Aiming at the structural lightweight design of a 700 mm aperture primary mirror for a space camera, a novel success history-based adaptive multi-objective differential evolution algorithm with dynamic constraint handling is proposed to solve the multi-objective optimization problem of simultaneously minimizing mass and compliance under strict constraints for surface error and first-order modal frequency. Firstly, a surrogate model for the mirror was constructed using the Kriging algorithm based on Optimal Latin Hypercube Sampling, establishing a mapping relationship between input design variables and output responses, thereby replacing computationally expensive finite element simulations. Subsequently, a dynamic constraint adjustment mechanism was introduced into the Success History-based Adaptive Multi-Object Differential Evolution algorithm for the surrogate model, dynamically relaxing and tightening constraint violation requirements during iteration. This allows for utilizing promising yet infeasible solutions for rapid convergence while ensuring the feasibility of the final solutions. Comparisons with 13 advanced constrained multi-objective optimization algorithms demonstrate that the proposed algorithm exhibits excellent convergence, diversity, and consistency. Finally, the optimal solution was selected from the Pareto front obtained by the proposed algorithm, and the design variable values were adjusted according to manufacturing constraints to yield the final optimization result, which was then verified by finite element simulation. The simulation results show that the final mirror structure meets all performance constraints, demonstrating the effectiveness and engineering applicability of the proposed algorithm for the structural lightweight design of space camera mirrors.

To address the problems of insufficient light energy utilization and light leakage in existing concentrator lighting systems, this paper proposes a novel Stepped Integrated No-Leakage Concentrator Lighting System. This system adopts a design that combines a concentrator module array with a stepped light guide plate. By constructing a stepped integrated concentrator structure and a composite parabolic coupling configuration, the system enables efficient solar energy collection and delivery, significantly improving concentration efficiency and energy utilization. First, based on the principles of geometric optics, theoretical modeling of the concentrator modules and light guide plate was conducted. The relationships among the paraboloid coefficient, step height of the light guide plate, and the number of concentrator modules were analyzed to clarify their influence on the geometric concentration ratio and concentration efficiency of the system. Subsequently, optical performance simulations under varying structural parameters were performed using a joint simulation platform based on SolidWorks Premium 2024 SP5.0 and LightTools(64) 8.6.0 Copyright (c) 1994-2018 Synopsys, Inc. The results indicate that the proposed structure achieves excellent light-guiding performance and high optical efficiency, with a maximum concentration efficiency of 94% and a geometric concentration ratio of 50. On this basis, a physical prototype was fabricated, and experimental testing was carried out. The results validated the accuracy of the simulation, with the system reaching a concentration efficiency of 54.6% at noon, further confirming the feasibility and superior performance of the proposed design. This study demonstrates that the Stepped Integrated No-Leakage Concentrator Lighting System offers significant advantages in enhancing light energy utilization and reducing leakage losses, providing an efficient solution for natural daylighting and interior illumination in green buildings.

The Nd:GYSAG crystal enables multi-wavelength near-infrared laser output, with adjustable wavelengths tailored for specific application requirements, making it highly valuable for space-borne water vapor detection. This study reports, for the first time, the side-pumping characteristics and electro-optical Q-switching performance of this crystal. Using Ø3 × 73 mm and Ø4 × 73 mm crystal rods doped with 1.21 at.% Nd:GYSAG (chemical formula Nd_0.033Gd_0.93Y_1.79Sc_0.70Al_4.54O_11.99), 1060.4 nm laser output was achieved under 808 nm laser diode (LD) side-pumping at a repetition rate of 100 Hz and a pump pulse width of 250 μs. The experimental results show that the Ø4 × 73 mm rod had a higher laser threshold but exhibited significantly superior slope efficiency and maximum output power compared to the Ø3 × 73 mm rod. Using a flat–flat resonator, optimal laser performance was obtained with an output coupler transmission of 35%, yielding a slope efficiency of 37.2%. A maximum output energy of 179.4 mJ was achieved at a pump energy of 646 mJ. Thermal lensing effects were compensated using a flat–convex cavity, leading to improved laser performance and beam quality. Electro-optical Q-switching experiments were conducted using a KD*P crystal. A comparison between voltage-applied and voltage-removed Q-switching techniques revealed superior performance for the voltage-applied method. High-performance laser output was realized, achieving a maximum pulse energy of 59.6 mJ, a pulse width of 14.93 ns, and a peak power of 3.99 MW. This study provides an important foundation for the development of near-infrared laser devices based on Nd:GYSAG.
