Micromachines, Volume 11, Issue 7 (July 2020) – 49 articles

  • Issues are regarded as officially published after their release is announced to the table of contents alert mailing list.
  • You may sign up for e-mail alerts to receive table of contents of newly released issues.
  • PDF is the official format for papers published in both, html and pdf forms. To view the papers in pdf format, click on the "PDF Full-text" link, and use the free Adobe Readerexternal link to open them.
Order results
Result details
Select all
Export citation of selected articles as:
Open AccessArticle
Electrical Properties of Ultra-Fast 3D-Trench Electrode Silicon Detector
Micromachines 2020, 11(7), 674; https://doi.org/10.3390/mi11070674 - 10 Jul 2020
Abstract
In our previous work on ultra-fast silicon detectors, extremely small carrier drift times of 50–100 picoseconds were predicted for electrode spacing of 5–10 μm. Expanding on these previous works, we systematically study the electrical characteristics of the ultra-fast, 3D-trench electrode silicon detector cell [...] Read more.
In our previous work on ultra-fast silicon detectors, extremely small carrier drift times of 50–100 picoseconds were predicted for electrode spacing of 5–10 μm. Expanding on these previous works, we systematically study the electrical characteristics of the ultra-fast, 3D-trench electrode silicon detector cell with p-type bulk silicon, such as electric potential distribution, electric field distribution, hole concentration distribution, and leakage current to analyze the full detector depletion voltage and other detector properties. To verify the prediction of ultra-fast response times, we simulate the instant induced current curves before and after irradiation with different minimum ionizing particle (MIP) hitting positions. High position resolution pixel detectors can be fabricated by constructing an array of these extremely small detector cells. Full article
(This article belongs to the Special Issue 3D Pixel Sensors and Detectors)
Open AccessArticle
Optofluidic Formaldehyde Sensing: Towards On-Chip Integration
Micromachines 2020, 11(7), 673; https://doi.org/10.3390/mi11070673 - 10 Jul 2020
Abstract
Formaldehyde (HCHO), a chemical compound used in the fabrication process of a broad range of household products, is present indoors as an airborne pollutant due to its high volatility caused by its low boiling point ( T = 19 °C). Miniaturization of [...] Read more.
Formaldehyde (HCHO), a chemical compound used in the fabrication process of a broad range of household products, is present indoors as an airborne pollutant due to its high volatility caused by its low boiling point ( T = 19 °C). Miniaturization of analytical systems towards palm-held devices has the potential to provide more efficient and more sensitive tools for real-time monitoring of this hazardous air pollutant. This work presents the initial steps and results of the prototyping process towards on-chip integration of HCHO sensing, based on the Hantzsch reaction coupled to the fluorescence optical sensing methodology. This challenge was divided into two individually addressed problems: (1) efficient airborne HCHO trapping into a microfluidic context and (2) 3,5–diacetyl-1,4-dihydrolutidine (DDL) molecular sensing in low interrogation volumes. Part (2) was addressed in this paper by proposing, fabricating, and testing a fluorescence detection system based on an ultra-low light Complementary metal-oxide-semiconductor (CMOS) image sensor. Two three-layer fluidic cell configurations (quartz–SU-8–quartz and silicon–SU-8–quartz) were tested, with both possessing a 3.5 µL interrogation volume. Finally, the CMOS-based fluorescence system proved the capability to detect an initial 10 µg/L formaldehyde concentration fully derivatized into DDL for both the quartz and silicon fluidic cells, but with a higher signal-to-noise ratio (SNR) for the silicon fluidic cell ( S N R s i l i c o n = 6.1 ) when compared to the quartz fluidic cell ( S N R q u a r t z = 4.9 ). The signal intensity enhancement in the silicon fluidic cell was mainly due to the silicon absorption coefficient at the excitation wavelength,   a ( λ a b s = 420   nm ) = 5 × 10 4   cm 1 , which is approximately five times higher than the absorption coefficient at the fluorescence emission wavelength, a ( λ e m = 515   nm ) = 9.25 × 10 3   cm 1 . Full article
Show Figures

Graphical abstract

Open AccessArticle
Design and Implementation of a Multifunction Wearable Device to Monitor Sleep Physiological Signals
Micromachines 2020, 11(7), 672; https://doi.org/10.3390/mi11070672 - 10 Jul 2020
Abstract
We present a wearable device built on an Adafruit Circuit Playground Express (CPE) board and integrated with a photoplethysmographic (PPG) optical sensor for heart rate monitoring and multiple embedded sensors for medical applications—in particular, sleep physiological signal monitoring. Our device is portable and [...] Read more.
We present a wearable device built on an Adafruit Circuit Playground Express (CPE) board and integrated with a photoplethysmographic (PPG) optical sensor for heart rate monitoring and multiple embedded sensors for medical applications—in particular, sleep physiological signal monitoring. Our device is portable and lightweight. Due to the microcontroller unit (MCU)-based architecture of the proposed device, it is scalable and flexible. Thus, with the addition of different plug-and-play sensors, it can be used in many applications in different fields. The innovation introduced in this study is that with additional sensors, we can determine whether there are intermediary variables that can be modified to improve our sleep monitoring algorithm. Additionally, although the proposed device has a relatively low cost, it achieves substantially improved performance compared to the commercially available Philips ActiWatch2 wearable device, which has been approved by the Food and Drug Administration (FDA). To assess the reliability of our device, we compared physiological sleep signals recorded simultaneously from volunteers using both our device and ActiWatch2. Motion and light detection data from our device were shown to be correlated to data simultaneously collected using the ActiWatch2, with correlation coefficients of 0.78 and 0.89, respectively. For 7 days of continuous data collection, there was only one instance of a false positive, in which our device detected a sleep interval, while the ActiWatch2 did not. The most important aspect of our research is the use of an open architecture. At the hardware level, general purpose input/output (GPIO), serial peripheral interface (SPI), integrated circuit (I2C), and universal asynchronous receiver-transmitter (UART) standards were used. At the software level, an object-oriented programming methodology was used to develop the system. Because the use of plug-and-play sensors is associated with the risk of adverse outcomes, such as system instability, this study heavily relied on object-oriented programming. Object-oriented programming improves system stability when hardware components are replaced or upgraded, allowing us to change the original system components at a low cost. Therefore, our device is easily scalable and has low commercialization costs. The proposed wearable device can facilitate the long-term tracking of physiological signals in sleep monitoring and related research. The open architecture of our device facilitates collaboration and allows other researchers to adapt our device for use in their own research, which is the main characteristic and contribution of this study. Full article
Open AccessArticle
Reconstructing of Embedded High-Aspect-Ratio Nano-Voids Generated by Ultrafast Laser Bessel Beams
Micromachines 2020, 11(7), 671; https://doi.org/10.3390/mi11070671 - 10 Jul 2020
Abstract
Ultrafast non-diffractive Bessel laser beams provide strong light confinement and show robust advantages for fabricating high-aspect-ratio nanoscale structures inside transparent materials. They take the form of nanoscale voids with typical diameters well below the wavelength and aspect ratio of more than 1000. Delivering [...] Read more.
Ultrafast non-diffractive Bessel laser beams provide strong light confinement and show robust advantages for fabricating high-aspect-ratio nanoscale structures inside transparent materials. They take the form of nanoscale voids with typical diameters well below the wavelength and aspect ratio of more than 1000. Delivering 3D morphologies of such nanoscale voids is an important issue to evaluate the result for fabrication. However, the characterization of such laser-induced structures is a difficult task. Here, an accurate and time-saving tomography-like methodology is proposed and adopted for reconstructing the morphology of high-aspect-ratio nano-holes. The technique allows an accurate assertion of laser parameters and position on nano-structured features. The reconstructed configuration reveals that nanoholes morphologies have a close relationship with energy distribution in the focal region. It suggests that the configuration of micro-explosion can be controlled by laser energy deposition in the process of laser-matter interaction down to the nanoscale. Full article
Show Figures

Figure 1

Open AccessEditorial
Editorial for the Special Issue on Silicon Photonics Bloom
Micromachines 2020, 11(7), 670; https://doi.org/10.3390/mi11070670 - 10 Jul 2020
Viewed by 45
(This article belongs to the Special Issue Silicon Photonics Bloom)
Open AccessArticle
Quantitative Image-Based Cell Viability (QuantICV) Assay for Microfluidic 3D Tissue Culture Applications
Micromachines 2020, 11(7), 669; https://doi.org/10.3390/mi11070669 - 09 Jul 2020
Viewed by 118
Abstract
Microfluidic 3D tissue culture systems are attractive for in vitro drug testing applications due to the ability of these platforms to generate 3D tissue models and perform drug testing at a very small scale. However, the minute cell number and liquid volume impose [...] Read more.
Microfluidic 3D tissue culture systems are attractive for in vitro drug testing applications due to the ability of these platforms to generate 3D tissue models and perform drug testing at a very small scale. However, the minute cell number and liquid volume impose significant technical challenges to perform quantitative cell viability measurements using conventional colorimetric or fluorometric assays, such as MTS or Alamar Blue. Similarly, live-dead staining approaches often utilize metabolic dyes that typically label the cytoplasm of live cells, which makes it difficult to segment and count individual cells in compact 3D tissue cultures. In this paper, we present a quantitative image-based cell viability (QuantICV) assay technique that circumvents current challenges of performing the quantitative cell viability assay in microfluidic 3D tissue cultures. A pair of cell-impermeant nuclear dyes (EthD-1 and DAPI) were used to sequentially label the nuclei of necrotic and total cell populations, respectively. Confocal microscopy and image processing algorithms were employed to visualize and quantify the cell nuclei in the 3D tissue volume. The QuantICV assay was validated and showed good concordance with the conventional bulk MTS assay in static 2D and 3D tumor cell cultures. Finally, the QuantICV assay was employed as an on-chip readout to determine the differential dose responses of parental and metastatic 3D oral squamous cell carcinoma (OSCC) to Gefitinib in a microfluidic 3D culture device. This proposed technique can be useful in microfluidic cell cultures as well as in a situation where conventional cell viability assays are not available. Full article
(This article belongs to the Special Issue Microfluidics for Cells and Other Organisms, Volume II)
Show Figures

Figure 1

Open AccessArticle
Mechanical Characterisation and Analysis of a Passive Micro Heat Exchanger
Micromachines 2020, 11(7), 668; https://doi.org/10.3390/mi11070668 - 09 Jul 2020
Viewed by 107
Abstract
Heat exchangers are widely used in many mechanical, electronic, and bioengineering applications at macro and microscale. Among these, the use of heat exchangers consisting of a single fluid passing through a set of geometries at different temperatures and two flows in T-shape channels [...] Read more.
Heat exchangers are widely used in many mechanical, electronic, and bioengineering applications at macro and microscale. Among these, the use of heat exchangers consisting of a single fluid passing through a set of geometries at different temperatures and two flows in T-shape channels have been extensively studied. However, the application of heat exchangers for thermal mixing over a geometry leading to vortex shedding has not been investigated. This numerical work aims to analyse and characterise a heat exchanger for microscale application, which consists of two laminar fluids at different temperature that impinge orthogonally onto a rectangular structure and generate vortex shedding mechanics that enhance thermal mixing. This work is novel in various aspects. This is the first work of its kind on heat transfer between two fluids (same fluid, different temperature) enhanced by vortex shedding mechanics. Additionally, this research fully characterise the underlying vortex mechanics by accounting all geometry and flow regime parameters (longitudinal aspect ratio, blockage ratio and Reynolds number), opposite to the existing works in the literature, which usually vary and analyse blockage ratio or longitudinal aspect ratio only. A relevant advantage of this heat exchanger is that represents a low-Reynolds passive device, not requiring additional energy nor moving elements to enhance thermal mixing. This allows its use especially at microscale, for instance in biomedical/biomechanical and microelectronic applications. Full article
(This article belongs to the Special Issue Analysis, Design and Fabrication of Micromixers)
Show Figures

Figure 1

Open AccessReview
Recent Developments of PFAS-Detecting Sensors and Future Direction: A Review
Micromachines 2020, 11(7), 667; https://doi.org/10.3390/mi11070667 - 08 Jul 2020
Viewed by 254
Abstract
Per- and poly-fluoroalkyl substances (PFASs) have recently been labeled as toxic constituents that exist in many aqueous environments. However, traditional methods used to determine the level of PFASs are often not appropriate for continuous environmental monitoring and management. Based on the current state [...] Read more.
Per- and poly-fluoroalkyl substances (PFASs) have recently been labeled as toxic constituents that exist in many aqueous environments. However, traditional methods used to determine the level of PFASs are often not appropriate for continuous environmental monitoring and management. Based on the current state of research, PFAS-detecting sensors have surfaced as a promising method of determination. These sensors are an innovative solution with characteristics that allow for in situ, low-cost, and easy-to-use capabilities. This paper presents a comprehensive review of the recent developments in PFAS-detecting sensors, and why the literature on determination methods has shifted in this direction compared to the traditional methods used. PFAS-detecting sensors discussed herein are primarily categorized in terms of the detection mechanism used. The topics covered also include the current limitations, as well as insight on the future direction of PFAS analyses. This paper is expected to be useful for the smart sensing technology development of PFAS detection methods and the associated environmental management best practices in smart cities of the future. Full article
(This article belongs to the Special Issue Micromachined Environmental Sensors)
Open AccessReview
Grating Couplers on Silicon Photonics: Design Principles, Emerging Trends and Practical Issues
Micromachines 2020, 11(7), 666; https://doi.org/10.3390/mi11070666 - 08 Jul 2020
Viewed by 179
Abstract
Silicon photonics is an enabling technology that provides integrated photonic devices and systems with low-cost mass manufacturing capability. It has attracted increasing attention in both academia and industry in recent years, not only for its applications in communications, but also in sensing. One [...] Read more.
Silicon photonics is an enabling technology that provides integrated photonic devices and systems with low-cost mass manufacturing capability. It has attracted increasing attention in both academia and industry in recent years, not only for its applications in communications, but also in sensing. One important issue of silicon photonics that comes with its high integration density is an interface between its high-performance integrated waveguide devices and optical fibers or free-space optics. Surface grating coupler is a preferred candidate that provides flexibility for circuit design and reduces effort for both fabrication and alignment. In the past decades, considerable research efforts have been made on in-plane grating couplers to address their insufficiency in coupling efficiency, wavelength sensitivity and polarization sensitivity compared with out-of-plane edge-coupling. Apart from improved performances, new functionalities are also on the horizon for grating couplers. In this paper, we review the current research progresses made on grating couplers, starting from their fundamental theories and concepts. Then, we conclude various methods to improve their performance, including coupling efficiency, polarization and wavelength sensitivity. Finally, we discuss some emerging research topics on grating couplers, as well as practical issues such as testing, packaging and promising applications. Full article
Open AccessArticle
In-Pixel Temperature Sensors with an Accuracy of ±0.25 °C, a 3σ Variation of ±0.7 °C in the Spatial Domain and a 3σ Variation of ±1 °C in the Temporal Domain
Micromachines 2020, 11(7), 665; https://doi.org/10.3390/mi11070665 - 08 Jul 2020
Viewed by 136
Abstract
This article presents in-pixel (of a CMOS image sensor (CIS)) temperature sensors with improved accuracy in the spatial and the temporal domain. The goal of the temperature sensors is to be used to compensate for dark (current) fixed pattern noise (FPN) during the [...] Read more.
This article presents in-pixel (of a CMOS image sensor (CIS)) temperature sensors with improved accuracy in the spatial and the temporal domain. The goal of the temperature sensors is to be used to compensate for dark (current) fixed pattern noise (FPN) during the exposure of the CIS. The temperature sensors are based on substrate parasitic bipolar junction transistor (BJT) and on the nMOS source follower of the pixel. The accuracy of these temperature sensors has been improved in the analog domain by using dynamic element matching (DEM), a temperature independent bias current based on a bandgap reference (BGR) with a temperature independent resistor, correlated double sampling (CDS), and a full BGR bias of the gain amplifier. The accuracy of the bipolar based temperature sensor has been improved to a level of ±0.25 °C, a 3σ variation of ±0.7 °C in the spatial domain, and a 3σ variation of ±1 °C in the temporal domain. In the case of the nMOS based temperature sensor, an accuracy of ±0.45 °C, 3σ variation of ±0.95 °C in the spatial domain, and ±1.4 °C in the temporal domain have been acquired. The temperature range is between −40 °C and 100 °C. Full article
Show Figures

Figure 1

Open AccessArticle
Effect of Annealing on the Thermoelectricity Properties of the WRe26-In2O3 Thin Film Thermocouples
Micromachines 2020, 11(7), 664; https://doi.org/10.3390/mi11070664 - 07 Jul 2020
Viewed by 170
Abstract
WRe26-In2O3 (WRe26 (tungsten-26% rhenium) and In2O3 thermoelectric materials) thin film thermocouples (TFTCs) have been fabricated based on magnetron sputtering technology, which can be used in temperature measurement. Many annealing processes were studied to promote the sensitivity of [...] Read more.
WRe26-In2O3 (WRe26 (tungsten-26% rhenium) and In2O3 thermoelectric materials) thin film thermocouples (TFTCs) have been fabricated based on magnetron sputtering technology, which can be used in temperature measurement. Many annealing processes were studied to promote the sensitivity of WRe26-In2O3 TFTCs. The optimal annealing process of the thermocouple under this kind of RF magnetron sputtering method was proposed after analyzing the properties of In2O3 films and the thermoelectric voltage of TFTCs at different annealing processes. The calibration results showed that the WRe26-In2O3 TFTCs achieved a thermoelectric voltage of 123.6 mV at a temperature difference of 612.9 K, with a sensitivity of up to 201.6 µV/K. Also, TFTC kept a stable thermoelectric voltage output at 973 K for 20 min and at 773 K for two hours. In general, the WRe26-In2O3 TFTCs developed in this work have great potential for practical applications. In future work, we will focus on the thermoelectric stability of TFTCs at higher temperatures. Full article
(This article belongs to the Special Issue Micro Process-Devices)
Show Figures

Figure 1

Open AccessArticle
Three-Dimensional Regeneration of Patient-Derived Intestinal Organoid Epithelium in a Physiodynamic Mucosal Interface-on-a-Chip
Micromachines 2020, 11(7), 663; https://doi.org/10.3390/mi11070663 - 07 Jul 2020
Viewed by 168
Abstract
The regeneration of the mucosal interface of the human intestine is critical in the host–gut microbiome crosstalk associated with gastrointestinal diseases. The biopsy-derived intestinal organoids provide genetic information of patients with physiological cytodifferentiation. However, the enclosed lumen and static culture condition substantially limit [...] Read more.
The regeneration of the mucosal interface of the human intestine is critical in the host–gut microbiome crosstalk associated with gastrointestinal diseases. The biopsy-derived intestinal organoids provide genetic information of patients with physiological cytodifferentiation. However, the enclosed lumen and static culture condition substantially limit the utility of patient-derived organoids for microbiome-associated disease modeling. Here, we report a patient-specific three-dimensional (3D) physiodynamic mucosal interface-on-a-chip (PMI Chip) that provides a microphysiological intestinal milieu under defined biomechanics. The real-time imaging and computational simulation of the PMI Chip verified the recapitulation of non-linear luminal and microvascular flow that simulates the hydrodynamics in a living human gut. The multiaxial deformations in a convoluted microchannel not only induced dynamic cell strains but also enhanced particle mixing in the lumen microchannel. Under this physiodynamic condition, an organoid-derived epithelium obtained from the patients diagnosed with Crohn’s disease, ulcerative colitis, or colorectal cancer independently formed 3D epithelial layers with disease-specific differentiations. Moreover, co-culture with the human fecal microbiome in an anoxic–oxic interface resulted in the formation of stochastic microcolonies without a loss of epithelial barrier function. We envision that the patient-specific PMI Chip that conveys genetic, epigenetic, and environmental factors of individual patients will potentially demonstrate the pathophysiological dynamics and complex host–microbiome crosstalk to target a patient-specific disease modeling. Full article
Show Figures

Figure 1

Open AccessArticle
Developing a Novel Miniature 3D-Printed TLBS with High Mechanical Efficiency and Better Controllability
Micromachines 2020, 11(7), 662; https://doi.org/10.3390/mi11070662 - 04 Jul 2020
Viewed by 171
Abstract
This paper focuses on the development of a 3D-printed threadless ball screw (TLBS) for the applications that require miniaturization, customization, and accuracy controllability. To enhance the efficiency of the TLBS, a novel model of the TLBS for analyzing the mechanical efficiency is presented [...] Read more.
This paper focuses on the development of a 3D-printed threadless ball screw (TLBS) for the applications that require miniaturization, customization, and accuracy controllability. To enhance the efficiency of the TLBS, a novel model of the TLBS for analyzing the mechanical efficiency is presented to obtain the key affecting factors. From these factors, the design parameters for fabrication are determined. For miniaturization, a novel 3D-printed one-piece preloaded structure of light weight of 0.9 g is implemented as the TLBS nut part. Experimental results show that the measured mechanical efficiency of TLBS is close to that predicted by the theoretical model with a normalized root mean square error of 3.16%. In addition, the mechanical efficiency of the present TLBS (maximum efficiency close to 90%) is better than that of the lead screw and close to the ball screw. The unique characteristic of the present TLBS is that its total torque loss is a weak function of the load, a phenomenon not observed in either the ball screw or the lead screw. This characteristic is advantageous in enhancing the controllability of accuracy at different loads. Full article
Show Figures

Figure 1

Open AccessArticle
Shaping Soft Robotic Microactuators by Wire Electrical Discharge Grinding
Micromachines 2020, 11(7), 661; https://doi.org/10.3390/mi11070661 - 04 Jul 2020
Viewed by 273
Abstract
Inflatable soft microactuators typically consist of an elastic material with an internal void that can be inflated to generate a deformation. A crucial feature of these actuators is the shape of ther inflatable void as it determines the bending motion. Due to fabrication [...] Read more.
Inflatable soft microactuators typically consist of an elastic material with an internal void that can be inflated to generate a deformation. A crucial feature of these actuators is the shape of ther inflatable void as it determines the bending motion. Due to fabrication limitations, low complex void geometries are the de facto standard, severely restricting attainable motions. This paper introduces wire electrical discharge grinding (WEDG) for shaping the inflatable void, increasing their complexity. This approach enables the creation of new deformation patterns and functionalities. The WEDG process is used to create various moulds to cast rubber microactuators. These microactuators are fabricated through a bonding-free micromoulding process, which is highly sensitive to the accuracy of the mould. The mould cavity (outside of the actuator) is defined by micromilling, whereas the mould insert (inner cavity of the actuator) is defined by WEDG. The deformation patterns are evaluated with a multi-segment linear bending model. The produced microactuators are also characterised and compared with respect to the morphology of the inner cavity. All microactuators have a cylindrical shape with a length of 8 mm and a diameter of 0.8 mm. Actuation tests at a maximum pressure of 50 kPa indicate that complex deformation patterns such as curling, differential bending or multi-points bending can be achieved. Full article
Show Figures

Figure 1

Open AccessArticle
An Electrochemical Immunosensor for Sensitive Detection of the Tumor Marker Carcinoembryonic Antigen (CEA) Based on Three-Dimensional Porous Nanoplatinum/Graphene
Micromachines 2020, 11(7), 660; https://doi.org/10.3390/mi11070660 - 03 Jul 2020
Viewed by 173
Abstract
Carcinoembryonic antigen (CEA) is an important broad-spectrum tumor marker. The quantitative detection of a low concentration of CEA has important medical significance. In this study, three-dimensional porous graphene-oxide-supported platinum metal nanoparticles (3DPt/HGO) composites were prepared by a wet chemical method and modified on [...] Read more.
Carcinoembryonic antigen (CEA) is an important broad-spectrum tumor marker. The quantitative detection of a low concentration of CEA has important medical significance. In this study, three-dimensional porous graphene-oxide-supported platinum metal nanoparticles (3DPt/HGO) composites were prepared by a wet chemical method and modified on an electrode with enhanced conductivity, a large surface area, and good adsorption of immobilizing antibodies (Ab1). Horseradish peroxidase (HRP)-functionalized Au nanoparticles were fabricated to label the secondary antibodies (Ab2). The proposed immunosensor showed a good linear relationship in the range of 0.001–150 ng/mL for CEA and a detection limit of 0.0006 ng/mL. The immunosensor had high sensitivity, good stability and reproducibility, and has great application prospects for the clinical diagnosis of cancer. Full article
(This article belongs to the Special Issue Graphene based Electronic Devices)
Show Figures

Graphical abstract

Open AccessArticle
Effect of Geometric Curvature on Collective Cell Migration in Tortuous Microchannel Devices
Micromachines 2020, 11(7), 659; https://doi.org/10.3390/mi11070659 - 02 Jul 2020
Viewed by 217
Abstract
Collective cell migration is an essential phenomenon in many naturally occurring pathophysiological processes, as well as in tissue engineering applications. Cells in tissues and organs are known to sense chemical and mechanical signals from the microenvironment and collectively respond to these signals. For [...] Read more.
Collective cell migration is an essential phenomenon in many naturally occurring pathophysiological processes, as well as in tissue engineering applications. Cells in tissues and organs are known to sense chemical and mechanical signals from the microenvironment and collectively respond to these signals. For the last few decades, the effects of chemical signals such as growth factors and therapeutic agents on collective cell behaviors in the context of tissue engineering have been extensively studied, whereas those of the mechanical cues have only recently been investigated. The mechanical signals can be presented to the constituent cells in different forms, including topography, substrate stiffness, and geometrical constraint. With the recent advancement in microfabrication technology, researchers have gained the ability to manipulate the geometrical constraints by creating 3D structures to mimic the tissue microenvironment. In this study, we simulate the pore curvature as presented to the cells within 3D-engineered tissue-scaffolds by developing a device that features tortuous microchannels with geometric variations. We show that both cells at the front and rear respond to the varying radii of curvature and channel amplitude by altering the collective migratory behavior, including cell velocity, morphology, and turning angle. These findings provide insights into adaptive migration modes of collective cells to better understand the underlying mechanism of cell migration for optimization of the engineered tissue-scaffold design. Full article
Show Figures

Figure 1

Open AccessReview
Powder-Based 3D Printing for the Fabrication of Device with Micro and Mesoscale Features
Micromachines 2020, 11(7), 658; https://doi.org/10.3390/mi11070658 - 30 Jun 2020
Viewed by 305
Abstract
Customized manufacturing of a miniaturized device with micro and mesoscale features is a key requirement of mechanical, electrical, electronic and medical devices. Powder-based 3D-printing processes offer a strong candidate for micromanufacturing due to the wide range of materials, fast production and high accuracy. [...] Read more.
Customized manufacturing of a miniaturized device with micro and mesoscale features is a key requirement of mechanical, electrical, electronic and medical devices. Powder-based 3D-printing processes offer a strong candidate for micromanufacturing due to the wide range of materials, fast production and high accuracy. This study presents a comprehensive review of the powder-based three-dimensional (3D)-printing processes and how these processes impact the creation of devices with micro and mesoscale features. This review also focuses on applications of devices with micro and mesoscale size features that are created by powder-based 3D-printing technology. Full article
(This article belongs to the Special Issue 10th Anniversary of Micromachines)
Show Figures

Figure 1

Open AccessArticle
Correlated Time-0 and Hot-Carrier Stress Induced FinFET Parameter Variabilities: Modeling Approach
Micromachines 2020, 11(7), 657; https://doi.org/10.3390/mi11070657 - 30 Jun 2020
Viewed by 236
Abstract
We identify correlation between the drain currents in pristine n-channel FinFET transistors and changes in time-0 currents induced by hot-carrier stress. To achieve this goal, we employ our statistical simulation model for hot-carrier degradation (HCD), which considers the effect of random dopants (RDs) [...] Read more.
We identify correlation between the drain currents in pristine n-channel FinFET transistors and changes in time-0 currents induced by hot-carrier stress. To achieve this goal, we employ our statistical simulation model for hot-carrier degradation (HCD), which considers the effect of random dopants (RDs) on HCD. For this analysis we generate a set of 200 device instantiations where each of them has its own unique configuration of RDs. For all “samples” in this ensemble we calculate time-0 currents (i.e. currents in undamaged FinFETs) and then degradation characteristics such as changes in the linear drain current and device lifetimes. The robust correlation analysis allows us to identify correlation between transistor lifetimes and drain currents in unstressed devices, which implies that FinFETs with initially higher currents degrade faster, i.e. have more prominent linear drain current changes and shorter lifetimes. Another important result is that although at stress conditions the distribution of drain currents becomes wider with stress time, in the operating regime drain current variability diminishes. Finally, we show that if random traps are also taken into account, all the obtained trends remain the same. Full article
Open AccessArticle
Rolling Nanoelectrode Lithography
Micromachines 2020, 11(7), 656; https://doi.org/10.3390/mi11070656 - 30 Jun 2020
Viewed by 197
Abstract
Non-uniformity and low throughput issues severely limit the application of nanoelectrode lithography for large area nanopatterning. This paper proposes, for the first time, a new rolling nanoelectrode lithography approach to overcome these challenges. A test-bed was developed to realize uniform pressure distribution over [...] Read more.
Non-uniformity and low throughput issues severely limit the application of nanoelectrode lithography for large area nanopatterning. This paper proposes, for the first time, a new rolling nanoelectrode lithography approach to overcome these challenges. A test-bed was developed to realize uniform pressure distribution over the whole contact area between the roller and the silicon specimen, so that the local oxidation process occurred uniformly over a large area of the specimen. In this work, a brass roller wrapped with a fabricated polycarbonate strip was used as a stamp to generate nanopatterns on a silicon surface. The experimental results show that a uniform pattern transfer for a large area can be achieved with this new rolling nanoelectrode lithography approach. The rolling speed and the applied bias voltage were identified as the primary control parameters for oxide growth. Furthermore, the pattern direction showed no significant influence on the oxide process. We therefore demonstrated that nanoelectrode lithography can be scaled up for large-area nanofabrication by incorporating a roller stamp. Full article
(This article belongs to the Special Issue Ultra Precision Technologies for Micromachining)
Show Figures

Figure 1

Open AccessArticle
Design of Graphene Phononic Crystals for Heat Phonon Engineering
Micromachines 2020, 11(7), 655; https://doi.org/10.3390/mi11070655 - 30 Jun 2020
Viewed by 214
Abstract
Controlling the heat transport and thermal conductivity through a material is of prime importance for thermoelectric applications. Phononic crystals, which are a nanostructured array of specially designed pores, can suppress heat transportation owing to the phonon wave interference, resulting in bandgap formation in [...] Read more.
Controlling the heat transport and thermal conductivity through a material is of prime importance for thermoelectric applications. Phononic crystals, which are a nanostructured array of specially designed pores, can suppress heat transportation owing to the phonon wave interference, resulting in bandgap formation in their band structure. To control heat phonon propagation in thermoelectric devices, phononic crystals with a bandgap in the THz regime are desirable. In this study, we carried out simulation on snowflake shaped phononic crystal and obtained several phononic bandgaps in the THz regime, with the highest being at ≈2 THz. The phononic bandgap position and the width of the bandgap were found to be tunable by varying the neck-length of the snowflake structure. A unique bandgap map computed by varying the neck-length continuously provides enormous amounts of information as to the size and position of the phononic bandgap for various pore dimensions. We have also carried out transmission spectrum analysis and found good agreement with the band structure calculations. The pressure map visualized at various frequencies validates the effectiveness of snowflake shaped nano-pores in suppressing the phonons partially or completely, depending on the transmission probabilities. Full article
(This article belongs to the Section A:Physics)
Show Figures

Figure 1

Open AccessArticle
Feasibility Study of an Automated Assembly Process for Ultrathin Chips
Micromachines 2020, 11(7), 654; https://doi.org/10.3390/mi11070654 - 30 Jun 2020
Viewed by 193
Abstract
This paper presents a feasibility study of an automated pick-and-place process for ultrathin chips on a standard automatic assembly machine. So far, scientific research about automated assembly of ultrathin chips, with thicknesses less than 50 µm, is missing, but is necessary for cost-effective, [...] Read more.
This paper presents a feasibility study of an automated pick-and-place process for ultrathin chips on a standard automatic assembly machine. So far, scientific research about automated assembly of ultrathin chips, with thicknesses less than 50 µm, is missing, but is necessary for cost-effective, high-quantity production of system-in-foil for applications in narrow spaces or flexible smart health systems applied in biomedical applications. Novel pick-and-place tools for ultrathin chip handling were fabricated and a process for chip detachment from thermal release foil was developed. On this basis, an adhesive bonding process for ultrathin chips with 30 µm thickness was developed and transferred to an automatic assembly machine. Multiple ultrathin chips aligned to each other were automatically placed and transferred onto glass and polyimide foil with a relative placement accuracy of ±25 µm. Full article
(This article belongs to the Section E:Engineering and Technology)
Show Figures

Figure 1

Open AccessArticle
Dielectrophoretic Microfluidic Device for Separating Microparticles Based on Size with Sub-Micron Resolution
Micromachines 2020, 11(7), 653; https://doi.org/10.3390/mi11070653 - 30 Jun 2020
Viewed by 182
Abstract
This article details the mathematical model of a microfluidic device aimed at separating any binary heterogeneous sample of microparticles into two homogeneous samples based on size with sub-micron resolution. The device consists of two sections, where the upstream section is dedicated to focusing [...] Read more.
This article details the mathematical model of a microfluidic device aimed at separating any binary heterogeneous sample of microparticles into two homogeneous samples based on size with sub-micron resolution. The device consists of two sections, where the upstream section is dedicated to focusing of microparticles, while the downstream section is dedicated to separation of the focused stream of microparticles into two samples based on size. Each section has multiple planar electrodes of finite size protruding into the microchannel from the top and bottom of each sidewall; each top electrode aligns with a bottom electrode and they form a pair leading to multiple pairs of electrodes on each side. The focusing section subjects all microparticles to repulsive dielectrophoretic force, from each set of the electrodes, to focus them next to one of the sidewalls. This separation section pushes the big microparticles toward the interior, away from the wall, of the microchannel using repulsive dielectrophoretic force, while the small microparticles move unaffected to achieve the desired degree of separation. The operating frequency of the set of electrodes in the separation section is maintained equal to the cross-over frequency of the small microparticles. The working of the device is demonstrated by separating a heterogeneous mixture consisting of polystyrene microparticles of different size (radii of 2 and 2.25 μm) into two homogeneous samples. The mathematical model is used for parametric study, and the performance is quantified in terms of separation efficiency and separation purity; the parameters considered include applied electric voltages, electrode dimensions, outlet widths, number of electrodes, and volumetric flowrate. The separation efficiencies and separation purities for both microparticles are 100% for low volumetric flow rates, a large number of electrode pairs, large electrode dimensions, and high differences between voltages in both sections. Full article
(This article belongs to the Special Issue Microfluidic Machines)
Show Figures

Figure 1

Open AccessArticle
Suppression of Surface Waviness Error of Fresnel Micro-Structured Mold by Using Non-Integer Rotation Speed Ratio in Parallel Grinding Process
Micromachines 2020, 11(7), 652; https://doi.org/10.3390/mi11070652 - 30 Jun 2020
Viewed by 174
Abstract
Fresnel micro-structured lenses are widely used in the field of modern optoelectronic technology. High-precision Fresnel micro-structured mold is the key technology to achieve its large-scale replication production. Focusing on the surface waviness error of Fresnel micro-structured mold machined by parallel grinding process, this [...] Read more.
Fresnel micro-structured lenses are widely used in the field of modern optoelectronic technology. High-precision Fresnel micro-structured mold is the key technology to achieve its large-scale replication production. Focusing on the surface waviness error of Fresnel micro-structured mold machined by parallel grinding process, this paper conducted theoretical modeling and experiment research. Based on the grinding kinematics theory, the simulation models of the surface waviness topography and the circular waviness profiles of the ground Fresnel micro-structured mold were developed, considering the combined influence of the non-integer rotation speed ratio and other grinding parameters. A series of grinding experiments were carried out to verify the proposed simulation models. The influence of a non-integer rotation speed ratio and a wave-shift value upon the surface waviness error of the ground Fresnel micro-structured molds were analyzed. Both the simulation and experimental results proved that choosing the non-integer rotation speed ratio and a proper wave-shift value could greatly reduce the surface waviness error and improve the surface quality and uniformity. Full article
(This article belongs to the Special Issue Ultra Precision Technologies for Micromachining)
Show Figures

Figure 1

Open AccessArticle
Optimization of MOEMS Projection Module Performance with Enhanced Piezoresistive Sensitivity
Micromachines 2020, 11(7), 651; https://doi.org/10.3390/mi11070651 - 30 Jun 2020
Viewed by 168
Abstract
In scanning laser projection systems, the laser modulation time is important for the projection resolution. The modulation time needs to be matched with the motion of the micromirror. For this paper, the piezoresistive sensor was integrated on the torsion beam of the micromirror [...] Read more.
In scanning laser projection systems, the laser modulation time is important for the projection resolution. The modulation time needs to be matched with the motion of the micromirror. For this paper, the piezoresistive sensor was integrated on the torsion beam of the micromirror to monitor the physical position of the micromirror. The feedback signal was used to generate the zero-crossing time, which was used to estimate the physical position of the resonating mirror over time. The estimated position was affected by the zero-crossing time and the error directly influenced the definition of the projected image. By reducing the impurity concentration from 3 × 1018/cm3 to 1 × 1018/cm3 and increasing shear stress on piezoresistive sensor, the sensitivity of the piezoresistive sensor increased from 4.4 mV/V° to 6.4 mV/V° and the error of the image pixel reduced from 1.5 pixels to 0.5 pixels. We demonstrated that the image quality of an Optical-Microeletromechanical Systems (MOEMS) laser projection could be improved by enhancing the sensitivity of the piezoresistive sensor. Full article
(This article belongs to the Special Issue Optical MEMS, Volume II)
Open AccessArticle
Two-Color Pixel Patterning for High-Resolution Organic Light-Emitting Displays Using Photolithography
Micromachines 2020, 11(7), 650; https://doi.org/10.3390/mi11070650 - 30 Jun 2020
Viewed by 186
Abstract
Nowadays, the display industry is endeavoring to develop technology to provide large-area organic light-emitting diode (OLED) display panels with 8K or higher resolution. Although the selective deposition of organic molecules through shadow masks has proven to be the method of choice for mobile [...] Read more.
Nowadays, the display industry is endeavoring to develop technology to provide large-area organic light-emitting diode (OLED) display panels with 8K or higher resolution. Although the selective deposition of organic molecules through shadow masks has proven to be the method of choice for mobile panels, it may not be so when independently defined high-resolution pixels are to be manufactured on a large substrate. This technical challenge motivated us to adopt the well-established photolithographic protocol to the OLED pixel patterning. In this study, we demonstrate the two-color OLED pixels integrated on a single substrate using a negative-tone highly fluorinated photoresist (PR) and fluorous solvents. Preliminary experiments were performed to examine the probable damaging effects of the developing and stripping processes upon a hole-transporting layer (HTL). No significant deterioration in the efficiency of the develop-processed device was observed. Efficiency of the device after lift-off was up to 72% relative to that of the reference device with no significant change in operating voltage. The procedure was repeated to successfully obtain two-color pixel arrays. Furthermore, the patterning of 15 μm green pixels was accomplished. It is expected that photolithography can provide a useful tool for the production of high-resolution large OLED displays in the near future. Full article
(This article belongs to the Special Issue Organic Electronic Devices, Volume II)
Show Figures

Figure 1

Open AccessArticle
Simple Device to Measure Pressure Using the Stress Impedance Effect of Amorphous Soft Magnetic Thin Film
Micromachines 2020, 11(7), 649; https://doi.org/10.3390/mi11070649 - 30 Jun 2020
Viewed by 166
Abstract
A simple micro-machined pressure sensor, based on the stress-impedance (SI) effect, was fabricated herein using typical micro-fabrication technologies. To sense pressure, a 1-µm thin, soft magnetic metallic film of FeSiB was sputtered and used as a diaphragm. Its electrical response (impedance change) was [...] Read more.
A simple micro-machined pressure sensor, based on the stress-impedance (SI) effect, was fabricated herein using typical micro-fabrication technologies. To sense pressure, a 1-µm thin, soft magnetic metallic film of FeSiB was sputtered and used as a diaphragm. Its electrical response (impedance change) was measured under pressure in a frequency band from 5 to 500 MHz. A lumped-element equivalent electric circuit was used to separate the impedance of the soft magnetic metal from other parasitic elements. The impedance change clearly depended on the applied pressure. It was also shown that the impedance change could be explained by a change in relative permeability, according to the theory of the SI effect. The radial stress in the diaphragm and the relative permeability exhibited a linear relationship. At a measurement frequency of 200 MHz, the largest sensor response, with a gauge factor of 385.7, was found. It was in the same order as the conventional sensors. As the proposed device is very simple, it has the potential for application as a cheap pressure sensor. Full article
(This article belongs to the Section E:Engineering and Technology)
Show Figures

Figure 1

Open AccessArticle
A 3D-Printed Modular Microreservoir for Drug Delivery
Micromachines 2020, 11(7), 648; https://doi.org/10.3390/mi11070648 - 30 Jun 2020
Viewed by 176
Abstract
Reservoir-based drug delivery microsystems have enabled novel and effective drug delivery concepts in recent decades. These systems typically comprise integrated storing and pumping components. Here we present a stand-alone, modular, thin, scalable, and refillable microreservoir platform as a storing component of these microsystems [...] Read more.
Reservoir-based drug delivery microsystems have enabled novel and effective drug delivery concepts in recent decades. These systems typically comprise integrated storing and pumping components. Here we present a stand-alone, modular, thin, scalable, and refillable microreservoir platform as a storing component of these microsystems for implantable and transdermal drug delivery. Three microreservoir capacities (1, 10, and 100 µL) were fabricated with 3 mm overall thickness using stereolithography 3D-printing technology, enabling the fabrication of the device structure comprising a storing area and a refill port. A thin, preformed dome-shaped storing membrane was created by the deposition of parylene-C over a polyethylene glycol sacrificial layer, creating a force-free membrane that causes zero forward flow and insignificant backward flow (2% of total volume) due to membrane force. A septum pre-compression concept was introduced that enabled the realization of a 1-mm-thick septa capable of ~65000 leak-free refill punctures under 100 kPa backpressure. The force-free storing membrane enables using normally-open micropumps for drug delivery, and potentially improves the efficiency and precision of normally-closed micropumps. The ultra-thin septum reduces the thickness of refillable drug delivery devices, and is capable of thousands of leak-free refills. This modular and scalable device can be used for drug delivery in different laboratory animals and humans, as a sampling device, and for lab-on-a-chip and point-of-care diagnostics applications. Full article
(This article belongs to the Special Issue Modular Microfluidics: Fundamental Studies and Applications)
Show Figures

Figure 1

Open AccessArticle
Micro Water Flow Measurement Using a Temperature-Compensated MEMS Piezoresistive Cantilever
Micromachines 2020, 11(7), 647; https://doi.org/10.3390/mi11070647 - 30 Jun 2020
Viewed by 167
Abstract
In this study, we propose a microelectromechanical system (MEMS) force sensor for microflow measurements. The sensor is equipped with a flow sensing piezoresistive cantilever and a dummy piezoresistive cantilever, which acts as a temperature reference. Since the dummy cantilever is also in the [...] Read more.
In this study, we propose a microelectromechanical system (MEMS) force sensor for microflow measurements. The sensor is equipped with a flow sensing piezoresistive cantilever and a dummy piezoresistive cantilever, which acts as a temperature reference. Since the dummy cantilever is also in the form of a thin cantilever, the temperature environment of the dummy sensor is almost identical to that of the sensing cantilever. The temperature compensation effect was measured, and the piezoresistive cantilever was combined with a gasket jig to enable the direct implementation of the piezoresistive cantilever in a flow tube. The sensor device stably measured flow rates from 20 μL/s to 400 μL/s in a silicon tube with a 2-mm inner diameter without being disturbed by temperature fluctuations. Full article
(This article belongs to the Special Issue MEMS Force Sensor)
Show Figures

Figure 1

Open AccessReview
Novel Strategies in Artificial Organ Development: What Is the Future of Medicine?
Micromachines 2020, 11(7), 646; https://doi.org/10.3390/mi11070646 - 30 Jun 2020
Viewed by 334
Abstract
The technology of tissue engineering is a rapidly evolving interdisciplinary field of science that elevates cell-based research from 2D cultures through organoids to whole bionic organs. 3D bioprinting and organ-on-a-chip approaches through generation of three-dimensional cultures at different scales, applied separately or combined, [...] Read more.
The technology of tissue engineering is a rapidly evolving interdisciplinary field of science that elevates cell-based research from 2D cultures through organoids to whole bionic organs. 3D bioprinting and organ-on-a-chip approaches through generation of three-dimensional cultures at different scales, applied separately or combined, are widely used in basic studies, drug screening and regenerative medicine. They enable analyses of tissue-like conditions that yield much more reliable results than monolayer cell cultures. Annually, millions of animals worldwide are used for preclinical research. Therefore, the rapid assessment of drug efficacy and toxicity in the early stages of preclinical testing can significantly reduce the number of animals, bringing great ethical and financial benefits. In this review, we describe 3D bioprinting techniques and first examples of printed bionic organs. We also present the possibilities of microfluidic systems, based on the latest reports. We demonstrate the pros and cons of both technologies and indicate their use in the future of medicine. Full article
(This article belongs to the Special Issue 3D-Bioprinted Organs-on-Chips for Clinical Application)
Show Figures

Figure 1

Open AccessArticle
Comparison of Multiple Displacement Amplification (MDA) and Multiple Annealing and Looping-Based Amplification Cycles (MALBAC) in Limited DNA Sequencing Based on Tube and Droplet
Micromachines 2020, 11(7), 645; https://doi.org/10.3390/mi11070645 - 29 Jun 2020
Viewed by 217
Abstract
Whole genome amplification (WGA) is crucial for whole genome sequencing to investigate complex genomic alteration at the single-cell or even single-molecule level. Multiple displacement amplification (MDA) and multiple annealing and looping based amplification cycles (MALBAC) are two most widely applied WGA methods, which [...] Read more.
Whole genome amplification (WGA) is crucial for whole genome sequencing to investigate complex genomic alteration at the single-cell or even single-molecule level. Multiple displacement amplification (MDA) and multiple annealing and looping based amplification cycles (MALBAC) are two most widely applied WGA methods, which have different advantages and disadvantages, dependent on research objectives. Herein, we compared the MDA and MALBAC to provide more information on their performance in droplets and tubes. We observed that the droplet method could dramatically reduce the amplification bias and retain the high accuracy of replication than the conventional tube method. Furthermore, the droplet method exhibited higher efficiency and sensitivity for both homozygous and heterozygous single nucleotide variants (SNVs) at the low sequencing depth. In addition, we also found that MALBAC offered a greater uniformity and reproducibility and MDA showed a better efficiency of genomic coverage and SNV detection. Our results provided insights that will allow future decision making. Full article
Show Figures

Figure 1

Previous Issue
Back to TopTop
