Multilayer liquid crystal devices can offer enhanced optical functionalities for augmented reality and photonic applications, but fabrication remains severely limited by solvent incompatibility between photoalignment materials and underlying polymerized layers. Conventional photoalignment agents use aggressive solvents like N,N-dimethylformamide that damage polymerized substrates, necessitating protective interlayers. This study demonstrates a water-soluble photoalignment approach using AbA-2522 that eliminates these fabrication barriers. The water-soluble alignment material enables direct multilayer processing without layer damage while maintaining alignment quality equivalent to conventional materials. We successfully fabricate compact transmissive devices integrating liquid crystal polarization gratings with quarter-wave plates, achieving a first-order diffraction efficiency of 65.4% for 9 μm period gratings for linearly polarized incident light (λ = 457 nm). The multilayer structure exhibits highly selective polarization-dependent diffraction with efficiency ratios exceeding 10:1 between preferred and suppressed orders, eliminating external polarization control elements. Polarized optical microscopy confirms excellent alignment uniformity, while the fabrication process offers environmental benefits and reduced complexity. This approach establishes a practical pathway for advanced multilayer photonic devices critical for next-generation augmented reality systems and photonic integration, addressing fundamental challenges that have limited multilayer liquid crystal device development. Full article

A simple and efficient approach to spatially addressed polychromatic modulation of light polarization using a photopatterned nematic liquid crystal film is proposed and investigated. In particular, we demonstrate linear polarization structuring of the broadband probe beam, including the formation of polarization singularities under the adiabatic propagation of linearly polarized light, which is achieved through in situ, rewritable photoalignment of nematic liquid crystal by a pump beam. This opto-optical control of polarization does not involve dynamic phase modulation and enables spatially resolved polarization patterning of broadband linearly polarized light in real time. Full article

The accurate and controlled alignment of liquid crystals (LCs) in modern optical devices is of great importance. Photoalignment is one of the most appealing approaches for achieving more versatile alignment in designs. One of the most important parameters of these devices is the thickness and the homogeneity in the photoaligned area, especially in devices that introduce retardance. In this work, we propose a novel polarimetric-based method for the measurement of thickness of homogeneous liquid crystal cells that considers diattenuation effects and how they affect the retardance generated by a liquid crystal variable retarder (LCVR). We experimentally demonstrate the production of dye-doped liquid crystal (DDLC) devices, photoaligned in the visible range with a 532 nm laser light, of two different thicknesses with a very high spatial homogeneity. Thinner devices can be used across the whole visible spectrum despite the residual diattenuation at shorter wavelengths, whereas thicker ones achieve the best degree of polarization (DOP) in the transmitted wavefronts, close to 100%, at longer wavelengths. Full article

In this paper, we present a novel approach for advanced, three-dimensional patterned ordering of nematic liquid crystals. Our method allows for simultaneous control of azimuth and tilt of molecules by using a two-step process based on patterned photoalignment (used to define azimuth) followed by selective polymer stabilization of molecules reorientated with an electric field (used to define tilt). We demonstrate that those two subsequent processes, realized with high-resolution patterned illumination with UV light, allow us to obtain multiple microdomains with independently controlled tilt and azimuth. It opens possibilities to create complex three-dimensional distributions of director within a single liquid crystal cell, which is impossible with any other technique so far. Moreover, although the polymer-stabilization process is used, it is still possible to retune the tilt of the molecules; however, the electric field intensity needed for tuning is slightly higher than in the non-polymerized areas of the sample. Full article

Properties of surface anchoring depend on the absorbed exposure energy and various potential interactions associated with liquid crystal and azo dye layers. In this study, we investigate a model of dispersion, steric and photoinduced interactions with the goal of providing a qualitative and quantitative description of orientationally ordered hard uniaxial liquid crystals and azo dye molecules. By using the Onsager theory, we estimated the effect of excluded volume. Typical repulsive potentials between liquid crystal and azo dye molecules are displayed graphically. The presence of statistical dispersion in molecular alignment of liquid crystals leads to potential wells in dipole–dipole interactions. Our mean field theory investigation of dipole–dipole interactions shows that the anchoring free energy is governed by the net interaction energy associated with the averaged dipole moments of liquid crystal and azo dye molecules, photoaligned surface dipole moments, and local charge densities. We also use the Fokker–Planck equation to show that rotational diffusion is described by the effective mean field potential, which includes photoinduced and van der Waals interactions. Our findings underscore the potential of mean field theory for intermolecular couplings in photoaligned surfaces, opening up new pathways of molecular design for a broad range of parameters. Full article

Spatially varying alignment of liquid crystals is essential for research and applications. One widely used method is based on the photopatterning of thin layers of azo-dye molecules, such as Brilliant Yellow (BY), that serve as an aligning substrate for a liquid crystal. In this study, we examine how photopatterning conditions, such as BY layer thickness ($b$), light intensity ($I$), irradiation dose, and age affect the alignment quality and the strength of the azimuthal surface anchoring. The azimuthal surface anchoring coefficient, $W$, is determined by analyzing the splitting of integer disclinations into half-integer disclinations at prepatterned substrates. The strongest anchoring is achieved for $b$ in the range of 5–8 nm. $W$ increases with the dose, and within the same dose, $W$ increases with $I$. Aging of a non-irradiated BY coating above 15 days reduces $W$. Our study also demonstrates that sealed photopatterned cells filled with a conventional nematic preserve their alignment quality for up to four weeks, after which time $W$ decreases. This work suggests the optimization pathways for photoalignment of nematic liquid crystals. Full article

Photoalignment by azo dye nanolayers can provide high alignment quality for large-area liquid crystal devices. Application of this technology to active optical elements for signal processing and communications is a hot topic of photonics research. In this article, we review recent demonstrations and performance of liquid crystal photonic devices, discuss the advantages of the proposed technology, and identify challenges and future prospects in the research field of photoaligned multi-domain liquid crystal structures. We believe that the developments discussed here can provide directions for future research and potential opportunities for applications of liquid crystal devices based on multi-domain photoalignment. Full article

The Pancharatnam–Berry (PB)-phase liquid crystal (LC) planar optical elements, featuring large apertures and a light weight, are emerging as the new generation optics. The primary method for fabricating large-aperture LC planar optical elements is through photo-alignment, utilizing polarization laser direct writing. However, conventional polarization direct writing suffers from an inertia-induced stopping step during splicing, leading to suboptimal optical effects. Here, we propose a novel highly efficient method for arbitrary polarization patterning, significantly reducing interface splicing errors in these optical elements. (We call it dynamic polarization patterning technology). This process involves simultaneous mobile splicing and real-time generation of different polarization patterns for exposure, eliminating the inertia-related splicing interruption. As a demonstration, we fabricated a lens with an aperture of approximately 1 cm within 30 min at 633 nm. Furthermore, we developed a 100% fill-factor lens array (3 × 3) with an element lens diameter of approximately 7 mm within 1.5 h at 532 nm. Their focal lengths were uniformly set at 30 cm, demonstrating superior convergence capabilities within their designated working wavelengths, alongside commendable performance in converging light across various other wavelengths. Our measurements confirmed the good focusing performance of these samples. The convergence spot size of the lens deviated by approximately 40% from the theoretical diffraction limit, whereas the lens array exhibited a deviation of around 30%. The dynamic polarization direct writing during uniform platform movement reduced splicing errors to a mere 100–200 nm. The enhancement in imaging quality can be primarily attributed to the innovative use of mobile polarization splicing exposure technology, coupled with the inherent self-smoothing properties of LC molecules. This synergy significantly mitigates the impact of seam diffraction interference. Full article

Extensive research has been devoted to spiral phase contrast imaging because of its notable capacity to enhance the edges of both phase and amplitude objects. We demonstrate a setup using ferroelectric liquid crystal (FLC) fork grating (FG) to enable switchable spiral phase contrast imaging within sub-milli-second responses. This system enables the electrical toggling between images featuring edge enhancement and those without it. The specially designed FLC FG generates a vortex beam while in a diffractive state and transmits a Gaussian beam when in a transmissive state. Using a two-step photo-alignment method, the produced FLC FG exhibits exceptional efficiency at approximately 35% and impressively rapid switching at around 307 μs. By introducing this method, we expand the potential applications of spiral phase contrast imaging, particularly in fields such as bio-sensing and photonics. Full article

We compare photoaligning properties of polymer layers fabricated from the same constituents: polymethyl-methacrylate (PMMA) and azo-dye Disperse Red 1 (DR1), either chemically attached to the PMMA main-chain, or physically mixed with it. Photoaligning properties depend on the preparation method drastically. Photoalignment was found to be far more efficient when PMMA is functionalized with DR1 compared to the case of physically mixing the constituents. This finding is supported by atomic force microscope (AFM) scans monitoring the light-induced changes at the polymer–air interface, and revealing a photoinduced mass transfer, especially in the case of functionalized PMMA. Full article

In this article, we present the procedure of preparation of flexible electronic paper with a photosensitive azo dye layer as the key element for changing the orientation of the polarization plane. The main steps of the technology for the fabrication of flexible e-paper are reported. The possible production of Digital Mirror Devices and the roll-to-roll process is discussed. Images on flexible e-paper are demonstrated, including bank card options. The advantages of optically rewritable e-paper technology in comparison with the e-ink usually used for this purpose are highlighted. Potential applications of flexible optically rewritable e-paper include price tags for supermarkets, indoor and outdoor advertisements, smart card labels, etc. Full article

We present a theoretical model of a cylindrical tunable liquid crystal lens based on the modulation of anchoring energy. The latter can be easily obtained using photoalignment techniques. The liquid crystal cell we propose exhibits strong anchoring at the top substrate and anchoring energy with a parabolic profile at the bottom substrate. The model describes the dependence of the focal length on the applied voltage and presents a theoretical study of the lens aberrations. The results obtained are of general relevance and can be used to optimize the performances of every type of liquid crystal lens with a parabolic profile. Full article

With the advancement of information display technologies, research on liquid crystals is undergoing a tremendous shift to photonic devices. For example, devices and configurations based on liquid crystal materials are being developed for various applications, such as spectroscopy, imaging, and fiber optics. One of the problems behind the development of photonic devices lies in the preparation of patterned surfaces that can provide high resolution. Among all liquid crystal alignment techniques, photoalignment represents a promising non-contact method for the fabrication of patterned surfaces. In this review, we discuss the original research findings on electro-optic effects, which were mainly achieved at the Department of Electronic and Computer Engineering of the Hong Kong University of Science and Technology and the collaborating research laboratories. Full article

In this paper, we report the first experimental results on capillary shear flows of a nematic liquid crystal 5CB (4-cyano-4′-pentylbiphenyl), arising due to interaction of the anisotropic liquid, correspondent to the continuous rotational symmetry, with photo-profiled polymer surfaces. The regular surface relief was obtained due to opto-mechanical deformation of azobenzene containing potoresponsive polymer film (PAZO) during irradiation with two-beam interference. Such surface treatment makes it possible to obtain a regular submicron profile with well-defined characteristics (direction, period, and height). The polarizing microscopy (PM) and dynamic light scattering (DLS) techniques were used to determine the direction of the surface orientation of LC and anchoring strength, which characterize the interaction of LC with the photo-profiled polymer surface. Two types of shear flows—spreading of LC droplets and capillary flow in a plane capillary, induced by the interaction of LC with one or two photo-profiled surfaces—were investigated for different directions of the flow relative to the direction of the relief. Strong anisotropy in the dynamics of the precursor film and contact line motion, as well as in the dynamical contact angle, was established. The experimental results were analyzed and compared with those previously obtained at the investigation of the spreading of LC droplets over a mechanically stamped submicron profile and capillary flows in plane capillaries with photo-aligned surfaces. Full article

Copolymer films of photoalignable liquid crystalline (LC) copolymethacrylates comprised of a phenyl benzoate mesogen connected with N-benzylideneaniline end moiety (NBA2) and benzoic acid (BA) side groups exhibit a photoinduced reorientation behavior. Significant thermally stimulated molecular reorientation attains a dichroism (D) greater than 0.7 for all copolymer films and a birefringence of 0.113–0.181. In situ thermal hydrolysis of the oriented NBA2 groups decreases the birefringence to 0.111–0.128. However, the oriented structures of the film are maintained, demonstrating a photo-durability, even though the NBA2 side groups photo-react. The hydrolyzed oriented films show higher photo-durability without changing their optical properties. Full article
