Machines, Volume 8, Issue 3 (September 2020) – 12 articles

  • Issues are regarded as officially published after their release is announced to the table of contents alert mailing list.
  • You may sign up for e-mail alerts to receive table of contents of newly released issues.
  • PDF is the official format for papers published in both, html and pdf forms. To view the papers in pdf format, click on the "PDF Full-text" link, and use the free Adobe Readerexternal link to open them.
Order results
Result details
Select all
Export citation of selected articles as:
Open AccessArticle
Model-Based Manipulation of Linear Flexible Objects: Task Automation in Simulation and Real World
Machines 2020, 8(3), 46; https://doi.org/10.3390/machines8030046 - 08 Aug 2020
Viewed by 139
Abstract
Manipulation of deformable objects is a desired skill in making robots ubiquitous in manufacturing, service, healthcare, and security. Common deformable objects (e.g., wires, clothes, bed sheets, etc.) are significantly more difficult to model than rigid objects. In this research, we contribute to the [...] Read more.
Manipulation of deformable objects is a desired skill in making robots ubiquitous in manufacturing, service, healthcare, and security. Common deformable objects (e.g., wires, clothes, bed sheets, etc.) are significantly more difficult to model than rigid objects. In this research, we contribute to the model-based manipulation of linear flexible objects such as cables. We propose a 3D geometric model of the linear flexible object that is subject to gravity and a physical model with multiple links connected by revolute joints and identified model parameters. These models enable task automation in manipulating linear flexible objects both in simulation and real world. To bridge the gap between simulation and real world and build a close-to-reality simulation of flexible objects, we propose a new strategy called Simulation-to-Real-to-Simulation (Sim2Real2Sim). We demonstrate the feasibility of our approach by completing the Plug Task used in the 2015 DARPA Robotics Challenge Finals both in simulation and real world, which involves unplugging a power cable from one socket and plugging it into another. Numerical experiments are implemented to validate our approach. Full article
(This article belongs to the Special Issue Intelligent Mechatronics Systems)
Show Figures

Figure 1

Open AccessArticle
Rehabilitation Machine for Bariatric Individuals
Machines 2020, 8(3), 45; https://doi.org/10.3390/machines8030045 - 07 Aug 2020
Viewed by 139
Abstract
Obesity is known to be growing worldwide. The World Health Organization (WHO) reports that obesity has tripled since 1975. In 2016, 39% of adults over 18 years old were overweight, and 13% were obese. Obesity is mostly preventable by adopting lifestyle improvements, enhancing [...] Read more.
Obesity is known to be growing worldwide. The World Health Organization (WHO) reports that obesity has tripled since 1975. In 2016, 39% of adults over 18 years old were overweight, and 13% were obese. Obesity is mostly preventable by adopting lifestyle improvements, enhancing diet quality, and doing physical exercise. The workload of the physical exercises should be proportionate to the patient’s capabilities. However, it must be considered that obese people are not used to training; they may not endure physical exertion and, even more critically, they could have some psychological impediments to the workouts. Physical exercises and equipment must, therefore, guarantee comfort and prevent situations in which the bariatric individual may feel inadequate. For these reasons, this study aims to design an innovative system to approach simple physical activities, like leg and arm exercises, to bariatric users to enable them to recover mobility and muscle tone gradually. The leading feature of this architecture is the design of hidden exercise mechanisms to overcome the psychological barriers of the users toward these kinds of machines. This paper proposes the initial design of the main sub-systems composing the rehabilitation machine, namely the leg curl and leg extension mechanism and its control architecture, the upper body exercises system, and a series of regulation mechanisms required to accommodate a wide range of users. The proposed functional design will then lead to the development of a prototype to validate the machine. Full article
Show Figures

Figure 1

Open AccessArticle
Advanced Strategy of Speed Predictive Control for Nonlinear Synchronous Reluctance Motors
Machines 2020, 8(3), 44; https://doi.org/10.3390/machines8030044 - 01 Aug 2020
Viewed by 234
Abstract
To gain fast dynamic response, high performance, and good tracking capability, several control strategies have been applied to synchronous reluctance motors (SynRMs). In this paper, a nonlinear advanced strategy of speed predictive control (SPC) based on the finite control set model predictive control [...] Read more.
To gain fast dynamic response, high performance, and good tracking capability, several control strategies have been applied to synchronous reluctance motors (SynRMs). In this paper, a nonlinear advanced strategy of speed predictive control (SPC) based on the finite control set model predictive control (FCS-MPC) is proposed and simulated for nonlinear SynRMs. The SPC overcomes the limitation of the cascaded control structure of the common vector control by employing a novel strategy that considers all the electrical and mechanical variables in one control law through a new cost function to obtain the switching signals for the power converter. The SynRM flux maps are known based on finite element method (FEM) analysis to take into consideration the effect of the nonlinearity of the machine. To clear the proposed strategy features, a functional and qualitative comparison between the proposed SPC, field-oriented control (FOC) with an anti-windup scheme, and current predictive control (CPC) with outer PI speed control loop is presented. For simplicity, particle swarm optimization (PSO) is performed to tune all the unknown parameters of the control strategies. The comparison features include controller design, dynamic and steady-state behaviors. Simulation results are presented to investigate the benefits and limitations of the three control strategies. Finally, the proposed SPC, FOC, and CPC have their own merits, and all methods encounter the requirements of advanced high-performance drives. Full article
(This article belongs to the Special Issue Design and Control of Rotating Electrical Machines)
Show Figures

Figure 1

Open AccessArticle
Roller Leveler Monitoring Using Acceleration Measurements and Models for Steel Strip Properties
Machines 2020, 8(3), 43; https://doi.org/10.3390/machines8030043 - 29 Jul 2020
Viewed by 217
Abstract
The advanced steel grades and high productivity requirements in the modern steel industry subject production machines to increased mechanical stresses, which inflicts losses. Novel data-oriented solutions to the monitoring of machines have a pivotal role in loss prevention, but the industrial data with [...] Read more.
The advanced steel grades and high productivity requirements in the modern steel industry subject production machines to increased mechanical stresses, which inflicts losses. Novel data-oriented solutions to the monitoring of machines have a pivotal role in loss prevention, but the industrial data with high sampling rates, noise, and dimensions bring challenges there. This study proposes a new monitoring approach for roller levelers based on vibration measurements and regression models for estimating steel strip properties including yield strength, width, and thickness. The regression residuals are monitored based on moving mean and range charts, which reveal changes from the expected normal operation. A high-dimensional feature set of 144,000 statistical features was studied with various feature selection methods, including filters and wrappers. Multiple linear regression and generalized regression neural network were applied in modeling. The approach was validated using data from an industrial roller leveler processing steel strips with diverse properties. The results reveal that the accurate prediction of the strip thickness from the strip properties is possible and multiple linear regression was generally the superior model therein. Additional simulations indicated that the control charts can detect deviant operation. Supplemental information about the momentary operation of the machine would improve the approach. Full article
(This article belongs to the Section Intelligent Machines)
Show Figures

Figure 1

Open AccessArticle
Surface Hardening of Machine Parts Using Nitriding and TiN Coating Deposition in Glow Discharge
Machines 2020, 8(3), 42; https://doi.org/10.3390/machines8030042 - 24 Jul 2020
Viewed by 196
Abstract
Surface hardening of machine parts substantially improves their performance. The best results are obtained when combined hardening consists of surface nitriding and subsequent deposition of hard coatings. The nitriding of machine parts immersed in the plasma of glow coatings have been studied, and [...] Read more.
Surface hardening of machine parts substantially improves their performance. The best results are obtained when combined hardening consists of surface nitriding and subsequent deposition of hard coatings. The nitriding of machine parts immersed in the plasma of glow coatings have been studied, and the study results are presented. Titanium atoms for coating synthesis are obtained via titanium evaporation in a hollow molybdenum anode of the discharge. Stable evaporation of titanium occurs only when the power density of electrons heating the liquid titanium does not exceed ~500 W/cm2. To start evaporation, it is only necessary to reduce the gas pressure to 0.02 Pa. To stop evaporation, it is enough to increase the gas pressure to 0.1 Pa. Fast argon and nitrogen atoms used for cleaning the machine parts, heating them, and bombarding the growing coating are obtained using a grid composed of plane-parallel plates under high negative voltage and immersed in plasma. Full article
Show Figures

Figure 1

Open AccessArticle
Automated Kinematic Analysis of Closed-Loop Planar Link Mechanisms
Machines 2020, 8(3), 41; https://doi.org/10.3390/machines8030041 - 23 Jul 2020
Viewed by 202
Abstract
The systematic kinematic analysis method for planar link mechanisms based on their unique procedures can clearly show the analysis process. The analysis procedure is expressed by a combination of many kinds of conversion functions proposed as the minimum calculation units for analyzing a [...] Read more.
The systematic kinematic analysis method for planar link mechanisms based on their unique procedures can clearly show the analysis process. The analysis procedure is expressed by a combination of many kinds of conversion functions proposed as the minimum calculation units for analyzing a part of the mechanism. When it is desired to perform this systematic kinematics analysis for a specific linkage mechanism, expert researchers can accomplish the analysis by searching for the procedure by themselves, however, it is difficult for non-expert users to find the procedure. This paper proposes the automatic procedure extraction algorithm for the systematic kinematic analysis of closed-loop planar link mechanisms. By limiting the types of conversion functions to only geometric calculations that are related to the two-link chain, the analysis procedure can be represented by only one type transformation function, and the procedure extraction algorithm can be described as a algorithm searching computable 2-link chain. The configuration of mechanism is described as the “LJ-matrix”, which shows the relationship of connections between links with pairs. The algorithm consists of four sub-processes, namely, “LJ-matrix generator”, “Solver process”, “Add-link process”, and “Over-constraint resolver”. Inputting the sketch of the mechanism into the proposed algorithm, it automatically extracts unique analysis procedure and generate a kinematic analysis program as a MATLAB code based on it. Several mechanisms are analyzed as examples to show the usefulness of the proposed method. Full article
(This article belongs to the Special Issue Selected Papers from Advances of Japanese Machine Design)
Show Figures

Figure 1

Open AccessArticle
Biaxial Testing Machine: Development and Evaluation
Machines 2020, 8(3), 40; https://doi.org/10.3390/machines8030040 - 21 Jul 2020
Viewed by 212
Abstract
Biaxial mechanical testing gained increased importance for characterization of materials that present anisotropic behavior and/or different responses when subjected to tensile and compression loadings. In this work, a new biaxial testing machine was developed. The various systems and components were designed, manufactured, assembled, [...] Read more.
Biaxial mechanical testing gained increased importance for characterization of materials that present anisotropic behavior and/or different responses when subjected to tensile and compression loadings. In this work, a new biaxial testing machine was developed. The various systems and components were designed, manufactured, assembled, and assessed. Uniaxial tensile tests were performed to validate the device, showing results consistent with those obtained on a universal testing machine. Finally, biaxial tensile tests were also performed on polypropylene cruciform specimens. The results revealed high precision levels, thus showing the potential of this new machine. Full article
(This article belongs to the Section Machine Design and Testing)
Show Figures

Figure 1

Open AccessArticle
Unbalance Estimation for a Large Flexible Rotor Using Force and Displacement Minimization
Machines 2020, 8(3), 39; https://doi.org/10.3390/machines8030039 - 14 Jul 2020
Viewed by 260
Abstract
Mass unbalance is one of the most prominent faults that occurs in rotating machines. The identification of unbalance in the case of large flexible rotors is crucial because in industrial applications such as paper machines and roll grinders, high vibrations can adversely affect [...] Read more.
Mass unbalance is one of the most prominent faults that occurs in rotating machines. The identification of unbalance in the case of large flexible rotors is crucial because in industrial applications such as paper machines and roll grinders, high vibrations can adversely affect the quality of the end product. The objective of this research is to determine the unbalance location, magnitude and phase for a large flexible rotor with few measured coordinates. To this end, an established force-based method comprising of modal expansion and equivalent load minimization is applied. Due to the anisotropic behavior of the test rotor, the force method required at least six measured coordinates to predict the unbalance with an error of 4 to 36%. To overcome this limitation, an alternate method, eliminating the use of modal expansion, is proposed. Here, displacements generated by varying the location of a reference unbalance along the rotor axis, are compared to measured displacements to detect the unbalance location. Furthermore, instead of force-based fault models, the minimization of displacements at measured locations determines the unbalance parameters. The test case in this study is the guiding roll of a paper machine and its different unbalance states. The algorithm is tested initially with a simulation-based model and then validated with an experimental set up. The results show that the displacement method can locate the unbalance close to the actual location and it can predict the unbalance magnitude and phase with only two measured coordinates. Lastly, using measured data from 15 measurement points across the tube section of the test rotor, a comparison shows how the selection of the two measured locations affects the estimation accuracy. Full article
Show Figures

Figure 1

Open AccessArticle
A Novel Adaptive and Nonlinear Electrohydraulic Active Suspension Control System with Zero Dynamic Tire Liftoff
Machines 2020, 8(3), 38; https://doi.org/10.3390/machines8030038 - 11 Jul 2020
Viewed by 285
Abstract
In this paper, a novel adaptive control system (NAC) is proposed for a restricted quarter-car electrohydraulic active suspension system. The main contribution of this NAC is its explicit tackling of the trade-off between passenger comfort/road holding and passenger comfort/suspension travel. Reducing suspension travel [...] Read more.
In this paper, a novel adaptive control system (NAC) is proposed for a restricted quarter-car electrohydraulic active suspension system. The main contribution of this NAC is its explicit tackling of the trade-off between passenger comfort/road holding and passenger comfort/suspension travel. Reducing suspension travel oscillations is another control target that was considered. Many researchers have developed control laws for constrained active suspension systems. However, most of the studies in the works of the latter have not directly examined the compromise between road holding, suspension travel, and passenger comfort. In this study, we proposed a novel adaptive control system to explicitly address the trade-off between passenger comfort and road holding, as well as the compromise between passenger comfort and suspension travel limits. The novelty of our control technique lies in its introduction of a modeling system for a dynamic landing tire system aimed at avoiding a dynamic tire liftoff. The proposed control consists of an adaptive neural networks’ backstepping control, coupled with a nonlinear control filter system aimed at tracking the output position of the nonlinear filter. The tracking control position is the difference between the sprung mass position and the output nonlinear filter signal. The results indicate that the novel adaptive control (NAC) can achieve the handling of car–road stability, ride comfort, and safe suspension travel compared to that of the other studies, demonstrating the controller’s effectiveness. Full article
(This article belongs to the Special Issue Intelligent Mechatronics Systems)
Show Figures

Figure 1

Open AccessReview
Sources of Excitation and Models for Cylindrical Gear Dynamics: A Review
Machines 2020, 8(3), 37; https://doi.org/10.3390/machines8030037 - 01 Jul 2020
Viewed by 308
Abstract
In this paper, a review of the evolution of the study of cylindrical gear dynamics is presented. After a brief historical introduction to the field, the first attempts to describe the complex interactions in those systems are analyzed introducing the dynamic factor and [...] Read more.
In this paper, a review of the evolution of the study of cylindrical gear dynamics is presented. After a brief historical introduction to the field, the first attempts to describe the complex interactions in those systems are analyzed introducing the dynamic factor and the first methodologies used to compute it. Next, the sources of excitation in geared systems are analyzed in detail and the models of the various contributions are discussed. Then, the paper focuses on the use of those sources in several dynamic models which are wildly different in terms of scope, applicability, complexity and methodology employed, ranging from simple analytical models, to lumped masses models up to multibody and finite element models. Finally, an outlook to the future evolution of the field is given and conclusions are drawn. Full article
Show Figures

Figure 1

Open AccessArticle
Electrical Discharge Machining with SiC Powder-Mixed Dielectric: An Effective Application in the Machining Process of Hardened 90CrSi Steel
Machines 2020, 8(3), 36; https://doi.org/10.3390/machines8030036 - 01 Jul 2020
Viewed by 297
Abstract
As a successful solution applied to electrical discharge machining (EDM), powder-mixed electrical discharge machining (PMEDM) has been proposed as an upgrade of the EDM process. The optimization of the process parameters of PMEDM is essential and pressing. In this study, Taguchi methods and [...] Read more.
As a successful solution applied to electrical discharge machining (EDM), powder-mixed electrical discharge machining (PMEDM) has been proposed as an upgrade of the EDM process. The optimization of the process parameters of PMEDM is essential and pressing. In this study, Taguchi methods and analysis of variance (ANOVA) were used to find the main parameters affecting surface roughness in the EDM process with SiC powder-mixed-dielectric of hardened 90CrSi steel. The PMEDM parameters selected were the powder concentration, the pulse-on-time, the pulse-off-time, the pulse current, and the server voltage. It was found that SiC powder exhibits positive effects on reducing surface roughness. The roughness obtained with the optimum powder concentration of 4 g/L was reduced by 30.02% compared to that when processed by conventional EDM. Furthermore, the pulse-off-time was found to be the most influential factor that gave an important effect on surface roughness followed by the powder concentration. The EDM condition including a powder concentration of 4 g/L, a pulse-on-time of 6 µs, a pulse-off-time of 21 µs, a pulse current of 8 A, and a server voltage of 4 V resulted in the best surface roughness. Full article
(This article belongs to the Section Advanced Manufacturing)
Show Figures

Figure 1

Open AccessFeature PaperArticle
Motor Current Signature Analysis-Based Permanent Magnet Synchronous Motor Demagnetization Characterization and Detection
Machines 2020, 8(3), 35; https://doi.org/10.3390/machines8030035 - 29 Jun 2020
Viewed by 318
Abstract
Neodymium-boron (NdFeB) permanent magnets (PMs) have been widely studied in the past years since they became the material of choice in permanent magnet synchronous machines (PMSMs). Although NdFeB PMs have a better energy density than other types of magnets and are cost-effective, their [...] Read more.
Neodymium-boron (NdFeB) permanent magnets (PMs) have been widely studied in the past years since they became the material of choice in permanent magnet synchronous machines (PMSMs). Although NdFeB PMs have a better energy density than other types of magnets and are cost-effective, their magnetization is very sensitive to the PMSM operating conditions, in particular temperature, where the irreversible demagnetization degree increases over time. Therefore, it is important to characterize and diagnose demagnetization at an early stage. In this context, this paper proposes a two-step analysis study dealing with both uniform and partial demagnetization. A 2D finite element method-based (FEM) approach is used for demagnetization characterization, and then a PMSM motor current signature analysis (MCSA) approach, based on fast Fourier transform (FFT), is considered where fault cases harmonics are considered as faults indices to detect demagnetization. In some situations, the proposed two-step approach achieved results that clearly allow distinguishing and characterizing demagnetization. Indeed, a local demagnetization introduces specific sub-harmonics while a uniform demagnetization leads to the current amplitude increase for a given torque. Full article
Show Figures

Figure 1
