Editor’s Choice Articles

Editor’s Choice articles are based on recommendations by the scientific editors of MDPI journals from around the world. Editors select a small number of articles recently published in the journal that they believe will be particularly interesting to readers, or important in the respective research area. The aim is to provide a snapshot of some of the most exciting work published in the various research areas of the journal.

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
17 pages, 19208 KiB
Article
Design, Characterization, and Preliminary Assessment of a Two-Degree-of-Freedom Powered Ankle–Foot Prosthesis
by Tsung-Han Hsieh, Hyungeun Song, Tony Shu, Junqing Qiao, Seong Ho Yeon, Matthew Carney, Luke Mooney, Jean-François Duval and Hugh Herr
Biomimetics 2024, 9(2), 76; https://doi.org/10.3390/biomimetics9020076 - 26 Jan 2024
Cited by 1 | Viewed by 1297
Abstract
Powered ankle prostheses have been proven to improve the walking economy of people with transtibial amputation. All commercial powered ankle prostheses that are currently available can only perform one-degree-of-freedom motion in a limited range. However, studies have shown that the frontal plane motion [...] Read more.
Powered ankle prostheses have been proven to improve the walking economy of people with transtibial amputation. All commercial powered ankle prostheses that are currently available can only perform one-degree-of-freedom motion in a limited range. However, studies have shown that the frontal plane motion during ambulation is associated with balancing. In addition, as more advanced neural interfaces have become available for people with amputation, it is possible to fully recover ankle function by combining neural signals and a robotic ankle. Accordingly, there is a need for a powered ankle prosthesis that can have active control on not only plantarflexion and dorsiflexion but also eversion and inversion. We designed, built, and evaluated a two-degree-of-freedom (2-DoF) powered ankle–foot prosthesis that is untethered and can support level-ground walking. Benchtop tests were conducted to characterize the dynamics of the system. Walking trials were performed with a 77 kg subject that has unilateral transtibial amputation to evaluate system performance under realistic conditions. Benchtop tests demonstrated a step response rise time of less than 50 milliseconds for a torque of 40 N·m on each actuator. The closed-loop torque bandwidth of the actuator is 9.74 Hz. Walking trials demonstrated torque tracking errors (root mean square) of less than 7 N·m. These results suggested that the device can perform adequate torque control and support level-ground walking. This prosthesis can serve as a platform for studying biomechanics related to balance and has the possibility of further recovering the biological function of the ankle–subtalar–foot complex beyond the existing powered ankles. Full article
(This article belongs to the Special Issue Biologically Inspired Assistive and Rehabilitation Robotics)
Show Figures

Graphical abstract

17 pages, 4704 KiB
Article
Numerical Investigation of Odor-Guided Navigation in Flying Insects: Impact of Turbulence, Wingbeat-Induced Flow, and Schmidt Number on Odor Plume Structures
by Menglong Lei, Mark A. Willis, Bryan E. Schmidt and Chengyu Li
Biomimetics 2023, 8(8), 593; https://doi.org/10.3390/biomimetics8080593 - 6 Dec 2023
Cited by 1 | Viewed by 1393
Abstract
Odor-guided navigation is fundamental to the survival and reproductive success of many flying insects. Despite its biological importance, the mechanics of how insects sense and interpret odor plumes in the presence of complex flow fields remain poorly understood. This study employs numerical simulations [...] Read more.
Odor-guided navigation is fundamental to the survival and reproductive success of many flying insects. Despite its biological importance, the mechanics of how insects sense and interpret odor plumes in the presence of complex flow fields remain poorly understood. This study employs numerical simulations to investigate the influence of turbulence, wingbeat-induced flow, and Schmidt number on the structure and perception of odor plumes by flying insects. Using an in-house computational fluid dynamics solver based on the immersed-boundary method, we solve the three-dimensional Navier–Stokes equations to model the flow field. The solver is coupled with the equations of motion for passive flapping wings to emulate wingbeat-induced flow. The odor landscape is then determined by solving the odor advection–diffusion equation. By employing a synthetic isotropic turbulence generator, we introduce turbulence into the flow field to examine its impact on odor plume structures. Our findings reveal that both turbulence and wingbeat-induced flow substantially affect odor plume characteristics. Turbulence introduces fluctuations and perturbations in the plume, while wingbeat-induced flow draws the odorant closer to the insect’s antennae. Moreover, we demonstrate that the Schmidt number, which affects odorant diffusivity, plays a significant role in odor detectability. Specifically, at high Schmidt numbers, larger fluctuations in odor sensitivity are observed, which may be exploited by insects to differentiate between various odorant volatiles emanating from the same source. This study provides new insights into the complex interplay between fluid dynamics and sensory biology and behavior, enhancing our understanding of how flying insects successfully navigate using olfactory cues in turbulent environments. Full article
(This article belongs to the Special Issue Computational Biomechanics and Biomimetics in Flying and Swimming)
Show Figures

Figure 1

20 pages, 7655 KiB
Article
Effect of Hindwings on the Aerodynamics and Passive Dynamic Stability of a Hovering Hawkmoth
by Ryusuke Noda, Toshiyuki Nakata and Hao Liu
Biomimetics 2023, 8(8), 578; https://doi.org/10.3390/biomimetics8080578 - 1 Dec 2023
Cited by 4 | Viewed by 1645
Abstract
Insects are able to fly stably in the complex environment of the various gusts that occur in nature. In addition, many insects suffer wing damage in their lives, but many species of insects are capable of flying without their hindwings. Here, we evaluated [...] Read more.
Insects are able to fly stably in the complex environment of the various gusts that occur in nature. In addition, many insects suffer wing damage in their lives, but many species of insects are capable of flying without their hindwings. Here, we evaluated the effect of hindwings on aerodynamics using a Navier–Stokes-based numerical model, and then the passive dynamic stability was evaluated by coupling the equation of motion in three degrees of freedom with the aerodynamic forces estimated by the CFD solver under large and small perturbation conditions. In terms of aerodynamic effects, the presence of the hindwings slightly reduces the efficiency for lift generation but enhances the partial LEV circulation and increases the downwash around the wing root. In terms of thrust, increasing the wing area around the hindwing region increases the thrust, and the relationship is almost proportional at the cycle-averaged value. The passive dynamic stability was not clearly affected by the presence of the hindwings, but the stability was slightly improved depending on the perturbation direction. These results may be useful for the integrated design of wing geometry and flight control systems in the development of flapping-winged micro air vehicles. Full article
(This article belongs to the Special Issue Computational Biomechanics and Biomimetics in Flying and Swimming)
Show Figures

Graphical abstract

21 pages, 1238 KiB
Article
A Dual-Layer Weight-Leader-Vicsek Model for Multi-AGV Path Planning in Warehouse
by Shiwei Lin, Ang Liu and Jianguo Wang
Biomimetics 2023, 8(7), 549; https://doi.org/10.3390/biomimetics8070549 - 15 Nov 2023
Viewed by 1482
Abstract
Multiple automatic guided vehicles are widely involved in industrial intelligence. Path planning is crucial for their successful application. However, achieving robust and efficient path planning of multiple automatic guided vehicles for real-time implementation is challenging. In this paper, we propose a two-layer strategy [...] Read more.
Multiple automatic guided vehicles are widely involved in industrial intelligence. Path planning is crucial for their successful application. However, achieving robust and efficient path planning of multiple automatic guided vehicles for real-time implementation is challenging. In this paper, we propose a two-layer strategy for multi-vehicle path planning. The approach aims to provide fast computation and operation efficiency for implementation. The start–destination matrix groups all the vehicles, generating a dynamic virtual leader for each group. In the first layer, the hybrid A* algorithm is employed for the path planning of the virtual leaders. The second layer is named leader–follower; the proposed Weight-Leader-Vicsek model is applied to navigate the vehicles following their virtual leaders. The proposed method can reduce computational load and achieve real-time navigation by quickly updating the grouped vehicles’ status. Collision and deadlock avoidance is also conducted in this model. Vehicles in different groups are treated as dynamic obstacles. We validated the method by conducted simulations through MATLAB to verify its path-planning functionality and experimented with a localization sensor. Full article
(This article belongs to the Special Issue Nature-Inspired Metaheuristic Optimization Algorithms)
Show Figures

Graphical abstract

29 pages, 5959 KiB
Article
Development of Self-Assembled Biomimetic Nanoscale Collagen-like Peptide-Based Scaffolds for Tissue Engineering: An In Silico and Laboratory Study
by Beatriz G. Goncalves, Ryan M. Heise and Ipsita A. Banerjee
Biomimetics 2023, 8(7), 548; https://doi.org/10.3390/biomimetics8070548 - 14 Nov 2023
Viewed by 2014
Abstract
Development of biocomposite scaffolds has gained tremendous attention due to their potential for tissue regeneration. However, most scaffolds often contain animal-derived collagen that may elicit an immunological response, necessitating the development of new biomaterials. Herein, we developed a new collagen-like peptide,(Pro-Ala-His)10 (PAH) [...] Read more.
Development of biocomposite scaffolds has gained tremendous attention due to their potential for tissue regeneration. However, most scaffolds often contain animal-derived collagen that may elicit an immunological response, necessitating the development of new biomaterials. Herein, we developed a new collagen-like peptide,(Pro-Ala-His)10 (PAH)10, and explored its ability to be utilized as a functional biomaterial by incorporating it with a newly synthesized peptide-based self-assembled gel. The gel was prepared by conjugating a pectin derivative, galataric acid, with a pro-angiogenic peptide (LHYQDLLQLQY) and further functionalized with a cortistatin-derived peptide, (Phe-Trp-Lys-Thr)4 (FWKT)4, and the bio-ionic liquid choline acetate. The self-assembly of (PAH)10 and its interactions with the galactarate-peptide conjugates were examined using replica exchange molecular dynamics (REMD) simulations. Results revealed the formation of a multi-layered scaffold, with enhanced stability at higher temperatures. We then synthesized the scaffold and examined its physicochemical properties and its ability to integrate with aortic smooth muscle cells. The scaffold was further utilized as a bioink for bioprinting to form three-dimensional cell-scaffold matrices. Furthermore, the formation of actin filaments and elongated cell morphology was observed. These results indicate that the (PAH)10 hybrid scaffold provides a suitable environment for cell adhesion, proliferation and growth, making it a potentially valuable biomaterial for tissue engineering. Full article
(This article belongs to the Special Issue Biomimetic Nanotechnology Vol. 3)
Show Figures

Figure 1

17 pages, 9465 KiB
Article
Complex Evaluation of Nanocomposite-Based Hydroxyapatite for Biomedical Applications
by Daniela Predoi, Simona Liliana Iconaru, Steluta Carmen Ciobanu, Nicolas Buton and Mihai Valentin Predoi
Biomimetics 2023, 8(7), 528; https://doi.org/10.3390/biomimetics8070528 - 6 Nov 2023
Cited by 2 | Viewed by 1496
Abstract
A magnesium-doped hydroxyapatite in chitosan matrix (MgHApC) sample was developed as a potential platform for numerous applications in the pharmaceutical, medical, and food industries. Magnesium-doped hydroxyapatite suspensions in the chitosan matrix were obtained by the coprecipitation technique. The surface shape and morphological features [...] Read more.
A magnesium-doped hydroxyapatite in chitosan matrix (MgHApC) sample was developed as a potential platform for numerous applications in the pharmaceutical, medical, and food industries. Magnesium-doped hydroxyapatite suspensions in the chitosan matrix were obtained by the coprecipitation technique. The surface shape and morphological features were determined by scanning electron microscopy (SEM). The hydrodynamic diameter of the suspended particles was determined by Dynamic light scattering (DLS) measurements. The stability of MgHApC suspensions was evaluated by ultrasonic measurements. The hydrodynamic diameter of the MgHApC particles in suspension was 29.5 nm. The diameter of MgHApC particles calculated from SEM was 12.5 ± 2 nm. Following the SEM observations, it was seen that the MgHApC particles have a spherical shape. The Fourier-transform infrared spectroscopy (FTIR) studies conducted on MgHApC proved the presence of chitosan and hydroxyapatite in the studied specimens. In vitro antimicrobial assays were performed on Escherichia coli ATCC 25922, Staphylococcus aureus ATCC 25923, Pseudomonas aeruginosa ATCC 27853, and Candida albicans ATCC 10231 microbial strains. The antimicrobial experiments showed that MgHApC exhibited very good antimicrobial properties against all the tested microorganisms. More than that, the results of the in vitro studies revealed that the antimicrobial properties of the samples depend on the incubation time. The evaluation of the sample’s cytotoxicity was performed using the human colon cancer (HCT-8) cell line. Our results suggested the great potential of MgHApC to be used in future applications in the field of biomedical applications (e.g., dentistry, orthopedics, etc.). Full article
(This article belongs to the Special Issue Biomimicry and Functional Materials 2.0)
Show Figures

Figure 1

0 pages, 4223 KiB
Article
A Bio-Inspired Arched Foot with Individual Toe Joints and Plantar Fascia
by Stuart Burgess, Alex Beeston, Joshua Carr, Kallia Siempou, Maya Simmonds and Yasmin Zanker
Biomimetics 2023, 8(6), 455; https://doi.org/10.3390/biomimetics8060455 - 26 Sep 2023
Viewed by 1966
Abstract
This paper presents the design and testing of an arched foot with several biomimetic features, including five individual MTP (toe) joints, four individual midfoot joints, and plantar fascia. The creation of a triple-arched foot represents a step further in bio-inspired design compared to [...] Read more.
This paper presents the design and testing of an arched foot with several biomimetic features, including five individual MTP (toe) joints, four individual midfoot joints, and plantar fascia. The creation of a triple-arched foot represents a step further in bio-inspired design compared to other published designs. The arched structure creates flexibility that is similar to human feet with a vertical deflection of up to 12 mm. The individual toe joints enable abduction–adduction in the forefoot and therefore a natural pronation motion. Adult female bone data was obtained and converted into a CAD model to accurately identify the location of bones, joints, and arches. An analytical model is presented that gives the relationship between the vertical stiffness and horizontal stiffness of the longitudinal arches and therefore allows the optimization of stiffness elements. Experimental tests have demonstrated a vertical arch stiffness of 76 N/mm which is similar to adult human feet. The range of movement of the foot is similar to human feet with the following values: dorsi-plantarflexion (28°/37°), inversion-eversion (30°/15°), and abduction–adduction (30°/39°). Tests have also demonstrated a three-point contact with the ground that is similar to human feet. Full article
(This article belongs to the Special Issue Biorobotics: 2nd Edition)
Show Figures

Graphical abstract

15 pages, 1647 KiB
Article
How Free Swimming Fosters the Locomotion of a Purely Oscillating Fish-like Body
by Damiano Paniccia, Luca Padovani, Giorgio Graziani, Claudio Lugni and Renzo Piva
Biomimetics 2023, 8(5), 401; https://doi.org/10.3390/biomimetics8050401 - 1 Sep 2023
Viewed by 1488
Abstract
The recoil motions in free swimming, given by lateral and angular rigid motions due to the interaction with the surrounding water, are of great importance for a correct evaluation of both the forward locomotion speed and efficiency of a fish-like body. Their contribution [...] Read more.
The recoil motions in free swimming, given by lateral and angular rigid motions due to the interaction with the surrounding water, are of great importance for a correct evaluation of both the forward locomotion speed and efficiency of a fish-like body. Their contribution is essential for calculating the actual movements of the body rear end whose prominent influence on the generation of the proper body deformation was established a long time ago. In particular, the recoil motions are found here to promote a dramatic improvement of the performance when damaged fishes, namely for a partial functionality of the tail or even for its complete loss, are considered. In fact, the body deformation, which turns out to become oscillating and symmetric in the extreme case, is shown to recover in the water frame a kind of undulation leading to a certain locomotion speed though at the expense of a large energy consumption. There has been a deep interest in the subject since the infancy of swimming studies, and a revival has recently arisen for biomimetic applications to robotic fish-like bodies. We intend here to apply a theoretical impulse model to the oscillating fish in free swimming as a suitable test case to strengthen our belief in the beneficial effects of the recoil motions. At the same time, we intend to exploit the linearity of the model to detect from the numerical simulations the intrinsic physical reasons related to added mass and vorticity release behind the experimental observations. Full article
(This article belongs to the Special Issue New Insights into Biological and Bioinspired Fluid Dynamics)
Show Figures

Figure 1

24 pages, 46546 KiB
Article
Biomimetics in Botanical Gardens—Educational Trails and Guided Tours
by Olga Speck and Thomas Speck
Biomimetics 2023, 8(3), 303; https://doi.org/10.3390/biomimetics8030303 - 11 Jul 2023
Cited by 1 | Viewed by 2218
Abstract
The first botanical gardens in Europe were established for the study of medicinal, poisonous, and herbal plants by students of medicine or pharmacy at universities. As the natural sciences became increasingly important in the 19th Century, botanical gardens additionally took on the role [...] Read more.
The first botanical gardens in Europe were established for the study of medicinal, poisonous, and herbal plants by students of medicine or pharmacy at universities. As the natural sciences became increasingly important in the 19th Century, botanical gardens additionally took on the role of public educational institutions. Since then, learning from living nature with the aim of developing technical applications, namely biomimetics, has played a special role in botanical gardens. Sir Joseph Paxton designed rainwater drainage channels in the roof of the Crystal Palace for the London World’s Fair in 1881, having been inspired by the South American giant water lily (Victoria amazonica). The development of the Lotus-Effect® at the Botanical Garden Bonn was inspired by the self-cleaning leaf surfaces of the sacred lotus (Nelumbo nucifera). At the Botanic Garden Freiburg, a self-sealing foam coating for pneumatic systems was developed based on the self-sealing of the liana stems of the genus Aristolochia. Currently, botanical gardens are both research institutions and places of lifelong learning. Numerous botanical gardens provide biomimetics trails with information panels at each station for self-study and guided biomimetics tours with simple experiments to demonstrate the functional principles transferred from the biological model to the technical application. We present eight information panels suitable for setting up education about biomimetics and simple experiments to support guided garden tours about biomimetics. Full article
Show Figures

Graphical abstract

20 pages, 28811 KiB
Article
Deep Learning Vision System for Quadruped Robot Gait Pattern Regulation
by Christyan Cruz Ulloa, Lourdes Sánchez, Jaime Del Cerro and Antonio Barrientos
Biomimetics 2023, 8(3), 289; https://doi.org/10.3390/biomimetics8030289 - 3 Jul 2023
Viewed by 3184
Abstract
Robots with bio-inspired locomotion systems, such as quadruped robots, have recently attracted significant scientific interest, especially those designed to tackle missions in unstructured terrains, such as search-and-rescue robotics. On the other hand, artificial intelligence systems have allowed for the improvement and adaptation of [...] Read more.
Robots with bio-inspired locomotion systems, such as quadruped robots, have recently attracted significant scientific interest, especially those designed to tackle missions in unstructured terrains, such as search-and-rescue robotics. On the other hand, artificial intelligence systems have allowed for the improvement and adaptation of the locomotion capabilities of these robots based on specific terrains, imitating the natural behavior of quadruped animals. The main contribution of this work is a method to adjust adaptive gait patterns to overcome unstructured terrains using the ARTU-R (A1 Rescue Task UPM Robot) quadruped robot based on a central pattern generator (CPG), and the automatic identification of terrain and characterization of its obstacles (number, size, position and superability analysis) through convolutional neural networks for pattern regulation. To develop this method, a study of dog gait patterns was carried out, with validation and adjustment through simulation on the robot model in ROS-Gazebo and subsequent transfer to the real robot. Outdoor tests were carried out to evaluate and validate the efficiency of the proposed method in terms of its percentage of success in overcoming stretches of unstructured terrains, as well as the kinematic and dynamic variables of the robot. The main results show that the proposed method has an efficiency of over 93% for terrain characterization (identification of terrain, segmentation and obstacle characterization) and over 91% success in overcoming unstructured terrains. This work was also compared against main developments in state-of-the-art and benchmark models. Full article
(This article belongs to the Special Issue Bio-Inspired Computing: Theories and Applications)
Show Figures

Figure 1

18 pages, 130916 KiB
Article
The Lift Effects of Chordwise Wing Deformation and Body Angle on Low-Speed Flying Butterflies
by Yan-Hung Fang, Chia-Hung Tang, You-Jun Lin, Szu-I Yeh and Jing-Tang Yang
Biomimetics 2023, 8(3), 287; https://doi.org/10.3390/biomimetics8030287 - 3 Jul 2023
Cited by 4 | Viewed by 2094
Abstract
This work investigates the effects of body angle and wing deformation on the lift of free-flying butterflies. The flight kinematics were recorded using three high-speed cameras, and particle-image velocimetry (PIV) was used to analyze the transient flow field around the butterfly. Parametric studies [...] Read more.
This work investigates the effects of body angle and wing deformation on the lift of free-flying butterflies. The flight kinematics were recorded using three high-speed cameras, and particle-image velocimetry (PIV) was used to analyze the transient flow field around the butterfly. Parametric studies via numerical simulations were also conducted to examine the force generation of the wing by fixing different body angles and amplifying the chordwise deformation. The results show that appropriately amplifying chordwise deformation enhances wing performance due to an increase in the strength of the vortex and a more stabilized attached vortex. The wing undergoes a significant chordwise deformation, which can generate a larger lift coefficient than that with a higher body angle, resulting in a 14% increase compared to a lower chordwise deformation and body angle. This effect is due to the leading-edge vortex attached to the curved wing, which alters the force from horizontal to vertical. It, therefore, produces more efficient lift during flight. These findings reveal that the chordwise deformation of the wing and the body angle could increase the lift of the butterfly. This work was inspired by real butterfly flight, and the results could provide valuable knowledge about lift generation for designing microaerial vehicles. Full article
(This article belongs to the Special Issue Computational Biomechanics and Biomimetics in Flying and Swimming)
Show Figures

Graphical abstract

17 pages, 4121 KiB
Article
LQR Control and Optimization for Trajectory Tracking of Biomimetic Robotic Fish Based on Unreal Engine
by Ming Wang, Kunlun Wang, Qianchuan Zhao, Xuehan Zheng, He Gao and Junzhi Yu
Biomimetics 2023, 8(2), 236; https://doi.org/10.3390/biomimetics8020236 - 4 Jun 2023
Cited by 5 | Viewed by 2494
Abstract
A realistic and visible dynamic simulation platform can significantly facilitate research on underwater robots. This paper uses the Unreal Engine to generate a scene that resembles real ocean environments, before building a visual dynamic simulation platform in conjunction with the Air-Sim system. On [...] Read more.
A realistic and visible dynamic simulation platform can significantly facilitate research on underwater robots. This paper uses the Unreal Engine to generate a scene that resembles real ocean environments, before building a visual dynamic simulation platform in conjunction with the Air-Sim system. On this basis, the trajectory tracking of a biomimetic robotic fish is simulated and assessed. More specifically, we propose a particle swarm optimization algorithm-based control strategy to optimize the discrete linear quadratic regulator controller for the trajectory tracking problem, as well as tracking and controlling discrete trajectories with misaligned time series through introducing a dynamic time warping algorithm. Simulation analyses of the biomimetic robotic fish following a straight line, a circular curve without mutation, and a four-leaf clover curve with mutation are carried out. The obtained results verify the feasibility and effectiveness of the proposed control strategy. Full article
(This article belongs to the Special Issue Artificial Intelligence (AI) 2.0)
Show Figures

Graphical abstract

12 pages, 3212 KiB
Article
Investigation of Fluidic Universal Gripper for Delicate Object Manipulation
by Changchun Wu, Hao Liu, Senyuan Lin, Yunquan Li and Yonghua Chen
Biomimetics 2023, 8(2), 209; https://doi.org/10.3390/biomimetics8020209 - 18 May 2023
Cited by 2 | Viewed by 1580
Abstract
The compliance of conventional granular jamming universal grippers is limited due to the increasing friction among particles when enveloping an object. This property limits the applications of such grippers. In this paper, we propose a fluidic-based approach for universal gripper which has a [...] Read more.
The compliance of conventional granular jamming universal grippers is limited due to the increasing friction among particles when enveloping an object. This property limits the applications of such grippers. In this paper, we propose a fluidic-based approach for universal gripper which has a much higher compliance compared to conventional granular jamming universal grippers. The fluid is made of micro-particles suspended in liquid. Jamming transition of the dense granular suspension fluid from a fluid (hydrodynamic interactions) to solid-like state (frictional contacts) in the gripper is achieved by external pressure from the inflation of an airbag. The basic jamming mechanism and theoretical analysis of the proposed fluid is investigated, and a prototype universal gripper based on the fluid is developed. The proposed universal gripper exhibits advantageous compliance and grasping robustness in sample grasping of delicate objects, such as plants and sponge objects, where the traditional granular jamming universal gripper fails. Full article
Show Figures

Figure 1

18 pages, 9791 KiB
Article
A Numerical Modelling Framework for Investigating the Ballistic Performance of Bio-Inspired Body Armours
by Abdallah Ghazlan, Tuan Ngo, Ping Tan, Phuong Tran and Yi Min Xie
Biomimetics 2023, 8(2), 195; https://doi.org/10.3390/biomimetics8020195 - 8 May 2023
Cited by 3 | Viewed by 2155
Abstract
Biological structures possess excellent damage tolerance, which makes them attractive for ballistic protection applications. This paper develops a finite element modelling framework to investigate the performance of several biological structures that are most relevant for ballistic protection, including nacre, conch, fish scales, and [...] Read more.
Biological structures possess excellent damage tolerance, which makes them attractive for ballistic protection applications. This paper develops a finite element modelling framework to investigate the performance of several biological structures that are most relevant for ballistic protection, including nacre, conch, fish scales, and crustacean exoskeleton. Finite element simulations were conducted to determine the geometric parameters of the bio-inspired structures that can survive projectile impact. The performances of the bio-inspired panels were benchmarked against a monolithic panel with the same 4.5 mm overall thickness and projectile impact condition. It was found that the biomimetic panels that were considered possessed better multi-hit resistant capabilities compared to the selected monolithic panel. Certain configurations arrested a fragment simulating projectile with an initial impact velocity of 500 m/s, which was similar to the performance of the monolithic panel. Full article
Show Figures

Graphical abstract

13 pages, 3568 KiB
Article
The Influence of Temperature on Anisotropic Wettability Revealed by Friction Force Measurement
by Zhen Lin, Kangjian Xiao, Lijun Li, Yurong Zhang, Xiaolong Zhang, Daobing Chen and Longjian Xue
Biomimetics 2023, 8(2), 180; https://doi.org/10.3390/biomimetics8020180 - 25 Apr 2023
Cited by 1 | Viewed by 1947
Abstract
Anisotropic surfaces with special wettability under various temperatures are of both fundamental interest and practical importance in many fields. However, little attention has been paid to the surfaces at temperatures between room temperature and the boiling point of water, which is partially due [...] Read more.
Anisotropic surfaces with special wettability under various temperatures are of both fundamental interest and practical importance in many fields. However, little attention has been paid to the surfaces at temperatures between room temperature and the boiling point of water, which is partially due to the lack of a suitable characterization technique. Here, using the MPCP (monitoring of the position of the capillary’s projection) technique, the influence of the temperature on the friction of a water droplet on the graphene-PDMS (GP) micropillar array (GP-MA) is investigated. The friction forces in the orthogonal directions and the anisotropy in the friction decrease when the GP-MA surface is heated up, based on the photothermal effect of graphene. The friction forces also decrease along the pre-stretching direction but increase in the orthogonal direction when the stretching is increased. The change in the contact area, the Marangoni flow inside a droplet, and the mass reduction are responsible for the temperature dependence. The findings strengthen our fundamental understanding of the dynamics of drop friction at high temperatures and could pave the way for the design of new functional surfaces with special wettabilities. Full article
(This article belongs to the Special Issue Biological Attachment Systems and Biomimetics)
Show Figures

Graphical abstract

16 pages, 3349 KiB
Article
Biomimetic Design and Topology Optimization of Discontinuous Carbon Fiber-Reinforced Composite Lattice Structures
by Zhong Hu
Biomimetics 2023, 8(2), 148; https://doi.org/10.3390/biomimetics8020148 - 6 Apr 2023
Cited by 2 | Viewed by 2313
Abstract
The ever-increasing requirements for structural performance drive the research and development of lighter, stronger, tougher, and multifunctional composite materials, especially, the lattice structures, heterogeneities, or hybrid compositions have attracted great interest from the materials research community. If it is pushed to the extreme, [...] Read more.
The ever-increasing requirements for structural performance drive the research and development of lighter, stronger, tougher, and multifunctional composite materials, especially, the lattice structures, heterogeneities, or hybrid compositions have attracted great interest from the materials research community. If it is pushed to the extreme, these concepts can consist of highly controlled lattice structures subject to biomimetic material design and topology optimization (TO). However, the strong coupling among the composition and the topology of the porous microstructure hinders the conventional trial-and-error approaches. In this work, discontinuous carbon fiber-reinforced polymer matrix composite materials were adopted for structural design. A three-dimensional (3D) periodic lattice block inspired by cuttlefish bone combined with computer modeling-based topology optimization was proposed. Through computer modeling, complex 3D periodic lattice blocks with various porosities were topologically optimized and realized, and the mechanical properties of the topology-optimized lattice structures were characterized by computer modeling. The results of this work were compared with other similar designs and experiments to validate the effectiveness of the proposed method. The proposed approach provides a design tool for more affordable and higher-performance structural materials. Full article
(This article belongs to the Special Issue Bionic Engineering for Boosting Multidisciplinary Integration)
Show Figures

Graphical abstract

31 pages, 7088 KiB
Article
Design of a Flapping Fins Mechanism for Roll Damping of Yachts at Anchor: Kinematic, Hydrodynamic and Structural Study
by Joel Guerrero, Paolo Silvestri and Andrea Canepa
Biomimetics 2023, 8(2), 144; https://doi.org/10.3390/biomimetics8020144 - 3 Apr 2023
Cited by 2 | Viewed by 1616
Abstract
The design of a flapping fins stabilization system for yachts at anchor (zero speed conditions) is presented in this study. The solution presented in this manuscript took inspiration from a solution proposed for the design of a biologically inspired flapping UAV. Although the [...] Read more.
The design of a flapping fins stabilization system for yachts at anchor (zero speed conditions) is presented in this study. The solution presented in this manuscript took inspiration from a solution proposed for the design of a biologically inspired flapping UAV. Although the application was different, we used the same principles and methodology to design and study the stabilization mechanism discussed hereafter. The proposed system uses flapping fins to damp the roll oscillations of the vessel, and when the stabilization system is retracted, the surface of each of the fins is flush with the hull, thus offering minimum resistance when the ship is in cruise conditions. The unsteady forces of the flapping fins were computed using computational fluid dynamics, and they were used as input to conduct the structural and durability study of the proposed mechanism. The vessel’s response to roll perturbations was also studied, using a multi-body dynamics approach. From the results obtained, and the design specifications defined, it was found that the response of the stabilization system was acceptable, and that the mechanism could withstand the inertial and hydrodynamic loads. Full article
(This article belongs to the Special Issue Biological and Bio-Inspired Fluid Dynamics)
Show Figures

Figure 1

21 pages, 1218 KiB
Article
Biomimetic Soft Underwater Robot Inspired by the Red Muscle and Tendon Structure of Fish
by Daisuke Aragaki, Toi Nishimura, Ryuki Sato and Aiguo Ming
Biomimetics 2023, 8(2), 133; https://doi.org/10.3390/biomimetics8020133 - 24 Mar 2023
Cited by 3 | Viewed by 2419
Abstract
Underwater robots are becoming increasingly important in various fields. Fish robots are attracting attention as an alternative to the screw-type robots currently in use. We developed a compact robot with a high swimming performance by mimicking the anatomical structure of fish. In this [...] Read more.
Underwater robots are becoming increasingly important in various fields. Fish robots are attracting attention as an alternative to the screw-type robots currently in use. We developed a compact robot with a high swimming performance by mimicking the anatomical structure of fish. In this paper, we focus on the red muscles, tendons, and vertebrae used for steady swimming of fish. A robot was fabricated by replacing the red muscle structure with shape memory alloy wires and rigid body links. In our previous work, undulation motions with various phase differences and backward quadratically increasing inter-vertebral bending angles were confirmed in the air, while the swimming performance in insulating fluid was poor. To improve the swimming performance, an improved robot was designed that mimics the muscle contractions of mackerel using a pulley mechanism, with the robot named UEC Mackerel. In swimming experiments using the improved robot, a maximum swimming speed of 25.8 mm/s (0.11 BL/s) was recorded, which is comparable to that of other soft-swimming robots. In addition, the cost of transport (COT), representing the energy consumption required for robot movement, was calculated, and a minimum COT of 0.08 was recorded, which is comparable to that of an actual fish. Full article
(This article belongs to the Special Issue Latest Trends in Bio-Inspired Underwater Robotics)
Show Figures

Figure 1

19 pages, 13055 KiB
Article
Owl-Neck-Spine-Inspired, Additively Manufactured, Joint Assemblies with Shape Memory Alloy Wire Actuators
by Robin Löffler, Stephan Tremmel and Rüdiger Hornfeck
Biomimetics 2023, 8(1), 117; https://doi.org/10.3390/biomimetics8010117 - 11 Mar 2023
Cited by 5 | Viewed by 2767
Abstract
Nature provides a considerable number of good examples for simple and very efficient joint assemblies. One example is the enormously flexible cervical spine of American barn owls, which consists of 14 cervical vertebrae. Each pair of vertebrae produces a comparatively small individual movement [...] Read more.
Nature provides a considerable number of good examples for simple and very efficient joint assemblies. One example is the enormously flexible cervical spine of American barn owls, which consists of 14 cervical vertebrae. Each pair of vertebrae produces a comparatively small individual movement in order to provide a large overall movement of the entire cervical spine. The biomimetic replication of such joints is difficult due to the delicate and geometric unrestricted joint shapes as well as the muscles that have to be mimicked. Using X-ray as well as micro-computed tomography images and with the utilisation of additive manufacturing, it was possible to produce the owl neck vertebrae in scaled-up form, to analyse them and then to transfer them into technically usable joint assemblies. The muscle substitution of these joints was realised by smart materials actuators in the form of shape memory alloy wire actuators. This actuator technology is outstanding for its muscle-like movement and for its high-energy density. The disadvantage of this wire actuator technology is the low rate of contraction, which means that a large length of wire has to be installed to generate adequate movement. For this reason, the actuator wires were integrated into additively manufactured carrier components to mimic biological joints. This resulted in joint designs that compensate for the disadvantages of the small contraction of the actuators by intelligently installing large wire lengths on comparatively small installation spaces, while also providing a sufficient force output. With the help of a test rig, the developed technical joint variants are examined and evaluated. This demonstrated the technical applicability of this biomimetic joints. Full article
(This article belongs to the Special Issue Biomimetic Design Method for Innovation and Sustainability)
Show Figures

Graphical abstract

27 pages, 18976 KiB
Article
Flow Control around the UAS-S45 Pitching Airfoil Using a Dynamically Morphing Leading Edge (DMLE): A Numerical Study
by Musavir Bashir, Nicola Zonzini, Ruxandra Mihaela Botez, Alessandro Ceruti and Tony Wong
Biomimetics 2023, 8(1), 51; https://doi.org/10.3390/biomimetics8010051 - 26 Jan 2023
Cited by 2 | Viewed by 1900
Abstract
This paper investigates the effect of the Dynamically Morphing Leading Edge (DMLE) on the flow structure and the behavior of dynamic stall vortices around a pitching UAS-S45 airfoil with the objective of controlling the dynamic stall. An unsteady parametrization framework was developed to [...] Read more.
This paper investigates the effect of the Dynamically Morphing Leading Edge (DMLE) on the flow structure and the behavior of dynamic stall vortices around a pitching UAS-S45 airfoil with the objective of controlling the dynamic stall. An unsteady parametrization framework was developed to model the time-varying motion of the leading edge. This scheme was then integrated within the Ansys-Fluent numerical solver by developing a User-Defined-Function (UDF), with the aim to dynamically deflect the airfoil boundaries, and to control the dynamic mesh used to morph and to further adapt it. The dynamic and sliding mesh techniques were used to simulate the unsteady flow around the sinusoidally pitching UAS-S45 airfoil. While the γReθ  turbulence model adequately captured the flow structures of dynamic airfoils associated with leading-edge vortex formations for a wide range of Reynolds numbers, two broader studies are here considered. Firstly, (i) an oscillating airfoil with the DMLE is investigated; the pitching-oscillation motion of an airfoil and its parameters are defined, such as the droop nose amplitude (AD) and the pitch angle at which the leading-edge morphing starts (MST). The effects of the AD and the MST on the aerodynamic performance was studied, and three different amplitude cases are considered. Secondly, (ii) the DMLE of an airfoil motion at stall angles of attack was investigated. In this case, the airfoil was set at stall angles of attack rather than oscillating it. This study will provide the transient lift and drag at different deflection frequencies of 0.5 Hz, 1 Hz, 2 Hz, 5 Hz, and 10 Hz. The results showed that the lift coefficient for the airfoil increased by 20.15%, while a 16.58% delay in the dynamic stall angle was obtained for an oscillating airfoil with DMLE with AD = 0.01 and MST = 14.75°, as compared to the reference airfoil. Similarly, the lift coefficients for two other cases, where AD = 0.05 and AD = 0.0075, increased by 10.67% and 11.46%, respectively, compared to the reference airfoil. Furthermore, it was shown that the downward deflection of the leading edge increased the stall angle of attack and the nose-down pitching moment. Finally, it was concluded that the new radius of curvature of the DMLE airfoil minimized the streamwise adverse pressure gradient and prevented significant flow separation by delaying the Dynamic Stall Vortex (DSV) occurrence. Full article
(This article belongs to the Special Issue Aircraft Morphing Systems 2.0)
Show Figures

Graphical abstract

18 pages, 2503 KiB
Article
Broadening the Taxonomic Breadth of Organisms in the Bio-Inspired Design Process
by Amanda K. Hund, Elizabeth Stretch, Dimitri Smirnoff, Gillian H. Roehrig and Emilie C. Snell-Rood
Biomimetics 2023, 8(1), 48; https://doi.org/10.3390/biomimetics8010048 - 23 Jan 2023
Cited by 3 | Viewed by 2133
Abstract
(1) Generating a range of biological analogies is a key part of the bio-inspired design process. In this research, we drew on the creativity literature to test methods for increasing the diversity of these ideas. We considered the role of the problem type, [...] Read more.
(1) Generating a range of biological analogies is a key part of the bio-inspired design process. In this research, we drew on the creativity literature to test methods for increasing the diversity of these ideas. We considered the role of the problem type, the role of individual expertise (versus learning from others), and the effect of two interventions designed to increase creativity—going outside and exploring different evolutionary and ecological “idea spaces” using online tools. (2) We tested these ideas with problem-based brainstorming assignments from a 180-person online course in animal behavior. (3) Student brainstorming was generally drawn to mammals, and the breadth of ideas was affected more by the assigned problem than by practice over time. Individual biological expertise had a small but significant effect on the taxonomic breadth of ideas, but interactions with team members did not. When students were directed to consider other ecosystems and branches of the tree of life, they increased the taxonomic diversity of biological models. In contrast, going outside resulted in a significant decrease in the diversity of ideas. (4) We offer a range of recommendations to increase the breadth of biological models generated in the bio-inspired design process. Full article
(This article belongs to the Special Issue Biomimetic Design Method for Innovation and Sustainability)
Show Figures

Figure 1

14 pages, 4700 KiB
Article
An Underactuated Adaptive Microspines Gripper for Rough Wall
by Xinxin Li, Wenqing Chen, Xiaosong Li, Xin Hou, Qian Zhao, Yonggang Meng and Yu Tian
Biomimetics 2023, 8(1), 39; https://doi.org/10.3390/biomimetics8010039 - 16 Jan 2023
Cited by 2 | Viewed by 2104
Abstract
Wall attachment has great potential in a broad range of applications such as robotic grasping, transfer printing, and asteroid sampling. Herein, a new type of underactuated bionic microspines gripper is proposed to attach to an irregular, rough wall. Experimental results revealed that the [...] Read more.
Wall attachment has great potential in a broad range of applications such as robotic grasping, transfer printing, and asteroid sampling. Herein, a new type of underactuated bionic microspines gripper is proposed to attach to an irregular, rough wall. Experimental results revealed that the gripper, profiting from its flexible structure and underactuated linkage mechanism, is capable of adapting submillimeter scale roughness to centimeter scale geometry irregularity in both normal and tangential attachment. The rigid-flexible coupling simulation analysis validated that the rough adaptation was achieved by the passive deformation of the zigzag flexible structure, while the centimeter-scale irregularity adaptation come from the underactuated design. The attachment test of a spine confirmed that a 5 mm sliding distance of the spine tip on the fine brick wall promises a saturated tangential attachment force, which can guide the stiffness design of flexible structure and parameter selection of underactuated linkage. Furthermore, the developed microspines gripper was successfully demonstrated to grasp irregular rocks, tree trunks, and granite plates. This work presents a generally applicable and dexterous passive adaption design to achieve rough wall attachment for flat and curved objects, which promotes the understanding and application of wall attachment. Full article
Show Figures

Figure 1

12 pages, 3411 KiB
Article
Long-Term Changes in Adipose Tissue in the Newly Formed Bone Induced by Recombinant Human BMP-2 In Vivo
by Hyouk-Keun Jee, Woo-Young Jeon, Han-Wool Kwak and Hyun Seok
Biomimetics 2023, 8(1), 33; https://doi.org/10.3390/biomimetics8010033 - 13 Jan 2023
Cited by 2 | Viewed by 1587
Abstract
Recombinant human bone morphogenetic protein-2 (rhBMP-2) induces osteogenesis and adipogenesis in bone scaffolds. We evaluated rhBMP-2-induced long-term changes in adipose tissue in the newly formed bone in different scaffolds forms. Bovine bone particles and blocks were grafted along with rhBMP-2 in the subperiosteal [...] Read more.
Recombinant human bone morphogenetic protein-2 (rhBMP-2) induces osteogenesis and adipogenesis in bone scaffolds. We evaluated rhBMP-2-induced long-term changes in adipose tissue in the newly formed bone in different scaffolds forms. Bovine bone particles and blocks were grafted along with rhBMP-2 in the subperiosteal space of a rat calvarial bone, and the formation of new bone and adipose tissue were evaluated at 6 and 16 weeks after the surgery. The bone mineral density (BMD) and trabecular thickness (TbTh) of the 16w particle group were significantly higher than those of the 6w particle group (p = 0.018 and 0.012, respectively). The BMD and TbTh gradually increased in the particle group from weeks 6 to 16. The average adipose tissue volume (ATV) of the 6w particle group was higher than that of the 16w particle group, although the difference was not significant (p > 0.05), and it decreased gradually. There were no significant changes in the bone volume (BV) and BMD between the 6w and 16w block groups. Histological analysis revealed favorable new bone regeneration in all groups. Adipose tissue was formed between the bone particles and at the center in the particle and block groups, respectively. The adipose tissue space decreased, and the proportion of new bone increased in the 16w particle group compared to that in the 6w group. To summarize, in the particle group, the adipose tissue decreased in a time-dependent manner, BMD and TbTh increased, and new bone formation increased from 6 to 16 weeks. These results suggest that rhBMP-2 effectively induces new bone formation in the long term in particle bone scaffolds. Full article
Show Figures

Graphical abstract

16 pages, 1545 KiB
Article
Quantifying the Leaping Motion Using a Self-Propelled Bionic Robotic Dolphin Platform
by Junzhi Yu, Tianzhu Wang, Di Chen and Yan Meng
Biomimetics 2023, 8(1), 21; https://doi.org/10.3390/biomimetics8010021 - 5 Jan 2023
Cited by 6 | Viewed by 1983
Abstract
Kinematic analysis of leaping motions can provide meaningful insights into unraveling the efficient and agile propulsive mechanisms in dolphin swimming. However, undisturbed kinematic examination of live dolphins has been very scarce due to the restriction of close-up biological observation with a motion capture [...] Read more.
Kinematic analysis of leaping motions can provide meaningful insights into unraveling the efficient and agile propulsive mechanisms in dolphin swimming. However, undisturbed kinematic examination of live dolphins has been very scarce due to the restriction of close-up biological observation with a motion capture system. The main objective of this study is to quantify the leaping motion of a self-propelled bionic robotic dolphin using a combined numerical and experimental method. More specifically, a dynamic model was established for the hydrodynamic analysis of a changeable submerged portion, and experimental data were then employed to identify hydrodynamic parameters and validate the effectiveness. The effects of wave-making resistance were explored, indicating that there is a varying nonlinear relationship between power and speed at different depths. In addition, the wave-making resistance can be reduced significantly when swimming at a certain depth, which leads to a higher speed and less consumed power. Quantitative estimation of leaping motion is carried out, and the results suggest that with increase of the exiting velocity and angle, the maximum height of the center of mass (CM) increases as well; furthermore, a small exiting angle usually requires a much larger exiting velocity to achieve a complete exiting motion. These findings provide implications for optimizing motion performance, which is an integral part of underwater operations in complex aquatic environments. Full article
(This article belongs to the Special Issue Latest Trends in Bio-Inspired Underwater Robotics)
Show Figures

Graphical abstract

12 pages, 3001 KiB
Article
In-Situ Surface Modification of ITO Substrate via Bio-Inspired Mussel Chemistry for Organic Memory Devices
by Minglei Gong, Wei Li, Fei Fan, Yu Chen and Bin Zhang
Biomimetics 2022, 7(4), 237; https://doi.org/10.3390/biomimetics7040237 - 12 Dec 2022
Cited by 2 | Viewed by 1346
Abstract
The development of organic memory devices, regarding factors such as structure construction, principle exploration, and material design, has become a powerful supplement to traditional silicon-based information storage. The in-situ growth of materials on substrate surfaces can achieve closer bonding between materials and electrodes. [...] Read more.
The development of organic memory devices, regarding factors such as structure construction, principle exploration, and material design, has become a powerful supplement to traditional silicon-based information storage. The in-situ growth of materials on substrate surfaces can achieve closer bonding between materials and electrodes. Bio-inspired by mussel chemistry, polydopamine (PDA) was self-assembled on a flexible substrate as a connecting layer, and 2-bromoiso-butyryl bromide (BiBB) was utilized as an initiator for the polymerization of an iridium complex via surface-initiated atom-transfer radical polymerization (SI-ATRP). A device with the structure of Al/PDA-PPy3Ir/ITO was constructed after the deposition of aluminum. The device exhibited a nonvolatile rewritable memory characteristic with a turn-on voltage of −1.0 V and an ON/OFF current ratio of 6.3 × 103. In addition, the memory performance of the Al/PDA-PPy3Ir/ITO device remained stable at bending states due to the intrinsic flexibility of the active layer, which can be expanded into the establishment of flexible memory devices. Spectroscopy and electrochemical characterization suggested that the resistive memory properties of the device stemmed from charge transfer between PDA and iridium polymer in the active layer (PDA-PPy3Ir) under an applied voltage. Full article
(This article belongs to the Section Biomimetic Design, Constructions and Devices)
Show Figures

Figure 1

14 pages, 2639 KiB
Article
Design of a Felid-like Humanoid Foot for Stability Enhancement
by Zhaoyang Cai, Xuechao Chen, Qingqing Li, Huaxin Liu and Zhangguo Yu
Biomimetics 2022, 7(4), 235; https://doi.org/10.3390/biomimetics7040235 - 12 Dec 2022
Cited by 3 | Viewed by 2072
Abstract
The foot is an important part of humanoid robot locomotion that can help with shock absorption while making contact with the ground. The mechanism of the foot directly affects walking stability. A novel foot mechanism inspired by the toes of felids is proposed. [...] Read more.
The foot is an important part of humanoid robot locomotion that can help with shock absorption while making contact with the ground. The mechanism of the foot directly affects walking stability. A novel foot mechanism inspired by the toes of felids is proposed. The foot has four bionic modules with soft pads and sharp claws installed at the four corners of a flat foot. This foot can reduce the impact experienced during foot landing and increase the time that the foot is in contact with the ground, which can improve the adaptability of the robot to different ground surface conditions with different levels of stiffness. The main structure of the bionic module is a four-bar linkage consisting of a slide way and a spring. Furthermore, the length of the four-bar linkage and the posture of the claw during insertion into soft ground are optimized to improve the stability and buffering performance. The validity of the proposed foot mechanism has been proved in simulations. Full article
(This article belongs to the Special Issue Bio-Inspired Design and Control of Legged Robot)
Show Figures

Figure 1

23 pages, 98577 KiB
Article
Starling-Behavior-Inspired Flocking Control of Fixed-Wing Unmanned Aerial Vehicle Swarm in Complex Environments with Dynamic Obstacles
by Weihuan Wu, Xiangyin Zhang and Yang Miao
Biomimetics 2022, 7(4), 214; https://doi.org/10.3390/biomimetics7040214 - 26 Nov 2022
Cited by 3 | Viewed by 2473
Abstract
For the sake of accomplishing the rapidity, safety and consistency of obstacle avoidance for a large-scale unmanned aerial vehicle (UAV) swarm in a dynamic and unknown 3D environment, this paper proposes a flocking control algorithm that mimics the behavior of starlings. By analyzing [...] Read more.
For the sake of accomplishing the rapidity, safety and consistency of obstacle avoidance for a large-scale unmanned aerial vehicle (UAV) swarm in a dynamic and unknown 3D environment, this paper proposes a flocking control algorithm that mimics the behavior of starlings. By analyzing the orderly and rapid obstacle avoidance behavior of a starling flock, a motion model inspired by a flock of starlings is built, which contains three kinds of motion patterns, including the collective pattern, evasion pattern and local-following pattern. Then, the behavior patterns of the flock of starlings are mapped on a fixed-wing UAV swarm to improve the ability of obstacle avoidance. The key contribution of this paper is collective and collision-free motion planning for UAV swarms in unknown 3D environments with dynamic obstacles. Numerous simulations are conducted in different scenarios and the results demonstrate that the proposed algorithm improves the speed, order and safety of the UAV swarm when avoiding obstacles. Full article
(This article belongs to the Special Issue Bio-Inspired Flight Systems and Bionic Aerodynamics)
Show Figures

Graphical abstract

12 pages, 2340 KiB
Article
Gradient Micropillar Array Inspired by Tree Frog for Robust Adhesion on Dry and Wet Surfaces
by Quan Liu, Fandong Meng, Di Tan, Zhekun Shi, Bo Zhu, Kangjian Xiao and Longjian Xue
Biomimetics 2022, 7(4), 209; https://doi.org/10.3390/biomimetics7040209 - 21 Nov 2022
Cited by 8 | Viewed by 2266
Abstract
The strong adhesion on dry and wet surfaces and the durability of bioinspired hierarchical fibrillar adhesives are critical for their applications. However, the critical design for the strong adhesion normally depends on fine sub-micron structures which could be damaged during repeat usage. Here, [...] Read more.
The strong adhesion on dry and wet surfaces and the durability of bioinspired hierarchical fibrillar adhesives are critical for their applications. However, the critical design for the strong adhesion normally depends on fine sub-micron structures which could be damaged during repeat usage. Here, we develop a tree frog-inspired gradient composite micropillars array (GP), which not only realizes a 2.3-times dry adhesion and a 5.6-times wet adhesion as compared to the pure polydimethylsiloxane (PDMS) micropillars array (PP), but also shows excellent durability over 200 repeating cycles of attachment/detachment and self-cleaning ability. A GP consists of stiffer tips and softer roots by incorporating gradient dispersed CaCO3 nanoparticles in PDMS micropillar stalks. The modulus gradient along the micropillar height facilitates the contact formation and enhances the maximum stress during the detaching. The study here provides a new design strategy for robust adhesives for practical applications in the fields of robotics, electronics, medical engineering, etc. Full article
(This article belongs to the Section Biomimetics of Materials and Structures)
Show Figures

Graphical abstract

47 pages, 7439 KiB
Article
Serval Optimization Algorithm: A New Bio-Inspired Approach for Solving Optimization Problems
by Mohammad Dehghani and Pavel Trojovský
Biomimetics 2022, 7(4), 204; https://doi.org/10.3390/biomimetics7040204 - 20 Nov 2022
Cited by 19 | Viewed by 2934
Abstract
This article introduces a new metaheuristic algorithm called the Serval Optimization Algorithm (SOA), which imitates the natural behavior of serval in nature. The fundamental inspiration of SOA is the serval’s hunting strategy, which attacks the selected prey and then hunts the prey in [...] Read more.
This article introduces a new metaheuristic algorithm called the Serval Optimization Algorithm (SOA), which imitates the natural behavior of serval in nature. The fundamental inspiration of SOA is the serval’s hunting strategy, which attacks the selected prey and then hunts the prey in a chasing process. The steps of SOA implementation in two phases of exploration and exploitation are mathematically modeled. The capability of SOA in solving optimization problems is challenged in the optimization of thirty-nine standard benchmark functions from the CEC 2017 test suite and CEC 2019 test suite. The proposed SOA approach is compared with the performance of twelve well-known metaheuristic algorithms to evaluate further. The optimization results show that the proposed SOA approach, due to the appropriate balancing exploration and exploitation, is provided better solutions for most of the mentioned benchmark functions and has superior performance compared to competing algorithms. SOA implementation on the CEC 2011 test suite and four engineering design challenges shows the high efficiency of the proposed approach in handling real-world optimization applications. Full article
(This article belongs to the Special Issue Bio-Inspired Design and Optimisation of Engineering Systems)
Show Figures

Figure 1

18 pages, 6232 KiB
Article
Enhanced Adhesion of Synthetic Discs with Micro-Patterned Margins
by Weimian Zhou and Xuan Wu
Biomimetics 2022, 7(4), 202; https://doi.org/10.3390/biomimetics7040202 - 18 Nov 2022
Cited by 4 | Viewed by 2283
Abstract
Many aquatic creatures in nature have non-cooperative surface scaling abilities using suction organs; micro-/nano-scale structures found in different parts of the organs play an important role in this mechanism. Synthetic bioinspired suction devices have been developed, but the mechanisms of bioinspired suction system [...] Read more.
Many aquatic creatures in nature have non-cooperative surface scaling abilities using suction organs; micro-/nano-scale structures found in different parts of the organs play an important role in this mechanism. Synthetic bioinspired suction devices have been developed, but the mechanisms of bioinspired suction system need further investigation. This paper presents the development of a synthetic adhesive disc inspired by the hillstream loach. The microscopic structures involved in adhesion of the hillstream loach were investigated. Bioinspired suction discs were designed with single-level or hierarchical micropatterned margins. Micro three-dimensional (3D) printing and micro electromechanical system (MEMs) technology were utilized in the fabrication of the discs, and the adhesion performance was tested on substrates with different roughness values. The engaging and disengaging processes of the margin were simulated by carrying out a peeling test on a submerged substrate. The interactions between the liquid film and the microstructures were observed using fluorescence microscopy. The enhanced adhesion forces due to the synergy of the hierarchically micro-patterned margin and the disc cavity were duplicated in the synthetic adhesion system. Full article
(This article belongs to the Special Issue Biological Adhesives: From Biology to Biomimetics)
Show Figures

Figure 1

12 pages, 3471 KiB
Article
Theoretical Design of a Bionic Spatial 3D-Arrayed Multifocal Metalens
by Guihui Duan, Ce Zhang, Dongsheng Yang and Zhaolong Wang
Biomimetics 2022, 7(4), 200; https://doi.org/10.3390/biomimetics7040200 - 16 Nov 2022
Cited by 1 | Viewed by 1914
Abstract
With the development of micro/nano-optics, metasurfaces are gaining increasing attention working as novel electromagnetic wave control devices. Among which, metalenses have been developed and applied as a typical application of metasurfaces owing to their unique optical properties. However, most of those previous metalenses [...] Read more.
With the development of micro/nano-optics, metasurfaces are gaining increasing attention working as novel electromagnetic wave control devices. Among which, metalenses have been developed and applied as a typical application of metasurfaces owing to their unique optical properties. However, most of those previous metalenses can only produce one focal point, which severely limits their applications. Inspired by the fly compound eye, we propose a special kind of spatial multifocal metalens. Our metalenses can reverse the polarization state of the incident circularly polarized light, which is then focused. In addition, a horizontally aligned multifocal metalens can be achieved by designing reasonable phase and region distributions, which is similar to a vertically aligned one. Most significantly, a spatially 3D-arrayed multifocal metalens with low crosstalk is well achieved by combining these two distribution methods. The proposed bionic 3D-arrayed multifocal metalens with amazing focusing effect promises applications in imaging, nanoparticle manipulation, optical communication, and other fields. Full article
(This article belongs to the Special Issue Bionic Functional Interfaces and Devices for Low-Carbon Applications)
Show Figures

Figure 1

15 pages, 2149 KiB
Article
“Descriptive Risk-Averse Bayesian Decision-Making,” a Model for Complex Biological Motion Perception in the Human Dorsal Pathway
by Khashayar Misaghian, Jesus Eduardo Lugo and Jocelyn Faubert
Biomimetics 2022, 7(4), 193; https://doi.org/10.3390/biomimetics7040193 - 7 Nov 2022
Cited by 3 | Viewed by 1672
Abstract
Biological motion perception is integral not only to survival but also to the social life of human beings. Identifying the underlying mechanisms and their associated neurobiological substrates has been a matter of investigation and debate for some time. Although, in general, it is [...] Read more.
Biological motion perception is integral not only to survival but also to the social life of human beings. Identifying the underlying mechanisms and their associated neurobiological substrates has been a matter of investigation and debate for some time. Although, in general, it is believed that the integration of local motion and dynamic form cues in the brain empowers the visual system to perceive/recognize biological motion stimuli, some recent studies have indicated the importance of dynamic form cues in such a process. Inspired by the previous neurophysiologically plausible biological motion perception models, a new descriptive risk-averse Bayesian simulation model, capable of discerning a ball’s direction from a set of complex biological motion soccer kick stimuli, is proposed. The model represents only the dorsal pathway as a motion information processing section of the visual system according to the two-stream theory. The stimuli used have been obtained from a previous psychophysical study on athletes in our lab. Furthermore, the acquired psychophysical data from that study have been used to re-enact human behavior using our simulation model. By adjusting the model parameters, the psychometric function of athlete subjects has been mimicked. A correlation analysis between human and simulation data shows a significant and robust correlation between angular thresholds and slopes of the psychometric functions of both groups. Although it is established that the visual system optimally integrates all available information in the decision-making process, the results conform to the speculations favoring motion cue importance over dynamic form by testing the limits in which biological motion perception only depends on motion information processing. Full article
Show Figures

Graphical abstract

24 pages, 2490 KiB
Article
A Fast-Tracking-Particle-Inspired Flow-Aided Control Approach for Air Vehicles in Turbulent Flow
by Hengye Yang, Gregory P. Bewley and Silvia Ferrari
Biomimetics 2022, 7(4), 192; https://doi.org/10.3390/biomimetics7040192 - 6 Nov 2022
Viewed by 1690
Abstract
Natural phenomena such as insect migration and the thermal soaring of birds in turbulent environments demonstrate animals’ abilities to exploit complex flow structures without knowledge of global velocity profiles. Similar energy-harvesting features can be observed in other natural phenomena such as particle transport [...] Read more.
Natural phenomena such as insect migration and the thermal soaring of birds in turbulent environments demonstrate animals’ abilities to exploit complex flow structures without knowledge of global velocity profiles. Similar energy-harvesting features can be observed in other natural phenomena such as particle transport in turbulent fluids. This paper presents a new feedback control approach inspired by experimental studies on particle transport that have recently illuminated particles’ ability to traverse homogeneous turbulence through the so-called fast-tracking effect. While in nature fast tracking is observed only in particles with inertial characteristics that match the flow parameters, the new fast-tracking feedback control approach presented in this paper employs available propulsion and actuation to allow the vehicle to respond to the surrounding flow in the same manner as ideal fast-tracking particles would. The resulting fast-tracking closed-loop controlled vehicle is then able to leverage homogeneous turbulent flow structures, such as sweeping eddies, to reduce travel time and energy consumption. The fast-tracking approach is shown to significantly outperform existing optimal control solutions, such as linear quadratic regulator and bang-bang control, and to be robust to changes in the vehicle characteristics and/or turbulent flow parameters. Full article
(This article belongs to the Special Issue Bio-Inspired Flight Systems and Bionic Aerodynamics)
Show Figures

Figure 1

15 pages, 9433 KiB
Article
Investigation on the Anisotropic Wetting Properties of Water Droplets on Bio-Inspired Groove Structures Fabricated by 3D Printing and Surface Modifications
by Ngoc Phuong Uyen Mai and Po-Yu Chen
Biomimetics 2022, 7(4), 174; https://doi.org/10.3390/biomimetics7040174 - 24 Oct 2022
Cited by 1 | Viewed by 1930
Abstract
The self-driving structure to orientate the water movement has attracted considerable attention. Inspired by the wedgelike structures of biological materials in nature, such as spider silks and cactus spines, anisotropic spreading can be realized by combining Laplace pressure gradient and hydrophilic surface. In [...] Read more.
The self-driving structure to orientate the water movement has attracted considerable attention. Inspired by the wedgelike structures of biological materials in nature, such as spider silks and cactus spines, anisotropic spreading can be realized by combining Laplace pressure gradient and hydrophilic surface. In this study, a series of groove patterns were fabricated by a combination of 3D printing and surface modification. PLA pattern was modified by the atmospheric pressure plasma, followed by grafting with hydrolyzed APTES. This work reports the anisotropic transport of water droplets on a series of designed dart-shaped groove patterns with specific angles in the main arrow and tail regions. This structure can induce capillary force to regulate droplets from the main cone to two wedgelike, whereas the droplets are hindered toward the opposite side is oat the vicinity of the groove’s tail. By means of the experiment, the mechanism of water transport in this pattern was revealed. This study can contribute a potential approach to manipulate and apply anisotropic wetting in many fields. Full article
Show Figures

Figure 1

20 pages, 2677 KiB
Article
Convergent Evolution of Adhesive Properties in Leaf Insect Eggs and Plant Seeds: Cross-Kingdom Bioinspiration
by Thies H. Büscher and Stanislav N. Gorb
Biomimetics 2022, 7(4), 173; https://doi.org/10.3390/biomimetics7040173 - 22 Oct 2022
Cited by 3 | Viewed by 2946
Abstract
Plants and animals are often used as a source for inspiration in biomimetic engineering. However, stronger engagement of biologists is often required in the field of biomimetics. The actual strength of using biological systems as a source of inspiration for human problem solving [...] Read more.
Plants and animals are often used as a source for inspiration in biomimetic engineering. However, stronger engagement of biologists is often required in the field of biomimetics. The actual strength of using biological systems as a source of inspiration for human problem solving does not lie in a perfect copy of a single system but in the extraction of core principles from similarly functioning systems that have convergently solved the same problem in their evolution. Adhesive systems are an example of such convergent traits that independently evolved in different organisms. We herein compare two analogous adhesive systems, one from plants seeds and one from insect eggs, to test their properties and functional principles for differences and similarities in order to evaluate the input that can be potentially used for biomimetics. Although strikingly similar, the eggs of the leaf insect Phyllium philippinicum and the seeds of the ivy gourd Coccinia grandis make use of different surface structures for the generation of adhesion. Both employ a water-soluble glue that is spread on the surface via reinforcing fibrous surface structures, but the morphology of these structures is different. In addition to microscopic analysis of the two adhesive systems, we mechanically measured the actual adhesion generated by both systems to quantitatively compare their functional differences on various standardized substrates. We found that seeds can generate much stronger adhesion in some cases but overall provided less reliable adherence in comparison to eggs. Furthermore, eggs performed better regarding repetitive attachment. The similarities of these systems, and their differences resulting from their different purposes and different structural/chemical features, can be informative for engineers working on technical adhesive systems. Full article
(This article belongs to the Special Issue Biological Attachment Systems and Biomimetics)
Show Figures

Graphical abstract

14 pages, 6070 KiB
Article
Double-Acting Soft Actuator for Soft Robotic Hand: A Bellow Pumping and Contraction Approach
by Hao Liu, Changchun Wu, Senyuan Lin, Yunquan Li and Yonghua Chen
Biomimetics 2022, 7(4), 171; https://doi.org/10.3390/biomimetics7040171 - 20 Oct 2022
Cited by 7 | Viewed by 3067
Abstract
When compressing a soft bellow, the bellow will contract and pump out the fluid inside the bellow. Utilizing this property, we propose a novel actuation method called compressing bellow actuation (CBA), which can output fluidic power and tendon-driven force simultaneously. Based on the [...] Read more.
When compressing a soft bellow, the bellow will contract and pump out the fluid inside the bellow. Utilizing this property, we propose a novel actuation method called compressing bellow actuation (CBA), which can output fluidic power and tendon-driven force simultaneously. Based on the CBA method, a double-acting soft actuator (DASA) combining fluidic elastomer actuator (FEA) and tendon-driven metacarpophalangeal (MCP) joint is proposed for robotic finger design. The proposed DASA exhibits both compliance and adaptiveness of FEAs, and controllability and large output force of the tendon-driven methods. The fluid in the bellow can be either air or water or even integration of the two, thus constituting three different actuation modes. Mathematical modeling of the relationship between bellow compression displacement and DASA’s bending angle is developed. Furthermore, experimental characterizations of DASA’s bending angle and blocking force are conducted at different actuation modes. The double-acting method can availably promote the bending angle of an FEA by up to 155%, and the blocking force by up to 132% when the FEA is water-filled. A soft robotic hand with a forearm prototype based on the DASA fingers is fabricated for the demonstration of finger motion and gripping applications. Full article
(This article belongs to the Special Issue Biomimetic Soft Robotics)
Show Figures

Graphical abstract

17 pages, 8155 KiB
Article
Injectability, Processability, Drug Loading, and Antibacterial Activity of Gentamicin-Impregnated Mesoporous Bioactive Glass Composite Calcium Phosphate Bone Cement In Vitro
by Ming-Hsien Hu, Pei-Yi Chu, Ssu-Meng Huang, Bo-Sin Shih, Chia-Ling Ko, Jin-Jia Hu and Wen-Cheng Chen
Biomimetics 2022, 7(3), 121; https://doi.org/10.3390/biomimetics7030121 - 28 Aug 2022
Cited by 14 | Viewed by 3731
Abstract
Calcium phosphate cement (CPC) is similar to bone in composition and has plasticity, while mesoporous bioactive glass (MBG) has the advantage of releasing Si, which can promote osteogenic properties and drug loading capacity. A sol–gel-prepared MBG micro-powder (mMBG) and further impregnated antibiotic gentamicin [...] Read more.
Calcium phosphate cement (CPC) is similar to bone in composition and has plasticity, while mesoporous bioactive glass (MBG) has the advantage of releasing Si, which can promote osteogenic properties and drug loading capacity. A sol–gel-prepared MBG micro-powder (mMBG) and further impregnated antibiotic gentamicin sulfate (Genta@mMBG: 2, 3, and 4 mg/mL) antibiotic were added to CPC at different weight ratios (5, 10, and 15 wt.%) to study CPC’s potential clinical applications. Different ratios of mMBG/CPC composite bone cement showed good injectability and disintegration resistance, but with increasing mMBG addition, the working/setting time and compressive strength decreased. The maximum additive amount was 10 wt.% mMBG due to the working time of ~5 min, the setting time of ~10 min, and the compressive strength of ~51 MPa, indicating that it was more suitable for clinical surgical applications than the other groups. The 2Genta@mMBG group loaded with 2 mg/mL gentamicin had good antibacterial activity, and the 10 wt.% 2Genta@mMBG/CPC composite bone cement still had good antibacterial activity but reduced the initial release of Genta. 2Genta@mMBG was found to have slight cytotoxicity, so 2Genta@mMBG was composited into CPC to improve the biocompatibility and to endow CPC with more advantages for clinical application. Full article
Show Figures

Graphical abstract

23 pages, 13379 KiB
Article
Novel Motion Sequences in Plant-Inspired Robotics: Combining Inspirations from Snap-Trapping in Two Plant Species into an Artificial Venus Flytrap Demonstrator
by Falk J. Tauber, Philipp Auth, Joscha Teichmann, Frank D. Scherag and Thomas Speck
Biomimetics 2022, 7(3), 99; https://doi.org/10.3390/biomimetics7030099 - 22 Jul 2022
Cited by 8 | Viewed by 3245
Abstract
The field of plant-inspired robotics is based on principles underlying the movements and attachment and adaptability strategies of plants, which together with their materials systems serve as concept generators. The transference of the functions and underlying structural principles of plants thus enables the [...] Read more.
The field of plant-inspired robotics is based on principles underlying the movements and attachment and adaptability strategies of plants, which together with their materials systems serve as concept generators. The transference of the functions and underlying structural principles of plants thus enables the development of novel life-like technical materials systems. For example, principles involved in the hinge-less movements of carnivorous snap-trap plants and climbing plants can be used in technical applications. A combination of the snap-trap motion of two plant species (Aldrovanda vesiculosa and Dionaea muscipula) has led to the creation of a novel motion sequence for plant-inspired robotics in an artificial Venus flytrap system, the Venus Flyflap. The novel motion pattern of Venus Flyflap lobes has been characterized by using four state-of-the-art actuation systems. A kinematic analysis of the individual phases of the new motion cycle has been performed by utilizing precise pneumatic actuation. Contactless magnetic actuation augments lobe motion into energy-efficient resonance-like oscillatory motion. The use of environmentally driven actuator materials has allowed autonomous motion generation via changes in environmental conditions. Measurement of the energy required for the differently actuated movements has shown that the Venus Flyflap is not only faster than the biological models in its closing movement, but also requires less energy in certain cases for the execution of this movement. Full article
Show Figures

Graphical abstract

15 pages, 8327 KiB
Article
Assessment of Optimal Conditions for Marine Invertebrate Cell-Mediated Mineralization of Organic Matrices
by Jeremy Elias, Thomas Angelini, Mark Q. Martindale and Laurie Gower
Biomimetics 2022, 7(3), 86; https://doi.org/10.3390/biomimetics7030086 - 26 Jun 2022
Viewed by 2374
Abstract
Cellular strategies and regulation of their crystallization mechanisms are essential to the formation of biominerals, and harnessing these strategies will be important for the future creation of novel non-native biominerals that recapitulate the impressive properties biominerals possess. Harnessing these biosynthetic strategies requires an [...] Read more.
Cellular strategies and regulation of their crystallization mechanisms are essential to the formation of biominerals, and harnessing these strategies will be important for the future creation of novel non-native biominerals that recapitulate the impressive properties biominerals possess. Harnessing these biosynthetic strategies requires an understanding of the interplay between insoluble organic matrices, mineral precursors, and soluble organic and inorganic additives. Our long-range goal is to use a sea anemone model system (Nematostella vectensis) to examine the role of intrinsically disordered proteins (IDPs) found in native biomineral systems. Here, we study how ambient temperatures (25–37 °C) and seawater solution compositions (varying NaCl and Mg ratios) will affect the infiltration of organic matrices with calcium carbonate mineral precursors generated through a polymer-induced liquid-precursor (PILP) process. Fibrillar collagen matrices were used to assess whether solution conditions were suitable for intrafibrillar mineralization, and SEM with EDS was used to analyze mineral infiltration. Conditions of temperatures 30 °C and above and with low Mg:Ca ratios were determined to be suitable conditions for calcium carbonate infiltration. The information obtained from these observations may be useful for the manipulation and study of cellular secreted IDPs in our quest to create novel biosynthetic materials. Full article
(This article belongs to the Special Issue Bioinspired Nanostructures for Innovative Functional Applications)
Show Figures

Graphical abstract
