This study presents an integrated design-to-operation framework for a PV–battery solar highway lighting system supported by IoT-based monitoring for highway-scale deployment. The proposed framework combines pole-level PV-battery sizing, annual energy-reliability simulation, road-level techno-economic optimization, and IoT-based digital monitoring. The Shoubra–Banha Freeway in Egypt, a 40 km corridor with a two-sided lighting arrangement, was selected as the case study. In the pole-level phase, dimming strategies, PV capacities, battery sizes, and battery technologies were evaluated using sequential parametric analysis under a reliability constraint of Loss of Load Probability (LLP) below 1%. The S2 aggressive dimming profile achieved the best operating performance, with an LLP of 0.003, energy reliability of 99.70%, and 2.89 kWh annual unmet load. The minimum feasible PV capacity was 0.8 kW, while the smallest acceptable storage capacity was 4.8 kWh nominal capacity, corresponding to approximately 3.84 kWh usable capacity under an 80% allowable depth of discharge. Among the tested battery technologies, LiFePO
4 achieved the best reliability performance, with an LLP of 0.007 and a 99.25% battery deficit coverage ratio. In the road-level phase, three deployment configurations were compared. Case B, using 12 m pole height and 36 m spacing, was selected as the best-balanced solution, requiring 2224 poles, achieving 99.30% energy reliability, an LLP of 0.007, annual PV generation of 3,178,341 kWh, and total CAPEX of approximately 2.88 × 10
8 EGP, equivalent to about 5.76 million USD based on an assumed exchange rate of 1 USD = 50 EGP. Lastly, the development of an IoT-based monitoring system design utilizing sector gateways, telemetry variables, alarm conditions, MQTT protocols, and dashboard displays was carried out. The scenario for gateways at 5 km intervals was advised due to its better fault isolation, lower gateway workload, and scalability. This indicates that the suggested approach offers a viable, cost-efficient, and technologically enabled solution for automated solar-powered street lighting systems.
