Dr. Xiyuan Feng

E-Mail Website
Guest Editor

School of Microelectronics, Northwestern Polytechnical University, Xi'an 710071, China
Interests: synergy between semiconductor device innovation; on-chip ESD protection techniques; TCAD-assisted device simulation; advanced ADC circuit design
Special Issues, Collections and Topics in MDPI journals

Dr. Yunlei Zhong

E-Mail Website
Guest Editor

Key Laboratory of Multifunctional Nanomaterials and Smart Systems, Division of Advanced Materials, Suzhou Institute of Nano-Tech and Nano-Bionics, Chinese Academy of Sciences, Suzhou 215123, China
Interests: novel condensed matter properties of low dimensional materials; optoelectronic devices; catalysis; energy storage
Special Issues, Collections and Topics in MDPI journals

Special Issue Information

Dear Colleagues,

This Special Issue addresses the critical intersection of emerging semiconductor materials with the full lifecycle of advanced semiconductor devices and integrated circuits (ICs)—from fabrication to long-term operational robustness. As Moore’s Law confronts physical scaling limits, materials like gallium nitride (GaN), silicon carbide (SiC) and two-dimensional (2D) materials (e.g., MoS₂, graphene) have emerged as game-changers, enabling higher efficiency, faster switching and novel functionalities. However, their integration introduces unprecedented challenges: non-ideal interfaces during fabrication, defect-mediated degradation under stress and complex multi-physics couplings that defy conventional reliability models.

We focus on bridging material innovation to practical deployment by exploring (1) advanced fabrication techniques tailored to emerging materials; (2) physics-based simulation tools to predict device lifetime and failure modes; and (3) protective strategies (e.g., passivation, thermal management) to mitigate material-specific vulnerabilities. Contributions span experimental characterization, computational modeling and case studies on power electronics, neuromorphic systems and beyond. This issue aims to foster cross-disciplinary collaboration, establishing a framework for ensuring trustworthiness in next-generation semiconductors and accelerating their industrial adoption.

Dr. Xiyuan Feng
Dr. Yunlei Zhong
Guest Editors

Manuscript Submission Information

Manuscripts should be submitted online at www.mdpi.com by registering and logging in to this website. Once you are registered, click here to go to the submission form. Manuscripts can be submitted until the deadline. All submissions that pass pre-check are peer-reviewed. Accepted papers will be published continuously in the journal (as soon as accepted) and will be listed together on the special issue website. Research articles, review articles as well as short communications are invited. For planned papers, a title and short abstract (about 250 words) can be sent to the Editorial Office for assessment.

Submitted manuscripts should not have been published previously, nor be under consideration for publication elsewhere (except conference proceedings papers). All manuscripts are thoroughly refereed through a single-blind peer-review process. A guide for authors and other relevant information for submission of manuscripts is available on the Instructions for Authors page. Micromachines is an international peer-reviewed open access monthly journal published by MDPI.
