Designs, Volume 6, Issue 1 (February 2022) – 20 articles

The shape complexity capability of additive manufacturing (AM) is currently the main thrust of the design for AM (DFAM) research. In order to aid designers embracing that complexity-for-free characteristics of AM, many design approaches have been put forth. However, AM does not only benefit parts’ designs: its capability can be harnessed at assembly level to design performant and innovative products. Most of the few contributions on the topic are concerned with part consolidation of existing assemblies, but other advantages such as assembly-free mechanisms, multi-material components, or even component embedding can also improve product design complexity. This paper aims to put forth a thorough DFAM framework for new product development (made of multiple parts) and which consider all the assembly-related characteristics of AM. It considers what can be called AM-based architecture minimization, which includes, among others, part consolidation and assembly-free mechanisms as well. Within context of an ‘AM-factory’, in which the most appropriate machine(s) is/are selected for easing a whole assembly manufacturing before the detailed geometric definition is committed. For the sake of completeness, a methodology based on functional flows has also been investigated for the parts’ design. A gripper as case study has been introduced to illustrate the framework. Full article

The study’s main aim was to predict the penetrant residual velocity, with it being a vital output parameter in the projectile target interaction. The ballistics have been probed on a wide spectrum of impact velocities for different applications. Determination of the residual velocity by analytical methods entails the use of the impulse momentum principle, and the process is further challenged by the necessary inclusion of various variables that directly affect the calculation of the residual velocity. These problems can be overcome by adopting a non-dimensional approach by determining the combination of variables required for the penetration process by carrying out and validating the non-dimensionalization of the pertinent variables. The process discussed in this study provides a reasonable correlation of the non-dimensional parameters, which was used to estimate and validate penetrant residual velocity. A generalized solution predicting the penetrator residual velocity for a wide range of materials for a variety of impact velocities is proposed. The result of this correlation was validated against the published data, and the method was largely in agreement, showing the robustness of the proposed finding. Full article

This paper describes a vector-controlled Permanent Magnet Synchronous Motor (PMSM) drive system with the current sensor fault detection mechanism. In general, the control structure is based on the well-known Field Oriented Control (FOC) algorithm. The structure is equipped with an additional algorithm for current sensor fault detection based on a neural network. The presented control structure is able to detect typical current sensor faults, such as lack of signal, intermittent signal, variable gain and signal noise. The application of the NN detector guarantees a faster detection of the sensor fault than classical detectors based on algorithmic methods or logical systems. This work focuses on presenting the methodology of designing detectors and their analysis, based solely on simulation analysis. The simulation results, conducted in the Matlab/Simulink environment, are presented for the above-mentioned faults in phase A and phase B for different speed conditions. Full article

Robots and especially mobile robots have experienced rapid growth, making them part of everyday life. An inertial measurement unit (IMU), which is a set of sensors, plays an important role in mobile robots’ navigation. Data collected by the IMU sensors on a robot are properly converted and useful information is calculated concerning, i.e., position, orientation, and acceleration. With the advancement of technology, IMUs have been transformed from large and complex devices into small, flexible, and efficient ones. The main sensors included in an IMU are the gyroscope, the accelerometer, and the magnetometer. Additionally, there are other sensors such as a barometer, a temperature sensor, a pressure sensor, or even an attitude sensor. The components that an IMU consists of are many and the main differences concern the technology they integrate, the designer purpose, and the specifications set by the manufacturer. The purpose of this review is a comparative presentation of 42 IMU models from 7 different manufacturers over the last five years comparing main features such as structure details, connectivity, and communication protocols. Moreover, statistical results are quantitatively and qualitatively presented providing a future user the possibility to select the proper IMU. Full article

During the execution of construction projects, uncertain events, such as delays, prolongations and disruptions of project activities, have the potential to cause a significant deviation between the planned and realized state of a project. As a result, progress on important project objectives can decrease and this leads to critical delays as well as heavy profit loss. For this reason, we propose the implementation of the customized evolutionary algorithm to generate resilient baseline schedules which include a sufficient number of time floats to absorb the negative impact of uncertainty. This way, the baseline solution is searched as a trade-off between project duration, its final profit and the overall baseline stability. The proposed algorithm is applied to real construction project data and the results of the analysis suggest improved stability for resilient baseline schedules. Application of the genetic algorithm to solve the existing multi-objective problem enables practical implementation of new technologies and methods in construction management. Resilient baseline schedules can be used in an uncertain environment to achieve more accurate predictions and support decision making in the areas of construction scheduling and costing. Full article

Escalation fuel consumption occurs in various regions of the world. However, world oil reserves decline from year to year so that it becomes scarce and causes oil prices to surge up. This problem can be solved by saving fuel consumption. One method of saving fuel is adding bio-additives from citronella oil as a sustainable resource to diesel fuels. Citronellal, citronellol and geraniol are the main components of citronella oil which can be used as fuel additives. This study aimed to evaluate the effect of citronella oil fractions as bio-additives to the performance of diesel engine. The research stages include: extraction of citronella oil, vacuum fractionation of citronella oil, physical chemical characterization of citronella oil and its fractions, formulation of bio-additive -fuel blending, characterization of blending, and evaluation of fuel efficiency. The effect of concentration of the bio-additives was examined towards three diesel fuels; dexlite, pertamina-dex, and biosolar. The results showed two main fractions of citronella oil; citronellal dominant component (FA) and citronellol-geraniol dominant components (FB). The concentration variation of bio-additives was 0.1–0.5%. Fuel consumption efficiency was tested using diesel engine at an engine speed of 2000 rpm and a load increment of 1000, 2000 and 3000 psi with 7 min running time. The fractions represented the different tendencies to enhance the fuel efficiency up to 46%, influenced by the mixture’s concentration. Generally, citronella oil and the fractions showed the potency as bio-additive to diesel fuels. Full article

This paper presents a design synthesis method for robust controllers of active vehicle suspensions (AVSs). Various control techniques have been applied to the design of AVSs for enhancing ride comfort and handling performance of ground vehicles. However, most of these model-based controller designs show poor robustness when the vehicle models are not accurate and operating conditions vary. To address the poor robustness problem of AVSs, a new controller is designed using the $H_{\infty }$ loop-shaping control technique. The controller targets robustness issues on vehicle models with parametric uncertainties and unmodelled dynamics. To facilitate the robust controller design, a design synthesis method is proposed: the $H_{\infty }$ loop-shaping controller design is formulated as a multi-objective optimization problem, the weighting functions’ parameters of the controller are treated as design variables, the expensive computing loads are handled by a parallel computing technique, and the solution of the optimization problem is the desired robust AVS controller. Simulation results demonstrate the benefits of the proposed AVS design. Full article

As additively manufactured radio frequency (RF) design expands towards higher frequencies, performance becomes ever more sensitive to print-induced dimensional variations. These slight deviations from design dimensions typically skew RF performance, resulting in low yields or poor device performance. In order to overcome this limitation, RF design paradigms must be developed for non-uniform process and material-specific variations. Therefore, a new generalized approach is developed to explore variation-tolerant designs for printed RF structures. This method evaluates the feature fidelity and S11 performance of micro-dispensed, X-band (8–12 GHz) patch antennas by evaluating the standard deviation in as-printed features, surface roughness, and thickness. It was found that the traditional designs based on optimal impedance matching values did not result in the most robust performance over multiple printing sessions. Rather, performance bounds determined by print deviation could be utilized to improve large-batch S11 results by up to 7 dB. This work demonstrates that establishing the average standard deviation of printed dimensions in any RF printing system and following the formulated design procedure could greatly improve performance over large datasets. As such, the method defined here can be applied to improve large-scale, printed RF yields and enable predictive performance metrics for any given printing method. Full article

Aircraft pavements are generally designed using deterministic methods and using conservatively selected input parameter values, which combine to result in a low probability of structural failure occurring during the structural design life of the pavement. In contrast, when predicting the actual time until an as-constructed pavement will reach a structural failure condition, stochastic methods are required to take into account the inherently variable nature of pavement material properties and layer thicknesses, and the best-estimate of the input parameter values must replace the conservative values that are commonly used to introduce design reliability. A case study on a rigid aircraft pavement demonstrates the difference between pavement thickness design and pavement life prediction. Using Monte Carlo simulation, it was found that 98.5% of the as-constructed pavement was stronger than the designed pavement and that the predicted fatigue life of the pavement was approximately 180 times greater than the effective design life. It was concluded that the significant difference between pavement design and pavement life prediction explains the practical observation that rigid aircraft pavement service life generally exceeds typical structural design lives. Full article

Fostering the development of additive manufacturing (AM) in the context of mass production is a key factor to ensure its adoption in the industry. It should be remembered that this technology intrinsically makes it possible to produce parts with unexpected complexities in terms of shape and structure, but this comes at a price: time. To overcome this productivity barrier, AM technology providers are developing 3D printing machines with high-speed performance and mass reproduction means in a single run. Although such trends can be seen as a natural evolution of this technology with respect to current consumption patterns, it still remains a scientific issue on production planning to be tackled. The objective is to address the on-demand production planning of different AM parts in FabLabs composed of unrelated parallel 3D printers. A novel framework is introduced to consider part orientation, path planning, and part-to-printer assignment, with a specific focus on fused filament fabrication technique. By targeting a minimum production time, it exhibits reasoning algorithms implemented in a Python application. A case study with a batch of six non-identical parts and two fused filament fabrication 3D printers is introduced to illustrate the added value of the framework and its operational side. Full article

An aerodynamic optimization for a Droop-Nose Leading-Edge (DNLE) morphing of a well-known UAV, the UAS-S45, is proposed, using a novel Black Widow Optimization (BWO) algorithm. This approach integrates the optimization algorithm with a modified Class-Shape Transformation (CST) parameterization method to enhance aerodynamic performance by minimizing drag and maximizing aerodynamic endurance at the cruise flight condition. The CST parameterization technique is used to parameterize the reference airfoil by introducing local shape changes and provide skin flexibility to obtain various optimized morphing airfoil configurations. The optimization framework uses an in-house MATLAB algorithm, while the aerodynamic calculations use the XFoil solver with flow transition estimation criteria. These results are validated with a CFD solver utilizing the Transition $\left(\gamma -R{e}_{\theta }\right)$ Shear Stress Transport (SST) turbulence model. Numerical studies verified the effectiveness of the optimization strategy, and the optimized airfoils have shown a significant improvement in overall aerodynamic performance by up to 12.18% drag reduction compared to the reference airfoil, and an increase in aerodynamic endurance of up to 10% for the UAS-S45 optimized airfoil configurations over its reference airfoil. These results indicate the importance of leading-edge morphing in enhancing the aerodynamic efficiency of the UAS-S45 airfoil. Full article

Quadcopters represent rotary wing configuration of the Unmanned Aerial Vehicles (UAVs) with immense application potential in industrial and strategic contexts. Tradeoff between flight endurance and payload capacity renders design optimization of UAVs a critical activity with substantial impact on the application possibilities. Among the structural parts of a typical Quadcopter, the central body frame constitutes major portion of the total weight. The present study aims at reduction of the frame weight while conforming with structural integrity requirements, through an integrated approach involving topology optimization, part consolidation and design for additive manufacturing (DFAM). Commercial UAV designs consist of multiple parts and fastening elements that necessitate considerable time and effort for assembly. This study reengineers the frame as a monocoque structure with desirable outcomes of weight reduction and less assembly time. The reengineered Quadcopter structure is manufactured through Fused Filament Fabrication (FFF) and characterized with reference to structural, vibrational and fatigue characteristics. Concomitant application of modal analysis, computational fluid dynamics and wind tunnel testing reveals close match between theoretical estimates and experimental results. Assembly and field trials of the monocoque Quadcopter structure affirm betterment of operational superiority and endurance vis-a-vis commercial UAV designs. Full article

Intermittent vesical self-catheterisation is a legitimate and safe technique that has been reported since the 1970s as a solution for the treatment and prevention of vesical urinary complications resulting from spinal cord injury. This practice, using clean technology, has been asserting itself as one of the best alternatives for people with neurogenic bladder. However, adherence is not complete due to some barriers imposed to this procedure by the injured, with emphasis on positioning, agility, and visual impairment. The solutions presented today to support self-catheterisation are expensive equipment that does not allow patients with advanced levels of spasticity to have their autonomy. A biomechanical support device was developed to aid self-catheterisation, mainly aimed at women with spasticity, filling the gap in the existing products. Despite the main objective of self-catheterisation, the system’s design made it possible to quantify the strength of the adductors for the sitting position during the execution of the adduction movement, particularly relevant for spastic patients. The device’s production was entirely carried out using the FDM methodology, with 3D printers, and its design and operation were thought to overcome the physical and psychological barriers imposed by the users. The system was first tested with a group of healthy volunteers to obtain a pattern of the adductors force in a sitting position and after with a group of spastic volunteers. The obtained data allows to compare the adductor force data and optimize the system, with particular functionalities for spastic patients, with the implementation of a motorised version and a visualization camera. The system, its developments, and results obtained are present and discussed. Full article

This study was aimed at generating data for designing a potential method to prevent the rupture of the abdominal aortic aneurysm (AAA). We found that the mechanical strength and stiffness of blood vessel walls was enhanced by the crosslinking of adventitial collagen through a photochemical process promoted by ultraviolet-A (UV-A) radiation. The experiments were carried out on samples isolated from 25 normal porcine aortas. The adventitial layer was separated from the other layers and exposed to UV radiation of 365-nm wavelength, in the presence of a riboflavin compound as the photosensitizer. Mechanical testing of 30 specimens, prior to and after exposure, indicated an increase in both strength (ultimate stress) and stiffness (Young’s modulus) of the adventitial specimens following irradiation. The crosslinking process also led to an enhanced resistance to experimental collagenolysis, as determined on six specimens. At this phase of conceptual design, we suggest that by applying this method to an aneurysmal dilated wall region, the stabilization of tunica adventitia may delay or prevent the rupture of the aneurysm and, with further investigation and refinement, can become a therapeutic strategy for arresting the progression of AAA. Full article

The United Arab Emirates (UAE) is a multiracial society with diverse housing and a potential real estate market. This study focused on users’ perceptions of the designs of available and affordable private housing stock in Dubai, Sharjah, and Ajman, which are the most populated states (emirates) of the UAE. A literature review and case studies of low- to medium-rise residential buildings were used to determine the parameters defining affordable housing design, and a model was developed of 7 design segments (independent variables) with 39 dependent variables. The model consists of a matrix of 39 design variables, in which each variable is set in a survey tool with a Likert scale to evaluate user satisfaction levels with the designs of their respective buildings. Questionnaires were distributed among the inhabitants of several buildings at different locations in the emirates. This study found that 16 anomalous design factors failed to satisfy users. It is likely that the results of this study will provide a blueprint for dialogue between regional building designers and end users to improve the designs of new buildings. The resulting design assessment matrix can be used for the analysis of residential buildings in other parts of the Gulf Cooperation Council region. Full article

This research investigates the communication barriers between designers and engineers in designing 4D Printing parts. We have proposed a conceptual design framework for 4D Printing symbols as the communication tool. Then, we have recruited sixty-fifty designers and engineers who participated in our online experiments. The focus of the online survey is to find out how designers and engineers understand reciprocal communication by using the proposed symbols. Our results showed that 85% of participants could understand the 4D Printing symbols correctly. The study concludes that using the conceptual framework can help designers and engineers communicate 4D Printing element information and stimulate design ideas effectively. Full article

Rapid prototyping has become increasingly popular over the past years. However, its application is heavily confined to a part size that fits the small build volume of additive machines. This paper presents a universal design method to overcome this limitation while preserving the economic advantages of rapid prototyping over conventional processes. It segments large, thin-walled parts and joins the segments. The method aims to produce an assembly with minimal loss to the performance and characteristics of a solid part. Based on a set of requirements, a universal segmentation approach and a novel hybrid joint design combining adhesive bonding and press fitting are developed. This design allows for the force transmission, positioning, and assembly of the segments adaptive to their individual geometry. The method is tailored to fused deposition modeling (FDM) by minimizing the need for support structures and actively compensating for manufacturing tolerances. While a universal application cannot be guaranteed, the adaptive design was proven for a variety of complex geometries. Using automotive trim parts as an example, the usability, benefits, and novelty of the design method is presented. The method itself shows a high potential to overcome the build volume limitation for thin-walled parts in an economic manner. Full article

This paper investigates the use of the Kriging response surface method to estimate failure values in carbon-fibre-epoxy composite flow-lines under the influence of stochastic processes. A case study of a 125 mm flow-line was investigated. The maximum stress, Tsai-Wu and Hashin failure criteria was used to assess the burst design under combined loading with axial forces, torsion and bending moments. An extensive set of measured values was generated using Monte Carlo simulation and used as the base case population to which the results from the response surfaces was compared. The response surfaces were evaluated in detail in their ability to reproduce the statistical moments, probability and cumulative distributions and failure values at low probabilities of failure. In addition, the optimisation of the response surface calculation was investigated in terms of reducing the number of input parameters and size of the response surface. Finally, a decision chart that can be used to build a response surface to calculate failures in a carbon fibre-epoxy-composite (CFEC) flow-line was proposed based on the findings obtained. The results show that the response surface method is suitable and can calculate failure values close to that calculated using a large set of measured values. The results from this paper provide an analytical framework for identifying the principal design parameters, response surface generation, and failure prediction for CFEC flow-lines. Full article
