Sensors, Volume 15, Issue 4 (April 2015) – 131 articles , Pages 7084-9609

Issues are regarded as officially published after their release is announced to the table of contents alert mailing list.
You may sign up for e-mail alerts to receive table of contents of newly released issues.
PDF is the official format for papers published in both, html and pdf forms. To view the papers in pdf format, click on the "PDF Full-text" link, and use the free Adobe Reader to open them.

Order results

Result details

Section

Show export options Show export options

Select all

Export citation of selected articles as:

12 pages, 1626 KiB

Open AccessArticle

A Room Temperature Nitric Oxide Gas Sensor Based on a Copper-Ion-Doped Polyaniline/Tungsten Oxide Nanocomposite

by Shih-Han Wang, Chi-Yen Shen, Jian-Ming Su and Shiang-Wen Chang

Sensors 2015, 15(4), 7084-7095; https://doi.org/10.3390/s150407084 - 24 Mar 2015

Cited by 41 | Viewed by 8851

The parts-per-billion-level nitric oxide (NO) gas sensing capability of a copper-ion-doped polyaniline/tungsten oxide nanocomposite (Cu²⁺/PANI/WO₃) film coated on a Rayleigh surface acoustic wave device was investigated. The sensor developed in this study was sensitive to NO gas at room [...] Read more.

The parts-per-billion-level nitric oxide (NO) gas sensing capability of a copper-ion-doped polyaniline/tungsten oxide nanocomposite (Cu²⁺/PANI/WO₃) film coated on a Rayleigh surface acoustic wave device was investigated. The sensor developed in this study was sensitive to NO gas at room temperature in dry nitrogen. The surface morphology, dopant distribution, and electric properties were characterized using scanning electron microscopy, energy-dispersive X-ray spectroscopy mapping, and Hall effect measurements, respectively. The Cu²⁺/PANI/WO₃ film exhibited high NO gas sensitivity and selectivity as well as long-term stability. At 1 ppb of NO, a signal with a frequency shift of 4.3 ppm and a signal-to-noise ratio of 17 was observed. The sensor exhibited distinct selectivity toward NO gas with no substantial response to O₂, NH₃ and CO₂ gases. Full article

(This article belongs to the Special Issue Acoustic Waveguide Sensors)

► Show Figures

Figure 1

29 pages, 3569 KiB

Open AccessArticle

A Floor-Map-Aided WiFi/Pseudo-Odometry Integration Algorithm for an Indoor Positioning System

by Jian Wang, Andong Hu, Chunyan Liu and Xin Li

Sensors 2015, 15(4), 7096-7124; https://doi.org/10.3390/s150407096 - 24 Mar 2015

Cited by 44 | Viewed by 8973

This paper proposes a scheme for indoor positioning by fusing floor map, WiFi and smartphone sensor data to provide meter-level positioning without additional infrastructure. A topology-constrained K nearest neighbor (KNN) algorithm based on a floor map layout provides the coordinates required to integrate [...] Read more.

This paper proposes a scheme for indoor positioning by fusing floor map, WiFi and smartphone sensor data to provide meter-level positioning without additional infrastructure. A topology-constrained K nearest neighbor (KNN) algorithm based on a floor map layout provides the coordinates required to integrate WiFi data with pseudo-odometry (P-O) measurements simulated using a pedestrian dead reckoning (PDR) approach. One method of further improving the positioning accuracy is to use a more effective multi-threshold step detection algorithm, as proposed by the authors. The “go and back” phenomenon caused by incorrect matching of the reference points (RPs) of a WiFi algorithm is eliminated using an adaptive fading-factor-based extended Kalman filter (EKF), taking WiFi positioning coordinates, P-O measurements and fused heading angles as observations. The “cross-wall” problem is solved based on the development of a floor-map-aided particle filter algorithm by weighting the particles, thereby also eliminating the gross-error effects originating from WiFi or P-O measurements. The performance observed in a field experiment performed on the fourth floor of the School of Environmental Science and Spatial Informatics (SESSI) building on the China University of Mining and Technology (CUMT) campus confirms that the proposed scheme can reliably achieve meter-level positioning. Full article

(This article belongs to the Special Issue Sensors for Indoor Mapping and Navigation)

► Show Figures

Graphical abstract

11 pages, 1354 KiB

Open AccessArticle

Thermodynamic Modeling and Analysis of an Optical Electric-Field Sensor

by Xia Xiao, Yan Xu and Zexing Dong

Sensors 2015, 15(4), 7125-7135; https://doi.org/10.3390/s150407125 - 24 Mar 2015

Cited by 21 | Viewed by 6028

The stability of the optical electric field sensor (OEFS) in actual operation is affected by environmental factors such as temperature and SF₆ (sulfur hexafluoride). To analyze the operational environment parameters affecting the optical properties of crystals, a thermodynamic model of the OEFS [...] Read more.

The stability of the optical electric field sensor (OEFS) in actual operation is affected by environmental factors such as temperature and SF₆ (sulfur hexafluoride). To analyze the operational environment parameters affecting the optical properties of crystals, a thermodynamic model of the OEFS in which the optical properties of the crystal are changed by the first-order effects and the second-order effects was established. The intensity parameters such as electric, stress and temperature fields were introduced. The theoretical analysis results show that under temperature, stress and electric field conditions, the optical properties of the sensing crystals are no longer changed only by the electro-optic effect, but also by the temperature and the stress fields. Further synthesis suggests the expected optical property changes under the effect of the environment fields. OEFS tests show that the accuracy of OEFS is dependent on temperature with a ratio error of −0.8%~1.5% in the temperature range from −25 °C to +40 °C. Full article

(This article belongs to the Special Issue Silicon Based Optical Sensors)

► Show Figures

Figure 1

20 pages, 963 KiB

Open AccessArticle

Informational Analysis for Compressive Sampling in Radar Imaging

by Jingxiong Zhang and Ke Yang

Sensors 2015, 15(4), 7136-7155; https://doi.org/10.3390/s150407136 - 24 Mar 2015

Cited by 9 | Viewed by 5173

Compressive sampling or compressed sensing (CS) works on the assumption of the sparsity or compressibility of the underlying signal, relies on the trans-informational capability of the measurement matrix employed and the resultant measurements, operates with optimization-based algorithms for signal reconstruction and is thus [...] Read more.

Compressive sampling or compressed sensing (CS) works on the assumption of the sparsity or compressibility of the underlying signal, relies on the trans-informational capability of the measurement matrix employed and the resultant measurements, operates with optimization-based algorithms for signal reconstruction and is thus able to complete data compression, while acquiring data, leading to sub-Nyquist sampling strategies that promote efficiency in data acquisition, while ensuring certain accuracy criteria. Information theory provides a framework complementary to classic CS theory for analyzing information mechanisms and for determining the necessary number of measurements in a CS environment, such as CS-radar, a radar sensor conceptualized or designed with CS principles and techniques. Despite increasing awareness of information-theoretic perspectives on CS-radar, reported research has been rare. This paper seeks to bridge the gap in the interdisciplinary area of CS, radar and information theory by analyzing information flows in CS-radar from sparse scenes to measurements and determining sub-Nyquist sampling rates necessary for scene reconstruction within certain distortion thresholds, given differing scene sparsity and average per-sample signal-to-noise ratios (SNRs). Simulated studies were performed to complement and validate the information-theoretic analysis. The combined strategy proposed in this paper is valuable for information-theoretic orientated CS-radar system analysis and performance evaluation. Full article

(This article belongs to the Section Remote Sensors)

► Show Figures

16 pages, 980 KiB

Open AccessArticle

Detection of Abnormal Events via Optical Flow Feature Analysis

by Tian Wang and Hichem Snoussi

Sensors 2015, 15(4), 7156-7171; https://doi.org/10.3390/s150407156 - 24 Mar 2015

Cited by 37 | Viewed by 6584

In this paper, a novel algorithm is proposed to detect abnormal events in video streams. The algorithm is based on the histogram of the optical flow orientation descriptor and the classification method. The details of the histogram of the optical flow orientation descriptor [...] Read more.

In this paper, a novel algorithm is proposed to detect abnormal events in video streams. The algorithm is based on the histogram of the optical flow orientation descriptor and the classification method. The details of the histogram of the optical flow orientation descriptor are illustrated for describing movement information of the global video frame or foreground frame. By combining one-class support vector machine and kernel principal component analysis methods, the abnormal events in the current frame can be detected after a learning period characterizing normal behaviors. The difference abnormal detection results are analyzed and explained. The proposed detection method is tested on benchmark datasets, then the experimental results show the effectiveness of the algorithm. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

34 pages, 2440 KiB

Open AccessReview

Network Challenges for Cyber Physical Systems with Tiny Wireless Devices: A Case Study on Reliable Pipeline Condition Monitoring

by Salman Ali, Saad Bin Qaisar, Husnain Saeed, Muhammad Farhan Khan, Muhammad Naeem and Alagan Anpalagan

Sensors 2015, 15(4), 7172-7205; https://doi.org/10.3390/s150407172 - 25 Mar 2015

Cited by 105 | Viewed by 25982

The synergy of computational and physical network components leading to the Internet of Things, Data and Services has been made feasible by the use of Cyber Physical Systems (CPSs). CPS engineering promises to impact system condition monitoring for a diverse range of fields [...] Read more.

The synergy of computational and physical network components leading to the Internet of Things, Data and Services has been made feasible by the use of Cyber Physical Systems (CPSs). CPS engineering promises to impact system condition monitoring for a diverse range of fields from healthcare, manufacturing, and transportation to aerospace and warfare. CPS for environment monitoring applications completely transforms human-to-human, human-to-machine and machine-to-machine interactions with the use of Internet Cloud. A recent trend is to gain assistance from mergers between virtual networking and physical actuation to reliably perform all conventional and complex sensing and communication tasks. Oil and gas pipeline monitoring provides a novel example of the benefits of CPS, providing a reliable remote monitoring platform to leverage environment, strategic and economic benefits. In this paper, we evaluate the applications and technical requirements for seamlessly integrating CPS with sensor network plane from a reliability perspective and review the strategies for communicating information between remote monitoring sites and the widely deployed sensor nodes. Related challenges and issues in network architecture design and relevant protocols are also provided with classification. This is supported by a case study on implementing reliable monitoring of oil and gas pipeline installations. Network parameters like node-discovery, node-mobility, data security, link connectivity, data aggregation, information knowledge discovery and quality of service provisioning have been reviewed. Full article

(This article belongs to the Special Issue Cyber-Physical Systems)

► Show Figures

Figure 1

22 pages, 749 KiB

Open AccessArticle

Performance and Stress Analysis of Metal Oxide Films for CMOS-Integrated Gas Sensors

by Lado Filipovic and Siegfried Selberherr

Sensors 2015, 15(4), 7206-7227; https://doi.org/10.3390/s150407206 - 25 Mar 2015

Cited by 48 | Viewed by 9800

The integration of gas sensor components into smart phones, tablets and wrist watches will revolutionize the environmental health and safety industry by providing individuals the ability to detect harmful chemicals and pollutants in the environment using always-on hand-held or wearable devices. Metal oxide [...] Read more.

The integration of gas sensor components into smart phones, tablets and wrist watches will revolutionize the environmental health and safety industry by providing individuals the ability to detect harmful chemicals and pollutants in the environment using always-on hand-held or wearable devices. Metal oxide gas sensors rely on changes in their electrical conductance due to the interaction of the oxide with a surrounding gas. These sensors have been extensively studied in the hopes that they will provide full gas sensing functionality with CMOS integrability. The performance of several metal oxide materials, such as tin oxide (SnO_²), zinc oxide (ZnO), indium oxide (In₂O₃) and indium-tin-oxide (ITO), are studied for the detection of various harmful or toxic cases. Due to the need for these films to be heated to temperatures between 250°C and 550°C during operation in order to increase their sensing functionality, a considerable degradation of the film can result. The stress generation during thin film deposition and the thermo-mechanical stress that arises during post-deposition cooling is analyzed through simulations. A tin oxide thin film is deposited using the efficient and economical spray pyrolysis technique, which involves three steps: the atomization of the precursor solution, the transport of the aerosol droplets towards the wafer and the decomposition of the precursor at or near the substrate resulting in film growth. The details of this technique and a simulation methodology are presented. The dependence of the deposition technique on the sensor performance is also discussed. Full article

(This article belongs to the Special Issue Smart Materials for Switchable Sensors)

► Show Figures

18 pages, 1348 KiB

Open AccessArticle

Integration of GPS Precise Point Positioning and MEMS-Based INS Using Unscented Particle Filter

by Mahmoud Abd Rabbou and Ahmed El-Rabbany

Sensors 2015, 15(4), 7228-7245; https://doi.org/10.3390/s150407228 - 25 Mar 2015

Cited by 37 | Viewed by 8524

Integration of Global Positioning System (GPS) and Inertial Navigation System (INS) integrated system involves nonlinear motion state and measurement models. However, the extended Kalman filter (EKF) is commonly used as the estimation filter, which might lead to solution divergence. This is usually encountered [...] Read more.

Integration of Global Positioning System (GPS) and Inertial Navigation System (INS) integrated system involves nonlinear motion state and measurement models. However, the extended Kalman filter (EKF) is commonly used as the estimation filter, which might lead to solution divergence. This is usually encountered during GPS outages, when low-cost micro-electro-mechanical sensors (MEMS) inertial sensors are used. To enhance the navigation system performance, alternatives to the standard EKF should be considered. Particle filtering (PF) is commonly considered as a nonlinear estimation technique to accommodate severe MEMS inertial sensor biases and noise behavior. However, the computation burden of PF limits its use. In this study, an improved version of PF, the unscented particle filter (UPF), is utilized, which combines the unscented Kalman filter (UKF) and PF for the integration of GPS precise point positioning and MEMS-based inertial systems. The proposed filter is examined and compared with traditional estimation filters, namely EKF, UKF and PF. Tightly coupled mechanization is adopted, which is developed in the raw GPS and INS measurement domain. Un-differenced ionosphere-free linear combinations of pseudorange and carrier-phase measurements are used for PPP. The performance of the UPF is analyzed using a real test scenario in downtown Kingston, Ontario. It is shown that the use of UPF reduces the number of samples needed to produce an accurate solution, in comparison with the traditional PF, which in turn reduces the processing time. In addition, UPF enhances the positioning accuracy by up to 15% during GPS outages, in comparison with EKF. However, all filters produce comparable results when the GPS measurement updates are available. Full article

(This article belongs to the Special Issue Inertial Sensors and Systems)

► Show Figures

Figure 1

21 pages, 4608 KiB

Open AccessArticle

Design of a Hybrid (Wired/Wireless) Acquisition Data System for Monitoring of Cultural Heritage Physical Parameters in Smart Cities

by Fernando-Juan García Diego, Borja Esteban and Paloma Merello

Sensors 2015, 15(4), 7246-7266; https://doi.org/10.3390/s150407246 - 25 Mar 2015

Cited by 28 | Viewed by 8460

Preventive conservation represents a working method and combination of techniques which helps in determining and controlling the deterioration process of cultural heritage in order to take the necessary actions before it occurs. It is acknowledged as important, both in terms of preserving and [...] Read more.

Preventive conservation represents a working method and combination of techniques which helps in determining and controlling the deterioration process of cultural heritage in order to take the necessary actions before it occurs. It is acknowledged as important, both in terms of preserving and also reducing the cost of future conservation measures. Therefore, long-term monitoring of physical parameters influencing cultural heritage is necessary. In the context of Smart Cities, monitoring of cultural heritage is of interest in order to perform future comparative studies and load information into the cloud that will be useful for the conservation of other heritage sites. In this paper the development of an economical and appropriate acquisition data system combining wired and wireless communication, as well as third party hardware for increased versatility, is presented. The device allows monitoring a complex network of points with high sampling frequency, with wired sensors in a 1-wire bus and a wireless centralized system recording data for monitoring of physical parameters, as well as the future possibility of attaching an alarm system or sending data over the Internet. This has been possible with the development of three board’s designs and more than 5000 algorithm lines. System tests have shown an adequate system operation. Full article

(This article belongs to the Special Issue Sensors and Smart Cities)

► Show Figures

Figure 1

27 pages, 6668 KiB

Open AccessArticle

High-Speed Incoming Infrared Target Detection by Fusion of Spatial and Temporal Detectors

by Sungho Kim

Sensors 2015, 15(4), 7267-7293; https://doi.org/10.3390/s150407267 - 25 Mar 2015

Cited by 34 | Viewed by 9901

This paper presents a method for detecting high-speed incoming targets by the fusion of spatial and temporal detectors to achieve a high detection rate for an active protection system (APS). The incoming targets have different image velocities according to the target-camera geometry. Therefore, [...] Read more.

This paper presents a method for detecting high-speed incoming targets by the fusion of spatial and temporal detectors to achieve a high detection rate for an active protection system (APS). The incoming targets have different image velocities according to the target-camera geometry. Therefore, single-target detector-based approaches, such as a 1D temporal filter, 2D spatial filter and 3D matched filter, cannot provide a high detection rate with moderate false alarms. The target speed variation was analyzed according to the incoming angle and target velocity. The speed of the distant target at the firing time is almost stationary and increases slowly. The speed varying targets are detected stably by fusing the spatial and temporal filters. The stationary target detector is activated by an almost zero temporal contrast filter (TCF) and identifies targets using a spatial filter called the modified mean subtraction filter (M-MSF). A small motion (sub-pixel velocity) target detector is activated by a small TCF value and finds targets using the same spatial filter. A large motion (pixel-velocity) target detector works when the TCF value is high. The final target detection is terminated by fusing the three detectors based on the threat priority. The experimental results of the various target sequences show that the proposed fusion-based target detector produces the highest detection rate with an acceptable false alarm rate. Full article

(This article belongs to the Special Issue Frontiers in Infrared Photodetection)

► Show Figures

29 pages, 3274 KiB

Open AccessArticle

Adaptive Software Architecture Based on Confident HCI for the Deployment of Sensitive Services in Smart Homes

by Mario Vega-Barbas, Iván Pau, María Luisa Martín-Ruiz and Fernando Seoane

Sensors 2015, 15(4), 7294-7322; https://doi.org/10.3390/s150407294 - 25 Mar 2015

Cited by 17 | Viewed by 11161

Smart spaces foster the development of natural and appropriate forms of human-computer interaction by taking advantage of home customization. The interaction potential of the Smart Home, which is a special type of smart space, is of particular interest in fields in which the [...] Read more.

Smart spaces foster the development of natural and appropriate forms of human-computer interaction by taking advantage of home customization. The interaction potential of the Smart Home, which is a special type of smart space, is of particular interest in fields in which the acceptance of new technologies is limited and restrictive. The integration of smart home design patterns with sensitive solutions can increase user acceptance. In this paper, we present the main challenges that have been identified in the literature for the successful deployment of sensitive services (e.g., telemedicine and assistive services) in smart spaces and a software architecture that models the functionalities of a Smart Home platform that are required to maintain and support such sensitive services. This architecture emphasizes user interaction as a key concept to facilitate the acceptance of sensitive services by end-users and utilizes activity theory to support its innovative design. The application of activity theory to the architecture eases the handling of novel concepts, such as understanding of the system by patients at home or the affordability of assistive services. Finally, we provide a proof-of-concept implementation of the architecture and compare the results with other architectures from the literature. Full article

(This article belongs to the Special Issue HCI In Smart Environments)

► Show Figures

Figure 1

26 pages, 1234 KiB

Open AccessArticle

An Adaptive Supervisory Sliding Fuzzy Cerebellar Model Articulation Controller for Sensorless Vector-Controlled Induction Motor Drive Systems

by Shun-Yuan Wang, Chwan-Lu Tseng, Shou-Chuang Lin, Chun-Jung Chiu and Jen-Hsiang Chou

Sensors 2015, 15(4), 7323-7348; https://doi.org/10.3390/s150407323 - 25 Mar 2015

Cited by 10 | Viewed by 7170

This paper presents the implementation of an adaptive supervisory sliding fuzzy cerebellar model articulation controller (FCMAC) in the speed sensorless vector control of an induction motor (IM) drive system. The proposed adaptive supervisory sliding FCMAC comprised a supervisory controller, integral sliding surface, and [...] Read more.

This paper presents the implementation of an adaptive supervisory sliding fuzzy cerebellar model articulation controller (FCMAC) in the speed sensorless vector control of an induction motor (IM) drive system. The proposed adaptive supervisory sliding FCMAC comprised a supervisory controller, integral sliding surface, and an adaptive FCMAC. The integral sliding surface was employed to eliminate steady-state errors and enhance the responsiveness of the system. The adaptive FCMAC incorporated an FCMAC with a compensating controller to perform a desired control action. The proposed controller was derived using the Lyapunov approach, which guarantees learning-error convergence. The implementation of three intelligent control schemes—the adaptive supervisory sliding FCMAC, adaptive sliding FCMAC, and adaptive sliding CMAC—were experimentally investigated under various conditions in a realistic sensorless vector-controlled IM drive system. The root mean square error (RMSE) was used as a performance index to evaluate the experimental results of each control scheme. The analysis results indicated that the proposed adaptive supervisory sliding FCMAC substantially improved the system performance compared with the other control schemes. Full article

(This article belongs to the Special Issue Selected Papers from 2014 International Symposium on Computer, Consumer and Control (IS3C 2014))

► Show Figures

Figure 1

11 pages, 2222 KiB

Open AccessArticle

A Wafer Level Vacuum Encapsulated Capacitive Accelerometer Fabricated in an Unmodified Commercial MEMS Process

by Adel Merdassi, Peng Yang and Vamsy P. Chodavarapu

Sensors 2015, 15(4), 7349-7359; https://doi.org/10.3390/s150407349 - 25 Mar 2015

Cited by 19 | Viewed by 9192

We present the design and fabrication of a single axis low noise accelerometer in an unmodified commercial MicroElectroMechanical Systems (MEMS) process. The new microfabrication process, MEMS Integrated Design for Inertial Sensors (MIDIS), introduced by Teledyne DALSA Inc. allows wafer level vacuum encapsulation at [...] Read more.

We present the design and fabrication of a single axis low noise accelerometer in an unmodified commercial MicroElectroMechanical Systems (MEMS) process. The new microfabrication process, MEMS Integrated Design for Inertial Sensors (MIDIS), introduced by Teledyne DALSA Inc. allows wafer level vacuum encapsulation at 10 milliTorr which provides a high Quality factor and reduces noise interference on the MEMS sensor devices. The MIDIS process is based on high aspect ratio bulk micromachining of single-crystal silicon layer that is vacuum encapsulated between two other silicon handle wafers. The process includes sealed Through Silicon Vias (TSVs) for compact design and flip-chip integration with signal processing circuits. The proposed accelerometer design is sensitive to single-axis in-plane acceleration and uses a differential capacitance measurement. Over ±1 g measurement range, the measured sensitivity was 1fF/g. The accelerometer system was designed to provide a detection resolution of 33 milli-g over the operational range of ±100 g. Full article

(This article belongs to the Special Issue Modeling, Testing and Reliability Issues in MEMS Engineering)

► Show Figures

Figure 1

28 pages, 8596 KiB

Open AccessArticle

Application of HFCT and UHF Sensors in On-Line Partial Discharge Measurements for Insulation Diagnosis of High Voltage Equipment

by Fernando Álvarez, Fernando Garnacho, Javier Ortego and Miguel Ángel Sánchez-Urán

Sensors 2015, 15(4), 7360-7387; https://doi.org/10.3390/s150407360 - 25 Mar 2015

Cited by 193 | Viewed by 24373

Partial discharge (PD) measurements provide valuable information for assessing the condition of high voltage (HV) insulation systems, contributing to their quality assurance. Different PD measuring techniques have been developed in the last years specially designed to perform on-line measurements. Non-conventional PD methods operating [...] Read more.

Partial discharge (PD) measurements provide valuable information for assessing the condition of high voltage (HV) insulation systems, contributing to their quality assurance. Different PD measuring techniques have been developed in the last years specially designed to perform on-line measurements. Non-conventional PD methods operating in high frequency bands are usually used when this type of tests are carried out. In PD measurements the signal acquisition, the subsequent signal processing and the capability to obtain an accurate diagnosis are conditioned by the selection of a suitable detection technique and by the implementation of effective signal processing tools. This paper proposes an optimized electromagnetic detection method based on the combined use of wideband PD sensors for measurements performed in the HF and UHF frequency ranges, together with the implementation of powerful processing tools. The effectiveness of the measuring techniques proposed is demonstrated through an example, where several PD sources are measured simultaneously in a HV installation consisting of a cable system connected by a plug-in terminal to a gas insulated substation (GIS) compartment. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

24 pages, 999 KiB

Open AccessArticle

An Analytical Model for Squeeze-Film Damping of Perforated Torsional Microplates Resonators

by Pu Li and Yuming Fang

Sensors 2015, 15(4), 7388-7411; https://doi.org/10.3390/s150407388 - 25 Mar 2015

Cited by 17 | Viewed by 7416

Squeeze-film damping plays a significant role in the performance of micro-resonators because it determines their quality factors. Perforations in microstructures are often used to control the squeeze-film damping in micro-resonators. To model the perforation effects on the squeeze-film damping, many analytical models have [...] Read more.

Squeeze-film damping plays a significant role in the performance of micro-resonators because it determines their quality factors. Perforations in microstructures are often used to control the squeeze-film damping in micro-resonators. To model the perforation effects on the squeeze-film damping, many analytical models have been proposed, however, most of the previous models have been concerned with the squeeze-film damping due to the normal motion between the perforated vibrating plate and a fixed substrate, while there is a lack of works that model the squeeze-film damping of perforated torsion microplates, which are also widely used in MEMS devices. This paper presents an analytical model for the squeeze-film damping of perforated torsion microplates. The derivation in this paper is based on a modified Reynolds equation that includes compressibility and rarefaction effects. The pressure distribution under the vibrating plate is obtained using the double sine series. Closed-form expressions for the stiffness and the damping coefficients of the squeeze-film are derived. The accuracy of the model is verified by comparing its results with the finite element method (FEM) results and the experimental results available in the literature. The regime of validity and limitations of the present model are assessed. Full article

(This article belongs to the Special Issue Modeling, Testing and Reliability Issues in MEMS Engineering)

► Show Figures

Figure 1

22 pages, 2389 KiB

Open AccessArticle

A Noncontact FMCW Radar Sensor for Displacement Measurement in Structural Health Monitoring

by Cunlong Li, Weimin Chen, Gang Liu, Rong Yan, Hengyi Xu and Yi Qi

Sensors 2015, 15(4), 7412-7433; https://doi.org/10.3390/s150407412 - 26 Mar 2015

Cited by 66 | Viewed by 11412

This paper investigates the Frequency Modulation Continuous Wave (FMCW) radar sensor for multi-target displacement measurement in Structural Health Monitoring (SHM). The principle of three-dimensional (3-D) displacement measurement of civil infrastructures is analyzed. The requirements of high-accuracy displacement and multi-target identification for the measuring [...] Read more.

This paper investigates the Frequency Modulation Continuous Wave (FMCW) radar sensor for multi-target displacement measurement in Structural Health Monitoring (SHM). The principle of three-dimensional (3-D) displacement measurement of civil infrastructures is analyzed. The requirements of high-accuracy displacement and multi-target identification for the measuring sensors are discussed. The fundamental measuring principle of FMCW radar is presented with rigorous mathematical formulas, and further the multiple-target displacement measurement is analyzed and simulated. In addition, a FMCW radar prototype is designed and fabricated based on an off-the-shelf radar frontend and data acquisition (DAQ) card, and the displacement error induced by phase asynchronism is analyzed. The conducted outdoor experiments verify the feasibility of this sensing method applied to multi-target displacement measurement, and experimental results show that three targets located at different distances can be distinguished simultaneously with millimeter level accuracy. Full article

(This article belongs to the Special Issue Novel Sensors for Non-Destructive Testing and Structural Health Monitoring)

► Show Figures

Figure 1

20 pages, 937 KiB

Open AccessArticle

A Distributed Transmission Rate Adjustment Algorithm in Heterogeneous CSMA/CA Networks

by Shuanglong Xie, Kay Soon Low and Erry Gunawan

Sensors 2015, 15(4), 7434-7453; https://doi.org/10.3390/s150407434 - 26 Mar 2015

Cited by 7 | Viewed by 5941

Distributed transmission rate tuning is important for a wide variety of IEEE 802.15.4 network applications such as industrial network control systems. Such systems often require each node to sustain certain throughput demand in order to guarantee the system performance. It is thus essential [...] Read more.

Distributed transmission rate tuning is important for a wide variety of IEEE 802.15.4 network applications such as industrial network control systems. Such systems often require each node to sustain certain throughput demand in order to guarantee the system performance. It is thus essential to determine a proper transmission rate that can meet the application requirement and compensate for network imperfections (e.g., packet loss). Such a tuning in a heterogeneous network is difficult due to the lack of modeling techniques that can deal with the heterogeneity of the network as well as the network traffic changes. In this paper, a distributed transmission rate tuning algorithm in a heterogeneous IEEE 802.15.4 CSMA/CA network is proposed. Each node uses the results of clear channel assessment (CCA) to estimate the busy channel probability. Then a mathematical framework is developed to estimate the on-going heterogeneous traffics using the busy channel probability at runtime. Finally a distributed algorithm is derived to tune the transmission rate of each node to accurately meet the throughput requirement. The algorithm does not require modifications on IEEE 802.15.4 MAC layer and it has been experimentally implemented and extensively tested using TelosB nodes with the TinyOS protocol stack. The results reveal that the algorithm is accurate and can satisfy the throughput demand. Compared with existing techniques, the algorithm is fully distributed and thus does not require any central coordination. With this property, it is able to adapt to traffic changes and re-adjust the transmission rate to the desired level, which cannot be achieved using the traditional modeling techniques. Full article

(This article belongs to the Special Issue Wireless Sensor Networks and the Internet of Things)

► Show Figures

Figure 1

8 pages, 2929 KiB

Open AccessArticle

A Naked Eye Refractive Index Sensor with a Visible Multiple Peak Metamaterial Absorber

by Heli Ma, Kun Song, Liang Zhou and Xiaopeng Zhao

Sensors 2015, 15(4), 7454-7461; https://doi.org/10.3390/s150407454 - 26 Mar 2015

Cited by 15 | Viewed by 7608

We report a naked eye refractive index sensor with a visible metamaterial absorber. The visible metamaterial absorber consisting of a silver dendritic/dielectric/metal structure shows multiple absorption peaks. By incorporating a gain material (rhodamine B) into the dielectric layer, the maximal magnitude of the [...] Read more.

We report a naked eye refractive index sensor with a visible metamaterial absorber. The visible metamaterial absorber consisting of a silver dendritic/dielectric/metal structure shows multiple absorption peaks. By incorporating a gain material (rhodamine B) into the dielectric layer, the maximal magnitude of the absorption peak can be improved by about 30%. As the metamaterial absorber is sensitive to the refractive index of glucose solutions, it can function as a sensor that quickly responds to variations of the refractive index of the liquid. Meanwhile, since the response is presented via color changes, it can be clearly observed by the naked eyes. Further experiments have confirmed that the sensor can be used repeatedly. Full article

(This article belongs to the Special Issue Metamaterial-Inspired Sensors)

► Show Figures

Graphical abstract

37 pages, 6133 KiB

Open AccessArticle

A Survey on the Feasibility of Sound Classification on Wireless Sensor Nodes

by Etto L. Salomons and Paul J. M. Havinga

Sensors 2015, 15(4), 7462-7498; https://doi.org/10.3390/s150407462 - 26 Mar 2015

Cited by 14 | Viewed by 7621

Wireless sensor networks are suitable to gain context awareness for indoor environments. As sound waves form a rich source of context information, equipping the nodes with microphones can be of great benefit. The algorithms to extract features from sound waves are often highly [...] Read more.

Wireless sensor networks are suitable to gain context awareness for indoor environments. As sound waves form a rich source of context information, equipping the nodes with microphones can be of great benefit. The algorithms to extract features from sound waves are often highly computationally intensive. This can be problematic as wireless nodes are usually restricted in resources. In order to be able to make a proper decision about which features to use, we survey how sound is used in the literature for global sound classification, age and gender classification, emotion recognition, person verification and identification and indoor and outdoor environmental sound classification. The results of the surveyed algorithms are compared with respect to accuracy and computational load. The accuracies are taken from the surveyed papers; the computational loads are determined by benchmarking the algorithms on an actual sensor node. We conclude that for indoor context awareness, the low-cost algorithms for feature extraction perform equally well as the more computationally-intensive variants. As the feature extraction still requires a large amount of processing time, we present four possible strategies to deal with this problem. Full article

(This article belongs to the Special Issue Acoustic Waveguide Sensors)

► Show Figures

13 pages, 2397 KiB

Open AccessArticle

Embedding Piezoresistive Pressure Sensors to Obtain Online Pressure Profiles Inside Fiber Composite Laminates

by Maryam Kahali Moghaddam, Arne Breede, Christian Brauner and Walter Lang

Sensors 2015, 15(4), 7499-7511; https://doi.org/10.3390/s150407499 - 27 Mar 2015

Cited by 30 | Viewed by 9109

The production of large and complex parts using fiber composite materials is costly due to the frequent formation of voids, porosity and waste products. By embedding different types of sensors and monitoring the process in real time, the amount of wastage can be [...] Read more.

The production of large and complex parts using fiber composite materials is costly due to the frequent formation of voids, porosity and waste products. By embedding different types of sensors and monitoring the process in real time, the amount of wastage can be significantly reduced. This work focuses on developing a knowledge-based method to improve and ensure complete impregnation of the fibers before initiation of the resin cure. Piezoresistive and capacitive pressure sensors were embedded in fiber composite laminates to measure the real-time the pressure values inside the laminate. A change of pressure indicates resin infusion. The sensors were placed in the laminate and the resin was infused by vacuum. The embedded piezoresistive pressure sensors were able to track the vacuum pressure in the fiber composite laminate setup, as well as the arrival of the resin at the sensor. The pressure increase due to closing the resin inlet was also measured. In contrast, the capacitive type of sensor was found to be inappropriate for measuring these quantities. The following study demonstrates real-time monitoring of pressure changes inside the fiber composite laminate, which validate the use of Darcy’s law in porous media to control the resin flow during infusion. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

25 pages, 3679 KiB

Open AccessArticle

Learning to Rapidly Re-Contact the Lost Plume in Chemical Plume Tracing

by Meng-Li Cao, Qing-Hao Meng, Jia-Ying Wang, Bing Luo, Ya-Qi Jing and Shu-Gen Ma

Sensors 2015, 15(4), 7512-7536; https://doi.org/10.3390/s150407512 - 27 Mar 2015

Cited by 6 | Viewed by 6405

Maintaining contact between the robot and plume is significant in chemical plume tracing (CPT). In the time immediately following the loss of chemical detection during the process of CPT, Track-Out activities bias the robot heading relative to the upwind direction, expecting to rapidly [...] Read more.

Maintaining contact between the robot and plume is significant in chemical plume tracing (CPT). In the time immediately following the loss of chemical detection during the process of CPT, Track-Out activities bias the robot heading relative to the upwind direction, expecting to rapidly re-contact the plume. To determine the bias angle used in the Track-Out activity, we propose an online instance-based reinforcement learning method, namely virtual trail following (VTF). In VTF, action-value is generalized from recently stored instances of successful Track-Out activities. We also propose a collaborative VTF (cVTF) method, in which multiple robots store their own instances, and learn from the stored instances, in the same database. The proposed VTF and cVTF methods are compared with biased upwind surge (BUS) method, in which all Track-Out activities utilize an offline optimized universal bias angle, in an indoor environment with three different airflow fields. With respect to our experimental conditions, VTF and cVTF show stronger adaptability to different airflow environments than BUS, and furthermore, cVTF yields higher success rates and time-efficiencies than VTF. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

34 pages, 3500 KiB

Open AccessArticle

Determination of Optimum Viewing Angles for the Angular Normalization of Land Surface Temperature over Vegetated Surface

by Huazhong Ren, Guangjian Yan, Rongyuan Liu, Zhao-Liang Li, Qiming Qin, Françoise Nerry and Qiang Liu

Sensors 2015, 15(4), 7537-7570; https://doi.org/10.3390/s150407537 - 27 Mar 2015

Cited by 18 | Viewed by 7134

Multi-angular observation of land surface thermal radiation is considered to be a promising method of performing the angular normalization of land surface temperature (LST) retrieved from remote sensing data. This paper focuses on an investigation of the minimum requirements of viewing angles to [...] Read more.

Multi-angular observation of land surface thermal radiation is considered to be a promising method of performing the angular normalization of land surface temperature (LST) retrieved from remote sensing data. This paper focuses on an investigation of the minimum requirements of viewing angles to perform such normalizations on LST. The normally kernel-driven bi-directional reflectance distribution function (BRDF) is first extended to the thermal infrared (TIR) domain as TIR-BRDF model, and its uncertainty is shown to be less than 0.3 K when used to fit the hemispheric directional thermal radiation. A local optimum three-angle combination is found and verified using the TIR-BRDF model based on two patterns: the single-point pattern and the linear-array pattern. The TIR-BRDF is applied to an airborne multi-angular dataset to retrieve LST at nadir (T_e-nadir) from different viewing directions, and the results show that this model can obtain reliable T_e-nadir from 3 to 4 directional observations with large angle intervals, thus corresponding to large temperature angular variations. The T_e-nadir is generally larger than temperature of the slant direction, with a difference of approximately 0.5~2.0 K for vegetated pixels and up to several Kelvins for non-vegetated pixels. The findings of this paper will facilitate the future development of multi-angular thermal infrared sensors. Full article

(This article belongs to the Section Remote Sensors)

► Show Figures

Graphical abstract

25 pages, 3762 KiB

Open AccessArticle

NFC Internal: An Indoor Navigation System

by Busra Ozdenizci, Vedat Coskun and Kerem Ok

Sensors 2015, 15(4), 7571-7595; https://doi.org/10.3390/s150407571 - 27 Mar 2015

Cited by 81 | Viewed by 14184

Indoor navigation systems have recently become a popular research field due to the lack of GPS signals indoors. Several indoors navigation systems have already been proposed in order to eliminate deficiencies; however each of them has several technical and usability limitations. In this [...] Read more.

Indoor navigation systems have recently become a popular research field due to the lack of GPS signals indoors. Several indoors navigation systems have already been proposed in order to eliminate deficiencies; however each of them has several technical and usability limitations. In this study, we propose NFC Internal, a Near Field Communication (NFC)-based indoor navigation system, which enables users to navigate through a building or a complex by enabling a simple location update, simply by touching NFC tags those are spread around and orient users to the destination. In this paper, we initially present the system requirements, give the design details and study the viability of NFC Internal with a prototype application and a case study. Moreover, we evaluate the performance of the system and compare it with existing indoor navigation systems. It is seen that NFC Internal has considerable advantages and significant contributions to existing indoor navigation systems in terms of security and privacy, cost, performance, robustness, complexity, user preference and commercial availability. Full article

(This article belongs to the Special Issue Sensors for Indoor Mapping and Navigation)

► Show Figures

Graphical abstract

9 pages, 1378 KiB

Open AccessArticle

Quartz Enhanced Photoacoustic Spectroscopy Based Trace Gas Sensors Using Different Quartz Tuning Forks

by Yufei Ma, Guang Yu, Jingbo Zhang, Xin Yu, Rui Sun and Frank K. Tittel

Sensors 2015, 15(4), 7596-7604; https://doi.org/10.3390/s150407596 - 27 Mar 2015

Cited by 39 | Viewed by 7598

A sensitive trace gas sensor platform based on quartz-enhanced photoacoustic spectroscopy (QEPAS) is reported. A 1.395 μm continuous wave (CW), distributed feedback pigtailed diode laser was used as the excitation source and H₂O was selected as the target analyte. Two kinds [...] Read more.

A sensitive trace gas sensor platform based on quartz-enhanced photoacoustic spectroscopy (QEPAS) is reported. A 1.395 μm continuous wave (CW), distributed feedback pigtailed diode laser was used as the excitation source and H₂O was selected as the target analyte. Two kinds of quartz tuning forks (QTFs) with a resonant frequency (f₀) of 30.72 kHz and 38 kHz were employed for the first time as an acoustic wave transducer, respectively for QEPAS instead of a standard QTF with a f₀ of 32.768 kHz. The QEPAS sensor performance using the three different QTFs was experimentally investigated and theoretically analyzed. A minimum detection limit of 5.9 ppmv and 4.3 ppmv was achieved for f₀ of 32.768 kHz and 30.72 kHz, respectively. Full article

(This article belongs to the Special Issue Optical Sensors for Chemical, Biological and Industrial Applications)

► Show Figures

Graphical abstract

14 pages, 3408 KiB

Open AccessArticle

An Improved Electrochemical Aptasensor for Chloramphenicol Detection Based on Aptamer Incorporated Gelatine

by Ezat Hamidi-Asl, Freddy Dardenne, Ronny Blust and Karolien De Wael

Sensors 2015, 15(4), 7605-7618; https://doi.org/10.3390/s150407605 - 27 Mar 2015

Cited by 35 | Viewed by 7985

Because of the biocompatible properties of gelatine and the good afﬁnity of aptamers for their targets, the combination of aptamer and gelatine type B is reported as promising for the development of biosensing devices. Here, an aptamer for chloramphenicol (CAP) is mixed with [...] Read more.

Because of the biocompatible properties of gelatine and the good afﬁnity of aptamers for their targets, the combination of aptamer and gelatine type B is reported as promising for the development of biosensing devices. Here, an aptamer for chloramphenicol (CAP) is mixed with different types of gelatine and dropped on the surface of disposable gold screen printed electrodes. The signal of the CAP reduction is investigated using differential pulse voltammetry. The diagnostic performance of the sensor is described and a detection limit of 1.83 × 10⁻¹⁰ M is found. The selectivity and the stability of the aptasensor are studied and compared to those of other CAP sensors described in literature. Full article

(This article belongs to the Special Issue Electrochemical Sensors and Biosensors: From Bench-Top to Point-of-Care)

► Show Figures

Graphical abstract

31 pages, 444 KiB

Open AccessArticle

On the Routing Protocol Influence on the Resilience of Wireless Sensor Networks to Jamming Attacks

by Carolina Del-Valle-Soto, Carlos Mex-Perera, Raul Monroy and Juan Arturo Nolazco-Flores

Sensors 2015, 15(4), 7619-7649; https://doi.org/10.3390/s150407619 - 27 Mar 2015

Cited by 21 | Viewed by 7645

In this work, we compare a recently proposed routing protocol, the multi-parent hierarchical (MPH) protocol, with two well-known protocols, the ad hoc on-demand distance vector (AODV) and dynamic source routing (DSR). For this purpose, we have developed a simulator, which faithfully reifies the [...] Read more.

In this work, we compare a recently proposed routing protocol, the multi-parent hierarchical (MPH) protocol, with two well-known protocols, the ad hoc on-demand distance vector (AODV) and dynamic source routing (DSR). For this purpose, we have developed a simulator, which faithfully reifies the workings of a given protocol, considering a fixed, reconfigurable ad hoc network given by the number and location of participants, and general network conditions. We consider a scenario that can be found in a large number of wireless sensor network applications, a single sink node that collects all of the information generated by the sensors. The metrics used to compare the protocols were the number of packet retransmissions, carrier sense multiple access (CSMA) inner loop retries, the number of nodes answering the queries from the coordinator (sink) node and the energy consumption. We tested the network under ordinary (without attacks) conditions (and combinations thereof) and when it is subject to different types of jamming attacks (in particular, random and reactive jamming attacks), considering several positions for the jammer. Our results report that MPH has a greater ability to tolerate such attacks than DSR and AODV, since it minimizes and encapsulates the network segment under attack. The self-configuring capabilities of MPH derived from a combination of a proactive routes update, on a periodic-time basis, and a reactive behavior provide higher resilience while offering a better performance (overhead and energy consumption) than AODV and DSR, as shown in our simulation results. Full article

(This article belongs to the Special Issue Wireless Sensor Networks and the Internet of Things)

► Show Figures

8 pages, 1452 KiB

Open AccessArticle

Highly Sensitive Measurement of Liquid Density in Air Using Suspended Microcapillary Resonators

by Oscar Malvar, Daniel Ramos, Carmen Martínez, Priscila Kosaka, Javier Tamayo and Montserrat Calleja

Sensors 2015, 15(4), 7650-7657; https://doi.org/10.3390/s150407650 - 30 Mar 2015

Cited by 24 | Viewed by 6615

We report the use of commercially available glass microcapillaries as micromechanical resonators for real-time monitoring of the mass density of a liquid that flows through the capillary. The vibration of a suspended region of the microcapillary is optically detected by measuring the forward [...] Read more.

We report the use of commercially available glass microcapillaries as micromechanical resonators for real-time monitoring of the mass density of a liquid that flows through the capillary. The vibration of a suspended region of the microcapillary is optically detected by measuring the forward scattering of a laser beam. The resonance frequency of the liquid filled microcapillary is measured for liquid binary mixtures of ethanol in water, glycerol in water and Triton in ethanol. The method achieves a detection limit in an air environment of 50 µg/mL that is only five times higher than that obtained with state-of-the-art suspended microchannel resonators encapsulated in vacuum. The method opens the door to novel advances for miniaturized total analysis systems based on microcapillaries with the add-on of mechanical transduction for sensing the rheological properties of the analyzed fluids without the need for vacuum encapsulation of the resonators. Full article

(This article belongs to the Section Biosensors)

► Show Figures

Figure 1

33 pages, 672 KiB

Open AccessArticle

PAD-MAC: Primary User Activity-Aware Distributed MAC for Multi-Channel Cognitive Radio Networks

by Amjad Ali, Md. Jalil Piran, Hansoo Kim, Jihyeok Yun and Doug Young Suh

Sensors 2015, 15(4), 7658-7690; https://doi.org/10.3390/s150407658 - 30 Mar 2015

Cited by 13 | Viewed by 5613

Cognitive radio (CR) has emerged as a promising technology to solve problems related to spectrum scarcity and provides a ubiquitous wireless access environment. CR-enabled secondary users (SUs) exploit spectrum white spaces opportunistically and immediately vacate the acquired licensed channels as primary users (PUs) [...] Read more.

Cognitive radio (CR) has emerged as a promising technology to solve problems related to spectrum scarcity and provides a ubiquitous wireless access environment. CR-enabled secondary users (SUs) exploit spectrum white spaces opportunistically and immediately vacate the acquired licensed channels as primary users (PUs) arrive. Accessing the licensed channels without the prior knowledge of PU traffic patterns causes severe throughput degradation due to excessive channel switching and PU-to-SU collisions. Therefore, it is significantly important to design a PU activity-aware medium access control (MAC) protocol for cognitive radio networks (CRNs). In this paper, we first propose a licensed channel usage pattern identification scheme, based on a two-state Markov model, and then estimate the future idle slots using previous observations of the channels. Furthermore, based on these past observations, we compute the rank of each available licensed channel that gives SU transmission success assessment during the estimated idle slot. Secondly, we propose a PU activity-aware distributed MAC (PAD-MAC) protocol for heterogeneous multi-channel CRNs that selects the best channel for each SU to enhance its throughput. PAD-MAC controls SU activities by allowing them to exploit the licensed channels only for the duration of estimated idle slots and enables predictive and fast channel switching. To evaluate the performance of the proposed PAD-MAC, we compare it with the distributed QoS-aware MAC (QC-MAC) and listen-before-talk MAC schemes. Extensive numerical results show the significant improvements of the PAD-MAC in terms of the SU throughput, SU channel switching rate and PU-to-SU collision rate. Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

17 pages, 723 KiB

Open AccessArticle

A Non-Chemical System for Online Weed Control

by Victor Rueda-Ayala, Gerassimos Peteinatos, Roland Gerhards and Dionisio Andújar

Sensors 2015, 15(4), 7691-7707; https://doi.org/10.3390/s150407691 - 30 Mar 2015

Cited by 22 | Viewed by 6800

Non-chemical weed control methods need to be directed towards a site-specific weeding approach, in order to be able to compete the conventional herbicide equivalents. A system for online weed control was developed. It automatically adjusts the tine angle of a harrow and creates [...] Read more.

Non-chemical weed control methods need to be directed towards a site-specific weeding approach, in order to be able to compete the conventional herbicide equivalents. A system for online weed control was developed. It automatically adjusts the tine angle of a harrow and creates different levels of intensity: from gentle to aggressive. Two experimental plots in a maize field were harrowed with two consecutive passes. The plots presented from low to high weed infestation levels. Discriminant capabilities of an ultrasonic sensor were used to determine the crop and weed variability of the field. A controlling unit used ultrasonic readings to adjust the tine angle, producing an appropriate harrowing intensity. Thus, areas with high crop and weed densities were more aggressively harrowed, while areas with lower densities were cultivated with a gentler treatment; areas with very low densities or without weeds were not treated. Although the weed development was relatively advanced and the soil surface was hard, the weed control achieved by the system reached an average of 51% (20%–91%), without causing significant crop damage as a result of harrowing. This system is proposed as a relatively low cost, online, and real-time automatic harrow that improves the weed control efficacy, reduces energy consumption, and avoids the usage of herbicide. Full article

(This article belongs to the Special Issue Agriculture and Forestry: Sensors, Technologies and Procedures)

► Show Figures

20 pages, 1063 KiB

Open AccessArticle

A Robust Method to Detect Zero Velocity for Improved 3D Personal Navigation Using Inertial Sensors

by Zhengyi Xu, Jianming Wei, Bo Zhang and Weijun Yang

Sensors 2015, 15(4), 7708-7727; https://doi.org/10.3390/s150407708 - 30 Mar 2015

Cited by 27 | Viewed by 6910

This paper proposes a robust zero velocity (ZV) detector algorithm to accurately calculate stationary periods in a gait cycle. The proposed algorithm adopts an effective gait cycle segmentation method and introduces a Bayesian network (BN) model based on the measurements of inertial sensors [...] Read more.

This paper proposes a robust zero velocity (ZV) detector algorithm to accurately calculate stationary periods in a gait cycle. The proposed algorithm adopts an effective gait cycle segmentation method and introduces a Bayesian network (BN) model based on the measurements of inertial sensors and kinesiology knowledge to infer the ZV period. During the detected ZV period, an Extended Kalman Filter (EKF) is used to estimate the error states and calibrate the position error. The experiments reveal that the removal rate of ZV false detections by the proposed method increases 80% compared with traditional method at high walking speed. Furthermore, based on the detected ZV, the Personal Inertial Navigation System (PINS) algorithm aided by EKF performs better, especially in the altitude aspect. Full article

(This article belongs to the Special Issue Sensors for Indoor Mapping and Navigation)

► Show Figures

Figure 1

14 pages, 1754 KiB

Open AccessArticle

Maximum Stress Estimation Model for Multi-Span Waler Beams with Deflections at the Supports Using Average Strains

by Sung Woo Park, Byung Kwan Oh and Hyo Seon Park

Sensors 2015, 15(4), 7728-7741; https://doi.org/10.3390/s150407728 - 30 Mar 2015

Cited by 4 | Viewed by 11584

The safety of a multi-span waler beam subjected simultaneously to a distributed load and deflections at its supports can be secured by limiting the maximum stress of the beam to a specific value to prevent the beam from reaching a limit state for [...] Read more.

The safety of a multi-span waler beam subjected simultaneously to a distributed load and deflections at its supports can be secured by limiting the maximum stress of the beam to a specific value to prevent the beam from reaching a limit state for failure or collapse. Despite the fact that the vast majority of accidents on construction sites occur at waler beams in retaining wall systems, no safety monitoring model that can consider deflections at the supports of the beam is available. In this paper, a maximum stress estimation model for a waler beam based on average strains measured from vibrating wire strain gauges (VWSGs), the most frequently used sensors in construction field, is presented. The model is derived by defining the relationship between the maximum stress and the average strains measured from VWSGs. In addition to the maximum stress, support reactions, deflections at supports, and the magnitudes of distributed loads for the beam structure can be identified by the estimation model using the average strains. Using simulation tests on two multi-span beams, the performance of the model is evaluated by estimating maximum stress, deflections at supports, support reactions, and the magnitudes of distributed loads. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

12 pages, 1056 KiB

Open AccessArticle

The Application of a Piezo-Resistive Cardiorespiratory Sensor System in an Automobile Safety Belt

by Syed Talha Ali Hamdani and Anura Fernando

Sensors 2015, 15(4), 7742-7753; https://doi.org/10.3390/s150407742 - 30 Mar 2015

Cited by 35 | Viewed by 12144

Respiratory and heart failure are conditions that can occur with little warning and may also be difficult to predict. Therefore continuous monitoring of these bio-signals is advantageous for ensuring human health. The car safety belt is mainly designed to secure the occupants of [...] Read more.

Respiratory and heart failure are conditions that can occur with little warning and may also be difficult to predict. Therefore continuous monitoring of these bio-signals is advantageous for ensuring human health. The car safety belt is mainly designed to secure the occupants of the vehicle in the event of an accident. In the current research a prototype safety belt is developed, which is used to acquire respiratory and heart signals, under laboratory conditions. The current safety belt is constructed using a copper ink based nonwoven material, which works based on the piezo-resistive effect due to the pressure exerted on the sensor as a result of expansion of the thorax/abdomen area of the body for respiration and due to the principle of ballistocardiography (BCG) in heart signal sensing. In this research, the development of a theoretical model to qualitatively describe the piezo-resistive material is also presented in order to predict the relative change in the resistance of the piezo-resistive material due to the pressure applied. Full article

(This article belongs to the Special Issue Selected Papers from the 1st International Electronic Conference on Sensors and Applications)

► Show Figures

Figure 1

14 pages, 1146 KiB

Open AccessArticle

Rationally Designing Aptamer Sequences with Reduced Affinity for Controlled Sensor Performance

by Lauren R. Schoukroun-Barnes and Ryan J. White

Sensors 2015, 15(4), 7754-7767; https://doi.org/10.3390/s150407754 - 31 Mar 2015

Cited by 14 | Viewed by 8380

The relative ease of predicting the secondary structure of nucleic acid sequences lends itself to the design of sequences to perform desired functions. Here, we combine the utility of nucleic acid aptamers with predictable control over the secondary structure to rationally design sequences [...] Read more.

The relative ease of predicting the secondary structure of nucleic acid sequences lends itself to the design of sequences to perform desired functions. Here, we combine the utility of nucleic acid aptamers with predictable control over the secondary structure to rationally design sequences with controlled affinity towards a target analyte when employed as the recognition element in an electrochemical sensor. Specifically, we present a method to modify an existing high-gain aptamer sequence to create sequences that, when employed in an electrochemical, aptamer-based sensor, exhibit reduced affinity towards a small molecule analyte tobramycin. Sensors fabricated with the high-gain parent sequence saturate at concentrations much below the therapeutic window for tobramycin (7–18 µM). Accordingly, the rationale behind modifying this high-gain sequence to reduce binding affinity was to tune sensor performance for optimal sensitivity in the therapeutic window. Using secondary structure predictions and analysis of the NMR structure of an aminoglycoside RNA aptamer bound to tobramycin, we are able to successfully modify the aptamer sequence to tune the dissociation constants of electrochemical aptamer-based sensors between 0.17 and 3 µM. The guidelines we present represent a general strategy to lessening binding affinity of sensors employing aptamer-modified electrodes. Full article

(This article belongs to the Special Issue Smart Materials for Switchable Sensors)

► Show Figures

Figure 1

39 pages, 5857 KiB

Open AccessArticle

Congestion Based Mechanism for Route Discovery in a V2I-V2V System Applying Smart Devices and IoT

by Natalia Parrado and Yezid Donoso

Sensors 2015, 15(4), 7768-7806; https://doi.org/10.3390/s150407768 - 31 Mar 2015

Cited by 29 | Viewed by 12575

The Internet of Things is a new paradigm in which objects in a specific context can be integrated into traditional communication networks to actively participate in solving a determined problem. The Vehicle-to-Vehicle (V2V) and Vehicle-to-Infrastructure (V2I) technologies are specific cases of IoT and [...] Read more.

The Internet of Things is a new paradigm in which objects in a specific context can be integrated into traditional communication networks to actively participate in solving a determined problem. The Vehicle-to-Vehicle (V2V) and Vehicle-to-Infrastructure (V2I) technologies are specific cases of IoT and key enablers for Intelligent Transportation Systems (ITS). V2V and V2I have been widely used to solve different problems associated with transportation in cities, in which the most important is traffic congestion. A high percentage of congestion is usually presented by the inappropriate use of resources in vehicular infrastructure. In addition, the integration of traffic congestion in decision making for vehicular traffic is a challenge due to its high dynamic behavior. In this paper, an optimization model over the load balancing in the congestion percentage of the streets is formulated. Later, we explore a fully congestion-oriented route discovery mechanism and we make a proposal on the communication infrastructure that should support it based on V2I and V2V communication. The mechanism is also compared with a modified Dijkstra’s approach that reacts at congestion states. Finally, we compare the results of the efficiency of the vehicle’s trip with the efficiency in the use of the capacity of the vehicular network. Full article

(This article belongs to the Special Issue Wireless Sensor Networks and the Internet of Things)

► Show Figures

Figure 1

16 pages, 1464 KiB

Open AccessArticle

A Support Vector Machine Approach for Truncated Fingerprint Image Detection from Sweeping Fingerprint Sensors

by Chi-Jim Chen, Tun-Wen Pai and Mox Cheng

Sensors 2015, 15(4), 7807-7822; https://doi.org/10.3390/s150407807 - 31 Mar 2015

Cited by 6 | Viewed by 6435

A sweeping fingerprint sensor converts fingerprints on a row by row basis through image reconstruction techniques. However, a built fingerprint image might appear to be truncated and distorted when the finger was swept across a fingerprint sensor at a non-linear speed. If the [...] Read more.

A sweeping fingerprint sensor converts fingerprints on a row by row basis through image reconstruction techniques. However, a built fingerprint image might appear to be truncated and distorted when the finger was swept across a fingerprint sensor at a non-linear speed. If the truncated fingerprint images were enrolled as reference targets and collected by any automated fingerprint identification system (AFIS), successful prediction rates for fingerprint matching applications would be decreased significantly. In this paper, a novel and effective methodology with low time computational complexity was developed for detecting truncated fingerprints in a real time manner. Several filtering rules were implemented to validate existences of truncated fingerprints. In addition, a machine learning method of supported vector machine (SVM), based on the principle of structural risk minimization, was applied to reject pseudo truncated fingerprints containing similar characteristics of truncated ones. The experimental result has shown that an accuracy rate of 90.7% was achieved by successfully identifying truncated fingerprint images from testing images before AFIS enrollment procedures. The proposed effective and efficient methodology can be extensively applied to all existing fingerprint matching systems as a preliminary quality control prior to construction of fingerprint templates. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

21 pages, 3628 KiB

Open AccessArticle

A Novel Multi-Digital Camera System Based on Tilt-Shift Photography Technology

by Tao Sun, Jun-yong Fang, Dong Zhao, Xue Liu and Qing-xi Tong

Sensors 2015, 15(4), 7823-7843; https://doi.org/10.3390/s150407823 - 31 Mar 2015

Cited by 13 | Viewed by 7406

Multi-digital camera systems (MDCS) are constantly being improved to meet the increasing requirement of high-resolution spatial data. This study identifies the insufficiencies of traditional MDCSs and proposes a new category MDCS based on tilt-shift photography to improve ability of the MDCS to acquire [...] Read more.

Multi-digital camera systems (MDCS) are constantly being improved to meet the increasing requirement of high-resolution spatial data. This study identifies the insufficiencies of traditional MDCSs and proposes a new category MDCS based on tilt-shift photography to improve ability of the MDCS to acquire high-accuracy spatial data. A prototype system, including two or four tilt-shift cameras (TSC, camera model: Nikon D90), is developed to validate the feasibility and correctness of proposed MDCS. Similar to the cameras of traditional MDCSs, calibration is also essential for TSC of new MDCS. The study constructs indoor control fields and proposes appropriate calibration methods for TSC, including digital distortion model (DDM) approach and two-step calibrated strategy. The characteristics of TSC are analyzed in detail via a calibration experiment; for example, the edge distortion of TSC. Finally, the ability of the new MDCS to acquire high-accuracy spatial data is verified through flight experiments. The results of flight experiments illustrate that geo-position accuracy of prototype system achieves 0.3 m at a flight height of 800 m, and spatial resolution of 0.15 m. In addition, results of the comparison between the traditional (MADC II) and proposed MDCS demonstrate that the latter (0.3 m) provides spatial data with higher accuracy than the former (only 0.6 m) under the same conditions. We also take the attitude that using higher accuracy TSC in the new MDCS should further improve the accuracy of the photogrammetry senior product. Full article

(This article belongs to the Section Remote Sensors)

► Show Figures

Figure 1

13 pages, 644 KiB

Open AccessArticle

Dielectric Sensors Based on Electromagnetic Energy Tunneling

by Omar Siddiqui, Mani Kashanianfard and Omar Ramahi

Sensors 2015, 15(4), 7844-7856; https://doi.org/10.3390/s150407844 - 31 Mar 2015

Cited by 11 | Viewed by 6183

We show that metallic wires embedded in narrow waveguide bends and channels demonstrate resonance behavior at specific frequencies. The electromagnetic energy at these resonances tunnels through the narrow waveguide channels with almost no propagation losses. Under the tunneling behavior, high-intensity electromagnetic fields are [...] Read more.

We show that metallic wires embedded in narrow waveguide bends and channels demonstrate resonance behavior at specific frequencies. The electromagnetic energy at these resonances tunnels through the narrow waveguide channels with almost no propagation losses. Under the tunneling behavior, high-intensity electromagnetic fields are produced in the vicinity of the metallic wires. These intense field resonances can be exploited to build highly sensitive dielectric sensors. The sensor operation is explained with the help of full-wave simulations. A practical setup consisting of a 3D waveguide bend is presented to experimentally observe the tunneling phenomenon. The tunneling frequency is predicted by determining the input impedance minima through a variational formula based on the Green function of a probe-excited parallel plate waveguide. Full article

(This article belongs to the Special Issue Metamaterial-Inspired Sensors)

► Show Figures

21 pages, 1127 KiB

Open AccessArticle

Using Multiple Barometers to Detect the Floor Location of Smart Phones with Built-in Barometric Sensors for Indoor Positioning

by Hao Xia, Xiaogang Wang, Yanyou Qiao, Jun Jian and Yuanfei Chang

Sensors 2015, 15(4), 7857-7877; https://doi.org/10.3390/s150407857 - 31 Mar 2015

Cited by 88 | Viewed by 10019

Following the popularity of smart phones and the development of mobile Internet, the demands for accurate indoor positioning have grown rapidly in recent years. Previous indoor positioning methods focused on plane locations on a floor and did not provide accurate floor positioning. In [...] Read more.

Following the popularity of smart phones and the development of mobile Internet, the demands for accurate indoor positioning have grown rapidly in recent years. Previous indoor positioning methods focused on plane locations on a floor and did not provide accurate floor positioning. In this paper, we propose a method that uses multiple barometers as references for the floor positioning of smart phones with built-in barometric sensors. Some related studies used barometric formula to investigate the altitude of mobile devices and compared the altitude with the height of the floors in a building to obtain the floor number. These studies assume that the accurate height of each floor is known, which is not always the case. They also did not consider the difference in the barometric-pressure pattern at different floors, which may lead to errors in the altitude computation. Our method does not require knowledge of the accurate heights of buildings and stories. It is robust and less sensitive to factors such as temperature and humidity and considers the difference in the barometric-pressure change trends at different floors. We performed a series of experiments to validate the effectiveness of this method. The results are encouraging. Full article

(This article belongs to the Special Issue Sensors for Indoor Mapping and Navigation)

► Show Figures

Figure 1

20 pages, 1291 KiB

Open AccessArticle

Coarse Initial Orbit Determination for a Geostationary Satellite Using Single-Epoch GPS Measurements

by Ghangho Kim, Chongwon Kim and Changdon Kee

Sensors 2015, 15(4), 7878-7897; https://doi.org/10.3390/s150407878 - 1 Apr 2015

Cited by 6 | Viewed by 6942

A practical algorithm is proposed for determining the orbit of a geostationary orbit (GEO) satellite using single-epoch measurements from a Global Positioning System (GPS) receiver under the sparse visibility of the GPS satellites. The algorithm uses three components of a state vector to [...] Read more.

A practical algorithm is proposed for determining the orbit of a geostationary orbit (GEO) satellite using single-epoch measurements from a Global Positioning System (GPS) receiver under the sparse visibility of the GPS satellites. The algorithm uses three components of a state vector to determine the satellite’s state, even when it is impossible to apply the classical single-point solutions (SPS). Through consideration of the characteristics of the GEO orbital elements and GPS measurements, the components of the state vector are reduced to three. However, the algorithm remains sufficiently accurate for a GEO satellite. The developed algorithm was tested on simulated measurements from two or three GPS satellites, and the calculated maximum position error was found to be less than approximately 40 km or even several kilometers within the geometric range, even when the classical SPS solution was unattainable. In addition, extended Kalman filter (EKF) tests of a GEO satellite with the estimated initial state were performed to validate the algorithm. In the EKF, a reliable dynamic model was adapted to reduce the probability of divergence that can be caused by large errors in the initial state. Full article

(This article belongs to the Special Issue Sensor Innovations for Spacecraft Guidance, Navigation, and Control)

► Show Figures

Figure 1

15 pages, 884 KiB

Open AccessArticle

A Simple Method for Decreasing the Liquid Junction Potential in a Flow-through-Type Differential pH Sensor Probe Consisting of pH-FETs by Exerting Spatiotemporal Control of the Liquid Junction

by Akira Yamada, Satoshi Mohri, Michihiro Nakamura and Keiji Naruse

Sensors 2015, 15(4), 7898-7912; https://doi.org/10.3390/s150407898 - 1 Apr 2015

Cited by 7 | Viewed by 6696

The liquid junction potential (LJP), the phenomenon that occurs when two electrolyte solutions of different composition come into contact, prevents accurate measurements in potentiometry. The effect of the LJP is usually remarkable in measurements of diluted solutions with low buffering capacities or low [...] Read more.

The liquid junction potential (LJP), the phenomenon that occurs when two electrolyte solutions of different composition come into contact, prevents accurate measurements in potentiometry. The effect of the LJP is usually remarkable in measurements of diluted solutions with low buffering capacities or low ion concentrations. Our group has constructed a simple method to eliminate the LJP by exerting spatiotemporal control of a liquid junction (LJ) formed between two solutions, a sample solution and a baseline solution (BLS), in a flow-through-type differential pH sensor probe. The method was contrived based on microfluidics. The sensor probe is a differential measurement system composed of two ion-sensitive field-effect transistors (ISFETs) and one Ag/AgCl electrode. With our new method, the border region of the sample solution and BLS is vibrated in order to mix solutions and suppress the overshoot after the sample solution is suctioned into the sensor probe. Compared to the conventional method without vibration, our method shortened the settling time from over two min to 15 s and reduced the measurement error by 86% to within 0.060 pH. This new method will be useful for improving the response characteristics and decreasing the measurement error of many apparatuses that use LJs. Full article

(This article belongs to the Section Chemical Sensors)

► Show Figures

Figure 1

20 pages, 2316 KiB

Open AccessArticle

Brain Process for Perception of the “Out of the Body” Tactile Illusion for Virtual Object Interaction

by Hye Jin Lee, Jaedong Lee, Chi Jung Kim, Gerard J. Kim, Eun-Soo Kim and Mincheol Whang

Sensors 2015, 15(4), 7913-7932; https://doi.org/10.3390/s150407913 - 1 Apr 2015

Cited by 10 | Viewed by 12817

“Out of the body” tactile illusion refers to the phenomenon in which one can perceive tactility as if emanating from a location external to the body without any stimulator present there. Taking advantage of such a tactile illusion is one way to provide [...] Read more.

“Out of the body” tactile illusion refers to the phenomenon in which one can perceive tactility as if emanating from a location external to the body without any stimulator present there. Taking advantage of such a tactile illusion is one way to provide and realize richer interaction feedback without employing and placing actuators directly at all stimulation target points. However, to further explore its potential, it is important to better understand the underlying physiological and neural mechanism. As such, we measured the brain wave patterns during such tactile illusion and mapped out the corresponding brain activation areas. Participants were given stimulations at different levels with the intention to create veridical (i.e., non-illusory) and phantom sensations at different locations along an external hand-held virtual ruler. The experimental data and analysis indicate that both veridical and illusory sensations involve, among others, the parietal lobe, one of the most important components in the tactile information pathway. In addition, we found that as for the illusory sensation, there is an additional processing resulting in the delay for the ERP (event-related potential) and involvement by the limbic lobe. These point to regarding illusion as a memory and recognition task as a possible explanation. The present study demonstrated some basic understanding; how humans process “virtual” objects and the way associated tactile illusion is generated will be valuable for HCI (Human-Computer Interaction). Full article

(This article belongs to the Special Issue HCI In Smart Environments)

► Show Figures

Figure 1

20 pages, 3338 KiB

Open AccessArticle

A Method for Improving the Pose Accuracy of a Robot Manipulator Based on Multi-Sensor Combined Measurement and Data Fusion

by Bailing Liu, Fumin Zhang and Xinghua Qu

Sensors 2015, 15(4), 7933-7952; https://doi.org/10.3390/s150407933 - 2 Apr 2015

Cited by 47 | Viewed by 7838

An improvement method for the pose accuracy of a robot manipulator by using a multiple-sensor combination measuring system (MCMS) is presented. It is composed of a visual sensor, an angle sensor and a series robot. The visual sensor is utilized to measure the [...] Read more.

An improvement method for the pose accuracy of a robot manipulator by using a multiple-sensor combination measuring system (MCMS) is presented. It is composed of a visual sensor, an angle sensor and a series robot. The visual sensor is utilized to measure the position of the manipulator in real time, and the angle sensor is rigidly attached to the manipulator to obtain its orientation. Due to the higher accuracy of the multi-sensor, two efficient data fusion approaches, the Kalman filter (KF) and multi-sensor optimal information fusion algorithm (MOIFA), are used to fuse the position and orientation of the manipulator. The simulation and experimental results show that the pose accuracy of the robot manipulator is improved dramatically by 38%~78% with the multi-sensor data fusion. Comparing with reported pose accuracy improvement methods, the primary advantage of this method is that it does not require the complex solution of the kinematics parameter equations, increase of the motion constraints and the complicated procedures of the traditional vision-based methods. It makes the robot processing more autonomous and accurate. To improve the reliability and accuracy of the pose measurements of MCMS, the visual sensor repeatability is experimentally studied. An optimal range of 1 x 0.8 x 1 ~ 2 x 0.8 x 1 m in the field of view (FOV) is indicated by the experimental results. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

16 pages, 2804 KiB

Open AccessArticle

Fast Video Encryption Using the H.264 Error Propagation Property for Smart Mobile Devices

by Yongwha Chung, Sungju Lee, Taewoong Jeon and Daihee Park

Sensors 2015, 15(4), 7953-7968; https://doi.org/10.3390/s150407953 - 2 Apr 2015

Cited by 20 | Viewed by 7013

In transmitting video data securely over Video Sensor Networks (VSNs), since mobile handheld devices have limited resources in terms of processor clock speed and battery size, it is necessary to develop an efficient method to encrypt video data to meet the increasing demand [...] Read more.

In transmitting video data securely over Video Sensor Networks (VSNs), since mobile handheld devices have limited resources in terms of processor clock speed and battery size, it is necessary to develop an efficient method to encrypt video data to meet the increasing demand for secure connections. Selective encryption methods can reduce the amount of computation needed while satisfying high-level security requirements. This is achieved by selecting an important part of the video data and encrypting it. In this paper, to ensure format compliance and security, we propose a special encryption method for H.264, which encrypts only the DC/ACs of I-macroblocks and the motion vectors of P-macroblocks. In particular, the proposed new selective encryption method exploits the error propagation property in an H.264 decoder and improves the collective performance by analyzing the tradeoff between the visual security level and the processing speed compared to typical selective encryption methods (i.e., I-frame, P-frame encryption, and combined I-/P-frame encryption). Experimental results show that the proposed method can significantly reduce the encryption workload without any significant degradation of visual security. Full article

(This article belongs to the Special Issue Visual Sensor Networks)

► Show Figures

Figure 1

16 pages, 2253 KiB

Open AccessArticle

A High Performance Sensor for Triaxial Cutting Force Measurement in Turning

by You Zhao, Yulong Zhao, Songbo Liang and Guanwu Zhou

Sensors 2015, 15(4), 7969-7984; https://doi.org/10.3390/s150407969 - 3 Apr 2015

Cited by 37 | Viewed by 8611

This paper presents a high performance triaxial cutting force sensor with excellent accuracy, favorable natural frequency and acceptable cross-interference for high speed turning process. Octagonal ring is selected as sensitive element of the designed sensor, which is drawn inspiration from ring theory. A [...] Read more.

This paper presents a high performance triaxial cutting force sensor with excellent accuracy, favorable natural frequency and acceptable cross-interference for high speed turning process. Octagonal ring is selected as sensitive element of the designed sensor, which is drawn inspiration from ring theory. A novel structure of two mutual-perpendicular octagonal rings is proposed and three Wheatstone full bridge circuits are specially organized in order to obtain triaxial cutting force components and restrain cross-interference. Firstly, the newly developed sensor is tested in static calibration; test results indicate that the sensor possesses outstanding accuracy in the range of 0.38%–0.83%. Secondly, impacting modal tests are conducted to identify the natural frequencies of the sensor in triaxial directions (i.e., 1147 Hz, 1122 Hz and 2035 Hz), which implies that the devised sensor can be used for cutting force measurement in a high speed lathe when the spindle speed does not exceed 17,205 rev/min in continuous cutting condition. Finally, an application of the sensor in turning process is operated to show its performance for real-time cutting force measurement; the measured cutting forces demonstrate a good accordance with the variation of cutting parameters. Thus, the developed sensor possesses perfect properties and it gains great potential for real-time cutting force measurement in turning. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

24 pages, 14085 KiB

Open AccessArticle

Network Design and Quality Checks in Automatic Orientation of Close-Range Photogrammetric Blocks

by Elisa Dall'Asta, Klaus Thoeni, Marina Santise, Gianfranco Forlani, Anna Giacomini and Riccardo Roncella

Sensors 2015, 15(4), 7985-8008; https://doi.org/10.3390/s150407985 - 3 Apr 2015

Cited by 27 | Viewed by 6372

Due to the recent improvements of automatic measurement procedures in photogrammetry, multi-view 3D reconstruction technologies are becoming a favourite survey tool. Rapidly widening structure-from-motion (SfM) software packages offer significantly easier image processing workflows than traditional photogrammetry packages. However, while most orientation and surface [...] Read more.

Due to the recent improvements of automatic measurement procedures in photogrammetry, multi-view 3D reconstruction technologies are becoming a favourite survey tool. Rapidly widening structure-from-motion (SfM) software packages offer significantly easier image processing workflows than traditional photogrammetry packages. However, while most orientation and surface reconstruction strategies will almost always succeed in any given task, estimating the quality of the result is, to some extent, still an open issue. An assessment of the precision and reliability of block orientation is necessary and should be included in every processing pipeline. Such a need was clearly felt from the results of close-range photogrammetric surveys of in situ full-scale and laboratory-scale experiments. In order to study the impact of the block control and the camera network design on the block orientation accuracy, a series of Monte Carlo simulations was performed. Two image block configurations were investigated: a single pseudo-normal strip and a circular highly-convergent block. The influence of surveying and data processing choices, such as the number and accuracy of the ground control points, autofocus and camera calibration was investigated. The research highlights the most significant aspects and processes to be taken into account for adequate in situ and laboratory surveys, when modern SfM software packages are used, and evaluates their effect on the quality of the results of the surface reconstruction. Full article

(This article belongs to the Section Remote Sensors)

► Show Figures

Figure 1

11 pages, 841 KiB

Open AccessArticle

Sensing Features of Long Period Gratings in Hollow Core Fibers

by Agostino Iadicicco and Stefania Campopiano

Sensors 2015, 15(4), 8009-8019; https://doi.org/10.3390/s150408009 - 3 Apr 2015

Cited by 27 | Viewed by 5921

We report on the investigation of the sensing features of the Long-Period fiber Gratings (LPGs) fabricated in hollow core photonic crystal fibers (HC-PCFs) by the pressure assisted Electric Arc Discharge (EAD) technique. In particular, the characterization of the LPG in terms of shift [...] Read more.

We report on the investigation of the sensing features of the Long-Period fiber Gratings (LPGs) fabricated in hollow core photonic crystal fibers (HC-PCFs) by the pressure assisted Electric Arc Discharge (EAD) technique. In particular, the characterization of the LPG in terms of shift in resonant wavelengths and changes in attenuation band depth to the environmental parameters: strain, temperature, curvature, refractive index and pressure is presented. The achieved results show that LPGs in HC-PCFs represent a novel high performance sensing platform for measurements of different physical parameters including strain, temperature and, especially, for measurements of environmental pressure. The pressure sensitivity enhancement is about four times greater if we compare LPGs in HC and standard fibers. Moreover, differently from LPGs in standard fibers, these LPGs realized in innovative fibers, i.e., the HC-PCFs, are not sensitive to surrounding refractive index. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

22 pages, 3919 KiB

Open AccessReview

Piezoelectric Micromachined Ultrasound Transducer (PMUT) Arrays for Integrated Sensing, Actuation and Imaging

by Yongqiang Qiu, James V. Gigliotti, Margeaux Wallace, Flavio Griggio, Christine E. M. Demore, Sandy Cochran and Susan Trolier-McKinstry

Sensors 2015, 15(4), 8020-8041; https://doi.org/10.3390/s150408020 - 3 Apr 2015

Cited by 345 | Viewed by 46340

Many applications of ultrasound for sensing, actuation and imaging require miniaturized and low power transducers and transducer arrays integrated with electronic systems. Piezoelectric micromachined ultrasound transducers (PMUTs), diaphragm-like thin film flexural transducers typically formed on silicon substrates, are a potential solution for integrated [...] Read more.

Many applications of ultrasound for sensing, actuation and imaging require miniaturized and low power transducers and transducer arrays integrated with electronic systems. Piezoelectric micromachined ultrasound transducers (PMUTs), diaphragm-like thin film flexural transducers typically formed on silicon substrates, are a potential solution for integrated transducer arrays. This paper presents an overview of the current development status of PMUTs and a discussion of their suitability for miniaturized and integrated devices. The thin film piezoelectric materials required to functionalize these devices are discussed, followed by the microfabrication techniques used to create PMUT elements and the constraints the fabrication imposes on device design. Approaches for electrical interconnection and integration with on-chip electronics are discussed. Electrical and acoustic measurements from fabricated PMUT arrays with up to 320 diaphragm elements are presented. The PMUTs are shown to be broadband devices with an operating frequency which is tunable by tailoring the lateral dimensions of the flexural membrane or the thicknesses of the constituent layers. Finally, the outlook for future development of PMUT technology and the potential applications made feasible by integrated PMUT devices are discussed. Full article

(This article belongs to the Special Issue Ultrasonic Sensors and Transducers for Applications in Biology, Medicine and NDT)

► Show Figures

Figure 1

12 pages, 646 KiB

Open AccessArticle

Experimental and Numerical Characterization of a Hybrid Fabry-Pérot Cavity for Temperature Sensing

by Aitor Lopez-Aldaba, Ana Margarida Rodrigues Pinto, Manuel Lopez-Amo, Orlando Frazão, José Luís Santos, José Manuel Baptista, Hardy Baierl, Jean-Louis Auguste, Raphael Jamier and Philippe Roy

Sensors 2015, 15(4), 8042-8053; https://doi.org/10.3390/s150408042 - 7 Apr 2015

Cited by 16 | Viewed by 6585

A hybrid Fabry-Pérot cavity sensing head based on a four-bridge microstructured fiber is characterized for temperature sensing. The characterization of this cavity is performed numerically and experimentally in the L-band. The sensing head output signal presents a linear variation with temperature changes, showing [...] Read more.

A hybrid Fabry-Pérot cavity sensing head based on a four-bridge microstructured fiber is characterized for temperature sensing. The characterization of this cavity is performed numerically and experimentally in the L-band. The sensing head output signal presents a linear variation with temperature changes, showing a sensitivity of 12.5 pm/°C. Moreover, this Fabry-Pérot cavity exhibits good sensitivity to polarization changes and high stability over time. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Graphical abstract

18 pages, 1224 KiB

Open AccessArticle

Hysteresis Analysis and Positioning Control for a Magnetic Shape Memory Actuator

by Jhih-Hong Lin and Mao-Hsiung Chiang

Sensors 2015, 15(4), 8054-8071; https://doi.org/10.3390/s150408054 - 7 Apr 2015

Cited by 11 | Viewed by 6167

Magnetic shape memory alloys (MSM alloys), a new kind of smart materials, have become a potential candidate in many engineering fields. MSMs have the advantage of bearing a huge strain, much larger than other materials. In addition, they also have fast response. These [...] Read more.

Magnetic shape memory alloys (MSM alloys), a new kind of smart materials, have become a potential candidate in many engineering fields. MSMs have the advantage of bearing a huge strain, much larger than other materials. In addition, they also have fast response. These characteristics make MSM a good choice in micro engineering. However, MSMs display the obvious hysteresis phenomenon of nonlinear behavior. Thus the difficulty in using the MSM element as a positioning actuator is increased due to the hysteresis. In this paper, the hysteresis phenomenon of the MSM actuator is analyzed, and the closed-loop positioning control is also implemented experimentally. For that, a modified fuzzy sliding mode control (MFSMC) is proposed. The MFSMC and the PID control are used to design the controllers for realizing the positioning control. The experimental results are compared under different experimental conditions, such as different frequency, amplitude, and loading. The experimental results show that the precise positioning control of MFSMC can be achieved satisfactorily. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

16 pages, 1391 KiB

Open AccessArticle

Nonlinear Optimization-Based Device-Free Localization with Outlier Link Rejection

by Wendong Xiao, Biao Song, Xiting Yu and Peiyuan Chen

Sensors 2015, 15(4), 8072-8087; https://doi.org/10.3390/s150408072 - 7 Apr 2015

Cited by 26 | Viewed by 6243

Device-free localization (DFL) is an emerging wireless technique for estimating the location of target that does not have any attached electronic device. It has found extensive use in Smart City applications such as healthcare at home and hospitals, location-based services at smart spaces, [...] Read more.

Device-free localization (DFL) is an emerging wireless technique for estimating the location of target that does not have any attached electronic device. It has found extensive use in Smart City applications such as healthcare at home and hospitals, location-based services at smart spaces, city emergency response and infrastructure security. In DFL, wireless devices are used as sensors that can sense the target by transmitting and receiving wireless signals collaboratively. Many DFL systems are implemented based on received signal strength (RSS) measurements and the location of the target is estimated by detecting the changes of the RSS measurements of the wireless links. Due to the uncertainty of the wireless channel, certain links may be seriously polluted and result in erroneous detection. In this paper, we propose a novel nonlinear optimization approach with outlier link rejection (NOOLR) for RSS-based DFL. It consists of three key strategies, including: (1) affected link identification by differential RSS detection; (2) outlier link rejection via geometrical positional relationship among links; (3) target location estimation by formulating and solving a nonlinear optimization problem. Experimental results demonstrate that NOOLR is robust to the fluctuation of the wireless signals with superior localization accuracy compared with the existing Radio Tomographic Imaging (RTI) approach. Full article

(This article belongs to the Special Issue Sensors and Smart Cities)

► Show Figures

Figure 1

21 pages, 4735 KiB

Open AccessArticle

Detection of Steel Fatigue Cracks with Strain Sensing Sheets Based on Large Area Electronics

by Yao Yao and Branko Glisic

Sensors 2015, 15(4), 8088-8108; https://doi.org/10.3390/s150408088 - 7 Apr 2015

Cited by 112 | Viewed by 10034

Reliable early-stage damage detection requires continuous monitoring over large areas of structure, and with sensors of high spatial resolution. Technologies based on Large Area Electronics (LAE) can enable direct sensing and can be scaled to the level required for Structural Health Monitoring (SHM) [...] Read more.

Reliable early-stage damage detection requires continuous monitoring over large areas of structure, and with sensors of high spatial resolution. Technologies based on Large Area Electronics (LAE) can enable direct sensing and can be scaled to the level required for Structural Health Monitoring (SHM) of civil structures and infrastructure. Sensing sheets based on LAE contain dense arrangements of thin-film strain sensors, associated electronics and various control circuits deposited and integrated on a flexible polyimide substrate that can cover large areas of structures. This paper presents the development stage of a prototype strain sensing sheet based on LAE for crack detection and localization. Two types of sensing-sheet arrangements with size 6 × 6 inch (152 × 152 mm) were designed and manufactured, one with a very dense arrangement of sensors and the other with a less dense arrangement of sensors. The sensing sheets were bonded to steel plates, which had a notch on the boundary, so the fatigue cracks could be generated under cyclic loading. The sensors within the sensing sheet that were close to the notch tip successfully detected the initialization of fatigue crack and localized the damage on the plate. The sensors that were away from the crack successfully detected the propagation of fatigue cracks based on the time history of the measured strain. The results of the tests have validated the general principles of the proposed sensing sheets for crack detection and identified advantages and challenges of the two tested designs. Full article

(This article belongs to the Special Issue Novel Sensors for Non-Destructive Testing and Structural Health Monitoring)

► Show Figures

Figure 1

12 pages, 3100 KiB

Open AccessArticle

Sensing Properties of Pd-Loaded Co₃O₄ Film for a ppb-Level NO Gas Sensor

by Takafumi Akamatsu, Toshio Itoh, Noriya Izu, Woosuck Shin and Kazuo Sato

Sensors 2015, 15(4), 8109-8120; https://doi.org/10.3390/s150408109 - 7 Apr 2015

Cited by 28 | Viewed by 7486

We prepared 0.1 wt%–30 wt% Pd-loaded Co₃O₄ by a colloidal mixing method and investigated the sensing properties of a Pd-loaded Co₃O₄ sensor element, such as the sensor response, 90% response time, 90% recovery time, and signal-to-noise ( [...] Read more.

We prepared 0.1 wt%–30 wt% Pd-loaded Co₃O₄ by a colloidal mixing method and investigated the sensing properties of a Pd-loaded Co₃O₄ sensor element, such as the sensor response, 90% response time, 90% recovery time, and signal-to-noise (S/N) ratio, toward low nitric oxide (NO) gas levels in the range from 50 to 200 parts per billion. The structural properties of the Pd-loaded Co₃O₄ powder were investigated using X-ray diffraction analysis and transmission electron microscopy. Pd in the powder existed as PdO. The sensor elements with 0.1 wt%–10 wt% Pd content have higher sensor properties than those without any Pd content. The response of the sensor element with a 30 wt% Pd content decreased markedly because of the aggregation and poor dispersibility of the PdO particles. High sensor response and S/N ratio toward the NO gas were achieved when a sensor element with 10 wt% Pd content was used. Full article

(This article belongs to the Special Issue Gas Sensors—Designs and Applications)

► Show Figures

Figure 1

10 pages, 259 KiB

Open AccessArticle

Corroles-Porphyrins: A Teamwork for Gas Sensor Arrays

by Rosamaria Capuano, Giuseppe Pomarico, Roberto Paolesse and Corrado Di Natale

Sensors 2015, 15(4), 8121-8130; https://doi.org/10.3390/s150408121 - 8 Apr 2015

Cited by 32 | Viewed by 6903

Porphyrins provide an excellent material for chemical sensors, and they have been used for sensing species both in air and solution. In the gas phase, the broad selectivity of porphyrins is largely dependant on molecular features, such as the metal ion complexed at [...] Read more.

Porphyrins provide an excellent material for chemical sensors, and they have been used for sensing species both in air and solution. In the gas phase, the broad selectivity of porphyrins is largely dependant on molecular features, such as the metal ion complexed at the core of the aromatic ring and the peripheral substituents. Although these features have been largely exploited to design gas sensor arrays, so far, little attention has been devoted to modify the sensing properties of these macrocycles by variation of the molecular aromatic ring. In this paper, the gas sensing properties of a porphyrin analog, the corrole, are studied in comparison with those of the parent porphyrin. Results show that changes in the aromatic ring have important consequences on the sensitivity and selectivity of the sensors and that porphyrins and corroles can positively cooperate to enhance the performance of sensor arrays. Full article

(This article belongs to the Special Issue Mass-Sensitive Sensors Based on Biomimetic Recognition)

► Show Figures

15 pages, 1691 KiB

Open AccessArticle

Decentralized System Identification Using Stochastic Subspace Identification for Wireless Sensor Networks

by Soojin Cho, Jong-Woong Park and Sung-Han Sim

Sensors 2015, 15(4), 8131-8145; https://doi.org/10.3390/s150408131 - 8 Apr 2015

Cited by 17 | Viewed by 7554

Wireless sensor networks (WSNs) facilitate a new paradigm to structural identification and monitoring for civil infrastructure. Conventional structural monitoring systems based on wired sensors and centralized data acquisition systems are costly for installation as well as maintenance. WSNs have emerged as a technology [...] Read more.

Wireless sensor networks (WSNs) facilitate a new paradigm to structural identification and monitoring for civil infrastructure. Conventional structural monitoring systems based on wired sensors and centralized data acquisition systems are costly for installation as well as maintenance. WSNs have emerged as a technology that can overcome such difficulties, making deployment of a dense array of sensors on large civil structures both feasible and economical. However, as opposed to wired sensor networks in which centralized data acquisition and processing is common practice, WSNs require decentralized computing algorithms to reduce data transmission due to the limitation associated with wireless communication. In this paper, the stochastic subspace identification (SSI) technique is selected for system identification, and SSI-based decentralized system identification (SDSI) is proposed to be implemented in a WSN composed of Imote2 wireless sensors that measure acceleration. The SDSI is tightly scheduled in the hierarchical WSN, and its performance is experimentally verified in a laboratory test using a 5-story shear building model. Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

Figure 1

17 pages, 3842 KiB

Open AccessArticle

Light-Addressable Measurement of in Vivo Tissue Oxygenation in an Unanesthetized Zebrafish Embryo via Phase-Based Phosphorescence Lifetime Detection

by Shih-Hao Huang, Chu-Hung Yu and Yi-Lung Chien

Sensors 2015, 15(4), 8146-8162; https://doi.org/10.3390/s150408146 - 8 Apr 2015

Cited by 4 | Viewed by 7989

We have developed a digital light modulation system that utilizes a modified commercial projector equipped with a laser diode as a light source for quantitative measurements of in vivo tissue oxygenation in an unanesthetized zebrafish embryo via phase-based phosphorescence lifetime detection. The oxygen-sensitive [...] Read more.

We have developed a digital light modulation system that utilizes a modified commercial projector equipped with a laser diode as a light source for quantitative measurements of in vivo tissue oxygenation in an unanesthetized zebrafish embryo via phase-based phosphorescence lifetime detection. The oxygen-sensitive phosphorescent probe (Oxyphor G4) was first inoculated into the bloodstream of 48 h post-fertilization (48 hpf) zebrafish embryos via the circulation valley to rapidly disperse probes throughout the embryo. The unanesthetized zebrafish embryo was introduced into the microfluidic device and immobilized on its lateral side by using a pneumatically actuated membrane. By controlling the illumination pattern on the digital micromirror device in the projector, the modulated excitation light can be spatially projected to illuminate arbitrarily-shaped regions of tissue of interest for in vivo oxygen measurements. We have successfully measured in vivo oxygen changes in the cardiac region and cardinal vein of a 48 hpf zebrafish embryo that experience hypoxia and subsequent normoxic conditions. Our proposed platform provides the potential for the real-time investigation of oxygen distribution in tissue microvasculature that relates to physiological stimulation and diseases in a developing organism. Full article

(This article belongs to the Special Issue Novel Biomaterials and Sensors for Tissue Engineering)

► Show Figures

Figure 1

10 pages, 1197 KiB

Open AccessArticle

Impact Wave Monitoring in Soil Using a Dynamic Fiber Sensor Based on Stimulated Brillouin Scattering

by Qingsong Cui, Sibel Pamukcu and Mesut Pervizpour

Sensors 2015, 15(4), 8163-8172; https://doi.org/10.3390/s150408163 - 8 Apr 2015

Cited by 6 | Viewed by 6345

The impact wave response of soil due to a ball drop is monitored on a 30.5 cm by 30.5 cm square soil box using a fiber sensor with dynamic strain sensing capability. The experiments are conducted in real time using a simple one-laser [...] Read more.

The impact wave response of soil due to a ball drop is monitored on a 30.5 cm by 30.5 cm square soil box using a fiber sensor with dynamic strain sensing capability. The experiments are conducted in real time using a simple one-laser one-modulator configuration with stimulated Brillouin scattering. The embedded BOTDA sensor grid successfully monitored the distribution and evolution of the inner strains of a sand bed during a mass impact on its surface. The measurement of the distributed dynamic strains was possible in several milliseconds and with 1 cm actual location resolution. This paper presents a time-domain signal analysis utilized for determining the dynamic strains in embedded fiber sensor. The results demonstrate the method to be a promising one for detection of subsurface vibration and movement in geotechnical Structure Health Monitoring (SHM). Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

19 pages, 3264 KiB

Open AccessArticle

Motion-Blurred Particle Image Restoration for On-Line Wear Monitoring

by Yeping Peng, Tonghai Wu, Shuo Wang, Ngaiming Kwok and Zhongxiao Peng

Sensors 2015, 15(4), 8173-8191; https://doi.org/10.3390/s150408173 - 8 Apr 2015

Cited by 36 | Viewed by 7393

On-line images of wear debris contain important information for real-time condition monitoring, and a dynamic imaging technique can eliminate particle overlaps commonly found in static images, for instance, acquired using ferrography. However, dynamic wear debris images captured in a running machine are unavoidably [...] Read more.

On-line images of wear debris contain important information for real-time condition monitoring, and a dynamic imaging technique can eliminate particle overlaps commonly found in static images, for instance, acquired using ferrography. However, dynamic wear debris images captured in a running machine are unavoidably blurred because the particles in lubricant are in motion. Hence, it is difficult to acquire reliable images of wear debris with an adequate resolution for particle feature extraction. In order to obtain sharp wear particle images, an image processing approach is proposed. Blurred particles were firstly separated from the static background by utilizing a background subtraction method. Second, the point spread function was estimated using power cepstrum to determine the blur direction and length. Then, the Wiener filter algorithm was adopted to perform image restoration to improve the image quality. Finally, experiments were conducted with a large number of dynamic particle images to validate the effectiveness of the proposed method and the performance of the approach was also evaluated. This study provides a new practical approach to acquire clear images for on-line wear monitoring. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

22 pages, 370 KiB

Open AccessArticle

Combining Users’ Activity Survey and Simulators to Evaluate Human Activity Recognition Systems

by Gorka Azkune, Aitor Almeida, Diego López-de-Ipiña and Liming Chen

Sensors 2015, 15(4), 8192-8213; https://doi.org/10.3390/s150408192 - 8 Apr 2015

Cited by 13 | Viewed by 9939

Evaluating human activity recognition systems usually implies following expensive and time-consuming methodologies, where experiments with humans are run with the consequent ethical and legal issues. We propose a novel evaluation methodology to overcome the enumerated problems, which is based on surveys for users [...] Read more.

Evaluating human activity recognition systems usually implies following expensive and time-consuming methodologies, where experiments with humans are run with the consequent ethical and legal issues. We propose a novel evaluation methodology to overcome the enumerated problems, which is based on surveys for users and a synthetic dataset generator tool. Surveys allow capturing how different users perform activities of daily living, while the synthetic dataset generator is used to create properly labelled activity datasets modelled with the information extracted from surveys. Important aspects, such as sensor noise, varying time lapses and user erratic behaviour, can also be simulated using the tool. The proposed methodology is shown to have very important advantages that allow researchers to carry out their work more efficiently. To evaluate the approach, a synthetic dataset generated following the proposed methodology is compared to a real dataset computing the similarity between sensor occurrence frequencies. It is concluded that the similarity between both datasets is more than significant. Full article

(This article belongs to the Special Issue Select Papers from UCAmI & IWAAL 2014 – The 8th International Conference on Ubiquitous Computing and Ambient Intelligence & the 6th International Workshop on Ambient Assisted Living (UCAmI & IWAAL 2014: Pervasive Sensing Solutions))

► Show Figures

18 pages, 13932 KiB

Open AccessArticle

Multi-Model Estimation Based Moving Object Detection for Aerial Video

by Yanning Zhang, Xiaomin Tong, Tao Yang and Wenguang Ma

Sensors 2015, 15(4), 8214-8231; https://doi.org/10.3390/s150408214 - 8 Apr 2015

Cited by 16 | Viewed by 7350

With the wide development of UAV (Unmanned Aerial Vehicle) technology, moving target detection for aerial video has become a popular research topic in the computer field. Most of the existing methods are under the registration-detection framework and can only deal with simple background [...] Read more.

With the wide development of UAV (Unmanned Aerial Vehicle) technology, moving target detection for aerial video has become a popular research topic in the computer field. Most of the existing methods are under the registration-detection framework and can only deal with simple background scenes. They tend to go wrong in the complex multi background scenarios, such as viaducts, buildings and trees. In this paper, we break through the single background constraint and perceive the complex scene accurately by automatic estimation of multiple background models. First, we segment the scene into several color blocks and estimate the dense optical flow. Then, we calculate an affine transformation model for each block with large area and merge the consistent models. Finally, we calculate subordinate degree to multi-background models pixel to pixel for all small area blocks. Moving objects are segmented by means of energy optimization method solved via Graph Cuts. The extensive experimental results on public aerial videos show that, due to multi background models estimation, analyzing each pixel’s subordinate relationship to multi models by energy minimization, our method can effectively remove buildings, trees and other false alarms and detect moving objects correctly. Full article

(This article belongs to the Section Remote Sensors)

► Show Figures

Figure 1

21 pages, 3873 KiB

Open AccessArticle

A Kinect-Based Real-Time Compressive Tracking Prototype System for Amphibious Spherical Robots

by Shaowu Pan, Liwei Shi and Shuxiang Guo

Sensors 2015, 15(4), 8232-8252; https://doi.org/10.3390/s150408232 - 8 Apr 2015

Cited by 74 | Viewed by 8224

A visual tracking system is essential as a basis for visual servoing, autonomous navigation, path planning, robot-human interaction and other robotic functions. To execute various tasks in diverse and ever-changing environments, a mobile robot requires high levels of robustness, precision, environmental adaptability and [...] Read more.

A visual tracking system is essential as a basis for visual servoing, autonomous navigation, path planning, robot-human interaction and other robotic functions. To execute various tasks in diverse and ever-changing environments, a mobile robot requires high levels of robustness, precision, environmental adaptability and real-time performance of the visual tracking system. In keeping with the application characteristics of our amphibious spherical robot, which was proposed for flexible and economical underwater exploration in 2012, an improved RGB-D visual tracking algorithm is proposed and implemented. Given the limited power source and computational capabilities of mobile robots, compressive tracking (CT), which is the effective and efficient algorithm that was proposed in 2012, was selected as the basis of the proposed algorithm to process colour images. A Kalman filter with a second-order motion model was implemented to predict the state of the target and select candidate patches or samples for the CT tracker. In addition, a variance ratio features shift (VR-V) tracker with a Kalman estimation mechanism was used to process depth images. Using a feedback strategy, the depth tracking results were used to assist the CT tracker in updating classifier parameters at an adaptive rate. In this way, most of the deficiencies of CT, including drift and poor robustness to occlusion and high-speed target motion, were partly solved. To evaluate the proposed algorithm, a Microsoft Kinect sensor, which combines colour and infrared depth cameras, was adopted for use in a prototype of the robotic tracking system. The experimental results with various image sequences demonstrated the effectiveness, robustness and real-time performance of the tracking system. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

13 pages, 1254 KiB

Open AccessArticle

An Ultrasound-Based Liquid Pressure Measurement Method in Small Diameter Pipelines Considering the Installation and Temperature

by Xue Li and Zhengxiang Song

Sensors 2015, 15(4), 8253-8265; https://doi.org/10.3390/s150408253 - 9 Apr 2015

Cited by 11 | Viewed by 7141

Liquid pressure is a key parameter for detecting and judging faults in hydraulic mechanisms, but traditional measurement methods have many deficiencies. An effective non-intrusive method using an ultrasound-based technique to measure liquid pressure in small diameter (less than 15 mm) pipelines is presented [...] Read more.

Liquid pressure is a key parameter for detecting and judging faults in hydraulic mechanisms, but traditional measurement methods have many deficiencies. An effective non-intrusive method using an ultrasound-based technique to measure liquid pressure in small diameter (less than 15 mm) pipelines is presented in this paper. The proposed method is based on the principle that the transmission speed of an ultrasonic wave in a Kneser liquid correlates with liquid pressure. Liquid pressure was calculated using the variation of ultrasonic propagation time in a liquid under different pressures: 0 Pa and X Pa. In this research the time difference was obtained by an electrical processing approach and was accurately measured to the nanosecond level through a high-resolution time measurement module. Because installation differences and liquid temperatures could influence the measurement accuracy, a special type of circuit called automatic gain control (AGC) circuit and a new back propagation network (BPN) model accounting for liquid temperature were employed to improve the measurement results. The corresponding pressure values were finally obtained by utilizing the relationship between time difference, transient temperature and liquid pressure. An experimental pressure measurement platform was built and the experimental results confirm that the proposed method has good measurement accuracy. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Graphical abstract

18 pages, 2247 KiB

Open AccessArticle

A New Method of Using Sensor Arrays for Gas Leakage Location Based on Correlation of the Time-Space Domain of Continuous Ultrasound

by Xu Bian, Yu Zhang, Yibo Li, Xiaoyue Gong and Shijiu Jin

Sensors 2015, 15(4), 8266-8283; https://doi.org/10.3390/s150408266 - 9 Apr 2015

Cited by 36 | Viewed by 7428

This paper proposes a time-space domain correlation-based method for gas leakage detection and location. It acquires the propagated signal on the skin of the plate by using a piezoelectric acoustic emission (AE) sensor array. The signal generated from the gas leakage hole (which [...] Read more.

This paper proposes a time-space domain correlation-based method for gas leakage detection and location. It acquires the propagated signal on the skin of the plate by using a piezoelectric acoustic emission (AE) sensor array. The signal generated from the gas leakage hole (which diameter is less than 2 mm) is time continuous. By collecting and analyzing signals from different sensors’ positions in the array, the correlation among those signals in the time-space domain can be achieved. Then, the directional relationship between the sensor array and the leakage source can be calculated. The method successfully solves the real-time orientation problem of continuous ultrasonic signals generated from leakage sources (the orientation time is about 15 s once), and acquires high accuracy location information of leakage sources by the combination of multiple sets of orientation results. According to the experimental results, the mean value of the location absolute error is 5.83 mm on a one square meter plate, and the maximum location error is generally within a ±10 mm interval. Meanwhile, the error variance is less than 20.17. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

18 pages, 1447 KiB

Open AccessArticle

Vineyard Yield Estimation Based on the Analysis of High Resolution Images Obtained with Artificial Illumination at Night

by Davinia Font, Marcel Tresanchez, Dani Martínez, Javier Moreno, Eduard Clotet and Jordi Palacín

Sensors 2015, 15(4), 8284-8301; https://doi.org/10.3390/s150408284 - 9 Apr 2015

Cited by 75 | Viewed by 8689

This paper presents a method for vineyard yield estimation based on the analysis of high-resolution images obtained with artificial illumination at night. First, this paper assesses different pixel-based segmentation methods in order to detect reddish grapes: threshold based, Mahalanobis distance, Bayesian classifier, linear [...] Read more.

This paper presents a method for vineyard yield estimation based on the analysis of high-resolution images obtained with artificial illumination at night. First, this paper assesses different pixel-based segmentation methods in order to detect reddish grapes: threshold based, Mahalanobis distance, Bayesian classifier, linear color model segmentation and histogram segmentation, in order to obtain the best estimation of the area of the clusters of grapes in this illumination conditions. The color spaces tested were the original RGB and the Hue-Saturation-Value (HSV). The best segmentation method in the case of a non-occluded reddish table-grape variety was the threshold segmentation applied to the H layer, with an estimation error in the area of 13.55%, improved up to 10.01% by morphological filtering. Secondly, after segmentation, two procedures for yield estimation based on a previous calibration procedure have been proposed: (1) the number of pixels corresponding to a cluster of grapes is computed and converted directly into a yield estimate; and (2) the area of a cluster of grapes is converted into a volume by means of a solid of revolution, and this volume is converted into a yield estimate; the yield errors obtained were 16% and −17%, respectively. Full article

(This article belongs to the Special Issue Agriculture and Forestry: Sensors, Technologies and Procedures)

► Show Figures

Figure 1

12 pages, 1045 KiB

Open AccessArticle

Portable and Reusable Optofluidics-Based Biosensing Platform for Ultrasensitive Detection of Sulfadimidine in Dairy Products

by Xiu-Juan Hao, Xiao-Hong Zhou, Yan Zhang, Feng Long, Lei Song and Han-Chang Shi

Sensors 2015, 15(4), 8302-8313; https://doi.org/10.3390/s150408302 - 9 Apr 2015

Cited by 22 | Viewed by 6450

Sulfadimidine (SM₂) is a highly toxic and ubiquitous pollutant which requires rapid, sensitive and portable detection method for environmental and food monitoring. Herein, the use for the detection of SM₂ of a portable optofluidics-based biosensing platform, which was used for [...] Read more.

Sulfadimidine (SM₂) is a highly toxic and ubiquitous pollutant which requires rapid, sensitive and portable detection method for environmental and food monitoring. Herein, the use for the detection of SM₂ of a portable optofluidics-based biosensing platform, which was used for the accurate detection of bisphenol A, atrazine and melamine, is reported for the first time. The proposed compact biosensing system combines the advantages of an evanescent wave immunosensor and microfluidic technology. Through the indirect competitive immunoassay, the detection limit of the proposed optofluidics-based biosensing platform for SM₂ reaches 0.05 μg·L⁻¹ at the concentration of Cy5.5-labeled antibody of 0.1 μg·mL⁻¹. Linearity is obtained over a dynamic range from 0.17 μg·L⁻¹ to 10.73 μg·L⁻¹. The surface of the fiber probe can be regenerated more than 300 times by means of 0.5% sodium dodecyl sulfate solution (pH = 1.9) washes without losing sensitivity. This method, featuring high sensitivity, portability and acceptable reproducibility shows potential in the detection of SM₂ in real milk and other dairy products. Full article

(This article belongs to the Special Issue Advances in Optical Biosensors)

► Show Figures

Graphical abstract

23 pages, 532 KiB

Open AccessArticle

Cross-Layer Cluster-Based Energy-Efficient Protocol for Wireless Sensor Networks

by Aboobeker Sidhik Koyamparambil Mammu, Unai Hernandez-Jayo, Nekane Sainz and Idoia De la Iglesia

Sensors 2015, 15(4), 8314-8336; https://doi.org/10.3390/s150408314 - 9 Apr 2015

Cited by 38 | Viewed by 6280

Recent developments in electronics and wireless communications have enabled the improvement of low-power and low-cost wireless sensors networks (WSNs). One of the most important challenges in WSNs is to increase the network lifetime due to the limited energy capacity of the network nodes. [...] Read more.

Recent developments in electronics and wireless communications have enabled the improvement of low-power and low-cost wireless sensors networks (WSNs). One of the most important challenges in WSNs is to increase the network lifetime due to the limited energy capacity of the network nodes. Another major challenge in WSNs is the hot spots that emerge as locations under heavy traffic load. Nodes in such areas quickly drain energy resources, leading to disconnection in network services. In such an environment, cross-layer cluster-based energy-efficient algorithms (CCBE) can prolong the network lifetime and energy efficiency. CCBE is based on clustering the nodes to different hexagonal structures. A hexagonal cluster consists of cluster members (CMs) and a cluster head (CH). The CHs are selected from the CMs based on nodes near the optimal CH distance and the residual energy of the nodes. Additionally, the optimal CH distance that links to optimal energy consumption is derived. To balance the energy consumption and the traffic load in the network, the CHs are rotated among all CMs. In WSNs, energy is mostly consumed during transmission and reception. Transmission collisions can further decrease the energy efficiency. These collisions can be avoided by using a contention-free protocol during the transmission period. Additionally, the CH allocates slots to the CMs based on their residual energy to increase sleep time. Furthermore, the energy consumption of CH can be further reduced by data aggregation. In this paper, we propose a data aggregation level based on the residual energy of CH and a cost-aware decision scheme for the fusion of data. Performance results show that the CCBE scheme performs better in terms of network lifetime, energy consumption and throughput compared to low-energy adaptive clustering hierarchy (LEACH) and hybrid energy-efficient distributed clustering (HEED). Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

21 pages, 1915 KiB

Open AccessArticle

A Method to Accurately Estimate the Muscular Torques of Human Wearing Exoskeletons by Torque Sensors

by Beomsoo Hwang and Doyoung Jeon

Sensors 2015, 15(4), 8337-8357; https://doi.org/10.3390/s150408337 - 9 Apr 2015

Cited by 54 | Viewed by 10099

In exoskeletal robots, the quantification of the user’s muscular effort is important to recognize the user’s motion intentions and evaluate motor abilities. In this paper, we attempt to estimate users’ muscular efforts accurately using joint torque sensor which contains the measurements of dynamic [...] Read more.

In exoskeletal robots, the quantification of the user’s muscular effort is important to recognize the user’s motion intentions and evaluate motor abilities. In this paper, we attempt to estimate users’ muscular efforts accurately using joint torque sensor which contains the measurements of dynamic effect of human body such as the inertial, Coriolis, and gravitational torques as well as torque by active muscular effort. It is important to extract the dynamic effects of the user’s limb accurately from the measured torque. The user’s limb dynamics are formulated and a convenient method of identifying user-specific parameters is suggested for estimating the user’s muscular torque in robotic exoskeletons. Experiments were carried out on a wheelchair-integrated lower limb exoskeleton, EXOwheel, which was equipped with torque sensors in the hip and knee joints. The proposed methods were evaluated by 10 healthy participants during body weight-supported gait training. The experimental results show that the torque sensors are to estimate the muscular torque accurately in cases of relaxed and activated muscle conditions. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

24 pages, 1568 KiB

Open AccessArticle

A Novel Method for Constructing a WIFI Positioning System with Efficient Manpower

by Yuanfeng Du, Dongkai Yang and Chundi Xiu

Sensors 2015, 15(4), 8358-8381; https://doi.org/10.3390/s150408358 - 10 Apr 2015

Cited by 52 | Viewed by 10451

With the rapid development of WIFI technology, WIFI-based indoor positioning technology has been widely studied for location-based services. To solve the problems related to the signal strength database adopted in the widely used fingerprint positioning technology, we first introduce a new system framework [...] Read more.

With the rapid development of WIFI technology, WIFI-based indoor positioning technology has been widely studied for location-based services. To solve the problems related to the signal strength database adopted in the widely used fingerprint positioning technology, we first introduce a new system framework in this paper, which includes a modified AP firmware and some cheap self-made WIFI sensor anchors. The periodically scanned reports regarding the neighboring APs and sensor anchors are sent to the positioning server and serve as the calibration points. Besides the calculation of correlations between the target points and the neighboring calibration points, we take full advantage of the important but easily overlooked feature that the signal attenuation model varies in different regions in the regression algorithm to get more accurate results. Thus, a novel method called RSSI Geography Weighted Regression (RGWR) is proposed to solve the fingerprint database construction problem. The average error of all the calibration points’ self-localization results will help to make the final decision of whether the database is the latest or has to be updated automatically. The effects of anchors on system performance are further researched to conclude that the anchors should be deployed at the locations that stand for the features of RSSI distributions. The proposed system is convenient for the establishment of practical positioning system and extensive experiments have been performed to validate that the proposed method is robust and manpower efficient. Full article

(This article belongs to the Special Issue Sensors for Indoor Mapping and Navigation)

► Show Figures

Figure 1

24 pages, 14042 KiB

Open AccessArticle

Georeferenced Scanning System to Estimate the Leaf Wall Area in Tree Crops

by Ignacio Del-Moral-Martínez, Jaume Arnó, Alexandre Escolà, Ricardo Sanz, Joan Masip-Vilalta, Joaquim Company-Messa and Joan R. Rosell-Polo

Sensors 2015, 15(4), 8382-8405; https://doi.org/10.3390/s150408382 - 10 Apr 2015

Cited by 16 | Viewed by 9029

This paper presents the use of a terrestrial light detection and ranging (LiDAR) system to scan the vegetation of tree crops to estimate the so-called pixelated leaf wall area (PLWA). Scanning rows laterally and considering only the half-canopy vegetation to the line of [...] Read more.

This paper presents the use of a terrestrial light detection and ranging (LiDAR) system to scan the vegetation of tree crops to estimate the so-called pixelated leaf wall area (PLWA). Scanning rows laterally and considering only the half-canopy vegetation to the line of the trunks, PLWA refers to the vertical projected area without gaps detected by LiDAR. As defined, PLWA may be different depending on the side from which the LiDAR is applied. The system is completed by a real-time kinematic global positioning system (RTK-GPS) sensor and an inertial measurement unit (IMU) sensor for positioning. At the end, a total leaf wall area (LWA) is computed and assigned to the X, Y position of each vertical scan. The final value of the area depends on the distance between two consecutive scans (or horizontal resolution), as well as the number of intercepted points within each scan, since PLWA is only computed when the laser beam detects vegetation. To verify system performance, tests were conducted related to the georeferencing task and synchronization problems between GPS time and central processing unit (CPU) time. Despite this, the overall accuracy of the system is generally acceptable. The Leaf Area Index (LAI) can then be estimated using PLWA as an explanatory variable in appropriate linear regression models. Full article

(This article belongs to the Collection Sensors in Agriculture and Forestry)

► Show Figures

23 pages, 624 KiB

Open AccessArticle

Research on Joint Parameter Inversion for an Integrated Underground Displacement 3D Measuring Sensor

by Nanying Shentu, Guohua Qiu, Qing Li, Renyuan Tong, Nankai Shentu and Yanjie Wang

Sensors 2015, 15(4), 8406-8428; https://doi.org/10.3390/s150408406 - 13 Apr 2015

Cited by 1 | Viewed by 6465

Underground displacement monitoring is a key means to monitor and evaluate geological disasters and geotechnical projects. There exist few practical instruments able to monitor subsurface horizontal and vertical displacements simultaneously due to monitoring invisibility and complexity. A novel underground displacement 3D measuring sensor [...] Read more.

Underground displacement monitoring is a key means to monitor and evaluate geological disasters and geotechnical projects. There exist few practical instruments able to monitor subsurface horizontal and vertical displacements simultaneously due to monitoring invisibility and complexity. A novel underground displacement 3D measuring sensor had been proposed in our previous studies, and great efforts have been taken in the basic theoretical research of underground displacement sensing and measuring characteristics by virtue of modeling, simulation and experiments. This paper presents an innovative underground displacement joint inversion method by mixing a specific forward modeling approach with an approximate optimization inversion procedure. It can realize a joint inversion of underground horizontal displacement and vertical displacement for the proposed 3D sensor. Comparative studies have been conducted between the measured and inversed parameters of underground horizontal and vertical displacements under a variety of experimental and inverse conditions. The results showed that when experimentally measured horizontal displacements and vertical displacements are both varied within 0 ~ 30 mm, horizontal displacement and vertical displacement inversion discrepancies are generally less than 3 mm and 1 mm, respectively, under three kinds of simulated underground displacement monitoring circumstances. This implies that our proposed underground displacement joint inversion method is robust and efficient to predict the measuring values of underground horizontal and vertical displacements for the proposed sensor. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

15 pages, 2326 KiB

Open AccessArticle

A Wireless and Portable Electronic Nose to Differentiate Musts of Different Ripeness Degree and Grape Varieties

by Manuel Aleixandre, Jose Pedro Santos, Isabel Sayago, Juan Mariano Cabellos, Teresa Arroyo and Maria Carmen Horrillo

Sensors 2015, 15(4), 8429-8443; https://doi.org/10.3390/s150408429 - 13 Apr 2015

Cited by 42 | Viewed by 6615

Two novel applications using a portable and wireless sensor system (e-nose) for the wine producing industry—The recognition and classification of musts coming from different grape ripening times and from different grape varieties—Are reported in this paper. These applications are very interesting because a [...] Read more.

Two novel applications using a portable and wireless sensor system (e-nose) for the wine producing industry—The recognition and classification of musts coming from different grape ripening times and from different grape varieties—Are reported in this paper. These applications are very interesting because a lot of varieties of grapes produce musts with low and similar aromatic intensities so they are very difficult to distinguish using a sensory panel. Therefore the system could be used to monitor the ripening evolution of the different types of grapes and to assess some useful characteristics, such as the identification of the grape variety origin and to prediction of the wine quality. Ripening grade of collected samples have been also evaluated by classical analytical techniques, measuring physicochemical parameters, such as, pH, Brix, Total Acidity (TA) and Probable Grade Alcoholic (PGA). The measurements were carried out for two different harvests, using different red (Barbera, Petit Verdot, Tempranillo, and Touriga) and white (Malvar, Malvasía, Chenin Blanc, and Sauvignon Blanc) grape musts coming from the experimental cellar of the IMIDRA at Madrid. Principal Component Analysis (PCA) and Probabilistic Neural Networks (PNN) have been used to analyse the obtained data by e-nose. In addition, and the Canonical Correlation Analysis (CCA) method has been carried out to correlate the results obtained by both technologies. Full article

(This article belongs to the Section Chemical Sensors)

► Show Figures

Graphical abstract

20 pages, 2033 KiB

Open AccessArticle

Bridge Displacement Monitoring Method Based on Laser Projection-Sensing Technology

by Xuefeng Zhao, Hao Liu, Yan Yu, Xiaodong Xu, Weitong Hu, Mingchu Li and Jingping Ou

Sensors 2015, 15(4), 8444-8463; https://doi.org/10.3390/s150408444 - 13 Apr 2015

Cited by 74 | Viewed by 10579

Bridge displacement is the most basic evaluation index of the health status of a bridge structure. The existing measurement methods for bridge displacement basically fail to realize long-term and real-time dynamic monitoring of bridge structures, because of the low degree of automation and [...] Read more.

Bridge displacement is the most basic evaluation index of the health status of a bridge structure. The existing measurement methods for bridge displacement basically fail to realize long-term and real-time dynamic monitoring of bridge structures, because of the low degree of automation and the insufficient precision, causing bottlenecks and restriction. To solve this problem, we proposed a bridge displacement monitoring system based on laser projection-sensing technology. First, the laser spot recognition method was studied. Second, the software for the displacement monitoring system was developed. Finally, a series of experiments using this system were conducted, and the results show that such a system has high measurement accuracy and speed. We aim to develop a low-cost, high-accuracy and long-term monitoring method for bridge displacement based on these preliminary efforts. Full article

(This article belongs to the Special Issue Novel Sensors for Non-Destructive Testing and Structural Health Monitoring)

► Show Figures

Figure 1

17 pages, 13781 KiB

Open AccessArticle

Detection of Atmospheric Water Deposits in Porous Media Using the TDR Technique

by Anna Nakonieczna, Marcin Kafarski, Andrzej Wilczek, Agnieszka Szypłowska, Grzegorz Janik, Małgorzata Albert and Wojciech Skierucha

Sensors 2015, 15(4), 8464-8480; https://doi.org/10.3390/s150408464 - 13 Apr 2015

Cited by 7 | Viewed by 5601

Investigating the intensity of atmospheric water deposition and its diurnal distribution is essential from the ecological perspective, especially regarding dry geographic regions. It is also important in the context of monitoring the amount of moisture present within building materials in order to protect [...] Read more.

Investigating the intensity of atmospheric water deposition and its diurnal distribution is essential from the ecological perspective, especially regarding dry geographic regions. It is also important in the context of monitoring the amount of moisture present within building materials in order to protect them from excessive humidity. The objective of this study was to test a constructed sensor and determine whether it could detect and track changes in the intensity of atmospheric water deposition. An operating principle of the device is based on the time-domain reflectometry technique. Two sensors of different plate volumes were manufactured. They were calibrated at several temperatures and tested during field measurements. The calibration turned out to be temperature independent. The outdoor measurements indicated that the upper limits of the measurement ranges of the sensors depended on the volumes of the plates and were equal to 1:2 and 2:8 mm H₂O. The respective sensitivities were equal to 3.2 x 10^-³ and 7.5 x 10^-³ g∙ps^-¹. The conducted experiments showed that the construction of the designed device and the time-domain reflectometry technique were appropriate for detecting and tracing the dynamics of atmospheric water deposition. The obtained outcomes were also collated with the readings taken in an actual soil sample. For this purpose, an open container sensor, which allows investigating atmospheric water deposition in soil, was manufactured. It turned out that the readings taken by the porous ceramic plate sensor reflected the outcomes of the measurements performed in a soil sample. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

18 pages, 744 KiB

Open AccessArticle

Noninvasive and Real-Time Plasmon Waveguide Resonance Thermometry

by Pengfei Zhang, Le Liu, Yonghong He, Yanfei Zhou, Yanhong Ji and Hui Ma

Sensors 2015, 15(4), 8481-8498; https://doi.org/10.3390/s150408481 - 13 Apr 2015

Cited by 7 | Viewed by 6386

In this paper, the noninvasive and real-time plasmon waveguide resonance (PWR) thermometry is reported theoretically and demonstrated experimentally. Owing to the enhanced evanescent field and thermal shield effect of its dielectric layer, a PWR thermometer permits accurate temperature sensing and has a wide [...] Read more.

In this paper, the noninvasive and real-time plasmon waveguide resonance (PWR) thermometry is reported theoretically and demonstrated experimentally. Owing to the enhanced evanescent field and thermal shield effect of its dielectric layer, a PWR thermometer permits accurate temperature sensing and has a wide dynamic range. A temperature measurement sensitivity of 9.4 × 10⁻³ °C is achieved and the thermo optic coefficient nonlinearity is measured in the experiment. The measurement of water cooling processes distributed in one dimension reveals that a PWR thermometer allows real-time temperature sensing and has potential to be applied for thermal gradient analysis. Apart from this, the PWR thermometer has the advantages of low cost and simple structure, since our transduction scheme can be constructed with conventional optical components and commercial coating techniques. Full article

(This article belongs to the Special Issue Optical Sensors for Chemical, Biological and Industrial Applications)

► Show Figures

Figure 1

13 pages, 904 KiB

Open AccessArticle

Monitoring of Low Levels of Furfural in Power Transformer Oil with a Sensor System Based on a POF-MIP Platform

by Nunzio Cennamo, Letizia De Maria, Girolamo D'Agostino, Luigi Zeni and Maria Pesavento

Sensors 2015, 15(4), 8499-8511; https://doi.org/10.3390/s150408499 - 13 Apr 2015

Cited by 86 | Viewed by 9534

In this work an innovative, miniaturized and low cost optical chemical sensor (POF-MIP platform), based on a molecular imprinted polymer (MIP) and surface plasmon resonance in a plastic optical fiber (POF), is presented and preliminarily tested for monitoring of furfural (furan-2-carbaldehyde) in transformer [...] Read more.

In this work an innovative, miniaturized and low cost optical chemical sensor (POF-MIP platform), based on a molecular imprinted polymer (MIP) and surface plasmon resonance in a plastic optical fiber (POF), is presented and preliminarily tested for monitoring of furfural (furan-2-carbaldehyde) in transformer oil. To this end, the optical platform was coupled to an MIP layer, highly selective for furfural. The ability of the developed sensor to directly detect furfural in the insulating oil was investigated. The detection limit of the sensor has been found to be 9 ppb, with a linear response up to about 30 ppb. However there is a sensible response up to 0.15 ppm. Because of the small linearity range, the Hill equation is suggested for the quantification. The sensor has been effectively tested in real oil samples collected from aged electrical equipment removed from service. The assessed concentration of furfural is in good agreement with that evaluated by a high pressure liquid chromatography (HLPC) method, confirming the good selectivity of the proposed sensor. Full article

(This article belongs to the Special Issue Optical Sensors for Chemical, Biological and Industrial Applications)

► Show Figures

Figure 1

15 pages, 610 KiB

Open AccessArticle

Development and Beam-Shape Analysis of an Integrated Fiber-Optic Confocal Probe for High-Precision Central Thickness Measurement of Small-Radius Lenses

by Boonsong Sutapun, Armote Somboonkaew, Ratthasart Amarit and Sataporn Chanhorm

Sensors 2015, 15(4), 8512-8526; https://doi.org/10.3390/s150408512 - 13 Apr 2015

Cited by 1 | Viewed by 6931

This work describes a new design of a fiber-optic confocal probe suitable for measuring the central thicknesses of small-radius optical lenses or similar objects. The proposed confocal probe utilizes an integrated camera that functions as a shape-encoded position-sensing device. The confocal signal for [...] Read more.

This work describes a new design of a fiber-optic confocal probe suitable for measuring the central thicknesses of small-radius optical lenses or similar objects. The proposed confocal probe utilizes an integrated camera that functions as a shape-encoded position-sensing device. The confocal signal for thickness measurement and beam-shape data for off-axis measurement can be simultaneously acquired using the proposed probe. Placing the probe’s focal point off-center relative to a sample’s vertex produces a non-circular image at the camera’s image plane that closely resembles an ellipse for small displacements. We were able to precisely position the confocal probe’s focal point relative to the vertex point of a ball lens with a radius of 2.5 mm, with a lateral resolution of 1.2 µm. The reflected beam shape based on partial blocking by an aperture was analyzed and verified experimentally. The proposed confocal probe offers a low-cost, high-precision technique, an alternative to a high-cost three-dimensional surface profiler, for tight quality control of small optical lenses during the manufacturing process. Full article

(This article belongs to the Special Issue Optical Sensors for Chemical, Biological and Industrial Applications)

► Show Figures

Graphical abstract

13 pages, 1968 KiB

Open AccessArticle

Measurement Method of Magnetic Field for the Wire Suspended Micro-Pendulum Accelerometer

by Yongle Lu, Leilei Li, Ning Hu, Yingjun Pan and Chunhua Ren

Sensors 2015, 15(4), 8527-8539; https://doi.org/10.3390/s150408527 - 13 Apr 2015

Cited by 4 | Viewed by 6552

Force producer is one of the core components of a Wire Suspended Micro-Pendulum Accelerometer; and the stability of permanent magnet in the force producer determines the consistency of the acceleration sensor’s scale factor. For an assembled accelerometer; direct measurement of magnetic field strength [...] Read more.

Force producer is one of the core components of a Wire Suspended Micro-Pendulum Accelerometer; and the stability of permanent magnet in the force producer determines the consistency of the acceleration sensor’s scale factor. For an assembled accelerometer; direct measurement of magnetic field strength is not a feasible option; as the magnetometer probe cannot be laid inside the micro-space of the sensor. This paper proposed an indirect measurement method of the remnant magnetization of Micro-Pendulum Accelerometer. The measurement is based on the working principle of the accelerometer; using the current output at several different scenarios to resolve the remnant magnetization of the permanent magnet. Iterative Least Squares algorithm was used for the adjustment of the data due to nonlinearity of this problem. The calculated remnant magnetization was 1.035 T. Compared to the true value; the error was less than 0.001 T. The proposed method provides an effective theoretical guidance for measuring the magnetic field of the Wire Suspended Micro-Pendulum Accelerometer; correcting the scale factor and temperature influence coefficients; etc. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

10 pages, 706 KiB

Open AccessArticle

A Label-Free Immunosensor for Ultrasensitive Detection of Ketamine Based on Quartz Crystal Microbalance

by Ya Yang, Yifeng Tu, Xiaoshu Wang, Jinyin Pan and Yun Ding

Sensors 2015, 15(4), 8540-8549; https://doi.org/10.3390/s150408540 - 13 Apr 2015

Cited by 25 | Viewed by 6074

In this study, we have developed a label-free immunosensor with the variation of resonance frequency (Δf) of a quartz crystal microbalance (QCM) as readout signal for ultrasensitive detection of Ketamine (KT). An optimized strategy for immobilization of KT antibody on the surface of [...] Read more.

In this study, we have developed a label-free immunosensor with the variation of resonance frequency (Δf) of a quartz crystal microbalance (QCM) as readout signal for ultrasensitive detection of Ketamine (KT). An optimized strategy for immobilization of KT antibody on the surface of the QCM chip was implemented via the self-assembly modification of 3-mercaptopropionic acid, and then activated with 1-ethyl-3- (3-dimethylaminoprophl) carbodiimide and n-hydroxysuccinimide. The specific affinity between the antibody and the antigen ensured a selective response toward KT. The Δf linearly related to the concentration of KT in the range of 1 to 40 pg/mL, with a detection limit of 0.86 pg/mL (S/N = 3). The obtained immunosensor was applied to detect the KT in spiked human urine without any pretreatment but dilution with recoveries from 91.8% to 108%. The developed sensor is promising to perform the portable or on-spot KT detection in clinic or forensic cases. Full article

(This article belongs to the Special Issue Mass-Sensitive Sensors Based on Biomimetic Recognition)

► Show Figures

Figure 1

20 pages, 2254 KiB

Open AccessArticle

EEMD Independent Extraction for Mixing Features of Rotating Machinery Reconstructed in Phase Space

by Zaichao Ma, Guangrui Wen and Cheng Jiang

Sensors 2015, 15(4), 8550-8569; https://doi.org/10.3390/s150408550 - 13 Apr 2015

Cited by 17 | Viewed by 6105

Empirical Mode Decomposition (EMD), due to its adaptive decomposition property for the non-linear and non-stationary signals, has been widely used in vibration analyses for rotating machinery. However, EMD suffers from mode mixing, which is difficult to extract features independently. Although the improved EMD, [...] Read more.

Empirical Mode Decomposition (EMD), due to its adaptive decomposition property for the non-linear and non-stationary signals, has been widely used in vibration analyses for rotating machinery. However, EMD suffers from mode mixing, which is difficult to extract features independently. Although the improved EMD, well known as the ensemble EMD (EEMD), has been proposed, mode mixing is alleviated only to a certain degree. Moreover, EEMD needs to determine the amplitude of added noise. In this paper, we propose Phase Space Ensemble Empirical Mode Decomposition (PSEEMD) integrating Phase Space Reconstruction (PSR) and Manifold Learning (ML) for modifying EEMD. We also provide the principle and detailed procedure of PSEEMD, and the analyses on a simulation signal and an actual vibration signal derived from a rubbing rotor are performed. The results show that PSEEMD is more efficient and convenient than EEMD in extracting the mixing features from the investigated signal and in optimizing the amplitude of the necessary added noise. Additionally PSEEMD can extract the weak features interfered with a certain amount of noise. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

25 pages, 3204 KiB

Open AccessArticle

Pedestrian Detection in Far-Infrared Daytime Images Using a Hierarchical Codebook of SURF

by Bassem Besbes, Alexandrina Rogozan, Adela-Maria Rus, Abdelaziz Bensrhair and Alberto Broggi

Sensors 2015, 15(4), 8570-8594; https://doi.org/10.3390/s150408570 - 13 Apr 2015

Cited by 33 | Viewed by 8746

One of the main challenges in intelligent vehicles concerns pedestrian detection for driving assistance. Recent experiments have showed that state-of-the-art descriptors provide better performances on the far-infrared (FIR) spectrum than on the visible one, even in daytime conditions, for pedestrian classification. In this [...] Read more.

One of the main challenges in intelligent vehicles concerns pedestrian detection for driving assistance. Recent experiments have showed that state-of-the-art descriptors provide better performances on the far-infrared (FIR) spectrum than on the visible one, even in daytime conditions, for pedestrian classification. In this paper, we propose a pedestrian detector with on-board FIR camera. Our main contribution is the exploitation of the specific characteristics of FIR images to design a fast, scale-invariant and robust pedestrian detector. Our system consists of three modules, each based on speeded-up robust feature (SURF) matching. The first module allows generating regions-of-interest (ROI), since in FIR images of the pedestrian shapes may vary in large scales, but heads appear usually as light regions. ROI are detected with a high recall rate with the hierarchical codebook of SURF features located in head regions. The second module consists of pedestrian full-body classification by using SVM. This module allows one to enhance the precision with low computational cost. In the third module, we combine the mean shift algorithm with inter-frame scale-invariant SURF feature tracking to enhance the robustness of our system. The experimental evaluation shows that our system outperforms, in the FIR domain, the state-of-the-art Haar-like Adaboost-cascade, histogram of oriented gradients (HOG)/linear SVM (linSVM) and MultiFtrpedestrian detectors, trained on the FIR images. Full article

(This article belongs to the Special Issue Sensors in New Road Vehicles)

► Show Figures

10 pages, 767 KiB

Open AccessArticle

Simultaneous Imaging of Two Different Cancer Biomarkers Using Aptamer-Conjugated Quantum Dots

by Jonghwan Lee, Hyo Jin Kang, Hyeok Jang, Youn Jung Lee, Yong Seung Lee, Bahy A. Ali, Abdulaziz A. Al-Khedhairy and Soonhag Kim

Sensors 2015, 15(4), 8595-8604; https://doi.org/10.3390/s150408595 - 13 Apr 2015

Cited by 30 | Viewed by 8124

Studying gene expression profile in a single cancer cell is important because multiple genes are associated with cancer development. Quantum dots (QDs) have been utilized as biological probes for imaging and detection. QDs display specific optical and electrical properties that depend on their [...] Read more.

Studying gene expression profile in a single cancer cell is important because multiple genes are associated with cancer development. Quantum dots (QDs) have been utilized as biological probes for imaging and detection. QDs display specific optical and electrical properties that depend on their size that can be applied for imaging and sensing applications. In this study, simultaneous imaging of the cancer biomarkers, tenascin-C and nucleolin, was performed using two types of aptamer-conjugated QDs. The simultaneous imaging of these two different cancer markers in three cancer cell lines was reliable and cell line-specific. Current requirements for cancer imaging technologies include the need for simple preparation methods and the ability to detect multiple cancer biomarkers and evaluate their intracellular localizations. The method employed in this study is a feasible solution to these requirements. Full article

(This article belongs to the Special Issue Inorganic Nanoparticles as Biomedical Probes)

► Show Figures

Figure 1

10 pages, 2081 KiB

Open AccessCommunication

Rapid Detection of Ebola Virus with a Reagent-Free, Point-of-Care Biosensor

by Justin T. Baca, Virginia Severns, Debbie Lovato, Darren W. Branch and Richard S. Larson

Sensors 2015, 15(4), 8605-8614; https://doi.org/10.3390/s150408605 - 14 Apr 2015

Cited by 54 | Viewed by 11362

Surface acoustic wave (SAW) sensors can rapidly detect Ebola antigens at the point-of-care without the need for added reagents, sample processing, or specialized personnel. This preliminary study demonstrates SAW biosensor detection of the Ebola virus in a concentration-dependent manner. The detection limit with [...] Read more.

Surface acoustic wave (SAW) sensors can rapidly detect Ebola antigens at the point-of-care without the need for added reagents, sample processing, or specialized personnel. This preliminary study demonstrates SAW biosensor detection of the Ebola virus in a concentration-dependent manner. The detection limit with this methodology is below the average level of viremia detected on the first day of symptoms by PCR. We observe a log-linear sensor response for highly fragmented Ebola viral particles, with a detection limit corresponding to 1.9 × 10⁴ PFU/mL prior to virus inactivation. We predict greatly improved sensitivity for intact, infectious Ebola virus. This point-of-care methodology has the potential to detect Ebola viremia prior to symptom onset, greatly enabling infection control and rapid treatment. This biosensor platform is powered by disposable AA batteries and can be rapidly adapted to detect other emerging diseases in austere conditions. Full article

(This article belongs to the Special Issue Biosensors for Pathogen Detection)

► Show Figures

Graphical abstract

9 pages, 785 KiB

Open AccessArticle

The Development of Love Wave-Based Humidity Sensors Incorporating Multiple Layers

by Lijun Wang, Jiansheng Liu and Shitang He

Sensors 2015, 15(4), 8615-8623; https://doi.org/10.3390/s150408615 - 14 Apr 2015

Cited by 13 | Viewed by 5599

A Love wave humidity sensor is developed by using a multilayer structure consisting of PVA/SiO₂ layers on an ST-90°X quartz substrate. The theoretical result shows that the sensor with such a two-layer structure can achieve a higher sensitivity and a smaller loss [...] Read more.

A Love wave humidity sensor is developed by using a multilayer structure consisting of PVA/SiO₂ layers on an ST-90°X quartz substrate. The theoretical result shows that the sensor with such a two-layer structure can achieve a higher sensitivity and a smaller loss than the structures with a single polymer layer. Comparative experiments are performed for the sensor incorporating PVA/SiO₂ layers and the sensor incorporating a PVA layer. The experimental results agree well with the theoretical predication. Full article

(This article belongs to the Special Issue Gas Sensors—Designs and Applications)

► Show Figures

Figure 1

18 pages, 7840 KiB

Open AccessArticle

Magnetic Nanoparticle Thermometer: An Investigation of Minimum Error Transmission Path and AC Bias Error

by Zhongzhou Du, Rijian Su, Wenzhong Liu and Zhixing Huang

Sensors 2015, 15(4), 8624-8641; https://doi.org/10.3390/s150408624 - 14 Apr 2015

Cited by 13 | Viewed by 5728

The signal transmission module of a magnetic nanoparticle thermometer (MNPT) was established in this study to analyze the error sources introduced during the signal flow in the hardware system. The underlying error sources that significantly affected the precision of the MNPT were determined [...] Read more.

The signal transmission module of a magnetic nanoparticle thermometer (MNPT) was established in this study to analyze the error sources introduced during the signal flow in the hardware system. The underlying error sources that significantly affected the precision of the MNPT were determined through mathematical modeling and simulation. A transfer module path with the minimum error in the hardware system was then proposed through the analysis of the variations of the system error caused by the significant error sources when the signal flew through the signal transmission module. In addition, a system parameter, named the signal-to-AC bias ratio (i.e., the ratio between the signal and AC bias), was identified as a direct determinant of the precision of the measured temperature. The temperature error was below 0.1 K when the signal-to-AC bias ratio was higher than 80 dB, and other system errors were not considered. The temperature error was below 0.1 K in the experiments with a commercial magnetic fluid (Sample SOR-10, Ocean Nanotechnology, Springdale, AR, USA) when the hardware system of the MNPT was designed with the aforementioned method. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

22 pages, 3534 KiB

Open AccessArticle

Exploring Direct 3D Interaction for Full Horizontal Parallax Light Field Displays Using Leap Motion Controller

by Vamsi Kiran Adhikarla, Jaka Sodnik, Peter Szolgay and Grega Jakus

Sensors 2015, 15(4), 8642-8663; https://doi.org/10.3390/s150408642 - 14 Apr 2015

Cited by 48 | Viewed by 11215

This paper reports on the design and evaluation of direct 3D gesture interaction with a full horizontal parallax light field display. A light field display defines a visual scene using directional light beams emitted from multiple light sources as if they are emitted [...] Read more.

This paper reports on the design and evaluation of direct 3D gesture interaction with a full horizontal parallax light field display. A light field display defines a visual scene using directional light beams emitted from multiple light sources as if they are emitted from scene points. Each scene point is rendered individually resulting in more realistic and accurate 3D visualization compared to other 3D displaying technologies. We propose an interaction setup combining the visualization of objects within the Field Of View (FOV) of a light field display and their selection through freehand gesture tracked by the Leap Motion Controller. The accuracy and usefulness of the proposed interaction setup was also evaluated in a user study with test subjects. The results of the study revealed high user preference for free hand interaction with light field display as well as relatively low cognitive demand of this technique. Further, our results also revealed some limitations and adjustments of the proposed setup to be addressed in future work. Full article

(This article belongs to the Special Issue HCI In Smart Environments)

► Show Figures

Graphical abstract

21 pages, 2348 KiB

Open AccessArticle

Multi-Camera and Structured-Light Vision System (MSVS) for Dynamic High-Accuracy 3D Measurements of Railway Tunnels

by Dong Zhan, Long Yu, Jian Xiao and Tanglong Chen

Sensors 2015, 15(4), 8664-8684; https://doi.org/10.3390/s150408664 - 14 Apr 2015

Cited by 59 | Viewed by 9190

Railway tunnel 3D clearance inspection is critical to guaranteeing railway operation safety. However, it is a challenge to inspect railway tunnel 3D clearance using a vision system, because both the spatial range and field of view (FOV) of such measurements are quite large. [...] Read more.

Railway tunnel 3D clearance inspection is critical to guaranteeing railway operation safety. However, it is a challenge to inspect railway tunnel 3D clearance using a vision system, because both the spatial range and field of view (FOV) of such measurements are quite large. This paper summarizes our work on dynamic railway tunnel 3D clearance inspection based on a multi-camera and structured-light vision system (MSVS). First, the configuration of the MSVS is described. Then, the global calibration for the MSVS is discussed in detail. The onboard vision system is mounted on a dedicated vehicle and is expected to suffer from multiple degrees of freedom vibrations brought about by the running vehicle. Any small vibration can result in substantial measurement errors. In order to overcome this problem, a vehicle motion deviation rectifying method is investigated. Experiments using the vision inspection system are conducted with satisfactory online measurement results. Full article

(This article belongs to the Special Issue Novel Sensors for Non-Destructive Testing and Structural Health Monitoring)

► Show Figures

Figure 1

27 pages, 1747 KiB

Open AccessArticle

Performance Analysis on Carrier Phase-Based Tightly-Coupled GPS/BDS/INS Integration in GNSS Degraded and Denied Environments

by Houzeng Han, Jian Wang, Jinling Wang and Xinglong Tan

Sensors 2015, 15(4), 8685-8711; https://doi.org/10.3390/s150408685 - 14 Apr 2015

Cited by 77 | Viewed by 9306

The integration of Global Navigation Satellite Systems (GNSS) carrier phases with Inertial Navigation System (INS) measurements is essential to provide accurate and continuous position, velocity and attitude information, however it is necessary to fix ambiguities rapidly and reliably to obtain high accuracy navigation [...] Read more.

The integration of Global Navigation Satellite Systems (GNSS) carrier phases with Inertial Navigation System (INS) measurements is essential to provide accurate and continuous position, velocity and attitude information, however it is necessary to fix ambiguities rapidly and reliably to obtain high accuracy navigation solutions. In this paper, we present the notion of combining the Global Positioning System (GPS), the BeiDou Navigation Satellite System (BDS) and low-cost micro-electro-mechanical sensors (MEMS) inertial systems for reliable navigation. An adaptive multipath factor-based tightly-coupled (TC) GPS/BDS/INS integration algorithm is presented and the overall performance of the integrated system is illustrated. A twenty seven states TC GPS/BDS/INS model is adopted with an extended Kalman filter (EKF), which is carried out by directly fusing ambiguity fixed double-difference (DD) carrier phase measurements with the INS predicted pseudoranges to estimate the error states. The INS-aided integer ambiguity resolution (AR) strategy is developed by using a dynamic model, a two-step estimation procedure is applied with adaptively estimated covariance matrix to further improve the AR performance. A field vehicular test was carried out to demonstrate the positioning performance of the combined system. The results show the TC GPS/BDS/INS system significantly improves the single-epoch AR reliability as compared to that of GPS/BDS-only or single satellite navigation system integrated strategy, especially for high cut-off elevations. The AR performance is also significantly improved for the combined system with adaptive covariance matrix in the presence of low elevation multipath related to the GNSS-only case. A total of fifteen simulated outage tests also show that the time to relock of the GPS/BDS signals is shortened, which improves the system availability. The results also indicate that TC integration system achieves a few centimeters accuracy in positioning based on the comparison analysis and covariance analysis, even in harsh environments (e.g., in urban canyons), thus we can see the advantage of positioning at high cut-off elevations that the combined GPS/BDS brings. Full article

(This article belongs to the Section Remote Sensors)

► Show Figures

Figure 1

20 pages, 4169 KiB

Open AccessArticle

A Study of New Pulse Auscultation System

by Ying-Yun Chen and Rong-Seng Chang

Sensors 2015, 15(4), 8712-8731; https://doi.org/10.3390/s150408712 - 14 Apr 2015

Cited by 10 | Viewed by 7850

This study presents a new type of pulse auscultation system, which uses a condenser microphone to measure pulse sound waves on the wrist, captures the microphone signal for filtering, amplifies the useful signal and outputs it to an oscilloscope in analog form for [...] Read more.

This study presents a new type of pulse auscultation system, which uses a condenser microphone to measure pulse sound waves on the wrist, captures the microphone signal for filtering, amplifies the useful signal and outputs it to an oscilloscope in analog form for waveform display and storage and delivers it to a computer to perform a Fast Fourier Transform (FFT) and convert the pulse sound waveform into a heartbeat frequency. Furthermore, it also uses an audio signal amplifier to deliver the pulse sound by speaker. The study observed the principles of Traditional Chinese Medicine’s pulsing techniques, where pulse signals at places called “cun”, “guan” and “chi” of the left hand were measured during lifting (100 g), searching (125 g) and pressing (150 g) actions. Because the system collects the vibration sound caused by the pulse, the sensor itself is not affected by the applied pressure, unlike current pulse piezoelectric sensing instruments, therefore, under any kind of pulsing pressure, it displays pulse changes and waveforms with the same accuracy. We provide an acquired pulse and waveform signal suitable for Chinese Medicine practitioners’ objective pulse diagnosis, thus providing a scientific basis for this Traditional Chinese Medicine practice. This study also presents a novel circuit design using an active filtering method. An operational amplifier with its differential features eliminates the interference from external signals, including the instant high-frequency noise. In addition, the system has the advantages of simple circuitry, cheap cost and high precision. Full article

(This article belongs to the Special Issue Smartphone-Based Sensors for Non-Invasive Physiological Monitoring)

► Show Figures

Figure 1

17 pages, 6201 KiB

Open AccessArticle

Segmentation and Tracking of Anticyclonic Eddies during a Submarine Volcanic Eruption Using Ocean Colour Imagery

by Javier Marcello, Francisco Eugenio, Sheila Estrada-Allis and Pablo Sangrà

Sensors 2015, 15(4), 8732-8748; https://doi.org/10.3390/s150408732 - 14 Apr 2015

Cited by 14 | Viewed by 7100

The eruptive phase of a submarine volcano located 2 km away from the southern coast of El Hierro Island started on October 2011. This extraordinary event provoked a dramatic perturbation of the water column. In order to understand and quantify the environmental impacts [...] Read more.

The eruptive phase of a submarine volcano located 2 km away from the southern coast of El Hierro Island started on October 2011. This extraordinary event provoked a dramatic perturbation of the water column. In order to understand and quantify the environmental impacts caused, a regular multidisciplinary monitoring was carried out using remote sensing sensors. In this context, we performed the systematic processing of every MODIS and MERIS and selected high resolution Worldview-2 imagery to provide information on the concentration of a number of biological, physical and chemical parameters. On the other hand, the eruption provided an exceptional source of tracer that allowed the study a variety of oceanographic structures. Specifically, the Canary Islands belong to a very active zone of long-lived eddies. Such structures are usually monitored using sea level anomaly fields. However these products have coarse spatial resolution and they are not suitable to perform submesoscale studies. Thanks to the volcanic tracer, detailed studies were undertaken with ocean colour imagery allowing, using the diffuse attenuation coefficient, to monitor the process of filamentation and axisymmetrization predicted by theoretical studies and numerical modelling. In our work, a novel 2-step segmentation methodology has been developed. The approach incorporates different segmentation algorithms and region growing techniques. In particular, the first step obtains an initial eddy segmentation using thresholding or clustering methods and, next, the fine detail is achieved by the iterative identification of the points to grow and the subsequent application of watershed or thresholding strategies. The methodology has demonstrated an excellent performance and robustness and it has proven to properly capture the eddy and its filaments. Full article

(This article belongs to the Section Remote Sensors)

► Show Figures

Figure 1

15 pages, 2755 KiB

Open AccessArticle

A Online NIR Sensor for the Pilot-Scale Extraction Process in Fructus Aurantii Coupled with Single and Ensemble Methods

by Xiaoning Pan, Yang Li, Zhisheng Wu, Qiao Zhang, Zhou Zheng, Xinyuan Shi and Yanjiang Qiao

Sensors 2015, 15(4), 8749-8763; https://doi.org/10.3390/s150408749 - 14 Apr 2015

Cited by 14 | Viewed by 7554

Model performance of the partial least squares method (PLS) alone and bagging-PLS was investigated in online near-infrared (NIR) sensor monitoring of pilot-scale extraction process in Fructus aurantii. High-performance liquid chromatography (HPLC) was used as a reference method to identify the active pharmaceutical [...] Read more.

Model performance of the partial least squares method (PLS) alone and bagging-PLS was investigated in online near-infrared (NIR) sensor monitoring of pilot-scale extraction process in Fructus aurantii. High-performance liquid chromatography (HPLC) was used as a reference method to identify the active pharmaceutical ingredients: naringin, hesperidin and neohesperidin. Several preprocessing methods and synergy interval partial least squares (SiPLS) and moving window partial least squares (MWPLS) variable selection methods were compared. Single quantification models (PLS) and ensemble methods combined with partial least squares (bagging-PLS) were developed for quantitative analysis of naringin, hesperidin and neohesperidin. SiPLS was compared to SiPLS combined with bagging-PLS. Final results showed the root mean square error of prediction (RMSEP) of bagging-PLS to be lower than that of PLS regression alone. For this reason, an ensemble method of online NIR sensor is here proposed as a means of monitoring the pilot-scale extraction process in Fructus aurantii, which may also constitute a suitable strategy for online NIR monitoring of CHM. Full article

(This article belongs to the Special Issue Chemical Sensors based on In Situ Spectroscopy)

► Show Figures

Graphical abstract

23 pages, 1289 KiB

Open AccessArticle

Sensor Anomaly Detection in Wireless Sensor Networks for Healthcare

by Shah Ahsanul Haque, Mustafizur Rahman and Syed Mahfuzul Aziz

Sensors 2015, 15(4), 8764-8786; https://doi.org/10.3390/s150408764 - 15 Apr 2015

Cited by 125 | Viewed by 14514

Wireless Sensor Networks (WSN) are vulnerable to various sensor faults and faulty measurements. This vulnerability hinders efficient and timely response in various WSN applications, such as healthcare. For example, faulty measurements can create false alarms which may require unnecessary intervention from healthcare personnel. [...] Read more.

Wireless Sensor Networks (WSN) are vulnerable to various sensor faults and faulty measurements. This vulnerability hinders efficient and timely response in various WSN applications, such as healthcare. For example, faulty measurements can create false alarms which may require unnecessary intervention from healthcare personnel. Therefore, an approach to differentiate between real medical conditions and false alarms will improve remote patient monitoring systems and quality of healthcare service afforded by WSN. In this paper, a novel approach is proposed to detect sensor anomaly by analyzing collected physiological data from medical sensors. The objective of this method is to effectively distinguish false alarms from true alarms. It predicts a sensor value from historic values and compares it with the actual sensed value for a particular instance. The difference is compared against a threshold value, which is dynamically adjusted, to ascertain whether the sensor value is anomalous. The proposed approach has been applied to real healthcare datasets and compared with existing approaches. Experimental results demonstrate the effectiveness of the proposed system, providing high Detection Rate (DR) and low False Positive Rate (FPR). Full article

(This article belongs to the Special Issue Wireless Sensor Network for Pervasive Medical Care)

► Show Figures

Figure 1

45 pages, 2014 KiB

Open AccessReview

Optical Nano Antennas: State of the Art, Scope and Challenges as a Biosensor Along with Human Exposure to Nano-Toxicology

by Abu Sulaiman Mohammad Zahid Kausar, Ahmed Wasif Reza, Tarik Abdul Latef, Mohammad Habib Ullah and Mohammad Ershadul Karim

Sensors 2015, 15(4), 8787-8831; https://doi.org/10.3390/s150408787 - 15 Apr 2015

Cited by 28 | Viewed by 12876

The concept of optical antennas in physical optics is still evolving. Like the antennas used in the radio frequency (RF) regime, the aspiration of optical antennas is to localize the free propagating radiation energy, and vice versa. For this purpose, optical antennas [...] Read more.

The concept of optical antennas in physical optics is still evolving. Like the antennas used in the radio frequency (RF) regime, the aspiration of optical antennas is to localize the free propagating radiation energy, and vice versa. For this purpose, optical antennas utilize the distinctive properties of metal nanostructures, which are strong plasmonic coupling elements at the optical regime. The concept of optical antennas is being advanced technologically and they are projected to be substitute devices for detection in the millimeter, infrared, and visible regimes. At present, their potential benefits in light detection, which include polarization dependency, tunability, and quick response times have been successfully demonstrated. Optical antennas also can be seen as directionally responsive elements for point detectors. This review provides an overview of the historical background of the topic, along with the basic concepts and parameters of optical antennas. One of the major parts of this review covers the use of optical antennas in biosensing, presenting biosensing applications with a broad description using different types of data. We have also mentioned the basic challenges in the path of the universal use of optical biosensors, where we have also discussed some legal matters. Full article

(This article belongs to the Special Issue Advances in Optical Biosensors)

► Show Figures

Figure 1

20 pages, 1319 KiB

Open AccessArticle

Damage Detection with Streamlined Structural Health Monitoring Data

by Jian Li, Jun Deng and Weizhi Xie

Sensors 2015, 15(4), 8832-8851; https://doi.org/10.3390/s150408832 - 15 Apr 2015

Cited by 32 | Viewed by 11319

The huge amounts of sensor data generated by large scale sensor networks in on-line structural health monitoring (SHM) systems often overwhelms the systems’ capacity for data transmission and analysis. This paper presents a new concept for an integrated SHM system in which a [...] Read more.

The huge amounts of sensor data generated by large scale sensor networks in on-line structural health monitoring (SHM) systems often overwhelms the systems’ capacity for data transmission and analysis. This paper presents a new concept for an integrated SHM system in which a streamlined data flow is used as a unifying thread to integrate the individual components of on-line SHM systems. Such an integrated SHM system has a few desirable functionalities including embedded sensor data compression, interactive sensor data retrieval, and structural knowledge discovery, which aim to enhance the reliability, efficiency, and robustness of on-line SHM systems. Adoption of this new concept will enable the design of an on-line SHM system with more uniform data generation and data handling capacity for its subsystems. To examine this concept in the context of vibration-based SHM systems, real sensor data from an on-line SHM system comprising a scaled steel bridge structure and an on-line data acquisition system with remote data access was used in this study. Vibration test results clearly demonstrated the prominent performance characteristics of the proposed integrated SHM system including rapid data access, interactive data retrieval and knowledge discovery of structural conditions on a global level. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

14 pages, 1733 KiB

Open AccessArticle

A Homogenous Fluorescence Quenching Based Assay for Specific and Sensitive Detection of Influenza Virus A Hemagglutinin Antigen

by Longyan Chen and Suresh Neethirajan

Sensors 2015, 15(4), 8852-8865; https://doi.org/10.3390/s150408852 - 15 Apr 2015

Cited by 20 | Viewed by 9083

Influenza pandemics cause millions of deaths worldwide. Effective surveillance is required to prevent their spread and facilitate the development of appropriate vaccines. In this study, we report the fabrication of a homogenous fluorescence-quenching-based assay for specific and sensitive detection of influenza virus surface [...] Read more.

Influenza pandemics cause millions of deaths worldwide. Effective surveillance is required to prevent their spread and facilitate the development of appropriate vaccines. In this study, we report the fabrication of a homogenous fluorescence-quenching-based assay for specific and sensitive detection of influenza virus surface antigen hemagglutinins (HAs). The core of the assay is composed of two nanoprobes namely the glycan-conjugated highly luminescent quantum dots (Gly-QDs), and the HA-specific antibody-modified gold nanoparticle (Ab-Au NPs). When exposed to strain-specific HA, a binding event between the HA and the two nanoprobes takes place, resulting in the formation of a sandwich complex which subsequently brings the two nanoprobes closer together. This causes a decrease in QDs fluorescence intensity due to a non-radiative energy transfer from QDs to Au NPs. A resulting correlation between the targets HA concentrations and fluorescence changes can be observed. Furthermore, by utilizing the specific interaction between HA and glycan with sialic acid residues, the assay is able to distinguish HAs originated from viral subtypes H1 (human) and H5 (avian). The detection limits in solution are found to be low nanomolar and picomolar level for sensing H1-HA and H5-HA, respectively. Slight increase in assay sensitivity was found in terms of detection limit while exposing the assay in the HA spiked in human sera solution. We believe that the developed assay could serve as a feasible and sensitive diagnostic tool for influenza virus detection and discrimination, with further improvement on the architectures. Full article

(This article belongs to the Special Issue FRET Biosensors)

► Show Figures

Figure 1

18 pages, 1948 KiB

Open AccessArticle

Monitoring the Corrosion Process of Reinforced Concrete Using BOTDA and FBG Sensors

by Jianghong Mao, Jiayun Chen, Lei Cui, Weiliang Jin, Chen Xu and Yong He

Sensors 2015, 15(4), 8866-8883; https://doi.org/10.3390/s150408866 - 15 Apr 2015

Cited by 62 | Viewed by 8605

Expansion and cracking induced by the corrosion of reinforcement concrete is the major factor in the failure of concrete durability. Therefore, monitoring of concrete cracking is critical for evaluating the safety of concrete structures. In this paper, we introduce a novel monitoring method [...] Read more.

Expansion and cracking induced by the corrosion of reinforcement concrete is the major factor in the failure of concrete durability. Therefore, monitoring of concrete cracking is critical for evaluating the safety of concrete structures. In this paper, we introduce a novel monitoring method combining Brillouin optical time domain analysis (BOTDA) and fiber Bragg grating (FBG), based on mechanical principles of concrete expansion cracking. BOTDA monitors concrete expansion and crack width, while FBG identifies the time and position of cracking. A water-pressure loading simulation test was carried out to determine the relationship between fiber strain, concrete expansion and crack width. An electrical accelerated corrosion test was also conducted to evaluate the ability of this novel sensor to monitor concrete cracking under practical conditions. Full article

(This article belongs to the Special Issue Novel Sensors for Non-Destructive Testing and Structural Health Monitoring)

► Show Figures

Figure 1

14 pages, 1204 KiB

Open AccessArticle

Comparison of Whole-Cell SELEX Methods for the Identification of Staphylococcus Aureus-Specific DNA Aptamers

by Jihea Moon, Giyoung Kim, Saet Byeol Park, Jongguk Lim and Changyeun Mo

Sensors 2015, 15(4), 8884-8897; https://doi.org/10.3390/s150408884 - 15 Apr 2015

Cited by 76 | Viewed by 11112

Whole-cell Systemic Evolution of Ligands by Exponential enrichment (SELEX) is the process by which aptamers specific to target cells are developed. Aptamers selected by whole-cell SELEX have high affinity and specificity for bacterial surface molecules and live bacterial targets. To identify DNA aptamers [...] Read more.

Whole-cell Systemic Evolution of Ligands by Exponential enrichment (SELEX) is the process by which aptamers specific to target cells are developed. Aptamers selected by whole-cell SELEX have high affinity and specificity for bacterial surface molecules and live bacterial targets. To identify DNA aptamers specific to Staphylococcus aureus, we applied our rapid whole-cell SELEX method to a single-stranded ssDNA library. To improve the specificity and selectivity of the aptamers, we designed, selected, and developed two categories of aptamers that were selected by two kinds of whole-cell SELEX, by mixing and combining FACS analysis and a counter-SELEX process. Using this approach, we have developed a biosensor system that employs a high affinity aptamer for detection of target bacteria. FAM-labeled aptamer sequences with high binding to S. aureus, as determined by fluorescence spectroscopic analysis, were identified, and aptamer A14, selected by the basic whole-cell SELEX using a once-off FACS analysis, and which had a high binding affinity and specificity, was chosen. The binding assay was evaluated using FACS analysis. Our study demonstrated the development of a set of whole-cell SELEX derived aptamers specific to S. aureus; this approach can be used in the identification of other bacteria. Full article

(This article belongs to the Special Issue Biosensors for Pathogen Detection)

► Show Figures

Figure 1

21 pages, 950 KiB

Open AccessArticle

Operational Safety Assessment of Turbo Generators with Wavelet Rényi Entropy from Sensor-Dependent Vibration Signals

by Xiaoli Zhang, Baojian Wang and Xuefeng Chen

Sensors 2015, 15(4), 8898-8918; https://doi.org/10.3390/s150408898 - 16 Apr 2015

Cited by 9 | Viewed by 6156

With the rapid development of sensor technology, various professional sensors are installed on modern machinery to monitor operational processes and assure operational safety, which play an important role in industry and society. In this work a new operational safety assessment approach with wavelet [...] Read more.

With the rapid development of sensor technology, various professional sensors are installed on modern machinery to monitor operational processes and assure operational safety, which play an important role in industry and society. In this work a new operational safety assessment approach with wavelet Rényi entropy utilizing sensor-dependent vibration signals is proposed. On the basis of a professional sensor and the corresponding system, sensor-dependent vibration signals are acquired and analyzed by a second generation wavelet package, which reflects time-varying operational characteristic of individual machinery. Derived from the sensor-dependent signals’ wavelet energy distribution over the observed signal frequency range, wavelet Rényi entropy is defined to compute the operational uncertainty of a turbo generator, which is then associated with its operational safety degree. The proposed method is applied in a 50 MW turbo generator, whereupon it is proved to be reasonable and effective for operation and maintenance. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Graphical abstract

12 pages, 2917 KiB

Open AccessArticle

Ultra-High Sensitivity Zinc Oxide Nanocombs for On-Chip Room Temperature Carbon Monoxide Sensing

by Xiaofang Pan and Xiaojin Zhao

Sensors 2015, 15(4), 8919-8930; https://doi.org/10.3390/s150408919 - 16 Apr 2015

Cited by 26 | Viewed by 6779

In this paper, we report an on-chip gas sensor based on novel zinc oxide (ZnO) nanocombs for carbon monoxide (CO) sensing. With ZnO gas sensing nanocombs fully integrated on a single silicon chip, the concept of low cost complementary-metal-oxide-semiconductor (CMOS) microsensor capable of [...] Read more.

In this paper, we report an on-chip gas sensor based on novel zinc oxide (ZnO) nanocombs for carbon monoxide (CO) sensing. With ZnO gas sensing nanocombs fully integrated on a single silicon chip, the concept of low cost complementary-metal-oxide-semiconductor (CMOS) microsensor capable of on-chip gas sensing and processing is enabled. Compared with all previous implementations, the proposed ZnO nanocombs feature much larger effective sensing area and exhibit ultra-high sensitivity even at the room temperature. Specifically, at room temperature, we demonstrate peak sensitivities as high as 7.22 and 8.93 for CO concentrations of 250 ppm and 500 ppm, respectively. As a result, by operating the proposed ZnO-nanocomb-based gas sensor at the room temperature, the widely adopted power consuming heating components are completely removed. This leads to not only great power saving, but also full compatibility between the gas sensor and the on-chip circuitry in term of acceptable operating temperature. In addition, the reported fast response/recovery time of ~200 s/~50 s (250 ppm CO) makes it well suited to real-life applications. Full article

(This article belongs to the Special Issue On-Chip Sensors)

► Show Figures

Figure 1

14 pages, 1207 KiB

Open AccessArticle

A Reliable and Simple Method for Fabricating a Poly(Dimethylsiloxane) Electrospray Ionization Chip with a Corner-Integrated Emitter

by Xiang Qian, Jie Xu, Cilong Yu, Yan Chen, Quan Yu, Kai Ni and Xiaohao Wang

Sensors 2015, 15(4), 8931-8944; https://doi.org/10.3390/s150408931 - 16 Apr 2015

Cited by 13 | Viewed by 8343

Monolithically integrated emitters have been increasingly applied to microfluidic devices that are coupled to mass spectrometers (MS) as electrospray ionization sources (ESI). A new method was developed to fabricate a duplicable structure which integrated the emitter into a poly(dimethylsiloxane) chip corner. Two photoresist [...] Read more.

Monolithically integrated emitters have been increasingly applied to microfluidic devices that are coupled to mass spectrometers (MS) as electrospray ionization sources (ESI). A new method was developed to fabricate a duplicable structure which integrated the emitter into a poly(dimethylsiloxane) chip corner. Two photoresist layers containing a raised base which guaranteed the precise integration of the electrospray tip emitter and ensured that the cutting out of the tip exerted no influence even during repeated prototyping were used to ease the operation of the process. Highly stable ESI-MS performance was obtained and the results were compared with those of a commercial fused-silica capillary source. Furthermore, chip-to-chip and run-to-run results indicated both reliability and reproducibility during repeated fabrication. These results reveal that the proposed chip can provide an ideal ion source for MS across many applications, especially with the perspective to be widely used in portable MS during on-site analysis. Full article

(This article belongs to the Special Issue On-Chip Sensors)

► Show Figures

Figure 1

23 pages, 3477 KiB

Open AccessArticle

Optimization of Capacitive Acoustic Resonant Sensor Using Numerical Simulation and Design of Experiment

by Rubaiyet Iftekharul Haque, Christophe Loussert, Michelle Sergent, Patrick Benaben and Xavier Boddaert

Sensors 2015, 15(4), 8945-8967; https://doi.org/10.3390/s150408945 - 16 Apr 2015

Cited by 9 | Viewed by 7609

Optimization of the acoustic resonant sensor requires a clear understanding of how the output responses of the sensor are affected by the variation of different factors. During this work, output responses of a capacitive acoustic transducer, such as membrane displacement, quality factor, and [...] Read more.

Optimization of the acoustic resonant sensor requires a clear understanding of how the output responses of the sensor are affected by the variation of different factors. During this work, output responses of a capacitive acoustic transducer, such as membrane displacement, quality factor, and capacitance variation, are considered to evaluate the sensor design. The six device parameters taken into consideration are membrane radius, backplate radius, cavity height, air gap, membrane tension, and membrane thickness. The effects of factors on the output responses of the transducer are investigated using an integrated methodology that combines numerical simulation and design of experiments (DOE). A series of numerical experiments are conducted to obtain output responses for different combinations of device parameters using finite element methods (FEM). Response surface method is used to identify the significant factors and to develop the empirical models for the output responses. Finally, these results are utilized to calculate the optimum device parameters using multi-criteria optimization with desirability function. Thereafter, the validating experiments are designed and deployed using the numerical simulation to crosscheck the responses. Full article

(This article belongs to the Special Issue Acoustic Waveguide Sensors)

► Show Figures

Graphical abstract

13 pages, 2063 KiB

Open AccessArticle

Stand-Off Biodetection with Free-Space Coupled Asymmetric Microsphere Cavities

by Zachary Ballard, Martin D. Baaske and Frank Vollmer

Sensors 2015, 15(4), 8968-8980; https://doi.org/10.3390/s150408968 - 16 Apr 2015

Cited by 30 | Viewed by 7441

Asymmetric microsphere resonant cavities (ARCs) allow for free-space coupling to high quality (Q) whispering gallery modes (WGMs) while exhibiting highly directional light emission, enabling WGM resonance measurements in the far-field. These remarkable characteristics make “stand-off” biodetection in which no coupling device is required [...] Read more.

Asymmetric microsphere resonant cavities (ARCs) allow for free-space coupling to high quality (Q) whispering gallery modes (WGMs) while exhibiting highly directional light emission, enabling WGM resonance measurements in the far-field. These remarkable characteristics make “stand-off” biodetection in which no coupling device is required in near-field contact with the resonator possible. Here we show asymmetric microsphere resonators fabricated from optical fibers which support dynamical tunneling to excite high-Q WGMs, and demonstrate free-space coupling to modes in an aqueous environment. We characterize the directional emission by fluorescence imaging, demonstrate coupled mode effects due to free space coupling by dynamical tunneling, and detect adsorption kinetics of a protein in aqueous solution. Based on our approach, new, more robust WGM biodetection schemes involving microfluidics and in-vivo measurements can be designed. Full article

(This article belongs to the Special Issue Advances in Optical Biosensors)

► Show Figures

Graphical abstract

19 pages, 1477 KiB

Open AccessArticle

Determination of Zinc, Cadmium and Lead Bioavailability in Contaminated Soils at the Single-Cell Level by a Combination of Whole-Cell Biosensors and Flow Cytometry

by Quentin Hurdebise, Cédric Tarayre, Christophe Fischer, Gilles Colinet, Serge Hiligsmann and Frank Delvigne

Sensors 2015, 15(4), 8981-8999; https://doi.org/10.3390/s150408981 - 16 Apr 2015

Cited by 34 | Viewed by 8022

Zinc, lead and cadmium are metallic trace elements (MTEs) that are widespread in the environment and tend to accumulate in soils because of their low mobility and non-degradability. The purpose of this work is to evaluate the applicability of biosensors as tools able [...] Read more.

Zinc, lead and cadmium are metallic trace elements (MTEs) that are widespread in the environment and tend to accumulate in soils because of their low mobility and non-degradability. The purpose of this work is to evaluate the applicability of biosensors as tools able to provide data about the bioavailability of such MTEs in contaminated soils. Here, we tested the genetically-engineered strain Escherichia coli pP_ZntAgfp as a biosensor applicable to the detection of zinc, lead and cadmium by the biosynthesis of green fluorescent protein (GFP) accumulating inside the cells. Flow cytometry was used to investigate the fluorescence induced by the MTEs. A curvilinear response to zinc between 0 and 25 mg/L and another curvilinear response to cadmium between 0 and 1.5 mg/L were highlighted in liquid media, while lead did not produce exploitable results. The response relating to a Zn²⁺/Cd²⁺ ratio of 10 was further investigated. In these conditions, E. coli pP_ZntAgfp responded to cadmium only. Several contaminated soils with a Zn²⁺/Cd²⁺ ratio of 10 were analyzed with the biosensor, and the metallic concentrations were also measured by atomic absorption spectroscopy. Our results showed that E. coli pP_ZntAgfp could be used as a monitoring tool for contaminated soils being processed. Full article

(This article belongs to the Special Issue Intracellular Sensing)

► Show Figures

Figure 1

22 pages, 1025 KiB

Open AccessArticle

An Ultrasonic Sensor System Based on a Two-Dimensional State Method for Highway Vehicle Violation Detection Applications

by Jun Liu, Jiuqiang Han, Hongqiang Lv and Bing Li

Sensors 2015, 15(4), 9000-9021; https://doi.org/10.3390/s150409000 - 16 Apr 2015

Cited by 19 | Viewed by 10838

With the continuing growth of highway construction and vehicle use expansion all over the world, highway vehicle traffic rule violation (TRV) detection has become more and more important so as to avoid traffic accidents and injuries in intelligent transportation systems (ITS) and vehicular [...] Read more.

With the continuing growth of highway construction and vehicle use expansion all over the world, highway vehicle traffic rule violation (TRV) detection has become more and more important so as to avoid traffic accidents and injuries in intelligent transportation systems (ITS) and vehicular ad hoc networks (VANETs). Since very few works have contributed to solve the TRV detection problem by moving vehicle measurements and surveillance devices, this paper develops a novel parallel ultrasonic sensor system that can be used to identify the TRV behavior of a host vehicle in real-time. Then a two-dimensional state method is proposed, utilizing the spacial state and time sequential states from the data of two parallel ultrasonic sensors to detect and count the highway vehicle violations. Finally, the theoretical TRV identification probability is analyzed, and actual experiments are conducted on different highway segments with various driving speeds, which indicates that the identification accuracy of the proposed method can reach about 90.97%. Full article

(This article belongs to the Special Issue Sensors in New Road Vehicles)

► Show Figures

Figure 1

17 pages, 1134 KiB

Open AccessArticle

Comparison of sEMG-Based Feature Extraction and Motion Classification Methods for Upper-Limb Movement

by Shuxiang Guo, Muye Pang, Baofeng Gao, Hideyuki Hirata and Hidenori Ishihara

Sensors 2015, 15(4), 9022-9038; https://doi.org/10.3390/s150409022 - 16 Apr 2015

Cited by 75 | Viewed by 9674

The surface electromyography (sEMG) technique is proposed for muscle activation detection and intuitive control of prostheses or robot arms. Motion recognition is widely used to map sEMG signals to the target motions. One of the main factors preventing the implementation of this kind [...] Read more.

The surface electromyography (sEMG) technique is proposed for muscle activation detection and intuitive control of prostheses or robot arms. Motion recognition is widely used to map sEMG signals to the target motions. One of the main factors preventing the implementation of this kind of method for real-time applications is the unsatisfactory motion recognition rate and time consumption. The purpose of this paper is to compare eight combinations of four feature extraction methods (Root Mean Square (RMS), Detrended Fluctuation Analysis (DFA), Weight Peaks (WP), and Muscular Model (MM)) and two classifiers (Neural Networks (NN) and Support Vector Machine (SVM)), for the task of mapping sEMG signals to eight upper-limb motions, to find out the relation between these methods and propose a proper combination to solve this issue. Seven subjects participated in the experiment and six muscles of the upper-limb were selected to record sEMG signals. The experimental results showed that NN classifier obtained the highest recognition accuracy rate (88.7%) during the training process while SVM performed better in real-time experiments (85.9%). For time consumption, SVM took less time than NN during the training process but needed more time for real-time computation. Among the four feature extraction methods, WP had the highest recognition rate for the training process (97.7%) while MM performed the best during real-time tests (94.3%). The combination of MM and NN is recommended for strict real-time applications while a combination of MM and SVM will be more suitable when time consumption is not a key requirement. Full article

(This article belongs to the Special Issue Sensor Systems for Motion Capture and Interpretation)

► Show Figures

Figure 1

39 pages, 1678 KiB

Open AccessArticle

A Multi-User Game-Theoretical Multipath Routing Protocol to Send Video-Warning Messages over Mobile Ad Hoc Networks

by Ahmad Mohamad Mezher, Mónica Aguilar Igartua, Luis J. De la Cruz Llopis, Esteve Pallarès Segarra, Carolina Tripp-Barba, Luis Urquiza-Aguiar, Jordi Forné and Emilio Sanvicente Gargallo

Sensors 2015, 15(4), 9039-9077; https://doi.org/10.3390/s150409039 - 17 Apr 2015

Cited by 7 | Viewed by 8968

The prevention of accidents is one of the most important goals of ad hoc networks in smart cities. When an accident happens, dynamic sensors (e.g., citizens with smart phones or tablets, smart vehicles and buses, etc.) could shoot a video clip of the [...] Read more.

The prevention of accidents is one of the most important goals of ad hoc networks in smart cities. When an accident happens, dynamic sensors (e.g., citizens with smart phones or tablets, smart vehicles and buses, etc.) could shoot a video clip of the accident and send it through the ad hoc network. With a video message, the level of seriousness of the accident could be much better evaluated by the authorities (e.g., health care units, police and ambulance drivers) rather than with just a simple text message. Besides, other citizens would be rapidly aware of the incident. In this way, smart dynamic sensors could participate in reporting a situation in the city using the ad hoc network so it would be possible to have a quick reaction warning citizens and emergency units. The deployment of an efficient routing protocol to manage video-warning messages in mobile Ad hoc Networks (MANETs) has important benefits by allowing a fast warning of the incident, which potentially can save lives. To contribute with this goal, we propose a multipath routing protocol to provide video-warning messages in MANETs using a novel game-theoretical approach. As a base for our work, we start from our previous work, where a 2-players game-theoretical routing protocol was proposed to provide video-streaming services over MANETs. In this article, we further generalize the analysis made for a general number of N players in the MANET. Simulations have been carried out to show the benefits of our proposal, taking into account the mobility of the nodes and the presence of interfering traffic. Finally, we also have tested our approach in a vehicular ad hoc network as an incipient start point to develop a novel proposal specifically designed for VANETs. Full article

(This article belongs to the Special Issue Sensors and Smart Cities)

► Show Figures

19 pages, 1590 KiB

Open AccessArticle

Application of Micro-Electro-Mechanical Sensors Contactless NDT of Concrete Structures

by Suyun Ham and John S. Popovics

Sensors 2015, 15(4), 9078-9096; https://doi.org/10.3390/s150409078 - 17 Apr 2015

Cited by 35 | Viewed by 9919

The utility of micro-electro-mechanical sensors (MEMS) for application in air-coupled (contactless or noncontact) sensing to concrete nondestructive testing (NDT) is studied in this paper. The fundamental operation and characteristics of MEMS are first described. Then application of MEMS sensors toward established concrete test [...] Read more.

The utility of micro-electro-mechanical sensors (MEMS) for application in air-coupled (contactless or noncontact) sensing to concrete nondestructive testing (NDT) is studied in this paper. The fundamental operation and characteristics of MEMS are first described. Then application of MEMS sensors toward established concrete test methods, including vibration resonance, impact-echo, ultrasonic surface wave, and multi-channel analysis of surface waves (MASW), is demonstrated. In each test application, the performance of MEMS is compared with conventional contactless and contact sensing technology. Favorable performance of the MEMS sensors demonstrates the potential of the technology for applied contactless NDT efforts. Objective: To illustrate the utility of air-coupled MEMS sensors for concrete NDT, as compared with conventional sensor technology. Full article

(This article belongs to the Special Issue Novel Sensors for Non-Destructive Testing and Structural Health Monitoring)

► Show Figures

Figure 1

15 pages, 2048 KiB

Open AccessArticle

Highly Sensitive and Selective Colorimetric and Off-On Fluorescent Reversible Chemosensors for Al³⁺ Based on the Rhodamine Fluorophore

by Naveen Mergu, Ashok Kumar Singh and Vinod Kumar Gupta

Sensors 2015, 15(4), 9097-9111; https://doi.org/10.3390/s150409097 - 17 Apr 2015

Cited by 69 | Viewed by 9203

A series of rhodamine derivatives L1–L3 have been prepared and characterized by IR, ¹H-NMR, ¹³C-NMR and ESI-MS. These compounds exhibited selective and sensitive “turn-on” fluorescent and colorimetric responses to Al³⁺ in methanol. Upon the addition of Al(III), the [...] Read more.

A series of rhodamine derivatives L1–L3 have been prepared and characterized by IR, ¹H-NMR, ¹³C-NMR and ESI-MS. These compounds exhibited selective and sensitive “turn-on” fluorescent and colorimetric responses to Al³⁺ in methanol. Upon the addition of Al(III), the spiro ring was opened and a metal-probe complex was formed in a 1:1 stoichiometry, as was further confirmed by ESI-MS spectroscopy. The chemo-dosimeters L1–L3 exhibited good binding constants and low detection limits towards Al(III). We also successfully demonstrate the reversibility of the metal to ligand complexation (opened ring to spirolactam ring). Full article

(This article belongs to the Section Chemical Sensors)

► Show Figures

Figure 1

24 pages, 1195 KiB

Open AccessArticle

Basic Characteristics of a Macroscopic Measure for Detecting Abnormal Changes in a Multiagent System

by Tetsuo Kinoshita

Sensors 2015, 15(4), 9112-9135; https://doi.org/10.3390/s150409112 - 17 Apr 2015

Cited by 5 | Viewed by 5023

Multiagent application systems must deal with various changes in both the system and the system environment at runtime. Generally, such changes have undesirable negative effects on the system. To manage and control the system, it is important to observe and detect negative effects [...] Read more.

Multiagent application systems must deal with various changes in both the system and the system environment at runtime. Generally, such changes have undesirable negative effects on the system. To manage and control the system, it is important to observe and detect negative effects using an appropriate observation function of the system’s behavior. This paper focuses on the design of this function and proposes a new macroscopic measure with which to observe behavioral characteristics of a runtime multiagent system. The proposed measure is designed as the variance of fluctuation of a macroscopic activity factor of the whole system, based on theoretical analysis of the macroscopic behavioral model of a multiagent system. Experiments are conducted to investigate basic characteristics of the proposed measure, using a test bed system. The results of experiments show that the proposed measure reacts quickly and increases drastically in response to abnormal changes in the system. Hence, the proposed measure is considered a measure that can be used to detect undesirable changes in a multiagent system. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

20 pages, 897 KiB

Open AccessArticle

Genetic Algorithm (GA)-Based Inclinometer Layout Optimization

by Weijie Liang, Ping Zhang, Xianping Chen, Miao Cai and Daoguo Yang

Sensors 2015, 15(4), 9136-9155; https://doi.org/10.3390/s150409136 - 17 Apr 2015

Cited by 10 | Viewed by 6648

This paper presents numerical simulation results of an airflow inclinometer with sensitivity studies and thermal optimization of the printed circuit board (PCB) layout for an airflow inclinometer based on a genetic algorithm (GA). Due to the working principle of the gas sensor, the [...] Read more.

This paper presents numerical simulation results of an airflow inclinometer with sensitivity studies and thermal optimization of the printed circuit board (PCB) layout for an airflow inclinometer based on a genetic algorithm (GA). Due to the working principle of the gas sensor, the changes of the ambient temperature may cause dramatic voltage drifts of sensors. Therefore, eliminating the influence of the external environment for the airflow is essential for the performance and reliability of an airflow inclinometer. In this paper, the mechanism of an airflow inclinometer and the influence of different ambient temperatures on the sensitivity of the inclinometer will be examined by the ANSYS-FLOTRAN CFD program. The results show that with changes of the ambient temperature on the sensing element, the sensitivity of the airflow inclinometer is inversely proportional to the ambient temperature and decreases when the ambient temperature increases. GA is used to optimize the PCB thermal layout of the inclinometer. The finite-element simulation method (ANSYS) is introduced to simulate and verify the results of our optimal thermal layout, and the results indicate that the optimal PCB layout greatly improves (by more than 50%) the sensitivity of the inclinometer. The study may be useful in the design of PCB layouts that are related to sensitivity improvement of gas sensors. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

23 pages, 1093 KiB

Open AccessArticle

Inertial Pocket Navigation System: Unaided 3D Positioning

by Estefania Munoz Diaz

Sensors 2015, 15(4), 9156-9178; https://doi.org/10.3390/s150409156 - 17 Apr 2015

Cited by 68 | Viewed by 8994

Inertial navigation systems use dead-reckoning to estimate the pedestrian’s position. There are two types of pedestrian dead-reckoning, the strapdown algorithm and the step-and-heading approach. Unlike the strapdown algorithm, which consists of the double integration of the three orthogonal accelerometer readings, the step-and-heading approach [...] Read more.

Inertial navigation systems use dead-reckoning to estimate the pedestrian’s position. There are two types of pedestrian dead-reckoning, the strapdown algorithm and the step-and-heading approach. Unlike the strapdown algorithm, which consists of the double integration of the three orthogonal accelerometer readings, the step-and-heading approach lacks the vertical displacement estimation. We propose the first step-and-heading approach based on unaided inertial data solving 3D positioning. We present a step detector for steps up and down and a novel vertical displacement estimator. Our navigation system uses the sensor introduced in the front pocket of the trousers, a likely location of a smartphone. The proposed algorithms are based on the opening angle of the leg or pitch angle. We analyzed our step detector and compared it with the state-of-the-art, as well as our already proposed step length estimator. Lastly, we assessed our vertical displacement estimator in a real-world scenario. We found that our algorithms outperform the literature step and heading algorithms and solve 3D positioning using unaided inertial data. Additionally, we found that with the pitch angle, five activities are distinguishable: standing, sitting, walking, walking up stairs and walking down stairs. This information complements the pedestrian location and is of interest for applications, such as elderly care. Full article

(This article belongs to the Special Issue Sensors for Indoor Mapping and Navigation)

► Show Figures

10 pages, 1624 KiB

Open AccessArticle

Measuring the Contractile Response of Isolated Tissue Using an Image Sensor

by David Díaz-Martín, José Gerardo Hernández-Jiménez, Manuel Rodríguez-Valido and Ricardo Borges

Sensors 2015, 15(4), 9179-9188; https://doi.org/10.3390/s150409179 - 20 Apr 2015

Cited by 3 | Viewed by 5546

Isometric or isotonic transducers have traditionally been used to study the contractile/relaxation effects of drugs on isolated tissues. However, these mechanical sensors are expensive and delicate, and they are associated with certain disadvantages when performing experiments in the laboratory. In this paper, a [...] Read more.

Isometric or isotonic transducers have traditionally been used to study the contractile/relaxation effects of drugs on isolated tissues. However, these mechanical sensors are expensive and delicate, and they are associated with certain disadvantages when performing experiments in the laboratory. In this paper, a method that uses an image sensor to measure the contractile effect of drugs on blood vessel rings and other luminal organs is presented. The new method is based on an image-processing algorithm, and it provides a fast, easy and non-expensive way to analyze the effects of such drugs. In our tests, we have obtained dose-response curves from rat aorta rings that are equivalent to those achieved with classical mechanic sensors. Full article

(This article belongs to the Special Issue Novel Biomaterials and Sensors for Tissue Engineering)

► Show Figures

Graphical abstract

21 pages, 907 KiB

Open AccessArticle

A Survey of MAC Protocols for Cognitive Radio Body Area Networks

by Sabin Bhandari and Sangman Moh

Sensors 2015, 15(4), 9189-9209; https://doi.org/10.3390/s150409189 - 20 Apr 2015

Cited by 28 | Viewed by 7461

The advancement in electronics, wireless communications and integrated circuits has enabled the development of small low-power sensors and actuators that can be placed on, in or around the human body. A wireless body area network (WBAN) can be effectively used to deliver the [...] Read more.

The advancement in electronics, wireless communications and integrated circuits has enabled the development of small low-power sensors and actuators that can be placed on, in or around the human body. A wireless body area network (WBAN) can be effectively used to deliver the sensory data to a central server, where it can be monitored, stored and analyzed. For more than a decade, cognitive radio (CR) technology has been widely adopted in wireless networks, as it utilizes the available spectra of licensed, as well as unlicensed bands. A cognitive radio body area network (CRBAN) is a CR-enabled WBAN. Unlike other wireless networks, CRBANs have specific requirements, such as being able to automatically sense their environments and to utilize unused, licensed spectra without interfering with licensed users, but existing protocols cannot fulfill them. In particular, the medium access control (MAC) layer plays a key role in cognitive radio functions, such as channel sensing, resource allocation, spectrum mobility and spectrum sharing. To address various application-specific requirements in CRBANs, several MAC protocols have been proposed in the literature. In this paper, we survey MAC protocols for CRBANs. We then compare the different MAC protocols with one another and discuss challenging open issues in the relevant research. Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

Figure 1

18 pages, 1168 KiB

Open AccessArticle

Using Silver Nano-Particle Ink in Electrode Fabrication of High Frequency Copolymer Ultrasonic Transducers: Modeling and Experimental Investigation

by Adit Decharat, Sanat Wagle, Svein Jacobsen and Frank Melandsø

Sensors 2015, 15(4), 9210-9227; https://doi.org/10.3390/s150409210 - 20 Apr 2015

Cited by 7 | Viewed by 6915

High frequency polymer-based ultrasonic transducers are produced with electrodes thicknesses typical for printed electrodes obtained from silver (Ag) nano-particle inks. An analytical three-port network is used to study the acoustic effects imposed by a thick electrode in a typical layered transducer configuration. Results [...] Read more.

High frequency polymer-based ultrasonic transducers are produced with electrodes thicknesses typical for printed electrodes obtained from silver (Ag) nano-particle inks. An analytical three-port network is used to study the acoustic effects imposed by a thick electrode in a typical layered transducer configuration. Results from the network model are compared to experimental findings for the implemented transducer configuration, to obtain a better understanding of acoustical effects caused by the additional printed mass loading. The proposed investigation might be supportive of identification of suitable electrode-depositing methods. It is also believed to be useful as a feasibility study for printed Ag-based electrodes in high frequency transducers, which may reduce both the cost and production complexity of these devices. Full article

(This article belongs to the Special Issue Novel Sensors for Non-Destructive Testing and Structural Health Monitoring)

► Show Figures

Figure 1

23 pages, 5334 KiB

Open AccessArticle

Visual Object Recognition with 3D-Aware Features in KITTI Urban Scenes

by J. Javier Yebes, Luis M. Bergasa and Miguel García-Garrido

Sensors 2015, 15(4), 9228-9250; https://doi.org/10.3390/s150409228 - 20 Apr 2015

Cited by 27 | Viewed by 10571

Driver assistance systems and autonomous robotics rely on the deployment of several sensors for environment perception. Compared to LiDAR systems, the inexpensive vision sensors can capture the 3D scene as perceived by a driver in terms of appearance and depth cues. Indeed, providing [...] Read more.

Driver assistance systems and autonomous robotics rely on the deployment of several sensors for environment perception. Compared to LiDAR systems, the inexpensive vision sensors can capture the 3D scene as perceived by a driver in terms of appearance and depth cues. Indeed, providing 3D image understanding capabilities to vehicles is an essential target in order to infer scene semantics in urban environments. One of the challenges that arises from the navigation task in naturalistic urban scenarios is the detection of road participants (e.g., cyclists, pedestrians and vehicles). In this regard, this paper tackles the detection and orientation estimation of cars, pedestrians and cyclists, employing the challenging and naturalistic KITTI images. This work proposes 3D-aware features computed from stereo color images in order to capture the appearance and depth peculiarities of the objects in road scenes. The successful part-based object detector, known as DPM, is extended to learn richer models from the 2.5D data (color and disparity), while also carrying out a detailed analysis of the training pipeline. A large set of experiments evaluate the proposals, and the best performing approach is ranked on the KITTI website. Indeed, this is the first work that reports results with stereo data for the KITTI object challenge, achieving increased detection ratios for the classes car and cyclist compared to a baseline DPM. Full article

(This article belongs to the Special Issue Sensors in New Road Vehicles)

► Show Figures

14 pages, 2943 KiB

Open AccessArticle

Modeling of Nanoparticular Magnetoresistive Systems and the Impact on Molecular Recognition

by Lisa Teich, Daniel Kappe, Thomas Rempel, Judith Meyer, Christian Schröder and Andreas Hütten

Sensors 2015, 15(4), 9251-9264; https://doi.org/10.3390/s150409251 - 20 Apr 2015

Cited by 6 | Viewed by 7606

The formation of magnetic bead or nanoparticle superstructures due to magnetic dipole dipole interactions can be used as configurable matter in order to realize low-cost magnetoresistive sensors with very high GMR-effect amplitudes. Experimentally, this can be realized by immersing magnetic beads or nanoparticles [...] Read more.

The formation of magnetic bead or nanoparticle superstructures due to magnetic dipole dipole interactions can be used as configurable matter in order to realize low-cost magnetoresistive sensors with very high GMR-effect amplitudes. Experimentally, this can be realized by immersing magnetic beads or nanoparticles in conductive liquid gels and rearranging them by applying suitable external magnetic fields. After gelatinization of the gel matrix the bead or nanoparticle positions are fixed and the resulting system can be used as a magnetoresistive sensor. In order to optimize such sensor structures we have developed a simulation tool chain that allows us not only to study the structuring process in the liquid state but also to rigorously calculate the magnetoresistive characteristic curves for arbitrary nanoparticle arrangements. As an application, we discuss the role of magnetoresistive sensors in finding answers to molecular recognition. Full article

(This article belongs to the Special Issue Nanoparticle-Based Biosensors)

► Show Figures

Figure 1

12 pages, 940 KiB

Open AccessArticle

The Use of the LanthaScreen TR-FRET CAR Coactivator Assay in the Characterization of Constitutive Androstane Receptor (CAR) Inverse Agonists

by Alejandro Carazo and Petr Pávek

Sensors 2015, 15(4), 9265-9276; https://doi.org/10.3390/s150409265 - 21 Apr 2015

Cited by 24 | Viewed by 9382

The constitutive androstane receptor (CAR) is a critical nuclear receptor in the gene regulation of xenobiotic and endobiotic metabolism. The LanthaScreenTM TR-FRET CAR coactivator assay provides a simple and reliable method to analyze the affinity of a ligand to the human CAR ligand-binding [...] Read more.

The constitutive androstane receptor (CAR) is a critical nuclear receptor in the gene regulation of xenobiotic and endobiotic metabolism. The LanthaScreenTM TR-FRET CAR coactivator assay provides a simple and reliable method to analyze the affinity of a ligand to the human CAR ligand-binding domain (LBD) with no need to use cellular models. This in silico assay thus enables the study of direct CAR ligands and the ability to distinguish them from the indirect CAR activators that affect the receptor via the cell signaling-dependent phosphorylation of CAR in cells. For the current paper we characterized the pharmacodynamic interactions of three known CAR inverse agonists/antagonists—PK11195, clotrimazole and androstenol—with the prototype agonist CITCO (6-(4-chlorophenyl)imidazo[2,1-b][1,3] thiazole-5-carbaldehyde-O-(3,4-dichlorobenzyl)oxime) using the TR-FRET LanthaScreenTM assay. We have confirmed that all three compounds are inverse agonists of human CAR, with IC50 0.51, 0.005, and 0.35 μM, respectively. All the compounds also antagonize the CITCO-mediated activation of CAR, but only clotrimazole was capable to completely reverse the effect of CITCO in the tested concentrations. Thus this method allows identifying not only agonists, but also antagonists and inverse agonists for human CAR as well as to investigate the nature of the pharmacodynamic interactions of CAR ligands. Full article

(This article belongs to the Special Issue FRET Biosensors)

► Show Figures

Graphical abstract

28 pages, 4410 KiB

Open AccessArticle

Online Learning Algorithm for Time Series Forecasting Suitable for Low Cost Wireless Sensor Networks Nodes

by Juan Pardo, Francisco Zamora-Martínez and Paloma Botella-Rocamora

Sensors 2015, 15(4), 9277-9304; https://doi.org/10.3390/s150409277 - 21 Apr 2015

Cited by 25 | Viewed by 8068

Time series forecasting is an important predictive methodology which can be applied to a wide range of problems. Particularly, forecasting the indoor temperature permits an improved utilization of the HVAC (Heating, Ventilating and Air Conditioning) systems in a home and thus a better [...] Read more.

Time series forecasting is an important predictive methodology which can be applied to a wide range of problems. Particularly, forecasting the indoor temperature permits an improved utilization of the HVAC (Heating, Ventilating and Air Conditioning) systems in a home and thus a better energy efficiency. With such purpose the paper describes how to implement an Artificial Neural Network (ANN) algorithm in a low cost system-on-chip to develop an autonomous intelligent wireless sensor network. The present paper uses a Wireless Sensor Networks (WSN) to monitor and forecast the indoor temperature in a smart home, based on low resources and cost microcontroller technology as the 8051MCU. An on-line learning approach, based on Back-Propagation (BP) algorithm for ANNs, has been developed for real-time time series learning. It performs the model training with every new data that arrive to the system, without saving enormous quantities of data to create a historical database as usual, i.e., without previous knowledge. Consequently to validate the approach a simulation study through a Bayesian baseline model have been tested in order to compare with a database of a real application aiming to see the performance and accuracy. The core of the paper is a new algorithm, based on the BP one, which has been described in detail, and the challenge was how to implement a computational demanding algorithm in a simple architecture with very few hardware resources. Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

19 pages, 731 KiB

Open AccessArticle

Directly Estimating Endmembers for Compressive Hyperspectral Images

by Hongwei Xu, Ning Fu, Liyan Qiao and Xiyuan Peng

Sensors 2015, 15(4), 9305-9323; https://doi.org/10.3390/s150409305 - 21 Apr 2015

Cited by 3 | Viewed by 5592

The large volume of hyperspectral images (HSI) generated creates huge challenges for transmission and storage, making data compression more and more important. Compressive Sensing (CS) is an effective data compression technology that shows that when a signal is sparse in some basis, only [...] Read more.

The large volume of hyperspectral images (HSI) generated creates huge challenges for transmission and storage, making data compression more and more important. Compressive Sensing (CS) is an effective data compression technology that shows that when a signal is sparse in some basis, only a small number of measurements are needed for exact signal recovery. Distributed CS (DCS) takes advantage of both intra- and inter- signal correlations to reduce the number of measurements needed for multichannel-signal recovery. HSI can be observed by the DCS framework to reduce the volume of data significantly. The traditional method for estimating endmembers (spectral information) first recovers the images from the compressive HSI and then estimates endmembers via the recovered images. The recovery step takes considerable time and introduces errors into the estimation step. In this paper, we propose a novel method, by designing a type of coherent measurement matrix, to estimate endmembers directly from the compressively observed HSI data via convex geometry (CG) approaches without recovering the images. Numerical simulations show that the proposed method outperforms the traditional method with better estimation speed and better (or comparable) accuracy in both noisy and noiseless cases. Full article

(This article belongs to the Section Remote Sensors)

► Show Figures

Figure 1

20 pages, 2556 KiB

Open AccessArticle

A Sparse Reconstruction Algorithm for Ultrasonic Images in Nondestructive Testing

by Giovanni Alfredo Guarneri, Daniel Rodrigues Pipa, Flávio Neves Junior, Lúcia Valéria Ramos De Arruda and Marcelo Victor Wüst Zibetti

Sensors 2015, 15(4), 9324-9343; https://doi.org/10.3390/s150409324 - 21 Apr 2015

Cited by 32 | Viewed by 7743

Ultrasound imaging systems (UIS) are essential tools in nondestructive testing (NDT). In general, the quality of images depends on two factors: system hardware features and image reconstruction algorithms. This paper presents a new image reconstruction algorithm for ultrasonic NDT. The algorithm reconstructs images [...] Read more.

Ultrasound imaging systems (UIS) are essential tools in nondestructive testing (NDT). In general, the quality of images depends on two factors: system hardware features and image reconstruction algorithms. This paper presents a new image reconstruction algorithm for ultrasonic NDT. The algorithm reconstructs images from A-scan signals acquired by an ultrasonic imaging system with a monostatic transducer in pulse-echo configuration. It is based on regularized least squares using a l1 regularization norm. The method is tested to reconstruct an image of a point-like reflector, using both simulated and real data. The resolution of reconstructed image is compared with four traditional ultrasonic imaging reconstruction algorithms: B-scan, SAFT, !-k SAFT and regularized least squares (RLS). The method demonstrates significant resolution improvement when compared with B-scan—about 91% using real data. The proposed scheme also outperforms traditional algorithms in terms of signal-to-noise ratio (SNR). Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

16 pages, 2828 KiB

Open AccessArticle

Sensing Based on Fano-Type Resonance Response of All-Dielectric Metamaterials

by Elena Semouchkina, Ran Duan, George Semouchkin and Ravindra Pandey

Sensors 2015, 15(4), 9344-9359; https://doi.org/10.3390/s150409344 - 21 Apr 2015

Cited by 45 | Viewed by 8962

A new sensing approach utilizing Mie resonances in metamaterial arrays composed of dielectric resonators is proposed. These arrays were found to exhibit specific, extremely high-Q factor (up to 15,000) resonances at frequencies corresponding to the lower edge of the array second transmission band. [...] Read more.

A new sensing approach utilizing Mie resonances in metamaterial arrays composed of dielectric resonators is proposed. These arrays were found to exhibit specific, extremely high-Q factor (up to 15,000) resonances at frequencies corresponding to the lower edge of the array second transmission band. The observed resonances possessed with features typical for Fano resonances (FRs), which were initially revealed in atomic processes and recently detected in macro-structures, where they resulted from interference between local resonances and a continuum of background waves. Our studies demonstrate that frequencies and strength of Fano-type resonances in all-dielectric arrays are defined by interaction between local Mie resonances and Fabry-Perot oscillations of Bloch eigenmodes that makes possible controlling the resonance responses by changing array arrangements. The opportunity for obtaining high-Q responses in compact arrays is investigated and promising designs for sensing the dielectric properties of analytes in the ambient are proposed. Full article

(This article belongs to the Special Issue Metamaterial-Inspired Sensors)

► Show Figures

Graphical abstract

28 pages, 1161 KiB

Open AccessArticle

Study of Multi-Armed Bandits for Energy Conservation in Cognitive Radio Sensor Networks

by Juan Zhang, Hong Jiang, Zhenhua Huang, Chunmei Chen and Hesong Jiang

Sensors 2015, 15(4), 9360-9387; https://doi.org/10.3390/s150409360 - 21 Apr 2015

Cited by 5 | Viewed by 6744

Technological advances have led to the emergence of wireless sensor nodes in wireless networks. Sensor nodes are usually battery powered and hence have strict energy constraints. As a result, energy conservation is very important in the wireless sensor network protocol design and the [...] Read more.

Technological advances have led to the emergence of wireless sensor nodes in wireless networks. Sensor nodes are usually battery powered and hence have strict energy constraints. As a result, energy conservation is very important in the wireless sensor network protocol design and the limited power resources are the biggest challenge in wireless network channels. Link adaptation techniques improve the link quality by adjusting medium access control (MAC) parameters such as frame size, data rate, and sleep time, thereby improving energy efficiency. In this paper we present an adaptive packet size strategy for energy efficient wireless sensor networks. The main goal is to reduce power consumption and extend the whole network life. In order to achieve this goal, the paper introduces the concept of a bounded MAB to find the optimal packet size to transfer by formulating different packet sizes for different arms under the channel condition. At the same time, in achieve fast convergence, we consider the bandwidth evaluation according to ACK. The experiment shows that the packet size is adaptive when the channel quality changes and our algorithm can obtain the optimal packet size. We observe that the MAB packet size adaptation scheme achieves the best energy efﬁciency across the whole simulation duration in comparison with the ﬁxed frame size scheme, the random packet size and the extended Kalman filter (EKF). Full article

(This article belongs to the Section Sensor Networks)

► Show Figures

Figure 1

16 pages, 1159 KiB

Open AccessArticle

A mRNA-Responsive G-Quadruplex-Based Drug Release System

by Hidenobu Yaku, Takashi Murashima, Daisuke Miyoshi and Naoki Sugimoto

Sensors 2015, 15(4), 9388-9403; https://doi.org/10.3390/s150409388 - 21 Apr 2015

Cited by 14 | Viewed by 7780

G-quadruplex-based drug delivery carriers (GDDCs) were designed to capture and release a telomerase inhibitor in response to a target mRNA. Hybridization between a loop on the GDDC structure and the mRNA should cause the G-quadruplex structure of the GDDC to unfold and release [...] Read more.

G-quadruplex-based drug delivery carriers (GDDCs) were designed to capture and release a telomerase inhibitor in response to a target mRNA. Hybridization between a loop on the GDDC structure and the mRNA should cause the G-quadruplex structure of the GDDC to unfold and release the bound inhibitor, anionic copper(II) phthalocyanine (CuAPC). As a proof of concept, GDDCs were designed with a 10-30-mer loop, which can hybridize with a target sequence in epidermal growth factor receptor (EGFR) mRNA. Structural analysis using circular dichroism (CD) spectroscopy showed that the GDDCs form a (3 + 1) type G-quadruplex structure in 100 mM KCl and 10 mM MgCl₂ in the absence of the target RNA. Visible absorbance titration experiments showed that the GDDCs bind to CuAPC with K_a values of 1.5 × 10⁵ to 5.9 × 10⁵ M⁻¹ (K_d values of 6.7 to 1.7 μM) at 25 °C, depending on the loop length. Fluorescence titration further showed that the G-quadruplex structure unfolds upon binding to the target RNA with K_a values above 1.0 × 10⁸ M⁻¹ (K_d values below 0.01 μM) at 25 °C. These results suggest the carrier can sense and bind to the target RNA, which should result in release of the bound drug. Finally, visible absorbance titration experiments demonstrated that the GDDC release CuAPC in response to the target RNA. Full article

(This article belongs to the Special Issue Next-Generation Nucleic Acid Sensors)

► Show Figures

Graphical abstract

23 pages, 1904 KiB

Open AccessArticle

An Improved Time-Frequency Analysis Method in Interference Detection for GNSS Receivers

by Kewen Sun, Tian Jin and Dongkai Yang

Sensors 2015, 15(4), 9404-9426; https://doi.org/10.3390/s150409404 - 21 Apr 2015

Cited by 44 | Viewed by 7357

In this paper, an improved joint time-frequency (TF) analysis method based on a reassigned smoothed pseudo Wigner–Ville distribution (RSPWVD) has been proposed in interference detection for Global Navigation Satellite System (GNSS) receivers. In the RSPWVD, the two-dimensional low-pass filtering smoothing function is introduced [...] Read more.

In this paper, an improved joint time-frequency (TF) analysis method based on a reassigned smoothed pseudo Wigner–Ville distribution (RSPWVD) has been proposed in interference detection for Global Navigation Satellite System (GNSS) receivers. In the RSPWVD, the two-dimensional low-pass filtering smoothing function is introduced to eliminate the cross-terms present in the quadratic TF distribution, and at the same time, the reassignment method is adopted to improve the TF concentration properties of the auto-terms of the signal components. This proposed interference detection method is evaluated by experiments on GPS L1 signals in the disturbing scenarios compared to the state-of-the-art interference detection approaches. The analysis results show that the proposed interference detection technique effectively overcomes the cross-terms problem and also preserves good TF localization properties, which has been proven to be effective and valid to enhance the interference detection performance of the GNSS receivers, particularly in the jamming environments. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

11 pages, 1416 KiB

Open AccessArticle

Elimination of Flammable Gas Effects in Cerium Oxide Semiconductor-Type Resistive Oxygen Sensors for Monitoring Low Oxygen Concentrations

by Toshio Itoh, Noriya Izu, Takafumi Akamatsu, Woosuck Shin, Yusuke Miki and Yasuo Hirose

Sensors 2015, 15(4), 9427-9437; https://doi.org/10.3390/s150409427 - 21 Apr 2015

Cited by 10 | Viewed by 6586

We have investigated the catalytic layer in zirconium-doped cerium oxide, Ce_0.9Zr_0.1O₂ (CeZr10) resistive oxygen sensors for reducing the effects of flammable gases, namely hydrogen and carbon monoxide. When the concentration of flammable gases is comparable to that of [...] Read more.

We have investigated the catalytic layer in zirconium-doped cerium oxide, Ce_0.9Zr_0.1O₂ (CeZr10) resistive oxygen sensors for reducing the effects of flammable gases, namely hydrogen and carbon monoxide. When the concentration of flammable gases is comparable to that of oxygen, the resistance of CeZr10 is affected by the presence of these gases. We have developed layered thick films, which consist of an oxygen sensor layer (CeZr10), an insulation layer (Al₂O₃), and a catalytic layer consisting of CeZr10 with 3 wt% added platinum, which was prepared via the screen printing method. The Pt-CeZr10 catalytic layer was found to prevent the detrimental effects of the flammable gases on the resistance of the sensor layer. This effect is due to the catalytic layer promoting the oxidation of hydrogen and carbon monoxide through the consumption of ambient O₂ and/or the lattice oxygen atoms of the Pt-CeZr10 catalytic layer. Full article

(This article belongs to the Special Issue Gas Sensors—Designs and Applications)

► Show Figures

Figure 1

28 pages, 8723 KiB

Open AccessArticle

An Informationally Structured Room for Robotic Assistance

by Tokuo Tsuji, Oscar Martinez Mozos, Hyunuk Chae, Yoonseok Pyo, Kazuya Kusaka, Tsutomu Hasegawa, Ken'ichi Morooka and Ryo Kurazume

Sensors 2015, 15(4), 9438-9465; https://doi.org/10.3390/s150409438 - 22 Apr 2015

Cited by 9 | Viewed by 8152

The application of assistive technologies for elderly people is one of the most promising and interesting scenarios for intelligent technologies in the present and near future. Moreover, the improvement of the quality of life for the elderly is one of the first priorities [...] Read more.

The application of assistive technologies for elderly people is one of the most promising and interesting scenarios for intelligent technologies in the present and near future. Moreover, the improvement of the quality of life for the elderly is one of the first priorities in modern countries and societies. In this work, we present an informationally structured room that is aimed at supporting the daily life activities of elderly people. This room integrates different sensor modalities in a natural and non-invasive way inside the environment. The information gathered by the sensors is processed and sent to a centralized management system, which makes it available to a service robot assisting the people. One important restriction of our intelligent room is reducing as much as possible any interference with daily activities. Finally, this paper presents several experiments and situations using our intelligent environment in cooperation with our service robot. Full article

(This article belongs to the Special Issue HCI In Smart Environments)

► Show Figures

15 pages, 2325 KiB

Open AccessArticle

Stability of the Nine Sky Quality Meters in the Dutch Night Sky Brightness Monitoring Network

by Peter Den Outer, Dorien Lolkema, Marty Haaima, Rene Van der Hoff, Henk Spoelstra and Wim Schmidt

Sensors 2015, 15(4), 9466-9480; https://doi.org/10.3390/s150409466 - 22 Apr 2015

Cited by 20 | Viewed by 7330

In the context of monitoring abundance of artificial light at night, the year-to-year stability of Sky Quality Meters (SQMs) is investigated by analysing intercalibrations derived from two measurement campaigns that were held in 2011 and 2012. An intercalibration comprises a light sensitivity factor [...] Read more.

In the context of monitoring abundance of artificial light at night, the year-to-year stability of Sky Quality Meters (SQMs) is investigated by analysing intercalibrations derived from two measurement campaigns that were held in 2011 and 2012. An intercalibration comprises a light sensitivity factor and an offset for each SQM. The campaigns were concerned with monitoring measurements, each lasting one month. Nine SQMs, together forming the Night Sky Brightness Monitoring network (MHN) in The Netherlands, were involved in both campaigns. The stability of the intercalibration of these instruments leads to a year-to-year uncertainty (standard deviation) of 5% in the measured median luminance occurring at the MHN monitoring locations. For the 10-percentiles and 90-percentiles, we find 8% and 4%, respectively. This means that, for urban and industrial areas, changes in the sky brightness larger than 5% become detectable. Rural and nature areas require an 8%–9% change of the median luminance to be detectable. The light sensitivety agrees within 8% for the whole group of SQMs. Full article

(This article belongs to the Special Issue Modern Technologies for Sensing Pollution in Air, Water, and Soil)

► Show Figures

Figure 1

38 pages, 1474 KiB

Open AccessArticle

Design and Field Test of a WSN Platform Prototype for Long-Term Environmental Monitoring

by Mihai T. Lazarescu

Sensors 2015, 15(4), 9481-9518; https://doi.org/10.3390/s150409481 - 22 Apr 2015

Cited by 44 | Viewed by 10137

Long-term wildfire monitoring using distributed in situ temperature sensors is an accurate, yet demanding environmental monitoring application, which requires long-life, low-maintenance, low-cost sensors and a simple, fast, error-proof deployment procedure. We present in this paper the most important design considerations and optimizations of [...] Read more.

Long-term wildfire monitoring using distributed in situ temperature sensors is an accurate, yet demanding environmental monitoring application, which requires long-life, low-maintenance, low-cost sensors and a simple, fast, error-proof deployment procedure. We present in this paper the most important design considerations and optimizations of all elements of a low-cost WSN platform prototype for long-term, low-maintenance pervasive wildfire monitoring, its preparation for a nearly three-month field test, the analysis of the causes of failure during the test and the lessons learned for platform improvement. The main components of the total cost of the platform (nodes, deployment and maintenance) are carefully analyzed and optimized for this application. The gateways are designed to operate with resources that are generally used for sensor nodes, while the requirements and cost of the sensor nodes are significantly lower. We define and test in simulation and in the field experiment a simple, but effective communication protocol for this application. It helps to lower the cost of the nodes and field deployment procedure, while extending the theoretical lifetime of the sensor nodes to over 16 years on a single 1 Ah lithium battery. Full article

(This article belongs to the Special Issue Wireless Sensor Networks and the Internet of Things)

► Show Figures

28 pages, 7546 KiB

Open AccessArticle

A Novel Identification Methodology for the Coordinate Relationship between a 3D Vision System and a Legged Robot

by Xun Chai, Feng Gao, Yang Pan, Chenkun Qi and Yilin Xu

Sensors 2015, 15(4), 9519-9546; https://doi.org/10.3390/s150409519 - 22 Apr 2015

Cited by 7 | Viewed by 7515

Coordinate identification between vision systems and robots is quite a challenging issue in the field of intelligent robotic applications, involving steps such as perceiving the immediate environment, building the terrain map and planning the locomotion automatically. It is now well established that current [...] Read more.

Coordinate identification between vision systems and robots is quite a challenging issue in the field of intelligent robotic applications, involving steps such as perceiving the immediate environment, building the terrain map and planning the locomotion automatically. It is now well established that current identification methods have non-negligible limitations such as a difficult feature matching, the requirement of external tools and the intervention of multiple people. In this paper, we propose a novel methodology to identify the geometric parameters of 3D vision systems mounted on robots without involving other people or additional equipment. In particular, our method focuses on legged robots which have complex body structures and excellent locomotion ability compared to their wheeled/tracked counterparts. The parameters can be identified only by moving robots on a relatively flat ground. Concretely, an estimation approach is provided to calculate the ground plane. In addition, the relationship between the robot and the ground is modeled. The parameters are obtained by formulating the identification problem as an optimization problem. The methodology is integrated on a legged robot called “Octopus”, which can traverse through rough terrains with high stability after obtaining the identification parameters of its mounted vision system using the proposed method. Diverse experiments in different environments demonstrate our novel method is accurate and robust. Full article

(This article belongs to the Section Physical Sensors)

► Show Figures

Figure 1

16 pages, 2967 KiB

Open AccessArticle

Heat Transfer and Friction Characteristics of the Microfluidic Heat Sink with Variously-Shaped Ribs for Chip Cooling

by Gui-Lian Wang, Da-Wei Yang, Yan Wang, Di Niu, Xiao-Lin Zhao and Gui-Fu Ding

Sensors 2015, 15(4), 9547-9562; https://doi.org/10.3390/s150409547 - 22 Apr 2015

Cited by 43 | Viewed by 11054

This paper experimentally and numerically investigated the heat transfer and friction characteristics of microfluidic heat sinks with variously-shaped micro-ribs, i.e., rectangular, triangular and semicircular ribs. The micro-ribs were fabricated on the sidewalls of microfluidic channels by a surface-micromachining micro-electro-mechanical system (MEMS) process [...] Read more.

This paper experimentally and numerically investigated the heat transfer and friction characteristics of microfluidic heat sinks with variously-shaped micro-ribs, i.e., rectangular, triangular and semicircular ribs. The micro-ribs were fabricated on the sidewalls of microfluidic channels by a surface-micromachining micro-electro-mechanical system (MEMS) process and used as turbulators to improve the heat transfer rate of the microfluidic heat sink. The results indicate that the utilizing of micro-ribs provides a better heat transfer rate, but also increases the pressure drop penalty for microchannels. Furthermore, the heat transfer and friction characteristics of the microchannels are strongly affected by the rib shape. In comparison, the triangular ribbed microchannel possesses the highest Nusselt number and friction factor among the three rib types. Full article

(This article belongs to the Special Issue Modeling, Testing and Reliability Issues in MEMS Engineering)

► Show Figures

Figure 1

19 pages, 3186 KiB

Open AccessArticle

A Study of a QCM Sensor Based on TiO₂ Nanostructures for the Detection of NO₂ and Explosives Vapours in Air

by Marcin Procek, Agnieszka Stolarczyk, Tadeusz Pustelny and Erwin Maciak

Sensors 2015, 15(4), 9563-9581; https://doi.org/10.3390/s150409563 - 22 Apr 2015

Cited by 70 | Viewed by 10826

The paper deals with investigations concerning the construction of sensors based on a quartz crystal microbalance (QCM) containing a TiO₂ nanostructures sensor layer. A chemical method of synthesizing these nanostructures is presented. The prepared prototype of the QCM sensing system, as well [...] Read more.

The paper deals with investigations concerning the construction of sensors based on a quartz crystal microbalance (QCM) containing a TiO₂ nanostructures sensor layer. A chemical method of synthesizing these nanostructures is presented. The prepared prototype of the QCM sensing system, as well as the results of tests for detecting low NO₂ concentrations in an atmosphere of synthetic air have been described. The constructed NO₂ sensors operate at room temperature, which is a great advantage, because resistance sensors based on wide gap semiconductors often require much higher operation temperatures, sometimes as high as 500 °C. The sensors constructed by the authors can be used, among other applications, in medical and chemical diagnostics, and also for the purpose of detecting explosive vapours. Reactions of the sensor to nitroglycerine vapours are presented as an example of its application. The influence of humidity on the operation of the sensor was studied. Full article

(This article belongs to the Special Issue Gas Sensors—Designs and Applications)

► Show Figures

Figure 1

10 pages, 871 KiB

Open AccessArticle

Immunity to Laser Power Variation in a DFB Diode Laser Based Optical Gas Sensor Using a Division Process

by Hengtai Chang, Jun Chang, Qingjie Huang, Qiang Wang, Changbin Tian, Wei Wei and Yuanyuan Liu

Sensors 2015, 15(4), 9582-9591; https://doi.org/10.3390/s150409582 - 22 Apr 2015

Cited by 3 | Viewed by 6734

The division process used in a DFB diode laser-based optical gas sensor was studied to improve the immunity to laser power variation. Residual amplitude modulation (RAM) in wavelength modulation spectroscopy (WMS) detection was eliminated by intensity normalization using a division process. As a [...] Read more.

The division process used in a DFB diode laser-based optical gas sensor was studied to improve the immunity to laser power variation. Residual amplitude modulation (RAM) in wavelength modulation spectroscopy (WMS) detection was eliminated by intensity normalization using a division process. As a result the detected harmonic signals showed a significant improvement in line shape. For the first harmonic (1f) signal, Bias was improved from 38.7% to 1.2%; Baseline Difference was improved from 2.7% to 0.69% and Asymmetry was improved from 15.4% to 0.22%. For the second harmonic (2f) signal, the Asymmetry Coefficient was improved from 103% to 5.1%. Moreover the division process can further suppress the influence of unstable laser power. As a result, for the 1f signal, stable detection with a variation coefficient of 0.59% was obtained over a wide dynamic range (0.38–8.1 mW). For the 2f signal, stable detection with a variation coefficient of 0.53% was obtained from 0.64 mW to 8.27 mW. The test results showed a good agreement with the theoretical analysis and the proposed method has considerable potential application in gas sensing. Full article

(This article belongs to the Special Issue Optical Sensors for Chemical, Biological and Industrial Applications)

► Show Figures

Figure 1

Show export options Show export options

Select all

Export citation of selected articles as:

Displaying articles 1-131

Previous Issue

Volume 15, March

Next Issue

Back to TopTop
