Machines

23 pages, 8375 KiB

Open AccessEditor’s ChoiceArticle

Artificial-Intelligence-Based Condition Monitoring of Industrial Collaborative Robots: Detecting Anomalies and Adapting to Trajectory Changes

by Samuel Ayankoso, Fengshou Gu, Hassna Louadah, Hamidreza Fahham and Andrew Ball

Machines 2024, 12(9), 630; https://doi.org/10.3390/machines12090630 - 7 Sep 2024

Viewed by 1453

Abstract

The increasing use of collaborative robots in smart manufacturing, owing to their flexibility and safety benefits, underscores a critical need for robust predictive maintenance strategies to prevent unexpected faults/failures of the machine. This paper focuses on fault detection and employs multivariate operational data [...] Read more.

The increasing use of collaborative robots in smart manufacturing, owing to their flexibility and safety benefits, underscores a critical need for robust predictive maintenance strategies to prevent unexpected faults/failures of the machine. This paper focuses on fault detection and employs multivariate operational data from a universal robot to detect anomalies or early-stage faults using test data from designed anomalous conditions and artificial-intelligence-based anomaly detection techniques called autoencoders. The performance of three autoencoders, namely, a multi-layer-perceptron-based autoencoder, convolutional-neural-network-based autoencoder, and sparse autoencoder, was compared in detecting anomalies. The results indicate that the autoencoders effectively detected anomalies in the examined complex and noisy datasets with more than 93% overall accuracy and an F1 score exceeding 96% for the considered anomalous cases. Moreover, the integration of trajectory change detection and anomaly detection algorithms (i.e., the dynamic time warping algorithm and sparse autoencoder, respectively) was proposed for the local implementation of online condition monitoring. This integrated approach to anomaly detection and trajectory change provides a practical, adaptive, and economical solution for enhancing the reliability and safety of collaborative robots in smart manufacturing environments. Full article

(This article belongs to the Special Issue Signal Processing and Artificial Intelligence Technology for High-End Equipment Fault Diagnosis)

► Show Figures

Figure 1

13 pages, 9787 KiB

Open AccessEditor’s ChoiceArticle

A Study on the Static and Dynamic Characteristics of the Spindle System of a Spiral Bevel Gear Grinding Machine

by Shuai Huang, Juxin Wang, Kaifeng Huang and Jianwu Yu

Machines 2024, 12(9), 619; https://doi.org/10.3390/machines12090619 - 4 Sep 2024

Viewed by 685

Abstract

To enhance the static and dynamic performance of the grinding wheel spindle system, with the gear grinding machine (YKF2060) as the research object, a static mechanics model of the spindle system was established based on Castigliano’s theorem, taking into account the equivalent effect [...] Read more.

To enhance the static and dynamic performance of the grinding wheel spindle system, with the gear grinding machine (YKF2060) as the research object, a static mechanics model of the spindle system was established based on Castigliano’s theorem, taking into account the equivalent effect of the triple-point contact ball bearing at the front end of the spindle. Meanwhile, based on the overall transfer matrix method, a dynamic model of the main spindle–eccentric shaft dual-rotor system was established, taking into account the effects of shear deformation and gyroscopic moments. On this basis, the effect of the spindle span, the front and rear overhang of the eccentric shaft, and the bearing stiffness on the static stiffness and first-order critical speed of the system was analyzed. Finally, static stiffness experiments, modal tests, and finite element simulation models were conducted to verify the static and dynamic models. The results show that the stiffness of the front outer bearing has the greatest influence on the static and dynamic performance of the system, while the stiffness of the rear inner bearing has the least influence. The relative errors of the static stiffness and the first two natural frequencies between static stiffness experiments, modal tests, and finite element simulation models are less than 10%, and the mode shapes match well. The established static and dynamic model can effectively reflect both the static and dynamic characteristics of the spindle system. Full article

(This article belongs to the Section Advanced Manufacturing)

► Show Figures

Figure 1

22 pages, 6340 KiB

Open AccessEditor’s ChoiceArticle

Detecting Anomalies in Hydraulically Adjusted Servomotors Based on a Multi-Scale One-Dimensional Residual Neural Network and GA-SVDD

by Xukang Yang, Anqi Jiang, Wanlu Jiang, Yonghui Zhao, Enyu Tang and Zhiqian Qi

Machines 2024, 12(9), 599; https://doi.org/10.3390/machines12090599 - 28 Aug 2024

Viewed by 569

Abstract

A high-pressure hydraulically adjusted servomotor is an electromechanical–hydraulic integrated system centered on a servo valve that plays a crucial role in ensuring the safe and stable operation of steam turbines. To address the issues of difficult fault diagnoses and the low maintenance efficiency [...] Read more.

A high-pressure hydraulically adjusted servomotor is an electromechanical–hydraulic integrated system centered on a servo valve that plays a crucial role in ensuring the safe and stable operation of steam turbines. To address the issues of difficult fault diagnoses and the low maintenance efficiency of adjusted hydraulic servomotors, this study proposes a model for detecting abnormalities of hydraulically adjusted servomotors. This model uses a multi-scale one-dimensional residual neural network (M1D_ResNet) for feature extraction and a genetic algorithm (GA)-optimized support vector data description (SVDD). Firstly, the multi-scale features of the vibration signals of the hydraulically adjusted servomotor were extracted and fused using one-dimensional convolutional blocks with three different scales to construct a multi-scale one-dimensional residual neural network binary classification model capable of recognizing normal and abnormal states. Then, this model was used as a feature extractor to create a feature set of normal data. Finally, an abnormal detection model for the hydraulically adjusted servomotor was constructed by optimizing the support vector data domain based on this feature set using a genetic algorithm. The proposed method was experimentally validated on a hydraulically adjusted servomotor dataset. The results showed that, compared with the traditional single-scale one-dimensional residual neural network, the multi-scale feature vectors fused by the multi-scale one-dimensional convolutional neural network contained richer state-sensitive information, effectively improving the performance of detecting abnormalities in the hydraulically adjusted servomotor. Full article

(This article belongs to the Special Issue Advanced Control and Fault Detection Techniques in Hydraulic Machines and Systems)

► Show Figures

Figure 1

24 pages, 11901 KiB

Open AccessEditor’s ChoiceArticle

The Workspace Analysis of the Delta Robot Using a Cross-Section Diagram Based on Zero Platform

by Jun-Ho Hong, Ji-Ho Lim, Euntaek Lee and Dongwon Shin

Machines 2024, 12(8), 583; https://doi.org/10.3390/machines12080583 - 22 Aug 2024

Viewed by 784

Abstract

This paper introduces a new concept of a zero-platform delta robot with three key parameters affecting the shape and size of the workspace. This concept is applied to directly bring the torus configuration into the links of the robot and shows its usefulness [...] Read more.

This paper introduces a new concept of a zero-platform delta robot with three key parameters affecting the shape and size of the workspace. This concept is applied to directly bring the torus configuration into the links of the robot and shows its usefulness in configuring and generating the workspace conveniently. Analyzing the workspace of parallel robots, such as delta robots, requires extensive computation due to the constraints between the links, typically requiring complex equations or numerical methods. This paper proposes a new method for quickly estimating the shape and size of the workspace using a cross-section diagram based on a geometrical analysis of the zero-platform delta robot. The shape and size of the workspace can be rapidly estimated because the intersection of three cross-section diagrams needs only the torus’s 2D operation. Comparing the workspace between the cross-section diagram and the 3D CAD software, this paper shows that the cross-section diagram can analyze the shape and size of the workspace quickly and give a more geometrical understanding of the workspace. Full article

(This article belongs to the Section Machine Design and Theory)

► Show Figures

Figure 1

18 pages, 3548 KiB

Open AccessEditor’s ChoiceArticle

Numerical and Experimental Study on Dummy Blade with Underplatform Damper

by Di Li, Chenhong Du, Hongguang Li and Guang Meng

Machines 2024, 12(7), 461; https://doi.org/10.3390/machines12070461 - 7 Jul 2024

Cited by 1 | Viewed by 1056

Abstract

To confirm the variation in damping ratio offered by dry friction dampers against structural vibration stress, this study developed a blade vibration response test system for capturing damping characteristic curves through both frequency sweep excitation and damping-freevibration methods. The damping-free vibration method demonstrates [...] Read more.

To confirm the variation in damping ratio offered by dry friction dampers against structural vibration stress, this study developed a blade vibration response test system for capturing damping characteristic curves through both frequency sweep excitation and damping-freevibration methods. The damping-free vibration method demonstrates high efficiency, allowing for the acquisition of a complete damping ratio characteristic curve in a single experiment. Experimental findings indicate that the two contact surfaces on the triangular prism damper produce distinct damping effects, closely aligning with the predicted damping characteristic curves. The peak damping ratio was found to be independent of the centrifugal load of the damper; dampers with varying contact areas produce approximately similar damping characteristics; and the damping effect shows a positive correlation with the root extension length. Full article

(This article belongs to the Special Issue Cutting-Edge Research in Tribology and Its Applications to Rolling Element Bearings)

► Show Figures

Figure 1

14 pages, 5333 KiB

Open AccessEditor’s ChoiceArticle

Response Surface Methodology for Kinematic Design of Soft Pneumatic Joints: An Application to a Bio-Inspired Scorpion-Tail-Actuator

by Michele Gabrio Antonelli, Pierluigi Beomonte Zobel and Nicola Stampone

Machines 2024, 12(7), 439; https://doi.org/10.3390/machines12070439 - 26 Jun 2024

Cited by 2 | Viewed by 1234

Abstract

In soft robotics, the most used actuators are soft pneumatic actuators because of their simplicity, cost-effectiveness, and safety. However, pneumatic actuation is also disadvantageous because of the strong non-linearities associated with using a compressible fluid. The identification of analytical models is often complex, [...] Read more.

In soft robotics, the most used actuators are soft pneumatic actuators because of their simplicity, cost-effectiveness, and safety. However, pneumatic actuation is also disadvantageous because of the strong non-linearities associated with using a compressible fluid. The identification of analytical models is often complex, and finite element analyses are preferred to evaluate deformation and tension states, which are computationally onerous. Alternatively, artificial intelligence algorithms can be used to follow model-free and data-driven approaches to avoid modeling complexity. In this work, however, the response surface methodology was adopted to identify a predictive model of the bending angle for soft pneumatic joints through geometric and functional parameters. The factorial plan was scheduled based on the design of the experiment, minimizing the number of tests needed and saving materials and time. Finally, a bio-inspired application of the identified model is proposed by designing the soft joints and making an actuator that replicates the movements of the scorpion’s tail in the attack position. The model was validated with two external reinforcements to achieve the same final deformation at different feeding pressures. The average absolute errors between predicted and experimental bending angles for I and II reinforcement allowed the identified model to be verified. Full article

(This article belongs to the Special Issue Intelligent Bio-Inspired Robots: New Trends and Future Perspectives)

► Show Figures

Figure 1

20 pages, 11034 KiB

Open AccessEditor’s ChoiceArticle

Experimental Evaluation of Mechanical Compression Properties of Aluminum Alloy Lattice Trusses for Anti-Ice System Applications

by Carlo Giovanni Ferro, Sara Varetti and Paolo Maggiore

Machines 2024, 12(6), 404; https://doi.org/10.3390/machines12060404 - 12 Jun 2024

Viewed by 893

Abstract

Lattice structures have emerged as promising materials for aerospace structure applications due to their high strength-to-weight ratios, customizable properties, and efficient use of materials. These properties make them attractive for use in anti-ice systems, where lightweight and heat exchange are essential. This paper [...] Read more.

Lattice structures have emerged as promising materials for aerospace structure applications due to their high strength-to-weight ratios, customizable properties, and efficient use of materials. These properties make them attractive for use in anti-ice systems, where lightweight and heat exchange are essential. This paper presents an extensive experimental investigation into mechanical compression properties of lattice trusses fabricated from AlSi10Mg powder alloy, a material commonly used in casted aerospace parts. The truss structures were manufactured using the additive manufacturing selective laser melting technique and were subjected to uniaxial compressive loading to assess their performance. The results demonstrate that AlSi10Mg lattice trusses exhibit remarkable compressive strength with strong correlations depending upon both topology and cells’ parameters setup. The findings described highlight the potential of AlSi10Mg alloy as a promising material for custom truss fabrication, offering customizable cost-effective and lightweight solutions for the aerospace market. This study also emphasizes the role of additive manufacturing in producing complex structures with pointwise-tailored mechanical properties. Full article

(This article belongs to the Special Issue Recent Advances in 3D Printing in Industry 4.0)

► Show Figures

Figure 1

15 pages, 4434 KiB

Open AccessEditor’s ChoiceArticle

Preliminary Testing of a Passive Exoskeleton Prototype Based on McKibben Muscles

by Maria Paterna, Carlo De Benedictis and Carlo Ferraresi

Machines 2024, 12(6), 388; https://doi.org/10.3390/machines12060388 - 5 Jun 2024

Cited by 1 | Viewed by 1062

Abstract

Upper-limb exoskeletons for industrial applications can enhance the comfort and productivity of workers by reducing muscle activity and intra-articular forces during overhead work. Current devices typically employ a spring-based mechanism to balance the gravitational torque acting on the shoulder. As an alternative, this [...] Read more.

Upper-limb exoskeletons for industrial applications can enhance the comfort and productivity of workers by reducing muscle activity and intra-articular forces during overhead work. Current devices typically employ a spring-based mechanism to balance the gravitational torque acting on the shoulder. As an alternative, this paper presents the design of a passive upper-limb exoskeleton based on McKibben artificial muscles. The interaction forces between the exoskeleton and the user, as well as the mechanical resistance of the exoskeleton structure, were investigated to finalize the design of the device prior to its prototyping. Details are provided about the solutions adopted to assemble, wear, and regulate the exoskeleton’s structure. The first version of the device weighing about 5.5 kg was manufactured and tested by two users in a motion analysis laboratory. The results of this study highlight that the exoskeleton can effectively reduce the activation level of shoulder muscles without affecting the lumbar strain. Full article

(This article belongs to the Special Issue Intelligent Bio-Inspired Robots: New Trends and Future Perspectives)

► Show Figures

Figure 1

24 pages, 14201 KiB

Open AccessEditor’s ChoiceArticle

Research on Collaboration Motion Planning Method for a Dual-Arm Robot Based on Closed-Chain Kinematics

by Yuantian Qin, Kai Zhang, Kuiquan Meng and Zhehang Yin

Machines 2024, 12(6), 387; https://doi.org/10.3390/machines12060387 - 4 Jun 2024

Viewed by 1255

Abstract

Aiming to address challenges in the motion coordination of dual-arm robot engineering applications, a comprehensive set of planning methods is devised. This paper takes a dual-arm system composed of two six-degrees-of-freedom industrial robots as the research object. Initially, a transformation model is established [...] Read more.

Aiming to address challenges in the motion coordination of dual-arm robot engineering applications, a comprehensive set of planning methods is devised. This paper takes a dual-arm system composed of two six-degrees-of-freedom industrial robots as the research object. Initially, a transformation model is established for the characteristic trajectories between the workpiece coordinate system and various other coordinate systems. Subsequently, the position and orientation curves of the working trajectory are discretized to facilitate the controller’s execution. Furthermore, an analysis is conducted of the closed-chain kinematics relationship between two arms of the robot and a pose-calibration method based on a reference coordinate system is introduced. Finally, constraints to the collaborative motion of the dual-arm robot are analyzed, leading to the establishment of a motion collaboration planning methodology. Simulations and experiments demonstrate that the proposed approach enables effective and collaborative task planning for dual-arm robots. Moreover, joint angle and angular velocity curves corresponding to the motion trajectory exhibit smoothness, reducing joint impacts. Full article

(This article belongs to the Section Automation and Control Systems)

► Show Figures

Figure 1

19 pages, 8284 KiB

Open AccessEditor’s ChoiceArticle

Establishment and Analysis of Load Spectrum for Bogie Frame of High-Speed Train at 400 km/h Speed Level

by Guidong Tao, Zhiming Liu, Chengxiang Ji and Guangxue Yang

Machines 2024, 12(6), 382; https://doi.org/10.3390/machines12060382 - 3 Jun 2024

Viewed by 1054

Abstract

The bogie frame, as one of the most critical load-bearing structures of the Electric Multiple Unit (EMU), is responsible for bearing and transmitting various loads from the car body, wheelsets, and its own installation components. With the increasing operating speed of high-speed EMUs, [...] Read more.

The bogie frame, as one of the most critical load-bearing structures of the Electric Multiple Unit (EMU), is responsible for bearing and transmitting various loads from the car body, wheelsets, and its own installation components. With the increasing operating speed of high-speed EMUs, especially when the design and operational speeds exceed 400 km/h, the applicability of current international standards is uncertain. The load spectrum serves as the foundation for structural reliability design and fatigue evaluation. In this paper, the measured loads of the bogie frame of a CR400AF high-speed train on the Beijing–Shanghai high-speed railway are obtained, and the time-domain characteristic of the measured loads is analyzed under different operating conditions. Then, through the Weibull distribution of three parameters, the Weibull parameters at the 450 km/h speed level are fitted, and the maximum load and cumulative frequency under the speed level are derived. Finally, the load spectrum of the bogie frame at the 450 km/h speed level is established, which provides a more realistic load condition for accurately evaluating the fatigue strength of bogie frames at higher speed levels. Full article

(This article belongs to the Section Vehicle Engineering)

► Show Figures

Figure 1

21 pages, 7912 KiB

Open AccessEditor’s ChoiceArticle

Abnormal Detection and Fault Diagnosis of Adjustment Hydraulic Servomotor Based on Genetic Algorithm to Optimize Support Vector Data Description with Negative Samples and One-Dimensional Convolutional Neural Network

by Xukang Yang, Anqi Jiang, Wanlu Jiang, Yonghui Zhao, Enyu Tang and Shangteng Chang

Machines 2024, 12(6), 368; https://doi.org/10.3390/machines12060368 - 24 May 2024

Cited by 5 | Viewed by 867

Abstract

Because of the difficulty in fault detection for and diagnosing the adjustment hydraulic servomotor, this paper uses feature extraction technology to extract the time domain and frequency domain features of the pressure signal of the adjustment hydraulic servomotor and splice the features of [...] Read more.

Because of the difficulty in fault detection for and diagnosing the adjustment hydraulic servomotor, this paper uses feature extraction technology to extract the time domain and frequency domain features of the pressure signal of the adjustment hydraulic servomotor and splice the features of multiple pressure signals through the Multi-source Information Fusion (MSIF) method. The comprehensive expression of device status information is obtained. After that, this paper proposes a fault detection Algorithm GA-SVDD-neg, which uses Genetic Algorithm (GA) to optimize Support Vector Data Description with negative examples (SVDD-neg). Through joint optimization with the Mutual Information (MI) feature selection algorithm, the features that are most sensitive to the state deterioration of the adjustment hydraulic servomotor are selected. Experiments show that the MI algorithm has a better performance than other feature dimensionality reduction algorithms in the field of the abnormal detection of adjustment hydraulic servomotors, and the GA-SVDD-neg algorithm has a stronger robustness and generality than other anomaly detection algorithms. In addition, to make full use of the advantages of deep learning in automatic feature extraction and classification, this paper realizes the fault diagnosis of the adjustment hydraulic servomotor based on 1D Convolutional Neural Network (1DCNN). The experimental results show that this algorithm has the same superior performance as the traditional algorithm in feature extraction and can accurately diagnose the known faults of the adjustment hydraulic servomotor. This research is of great significance for the intelligent transformation of adjustment hydraulic servomotors and can also provide a reference for the fault warning and diagnosis of the Electro-Hydraulic (EH) system of the same type of steam turbine. Full article

(This article belongs to the Section Machines Testing and Maintenance)

► Show Figures

Figure 1

34 pages, 1581 KiB

Open AccessEditor’s ChoiceArticle

Machine Learning Approach for LPRE Bearings Remaining Useful Life Estimation Based on Hidden Markov Models and Fatigue Modelling

by Federica Galli, Philippe Weber, Ghaleb Hoblos, Vincent Sircoulomb, Giuseppe Fiore and Charlotte Rostain

Machines 2024, 12(6), 367; https://doi.org/10.3390/machines12060367 - 24 May 2024

Viewed by 1033

Abstract

Ball bearings are one of the most critical components of rotating machines. They ensure shaft support and friction reduction, thus their malfunctioning directly affects the machine’s performance. As a consequence, it is necessary to monitor the health conditions of such a component to [...] Read more.

Ball bearings are one of the most critical components of rotating machines. They ensure shaft support and friction reduction, thus their malfunctioning directly affects the machine’s performance. As a consequence, it is necessary to monitor the health conditions of such a component to avoid major degradations which could permanently damage the entire machine. In this context, HMS (Health Monitoring Systems) and PHM (Prognosis and Health Monitoring) methodologies propose a wide range of algorithms for bearing diagnosis and prognosis. The present article proposes an end-to-end PHM approach for ball bearing RUL (Remaining Useful Life) estimation. The proposed methodology is composed of three main steps: HI (Health Indicator) construction, bearing diagnosis and RUL estimation. The HI is obtained by processing non-stationary vibration data with the MODWPT (Maximum Overlap Discrete Wavelet Packet Transform). After that, a degradation profile is defined and coupled with crack initiation and crack propagation fatigue models. Lastly, a MB-HMM (Hidden Markov Model) is trained to capture the bearing degradation dynamics. This latter model is used to estimate the current degradation state as well as the RUL. The obtained results show good RUL prediction capabilities. In particular, the fatigue models allowed a reduction of the ML (Machine Learning) model size, improving the algorithms training phase. Full article

(This article belongs to the Special Issue Advances in Bearing Modeling, Fault Diagnosis, RUL Prediction (2nd Edition))

► Show Figures

Figure 1

21 pages, 6405 KiB

Open AccessEditor’s ChoiceArticle

New Health Indicator Construction and Fault Detection Network for Rolling Bearings via Convolutional Auto-Encoder and Contrast Learning

by Dongdong Wu, Da Chen and Gang Yu

Machines 2024, 12(6), 362; https://doi.org/10.3390/machines12060362 - 23 May 2024

Cited by 3 | Viewed by 1059

Abstract

As one of the most important components in rotating machinery, if bearings fail, serious disasters may occur. Therefore, the remaining useful life (RUL) prediction of bearings is of great significance. Health indicator (HI) construction and early fault detection play a crucial role in [...] Read more.

As one of the most important components in rotating machinery, if bearings fail, serious disasters may occur. Therefore, the remaining useful life (RUL) prediction of bearings is of great significance. Health indicator (HI) construction and early fault detection play a crucial role in data-driven RUL prediction. Unfortunately, most existing HI construction methods require prior knowledge and preset trends, making it difficult to reflect the actual degradation trend of bearings. And the existing early fault detection methods rely on massive historical data, yet manual annotation is time-consuming and laborious. To address the above issues, a novel deep convolutional auto-encoder (CAE) based on envelope spectral feature extraction is developed in this work. A sliding value window is defined in the envelope spectrum to obtain initial health indicators, which are used as preliminary labels for model training. Subsequently, CAE is trained by minimizing the composite loss function. The proposed construction method can reflect the actual degradation trend of bearings. Afterwards, the autoencoder is pre-trained through contrast learning (CL) to improve its discriminative ability. The model that has undergone offline pre-training is more sensitive to early faults. Finally, the HI construction method is combined with the early fault detection method to obtain a comprehensive network for online health assessment and fault detection, thus laying a solid foundation for subsequent RUL prediction. The superiority of the proposed method has been verified through experiments. Full article

(This article belongs to the Section Machines Testing and Maintenance)

► Show Figures

Figure 1

19 pages, 9470 KiB

Open AccessEditor’s ChoiceArticle

Optimizing Machining Efficiency in High-Speed Milling of Super Duplex Stainless Steel with SiAlON Ceramic Inserts

by Monica Guimarães, Victor Saciotto, Qianxi He, Jose M. DePaiva, Anselmo Diniz and Stephen Veldhuis

Machines 2024, 12(5), 349; https://doi.org/10.3390/machines12050349 - 17 May 2024

Cited by 1 | Viewed by 1520

Abstract

Super duplex stainless steels (SDSSs) are widely utilized across industries owing to their remarkable mechanical properties and corrosion resistance. However, machining SDSS presents considerable challenges, particularly at high speeds. This study investigates the machinability of SDSS grade SAF 2507 (UNS S32750) under high-speed [...] Read more.

Super duplex stainless steels (SDSSs) are widely utilized across industries owing to their remarkable mechanical properties and corrosion resistance. However, machining SDSS presents considerable challenges, particularly at high speeds. This study investigates the machinability of SDSS grade SAF 2507 (UNS S32750) under high-speed milling conditions using SiAlON insert tools. Comprehensive analysis of key machinability indicators, including chip compression ratio, chip analysis, shear angle, tool wear, and friction conditions, reveals that lower cutting speeds optimize machining performance, reducing cutting forces and improving chip formation. Finite element analysis (FEA) corroborates the efficacy of lower speeds and moderate feed rates. Furthermore, insights into friction dynamics at the tool–chip interface are offered, alongside strategies for enhancing SDSS machining. This study revealed the critical impact of cutting speed on cutting forces, with a significant reduction in forces at cutting speeds of 950 and 1350 m/min, but a substantial increase at 1750 m/min, particularly when tool wear is severe. Furthermore, the combination of 950 and 1350 m/min cutting speeds with a 0.2 mm/tooth feed rate led to smoother chip surfaces and decreased friction coefficients, thus enhancing machining efficiency. The presence of stick–slip phenomena at 1750 m/min indicated thermoplastic instability. Optimizing machining parameters for super duplex stainless steel necessitates balancing material removal rate and surface integrity, as the latter plays an important role in ensuring long-term performance and reliability in critical applications. Full article

(This article belongs to the Special Issue Recent Advances in Surface Integrity with Machining and Milling)

► Show Figures

Figure 1

24 pages, 6524 KiB

Open AccessEditor’s ChoiceArticle

Systematic Development of a Novel Laser-Sintering Machine with Roving Integration and Sustainability Evaluation

by Michael Baranowski, Johannes Scholz, Florian Kößler and Jürgen Fleischer

Machines 2024, 12(5), 336; https://doi.org/10.3390/machines12050336 - 14 May 2024

Viewed by 827

Abstract

Incorporating continuous carbon fibre-reinforced polymer (CCFRP) parts within additive manufacturing processes presents a significant advancement in the fabrication of robust lightweight parts, particularly relevant to aerospace, engineering, and various industrial sectors. Nonetheless, prevailing additive manufacturing methodologies for CCFRP parts exhibit notable limitations. Techniques [...] Read more.

Incorporating continuous carbon fibre-reinforced polymer (CCFRP) parts within additive manufacturing processes presents a significant advancement in the fabrication of robust lightweight parts, particularly relevant to aerospace, engineering, and various industrial sectors. Nonetheless, prevailing additive manufacturing methodologies for CCFRP parts exhibit notable limitations. Techniques reliant on resin and extrusion entail extensive and costly post-processing procedures to eliminate support structures, constraining design versatility and complicating small-scale production endeavours. In contrast, laser sintering (LS) emerges as a promising avenue for industrial application. It facilitates the efficient and cost-effective manufacturing of resilient parts without needing support structures. However, the current state of research and technological capabilities has yet to yield an LS machine that integrates the benefits of continuous fibre reinforcement with the inherent advantages of the LS process. This paper describes the systematic development process according to VDI 2221 of a new type of LS machine with automated continuous fibre integration while keeping the advantages of the LS process. The resulting physical prototype of the machine is also presented. Furthermore, this study presents an approach to integrate the cost and Product Carbon Footprint of the process in the product design. For this purpose, a machine state model was developed, and the costs and Product Carbon footprint of a part were analysed based on the model. The promising potential for future lightweight products is demonstrated through the production of CCFRP parts. Full article

(This article belongs to the Special Issue Advances in Composites Manufacturing: Machines, Systems and Processes)

► Show Figures

Figure 1

19 pages, 4774 KiB

Open AccessEditor’s ChoiceArticle

Resonant Fatigue Tests on Polished Drill Pipe Specimens

by Ciro Santus, Lorenzo Romanelli, Leonardo Bertini, Alessandro Burchianti and Tomoya Inoue

Machines 2024, 12(5), 314; https://doi.org/10.3390/machines12050314 - 3 May 2024

Cited by 1 | Viewed by 1061

Abstract

In this study, the fatigue strength of polished drill pipe specimens was investigated and compared with previous test results of corroded and not-corroded pipes. The resonant fatigue test rig, which was designed and implemented by the University of Pisa, is initially presented by [...] Read more.

In this study, the fatigue strength of polished drill pipe specimens was investigated and compared with previous test results of corroded and not-corroded pipes. The resonant fatigue test rig, which was designed and implemented by the University of Pisa, is initially presented by providing a detailed description of the set-up of the machine, the calibration of the strain gauges, the control system, and the correct identification of the vibrational node locations. A polishing rig was also designed and put into operation to remove the corrosion pits from the outer surface of almost the entire length of the drill pipe specimens. After the fatigue tests with the resonant rig, and the observation of the fatigue fracture of the specimens, a few samples were extracted from different zones (corroded and not corroded) of the failed drill pipe specimens. This allowed for investigations to be carried out using a scanning electronic microscope. The obtained results were analyzed using the Murakami model, and a discussion is presented about the effect of the corrosion pits on the fatigue strength. Full article

(This article belongs to the Special Issue Design and Experimental Activity of Testing Machines and Mechanical Test Rigs)

► Show Figures

Figure 1

21 pages, 7766 KiB

Open AccessEditor’s ChoiceArticle

Tool Wear Prediction Based on Residual Connection and Temporal Networks

by Ziteng Li, Xinnan Lei, Zhichao You, Tao Huang, Kai Guo, Duo Li and Huan Liu

Machines 2024, 12(5), 306; https://doi.org/10.3390/machines12050306 - 1 May 2024

Viewed by 1611

Abstract

Since tool wear accumulates in the cutting process, the condition of the cutting tool shows a degradation trend, which ultimately affects the surface quality. Tool wear monitoring and prediction are of significant importance in intelligent manufacturing. The cutting signal shows short-term randomness due [...] Read more.

Since tool wear accumulates in the cutting process, the condition of the cutting tool shows a degradation trend, which ultimately affects the surface quality. Tool wear monitoring and prediction are of significant importance in intelligent manufacturing. The cutting signal shows short-term randomness due to non-uniform materials in the workpiece, making it difficult to accurately monitor tool condition by relying on instantaneous signals. To reduce the impact of transient fluctuations, this paper proposes a novel network based on deep learning to monitor and predict tool wear. Firstly, a CNN model based on residual connection was designed to extract deep features from multi-sensor signals. After that, a temporal model based on an encoder and decoder was built for short-term monitoring and long-term prediction. It captured the instantaneous features and long-term trend features by mining the temporal dependence of the signals. In addition, an encoder and decoder-based temporal model is proposed for smoothing correction to improve the estimation accuracy of the temporal model. To validate the performance of the proposed model, the PHM dataset was used for wear monitoring and prediction and compared with other deep learning models. In addition, CFRP milling experiments were conducted to verify the stability and generalization of the model under different machining conditions. The experimental results show that the model outperformed other deep learning models in terms of MAE, MAPE, and RMSE. Full article

(This article belongs to the Special Issue Machinery Condition Monitoring and Intelligent Fault Diagnosis)

► Show Figures

Figure 1

21 pages, 37705 KiB

Open AccessEditor’s ChoiceArticle

Development of a Hand-Fan-Shaped Arm and a Model Predictive Controller for Leg Crossing, Walking, and One-Legged Balancing of a Wheeled-Bipedal Jumping Robot

by Seho Kim and Kiwon Yeom

Machines 2024, 12(5), 284; https://doi.org/10.3390/machines12050284 - 24 Apr 2024

Viewed by 1471

Abstract

Bipedal walking robots are advancing research by performing challenging human-like movements in complex environments. Particularly, wheeled-bipedal robots are used in many indoor environments by overcoming the speed and maneuverability limitations of bipedal walking robots without wheels. However, when both wheels lose contact with [...] Read more.

Bipedal walking robots are advancing research by performing challenging human-like movements in complex environments. Particularly, wheeled-bipedal robots are used in many indoor environments by overcoming the speed and maneuverability limitations of bipedal walking robots without wheels. However, when both wheels lose contact with the ground, maintaining lateral balance becomes challenging, and there is an increased risk of toppling over. Furthermore, utilizing robotic arms similar to human arms, in addition to wheel-based balance, could enable more precise and stable control. In this paper, we develop a wheeled-bipedal robot that is able to jump and drive while also being able to cross its legs and balance on one leg (the OLEBOT). The OLEBOT is designed with a hand-fan-shaped end-effector capable of generating compensatory torque. By tilting the hand-fan-shaped end-effector in the opposite direction, OLEBOT achieves pitch control and single-leg balance. In jumping scenario, it imitates the arm movements of a person performing stationary high jumps, while utilizing a cam-based leg joint system to boost jump height. In addition, this paper develops a control architecture based on model predictive control (MPC) to ensure stable posture in driving, jumping, and one-legged balancing scenarios for OLEBOT. Finally, the experimental results demonstrate that OLEBOT is capable of maintaining a stable posture using a wheeled-bipedal system and achieving balance in a one-legged stance. Full article

(This article belongs to the Section Automation and Control Systems)

► Show Figures

Figure 1

28 pages, 18980 KiB

Open AccessEditor’s ChoiceArticle

A Real-Time Dual-Task Defect Segmentation Network for Grinding Wheels with Coordinate Attentioned-ASP and Masked Autoencoder

by Yifan Li, Chuanbao Li, Ping Zhang and Han Wang

Machines 2024, 12(4), 276; https://doi.org/10.3390/machines12040276 - 21 Apr 2024

Viewed by 1211

Abstract

The current network for the dual-task grinding wheel defect semantic segmentation lacks high-precision lightweight designs, making it challenging to balance lightweighting and segmentation accuracy, thus severely limiting its practical application in grinding wheel production lines. Additionally, recent approaches for addressing the natural class [...] Read more.

The current network for the dual-task grinding wheel defect semantic segmentation lacks high-precision lightweight designs, making it challenging to balance lightweighting and segmentation accuracy, thus severely limiting its practical application in grinding wheel production lines. Additionally, recent approaches for addressing the natural class imbalance in defect segmentation fail to leverage the inexhaustible unannotated raw data on the production line, posing huge data wastage. Targeting these two issues, firstly, by discovering the similarity between Coordinate Attention (CA) and ASPP, this study has introduced a novel lightweight CA-ASP module to the DeeplabV3+, which is 45.3% smaller in parameter size and 53.2% lower in FLOPs compared to the ASPP, while achieving better segmentation precision. Secondly, we have innovatively leveraged the Masked Autoencoder (MAE) to address imbalance. By developing a new Hybrid MAE and applying it to self-supervised pretraining on tremendous unannotated data, we have significantly uplifted the network’s semantic understanding on the minority classes, which leads to further rises in both the overall accuracy and accuracy of the minorities without additional computational growth. Lastly, transfer learning has been deployed to fully utilize the highly related dual tasks. Experimental results demonstrate that the proposed methods with a real-time latency of 9.512 ms obtain a superior segmentation accuracy on the mIoU score over the compared real-time state-of-the-art methods, excelling in managing the imbalance and ensuring stability on the complicated scenes across the dual tasks. Full article

(This article belongs to the Special Issue Application of Deep Learning in Fault Diagnosis)

► Show Figures

Figure 1

15 pages, 5501 KiB

Open AccessEditor’s ChoiceArticle

A Study on the Cavitation Effect of Elastic Material with Textured Surfaces under Fluid Lubrication Conditions

by Haocheng Sun, Zhijun Yan, Shibo Wu, Ze Liu and Yuanyuan Jiang

Machines 2024, 12(4), 267; https://doi.org/10.3390/machines12040267 - 17 Apr 2024

Cited by 3 | Viewed by 1053

Abstract

This study investigates the effect of the elastic surface micro-texture on the cavitation and lubrication characteristics of the friction pairs through theoretical and experimental research. Through numerical simulations and experiments, the influences of the elastic modulus and sliding speed on the lubrication performance [...] Read more.

This study investigates the effect of the elastic surface micro-texture on the cavitation and lubrication characteristics of the friction pairs through theoretical and experimental research. Through numerical simulations and experiments, the influences of the elastic modulus and sliding speed on the lubrication performance of the friction pair are studied. The results show that under certain speed and load conditions, the friction coefficient of the elastic texture is smaller, and the lubrication performance is better than that of the rigid texture. Increasing the sliding speed and texture spacing properly can improve the lubrication performance of elastic friction pairs. In addition, as the elastic modulus decreases, the elastic deformation and oil film thickness increase, and the cavitation phenomenon becomes more significant. Thus, the lubrication performance of the friction pair is improved. Full article

(This article belongs to the Section Material Processing Technology)

► Show Figures

Figure 1

17 pages, 6269 KiB

Open AccessEditor’s ChoiceArticle

Investigation of Force-Controlled Polishing of Complex Curved PMMA Parts on a Machining Center

by Xiangran Meng, Yingpeng Wang, Xiaolong Yin, Haoyu Fu, Shuoxue Sun and Yuwen Sun

Machines 2024, 12(4), 259; https://doi.org/10.3390/machines12040259 - 14 Apr 2024

Viewed by 1338

Abstract

During the polishing process of complex curved PMMA parts, the polishing force is an important factor affecting the surface quality and optical performance. In this paper, a force-controlled polishing device integrated into a machining center to maintain the polishing force is investigated. In [...] Read more.

During the polishing process of complex curved PMMA parts, the polishing force is an important factor affecting the surface quality and optical performance. In this paper, a force-controlled polishing device integrated into a machining center to maintain the polishing force is investigated. In order to achieve the real-time active control of the polishing force, the linear voice coil motor and force sensors are used for motion and measurement. A compact structure was designed to couple the linear motion of the voice coil motor with the rotation for polishing. The force-controlled polishing system with a high real-time hardware architecture was developed to perform complex curved polishing path movement with precise force control. Next, the polishing force between the device and the workpiece was analyzed to obtain the mathematical model of the device. Considering the impact during the approaching phase of polishing, a fuzzy PI controller was proposed to reduce the overshoot and response time. To implement the control method, the controller model was established on Simulink and the control system was developed based on TwinCAT 3 software with real-time computing capability. Finally, a polishing experiment involving a complex curved PMMA part was conducted by a force-controlled polishing device integrated into a five-axis machining center. The results show that the device can effectively maintain the polishing force to improve surface quality and optical performance. Full article

(This article belongs to the Special Issue Machine Tools for Precision Machining: Design, Control and Prospects)

► Show Figures

Figure 1

15 pages, 37348 KiB

Open AccessEditor’s ChoiceArticle

Manufacturing via Plasma Metal Deposition of Hastelloy C-22 Specimens Made from Particles with Different Granulometries

by Isabel Montealegre-Meléndez, Eva M. Pérez-Soriano, Enrique Ariza, Erich Neubauer, Michael Kitzmantel and Cristina Arévalo

Machines 2024, 12(4), 253; https://doi.org/10.3390/machines12040253 - 11 Apr 2024

Cited by 1 | Viewed by 3920

Abstract

Additive manufacturing techniques offer significant advantages for creating complex components efficiently, saving both time and materials. This makes them particularly appealing for producing parts from intricate alloys, such as Hastelloy C-22. One such technique, plasma metal deposition, uses plasma on powdered material to [...] Read more.

Additive manufacturing techniques offer significant advantages for creating complex components efficiently, saving both time and materials. This makes them particularly appealing for producing parts from intricate alloys, such as Hastelloy C-22. One such technique, plasma metal deposition, uses plasma on powdered material to build up layers. The novelty of this work is to analyze and determine whether there is a correlation between the particle size and the final behaviour of specimens produced via additive manufacturing. To achieve this, four powders with an identical chemical composition but different granulometries were employed. Additionally, some of the samples underwent thermal treatment (progressive heating at 10 °C/min until 1120 °C, maintained for 20 min, followed by rapid air cooling). Four walls were constructed, and after mechanical, tribological, and microstructural characterization, it was determined that the influence of the thermal treatment remained consistent, regardless of particle size. It was observed that the particle size slightly affected the final properties: the finer the powder, the lower the ultimate tensile strength values. Furthermore, it was evident that the thermal treatment substantially affected the microstructure and wear behavior of all the specimens, regardless of their initial particle size. Full article

(This article belongs to the Special Issue Advance in Additive Manufacturing)

► Show Figures

Figure 1

22 pages, 8155 KiB

Open AccessEditor’s ChoiceArticle

Research on the Control Method of a Brushless DC Motor Based on Second-Order Active Disturbance Rejection Control

by Pan Zhang, Zhaoyao Shi, Bo Yu and Haijiang Qi

Machines 2024, 12(4), 244; https://doi.org/10.3390/machines12040244 - 8 Apr 2024

Cited by 4 | Viewed by 1613

Abstract

This research addresses the issues of weak anti-disturbance ability, fast response, and incompatibility of overshoot in the control process of brushless DC motors (BLDCs). A six-step commutation control method based on second-order active disturbance rejection control (ADRC) is derived following the analysis of [...] Read more.

This research addresses the issues of weak anti-disturbance ability, fast response, and incompatibility of overshoot in the control process of brushless DC motors (BLDCs). A six-step commutation control method based on second-order active disturbance rejection control (ADRC) is derived following the analysis of the BLDC model and the mathematical model of ADRC. A control model of the BLDC using both PI and ADRC is constructed. Detailed comparative and quantitative analyses of the simulation results using PI and ADRC are conducted, focusing on the anti-load disturbance capabilities using the integrated square error (ISE), integrated time square error (ITSE), integrated absolute error (IAE), and integrated time absolute error (ITAE). Experimental testing on the STM32F4 controller is also carried out, analyzing four error integral criteria in depth. The results indicate that both the ADRC and PI control modes can track the target signal without overshooting, demonstrating strong anti-load disturbance ability and robustness at varying working speeds. In the BLDC control system, using the ADRC control method can achieve fast and non-overshoot tracking of target signals compared to the PI control method, and ADRC has stronger resistance to load disturbances. Full article

(This article belongs to the Special Issue Design and Control of Electrical Drives and Electrical Machines)

► Show Figures

Figure 1

25 pages, 8723 KiB

Open AccessEditor’s ChoiceArticle

Experimental Investigation and Control of Driveline Torsional Vibrations during Clutch-to-Clutch Shifts of Electrified Vehicles

by Sooyoung Kim

Machines 2024, 12(4), 239; https://doi.org/10.3390/machines12040239 - 5 Apr 2024

Viewed by 1095

Abstract

An electrified vehicle equipped with a stepped-ratio transmission and clutch(es) requires precise control of the clutch actuator(s) and power sources to achieve optimal gear shift performance, which is characterized by smooth and swift gear shifts. Owing to the absence of the smoothing effect [...] Read more.

An electrified vehicle equipped with a stepped-ratio transmission and clutch(es) requires precise control of the clutch actuator(s) and power sources to achieve optimal gear shift performance, which is characterized by smooth and swift gear shifts. Owing to the absence of the smoothing effect of torque converters, dual-clutch transmission (DCT) powertrains are prone to inducing abrupt shift shocks—particularly during rapid clutch-to-clutch shifts. Balancing the smoothness and speed of shifts is a significant challenge and was the key focus of this study. Multiple experiments and model-based analyses were conducted to investigate the tradeoff between smoothness and shift time during the clutch-to-clutch shifts of a parallel-type hybrid electric vehicle with a dry DCT. Additionally, the adverse effects of inaccurate power-source control on shift quality were experimentally investigated. The results revealed the primary physical factors in terms of control causing torsional driveline oscillations in clutch-to-clutch shifts. According to these observations, a detailed quantitative guide including how to generate reference trajectories for shift control is proposed, with the aim of reducing the driveline torsional vibrations without compromising the shift time. The effectiveness of the proposed control strategy was demonstrated through real-time experiments on an electrified powertrain with a DCT using a dedicated test bench. This study provides valuable insights for optimizing the shift performance of electrified vehicles—particularly for managing torsional vibrations during clutch-to-clutch shifts. Full article

(This article belongs to the Special Issue Advances in Vehicle Brake and Clutch Systems)

► Show Figures

Figure 1

21 pages, 14691 KiB

Open AccessEditor’s ChoiceArticle

Design of a Flexure-Based Flywheel for the Storage of Angular Momentum and Kinetic Energy

by Patrick Flückiger, Florent Cosandier, Hubert Schneegans and Simon Henein

Machines 2024, 12(4), 232; https://doi.org/10.3390/machines12040232 - 30 Mar 2024

Viewed by 1175

Abstract

The flywheel is a widespread mechanical component used for the storage of kinetic energy and angular momentum. It typically consists of cylindrical inertia rotating about its axis on rolling bearings, which involves undesired friction, lubrication, and wear. This paper presents an alternative mechanism [...] Read more.

The flywheel is a widespread mechanical component used for the storage of kinetic energy and angular momentum. It typically consists of cylindrical inertia rotating about its axis on rolling bearings, which involves undesired friction, lubrication, and wear. This paper presents an alternative mechanism that is functionally equivalent to a classical flywheel while relying exclusively on limited-stroke flexure joints. This novel one-degree-of-freedom zero-force mechanism has no wear and requires no lubrication: it is thus compatible with extreme environments, such as vacuum, cryogenics, or ionizing radiation. The mechanism is composed of two coupled pivoting rigid bodies whose individual angular momenta vary during motion but whose sum is constant at all times when the pivoting rate is constant. The quantitative comparison of the flexure-based flywheel to classical ones based on a hollow cylinder as inertia shows that the former typically stores 6 times less angular momentum and kinetic energy for the same mass while typically occupying 10 times more volume. The freedom of design of the shape of the rigid bodies offers the possibility of modifying the ratio of the stored kinetic energy versus angular momentum, which is not possible with classical flywheels. For example, a flexure-based flywheel with rigid pivoting bodies in the shape of thin discs stores 100 times more kinetic energy than a classical flywheel with the same angular momentum. A proof-of-concept prototype was successfully built and characterized in terms of reaction moment generation, which validates the presented analytical model. Full article

(This article belongs to the Special Issue Dynamics and Optimization of Compliant and Flexible Mechanisms)

► Show Figures

Figure 1

19 pages, 12946 KiB

Open AccessEditor’s ChoiceArticle

AC-Winding-Resistance Calculation of Toroidal Inductors with Solid-Round-Wire and Litz-Wire Winding Based on Complex Permeability Modeling

by Dae-Yong Um, Seung-Ahn Chae and Gwan-Soo Park

Machines 2024, 12(4), 228; https://doi.org/10.3390/machines12040228 - 28 Mar 2024

Cited by 1 | Viewed by 1776

Abstract

This paper has investigated a method for calculating the frequency-dependent winding resistance of toroidal inductor windings with Litz-wire as well as solid-round wire. The modified Dowell’s model is employed to address the effectiveness for inductor windings with the low and high filling factors. [...] Read more.

This paper has investigated a method for calculating the frequency-dependent winding resistance of toroidal inductor windings with Litz-wire as well as solid-round wire. The modified Dowell’s model is employed to address the effectiveness for inductor windings with the low and high filling factors. To overcome the limitation of this model, especially for a winding densely wound around the core, an alternative approach based on the complex permeability and iterative calculations is proposed. For the calculated AC-resistance factor of five inductors with different numbers of turns, layers with the same wire diameters are compared with that of FEA, and the three air-core toroidal windings are manufactured and tested within the frequency where the self-resonance can be neglected. The proposed model demonstrates the versality of the AC-resistance calculation of both solid- and Litz-wire windings within an error of 15% across a wide range of frequencies up to 1 MHz, compared with FEA. Full article

(This article belongs to the Section Electrical Machines and Drives)

► Show Figures

Figure 1

14 pages, 3763 KiB

Open AccessEditor’s ChoiceArticle

Supercritical Operation of Bearingless Cross-Flow Fan

by Ivana Bagaric, Daniel Steinert, Thomas Nussbaumer and Johann W. Kolar

Machines 2024, 12(4), 223; https://doi.org/10.3390/machines12040223 - 27 Mar 2024

Cited by 1 | Viewed by 1216

Abstract

This paper presents a decoupled bearingless cross-flow fan (CFF) that operates at a supercritical speed, thereby increasing the maximum achievable rotational speed and fluid dynamic power. In magnetically levitated CFF rotors, the rotational speed and fan performance are limited by the bending resonance [...] Read more.

This paper presents a decoupled bearingless cross-flow fan (CFF) that operates at a supercritical speed, thereby increasing the maximum achievable rotational speed and fluid dynamic power. In magnetically levitated CFF rotors, the rotational speed and fan performance are limited by the bending resonance frequency. This is primarily defined by the low mechanical bending stiffness of the CFF blades, which are optimised for fluid dynamic performance, and the heavy rotor magnets on both rotor sides, which add significant mass but a minimal contribution to the overall rotor stiffness. This results in detrimental deformations of the CFF blades in the vicinity of the rotor bending resonance frequency; hence, the CFF is speed-limited to subcritical rotational speeds. The novel CFF rotor presented in this study features additional mechanical decoupling elements with low bending stiffness between the fan blades and the rotor magnets. Thus, the unbalance forces primarily deform the soft decoupling elements, which enables them to pass resonances without CFF blade damage and allows rotor operation in the supercritical speed region due to the self-centring effect of the rotor. The effects of the novel rotor design on the rotor dynamic behaviour are investigated by means of a mass-spring-damper model. The influence of different decoupling elements on the magnetic bearing is experimentally tested and evaluated, from which an optimised decoupled CFF rotor is derived. The final prototype enables a stable operation at 7000 rpm in the supercritical speed region. This corresponds to a rotational speed increase of 40%, resulting in a

28 %

higher, validated fluid flow and a

100 %

higher static pressure compared to the previously presented bearingless CFF without decoupling elements. Full article

(This article belongs to the Section Machine Design and Theory)

► Show Figures

Figure 1

20 pages, 7249 KiB

Open AccessEditor’s ChoiceArticle

Enhancing Real-Time Kinematic Relative Positioning for Unmanned Aerial Vehicles

by Yujin Shin, Chanhee Lee and Euiho Kim

Machines 2024, 12(3), 202; https://doi.org/10.3390/machines12030202 - 19 Mar 2024

Cited by 2 | Viewed by 1433

Abstract

Real-time kinematic (RTK) positioning of the global navigation satellite systems (GNSS) is used to provide centimeter-level positioning accuracy. There are several ways to implement RTK but a Kalman filter-based RTK is preferred because of its superior capability to resolve GNSS carrier phase integer [...] Read more.

Real-time kinematic (RTK) positioning of the global navigation satellite systems (GNSS) is used to provide centimeter-level positioning accuracy. There are several ways to implement RTK but a Kalman filter-based RTK is preferred because of its superior capability to resolve GNSS carrier phase integer ambiguities. However, the positioning performance of the Kalman filter-based RTK is often compromised by various factors when it comes to determining a precise relative position vector between moving unmanned aerial vehicles (UAVs) equipped with low-cost GNSS receivers and antennas, where the locations of both GNSS antennas are not accurately known and change over time. Some of the critical factors that lead to a high rate of incorrect resolutions of carrier phase integer ambiguities are measurement time differences between GNSS receivers, frequent cycle slips with high noise in code and carrier phase measurements, and an improper Kalman filter gain due to a newly risen satellite. In this paper, effective methods to deal with those factors to achieve a seamless Kalman filter-based RTK performance in moving UAVs are presented. Using our extensive 45 flight tests data sets, conducted over a duration of 3 to 12 min, the RTK positioning results showed that the root-mean-square position error (RMSE) decreased by up to 95.13%, with an average of 65.31%, and that the percentage of epochs that passed the ratio test, which is the most common method for validating double differenced carrier phase integer ambiguity resolution, increased by up to 130%, with an average of 23.54%. Full article

(This article belongs to the Special Issue Autonomous Navigation of Mobile Robots and UAV)

► Show Figures

Figure 1

12 pages, 6554 KiB

Open AccessEditor’s ChoiceArticle

Two-Step PM Procedure for Fabrication of Super-Engineering Plastic Gears

by Tatsuhiko Aizawa, Tomohiro Miyata and Kiyoyuki Endoh

Machines 2024, 12(3), 174; https://doi.org/10.3390/machines12030174 - 4 Mar 2024

Cited by 1 | Viewed by 1390

Abstract

The two-step PM (powder metallurgy)-route procedure was proposed to fabricate a super-engineering plastic gear directly from powder feedstock. Its lightweight, fully dense integrity and high-stiffness has been found to be suitable for reducers in robotics and electric vehicles, as they work even in [...] Read more.

The two-step PM (powder metallurgy)-route procedure was proposed to fabricate a super-engineering plastic gear directly from powder feedstock. Its lightweight, fully dense integrity and high-stiffness has been found to be suitable for reducers in robotics and electric vehicles, as they work even in severe environmental conditions. In this study, the green compaction and sinter-forging processes were used to consolidate the polyimide powder feedstock and to sinter forge the solid preform into the final products. To demonstrate the high density of preforms and sinter-forged gears, a hardness measurement and X-ray computer tomography were employed. The gear-grade balancing was also evaluated to describe the effect of fine sinter-forging conditions on the dimensional quality of polyimide gears. High gear grade with JIS-2 class proved that the polyimide was useful as a matrix of lightweight and high-strength gears. Full article

(This article belongs to the Section Advanced Manufacturing)

► Show Figures

Figure 1

17 pages, 10054 KiB

Open AccessEditor’s ChoiceArticle

Analytical Solution for Electromagnetic Performance Analysis of Permanent Magnet Synchronous Motor with a Parallel Magnetized Cylindrical Permanent Magnet

by Hao Lin, Haipeng Geng, Ling Li, Leiming Song and Xiaojun Hu

Machines 2024, 12(3), 152; https://doi.org/10.3390/machines12030152 - 22 Feb 2024

Cited by 1 | Viewed by 1805

Abstract

High-speed direct-drive permanent magnet synchronous motors (PMSMs), supported by elastic foil gas bearings, have broad applications, such as in microcompressors. However, some problems remain to be solved for the electrical performance analysis of PMSMs. For example, there is presently no related analytical model [...] Read more.

High-speed direct-drive permanent magnet synchronous motors (PMSMs), supported by elastic foil gas bearings, have broad applications, such as in microcompressors. However, some problems remain to be solved for the electrical performance analysis of PMSMs. For example, there is presently no related analytical model that can be used in rotor dynamics expression for this type of PMSM. This study aimed to establish theoretical models for electromagnetic force density and torque. The process involved both theoretical and experimental research. The analytic models of air gap magnetic density, electromagnetic force density, and electromagnetic performance were established for a PMSM with a parallel magnetized cylindrical permanent magnet. The analytic calculation was conducted, and the results of the analytic model were obtained. The analytical model of the electromagnetic torque and force can be applied in theoretical research on rotor dynamics. The model provides a theoretical basis and method for studying the influence of the electromagnetic load on rotor dynamics. A finite element simulation analysis of the electrical performance of the PMSM was carried out. An electrical performance experiment was conducted. The deviation between the experimental result and the theoretical value was less than 4%. This result indicated that the analytic models could be used in a dynamics analysis of compressors that are directly driven by a PMSM for application in engineering and industrial contexts. Full article

(This article belongs to the Special Issue Optimal Design and Drive of Permanent Magnet Synchronous Motors)

► Show Figures

Figure 1

25 pages, 9519 KiB

Open AccessEditor’s ChoiceArticle

Design and Control of a Climbing Robot for Autonomous Vertical Gardening

by Marko Jamšek, Gal Sajko, Jurij Krpan and Jan Babič

Machines 2024, 12(2), 141; https://doi.org/10.3390/machines12020141 - 17 Feb 2024

Cited by 2 | Viewed by 1981

Abstract

This paper focuses on the development of a novel climbing robot that is designed for autonomous maintenance of vertical gardens in urban environments. The robot, designed with a unique five-legged structure, is equipped with a range of electrical and mechanical components, enabling it [...] Read more.

This paper focuses on the development of a novel climbing robot that is designed for autonomous maintenance of vertical gardens in urban environments. The robot, designed with a unique five-legged structure, is equipped with a range of electrical and mechanical components, enabling it to autonomously navigate and maintain a specially designed vertical garden wall facilitating interactive maintenance and growth monitoring. The motion planning and control of the robot were developed to ensure precise and adaptive movement across the vertical garden wall. Advanced algorithms were employed to manage the complex dynamics of the robot’s movements, optimizing its efficiency and effectiveness in navigating and maintaining the garden structure. The operation of the robot in maintaining the vertical garden was evaluated during a two-week trial where the robot successfully performed nearly 8000 leg movements, with only 0.6% requiring human intervention. This demonstrates a high level of autonomy and reliability. This study concludes that the pentapod robot demonstrates significant potential for automating the maintenance of vertical gardens, offering a promising tool for enhancing urban green spaces. Full article

(This article belongs to the Special Issue The Latest Advances in Climbing and Walking Robots)

► Show Figures

Figure 1

19 pages, 7851 KiB

Open AccessEditor’s ChoiceArticle

An Air Spring Resonant Vibration Exciter for Large Structures

by Renato Brancati, Domenico De Falco, Giandomenico Di Massa, Stefano Pagano and Ernesto Rocca

Machines 2024, 12(2), 131; https://doi.org/10.3390/machines12020131 - 12 Feb 2024

Viewed by 1511

Abstract

Periodic monitoring of large industrial and civil structures is carried out through static and dynamic measurements. The monitoring, carried out over many years, offers important information for evaluating the health of structures and their management. Dynamic tests are carried out starting from measurements [...] Read more.

Periodic monitoring of large industrial and civil structures is carried out through static and dynamic measurements. The monitoring, carried out over many years, offers important information for evaluating the health of structures and their management. Dynamic tests are carried out starting from measurements of the vibrations of the structure induced by mechanical devices or by the surrounding environment. If a ground support element is available, it is possible to exert a forcing action on the structure using actuators fixed to the support. When a ground support is unavailable, the structure can be forced using devices comprised of masses with rotary or reciprocating translational motion. These masses must be large enough to excite appreciable mechanical vibrations of the structure. In this paper, a vibration exciter, based on a mass suspended on an air spring and forced to vibrate at the resonant frequency, is proposed. Thanks to the resonant condition, the force transmitted to the structure is amplified compared to that applied to the mass. The excitation frequency can be adjusted by altering the inflation pressure of the air spring to modify the natural frequency of the system. In the paper, after the presentation of some mechanical devices used as vibration exciters for large structures, the proposed device is described and the first experimental results are reported. Full article

(This article belongs to the Section Machine Design and Theory)

► Show Figures

Figure 1

21 pages, 30482 KiB

Open AccessEditor’s ChoiceArticle

Design and Testing of a New Type of Planetary Traction Drive Bearing-Type Reducer

by Hongyu Shu, Yijie Yu, Ran Shu, Wenjie Wang and Changjiang Pan

Machines 2024, 12(2), 107; https://doi.org/10.3390/machines12020107 - 4 Feb 2024

Viewed by 1947

Abstract

This paper presents the design and development of a new type of planetary traction drive bearing-type reducer. In this design, the transmission outer ring is replaced with an elastic ring. The design constructs a circular arc at the axial end of the rolling [...] Read more.

This paper presents the design and development of a new type of planetary traction drive bearing-type reducer. In this design, the transmission outer ring is replaced with an elastic ring. The design constructs a circular arc at the axial end of the rolling body’s contour line. This ensures that the contact point of this arc with the reducer’s outer ring and the inner ring’s axial end face is maintained on the radial traction contact line. As a result, it can replace the thrust bearing and provide an axial support function. It has the advantages of simple structure, easy processing, smooth transmission, and low noise. This paper first introduces the design and development process of this bearing-type reducer and presents systematic research on its transmission principle and dynamics. Subsequently, in response to the edge effect phenomenon of the outer ring contact line, the contour line of the outer ring is refined by adopting the shaping method used for bearing rollers, establishing a full circular arc profile shaping method, which significantly improves its edge effect. Finally, in our investigations, combined with experimental tests, a prototype of the bearing-type reducer was fabricated, and the speed ratio, torque, and transmission efficiency of the reducer were studied. The results demonstrate that the bearing-type reducer can achieve high transmission accuracy and efficiency. The transmission performance varies significantly under different lubrication conditions, with the peak efficiency reaching as high as 99.97% when using Santotrac 50 traction oil. The results verify the feasibility of the proposed design method and have the potential to be applied in wheel hub motors and robot joints. Full article

(This article belongs to the Section Electrical Machines and Drives)

► Show Figures

Figure 1

19 pages, 7670 KiB

Open AccessEditor’s ChoiceArticle

Automated Maximum Torque per Ampere Identification for Synchronous Reluctance Machines with Limited Flux Linkage Information

by Shuo Wang, Vasyl Varvolik, Yuli Bao, Ahmed Aboelhassan, Michele Degano, Giampaolo Buticchi and He Zhang

Machines 2024, 12(2), 96; https://doi.org/10.3390/machines12020096 - 29 Jan 2024

Cited by 2 | Viewed by 1492

Abstract

The synchronous reluctance machine is well-known for its highly nonlinear magnetic saturation and cross-saturation characteristics. For high performance and high-efficiency control, the flux-linkage maps and maximum torque per ampere table are of paramount importance. This study proposes a novel automated online searching method [...] Read more.

The synchronous reluctance machine is well-known for its highly nonlinear magnetic saturation and cross-saturation characteristics. For high performance and high-efficiency control, the flux-linkage maps and maximum torque per ampere table are of paramount importance. This study proposes a novel automated online searching method for obtaining accurate flux-linkage and maximum torque per ampere Identification. A limited 6 × 2 dq-axis flux-linkage look-up table is acquired by applying symmetric triangle pulses during the self-commissioning stage. Then, three three-dimensional modified linear cubic spline interpolation methods are applied to extend the flux-linkage map. The proposed golden section searching method can be easily implemented to realize higher maximum torque per ampere accuracy after 11 iterations with a standard drive, which is a proven faster solution with reduced memory sources occupied. The proposed algorithm is verified and tested on a 15-kW SynRM drive. Furthermore, the iterative and execution times are evaluated. Full article

(This article belongs to the Special Issue Electrical Machines and Drives: Modeling, Simulation and Testing)

► Show Figures

Figure 1

22 pages, 24921 KiB

Open AccessEditor’s ChoiceArticle

Development of a Compact Incremental Forming Machine

by Tatiana P. Resende, Gustavo P. Carmo, Daniel G. Afonso and Ricardo J. Alves de Sousa

Machines 2024, 12(2), 86; https://doi.org/10.3390/machines12020086 - 23 Jan 2024

Viewed by 1517

Abstract

Since the beginning of the 21st century, incremental sheet-metal-forming processes, such as single-point incremental forming (SPIF), have been the subject of extensive research. The SPIF process is highlighted as an efficient and cost-effective solution for producing complex parts with different materials and scales, [...] Read more.

Since the beginning of the 21st century, incremental sheet-metal-forming processes, such as single-point incremental forming (SPIF), have been the subject of extensive research. The SPIF process is highlighted as an efficient and cost-effective solution for producing complex parts with different materials and scales, surpassing conventional methods and being ideal for small series and customized products. Various machines can be used to implement SPIF, such as adapted milling machines, serial robots, and dedicated machines, each with its own advantages. However, although it requires a higher initial investment, a dedicated machine offers superior performance. The objective of this project was the creation of a compact and portable dedicated machine, which included the design of suitable kinematics, a mechanical project, and numerical control. The structural design led to the optimization of the dimensions of the robot arms. Direct and indirect kinematics were analyzed. Finally, the careful selection and adaptation of components were carried out, bearing in mind the support system of the forming punch, including the selection and sizing of motors, reducers, and linear actuators. A functional early prototype was successfully built and tested. Full article

(This article belongs to the Special Issue Advances in Composites Manufacturing: Machines, Systems and Processes)

► Show Figures

Figure 1

15 pages, 4215 KiB

Open AccessEditor’s ChoiceArticle

A Novel Load Extrapolation Method for Multiple Non-Stationary Loads on the Drill Pipe of a Rotary Rig

by Haijin Wang, Zonghai Zhang, Jiguang Zhang, Yuying Shen and Jixin Wang

Machines 2024, 12(1), 75; https://doi.org/10.3390/machines12010075 - 19 Jan 2024

Cited by 2 | Viewed by 1516

Abstract

The drill pipe of a rotary rig is subject to the dynamic influence of non-stationary loads, including rotation torque and applied force. In order to address the challenge of simultaneously extrapolating multiple non-stationary loads, a novel extrapolation framework is proposed. This framework utilizes [...] Read more.

The drill pipe of a rotary rig is subject to the dynamic influence of non-stationary loads, including rotation torque and applied force. In order to address the challenge of simultaneously extrapolating multiple non-stationary loads, a novel extrapolation framework is proposed. This framework utilizes rainflow counting to obtain mean and amplitude sequences of the loads. The extreme values of the amplitude sequence are fitted using the Generalized Pareto Distribution (GPD), while the median values are fitted using the Double Kernel Density Estimation (DKDE). By extrapolating the Inverse Cumulative Distribution Function (ICDF) based on the fitted distribution, a new amplitude sequence can be derived. The combination of this extrapolated amplitude sequence with the original mean sequence forms a new load spectrum. The results of applying the proposed extrapolation method to the drill pipe of a rotary rig demonstrate the ability of the method to yield conservative extrapolation results and accurately capture the variations in damage under the original working conditions. Full article

(This article belongs to the Section Machine Design and Theory)

► Show Figures

Figure 1

17 pages, 4577 KiB

Open AccessEditor’s ChoiceArticle

An Experimental and Numerical Study of the Laser Ablation of Bronze

by Esmaeil Ghadiri Zahrani, Vasiliki E. Alexopoulou, Emmanouil L. Papazoglou, Bahman Azarhoushang and Angelos Markopoulos

Machines 2024, 12(1), 63; https://doi.org/10.3390/machines12010063 - 16 Jan 2024

Cited by 3 | Viewed by 1400

Abstract

The use of lasers in various precise material removal processes has emerged as a viable and efficient alternative to traditional mechanical methods. However, the laser ablation of materials is a complex, multi-parameter process where scanning paths need to be repeated multiple times. This [...] Read more.

The use of lasers in various precise material removal processes has emerged as a viable and efficient alternative to traditional mechanical methods. However, the laser ablation of materials is a complex, multi-parameter process where scanning paths need to be repeated multiple times. This repetition causes changes in the absorption and temperature distribution along the scanning path, thereby affecting the accuracy of the ablation. Therefore, it is crucial to thoroughly study these phenomena. This article presents an experimental and numerical study on the laser ablation of bronze (DIN: 1705) in a multi-track ablation process. Specifically, six consecutive passes using a ns laser at three different energy densities were conducted. After each pass, measurements of the ablation depth and pile-up height were taken at three distinct points along the track (start, middle, and end) to evaluate the efficiency and quality of the process. To gain a deeper understanding of the underlying physical mechanisms, a numerical simulation model based on the Finite Element Method (FEM) was developed. The effective absorptivity was defined through reverse engineering, and the material’s cooling rates were also estimated. This study’s findings provide significant insights into the influence of machining parameters on the ablation process and its progression with varying numbers of consecutive repetitions. A primarily linear correlation was deduced between the ablation depth, energy density, and number of repetitions, while the relationship with the pile-up height appeared to be more ambiguous and nonlinear. The estimated cooling rates ranged from 10⁶ to 10¹⁰ [K/s]. Additionally, a heat accumulation phenomenon and a gradual temperature increase resulting from consecutive laser scans were also observed. A good agreement between the simulation results and experiments for the ablation depths was observed. Full article

(This article belongs to the Special Issue Advances and Trends in Non-conventional, Abrasive and Precision Machining 2022)

► Show Figures

Figure 1

25 pages, 25756 KiB

Open AccessEditor’s ChoiceArticle

Analysis of the Control Characteristics of the Electro-Hydraulic Vibration System Based on the Single-Neuron Control Algorithm

by Wenang Jia, Zeji Chen, Tongzhong Chen and Sheng Li

Machines 2024, 12(1), 58; https://doi.org/10.3390/machines12010058 - 12 Jan 2024

Viewed by 1412

Abstract

This paper proposes an electro-hydraulic vibration control system based on the single-neuron PID algorithm, which improves the operating frequency of the electro-hydraulic fatigue testing machine and the control accuracy of the load force. Through mathematical modeling of the electro-hydraulic vibration system (EVS), a [...] Read more.

This paper proposes an electro-hydraulic vibration control system based on the single-neuron PID algorithm, which improves the operating frequency of the electro-hydraulic fatigue testing machine and the control accuracy of the load force. Through mathematical modeling of the electro-hydraulic vibration system (EVS), a MATLAB/Simulink simulation, and experimental testing, this study systematically analyzes the output waveform of the EVS as well as the closed-loop situation of load force amplitude and offset under the action of the single-neuron PID algorithm. The results show that: the EVS with a 2D vibration valve as the core, which can control the movement of the spool in the two-degrees-of-freedom direction, can realize the output of an approximate sinusoidal load force waveform from 0 to 800 Hz. The system controlled by the single-neuron PID algorithm is less complex to operate than the traditional PID algorithm. It also has a short rise time for the output load force amplitude curve and a maximum control error of only 1.2%. Furthermore, it exhibits a rapid closed-loop response to the load force offset. The range variability of the load force is measured to be 1.43%. A new scheme for the design of EVS is provided in this study, which broadens the application range of electro-hydraulic fatigue testing machines. Full article

(This article belongs to the Section Machine Design and Theory)

► Show Figures

Figure 1

29 pages, 24569 KiB

Open AccessEditor’s ChoiceArticle

New Method for Precise Measurement of Clamping Plate Deformations on Forming Presses

by Georg Ivanov, Thomas Burkhardt, Lars Penter and Steffen Ihlenfeldt

Machines 2024, 12(1), 40; https://doi.org/10.3390/machines12010040 - 5 Jan 2024

Viewed by 1458

Abstract

The deformation of press bolster plates under load can significantly impact the quality of manufactured workpieces. Consequently, press manufacturers are usually obliged to provide the metric proof of the permissible deformation values during the press commissioning process. Unfortunately, the existing measurement methods for [...] Read more.

The deformation of press bolster plates under load can significantly impact the quality of manufactured workpieces. Consequently, press manufacturers are usually obliged to provide the metric proof of the permissible deformation values during the press commissioning process. Unfortunately, the existing measurement methods for determining bolster plate deformations present flaws in the measurement accuracy, the application flexibility, the metrological effort, and other aspects. These issues have been addressed through the development of a new measurement method using multiple inclination profiles on the surface of the measured object. Based on the difference in the inclination between the unloaded and loaded states, the method approximates the inclination surface and calculates the deformation of the measured object through integration. The measurement method was first used for commissioning tests of forming presses. A comparison with the results obtained with a measurement frame equipped with high-resolution measurement probes demonstrates an accuracy of the new method of less than 20 µm. Full article

(This article belongs to the Special Issue Design and Experimental Activity of Testing Machines and Mechanical Test Rigs)

► Show Figures

Figure 1

22 pages, 8263 KiB

Open AccessEditor’s ChoiceArticle

Research on the Hobbing Processing Method of Marine Beveloid Gear

by Jianmin Wen, Haoyu Yao, Hui Li and Bindi You

Machines 2024, 12(1), 35; https://doi.org/10.3390/machines12010035 - 4 Jan 2024

Cited by 1 | Viewed by 1976

Abstract

Due to the particular structure of the beveloid gear, it cannot be directly hobbed by an ordinary gear hobbing machine. The existing processing method is complex and has a high cost. Therefore, the mass production and industrialization of beveloid gears are limited. To [...] Read more.

Due to the particular structure of the beveloid gear, it cannot be directly hobbed by an ordinary gear hobbing machine. The existing processing method is complex and has a high cost. Therefore, the mass production and industrialization of beveloid gears are limited. To improve the machining efficiency and accuracy of processing beveloid gears, we proposed a hobbing method via the modification of ordinary hobbing machines. At first, we completed the derivation and calculation of the relevant processing parameters of the beveloid gear based on the study of the structural characteristics of the beveloid gear and the principle of hobbing machining. Then, we proposed and designed a beveloid gear hobbing method, and the modification of the ordinary hobbing machine was completed by using a hanging wheel mechanism in synchronous belt type. Finally, we completed the actual hobbing of the beveloid gear, and the feasibility of the proposed method was verified. After that, we analyzed the machining error of the trial-produced beveloid gear; the results showed that the accuracy of the trial-produced beveloid gear met the 6-level standard, which also verified the accuracy of the proposed method. Full article

(This article belongs to the Special Issue Advancements in Mechanical Power Transmission and Its Elements)

► Show Figures

Figure 1

20 pages, 9439 KiB

Open AccessEditor’s ChoiceArticle

Novel Design of Variable Stiffness Pneumatic Flexible Shaft Coupling: Determining the Mathematical-Physical Model and Potential Benefits

by Peter Kaššay, Robert Grega, Matej Urbanský, Jozef Krajňák, Matúš Kačír and Lucia Žuľová

Machines 2024, 12(1), 28; https://doi.org/10.3390/machines12010028 - 31 Dec 2023

Cited by 2 | Viewed by 1778

Abstract

Presently, mechanical system vibroisolation is becoming increasingly important. One of the new approaches is semi-active vibroisolation using elements capable of changing a selected mechanical property. These include, among others, pneumatic flexible shaft couplings capable of changing torsional stiffness during operation. The main goal [...] Read more.

Presently, mechanical system vibroisolation is becoming increasingly important. One of the new approaches is semi-active vibroisolation using elements capable of changing a selected mechanical property. These include, among others, pneumatic flexible shaft couplings capable of changing torsional stiffness during operation. The main goal of the article is to examine the potential advantages of a newly patented pneumatic coupling over a current type with the same pneumatic element arrangement. For comparison, parameters determinable from static load characteristics were selected. These parameters are maximum twist angle and torque, average torsional stiffness, and the percentage of torque transmitted by the bellows rubber shell. In all cases, the new coupling had better properties. Since the prototype of the new coupling has not yet been produced, its parameters were determined from its mathematical-physical model. The article contains a full procedure to obtain the static load characteristic of a new coupling type, beginning with the determination of air bellows force/height and volume/height characteristics, then optimum sizes of coupling with regards to the operating range of elements, the dependency of element height on the coupling’s twist angle, and finally the computation of the static load characteristic considering isothermal gas compression. The presented procedure can be applied to any pneumatic bellows where the force/height characteristics of different pressures are given. Full article

(This article belongs to the Special Issue Research on Rotor Dynamics and Vibration Control)

► Show Figures

Figure 1

17 pages, 4925 KiB

Open AccessEditor’s ChoiceArticle

Design and Control of Autonomous Flying Excavator

by Arif Zaman and Jaho Seo

Machines 2024, 12(1), 23; https://doi.org/10.3390/machines12010023 - 29 Dec 2023

Cited by 1 | Viewed by 1819

Abstract

This study presents a drone-based excavation platform prototype with the key objectives of balancing stability during excavation, sensing, and digging the soil pile autonomously without human intervention. The whole platform was first designed in CAD software, and then each part of the excavator [...] Read more.

This study presents a drone-based excavation platform prototype with the key objectives of balancing stability during excavation, sensing, and digging the soil pile autonomously without human intervention. The whole platform was first designed in CAD software, and then each part of the excavator assembly was 3D printed by using PLA filament. The physical system was then combined with numerous electronic components and linked to various software applications for a drone to perform autonomous excavations. Pixhawk Orange Cube served as the main controller for the drone, while Nvidia Jetson Nano was used for processing data and controlling the tip of the bucket at a specified location for the autonomous excavator. Two scenarios were considered to validate the functionality of the developed platform. In the first scenario, the drone flies independently to a construction site, lands, senses the soil, excavates it, and then travels to another location specified by the mission to deposit the soil. Full article

(This article belongs to the Special Issue Control and Mechanical System Engineering)

► Show Figures

Figure 1

25 pages, 9757 KiB

Open AccessEditor’s ChoiceArticle

Redesign of a Disc-on-Disc Computer Numerical Control Tribometer for a Wide-Range and Shudder-Resistant Operation

by Matija Hoić, Mario Hrgetić, Nenad Kranjčević, Joško Deur and Andreas Tissot

Machines 2024, 12(1), 14; https://doi.org/10.3390/machines12010014 - 26 Dec 2023

Viewed by 1411

Abstract

The paper presents a redesign of the custom disc-on-disc-type tribometer intended for the experimental characterization of the friction and wear of automotive dry clutch friction lining. The redesign is aimed at expanding the operating range at which the machine is not sensitive to [...] Read more.

The paper presents a redesign of the custom disc-on-disc-type tribometer intended for the experimental characterization of the friction and wear of automotive dry clutch friction lining. The redesign is aimed at expanding the operating range at which the machine is not sensitive to shudder vibrations. This is achieved through a set of hardware and software upgrade measures. First, the natural frequency of the normal load-generation linear axis of the machine is increased by enlarging its bending stiffness and reducing the suspended mass. The former is realized by replacing the single, two-axial force/torque piezoelectric sensor with a set of three three-axial piezoelectric force sensors, adding a set of stiff linear guides, and reducing the lengths of the cantilevers of lateral forces acting on the linear axis guide system. The latter is accomplished by reducing the overall dimensions of the cooling disc and redesigning the thermal insulation components. The shudder sensitivity resistance is further reduced through individual normal force-readings-based adjustment of parallelism between friction contact surfaces and the increase in the stiffness of eccentrically positioned water-cooling pipes. Finally, the stability of the coefficient of friction and, consequently, the wear process are boosted by adjusting the control routines to minimize the circumferential and/or radial temperature gradients. These adjustments include the introduction of a clutch lock-up interval at the end of the clutch closing cycle, a minimum cooling delay inserted between two closing cycles, and maximum normal force demand of the clutch torque controller. The performance gain of the upgraded tribometer is demonstrated through a study of the dry clutch friction plate static wear experimental characterization for a wide range of operating conditions. Full article

(This article belongs to the Special Issue Advances in Vehicle Brake and Clutch Systems)

► Show Figures

Figure 1

21 pages, 11951 KiB

Open AccessEditor’s ChoiceArticle

A Control Architecture for Developing Reactive Hybrid Remotely Operated Underwater Vehicles

by Fernando Gómez-Bravo, Alejandro Garrocho-Cruz, Olga Marín-Cañas, Inmaculada Pulido-Calvo, Juan Carlos Gutierrez-Estrada and Antonio Peregrín-Rubio

Machines 2024, 12(1), 1; https://doi.org/10.3390/machines12010001 - 19 Dec 2023

Cited by 1 | Viewed by 1711

Abstract

This article introduces a control architecture designed for the development of Hybrid Remotely Operated Underwater Vehicles. The term ”Hybrid” characterizes Remotely Operated systems capable of autonomously executing specific operations. The presented architecture maintains teleoperation capabilities while enabling two fully autonomous applications. The approach [...] Read more.

This article introduces a control architecture designed for the development of Hybrid Remotely Operated Underwater Vehicles. The term ”Hybrid” characterizes Remotely Operated systems capable of autonomously executing specific operations. The presented architecture maintains teleoperation capabilities while enabling two fully autonomous applications. The approach emphasizes the implementation of reactive navigation by exclusively utilizing data from a Mechanical Scanned Imaging Sonar for control decisions. This mandates the control system to solely react to data derived from the vehicle’s environment, without considering other positioning information or state estimation. The study involves transforming a small-scale commercial Remotely Operated Underwater Vehicle into a hybrid system without structural modifications, and details the development of an intermediate Operational Control Layer responsible for sensor data processing and task execution control. Two practical applications, inspired by tasks common in natural or open-water aquaculture farms, are explored: one for conducting transects, facilitating monitoring and maintenance operations, and another for navigating toward an object for inspection purposes. Experimental results validate the feasibility and effectiveness of the authors’ hypotheses. This approach expands the potential applications of underwater vehicles and facilitates the development of Hybrid Remotely Operated Underwater Vehicles, enabling the execution of autonomous reactive tasks. Full article

(This article belongs to the Special Issue Mobile Robotics: Mathematics, Models and Methods)

► Show Figures

Figure 1

23 pages, 7443 KiB

Open AccessEditor’s ChoiceArticle

A Technique for Bearing Fault Diagnosis Using Novel Wavelet Packet Transform-Based Signal Representation and Informative Factor LDA

by Andrei S. Maliuk, Zahoor Ahmad and Jong-Myon Kim

Machines 2023, 11(12), 1080; https://doi.org/10.3390/machines11121080 - 11 Dec 2023

Cited by 3 | Viewed by 2136

Abstract

This paper proposes a new method for bearing fault diagnosis using wavelet packet transform (WPT)-based signal representation and informative factor linear discriminant analysis (IF-LDA). Time–frequency domain approaches for analyzing bearing vibration signals have gained wide acceptance due to their effectiveness in extracting information [...] Read more.

This paper proposes a new method for bearing fault diagnosis using wavelet packet transform (WPT)-based signal representation and informative factor linear discriminant analysis (IF-LDA). Time–frequency domain approaches for analyzing bearing vibration signals have gained wide acceptance due to their effectiveness in extracting information related to bearing health. WPT is a prominent method in this category, offering a balanced approach between short-time Fourier transform and empirical mode decomposition. However, the existing methods for bearing fault diagnosis often overlook the limitations of WPT regarding its dependence on the mother wavelet parameters for feature extraction. This work addresses this issue by introducing a novel signal representation method that employs WPT with a new rule for selecting the mother wavelet based on the power spectrum energy-to-entropy ratio of the reconstructed coefficients and a combination of the nodes from different WPT trees. Furthermore, an IF-LDA feature preprocessing technique is proposed, resulting in a highly sensitive set of features for bearing condition assessment. The k-nearest neighbors algorithm is employed as the classifier, and the proposed method is evaluated using datasets from Paderborn and Case Western Reserve universities. The performance of the proposed method demonstrates its effectiveness in bearing fault diagnosis, surpassing existing techniques in terms of fault identification and diagnosis performance. Full article

(This article belongs to the Special Issue New Advances in Rotating Machinery)

► Show Figures

Figure 1

18 pages, 6413 KiB

Open AccessEditor’s ChoiceArticle

Modal Balancing of Warped Rotors without Trial Runs Using the Numerical Assembly Technique

by Georg Quinz, Gregor Überwimmer, Michael Klanner and Katrin Ellermann

Machines 2023, 11(12), 1073; https://doi.org/10.3390/machines11121073 - 7 Dec 2023

Cited by 1 | Viewed by 1284

Abstract

The increasing use of high-speed machinery leads to a growing demand for efficient balancing methods for flexible rotors. Conventional balancing methods are costly and time-consuming since they require multiple trial runs. For this reason, recent research focuses on model-based balancing methods, which substitute [...] Read more.

The increasing use of high-speed machinery leads to a growing demand for efficient balancing methods for flexible rotors. Conventional balancing methods are costly and time-consuming since they require multiple trial runs. For this reason, recent research focuses on model-based balancing methods, which substitute measurements with simulations. This work presents and examines a model-based modal balancing method, which utilizes the Numerical Assembly Technique (NAT) for the in situ balancing of warped rotors with flexible behaviour. NAT is a successive modification of discrete–continuous modelling that leads to analytical harmonic solutions and is very computationally efficient. In this version of NAT, internal damping is also included with a viscoelastic material model using fractional time derivatives. The modal balancing procedure is adapted to handle measurements outside of the critical speeds and the effect of the pre-bend on the rotor. The accuracy of the simulations is shown by comparing measured mode shapes and eigenvalues with values calculated with NAT. Furthermore, the first two modes of a rotor test bed are successfully balanced without trial runs. Full article

(This article belongs to the Special Issue New Advances in Rotating Machinery)

► Show Figures

Figure 1

22 pages, 10747 KiB

Open AccessEditor’s ChoiceArticle

Bioinspired Design for Lightweighting and Vibration Behavior Optimization in Large-Scale Aeronautical Tooling: A Comparative Study

by Ignacio Laraudogoitia Blanc, Christian Hamm, Maider García de Cortázar, Nils Kaiser, Oleksander Savysko and Franck Andrés Girot Mata

Machines 2023, 11(12), 1067; https://doi.org/10.3390/machines11121067 - 4 Dec 2023

Cited by 1 | Viewed by 1943

Abstract

A comparative study is presented, focusing on three different bioinspired design methodologies applied to a large-scale aeronautical tooling use case. The study aims to optimize the structure in terms of the first vibration mode, minimizing mass, and supporting operational loads. The development of [...] Read more.

A comparative study is presented, focusing on three different bioinspired design methodologies applied to a large-scale aeronautical tooling use case. The study aims to optimize the structure in terms of the first vibration mode, minimizing mass, and supporting operational loads. The development of lightweight metallic components is of great importance for industries such as aerospace, automotive, and energy harvesting, where weight reduction can lead to significant improvements in performance, efficiency, and sustainability. Bioinspired design offers a promising approach to achieving these goals. The study begins with an introduction to natural selection and various bioinspired concepts. It proceeds with a thorough review of the selected bioinspired design methodologies and tools, which are then applied to the chosen use case. The outcomes for each methodology were explored with respect to the design requirements. Subsequently, the most suitable design was selected according to the success criteria defined and its validation is explained. The manufacturing of this design was carried out using an advanced and novel approach specifically tailored to accommodate the large dimensions and complexity of the structure. Finally, modal testing was performed to validate the entire process, and the results obtained demonstrate the potential effectiveness of bioinspired design methodologies in achieving lightweighting and optimizing vibration modes for large-scale aeronautical tooling. Full article

(This article belongs to the Section Machine Design and Theory)

► Show Figures

Figure 1

15 pages, 9284 KiB

Open AccessEditor’s ChoiceArticle

An Experimental Investigation into the Performance and Emission Characteristics of a Gasoline Direct Injection Engine Fueled with Isopropanol Gasoline Blends

by Simeon Iliev, Zdravko Ivanov, Radostin Dimitrov, Veselin Mihaylov, Daniel Ivanov, Stoyan Stoyanov and Slavena Atanasova

Machines 2023, 11(12), 1062; https://doi.org/10.3390/machines11121062 - 29 Nov 2023

Cited by 2 | Viewed by 1904

Abstract

Propanol isomers, which are oxygen-rich fuels, possess superior octane ratings and energy density in comparison to methanol and ethanol. Recently, due to advancements in fermentation techniques, these propanol isomers have garnered increased interest as additives for engines. They are being explored to decrease [...] Read more.

Propanol isomers, which are oxygen-rich fuels, possess superior octane ratings and energy density in comparison to methanol and ethanol. Recently, due to advancements in fermentation techniques, these propanol isomers have garnered increased interest as additives for engines. They are being explored to decrease emissions and reduce the usage of conventional fossil fuels. This study delves into this emerging field. One of the alternatives is the use of alcohol fuels in their pure state or as additives to traditional fuels. Alcohols, due to their higher volumetric energy density, are better fuels for spark ignition engines than hydrogen and biogas. Alcohol-blended fuels or alcohol fuels in their pure state may be used in gasoline engines to reduce exhaust emissions. The current research emphasizes the effect of isopropanol gasoline blends on the performance and emissions characteristics of a gasoline direct injection (GDI) engine. This investigation was conducted with different blends of isopropanol and gasoline (by volume: 10% isopropanol [IP10], 20% isopropanol [IP10], 30% isopropanol [IP30], 40% isopropanol [IP40], and 50% isopropanol [IP50]). The reviewed results showed that with increasing isopropanol in the fuel blends, engine brake power increased while BSFC decreased. In terms of emissions, with the increase in isopropanol in the fuel blends, CO and HC emissions decreased while CO₂ and NOx emissions increased. Full article

(This article belongs to the Special Issue Advanced Engine Energy Saving Technology)

► Show Figures

Figure 1

17 pages, 4492 KiB

Open AccessEditor’s ChoiceArticle

Vibration Analysis for Fault Diagnosis in Induction Motors Using One-Dimensional Dilated Convolutional Neural Networks

by Xiaopeng Liu, Jianfeng Hong, Kang Zhao, Bingxiang Sun, Weige Zhang and Jiuchun Jiang

Machines 2023, 11(12), 1061; https://doi.org/10.3390/machines11121061 - 29 Nov 2023

Viewed by 2536

Abstract

Motor faults not only damage the motor body but also affect the entire production system. When the motor runs in a steady state, the characteristic frequency of the fault current is close to the fundamental frequency, so it is difficult to effectively extract [...] Read more.

Motor faults not only damage the motor body but also affect the entire production system. When the motor runs in a steady state, the characteristic frequency of the fault current is close to the fundamental frequency, so it is difficult to effectively extract the fault current components, such as the broken rotor bar. In this paper, according to the characteristics of electromagnetic force and vibration, when the rotor eccentricity and the broken bar occur, the vibration signal is used to analyze and diagnose the fault. Firstly, the frequency, order, and amplitude characteristics of electromagnetic force under rotor eccentricity and broken bar fault are analyzed. Then, the fault vibration acceleration value collected by a one-dimensional dilated convolution pair is extracted, and the SeLU activation function and residual connection are introduced to solve the problem of gradient disappearance and network degradation, and the fault motor model is established by combining average ensemble learning and SoftMax multi-classifier. Finally, experiments of normal rotor eccentricity and broken bar faults are carried out on 4-pole asynchronous motors. The experimental results show that the accuracy of the proposed method for motor fault detection can reach 99%, which meets the requirements of fault motor detection and is helpful for further application. Full article

(This article belongs to the Special Issue Application of Deep Learning in Intelligent Machines)

► Show Figures

Figure 1

20 pages, 17150 KiB

Open AccessEditor’s ChoiceArticle

Microwave Frequency Offset Induced by Subsurface Damage in Abrasive-Machined Semiconductor Ceramic Waveguide

by Haoji Wang, Jinhua Wei, Bin Lin, Xiaoqi Cui, Hetian Hou, Zhiyuan Fu, Jianchun Ding and Tianyi Sui

Machines 2023, 11(12), 1057; https://doi.org/10.3390/machines11121057 - 28 Nov 2023

Viewed by 1302

Abstract

Ceramic waveguide components play a critical role in modern microwave semiconductor systems. For the first time, this work reports experimental results obtained when dielectric ceramics are abrasive-machined into waveguide components. This process will cause subsurface damage (SSD), resulting in a deviation in their [...] Read more.

Ceramic waveguide components play a critical role in modern microwave semiconductor systems. For the first time, this work reports experimental results obtained when dielectric ceramics are abrasive-machined into waveguide components. This process will cause subsurface damage (SSD), resulting in a deviation in their working frequency which can degrade the performance of the system. For a substrate-integrated waveguide (SIW) resonator working at 10.1 GHz, SSD with a depth of 89 um can cause a maximum frequency offset of 20.2%. For a mm wave component working at 70 GHz, the corresponding frequency offset could increase to 169%. Three resonator SIW filters with SSD are studied, and the results demonstrate that the frequency offset induced by SSD can reduce the pass rate of the filters from 95.4% to 0%. A theoretical analysis is performed to reveal the mechanism and to offer a quantitative estimation of the limiting range of the offset caused by SSD. Feasible methods for reducing the offset caused by SSD, such as structure design, processing optimization, and material reinforcement, are discussed. Full article

(This article belongs to the Special Issue Abrasive Machining of Semiconductor Materials: Equipment, Materials, and Processes)

► Show Figures

Figure 1

Journal Menu

Journal Browser

Editor’s Choice Articles

Further Information

Guidelines

MDPI Initiatives

Follow MDPI
