Editor’s Choice Articles

Straining of sheet metal leads to surface roughness changes. In this study, foils of AISI 201 and AISI 304 stainless steel were strained in uniaxial tension to impose roughening of their surfaces. Thereafter, the corrosion resistance, electrical resistivity, magnetic field density, and lubricated friction of the resulting surfaces were evaluated. The effect of strain-rate on the surface roughening, and thereby on the friction against tools, corrosion resistance, and occurrence of deformation-induced martensite was investigated. The AISI 304 material showed higher roughening than AISI 201 at low strain-rate. Lubricated friction is clearly affected by the changes to the surface of the strained foils that occur. When simulating a micro-forming process, the effect of strain-induced changes should be included where possible to maintain a high fidelity of the simulation. Strain-rate, in the range tested in this work, had only a minor effect on corrosion properties; however, the martensite fraction was reduced for material elongated at higher strain-rates. Full article

Additive Manufacturing (AM) is gaining importance as an alternative and complementary technology to conventional manufacturing processes. Among AM technologies, the Atomic Diffusion Additive Manufacturing (ADAM) technology is a novel extrusion-based process involving metallic filaments. In this work, the widely used 17-4 PH stainless steel filament was selected to study the effect of different deposition strategies of ADAM technology on mechanical properties. The printed parts had mechanical properties comparable to those obtained by other more developed AM technologies. In the case of tensile and fatigue tests, obtained values were in general greatly affected by deposition strategy, achieving better results in horizontal built orientation specimens. Interestingly, the effect was also considered of machining post-process (turning), which in the case of the tensile test had no remarkable effect, while in fatigue tests it led to an improvement in fatigue life of two to four times in the tested range of stresses. Full article

Thermal conductivity (TC) is greatly influenced by the working temperature, microstructures, thermal processing (heat treatment) history and the composition of alloys. Due to computational costs and lengthy experimental procedures, obtaining the thermal conductivity for novel alloys, particularly parts made with additive manufacturing, is difficult and it is almost impossible to optimize the compositional space for an absolute targeted value of thermal conductivity. To address these difficulties, a machine learning method is explored to predict the TC of additive manufactured alloys. To accomplish this, an extensive thermal conductivity dataset for additively manufactured alloys was generated for several AM alloy families (nickel, copper, iron, cobalt-based) over various temperatures (300–1273 K). This unique dataset was used in training and validating machine learning models. Among the five different regression machine learning models trained with the dataset, extreme gradient boosting performs the best as compared with other models with an R² score of 0.99. Furthermore, the accuracy of this model was tested using Inconel 718 and GRCop-42 fabricated with laser powder bed fusion-based additive manufacture, which have never been observed by the extreme gradient boosting model, and a good match between the experimental results and machine learning prediction was observed. The average mean error in predicting the thermal conductivity of Inconel 718 and GRCop-42 at different temperatures was 3.9% and 2.08%, respectively. This paper demonstrates that the thermal conductivity of novel AM alloys could be predicted quickly based on the dataset and the ML model. Full article

This paper presents a systematic approach to developing big data analytics for manufacturing process-relevant decision-making activities from the perspective of smart manufacturing. The proposed analytics consist of five integrated system components: (1) Data Preparation System, (2) Data Exploration System, (3) Data Visualization System, (4) Data Analysis System, and (5) Knowledge Extraction System. The functional requirements of the integrated system components are elucidated. In addition, JAVA™- and spreadsheet-based systems are developed to realize the proposed system components. Finally, the efficacy of the analytics is demonstrated using a case study where the goal is to determine the optimal material removal conditions of a dry Electrical Discharge Machining operation. The analytics identified the variables (among voltage, current, pulse-off time, gas pressure, and rotational speed) that effectively maximize the material removal rate. It also identified the variables that do not contribute to the optimization process. The analytics also quantified the underlying uncertainty. In summary, the proposed approach results in transparent, big-data-inequality-free, and less resource-dependent data analytics, which is desirable for small and medium enterprises—the actual sites where machining is carried out. Full article

While Inconel 718 is a widely used engineering material in industrial fields such as the aerospace and automotive fields, the machined surface integrity has a significant effect on the performance of its components and parts. In this work, the laser-assisted micro-milling process of Inconel 718 is investigated using a combination of experiments and finite element simulations. Firstly, an experimental platform of laser-assisted milling is built, and a three-dimensional thermal–mechanical coupled finite element model of laser-assisted milling of Inconel 718 is then established. Secondly, laser-assisted milling experiments and finite element simulations are conducted to investigate the impact of laser assistance on cutting force, chip morphology, tool wear and surface topography of Inconel 718 under a milling process. The results indicate that laser-assisted milling results in a moderate reduction in cutting forces while enhancing surface integrity and chip continuity, as compared with ordinary milling. Thirdly, orthogonal experiments of laser-assisted milling of Inconel 718 are conducted to discover the optimal processing parameters, including spindle speed, feed per tooth, milling depth and laser parameters. Finally, single-factor experiments are conducted to investigate the effect of laser power on cutting force, chip morphology, tool wear, groove burr and surface roughness in the laser-assisted milling of Inconel 718. And, a minimal surface roughness Sa of 137 nm for Inconel 718 accompanied by minimal tool wear is experimentally obtained via laser-assisted milling. These findings highlight the effectiveness of applying laser assistance in enhancing the machinability of difficult-to-machine materials for achieving desirable machined surface integrity. Full article

Shearing high-strength steels often leads to a subpar cut quality and excessive stress on the tool components. To enhance the quality of the cut surface, intricate techniques like fine blanking are commonly employed. However, for applications with lower quality requirements, precision shear cutting offers an alternative solution. This research paper introduces a novel approach to directly superimpose radial stress on a workpiece during the precision shear cutting process and showcases for the first time how the application of direct stress superimposition can impact the cut surface by concurrently modifying the shear cutting edge and punch surface. A statistical experimental design is employed to investigate the interrelationships between the parameters and their effects. The results indicate that the overall cut quality, including cylindricity, clean-cut angle, rollover height, and tool stress, defined by punch force and retraction force, is influenced by the superimposed stress. Regarding the clean-cut zone, the statistical significance of direct radially superimposed stress was not observed, except when interacting with sheet thickness and clearance. Additionally, the sheet thickness and cutting gap emerged as significant parameters affecting the overall quality of the cut surface. Full article

Laser-based powder bed fusion is an additive manufacturing process in which a high-power laser melts a thin layer of metal powder layer by layer to yield a three-dimensional object. An inert gas must remove process byproducts formed during laser processing to ensure a stable and consistent process. The process byproducts include a plasma plume and spatter particles. An NC sensor gantry is installed inside a bespoke open-architecture laser-based powder bed fusion system to experimentally characterize the gas velocity throughout the processing area. The flow maps are compared to manufactured samples, where the relative density and melt pools are analyzed, seeking a potential correlation between local gas flow conditions and the components. The results show a correlation between low gas flow velocities and increased porosity, leading to lower part quality. Local flow conditions across the build plate also directly impact components, highlighting the importance of optimizing the gas flow subsystem. The experimental flow analysis method enables optimization of the gas flow inlet geometry, and the data may be used to calibrate the computational modeling of the process. Full article

Multi-material additive manufacturing (AM) attempts to utilize the full benefits of complex part production with a comprehensive and complementary material spectrum. In this context, this research article presents new processing strategies in the field of polymer- and metal-based multi-material AM. The investigation highlights the current progress in powder-based multi-material AM based on three successfully utilized technological approaches: additive and formative manufacturing of hybrid metal parts with locally adapted and tailored properties, material-efficient AM of multi-material polymer parts through electrophotography, and the implementation of UV-curable thermosets within the laser-based powder bed fusion of plastics. Owing to the complex requirements for the mechanical testing of multi-material parts with an emphasis on the transition area, this research targets an experimental shear testing set-up as a universal method for both metal- and polymer-based processes. The method was selected based on the common need of all technologies for the sufficient characterization of the bonding behavior between the individual materials. Full article

Driven by high energy prices, AHSS are still gaining importance in the automotive industry regarding electric vehicles and their battery range. Simulation-based design of forming processes can contribute to exploiting their potential for lightweight design. Fracture models are frequently used to predict the material’s failure and are often parametrised using different tensile tests with optical measurements. Hereby, the fracture is determined by a surface crack. However, for many steels, the fracture initiation already occurs inside the specimen prior to a crack on the surface. This leads to inaccuracies and more imprecise fracture models. Using a method that detects the fracture initiation within the specimen, such as acoustic emission analysis, has a high potential to improve the modelling accuracy. In the presented paper, tests for fracture characterisation with two AHSS were performed for a wide range of stress states and measured with a conventional optical as well as a new acoustical measurement system. The tests were analysed regarding the fracture initiation using both measurement systems. Numerical models of the tests were created, and the EMC fracture model was parametrised based on the two evaluation areas: a surface crack as usual and a fracture from the inside as a novelty. The two fracture models were used in a deep drawing simulation for analysis, comparison and validation with deep drawing experiments. It was shown that the evaluation area for the fracture initiation had a significant impact on the fracture model. Hence, the failure prediction of the EMC fracture model from the acoustic evaluation method showed a higher agreement in the numerical simulations with the experiments than the model from the optical evaluation. Full article

Dynamic machine tool simulation models can be used for various applications such as process simulations, design optimization, and condition monitoring. However, all these applications require that the model replicates the real system’s behavior as accurately as possible. Next to carefully building the model, the parameterization of the model, that is, determining the parameter values the model is based upon, is the most crucial step. This paper describes the application of both sensitivity-based and black-box parameter identification to a machine tool. It further provides a comparison between these two methods and the method of sequential assembly. It is shown that both methods can increase the mode shape conformity by more than 25% and significantly reduce damping deviations. However, sensitivity-based parameter identification is the most economical method, offering the chance to update a dynamic machine tool model within minutes. Full article

Fatigue properties of parts are of particular concern for safety-critical structures. It is well-known that discontinuities in shape or non-uniformities in materials are frequently a potential nucleus of fatigue failure. This is especially crucial for the Ti6Al4V alloy, which presents high susceptibility to the notch effect. This study investigates how post-processing treatments affect the mechanical performance of Ti6Al4V samples manufactured by laser powder bed fusion technology. All the fatigue samples were subjected to a HIP cycle and post-processed by machining and using combinations of alternative mechanical and electrochemical surface treatments. The relationship between surface properties such as roughness, topography and residual stresses with fatigue performance was assessed. Compressive residual stresses were introduced in all surface-treated samples, and after tribofinishing, roughness was reduced to 0.31 ± 0.10 µm, which was found to be the most critical factor. Fractures occurred on the surface as HIP removed critical internal defects. The irregularities found in the form of cavities or pits were stress concentrators that initiated cracks. It was concluded that machined surfaces presented a fatigue behavior comparable to wrought material, offering a fatigue limit superior to 450 MPa. Additionally, alternative surface treatments showed a fatigue behavior equivalent to the casting material. Full article

The innovative Green Ceramic Hybrid Machining (GCHM) process sequentially combines milling with a cutting tool (GCM, Green Ceramic Machining) and laser beam machining (GCLBM) of a ceramic material (black Y-TZP in this study) at the green stage mainly to increase productivity, avoid taper angle limitations of laser beam machining, and obtain micro-features. The study focuses on the reliability and the repeatability of the properties of sintered parts obtained by three manufacturing processes (GCM, GCLBM, GCHM) to assess the performance of hybridisation. It turns out that GCHM is a compromise of both milling and laser beam processes; it increases the repeatability of the surface quality and it slightly reduces (less than 7%) the flexural strength by comparison to milling for a similar reliability. The study also highlights that the surface quality of GCLBM processed parts relies on of the surface generated by the previous operation. Milling that surface at the previous step is therefore recommended, corresponding to the sequence adopted by GCHM. Full article

Nickel-based Ni-Cr-Si-B self-fluxing alloys are excellent candidates to replace cobalt-based alloys in aeronautical components. In this work, metal additive manufacturing by directed energy deposition using a laser beam (DED-LB, also known as LMD) and gas-atomized powders as a material feedstock is presented as a potential manufacturing route for the complex processing of these alloys. This research deals with the advanced material characterization of these alloys obtained by LMD and the study and understanding of their solidification paths and strengthening mechanisms. The as-built microstructure, the Vickers hardness at room temperature and at high temperatures, the nanoindentation hardness and elastic modulus of the main phases and precipitates, and the strengthening mechanisms were studied in bulk cylinders manufactured under different chemical composition grades and DED-LB/p process parameter sets (slow, normal, and fast deposition speeds), with the aim of determining the influence of the chemical composition in commercial Ni-Cr-Si-Fe-B alloys. The hardening of Ni-Cr-Si-Fe-B alloys obtained by LMD is a combination of the solid solution hardening of gamma nickel dendrites and eutectics and the contribution of the precipitation hardening of small chromium-rich carbides and hard borides evenly distributed in the as-built microstructure. Full article

This paper introduces a new formability test based on double-action radial extrusion to characterize material formability in the three-dimensional to plane-stress material flow transitions that are found in bulk metal-formed parts. The presentation draws from a multidirectional tool, which was designed to convert the vertical press stroke into horizontal movement of the compression punches towards each other, aspects of experimental strain determination, fractography, and finite element analysis. Results show that three-dimensional to plane-stress material flow transitions at the radially extruded flanges lead to different modes of fracture (by tension and by shear) that may or may not be preceded by necking, such as in sheet metal forming. The new formability test also reveals adequate characteristics to characterize the failure limits of very ductile wrought and additively manufactured metallic materials, which cannot be easily determined by conventional upset compression tests, and to facilitate the identification of the instant of cracking and of the corresponding fracture strains by combination of the force vs. time evolutions with the in-plane strains obtained from digital image correlation. Full article

The residual stress state of the machined sub-surface influences the service quality indicators of a component, such as fatigue life, tribological properties, and distortion. During machining, the radius of the cutting edge changes due to tool wear. The cutting-edge rounding significantly affects the residual stress state in the part and the occurring process forces. This paper presents a tool wear prediction model based on in-process measured cutting forces. The effects of the cutting-edge geometry on the force behavior and the machining-induced residual stresses were examined experimentally. The resulting database was used to realize a Machine Learning algorithm to calculate the hidden value of tool wear. The predictions were validated by milling experiments using rounded cutting edges for different process parameters. The microgeometry of the cutting edge could be determined with a Root Mean Square Error of 8.94 μm. Full article

Wire arc additive manufacturing (WAAM) is an emerging and promising technology for producing medium-to-large-scale metallic components/structures for different industries, i.e., aerospace, automotive, shipbuilding, etc. It is now a feasible alternative to traditional manufacturing processes due to its shorter lead time, low material waste, and cost-effectiveness. WAAM has been widely used to produce components using different materials, including copper-based alloy wires, in the past decades. This review paper highlights the critical aspects of WAAM process in terms of technology, various challenges faced during WAAM process, different in-process and post-process operations, process monitoring methods, various gases, and different types of materials used in WAAM process. Furthermore, it briefly overviews recent developments in depositing different copper-based alloys via WAAM process. Full article

X-ray-computed tomography (CT) is today’s gold standard for the non-destructive evaluation of internal component defects such as cracks and porosity. Using automated standardized evaluation algorithms, an analysis can be performed without knowledge of the shape, location, or size of the defects. Both the measurement and the evaluation are based on the fact that the component has no internal structures or cavities. However, additive manufacturing (AM) and hybrid subtractive procedures offer the possibility of integrating internal structures directly during the building process. The examination of powder bed fusion (PBF) samples made of Ti64 and PA12 showed that the standardized evaluation methods were not able to identify internal structures correctly. Different evaluation methods for the CT-measured values were analyzed and recommendations on a procedure for measuring internal structures are given. Full article

In this work, an innovative manufacturing approach that includes a fully linked and integrated manufacturing system consisting of a laser-based directed energy deposition (DED-LB/M) module and a forming press is presented. The alternating additive manufacturing (AM) process is based on a combination of a DED-LB/M process using a laser power of 600 W and a feed rate of 400 mm/min and a subsequent forming process, in which the structure is upset with a hydraulic press using a constant forming force of 500 kN in order to smooth the surface and influence the accuracy of the components. For the generation of a fundamental process understanding, a cuboid, basic shape was chosen as geometry for the investigations. The aim is to improve part properties by applying the process steps to generate part properties, which are superior to solely additive manufactured material. It is shown that the geometry of additive manufactured structures can be adapted, and the top surface can be smoothed due to the forming operation. The mean roughness value Rz decreases up to 50% after the forming operation. The hardness can be increased by work hardening. Of special interest is that the higher hardness can be kept up even though a further DED-LB/M process step and forming operation are applied to the additively manufactured and formed structure again. Finally, an analysis of the new manufacturing approach regarding its potential is given. Full article

Ultrafast lasers are proven and continually evolving manufacturing tools. Concurrently, additive manufacturing (AM) has emerged as a key area of interest for 3D fabrication of objects with arbitrary geometries. Use of ultrafast lasers for AM presents possibilities for next generation manufacturing techniques for hard-to-process materials, transparent materials, and micro- and nano-manufacturing. Of particular interest are selective laser melting/sintering (SLM/SLS), multiphoton lithography (MPL), laser-induced forward transfer (LIFT), pulsed laser deposition (PLD), and welding. The development, applications, and recent advancements of these technologies are described in this review as an overview and delineation of the burgeoning ultrafast laser AM field. As they mature, their adoption by industry and incorporation into commercial systems will be facilitated by process advancements such as: process monitoring and control, increased throughput, and their integration into hybrid manufacturing systems. Recent progress regarding these aspects is also reviewed. Full article

VDM Alloy 780 is a novel Ni-based superalloy that allows for approximately 50 °C higher operating temperatures, compared to Inconel 718, without a significant decrease in mechanical properties. The age hardenable NiCoCr Alloy combines increased temperature strength with oxidation resistance, as well as improved microstructural stability due to γ′-precipitation. These advantages make it suitable for wear- and corrosion-resistant coatings that can be used in high temperature applications. However, VDM Alloy 780 has not yet been sufficiently investigated for laser metal deposition applications. A design of experiments with single tracks on 316L specimens was carried out to evaluate the influence of the process parameters on clad quality. Subsequently, the quality of the clads was evaluated by means of destructive and non-destructive testing methods, in order to verify the suitability of VDM Alloy 780 for laser metal deposition applications. The single-track experiments provide a basis for coating or additive manufacturing applications. For conveying the results, scatter plots with regression lines are presented, which illustrate the influence of specific energy density on the resulting porosity, dilution, powder efficiency, aspect ratio, width and height. Finally, the clad quality, in terms of porosity, is visualized by two process maps with different mass per unit lengths. Full article

The recent success of the process monitoring method Electron Optical Imaging, applied in the additive manufacturing process Electron Beam Powder Bed Fusion, necessitates a clear understanding of the underlying image formation process. Newly developed multi-detector systems enable the reconstruction of the build surface topography in-situ but add complexity to the method. This work presents a physically based raytracing model, which rationalises the effect of detector positioning on image contrast development and masking. The model correctly describes the effect of multiple scattering events on vacuum chamber walls or heat shields and represents, therefore, a predictive tool for designing future detector systems. Most importantly, this work provides a validated method to compute build surface height gradients directly from experimentally recorded electron-optical images of a multi-detector system without any calibration steps. The computed surface height gradients can be used subsequently as input of normal integration algorithms aiming at the in-situ reconstruction of the build surface topography. Full article

Additive Manufacturing (AM) has been a growing industry, specifically when trying to mass produce products more cheaply and efficiently. However, there are too many current setbacks for AM to replace traditional production methods. One of the major problems with 3D printing is the high error rate compared to other forms of production. These high error rates lead to wasted material and valuable time. Furthermore, even when parts do not result in total failure, the outcome can often be less than desirable, with minor misprints or porosity causing weaknesses in the product. To help mitigate error and better understand the quality of a given print, the field of AM monitoring in research has been ever-growing. This paper looks through the literature on two AM processes: fused deposition modeling (FDM) and laser bed powder fusion (LBPF) printers, to see the current process monitoring architecture. The review focuses on the optical monitoring of 3D printing and separates the studies by type of camera. This review then summarizes specific trends in literature, points out the current limitations of the field of research, and finally suggests architecture and research focuses that will help forward the process monitoring field. Full article

This paper describes a hybrid manufacturing approach for silicon carbide (SiC) freeform surfaces using binder jet additive manufacturing (BJAM) to print the preform and machining to obtain the design geometry. Although additive manufacturing (AM) techniques such as BJAM allow for the fabrication of complex geometries, additional machining or grinding is often required to achieve the desired surface finish and shape. Hybrid manufacturing has been shown to provide an effective solution. However, hybrid manufacturing also has its own challenges, depending on the combination of processes. For example, when the subtractive and additive manufacturing steps are performed sequentially on separate systems, it is necessary to define a common coordinate system for part transfer. This can be difficult because AM preforms do not inherently contain features that can serve as datums. Additionally, it is important to confirm that the intended final geometry is contained within the AM preform. The approach described here addresses these challenges by using structured light scanning to create a stock model for machining. Results show that a freeform surface was machined with approximately 70 µm of maximum deviation from that which was planned. Full article

Computer-aided manufacturing (CAM) techniques for hybrid manufacturing have led to new application areas in the manufacturing industry. In the tooling industry, cooling channels are used to enable specific heating and cooling cycles to improve the performance of the process. These internal cooling channels have been designed with limited manufacturing processes in mind, so, until recently, they were often straight in shape for cross-drilling operations and manufactured from a cast billet. To show a novel application of this common technology, a tool with integrated conformal cooling channels was manufactured using hybrid manufacturing (blown-powder DED and CNC machining) techniques. The computer-aided manufacturing strategy used, and the lessons learned are presented and discussed to enable future work in this industrial application space. Full article

The paper presents the microstructural characterization of the chip roots in high-speed steels and ceramic Ti₃SiC₂. The process of chip formation and the obtaining of adequate samples were carried out using the quick-stop method. The tests were carried out during the milling process; the “quick stop” method was carried out in order to obtain samples of the chip roots. This method was developed in-house by the authors. The chip roots were microscopically studied by means of a light microscope (LM) and a scanning electron microscope (SEM). Before the actual analysis, preparation was performed based on the standard metallographic technique. The analysis of the high-speed steels samples showed that, for the used cutting conditions, a discontinuous chip with a built-up edge (BUE) was formed. During the processing of the Ti₃SiC₂ ceramic, a significant difference was manifested in the chip formation process and a powder-like chip was produced. After utilizing a careful cutting process, a chip pattern was observed, from which it is evident that chip breakage during ceramic processing occurs without prior plastic deformation. In addition, the cutting force F_c was also measured during the milling process of the high-speed steels and the ceramic, and it was correlated with the cutting speed, feed per tooth and depth of cut. Full article

Additively manufactured thin-walled structures through selective laser melting (SLM) are of great interest in achieving carbon-neutral industrial manufacturing. However, residual stresses and warpages as well as recoater crashes often occur in SLM, leading to the build failure of parts, especially for large-scale and lightweight geometries. The challenge in this work consists of investigating how the recoater affects the warpage and (sometimes) causes the failure of different thin-walled Ti6Al4V parts (wall thickness of 1.0 mm). All these parts are printed on the same platform using a commercial SLM machine. After the loose powder removal and before the cutting operation, a 3D-scanner is used to obtain the actual warpage of each component. Next, an in-house coupled thermo-mechanical finite element model suitable for the numerical simulation of the SLM process is enhanced to consider the recoater effects. This numerical framework is calibrated to predict the thin-walled warpage as measured by the 3D-scanner. The combination of numerical predictions with experimental observations facilitates a comprehensive understanding of the mechanical behavior of different thin-walled components as well as the failure mechanism due to the recoater. The findings show that the use of a higher laser energy input causes larger residual stresses and warpage responsible for the recoater crashes. Finally, potential solutions to mitigate the warpage and the recoater crashes in the SLM of lightweight structures are assessed using the validated model. Full article

The damage layer produced during the Niobium sheets and cavity fabrication processes is one of the main reasons why cavities have to undergo an extensive surface preparation process to recover optimal superconducting properties. Today, this includes the use of lengthy, costly, and dangerous conventional polishing techniques as buffered chemical polishing (BCP), or electro-polishing (EP). We propose to avoid or at least significantly reduce the use of acids. We developed a novel method based on metallographic polishing of Nb sheets, consisting of 2–3 steps. We demonstrate that this surface processing procedure could be transferred to large dimensions and an industrialized scale thanks to the limited number of steps and its compatibility with standard lapping polishing devices. Full article

Consistent high volumetric performance of machine tools is an essential requirement for high-quality machining. Periodic machine tool calibration ensures said performance and allows for timely corrective actions preventing scrap or rework. Reducing the duration of the calibration process decreases associated cost through non-productive downtime and allows for data acquisition in thermal real-time. The authors enhance an indirect calibration method based on measuring points within the machine volume using a laser tracker by removing the necessity for standstill. To circumvent requiring high fidelity space and time synchronization between metrology system and machine tool, only deviations perpendicular to the path are considered. To do so, the 3D laser tracker data are rotationally transformed such that one axis aligns with the motion direction and can subsequently be omitted as input data for the system of equations solving for geometric errors. Due to the absence of unique measurement-point-to-machine-point mapping, data alignment between nominal path and measurement data is proposed as an iterative alignment process of points to path. The method is tested simulatively and experimentally. It demonstrated conformity to the simulation as well as to the pre-existing calibration method based on laser trackers and shows good agreement with the direct calibration device API XD Laser. Full article

A distinctive characteristic of the powder bed fusion with electron beam (PBF-EB) process is the sintering of the powder particles. For certain metallic materials, this is crucial for the success of the subsequent step, the melting, and, generally, the whole process. Despite the sintering mechanisms that occur during the PBF-EB process being similar to well-known powder metallurgy, the neck growth rates are significantly different. Therefore, specific analyses are needed to understand the influence of the PBF-EB process conditions on neck growth and neck growth rate. Additionally, some aspects, such as the rigid body motion of the particles during the sintering process, are still challenging to analyze. This work systematically investigated the effects of different particle diameters and particle diameter ratios. Additionally, the impact of the rigid body motion of the particles in the sintering was analyzed. This work demonstrated that the sintering results significantly depended on the EB-PBF process conditions. Full article

Given its layer-based nature, additive manufacturing is known as a family of highly capable processes for fabricating complex 3D geometries designed by means of evolutionary topology optimization. However, the required support structures for the overhanging features of these complex geometries can be concerningly wasteful. This article presents an approach for studying the manufacturability of the topology-optimized complex 3D parts required for additive manufacturing and finding the optimum corresponding build direction for the fabrication process. The developed methodology uses the density gradient of the design matrix created during the evolutionary topology optimization of the 3D domains to determine the optimal build orientation for additive manufacturing with the objective of minimizing the need for support structures. Highly satisfactory results are obtained by implementing the developed methodology in analytical and experimental studies, which demonstrate potential additive manufacturing mass savings of 170% of the structure’s weight. The developed methodology can be readily used in a variety of evolutionary topology optimization algorithms to design complex 3D geometries for additive manufacturing technologies with a minimized level of waste due to reducing the need for support structures. Full article

Metal additive manufacturing has reached a level where products and components can be directly fabricated for applications requiring small batches and customized designs, from tinny body implants to long pedestrian bridges over rivers. Wire-fed directed energy deposition based additive manufacturing enables fabricating large parts in a cost-effective way. However, achieving reliable mechanical properties, desired structural integrity, and homogeneity in microstructure and grain size is challenging due to layerwise-built characteristics. Manufacturing processes, alloy composition, process variables, and post-processing of the fabricated part strongly affect the resultant microstructure and, as a consequence, component serviceability. This paper reviews the advances in wire-fed directed energy deposition, specifically wire arc metal additive processes, and the recent efforts in grain tailoring during the process for the desired size and shape. The paper also addresses modeling methods that can improve the qualification of fabricated parts by modifying the microstructure and avoid repetitive trials and material waste. Full article

Laser powder bed fusion, particularly the selective laser melting (SLM), is an additive manufacturing (AM) technology used to produce near-net-shaped engineering components for biomedical applications, especially in orthopaedics. Ti6Al4V is commonly used for producing orthopaedic implants using SLM because it has excellent mechanical qualities, a high level of biocompatibility, and corrosion resistance. However, the main problems associated with this process are the result of its surface properties: it has to be able to promote cell attachment but, at the same time, avoid bacteria colonization. Surface modification is used as a post-processing technique to provide items the unique qualities that can improve their functionality and performance in particular working conditions. The goal of this work was to produce and analyse Ti6Al4V samples fabricated by SLM with different building directions in relation to the building plate (0° and 45°) and post-processed by anodization and passivation. The results demonstrate how the production and post processes had an impact on osteoblast attachment, mineralization, and osseointegration over an extended period of time. Though the anodization treatment result was cytotoxic, the biocompatibility of as-built specimens and specimens after passivation treatment was confirmed. In addition, it was discovered that effective post-processing increases the mineralization of these types of 3D-printed surfaces. Full article

Non-isothermal laser-based powder bed fusion (LPBF) of polymers suggests the potential for significantly extending the range of materials applicable for powder-based additive manufacturing of polymers, relying on the absence of a material-specific processing window. To allow for the support-free manufacturing of polymers at a build chamber temperature of 25 °C, applied processing strategies comprise the combination of fractal exposure strategies and locally quasi-simultaneous exposure of distinct segments of a particular cross section for minimizing crystallization-induced part deflection. Based on the parameter-dependent control of emerging cooling rates, formed part morphologies and resulting mechanical properties can be modified. Thermographic in situ measurements allow for correlating thermal processing conditions and crystallization kinetics with component-specific mechanical, morphological, and microstructural properties, assessed ex situ. Part morphologies formed at crystallization temperatures below 70 °C, induced by reduced laser exposure times, are characterized by a nano-spherulitic structure, exhibiting an enhanced elongation at break. An ambient temperature of 25 °C is associated with the predominant formation of a combined (α + γ)-phase, induced by the rapid cooling and subsequent laser-induced tempering of distinct layers, yielding a periodic microstructural evolution. The presented results demonstrate a novel approach for obtaining nano-spherulitic morphologies, enabling the exposure-based targeted adaption of morphological properties. Furthermore, the thermographic inline assessment of crystallization kinetics allows for the enhanced understanding of process-morphology interdependencies in laser-based manufacturing processes of semi-crystalline polymers. Full article

Metal additive manufacturing (AM)-fabricated high-strength aluminum (HS-Al) alloys (2xxx, 6xxx, and 7xxx) tend to produce fatal metallurgical defects such as porosity and cracks. Since Al is the most important lightweight structural material in automotive and aviation industries, successful printing of HS-Al alloys is in high demand. Therefore, this review focuses on the formation mechanisms and research advancements to address these metallurgical defects. Firstly, the process optimization strategies, including AM parameter optimization, hybrid AM processes, and post-processing treatment, and their effectiveness and limitations have been reviewed thoroughly. However, process optimization can address defects such as porosity, surface roughness, and residual stresses but has limited effectiveness on cracking alleviation. Secondly, the research efforts on composition modification to address cracking in AM of HS-Al alloys are critically discussed. Different from process optimization, composition modification alters the solidification dynamics in AM of HS-Al alloys and hence is considered the most promising route for crack-free printing. Full article

With the development of the Internet of Things (IoT), Big Data, Artificial Intelligence technology, and the emergence of modern information technologies such as intelligent manufacturing, welding systems are changing, and intelligentized welding manufacturing and systems (IWMS) utilizing these technologies are attracting attention from both academia and industry. This paper investigates sensing technology, multi-information sensor fusion technology, feature recognition technology, the quality prediction method, control method, and intelligent welding production line application in the IWMS. Combining IoT technology and multi-agent systems, a hierarchical structure model welding manufacturing system (IoT-MAS) in the form of “leader-following” was constructed. The multi-agent welding manufacturing system has the advantages of distribution, intelligence, internal coordination and so on. The IoT-MAS consists of several sub-agents, which are divided into five categories according to their functions and internal processing logic. Combined with the functions of the intelligent welding manufacturing system, the agent structure of the whole welding process was proposed, and the matching communication technology and algorithm were designed. The intelligent welding manufacturing system based on IoT-MAS proposed in this paper can effectively solve the integrated design problem of large welding manufacturing systems. Full article

Access to vacuum systems is limited because of economic costs. A rapidly growing approach to reduce the costs of scientific equipment is to combine open-source hardware methods with digital distributed manufacturing with 3D printers. Although high-end 3D printers can manufacture vacuum components, again, the cost of access to tooling is economically prohibitive. Low-cost material extrusion 3D printing with plastic overcomes the cost issue, but two problems arise when attempting to use plastic in or as part of vacuum systems: the outgassing of polymers and their sealing. To overcome these challenges, this study explores the potential of using post-processing heat treatments to seal 3D printed polypropylene for use in vacuum environments. The effect of infill overlap and heat treatment with a readily available heat gun on 3D printed PP parts was investigated in detail on ISO-standardized KF vacuum fitting parts and with the use of computer vision-based monitoring of vacuum pump down velocities. The results showed that infill overlap and heat treatment both had a large impact on the vacuum pressures obtainable with 3D printed parts. Heat treatment combined with 98% infill reliably sealed parts for use in vacuum systems, which makes the use of low-cost desktop 3D printers viable for manufacturing vacuum components for open scientific hardware. Full article

This article presents a cost-effective and reliable method for welding 30 mm thick sheets of shipbuilding steel EH36. The method proposes to perform butt welding in a two-run technique using hybrid laser arc welding (HLAW) and submerged arc welding (SAW). The HLAW is performed as a partial penetration weld with a penetration depth of approximately 25 mm. The SAW is carried out as a second run on the opposite side. With a SAW penetration depth of 8 mm, the weld cross-section is closed with the reliable intersection of both passes. The advantages of the proposed welding method are: no need for forming of the HLAW root; the SAW pass can effectively eliminate pores in the HLAW root; the high stability of the welding process regarding the preparation quality of the weld edges. Plasma cut edges can be welded without lack of fusion defects. The weld quality achieved is confirmed by destructive tests. Full article

Laser additively manufactured duplex stainless steels contain mostly ferrite in the as-built parts due to rapid solidification of the printed layers. To achieve duplex microstructures (ferrite and austenite in roughly equal proportions) and, thus, a good combination of mechanical properties and corrosion resistance, an austenitic stainless steel powder (X2CrNiMo17-12-2) and a super duplex stainless steel powder (X2CrNiMoN25-7-4) were mixed in different proportions and the powder mixtures were processed via PBF-LB/M (Laser Powder Bed Fusion) under various processing conditions by varying the laser power and the laser scanning speed. The optimal process parameters for dense as-built parts were determined by means of light optical microscopy and density measurements. The austenitic and ferritic phase formation of the mixed alloys was significantly influenced by the chemical composition adjusted by powder mixing and the laser energy input during PBF-LB/M. The austenite content increases, on the one hand, with an increasing proportion of X2CrNiMo17-12-2 in the powder mixtures and on the other hand with increasing laser energy input. The latter phenomenon could be attributed to a slower solidification and a higher melt pool homogeneity with increasing energy input influencing the phase formation during solidification and cooling. The desired duplex microstructures could be achieved by mixing the X2CrNiMo17-12-2 powder and the X2CrNiMoN25-7-4 powder at a specific mixing ratio and building with the optimal PBF-LB/M parameters. Full article

The activities within a European network to develop accurate experimental and numerical methods to assess residual stresses in structural weldments are reported. The NeT Task Group 6 or NeT-TG6 project examined an Alloy 600 plate containing a three-pass slot weld made with Alloy 82 consumables. A number of identical specimens were fabricated and detailed records of the manufacturing history were kept. Parallel measurement and simulation round robins were performed. Residual stresses were measured using neutron diffraction via five different instruments. The acquired database is large enough to generate reliable mean profiles, to identify clear outliers, and to establish the systematic uncertainty associated with this non-destructive technique. NeT-TG6 gives a valuable insight into the real-world variability of diffraction-based residual stress measurements, and forms a reliable foundation against which to benchmark other measurement methods. The mean measured profiles were used to validate the accuracy achieved by the network in the prediction of residual stresses. Full article

Surface finishing is challenging in the context of additively manufactured components with complex geometries. Magnetic abrasive finishing (MAF) is a promising surface finishing technology that can refine the surface quality of components with complex shapes produced by additive manufacturing. However, there is insufficient study regarding the impact of MAF on microstructure–property relationships for additively manufactured builds, which is critical for evaluating mechanical performance. In this work, we studied the effects of different combinations of MAF and heat treatment steps on the microstructure–property relationships of Inconel 718 superalloys made by laser powder bed fusion (LPBF). The application of MAF was found to significantly reduce the surface roughness and refine the grain size of aged alloys. Moreover, MAF was able to increase the alloy elongation, which could be further influenced by the sequence of MAF and different heat treatment steps. The highest elongation could be achieved when MAF was performed between homogenization and aging processes. This work indicates that an effective combination of surface finishing and heat treatment is critical for the improvement of alloy performance. Furthermore, it demonstrates a promising solution for improving the performance of LPBF Inconel 718 by integrating MAF and heat treatment, which provides new perspectives on the post-processing optimization of additively manufactured alloys. Full article

Wire Arc Additive Manufacturing (WAAM) has many applications in fabricating complex metal parts. However, controlling surface roughness is very challenging in WAAM processes. Typically, machining methods are applied to reduce the surface roughness after a part is fabricated, which is costly and ineffective. Therefore, controlling the WAAM process parameters to achieve better surface roughness is important. This paper proposes a machine learning method based on Gaussian Process Regression to construct a model between the WAAM process parameters and top surface roughness. In order to measure the top surface roughness of a manufactured part, a 3D laser measurement system is developed. The experimental datasets are collected and then divided into training and testing datasets. A top surface roughness model is then constructed using the training datasets and verified using the testing datasets. Experimental results demonstrate that the proposed method achieves less than 50 μm accuracy in surface roughness prediction. Full article

In this work, friction stir spot welding of 5754 aluminum alloy to dual phase steel was investigated using two different ratios of martensite and ferrite (0.38 and 0.61) for steel sheet initial microstructure and varying tool rotation speed (800, 1200 and 2000 rpm). The effect of these parameters on the joint formation was evaluated by studying the plunging force response during the process and the main characteristics of the joint at (i) macrolevel, i.e., hook morphology and bond width, and (ii) microlevel, i.e., steel hook and sheet microstructure and intermetallic compounds. The plunging force was reduced by increased tool rotation speed while there was no significant effect from the initial steel microstructure ratio of martensite and ferrite on the plunging force. The macrostructural characterization of the joints showed that the hook morphology and bond width were affected by the steel sheet initial microstructures as well as by the tool rotation speed and by the material flow driver; tool pin or shoulder. At microstructural level, a progressive variation in the ratio of martensite and ferrite was observed for the steel hook and sheet microstructure. The zones closer to the tool presented a fully martensitic microstructure while the zones away from the tool showed a gradual increase in the ferrite amount until reaching the ratio of ferrite and martensite of the steel sheet initial microstructure. Different types of FexAly intermetallic compounds were found in three zones of the joint; the hook tips, in the hooks close to the exit hole and in the corner of the exit hole. These compounds were characterized by a brittle behavior with hardness values varying from 456 to 937 HV01. Full article

To better support the transition to more industrial uses of additive manufacturing, this study examined the use of an Arcam Q20+ industrial 3D printer for producing heavily nested Ti-6Al-4V parts with both in-specification (IS) and out of specification (OS) oxygen content in reused grade 5 powder chemistries. Both the OS and IS powder chemistries were evaluated to understand their impact on build integrity and on static and fatigue performance. The results from our evaluations showed that controlling the bed preheat temperature in the Q20+ to relatively low values (326–556 °C) was effective in limiting microstructural coarsening during the long build time and enabled adequate/balanced performance vis à vis the tensile strength and ductility. Overall, the tensile properties of the IS Ti-6Al-4V material in the as-built and machined states fully met the requirements of ASTM F2924-14. By contrast, the ductility was compromised at oxygen levels above 0.2 wt.% (OS) in Ti-6Al-4V produced by EBM. Removal of the surface layer by machining increased the consistency and performance of the IS and OS Ti-6Al-4V materials. The fatigue behaviour of the EBM Ti-6Al-4V material was in the range of properties produced by casting. Due to the strong influence of both the surface finish and oxygen content on the fatigue strength, the IS Ti-6Al-4V material exhibited the highest performance, with results that were in the range of parts that had been cast plus hot isostatically pressed. Full article
