Micromachines, Volume 9, Issue 12 (December 2018)

  • Issues are regarded as officially published after their release is announced to the table of contents alert mailing list.
  • You may sign up for e-mail alerts to receive table of contents of newly released issues.
  • PDF is the official format for papers published in both, html and pdf forms. To view the papers in pdf format, click on the "PDF Full-text" link, and use the free Adobe Readerexternal link to open them.
Cover Story (view full-size image) A particular challenge in intravascular treatments is the control of submillimeter guidewires. This [...] Read more.
View options order results:
result details:
Displaying articles 1-63
Export citation of selected articles as:
Open AccessArticle Temperature Field of Tool Engaged Cutting Zone for Milling of Titanium Alloy with Ball-End Milling
Micromachines 2018, 9(12), 672; https://doi.org/10.3390/mi9120672 (registering DOI)
Received: 26 November 2018 / Revised: 14 December 2018 / Accepted: 16 December 2018 / Published: 18 December 2018
PDF Full-text (4979 KB) | HTML Full-text | XML Full-text
Abstract
When milling titanium alloy, the cutting temperature has a strong impact on the degree of tool wear and, in turn, tool life and the surface quality of the workpiece. The distribution of the temperature field on a tool’s rake face can be improved
[...] Read more.
When milling titanium alloy, the cutting temperature has a strong impact on the degree of tool wear and, in turn, tool life and the surface quality of the workpiece. The distribution of the temperature field on a tool’s rake face can be improved through the use of micro-textures, which help to reduce friction and, ultimately, wear on the tool. In this paper we present a new way to measure cutting temperature and examine heat distribution when milling titanium alloy with micro-textured ball-end milling tools. We first establish the heat flux density function for the contact area between the workpiece and the tool and then for the rest of the tool. Thermal stress simulation shows that adhesive wear tends to happen in the contact area and on the flank face, rather than at the tip of the tool, with the temperature distribution gradient for the rest of the tool being more uniform. The maximum value for thermal stress on the cutting edge was 2.0782 × 106 Pa. This decrease as you move away from the cutting edge along the contact area between the tool and the workpiece. Maximum deformation of the tool is also mainly concentrated at the principal contact point, with a value of 1.9445 × 10−9 m. This, too, decreases as you move away from the cutting edge and into the rest of the contact area. This research provides the basis for the optimization of tool structure and further investigation of the thermo-mechanical coupling behavior of micro-textured ball-end milling cutters when milling titanium alloy. Full article
Figures

Figure 1

Open AccessArticle Development of Microfluidic Stretch System for Studying Recovery of Damaged Skeletal Muscle Cells
Micromachines 2018, 9(12), 671; https://doi.org/10.3390/mi9120671
Received: 20 November 2018 / Revised: 9 December 2018 / Accepted: 16 December 2018 / Published: 18 December 2018
PDF Full-text (1674 KB) | HTML Full-text | XML Full-text | Supplementary Files
Abstract
The skeletal muscle occupies about 40% mass of the human body and plays a significant role in the skeletal movement control. Skeletal muscle injury also occurs often and causes pain, discomfort, and functional impairment in daily living. Clinically, most studies observed the recovery
[...] Read more.
The skeletal muscle occupies about 40% mass of the human body and plays a significant role in the skeletal movement control. Skeletal muscle injury also occurs often and causes pain, discomfort, and functional impairment in daily living. Clinically, most studies observed the recovery phenomenon of muscle by massage or electrical stimulation, but there are limitations on quantitatively analyzing the effects on recovery. Although additional efforts have been made within in vitro biochemical research, some questions still remain for effects of the different cell microenvironment for recovery. To overcome these limitations, we have developed a microfluidic system to investigate appropriate conditions for repairing skeletal muscle injury. First, the muscle cells were cultured in the microfluidic chip and differentiated to muscle fibers. After differentiation, we treated hydrogen peroxide and 18% axial stretch to cause chemical and physical damage to the muscle fibers. Then the damaged muscle fibers were placed under the cyclic stretch condition to allow recovery. Finally, we analyzed the damage and recovery by quantifying morphological change as well as the intensity change of intracellular fluorescent signals and showed the skeletal muscle fibers recovered better in the cyclic stretched condition. In total, our in situ generation of muscle damage and induction recovery platform may be a key system for investigating muscle recovery and rehabilitation. Full article
(This article belongs to the Special Issue Microfluidic Cell Assay Chips)
Figures

Figure 1

Open AccessArticle A Trace Carbon Monoxide Sensor Based on Differential Absorption Spectroscopy Using Mid-Infrared Quantum Cascade Laser
Micromachines 2018, 9(12), 670; https://doi.org/10.3390/mi9120670
Received: 25 November 2018 / Revised: 12 December 2018 / Accepted: 14 December 2018 / Published: 18 December 2018
PDF Full-text (2192 KB) | HTML Full-text | XML Full-text
Abstract
Carbon monoxide (CO), as a dangerous emission gas, is easy to accumulate in the complex underground environment and poses a serious threat to the safety of miners. In this paper, a sensor using a quantum cascade laser with an excitation wavelength of 4.65
[...] Read more.
Carbon monoxide (CO), as a dangerous emission gas, is easy to accumulate in the complex underground environment and poses a serious threat to the safety of miners. In this paper, a sensor using a quantum cascade laser with an excitation wavelength of 4.65 μm as the light source, and a compact multiple reflection cell with a light path length of 12 m is introduced to detect trace CO gas. The sensor adopts the long optical path differential absorption spectroscopy technique (LOP-DAST) and obtains minimum detection limit (MDL) of 108 ppbv by comparing the residual difference between the measured spectrum and the Voigt theoretical spectrum. As a comparison, the MDL of the proposed sensor was also estimated by Allan deviation; the minimum value of 61 ppbv is achieved while integration time is 40 s. The stability of the sensor can reach 2.1 × 10−3 during the 2 h experimental test and stability of 1.7 × 10−2 can still be achieved in a longer 12 h experimental test. Full article
(This article belongs to the Special Issue Infrared Nanophotonics: Materials, Devices, and Applications)
Figures

Figure 1

Open AccessArticle Hyaluronate-Functionalized Graphene for Label-Free Electrochemical Cytosensing
Micromachines 2018, 9(12), 669; https://doi.org/10.3390/mi9120669
Received: 22 November 2018 / Revised: 12 December 2018 / Accepted: 15 December 2018 / Published: 18 December 2018
PDF Full-text (2681 KB) | HTML Full-text | XML Full-text | Supplementary Files
Abstract
Electrochemical sensors for early tumor cell detection are currently an important area of research, as this special region directly improves the efficiency of cancer treatment. Functional graphene is a promising alternative for selective recognition and capture of target cancer cells. In our work,
[...] Read more.
Electrochemical sensors for early tumor cell detection are currently an important area of research, as this special region directly improves the efficiency of cancer treatment. Functional graphene is a promising alternative for selective recognition and capture of target cancer cells. In our work, an effective cytosensor of hyaluronate-functionalized graphene (HG) was prepared through chemical reduction of graphene oxide. The as-prepared HG nanostructures were characterized with Fourier transform infrared spectroscopy and transmission electron microscopy coupled with cyclic voltammograms and electrochemical impedance spectroscopy, respectively. The self-assembly of HG with ethylene diamine, followed by sodium hyaluronate, enabled the fabrication of a label-free electrochemical impedance spectroscopy cytosensor with high stability and biocompatibility. Finally, the proposed cytosensor exhibited satisfying electrochemical behavior and cell-capture capacity for human colorectal cancer cells HCT-116, and also displayed a wide linear range, from 5.0 × 102 cells∙mL−1 to 5.0 × 106 cells∙mL−1, and a low detection limit of 100 cells∙mL−1 (S/N = 3) for quantification. This work paves the way for graphene applications in electrochemical cytosensing and other bioassays. Full article
(This article belongs to the Special Issue Graphene Nanoelectronic Devices)
Figures

Figure 1

Open AccessArticle Numerical and Experimental Analyses of Three- Dimensional Unsteady Flow around a Micro-Pillar Subjected to Rotational Vibration
Micromachines 2018, 9(12), 668; https://doi.org/10.3390/mi9120668
Received: 6 November 2018 / Revised: 10 December 2018 / Accepted: 13 December 2018 / Published: 17 December 2018
PDF Full-text (1222 KB) | Supplementary Files
Abstract
The steady streaming (SS) phenomenon is gaining increased attention in the microfluidics community, because it can generate net mass flow from zero-mean vibration. We developed numerical simulation and experimental measurement tools to analyze this vibration-induced flow, which has been challenging due to its
[...] Read more.
The steady streaming (SS) phenomenon is gaining increased attention in the microfluidics community, because it can generate net mass flow from zero-mean vibration. We developed numerical simulation and experimental measurement tools to analyze this vibration-induced flow, which has been challenging due to its unsteady nature. The validity of these analysis methods is confirmed by comparing the three-dimensional (3D) flow field and the resulting particle trajectories induced around a cylindrical micro-pillar under circular vibration. In the numerical modeling, we directly solved the flow in the Lagrangian frame so that the substrate with a micro-pillar becomes stationary, and the results were converted to a stationary Eulerian frame to compare with the experimental results. The present approach enables us to avoid the introduction of a moving boundary or infinitesimal perturbation approximation. The flow field obtained by the micron-resolution particle image velocimetry (micro-PIV) measurement supported the three-dimensionality observed in the numerical results, which could be important for controlling the mass transport and manipulating particulate objects in microfluidic systems. Full article
Figures

Graphical abstract

Open AccessArticle Modeling and Analysis of Upright Piezoelectric Energy Harvester under Aerodynamic Vortex-induced Vibration
Micromachines 2018, 9(12), 667; https://doi.org/10.3390/mi9120667
Received: 28 November 2018 / Revised: 11 December 2018 / Accepted: 14 December 2018 / Published: 17 December 2018
PDF Full-text (5405 KB) | HTML Full-text | XML Full-text
Abstract
This paper presents an upright piezoelectric energy harvester (UPEH) with cylinder extension along its longitudinal direction. The UPEH can generate energy from low-speed wind by bending deformation produced by vortex-induced vibrations (VIVs). The UPEH has the advantages of less working space and ease
[...] Read more.
This paper presents an upright piezoelectric energy harvester (UPEH) with cylinder extension along its longitudinal direction. The UPEH can generate energy from low-speed wind by bending deformation produced by vortex-induced vibrations (VIVs). The UPEH has the advantages of less working space and ease of setting up an array over conventional vortex-induced vibration harvesters. The nonlinear distributed modeling method is established based on Euler–Bernoulli beam theory and aerodynamic vortex-induced force of the cylinder is obtained by the van der Pol wake oscillator theory. The fluid–solid–electricity governing coupled equations are derived using Lagrange’s equation and solved through Galerkin discretization. The effect of cylinder gravity on the dynamic characteristics of the UPEH is also considered using the energy method. The influences of substrate dimension, piezoelectric dimension, the mass of cylinder extension, and electrical load resistance on the output performance of harvester are studied using the theoretical model. Experiments were carried out and the results were in good agreement with the numerical results. The results showed that a UPEH configuration achieves the maximum power of 635.04 μW at optimum resistance of 250 kΩ when tested at a wind speed of 4.20 m/s. The theoretical results show that the UPEH can get better energy harvesting output performance with a lighter tip mass of cylinder, and thicker and shorter substrate in its synchronization working region. This work will provide the theoretical guidance for studying the array of multiple upright energy harvesters. Full article
(This article belongs to the Special Issue Smart Miniaturised Energy Harvesting)
Figures

Figure 1

Open AccessArticle A Miniature Resonant and Torsional Magnetometer Based on Lorentz Force
Micromachines 2018, 9(12), 666; https://doi.org/10.3390/mi9120666
Received: 28 November 2018 / Revised: 10 December 2018 / Accepted: 12 December 2018 / Published: 17 December 2018
PDF Full-text (3726 KB) | HTML Full-text | XML Full-text | Supplementary Files
Abstract
A microelectromechanical system (MEMS) torsional resonant magnetometer based on Lorentz force was investigated, consisting of torsional structures, torsional beams, metal plates, a coil, and a glass substrate. The Lorentz force, introduced by the interaction between the current in the MEMS coil and an
[...] Read more.
A microelectromechanical system (MEMS) torsional resonant magnetometer based on Lorentz force was investigated, consisting of torsional structures, torsional beams, metal plates, a coil, and a glass substrate. The Lorentz force, introduced by the interaction between the current in the MEMS coil and an external horizontal magnetic field, leads to displacement of the torsional structure. The strength of the magnetic field is proportional to this displacement, and can be detected with two sensing capacitors fabricated on the torsion structure and the substrate. To improve sensor sensitivity, a folded torsional beam and a double-layer excitation coil were introduced. The fabrication processes included lift-off, anodic bonding, chemical mechanical planarization, silicon nitride (SiNx) deposition, plasma-enhanced chemical vapor deposition, and inductively coupled plasma release. The prototype of the magnetometer was finished and packaged. The sensor performance, including its sensitivity and repeatability, was tested in a low-pressure environment. Additionally, the influences of structural parameters were analyzed, including the resistance of the excitation coil, the initial value of the capacitors, the elastic coefficient of the torsional beam, and the number of layers in the excitation coil. The test results demonstrated that this sensor could meet the requirements for attitude determination systems in low earth orbit satellites. Full article
Figures

Figure 1

Open AccessArticle In Situ Analysis of Interactions between Fibroblast and Tumor Cells for Drug Assays with Microfluidic Non-Contact Co-Culture
Micromachines 2018, 9(12), 665; https://doi.org/10.3390/mi9120665
Received: 5 November 2018 / Revised: 2 December 2018 / Accepted: 11 December 2018 / Published: 17 December 2018
PDF Full-text (8380 KB) | HTML Full-text | XML Full-text
Abstract
Fibroblasts have significant involvement in cancer progression and are an important therapeutic target for cancer. Here, we present a microfluidic non-contact co-culture device to analyze interactions between tumor cells and fibroblasts. Further, we investigate myofibroblast behaviors induced by lung tumor cells as responses
[...] Read more.
Fibroblasts have significant involvement in cancer progression and are an important therapeutic target for cancer. Here, we present a microfluidic non-contact co-culture device to analyze interactions between tumor cells and fibroblasts. Further, we investigate myofibroblast behaviors induced by lung tumor cells as responses to gallic acid and baicalein. Human lung fibroblast (HLF) and lung cancer cell line (A549) cells were introduced into neighboring, separated regions by well-controlled laminar flows. The phenotypic behavior and secretion activity of the tumor cells indicate that fibroblasts could become activated through paracrine signaling to create a supportive microenvironment for cancer cells when HLF is co-cultured with A549. Furthermore, both gallic acid (GA) and baicalein (BAE) could inhibit the activation of fibroblasts. In situ analysis of various cell communications via the paracrine pathway could be realizable in this contactless co-culture single device. This device facilitates a better understanding of interactions between heterotypic cells, thus exploring the mechanism of cancer, and performs anti-invasion drug assays in a relatively complex microenvironment. Full article
(This article belongs to the Special Issue Microfluidics for Cell and Other Organisms)
Figures

Figure 1

Open AccessArticle Heterodimeric Plasmonic Nanogaps for Biosensing
Micromachines 2018, 9(12), 664; https://doi.org/10.3390/mi9120664
Received: 28 November 2018 / Revised: 13 December 2018 / Accepted: 13 December 2018 / Published: 16 December 2018
PDF Full-text (2788 KB) | HTML Full-text | XML Full-text | Supplementary Files
Abstract
We report the study of heterodimeric plasmonic nanogaps created between gold nanostar (AuNS) tips and gold nanospheres. The selective binding is realized by properly functionalizing the two nanostructures; in particular, the hot electrons injected at the nanostar tips trigger a regio-specific chemical link
[...] Read more.
We report the study of heterodimeric plasmonic nanogaps created between gold nanostar (AuNS) tips and gold nanospheres. The selective binding is realized by properly functionalizing the two nanostructures; in particular, the hot electrons injected at the nanostar tips trigger a regio-specific chemical link with the functionalized nanospheres. AuNSs were synthesized in a simple, one-step, surfactant-free, high-yield wet-chemistry method. The high aspect ratio of the sharp nanostar tip collects and concentrates intense electromagnetic fields in ultrasmall surfaces with small curvature radius. The extremities of these surface tips become plasmonic hot spots, allowing significant intensity enhancement of local fields and hot-electron injection. Electron energy-loss spectroscopy (EELS) was performed to spatially map local plasmonic modes of the nanostar. The presence of different kinds of modes at different position of these nanostars makes them one of the most efficient, unique, and smart plasmonic antennas. These modes are harnessed to mediate the formation of heterodimers (nanostar-nanosphere) through hot-electron-induced chemical modification of the tip. For an AuNS-nanosphere heterodimeric gap, the intensity enhancement factor in the hot-spot region was determined to be 106, which is an order of magnitude greater than the single nanostar tip. The intense local electric field within the nanogap results in ultra-high sensitivity for the presence of bioanalytes captured in that region. In case of a single BSA molecule (66.5 KDa), the sensitivity was evaluated to be about 1940 nm/RIU for a single AuNS, but was 5800 nm/RIU for the AuNS-nanosphere heterodimer. This indicates that this heterodimeric nanostructure can be used as an ultrasensitive plasmonic biosensor to detect single protein molecules or nucleic acid fragments of lower molecular weight with high specificity. Full article
(This article belongs to the Special Issue Nanocrystal based Nanophotonic Devices)
Figures

Figure 1

Open AccessArticle Role of Solid Wall Properties in the Interface Slip of Liquid in Nanochannels
Micromachines 2018, 9(12), 663; https://doi.org/10.3390/mi9120663
Received: 15 November 2018 / Revised: 9 December 2018 / Accepted: 12 December 2018 / Published: 16 December 2018
PDF Full-text (1759 KB) | HTML Full-text | XML Full-text
Abstract
A two-dimensional molecular dynamics model of the liquid flow inside rough nanochannels is developed to investigate the effect of a solid wall on the interface slip of liquid in nanochannels with a surface roughness constructed by rectangular protrusions. The liquid structure, velocity profile,
[...] Read more.
A two-dimensional molecular dynamics model of the liquid flow inside rough nanochannels is developed to investigate the effect of a solid wall on the interface slip of liquid in nanochannels with a surface roughness constructed by rectangular protrusions. The liquid structure, velocity profile, and confined scale on the boundary slip in a rough nanochannel are investigated, and the comparison of those with a smooth nanochannel are presented. The influence of solid wall properties, including the solid wall density, wall-fluid coupling strength, roughness height and spacing, on the interfacial velocity slip are all analyzed and discussed. It is indicated that the rough surface induces a smaller magnitude of the density oscillations and extra energy losses compared with the smooth solid surface, which reduce the interfacial slip of liquid in a nanochannel. In addition, once the roughness spacing is very small, the near-surface liquid flow dominates the momentum transfer at the interface between liquid and solid wall, causing the role of both the corrugation of wall potential and wall-fluid coupling strength to be less obvious. In particular, the slip length increases with increasing confined scales and shows no dependence on the confined scale once the confined scale reaches a critical value. The critical confined scale for the rough channel is larger than that of the smooth scale. Full article
(This article belongs to the Section A:Physics)
Figures

Figure 1

Open AccessArticle Etching-Assisted Ablation of the UV-Transparent Fluoropolymer CYTOP Using Various Laser Pulse Widths and Subsequent Microfluidic Applications
Micromachines 2018, 9(12), 662; https://doi.org/10.3390/mi9120662
Received: 29 November 2018 / Revised: 10 December 2018 / Accepted: 12 December 2018 / Published: 15 December 2018
PDF Full-text (3386 KB) | HTML Full-text | XML Full-text
Abstract
This work demonstrated the surface microfabrication of the UV-transparent fluoropolymer CYTOP (perfluoro 1-butenyl vinyl ether), by etching-assisted ablation using lasers with different pulse widths. In previous studies, we developed a technique for CYTOP microfluidic fabrication using laser ablation followed by etching and annealing.
[...] Read more.
This work demonstrated the surface microfabrication of the UV-transparent fluoropolymer CYTOP (perfluoro 1-butenyl vinyl ether), by etching-assisted ablation using lasers with different pulse widths. In previous studies, we developed a technique for CYTOP microfluidic fabrication using laser ablation followed by etching and annealing. However, this technique was not suitable for some industrial applications due to the requirement for prolonged etching of the irradiated areas. The present work developed a faster etching-assisted ablation method in which the laser ablation of CYTOP took place in fluorinated etching solvent and investigated into the fabrication mechanism of ablated craters obtained from various pulse width lasers. The mechanism study revealed that the efficient CYTOP microfabrication can be achieved with a longer pulse width laser using this technique. Therefore, the rapid, high-quality surface microfabrication of CYTOP was demonstrated using a conventional nanosecond laser. Additionally, Microfluidic systems were produced on a CYTOP substrate via the new etching-assisted laser ablation process followed by annealing within 1 h, which is faster than the prior work of the microfluidic chip fabrication. Subsequently, CYTOP and polydimethylsiloxane substrates were bonded to create a 3D microfluidic chip that allowed for a clear microscopic image of the fluid boundary. Full article
(This article belongs to the Special Issue Microfluidic Cell Assay Chips)
Figures

Graphical abstract

Open AccessArticle Investigation of Product and Process Fingerprints for Fast Quality Assurance in Injection Molding of Micro-Structured Components
Micromachines 2018, 9(12), 661; https://doi.org/10.3390/mi9120661
Received: 30 October 2018 / Revised: 12 December 2018 / Accepted: 13 December 2018 / Published: 15 December 2018
PDF Full-text (11613 KB) | HTML Full-text | XML Full-text
Abstract
Injection molding is increasingly gaining favor in the manufacturing of polymer components since it can ensure a cost-efficient production with short cycle times. To ensure the quality of the finished parts and the stability of the process, it is essential to perform frequent
[...] Read more.
Injection molding is increasingly gaining favor in the manufacturing of polymer components since it can ensure a cost-efficient production with short cycle times. To ensure the quality of the finished parts and the stability of the process, it is essential to perform frequent metrological inspections. In contrast to the short cycle time of injection molding itself, a metrological quality control can require a significant amount of time and the late detection of a problem may then result in increased wastage. This paper presents an alternative approach to process monitoring and the quality control of injection molded parts with the concept of “Product and Process Fingerprints” that use direct and indirect quality indicators extracted from part quality data in-mold and machine processed data. The proposed approach is based on the concept of product and process fingerprints in the form of calculated indices that are correlated to the quality of the molded parts. A statistically designed set of experiments was undertaken to map the experimental space and quantify the replication of micro-features depending on their position and on combinations of processing parameters with their main effects to discover to what extent the effects of process variation were dependent on feature shape, size, and position. The results show that a number of product and process fingerprints correlate well with the quality of the micro features of the manufactured part depending on their geometry and location and can be used as indirect indicators of part quality. The concept can, thus, support the creation of a rapid quality monitoring system that has the potential to decrease the use of off-line, time-consuming, and detailed metrology for part approval and can thus act as an early warning system during manufacturing. Full article
(This article belongs to the Special Issue Product/Process Fingerprint in Micro Manufacturing)
Figures

Figure 1

Open AccessArticle Separation and Characterization of Prostate Cancer Cell Subtype according to Their Motility Using a Multi-Layer CiGiP Culture
Micromachines 2018, 9(12), 660; https://doi.org/10.3390/mi9120660
Received: 26 November 2018 / Revised: 12 December 2018 / Accepted: 13 December 2018 / Published: 14 December 2018
PDF Full-text (2901 KB) | HTML Full-text | XML Full-text
Abstract
Cancer cell metastasis has been recognized as one hallmark of malignant tumor progression; thus, measuring the motility of cells, especially tumor cell migration, is important for evaluating the therapeutic effects of anti-tumor drugs. Here, we used a paper-based cell migration platform to separate
[...] Read more.
Cancer cell metastasis has been recognized as one hallmark of malignant tumor progression; thus, measuring the motility of cells, especially tumor cell migration, is important for evaluating the therapeutic effects of anti-tumor drugs. Here, we used a paper-based cell migration platform to separate and isolate cells according to their distinct motility. A multi-layer cells-in-gels-in-paper (CiGiP) stack was assembled. Only a small portion of DU 145 prostate cancer cells seeded in the middle layer could successfully migrate into the top and bottom layers of the stack, showing heterogeneous motility. The cells with distinct migration were isolated for further analysis. Quantitative PCR assay results demonstrated that cells with higher migration potential had increased expression of the ALDH1A1, SRY (sex-determining region Y)-box 2, NANOG, and octamer-binding transcription 4. Increased doxorubicin tolerance was also observed in cells that migrated through the CiGiP layers. In summary, the separation and characterization of prostate cancer cell subtype can be achieved by using the multi-layer CiGiP cell migration platform. Full article
(This article belongs to the Special Issue Microfluidics for Cell and Other Organisms)
Figures

Figure 1

Open AccessArticle 3D Numerical Simulation of a Z Gate Layout MOSFET for Radiation Tolerance
Micromachines 2018, 9(12), 659; https://doi.org/10.3390/mi9120659
Received: 11 November 2018 / Revised: 10 December 2018 / Accepted: 11 December 2018 / Published: 14 December 2018
PDF Full-text (1203 KB) | HTML Full-text | XML Full-text
Abstract
In this paper, for the first time, an n-channel metal-oxide-semiconductor field-effect transistor (NMOSFET) layout with a Z gate and an improved total ionizing dose (TID) tolerance is proposed. The novel layout can be radiation-hardened with a fixed charge density at the shallow trench
[...] Read more.
In this paper, for the first time, an n-channel metal-oxide-semiconductor field-effect transistor (NMOSFET) layout with a Z gate and an improved total ionizing dose (TID) tolerance is proposed. The novel layout can be radiation-hardened with a fixed charge density at the shallow trench isolation (STI) of 3.5 × 1012 cm−2. Moreover, it has the advantages of a small footprint, no limitation in W/L design, and a small gate capacitance compared with the enclosed gate layout. Beside the Z gate layout, a non-radiation-hardened single gate layout and a radiation-hardened enclosed gate layout are simulated using the Sentaurus 3D technology computer-aided design (TCAD) software. First, the transfer characteristics curves (Id-Vg) curves of the three layouts are compared to verify the radiation tolerance characteristic of the Z gate layout; then, the threshold voltage and the leakage current of the three layouts are extracted to compare their TID responses. Lastly, the threshold voltage shift and the leakage current increment at different radiation doses for the three layouts are presented and analyzed. Full article
(This article belongs to the Special Issue Miniaturized Transistors)
Figures

Figure 1

Open AccessArticle Model Development for Threshold Voltage Stability Dependent on High Temperature Operations in Wide-Bandgap GaN-Based HEMT Power Devices
Micromachines 2018, 9(12), 658; https://doi.org/10.3390/mi9120658
Received: 23 November 2018 / Revised: 23 November 2018 / Accepted: 10 December 2018 / Published: 14 December 2018
PDF Full-text (2677 KB) | HTML Full-text | XML Full-text
Abstract
Temperature-dependent threshold voltage (Vth) stability is a significant issue in the practical application of semi-conductor power devices, especially when they are undergoing a repeated high-temperature operation condition. The Vth analytical model and its stability are dependent on high-temperature operations
[...] Read more.
Temperature-dependent threshold voltage (Vth) stability is a significant issue in the practical application of semi-conductor power devices, especially when they are undergoing a repeated high-temperature operation condition. The Vth analytical model and its stability are dependent on high-temperature operations in wide-bandgap gallium nitride (GaN)-based high electron mobility transistor (HEMT) devices that were investigated in this work. The temperature effects on the physical parameters—such as barrier height, conduction band, and polarization charge—were analysed to understand the mechanism of Vth stability. The Vth analytical model under high-temperature operation was then proposed and developed to study the measurement temperatures and repeated rounds dependent on Vth stability. The validity of the model was verified by comparing the theoretical calculation data with the experimental measurement and technology computer-aided design (TCAD) simulation results. This work provides an effective theoretical reference on the Vth stability of power devices in practical, high-temperature applications. Full article
(This article belongs to the Special Issue Wide Bandgap Semiconductor Based Micro/Nano Devices)
Figures

Figure 1

Open AccessArticle Improving ESD Protection Robustness Using SiGe Source/Drain Regions in Tunnel FET
Micromachines 2018, 9(12), 657; https://doi.org/10.3390/mi9120657
Received: 14 November 2018 / Revised: 7 December 2018 / Accepted: 9 December 2018 / Published: 12 December 2018
PDF Full-text (2875 KB) | HTML Full-text | XML Full-text
Abstract
Currently, a tunnel field-effect transistor (TFET) is being considered as a suitable electrostatic discharge (ESD) protection device in advanced technology. In addition, silicon-germanium (SiGe) engineering is shown to improve the performance of TFET-based ESD protection devices. In this paper, a new TFET with
[...] Read more.
Currently, a tunnel field-effect transistor (TFET) is being considered as a suitable electrostatic discharge (ESD) protection device in advanced technology. In addition, silicon-germanium (SiGe) engineering is shown to improve the performance of TFET-based ESD protection devices. In this paper, a new TFET with SiGe source/drain (S/D) regions is proposed, and its ESD characteristics are evaluated using technology computer aided design (TCAD) simulations. Under a transmission line pulsing (TLP) stressing condition, the triggering voltage of the SiGe S/D TFET is reduced by 35% and the failure current is increased by 17% in comparison with the conventional Si S/D TFET. Physical insights relevant to the ESD enhancement of the SiGe S/D TFET are provided and discussed. Full article
(This article belongs to the Special Issue Miniaturized Transistors)
Figures

Figure 1

Open AccessArticle Mesoporous Highly-Deformable Composite Polymer for a Gapless Triboelectric Nanogenerator via a One-Step Metal Oxidation Process
Micromachines 2018, 9(12), 656; https://doi.org/10.3390/mi9120656
Received: 16 November 2018 / Revised: 3 December 2018 / Accepted: 8 December 2018 / Published: 11 December 2018
PDF Full-text (2490 KB) | HTML Full-text | XML Full-text
Abstract
The oxidation of metal microparticles (MPs) in a polymer film yields a mesoporous highly-deformable composite polymer for enhancing performance and creating a gapless structure of triboelectric nanogenerators (TENGs). This is a one-step scalable synthesis for developing large-scale, cost-effective, and light-weight mesoporous polymer composites.
[...] Read more.
The oxidation of metal microparticles (MPs) in a polymer film yields a mesoporous highly-deformable composite polymer for enhancing performance and creating a gapless structure of triboelectric nanogenerators (TENGs). This is a one-step scalable synthesis for developing large-scale, cost-effective, and light-weight mesoporous polymer composites. We demonstrate mesoporous aluminum oxide (Al2O3) polydimethylsiloxane (PDMS) composites with a nano-flake structure on the surface of Al2O3 MPs in pores. The porosity of mesoporous Al2O3-PDMS films reaches 71.35% as the concentration of Al MPs increases to 15%. As a result, the film capacitance is enhanced 1.8 times, and TENG output performance is 6.67-times greater at 33.3 kPa and 4 Hz. The pressure sensitivity of 6.71 V/kPa and 0.18 μA/kPa is determined under the pressure range of 5.5–33.3 kPa. Based on these structures, we apply mesoporous Al2O3-PDMS film to a gapless TENG structure and obtain a linear pressure sensitivity of 1.00 V/kPa and 0.02 μA/kPa, respectively. Finally, we demonstrate self-powered safety cushion sensors for monitoring human sitting position by using gapless TENGs, which are developed with a large-scale and highly-deformable mesoporous Al2O3-PDMS film with dimensions of 6 × 5 pixels (33 × 27 cm2). Full article
(This article belongs to the Special Issue Nanogenerators in Korea)
Figures

Figure 1

Open AccessArticle White-Light Photosensors Based on Ag Nanoparticle-Reduced Graphene Oxide Hybrid Materials
Micromachines 2018, 9(12), 655; https://doi.org/10.3390/mi9120655
Received: 17 October 2018 / Revised: 22 November 2018 / Accepted: 7 December 2018 / Published: 11 December 2018
PDF Full-text (2901 KB) | HTML Full-text | XML Full-text
Abstract
The unique and outstanding electrical and optical properties of graphene make it a potential material to be used in the construction of high-performance photosensors. However, the fabrication process of a graphene photosensor is usually complicated and the size of the device also is
[...] Read more.
The unique and outstanding electrical and optical properties of graphene make it a potential material to be used in the construction of high-performance photosensors. However, the fabrication process of a graphene photosensor is usually complicated and the size of the device also is restricted to micrometer scale. In this work, we report large-area photosensors based on reduced graphene oxide (rGO) implemented with Ag nanoparticles (AgNPs) via a simple and cost-effective method. To further optimize the performance of photosensors, the absorbance and distribution of the electrical field intensity of graphene with AgNPs was simulated using the finite-difference time-domain (FDTD) method through use of the surface plasmon resonance effect. Based on the simulated results, we constructed photosensors using rGO with 60–80 nm AgNPs and analyzed the characteristics at room temperature under white-light illumination for outdoor environment applications. The on/off ratio of the photosensor with AgNPs was improved from 1.166 to 9.699 at the bias voltage of −1.5 V, which was compared as a sample without AgNPs. The proposed photosensor affords a new strategy to construct cost-effective and large-area graphene films which raises opportunities in the field of next-generation optoelectronic devices operated in an outdoor environment. Full article
(This article belongs to the Special Issue Carbon Based Electronic Devices)
Figures

Figure 1

Open AccessReview Nanoindentation of Soft Biological Materials
Micromachines 2018, 9(12), 654; https://doi.org/10.3390/mi9120654
Received: 29 October 2018 / Revised: 27 November 2018 / Accepted: 5 December 2018 / Published: 11 December 2018
PDF Full-text (2909 KB) | HTML Full-text | XML Full-text
Abstract
Nanoindentation techniques, with high spatial resolution and force sensitivity, have recently been moved into the center of the spotlight for measuring the mechanical properties of biomaterials, especially bridging the scales from the molecular via the cellular and tissue all the way to the
[...] Read more.
Nanoindentation techniques, with high spatial resolution and force sensitivity, have recently been moved into the center of the spotlight for measuring the mechanical properties of biomaterials, especially bridging the scales from the molecular via the cellular and tissue all the way to the organ level, whereas characterizing soft biomaterials, especially down to biomolecules, is fraught with more pitfalls compared with the hard biomaterials. In this review we detail the constitutive behavior of soft biomaterials under nanoindentation (including AFM) and present the characteristics of experimental aspects in detail, such as the adaption of instrumentation and indentation response of soft biomaterials. We further show some applications, and discuss the challenges and perspectives related to nanoindentation of soft biomaterials, a technique that can pinpoint the mechanical properties of soft biomaterials for the scale-span is far-reaching for understanding biomechanics and mechanobiology. Full article
(This article belongs to the Special Issue Small Scale Deformation using Advanced Nanoindentation Techniques)
Figures

Figure 1

Open AccessArticle Manufacturing Signatures of Injection Molding and Injection Compression Molding for Micro-Structured Polymer Fresnel Lens Production
Micromachines 2018, 9(12), 653; https://doi.org/10.3390/mi9120653
Received: 18 September 2018 / Revised: 2 December 2018 / Accepted: 7 December 2018 / Published: 10 December 2018
PDF Full-text (14529 KB) | HTML Full-text | XML Full-text
Abstract
Injection compression molding (ICM) provides enhanced optical performances of molded polymer optics in terms of birefringence and transmission of light compared to Injection molding (IM). Nevertheless, ICM requires case-dedicated process optimization to ensure that the required high accuracy geometrical replication is achieved, particularly
[...] Read more.
Injection compression molding (ICM) provides enhanced optical performances of molded polymer optics in terms of birefringence and transmission of light compared to Injection molding (IM). Nevertheless, ICM requires case-dedicated process optimization to ensure that the required high accuracy geometrical replication is achieved, particularly especially in the case of surface micro-features. In this study, two factorial designs of experiments (DOE) were carried out to investigate the replication capability of IM and ICM on a micro structured Fresnel lens. A laser scanning confocal microscope was employed for the quality control of the optical components. Thus, a detailed uncertainty budget was established for the dimensional measurements of the replicated Fresnel lenses, considering specifically peak-to-valley (PV) step height and the pitch of the grooves. Additional monitoring of injection pressure allowed for the definition of a manufacturing signature, namely, the process fingerprint for the evaluation of the replication fidelity under different process conditions. Moreover, considerations on the warpage of parts were related to a manufacturing signature of the molding processes. At last, the global part mass average and standard deviation were measured to correlate local geometrical replication performances with global part quality trends. Full article
(This article belongs to the Special Issue Product/Process Fingerprint in Micro Manufacturing)
Figures

Figure 1

Open AccessArticle Explosion Suppression Mechanism Characteristics of MEMS S&A Device With In Situ Synthetic Primer
Micromachines 2018, 9(12), 652; https://doi.org/10.3390/mi9120652
Received: 29 October 2018 / Revised: 23 November 2018 / Accepted: 5 December 2018 / Published: 10 December 2018
PDF Full-text (4180 KB) | HTML Full-text | XML Full-text
Abstract
The traditional silicon-based micro-electro-mechanical systems (MEMS) safety and arming (S&A) device fuze cannot isolate abnormal outputs in the detonation environment, which creates hazards for personnel. To address this problem, we report the design of a MEMS S&A device with integrated silver, copper, nickel
[...] Read more.
The traditional silicon-based micro-electro-mechanical systems (MEMS) safety and arming (S&A) device fuze cannot isolate abnormal outputs in the detonation environment, which creates hazards for personnel. To address this problem, we report the design of a MEMS S&A device with integrated silver, copper, nickel and polyimide (PI) films, which is based on the principle of a MEMS S&A device and uses copper azide as the primer. The MEMS S&A device was optimized using theoretical calculations of the explosion suppression mechanism performance in a detonation field, where the theoretical model was verified by dynamic simulation (LS-Dyna). Silicon-based MEMS processing technology was used to integrate the MEMS S&A device with energy-absorbing materials, and the device performance was compared in detonation tests. Silicon-based MEMS S&A devices with silver, copper, nickel, and PI (100-μm-thick) achieved a reliable explosion suppression mechanism capability when exposed to a detonation wave. The residual stress was measured using Raman microscopy, and the PI film exhibited the best explosion suppression mechanism performance of the four materials. A reliability test to determine the maximum explosion suppression mechanism dose for a MEMS S&A device attached to a PI film (100-μm-thick) showed that the maximum amount of primer needed for the effective explosion suppression mechanism capability on the MEMS S&A device was 0.45 mg. Full article
Figures

Figure 1

Open AccessReview Recent Advances in AIV Biosensors Composed of Nanobio Hybrid Material
Micromachines 2018, 9(12), 651; https://doi.org/10.3390/mi9120651
Received: 13 October 2018 / Revised: 29 November 2018 / Accepted: 6 December 2018 / Published: 9 December 2018
PDF Full-text (3307 KB) | HTML Full-text | XML Full-text
Abstract
Since the beginning of the 2000s, globalization has accelerated because of the development of transportation systems that allow for human and material exchanges throughout the world. However, this globalization has brought with it the rise of various pathogenic viral agents, such as Middle
[...] Read more.
Since the beginning of the 2000s, globalization has accelerated because of the development of transportation systems that allow for human and material exchanges throughout the world. However, this globalization has brought with it the rise of various pathogenic viral agents, such as Middle East respiratory syndrome coronavirus (MERS-CoV), severe acute respiratory syndrome coronavirus (SARS-CoV), Zika virus, and Dengue virus. In particular, avian influenza virus (AIV) is highly infectious and causes economic, health, ethnical, and social problems to human beings, which has necessitated the development of an ultrasensitive and selective rapid-detection system of AIV. To prevent the damage associated with the spread of AIV, early detection and adequate treatment of AIV is key. There are traditional techniques that have been used to detect AIV in chickens, ducks, humans, and other living organisms. However, the development of a technique that allows for the more rapid diagnosis of AIV is still necessary. To achieve this goal, the present article reviews the use of an AIV biosensor employing nanobio hybrid materials to enhance the sensitivity and selectivity of the technique while also reducing the detection time and high-throughput process time. This review mainly focused on four techniques: the electrochemical detection system, electrical detection method, optical detection methods based on localized surface plasmon resonance, and fluorescence. Full article
Figures

Figure 1

Open AccessArticle Effect of Dielectric Distributed Bragg Reflector on Electrical and Optical Properties of GaN-Based Flip-Chip Light-Emitting Diodes
Micromachines 2018, 9(12), 650; https://doi.org/10.3390/mi9120650
Received: 31 October 2018 / Revised: 30 November 2018 / Accepted: 6 December 2018 / Published: 8 December 2018
PDF Full-text (2745 KB) | HTML Full-text | XML Full-text
Abstract
We demonstrated two types of GaN-based flip-chip light-emitting diodes (FCLEDs) with distributed Bragg reflector (DBR) and without DBR to investigate the effect of dielectric TiO2/SiO2 DBR on optical and electrical characteristics of FCLEDs. The reflector consisting of two single TiO
[...] Read more.
We demonstrated two types of GaN-based flip-chip light-emitting diodes (FCLEDs) with distributed Bragg reflector (DBR) and without DBR to investigate the effect of dielectric TiO2/SiO2 DBR on optical and electrical characteristics of FCLEDs. The reflector consisting of two single TiO2/SiO2 DBR stacks optimized for different central wavelengths demonstrates a broader reflectance bandwidth and a less dependence of reflectance on the incident angle of light. As a result, the light output power (LOP) of FCLED with DBR shows 25.3% higher than that of FCLED without DBR at 150 mA. However, due to the better heat dissipation of FCLED without DBR, it was found that the light output saturation current shifted from 268 A/cm2 for FCLED with DBR to 296 A/cm2 for FCLED without DBR. We found that the use of via-hole-based n-type contacts can spread injection current uniformly over the entire active emitting region. Our study paves the way for application of DBR and via-hole-based n-type contact in high-efficiency FCLEDs. Full article
(This article belongs to the Special Issue Wide Bandgap Semiconductor Based Micro/Nano Devices)
Figures

Figure 1

Open AccessArticle Interfacing Digital Microfluidics with Ambient Mass Spectrometry Using SU-8 as Dielectric Layer
Micromachines 2018, 9(12), 649; https://doi.org/10.3390/mi9120649
Received: 20 November 2018 / Revised: 27 November 2018 / Accepted: 6 December 2018 / Published: 8 December 2018
PDF Full-text (3778 KB) | HTML Full-text | XML Full-text | Supplementary Files
Abstract
This work describes the interfacing of electrowetting-on-dielectric based digital microfluidic (DMF) sample preparation devices with ambient mass spectrometry (MS) via desorption atmospheric pressure photoionization (DAPPI). The DMF droplet manipulation technique was adopted to facilitate drug distribution and metabolism assays in droplet scale, while
[...] Read more.
This work describes the interfacing of electrowetting-on-dielectric based digital microfluidic (DMF) sample preparation devices with ambient mass spectrometry (MS) via desorption atmospheric pressure photoionization (DAPPI). The DMF droplet manipulation technique was adopted to facilitate drug distribution and metabolism assays in droplet scale, while ambient mass spectrometry (MS) was exploited for the analysis of dried samples directly on the surface of the DMF device. Although ambient MS is well-established for bio- and forensic analyses directly on surfaces, its interfacing with DMF is scarce and requires careful optimization of the surface-sensitive processes, such as sample precipitation and the subsequent desorption/ionization. These technical challenges were addressed and resolved in this study by making use of the high mechanical, thermal, and chemical stability of SU-8. In our assay design, SU-8 served as the dielectric layer for DMF as well as the substrate material for DAPPI-MS. The feasibility of SU-8 based DMF devices for DAPPI-MS was demonstrated in the analysis of selected pharmaceuticals following on-chip liquid-liquid extraction or an enzymatic dealkylation reaction. The lower limits of detection were in the range of 1–10 pmol per droplet (0.25–1.0 µg/mL) for all pharmaceuticals tested. Full article
(This article belongs to the Special Issue SU-8 for Microfluidics and Lab-on-a-chip)
Figures

Figure 1

Open AccessArticle Fabrication of Stable Carbon Nanotube Cold Cathode Electron Emitters with Post-Growth Electrical Aging
Micromachines 2018, 9(12), 648; https://doi.org/10.3390/mi9120648
Received: 8 November 2018 / Revised: 27 November 2018 / Accepted: 5 December 2018 / Published: 7 December 2018
PDF Full-text (4376 KB) | HTML Full-text | XML Full-text
Abstract
We fabricated carbon nanotube (CNT) cold cathode emitters with enhanced and stable electron emission properties and long-time stability with electrical aging as a post-treatment. Our CNT field emitters showed improved electrical properties by electrical aging. We set the applied bias for effective electrical
[...] Read more.
We fabricated carbon nanotube (CNT) cold cathode emitters with enhanced and stable electron emission properties and long-time stability with electrical aging as a post-treatment. Our CNT field emitters showed improved electrical properties by electrical aging. We set the applied bias for effective electrical aging, with the bias voltage defined at the voltage where Joule heating appeared. At the initial stage of aging, the electron emission current started to increase and then was saturated within 3 h. We understood that 5 h aging time was enough at proper aging bias. If the aging bias is higher, excessive heating damages CNT emitters. With the electrical aging, we obtained improved electron emission current from 3 mA to 6 mA. The current of 6 mA was steadily driven for 9 h. Full article
(This article belongs to the Special Issue Carbon Based Electronic Devices)
Figures

Figure 1

Open AccessArticle Numerical Solution of the Electrokinetic Equations for Multi-ionic Electrolytes Including Different Ionic Size Related Effects
Micromachines 2018, 9(12), 647; https://doi.org/10.3390/mi9120647
Received: 8 November 2018 / Revised: 26 November 2018 / Accepted: 5 December 2018 / Published: 7 December 2018
PDF Full-text (2157 KB) | HTML Full-text | XML Full-text
Abstract
One of the main assumptions of the standard electrokinetic model is that ions behave as point-like entities. In a previous work (López-García, et al., 2015) we removed this assumption and analyzed the influence of finite ionic size on the dielectric and electrokinetic properties
[...] Read more.
One of the main assumptions of the standard electrokinetic model is that ions behave as point-like entities. In a previous work (López-García, et al., 2015) we removed this assumption and analyzed the influence of finite ionic size on the dielectric and electrokinetic properties of colloidal suspensions using both the Bikerman and the Carnahan–Starling equations for the steric interactions. It was shown that these interactions improved upon the standard model predictions so that the surface potential, electrophoretic mobility, and the conductivity and permittivity increment values were increased. In the present study, we extend our preceding works to systems made of three or more ionic species with different ionic sizes. Under these conditions, the Bikerman and Carnahan–Starling expressions cease to be valid since they were deduced for single-size spheres. Fortunately, the Carnahan–Starling expression has been extended to mixtures of spheres of unequal size, namely the “Boublik–Mansoori–Carnahan–Starling–Leland” (BMCSL) equation of state, making it possible to analyze the most general case. It is shown that the BMCSL expression leads to results that differ qualitatively and quantitatively from the standard electrokinetic model. Full article
(This article belongs to the Special Issue AC Electrokinetics in Microfluidic Devices)
Figures

Figure 1

Open AccessArticle High-Precision and Low-Cost Wireless 16-Channel Measurement System for Malachite Green Detection
Micromachines 2018, 9(12), 646; https://doi.org/10.3390/mi9120646
Received: 14 November 2018 / Revised: 30 November 2018 / Accepted: 4 December 2018 / Published: 7 December 2018
PDF Full-text (8710 KB) | HTML Full-text | XML Full-text
Abstract
Focusing on the issue of the malachite green traditional test methods such as large volume, high cost and high complex, this paper proposed a novel multi-channel electrochemical malachite green detection system. Specific recognition properties of malachite green DNA adapter is employed to realize
[...] Read more.
Focusing on the issue of the malachite green traditional test methods such as large volume, high cost and high complex, this paper proposed a novel multi-channel electrochemical malachite green detection system. Specific recognition properties of malachite green DNA adapter is employed to realize accurate sensing of concentration of malachite green, which can achieve precise detection of malachite green concentration with low noise and high precision. The maximum measurement capability of multi-channel acquisition system is 16 samples in a batch. According to the experimental results, malachite green could be detected quantitatively in the range from 10−3 μg/mL to 10 μg/mL, which performs well in the test of malachite green residues in aquatic product transportation. Full article
Figures

Figure 1

Open AccessArticle The Effect of Encapsulation Geometry on the Performance of Stretchable Interconnects
Micromachines 2018, 9(12), 645; https://doi.org/10.3390/mi9120645
Received: 29 September 2018 / Revised: 18 November 2018 / Accepted: 29 November 2018 / Published: 5 December 2018
Viewed by 101 | PDF Full-text (7744 KB) | HTML Full-text | XML Full-text
Abstract
The stretchability of electronic devices is typically obtained by tailoring the stretchable interconnects that link the functional units together. The durability of the interconnects against environmental conditions, such as deformation and chemicals, is therefore important to take into account. Different approaches, including encapsulation,
[...] Read more.
The stretchability of electronic devices is typically obtained by tailoring the stretchable interconnects that link the functional units together. The durability of the interconnects against environmental conditions, such as deformation and chemicals, is therefore important to take into account. Different approaches, including encapsulation, are commonly used to improve the endurance of stretchable interconnects. In this paper, the geometry of encapsulation layer is initially investigated using finite element analysis. Then, the stretchable interconnects with a narrow-to-wide layout are screen-printed using silver flake ink as a conductor on a thermoplastic polyurethane (TPU) substrate. Printed ultraviolet (UV)-curable screen-printed dielectric ink and heat-laminated TPU film are used for the encapsulation of the samples. The electromechanical tests reveal a noticeable improvement in performance of encapsulated samples compared to non-protected counterparts in the case of TPU encapsulation. The improvement is even greater with partial coverage of the encapsulation layer. A device with a modified encapsulation layer can survive for 10,000 repetitive cycles at 20% strain, while maintaining the electrical and mechanical performance. Full article
(This article belongs to the Special Issue Printed Flexible and Stretchable Electronics)
Figures

Figure 1

Open AccessArticle Fabrication and Characteristics of SnAgCu Alloy Nanowires for Electrical Connection Application
Micromachines 2018, 9(12), 644; https://doi.org/10.3390/mi9120644
Received: 15 November 2018 / Revised: 27 November 2018 / Accepted: 3 December 2018 / Published: 5 December 2018
Viewed by 92 | PDF Full-text (3677 KB) | HTML Full-text | XML Full-text
Abstract
As electronic products become more functional, the devices are required to provide better performances and meet ever smaller form factor requirements. To achieve a higher I/O density within the smallest form factor package, applying nanotechniques to electronic packaging can be regarded as a
[...] Read more.
As electronic products become more functional, the devices are required to provide better performances and meet ever smaller form factor requirements. To achieve a higher I/O density within the smallest form factor package, applying nanotechniques to electronic packaging can be regarded as a possible approach in microelectronic technology. Sn-3.0 wt% Ag-0.5 wt% Cu (SAC305) is a common solder material of electrical connections in microelectronic devices. In this study, SAC305 alloy nanowire was fabricated in a porous alumina membrane with a pore diameter of 50 nm by the pressure casting method. The crystal structure and composition analyses of SAC305 nanowires show that the main structure of the nanowire is β-Sn, and the intermetallic compound, Ag3Sn, locates randomly but always appears on the top of the nanowire. Furthermore, differential scanning calorimetry (DSC) results indicate the melting point of SAC305 alloy nanowire is around 227.7 °C. The melting point of SAC305 alloy nanowire is significantly higher than that of SAC305 bulk alloy (219.4 °C). It is supposed that the non-uniform phase distribution and composite difference between the nanowires causes the change of melting temperature. Full article
Figures

Figure 1

Open AccessArticle Variability Predictions for the Next Technology Generations of n-type SixGe1−x Nanowire MOSFETs
Micromachines 2018, 9(12), 643; https://doi.org/10.3390/mi9120643
Received: 21 November 2018 / Revised: 29 November 2018 / Accepted: 30 November 2018 / Published: 5 December 2018
Viewed by 112 | PDF Full-text (1373 KB) | HTML Full-text | XML Full-text
Abstract
Using a state-of-the-art quantum transport simulator based on the effective mass approximation, we have thoroughly studied the impact of variability on SixGe1x channel gate-all-around nanowire metal-oxide-semiconductor field-effect transistors (NWFETs) associated with random discrete dopants, line edge roughness, and
[...] Read more.
Using a state-of-the-art quantum transport simulator based on the effective mass approximation, we have thoroughly studied the impact of variability on Si x Ge 1 x channel gate-all-around nanowire metal-oxide-semiconductor field-effect transistors (NWFETs) associated with random discrete dopants, line edge roughness, and metal gate granularity. Performance predictions of NWFETs with different cross-sectional shapes such as square, circle, and ellipse are also investigated. For each NWFETs, the effective masses have carefully been extracted from s p 3 d 5 s tight-binding band structures. In total, we have generated 7200 transistor samples and performed approximately 10,000 quantum transport simulations. Our statistical analysis reveals that metal gate granularity is dominant among the variability sources considered in this work. Assuming the parameters of the variability sources are the same, we have found that there is no significant difference of variability between SiGe and Si channel NWFETs. Full article
(This article belongs to the Special Issue Miniaturized Transistors)
Figures

Figure 1

Back to Top
