Search Results (1,431)

Existing macroscopic finite element models for electron beam welding (EBW) typically assume isotropic material behavior, often failing to accurately predict residual stresses induced by strong crystallographic textures. To address this limitation, this study established a sequential dual-scale coupled numerical model bridging micro-texture to macro-mechanics by combining the crystal plasticity finite element method (CPFEM) with thermal-elastic-plastic theory. Representative volume elements (RVEs) incorporating α and β dual-phase characteristics were constructed based on electron backscatter diffraction (EBSD) data from the TA15 weld cross-section. Through simulated tensile and shear calculations on the RVEs, homogenized orthotropic stiffness matrices and Hill yield constitutive parameters were derived and mapped onto the macroscopic model. Simulation results indicate that the proposed model maintains the prediction error for molten pool morphology within 16.3%, while effectively correcting the stress overestimation inherent in isotropic models. Specifically, it adjusts the peak longitudinal residual stress at the weld center from 800 MPa to approximately 350 MPa, significantly reducing the anomalous “M-shaped” stress distribution. By successfully capturing shear stress components, this work provides a high-fidelity computational approach for predicting complex stress states in welded joints, offering critical insights for structural integrity assessment. Full article

Magnesium alloys’ poor corrosion resistance limits their applications as biodegradable bone repair materials. Alloying tailors Mg alloys’ microstructure and properties. The present study investigates the effect of 2 wt.% Ag addition on the microstructure and initial corrosion behavior of hot-rolled Mg-1Ca alloy. Mg-1Ca and Mg-1Ca-2Ag alloys were prepared by melting using Mg-2Ca and Mg-4Ag master alloys, followed by homogenization at 400 °C for 2 h, hot rolling, and stress-relief annealing at 400 °C for 6 h. The alloys were systematically characterized using field-emission scanning electron microscopy (FESEM), transmission electron microscopy (TEM), electron backscatter diffraction (EBSD), and X-ray diffraction (XRD). Initial corrosion behavior was evaluated via 3 h immersion tests in simulated body fluid (SBF). Results reveal Ag’s high thermal diffusivity promotes segregation at tensile twin boundaries, forming Ag₃Mg nanoparticles. These nanoparticles hinder grain boundary migration and, with increased deformation, facilitate grain rotation and high-angle grain boundary formation, weakening texture. Internal stress accumulation near twin boundaries—driven by grain orientation variation and nanoparticles—induces ~86° rotation of {10–12} tensile twins around the c-axis, forming double twins. During corrosion, nanoparticles and double twins synergistically promote dense protective film formation, significantly reducing corrosion rates. Full article

The AA7075 holds significant importance in the aerospace field. Understanding its microstructure evolution and constitutive relationships during warm deformation is crucial for optimizing forming processes. To this end, isothermal compression experiments were conducted at different temperatures and strain rates to analyze their flow stress behavior. The microstructure evolution was characterized using electron backscatter diffraction (EBSD) and transmission electron microscopy (TEM). Microstructural analysis confirmed that dynamic recovery constitutes the predominant softening mechanism under warm forming conditions. The results indicate that flow stress is highly sensitive to deformation parameters, decreasing with increasing temperature and rising with increasing strain rate. To accurately describe the flow behavior, two distinct constitutive models were formulated: (1) a phenomenological Hensel–Spittel–Garofalo (HSG) model; (2) a novel hybrid machine-learning model that innovatively integrates the Harris Hawks Optimization (HHO) algorithm with an LSTM model. Both constitutive models demonstrate reasonable predictive accuracy. In comparison, the HHO-LSTM model demonstrated a superior ability to capture complex nonlinear relationships, achieving highly precise predictions of flow stress across the full range of deformation conditions tested in this work. The hybrid machine-learning model proposed in this study provides a highly accurate method for describing and predicting the flow behavior of the AA7075 during warm forming, offering a powerful predictive tool for engineering applications. Full article

With the ongoing miniaturization of solder joints in three-dimensional integrated electronic packaging, electromigration reliability has become a pressing concern. This study systematically examines the interfacial intermetallic compound (IMC) growth behavior of Cu/Sn-58Bi/Cu joint under electromigration (EM) with a symmetrical square-wave alternating current (AC). Electron backscatter diffraction (EBSD) was employed to perform statistical spatial analysis of Sn grain orientations within the joints to reveal the growth mechanism of interfacial IMC. Results demonstrate that the AC field markedly enhances the anisotropy of IMC growth in Cu/Sn-58Bi/Cu joints, exhibiting two phenomena: uniform growth on both sides and rapid growth (polar growth) on one side of the interfacial IMC. Among them, the IMC thickness difference characterization quantity Δ_IMC reached as high as 45.56% for the latter. This is attributed to the directional regulation of atomic migration rate by Sn grain orientation (the angle θ between the c-axis and the electron flow) and is further amplified by the altered atomic diffusion pathways imposed by the Bi phase distribution. Specifically, the Sn grains exhibit a pronounced preferential orientation mode along the current path (horizontal direction), with an orientation gradient of 0.915 μm⁻¹. The arrangement of Bi-rich phases alters the distribution of Sn grains in Cu/Sn-58Bi/Cu joints, thereby reshaping the internal electron transport pathways and significantly intensifying the orientation-dependent effect of IMC growth. Moreover, Sn grains adjacent to the Bi-rich phase boundaries (phase boundary grains) display a stronger tendency for c-axis orientation parallel to the current direction, exhibiting an average effective orientation parameter 1.948 times greater than that of bulk grains, which establishes a well-defined spatial orientation gradient. Full article

The microstructural and textural evolution in hot-rolled Fe–3.0 wt.% Si steel sheets was investigated by quasi in situ electron backscatter diffraction (EBSD) analysis. During recrystallization, the Goss texture intensity in the surface region remains essentially unchanged, whereas the α and α* textures are strengthened. In the center region, the α texture weakens, and the α* texture shows little variation, while the Goss texture becomes intensified. In the surface region, {112}<110> recrystallized grains nucleate by consuming deformed matrices with orientations near {114}<221> and {110}<112>. Recrystallized {114}<481> and {001}<210> grains consume deformed matrices near {114}<221> and Goss orientations, while Goss grains nucleate by consuming Goss-oriented deformed matrices. In the center region, {112}<110>, {114}<481>, and {001}<210> recrystallized grains nucleate and grow by consuming α and λ type deformed matrices, whereas Goss recrystallized grains preferentially consume deformed matrices with orientations of {111}<112>. Full article

The ductile shear zones in northern Guangxi provide a crucial window for understanding Paleozoic collisional deformation and the tectonic evolution of the South China Block. The Jiufeng–Gandong ductile shear zone is located in the western part of the Motianling pluton in northern Guangxi. The penetrative mylonitic foliation within the ductile zone dips toward the ESE at angles of 55°–85°. Kinematic analyses indicate that the Jiufeng–Gandong ductile shear zone experienced sinistral thrust shearing. Anisotropy of magnetic susceptibility (AMS) results show that the shear zone generally strikes in an NNE direction, with a length exceeding 30 km and a maximum width of more than 2.5 km. The flattening degree (E value) of the magnetic susceptibility ellipsoid suggests that deformation within the shear zone is dominated by flattening strain, accompanied by a component of extensional strain. Quartz dynamic recrystallization mechanisms and electron backscatter diffraction (EBSD) analyses indicate that the sinistral thrust shearing occurred at deformation temperatures of approximately 350–650 °C. LA–ICP–MS U–Pb dating of zircons from a mafic mylonite yields a crystallization age of 443.0 ± 2.8 Ma. By integrating macro- and microstructural observations, magnetic fabric data, quartz EBSD fabric analyses, regional published geochronological constraints, and hydrothermal zircon U–Pb ages obtained in this study, we propose that the Jiufeng–Gandong ductile shear zone developed during Caledonian thrusting of the Cathaysia Block onto the Yangtze Block from SE to NW. Under collisional compression, the shear zone underwent medium- to high-temperature sinistral thrust shearing accompanied by dominant flattening strain. These results elucidate the geometry, strain characteristics, and tectonic regime of the Jiufeng–Gandong ductile shear zone, providing new insights into the Caledonian tectonic evolution of South China. Full article

Inverse pole figure mapping is a common orientation visualization method used in electron backscatter diffraction (EBSD) software to display crystal orientations. Although this technique has been routinely used in commercial EBSD software, the coloring algorithm employed to map the orientation and construct the color key (standard stereographic triangle) has not been reported in the literature. This paper presents a simple algorithm to color the standard stereographic triangles of the 11 Laue groups by mapping the Maxwell color triangle to the curved standard stereographic triangles using nonlinear shape functions commonly employed in finite element methods. Detailed procedures are given to illustrate how the mapping is performed and how it is used to construct inverse pole figure maps from Euler angles. Color coding of the seven different standard stereographic triangles is demonstrated using a computer program written in C++. It is shown that the simple color-coding algorithm presented in this paper can be conveniently utilized to display orientation data in inverse pole figure maps, which is a critical part of designing customized EBSD software. It also provides a method to adjust the color center within the curved triangles to more uniformly distribute the color, which is not available in commercial EBSD software. The algorithm can also be used to design orientation representation software for other applications, e.g., crystal plasticity simulations, where representation of orientation data is also a routine task. Full article

The performance of Zr-2.5Nb alloy pressure tubes in nuclear reactors is critically dependent on the behavior of precipitated hydrides. In this study, a hydrogen-charged Zr-2.5Nb alloy pressure tube was subjected to in situ tensile testing combined with electron backscatter diffraction to elucidate microcrack evolution and microstructural adaptation. Initially, longitudinal hydride–hydride interface cracks nucleated at non-coherent interfaces of two types of hydrides due to the inherent brittleness. Subsequently, stress redistribution by a small proportion of hydride–hydride interface cracks resulted in the emergence of microcracks at the transverse hydride–matrix interfaces, accompanied by partial hydride phase transformation. Finally, under high strain conditions, increased dislocation movement in the matrix triggered a single slip system, leading to the formation of numerous low-angle grain boundaries. As strain further increased, multiple slip systems were activated, and longitudinal matrix–matrix interface cracks began to nucleate at certain grain boundary locations. Full article

Aimed at improving the mechanical performance of welded joints in stainless steel composite materials, this research investigates the evolutionary characteristics of microstructure at the interface between the transition layer weld and base layer weld through electron backscatter diffraction (EBSD) and X-ray diffraction (XRD) analytical techniques. In addition, molecular dynamics simulation methods are employed to conduct an in-depth study on the atomic diffusion behavior during the welding process. The results show that carbon and chromium atoms undergo asymmetric diffusion at the interface, forming a decarburized and a carburized zone. The diffusion coefficient of carbon atoms was the largest, with the diffusion mechanism being interstitial diffusion. Followed by chromium atoms, the diffusion coefficient of Fe was the smallest. On the base layer weld side, two structural zones with different grain sizes were formed; the zone close to the interface was a coarse ferrite microstructure with the lower geometrically necessary dislocation density, the zone far from the interface was a finer-grained ferrite and pearlite microstructure. As the welding heat input of the transition layer weld increases, the average density of geometrically necessary dislocations, the decarburized layer thickness, the average grain size, and the diffusion coefficients of Cr and C atoms at the interface all exhibit a concomitant upward trend. Concurrently, a carbon–chromium compound precipitates at the interface. Full article

In this study, X70 line pipe steels were subjected to different hot rolling treatments under three conditions with varying roughing (R) and finishing (F) reductions while maintaining the same total reduction to investigate the effect on drop weight tear test (DWTT) toughness and hydrogen-induced damage as assessed through electrochemical charging. Scanning Electron Microscope (SEM) images were used to analyze microstructure phases and their volume fractions, while Electron Backscatter Diffraction (EBSD) provided quantitative microscopy, and X-ray analysis examined crystallographic texture. Although all steels exhibited similar microstructure phases, the effective grain size and morphology varied slightly across the thickness. As these variations were minor, the focus shifted to other microstructural features such as textural characteristics. Overall, the steel with the medium R/F reduction demonstrated improved DWTT performance and greater hydrogen cracking and blistering resistance. This was attributed to stronger Transformed Brass (TBr) and Transformed Copper (TC) components, weaker Rotated-Cube (RC) texture, and lower Kernel Average Misorientation (KAM) values. Across the three steels in this work, this study demonstrates that increased fraction of blocky austenite/martensite as secondary phases, high geometrically necessary dislocation (GND) density, and RC texture negatively affect both DWTT and hydrogen damage resistance, whereas gamma (γ)-fiber and {332}<113> textures have positive effects. Improving these metallurgical factors can therefore boost toughness and reduce hydrogen-induced damage in line-pipe steels. Full article

The strategic balance between strength and electrical conductivity in Al-Mg-Si alloys is a critical challenge that must be overcome to enable their widespread adoption as viable alternatives to copper conductors in power transmission systems. To address this, the present study comprehensively investigates model alloys with Mg/Si ratios ranging from 1.0 to 2.0. A multi-faceted experimental approach was employed, combining tailored thermo-mechanical treatments (solution treatment, cold drawing, and isothermal annealing) with comprehensive microstructural characterization techniques, including electron backscatter diffraction (EBSD) and scanning electron microscopy (SEM). The results elucidate a fundamental competitive mechanism governing property optimization: excess Mg atoms concurrently contribute to solid-solution strengthening via the formation of Cottrell atmospheres around dislocations, while simultaneously enhancing electron scattering, which is detrimental to conductivity. A critical synergy was identified at the Mg/Si ratio of 1.75, which promotes the dense precipitation of fine β″ phase while facilitating extensive recovery of high dislocation density. Furthermore, EBSD analysis confirmed the development of a microstructure comprising 74.1% high-angle grain boundaries alongside a low dislocation density (KAM ≤ 2°). This specific microstructural configuration effectively minimizes electron scattering while providing moderate grain boundary strengthening, thereby synergistically achieving an optimal balance between strength and electrical conductivity. Consequently, this work elucidates the key quantitative relationships and competitive mechanisms among composition (Mg/Si ratio), processing parameters, microstructure evolution, and final properties within the studied Al-xMg-0.5Si alloy system. These findings establish a clear design guideline and provide a fundamental understanding for developing high-performance aluminum-based conductor alloys with tailored Mg/Si ratios. Full article

To address the performance deficiencies in welded joints in 2507 duplex stainless-steel pipes under demanding service conditions such as deep-sea operation, this study investigates drawn 2507 duplex stainless-steel pipes. Vacuum-fusion welding coupled with ER2507 wire filling is employed to fabricate the joints. The joint microstructure and tensile behavior are systematically analyzed using microstructural characterization techniques (electron backscatter diffraction and transmission electron microscopy) and uniaxial tensile testing. The results indicate that the joint exhibits a graded microstructure along the welding direction: base metal-heat affected zone-weld metal. The austenite phase fraction in the fusion zone decreases to 27.6%. The joint achieves an ultimate tensile strength of 833.3 MPa and a total elongation of close to 23%, demonstrating an excellent combination of strength and ductility. During tensile deformation, the ferrite and austenite phases undergo coordinated deformation. Strain is distributed relatively uniformly at low strain levels but localized preferentially within the fusion zone at high strain levels. Fractographic analyses reveal a ductile fracture mode. This research provides theoretical support and technical reference for optimizing welding processes and assessing the service safety of 2507 duplex stainless-steel pipes in deep-sea pipeline-engineering applications. Full article

Super duplex stainless steels (SDSSs) can be effectively fabricated via Laser Powder Bed Fusion (LPBF), yet achieving the necessary phase balance remains a critical metallurgical challenge. The rapid solidification rates inherent to the LPBF process typically result in a predominantly ferritic microstructure. Since CSL boundaries—specifically high-symmetry ∑3 twins—form preferentially in the austenite phase, achieving a high fraction of these boundaries in the ferritic as-built LPBF state remains a significant challenge. To address this limitation, we implemented a feedstock modification strategy by mechanically blending 2507 SDSS powder with 3 and 6 wt.% elemental nickel prior to LPBF processing. The microstructural evolution, phase distribution, and boundary character were comprehensively evaluated using Electron Backscatter Diffraction (EBSD). Analysis revealed that the addition of nickel did not compromise densification, with all samples achieving relative densities exceeding 99.2%. While the base alloy remained 98.5% ferritic, the addition of 6 wt.% Ni successfully promoted the formation of approximately 31.1 wt.% austenite, characterized by intragranular laths formed via a massive-like transformation mechanism⁶. Crucially, despite the theoretical increase in Stacking Fault Energy (SFE) associated with high nickel content, the restored austenite phase exhibited a significant fraction of high-symmetry CSL ∑3 twin boundaries (rising to 7.05%). These findings demonstrate that compositional modification can overcome the kinetic limitations of the LPBF process, facilitating the development of a favorable Grain Boundary Character Distribution (GBCD). Full article

This study investigates the effects of post-build heat treatments—such as annealing, quenching, and aging—on the microstructure and hardness of Laser Powder Bed Fusion (PBF-LB) Ti-6Al-4V. Specimens were subjected to annealing (950 °C, 1010 °C) or solution treatment/quenching (950 °C, 1010 °C), followed by aging (350–550 °C). Microstructural evolution was analyzed using optical microscopy (OM), scanning electron microscopy (SEM), X-ray diffraction (XRD), electron backscatter diffraction (EBSD), and Vickers hardness testing. Results showed that the as-built sample exhibited high hardness (365.2 HV_0.1) due to fine α′ martensite. Sub-β-transus annealing at 950 °C decomposed α′ into equilibrium α + 1.25% β (329 HV_0.1), while super-β-transus annealing at 1010 °C formed coarse lamellar structures of α + 1.5% β, yielding the lowest hardness (319 HV_0.1). Quenching from 1010 °C produced dominant α′ martensite with high hardness (371.6 HV_0.1). Notably, aging samples quenched from 950 °C increased hardness, peaking at 382.6 HV_0.1 at 450 °C due to precipitation, before decreasing to 364.4 HV_0.1 at 550 °C due to coarsening. These findings demonstrate that optimizing heat treatment temperatures is critical for controlling phase transformations and tailoring mechanical properties in additively manufactured Ti-6Al-4V components. Full article

Numerical simulations of the forming limit diagram (FLD) for SUS430/Al1050/TA1 laminated metal composites (LMCs) are conducted through the crystal plasticity finite element (CPFE) model integrated with the Marciniak–Kuczyński (M–K) theory. Representative volume elements (RVEs) that reconstruct the measured crystallographic texture, as characterized by electron backscatter diffraction (EBSD), are developed. The optimal grain number and mesh density for the RVE are calibrated through convergence analysis by curve-fitting simulated stress–strain responses to the uniaxial tensile data. The established multi-scale model successfully predicts the FLDs of the SUS430/Al1050/TA1 laminated sheet under two stacking sequences, namely, the SUS layer or the TA1 layer in contact with the die. The Nakazima test results validate the effectiveness of the proposed model as an efficient and accurate predictive tool. This study extends the CPFE–MK framework to multi-layer LMCs, overcoming the limitations of conventional single-layer models, which incorporate FCC, BCC, and HCP crystalline structures. Furthermore, the deformation-induced texture evolution under different loading paths is analyzed, establishing the relationship between micro-scale deformation mechanisms and the macro-scale forming behavior. Full article
