Photonics, Volume 8, Issue 9 (September 2021) – 61 articles

Cover Story (view full-size image): Knowledge of the scattering and absorption parameters of biological tissue in a broad wavelength range is important for a variety of light-based diagnostic and therapeutical applications, such as for treatment planning in photodynamic therapy, for understanding microscopical images, and for non-invasive measurements of vital parameters. In this paper, we present spectra of the effective scattering coefficient µs’ and absorption coefficient µa of different porcine sample types for wavelengths between 400 nm and 1400 nm obtained with integrating sphere measurements and solutions of the radiative transport equation. The derived spectra were applied to quantify the concentration of relevant tissue chromophores, for example, oxy- and deoxyhemoglobin, collagen, water, and fat. View this paper
  • Issues are regarded as officially published after their release is announced to the table of contents alert mailing list.
  • You may sign up for e-mail alerts to receive table of contents of newly released issues.
  • PDF is the official format for papers published in both, html and pdf forms. To view the papers in pdf format, click on the "PDF Full-text" link, and use the free Adobe Reader to open them.
Order results
Result details
Section
Select all
Export citation of selected articles as:
12 pages, 1173 KiB
Article
Characterization of Collagen I Fiber Thickness, Density, and Orientation in the Human Skin In Vivo Using Second-Harmonic Generation Imaging
by Marius Kröger, Johannes Schleusener, Sora Jung and Maxim E. Darvin
Photonics 2021, 8(9), 404; https://doi.org/10.3390/photonics8090404 - 21 Sep 2021
Cited by 12 | Viewed by 4452
Abstract
The assessment of dermal alterations is necessary to monitor skin aging, cancer, and other skin diseases and alterations. The gold standard of morphologic diagnostics is still histopathology. Here, we proposed parameters to distinguish morphologically different collagen I structures in the extracellular matrix and [...] Read more.
The assessment of dermal alterations is necessary to monitor skin aging, cancer, and other skin diseases and alterations. The gold standard of morphologic diagnostics is still histopathology. Here, we proposed parameters to distinguish morphologically different collagen I structures in the extracellular matrix and to characterize varying collagen I structures in the skin with similar SAAID (SHG-to-AF Aging Index of Dermis, SHG—second-harmonic generation; AF—autofluorescence) values. Test datasets for the papillary and reticular extracellular matrix from images in 24 female subjects, 36 to 50 years of age, were generated. Parameters for SAAID, edge detection, and fast Fourier transformation directionality were determined. Additionally, textural analyses based on the grey level co-occurrence matrix (GLCM) were conducted. At first, changes in the GLCM parameters were determined in the native greyscale images and, furthermore, in the Hilbert-transformed images. Our results demonstrate a robust set of parameters for noninvasive in vivo classification for morphologically different collagen I structures in the skin, with similar and different SAAID values. We anticipate our method to enable an automated prevention and monitoring system with an age- and gender-specific algorithm. Full article
(This article belongs to the Special Issue Tissue Optics)
Show Figures

Figure 1

12 pages, 859 KiB
Article
Variant-Coherence Gaussian Sources
by Franco Gori and Massimo Santarsiero
Photonics 2021, 8(9), 403; https://doi.org/10.3390/photonics8090403 - 21 Sep 2021
Cited by 4 | Viewed by 1822
Abstract
The celebrated Gaussian Schell model source with its shift-invariant degree of coherence may be the basis for devising sources with space-variant properties in the spirit of structured coherence. Starting from superpositions of Gaussian Schell model sources, we present two classes of genuine cross-spectral [...] Read more.
The celebrated Gaussian Schell model source with its shift-invariant degree of coherence may be the basis for devising sources with space-variant properties in the spirit of structured coherence. Starting from superpositions of Gaussian Schell model sources, we present two classes of genuine cross-spectral densities whose degree of coherence varies across the source area. The first class is based on the use of the Laplace transform while the second deals with cross-spectral densities that are shape-invariant upon paraxial propagation. For the latter, we present a set of shape-invariant cross-spectral densities for which the modal expansion can be explicitly found. We finally solve the problem of ascertain whether an assigned cross-spectral density is shape-invariant by checking if it satisfies a simple differential constraint. Full article
(This article belongs to the Special Issue Structured Light Coherence)
Show Figures

Figure 1

16 pages, 3390 KiB
Article
Going Deeper into OSNR Estimation with CNN
by Fangqi Shen, Jing Zhou, Zhiping Huang and Longqing Li
Photonics 2021, 8(9), 402; https://doi.org/10.3390/photonics8090402 - 20 Sep 2021
Cited by 7 | Viewed by 2714
Abstract
As optical performance monitoring (OPM) requires accurate and robust solutions to tackle the increasing dynamic and complicated optical network architectures, we experimentally demonstrate an end-to-end optical signal-to-noise (OSNR) estimation method based on the convolutional neural network (CNN), named OptInception. The design principles of [...] Read more.
As optical performance monitoring (OPM) requires accurate and robust solutions to tackle the increasing dynamic and complicated optical network architectures, we experimentally demonstrate an end-to-end optical signal-to-noise (OSNR) estimation method based on the convolutional neural network (CNN), named OptInception. The design principles of the proposed scheme are specified. The idea behind the combination of the Inception module and finite impulse response (FIR) filter is elaborated as well. We experimentally evaluate the mean absolute error (MAE) and root-mean-squared error (RMSE) of the OSNR monitored in PDM-QPSK and PDM-16QAM signals under various symbol rates. The results suggest that the MAE reaches as low as 0.125 dB and RMSE is 0.246 dB in general. OptInception is also proved to be insensitive to the symbol rate, modulation format, and chromatic dispersion. The investigation of kernels in CNN indicates that the proposed scheme helps convolutional layers learn much more than a lowpass filter or bandpass filter. Finally, a comparison in performance and complexity presents the advantages of OptInception. Full article
(This article belongs to the Section Optical Communication and Network)
Show Figures

Figure 1

13 pages, 6462 KiB
Article
Study on Transmission Characteristics and Bandgap Types of Plasma Photonic Crystal
by Yichao Liang, Zhen Liu, Jun Peng, Liguang Lin, Rubing Lin and Qi Lin
Photonics 2021, 8(9), 401; https://doi.org/10.3390/photonics8090401 - 20 Sep 2021
Cited by 8 | Viewed by 2611
Abstract
A plasma photonic crystal (PPC) was formed using an array of discharge plasma tubes. The transmission spectra and bandstructure of PPCs with different lattice types under different polarization modes were studied through simulation and measurement. To study the types of bandgap in PPCs, [...] Read more.
A plasma photonic crystal (PPC) was formed using an array of discharge plasma tubes. The transmission spectra and bandstructure of PPCs with different lattice types under different polarization modes were studied through simulation and measurement. To study the types of bandgap in PPCs, the bandstructure of the PPC is calculated using symplectic finite difference time domain (SFDTD), a modified plane wave expansion (PWE) method, and a finite element method (FEM) based on weak form equations. The bandstructure of the PPC is compared with the transmission curve results. The results show that the bandgap is stable in the PPC, and the experimental and numerical results of the transmission spectra agree well. There are different types of bandgap in the PPC; the bandgap under TE-like polarization is caused by localized surface plasmon (LSP) and Bragg scattering. The bandgap under TM-like polarization is caused by the cutoff effect of plasma on the electromagnetic wave and Bragg scattering. The lattice type also affects the position and number of the bandgap. The three methods have their advantages and disadvantages when calculating bandstructure. Therefore, it is necessary to combine the results of three methods and experimental results to accurately determine the bandgap type of the PPC. Full article
(This article belongs to the Special Issue Photonic Devices and Systems)
Show Figures

Figure 1

16 pages, 3249 KiB
Article
SP-ILC: Concurrent Single-Pixel Imaging, Object Location, and Classification by Deep Learning
by Zhe Yang, Yu-Ming Bai, Li-Da Sun, Ke-Xin Huang, Jun Liu, Dong Ruan and Jun-Lin Li
Photonics 2021, 8(9), 400; https://doi.org/10.3390/photonics8090400 - 18 Sep 2021
Cited by 10 | Viewed by 2986
Abstract
We propose a concurrent single-pixel imaging, object location, and classification scheme based on deep learning (SP-ILC). We used multitask learning, developed a new loss function, and created a dataset suitable for this project. The dataset consists of scenes that contain different numbers of [...] Read more.
We propose a concurrent single-pixel imaging, object location, and classification scheme based on deep learning (SP-ILC). We used multitask learning, developed a new loss function, and created a dataset suitable for this project. The dataset consists of scenes that contain different numbers of possibly overlapping objects of various sizes. The results we obtained show that SP-ILC runs concurrent processes to locate objects in a scene with a high degree of precision in order to produce high quality single-pixel images of the objects, and to accurately classify objects, all with a low sampling rate. SP-ILC has potential for effective use in remote sensing, medical diagnosis and treatment, security, and autonomous vehicle control. Full article
(This article belongs to the Special Issue Smart Pixels and Imaging)
Show Figures

Figure 1

11 pages, 4222 KiB
Communication
Optical Detection of VOC Vapors Using Nb2O5 Bragg Stack in Transmission Mode
by Rosen Georgiev, Yoana Chorbadzhiyska, Venelin Pavlov, Biliana Georgieva and Tsvetanka Babeva
Photonics 2021, 8(9), 399; https://doi.org/10.3390/photonics8090399 - 18 Sep 2021
Cited by 1 | Viewed by 1918
Abstract
In this study, an emphasis is put on vapor-sensitive Bragg stacks as an important class of optical sensors. All-niobia Bragg stacks were deposited by spin-coating of sol-gel Nb2O5 thin films alternated with mesoporous layers after proper design through optimization of [...] Read more.
In this study, an emphasis is put on vapor-sensitive Bragg stacks as an important class of optical sensors. All-niobia Bragg stacks were deposited by spin-coating of sol-gel Nb2O5 thin films alternated with mesoporous layers after proper design through optimization of operating wavelength and number of layers in the stack. Mesoporous Nb2O5 films with different morphology and identical structure were obtained using organic templates (Pluronics PE6200 and PE6800) and subsequent annealing. Transmittance measurements were performed as a detection method that offers technological simplicity and accuracy. It was demonstrated that stacks including PE6200 templated films exhibit higher sensitivity than stacks templated with PE6800. It was assumed and verified by computer-aided modelling of experimental data that mesoporous films prepared with addition of PE6200, although less porous, were more stable compared to those templated with PE6800, and did not collapse during the thermal treatment of the stacks. Furthermore, the reproducibility of optical response was studied by sorption and desorption cycles of acetone vapors. The suitability of all-niobia Bragg stacks for optical sensing of VOCs was discussed. Full article
(This article belongs to the Special Issue Optical Sensing)
Show Figures

Figure 1

13 pages, 19575 KiB
Communication
A Novel Time Delay Estimation and Calibration Method of TI-ADC Based on a Coherent Optical Communication System
by Yongjie Zhao, Sida Li, Longqing Li and Zhiping Huang
Photonics 2021, 8(9), 398; https://doi.org/10.3390/photonics8090398 - 17 Sep 2021
Cited by 3 | Viewed by 2260
Abstract
In optical communication systems, coherent detection is a standard method. The received signal enters the digital domain after passing through a time-interleaved analog-to-digital converter (TI-ADC). However, the time delay of the ADC brings noise into the signal, which decreases the signal quality; therefore, [...] Read more.
In optical communication systems, coherent detection is a standard method. The received signal enters the digital domain after passing through a time-interleaved analog-to-digital converter (TI-ADC). However, the time delay of the ADC brings noise into the signal, which decreases the signal quality; therefore, ADC calibration is essential. At present, there are many calibration methods for time delay, but their performances are not satisfactory at a high sampling frequency. This paper presents a method of time delay estimation and calibration in a coherent optical communication system. First, the expected maximum (EM) method is used to roughly estimate the time delay and then transfer the estimated value into the trained back propagation (BP) neural network to generate more accurate results. Second, the sampled signal is reconstructed, and then a finite impulse response (FIR) filter is designed to compensate for the time delay. There are several advantages of the proposed method compared with previous works: the convergence with a BP network is faster, the estimation accuracy is higher, and the calibration does not affect the sample operation of the ADC working in the background mode. In addition, the proposed calibration method does not need additional circuits and its low power consumption provides more sources for dispersion compensation, error correction, and other subsequent operations in the coherent optical communication system. Based on the quadrature phase shift keying (QPSK) system, the proposed method was implemented in a 16-channel/8-bit, 40-GS/s ADC. After estimation and calibration, the relative error of estimation was below 1%, the signal noise distortion rate (SNDR) reached 55.9 dB, the spurious free dynamic range (SFDR) improved to 61.2 dB, and the effective number of bits (ENOB) was 6.7 bits. The results demonstrate that the proposed method has a better calibration performance than other methods. Full article
Show Figures

Figure 1

13 pages, 2191 KiB
Article
Accurate Imaging of Wide Beam Active Millimeter Wave Based on Angular Spectrum Theory and Simulation Verification
by Hua Zong, He Zhang and Jinghui Qiu
Photonics 2021, 8(9), 397; https://doi.org/10.3390/photonics8090397 - 17 Sep 2021
Cited by 2 | Viewed by 2116
Abstract
Due to the fact that a millimeter-wave (MMW) has a strong ability to penetrate clothing, MMW holographic imaging technology can conduct a non-contact inspection of the human body’s surface. In recent years, personnel surveillance systems utilizing MMW holographic imaging technology has achieved rapid [...] Read more.
Due to the fact that a millimeter-wave (MMW) has a strong ability to penetrate clothing, MMW holographic imaging technology can conduct a non-contact inspection of the human body’s surface. In recent years, personnel surveillance systems utilizing MMW holographic imaging technology has achieved rapid progress. However, limited by MMW holographic imaging’s image quality, the existing imaging technology cannot accurately detect whether the human body carries hidden objects. Additionally, real-time inspection requirements cannot be practically satisfied, and the system cost is relatively high. In this paper, a reconstruction algorithm with enhanced imaging quality, which can solve the problem of spherical wave attenuation with distance, making imaging results more accurate. The sampling conditions and imaging resolution are simulated and analyzed, which verify the azimuth resolution. Furthermore, the antenna beam’s holographic imaging simulation is optimized, effectively improving the quality of the reconstructed image. The proposed scheme provides theoretical support for determining antenna step and scanning aperture size in engineering and have theoretical guiding significance for improving the image quality of millimeter-wave holography and reducing system cost. Full article
Show Figures

Figure 1

16 pages, 4664 KiB
Communication
Passive Athermal Optical Design Method Considering Thermal-Induced Surface Deformation
by Tao Liu, Chong Wang, Yi Yu, Zhenyu Liu and Fengyun He
Photonics 2021, 8(9), 396; https://doi.org/10.3390/photonics8090396 - 16 Sep 2021
Cited by 6 | Viewed by 3563
Abstract
Temperature variation not only results in changes in refractive index, radius, thickness, and air space, but also leads to surface deformation due to the mismatch in thermal expansion coefficients between glass and mechanical materials. However, existing passive athermal optical design methods cannot optimize [...] Read more.
Temperature variation not only results in changes in refractive index, radius, thickness, and air space, but also leads to surface deformation due to the mismatch in thermal expansion coefficients between glass and mechanical materials. However, existing passive athermal optical design methods cannot optimize thermal-induced surface deformation, and optimization methods usually focus on structural optimization or thermal control rather than optical optimization. Here, we investigate the deterioration in image quality caused by thermal-induced surface deformation and propose a passive athermal optical design method to reduce deterioration. To this end, MATLAB was utilized to jointly call finite element analysis (FEA) software (COMSOL) and optical design software (Code V) to realize the data exchange of an optical–mechanical–thermal integrated analysis for iterative optical optimization. This process makes automatic iterative optimization possible by transforming parametric FEA results into Zernike coefficients in each iteration of optimization. The theoretical and design examples indicate that our method can effectively reduce the degradation in image quality with surface deformation. Our method provides an optical optimization approach for optical designers to work on a passive athermal optical design by considering thermal-induced surface deformation. Full article
(This article belongs to the Special Issue Optical Instrumentation)
Show Figures

Figure 1

17 pages, 10083 KiB
Article
Substrate Cleaning Threshold for Various Coated Al Alloys Using a Continuous-Wave Laser
by Xudong Sun, Qiansong Yu, Xiaoyu Bai, Guangyong Jin, Jixing Cai and Boshi Yuan
Photonics 2021, 8(9), 395; https://doi.org/10.3390/photonics8090395 - 16 Sep 2021
Cited by 7 | Viewed by 2760
Abstract
In this study, different coatings (gray epoxy primer, white epoxy varnish and red alkyd paint) of 7075 aluminum alloy are cleaned with a 500 W continuous-wave (CW) fiber laser. We analyzed the influence of the laser power density on the temperature evolution and [...] Read more.
In this study, different coatings (gray epoxy primer, white epoxy varnish and red alkyd paint) of 7075 aluminum alloy are cleaned with a 500 W continuous-wave (CW) fiber laser. We analyzed the influence of the laser power density on the temperature evolution and target surface morphology. Under the condition of continuous laser irradiation for 1 s, the experimental results indicated that the suitable cleaning thresholds of epoxy primer, epoxy primer and epoxy varnish, as well as epoxy primer, epoxy varnish and alkyd paint were 177.74, 192.89 and 147.44 W/mm2. The results show that the cleaning threshold of thicker three-layer paint target was smaller than the single-layer paint layer, and we analyze the mechanism of this phenomenon. Full article
(This article belongs to the Special Issue Photonic Devices and Systems)
Show Figures

Figure 1

19 pages, 4916 KiB
Article
Detection of Small Moving Objects in Long Range Infrared Videos from a Change Detection Perspective
by Chiman Kwan and Jude Larkin
Photonics 2021, 8(9), 394; https://doi.org/10.3390/photonics8090394 - 16 Sep 2021
Cited by 18 | Viewed by 3071
Abstract
Detection of small moving objects in long range infrared (IR) videos is challenging due to background clutter, air turbulence, and small target size. In this paper, we present two unsupervised, modular, and flexible frameworks to detect small moving targets. The key idea was [...] Read more.
Detection of small moving objects in long range infrared (IR) videos is challenging due to background clutter, air turbulence, and small target size. In this paper, we present two unsupervised, modular, and flexible frameworks to detect small moving targets. The key idea was inspired by change detection (CD) algorithms where frame differences can help detect motions. Our frameworks consist of change detection, small target detection, and some post-processing algorithms such as image denoising and dilation. Extensive experiments using actual long range mid-wave infrared (MWIR) videos with target distances beyond 3500 m from the camera demonstrated that one approach, using Local Intensity Gradient (LIG) only once in the workflow, performed better than the other, which used LIG in two places, in a 3500 m video, but slightly worse in 4000 m and 5000 m videos. Moreover, we also investigated the use of synthetic bands for target detection and observed promising results for 4000 m and 5000 m videos. Finally, a comparative study with two conventional methods demonstrated that our proposed scheme has comparable performance. Full article
(This article belongs to the Special Issue Near- and Mid-Infrared Photonics Technologies)
Show Figures

Figure 1

12 pages, 49841 KiB
Article
Characteristics of Spiral Patterns Formed by Coaxial Interference between Two Vortex Beams with Different Radii of Wavefront Curvatures
by Jingbo Ma, Peng Li and Yuzong Gu
Photonics 2021, 8(9), 393; https://doi.org/10.3390/photonics8090393 - 14 Sep 2021
Cited by 7 | Viewed by 3522
Abstract
Spiral pattern is formed for coaxial interference between two vortex beams with different radii of wavefront curvatures and different topological charges (TCs). A theoretical model considering various parameters (such as phase difference, radius of wavefront curvature, and TCs) is established to predict all [...] Read more.
Spiral pattern is formed for coaxial interference between two vortex beams with different radii of wavefront curvatures and different topological charges (TCs). A theoretical model considering various parameters (such as phase difference, radius of wavefront curvature, and TCs) is established to predict all kinds of interference patterns. An improved Mach-Zehnder interferometer is set up in an experiment to generate different kinds of spiral patterns and verify the theoretical model. The number of spiral lobes is determined by the absolute value of TCs’ difference between two vortex beams, and the twist direction relates to the sign of TCs’ difference and the difference of reciprocals for the radii of wavefront curvature, clockwise for the same sign, and counterclockwise for the opposite signs. The twist direction of the spiral pattern reverses and the lobes direction near the core of the pattern changes obviously when the spherical wave changes from convergence to divergence. Full article
Show Figures

Figure 1

14 pages, 3746 KiB
Article
Proposal of a Cascade Photonic Crystal XOR Logic Gate for Optical Integrated Circuits with Investigation of Fabrication Error and Optical Power Changes
by Ahmad Mohebzadeh-Bahabady and Saeed Olyaee
Photonics 2021, 8(9), 392; https://doi.org/10.3390/photonics8090392 - 14 Sep 2021
Cited by 8 | Viewed by 2693
Abstract
A compact and simple structure is designed to create an all-optical XOR logic gate using a two-dimensional, photonic crystal lattice. The structure was implemented using three waveguides connected by two nano-resonators. The plane wave expansion method was used to obtain the photonic band [...] Read more.
A compact and simple structure is designed to create an all-optical XOR logic gate using a two-dimensional, photonic crystal lattice. The structure was implemented using three waveguides connected by two nano-resonators. The plane wave expansion method was used to obtain the photonic band gap and the finite-difference time-domain method was used to investigate the behavior of the electromagnetic field in the photonic crystal structure. Examining the high contrast ratio and high-speed cascade, all-optical XOR on a chip, the effects of fabrication error and the changes in the input optical power showed that the structure could be used in optical integrated circuits. The contrast ratio and data transfer rate of the cascade XOR logic gate were respectively obtained as 44.29 dB and 1.5 Tb/s. In addition, the designed structure had very small dimensions at 158.65 μm2 and required very low power to operate, which made it suitable for low-power circuits. This structure could also be used as a NOT logic gate. Therefore, an XNOR logic gate can be designed using XOR and NOT logic gates. Full article
(This article belongs to the Special Issue Optoelectronics)
Show Figures

Figure 1

10 pages, 2333 KiB
Communication
Application of Visible Aquaphotomics for the Evaluation of Dissolved Chemical Concentrations in Aqueous Solutions
by Vladyslav Bozhynov, Zoltan Kovacs, Petr Cisar and Jan Urban
Photonics 2021, 8(9), 391; https://doi.org/10.3390/photonics8090391 - 14 Sep 2021
Cited by 2 | Viewed by 1682
Abstract
This paper introduces novel research in aquaphotomics, extending the study of water–light interactions to the visible spectral range. This approach can potentially reduce the cost and increase the speed of spectral measurements, while providing additional information by extending the useful range in spectrophotometry. [...] Read more.
This paper introduces novel research in aquaphotomics, extending the study of water–light interactions to the visible spectral range. This approach can potentially reduce the cost and increase the speed of spectral measurements, while providing additional information by extending the useful range in spectrophotometry. To demonstrate our method, we investigated the applicability of the visible spectral range for the quantification of NaCl dissolved in aqueous samples. Spectral measurements were conducted using a visible spectrometer in the range of 380–730 nm. The evaluation of molecular species concentration was based on multivariate analysis (MVA). Principal component analysis (PCA) showed a separation of all groups of samples by salt concentration. The partial least squares regression (PLSR) model presented high accuracy and a relationship between spectral variables in the visible range and NaCl concentration in water. The validity of the regression model was confirmed through independent prediction of NaCl concentration values in test samples with unknown concentrations. The presented results demonstrate the success of the approach in evaluating concentration changes in visible light, and thus extend the measurable spectral range of such analysis. Full article
Show Figures

Figure 1

14 pages, 4785 KiB
Article
Laser Fluorescence and Extinction Methods for Measuring the Flow and Composition of Milk in a Milking Machine
by Vladimir V. Kirsanov, Alexey V. Shkirin, Dmitriy Yu. Pavkin, Dmitry N. Ignatenko, Georgy L. Danielyan, Artyom R. Khakimov and Nikolai F. Bunkin
Photonics 2021, 8(9), 390; https://doi.org/10.3390/photonics8090390 - 14 Sep 2021
Cited by 5 | Viewed by 2575
Abstract
Automation of milking systems is linked to accurate measurement of fluctuations in milk flow during milking. To assess the fluctuations of the milk flow, the formation and movement of milk portions in the milking machine-milk pipeline system was studied. By considering the movement [...] Read more.
Automation of milking systems is linked to accurate measurement of fluctuations in milk flow during milking. To assess the fluctuations of the milk flow, the formation and movement of milk portions in the milking machine-milk pipeline system was studied. By considering the movement of a milk plug along the milk pipeline, a hydraulic model of the formation of a critical volume of milk in the milking machine manifold was compiled. In practice, the most expedient way of determining milk flow parameters may be to measure the laser fluorescent and extinction responses of moving air-milk mixture. We have implemented a new laser sensing method for measuring the flow rate and composition of milk on the basis of counting the optical response pulses received from moving dispersed components by a CCD array or a randomized fiber optic bundle. Using the developed laser sensors, the theoretical model of milk flow was tested. Full article
Show Figures

Figure 1

5 pages, 201 KiB
Editorial
Special Issue “Optical Fiber Interferometric Sensors: New Production Methodologies and Novel Applications”
by M. Fátima Domingues, Nélia Alberto and Paulo André
Photonics 2021, 8(9), 389; https://doi.org/10.3390/photonics8090389 - 14 Sep 2021
Viewed by 2076
Abstract
The collection of papers presented in this Special Issue (SI) portraits the state-of-the-art of photonic-based interferometric sensors, where new application areas were explored (such as spirometry) and novel sensitivity limits were achieved, using innovative sensing techniques for the monitoring of parameters, such as [...] Read more.
The collection of papers presented in this Special Issue (SI) portraits the state-of-the-art of photonic-based interferometric sensors, where new application areas were explored (such as spirometry) and novel sensitivity limits were achieved, using innovative sensing techniques for the monitoring of parameters, such as displacement, temperature or salinity. Full article
12 pages, 406 KiB
Communication
Statistics of the Optical Phase of a Gain-Switched Semiconductor Laser for Fast Quantum Randomness Generation
by Angel Valle
Photonics 2021, 8(9), 388; https://doi.org/10.3390/photonics8090388 - 13 Sep 2021
Cited by 4 | Viewed by 2601
Abstract
The statistics of the optical phase of the light emitted by a semiconductor laser diode when subject to periodic modulation of the applied bias current are theoretically analyzed. Numerical simulations of the stochastic rate equations describing the previous system are performed to describe [...] Read more.
The statistics of the optical phase of the light emitted by a semiconductor laser diode when subject to periodic modulation of the applied bias current are theoretically analyzed. Numerical simulations of the stochastic rate equations describing the previous system are performed to describe the temporal dependence of the phase statistics. These simulations are performed by considering two cases corresponding to random and deterministic initial conditions. In contrast to the Gaussian character of the phase that has been assumed in previous works, we show that the phase is not distributed as a Gaussian during the initial stages of evolution. We characterize the time it takes the phase to become Gaussian by calculating the dynamical evolution of the kurtosis coefficient of the phase. We show that, under the typical gain-switching with square-wave modulation used for quantum random number generation, quantity is in the ns time scale; that corresponds to the time it takes the system to lose the memory of the distribution of the initial conditions. We compare the standard deviation of the phase obtained with random and deterministic initial conditions to show that their differences become more important as the modulation speed is increased. Full article
(This article belongs to the Special Issue Nonlinear Dynamics of Semiconductor Lasers and Their Applications)
Show Figures

Figure 1

10 pages, 8878 KiB
Article
Adaptive Nonlinear Phase Compensation in a Femtosecond Hybrid Laser with Varying Pulse Repetition Rate
by Luka Černe, Jaka Petelin and Rok Petkovšek
Photonics 2021, 8(9), 387; https://doi.org/10.3390/photonics8090387 - 13 Sep 2021
Viewed by 2253
Abstract
In this manuscript, an implementation of a tunable nonlinear phase compensation method is demonstrated on a typical femtosecond hybrid laser consisting of a fiber pre-amplifier and an additional solid-state amplifier. This enables one to achieve constant laser pulse parameters over a wide range [...] Read more.
In this manuscript, an implementation of a tunable nonlinear phase compensation method is demonstrated on a typical femtosecond hybrid laser consisting of a fiber pre-amplifier and an additional solid-state amplifier. This enables one to achieve constant laser pulse parameters over a wide range of pulse repetition rates in such a laser. As the gain in the solid-state amplifier is inversely proportional to the input power, the shortfall in the solid-state gain at higher repetition rates must be compensated for with fiber pre-amplifier to ensure constant pulse energy. This increases the accumulated nonlinear phase and consequently alters the laser pulse parameters such as pulse duration and Strehl ratio. To overcome this issue, the nonlinear phase must be compensated for, and what is more it should be compensated for to a different extent at different pulse repetition rates. This is achieved with a tunable CFBG, used also as a pulse stretcher. Using this concept, we demonstrate that constant laser pulse parameters such as pulse energy, pulse duration and Strehl ratio can be achieved in a hybrid laser regardless of the pulse repetition rate. Full article
Show Figures

Figure 1

20 pages, 2576 KiB
Article
Y-Shaped Demultiplexer Photonic Circuits Based on Detuned Stubs: Application to Radiofrequency Domain
by Abdelkader Mouadili, Soufyane Khattou, Madiha Amrani, El Houssaine El Boudouti, Noureddine Fettouhi, Abdelkrim Talbi, Abdellatif Akjouj and Bahram Djafari-Rouhani
Photonics 2021, 8(9), 386; https://doi.org/10.3390/photonics8090386 - 11 Sep 2021
Cited by 3 | Viewed by 2192
Abstract
We present a theoretical and experimental study of photonic demultiplexers based on detuned stubs. The demultiplexers consist of Y-shaped structures with one input line and two output lines. Two different types of structures are proposed to achieve a selective transfer of a single [...] Read more.
We present a theoretical and experimental study of photonic demultiplexers based on detuned stubs. The demultiplexers consist of Y-shaped structures with one input line and two output lines. Two different types of structures are proposed to achieve a selective transfer of a single mode in one output line without disturbing the second one. (i) In the first platform each output contains two different stubs attached at two different sites (U-shaped resonators). We derive in closed form the geometrical parameters of the stubs to achieve a selected frequency in each line while keeping the other line unaffected. The frequency selection can be made on the basis of two different mechanisms, namely a Fano or an electromagnetic induced transparency (EIT) resonance. Consequently, different demultiplexing schemes can be designed by a combination of the two mechanisms, such as Fano-Fano, Fano-EIT or EIT-EIT. In particular, the width of the Fano or EIT resonances can become zero for an appropriate choice of the stubs’ lengths, giving rise to trapped modes also called bound in continuum states (BICs) with infinite quality factors. We also show that the crosstalk between the two outputs can reach minimum values around −45 dB. (ii) In the second platform, each output line contains a photonic comb with a defect stub. The latter is appropriately designed to filter one or a few frequencies in the bandgap of the photonic comb. The analytical calculations are performed with the help of the Green’s function method which enables us to derive the transmission and reflection coefficients as well as the density of states (DOS). These results are confirmed by experimental measurements using coaxial cables in the radio frequency domain. Full article
Show Figures

Figure 1

8 pages, 2884 KiB
Communication
Electrical Characterizations of 35-kV Semi-Insulating Gallium Arsenide Photoconductive Switch
by Cheng Ma, Meilin Wu, Wennan Wang, Yaqiong Jia and Wei Shi
Photonics 2021, 8(9), 385; https://doi.org/10.3390/photonics8090385 - 10 Sep 2021
Cited by 2 | Viewed by 2692
Abstract
In this paper, a three-layer GaAs photoconductive semiconductor switch (GaAs PCSS) is designed to withstand high voltage from 20 to 35 kV. The maximum avalanche gain and minimum on-state resistance of GaAs PCSS are 1385 and 0.58 Ω, respectively, which are the highest [...] Read more.
In this paper, a three-layer GaAs photoconductive semiconductor switch (GaAs PCSS) is designed to withstand high voltage from 20 to 35 kV. The maximum avalanche gain and minimum on-state resistance of GaAs PCSS are 1385 and 0.58 Ω, respectively, which are the highest values reported to date. Finally, the influence of the bias voltage on the avalanche stability is analyzed. The stability of the GaAs PCSS is evaluated and calculated. The results show that the jitter values at the bias voltages of 30 kV and 35 kV are 164.3 ps and 106.9 ps, respectively. This work provides guidance for the design of semiconductor switches with high voltage and high gain. Full article
Show Figures

Graphical abstract

16 pages, 1095 KiB
Article
Optical Amplification and Fast-Slow Light in a Three-Mode Cavity Optomechanical System without Rotating Wave Approximation
by Yan-Na Zhao, Tie Wang, Dong-Yang Wang, Xue Han, Shou Zhang and Hong-Fu Wang
Photonics 2021, 8(9), 384; https://doi.org/10.3390/photonics8090384 - 9 Sep 2021
Cited by 5 | Viewed by 2410
Abstract
We investigate the optical amplification of the output field and fast-slow light effect in a three-mode cavity optomechanical system without rotating wave approximation and discuss two ways of realizing the optical amplification effect. Resorting to the Coulomb coupling between the nanomechanical resonators, the [...] Read more.
We investigate the optical amplification of the output field and fast-slow light effect in a three-mode cavity optomechanical system without rotating wave approximation and discuss two ways of realizing the optical amplification effect. Resorting to the Coulomb coupling between the nanomechanical resonators, the asymmetric double optomechanically induced amplification effect can be achieved by utilizing the counterrotating term. Moreover, we find a remarkable optical amplification effect and observe the prominent fast-slow light effect at the singular point since the introduction of mechanical gain. Meanwhile, the transmission rate of the output field is increased by four orders of magnitude and the group delay time can reach in the order of 105μs. Our work is of great significance for the potential applications of optomechanically induced amplification in quantum information processing and quantum precision measurement. Full article
(This article belongs to the Special Issue Optomechanics: Science and Applications)
Show Figures

Figure 1

10 pages, 2128 KiB
Article
Deformation Measurements of Neuronal Excitability Using Incoherent Holography Lattice Light-Sheet Microscopy (IHLLS)
by Mariana Potcoava, Jonathan Art, Simon Alford and Christopher Mann
Photonics 2021, 8(9), 383; https://doi.org/10.3390/photonics8090383 - 9 Sep 2021
Cited by 7 | Viewed by 2337
Abstract
Stimuli to excitable cells and various cellular processes can cause cell surface deformations; for example, when excitable cell membrane potentials are altered during action potentials. However, these cellular changes may be at or below the diffraction limit (in dendrites the structures measured are [...] Read more.
Stimuli to excitable cells and various cellular processes can cause cell surface deformations; for example, when excitable cell membrane potentials are altered during action potentials. However, these cellular changes may be at or below the diffraction limit (in dendrites the structures measured are as small as 1 µm), and imaging by traditional methods is challenging. Using dual lenses incoherent holography lattice light-sheet (IHLLS-2L) detection with holographic phase imaging of selective fluorescent markers, we can extract the full-field cellular morphology or structural changes of the object’s phase in response to external stimulus. This approach will open many new possibilities in imaging neuronal activity and, overall, in light sheet imaging. In this paper, we present IHLLS-2L as a well-suited technique for quantifying cell membrane deformation in neurons without the actuation of a sample stage or detection microscope objective. Full article
(This article belongs to the Special Issue Holography)
Show Figures

Figure 1

11 pages, 2263 KiB
Communication
All-Fiber Gas Raman Laser by D2-Filled Hollow-Core Photonic Crystal Fibers
by Wenxi Pei, Hao Li, Wei Huang, Meng Wang and Zefeng Wang
Photonics 2021, 8(9), 382; https://doi.org/10.3390/photonics8090382 - 9 Sep 2021
Cited by 5 | Viewed by 2434
Abstract
We report here an all-fiber structure tunable gas Raman laser based on deuterium-filled hollow-core photonic crystal fibers (HC-PCFs). An all-fiber gas cavity is fabricated by fusion splicing a 49 m high-pressure deuterium-filled HC-PCF with two solid-core single-mode fibers at both ends. When pumped [...] Read more.
We report here an all-fiber structure tunable gas Raman laser based on deuterium-filled hollow-core photonic crystal fibers (HC-PCFs). An all-fiber gas cavity is fabricated by fusion splicing a 49 m high-pressure deuterium-filled HC-PCF with two solid-core single-mode fibers at both ends. When pumped with a pulsed fiber amplifier seeded by a tunable laser diode at 1.5 μm, Raman lasers ranging from 1643 nm to 1656 nm are generated. The maximum output power is ~1.2 W with a Raman conversion efficiency of ~45.6% inside the cavity. This work offers an alternative choice for all-fiber lasers operating at 1.6–1.7 μm band. Full article
(This article belongs to the Special Issue Novel Specialty Optical Fibers and Applications)
Show Figures

Figure 1

12 pages, 5165 KiB
Article
Aerial Projection 3D Display Based on Integral Imaging
by Wu-Xiang Zhao, Han-Le Zhang, Qing-Lin Ji, Huan Deng and Da-Hai Li
Photonics 2021, 8(9), 381; https://doi.org/10.3390/photonics8090381 - 9 Sep 2021
Cited by 6 | Viewed by 3455
Abstract
We proposed an aerial projection 3D display based on integral imaging. It is composed of a projector, a lens-array holographic optical element (HOE), and two parabolic mirrors. The lens-array HOE is a diffraction grating and is made by the volume holography technique. The [...] Read more.
We proposed an aerial projection 3D display based on integral imaging. It is composed of a projector, a lens-array holographic optical element (HOE), and two parabolic mirrors. The lens-array HOE is a diffraction grating and is made by the volume holography technique. The lens-array HOE can be produced on a thin glass plate, and it has the optical properties of a lens array when the Bragg condition is satisfied. When the display beams of the element image array (EIA) are projected on the lens-array HOE, 3D images can be reconstructed. The two parabolic mirrors can project 3D images into the air. The Bragg-unmatched light simply passes through the lens-array HOE. Therefore, the aerial projection 3D images appear to be imaged in the air without any medium. In the experiment, a BenQ projector was used for the projection of 3D images, with a resolution of 1600 × 1200. The diameter and the height of each parabolic mirror are 150 mm and 25 mm, respectively. The inner diameter of the parabolic mirror is 40 mm. The 3D images were projected in the air, and the experimental results prove the correctness of our display system. Full article
(This article belongs to the Special Issue Smart Pixels and Imaging)
Show Figures

Figure 1

13 pages, 2910 KiB
Article
Performance Enhancement of Opened Resonance Photoacoustic Cells Based on Three Dimensional Topology Optimization
by Zihao Tang, Wenjun Ni, Zehao Li, Jin Hou, Shaoping Chen, Perry Ping Shum and Chunyong Yang
Photonics 2021, 8(9), 380; https://doi.org/10.3390/photonics8090380 - 9 Sep 2021
Cited by 3 | Viewed by 2192
Abstract
Photoacoustic (PA) spectroscopy techniques enable the detection of trace substances. However, lower threshold detection requirements are increasingly common in practical applications. Thus, we propose a systematic geometry topology optimization approach on a PA cell to enhance the intensity of its detection signal. The [...] Read more.
Photoacoustic (PA) spectroscopy techniques enable the detection of trace substances. However, lower threshold detection requirements are increasingly common in practical applications. Thus, we propose a systematic geometry topology optimization approach on a PA cell to enhance the intensity of its detection signal. The model of topology optimization and pressure acoustics in the finite element method was exploited to construct a PA cell and then acquire the optimal structure. In the assessment, a thermo-acoustic model was constructed to properly simulate the frequency response over the range of 0–70 kHz and the temperature field distribution. The simulation results revealed that the acoustic gain of the optimized cell was 2.7 and 1.3 times higher than conventional cells near 25 and 52 kHz, respectively. Moreover, the optimized PA cell achieved a lower threshold detection over a wide frequency range. Ultimately, this study paves a new way for designing and optimizing the geometry of multifarious high-sensitivity PA sensors. Full article
(This article belongs to the Section Lasers, Light Sources and Sensors)
Show Figures

Figure 1

13 pages, 1958 KiB
Article
Sensitivity Enhanced Refractive Index Fiber Sensor Based on Long-Range Surface Plasmon Resonance in SiO2-Au-TiO2 Heterostructure
by Wenyi Bu, Zhifang Wu, Perry Ping Shum, Xuguang Shao and Jixiong Pu
Photonics 2021, 8(9), 379; https://doi.org/10.3390/photonics8090379 - 9 Sep 2021
Cited by 9 | Viewed by 2816
Abstract
Long-range surface plasmon resonance (LRSPR), generated from a coupled plasmon polariton in a thin metal slab sandwiched by two dielectrics, has attracted more and more attention due to its merits, such as longer propagation and deeper penetration than conventional single-interface surface plasmon resonance. [...] Read more.
Long-range surface plasmon resonance (LRSPR), generated from a coupled plasmon polariton in a thin metal slab sandwiched by two dielectrics, has attracted more and more attention due to its merits, such as longer propagation and deeper penetration than conventional single-interface surface plasmon resonance. Many useful applications related to light–medium interaction have been demonstrated based on the LRSPR effect, especially in the sensing area. Here, we propose and demonstrate an LRSPR-based refractive index sensor by using a SiO2-Au-TiO2 heterostructure, in which a D-shaped honeycomb-microstructure optical fiber (MOF) is designed as the silica substrate and then deposited with a gold film and thin-layer titanium dioxide (TiO2). By using the full-vector finite-element method (FEM), this heterostructure is numerically investigated and demonstrated to excite LRSPR without a buffer layer, which is usually necessary in previous LRSPR devices. Through comprehensive discussion about the influence of structural parameters on the resonant wavelength, the excitation of the LRSPR in the proposed heterostructure is revealed to be highly related to the effective refractive index of MOF’s fundamental core mode, which is mainly determined by the MOF’s pitch, the thicknesses of the silica web and the planar-layer silica. Moreover, the thin-layer TiO2 plays an important role in significantly enhancing the resonance and the sensitivity to analyte’s refractive index as well, when it is coated on the top of the Au film rather than between the metal and waveguide. Finally, the proposed LRSPR sensor based on SiO2-Au-TiO2 heterostructure shows an ultra-high wavelength sensitivity of 20,100 nm/RIU and the corresponding minimum resolution is as low as 4.98×107 RIU. Thus, the proposed LRSPR device offers considerable potential for sensing applications in biomedical and biochemical areas. Full article
(This article belongs to the Special Issue Novel Specialty Optical Fibers and Applications)
Show Figures

Figure 1

11 pages, 1846 KiB
Article
Generation of Energetic Highly Elliptical Extreme Ultraviolet Radiation
by Emmanouil Vassakis, Ioannis Orfanos, Ioannis Liontos and Emmanouil Skantzakis
Photonics 2021, 8(9), 378; https://doi.org/10.3390/photonics8090378 - 9 Sep 2021
Cited by 4 | Viewed by 2658
Abstract
In this study, the generation of energetic coherent extreme ultraviolet (XUV) radiation with the potential for controlled polarization is reported. The XUV radiation results from the process of high harmonic generation (HHG) in a gas phase atomic medium, driven by an intense two-color [...] Read more.
In this study, the generation of energetic coherent extreme ultraviolet (XUV) radiation with the potential for controlled polarization is reported. The XUV radiation results from the process of high harmonic generation (HHG) in a gas phase atomic medium, driven by an intense two-color circularly polarized counter-rotating laser field, under loose focusing geometry conditions. The energy of the XUV radiation emitted per laser pulse is found to be of the order of ~100 nJ with the spectrum spanning from 17 to 26 eV. The demonstrated energy values (along with tight XUV focusing geometries) are sufficient to induce nonlinear processes. Our results challenge current perspectives regarding ultrafast investigations of chiral phenomena in the XUV spectral region. Full article
(This article belongs to the Special Issue Extreme-Ultraviolet and X-ray Optics)
Show Figures

Figure 1

10 pages, 22145 KiB
Communication
Study on Aberration Correction of Adaptive Optics Based on Convolutional Neural Network
by Jin Li, Luwei Wang, Yong Guo, Yangrui Huang, Zhigang Yang, Wei Yan and Junle Qu
Photonics 2021, 8(9), 377; https://doi.org/10.3390/photonics8090377 - 8 Sep 2021
Cited by 2 | Viewed by 2946
Abstract
The existence of aberrations has always been an important limiting factor in the imaging field. Especially in optical microscopy imaging, the accumulated aberration of the optical system and the biological samples distorts the wavefront on the focal plane, thereby reducing the imaging resolution. [...] Read more.
The existence of aberrations has always been an important limiting factor in the imaging field. Especially in optical microscopy imaging, the accumulated aberration of the optical system and the biological samples distorts the wavefront on the focal plane, thereby reducing the imaging resolution. Here, we propose an adaptive optical aberration correction method based on convolutional neural network. By establishing the relationship between the Zernike polynomial and the distorted wavefront, with the help of the fast calculation advantage of an artificial intelligence neural network, the distorted wavefront information can be output in a short time for the reconstruction of the wavefront to achieve the purpose of improving imaging resolution. Experimental results show that this method can effectively compensate the aberrations introduced by the system, agarose and HeLa cells. After correcting, the point spread function restored the doughnut-shape, and the resolution of the HeLa cell image increased about 20%. Full article
(This article belongs to the Special Issue Adaptive Optics for Biological Imaging)
Show Figures

Figure 1

19 pages, 5851 KiB
Article
Image Restoration Based on End-to-End Unrolled Network
by Xiaoping Tao, Hao Zhou and Yueting Chen
Photonics 2021, 8(9), 376; https://doi.org/10.3390/photonics8090376 - 8 Sep 2021
Cited by 5 | Viewed by 2977
Abstract
Recent studies on image restoration (IR) methods under unrolled optimization frameworks have shown that deep convolutional neural networks (DCNNs) can be implicitly used as priors to solve inverse problems. Due to the ill-conditioned nature of the inverse problem, the selection of prior knowledge [...] Read more.
Recent studies on image restoration (IR) methods under unrolled optimization frameworks have shown that deep convolutional neural networks (DCNNs) can be implicitly used as priors to solve inverse problems. Due to the ill-conditioned nature of the inverse problem, the selection of prior knowledge is crucial for the process of IR. However, the existing methods use a fixed DCNN in each iteration, and so they cannot fully adapt to the image characteristics at each iteration stage. In this paper, we combine deep learning with traditional optimization and propose an end-to-end unrolled network based on deep priors. The entire network contains several iterations, and each iteration is composed of analytic solution updates and a small multiscale deep denoiser network. In particular, we use different denoiser networks at different stages to improve adaptability. Compared with a fixed DCNN, it greatly reduces the number of computations when the total parameters are equal and the number of iterations is the same, but the gains from a practical runtime are not as significant as indicated in the FLOP count. The experimental results of our method of three IR tasks, including denoising, deblurring, and lensless imaging, demonstrate that our proposed method achieves state-of-the-art performances in terms of both visual effects and quantitative evaluations. Full article
(This article belongs to the Special Issue Smart Pixels and Imaging)
Show Figures

Figure 1

19 pages, 6115 KiB
Article
Design and Simulation of Terahertz Perfect Absorber with Tunable Absorption Characteristic Using Fractal-Shaped Graphene Layers
by Amir Maghoul, Ali Rostami, Nilojan Gnanakulasekaran and Ilangko Balasingham
Photonics 2021, 8(9), 375; https://doi.org/10.3390/photonics8090375 - 7 Sep 2021
Cited by 7 | Viewed by 2674
Abstract
Graphene material, due to its unique conductivity and transparency properties, is utilized extensively in designing tunable terahertz perfect absorbers. This paper proposes a framework to design a tunable terahertz perfect absorber based on fractal triangle-shaped graphene layers embedded into dielectric substrates with the [...] Read more.
Graphene material, due to its unique conductivity and transparency properties, is utilized extensively in designing tunable terahertz perfect absorbers. This paper proposes a framework to design a tunable terahertz perfect absorber based on fractal triangle-shaped graphene layers embedded into dielectric substrates with the potential for spectral narrowing and widening of the absorption response without the need for geometric manipulation. In this way, the absorption cross-section spectra of the suggested configurations are achieved over the absorption band. First, the defection impact on the single-layer fractal triangle-shaped graphene structure inserted in insulators of the absorber is evaluated. Then, a flexible tunability of the absorbance’s peak is indicated by controlling the Fermi energy. By stacking fractal graphene sheets as a double graphene layer configuration in both the same and cross-states positioning, it is demonstrated that the absorption characteristics can be switched at 6–8 THz with a stronger amplitude, and 16–18 THz with a lower intensity. The impact of changing the Fermi potentials of embedded graphene layers is yielded, resulting in a plasmonic resonance shift and a significant broadening of the absorption bandwidth of up to five folds. Following, the absorption spectra related to the fractal triangle-shaped structures consist of a multi-stage architecture characterized by a spectral response experiencing a multiband absorbance rate and an absorption intensity of over 8 × 106 nm2 in a five-stage perfect absorber. Ultimately, the variations of the absorbance parameter and plasmonic mode under rotating the graphene sheet are explored for single and double fractal triangle-shaped perfect configurations on the absorption band. The presented mechanism demonstrates the tunability of the absorption spectrum in terms of narrowing or broadening and switching the plasmonic resonance by configuring multi-stage structures that can employ a broad range of applications for sensory devices. Full article
Show Figures

Figure 1

Previous Issue
Next Issue
Back to TopTop
