This paper presents a multi-criteria decision-making (MCDM) approach for optimizing a microgrid system to achieve Plus-Energy Building (PEB) performance at the University of Coimbra’s Electrical Engineering Department. Using Python 3.12.8, Rhino 7, and PVsyst 8.0.1, simulations considered architectural and visual constraints, with economic feasibility assessed through a TOPSIS (Technique for Order of Preference by Similarity to Ideal Solution) analysis. The system is projected to generate approximately 1 GWh annually, with a 98% probability of exceeding 1076 MWh based on Gaussian estimation. Consumption is estimated at 460 MWh, while a 3.8 MWh battery ensures up to 72 h of autonomy. Rooftop panels and green parking arrays, fixed at 13.5° and 59°, minimize visual impact while contributing a surplus of +160% energy injection (or a net surplus of +60% energy after self-consumption). Assuming a battery cost of EUR 200/kWh, each hour of energy storage for the building requires 61 kWh of extra capacity with a cost of 12,200 (EUR/hr.storage). Recognizing environmental variability, these figures represent cross-validated probabilistic estimates derived from both PVsyst and Monte Carlo simulation using Python, reinforcing confidence in system feasibility. A holistic photovoltaic optimization strategy balances technical, economic, and architectural factors, demonstrating the potential of PEBs as a sustainable energy solution for academic institutions. Full article

Indoor environmental quality profoundly impacts student learning outcomes and teacher effectiveness, particularly in primary education, where children spend most of their developmental years. The study compares the New Zealand Ministry of Education’s Designing Quality Learning Spaces (DQLS) version 2.0 for primary school classrooms with international standards set by OECD countries to develop IAQ and thermal comfort best practices in New Zealand across six climate zones. The research evaluates indoor air quality (IAQ) and thermal comfort factors affecting students’ and teachers’ health and performance. Using Ladybug and Honeybee plugin tools in Grasshopper with Energy Plus, integrated into Rhino 7 software, the study employed advanced building optimisation methods, using multi-criteria optimisation and parametric modelling. This approach enabled a comprehensive analysis of building envelope parameters for historical classroom designs, the Avalon block (constructed between 1955 and 2000). Optimise window-to-wall ratios, ceiling heights, window placement, insulation values (R-values), clothing insulation (Clo), and window opening schedules. Our findings demonstrate that strategic modifications to the building envelope can significantly improve occupant comfort and energy performance. Specifically, increasing ceiling height by 0.8 m, raising windows by 0.3 m vertically, and reducing the window-to-wall ratio to 25% created optimal conditions across multiple performance criteria. These targeted adjustments improved adaptive thermal comfort, ventilation, carbon dioxide, and energy efficiency while maintaining local and international standards. The implications of the findings extend beyond the studied classrooms, offering evidence-based strategies for overall design and building performance guidelines in educational facilities. This research demonstrates the efficacy of applying computational design optimisation during early design phases, providing policymakers and architects with practical solutions that could inform future revisions of New Zealand’s school design standards and align them more closely with international best practices for educational environments. Full article

This study focused on the novel ventilation solution used in the control room of an electric submersible pump on a jack-up offshore platform, with the core objective of exploring the advantages of tunnel ventilation over the traditional ceiling-mounted ventilation system. At the beginning of the research, a three-dimensional physical model of the room’s air conditioning and ventilation system was constructed using Rhino 7 software. Subsequently, the computational fluid dynamics software Airpak 3.0 was employed to conduct detailed thermodynamic calculations on the model. Based on this, the study meticulously compared the performance of the two ventilation systems from multiple perspectives: one aspect examined the airflow and temperature distribution through temperature contour maps, velocity vector maps, and airflow streamlines; another focused on the comfort level of personnel, as reflected in the key indicators of the predicted mean vote and predicted percentage dissatisfied. The results demonstrated that tunnel ventilation is highly effective in reducing the indoor temperature and significantly improving personnel comfort. Further optimization analysis revealed that, under specific inlet conditions, namely when the inlet velocity reaches 1.16 m/s and the inlet temperature is 17 °C, the most ideal ventilation effect can be achieved, thereby fully and effectively meeting human thermal comfort requirements. Overall, the findings of this study not only provide a novel solution for the environmental control system design of offshore platforms but also lay a solid scientific foundation for continued exploration in related fields, offering a reliable reference for future research. Full article

The built environment in which we live holds the potential to provide life experiences that allow pedestrians to observe, feel, learn, and grow through their surroundings in everyday urban spaces. If a city offers opportunities for careful observation and exploration according to users’ preferences, it will become more appealing to many people. This study selected Midtown, New York, as the research site and collected a total of seven datasets based on 30 intersections in the area. The data, categorized into three main areas—activity, comfort, and natural elements—were evaluated, visualized, and restructured using a path exploration algorithm to produce a final user-based map. For this, 3D modeling software Rhino version 7, visual programming tool Grasshopper, and Grasshopper verion 2023 plugin programs were used. The final result included 3D route information, quantitative measurement data, and multidimensional visual materials. This approach presents an alternative to traditional route navigation based on uniform criteria and, through data-driven design, is believed to ultimately enhance walkability, activate urban spaces, and contribute to the development of sustainable cities. The scope of related research can further expand as the targets, duration, and methods of data collection continue to evolve and as case studies in various cities increase. Full article

This simulation study explores the potential of a novel façade design with integrated control system comprising a dynamic photovoltaic (PV) facade integrated with dimming lighting control to enhance the work environment in office buildings and achieve energy-efficient solutions. Parametric modeling using the Grasshopper plug-in for Rhino software 7, coupled with energy simulation through the Honeybee environmental plug-in for the EnergyPlus program, are used in the methodology. The integrated control strategy was simulated to study in a single office space, utilizing the Daysim engine to assess indoor daylight quality and focusing on Daylight Factor (DF) and Daylight Glare Probability (DGP). Additionally, two artificial lighting control systems were examined for potential integration with the dynamic PV facade to minimize lighting load. The study employs the Galapagos evolutionary solver function embedded within Grasshopper to identify optimum solutions. The dynamic PV façade achieves substantial reductions in overall energy consumption, cutting it by 73% in June, 54% in July, 54.5% in August, and 52.55% in September. The results demonstrate substantial reductions in total energy consumption, with notable savings in heating and cooling due to the dynamic facade’s ability to balance and control solar radiation during working hours. Moreover, the dynamic PV facade contributes to electricity generation, demonstrating its potential to improve visual comfort, decrease energy consumption, and generate electric energy through rotational adjustments and varying transparency levels. Full article

Pedestrian vitality in commercial streets is influenced by various factors, among which the spatial form of the street and the resulting thermal environment have a significant impact. This study, from the perspective of thermal comfort, combines thermal comfort simulation with pedestrian simulation to establish an optimization model based on pedestrian vitality. The model aims to analyze and quantify the impact of street spatial form on thermal comfort and pedestrian vitality, providing a comprehensive evaluation of optimization schemes for commercial street spaces. Firstly, the study identifies the levels of spatial design parameters for commercial streets and generates optimized design scenarios for commercial street spaces. Using the simulation platforms Rhino 7 Grasshopper and MATLAB R2023a, a pedestrian simulation model guided by thermal comfort is constructed and validated against empirical data. Next, the influence of commercial street spatial design parameters on store visitations is assessed, identifying the most critical design parameters. Finally, design strategies for commercial streets are proposed based on vitality-oriented layouts. The results indicate that the spatial form of the street significantly affects store visitations, with the street width-to-height ratio being the most influential factor, followed by street orientation and interface form. NW-SE-oriented streets show a 47.2% higher Total Store Visitations (TSV) value compared to E-W-oriented streets, while E-W streets exhibit a Differential Store Visitation (DSV) value 4.47 times that of NW-SE streets. Streets with a W/H ratio of 0.25 have a 54.9% higher Total Store Visitations value than those with a W/H ratio of 0.9, and streets with a W/H ratio of 0.65 exhibit a Differential Store Visitations value 1.21 times that of streets with a W/H ratio of 0.25. Considering overall street vitality, the study recommends NW-SE- and NE-SW-oriented streets, with a width-to-height ratio between 0.25 and 0.4. The study also proposes strategies for the modification and expansion of streets in different orientations, providing the scientific basis and optimization recommendations for the planning and renovation of commercial streets in cold regions during summer. Full article

Students and educators spend significant time in learning spaces on university campuses. Energy efficiency has become a concern among facility managers, given the need to maintain acceptable indoor air quality (IAQ) levels during and after the COVID-19 pandemic. This paper investigates the relationship between control and extraneous variables in a university classroom’s total mechanical ventilation (kWh). The model is built using Grasshopper software on Rhino Version 7. Our methodology encompasses (1) an extensive review of recent trends for studying IAQ and energy, (2) selecting parameters for simulation, (3) model configuration on Grasshopper, and finally, (4) a formulation of a pertinent equation to consolidate the relationship between the studied factors and the total mechanical ventilation energy (kWh). Central to this study are two key research questions: (1) What correlations exist between various parameters related to occupancy and IAQ in educational spaces? And (2) how can we optimize energy efficiency in university classrooms? The main contribution of this research is a generated equation representing the annual mechanical ventilation energy consumption based on selected parameters of classroom height, area, occupancy, window location, and ventilation rate of HVAC systems. We find that occupancy and class volume are the two most influential factors directly affecting mechanical ventilation energy consumption. The equation serves as a valuable estimation tool for facility managers, designers, and campus operations to investigate how fluctuations in occupancy can influence ventilation energy consumption in the physical attributes of a university classroom. This enables proactive decision-making, optimizing energy efficiency and resource allocation in real-time to promote sustainable and cost-effective campus operations. Full article

It is well known that finite element analysis (FEA) is a powerful tool when it comes to the design and analysis of complex structures for various load combinations, including light steel curve members. This abstract provides an overview of the FEA simulation process for designing such members (cure members), which involves constructing a 3D model, discretising the member into small elements, assigning material properties, defining boundary conditions, conducting the simulation, analysing the results, and making any necessary modifications to the design. FEA simulations can provide valuable insights into the behaviour of light steel curved members under different load combinations. This enables designers to optimise designs for strength, safety, and cost-effectiveness. This article proposes using two commercial 3D software programs, Rhino 7 and Strand7, to complete the FEA simulation of light steel curved members. The 3D model is created in Rhino 7, and the individual elements are discretised into more minor elements using Strand7 for assigning material properties, defining boundary conditions, running simulations, and analysing the results. The paper presents five case studies of steel–glass façades and applies the proposed methodology to each. Examples include Phoenix International Media Center in Beijing, Kazakhstan Pavilion and Science Museum in Astana, Moynihan Train Hall in New York City, Chadstone Shopping Centre in Melbourne, and the central light rail station in The Hague. Full article

These days, high-density cities are facing growing challenges related to the urban heat island (UHI) effect. Greening can be a nature-based solution for UHI effect mitigation. This study aims to evaluate the potential of nature-based solutions to improve the urban living environments in Baishizhou, a high-density neighbourhood in Shenzhen. An integrated 3D visualisation research method was proposed in this study. Rhino 7, Grasshopper, and ENVI-met software were combined to evaluate environment characteristics before and after design, as well as compare differences in the outdoor thermal comfort index and the building surface temperature. The greening design scenarios include adding trees, green roofs, and green facades. The simulations ran for 24 h during the test period from 01:00 to 24:00 on 9 August 2019, which was the hottest day in Shenzhen. Baishizhou was selected as the test area for this study and environmental simulation. Results indicated that (1) vegetation has a positive cooling effect, providing outdoor thermal comfort, while shade “trees” provide significant cooling effects on hot days in tropical and subtropical climates; (2) adding green roofs and green facades to a building can significantly affect the cooling effect. Full article

The present work is focused on the analysis of the microstructure of the exoskeleton of the sea urchin Paracentrotus lividus and the extraction of design concepts by implementing geometrically described 3D Voronoi diagrams. Scanning electron microscopy (SEM) analysis of dried sea urchin shells revealed a foam-like microstructure, also known as the stereom. Subsequently, parametric, digital models were created with the aid of the computer-aided design (CAD) software Rhinoceros 3D (v. Rhino 7, 7.1.20343.09491) combined with the visual programming environment Grasshopper. Variables such as node count, rod thickness and mesh smoothness of the biologically-inspired Voronoi lattice were adapted for 3D printing cubic specimens using the fused filament fabrication (FFF) method. The filaments used in the process were a commercial polylactic acid (PLA), a compound of polylactic acid/polyhydroxyalkanoate (PLA/PHA) and a wood fiber polylactic acid/polyhydroxyalkanoate (PLA/PHA) composite. Nanoindentation tests coupled with finite element analysis (FEA) produced the stress–strain response of the materials under study and were used to simulate the Voronoi geometries under a compression loading regime in order to study their deformation and stress distribution in relation to experimental compression testing. The PLA blend with polyhydroxyalkanoate seems to have a minor effect on the mechanical behavior of such structures, whereas when wood fibers are added to the compound, a major decrease in strength occurs. The computational model results significantly coincide with the experimental results. Full article

Measuring the dimensions of personalized devices can provide relevant information for the production of future such devices used in various medical specialties. Difficulties with standardizing such measurement and obtaining high accuracy, alongside cost-intensive measuring methodologies, has dampened interest in this practice. This study presents a methodology for automatized measurements of personalized medical appliances of variable shape, in this case an orthodontic appliance known as Tübingen Palatal Plate (TPP). Parameters such as length, width and angle could help to standardize and improve its future use. A semi-automatic and custom-made program, based on Rhinoceros 7 and Grasshopper, was developed to measure the device (via an extraoral scanner digital file). The program has a user interface that allows the import of the desired part, where the user is able to select the necessary landmarks. From there, the program is able to process the digital file, calculate the necessary dimensions automatically and directly export all measurements into a document for further processing. In this way, a solution for reducing the time for measuring multiple dimensions and parts while reducing human error can be achieved. Full article

Traditional inverse distance weighting (IDW) interpolation is a process employed to estimate unknown values based on neighborhoods in 2D space. Proposed in this study is an improved IDW interpolation method that uses 3D search neighborhoods for effective interpolation on vertically connected observation data, such as water level, depth, and altitude. Borehole data are the data collected by subsurface boring activities and exhibit heterogeneous spatial distribution as they are densely populated near civil engineering or construction sites. In addition, they are 3D spatial data that show different subsurface characteristics by depth. The subsurface characteristics observed as such are used as core data in spatial modeling in fields, such as geology modeling, estimation of groundwater table distribution, global warming assessment, and seismic liquefaction assessment, among others. Therefore, this study proposed a seismic liquefaction assessment and mapping workflow using an improved IDW application by combining geographic information system (GIS) (ArcGIS (Esri, Redlands, CA, USA)), NURBS-based 3D CAD system (Rhino/Grasshopper (Robert McNeel & Associates, Seattle, WA, USA)), and numerical analysis system (MATLAB (MathWorks, Natick, MA, USA)). The 3D neighborhood search was conducted by the B-rep-based 3D topology analysis, and the mapping was done under the 2.5D environment by combining the voxel layer, DEM, and aerial images. The experiment was performed by collecting data in Songpa-gu, Seoul, which has the highest population density among the OECD countries. The results of the experiment showed between 7 and 105 areas with liquefaction potentials according to the search distance and the method of the approach. Finally, this study improved users’ accessibility to interpolation results by producing a 3D web app that used REST API based on OGC I3S Standards. Such an approach can be applied effectively in spatial modeling that uses 3D observation data, and in the future, it can contribute to the expansion of 3D GIS application. Full article

Whether it is a plant- or animal-based bio-inspiration design, it has always been able to address one or more product/component optimisation issues. Today’s scientists or engineers look to nature for an optimal, economically viable, long-term solution. Similarly, a proposal is made in this current work to use seven different bio-inspired structures for automotive impact resistance. All seven of these structures are derived from plant and animal species and are intended to be tested for compressive loading to achieve load-bearing capacity. The work may even cater to optimisation techniques to solve the real-time problem using algorithm-based generative shape designs built using CATIA V6 in unit dimension. The samples were optimised with Rhino 7 software and then simulated with ANSYS workbench. To carry out the comparative study, an experimental work of bioprinting in fused deposition modelling (3D printing) was carried out. The goal is to compare the results across all formats and choose the best-performing concept. The results were obtained for compressive load, flexural load, and fatigue load conditions, particularly the number of life cycles, safety factor, damage tolerance, and bi-axiality indicator. When compared to previous research, the results are in good agreement. Because of their multifunctional properties combining soft and high stiffness and lightweight properties of novel materials, novel materials have many potential applications in the medical, aerospace, and automotive sectors. Full article
