Real-time wideband radio frequency (RF) spectrum monitoring is increasingly important for unmanned aerial vehicle (UAV) detection and RF surveillance. Low-cost software-defined radio (SDR) networks are attractive but constrained by limited instantaneous bandwidth per node, I/Q data transfer bottlenecks over USB 2.0, and multi-node computational overhead. This paper proposes a bandwidth-efficient FPGA-GPU heterogeneous architecture addressing these limitations. A hardware-efficient cell-averaging constant false alarm rate (CA-CFAR) IP core is deployed on the edge FPGA of each SDR node, forwarding only signal-containing intervals to reduce data transfer volume proportionally to the target duty cycle. Spectra from multiple nodes are stitched into a wideband view and processed in real time via a GPU-accelerated pipeline. The CA-CFAR IP occupies 16.3% of available LUTs with no BRAM and a fixed 10-cycle latency at 100 MHz. Experiments on a five-SDR testbed demonstrate an 88% data transfer reduction at a 10% duty cycle, 376 μs latency from signal acquisition to display-buffer preparation, 96.26% detection probability at −83.16 dBm (SNR ≈ 13 dB), and a 4.5× to 6.0× GPU speedup over CPU processing. These results support real-time wideband RF monitoring on resource-constrained SDR platforms. Full article

This paper proposes a micro-Doppler flash detection framework for hovering unmanned aerial vehicle (UAV) detection with linear frequency modulated continuous wave (LFMCW) radar under the dual constraints of strong ground clutter and severe thermal noise conditions. In such scenarios, conventional methods fail not only due to the spectral overlap between hovering targets and clutter but also because of the visual disappearance of micro-Doppler features under heavy noise. The framework consists of three sequential modules. A prior-template orthogonal projection (PTOP) module suppresses clutter via a single-step orthogonal projection, preserving the micro-Doppler flash signature without distortion while approximately maintaining the Gaussian noise statistics required for subsequent detection. A flash power spectrum construction module then collapses the periodic blade flash energy onto a sharp spectral peak in a one-dimensional (1D) power spectrum via Gabor transform, power projection, and fast Fourier transform (FFT). A cell-averaging constant false alarm rate (CA-CFAR) detection module with an analytically derived threshold factor finally renders a reliable detection decision. Simulations under a signal-to-clutter ratio (SCR) of $-21$ dB and signal-to-noise ratio (SNR) of $-23$ dB confirm that the proposed framework achieves reliable detection even when the micro-Doppler flash signatures are visually obscured by residual noise in the time–frequency domain. Parametric SNR sweep curves and a two-dimensional (2D) SCR–SNR detection-probability heatmap under a non-stationary clutter model further quantify the practical performance boundaries of the framework. By transforming these concealed periodic features into a sharp spectral peak, the framework provides robust detection performance where conventional range-Doppler and moving target indication (MTI)-based methods both exhibit severe performance degradation. Full article

To overcome the limitations of Orthonormal Basis Function (OBF) methods in magnetic anomaly detection, including high false alarm rates and ambiguous target localization due to background noise, this paper introduces a high-confidence detection algorithm based on hierarchical clustering with an optimal cut height. The core of our approach is a theoretically derived optimal cut height, which is calculated from a physical model of the magnetic dipole’s vertical gradient field. This model establishes the implicit functional relationship between the effective detection range and key parameters, including magnetic moment orientation, geomagnetic inclination, and sensor height. The calculated optimal cut height serves as the critical criterion in a complete-linkage hierarchical clustering algorithm, which processes the alarm point clouds generated by a preliminary Greatest-of Cell-Averaging Constant False Alarm Rate (GOCA-CFAR) detector. This effectively suppresses isolated false alarms caused by background fluctuations while preserving spatially coherent alarm clusters within the target’s effective detection range, thereby significantly enhancing detection confidence. Results from both simulations and field experiments validate the efficacy of the proposed algorithm, demonstrating its superior capability to reliably discriminate genuine targets from false alarms compared to traditional one-dimensional CFAR detection. Full article

The target detection method based on a constant false alarm rate (CFAR) and feature space is commonly used in remote sensing for detecting maritime targets within sea clutter. However, the performance of traditional CFAR techniques heavily relies on the signal-to-clutter ratio (SCR) in a single observational channel, while feature space methods are overly sensitive to the number of pulse accumulations and rigidly apply outlier classifiers to define detection regions, without theoretical derivation. To address these limitations, this paper proposes a two-dimensional (2D) CFAR target detection method based on echo data from dual-polarization observational channels. First, statistical models of the amplitude distribution for horizontal–horizontal (HH) and vertical–vertical (VV) polarization sea clutter radar echoes are validated under identical observation conditions using measured data, and their correlations are analyzed. Then, the Copula function is introduced as a theoretical foundation to rigorously derive and extend the cell-averaging CFAR detector through strict mathematical formulations, transitioning from single statistics to 2D detection statistics. This leads to the proposed target detection method. Testing with measured data from publicly available datasets demonstrates that the proposed method effectively achieves adaptive false alarm control and significantly improves the detection performance compared to existing single-pulse one-dimensional CFAR detection methods. Full article

Accurate peak detection in the frequency domain is fundamental to reliable range estimation in Frequency-Modulated Continuous-Wave (FMCW) radar systems, particularly in challenging conditions characterized by a low signal-to-noise ratio (SNR) and phase noise impairments. This paper presents a comprehensive comparative analysis of five peak detection algorithms: FFT thresholding, Cell-Averaging Constant False Alarm Rate (CA-CFAR), a simplified Matrix Pencil Method (MPM), SVD-based detection, and a novel Learned Thresholded Subspace Projection (LTSP) approach. The proposed LTSP method leverages singular value decomposition (SVD) to extract the dominant signal subspace, followed by signal reconstruction and spectral peak analysis, enabling robust detection in noisy and spectrally distorted environments. Each technique was analytically modeled and extensively evaluated through Monte Carlo simulations across a wide range of SNRs and oscillator phase noise levels, from $-100$ dBc/Hz to $-70$ dBc/Hz. Additionally, real-world validation was performed using a custom-built harmonic FMCW radar prototype operating in the 2.4–2.5 GHz transmission band and 4.8–5.0 GHz harmonic reception band. Results show that CA-CFAR offers the highest resilience to phase noise, while the proposed LTSP method delivers competitive detection performance with improved robustness over conventional FFT and MPM techniques. Furthermore, the hardware feasibility of each algorithm is assessed for implementation on a Xilinx FPGA platform, highlighting practical trade-offs between detection performance, computational complexity, and resource utilization. These findings provide valuable guidance for the design of real-time, embedded FMCW radar systems operating under adverse conditions. Full article

Reverberation is the main background interference in active sonar and seriously interferes with the extraction of the target echo. Active sonar systems can use short-pulse continuous wave (CW) signals to reduce the reverberation intensity. However, as the pulse width of the CW signals decreases, the reverberation envelope exhibits a high-frequency oscillating phenomenon. Active sonar often uses the cell average constant false alarm ratio (CA-CFAR) method to process the reverberation, which steadily decays with transmission distance. However, the high-frequency oscillation of the reverberation envelope deteriorates the performance of CA-CFAR, which causes a higher false alarm rate. To tackle this problem, the formation mechanism of the high-frequency oscillation characteristics of the reverberation envelope of the short-pulse-width CW signals is modeled and analyzed, and on this basis, an α filter is designed to suppress the high-frequency oscillation of the reverberation envelope before applying CA-CFAR. The simulation and lake trial results indicate that this method can effectively suppress high-frequency oscillations of the reverberation envelope, as well as exhibit robustness and resistance to reverberation interference. Full article

Gesture recognition technology has been quickly developed in the field of human–computer interaction. The multiple-input multiple-output (MIMO) radar is popular in gesture recognition because of its notable spatial resolution. This work proposes a MIMO radar-based hand gesture recognition algorithm with low complexity. We leverage low-complexity adaptive signal processing to extract trajectory information and minimize noise to create a system that can be applied in real-world applications with small training datasets. First, a spectrum analysis is utilized on range-Doppler maps (RDMs), and a cell-averaging constant false alarm rate (CA-CFAR) with mirror filters is applied to improve the robustness of noise. Then, the features related to the distance, speed, direction, and elevation angle of the moving object are determined using the proposed adaptive signal analysis techniques. For classification, the random forest algorithm is implemented. The proposed system can precisely distinguish and identify eight gestures, including waving, moving to the left or right, patting, pushing, pulling, and rotating clockwise or anti-clockwise, with an accuracy of 95%. Experiments demonstrate the capability of the proposed hand gesture recognition system to classify different movements precisely. Full article

Ground-Based Synthetic Aperture Radar (GBSAR) has non-contact, all-weather, high resolution imaging and microdeformation sensing capabilities, which offers advantages in applications such as building structure monitoring and mine slope deformation retrieval. The Circular Scanning Ground-Based Synthetic Aperture Radar (CS-GBSAR) is one of its newest developed working mode, in which the radar rotates around an axis in a vertical plane. Such nonlinear observation geometry brings the unique advantage of three-dimensional (3D) imaging compared with traditional GBSAR modes. However, such nonlinear observation geometry causes strong sidelobes in SAR images, which makes it a difficult task to extract point cloud data. The Conventional Cell Averaging Constant False Alarm Rate (CA-CFAR) algorithm can extract 3D point cloud data layer-by-layer at different heights, which is time consuming and is easily influenced by strong sidelobes to obtain inaccurate results. To address these problems, this paper proposes a new two-step CFAR-based 3D point cloud extraction method for CS-GBSAR, which can extract accurate 3D point cloud data under the influence of strong sidelobes. It first utilizes maximum projection to obtain three-view images from 3D image data. Then, the first step CA-CFAR is applied to obtain the coarse masks of three-views. Then, the volume mask in the original 3D image is obtained via inverse projection. This can remove strong sidelobes outside the potential target region and obtain potential target area data by intersecting it with the SAR 3D image. Then, the second step CA-CFAR is applied to the potential target area data to obtain 3D point clouds. Finally, to further eliminate the residual strong sidelobes and output accurate 3D point clouds, the modified Density-Based Spatial Clustering of Applications with Noise (DBSCAN) clustering algorithm is applied. The original DBSCAN method uses a spherical template to cluster. It covers more points, which is easily influenced by the strong sidelobe. Hence, the clustering results have more noise points. Meanwhile, modified DBSCAN clusters have a cylindrical template to accommodate the data’s features, which can reduce false clustering. The proposed method is validated via real data acquired by the North China University of Technology (NCUT)-developed CS-GBSAR system. The laser detection and ranging (LiDAR) data are used as the reference ground truth to demonstrate the method. The comparison experiment with conventional method shows that the proposed method can reduce 95.4% false clustered points and remove the strong sidelobes, which shows the better performance of the proposed method. Full article

The traditional constant false alarm rate (CFAR) method, with fixed parameter settings and single noise background calculation, is unable to intelligently catch the current detection background. To improve the performance of the CFAR method, this paper proposes a target detection method based on decision tree classification (DTC) for high-frequency surface wave radar (HFSWR). Firstly, the training sample set and labels are obtained by means of a ship automatic identification system (AIS). Then, feature vector of range dimension, Doppler dimension and range-Doppler (RD) dimension is extracted by way of cell averaging, ordered statistics, censored mean and trimmed mean. Finally, DTC is used to recognize “true” and “false” targets in feature space. Experimental results show that, under the same number of detection targets, the DTC method is superior to traditional CFAR methods, and the accuracy of target detection can be increased by more than 5%. Full article

The constant false-alarm rate (CFAR) algorithm is essential for detecting targets during radar signal processing. It has been improved to accurately detect targets, especially in nonhomogeneous environments, such as multitarget or clutter edge environments. For example, there are sort-based and variable index-based algorithms. However, these algorithms require large amounts of computation, making them difficult to apply in radar applications that require real-time target detection. We propose a new CFAR algorithm that determines the environment of a received signal through a new decision criterion and applies the optimal CFAR algorithms such as the modified variable index (MVI) and automatic censored cell averaging-based ordered data variability (ACCA-ODV). The Monte Carlo simulation results of the proposed CFAR algorithm showed a high detection probability of 93.8% in homogeneous and nonhomogeneous environments based on an SNR of 25 dB. In addition, this paper presents the hardware design, field-programmable gate array (FPGA)-based implementation, and verification results for the practical application of the proposed algorithm. We reduced the hardware complexity by time-sharing sum and square operations and by replacing division operations with multiplication operations when calculating decision parameters. We also developed a low-complexity and high-speed sorter architecture that performs sorting for the partial data in leading and lagging windows. As a result, the implementation used 8260 LUTs and 3823 registers and took 0.6 $\mathsf{\mu }$s to operate. Compared with the previously proposed FPGA implementation results, it is confirmed that the complexity and operation speed of the proposed CFAR processor are very suitable for real-time implementation. Full article

A Multiple-Input Multiple-Output (MIMO) Frequency-Modulated Continuous Wave (FMCW) radar can provide a range-angle map that expresses the signal power against each range and angle. It is possible to estimate object locations by detecting the signal power that exceeds a threshold using an algorithm, such as Constant False Alarm Rate (CFAR). However, noise and multipath components often exist over the range-angle map, which could produce false alarms for an undesired location depending on the threshold setting. In other words, the threshold setting is sensitive in noisy range-angle maps. Therefore, if the noise is reduced, the threshold can be easily set to reduce the number of false alarms. In this paper, we propose a method that improves the CFAR threshold tolerance by denoising a range-angle map using Deep Image Prior (DIP). DIP is an unsupervised deep-learning technique that enables image denoising. In the proposed method, DIP is applied to the range-angle map calculated by the Curve-Length (CL) method, and then the object location is detected over the denoised range-angle map based on Cell-Averaging CFAR (CA-CFAR), which is a typical threshold setting algorithm. Through the experiments to estimate human locations in indoor environments, we confirmed that the proposed method with DIP reduced the number of false alarms and estimated the human location accurately while improving the tolerance of the threshold setting, compared to the method without DIP. Full article

Traditional radar target detection algorithms are mostly based on statistical theory. They have weak generalization capabilities for complex sea clutter environments and diverse target characteristics, and their detection performance would be significantly reduced. In this paper, the range-azimuth-frame information obtained by scanning radar is converted into plain position indicator (PPI) images, and a novel Radar-PPInet is proposed and used for marine target detection. The model includes CSPDarknet53, SPP, PANet, power non-maximum suppression (P-NMS), and multi-frame fusion section. The prediction frame coordinates, target category, and corresponding confidence are directly given through the feature extraction network. The network structure strengthens the receptive field and attention distribution structure, and further improves the efficiency of network training. P-NMS can effectively improve the problem of missed detection of multi-targets. Moreover, the false alarms caused by strong sea clutter are reduced by the multi-frame fusion, which is also a benefit for weak target detection. The verification using the X-band navigation radar PPI image dataset shows that compared with the traditional cell-average constant false alarm rate detector (CA-CFAR) and the two-stage Faster R-CNN algorithm, the proposed method significantly improved the detection probability by 15% and 10% under certain false alarm probability conditions, which is more suitable for various environment and target characteristics. Moreover, the computational burden is discussed showing that the Radar-PPInet detection model is significantly lower than the Faster R-CNN in terms of parameters and calculations. Full article

Traditional constant false alarm rate (CFAR) methods have shown their potential for foreign object debris (FOD) indication. However, the performance of these methods would deteriorate under the complex clutter background in airport scenes. This paper presents a threshold-improved approach based on the cell-averaging clutter-map (CA-CM-) CFAR and tests it on a millimeter-wave (MMW) radar system. Clutter cases are first classified with variability indexes (VIs). In homogeneous background, the threshold is calculated by the student-t-distributed test statistic; under the discontinuous clutter conditions, the threshold is modified according to current VI conditions, in order to address the performance decrease caused by extended clutter edges. Experimental results verify that the chosen targets can be indicated by the t-distributed threshold in homogeneous background. Moreover, effective detection of the obscured targets could also be achieved with significant detectability improvement at extended clutter edges. Full article

Although radiation power minimization is the most important method for an advanced stealth aircraft to achieve the low probability of detection (LPD) performance against the opposite passive detection system (PDS), it is not always effective when the performance of PDS is advanced. In a target tracking scenario, an interference tactic is proposed in this paper to keep the airborne radar in an LPD state. Firstly, this paper introduces the minimization radiation power design of airborne radar based on the distance between the radar and the target, and introduces the minimization radiation power design of the airborne jammer based on the predicted detection probability of the opposite PDS. Then, after consulting the most commonly used constant false alarm rate (CFAR) technologies in passive detection systems, including the cell average CFAR, the greatest of CFAR, the smallest of CFAR and the ordered statistic CFAR, this paper analyzes their relationships and points out the way of interference. Finally, based on the constraints, not only including the predicted detection probabilities of airborne radar and opposite PDS, respectively, but also including the time synchronization which is necessary to avoid the leaked interference power generated by airborne jammer jamming the airborne radar echoes from the target, this paper establishes a math model to minimize the total interference power of airborne jammer without interfering target tracking. Simulation results show that the proposed model is effective. Full article

Multiple-input multiple-output (MIMO) radar is playing an important role in military and civilian fields. However, radio frequency (RF) multi-links have a large data-processing capacity and the system is bulky and complex. Therefore, a single-link RF MIMO has been the subject of heated discussed in recent years. Single-link technology shares the same regularity with that of the multi-link MIMO system, which makes the MIMO system simpler in structure without affecting its performance. In this study, a 2 × 2 array single RF link MIMO radar at X band was designed by combining MIMO radar with the concept of a single RF link in the communication field, and a simulation platform for studying its properties was established using SystemVue software. The whole system is controlled by the exclusive OR (XOR) operation results of two transmission signals, and one signal can control the antenna-switching signal to form a variety of orthogonal bases. The received two original signals are demodulated and the control signals enter the corresponding matched filters. The signal is processed by fast Fourier transformation (FFT) and the cell-averaging constant false alarm rate algorithm (CA-CFAR) is used to judge the signal. For multiple measurements, the Monte Carlo method was adopted to obtain its mean value as the final result. Compared with the traditional MIMO radar performance in acquiring the target position, speed, and detection probability, the results show that the computation time can be greatly reduced (due to decrease in the number of links in MIMO radar system) without any deterioration in the MIMO radar performance. The single RF link technology provides a broad prospect for the miniaturization of small radar applications. Full article
