J. Manuf. Mater. Process., Volume 5, Issue 2 (June 2021) – 36 articles

  • Issues are regarded as officially published after their release is announced to the table of contents alert mailing list.
  • You may sign up for e-mail alerts to receive table of contents of newly released issues.
  • PDF is the official format for papers published in both, html and pdf forms. To view the papers in pdf format, click on the "PDF Full-text" link, and use the free Adobe Readerexternal link to open them.
Order results
Result details
Select all
Export citation of selected articles as:
Article
The Energy Balance in Aluminum–Copper High-Speed Collision Welding
J. Manuf. Mater. Process. 2021, 5(2), 62; https://doi.org/10.3390/jmmp5020062 - 15 Jun 2021
Viewed by 168
Abstract
Collision welding is a joining technology that is based on the high-speed collision and the resulting plastic deformation of at least one joining partner. The ability to form a high-strength substance-to-substance bond between joining partners of dissimilar metals allows us to design a [...] Read more.
Collision welding is a joining technology that is based on the high-speed collision and the resulting plastic deformation of at least one joining partner. The ability to form a high-strength substance-to-substance bond between joining partners of dissimilar metals allows us to design a new generation of joints. However, the occurrence of process-specific phenomena during the high-speed collision, such as a so-called jet or wave formation in the interface, complicates the prediction of bond formation and the resulting bond properties. In this paper, the collision welding of aluminum and copper was investigated at the lower limits of the process. The experiments were performed on a model test rig and observed by high-speed imaging to determine the welding window, which was compared to the ones of similar material parings from former investigation. This allowed to deepen the understanding of the decisive mechanisms at the welding window boundaries. Furthermore, an optical and a scanning electron microscope with energy dispersive X-ray analysis were used to analyze the weld interface. The results showed the important and to date neglected role of the jet and/or the cloud of particles to extract energy from the collision zone, allowing bond formation without melting and intermetallic phases. Full article
(This article belongs to the Special Issue Impulse-Based Manufacturing Technologies)
Show Figures

Figure 1

Article
Sonotrodes for Ultrasonic Welding of Titanium/CFRP-Joints—Materials Selection and Design
J. Manuf. Mater. Process. 2021, 5(2), 61; https://doi.org/10.3390/jmmp5020061 - 12 Jun 2021
Viewed by 269
Abstract
Ultrasonic welding of titanium alloy Ti6Al4V to carbon fibre reinforced polymer (CFRP) at 20 kHz frequency requires suitable welding tools, so called sonotrodes. The basic function of ultrasonic welding sonotrodes is to oscillate with displacement amplitudes typically up to 50 µm at frequencies [...] Read more.
Ultrasonic welding of titanium alloy Ti6Al4V to carbon fibre reinforced polymer (CFRP) at 20 kHz frequency requires suitable welding tools, so called sonotrodes. The basic function of ultrasonic welding sonotrodes is to oscillate with displacement amplitudes typically up to 50 µm at frequencies close to the eigenfrequency of the oscillation unit. Material properties, the geometry of the sonotrode, and the sonotrode tip topography together determine the longevity of the sonotrode. Durable sonotrodes for ultrasonic welding of high-strength joining partners, e.g., titanium alloys, have not been investigated so far. In this paper, finite element simulations were used to establish a suitable design assuring the oscillation of a longitudinal eigenmode at the operation frequency of the welding machine and to calculate local mechanical stresses. The primary aim of this work is to design a sonotrode that can be used to join high-strength materials such as Ti6Al4V by ultrasonic welding considering the longevity of the welding tools and high-strength joints. Material, sonotrode geometry, and sonotrode tip topography were designed and investigated experimentally to identify the most promising sonotrode design for continuous ultrasonic welding of Ti6AlV4 and CFRP. Eigenfrequency and modal shape were measured in order to examine the reliability of the calculations and to compare the performance of all investigated sonotrodes. Full article
Show Figures

Figure 1

Article
Simulation Based Prediction of Compliance Induced Shape Deviations in Internal Traverse Grinding
J. Manuf. Mater. Process. 2021, 5(2), 60; https://doi.org/10.3390/jmmp5020060 - 08 Jun 2021
Viewed by 253
Abstract
Internal traverse grinding (ITG) using electroplated cBN tools in high-speed grinding conditions is a highly efficient manufacturing process for bore machining in a single axial stroke. However, process control is difficult. Due to the axial direction of feed, changes in process normal force [...] Read more.
Internal traverse grinding (ITG) using electroplated cBN tools in high-speed grinding conditions is a highly efficient manufacturing process for bore machining in a single axial stroke. However, process control is difficult. Due to the axial direction of feed, changes in process normal force and thus radial deflection of the tool and workpiece spindle system, lead to deviations in the workpiece contour along the length of the bore, especially at tool exit. Simulations including this effect could provide a tool to design processes which enhance shape accuracy of components. A geometrical physically-based simulation is herein developed to model the influence of system compliance on the resulting workpiece contour. Realistic tool topographies, obtained from measurements, are combined with an FE-calibrated surrogate model for process forces and with an empirical compliance model. In quasistatic experimental investigations, the spindle deflection is determined in relation to the acting normal forces by using piezoelectric force measuring elements and eddy current sensors. In grinding tests with in-process force measurement technology and followed by measurement of the resulting workpiece contours, the simulation system is validated. The process forces and the resulting characteristic shape deviations are predicted in good qualitative accordance with the experimental results. Full article
(This article belongs to the Special Issue Progress in Digital Twin Integration for Smart Machining)
Show Figures

Graphical abstract

Article
Generation of Efficient Iso-Planar Printing Path for Multi-Axis FDM Printing
J. Manuf. Mater. Process. 2021, 5(2), 59; https://doi.org/10.3390/jmmp5020059 - 07 Jun 2021
Viewed by 154
Abstract
The emerging multi-axis fused deposition modeling (FDM) printing process is a powerful technology for fabricating complicated 3D models that otherwise would require extensive support structures or suffer the severe stair-case effect if printed on a conventional three-axis FDM printer. However, because of the [...] Read more.
The emerging multi-axis fused deposition modeling (FDM) printing process is a powerful technology for fabricating complicated 3D models that otherwise would require extensive support structures or suffer the severe stair-case effect if printed on a conventional three-axis FDM printer. However, because of the addition of two rotary axes which enables the printing nozzle to change its orientation continuously, and the fact that the printing layer is now curved, determining how a nozzle printing path to cover the layer becomes a non-trivial issue, since the rotary axes of the printer in general have a much worse kinematic capacity than the linear axes. In this paper, specifically targeting robotic printing, we first propose an efficiency indicator called the material deposition rate which considers both the local geometry of the layer surface and the kinematic capacities of the printer. By maximizing this indicator globally, a best drive plane direction is found, and then the classic iso-planar method is adopted to generate the printing path for the layer, which not only upholds the specified printing quality but also strives to maximize the kinematic capacities of the printer to minimize the total printing time. Preliminary experiments in both computer simulation and physical printing are carried out and the results give a positive confirmation on the proposed method. Full article
(This article belongs to the Special Issue Advances in Multi-Axis Machining)
Show Figures

Figure 1

Communication
Dual-Axial Tool Servo Diamond Turning of Hierarchical Micro-Nano-Structured Surfaces
J. Manuf. Mater. Process. 2021, 5(2), 58; https://doi.org/10.3390/jmmp5020058 - 07 Jun 2021
Viewed by 196
Abstract
This paper reports on a dual-axial tool servo diamond turning method for the one-step fabrication of hierarchical micro-nano-structured surfaces. With respect to the dual-axial servo motion (XZ), the z-axis motion can generate the primary surface with a complex shape, and the x [...] Read more.
This paper reports on a dual-axial tool servo diamond turning method for the one-step fabrication of hierarchical micro-nano-structured surfaces. With respect to the dual-axial servo motion (XZ), the z-axis motion can generate the primary surface with a complex shape, and the x-axis motion is used to synchronously form the secondary structure via controlling the residual tool marks. The toolpath determination algorithm for the developed turning method is described in detail, and the effect of the machining parameters on the basic feature and sizes of the generated secondary structures is investigated through conducting the numerical simulation for both toolpath and surface generation. The simulation result indicates that the additional x-axial motion is effective for the deterministic generation of a variety of secondary structures. Finally, taking advantage of an ultra-precision lathe with a self-developed tri-axial FTS, a hierarchical surface with high accuracy is practically generated. Full article
(This article belongs to the Special Issue Progress in Precision Machining)
Show Figures

Figure 1

Communication
An Approach to Detect White Spots during Pre-Turning of DA718 Components
J. Manuf. Mater. Process. 2021, 5(2), 57; https://doi.org/10.3390/jmmp5020057 - 01 Jun 2021
Viewed by 413
Abstract
The increasing demand for high-performance components is leading to a greater use of advanced alloys such as DA718, which is, e.g., used in engine parts due to its high-temperature strength. The strict quality requirements pose major challenges for the machining of engine components [...] Read more.
The increasing demand for high-performance components is leading to a greater use of advanced alloys such as DA718, which is, e.g., used in engine parts due to its high-temperature strength. The strict quality requirements pose major challenges for the machining of engine components for aircrafts. Quality deviations along the value chain can lead to high costs due to rework and, in the worst case, rejections in order to prevent material failure within a safety-critical environment. These deviations include, e.g., an increased surface roughness, deviations in the shape tolerances as well as increased internal stresses or surface deformations. Material defects are an additional reason to reject the manufactured components. These are usually inspected only at the end of the value chain and—due to measurement limitations—only if they occur close to the surface of the workpiece. Ultrasonic testing is used in order to detect defects near the surface of the raw part. For the evaluation of the finished part, etching and optical inspection of the surface is used. However, defects inside the components cannot be detected in this way. If material defects are located in areas subjected to intense load changes and high temperatures, the components have to be rejected since engine parts require a high level of fatigue strength. Such rejects constitute a significant economic risk, as a large part of the added value has already been completed and a significant amount of machine time has been invested. Thus, an identification of material defects in an earlier stage of the manufacturing process is required. In this paper, fundamental investigations on machining artificially generated material defects in a micro-milling process and the signal analysis during the pre-turning of turbine disks made of nickel-based materials like DA718 will be presented. Based on force measurements, characteristic signals were identified that could indicate material defects during the turning process. Full article
(This article belongs to the Special Issue Progress in Digital Twin Integration for Smart Machining)
Show Figures

Figure 1

Article
Influence of Constitutive Models and the Choice of the Parameters on FE Simulation of Ti6Al4V Orthogonal Cutting Process for Different Uncut Chip Thicknesses
J. Manuf. Mater. Process. 2021, 5(2), 56; https://doi.org/10.3390/jmmp5020056 - 29 May 2021
Viewed by 425
Abstract
The constitutive model and its pertinent set of parameters are important input data in finite element modeling to define the behavior of Ti6Al4V during machining process. The present work focusses on comparing different constitutive models and the parameters sets available in literatures and [...] Read more.
The constitutive model and its pertinent set of parameters are important input data in finite element modeling to define the behavior of Ti6Al4V during machining process. The present work focusses on comparing different constitutive models and the parameters sets available in literatures and investigating the quality of the predictions when varying uncut chip thickness (40 µm, 60 µm, 100 µm and 280 µm). In addition, temperature-dependent strain hardening factor along with strain softening phenomenon based reconstructed material model is proposed. The results from the numerical simulations are compared with experimental results available in literature. The comparison shows that the force values are highly influenced by constitutive models and the choice of parameters sets, whereas the chip morphologies are mainly influenced by the uncut chip thickness and constitutive models. This work justifies the need for an appropriate set of parameters and constitutive model that replicate the machining behavior of Ti6Al4V alloy for different cutting conditions. Full article
(This article belongs to the Special Issue Advances in Modelling of Machining Operations)
Show Figures

Figure 1

Article
Thermal Effects on Surface and Subsurface Modifications in Laser-Combined Deep Rolling
J. Manuf. Mater. Process. 2021, 5(2), 55; https://doi.org/10.3390/jmmp5020055 - 28 May 2021
Viewed by 210
Abstract
Knowledge of the relationships between thermomechanical process loads and the resulting modifications in the surface layer enables targeted adjustments of the required surface integrity independent of the manufacturing process. In various processes with thermomechanical impact, thermal and mechanical loads act simultaneously and affect [...] Read more.
Knowledge of the relationships between thermomechanical process loads and the resulting modifications in the surface layer enables targeted adjustments of the required surface integrity independent of the manufacturing process. In various processes with thermomechanical impact, thermal and mechanical loads act simultaneously and affect each other. Thus, the effects on the modifications are interdependent. To gain a better understanding of the interactions of the two loads, it is necessary to vary thermal and mechanical loads independently. A new process of laser-combined deep rolling can fulfil exactly this requirement. The presented findings demonstrate that thermal loads can support the generation of residual compressive stresses to a certain extent. If the thermal loads are increased further, this has a negative effect on the surface layer and the residual stresses are shifted in the direction of tension. The results show the optimum range of thermal loads to further increase the compressive residual stresses in the surface layer and allow to gain a better understanding of the interactions between thermal and mechanical loads. Full article
(This article belongs to the Special Issue Surface Integrity in Machining and Post-processing)
Show Figures

Figure 1

Communication
Pressing and Infiltration of Metal Matrix Nanocomposites
J. Manuf. Mater. Process. 2021, 5(2), 54; https://doi.org/10.3390/jmmp5020054 - 28 May 2021
Viewed by 436
Abstract
The ability to produce metal matrix nanocomposites via pressing and infiltration was validated. Al/TiC nanocomposite was used as the model material. Pressing the powder in a die yielded cylindrical specimens with a green density of 1.98 ± 0.05 g/cm3, which was [...] Read more.
The ability to produce metal matrix nanocomposites via pressing and infiltration was validated. Al/TiC nanocomposite was used as the model material. Pressing the powder in a die yielded cylindrical specimens with a green density of 1.98 ± 0.05 g/cm3, which was increased to only 2.11 ± 0.12 g/cm3 by sintering. Direct infiltration of the pressed specimens at 1050 °C for 3.5 h yielded specimens with a density of 3.07 ± 0.08 g/cm3, an open porosity of 3.06 ± 1.40%, and an areal void fraction of 8.09 ± 2.67%. The TiC nanoparticles were verified to be well dispersed using energy-dispersive X-ray spectroscopy. The measured hardness of 64 ± 3 HRA makes it a promising material for structural applications in industries such as aerospace and automotive. Full article
(This article belongs to the Special Issue Powder Metallurgy and Additive Manufacturing/3D Printing of Materials)
Show Figures

Figure 1

Article
Investigations on Roller-Based Filament Drives
J. Manuf. Mater. Process. 2021, 5(2), 53; https://doi.org/10.3390/jmmp5020053 - 21 May 2021
Viewed by 276
Abstract
The filament drive is a key part of the extrusion assembly of a Fused Filament Fabrication printer. This investigation examines the maximum feed force and the slip of different driving rollers using a filament made of polylactic-acid (PLA) on a test stand. The [...] Read more.
The filament drive is a key part of the extrusion assembly of a Fused Filament Fabrication printer. This investigation examines the maximum feed force and the slip of different driving rollers using a filament made of polylactic-acid (PLA) on a test stand. The test stand systematically varies the main feed process parameters: feed velocity, pinch force between the rollers, and feed force. The maximum feed force has a characteristic dependency on the pinch force combined with a feed-velocity-dependency, which is influenced by the outer diameter of the driving roller. The slip was found to increase linearly with the feed force. The slip decreases with increasing pinch force and is nearly constant for pinch forces above 77 N—172 N, depending on the driving roller tooth geometry and outer diameter. A model derived from contact mechanics was used for phenomenological modeling of the slip in relation to pinch force and feed velocity. An exponential ansatz provided good modeling of the slip at a constant pinch force. The model of the slip combined with the extrusion forces in the liquefier can be used to estimate the material flow in the future, thus leading to increased precision of the parts in a magnitude of systems. Full article
Show Figures

Figure 1

Article
Open Source Vacuum Oven Design for Low-Temperature Drying: Performance Evaluation for Recycled PET and Biomass
J. Manuf. Mater. Process. 2021, 5(2), 52; https://doi.org/10.3390/jmmp5020052 - 20 May 2021
Viewed by 353
Abstract
Vacuum drying can dehydrate materials further than dry heat methods, while protecting sensitive materials from thermal degradation. Many industries have shifted to vacuum drying as cost- or time-saving measures. Small-scale vacuum drying, however, has been limited by the high costs of specialty scientific [...] Read more.
Vacuum drying can dehydrate materials further than dry heat methods, while protecting sensitive materials from thermal degradation. Many industries have shifted to vacuum drying as cost- or time-saving measures. Small-scale vacuum drying, however, has been limited by the high costs of specialty scientific tools. To make vacuum drying more accessible, this study provides design and performance information for a small-scale open source vacuum oven, which can be fabricated from off-the-shelf and 3-D printed components. The oven is tested for drying speed and effectiveness on both waste plastic polyethylene terephthalate (PET) and a consortium of bacteria developed for bioprocessing of terephthalate wastes to assist in distributed recycling of PET for both additive manufacturing as well as potential food. Both materials can be damaged when exposed to high temperatures, making vacuum drying a desirable solution. The results showed that the open source vacuum oven was effective at drying both plastic and biomaterials, drying at a higher rate than a hot-air dryer for small samples or for low volumes of water. The system can be constructed for less than 20% of commercial vacuum dryer costs for several laboratory-scale applications, including dehydration of bio-organisms, drying plastic for distributed recycling and additive manufacturing, and chemical processing. Full article
Show Figures

Figure 1

Article
Influence of Tool Length and Profile Errors on the Inaccuracy of Cubic-Machining Test Results
J. Manuf. Mater. Process. 2021, 5(2), 51; https://doi.org/10.3390/jmmp5020051 - 19 May 2021
Viewed by 306
Abstract
A cubic-machining test has been proposed to evaluate the geometric errors of rotary axes in five-axis machine tools using a 3 × 3 zone area in the same plane with different tool postures. However, as only the height deviation among the machining zones [...] Read more.
A cubic-machining test has been proposed to evaluate the geometric errors of rotary axes in five-axis machine tools using a 3 × 3 zone area in the same plane with different tool postures. However, as only the height deviation among the machining zones is detected by evaluating the test results, the machining test results are expected to be affected by some error parameters of tool sides, such as tool length and profile errors, and there is no research investigation on how the tool side error influences the cubic-machining test accuracy. In this study, machining inaccuracies caused by tool length and tool profile errors were investigated. The machining error caused by tool length error was formulated, and an intentional tool length error was introduced in the simulations and actual machining tests. As a result, the formulated and simulated influence of tool length error agreed with the actual machining results. Moreover, it was confirmed that the difference between the simulation result and the actual machining result can be explained by the influence of the tool profile error. This indicates that the accuracy of the cubic-machining test is directly affected by tool side errors. Full article
(This article belongs to the Special Issue Advances in Multi-Axis Machining)
Show Figures

Figure 1

Article
The Effect of MQL on Tool Wear Progression in Low-Frequency Vibration-Assisted Drilling of CFRP/Ti6Al4V Stack Material
J. Manuf. Mater. Process. 2021, 5(2), 50; https://doi.org/10.3390/jmmp5020050 - 17 May 2021
Viewed by 422
Abstract
In this paper, the tool wear mechanisms for low-frequency vibration-assisted drilling (LF-VAD) of carbon fiber-reinforced polymer (CFRP)/Ti6Al4V stacks are investigated at various machining parameters. Based on the kinematics analysis, the effect of vibration amplitude on the chip formation, uncut chip thickness, chip radian, [...] Read more.
In this paper, the tool wear mechanisms for low-frequency vibration-assisted drilling (LF-VAD) of carbon fiber-reinforced polymer (CFRP)/Ti6Al4V stacks are investigated at various machining parameters. Based on the kinematics analysis, the effect of vibration amplitude on the chip formation, uncut chip thickness, chip radian, and axial velocity are examined. Subsequently, the effect of LF-VAD on the cutting temperature, tool wear, delamination, and geometrical accuracy was evaluated for different vibration amplitudes. The LF-VAD with the utilization of minimum quantity lubricant (MQL) resulted in a successful drilling process of 50 holes, with a 63% reduction in the cutting temperature. For the rake face, LF-VAD reduced the adhered height of Ti6Al4V by 80% at the low cutting speed and reduced the crater depth by 33% at the high cutting speed. On the other hand, LF-VAD reduced the flank wear land by 53%. Furthermore, LF-VAD showed a significant enhancement on the CFRP delamination, geometrical accuracy, and burr formation. Full article
Show Figures

Figure 1

Article
Functional Analysis of Components Manufactured by a Sheet-Bulk Metal Forming Process
J. Manuf. Mater. Process. 2021, 5(2), 49; https://doi.org/10.3390/jmmp5020049 - 17 May 2021
Viewed by 342
Abstract
Due to rising demands regarding the functionality and load-bearing capacity of functional components such as synchronizer rings in gear systems, conventional forming operations are reaching their limits with respect to formability and efficiency. One way to meet these challenges is the application of [...] Read more.
Due to rising demands regarding the functionality and load-bearing capacity of functional components such as synchronizer rings in gear systems, conventional forming operations are reaching their limits with respect to formability and efficiency. One way to meet these challenges is the application of the innovative process class of sheet-bulk metal forming (SBMF). By applying bulk forming operations to sheet metal, the advantages of both process classes can be combined, thus realizing an optimized part weight and an adapted load-bearing capacity. Different approaches to manufacturing relevant part geometries were presented and evaluated regarding the process properties and applicability. In this contribution, a self-learning engineering workbench was used to provide geometry-based data regarding a novel component geometry with circumferential involute gearing manufactured in an SBMF process combination of deep drawing and upsetting. Within the comprehensive investigations, the mechanical and geometrical properties of the part were analyzed. Moreover, the manufactured components were compared regarding the increased fatigue strength in cyclic load tests. With the gained experimental and numerical data, the workbench was used for the first time to generate the desired component as a CAD model, as well as to derive design guidelines referring to the investigated properties and fatigue behavior. Full article
Show Figures

Figure 1

Article
Surface Integrity Investigation to Determine Rough Milling Effects for Assessment of Machining Allowance for Subsequent Finish Milling of Alloy 718
J. Manuf. Mater. Process. 2021, 5(2), 48; https://doi.org/10.3390/jmmp5020048 - 13 May 2021
Viewed by 555
Abstract
The planned material volume to be removed from a blank to create the final shape of a part is commonly referred to as allowance. Determination of machining allowance is essential and has a great impact on productivity. The objective of the present work [...] Read more.
The planned material volume to be removed from a blank to create the final shape of a part is commonly referred to as allowance. Determination of machining allowance is essential and has a great impact on productivity. The objective of the present work is to use a case study to investigate how a prior rough milling operation affects the finish machined surface and, after that, to use this knowledge to design a methodology for how to assess the machining allowance for subsequent milling operations based on residual stresses. Subsequent milling operations were performed to study the final surface integrity across a milled slot. This was done by rough ceramic milling followed by finish milling in seven subsequent steps. The results show that the up-, centre and down-milling induce different stresses and impact depths. Employing the developed methodology, the depth where the directional influence of the milling process diminishes has been shown to be a suitable minimum limit for the allowance. At this depth, the plastic flow causing severe deformation is not present anymore. It was shown that the centre of the milled slot has the deepest impact depth of 500 µm, up-milling caused an intermediate impact depth of 400 µm followed by down milling with an impact depth of 300 µm. With merged envelope profiles, it was shown that the effects from rough ceramic milling are gone after 3 finish milling passes, with a total depth of cut of 150 µm. Full article
(This article belongs to the Special Issue Surface Integrity in Machining and Post-processing)
Show Figures

Graphical abstract

Article
Electrohydraulic Forming of Low Volume and Prototype Parts: Process Design and Practical Examples
J. Manuf. Mater. Process. 2021, 5(2), 47; https://doi.org/10.3390/jmmp5020047 - 13 May 2021
Viewed by 317
Abstract
Electro-Hydraulic Forming (EHF) is a high rate sheet metal forming process based on the electrical discharge of high voltage capacitors in a water-filled chamber. During the discharge, the pulsed pressure wave propagates from the electrodes and forms a sheet metal blank into a [...] Read more.
Electro-Hydraulic Forming (EHF) is a high rate sheet metal forming process based on the electrical discharge of high voltage capacitors in a water-filled chamber. During the discharge, the pulsed pressure wave propagates from the electrodes and forms a sheet metal blank into a die. The performed literature review shows that this technology is suitable for forming parts of a broad range of dimensions and complex shapes. One of the barriers for broader implementation of this technology is the complexity of a full-scale simulation of EHF which includes the simulation of an expanding plasma channel, the propagation of waves in a fluid filled chamber, and the high-rate forming of a blank in contact with a rigid die. The objective of the presented paper is to establish methods of designing the EHF processes using simplified methods. The paper describes a numerical approach on how to define the shape of preforming pockets. The concept includes imposing principal strains from the formed blank into the initial mesh of the flat blank. The principal strains are applied with the opposite sign creating compression in the flat blank. The corresponding principal stresses in the blank are calculated based upon Hooke’s law. The blank is then virtually placed between two rigid plates. One of the plates has windows into which the material is getting bulged driven by the in-plane compressive stresses. The prediction of the shape of the bulged sheet provides the information on the shape of the preforming pockets. It is experimentally demonstrated that using these approaches, EHF forming is feasible for forming of a fragment of a decklid panel and a deep panel with complex curvature. Full article
(This article belongs to the Special Issue Impulse-Based Manufacturing Technologies)
Show Figures

Figure 1

Article
Mechanics Modeling of Residual Stress Considering Effect of Preheating in Laser Powder Bed Fusion
J. Manuf. Mater. Process. 2021, 5(2), 46; https://doi.org/10.3390/jmmp5020046 - 12 May 2021
Viewed by 335
Abstract
This study aimed at the investigation of the effect of substrate temperature on residual stress in laser powder bed fusion using a physics-based analytical model. In this study, an analytical model is proposed to predict the residual stress through the calculation of preheating [...] Read more.
This study aimed at the investigation of the effect of substrate temperature on residual stress in laser powder bed fusion using a physics-based analytical model. In this study, an analytical model is proposed to predict the residual stress through the calculation of preheating affected temperature profile and thermal stress. The effect of preheating is super-positioned with initial temperature in the modeling of temperature profile using a moving heat source approach; the resultant temperature gradient is then employed to predict the thermal stress from a point body load approach. If the thermal stress exceeds the yield strength of the material, then the residual stress under cyclic heating and cooling will be calculated based on the incremental plasticity and kinematic hardening behavior of metal. IN718 is used as a material example to pursue this investigation. To validate the predicted residual stress, experimental measurements are conducted using X-ray diffraction on IN718 samples manufactured via laser powder bed fusion under different process conditions. Results showed that preheating of the substrate could reduce the residual stress in an additively manufactured part due to the reduction in temperature gradient and resultant shrinkage stresses. However, the excessive preheating could have an opposite impact on residual stress accumulation. Moreover, the results confirm that the proposed model is a valuable tool for the prediction of residual stress, eliminating the costly experiments and time-consuming finite element simulations. Full article
Show Figures

Figure 1

Article
Analysis of Proximity Consequences of Coil Windings in Electromagnetic Forming
J. Manuf. Mater. Process. 2021, 5(2), 45; https://doi.org/10.3390/jmmp5020045 - 08 May 2021
Viewed by 356
Abstract
Multiturn coils are required for manufacturing sheet metal parts with varying depths and special geometrical features using electromagnetic forming (EMF). Due to close coil turns, the physical phenomena of the proximity effect and Lorentz forces between the parallel coil windings are observed. This [...] Read more.
Multiturn coils are required for manufacturing sheet metal parts with varying depths and special geometrical features using electromagnetic forming (EMF). Due to close coil turns, the physical phenomena of the proximity effect and Lorentz forces between the parallel coil windings are observed. This work attempts to investigate the mechanical consequences of these phenomena using numerical and experimental methods. A numerical model was developed in LS-DYNA. It was validated using experimental post-mortem strain and laser-based velocity measurements after and during the experiments, respectively. It was observed that the proximity effect in the parallel conductors led to current density localization at the closest or furthest ends of the conductor cross-section and high local curvature of the formed sheet. Further analysis of the forces between two coil windings explained the departure from the “inverse-distance” rule observed in the literature. Finally, some measures to prevent or reduce undesired coil deformation are provided. Full article
(This article belongs to the Special Issue Impulse-Based Manufacturing Technologies)
Show Figures

Figure 1

Article
Simulation Study on Single-Lip Deep Hole Drilling Using Design of Experiments
J. Manuf. Mater. Process. 2021, 5(2), 44; https://doi.org/10.3390/jmmp5020044 - 04 May 2021
Viewed by 419
Abstract
Single-lip deep hole drilling (SLD) is characterized by a high surface quality and compressive residual stress in the subsurface of the drill hole. These properties are strongly dependent on the cutting parameters of the SLD process and the actual geometry of the insert [...] Read more.
Single-lip deep hole drilling (SLD) is characterized by a high surface quality and compressive residual stress in the subsurface of the drill hole. These properties are strongly dependent on the cutting parameters of the SLD process and the actual geometry of the insert and the guide pads. In the present work, full 3D FE simulations of the SLD process were carried out to analyze the thermo-mechanical as-is state in the drilling contact zone by evaluating the feed force, the temperature, as well as the residual stress in the drill hole subsurface. An extensive simulation study was conducted on the effect of the process parameters on the properties using design of experiments (DoE). For the simulations, the Johnson–Cook (JC) constitutive law and the element elimination technique (EET) were applied to represent the material behavior of the workpiece, including chip formation. In-process measurements as well as results from the hole-drilling method to determine residual stresses were conducted to verify the numerical results. By means of DoE and analysis of variance (ANOVA), regression models were developed to describe the effect of the feed rate, cutting speed, and guide pad height on the temperature, feed force, and residual stress in the subsurface. Full article
(This article belongs to the Special Issue Surface Integrity in Machining and Post-processing)
Show Figures

Figure 1

Article
Influence of a Discontinuous Process Strategy on Microstructure and Microhardness in Drilling Inconel 718
J. Manuf. Mater. Process. 2021, 5(2), 43; https://doi.org/10.3390/jmmp5020043 - 02 May 2021
Viewed by 427
Abstract
Nickel-base alloys are proven materials in the fields of the aerospace and oil industry, which is due to their characteristic material properties of high temperature strength, high toughness and good oxidation resistance. These properties are beneficial to applications in technical components in general. [...] Read more.
Nickel-base alloys are proven materials in the fields of the aerospace and oil industry, which is due to their characteristic material properties of high temperature strength, high toughness and good oxidation resistance. These properties are beneficial to applications in technical components in general. However, they also represent challenges for machining. Especially while drilling Inconel 718, high temperatures occur in the chip-formation zone that implicate high thermal load in the material and thus, influence the surface integrity, for example, by causing white layers. Hence, the development of strategies to improve the ability to supply cutting edges with cooling lubricant is becoming increasingly important. In this context, an alternative process design, the discontinuous drilling, takes place, characterized by a periodic interruption of feed motion and thus, chip formation. A minor retraction movement from the contact zone enables the cooling lubricant to reach the cutting edges and to reduce their thermal load. In comparison to the conventional process of drilling Inconel 718, the effects of discontinuous drilling with varying numbers of interruptions on the resulting surface integrity and further parameters of drilling qualities are analyzed. Thereby, the prevention of process-related phase transformations due to thermal impact was discovered when a discontinuous drilling strategy was implemented. Full article
(This article belongs to the Special Issue Surface Integrity in Machining and Post-processing)
Show Figures

Figure 1

Article
Machining Ti-6Al-4V Alloy Using Nano-Cutting Fluids: Investigation and Analysis
J. Manuf. Mater. Process. 2021, 5(2), 42; https://doi.org/10.3390/jmmp5020042 - 27 Apr 2021
Viewed by 373
Abstract
Minimum Quantity Lubrication nanofluid (MQL-nanofluid) is a viable sustainable alternative to conventional flood cooling and provides very good cooling and lubrication in the machining of difficult to cut materials such as titanium and Inconel. The cutting action provides very difficult conditions for the [...] Read more.
Minimum Quantity Lubrication nanofluid (MQL-nanofluid) is a viable sustainable alternative to conventional flood cooling and provides very good cooling and lubrication in the machining of difficult to cut materials such as titanium and Inconel. The cutting action provides very difficult conditions for the coolant to access the cutting zone and the level of difficulty increases with higher cutting speeds. Furthermore, high compressive stresses, strain hardening and high chemical activity results in the formation of a ‘seizure zone’ at the tool-chip interface. In this work, the impact of MQL-nanofluid at the seizure zone and the corresponding effects on tool wear, surface finish, and power consumption during machining of Ti-6Al-4V was investigated. Aluminum Oxide (Al2O3) nanoparticles were selected to use as nano-additives at different weight fraction concentrations (0, 2, and 4 wt.%). It was observed that under pure MQL strategy there was significant material adhesion on the rake face of the tool while the adhesion was reduced in the presence of MQL-nanofluid at the tool-chip interface, thus indicating a reduction in the tool chip contact length (TCCL) and reduced seizure effect. Furthermore, the flank wear varied from 0.162 to 0.561 mm and the average surface roughness (Ra) varied from 0.512 to 2.81 µm. The results indicate that the nanoparticle concentration and the reduction in the seizure zone positively influence the tool life and quality of surface finish. Full article
Show Figures

Figure 1

Article
Modeling of Drag Finishing—Influence of Abrasive Media Shape
J. Manuf. Mater. Process. 2021, 5(2), 41; https://doi.org/10.3390/jmmp5020041 - 26 Apr 2021
Viewed by 373
Abstract
Drag finishing is a widely used superfinishing technique in the industry to polish parts under the action of abrasive media combined with an active surrounding liquid. However, the understanding of this process is not complete. It is known that pyramidal abrasive media are [...] Read more.
Drag finishing is a widely used superfinishing technique in the industry to polish parts under the action of abrasive media combined with an active surrounding liquid. However, the understanding of this process is not complete. It is known that pyramidal abrasive media are more prone to rapidly improving the surface roughness compared to spherical ones. Thus, this paper aims to model how the shape of abrasive media (spherical vs. pyramidal) influences the material removal mechanisms at the interface. An Arbitrary Lagrangian–Eulerian model of drag finishing is proposed with the purpose of estimating the mechanical loadings (normal stress, shear stress) induced by both abrasive media at the interface. The rheological behavior of both abrasive slurries (media and liquid) has been characterized by means of a Casagrande direct shear test. In parallel, experimental drag finishing tests were carried out with both media to quantify the drag forces. The correlation between the numerical and experimental drag forces highlights that the abrasive media with a pyramidal shape exhibits a higher shear resistance, and this is responsible for inducing higher mechanical loadings on the surfaces and, through this, for a faster decrease of the surface roughness. Full article
(This article belongs to the Special Issue Surface Integrity in Machining and Post-processing)
Show Figures

Figure 1

Article
Work Envelope Expansion and Parametric Optimization in WAAM with Relative Density and Surface Aspect as Quality Constraints: The Case of Al5Mg Thin Walls with Active Cooling
J. Manuf. Mater. Process. 2021, 5(2), 40; https://doi.org/10.3390/jmmp5020040 - 23 Apr 2021
Viewed by 393
Abstract
The successful and efficient production of parts with specific features by Wire + Arc Additive Manufacturing (WAAM) strongly depends on the selection of proper and typically interrelated deposition parameters. This task might be particularly challenging in the making of thin walls, which might [...] Read more.
The successful and efficient production of parts with specific features by Wire + Arc Additive Manufacturing (WAAM) strongly depends on the selection of proper and typically interrelated deposition parameters. This task might be particularly challenging in the making of thin walls, which might be highly impacted by processing conditions and heat accumulation. In this context, this study aims at expanding the work envelope and optimizing the parametric conditions in WAAM with relative density and surface aspects of the preforms as quality constraints. The experimental approach was based on the deposition of thin Al5Mg walls by the CMT process on its standard welding setup and with an active cooling technique to enhance the deposition robustness. Internal voids were estimated by Archimedes’ method. The surface quality of the walls was assessed through the visual aspect and the surface waviness by cross-section analysis. All the conditions presented relative density higher than 98%. The upgrade of the standard welding hardware to WAAM purposes through the addition of a supplementary shielding gas nozzle to the torch and the intensity of the heat sinking from the part significantly expanded the process work envelope, with its applicability being successfully demonstrated with multi-objective optimization. To sum up, a decision-making procedure is presented towards achieving intended preform quality. Full article
Show Figures

Figure 1

Article
Machine Learning Driven Prediction of Residual Stresses for the Shot Peening Process Using a Finite Element Based Grey-Box Model Approach
J. Manuf. Mater. Process. 2021, 5(2), 39; https://doi.org/10.3390/jmmp5020039 - 21 Apr 2021
Viewed by 432
Abstract
The shot peening process is a common procedure to enhance fatigue strength on load-bearing components in the metal processing environment. The determination of optimal process parameters is often carried out by costly practical experiments. An efficient method to predict the resulting residual stress [...] Read more.
The shot peening process is a common procedure to enhance fatigue strength on load-bearing components in the metal processing environment. The determination of optimal process parameters is often carried out by costly practical experiments. An efficient method to predict the resulting residual stress profile using different parameters is finite element analysis. However, it is not possible to include all influencing factors of the materials’ physical behavior and the process conditions in a reasonable simulation. Therefore, data-driven models in combination with experimental data tend to generate a significant advantage for the accuracy of the resulting process model. For this reason, this paper describes the development of a grey-box model, using a two-dimensional geometry finite element modeling approach. Based on this model, a Python framework was developed, which is capable of predicting residual stresses for common shot peening scenarios. This white-box-based model serves as an initial state for the machine learning technique introduced in this work. The resulting algorithm is able to add input data from practical residual stress experiments by adapting the initial model, resulting in a steady increase of accuracy. To demonstrate the practical usage, a corresponding Graphical User Interface capable of recommending shot peening parameters based on user-required residual stresses was developed. Full article
(This article belongs to the Special Issue Advances in Micro and Nanomanufacturing)
Show Figures

Figure 1

Review
A Review of Post-Processing Technologies in Additive Manufacturing
J. Manuf. Mater. Process. 2021, 5(2), 38; https://doi.org/10.3390/jmmp5020038 - 18 Apr 2021
Viewed by 711
Abstract
Additive manufacturing (AM) technology has rapidly evolved with research advances related to AM processes, materials, and designs. The advantages of AM over conventional techniques include an augmented capability to produce parts with complex geometries, operational flexibility, and reduced production time. However, AM processes [...] Read more.
Additive manufacturing (AM) technology has rapidly evolved with research advances related to AM processes, materials, and designs. The advantages of AM over conventional techniques include an augmented capability to produce parts with complex geometries, operational flexibility, and reduced production time. However, AM processes also face critical issues, such as poor surface quality and inadequate mechanical properties. Therefore, several post-processing technologies are applied to improve the surface quality of the additively manufactured parts. This work aims to document post-processing technologies and their applications concerning different AM processes. Various types of post-process treatments are reviewed and their integrations with AM process are discussed. Full article
(This article belongs to the Special Issue Metal Additive Manufacturing and Its Post Processing Techniques)
Show Figures

Figure 1

Article
Influence of Heat Treatments, Parameters and Machining Conditions on Machinability in the Turning of Recycled 6061 Aluminum Alloy
J. Manuf. Mater. Process. 2021, 5(2), 37; https://doi.org/10.3390/jmmp5020037 - 14 Apr 2021
Viewed by 503
Abstract
Some manufacturing companies now use recycled aluminum alloys. It is important that they have the necessary data relating to the control of the machinability of these alloys. Thus, this study on the machinability in the turning of two recycled aluminum alloys by a [...] Read more.
Some manufacturing companies now use recycled aluminum alloys. It is important that they have the necessary data relating to the control of the machinability of these alloys. Thus, this study on the machinability in the turning of two recycled aluminum alloys by a 6061 R and 6061 R-T6 smelter was conducted. The aim of this study is to provide solutions to the problem posed, which is whether recycled aluminum alloys have good machinability skills, such as virgin aluminum alloys. To provide these solutions, the experimental designs were used to study the influence of cutting parameters and conditions (feed, cutting speed, lubrication) and material hardness on machinability characteristics (surface roughness, mass concentration of metal particles, and chip morphology). The results of this study show that the two alloys studied have good machinability. The feed, hardness and lubrication significantly influence the machinability of these two alloys. Predictive models to assess the machinability of these recycled alloys have been established. Full article
(This article belongs to the Special Issue Accuracy Improvements in Machine Tools and Machining)
Show Figures

Figure 1

Article
Further Development of Wear Calculation and Wear Reduction in Cold Forging Processes
J. Manuf. Mater. Process. 2021, 5(2), 36; https://doi.org/10.3390/jmmp5020036 - 13 Apr 2021
Viewed by 380
Abstract
Tools are of strategic importance for industrial manufacturing processes. Their behaviour has a great influence on the productivity of the process and the quality of the product. A material saving and efficient technique for processing metallic workpieces is cold forging. One major challenge [...] Read more.
Tools are of strategic importance for industrial manufacturing processes. Their behaviour has a great influence on the productivity of the process and the quality of the product. A material saving and efficient technique for processing metallic workpieces is cold forging. One major challenge of this production method is the handling of high contact normal stresses in the tool contact, which can lead to severe tool wear. To investigate promising approaches for understanding wear modelling and wear reduction a demonstrator process based on the first stage of a total five-staged cold forging process for the manufacturing of a bolt anchor is considered in the scope of this research. This work aims at the further development of a numerical wear calculation based on an adapted Archard model in order to be able to realistically predict the tool wear in cold forging processes. Therefore, the material characterization of the used workpiece material as well as an investigation of the worn tool dies takes place to validate a numerical wear calculation model. Furthermore, this research addresses a reduction in wear by identifying critical areas and changing the inlet geometry of the investigated demonstrator tool die. This way, conclusions can be drawn about the wear sensitivity during numerical process design, and particularly critical areas can be geometrically modified in terms of the design. Full article
Show Figures

Figure 1

Article
Adiabatic Blanking: Influence of Clearance, Impact Energy, and Velocity on the Blanked Surface
J. Manuf. Mater. Process. 2021, 5(2), 35; https://doi.org/10.3390/jmmp5020035 - 13 Apr 2021
Viewed by 417
Abstract
In contrast to other cutting processes, adiabatic blanking typically features high blanking velocities (>3 m/s), which can lead to the formation of adiabatic shear bands in the blanking surface. The produced surfaces have excellent properties, such as high hardness, low roll-over, and low [...] Read more.
In contrast to other cutting processes, adiabatic blanking typically features high blanking velocities (>3 m/s), which can lead to the formation of adiabatic shear bands in the blanking surface. The produced surfaces have excellent properties, such as high hardness, low roll-over, and low roughness. However, details about the qualitative and quantitative influence of significant process parameters on the quality of the blanked surface are still lacking. In the presented study, a variable tool is used for a systematic investigation of different process parameters and their influences on the blanked surface of a hardened 22MnB5 steel. Different relative clearances (1.67% to 16.67%), velocities (7 to 12.5 m/s), and impact energies (250 J to 1000 J) were studied in detail. It is demonstrated that a relative clearance of ≤6.67% and an impact velocity of ≥7 m/s lead to adiabatic shear band formation, regardless of the impact energy. Further, an initiated shear band results in the formation of an S-shaped surface. Unexpectedly, a low impact energy results in the highest geometric accuracy. The influence of the clearance, the velocity, and the impact energy on the evolution of adiabatic shear band formation is shown for the first time. The gained knowledge can enable a functionalization of the blanked surfaces in the future. Full article
(This article belongs to the Special Issue Impulse-Based Manufacturing Technologies)
Show Figures

Figure 1

Article
The Performance of Polycrystalline Diamond (PCD) Tools Machined by Abrasive Grinding and Electrical Discharge Grinding (EDG) in High-Speed Turning
J. Manuf. Mater. Process. 2021, 5(2), 34; https://doi.org/10.3390/jmmp5020034 - 12 Apr 2021
Viewed by 463
Abstract
Polycrystalline diamond (PCD) tools are widely used in industry due to their outstanding physical properties. However, the ultra-high hardness of PCD significantly limits the machining efficiency of conventional abrasive grinding processes, which are utilized to manufacture PCD tools. In contrast, electrical discharge grinding [...] Read more.
Polycrystalline diamond (PCD) tools are widely used in industry due to their outstanding physical properties. However, the ultra-high hardness of PCD significantly limits the machining efficiency of conventional abrasive grinding processes, which are utilized to manufacture PCD tools. In contrast, electrical discharge grinding (EDG) has significantly higher machining efficiency because of its unique material removal mechanism. In this study, the quality and performance of PCD tools machined by abrasive grinding and EDG were investigated. The performance of cutting tools consisted of different PCD materials was tested by high-speed turning of titanium alloy Ti6Al4V. Flank wear and crater wear were investigated by analyzing the worn profile, micro morphology, chemical decomposition, and cutting forces. The results showed that an adhesive-abrasive process dominated the processes of flank wear and crater wear. Tool material loss in the wear process was caused by the development of thermal cracks. The development of PCD tools’ wear made of small-sized diamond grains was a steady adhesion-abrasion process without any catastrophic damage. In contrast, a large-scale fracture happened in the wear process of PCD tools made of large-sized diamond grains. Adhesive wear was more severe on the PCD tools machined by EDG. Full article
(This article belongs to the Special Issue Advances in Multi-Axis Machining)
Show Figures

Figure 1

Article
Identification and Mapping of Manufacturability Constraints for Extrusion-Based Additive Manufacturing
J. Manuf. Mater. Process. 2021, 5(2), 33; https://doi.org/10.3390/jmmp5020033 - 10 Apr 2021
Viewed by 450
Abstract
This article develops and demonstrates a set of design-focused manufacturability constraints for the fused deposition modeling/fused filament fabrication (FDM/FFF) process. These can be mapped from the basic behavior and process characteristics and formulated in terms of implicit or explicit design constraints. When the [...] Read more.
This article develops and demonstrates a set of design-focused manufacturability constraints for the fused deposition modeling/fused filament fabrication (FDM/FFF) process. These can be mapped from the basic behavior and process characteristics and formulated in terms of implicit or explicit design constraints. When the FDM/FFF process is explored and examined for its natural limitations and behavior, it can provide a set of manufacturing considerations (advantages, limitations, and best practices). These can be converted into manufacturing constraints, which are practical limits on the ability of the process. Finally, these can be formulated in terms of design–useful manufacturability constraints. Many of the constants and parameters must be determined experimentally for specific materials. The final list of 54 major manufacturability constraints presented in this work will better inform designers considering using FDM/FFF as a manufacturing process, and help guide design decisions. After derivation and presentation of the constraint set, extensive discussion about practical implementation is provided at the end of the paper, including advice about experimentally determining constants and appropriate printing parameters. Finally, three case studies are presented which implement the constraints for simple design problems. Full article
Show Figures

Figure 1

Previous Issue
Back to TopTop
