in patients with neuromuscular disorders and gait abnormalities. Even though there are several tools available to quantify ambulatory behavior in a home environment, reliable measurement of joint motion is still limited to laboratory tests. The aim of this study was to develop and evaluate a novel inertial sensor system for ambulatory behavior and joint motion measurement in the everyday environment. An algorithm for behavior classification, step detection, and knee angle calculation was developed. The validation protocol consisted of simulated daily activities in a laboratory environment. The tests were performed with ten healthy subjects and eleven patients with multiple sclerosis. Activity classification showed comparable performance to commercially available activPAL sensors. Step detection with our sensor system was more accurate. The calculated flexion-extension angle of the knee joint showed a root mean square error of less than 5° compared with results obtained using an electro-mechanical goniometer. This new system combines ambulatory behavior assessment and knee angle measurement for long-term measurement periods in a home environment. The wearable sensor system demonstrated high validity for behavior classification and knee joint angle measurement in a laboratory setting. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

18 pages, 2544 KiB

Open AccessArticle

Carbon Fiber Epoxy Composites for Both Strengthening and Health Monitoring of Structures

by Rita Salvado, Catarina Lopes, Leszek Szojda, Pedro Araújo, Marcin Gorski, Fernando José Velez, João Castro-Gomes and Rafal Krzywon

Sensors 2015, 15(5), 10753-10770; https://doi.org/10.3390/s150510753 - 6 May 2015

Cited by 47 | Viewed by 7806

Abstract

This paper presents a study of the electrical and mechanical behavior of several continuous carbon fibers epoxy composites for both strengthening and monitoring of structures. In these composites, the arrangement of fibers was deliberately diversified to test and understand the ability of the [...] Read more.

This paper presents a study of the electrical and mechanical behavior of several continuous carbon fibers epoxy composites for both strengthening and monitoring of structures. In these composites, the arrangement of fibers was deliberately diversified to test and understand the ability of the composites for self-sensing low strains. Composites with different arrangements of fibers and textile weaves, mainly unidirectional continuous carbon reinforced composites, were tested at the dynamometer. A two-probe method was considered to measure the relative electrical resistance of these composites during loading. The measured relative electrical resistance includes volume and contact electrical resistances. For all tested specimens, it increases with an increase in tensile strain, at low strain values. This is explained by the improved alignment of fibers and resulting reduction of the number of possible contacts between fibers during loading, increasing as a consequence the contact electrical resistance of the composite. Laboratory tests on strengthening of structural elements were also performed, making hand-made composites by the “wet process”, which is commonly used in civil engineering for the strengthening of all types of structures in-situ. Results show that the woven epoxy composite, used for strengthening of concrete elements is also able to sense low deformations, below 1%. Moreover, results clearly show that this textile sensor also improves the mechanical work of the strengthened structural elements, increasing their bearing capacity. Finally, the set of obtained results supports the concept of a textile fabric capable of both structural upgrade and self-monitoring of structures, especially large structures of difficult access and needing constant, sometimes very expensive, health monitoring. Full article

(This article belongs to the Special Issue Selected Papers from the 1st International Electronic Conference on Sensors and Applications)

► Show Figures

Figure 1

20 pages, 6208 KiB

Open AccessArticle

Multiple Leader Candidate and Competitive Position Allocation for Robust Formation against Member Robot Faults

by Ji-Wook Kwon, Jin Hyo Kim and Jiwon Seo

Sensors 2015, 15(5), 10771-10790; https://doi.org/10.3390/s150510771 - 6 May 2015

Cited by 12 | Viewed by 5846

Abstract

This paper proposes a Multiple Leader Candidate (MLC) structure and a Competitive Position Allocation (CPA) algorithm which can be applicable for various applications including environmental sensing. Unlike previous formation structures such as virtual-leader and actual-leader structures with position allocation including a rigid allocation [...] Read more.

This paper proposes a Multiple Leader Candidate (MLC) structure and a Competitive Position Allocation (CPA) algorithm which can be applicable for various applications including environmental sensing. Unlike previous formation structures such as virtual-leader and actual-leader structures with position allocation including a rigid allocation and an optimization based allocation, the formation employing the proposed MLC structure and CPA algorithm is robust against the fault (or disappearance) of the member robots and reduces the entire cost. In the MLC structure, a leader of the entire system is chosen among leader candidate robots. The CPA algorithm is the decentralized position allocation algorithm that assigns the robots to the vertex of the formation via the competition of the adjacent robots. The numerical simulations and experimental results are included to show the feasibility and the performance of the multiple robot system employing the proposed MLC structure and the CPA algorithm. Full article

(This article belongs to the Special Issue Sensors for Robots)

► Show Figures

Figure 1

15 pages, 2638 KiB

Open AccessArticle

Toward Realization of 2.4 GHz Balunless Narrowband Receiver Front-End for Short Range Wireless Applications

by Munir M. El-Desouki, Syed Manzoor Qasim, Mohammed S. BenSaleh and M. Jamal Deen

Sensors 2015, 15(5), 10791-10805; https://doi.org/10.3390/s150510791 - 7 May 2015

Cited by 12 | Viewed by 6456

Abstract

The demand for radio frequency (RF) transceivers operating at 2.4 GHz band has attracted considerable research interest due to the advancement in short range wireless technologies. The performance of RF transceivers depends heavily on the transmitter and receiver front-ends. The receiver front-end is [...] Read more.

The demand for radio frequency (RF) transceivers operating at 2.4 GHz band has attracted considerable research interest due to the advancement in short range wireless technologies. The performance of RF transceivers depends heavily on the transmitter and receiver front-ends. The receiver front-end is comprised of a low-noise amplifier (LNA) and a downconversion mixer. There are very few designs that focus on connecting the single-ended output LNA to a double-balanced mixer without the use of on-chip transformer, also known as a balun. The objective of designing such a receiver front-end is to achieve high integration and low power consumption. To meet these requirements, we present the design of fully-integrated 2.4 GHz receiver front-end, consisting of a narrow-band LNA and a double balanced mixer without using a balun. Here, the single-ended RF output signal of the LNA is translated into differential signal using an NMOS-PMOS (n-channel metal-oxide-semiconductor, p-channel metal-oxide-semiconductor) transistor differential pair instead of the conventional NMOS-NMOS transistor configuration, for the RF amplification stage of the double-balanced mixer. The proposed receiver circuit fabricated using TSMC 0.18 µm CMOS technology operates at 2.4 GHz and produces an output signal at 300 MHz. The fabricated receiver achieves a gain of 16.3 dB and consumes only 6.74 mW operating at 1.5 V, while utilizing 2.08 mm² of chip area. Measurement results demonstrate the effectiveness and suitability of the proposed receiver for short-range wireless applications, such as in wireless sensor network (WSN). Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

Figure 1

19 pages, 4438 KiB

Open AccessArticle

POIS, a Low Cost Tilt and Position Sensor: Design and First Tests

by Giuseppe Artese, Michele Perrelli, Serena Artese, Sebastiano Meduri and Natale Brogno

Sensors 2015, 15(5), 10806-10824; https://doi.org/10.3390/s150510806 - 7 May 2015

Cited by 21 | Viewed by 7439

Abstract

An integrated sensor for the measurement and monitoring of position and inclination, characterized by low cost, small size and low weight, has been designed, realized and calibrated at the Geomatics Lab of the University of Calabria. The design of the prototype, devoted to [...] Read more.

An integrated sensor for the measurement and monitoring of position and inclination, characterized by low cost, small size and low weight, has been designed, realized and calibrated at the Geomatics Lab of the University of Calabria. The design of the prototype, devoted to the monitoring of landslides and structures, was aiming at realizing a fully automated monitoring instrument, able to send the data acquired periodically or upon request by a control center through a bidirectional transmission protocol. The sensor can be released with different accuracy and range of measurement, by choosing bubble vials with different characteristics. The instrument is provided with a computer, which can be programmed so as to independently perform the processing of the data collected by a single sensor or a by a sensor network, and to transmit, consequently, alert signals if the thresholds determined by the monitoring center are exceeded. The bidirectional transmission also allows the users to vary the set of the monitoring parameters (time of acquisition, duration of satellite acquisitions, thresholds for the observed data). In the paper, hardware and software of the sensor are described, along with the calibration, the results of laboratory tests and of the first in field acquisitions. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

27 pages, 3322 KiB

Open AccessArticle

A Fuzzy-Based Fusion Method of Multimodal Sensor-Based Measurements for the Quantitative Evaluation of Eye Fatigue on 3D Displays

by Jae Won Bang, Jong-Suk Choi, Hwan Heo and Kang Ryoung Park

Sensors 2015, 15(5), 10825-10851; https://doi.org/10.3390/s150510825 - 7 May 2015

Cited by 6 | Viewed by 6067

Abstract

With the rapid increase of 3-dimensional (3D) content, considerable research related to the 3D human factor has been undertaken for quantitatively evaluating visual discomfort, including eye fatigue and dizziness, caused by viewing 3D content. Various modalities such as electroencephalograms (EEGs), biomedical signals, and [...] Read more.

With the rapid increase of 3-dimensional (3D) content, considerable research related to the 3D human factor has been undertaken for quantitatively evaluating visual discomfort, including eye fatigue and dizziness, caused by viewing 3D content. Various modalities such as electroencephalograms (EEGs), biomedical signals, and eye responses have been investigated. However, the majority of the previous research has analyzed each modality separately to measure user eye fatigue. This cannot guarantee the credibility of the resulting eye fatigue evaluations. Therefore, we propose a new method for quantitatively evaluating eye fatigue related to 3D content by combining multimodal measurements. This research is novel for the following four reasons: first, for the evaluation of eye fatigue with high credibility on 3D displays, a fuzzy-based fusion method (FBFM) is proposed based on the multimodalities of EEG signals, eye blinking rate (BR), facial temperature (FT), and subjective evaluation (SE); second, to measure a more accurate variation of eye fatigue (before and after watching a 3D display), we obtain the quality scores of EEG signals, eye BR, FT and SE; third, for combining the values of the four modalities we obtain the optimal weights of the EEG signals BR, FT and SE using a fuzzy system based on quality scores; fourth, the quantitative level of the variation of eye fatigue is finally obtained using the weighted sum of the values measured by the four modalities. Experimental results confirm that the effectiveness of the proposed FBFM is greater than other conventional multimodal measurements. Moreover, the credibility of the variations of the eye fatigue using the FBFM before and after watching the 3D display is proven using a t-test and descriptive statistical analysis using effect size. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

20 pages, 3123 KiB

Open AccessArticle

A Micro-Computed Tomography Technique to Study the Quality of Fibre Optics Embedded in Composite Materials

by Gabriele Chiesura, Geert Luyckx, Eli Voet, Nicolas Lammens, Wim Van Paepegem, Joris Degrieck, Manuel Dierick, Luc Van Hoorebeke, Pieter Vanderniepen, Sanne Sulejmani, Camille Sonnenfeld, Thomas Geernaert and Francis Berghmans

Sensors 2015, 15(5), 10852-10871; https://doi.org/10.3390/s150510852 - 7 May 2015

Cited by 15 | Viewed by 7416

Abstract

Quality of embedment of optical fibre sensors in carbon fibre-reinforced polymers plays an important role in the resultant properties of the composite, as well as for the correct monitoring of the structure. Therefore, availability of a tool able to check the optical fibre [...] Read more.

Quality of embedment of optical fibre sensors in carbon fibre-reinforced polymers plays an important role in the resultant properties of the composite, as well as for the correct monitoring of the structure. Therefore, availability of a tool able to check the optical fibre sensor-composite interaction becomes essential. High-resolution 3D X-ray Micro-Computed Tomography, or Micro-CT, is a relatively new non-destructive inspection technique which enables investigations of the internal structure of a sample without actually compromising its integrity. In this work the feasibility of inspecting the position, the orientation and, more generally, the quality of the embedment of an optical fibre sensor in a carbon fibre reinforced laminate at unit cell level have been proven. Full article

(This article belongs to the Special Issue Optical Fiber Sensors 2012)

► Show Figures

Figure 1

19 pages, 7747 KiB

Open AccessArticle

Quaternion-Based Unscented Kalman Filter for Accurate Indoor Heading Estimation Using Wearable Multi-Sensor System

by Xuebing Yuan, Shuai Yu, Shengzhi Zhang, Guoping Wang and Sheng Liu

Sensors 2015, 15(5), 10872-10890; https://doi.org/10.3390/s150510872 - 7 May 2015

Cited by 100 | Viewed by 12411

Abstract

Inertial navigation based on micro-electromechanical system (MEMS) inertial measurement units (IMUs) has attracted numerous researchers due to its high reliability and independence. The heading estimation, as one of the most important parts of inertial navigation, has been a research focus in this field. [...] Read more.

Inertial navigation based on micro-electromechanical system (MEMS) inertial measurement units (IMUs) has attracted numerous researchers due to its high reliability and independence. The heading estimation, as one of the most important parts of inertial navigation, has been a research focus in this field. Heading estimation using magnetometers is perturbed by magnetic disturbances, such as indoor concrete structures and electronic equipment. The MEMS gyroscope is also used for heading estimation. However, the accuracy of gyroscope is unreliable with time. In this paper, a wearable multi-sensor system has been designed to obtain the high-accuracy indoor heading estimation, according to a quaternion-based unscented Kalman filter (UKF) algorithm. The proposed multi-sensor system including one three-axis accelerometer, three single-axis gyroscopes, one three-axis magnetometer and one microprocessor minimizes the size and cost. The wearable multi-sensor system was fixed on waist of pedestrian and the quadrotor unmanned aerial vehicle (UAV) for heading estimation experiments in our college building. The results show that the mean heading estimation errors are less 10° and 5° to multi-sensor system fixed on waist of pedestrian and the quadrotor UAV, respectively, compared to the reference path. Full article

(This article belongs to the Special Issue Sensors for Indoor Mapping and Navigation)

► Show Figures

Figure 1

18 pages, 1003 KiB

Open AccessArticle

Resource-Efficient Fusion with Pre-Compensated Transmissions for Cooperative Spectrum Sensing

by Dayan Adionel Guimarães, Guilherme Pedro Aquino and Marco E. G. V. Cattaneo

Sensors 2015, 15(5), 10891-10908; https://doi.org/10.3390/s150510891 - 8 May 2015

Cited by 4 | Viewed by 5146

Abstract

Recently, a novel fusion scheme for cooperative spectrum sensing was proposed for saving resources in the control channel. Secondary users (SUs) simultaneously report their decisions using binary modulations with the same carrier frequencies. The transmitted symbols add incoherently at the fusion centre (FC), [...] Read more.

Recently, a novel fusion scheme for cooperative spectrum sensing was proposed for saving resources in the control channel. Secondary users (SUs) simultaneously report their decisions using binary modulations with the same carrier frequencies. The transmitted symbols add incoherently at the fusion centre (FC), leading to a larger set of symbols in which a subset is associated with the presence of the primary user (PU) signal, and another subset is associated with the absence of such a signal. The decision criterion applied for discriminating these subsets works under the assumption that the channel gains are known at the FC. In this paper, we propose a new simultaneous transmission and decision scheme in which the task of channel estimation is shifted from the FC to the SUs, without the need for feeding-back of the estimates to the FC. The estimates are used at the SUs to pre-compensate for the reporting channel phase rotations and to partially compensate for the channel gains. This partial compensation is the result of signal clipping for peak-to-average power ratio (PAPR) control. We show, analytically and with simulations, that this new scheme can produce large performance improvements, yet reduces the implementation complexity when compared with the original one. Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

14 pages, 11117 KiB

Open AccessArticle

Electrical Impedance Spectroscopy-Based Defect Sensing Technique in Estimating Cracks

by Tingting Zhang, Liangdong Zhou, Habib Ammari and Jin Keun Seo

Sensors 2015, 15(5), 10909-10922; https://doi.org/10.3390/s150510909 - 8 May 2015

Cited by 15 | Viewed by 6433

Abstract

A defect sensing method based on electrical impedance spectroscopy is proposed to image cracks and reinforcing bars in concrete structures. The method utilizes the frequency-dependent behavior of thin insulating cracks: low-frequency electrical currents are blocked by insulating cracks, whereas high-frequency currents can pass [...] Read more.

A defect sensing method based on electrical impedance spectroscopy is proposed to image cracks and reinforcing bars in concrete structures. The method utilizes the frequency-dependent behavior of thin insulating cracks: low-frequency electrical currents are blocked by insulating cracks, whereas high-frequency currents can pass through thin cracks to probe the conducting bars. From various frequency-dependent electrical impedance tomography (EIT) images, we can show its advantage in terms of detecting both thin cracks with their thickness and bars. We perform numerical simulations and phantom experiments to support the feasibility of the proposed method. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

25 pages, 3549 KiB

Open AccessArticle

Multi-Scale Pixel-Based Image Fusion Using Multivariate Empirical Mode Decomposition

by Naveed Ur Rehman, Shoaib Ehsan, Syed Muhammad Umer Abdullah, Muhammad Jehanzaib Akhtar, Danilo P. Mandic and Klaus D. McDonald-Maier

Sensors 2015, 15(5), 10923-10947; https://doi.org/10.3390/s150510923 - 8 May 2015

Cited by 33 | Viewed by 7400

Abstract

A novel scheme to perform the fusion of multiple images using the multivariate empirical mode decomposition (MEMD) algorithm is proposed. Standard multi-scale fusion techniques make a priori assumptions regarding input data, whereas standard univariate empirical mode decomposition (EMD)-based fusion techniques suffer from inherent [...] Read more.

A novel scheme to perform the fusion of multiple images using the multivariate empirical mode decomposition (MEMD) algorithm is proposed. Standard multi-scale fusion techniques make a priori assumptions regarding input data, whereas standard univariate empirical mode decomposition (EMD)-based fusion techniques suffer from inherent mode mixing and mode misalignment issues, characterized respectively by either a single intrinsic mode function (IMF) containing multiple scales or the same indexed IMFs corresponding to multiple input images carrying different frequency information. We show that MEMD overcomes these problems by being fully data adaptive and by aligning common frequency scales from multiple channels, thus enabling their comparison at a pixel level and subsequent fusion at multiple data scales. We then demonstrate the potential of the proposed scheme on a large dataset of real-world multi-exposure and multi-focus images and compare the results against those obtained from standard fusion algorithms, including the principal component analysis (PCA), discrete wavelet transform (DWT) and non-subsampled contourlet transform (NCT). A variety of image fusion quality measures are employed for the objective evaluation of the proposed method. We also report the results of a hypothesis testing approach on our large image dataset to identify statistically-significant performance differences. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

25 pages, 3193 KiB

Open AccessArticle

Autonomous Aerial Refueling Ground Test Demonstration—A Sensor-in-the-Loop, Non-Tracking Method

by Chao-I Chen, Robert Koseluk, Chase Buchanan, Andrew Duerner, Brian Jeppesen and Hunter Laux

Sensors 2015, 15(5), 10948-10972; https://doi.org/10.3390/s150510948 - 11 May 2015

Cited by 19 | Viewed by 11745

Abstract

An essential capability for an unmanned aerial vehicle (UAV) to extend its airborne duration without increasing the size of the aircraft is called the autonomous aerial refueling (AAR). This paper proposes a sensor-in-the-loop, non-tracking method for probe-and-drogue style autonomous aerial refueling tasks by [...] Read more.

An essential capability for an unmanned aerial vehicle (UAV) to extend its airborne duration without increasing the size of the aircraft is called the autonomous aerial refueling (AAR). This paper proposes a sensor-in-the-loop, non-tracking method for probe-and-drogue style autonomous aerial refueling tasks by combining sensitivity adjustments of a 3D Flash LIDAR camera with computer vision based image-processing techniques. The method overcomes the inherit ambiguity issues when reconstructing 3D information from traditional 2D images by taking advantage of ready to use 3D point cloud data from the camera, followed by well-established computer vision techniques. These techniques include curve fitting algorithms and outlier removal with the random sample consensus (RANSAC) algorithm to reliably estimate the drogue center in 3D space, as well as to establish the relative position between the probe and the drogue. To demonstrate the feasibility of the proposed method on a real system, a ground navigation robot was designed and fabricated. Results presented in the paper show that using images acquired from a 3D Flash LIDAR camera as real time visual feedback, the ground robot is able to track a moving simulated drogue and continuously narrow the gap between the robot and the target autonomously. Full article

(This article belongs to the Special Issue UAV Sensors for Environmental Monitoring)

► Show Figures

Figure 1

18 pages, 4061 KiB

Open AccessArticle

A Tapered Aluminium Microelectrode Array for Improvement of Dielectrophoresis-Based Particle Manipulation

by Muhamad Ramdzan Buyong, Farhad Larki, Mohd Syafiq Faiz, Azrul Azlan Hamzah, Jumrail Yunas and Burhanuddin Yeop Majlis

Sensors 2015, 15(5), 10973-10990; https://doi.org/10.3390/s150510973 - 11 May 2015

Cited by 48 | Viewed by 6104

Abstract

In this work, the dielectrophoretic force (F_DEP) response of Aluminium Microelectrode Arrays with tapered profile is investigated through experimental measurements and numerical simulations. A standard CMOS processing technique with a step for the formation of a tapered profile resist is implemented [...] Read more.

In this work, the dielectrophoretic force (F_DEP) response of Aluminium Microelectrode Arrays with tapered profile is investigated through experimental measurements and numerical simulations. A standard CMOS processing technique with a step for the formation of a tapered profile resist is implemented in the fabrication of Tapered Aluminium Microelectrode Arrays (TAMA). The F_DEPis investigated through analysis of the Clausius-Mossotti factor (CMF) and cross-over frequency (f_xo). The performance of TAMA with various side wall angles is compared to that of microelectrodes with a straight cut sidewall profile over a wide range of frequencies through FEM numerical simulations. Additionally, electric field measurement (EFM) is performed through scanning probe microscopy (SPM) in order to obtain the region of force focus in both platforms. Results showed that the tapered profile microelectrodes with angles between 60° and 70° produce the highest electric field gradient on the particles. Also, the region of the strongest electric field in TAMA is located at the bottom and top edge of microelectrode while the strongest electric field in microelectrodes with straight cut profile is found at the top corner of the microelectrode. The latter property of microelectrodes improves the probability of capturing/repelling the particles at the microelectrode’s side wall. Full article

(This article belongs to the Section Chemical Sensors)

► Show Figures

Graphical abstract

21 pages, 1502 KiB

Open AccessArticle

Faults Diagnostics of Railway Axle Bearings Based on IMF’s Confidence Index Algorithm for Ensemble EMD

by Cai Yi, Jianhui Lin, Weihua Zhang and Jianming Ding

Sensors 2015, 15(5), 10991-11011; https://doi.org/10.3390/s150510991 - 11 May 2015

Cited by 72 | Viewed by 7406

Abstract

As train loads and travel speeds have increased over time, railway axle bearings have become critical elements which require more efficient non-destructive inspection and fault diagnostics methods. This paper presents a novel and adaptive procedure based on ensemble empirical mode decomposition (EEMD) and [...] Read more.

As train loads and travel speeds have increased over time, railway axle bearings have become critical elements which require more efficient non-destructive inspection and fault diagnostics methods. This paper presents a novel and adaptive procedure based on ensemble empirical mode decomposition (EEMD) and Hilbert marginal spectrum for multi-fault diagnostics of axle bearings. EEMD overcomes the limitations that often hypothesize about data and computational efforts that restrict the application of signal processing techniques. The outputs of this adaptive approach are the intrinsic mode functions that are treated with the Hilbert transform in order to obtain the Hilbert instantaneous frequency spectrum and marginal spectrum. Anyhow, not all the IMFs obtained by the decomposition should be considered into Hilbert marginal spectrum. The IMFs’ confidence index arithmetic proposed in this paper is fully autonomous, overcoming the major limit of selection by user with experience, and allows the development of on-line tools. The effectiveness of the improvement is proven by the successful diagnosis of an axle bearing with a single fault or multiple composite faults, e.g., outer ring fault, cage fault and pin roller fault. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

15 pages, 907 KiB

Open AccessArticle

Effects of Temperature and X-rays on Plastic Scintillating Fiber and Infrared Optical Fiber

by Bongsoo Lee, Sang Hun Shin, Kyoung Won Jang and Wook Jae Yoo

Sensors 2015, 15(5), 11012-11026; https://doi.org/10.3390/s150511012 - 11 May 2015

Cited by 7 | Viewed by 7436

Abstract

In this study, we have studied the effects of temperature and X-ray energy variations on the light output signals from two different fiber-optic sensors, a fiber-optic dosimeter (FOD) based on a BCF-12 as a plastic scintillating fiber (PSF) and a fiber-optic thermometer (FOT) [...] Read more.

In this study, we have studied the effects of temperature and X-ray energy variations on the light output signals from two different fiber-optic sensors, a fiber-optic dosimeter (FOD) based on a BCF-12 as a plastic scintillating fiber (PSF) and a fiber-optic thermometer (FOT) using a silver halide optical fiber as an infrared optical fiber (IR fiber). During X-ray beam irradiation, the scintillating light and IR signals were measured simultaneously using a dosimeter probe of the FOD and a thermometer probe of the FOT. The probes were placed in a beaker with water on the center of a hotplate, under variation of the tube potential of a digital radiography system or the temperature of the water in the beaker. From the experimental results, in the case of the PSF, the scintillator light output at the given tube potential decreased as the temperature increased in the temperature range from 25 to 60 °C. We demonstrated that commonly used BCF-12 has a significant temperature dependence of −0.263 ± 0.028%/°C in the clinical temperature range. Next, in the case of the IR fiber, the intensity of the IR signal was almost uniform at each temperature regardless of the tube potential range from 50 to 150 kVp. Therefore, we also demonstrated that the X-ray beam with an energy range used in diagnostic radiology does not affect the IR signals transmitted via a silver halide optical fiber. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

23 pages, 4737 KiB

Open AccessArticle

Current Sensor Fault Diagnosis Based on a Sliding Mode Observer for PMSM Driven Systems

by Gang Huang, Yi-Ping Luo, Chang-Fan Zhang, Yi-Shan Huang and Kai-Hui Zhao

Sensors 2015, 15(5), 11027-11049; https://doi.org/10.3390/s150511027 - 11 May 2015

Cited by 26 | Viewed by 7517

Abstract

This paper proposes a current sensor fault detection method based on a sliding mode observer for the torque closed-loop control system of interior permanent magnet synchronous motors. First, a sliding mode observer based on the extended flux linkage is built to simplify the [...] Read more.

This paper proposes a current sensor fault detection method based on a sliding mode observer for the torque closed-loop control system of interior permanent magnet synchronous motors. First, a sliding mode observer based on the extended flux linkage is built to simplify the motor model, which effectively eliminates the phenomenon of salient poles and the dependence on the direct axis inductance parameter, and can also be used for real-time calculation of feedback torque. Then a sliding mode current observer is constructed in αβ coordinates to generate the fault residuals of the phase current sensors. The method can accurately identify abrupt gain faults and slow-variation offset faults in real time in faulty sensors, and the generated residuals of the designed fault detection system are not affected by the unknown input, the structure of the observer, and the theoretical derivation and the stability proof process are concise and simple. The RT-LAB real-time simulation is used to build a simulation model of the hardware in the loop. The simulation and experimental results demonstrate the feasibility and effectiveness of the proposed method. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

26 pages, 2230 KiB

Open AccessArticle

Fusing Range Measurements from Ultrasonic Beacons and a Laser Range Finder for Localization of a Mobile Robot

by Nak Yong Ko and Tae-Yong Kuc

Sensors 2015, 15(5), 11050-11075; https://doi.org/10.3390/s150511050 - 11 May 2015

Cited by 36 | Viewed by 7792

Abstract

This paper proposes a method for mobile robot localization in a partially unknown indoor environment. The method fuses two types of range measurements: the range from the robot to the beacons measured by ultrasonic sensors and the range from the robot to the [...] Read more.

This paper proposes a method for mobile robot localization in a partially unknown indoor environment. The method fuses two types of range measurements: the range from the robot to the beacons measured by ultrasonic sensors and the range from the robot to the walls surrounding the robot measured by a laser range finder (LRF). For the fusion, the unscented Kalman filter (UKF) is utilized. Because finding the Jacobian matrix is not feasible for range measurement using an LRF, UKF has an advantage in this situation over the extended KF. The locations of the beacons and range data from the beacons are available, whereas the correspondence of the range data to the beacon is not given. Therefore, the proposed method also deals with the problem of data association to determine which beacon corresponds to the given range data. The proposed approach is evaluated using different sets of design parameter values and is compared with the method that uses only an LRF or ultrasonic beacons. Comparative analysis shows that even though ultrasonic beacons are sparsely populated, have a large error and have a slow update rate, they improve the localization performance when fused with the LRF measurement. In addition, proper adjustment of the UKF design parameters is crucial for full utilization of the UKF approach for sensor fusion. This study contributes to the derivation of a UKF-based design methodology to fuse two exteroceptive measurements that are complementary to each other in localization. Full article

(This article belongs to the Special Issue Acoustic Waveguide Sensors)

► Show Figures

16 pages, 4972 KiB

Open AccessArticle

MMP-2/9-Specific Activatable Lifetime Imaging Agent

by Marcus T.M. Rood, Marcel Raspe, Jan Bart ten Hove, Kees Jalink, Aldrik H. Velders and Fijs W.B. Van Leeuwen

Sensors 2015, 15(5), 11076-11091; https://doi.org/10.3390/s150511076 - 12 May 2015

Cited by 7 | Viewed by 13321

Abstract

Optical (molecular) imaging can benefit from a combination of the high signal-to-background ratio of activatable fluorescence imaging with the high specificity of luminescence lifetime imaging. To allow for this combination, both imaging techniques were integrated in a single imaging agent, a so-called activatable [...] Read more.

Optical (molecular) imaging can benefit from a combination of the high signal-to-background ratio of activatable fluorescence imaging with the high specificity of luminescence lifetime imaging. To allow for this combination, both imaging techniques were integrated in a single imaging agent, a so-called activatable lifetime imaging agent. Important in the design of this imaging agent is the use of two luminophores that are tethered by a specific peptide with a hairpin-motive that ensured close proximity of the two while also having a specific amino acid sequence available for enzymatic cleavage by tumor-related MMP-2/9. Ir(ppy)₃and Cy5 were used because in close proximity the emission intensities of both luminophores were quenched and the influence of Cy5 shortens the Ir(ppy)₃ luminescence lifetime from 98 ns to 30 ns. Upon cleavage in vitro, both effects are undone, yielding an increase in Ir(ppy)₃ and Cy5 luminescence and a restoration of Ir(ppy)₃ luminescence lifetime to 94 ns. As a reference for the luminescence activation, a similar imaging agent with the more common Cy3-Cy5 fluorophore pair was used. Our findings underline that the combination of enzymatic signal activation with lifetime imaging is possible and that it provides a promising method in the design of future disease specific imaging agents. Full article

(This article belongs to the Special Issue FRET Biosensors)

► Show Figures

Graphical abstract

26 pages, 19429 KiB

Open AccessArticle

Assessing Visual Attention Using Eye Tracking Sensors in Intelligent Cognitive Therapies Based on Serious Games

by Maite Frutos-Pascual and Begonya Garcia-Zapirain

Sensors 2015, 15(5), 11092-11117; https://doi.org/10.3390/s150511092 - 12 May 2015

Cited by 62 | Viewed by 10787

Abstract

This study examines the use of eye tracking sensors as a means to identify children’s behavior in attention-enhancement therapies. For this purpose, a set of data collected from 32 children with different attention skills is analyzed during their interaction with a set of [...] Read more.

This study examines the use of eye tracking sensors as a means to identify children’s behavior in attention-enhancement therapies. For this purpose, a set of data collected from 32 children with different attention skills is analyzed during their interaction with a set of puzzle games. The authors of this study hypothesize that participants with better performance may have quantifiably different eye-movement patterns from users with poorer results. The use of eye trackers outside the research community may help to extend their potential with available intelligent therapies, bringing state-of-the-art technologies to users. The use of gaze data constitutes a new information source in intelligent therapies that may help to build new approaches that are fully-customized to final users’ needs. This may be achieved by implementing machine learning algorithms for classification. The initial study of the dataset has proven a 0.88 (±0.11) classification accuracy with a random forest classifier, using cross-validation and hierarchical tree-based feature selection. Further approaches need to be examined in order to establish more detailed attention behaviors and patterns among children with and without attention problems. Full article

(This article belongs to the Special Issue HCI In Smart Environments)

► Show Figures

15 pages, 1043 KiB

Open AccessArticle

Free-Base Carboxyphenyl Porphyrin Films Using a TiO₂ Columnar Matrix: Characterization and Application as NO₂ Sensors

by Javier Roales, José M. Pedrosa, María G. Guillén, Tânia Lopes-Costa, Pedro Castillero, Angel Barranco and Agustín R. González-Elipe

Sensors 2015, 15(5), 11118-11132; https://doi.org/10.3390/s150511118 - 12 May 2015

Cited by 33 | Viewed by 7272

Abstract

The anchoring effect on free-base carboxyphenyl porphyrin films using TiO₂ microstructured columns as a host matrix and its influence on NO₂ sensing have been studied in this work. Three porphyrins have been used: 5-(4-carboxyphenyl)10,15,20-triphenyl-21H,23H-porphyrin (MCTPP); 5,10,15,20-tetrakis(4-carboxyphenyl)-21H [...] Read more.

The anchoring effect on free-base carboxyphenyl porphyrin films using TiO₂ microstructured columns as a host matrix and its influence on NO₂ sensing have been studied in this work. Three porphyrins have been used: 5-(4-carboxyphenyl)10,15,20-triphenyl-21H,23H-porphyrin (MCTPP); 5,10,15,20-tetrakis(4-carboxyphenyl)-21H,23H-porphyrin (p-TCPP); and 5,10,15,20-tetrakis(3-carboxyphenyl)-21H,23H-porphyrin (m-TCPP). The analysis of UV-Vis spectra of MCTPP/TiO₂, p-TCPP/TiO₂ and m-TCPP/TiO₂ composite films has revealed that m-TCPP/TiO₂films are the most stable, showing less aggregation than the other porphyrins. IR spectroscopy has shown that m-TCPP is bound to TiO₂ through its four carboxylic acid groups, while p-TCPP is anchored by only one or two of these groups. MCTPP can only be bound by one carboxylic acid. Consequently, the binding of p-TCPP and MCTPP to the substrate allows them to form aggregates, whereas the more fixed anchoring of m-TCPP reduces this effect. The exposure of MCTPP/TiO₂, p-TCPP/TiO₂ and m-TCPP/TiO₂ films to NO₂ has resulted in important changes in their UV-Vis spectra, revealing good sensing capabilities in all cases. The improved stability of films made with m-TCPP suggests this molecule as the best candidate among our set of porphyrins for the fabrication of NO₂ sensors. Moreover, their concentration-dependent responses upon exposure to low concentrations of NO₂ confirm the potential of m-TCPP as a NO₂ sensor. Full article

(This article belongs to the Special Issue Gas Sensors—Designs and Applications)

► Show Figures

Graphical abstract

18 pages, 2684 KiB

Open AccessArticle

Temperature-Compensated Force/Pressure Sensor Based on Multi-Walled Carbon Nanotube Epoxy Composites

by Nghia Trong Dinh and Olfa Kanoun

Sensors 2015, 15(5), 11133-11150; https://doi.org/10.3390/s150511133 - 12 May 2015

Cited by 29 | Viewed by 7139

Abstract

In this study, we propose a multi-walled carbon nanotube epoxy composite sensor for force and pressure sensing in the range of 50 N–2 kN. A manufacturing procedure, including material preparation and deposition techniques, is proposed. The electrode dimensions and the layer thickness were [...] Read more.

In this study, we propose a multi-walled carbon nanotube epoxy composite sensor for force and pressure sensing in the range of 50 N–2 kN. A manufacturing procedure, including material preparation and deposition techniques, is proposed. The electrode dimensions and the layer thickness were optimized by the finite element method. Temperature compensation is realized by four nanocomposites elements, where only two elements are exposed to the measurand. In order to investigate the influence of the filler contents, samples with different compositions were prepared and investigated. Additionally, the specimens are characterized by cyclical and stepped force/pressure loads or at defined temperatures. The results show that the choice of the filler content should meet a compromise between sensitivity, temperature influence and noise behavior. At constant temperature, a force of at least 50N can be resolved. The measurement error due to the temperature influence is 150N in a temperature range of –20°C–50°C. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

18 pages, 7321 KiB

Open AccessArticle

Gait Measurement System for the Multi-Target Stepping Task Using a Laser Range Sensor

by Ayanori Yorozu, Shu Nishiguchi, Minoru Yamada, Tomoki Aoyama, Toshiki Moriguchi and Masaki Takahashi

Sensors 2015, 15(5), 11151-11168; https://doi.org/10.3390/s150511151 - 13 May 2015

Cited by 13 | Viewed by 8287

Abstract

For the prevention of falling in the elderly, gait training has been proposed using tasks such as the multi-target stepping task (MTST), in which participants step on assigned colored targets. This study presents a gait measurement system using a laser range sensor for [...] Read more.

For the prevention of falling in the elderly, gait training has been proposed using tasks such as the multi-target stepping task (MTST), in which participants step on assigned colored targets. This study presents a gait measurement system using a laser range sensor for the MTST to evaluate the risk of falling. The system tracks both legs and measures general walking parameters such as stride length and walking speed. Additionally, it judges whether the participant steps on the assigned colored targets and detects cross steps to evaluate cognitive function. However, situations in which one leg is hidden from the sensor or the legs are close occur and are likely to lead to losing track of the legs or false tracking. To solve these problems, we propose a novel leg detection method with five observed leg patterns and global nearest neighbor-based data association with a variable validation region based on the state of each leg. In addition, methods to judge target steps and detect cross steps based on leg trajectory are proposed. From the experimental results with the elderly, it is confirmed that the proposed system can improve leg-tracking performance, judge target steps and detect cross steps with high accuracy. Full article

(This article belongs to the Special Issue Sensor Systems for Motion Capture and Interpretation)

► Show Figures

Figure 1

20 pages, 2463 KiB

Open AccessArticle

Assessment of Taste Attributes of Peanut Meal Enzymatic-Hydrolysis Hydrolysates Using an Electronic Tongue

by Li Wang, Qunfeng Niu, Yanbo Hui, Huali Jin and Shengsheng Chen

Sensors 2015, 15(5), 11169-11188; https://doi.org/10.3390/s150511169 - 13 May 2015

Cited by 18 | Viewed by 7318

Abstract

Peanut meal is the byproduct of high-temperature peanut oil extraction; it is mainly composed of proteins, which have complex tastes after enzymatic hydrolysis to free amino acids and small peptides. The enzymatic hydrolysis method was adopted by using two compound proteases of trypsin [...] Read more.

Peanut meal is the byproduct of high-temperature peanut oil extraction; it is mainly composed of proteins, which have complex tastes after enzymatic hydrolysis to free amino acids and small peptides. The enzymatic hydrolysis method was adopted by using two compound proteases of trypsin and flavorzyme to hydrolyze peanut meal aiming to provide a flavor base. Hence, it is necessary to assess the taste attributes and assign definite taste scores of peanut meal double enzymatic hydrolysis hydrolysates (DEH). Conventionally, sensory analysis is used to assess taste intensity in DEH. However, it has disadvantages because it is expensive and laborious. Hence, in this study, both taste attributes and taste scores of peanut meal DEH were evaluated using an electronic tongue. In this regard, the response characteristics of the electronic tongue to the DEH samples and standard five taste samples were researched to qualitatively assess the taste attributes using PCA and DFA. PLS and RBF neural network (RBFNN) quantitative prediction models were employed to compare predictive abilities and to correlate results obtained from the electronic tongue and sensory analysis, respectively. The results showed that all prediction models had good correlations between the predicted scores from electronic tongue and those obtained from sensory analysis. The PLS and RBFNN prediction models constructed using the voltage response values from the sensors exhibited higher correlation and prediction ability than that of principal components. As compared with the taste performance by PLS model, that of RBFNN models was better. This study exhibits potential advantages and a concise objective taste assessment tool using the electronic tongue in the assessment of DEH taste attributes in the food industry. Full article

(This article belongs to the Special Issue Sensors for Food Safety and Quality)

► Show Figures

Figure 1

19 pages, 3469 KiB

Open AccessArticle

Modification of an RBF ANN-Based Temperature Compensation Model of Interferometric Fiber Optical Gyroscopes

by Jianhua Cheng, Bing Qi, Daidai Chen and René Jr. Landry

Sensors 2015, 15(5), 11189-11207; https://doi.org/10.3390/s150511189 - 13 May 2015

Cited by 32 | Viewed by 5972

Abstract

This paper presents modification of Radial Basis Function Artificial Neural Network (RBF ANN)-based temperature compensation models for Interferometric Fiber Optical Gyroscopes (IFOGs). Based on the mathematical expression of IFOG output, three temperature relevant terms are extracted, which include: (1) temperature of fiber loops; [...] Read more.

This paper presents modification of Radial Basis Function Artificial Neural Network (RBF ANN)-based temperature compensation models for Interferometric Fiber Optical Gyroscopes (IFOGs). Based on the mathematical expression of IFOG output, three temperature relevant terms are extracted, which include: (1) temperature of fiber loops; (2) temperature variation of fiber loops; (3) temperature product term of fiber loops. Then, the input-modified RBF ANN-based temperature compensation scheme is established, in which temperature relevant terms are transferred to train the RBF ANN. Experimental temperature tests are conducted and sufficient data are collected and post-processed to form the novel RBF ANN. Finally, we apply the modified RBF ANN based on temperature compensation model in two IFOGs with temperature compensation capabilities. The experimental results show the proposed temperature compensation model could efficiently reduce the influence of environment temperature on the output of IFOG, and exhibit a better temperature compensation performance than conventional scheme without proposed improvements. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

14 pages, 2787 KiB

Open AccessArticle

Afocal Optical Flow Sensor for Reducing Vertical Height Sensitivity in Indoor Robot Localization and Navigation

by Dong-Hoon Yi, Tae-Jae Lee and Dong-Il Cho

Sensors 2015, 15(5), 11208-11221; https://doi.org/10.3390/s150511208 - 13 May 2015

Cited by 14 | Viewed by 9597

Abstract

This paper introduces a novel afocal optical flow sensor (OFS) system for odometry estimation in indoor robotic navigation. The OFS used in computer optical mouse has been adopted for mobile robots because it is not affected by wheel slippage. Vertical height variance is [...] Read more.

This paper introduces a novel afocal optical flow sensor (OFS) system for odometry estimation in indoor robotic navigation. The OFS used in computer optical mouse has been adopted for mobile robots because it is not affected by wheel slippage. Vertical height variance is thought to be a dominant factor in systematic error when estimating moving distances in mobile robots driving on uneven surfaces. We propose an approach to mitigate this error by using an afocal (infinite effective focal length) system. We conducted experiments in a linear guide on carpet and three other materials with varying sensor heights from 30 to 50 mm and a moving distance of 80 cm. The same experiments were repeated 10 times. For the proposed afocal OFS module, a 1 mm change in sensor height induces a 0.1% systematic error; for comparison, the error for a conventional fixed-focal-length OFS module is 14.7%. Finally, the proposed afocal OFS module was installed on a mobile robot and tested 10 times on a carpet for distances of 1 m. The average distance estimation error and standard deviation are 0.02% and 17.6%, respectively, whereas those for a conventional OFS module are 4.09% and 25.7%, respectively. Full article

(This article belongs to the Special Issue Sensors for Indoor Mapping and Navigation)

► Show Figures

Graphical abstract

17 pages, 1818 KiB

Open AccessArticle

An Adaptive Compensation Algorithm for Temperature Drift of Micro-Electro-Mechanical Systems Gyroscopes Using a Strong Tracking Kalman Filter

by Yibo Feng, Xisheng Li and Xiaojuan Zhang

Sensors 2015, 15(5), 11222-11238; https://doi.org/10.3390/s150511222 - 13 May 2015

Cited by 27 | Viewed by 8410

Abstract

We present an adaptive algorithm for a system integrated with micro-electro-mechanical systems (MEMS) gyroscopes and a compass to eliminate the influence from the environment, compensate the temperature drift precisely, and improve the accuracy of the MEMS gyroscope. We use a simplified drift model [...] Read more.

We present an adaptive algorithm for a system integrated with micro-electro-mechanical systems (MEMS) gyroscopes and a compass to eliminate the influence from the environment, compensate the temperature drift precisely, and improve the accuracy of the MEMS gyroscope. We use a simplified drift model and changing but appropriate model parameters to implement this algorithm. The model of MEMS gyroscope temperature drift is constructed mostly on the basis of the temperature sensitivity of the gyroscope. As the state variables of a strong tracking Kalman filter (STKF), the parameters of the temperature drift model can be calculated to adapt to the environment under the support of the compass. These parameters change intelligently with the environment to maintain the precision of the MEMS gyroscope in the changing temperature. The heading error is less than 0.6° in the static temperature experiment, and also is kept in the range from 5° to −2° in the dynamic outdoor experiment. This demonstrates that the proposed algorithm exhibits strong adaptability to a changing temperature, and performs significantly better than KF and MLR to compensate the temperature drift of a gyroscope and eliminate the influence of temperature variation. Full article

(This article belongs to the Special Issue Modeling, Testing and Reliability Issues in MEMS Engineering)

► Show Figures

Figure 1

19 pages, 3145 KiB

Open AccessArticle

NDIR Gas Sensor for Spatial Monitoring of Carbon Dioxide Concentrations in Naturally Ventilated Livestock Buildings

by Luciano B. Mendes, Nico W. M. Ogink, Nadège Edouard, Hendrik Jan C. Van Dooren, Ilda De Fátima F. Tinôco and Julio Mosquera

Sensors 2015, 15(5), 11239-11257; https://doi.org/10.3390/s150511239 - 13 May 2015

Cited by 64 | Viewed by 14464

Abstract

The tracer gas ratio method, using CO₂ as natural tracer, has been suggested as a pragmatic option to measure emissions from naturally ventilated (NV) barns without the need to directly estimate the ventilation rate. The aim of this research was to assess [...] Read more.

The tracer gas ratio method, using CO₂ as natural tracer, has been suggested as a pragmatic option to measure emissions from naturally ventilated (NV) barns without the need to directly estimate the ventilation rate. The aim of this research was to assess the performance of a low-cost Non-Dispersive Infra-Red (NDIR) sensor for intensive spatial field monitoring of CO₂ concentrations in a NV dairy cow house. This was achieved by comparing NDIR sensors with two commonly applied methods, a Photo-Acoustic Spectroscope (PAS) Gas Monitor and an Open-Path laser (OP-laser). First, calibrations for the NDIR sensors were obtained in the laboratory. Then, the NDIR sensors were placed in a dairy cow barn for comparison with the PAS and OP-laser methods. The main conclusions were: (a) in order to represent the overall barn CO₂ concentration of the dairy cow barn, the number of NDIR sensors to be accounted for average concentration calculation was dependent on barn length and on barn area occupation; and (b) the NDIR CO₂ sensors are suitable for multi-point monitoring of CO₂ concentrations in NV livestock barns, being a feasible alternative for the PAS and the OP-laser methods to monitor single-point or averaged spatial CO₂ concentrations in livestock barns. Full article

(This article belongs to the Section Chemical Sensors)

► Show Figures

Figure 1

19 pages, 1130 KiB

Open AccessArticle

Estimation of Joint Forces and Moments for the In-Run and Take-Off in Ski Jumping Based on Measurements with Wearable Inertial Sensors

by Grega Logar and Marko Munih

Sensors 2015, 15(5), 11258-11276; https://doi.org/10.3390/s150511258 - 13 May 2015

Cited by 35 | Viewed by 9720

Abstract

This study uses inertial sensors to measure ski jumper kinematics and joint dynamics, which was until now only a part of simulation studies. For subsequent calculation of dynamics in the joints, a link-segment model was developed. The model relies on the recursive Newton–Euler [...] Read more.

This study uses inertial sensors to measure ski jumper kinematics and joint dynamics, which was until now only a part of simulation studies. For subsequent calculation of dynamics in the joints, a link-segment model was developed. The model relies on the recursive Newton–Euler inverse dynamics. This approach allowed the calculation of the ground reaction force at take-off. For the model validation, four ski jumpers from the National Nordic center performed a simulated jump in a laboratory environment on a force platform; in total, 20 jumps were recorded. The results fit well to the reference system, presenting small errors in the mean and standard deviation and small root-mean-square errors. The error is under 12% of the reference value. For field tests, six jumpers participated in the study; in total, 28 jumps were recorded. All of the measured forces and moments were within the range of prior simulated studies. The proposed system was able to indirectly provide the values of forces and moments in the joints of the ski-jumpers’ body segments, as well as the ground reaction force during the in-run and take-off phases in comparison to the force platform installed on the table. Kinematics assessment and estimation of dynamics parameters can be applied to jumps from any ski jumping hill. Full article

(This article belongs to the Special Issue Sensor Systems for Motion Capture and Interpretation)

► Show Figures

18 pages, 262 KiB

Open AccessArticle

On the Deployment of a Connected Sensor Network for Confident Information Coverage

by Huping Xu, Jiajun Zhu and Bang Wang

Sensors 2015, 15(5), 11277-11294; https://doi.org/10.3390/s150511277 - 14 May 2015

Cited by 18 | Viewed by 5111

Abstract

Coverage and connectivity are two important performance metrics in wireless sensor networks. In this paper, we study the sensor placement problem to achieve both coverage and connectivity. Instead of using the simplistic disk coverage model, we use our recently proposed confident information coverage [...] Read more.

Coverage and connectivity are two important performance metrics in wireless sensor networks. In this paper, we study the sensor placement problem to achieve both coverage and connectivity. Instead of using the simplistic disk coverage model, we use our recently proposed confident information coverage model as the sensor coverage model. The grid approach is applied to discretize the sensing field, and our objective is to place the minimum number of sensors to form a connected network and to provide confident information coverage for all of the grid points. We first formulate the sensor placement problem as a constrained optimization problem. Then, two heuristic algorithms, namely the connected cover formation (CCF) algorithm and the cover formation and relay placement with redundancy removal (CFRP-RR) algorithm, are proposed to find the approximate solutions for the sensor placement problem. The simulation results validate their effectiveness, and the CCF algorithm performs slightly better than the CFRP-RR algorithm. Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

17 pages, 1465 KiB

Open AccessArticle

Heart Rate Variability Monitoring during Sleep Based on Capacitively Coupled Textile Electrodes on a Bed

by Hong Ji Lee, Su Hwan Hwang, Hee Nam Yoon, Won Kyu Lee and Kwang Suk Park

Sensors 2015, 15(5), 11295-11311; https://doi.org/10.3390/s150511295 - 14 May 2015

Cited by 58 | Viewed by 10493

Abstract

In this study, we developed and tested a capacitively coupled electrocardiogram (ECG) measurement system using conductive textiles on a bed, for long-term healthcare monitoring. The system, which was designed to measure ECG in a bed with no constraints of sleep position and posture, [...] Read more.

In this study, we developed and tested a capacitively coupled electrocardiogram (ECG) measurement system using conductive textiles on a bed, for long-term healthcare monitoring. The system, which was designed to measure ECG in a bed with no constraints of sleep position and posture, included a foam layer to increase the contact region with the curvature of the body and a cover to ensure durability and easy installation. Nine healthy subjects participated in the experiment during polysomnography (PSG), and the heart rate (HR) coverage and heart rate variability (HRV) parameters were analyzed to evaluate the system. The experimental results showed that the mean of R-peak coverage was 98.0% (95.5%–99.7%), and the normalized errors of HRV time and spectral measures between the Ag/AgCl system and our system ranged from 0.15% to 4.20%. The root mean square errors for inter-beat (RR) intervals and HR were 1.36 ms and 0.09 bpm, respectively. We also showed the potential of our developed system for rapid eye movement (REM) sleep and wake detection as well as for recording of abnormal states. Full article

(This article belongs to the Collection Sensors for Globalized Healthy Living and Wellbeing)

► Show Figures

Figure 1

24 pages, 3654 KiB

Open AccessArticle

Measuring Kinematic Variables in Front Crawl Swimming Using Accelerometers: A Validation Study

by Andrew J. Callaway

Sensors 2015, 15(5), 11363-11386; https://doi.org/10.3390/s150511363 - 14 May 2015

Cited by 26 | Viewed by 13946

Abstract

Objective data on swimming performance is needed to meet the demands of the swimming coach and athlete. The purpose of this study is to use a multiple inertial measurement units to calculate Lap Time, Velocity, Stroke Count, Stroke Duration, Stroke Rate and Phases [...] Read more.

Objective data on swimming performance is needed to meet the demands of the swimming coach and athlete. The purpose of this study is to use a multiple inertial measurement units to calculate Lap Time, Velocity, Stroke Count, Stroke Duration, Stroke Rate and Phases of the Stroke (Entry, Pull, Push, Recovery) in front crawl swimming. Using multiple units on the body, an algorithm was developed to calculate the phases of the stroke based on the relative position of the body roll. Twelve swimmers, equipped with these devices on the body, performed fatiguing trials. The calculated factors were compared to the same data derived to video data showing strong positive results for all factors. Four swimmers required individual adaptation to the stroke phase calculation method. The developed algorithm was developed using a search window relative to the body roll (peak/trough). This customization requirement demonstrates that single based devices will not be able to determine these phases of the stroke with sufficient accuracy. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Graphical abstract

15 pages, 737 KiB

Open AccessArticle

Determining the Leaf Emissivity of Three Crops by Infrared Thermometry

by Chiachung Chen

Sensors 2015, 15(5), 11387-11401; https://doi.org/10.3390/s150511387 - 15 May 2015

Cited by 51 | Viewed by 8270

Abstract

Plant temperature can provide important physiological information for crop management. Non-contact measurement with an infrared thermometer is useful for detecting leaf temperatures. In this study, a novel technique was developed to measure leaf emissivity using an infrared thermometer with an infrared sensor and [...] Read more.

Plant temperature can provide important physiological information for crop management. Non-contact measurement with an infrared thermometer is useful for detecting leaf temperatures. In this study, a novel technique was developed to measure leaf emissivity using an infrared thermometer with an infrared sensor and a thermocouple wire. The measured values were transformed into true temperatures by calibration equations to improve the measurement accuracy. The relationship between two kinds of measurement temperatures and setting emissivities was derived as a model for calculating of true emissivity. The emissivities of leaves of three crops were calculated by the mathematical equation developed in this study. The mean emissivities were 0.9809, 0.9783, 0.981 and 0.9848 for Phalaenopsis mature and new leaves and Paphiopedilum and Malabar chestnut leaves, respectively. Emissivity differed significantly between leaves of Malabar chestnut and the two orchids. The range of emissivities determined in this study was similar to that in the literature. The precision of the measurement is acceptable. The method developed in this study is a real-time, in situ technique and could be used for agricultural and forestry plants. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

15 pages, 468 KiB

Open AccessArticle

Intelligent Detection of Cracks in Metallic Surfaces Using a Waveguide Sensor Loaded with Metamaterial Elements

by Abdulbaset Ali, Bing Hu and Omar Ramahi

Sensors 2015, 15(5), 11402-11416; https://doi.org/10.3390/s150511402 - 15 May 2015

Cited by 36 | Viewed by 7753

Abstract

This work presents a real life experiment of implementing an artificial intelligence model for detecting sub-millimeter cracks in metallic surfaces on a dataset obtained from a waveguide sensor loaded with metamaterial elements. Crack detection using microwave sensors is typically based on human observation [...] Read more.

This work presents a real life experiment of implementing an artificial intelligence model for detecting sub-millimeter cracks in metallic surfaces on a dataset obtained from a waveguide sensor loaded with metamaterial elements. Crack detection using microwave sensors is typically based on human observation of change in the sensor’s signal (pattern) depicted on a high-resolution screen of the test equipment. However, as demonstrated in this work, implementing artificial intelligence to classify cracked from non-cracked surfaces has appreciable impact in terms of sensing sensitivity, cost, and automation. Furthermore, applying artificial intelligence for post-processing data collected from microwave sensors is a cornerstone for handheld test equipment that can outperform rack equipment with large screens and sophisticated plotting features. The proposed method was tested on a metallic plate with different cracks and the obtained experimental results showed good crack classification accuracy rates. Full article

(This article belongs to the Special Issue Metamaterial-Inspired Sensors)

► Show Figures

14 pages, 5004 KiB

Open AccessArticle

Fluorescence Characteristics and Lifetime Images of Photosensitizers of Talaporfin Sodium and Sodium Pheophorbide a in Normal and Cancer Cells

by Kamlesh Awasthi, Kazuhito Yamamoto, Kazunari Furuya, Takakazu Nakabayashi, Liming Li and Nobuhiro Ohta

Sensors 2015, 15(5), 11417-11430; https://doi.org/10.3390/s150511417 - 18 May 2015

Cited by 19 | Viewed by 6569

Abstract

Fluorescence spectra and fluorescence lifetime images of talaporfin sodium and sodium-pheophorbide a, which can be regarded as photosensitizers for photodynamic therapy, were measured in normal and cancer cells. The reduction of the fluorescence intensity by photoirradiation was observed for both photosensitizers in both [...] Read more.

Fluorescence spectra and fluorescence lifetime images of talaporfin sodium and sodium-pheophorbide a, which can be regarded as photosensitizers for photodynamic therapy, were measured in normal and cancer cells. The reduction of the fluorescence intensity by photoirradiation was observed for both photosensitizers in both cells, but the quenching rate was much faster in cancer cells than in normal cells. These results are explained in terms of the excessive generation of reactive oxygen species via photoexcitation of these photosensitizers in cancer cells. The fluorescence lifetimes of both photosensitizers in cancer cells are different from those in normal cells, which originates from the different intracellular environments around the photosensitizers between normal and cancer cells. Full article

(This article belongs to the Special Issue Intracellular Sensing)

► Show Figures

Figure 1

11 pages, 1069 KiB

Open AccessArticle

A Colorimetric Enzyme-Linked Immunosorbent Assay (ELISA) Detection Platform for a Point-of-Care Dengue Detection System on a Lab-on-Compact-Disc

by Aung Thiha and Fatimah Ibrahim

Sensors 2015, 15(5), 11431-11441; https://doi.org/10.3390/s150511431 - 18 May 2015

Cited by 116 | Viewed by 17049

Abstract

The enzyme-linked Immunosorbent Assay (ELISA) is the gold standard clinical diagnostic tool for the detection and quantification of protein biomarkers. However, conventional ELISA tests have drawbacks in their requirement of time, expensive equipment and expertise for operation. Hence, for the purpose of rapid, [...] Read more.

The enzyme-linked Immunosorbent Assay (ELISA) is the gold standard clinical diagnostic tool for the detection and quantification of protein biomarkers. However, conventional ELISA tests have drawbacks in their requirement of time, expensive equipment and expertise for operation. Hence, for the purpose of rapid, high throughput screening and point-of-care diagnosis, researchers are miniaturizing sandwich ELISA procedures on Lab-on-a-Chip and Lab-on-Compact Disc (LOCD) platforms. This paper presents a novel integrated device to detect and interpret the ELISA test results on a LOCD platform. The system applies absorption spectrophotometry to measure the absorbance (optical density) of the sample using a monochromatic light source and optical sensor. The device performs automated analysis of the results and presents absorbance values and diagnostic test results via a graphical display or via Bluetooth to a smartphone platform which also acts as controller of the device. The efficacy of the device was evaluated by performing dengue antibody IgG ELISA on 64 hospitalized patients suspected of dengue. The results demonstrate high accuracy of the device, with 95% sensitivity and 100% specificity in detection when compared with gold standard commercial ELISA microplate readers. This sensor platform represents a significant step towards establishing ELISA as a rapid, inexpensive and automatic testing method for the purpose of point-of-care-testing (POCT) in resource-limited settings. Full article

(This article belongs to the Special Issue Electrochemical Sensors and Biosensors: From Bench-Top to Point-of-Care)

► Show Figures

Graphical abstract

12 pages, 1048 KiB

Open AccessArticle

Design of an Embedded CMOS Temperature Sensor for Passive RFID Tag Chips

by Fangming Deng, Yigang He, Bing Li, Lihua Zhang, Xiang Wu, Zhihui Fu and Lei Zuo

Sensors 2015, 15(5), 11442-11453; https://doi.org/10.3390/s150511442 - 18 May 2015

Cited by 25 | Viewed by 7558

Abstract

This paper presents an ultra-low embedded power temperature sensor for passive RFID tags. The temperature sensor converts the temperature variation to a PTAT current, which is then transformed into a temperature-controlled frequency. A phase locked loop (PLL)-based sensor interface is employed to directly [...] Read more.

This paper presents an ultra-low embedded power temperature sensor for passive RFID tags. The temperature sensor converts the temperature variation to a PTAT current, which is then transformed into a temperature-controlled frequency. A phase locked loop (PLL)-based sensor interface is employed to directly convert this temperature-controlled frequency into a corresponding digital output without an external reference clock. The fabricated sensor occupies an area of 0.021 mm² using the TSMC 0.18 1P6M mixed-signal CMOS process. Measurement results of the embedded sensor within the tag system shows a 92 nW power dissipation under 1.0 V supply voltage at room temperature, with a sensing resolution of 0.15 °C/LSB and a sensing accuracy of −0.7/0.6 °C from −30 °C to 70 °C after 1-point calibration at 30 °C. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

11 pages, 3975 KiB

Open AccessArticle

A Wireless LC Sensor Coated with Ba_0.9Bi_0.066TiO₃for Measuring Temperature

by Milan Radovanovic, Bojana Mojic-Lante, Katarina N. Cvejin, Vladimir V. Srdic and Goran M. Stojanovic

Sensors 2015, 15(5), 11454-11464; https://doi.org/10.3390/s150511454 - 18 May 2015

Cited by 14 | Viewed by 5967

Abstract

This paper presents a passive LC wireless sensor for measuring temperature. The sensor is designed as a parallel connection of a spiral inductor and an interdigitated capacitor and it was fabricated in a conductive layer using LTCC (Low Temperature Co-fired Ceramic) technology. The [...] Read more.

This paper presents a passive LC wireless sensor for measuring temperature. The sensor is designed as a parallel connection of a spiral inductor and an interdigitated capacitor and it was fabricated in a conductive layer using LTCC (Low Temperature Co-fired Ceramic) technology. The inderdigitated capacitor electrodes were coated with a thin film of bismuth doped barium titanate (Ba_0.9Bi_0.066TiO₃), whose permittivity changes with temperature, which directly induces changes in the capacitance of the interdigitated capacitor and consequently changes the resonant frequency of the sensor. The measurements of S-parameter of the sensor were performed using a Vector Network Analyzer (E5071B, Agilent Technologies, Santa Clara, CA, USA), whose port was connected to the antenna coil that was placed around the sensor in order to be able to wirelessly detect temperature, in the temperature range from 25 °C to 165 °C. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

20 pages, 1731 KiB

Open AccessArticle

A Wearable Context-Aware ECG Monitoring System Integrated with Built-in Kinematic Sensors of the Smartphone

by Fen Miao, Yayu Cheng, Yi He, Qingyun He and Ye Li

Sensors 2015, 15(5), 11465-11484; https://doi.org/10.3390/s150511465 - 19 May 2015

Cited by 122 | Viewed by 19607

Abstract

Continuously monitoring the ECG signals over hours combined with activity status is very important for preventing cardiovascular diseases. A traditional ECG holter is often inconvenient to carry because it has many electrodes attached to the chest and because it is heavy. This work [...] Read more.

Continuously monitoring the ECG signals over hours combined with activity status is very important for preventing cardiovascular diseases. A traditional ECG holter is often inconvenient to carry because it has many electrodes attached to the chest and because it is heavy. This work proposes a wearable, low power context-aware ECG monitoring system integrated built-in kinetic sensors of the smartphone with a self-designed ECG sensor. The wearable ECG sensor is comprised of a fully integrated analog front-end (AFE), a commercial micro control unit (MCU), a secure digital (SD) card, and a Bluetooth module. The whole sensor is very small with a size of only 58 × 50 × 10 mm for wearable monitoring application due to the AFE design, and the total power dissipation in a full round of ECG acquisition is only 12.5 mW. With the help of built-in kinetic sensors of the smartphone, the proposed system can compute and recognize user’s physical activity, and thus provide context-aware information for the continuous ECG monitoring. The experimental results demonstrated the performance of proposed system in improving diagnosis accuracy for arrhythmias and identifying the most common abnormal ECG patterns in different activities. In conclusion, we provide a wearable, accurate and energy-efficient system for long-term and context-aware ECG monitoring without any extra cost on kinetic sensor design but with the help of the widespread smartphone. Full article

(This article belongs to the Special Issue Smartphone-Based Sensors for Non-Invasive Physiological Monitoring)

► Show Figures

Figure 1

14 pages, 13164 KiB

Open AccessArticle

A Flexible Three-in-One Microsensor for Real-Time Monitoring of Internal Temperature, Voltage and Current of Lithium Batteries

by Chi-Yuan Lee, Huan-Chih Peng, Shuo-Jen Lee, I-Ming Hung, Chien-Te Hsieh, Chuan-Sheng Chiou, Yu-Ming Chang and Yen-Pu Huang

Sensors 2015, 15(5), 11485-11498; https://doi.org/10.3390/s150511485 - 19 May 2015

Cited by 39 | Viewed by 10426

Abstract

Lithium batteries are widely used in notebook computers, mobile phones, 3C electronic products, and electric vehicles. However, under a high charge/discharge rate, the internal temperature of lithium battery may rise sharply, thus causing safety problems. On the other hand, when the lithium battery [...] Read more.

Lithium batteries are widely used in notebook computers, mobile phones, 3C electronic products, and electric vehicles. However, under a high charge/discharge rate, the internal temperature of lithium battery may rise sharply, thus causing safety problems. On the other hand, when the lithium battery is overcharged, the voltage and current may be affected, resulting in battery instability. This study applies the micro-electro-mechanical systems (MEMS) technology on a flexible substrate, and develops a flexible three-in-one microsensor that can withstand the internal harsh environment of a lithium battery and instantly measure the internal temperature, voltage and current of the battery. Then, the internal information can be fed back to the outside in advance for the purpose of safety management without damaging the lithium battery structure. The proposed flexible three-in-one microsensor should prove helpful for the improvement of lithium battery design or material development in the future. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

12 pages, 1186 KiB

Open AccessArticle

Photonic Crystal Fiber-Based Surface Plasmon Resonance Sensor with Selective Analyte Channels and Graphene-Silver Deposited Core

by Ahmmed A. Rifat, G. Amouzad Mahdiraji, Desmond M. Chow, Yu Gang Shee, Rajib Ahmed and Faisal Rafiq Mahamd Adikan

Sensors 2015, 15(5), 11499-11510; https://doi.org/10.3390/s150511499 - 19 May 2015

Cited by 306 | Viewed by 14330

Abstract

We propose a surface plasmon resonance (SPR) sensor based on photonic crystal fiber (PCF) with selectively filled analyte channels. Silver is used as the plasmonic material to accurately detect the analytes and is coated with a thin graphene layer to prevent oxidation. The [...] Read more.

We propose a surface plasmon resonance (SPR) sensor based on photonic crystal fiber (PCF) with selectively filled analyte channels. Silver is used as the plasmonic material to accurately detect the analytes and is coated with a thin graphene layer to prevent oxidation. The liquid-filled cores are placed near to the metallic channel for easy excitation of free electrons to produce surface plasmon waves (SPWs). Surface plasmons along the metal surface are excited with a leaky Gaussian-like core guided mode. Numerical investigations of the fiber’s properties and sensing performance are performed using the finite element method (FEM). The proposed sensor shows maximum amplitude sensitivity of 418 Refractive Index Units (RIU⁻¹) with resolution as high as 2.4 × 10⁻⁵ RIU. Using the wavelength interrogation method, a maximum refractive index (RI) sensitivity of 3000 nm/RIU in the sensing range of 1.46–1.49 is achieved. The proposed sensor is suitable for detecting various high RI chemicals, biochemical and organic chemical analytes. Additionally, the effects of fiber structural parameters on the properties of plasmonic excitation are investigated and optimized for sensing performance as well as reducing the sensor’s footprint. Full article

(This article belongs to the Special Issue Optical Sensors for Chemical, Biological and Industrial Applications)

► Show Figures

Figure 1

17 pages, 1688 KiB

Open AccessArticle

Design of a Novel Telerehabilitation System with a Force-Sensing Mechanism

by Songyuan Zhang, Shuxiang Guo, Baofeng Gao, Hideyuki Hirata and Hidenori Ishihara

Sensors 2015, 15(5), 11511-11527; https://doi.org/10.3390/s150511511 - 19 May 2015

Cited by 53 | Viewed by 7528

Abstract

Many stroke patients are expected to rehabilitate at home, which limits their access to proper rehabilitation equipment, treatment, or assessment by therapists. We have developed a novel telerehabilitation system that incorporates a human-upper-limb-like device and an exoskeleton device. The system is designed to [...] Read more.

Many stroke patients are expected to rehabilitate at home, which limits their access to proper rehabilitation equipment, treatment, or assessment by therapists. We have developed a novel telerehabilitation system that incorporates a human-upper-limb-like device and an exoskeleton device. The system is designed to provide the feeling of real therapist–patient contact via telerehabilitation. We applied the principle of a series elastic actuator to both the master and slave devices. On the master side, the therapist can operate the device in a rehabilitation center. When performing passive training, the master device can detect the therapist’s motion while controlling the deflection of elastic elements to near-zero, and the patient can receive the motion via the exoskeleton device. When performing active training, the design of the force-sensing mechanism in the master device can detect the assisting force added by the therapist. The force-sensing mechanism also allows force detection with an angle sensor. Patients’ safety is guaranteed by monitoring the motor’s current from the exoskeleton device. To compensate for any possible time delay or data loss, a torque-limiter mechanism was also designed in the exoskeleton device for patients’ safety. Finally, we successfully performed a system performance test for passive training with transmission control protocol/internet protocol communication. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

23 pages, 478 KiB

Open AccessArticle

Semi-Supervised Bayesian Classification of Materials with Impact-Echo Signals

by Jorge Igual, Addisson Salazar, Gonzalo Safont and Luis Vergara

Sensors 2015, 15(5), 11528-11550; https://doi.org/10.3390/s150511528 - 19 May 2015

Cited by 28 | Viewed by 5571

Abstract

The detection and identification of internal defects in a material require the use of some technology that translates the hidden interior damages into observable signals with different signature-defect correspondences. We apply impact-echo techniques for this purpose. The materials are classified according to their [...] Read more.

The detection and identification of internal defects in a material require the use of some technology that translates the hidden interior damages into observable signals with different signature-defect correspondences. We apply impact-echo techniques for this purpose. The materials are classified according to their defective status (homogeneous, one defect or multiple defects) and kind of defect (hole or crack, passing through or not). Every specimen is impacted by a hammer, and the spectrum of the propagated wave is recorded. This spectrum is the input data to a Bayesian classifier that is based on the modeling of the conditional probabilities with a mixture of Gaussians. The parameters of the Gaussian mixtures and the class probabilities are estimated using an extended expectation-maximization algorithm. The advantage of our proposal is that it is flexible, since it obtains good results for a wide range of models even under little supervision; e.g., it obtains a harmonic average of precision and recall value of 92.38% given only a 10% supervision ratio. We test the method with real specimens made of aluminum alloy. The results show that the algorithm works very well. This technique could be applied in many industrial problems, such as the optimization of the marble cutting process. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

24 pages, 9048 KiB

Open AccessArticle

Towards the Automatic Scanning of Indoors with Robots

by Antonio Adán, Blanca Quintana, Andres S. Vázquez, Alberto Olivares, Eduardo Parra and Samuel Prieto

Sensors 2015, 15(5), 11551-11574; https://doi.org/10.3390/s150511551 - 19 May 2015

Cited by 30 | Viewed by 8654

Abstract

This paper is framed in both 3D digitization and 3D data intelligent processing research fields. Our objective is focused on developing a set of techniques for the automatic creation of simple three-dimensional indoor models with mobile robots. The document presents the principal steps [...] Read more.

This paper is framed in both 3D digitization and 3D data intelligent processing research fields. Our objective is focused on developing a set of techniques for the automatic creation of simple three-dimensional indoor models with mobile robots. The document presents the principal steps of the process, the experimental setup and the results achieved. We distinguish between the stages concerning intelligent data acquisition and 3D data processing. This paper is focused on the first stage. We show how the mobile robot, which carries a 3D scanner, is able to, on the one hand, make decisions about the next best scanner position and, on the other hand, navigate autonomously in the scene with the help of the data collected from earlier scans. After this stage, millions of 3D data are converted into a simplified 3D indoor model. The robot imposes a stopping criterion when the whole point cloud covers the essential parts of the scene. This system has been tested under real conditions indoors with promising results. The future is addressed to extend the method in much more complex and larger scenarios. Full article

(This article belongs to the Special Issue Sensors for Indoor Mapping and Navigation)

► Show Figures

12 pages, 810 KiB

Open AccessArticle

A Wavelet-Based Approach to Fall Detection

by Luca Palmerini, Fabio Bagalà, Andrea Zanetti, Jochen Klenk, Clemens Becker and Angelo Cappello

Sensors 2015, 15(5), 11575-11586; https://doi.org/10.3390/s150511575 - 20 May 2015

Cited by 41 | Viewed by 8801

Abstract

Falls among older people are a widely documented public health problem. Automatic fall detection has recently gained huge importance because it could allow for the immediate communication of falls to medical assistance. The aim of this work is to present a novel wavelet-based [...] Read more.

Falls among older people are a widely documented public health problem. Automatic fall detection has recently gained huge importance because it could allow for the immediate communication of falls to medical assistance. The aim of this work is to present a novel wavelet-based approach to fall detection, focusing on the impact phase and using a dataset of real-world falls. Since recorded falls result in a non-stationary signal, a wavelet transform was chosen to examine fall patterns. The idea is to consider the average fall pattern as the “prototype fall”.In order to detect falls, every acceleration signal can be compared to this prototype through wavelet analysis. The similarity of the recorded signal with the prototype fall is a feature that can be used in order to determine the difference between falls and daily activities. The discriminative ability of this feature is evaluated on real-world data. It outperforms other features that are commonly used in fall detection studies, with an Area Under the Curve of 0.918. This result suggests that the proposed wavelet-based feature is promising and future studies could use this feature (in combination with others considering different fall phases) in order to improve the performance of fall detection algorithms. Full article

(This article belongs to the Collection Sensors for Globalized Healthy Living and Wellbeing)

► Show Figures

Figure 1

14 pages, 3266 KiB

Open AccessArticle

Mapping the Salinity Gradient in a Microfluidic Device with Schlieren Imaging

by Chen-li Sun, Shao-Tuan Chen and Po-Jen Hsiao

Sensors 2015, 15(5), 11587-11600; https://doi.org/10.3390/s150511587 - 20 May 2015

Cited by 4 | Viewed by 7444

Abstract

This work presents the use of the schlieren imaging to quantify the salinity gradients in a microfluidic device. By partially blocking the back focal plane of the objective lens, the schlieren microscope produces an image with patterns that correspond to spatial derivative of [...] Read more.

This work presents the use of the schlieren imaging to quantify the salinity gradients in a microfluidic device. By partially blocking the back focal plane of the objective lens, the schlieren microscope produces an image with patterns that correspond to spatial derivative of refractive index in the specimen. Since salinity variation leads to change in refractive index, the fluid mixing of an aqueous salt solution of a known concentration and water in a T-microchannel is used to establish the relation between salinity gradients and grayscale readouts. This relation is then employed to map the salinity gradients in the target microfluidic device from the grayscale readouts of the corresponding micro-schlieren image. For saline solution with salinity close to that of the seawater, the grayscale readouts vary linearly with the salinity gradient, and the regression line is independent of the flow condition and the salinity of the injected solution. It is shown that the schlieren technique is well suited to quantify the salinity gradients in microfluidic devices, for it provides a spatially resolved, non-invasive, full-field measurement. Full article

(This article belongs to the Special Issue Modeling, Testing and Reliability Issues in MEMS Engineering 2013)

► Show Figures

Figure 1

27 pages, 5237 KiB

Open AccessArticle

A Negative Index Metamaterial-Inspired UWB Antenna with an Integration of Complementary SRR and CLS Unit Cells for Microwave Imaging Sensor Applications

by Mohammad Tariqul Islam, Md. Moinul Islam, Md. Samsuzzaman, Mohammad Rashed Iqbal Faruque and Norbahiah Misran

Sensors 2015, 15(5), 11601-11627; https://doi.org/10.3390/s150511601 - 20 May 2015

Cited by 81 | Viewed by 10852

Abstract

This paper presents a negative index metamaterial incorporated UWB antenna with an integration of complementary SRR (split-ring resonator) and CLS (capacitive loaded strip) unit cells for microwave imaging sensor applications. This metamaterial UWB antenna sensor consists of four unit cells along one axis, [...] Read more.

This paper presents a negative index metamaterial incorporated UWB antenna with an integration of complementary SRR (split-ring resonator) and CLS (capacitive loaded strip) unit cells for microwave imaging sensor applications. This metamaterial UWB antenna sensor consists of four unit cells along one axis, where each unit cell incorporates a complementary SRR and CLS pair. This integration enables a design layout that allows both a negative value of permittivity and a negative value of permeability simultaneous, resulting in a durable negative index to enhance the antenna sensor performance for microwave imaging sensor applications. The proposed MTM antenna sensor was designed and fabricated on an FR4 substrate having a thickness of 1.6 mm and a dielectric constant of 4.6. The electrical dimensions of this antenna sensor are 0.20 λ × 0.29 λ at a lower frequency of 3.1 GHz. This antenna sensor achieves a 131.5% bandwidth (VSWR < 2) covering the frequency bands from 3.1 GHz to more than 15 GHz with a maximum gain of 6.57 dBi. High fidelity factor and gain, smooth surface-current distribution and nearly omni-directional radiation patterns with low cross-polarization confirm that the proposed negative index UWB antenna is a promising entrant in the field of microwave imaging sensors. Full article

(This article belongs to the Special Issue Metamaterial-Inspired Sensors)

► Show Figures

Figure 1

25 pages, 2790 KiB

Open AccessArticle

An Energy-Efficient Transmission Scheme for Real-Time Data in Wireless Sensor Networks

by Jin-Woo Kim, José Ramón Ramos Barrado and Dong-Keun Jeon

Sensors 2015, 15(5), 11628-11652; https://doi.org/10.3390/s150511628 - 20 May 2015

Cited by 14 | Viewed by 7726

Abstract

The Internet of things (IoT) is a novel paradigm where all things or objects in daily life can communicate with other devices and provide services over the Internet. Things or objects need identifying, sensing, networking and processing capabilities to make the IoT paradigm [...] Read more.

The Internet of things (IoT) is a novel paradigm where all things or objects in daily life can communicate with other devices and provide services over the Internet. Things or objects need identifying, sensing, networking and processing capabilities to make the IoT paradigm a reality. The IEEE 802.15.4 standard is one of the main communication protocols proposed for the IoT. The IEEE 802.15.4 standard provides the guaranteed time slot (GTS) mechanism that supports the quality of service (QoS) for the real-time data transmission. In spite of some QoS features in IEEE 802.15.4 standard, the problem of end-to-end delay still remains. In order to solve this problem, we propose a cooperative medium access scheme (MAC) protocol for real-time data transmission. We also evaluate the performance of the proposed scheme through simulation. The simulation results demonstrate that the proposed scheme can improve the network performance. Full article

(This article belongs to the Special Issue Towards Energy-Neutral WSN Architectures: Energy Harvesting and Other Enabling Technologies)

► Show Figures

Figure 1

12 pages, 2004 KiB

Open AccessArticle

Medically Relevant Assays with a Simple Smartphone and Tablet Based Fluorescence Detection System

by Piotr Wargocki, Wei Deng, Ayad G. Anwer and Ewa M. Goldys

Sensors 2015, 15(5), 11653-11664; https://doi.org/10.3390/s150511653 - 20 May 2015

Cited by 23 | Viewed by 17156

Abstract

Cell phones and smart phones can be reconfigured as biomedical sensor devices but this requires specialized add-ons. In this paper we present a simple cell phone-based portable bioassay platform, which can be used with fluorescent assays in solution. The system consists of a [...] Read more.

Cell phones and smart phones can be reconfigured as biomedical sensor devices but this requires specialized add-ons. In this paper we present a simple cell phone-based portable bioassay platform, which can be used with fluorescent assays in solution. The system consists of a tablet, a polarizer, a smart phone (camera) and a box that provides dark readout conditions. The assay in a well plate is placed on the tablet screen acting as an excitation source. A polarizer on top of the well plate separates excitation light from assay fluorescence emission enabling assay readout with a smartphone camera. The assay result is obtained by analysing the intensity of image pixels in an appropriate colour channel. With this device we carried out two assays, for collagenase and trypsin using fluorescein as the detected fluorophore. The results of collagenase assay with the lowest measured concentration of 3.75 µg/mL and 0.938 µg in total in the sample were comparable to those obtained by a microplate reader. The lowest measured amount of trypsin was 930 pg, which is comparable to the low detection limit of 400 pg for this assay obtained in a microplate reader. The device is sensitive enough to be used in point-of-care medical diagnostics of clinically relevant conditions, including arthritis, cystic fibrosis and acute pancreatitis. Full article

(This article belongs to the Special Issue Smartphone-Based Sensors for Non-Invasive Physiological Monitoring)

► Show Figures

Figure 1

20 pages, 3427 KiB

Open AccessArticle

Classifying Sources Influencing Indoor Air Quality (IAQ) Using Artificial Neural Network (ANN)

by Shaharil Mad Saad, Allan Melvin Andrew, Ali Yeon Md Shakaff, Abdul Rahman Mohd Saad, Azman Muhamad Yusof @ Kamarudin and Ammar Zakaria

Sensors 2015, 15(5), 11665-11684; https://doi.org/10.3390/s150511665 - 20 May 2015

Cited by 61 | Viewed by 11879

Abstract

Monitoring indoor air quality (IAQ) is deemed important nowadays. A sophisticated IAQ monitoring system which could classify the source influencing the IAQ is definitely going to be very helpful to the users. Therefore, in this paper, an IAQ monitoring system has been proposed [...] Read more.

Monitoring indoor air quality (IAQ) is deemed important nowadays. A sophisticated IAQ monitoring system which could classify the source influencing the IAQ is definitely going to be very helpful to the users. Therefore, in this paper, an IAQ monitoring system has been proposed with a newly added feature which enables the system to identify the sources influencing the level of IAQ. In order to achieve this, the data collected has been trained with artificial neural network or ANN—a proven method for pattern recognition. Basically, the proposed system consists of sensor module cloud (SMC), base station and service-oriented client. The SMC contain collections of sensor modules that measure the air quality data and transmit the captured data to base station through wireless network. The IAQ monitoring system is also equipped with IAQ Index and thermal comfort index which could tell the users about the room’s conditions. The results showed that the system is able to measure the level of air quality and successfully classify the sources influencing IAQ in various environments like ambient air, chemical presence, fragrance presence, foods and beverages and human activity. Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

Figure 1

16 pages, 1900 KiB

Open AccessArticle

Optimal Self-Tuning PID Controller Based on Low Power Consumption for a Server Fan Cooling System

by Chengming Lee and Rongshun Chen

Sensors 2015, 15(5), 11685-11700; https://doi.org/10.3390/s150511685 - 20 May 2015

Cited by 32 | Viewed by 11391

Abstract

Recently, saving the cooling power in servers by controlling the fan speed has attracted considerable attention because of the increasing demand for high-density servers. This paper presents an optimal self-tuning proportional-integral-derivative (PID) controller, combining a PID neural network (PIDNN) with fan-power-based optimization in [...] Read more.

Recently, saving the cooling power in servers by controlling the fan speed has attracted considerable attention because of the increasing demand for high-density servers. This paper presents an optimal self-tuning proportional-integral-derivative (PID) controller, combining a PID neural network (PIDNN) with fan-power-based optimization in the transient-state temperature response in the time domain, for a server fan cooling system. Because the thermal model of the cooling system is nonlinear and complex, a server mockup system simulating a 1U rack server was constructed and a fan power model was created using a third-order nonlinear curve fit to determine the cooling power consumption by the fan speed control. PIDNN with a time domain criterion is used to tune all online and optimized PID gains. The proposed controller was validated through experiments of step response when the server operated from the low to high power state. The results show that up to 14% of a server’s fan cooling power can be saved if the fan control permits a slight temperature response overshoot in the electronic components, which may provide a time-saving strategy for tuning the PID controller to control the server fan speed during low fan power consumption. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

24 pages, 1482 KiB

Open AccessArticle

Entropy-Based TOA Estimation and SVM-Based Ranging Error Mitigation in UWB Ranging Systems

by Zhendong Yin, Kai Cui, Zhilu Wu and Liang Yin

Sensors 2015, 15(5), 11701-11724; https://doi.org/10.3390/s150511701 - 21 May 2015

Cited by 30 | Viewed by 6815

Abstract

The major challenges for Ultra-wide Band (UWB) indoor ranging systems are the dense multipath and non-line-of-sight (NLOS) problems of the indoor environment. To precisely estimate the time of arrival (TOA) of the first path (FP) in such a poor environment, a novel approach [...] Read more.

The major challenges for Ultra-wide Band (UWB) indoor ranging systems are the dense multipath and non-line-of-sight (NLOS) problems of the indoor environment. To precisely estimate the time of arrival (TOA) of the first path (FP) in such a poor environment, a novel approach of entropy-based TOA estimation and support vector machine (SVM) regression-based ranging error mitigation is proposed in this paper. The proposed method can estimate the TOA precisely by measuring the randomness of the received signals and mitigate the ranging error without the recognition of the channel conditions. The entropy is used to measure the randomness of the received signals and the FP can be determined by the decision of the sample which is followed by a great entropy decrease. The SVM regression is employed to perform the ranging-error mitigation by the modeling of the regressor between the characteristics of received signals and the ranging error. The presented numerical simulation results show that the proposed approach achieves significant performance improvements in the CM1 to CM4 channels of the IEEE 802.15.4a standard, as compared to conventional approaches. Full article

(This article belongs to the Special Issue Sensors for Indoor Mapping and Navigation)

► Show Figures

Figure 1

16 pages, 1286 KiB

Open AccessArticle

Evaluation of Three State-of-the-Art Classifiers for Recognition of Activities of Daily Living from Smart Home Ambient Data

by Tobias Nef, Prabitha Urwyler, Marcel Büchler, Ioannis Tarnanas, Reto Stucki, Dario Cazzoli, René Müri and Urs Mosimann

Sensors 2015, 15(5), 11725-11740; https://doi.org/10.3390/s150511725 - 21 May 2015

Cited by 79 | Viewed by 10165

Abstract

Smart homes for the aging population have recently started attracting the attention of the research community. The “health state” of smart homes is comprised of many different levels; starting with the physical health of citizens, it also includes longer-term health norms and outcomes, [...] Read more.

Smart homes for the aging population have recently started attracting the attention of the research community. The “health state” of smart homes is comprised of many different levels; starting with the physical health of citizens, it also includes longer-term health norms and outcomes, as well as the arena of positive behavior changes. One of the problems of interest is to monitor the activities of daily living (ADL) of the elderly, aiming at their protection and well-being. For this purpose, we installed passive infrared (PIR) sensors to detect motion in a specific area inside a smart apartment and used them to collect a set of ADL. In a novel approach, we describe a technology that allows the ground truth collected in one smart home to train activity recognition systems for other smart homes. We asked the users to label all instances of all ADL only once and subsequently applied data mining techniques to cluster in-home sensor firings. Each cluster would therefore represent the instances of the same activity. Once the clusters were associated to their corresponding activities, our system was able to recognize future activities. To improve the activity recognition accuracy, our system preprocessed raw sensor data by identifying overlapping activities. To evaluate the recognition performance from a 200-day dataset, we implemented three different active learning classification algorithms and compared their performance: naive Bayesian (NB), support vector machine (SVM) and random forest (RF). Based on our results, the RF classifier recognized activities with an average specificity of 96.53%, a sensitivity of 68.49%, a precision of 74.41% and an F-measure of 71.33%, outperforming both the NB and SVM classifiers. Further clustering markedly improved the results of the RF classifier. An activity recognition system based on PIR sensors in conjunction with a clustering classification approach was able to detect ADL from datasets collected from different homes. Thus, our PIR-based smart home technology could improve care and provide valuable information to better understand the functioning of our societies, as well as to inform both individual and collective action in a smart city scenario. Full article

(This article belongs to the Special Issue Sensors and Smart Cities)

► Show Figures

Figure 1

28 pages, 4424 KiB

Open AccessArticle

An Ultra-Low Power Wireless Sensor Network for Bicycle Torque Performance Measurements

by Sadik K. Gharghan, Rosdiadee Nordin and Mahamod Ismail

Sensors 2015, 15(5), 11741-11768; https://doi.org/10.3390/s150511741 - 21 May 2015

Cited by 25 | Viewed by 10342

Abstract

In this paper, we propose an energy-efficient transmission technique known as the sleep/wake algorithm for a bicycle torque sensor node. This paper aims to highlight the trade-off between energy efficiency and the communication range between the cyclist and coach. Two experiments were conducted. [...] Read more.

In this paper, we propose an energy-efficient transmission technique known as the sleep/wake algorithm for a bicycle torque sensor node. This paper aims to highlight the trade-off between energy efficiency and the communication range between the cyclist and coach. Two experiments were conducted. The first experiment utilised the Zigbee protocol (XBee S2), and the second experiment used the Advanced and Adaptive Network Technology (ANT) protocol based on the Nordic nRF24L01 radio transceiver chip. The current consumption of ANT was measured, simulated and compared with a torque sensor node that uses the XBee S2 protocol. In addition, an analytical model was derived to correlate the sensor node average current consumption with a crank arm cadence. The sensor node achieved 98% power savings for ANT relative to ZigBee when they were compared alone, and the power savings amounted to 30% when all components of the sensor node are considered. The achievable communication range was 65 and 50 m for ZigBee and ANT, respectively, during measurement on an outdoor cycling track (i.e., velodrome). The conclusions indicate that the ANT protocol is more suitable for use in a torque sensor node when power consumption is a crucial demand, whereas the ZigBee protocol is more convenient in ensuring data communication between cyclist and coach. Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

Figure 1

18 pages, 2054 KiB

Open AccessArticle

Building Keypoint Mappings on Multispectral Images by a Cascade of Classifiers with a Resurrection Mechanism

by Yong Li, Jing Jing, Hongbin Jin and Wei Qiao

Sensors 2015, 15(5), 11769-11786; https://doi.org/10.3390/s150511769 - 21 May 2015

Cited by 1 | Viewed by 5120

Abstract

Inspired by the boosting technique for detecting objects, this paper proposes a cascade structure with a resurrection mechanism to establish keypoint mappings on multispectral images. The cascade structure is composed of four steps by utilizing best bin first (BBF), color and intensity distribution [...] Read more.

Inspired by the boosting technique for detecting objects, this paper proposes a cascade structure with a resurrection mechanism to establish keypoint mappings on multispectral images. The cascade structure is composed of four steps by utilizing best bin first (BBF), color and intensity distribution of segment (CIDS), global information and the RANSAC process to remove outlier keypoint matchings. Initial keypoint mappings are built with the descriptors associated with keypoints; then, at each step, only a small number of keypoint mappings of a high confidence are classified to be incorrect. The unclassified keypoint mappings will be passed on to subsequent steps for determining whether they are correct. Due to the drawback of a classification rule, some correct keypoint mappings may be misclassified as incorrect at a step. Observing this, we design a resurrection mechanism, so that they will be reconsidered and evaluated by the rules utilized in subsequent steps. Experimental results show that the proposed cascade structure combined with the resurrection mechanism can effectively build more reliable keypoint mappings on multispectral images than existing methods. Full article

(This article belongs to the Section Remote Sensors)

► Show Figures

18 pages, 3933 KiB

Open AccessArticle

Modeling of Acoustic Emission Signal Propagation in Waveguides

by Andreea-Manuela Zelenyak, Marvin A. Hamstad and Markus G. R. Sause

Sensors 2015, 15(5), 11805-11822; https://doi.org/10.3390/s150511805 - 21 May 2015

Cited by 59 | Viewed by 10360

Abstract

Acoustic emission (AE) testing is a widely used nondestructive testing (NDT) method to investigate material failure. When environmental conditions are harmful for the operation of the sensors, waveguides are typically mounted in between the inspected structure and the sensor. Such waveguides can be [...] Read more.

Acoustic emission (AE) testing is a widely used nondestructive testing (NDT) method to investigate material failure. When environmental conditions are harmful for the operation of the sensors, waveguides are typically mounted in between the inspected structure and the sensor. Such waveguides can be built from different materials or have different designs in accordance with the experimental needs. All these variations can cause changes in the acoustic emission signals in terms of modal conversion, additional attenuation or shift in frequency content. A finite element method (FEM) was used to model acoustic emission signal propagation in an aluminum plate with an attached waveguide and was validated against experimental data. The geometry of the waveguide is systematically changed by varying the radius and height to investigate the influence on the detected signals. Different waveguide materials were implemented and change of material properties as function of temperature were taken into account. Development of the option of modeling different waveguide options replaces the time consuming and expensive trial and error alternative of experiments. Thus, the aim of this research has important implications for those who use waveguides for AE testing. Full article

(This article belongs to the Special Issue Acoustic Waveguide Sensors)

► Show Figures

Figure 1

13 pages, 2164 KiB

Open AccessArticle

Highly Stable Liquid Metal-Based Pressure Sensor Integrated with a Microfluidic Channel

by Taekeon Jung and Sung Yang

Sensors 2015, 15(5), 11823-11835; https://doi.org/10.3390/s150511823 - 21 May 2015

Cited by 107 | Viewed by 14220

Abstract

Pressure measurement is considered one of the key parameters in microfluidic systems. It has been widely used in various fields, such as in biology and biomedical fields. The electrical measurement method is the most widely investigated; however, it is unsuitable for microfluidic systems [...] Read more.

Pressure measurement is considered one of the key parameters in microfluidic systems. It has been widely used in various fields, such as in biology and biomedical fields. The electrical measurement method is the most widely investigated; however, it is unsuitable for microfluidic systems because of a complicated fabrication process and difficult integration. Moreover, it is generally damaged by large deflection. This paper proposes a thin-film-based pressure sensor that is free from these limitations, using a liquid metal called galinstan. The proposed pressure sensor is easily integrated into a microfluidic system using soft lithography because galinstan exists in a liquid phase at room temperature. We investigated the characteristics of the proposed pressure sensor by calibrating for a pressure range from 0 to 230 kPa (R² > 0.98) using deionized water. Furthermore, the viscosity of various fluid samples was measured for a shear-rate range of 30–1000 s⁻¹. The results of Newtonian and non-Newtonian fluids were evaluated using a commercial viscometer and normalized difference was found to be less than 5.1% and 7.0%, respectively. The galinstan-based pressure sensor can be used in various microfluidic systems for long-term monitoring with high linearity, repeatability, and long-term stability. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

18 pages, 4998 KiB

Open AccessArticle

Electronic Properties of DNA-Based Schottky Barrier Diodes in Response to Alpha Particles

by Hassan Maktuff Jaber Al-Ta'ii, Vengadesh Periasamy and Yusoff Mohd Amin

Sensors 2015, 15(5), 11836-11853; https://doi.org/10.3390/s150511836 - 21 May 2015

Cited by 14 | Viewed by 7388

Abstract

Detection of nuclear radiation such as alpha particles has become an important field of research in recent history due to nuclear threats and accidents. In this context; deoxyribonucleic acid (DNA) acting as an organic semiconducting material could be utilized in a metal/semiconductor Schottky [...] Read more.

Detection of nuclear radiation such as alpha particles has become an important field of research in recent history due to nuclear threats and accidents. In this context; deoxyribonucleic acid (DNA) acting as an organic semiconducting material could be utilized in a metal/semiconductor Schottky junction for detecting alpha particles. In this work we demonstrate for the first time the effect of alpha irradiation on an Al/DNA/p-Si/Al Schottky diode by investigating its current-voltage characteristics. The diodes were exposed for different periods (0–20 min) of irradiation. Various diode parameters such as ideality factor, barrier height, series resistance, Richardson constant and saturation current were then determined using conventional, Cheung and Cheung’s and Norde methods. Generally, ideality factor or n values were observed to be greater than unity, which indicates the influence of some other current transport mechanism besides thermionic processes. Results indicated ideality factor variation between 9.97 and 9.57 for irradiation times between the ranges 0 to 20 min. Increase in the series resistance with increase in irradiation time was also observed when calculated using conventional and Cheung and Cheung’s methods. These responses demonstrate that changes in the electrical characteristics of the metal-semiconductor-metal diode could be further utilized as sensing elements to detect alpha particles. Full article

(This article belongs to the Special Issue Next-Generation Nucleic Acid Sensors)

► Show Figures

Figure 1

19 pages, 1168 KiB

Open AccessArticle

Branch-Based Centralized Data Collection for Smart Grids Using Wireless Sensor Networks

by Kwangsoo Kim and Seong-il Jin

Sensors 2015, 15(5), 11854-11872; https://doi.org/10.3390/s150511854 - 21 May 2015

Cited by 18 | Viewed by 6311

Abstract

A smart grid is one of the most important applications in smart cities. In a smart grid, a smart meter acts as a sensor node in a sensor network, and a central device collects power usage from every smart meter. This paper focuses [...] Read more.

A smart grid is one of the most important applications in smart cities. In a smart grid, a smart meter acts as a sensor node in a sensor network, and a central device collects power usage from every smart meter. This paper focuses on a centralized data collection problem of how to collect every power usage from every meter without collisions in an environment in which the time synchronization among smart meters is not guaranteed. To solve the problem, we divide a tree that a sensor network constructs into several branches. A conflict-free query schedule is generated based on the branches. Each power usage is collected according to the schedule. The proposed method has important features: shortening query processing time and avoiding collisions between a query and query responses. We evaluate this method using the ns-2 simulator. The experimental results show that this method can achieve both collision avoidance and fast query processing at the same time. The success rate of data collection at a sink node executing this method is 100%. Its running time is about 35 percent faster than that of the round-robin method, and its memory size is reduced to about 10% of that of the depth-first search method. Full article

(This article belongs to the Special Issue Sensors and Smart Cities)

► Show Figures

16 pages, 1740 KiB

Open AccessArticle

Surface Acoustic Wave (SAW) Resonators for Monitoring Conditioning Film Formation

by Siegfried Hohmann, Svea Kögel, Yvonne Brunner, Barbara Schmieg, Christina Ewald, Frank Kirschhöfer, Gerald Brenner-Weiß and Kerstin Länge

Sensors 2015, 15(5), 11873-11888; https://doi.org/10.3390/s150511873 - 21 May 2015

Cited by 23 | Viewed by 9641

Abstract

We propose surface acoustic wave (SAW) resonators as a complementary tool for conditioning film monitoring. Conditioning films are formed by adsorption of inorganic and organic substances on a substrate the moment this substrate comes into contact with a liquid phase. In the case [...] Read more.

We propose surface acoustic wave (SAW) resonators as a complementary tool for conditioning film monitoring. Conditioning films are formed by adsorption of inorganic and organic substances on a substrate the moment this substrate comes into contact with a liquid phase. In the case of implant insertion, for instance, initial protein adsorption is required to start wound healing, but it will also trigger immune reactions leading to inflammatory responses. The control of the initial protein adsorption would allow to promote the healing process and to suppress adverse immune reactions. Methods to investigate these adsorption processes are available, but it remains difficult to translate measurement results into actual protein binding events. Biosensor transducers allow user-friendly investigation of protein adsorption on different surfaces. The combination of several transduction principles leads to complementary results, allowing a more comprehensive characterization of the adsorbing layer. We introduce SAW resonators as a novel complementary tool for time-resolved conditioning film monitoring. SAW resonators were coated with polymers. The adsorption of the plasma proteins human serum albumin (HSA) and fibrinogen onto the polymer-coated surfaces were monitored. Frequency results were compared with quartz crystal microbalance (QCM) sensor measurements, which confirmed the suitability of the SAW resonators for this application. Full article

(This article belongs to the Special Issue Acoustic Waveguide Sensors)

► Show Figures

Graphical abstract

25 pages, 1510 KiB

Open AccessArticle

A Lightweight White-Box Symmetric Encryption Algorithm against Node Capture for WSNs

by Yang Shi, Wujing Wei and Zongjian He

Sensors 2015, 15(5), 11928-11952; https://doi.org/10.3390/s150511928 - 21 May 2015

Cited by 42 | Viewed by 7092

Abstract

Wireless Sensor Networks (WSNs) are often deployed in hostile environments and, thus, nodes can be potentially captured by an adversary. This is a typical white-box attack context, i.e., the adversary may have total visibility of the implementation of the build-in cryptosystem and [...] Read more.

Wireless Sensor Networks (WSNs) are often deployed in hostile environments and, thus, nodes can be potentially captured by an adversary. This is a typical white-box attack context, i.e., the adversary may have total visibility of the implementation of the build-in cryptosystem and full control over its execution platform. Handling white-box attacks in a WSN scenario is a challenging task. Existing encryption algorithms for white-box attack contexts require large memory footprint and, hence, are not applicable for wireless sensor networks scenarios. As a countermeasure against the threat in this context, in this paper, we propose a class of lightweight secure implementations of the symmetric encryption algorithm SMS4. The basic idea of our approach is to merge several steps of the round function of SMS4 into table lookups, blended by randomly generated mixing bijections. Therefore, the size of the implementations are significantly reduced while keeping the same security efficiency. The security and efficiency of the proposed solutions are theoretically analyzed. Evaluation shows our solutions satisfy the requirement of sensor nodes in terms of limited memory size and low computational costs. Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

Figure 1

19 pages, 1212 KiB

Open AccessArticle

User Activity Recognition in Smart Homes Using Pattern Clustering Applied to Temporal ANN Algorithm

by Serge Thomas Mickala Bourobou and Younghwan Yoo

Sensors 2015, 15(5), 11953-11971; https://doi.org/10.3390/s150511953 - 21 May 2015

Cited by 107 | Viewed by 12737

Abstract

This paper discusses the possibility of recognizing and predicting user activities in the IoT (Internet of Things) based smart environment. The activity recognition is usually done through two steps: activity pattern clustering and activity type decision. Although many related works have been suggested, [...] Read more.

This paper discusses the possibility of recognizing and predicting user activities in the IoT (Internet of Things) based smart environment. The activity recognition is usually done through two steps: activity pattern clustering and activity type decision. Although many related works have been suggested, they had some limited performance because they focused only on one part between the two steps. This paper tries to find the best combination of a pattern clustering method and an activity decision algorithm among various existing works. For the first step, in order to classify so varied and complex user activities, we use a relevant and efficient unsupervised learning method called the K-pattern clustering algorithm. In the second step, the training of smart environment for recognizing and predicting user activities inside his/her personal space is done by utilizing the artificial neural network based on the Allen’s temporal relations. The experimental results show that our combined method provides the higher recognition accuracy for various activities, as compared with other data mining classification algorithms. Furthermore, it is more appropriate for a dynamic environment like an IoT based smart home. Full article

(This article belongs to the Special Issue Sensors and Smart Cities)

► Show Figures

Figure 1

16 pages, 2462 KiB

Open AccessArticle

A Highly Sensitive Porous Silicon (P-Si)-Based Human Kallikrein 2 (hK2) Immunoassay Platform toward Accurate Diagnosis of Prostate Cancer

by Sang Wook Lee, Kazuo Hosokawa, Soyoun Kim, Ok Chan Jeong, Hans Lilja, Thomas Laurell and Mizuo Maeda

Sensors 2015, 15(5), 11972-11987; https://doi.org/10.3390/s150511972 - 22 May 2015

Cited by 11 | Viewed by 7521

Abstract

Levels of total human kallikrein 2 (hK2), a protein involved the pathology of prostate cancer (PCa), could be used as a biomarker to aid in the diagnosis of this disease. In this study, we report on a porous silicon antibody immunoassay platform for [...] Read more.

Levels of total human kallikrein 2 (hK2), a protein involved the pathology of prostate cancer (PCa), could be used as a biomarker to aid in the diagnosis of this disease. In this study, we report on a porous silicon antibody immunoassay platform for the detection of serum levels of total hK2. The surface of porous silicon has a 3-dimensional macro- and nanoporous structure, which offers a large binding capacity for capturing probe molecules. The tailored pore size of the porous silicon also allows efficient immobilization of antibodies by surface adsorption, and does not require chemical immobilization. Monoclonal hK2 capture antibody (6B7) was dispensed onto P-Si chip using a piezoelectric dispenser. In total 13 × 13 arrays (169 spots) were spotted on the chip with its single spot volume of 300 pL. For an optimization of capture antibody condition, we firstly performed an immunoassay of the P-Si microarray under a titration series of hK2 in pure buffer (PBS) at three different antibody densities (75, 100 and 145 µg/mL). The best performance of the microarray platform was seen at 100 µg/mL of the capture antibody concentration (LOD was 100 fg/mL). The platform then was subsequently evaluated for a titration series of serum-spiked hK2 samples. The developed platform utilizes only 15 µL of serum per test and the total assay time is about 3 h, including immobilization of the capture antibody. The detection limit of the hK2 assay was 100 fg/mL in PBS buffer and 1 pg/mL in serum with a dynamic range of 10⁶ (10⁻⁴ to 10² ng/mL). Full article

(This article belongs to the Special Issue Immunosensors 2014)

► Show Figures

Figure 1

12 pages, 1898 KiB

Open AccessArticle

Gated Silicon Drift Detector Fabricated from a Low-Cost Silicon Wafer

by Hideharu Matsuura, Shungo Sakurai, Yuya Oda, Shinya Fukushima, Shohei Ishikawa, Akinobu Takeshita and Atsuki Hidaka

Sensors 2015, 15(5), 12022-12033; https://doi.org/10.3390/s150512022 - 22 May 2015

Cited by 4 | Viewed by 7517

Abstract

Inexpensive high-resolution silicon (Si) X-ray detectors are required for on-site surveys of traces of hazardous elements in food and soil by measuring the energies and counts of X-ray fluorescence photons radially emitted from these elements. Gated silicon drift detectors (GSDDs) are much cheaper [...] Read more.

Inexpensive high-resolution silicon (Si) X-ray detectors are required for on-site surveys of traces of hazardous elements in food and soil by measuring the energies and counts of X-ray fluorescence photons radially emitted from these elements. Gated silicon drift detectors (GSDDs) are much cheaper to fabricate than commercial silicon drift detectors (SDDs). However, previous GSDDs were fabricated from \(10\)-k\(\Omega \cdot\)cm Si wafers, which are more expensive than \(2\)-k\(\Omega \cdot\)cm Si wafers used in commercial SDDs. To fabricate cheaper portable X-ray fluorescence instruments, we investigate GSDDs formed from \(2\)-k\(\Omega \cdot\)cm Si wafers. The thicknesses of commercial SDDs are up to \(0.5\) mm, which can detect photons with energies up to \(27\) keV, whereas we describe GSDDs that can detect photons with energies of up to \(35\) keV. We simulate the electric potential distributions in GSDDs with Si thicknesses of \(0.5\) and \(1\) mm at a single high reverse bias. GSDDs with one gate pattern using any resistivity Si wafer can work well for changing the reverse bias that is inversely proportional to the resistivity of the Si wafer. Full article

(This article belongs to the Special Issue State-of-the-Art Sensors Technology in Japan 2015)

► Show Figures

19 pages, 9047 KiB

Open AccessArticle

Highly Sensitive Bacteria Quantification Using Immunomagnetic Separation and Electrochemical Detection of Guanine-Labeled Secondary Beads

by Harikrishnan Jayamohan, Bruce K. Gale, Bj Minson, Christopher J. Lambert, Neil Gordon and Himanshu J. Sant

Sensors 2015, 15(5), 12034-12052; https://doi.org/10.3390/s150512034 - 22 May 2015

Cited by 50 | Viewed by 11048

Abstract

In this paper, we report the ultra-sensitive indirect electrochemical detection of E. coli O157:H7 using antibody functionalized primary (magnetic) beads for capture and polyguanine (polyG) oligonucleotide functionalized secondary (polystyrene) beads as an electrochemical tag. Vacuum filtration in combination with E. coli O157:H7 specific [...] Read more.

In this paper, we report the ultra-sensitive indirect electrochemical detection of E. coli O157:H7 using antibody functionalized primary (magnetic) beads for capture and polyguanine (polyG) oligonucleotide functionalized secondary (polystyrene) beads as an electrochemical tag. Vacuum filtration in combination with E. coli O157:H7 specific antibody modified magnetic beads were used for extraction of E. coli O157:H7 from 100 mL samples. The magnetic bead conjugated E. coli O157:H7 cells were then attached to polyG functionalized secondary beads to form a sandwich complex (magnetic bead/E. coli secondary bead). While the use of magnetic beads for immuno-based capture is well characterized, the use of oligonucleotide functionalized secondary beads helps combine amplification and potential multiplexing into the system. The antibody functionalized secondary beads can be easily modified with a different antibody to detect other pathogens from the same sample and enable potential multiplexing. The polyGs on the secondary beads enable signal amplification up to 10\(^{8}\) guanine tags per secondary bead (\(7.5\times10^{6}\) biotin-FITC per secondary bead, 20 guanines per oligonucleotide) bound to the target (E. coli). A single-stranded DNA probe functionalized reduced graphene oxide modified glassy carbon electrode was used to bind the polyGs on the secondary beads. Fluorescent imaging was performed to confirm the hybridization of the complex to the electrode surface. Differential pulse voltammetry (DPV) was used to quantify the amount of polyG involved in the hybridization event with tris(2,2'-bipyridine)ruthenium(II) (Ru(bpy)\(_{3}^{2+}\)) as the mediator. The amount of polyG signal can be correlated to the amount of E. coli O157:H7 in the sample. The method was able to detect concentrations of E. coli O157:H7 down to 3 CFU/100 mL, which is 67 times lower than the most sensitive technique reported in literature. The signal to noise ratio for this work was 3. We also demonstrate the use of the protocol for detection of E. coli O157:H7 seeded in waste water effluent samples. Full article

(This article belongs to the Special Issue Biosensors for Pathogen Detection)

► Show Figures

27 pages, 2019 KiB

Open AccessArticle

Multisensor Super Resolution Using Directionally-Adaptive Regularization for UAV Images

by Wonseok Kang, Soohwan Yu, Seungyong Ko and Joonki Paik

Sensors 2015, 15(5), 12053-12079; https://doi.org/10.3390/s150512053 - 22 May 2015

Cited by 10 | Viewed by 7552

Abstract

In various unmanned aerial vehicle (UAV) imaging applications, the multisensor super-resolution (SR) technique has become a chronic problem and attracted increasing attention. Multisensor SR algorithms utilize multispectral low-resolution (LR) images to make a higher resolution (HR) image to improve the performance of the [...] Read more.

In various unmanned aerial vehicle (UAV) imaging applications, the multisensor super-resolution (SR) technique has become a chronic problem and attracted increasing attention. Multisensor SR algorithms utilize multispectral low-resolution (LR) images to make a higher resolution (HR) image to improve the performance of the UAV imaging system. The primary objective of the paper is to develop a multisensor SR method based on the existing multispectral imaging framework instead of using additional sensors. In order to restore image details without noise amplification or unnatural post-processing artifacts, this paper presents an improved regularized SR algorithm by combining the directionally-adaptive constraints and multiscale non-local means (NLM) filter. As a result, the proposed method can overcome the physical limitation of multispectral sensors by estimating the color HR image from a set of multispectral LR images using intensity-hue-saturation (IHS) image fusion. Experimental results show that the proposed method provides better SR results than existing state-of-the-art SR methods in the sense of objective measures. Full article

(This article belongs to the Special Issue UAV Sensors for Environmental Monitoring)

► Show Figures

12 pages, 1344 KiB

Open AccessArticle

Iterative Precise Conductivity Measurement with IDEs

by Jaromír Hubálek

Sensors 2015, 15(5), 12080-12091; https://doi.org/10.3390/s150512080 - 22 May 2015

Cited by 8 | Viewed by 7485

Abstract

The paper presents a new approach in the field of precise electrolytic conductivity measurements with planar thin- and thick-film electrodes. This novel measuring method was developed for measurement with comb-like electrodes called interdigitated electrodes (IDEs). Correction characteristics over a wide range of specific [...] Read more.

The paper presents a new approach in the field of precise electrolytic conductivity measurements with planar thin- and thick-film electrodes. This novel measuring method was developed for measurement with comb-like electrodes called interdigitated electrodes (IDEs). Correction characteristics over a wide range of specific conductivities were determined from an interface impedance characterization of the thick-film IDEs. The local maximum of the capacitive part of the interface impedance is used for corrections to get linear responses. The measuring frequency was determined at a wide range of measured conductivity. An iteration mode of measurements was suggested to precisely measure the conductivity at the right frequency in order to achieve a highly accurate response. The method takes precise conductivity measurements in concentration ranges from 10⁻⁶ to 1 M without electrode cell replacement. Full article

(This article belongs to the Special Issue Selected Papers from XIV. Workshop of Physical Chemists and Electrochemists)

► Show Figures

Graphical abstract

11 pages, 3785 KiB

Open AccessArticle

LED-Absorption-QEPAS Sensor for Biogas Plants

by Michael Köhring, Stefan Böttger, Ulrike Willer and Wolfgang Schade

Sensors 2015, 15(5), 12092-12102; https://doi.org/10.3390/s150512092 - 22 May 2015

Cited by 45 | Viewed by 9594

Abstract

A new sensor for methane and carbon dioxide concentration measurements in biogas plants is presented. LEDs in the mid infrared spectral region are implemented as low cost light source. The combination of quartz-enhanced photoacoustic spectroscopy with an absorption path leads to a sensor [...] Read more.

A new sensor for methane and carbon dioxide concentration measurements in biogas plants is presented. LEDs in the mid infrared spectral region are implemented as low cost light source. The combination of quartz-enhanced photoacoustic spectroscopy with an absorption path leads to a sensor setup suitable for the harsh application environment. The sensor system contains an electronics unit and the two gas sensors; it was designed to work as standalone device and was tested in a biogas plant for several weeks. Gas concentration dependent measurements show a precision better than 1% in a range between 40% and 60% target gas concentration for both sensors. Concentration dependent measurements with different background gases show a considerable decrease in cross sensitivity against the major components of biogas in direct comparison to common absorption based sensors. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Graphical abstract

Review

Jump to: Research, Other

13 pages, 2380 KiB

Open AccessReview

Development of a HIV-1 Virus Detection System Based on Nanotechnology

by Jin-Ho Lee, Byung-Keun Oh and Jeong-Woo Choi

Sensors 2015, 15(5), 9915-9927; https://doi.org/10.3390/s150509915 - 27 Apr 2015

Cited by 21 | Viewed by 8668

Abstract

Development of a sensitive and selective detection system for pathogenic viral agents is essential for medical healthcare from diagnostics to therapeutics. However, conventional detection systems are time consuming, resource-intensive and tedious to perform. Hence, the demand for sensitive and selective detection system for [...] Read more.

Development of a sensitive and selective detection system for pathogenic viral agents is essential for medical healthcare from diagnostics to therapeutics. However, conventional detection systems are time consuming, resource-intensive and tedious to perform. Hence, the demand for sensitive and selective detection system for virus are highly increasing. To attain this aim, different aspects and techniques have been applied to develop virus sensor with improved sensitivity and selectivity. Here, among those aspects and techniques, this article reviews HIV virus particle detection systems incorporated with nanotechnology to enhance the sensitivity. This review mainly focused on four different detection system including vertically configured electrical detection based on scanning tunneling microscopy (STM), electrochemical detection based on direct electron transfer in virus, optical detection system based on localized surface plasmon resonance (LSPR) and surface enhanced Raman spectroscopy (SERS) using plasmonic nanoparticle. Full article

(This article belongs to the Special Issue Biosensors for Pathogen Detection)

► Show Figures

Figure 1

21 pages, 1021 KiB

Open AccessReview

Fluorescence Spectroscopy and Chemometric Modeling for Bioprocess Monitoring

by Saskia M. Faassen and Bernd Hitzmann

Sensors 2015, 15(5), 10271-10291; https://doi.org/10.3390/s150510271 - 30 Apr 2015

Cited by 101 | Viewed by 12891

Abstract

On-line sensors for the detection of crucial process parameters are desirable for the monitoring, control and automation of processes in the biotechnology, food and pharma industry. Fluorescence spectroscopy as a highly developed and non-invasive technique that enables the on-line measurements of substrate and [...] Read more.

On-line sensors for the detection of crucial process parameters are desirable for the monitoring, control and automation of processes in the biotechnology, food and pharma industry. Fluorescence spectroscopy as a highly developed and non-invasive technique that enables the on-line measurements of substrate and product concentrations or the identification of characteristic process states. During a cultivation process significant changes occur in the fluorescence spectra. By means of chemometric modeling, prediction models can be calculated and applied for process supervision and control to provide increased quality and the productivity of bioprocesses. A range of applications for different microorganisms and analytes has been proposed during the last years. This contribution provides an overview of different analysis methods for the measured fluorescence spectra and the model-building chemometric methods used for various microbial cultivations. Most of these processes are observed using the BioView^® Sensor, thanks to its robustness and insensitivity to adverse process conditions. Beyond that, the PLS-method is the most frequently used chemometric method for the calculation of process models and prediction of process variables. Full article

(This article belongs to the Special Issue Sensors for Bioprocess Monitoring and Control)

► Show Figures

Figure 1

19 pages, 1466 KiB

Open AccessReview

Field Effect Sensors for Nucleic Acid Detection: Recent Advances and Future Perspectives

by Bruno Veigas, Elvira Fortunato and Pedro V. Baptista

Sensors 2015, 15(5), 10380-10398; https://doi.org/10.3390/s150510380 - 4 May 2015

Cited by 81 | Viewed by 11476

Abstract

In the last decade the use of field-effect-based devices has become a basic structural element in a new generation of biosensors that allow label-free DNA analysis. In particular, ion sensitive field effect transistors (FET) are the basis for the development of radical new [...] Read more.

In the last decade the use of field-effect-based devices has become a basic structural element in a new generation of biosensors that allow label-free DNA analysis. In particular, ion sensitive field effect transistors (FET) are the basis for the development of radical new approaches for the specific detection and characterization of DNA due to FETs’ greater signal-to-noise ratio, fast measurement capabilities, and possibility to be included in portable instrumentation. Reliable molecular characterization of DNA and/or RNA is vital for disease diagnostics and to follow up alterations in gene expression profiles. FET biosensors may become a relevant tool for molecular diagnostics and at point-of-care. The development of these devices and strategies should be carefully designed, as biomolecular recognition and detection events must occur within the Debye length. This limitation is sometimes considered to be fundamental for FET devices and considerable efforts have been made to develop better architectures. Herein we review the use of field effect sensors for nucleic acid detection strategies—from production and functionalization to integration in molecular diagnostics platforms, with special focus on those that have made their way into the diagnostics lab. Full article

(This article belongs to the Special Issue Next-Generation Nucleic Acid Sensors)

► Show Figures

Figure 1

30 pages, 7092 KiB

Open AccessReview

Fabrication and Robotization of Ultrasensitive Plasmonic Nanosensors for Molecule Detection with Raman Scattering

by Xiaobin Xu, Kwanoh Kim, Chao Liu and Donglei Fan

Sensors 2015, 15(5), 10422-10451; https://doi.org/10.3390/s150510422 - 4 May 2015

Cited by 15 | Viewed by 9018

Abstract

In this work, we introduce the history and mechanisms of surface enhanced Raman scattering (SERS), discuss various techniques for fabrication of state-of-the-art SERS substrates, and review recent work on robotizing plasmonic nanoparticles, especially, the efforts we made on fabrication, characterization, and robotization of [...] Read more.

In this work, we introduce the history and mechanisms of surface enhanced Raman scattering (SERS), discuss various techniques for fabrication of state-of-the-art SERS substrates, and review recent work on robotizing plasmonic nanoparticles, especially, the efforts we made on fabrication, characterization, and robotization of Raman nanosensors by design. Our nanosensors, consisting of tri-layer nanocapsule structures, are ultrasensitive, well reproducible, and can be robotized by either electric or magnetic tweezers. Three applications using such SERS nanosensors were demonstrated, including location predictable detection, single-cell bioanalysis, and tunable molecule release and monitoring. The integration of SERS and nanoelectromechanical system (NEMS) devices is innovative in both device concept and fabrication, and could potentially inspire a new device scheme for various bio-relevant applications. Full article

(This article belongs to the Special Issue Inorganic Nanoparticles as Biomedical Probes)

► Show Figures

Figure 1

30 pages, 3192 KiB

Open AccessReview

Surface Plasmon Resonance: A Versatile Technique for Biosensor Applications

by Hoang Hiep Nguyen, Jeho Park, Sebyung Kang and Moonil Kim

Sensors 2015, 15(5), 10481-10510; https://doi.org/10.3390/s150510481 - 5 May 2015

Cited by 1084 | Viewed by 54993

Abstract

Surface plasmon resonance (SPR) is a label-free detection method which has emerged during the last two decades as a suitable and reliable platform in clinical analysis for biomolecular interactions. The technique makes it possible to measure interactions in real-time with high sensitivity and [...] Read more.

Surface plasmon resonance (SPR) is a label-free detection method which has emerged during the last two decades as a suitable and reliable platform in clinical analysis for biomolecular interactions. The technique makes it possible to measure interactions in real-time with high sensitivity and without the need of labels. This review article discusses a wide range of applications in optical-based sensors using either surface plasmon resonance (SPR) or surface plasmon resonance imaging (SPRI). Here we summarize the principles, provide examples, and illustrate the utility of SPR and SPRI through example applications from the biomedical, proteomics, genomics and bioengineering fields. In addition, SPR signal amplification strategies and surface functionalization are covered in the review. Full article

(This article belongs to the Special Issue Resonant Sensors and Sensor Fusion)

► Show Figures

Figure 1

51 pages, 923 KiB

Open AccessReview

The Elderly’s Independent Living in Smart Homes: A Characterization of Activities and Sensing Infrastructure Survey to Facilitate Services Development

by Qin Ni, Ana Belén García Hernando and Iván Pau De la Cruz

Sensors 2015, 15(5), 11312-11362; https://doi.org/10.3390/s150511312 - 14 May 2015

Cited by 222 | Viewed by 19557

Abstract

Human activity detection within smart homes is one of the basis of unobtrusive wellness monitoring of a rapidly aging population in developed countries. Most works in this area use the concept of “activity” as the building block with which to construct applications such [...] Read more.

Human activity detection within smart homes is one of the basis of unobtrusive wellness monitoring of a rapidly aging population in developed countries. Most works in this area use the concept of “activity” as the building block with which to construct applications such as healthcare monitoring or ambient assisted living. The process of identifying a specific activity encompasses the selection of the appropriate set of sensors, the correct preprocessing of their provided raw data and the learning/reasoning using this information. If the selection of the sensors and the data processing methods are wrongly performed, the whole activity detection process may fail, leading to the consequent failure of the whole application. Related to this, the main contributions of this review are the following: first, we propose a classification of the main activities considered in smart home scenarios which are targeted to older people’s independent living, as well as their characterization and formalized context representation; second, we perform a classification of sensors and data processing methods that are suitable for the detection of the aforementioned activities. Our aim is to help researchers and developers in these lower-level technical aspects that are nevertheless fundamental for the success of the complete application. Full article

(This article belongs to the Collection Sensors for Globalized Healthy Living and Wellbeing)

► Show Figures

Figure 1

18 pages, 2290 KiB

Open AccessReview

ZnO Nanostructure-Based Intracellular Sensor

by Muhammad H. Asif, Bengt Danielsson and Magnus Willander

Sensors 2015, 15(5), 11787-11804; https://doi.org/10.3390/s150511787 - 21 May 2015

Cited by 29 | Viewed by 7155

Abstract

Recently ZnO has attracted much interest because of its usefulness for intracellular measurements of biochemical species by using its semiconducting, electrochemical, catalytic properties and for being biosafe and biocompatible. ZnO thus has a wide range of applications in optoelectronics, intracellular nanosensors, transducers, energy [...] Read more.

Recently ZnO has attracted much interest because of its usefulness for intracellular measurements of biochemical species by using its semiconducting, electrochemical, catalytic properties and for being biosafe and biocompatible. ZnO thus has a wide range of applications in optoelectronics, intracellular nanosensors, transducers, energy conversion and medical sciences. This review relates specifically to intracellular electrochemical (glucose and free metal ion) biosensors based on functionalized zinc oxide nanowires/nanorods. For intracellular measurements, the ZnO nanowires/nanorods were grown on the tip of a borosilicate glass capillary (0.7 µm in diameter) and functionalized with membranes or enzymes to produce intracellular selective metal ion or glucose sensors. Successful intracellular measurements were carried out using ZnO nanowires/nanorods grown on small tips for glucose and free metal ions using two types of cells, human fat cells and frog oocytes. The sensors in this study were used to detect real-time changes of metal ions and glucose across human fat cells and frog cells using changes in the electrochemical potential at the interface of the intracellular micro-environment. Such devices are helpful in explaining various intracellular processes involving ions and glucose. Full article

(This article belongs to the Special Issue Intracellular Sensing)

► Show Figures

Figure 1

39 pages, 812 KiB

Open AccessReview

Fruit Quality Evaluation Using Spectroscopy Technology: A Review

by Hailong Wang, Jiyu Peng, Chuanqi Xie, Yidan Bao and Yong He

Sensors 2015, 15(5), 11889-11927; https://doi.org/10.3390/s150511889 - 21 May 2015

Cited by 311 | Viewed by 17336

Abstract

An overview is presented with regard to applications of visible and near infrared (Vis/NIR) spectroscopy, multispectral imaging and hyperspectral imaging techniques for quality attributes measurement and variety discrimination of various fruit species, i.e., apple, orange, kiwifruit, peach, grape, strawberry, grape, jujube, banana, [...] Read more.

An overview is presented with regard to applications of visible and near infrared (Vis/NIR) spectroscopy, multispectral imaging and hyperspectral imaging techniques for quality attributes measurement and variety discrimination of various fruit species, i.e., apple, orange, kiwifruit, peach, grape, strawberry, grape, jujube, banana, mango and others. Some commonly utilized chemometrics including pretreatment methods, variable selection methods, discriminant methods and calibration methods are briefly introduced. The comprehensive review of applications, which concentrates primarily on Vis/NIR spectroscopy, are arranged according to fruit species. Most of the applications are focused on variety discrimination or the measurement of soluble solids content (SSC), acidity and firmness, but also some measurements involving dry matter, vitamin C, polyphenols and pigments have been reported. The feasibility of different spectral modes, i.e., reflectance, interactance and transmittance, are discussed. Optimal variable selection methods and calibration methods for measuring different attributes of different fruit species are addressed. Special attention is paid to sample preparation and the influence of the environment. Areas where further investigation is needed and problems concerning model robustness and model transfer are identified. Full article

(This article belongs to the Special Issue Sensors for Food Safety and Quality)

► Show Figures

Graphical abstract

29 pages, 634 KiB

Open AccessReview

Survey of WBSNs for Pre-Hospital Assistance: Trends to Maximize the Network Lifetime and Video Transmission Techniques

by Enrique Gonzalez, Raul Peña, Cesar Vargas-Rosales, Alfonso Avila and David Perez-Diaz De Cerio

Sensors 2015, 15(5), 11993-12021; https://doi.org/10.3390/s150511993 - 22 May 2015

Cited by 27 | Viewed by 18315

Abstract

This survey aims to encourage the multidisciplinary communities to join forces for innovation in the mobile health monitoring area. Specifically, multidisciplinary innovations in medical emergency scenarios can have a significant impact on the effectiveness and quality of the procedures and practices in the [...] Read more.

This survey aims to encourage the multidisciplinary communities to join forces for innovation in the mobile health monitoring area. Specifically, multidisciplinary innovations in medical emergency scenarios can have a significant impact on the effectiveness and quality of the procedures and practices in the delivery of medical care. Wireless body sensor networks (WBSNs) are a promising technology capable of improving the existing practices in condition assessment and care delivery for a patient in a medical emergency. This technology can also facilitate the early interventions of a specialist physician during the pre-hospital period. WBSNs make possible these early interventions by establishing remote communication links with video/audio support and by providing medical information such as vital signs, electrocardiograms, etc. in real time. This survey focuses on relevant issues needed to understand how to setup a WBSN for medical emergencies. These issues are: monitoring vital signs and video transmission, energy efficient protocols, scheduling, optimization and energy consumption on a WBSN. Full article

(This article belongs to the Special Issue Wireless Sensor Network for Pervasive Medical Care)

► Show Figures

Graphical abstract

Other

Jump to: Research, Review

23 pages, 4388 KiB

Open AccessTechnical Note

Bore-Sight Calibration of Multiple Laser Range Finders for Kinematic 3D Laser Scanning Systems

by Jaehoon Jung, Jeonghyun Kim, Sanghyun Yoon, Sangmin Kim, Hyoungsig Cho, Changjae Kim and Joon Heo

Sensors 2015, 15(5), 10292-10314; https://doi.org/10.3390/s150510292 - 4 May 2015

Cited by 11 | Viewed by 8235

Abstract

The Simultaneous Localization and Mapping (SLAM) technique has been used for autonomous navigation of mobile systems; now, its applications have been extended to 3D data acquisition of indoor environments. In order to reconstruct 3D scenes of indoor space, the kinematic 3D laser scanning [...] Read more.

The Simultaneous Localization and Mapping (SLAM) technique has been used for autonomous navigation of mobile systems; now, its applications have been extended to 3D data acquisition of indoor environments. In order to reconstruct 3D scenes of indoor space, the kinematic 3D laser scanning system, developed herein, carries three laser range finders (LRFs): one is mounted horizontally for system-position correction and the other two are mounted vertically to collect 3D point-cloud data of the surrounding environment along the system’s trajectory. However, the kinematic laser scanning results can be impaired by errors resulting from sensor misalignment. In the present study, the bore-sight calibration of multiple LRF sensors was performed using a specially designed double-deck calibration facility, which is composed of two half-circle-shaped aluminum frames. Moreover, in order to automatically achieve point-to-point correspondences between a scan point and the target center, a V-shaped target was designed as well. The bore-sight calibration parameters were estimated by a constrained least squares method, which iteratively minimizes the weighted sum of squares of residuals while constraining some highly-correlated parameters. The calibration performance was analyzed by means of a correlation matrix. After calibration, the visual inspection of mapped data and residual calculation confirmed the effectiveness of the proposed calibration approach. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

5 pages, 198 KiB

Open AccessReply

Revision of J3Gen and Validity of the Attacks by Peinado et al.

by Alberto Peinado, Jorge Munilla and Amparo Fúster-Sabater

Sensors 2015, 15(5), 11988-11992; https://doi.org/10.3390/s150511988 - 22 May 2015

Cited by 1 | Viewed by 4546

Abstract

This letter is the reply to: Remarks on Peinado et al.’s Analysis of J3Gen by J. Garcia-Alfaro, J. Herrera-Joancomartí and J. Melià-Seguí published in Sensors 2015, 15, 6217–6220. Peinado et al. cryptanalyzed the pseudorandom number generator proposed by Melià-Seguí et al., describing two [...] Read more.

This letter is the reply to: Remarks on Peinado et al.’s Analysis of J3Gen by J. Garcia-Alfaro, J. Herrera-Joancomartí and J. Melià-Seguí published in Sensors 2015, 15, 6217–6220. Peinado et al. cryptanalyzed the pseudorandom number generator proposed by Melià-Seguí et al., describing two possible attacks. Later, Garcia-Alfaro claimed that one of this attack did not hold in practice because the assumptions made by Peinado et al. were not correct. This letter reviews those remarks, showing that J3Gen is anyway flawed and that, without further information, the interpretation made by Peinado et al. seems to be correct. Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

Figure 1

Journal Menu

Journal Browser

Sensors, Volume 15, Issue 5 (May 2015) – 130 articles , Pages 9610-12102

Research

Review

Other

Further Information

Guidelines

MDPI Initiatives

Follow MDPI
