Fluids, Volume 7, Issue 7 (July 2022) – 42 articles

Cover Story (view full-size image): The aim of the present manuscript is to investigate the noise footprint, in propulsive and energy harvesting configurations, of a propeller for the propulsion of a hybrid electric aircraft. The frequency domain analysis reveals a significant modification in the nature of the noise source. In a propulsive configuration, most of the energy is related to the tonal noise; on the other hand, in an energy harvesting configuration, the broadband noise component increases significantly compared to the propulsive mode. In addition, an innovative strategy for tonal and broadband noise decomposition, based on proper orthogonal decomposition (POD), has been defined. This algorithm shows promising results; in fact, in both the time and the Fourier domain, the two reconstructed components perfectly describe the original signal. View this paper
  • Issues are regarded as officially published after their release is announced to the table of contents alert mailing list.
  • You may sign up for e-mail alerts to receive table of contents of newly released issues.
  • PDF is the official format for papers published in both, html and pdf forms. To view the papers in pdf format, click on the "PDF Full-text" link, and use the free Adobe Reader to open them.
Order results
Result details
Section
Select all
Export citation of selected articles as:
21 pages, 7580 KiB
Article
The Effects of Compressibility on the Performance and Modal Structures of a Sweeping Jet Emitted from Various Scales of a Fluidic Oscillator
by Daniel J. Portillo, Eugene Hoffman, Matt Garcia, Elijah LaLonde, Christopher Combs and R. Lyle Hood
Fluids 2022, 7(7), 251; https://doi.org/10.3390/fluids7070251 - 21 Jul 2022
Cited by 2 | Viewed by 2084
Abstract
Investigations of fluidic oscillators, or sweeping jet actuators, have primarily been conducted within the incompressible flow regime, which limits the accuracy of estimating fluidic oscillator performance for compressible flows. The objective of this study was to evaluate the effects of gas compressibility on [...] Read more.
Investigations of fluidic oscillators, or sweeping jet actuators, have primarily been conducted within the incompressible flow regime, which limits the accuracy of estimating fluidic oscillator performance for compressible flows. The objective of this study was to evaluate the effects of gas compressibility on the performance of a fluidic oscillator. A commonly used fluidic oscillator geometry (the Bray geometry) was scaled to five different sizes, 3D printed, and tested over a range of air flow rates. High-speed Schlieren images captured the sweeping jet exiting the fluidic oscillators, and custom MATLAB algorithms were used to calculate the oscillation frequencies and angles. A spectral proper orthogonal decomposition (SPOD) method was used to identify and compare the mode structures within the flow fields. All the results were compared using dimensionless parameters to observe performance trends. The results showed that the oscillation frequencies were directly proportional to the flow rate, while the oscillation angles were inversely proportional to the flow rate, regardless of scale size. The angular velocities were not proportional to the flow rate or scale size and exhibited maxima within the evaluated ranges. For all scale sizes, the mode structures were symmetric across the centerlines of the fluidic oscillators and extended further beyond the fluidic oscillators at higher flow rates. These results enable the prediction of fluidic oscillator performance, which can significantly improve the design process for an application where a fluidic oscillator may be used, such as aerospace applications, power generation, heat exchangers, or medical devices. Full article
Show Figures

Figure 1

14 pages, 5885 KiB
Article
Numerical Characterization of the Flow Dynamics and COP Estimation of a Binary Fluid Ejector Ground Source Heat Pump Cooling System
by Mouhammad El Hassan
Fluids 2022, 7(7), 250; https://doi.org/10.3390/fluids7070250 - 20 Jul 2022
Cited by 5 | Viewed by 1712
Abstract
Ejector-based refrigeration systems can make direct use of many forms of thermal energy, such as solar thermal, waste heat, biogas, or natural gas. The present paper describes the estimation of the thermal coefficient of performance (COP) of a binary fluid ejector ground source [...] Read more.
Ejector-based refrigeration systems can make direct use of many forms of thermal energy, such as solar thermal, waste heat, biogas, or natural gas. The present paper describes the estimation of the thermal coefficient of performance (COP) of a binary fluid ejector ground source heat pump (BFE GSHP) cooling system. A method for fluid selection was defined based on the favorable thermo-physical properties of the working fluids. A short list of fluid pairs were selected based on their favorable properties for the BFE GSHP cooling system. Computational Fluid Dynamics (CFD) investigation was conducted for the selected fluid pairs and a suitable ejector geometry is proposed for the high compression ratios encountered in the GSHP applications. The mixing between primary and secondary fluids was investigated using physical analysis of the CFD results. The effect of the fluids’ thermo-physical properties on the system performance was also discussed. Full article
Show Figures

Figure 1

15 pages, 1462 KiB
Article
Riblet Drag Reduction Modeling and Simulation
by Benedetto Mele
Fluids 2022, 7(7), 249; https://doi.org/10.3390/fluids7070249 - 19 Jul 2022
Cited by 7 | Viewed by 2981
Abstract
One of the most interesting passive drag reduction techniques is based on the use of riblets or streamwise grooved surfaces. Detailed flow features inside the grooves can be numerically detected only by Direct Numerical Simulations (DNS), still unfeasible for high Reynolds numbers and [...] Read more.
One of the most interesting passive drag reduction techniques is based on the use of riblets or streamwise grooved surfaces. Detailed flow features inside the grooves can be numerically detected only by Direct Numerical Simulations (DNS), still unfeasible for high Reynolds numbers and complex flows. Many papers report the DNS of flows on microgrooved surfaces providing fundamental details on the drag reduction devices, but all are limited to plate or channel flows far from engineering Reynolds numbers. The numerical simulation of riblets and other drag reduction devices at very high Reynolds numbers is difficult to perform due to the riblet dimensions (microns in aeronautical applications). To overcome these difficulties, some models for riblet simulation have been developed in recent years, due to the data provided by DNS, experiments, and theoretical analyses. In all these models, the drag reduction is modeled rather than effectively captured; however, the analysis of some nonlocal effects on practical aeronautical configurations with riblets, requires their adoption. In this paper, the capabilities of these models in predicting riblets’ performance and some interesting features of the riblets’ effect on form drag and shock waves are shown. Two models are discussed and compared showing their respective advantages and limitations and providing possible enhancements. A comparison between the two models in terms of accuracy and convergence is discussed, and two new formulae are proposed to improve one of these models. Finally, a review of the results obtained by the two models is provided showing their capabilities in the analysis of the riblet effect on complex configurations. Full article
(This article belongs to the Special Issue Drag Reduction in Turbulent Flows)
Show Figures

Figure 1

19 pages, 3751 KiB
Article
CHP-Based Economic Emission Dispatch of Microgrid Using Harris Hawks Optimization
by Vimal Tiwari, Hari Mohan Dubey, Manjaree Pandit and Surender Reddy Salkuti
Fluids 2022, 7(7), 248; https://doi.org/10.3390/fluids7070248 - 18 Jul 2022
Cited by 9 | Viewed by 1813
Abstract
In this paper, the economically self-sufficient microgrid is planned to provide electric power and heat demand. The combined heat and power-based microgrid needs strategic placement of distributed generators concerning optimal size, location, and type. As fossil fuel cost and emission depend mainly on [...] Read more.
In this paper, the economically self-sufficient microgrid is planned to provide electric power and heat demand. The combined heat and power-based microgrid needs strategic placement of distributed generators concerning optimal size, location, and type. As fossil fuel cost and emission depend mainly on the types of distributed generator units used in the microgrid, economic emission dispatch is performed for an hour with a static load demand and multiple load demands over 24 h of a day. The TOPSIS ranking approach is used as a tool to obtain the best compromise solution. Harris Hawks Optimization (HHO) is used to solve the problem. For validation, the obtained results in terms of cost, emission, and heat are compared with the reported results by DE and PSO, which shows the superiority of HHO over them. The impact of renewable integration in terms of cost and emission is also investigated. With renewable energy integration, fuel cost is reduced by 18% and emission is reduced by 3.4% for analysis under static load demand, whereas for the multiple load demands over 24 h, fuel cost is reduced by 14.95% and emission is reduced by 5.58%. Full article
(This article belongs to the Special Issue Wind and Wave Renewable Energy Systems, Volume II)
Show Figures

Figure 1

23 pages, 1089 KiB
Article
Electrohydrodynamic Liquid Sheet Instability of Moving Viscoelastic Couple-Stress Dielectric Fluid Surrounded by an Inviscid Gas through Porous Medium
by Mohamed Fahmy El-Sayed and Agaeb Mahal Alanzi
Fluids 2022, 7(7), 247; https://doi.org/10.3390/fluids7070247 - 18 Jul 2022
Cited by 1 | Viewed by 1925
Abstract
Viscoelastic liquid sheet of couple-stress type streaming with relative motion into an inviscid gas through porous molium is studied theoretically and quantitatively in this project. To derive the differential equations that describe liquids, gases, and the electric field, we linearized the governing equations [...] Read more.
Viscoelastic liquid sheet of couple-stress type streaming with relative motion into an inviscid gas through porous molium is studied theoretically and quantitatively in this project. To derive the differential equations that describe liquids, gases, and the electric field, we linearized the governing equations of motion and continuity, Maxwell’s equations in quasi-static approximation, and the appropriate boundary conditions at the two interfaces. Then we used the normal mode method. It was demonstrated analytically that the solutions to these differential equations can be found for both symmetric and antisymmetric disturbances, respectively. We could not obtain an explicit form of the growth rates since we could not solve the dispersion relations for both situations because they were obtained in highly complex forms. The Mathematica program is used to solve the dimensionless forms of the dispersion relations numerically using Gaster’s theorem. Various influences on the stability analysis of the considered system have been studied in detail, and it is determined that the system in the presence of a porous material is more unstable than it would be otherwise. In a two-dimensional system, the antisymmetric disturbance case is found to be more unstable than the corresponding symmetric disturbance situation. Some characteristics, such as Wabe number, Ohnesorge number, and electric field, have destabilizing effects, whereas others, such as porosity, medium permeability, viscoelasticity parameter, gas-to-liquid viscosity ratio, and dielachic constants, have stabilizing effects. Finally, it is discovered that the gas-to-liquid velocity ratio plays a dual role in the stability condition depending on whether the gas-to-liquid velocity ratio U ≶ 1. In the past, we have only found evidence of very few previous studies. Full article
(This article belongs to the Topic Fluid Mechanics)
Show Figures

Figure 1

16 pages, 2983 KiB
Review
Advances in CFD Modeling of Urban Wind Applied to Aerial Mobility
by Adrián García-Gutiérrez, Jesús Gonzalo, Deibi López and Adrián Delgado
Fluids 2022, 7(7), 246; https://doi.org/10.3390/fluids7070246 - 18 Jul 2022
Cited by 5 | Viewed by 3036
Abstract
The feasibility, safety, and efficiency of a drone mission in an urban environment are heavily influenced by atmospheric conditions. However, numerical meteorological models cannot cope with fine-grained grids capturing urban geometries; they are typically tuned for best resolutions ranging from 1 to 10 [...] Read more.
The feasibility, safety, and efficiency of a drone mission in an urban environment are heavily influenced by atmospheric conditions. However, numerical meteorological models cannot cope with fine-grained grids capturing urban geometries; they are typically tuned for best resolutions ranging from 1 to 10 km. To enable urban air mobility, new now-casting techniques are being developed based on different techniques, such as data assimilation, variational analysis, machine-learning algorithms, and time series analysis. Most of these methods require generating an urban wind field database using CFD codes coupled with the mesoscale models. The quality and accuracy of that database determines the accuracy of the now-casting techniques. This review describes the latest advances in CFD simulations applied to urban wind and the alternatives that exist for the coupling with the mesoscale model. First, the distinct turbulence models are introduced, analyzing their advantages and limitations. Secondly, a study of the meshing is introduced, exploring how it has to be adapted to the characteristics of the urban environment. Then, the several alternatives for the definition of the boundary conditions and the interpolation methods for the initial conditions are described. As a key step, the available order reduction methods applicable to the models are presented, so the size and operability of the wind database can be reduced as much as possible. Finally, the data assimilation techniques and the model validation are presented. Full article
(This article belongs to the Special Issue Aerodynamics and Aeroacoustics of Vehicles, Volume II)
Show Figures

Graphical abstract

12 pages, 1179 KiB
Article
Volumetric Rendering on Wavelet-Based Adaptive Grid
by Alexei V. Vezolainen, Gordon Erlebacher, Oleg V. Vasilyev and David A. Yuen
Fluids 2022, 7(7), 245; https://doi.org/10.3390/fluids7070245 - 16 Jul 2022
Viewed by 2244
Abstract
Numerical modeling of physical phenomena frequently involves processes across a wide range of spatial and temporal scales. In the last two decades, the advancements in wavelet-based numerical methodologies to solve partial differential equations, combined with the unique properties of wavelet analysis to resolve [...] Read more.
Numerical modeling of physical phenomena frequently involves processes across a wide range of spatial and temporal scales. In the last two decades, the advancements in wavelet-based numerical methodologies to solve partial differential equations, combined with the unique properties of wavelet analysis to resolve localized structures of the solution on dynamically adaptive computational meshes, make it feasible to perform large-scale numerical simulations of a variety of physical systems on a dynamically adaptive computational mesh that changes both in space and time. Volumetric visualization of the solution is an essential part of scientific computing, yet the existing volumetric visualization techniques do not take full advantage of multi-resolution wavelet analysis and are not fully tailored for visualization of a compressed solution on the wavelet-based adaptive computational mesh. Our objective is to explore the alternatives for the visualization of time-dependent data on space-time varying adaptive mesh using volume rendering while capitalizing on the available sparse data representation. Two alternative formulations are explored. The first one is based on volumetric ray casting of multi-scale datasets in wavelet space. Rather than working with the wavelets at the finest possible resolution, a partial inverse wavelet transform is performed as a preprocessing step to obtain scaling functions on a uniform grid at a user-prescribed resolution. As a result, a solution in physical space is represented by a superposition of scaling functions on a coarse regular grid and wavelets on an adaptive mesh. An efficient and accurate ray casting algorithm is based just on these coarse scaling functions. Additional details are added during the ray tracing by taking an appropriate number of wavelets into account based on support overlap with the interpolation point, wavelet coefficient magnitude, and other characteristics, such as opacity accumulation (front to back ordering) and deviation from frontal viewing direction. The second approach is based on complementing of wavelet-based adaptive mesh to the traditional Adaptive Mesh Refinement (AMR) mesh. Both algorithms are illustrated and compared to the existing volume visualization software for Rayleigh-Benard thermal convection and electron density data sets in terms of rendering time and visual quality for different data compression of both wavelet-based and AMR adaptive meshes. Full article
(This article belongs to the Special Issue Wavelets and Fluids)
Show Figures

Figure 1

18 pages, 5017 KiB
Article
Influence of Sill on the Hydraulic Regime in Sluice Gates: An Experimental and Numerical Analysis
by Rasoul Daneshfaraz, Reza Norouzi, Hamidreza Abbaszadeh, Alban Kuriqi and Silvia Di Francesco
Fluids 2022, 7(7), 244; https://doi.org/10.3390/fluids7070244 - 16 Jul 2022
Cited by 19 | Viewed by 3622
Abstract
This study investigates experimentally and numerically the effects of sills with different geometric specifications at various positions on the hydraulic characteristics of flow through sluice gates. The simulation results showed that the RNG turbulence model’s statistical indicators yield high accuracy compared to the [...] Read more.
This study investigates experimentally and numerically the effects of sills with different geometric specifications at various positions on the hydraulic characteristics of flow through sluice gates. The simulation results showed that the RNG turbulence model’s statistical indicators yield high accuracy compared to the k-ε, k-ω, and LES turbulence models. The discharge coefficient (Cd) has an inverse relationship with gate opening. Regarding sill state, the discharge coefficient is higher than no-sill state. In the case of non-suppressed sills, the Cd decreases compared to the smaller openings as the opening of the gate changes. The results showed that the Cd with a sill in the tangent position upstream of the gate is higher than the downstream tangent and below situations. Increasing the sill length leads to an increase in flow shear stress and consequently a decrease in Cd. The Cd of gates with different sill thicknesses is always higher than the no-sill state, but due to the constant ratio of the fluid depth above the sill to the gate opening, the Cd increases to a certain extent and then decreases with increasing sill thickness. Full article
Show Figures

Figure 1

18 pages, 3009 KiB
Article
The Influence of Characteristic Sea State Parameters on the Accuracy of Irregular Wave Field Simulations of Different Complexity
by Helene Lünser, Moritz Hartmann, Nicolas Desmars, Jasper Behrendt, Norbert Hoffmann and Marco Klein
Fluids 2022, 7(7), 243; https://doi.org/10.3390/fluids7070243 - 15 Jul 2022
Cited by 4 | Viewed by 1818
Abstract
The accurate description of the complex genesis and evolution of ocean waves, as well as the associated kinematics and dynamics is indispensable for the design of offshore structures and the assessment of marine operations. In the majority of cases, the water-wave problem is [...] Read more.
The accurate description of the complex genesis and evolution of ocean waves, as well as the associated kinematics and dynamics is indispensable for the design of offshore structures and the assessment of marine operations. In the majority of cases, the water-wave problem is reduced to potential flow theory on a somehow simplified level. However, the nonlinear terms in the surface boundary conditions and the fact that they must be fulfilled on the unknown water surface make the boundary value problem considerably complex. Hereby, the contrary objectives with respect to a very accurate representation of reality and numerical efficiency must be balanced wisely. This paper investigates the influence of characteristic sea state parameters on the accuracy of irregular wave field simulations of different complexity. For this purpose, the high-order spectral method was applied and the underlying Taylor series expansion was truncated at different orders so that numerical simulations of different complexity can be investigated. It is shown that, for specific characteristic sea state parameters, the boundary value problem can be significantly reduced while providing sufficient accuracy. Full article
(This article belongs to the Special Issue Nonlinear Wave Hydrodynamics, Volume II)
Show Figures

Graphical abstract

18 pages, 12223 KiB
Article
POD-Based Model-Order Reduction for Discontinuous Parameters
by Niklas Karcher
Fluids 2022, 7(7), 242; https://doi.org/10.3390/fluids7070242 - 14 Jul 2022
Cited by 1 | Viewed by 2278
Abstract
Reduced-order models (ROMs) based on proper orthogonal decomposition (POD) are widely used in industry. Due to the rigid requirements on the input data, these methods struggle with discontinuous parameters, e.g., optional rear spoiler on a car. In order to also include these types [...] Read more.
Reduced-order models (ROMs) based on proper orthogonal decomposition (POD) are widely used in industry. Due to the rigid requirements on the input data, these methods struggle with discontinuous parameters, e.g., optional rear spoiler on a car. In order to also include these types of parameters, a new method is presented that splits the full-order model (FOM) domain with its discontinuous parameters into multiple ROM subdomains. The resulting subdomains then again comply with the ROM requirements, and the established and proven ROM methods can be applied. The steps involved in computing a ROM based on the proposed method, by setting up the subdomains, mapping the FOM data into the domains, as well as computing the ROMs on the domains, are shown in detail in this paper. The method is employed on two use cases. The academic one-dimensional use case focuses on how the steps involved are employed and analyzes the introduced errors. The second use case’s FOM is based on the DrivAer body with an optional rear spoiler computed using computational fluid dynamics (CFD) and demonstrates the usage in an industrial environment. Full article
(This article belongs to the Special Issue Aerodynamics of Road Vehicles and Trains)
Show Figures

Figure 1

19 pages, 9150 KiB
Article
Viscoelasticity-Induced Instability in Plane Couette Flow at Very Low Reynolds Number
by Tomohiro Nimura and Takahiro Tsukahara
Fluids 2022, 7(7), 241; https://doi.org/10.3390/fluids7070241 - 13 Jul 2022
Cited by 2 | Viewed by 1788
Abstract
Elasto-inertial turbulence (EIT), a new turbulent state found in polymer solutions with viscoelastic properties, is associated with drag-reduced turbulence. However, the relationship between EIT and drag-reduced turbulence is not currently well-understood, and it is important to elucidate the mechanism of the transition to [...] Read more.
Elasto-inertial turbulence (EIT), a new turbulent state found in polymer solutions with viscoelastic properties, is associated with drag-reduced turbulence. However, the relationship between EIT and drag-reduced turbulence is not currently well-understood, and it is important to elucidate the mechanism of the transition to EIT. The instability of viscoelastic fluids has been studied in a canonical wall-bounded shear flow to investigate the transition process of EIT. In this study, we numerically deduced that an instability occurs in the linearly stable viscoelastic plane Couette flow for lower Reynolds numbers, at which a non-linear unstable solution exists. Under instability, the flow structure is elongated in the spanwise direction and regularly arranged in the streamwise direction, which is a characteristic structure of EIT. The regularity of the flow structure depends on the Weissenberg number, which represents the strength of elasticity; the structure becomes disordered under high Weissenberg numbers. In the energy spectrum of velocity fluctuations, a steep decay law of the structure’s scale towards a small scale is observed, and this can be recognized as a ubiquitous feature of EIT. The existence of instability in viscoelastic plane Couette flow supports the idea that the transitional path toward EIT may be mediated by subcritical instability. Full article
(This article belongs to the Special Issue Instabilities in Viscoelastic Fluid Flows)
Show Figures

Figure 1

21 pages, 1280 KiB
Article
Dimples for Skin-Friction Drag Reduction: Status and Perspectives
by Federica Gattere, Alessandro Chiarini and Maurizio Quadrio
Fluids 2022, 7(7), 240; https://doi.org/10.3390/fluids7070240 - 13 Jul 2022
Cited by 10 | Viewed by 3239
Abstract
Dimples are small concavities imprinted on a flat surface, known to affect heat transfer and also flow separation and aerodynamic drag on bluff bodies when acting as a standard roughness. Recently, dimples have been proposed as a roughness pattern that is capable of [...] Read more.
Dimples are small concavities imprinted on a flat surface, known to affect heat transfer and also flow separation and aerodynamic drag on bluff bodies when acting as a standard roughness. Recently, dimples have been proposed as a roughness pattern that is capable of reducing the turbulent drag of a flat plate by providing a reduction of skin friction that compensates the dimple-induced pressure drag and leads to a global benefit. The question whether dimples do actually work to reduce friction drag is still unsettled. In this paper, we provide a comprehensive review of the available information, touching upon the many parameters that characterize the problem. A number of reasons that contribute to explaining the contrasting literature information are discussed. We also provide guidelines for future studies by highlighting key methodological steps required for a meaningful comparison between a flat and dimpled surface in view of drag reduction. Full article
(This article belongs to the Special Issue Drag Reduction in Turbulent Flows)
Show Figures

Figure 1

17 pages, 1773 KiB
Article
Identifying the Origin of Turbulence Using Convolutional Neural Networks
by Justin Brown, Jacqueline Zimny and Timour Radko
Fluids 2022, 7(7), 239; https://doi.org/10.3390/fluids7070239 - 13 Jul 2022
Cited by 1 | Viewed by 1766
Abstract
Though turbulence is often thought to have universal behavior regardless of origin, it may be possible to distinguish between the types of turbulence generated by different sources. Prior work in turbulence modeling has shown that the fundamental “constants” of turbulence models are often [...] Read more.
Though turbulence is often thought to have universal behavior regardless of origin, it may be possible to distinguish between the types of turbulence generated by different sources. Prior work in turbulence modeling has shown that the fundamental “constants” of turbulence models are often problem-dependent and need to be calibrated to the desired application. This has resulted in the introduction of machine learning techniques to attempt to apply the general body of turbulence simulations to the modeling of turbulence at the subgrid-scale. This suggests that the inverse is likely also possible: that machine learning can use the properties of turbulence at small scales to identify the nature of the original source and potentially distinguish between different classes of turbulence-generating systems, which is a novel pursuit. We perform numerical simulations of three forms of turbulence—convection, wake, and jet—and then train a convolutional neural network to distinguish between these cases using only a narrow field of view of the velocity field. We find that the network is capable of identifying the correct case with 86% accuracy. This work has implications for distinguishing artificial sources of turbulence from natural ones and aiding in identifying the mechanism of turbulence in nature, permitting more accurate mixing models. Full article
Show Figures

Figure 1

19 pages, 3136 KiB
Article
Microfluidic Invasion Chemotaxis Platform for 3D Neurovascular Co-Culture
by Emel Sokullu, Zeynel Levent Cücük, Misagh Rezapour Sarabi, Mehmet Tugrul Birtek, Hesam Saghaei Bagheri and Savas Tasoglu
Fluids 2022, 7(7), 238; https://doi.org/10.3390/fluids7070238 - 13 Jul 2022
Cited by 12 | Viewed by 2649
Abstract
Advances in microfabrication and biomaterials have enabled the development of microfluidic chips for studying tissue and organ models. While these platforms have been developed primarily for modeling human diseases, they are also used to uncover cellular and molecular mechanisms through in vitro studies, [...] Read more.
Advances in microfabrication and biomaterials have enabled the development of microfluidic chips for studying tissue and organ models. While these platforms have been developed primarily for modeling human diseases, they are also used to uncover cellular and molecular mechanisms through in vitro studies, especially in the neurovascular system, where physiological mechanisms and three-dimensional (3D) architecture are difficult to reconstruct via conventional assays. An extracellular matrix (ECM) model with a stable structure possessing the ability to mimic the natural extracellular environment of the cell efficiently is useful for tissue engineering applications. Conventionally used techniques for this purpose, for example, Matrigels, have drawbacks of owning complex fabrication procedures, in some cases not efficient enough in terms of functionality and expenses. Here, we proposed a fabrication protocol for a GelMA hydrogel, which has shown structural stability and the ability to imitate the natural environment of the cell accurately, inside a microfluidic chip utilizing co-culturing of two human cell lines. The chemical composition of the synthesized GelMA was identified by Fourier transform infrared spectrophotometry (FTIR), its surface morphology was observed by field emission electron microscopy (FESEM), and the structural properties were analyzed by atomic force microscopy (AFM). The swelling behavior of the hydrogel in the microfluidic chip was imaged, and its porosity was examined for 72 h by tracking cell localization using immunofluorescence. GelMA exhibited the desired biomechanical properties, and the viability of cells in both platforms was more than 80% for seven days. Furthermore, GelMA was a viable platform for 3D cell culture studies and was structurally stable over long periods, even when prepared by photopolymerization in a microfluidic platform. This work demonstrated a viable strategy to conduct co-culturing experiments as well as modeling invasion and migration events. This microfluidic assay may have application in drug delivery and dosage optimization studies. Full article
Show Figures

Figure 1

18 pages, 1742 KiB
Article
Estimation of Flow Field in Natural Convection with Density Stratification by Local Ensemble Transform Kalman Filter
by Masahiro Ishigaki, Yoshiyasu Hirose, Satoshi Abe, Toru Nagai and Tadashi Watanabe
Fluids 2022, 7(7), 237; https://doi.org/10.3390/fluids7070237 - 12 Jul 2022
Cited by 1 | Viewed by 1475
Abstract
For estimating thermal flow in a nuclear reactor during an accident accurately, it is important to improve the accuracy of computational fluid dynamics simulations. The temperature and flow velocity are not homogeneous and have large variations in a reactor containment vessel because of [...] Read more.
For estimating thermal flow in a nuclear reactor during an accident accurately, it is important to improve the accuracy of computational fluid dynamics simulations. The temperature and flow velocity are not homogeneous and have large variations in a reactor containment vessel because of its very large volume. In addition, Kelm’s work pointed out that the influence of variations of initial and boundary conditions was important. Therefore, it is necessary to set the initial and boundary conditions taking into account the variations of these physical quantities. However, it is a difficult subject to set such complicated initial and boundary conditions. Then, we can obtain realistic initial and boundary conditions and an accurate flow field by data assimilation, and we can improve the accuracy of the simulation result. In this study, we applied data assimilation by a local ensemble transform Kalman filter to a simulation of natural convection behavior in density stratification, and we performed a twin model experiment. We succeeded in estimating the flow fields and improving the simulation accuracy by the data assimilation, even if we applied the boundary condition with error for the true condition. Full article
Show Figures

Figure 1

17 pages, 4378 KiB
Article
Arbitrary Hybrid Turbulence Modeling Approach for High-Fidelity NREL Phase VI Wind Turbine CFD Simulation
by Bagdaulet Kamalov, Sagidolla Batay, Dinmukhamed Zhangaskhanov, Yong Zhao and Eddie Yin Kwee Ng
Fluids 2022, 7(7), 236; https://doi.org/10.3390/fluids7070236 - 12 Jul 2022
Viewed by 1878
Abstract
Today, growth in renewable energy is increasing, and wind energy is one of the key renewable energy sources which is helping to reduce carbon emissions and build a more sustainable world. Developed countries and worldwide organizations are investing in technology and industrial application [...] Read more.
Today, growth in renewable energy is increasing, and wind energy is one of the key renewable energy sources which is helping to reduce carbon emissions and build a more sustainable world. Developed countries and worldwide organizations are investing in technology and industrial application development. However, extensive experiments using wind turbines are expensive, and numerical simulations are a cheaper alternative for advanced analysis of wind turbines. The aerodynamic properties of wind turbines can be analyzed and optimized using CFD tools. Currently, there is a general lack of available high-fidelity analysis for the wind turbine design community. This study aims to fill this urgent gap. In this paper, an arbitrary hybrid turbulence model (AHTM) was implemented in the open-source code OpenFOAM and compared with the traditional URANS model using the NREL Phase VI wind turbine as a benchmark case. It was found that the AHTM model gives more accurate results than the traditional URANS model. Furthermore, the results of the VLES and URANS models can be improved by improving the mesh quality for usage of higher-order schemes and taking into consideration aeroelastic properties of the wind turbine, which will pave the way for high-fidelity concurrent multidisciplinary design optimization of wind turbines. Full article
Show Figures

Figure 1

20 pages, 2462 KiB
Article
Numerical Simulation of Irregular Breaking Waves Using a Coupled Artificial Compressibility Method
by Athanasios Dermatis, Dimitrios Ntouras and George Papadakis
Fluids 2022, 7(7), 235; https://doi.org/10.3390/fluids7070235 - 11 Jul 2022
Cited by 4 | Viewed by 2317
Abstract
Wave breaking is widely recognized as a very challenging phenomenon to emulate using numerical/computational methods. On that condition, the transition from modelling regular to irregular breaking waves is not trivial. Even though some issues are surpassed in CFD simulations, there still are two [...] Read more.
Wave breaking is widely recognized as a very challenging phenomenon to emulate using numerical/computational methods. On that condition, the transition from modelling regular to irregular breaking waves is not trivial. Even though some issues are surpassed in CFD simulations, there still are two substantial problems to account for. The first one entails the proper generation of irregular waves in a numerical wave tank, while the second is the introduction of the turbulent regime of breaking in the solver. The present work addresses these two problems by employing the Stabilized kω SST model for turbulence closure and by proposing an efficient and accurate method for irregular wave generation. Apart from that, an artificial compressibility method is used for coupling the system of equations, which solves these equations in a non-segregated manner and overcomes problems pertaining to the existence of the interface in free-surface flows. The methodology is validated through the test case of irregular wave propagation over a submerged breaker bar and a piecewise sloped bottom, indicating the ability of the method to capture irregular breaking wave phenomena. Simulations are in fair agreement with experimental data regarding energy spectra and free surface time-series, while results suggest that the known over-prediction of turbulent kinetic energy (TKE) is significantly constrained by the stabilized kω SST model. Full article
(This article belongs to the Collection Advances in Flow of Multiphase Fluids and Granular Materials)
Show Figures

Figure 1

16 pages, 7951 KiB
Article
Numerical Investigation of the Hydrodynamic Behavior of Trash-Blocking Nets for Water Intake Engineering of Nuclear Power Plant
by Zhenqiang Jiang, Tongyan Wang, Bin Wang, Tiaojian Xu, Changlei Ma and Kanmin Shen
Fluids 2022, 7(7), 234; https://doi.org/10.3390/fluids7070234 - 11 Jul 2022
Cited by 1 | Viewed by 1577
Abstract
In order to ensure the safety of the cooling water source of coastal nuclear power plants (NPP), trash-blocking nets (TBNs) are usually installed at the entrance of the penstock to prevent marine sewage and organisms flowing into the front pool of the pump [...] Read more.
In order to ensure the safety of the cooling water source of coastal nuclear power plants (NPP), trash-blocking nets (TBNs) are usually installed at the entrance of the penstock to prevent marine sewage and organisms flowing into the front pool of the pump house of the nuclear power plant. The safety evaluation of these trash-blocking nets is of paramount importance for the stable operation of a nuclear power plant. However, there is no reliable analysis method for improving the design of trash-blocking nets and mooring systems. In this study, a numerical model of in-current trash-blocking nets based on the lumped mass method was developed to calculate the tension force on the trash-blocking nets and mooring system. A comparison with the experimental data indicates that the present numerical model is appropriate for calculating the in-current hydrodynamic loads on the trash-blocking nets. In addition, the effects of the width of trash-blocking nets, hanging ratio, water depth, and net solidity are discussed in detail, and the damage process of trash-blocking nets was also investigated. The results indicate that the maximum tension force on the trash-blocking net linearly increases with the increasing width of trash-blocking nets, and it is greatly decreased with the increase in the horizontal hanging ratio of trash-blocking nets. It can be increased by 200% when the net solidity is increased from 0.16 to 0.6. Two damage modes for mooring lines can be observed, which are determined by the strength of mooring lines. Full article
Show Figures

Figure 1

19 pages, 11760 KiB
Article
Amplification of Wave Groups in the Forced Nonlinear Schrödinger Equation
by Montri Maleewong and Roger H. J. Grimshaw
Fluids 2022, 7(7), 233; https://doi.org/10.3390/fluids7070233 - 8 Jul 2022
Cited by 9 | Viewed by 1640
Abstract
In many physical contexts, notably including deep-water waves, modulation instability in one space dimension is often studied by using the nonlinear Schrödinger equation. The principal solutions of interest are solitons and breathers which are adopted as models of wave packets. The Peregrine breather [...] Read more.
In many physical contexts, notably including deep-water waves, modulation instability in one space dimension is often studied by using the nonlinear Schrödinger equation. The principal solutions of interest are solitons and breathers which are adopted as models of wave packets. The Peregrine breather in particular is often invoked as a model of a rogue wave. In this paper, we add a linear growth term to the nonlinear Schrödinger equation to model the amplification of propagating wave groups. This is motivated by an application to wind-generated water waves, but this forced nonlinear Schrödinger equation potentially has much wider applicability. We describe a series of numerical simulations which in the absence of the forcing term would generate solitons and/or breathers. We find that overall the effect of the forcing term is to favour the generation of solitons with amplitudes growing at twice the linear growth rate over the generation of breathers. Full article
(This article belongs to the Section Mathematical and Computational Fluid Mechanics)
Show Figures

Figure 1

18 pages, 25355 KiB
Article
The Role of Pin Fin Array Configurations and Bubble Characteristics on the Pool Boiling Heat Transfer Enhancement
by Indro Pranoto, Muhammad Aulia Rahman and Joko Waluyo
Fluids 2022, 7(7), 232; https://doi.org/10.3390/fluids7070232 - 8 Jul 2022
Cited by 8 | Viewed by 2248
Abstract
Pool boiling surface modification by pin fin array has demonstrated a practical but effective cooling enhancement. Whilst the main challenge is to determine the best configuration of the pin fin dimensions and positioning, it is known that the result varies among the working [...] Read more.
Pool boiling surface modification by pin fin array has demonstrated a practical but effective cooling enhancement. Whilst the main challenge is to determine the best configuration of the pin fin dimensions and positioning, it is known that the result varies among the working conditions. To obtain a more general formulation, it is utterly vital to obtain a deep understanding of the pool boiling mechanism during the phase-change process. This study aimed to analyze the role of pin fin array configuration on the pool boiling phenomenon by generating visualization and non-dimensional analysis. The results illustrated three different regimes occurring during the boiling process: natural convection, isolated bubble, and merged bubble. For all regimes, the average heat transfer performance was enhanced as the fin gap rose to 17% and 63% for circular and rectangular pin fins, respectively. Furthermore, Grashof (Gr) and Bond (Bo) numbers were calculated to quantitatively describe the effect on the bubble dynamics. From these approaches, it was found that the insulated bubble regime provides a better means of cooling by around 60% due to the better bubble dynamics. Full article
(This article belongs to the Section Heat and Mass Transfer)
Show Figures

Graphical abstract

14 pages, 647 KiB
Article
Note on the Early Thermoelastic Stage Preceding Rayleigh–Bénard Convection in Soft Materials
by Rachid Rahouadj, Chérif Nouar and Antonio Pereira
Fluids 2022, 7(7), 231; https://doi.org/10.3390/fluids7070231 - 8 Jul 2022
Viewed by 1276
Abstract
In this paper, we focus on the first stage of transition to Rayleigh–Bénard convection in soft-jammed systems (yield stress fluids) confined in a parallelepiped box heated from the bottom. Up to yielding, the material is in a solid-state with a constant elastic modulus. [...] Read more.
In this paper, we focus on the first stage of transition to Rayleigh–Bénard convection in soft-jammed systems (yield stress fluids) confined in a parallelepiped box heated from the bottom. Up to yielding, the material is in a solid-state with a constant elastic modulus. By means of a linear thermoelastic model, an analytical solution for stresses and strains induced by the gravity and the temperature gradient is derived. The analytical solution allows us to emphasize the appropriate dimensionless parameters. The onset of plastic deformation is then investigated using the classical yield criteria (Tresca, von Mises and Drucker–Prager). This analysis is subsequently applied to experimental data of the literature dealing with Rayleigh–Bénard convection in Carbopol micro gels. Full article
(This article belongs to the Special Issue Convection in Fluid and Porous Media)
Show Figures

Figure 1

14 pages, 2995 KiB
Article
Prediction of Critical Heat Flux for Subcooled Flow Boiling in Annulus and Transient Surface Temperature Change at CHF
by Wei Liu
Fluids 2022, 7(7), 230; https://doi.org/10.3390/fluids7070230 - 7 Jul 2022
Cited by 1 | Viewed by 1881
Abstract
The ability to predict critical heat flux (CHF) is of considerable interest for high-heat equipment, including nuclear reactors. CHF prediction from a mechanistic model for subcooled flow boiling in rod bundles still remains unsolved. In this paper, we try to predict the CHF [...] Read more.
The ability to predict critical heat flux (CHF) is of considerable interest for high-heat equipment, including nuclear reactors. CHF prediction from a mechanistic model for subcooled flow boiling in rod bundles still remains unsolved. In this paper, we try to predict the CHF in an annulus, which is the most basic flow geometry simplified from a fuel bundle, using a liquid sublayer dryout model. The prediction is validated with both water and R113 data, showing an accuracy within ±30%. After the CHF in an annulus is calculated successfully, a near-wall vapor–liquid structure is proposed on the basis of the liquid sublayer dryout model. Modeling of heat transfer modes over the heating surface at CHF is performed, and predictions of the changes in liquid sublayer thickness and heater surface temperature at the CHF occurrence point are carried out by solving the heat conduction equation in cylindrical coordinates with a convective boundary condition, which changes with the change in flow pattern over the heating surface. Transient changes in the liquid sublayer thickness and surface temperature at the CHF occurrence point are reported. Full article
(This article belongs to the Special Issue Advances in Multiphase Flow Science and Technology)
Show Figures

Figure 1

14 pages, 2580 KiB
Article
Thermographic Observation and Hydrodynamic Patterns of Inclined Ethanol Droplet Train Impingement on a Non-Uniformly Heated Glass Surface
by Baris Burak Kanbur, Sheng Quan Heng and Fei Duan
Fluids 2022, 7(7), 229; https://doi.org/10.3390/fluids7070229 - 7 Jul 2022
Cited by 1 | Viewed by 1624
Abstract
Droplet train impingement is a fundamental approach to mimic the complicated interactions between the fluid and the substrate in advanced thermal engineering applications in industry. Differently from previous studies, the main original contribution of this study is to perform an inclined droplet train [...] Read more.
Droplet train impingement is a fundamental approach to mimic the complicated interactions between the fluid and the substrate in advanced thermal engineering applications in industry. Differently from previous studies, the main original contribution of this study is to perform an inclined droplet train impingement on a non-uniformly heated surface. Ethanol was used as the liquid for droplet train impingement applications, while glass substrate was selected as the target surface. The inclined flow angle was 63 degrees. Both optical and thermographic observations were performed on the target surface by focusing on the droplet impact area. Three experimental sets were created with the Weber numbers 667.57, 841.90, and 998.01. A surface temperature range was selected between 85.00 °C and 200.00 °C, which was above the boiling point of the ethanol. The maximum spreading length was measured at 0.97 mm at the surface temperature of 82.00 °C for the experiment with the Weber number of 998.01, whilst the minimum spreading length was found at 0.18 mm at the highest surface temperature for the experiment with the Weber number of 667.57. A uniform splashing direction was observed above 170.00 °C for all experiments, which meant that the sign of the transition regime appeared. Full article
(This article belongs to the Topic Fluid Mechanics)
Show Figures

Figure 1

14 pages, 4578 KiB
Article
Aerodynamics of High-Speed Trains with Respect to Ground Simulation
by Dennis Weidner, Daniel Stoll, Timo Kuthada and Andreas Wagner
Fluids 2022, 7(7), 228; https://doi.org/10.3390/fluids7070228 - 5 Jul 2022
Cited by 2 | Viewed by 2976
Abstract
Wind tunnel testing is commonly used to assess and optimize the aerodynamic characteristics of high-speed trains. The train model is usually mounted above a static ground plane, but a moving ground is necessary for the correct representation of the relative motion between train [...] Read more.
Wind tunnel testing is commonly used to assess and optimize the aerodynamic characteristics of high-speed trains. The train model is usually mounted above a static ground plane, but a moving ground is necessary for the correct representation of the relative motion between train and ground. This study focuses on the effect of the applied ground simulation on the aerodynamics of a high-speed train. Wind tunnel tests using a stationary and a moving ground were carried out using a 1:20 scale model of a high-speed train’s first car. Numerical simulations for two moving ground configurations are created, and the simulation setup is validated using surface pressure measurements from the wind tunnel tests. It is shown that the ground simulation has a significant effect on the drag in the considered yaw angle range. Additionally, the change in drag due to bogie fairings is evaluated and an impact of the applied ground simulation on the drag reduction is observed. The drag reduction of front and rear bogie fairings is valued similarly using a static ground, however on a moving ground the drag reduction of front bogie fairings is significantly increased. Good agreement between simulations and experiments is achieved. Full article
(This article belongs to the Special Issue Aerodynamics of Road Vehicles and Trains)
Show Figures

Figure 1

15 pages, 736 KiB
Article
Periodic and Solitary Wave Solutions of the Long Wave–Short Wave Yajima–Oikawa–Newell Model
by Marcos Caso-Huerta, Antonio Degasperis, Priscila Leal da Silva, Sara Lombardo and Matteo Sommacal
Fluids 2022, 7(7), 227; https://doi.org/10.3390/fluids7070227 - 4 Jul 2022
Cited by 3 | Viewed by 2033
Abstract
Models describing long wave–short wave resonant interactions have many physical applications, from fluid dynamics to plasma physics. We consider here the Yajima–Oikawa–Newell (YON) model, which was recently introduced, combining the interaction terms of two long wave–short wave, integrable models, one proposed by Yajima–Oikawa, [...] Read more.
Models describing long wave–short wave resonant interactions have many physical applications, from fluid dynamics to plasma physics. We consider here the Yajima–Oikawa–Newell (YON) model, which was recently introduced, combining the interaction terms of two long wave–short wave, integrable models, one proposed by Yajima–Oikawa, and the other one by Newell. The new YON model contains two arbitrary coupling constants and it is still integrable—in the sense of possessing a Lax pair—for any values of these coupling constants. It reduces to the Yajima–Oikawa or the Newell systems for special choices of these two parameters. We construct families of periodic and solitary wave solutions, which display the generation of very long waves. We also compute the explicit expression of a number of conservation laws. Full article
(This article belongs to the Special Issue Nonlinear Wave Hydrodynamics, Volume II)
Show Figures

Figure 1

16 pages, 11374 KiB
Article
Modeling of Flow Heat Transfer Processes and Aerodynamics in the Cabins of Vehicles
by Alexey N. Beskopylny, Ivan Panfilov and Besarion Meskhi
Fluids 2022, 7(7), 226; https://doi.org/10.3390/fluids7070226 - 3 Jul 2022
Cited by 5 | Viewed by 1991
Abstract
Ensuring comfortable climatic conditions for operators in the cabin of technological machines is an important scientific and technical task affecting operator health. This article implements numerical and analytical modeling of the thermal state of the vehicle cabin, considering external airflow and internal ventilation. [...] Read more.
Ensuring comfortable climatic conditions for operators in the cabin of technological machines is an important scientific and technical task affecting operator health. This article implements numerical and analytical modeling of the thermal state of the vehicle cabin, considering external airflow and internal ventilation. A method for calculating the heat transfer coefficients of a multilayer cabin wall for internal and external air under conditions of forced convective heat exchange is proposed. The cabin is located in the external aerodynamic flow to consider the speed and direction of the wind, as well as the speed of traffic. Inside the cabin, the operation of the climate system is modeled as an incoming flow of a given temperature and flow rate. The fields of velocities, pressures, and temperatures are calculated by the method of computer hydrodynamics for the averaged Navier–Stokes equations and the energy equation using the turbulence model. To verify the model, the values of the obtained heat transfer coefficients were compared with three applied theories obtained from experimental data based on dimensionless complexes for averaged velocities and calculated by a numerical method. It is shown that the use of numerical simulation considering the external air domain makes it possible to obtain more accurate results from 5% to 75% compared to applied theories, particularly in areas with large velocity gradients. This method makes it possible to get more accurate values of the heat transfer coefficients than for averaged velocities. Full article
Show Figures

Figure 1

21 pages, 3582 KiB
Article
Performance Comparison of Newtonian and Non-Newtonian Fluid on a Heterogeneous Slip/No-Slip Journal Bearing System Based on CFD-FSI Method
by Mohammad Tauviqirrahman, J. Jamari, S. Susilowati, Caecilia Pujiastuti, Budi Setiyana, Ahmad Hafil Pasaribu and Muhammad Imam Ammarullah
Fluids 2022, 7(7), 225; https://doi.org/10.3390/fluids7070225 - 2 Jul 2022
Cited by 41 | Viewed by 3652
Abstract
It is a well-known fact that incorporating a slip boundary into the contact surfaces improves bearing performance significantly. Regrettably, no research into the effect of slip on the behavior of journal bearing systems operating with non-Newtonian lubricants has been conducted thus far. The [...] Read more.
It is a well-known fact that incorporating a slip boundary into the contact surfaces improves bearing performance significantly. Regrettably, no research into the effect of slip on the behavior of journal bearing systems operating with non-Newtonian lubricants has been conducted thus far. The main purpose of this work is to explore the performance comparison of Newtonian and non-Newtonian fluid on a heterogeneous slip/no-slip journal bearing system. The tribological and acoustic behavior of journal bearing is investigated in this study using a rigorous program that combines CFD (computational fluid dynamics) and two-way FSI (fluid–structure interaction) procedures to simulate Newtonian vs. non-Newtonian conditions with and without slip boundary. The numerical results indicate that irrespective of the lubricant type (i.e., Newtonian or non-Newtonian), an engineered heterogeneous slip/no-slip pattern leads to the improvement of the bearing performance (i.e., increased load-carrying capacity, reduced coefficient of friction, and decreased noise) compared to conventional journal bearing. Furthermore, the influence of the eccentricity ratio is discussed, which confirms that the slip beneficial effect becomes stronger as the eccentricity ratio decreases. It has also been noticed that the Newtonian lubricant is preferable for improving tribological performance, whereas non-Newtonian fluid is recommended for lowering bearing noise. Full article
(This article belongs to the Collection Non-Newtonian Fluid Mechanics)
Show Figures

Figure 1

22 pages, 986 KiB
Article
Electroviscoelstic Stability Analysis of Cylindrical Structures in Walters B Conducting Fluids Streaming through Porous Medium
by T. M. N. Metwaly and N. M. Hafez
Fluids 2022, 7(7), 224; https://doi.org/10.3390/fluids7070224 - 1 Jul 2022
Cited by 1 | Viewed by 1641
Abstract
In this research, the linear stability of a cylindrical interface between two viscoelstic Walters B conducting fluids moving through a porous medium is investigated theoretically and numerically. The fluids are influenced by a uniform axial electric field. The cylindrical structure preserves heat and [...] Read more.
In this research, the linear stability of a cylindrical interface between two viscoelstic Walters B conducting fluids moving through a porous medium is investigated theoretically and numerically. The fluids are influenced by a uniform axial electric field. The cylindrical structure preserves heat and mass transfer across the interface. The governing equations of motion and continuity are linearized, as are Maxwell’s equations in quasi-static approximation and the suitable boundary conditions at the interface. The method of normal modes has been used to obtain a quadratic characteristic equation in frequency with complex coefficients describing the interaction between viscoelstic Walters B conducting fluids and the electric field. In light of linear stability theory, the Routh–Hurwitz criteria are used to govern the structure’s stability. Several special cases are recoverd under suitable data choices. The stability analysis is conferred in detail via the behaviors of the applied electric field and the imaginary growth rate part with the wavenumbers. The effects of various parameters on the interfacial stability are theoretically presented and illustrated graphically through two sets of figures. Our results demonstrate that kinematic viscosities, kinematic viscoelasticities, and medium porosity improve stability, whereas medium permeability, heat and mass transfer coefficients, and fluid velocities decrease it. Finally, electrical conductivity has a critical influence on the structure’s stability. Full article
(This article belongs to the Special Issue Instabilities in Viscoelastic Fluid Flows)
Show Figures

Graphical abstract

11 pages, 9245 KiB
Article
Experimental Investigation of the Vortex Dynamics in Circular Jet Impinging on Rotating Disk
by Mouhammad El Hassan and David S. Nobes
Fluids 2022, 7(7), 223; https://doi.org/10.3390/fluids7070223 - 1 Jul 2022
Cited by 3 | Viewed by 1637
Abstract
A circular jet impinging perpendicularly onto a rotating disk is studied in order to understand the influence of centrifugal forces on the radial wall jet. Time-resolved Particle Image Velocimetry (TR-PIV) measurements are conducted in different jet regions in order to investigate the flow [...] Read more.
A circular jet impinging perpendicularly onto a rotating disk is studied in order to understand the influence of centrifugal forces on the radial wall jet. Time-resolved Particle Image Velocimetry (TR-PIV) measurements are conducted in different jet regions in order to investigate the flow physics of the large-scale vortical structures and the boundary layer development on the impinging wall for both stationary and rotating impinging disks. The Reynolds number is ReD = 2480, the orifice-to-plate distance H = 4D (D is the jet-orifice diameter) and the rotation rate is 200 RPM. It is found that the rotation of the impinging wall results in strong centrifugal effects, which affect different regions of the jet. Both radial velocity profiles and turbulence intensity distributions show different behavior when comparing the stationary and rotating cases. Finite Time Lyapunov Exponent (FTLE) analysis is implemented to describe the time-resolved behavior of the large-scale vortical structures and flow separation. Full article
Show Figures

Graphical abstract

34 pages, 16916 KiB
Article
Mathematical and Computational Modeling of Poroelastic Cell Scaffolds Used in the Design of an Implantable Bioartificial Pancreas
by Yifan Wang, Sunčica Čanić, Martina Bukač, Charles Blaha and Shuvo Roy
Fluids 2022, 7(7), 222; https://doi.org/10.3390/fluids7070222 - 1 Jul 2022
Cited by 1 | Viewed by 2266
Abstract
We present a multi-scale mathematical model and a novel numerical solver to study blood plasma flow and oxygen concentration in a prototype model of an implantable Bioartificial Pancreas (iBAP) that operates under arteriovenous pressure differential without the need for immunosuppressive therapy. The iBAP [...] Read more.
We present a multi-scale mathematical model and a novel numerical solver to study blood plasma flow and oxygen concentration in a prototype model of an implantable Bioartificial Pancreas (iBAP) that operates under arteriovenous pressure differential without the need for immunosuppressive therapy. The iBAP design consists of a poroelastic cell scaffold containing the healthy transplanted cells, encapsulated between two semi-permeable nano-pore size membranes to prevent the patient’s own immune cells from attacking the transplant. The device is connected to the patient’s vascular system via an anastomosis graft bringing oxygen and nutrients to the transplanted cells of which oxygen is the limiting factor for long-term viability. Mathematically, we propose a (nolinear) fluid–poroelastic structure interaction model to describe the flow of blood plasma through the scaffold containing the cells, and a set of (nonlinear) advection–reaction–diffusion equations defined on moving domains to study oxygen supply to the cells. These macro-scale models are solved using finite element method based solvers. One of the novelties of this work is the design of a novel second-order accurate fluid–poroelastic structure interaction solver, for which we prove that it is unconditionally stable. At the micro/nano-scale, Smoothed Particle Hydrodynamics (SPH) simulations are used to capture the micro/nano-structure (architecture) of cell scaffolds and obtain macro-scale parameters, such as hydraulic conductivity/permeability, from the micro-scale scaffold-specific architecture. To avoid expensive micro-scale simulations based on SPH simulations for every new scaffold architecture, we use Encoder–Decoder Convolution Neural Networks. Based on our numerical simulations, we propose improvements in the current prototype design. For example, we show that highly elastic scaffolds have a higher capacity for oxygen transfer, which is an important finding considering that scaffold elasticity can be controlled during their fabrication, and that elastic scaffolds improve cell viability. The mathematical and computational approaches developed in this work provide a benchmark tool for computational analysis of not only iBAP, but also, more generally, of cell encapsulation strategies used in the design of devices for cell therapy and bio-artificial organs. Full article
(This article belongs to the Section Mathematical and Computational Fluid Mechanics)
Show Figures

Graphical abstract

Previous Issue
Next Issue
Back to TopTop
