Cricula trifenestrata Helfer was recently documented on cinnamon (Cinnamomum spp.), a novel host plant in Thailand. We compared life history and behavior under natural field, semi-natural caged, and laboratory conditions on cinnamon, plus opportunistic collection from hog plum (Spondias pinnata). Laboratory rearing significantly extended development (62.30 ± 3.68 days) versus field conditions (56.30 ± 1.83 days, p < 0.001) through delayed egg and pupal stages, indicating life history plasticity. We discovered density-dependent oviposition plasticity (linear arrangements in field: 155.6 ± 84.9 eggs/batch; clustered in laboratory) and novel gregarious cocooning behavior, where 85.1% of individuals (n = 47 sites) aggregated to form communal clusters with unique reticulated architecture. Female cocoon shell ratio (CSR) was significantly higher in laboratory (5.02 ± 0.72%) and hog plum cohorts (5.30 ± 0.30%) than field conditions (3.92 ± 0.51%, p = 0.002). Opportunistic rearing yielded >2 kg fresh cocoons, with clusters reaching 0.220 kg. These findings establish biological baselines for C. trifenestrata Helfer on cinnamon, reveal sophisticated social behaviors expanding lepidopteran sociality concepts, and demonstrate commercial potential for sustainable sericulture integrated with pest management. Full article

The free-form single-layer reticulated shell structure has the characteristics of complex shape, a high degree of static indeterminacy, and difficult node positioning in the construction process, and the nodal deviations that may occur in the construction stage have a significant impact on the reliability performance of the structure. In order to evaluate the influence of the nodal deviation on the reliability performance of the structure in the process of shape optimization, this paper takes the free-form surface of the rectangular plane as the initial structure. Shape optimization is carried out with the objective function of minimizing the strain energy under the uniform vertical load, and the influence of the nodal deviation on the reliability performance of the optimized structure is performed by analyzing changes in the structural response’s probability density function (PDF). The elastic modulus, yield strength, and nodal deviation of the material were selected as the basic random variables, and the PDF of the structural response was calculated using the probability density evolution method. In the case of considering and ignoring the nodal deviation, respectively, the PDF of the maximum displacement response of the structure under the same iteration step is calculated and compared. The results indicate that compared with the initial structure, the reliability performance of the optimized structure is significantly less sensitive to node deviations. Full article

Optimization methods tailored for practical engineering applications continue to evolve in order to realize lightweight single-layer reticulated shell structures and maximize node stiffness. This paper takes the minimum amount of steel as the objective function, and divides the rod types into three groups and three corresponding one-to-one optimization schemes. Considering the stress and stiffness of the rod and the displacement and stability constraints of the whole structure, the equal step search method combined with the criterion method is used to optimize the rod size. Then the multi-scale calculation model based on the multi-point constraint method is established. Through calculation and analysis, the boundary load condition of the target node is obtained as the boundary condition of node optimization. Finally, the variable density method is used to optimize the topology of the node domain, and the minimum member size is included in the constraint conditions to obtain the optimized node form that is conducive to additive manufacturing. The research shows that reasonable cross-section value and grouping of members can effectively reduce the steel consumption without compromising the overall stability performance. The amount of steel used in the three optimization plans was reduced by 12%, 23%, and 28%, respectively, compared to before the optimization. The multi-scale model not only takes into account the calculation accuracy, but also can effectively simulate the stress conditions in the node domain. The development of topology optimization and additive manufacturing technology broadens the space for optimization design, and provides new ideas for advanced design to integrate intelligent manufacturing. Full article

This study explores reinforcement learning algorithms combined with graph embedding methods to optimize the assembly sequence of complex single-layer reticulate shells. To minimize the number of temporary support brackets during installation, the structural assembly process is modeled using the inverse dismantling process. The remaining members of the structure at each iteration step are scored, and the one with the highest score for removal is selected. Next, this study trains an effective intelligent agent to assemble the structure. The proposed method can be used to design several types of latticed shells. The trained intelligent model can complete the assembly sequence design of the mesh shell without requiring any other data except for previous structural information. To verify the feasibility of the novel method, it is compared with the empirical approach used in the traditional assembly sequence design process. The feasibility of the new method is demonstrated. It is indicated that the novel method can obtain the optimal solution accurately and efficiently. In addition, it has more innovative choices for installation sequences than the conventional technique. It has enormous potential and application in the civil engineering field. Full article

Single-layer steel reticulated shell structures have a long history and are widely distributed. As their service life increases, corrosion in these structures becomes an increasingly prominent problem. However, currently, there is nearly no research available on the static behavior of corroded steel reticulated shell structures. Therefore, taking the single-layer steel reticulated shell structure as the research object, an accelerated corrosion test was first carried out on Q345, a commonly used steel for this structure, and an equivalent conversion calculation method was proposed. Then, a Python program (version 3.5.0) for single-layer reticulated shells considering component dimensions, joint stiffness, and random corrosion was written, and numerical simulation analysis was carried out on the static behavior of single-layer steel reticulated shell structures after corrosion. Finally, based on parametric analysis, the random corrosion influence coefficient and joint stiffness influence coefficient were derived, and a calculation method for the elastic–plastic ultimate bearing capacity of the structure was established, which could enhance the current design methods for steel reticulated shells by taking corrosion effects into account. The research results will provide specific and programmed references for the damage identification and safety assessment of single-layer steel reticulated shell structures during their service life in strongly corrosive environments along the coast and offshore, holding important engineering significance and scientific value. Full article

This study proposes an improved mixed-variable quantum particle swarm optimization (QPSO) algorithm capable of optimizing both continuous and discrete variables. The algorithm is applied to the wind resistance optimization of a cable-stiffened, single-layer spherical reticulated shell (SLSRS), optimizing discrete variables like member dimensions and cable dimensions alongside continuous variables such as cable prestress. Through a computational case study on an SLSRS, the optimization results of the proposed QPSO method are compared with other optimization techniques, validating its accuracy and reliability. Furthermore, this study establishes a mathematical model for the wind resistance optimization of cable-stiffened SLSRSs and outlines the wind resistance optimization process based on the mixed-variable QPSO algorithm. The optimization of these structures reveals the strong stability and global search capabilities of the proposed algorithm. Additionally, the comparison of section optimization and shape optimization highlights the significant impact of the shell shape on steel usage and costs, underscoring the importance of shape optimization in the design process. Full article

In recent years, there have been more and more engineering examples of installing giant suspended equipment (e.g., central suspended LED display) in large-span space structures; however, there are fewer studies on the seismic response and strong-seismic failure process of large-span space structures after the addition of central suspended equipment. In this paper, changes in the nodal displacements of the reticulated shell structure before and after the addition of the central suspended equipment, the proportion and distribution characteristics of the plastic shell members, and the strong seismic deformation of the reticulated shell structures are taken as indexes under the different ground motions. This paper analyses the influence characteristics of the suspended equipment on the seismic response of Kiewitt K-8 single-layer spherical reticulated shell structures and reveals the influence laws of suspended equipment with different masses on the displacement of mounting nodes and the nodes in other rings in the reticulated shell structure. Based on the plastic degree development analysis of the structures under strong ground motion, the paper analyses the failure mechanism of the reticulated shell structures with central suspended equipment and summarizes two typical failure modes. The paper analyses the influence laws and characteristics of different factors (span, rise-to-span ratio, different seismic loads and the length of suspended cables) on the seismic response of the reticulated shell structures with central suspended equipment. Full article

Aluminum alloy offers the advantages of being lightweight, high in strength, corrosion-resistant, and easy to process. It has a promising application prospect in large-span space structures, with its primary application form being single-layer reticulated shells. In this study, shaking table tests were conducted on a 1/25 scale aluminum alloy single-layer spherical reticulated shell structure. A finite element (FE) model of the reticulated shell structure was established in Ansys. Compared with the experimental results, the deviation in natural frequency, acceleration amplitude, and displacement amplitude was less than 20%, confirming the validity of the model. An extensive analysis of the various rise–span ratios and connection constraints of a single-layer spherical reticulated shell structure was carried out using the proposed FE model. The experimental and simulation results showed that as the rise–span ratio of the aluminum alloy reticulated shell increases, the natural frequency of the reticulated shell structure also increases while the dynamic performance decreases. The connection of the circumferential members changes from a rigid connection to a hinged connection. The natural frequency of the reticulated shell structure is reduced by about 40% while the acceleration and displacement response values are decreased by approximately 15%. Full article

This paper focuses on the response of reticulated shell structures under oblique impact loads, with a departure from the traditional emphasis on vertical impact loads. These structures are typically utilised in large-span spaces such as iconic buildings and large venues. The study begins by establishing a numerical simulation method for reticulated shell structures subjected to oblique impact loads, which is then validated against existing experimental results. Building on this verified method, the research delves into the effects of varying impactor mass, velocity, and initial kinetic energy on the reticulated shell structure under oblique impacts, as well as the influence of different oblique impact angles. The study extensively examines the failure modes of the structure, node displacements in the structure, and variations in member stress under different impactor parameters. It further investigates how these parameters influence the maximum impact bearing capacity, impact duration, energy dissipation capability, and response forms of the structures, analyzing the reasons behind these effects. The findings offer valuable insights for further research and practical engineering design of reticulated shell structures. Full article

Due to the size limitations of shaking tables, dynamic scale models of large-span space structures for engineering have small cross-sections and thin wall thicknesses. It is difficult to use the structural steels commonly used in prototypes to make dynamic scale models. In this paper, 304 stainless steel is proposed for making the scale model, and the similarity relationship between the structural-steel prototype and the 304-stainless-steel dynamic scale model was studied. Firstly, a uniaxial test was conducted to study the elastic modulus similarity and the yielding stress similarity. The test results demonstrated that the elastic modulus similarity ratio was 1:1, and the stress similarity ratios of the 304 stainless steel and the three typical structural steels were 1:1 (Q235 steel), 1:1.5 (Q355 steel) and 1:1.8 (Q420 steel). Then, the similarities of other variables were derived using the dimensional analysis method. In the end, a numerical analysis was conducted to verify the similarity relationship between the structural-steel prototype and the 304-stainless-steel dynamic scale model. In the numerical analysis, a single-layer spherical reticulated shell structure and a dynamic scale model with a length similarity ratio of 1:20 were established by using the ABAQUS 2021 software, and the node displacement, the element internal force and natural vibration characteristics were analyzed. The results show that standard deviations of the displacements, the internal forces and the natural vibration frequencies between the prototype and the scale model were within 5%. It turns out that the proposed similarity between the structural-steel prototype and the 304-stainless-steel dynamic scale model was applicable in the elastic stage. The findings provide a reference for designing a dynamic scale model of large-span space structures for engineering by using 304 stainless steel. Full article

As large-span structures, reticulated shells are widely used in large-scale public building and act as emergency shelters in the event of sudden disasters. However, spatial reticulated shells are dynamic-sensitive structures; the effect of the initial structural damage on dynamic stability should be considered. In this study, a new nonlinear dynamic model of cylindrical reticulated shells with initial damage is proposed to investigate the effect of initial damage accurately. Firstly, the damage constitutive relations of the building steels are built based on the irreversible thermodynamic theory; furthermore, its fundamental equations are obtained using simulated shell methods. Then, the nonlinear vibration differential equations with damage are obtained and studied with support. Meanwhile, the nonlinear natural vibration frequency with initial damage is derivatized. After that, a bifurcation problem with initial damage is studied by using Flouquet Index, and the dynamic stability state at the equilibrium point is analyzed in depth. It is found that the local dynamic stability of the system is determined via its initial condition, geometric parameters, and initial damage. Moreover, the initial damage dominates over other influence factors due to its strong randomness and uncertainty for the same structure. The damage accumulation results in the transition of the equilibrium point. In addition, the nonlinear natural vibration frequency decreases to zero with the accumulation of the damage reaching 0.618; the local stability of cylindrical reticulated shells fails and they even lose whole stability. This study provides a theoretical foundation for the future investigation of whole stability with initial damage. Full article

The application of BIM technology in building construction provides the possibility to realize design accuracy, to visualize the construction details, to optimize construction schemes, and to enhance cooperation among various professionals. The Yancheng Nanyang Airport terminal 2 project, with its large span of steel roof structure, complex installation in mechanical and electrical pipeline (MEP) engineering, and difficulty in construction organization, is taken as the engineering background. The whole process application of BIM technology in the construction process is introduced. In structural engineering construction, the application of BIM technology can provide guidance for plane layout of the construction site, and can also assist in deepening the designs of irregular steel components. In steel construction, the application of BIM technology gives a commendable visual demonstration of the construction process of the metal roof system and the single-layer reticulated shell. In MEP engineering, the application of BIM technology provides a great approach to establish a synthesis of pipeline drawings to further form pipeline section diagrams and operation drawings. By integrating the dimension of time, precision control, and deviation rectification, a recursive construction drawing can be built. With respect to synergistic management, the quality and safety management in the construction site can be implemented on the basis of BIM terminal equipment as well. This paper will give a great reference on the application of BIM technology in the airport terminal construction. Full article

Aluminum alloy gusset (AAG) joints are widely applied in space reticulated shell structures. To investigate the flexural performance of AAG joints under the combined action of shear force and in-plane and out-of-plane bending moments, this analysis was developed by means of finite element (FE) models implemented in the non-linear code ABAQUS, and the accuracy of the FE simulation results based on the existing AAG joint test results was verified. The FE simulation results effectively described the mechanical properties of the AAG joints, including the failure mode, deformation process and bending moment-rotation curves. Furthermore, a parametric study was conducted by varying the height of the member section, the number of bolts, the radius of the joint plate, the thickness of the joint plate, the bolt preload force, and the ratio of in-plane to out-of-plane bending moments. It was found that these parameters had different effects on the bending behavior of the AAG joints. Full article

Steel smelting and production produces a large amount of exhaust gas, which is damaging to the environment. Prestressed spatial arch-supported partial single-layer reticulated shells (PSASPSRSs) are introduced to promote sustainable development in the construction industry. An optimization strategy based on uniform design experiments and iterations is proposed with respect to the design of PSASPSRSs. The optimization aims to reduce steel consumption as much as possible. The optimization constraint takes into account the stability coefficient, frequency, and deflection of the structures. The search space gradually shrinks around the local optimal solution and moves toward the global optimal solution during the optimization process. The optimization procedure stops when the error between local optimal solutions is less than the permitted error of 5%. The tensile force of the prestressed cable, the unified design stress ratio of the members, and the radial grid number of the single-layer reticulated shells act as optimization variables in the finite element model. The parametric analysis revealed that the radial grid number of single-layer reticulated shells significantly affected steel consumption, which was reduced by 13% in the optimized structure. The effectiveness and the practicality of the proposed optimization strategy in the initial design of complicated space grid structures are systematically illustrated. Full article

Spherical reticulated shell structure is an important structural form of large-span space buildings. It is of great significance to monitor three-dimensional (3D) dynamic responses of spherical reticulated shell structure to better understand its seismic performances, which will be helpful in the future to ensure the healthy condition of large-span space buildings during their lifespan. In this study, with the advantages of non-contact and high accuracy, a high-speed videogrammetric measurement method is proposed for monitoring the 3D dynamic responses of the seismically isolated, spherical, reticulated shell structural model. Two issues—the high-speed videogrammetric acquisition system and network configuration, as well as image sequence target tracking and positioning—are emphasized to achieve a cache of high-speed images and to improve the accuracy of tracking and positioning target points. The experimental results on the shaking table from the proposed method have been compared with those from traditional Optotrak Certus and accelerometers. The results prove that the proposed method is capable and useful for analyzing the seismic performance of spherical reticulated shell structures, as the dynamic responses monitoring accuracy of the method can reach the submillimeter level, with root mean square error values of 0.32 mm, 0.7 mm and 0.06 mm in the X, Y and Z directions, respectively. Full article
