Batteries

14 pages, 6405 KiB

Open AccessArticle

Boosting the Capacitance of Aqueous Zinc-Ion Hybrid Capacitors by Engineering Hierarchical Porous Carbon Architecture

by Yanzhen Li, Xin Zhang, Tong Lu, Ying Zhang, Xue Li, Dengfeng Yu and Gongyuan Zhao

Batteries 2023, 9(8), 429; https://doi.org/10.3390/batteries9080429 - 17 Aug 2023

Cited by 6 | Viewed by 1802

With the merits of having excellent safety, being low cost and being environmentally friendly, zinc-ion hybrid supercapacitors (ZHSCs) are expected to be widely used in large-scale energy storage and flexible wearable devices. However, limited by their sluggish kinetic process, ZHSCs suffer from low-specific [...] Read more.

With the merits of having excellent safety, being low cost and being environmentally friendly, zinc-ion hybrid supercapacitors (ZHSCs) are expected to be widely used in large-scale energy storage and flexible wearable devices. However, limited by their sluggish kinetic process, ZHSCs suffer from low-specific capacity and poor cycling stability at high cathode mass loading. Herein, a novel designed oxygen-rich hierarchical porous carbon (HPOC) is obtained by a one-step strategy of synchronous activation and templated for high-performance ZHSCs. The fabricated ZHSCs with HPOCs show significant improvement in Zn-ion storage capability, with a capacity of 209.4 mAh g⁻¹ at 0.1 A g⁻¹ and 108.3 mAh g⁻¹ at 10 A g⁻¹. Additionally, the cycling stability is excellent, with 92.3% retention after 4000 cycles. Furthermore, an impressive areal capacity of 1.7 mAh cm⁻² is achieved, even with a high mass loading of 12.5 mg cm⁻². More importantly, the flexible quasi-solid state ZHSCs also show a considerable capability (183.5 mAh g⁻¹ at 0.1 A g⁻¹) and a high energy density of 178.0 Wh kg⁻¹. This promising result suggests a valuable route to produce functional nanocarbon materials for zinc storage applications. Full article

(This article belongs to the Special Issue Electrolytes for Solid State Batteries)

► Show Figures

Figure 1

16 pages, 8412 KiB

Open AccessArticle

Boosting the Power of Na_0.44MnO₂: Unlocking Its Potential for Aqueous Sodium-Ion Storage through Nanostructuring and Hybridization

by Mehdi Soleimanzade, Mariano Radaelli, Jacopo Manidi, Maksim Bahdanchyk and Antonello Vicenzo

Batteries 2023, 9(8), 428; https://doi.org/10.3390/batteries9080428 - 17 Aug 2023

Cited by 2 | Viewed by 1726

Abstract

We report an effective processing route, combining nanostructure formation and hybridization, to improve the rate performance of the tunnel-structure sodium manganese oxide Na_0.44MnO₂ (NMO) as a cathode material for aqueous sodium ion storage. We use hydrothermal synthesis to prepare an [...] Read more.

We report an effective processing route, combining nanostructure formation and hybridization, to improve the rate performance of the tunnel-structure sodium manganese oxide Na_0.44MnO₂ (NMO) as a cathode material for aqueous sodium ion storage. We use hydrothermal synthesis to prepare an NMO/CNF (Carbon NanoFiber) hybrid, consisting of uniform oxide nanowires with an average width of 70 nm and length in the range of several tenths of µm. The highly dispersed CNFs impart high conductivity to the NMO/CNF electrode, allowing high-rate performance at a C-rate of up to 20 C, with a delivered capacity of more than half the theoretical value in a 1 M Na₂SO₄ electrolyte. Moreover, the NMO/CNF hybrid shows good electrochemical stability under several hundred cycles at a high C-rate. However, the NMO nanowire electrodes reveal a lower-than-expected capacity, probably as a result of the tendency of nanowires to form bundles, which prevents direct contact with conductive fibers and induce the under-utilization of active material. With this study, we demonstrate a strong improvement of the otherwise inherently low-rate performance of NMO through oxide nanostructuring and hybridization with carbon fibers, paving the way for further research on NMO-based materials for aqueous sodium ion storage. Full article

(This article belongs to the Special Issue Research on Aqueous Rechargeable Batteries)

► Show Figures

Figure 1

15 pages, 2415 KiB

Open AccessEditor’s ChoiceArticle

Evolution of Safety Behavior of High-Power and High-Energy Commercial Li-Ion Cells after Electric Vehicle Aging

by Pierre Kuntz, Loïc Lonardoni, Sylvie Genies, Olivier Raccurt and Philippe Azaïs

Batteries 2023, 9(8), 427; https://doi.org/10.3390/batteries9080427 - 16 Aug 2023

Cited by 4 | Viewed by 1560

Abstract

The Li-ion battery is one of the key components in electric car development due to its performance in terms of energy density, power density and cyclability. However, this technology is likely to present safety problems with the appearance of cell thermal runaway, which [...] Read more.

The Li-ion battery is one of the key components in electric car development due to its performance in terms of energy density, power density and cyclability. However, this technology is likely to present safety problems with the appearance of cell thermal runaway, which can cause a car fire in the case of propagation in the battery pack. Today, standards describing safety compliance tests, which are a prerequisite for marketing Li-ion cells, are carried out on fresh cells only. It is therefore important to carry out research into the impact of cell aging on battery safety behavior in order to ensure security throughout the life of the battery, from manufacturing to recycling. In this article, the impact of Li-ion cell aging on safety is studied. Three commercial 18,650 cells with high-power and high-energy designs were aged using a Battery Electric Vehicle (BEV) aging profile in accordance with the International Electrotechnical Commission standard IEC 62-660. Several thermal (Accelerating Rate Calorimetry—ARC) and standardized safety (short-circuit, overcharge) tests were performed on fresh and aged cells. This study highlights the impact of aging on safety by comparing the safety behavior of fresh and aged cells with their aging conditions and the degradation mechanisms involved. Full article

(This article belongs to the Special Issue Thermal Safety of Lithium Ion Batteries)

► Show Figures

Graphical abstract

11 pages, 3211 KiB

Open AccessArticle

Flexible and Stable N-Isopropylacrylamide/Sodium Alginate Gel Electrolytes for Aqueous Zn-MNO₂ Batteries

by Kehuang Wang, Mingliang Shangguan, Yibo Zhao, Haoran Tian, Fu Wang, Jinliang Yuan and Lan Xia

Batteries 2023, 9(8), 426; https://doi.org/10.3390/batteries9080426 - 15 Aug 2023

Cited by 1 | Viewed by 1584

Abstract

Rechargeable aqueous Zn-ion batteries (ZIBs) have attracted considerable attention owing to their high theoretical capacity of 820 mA h g⁻¹, low cost and intrinsic safety. However, the electrolyte leakage and the instability issues of Zn negative electrodes originating from side reactions [...] Read more.

Rechargeable aqueous Zn-ion batteries (ZIBs) have attracted considerable attention owing to their high theoretical capacity of 820 mA h g⁻¹, low cost and intrinsic safety. However, the electrolyte leakage and the instability issues of Zn negative electrodes originating from side reactions between the aqueous electrolyte and Zn negative electrode not only restrict the battery stability, but also result in the short circuit of aqueous ZIBs. Herein, we report a flexible and stable N-isopropylacrylamide/sodium alginate (N-SA) gel electrolyte, which possesses high mechanical strength and high ionic conductivity of 2.96 × 10⁻² S cm⁻¹, and enables the Zn metal negative electrode and MnO₂ positive electrode to reversibly and stably cycle. Compared to the liquid electrolyte, the N-SA hydrogel electrolyte can effectively form a uniform Zn deposition and suppress the generation of irreversible by-products. The assembled symmetric Zn/Zn cells at a current density of 1 mA cm⁻² (capacity: 1 mAh cm⁻²) show a stable voltage profile, which maintains a low level of about 100 mV over 2600 h without an obvious short circuit or any overpotential increasing. Specially, the assembled Zn/N-SA/MnO₂ batteries can deliver a high specific capacity of 182 mAh g⁻¹ and maintain 98% capacity retention after 650 cycles at 0.5 A g⁻¹. This work provides a simple method to fabricate high-performance SA-based hydrogel electrolytes, which illustrates their potential for flexible batteries for wearable electronics. Full article

(This article belongs to the Special Issue Rechargeable Multivalent Metal-Ion Batteries)

► Show Figures

Figure 1

16 pages, 8164 KiB

Open AccessArticle

AdaBoost.Rt-LSTM Based Joint SOC and SOH Estimation Method for Retired Batteries

by Ran Li, Pengdong Liu, Kexin Li and Xiaoyu Zhang

Batteries 2023, 9(8), 425; https://doi.org/10.3390/batteries9080425 - 15 Aug 2023

Cited by 2 | Viewed by 1660

Abstract

Achieving accurate retired battery state of health (SOH) and state of charge (SOC) estimation is a safe prerequisite for securing the battery secondary utilization and thus effectively improving the energy utilization efficiency. The data-driven approach is efficient and accurate, and does not rely [...] Read more.

Achieving accurate retired battery state of health (SOH) and state of charge (SOC) estimation is a safe prerequisite for securing the battery secondary utilization and thus effectively improving the energy utilization efficiency. The data-driven approach is efficient and accurate, and does not rely on accurate battery models, which is a hot direction in battery state estimation research. However, the huge number of retired batteries and obvious consistency differences bring bottleneck problems such as long learning time and low model updating efficiency to the traditional data-driven algorithm. In view of this, this paper proposes an integrated learning algorithm based on AdaBoost. Rt-LSTM to realize the joint estimation of SOC and SOH of retired lithium batteries, which relies on the LSTM neural network model and completes the correlation adaption in the spatio-temporal dimension of the whole life cycle sample data. The LSTM model is used as the base learner to construct the AdaBoost. Rt-LSTM strong learning model. The LSTM weak predictor is combined with weights to form a strong predictor, which greatly solves the problem of low accuracy of state estimation due to the large number and variability of retired batteries. Simulation and experimental comparison show that the integrated algorithm proposed in this paper is suitable for improving the SOC and SOH prediction accuracy and the generalization performance of the model. Full article

(This article belongs to the Special Issue Battery Energy Storage in Advanced Power Systems)

► Show Figures

Figure 1

13 pages, 4561 KiB

Open AccessArticle

Rapid Estimation of Battery Storage Capacity through Multiple Linear Regression

by Chulwon Jung and Woongchul Choi

Batteries 2023, 9(8), 424; https://doi.org/10.3390/batteries9080424 - 12 Aug 2023

Cited by 1 | Viewed by 1596

Abstract

Due to global warming issues, the rapid growth of electric vehicle sales is fully expected to result in a dramatic increase in returned batteries after the first use. Naturally, industries have shown great interest in establishing business models for retired battery reuse and [...] Read more.

Due to global warming issues, the rapid growth of electric vehicle sales is fully expected to result in a dramatic increase in returned batteries after the first use. Naturally, industries have shown great interest in establishing business models for retired battery reuse and recycling. However, they still have many challenges, such as high costs from the logistics of returned batteries and evaluating returned battery quality. One of the most important characteristics of a returned battery is the battery storage capacity. Conventionally, the battery’s energy capacity is measured through the low current full charging and discharging process. While this traditional measurement procedure gives a reliable estimate of battery storage capacity, the time required for a reliable estimate is unacceptably long to support profitable business models. In this paper, we propose a new algorithm to estimate battery storage capacity that can dramatically reduce the time for estimation through the partial discharging process. To demonstrate the applicability of the proposed algorithm, cylindrical and prismatic cells were used in the experiments. Initially, five indicators were selected from the voltage response curves that can identify battery storage capacity. Then, the five indicators were applied to principal component analysis (PCA) to extract dominant factors. The extracted factors were applied to a multiple linear regression model to produce a reliable estimation of battery storage capacity. Full article

(This article belongs to the Section Battery Modelling, Simulation, Management and Application)

► Show Figures

Graphical abstract

16 pages, 7195 KiB

Open AccessArticle

The Investigation of Triple-Lithiated Transition Metal Oxides Synthesized from the Spent LiCoO₂

by Alexandra Kosenko, Konstantin Pushnitsa, Vladislav Chernyavsky, Pavel Novikov and Anatoliy A. Popovich

Batteries 2023, 9(8), 423; https://doi.org/10.3390/batteries9080423 - 12 Aug 2023

Viewed by 1274

Abstract

The environmentally friendly closed cycle of the regeneration process of spent LiCoO₂ was successfully developed and the following synthesis of triple-lithiated transition metal oxides was carried out. A hydrometallurgy recycling route with the usage of 1.5 mol/L of malic acid and 3 [...] Read more.

The environmentally friendly closed cycle of the regeneration process of spent LiCoO₂ was successfully developed and the following synthesis of triple-lithiated transition metal oxides was carried out. A hydrometallurgy recycling route with the usage of 1.5 mol/L of malic acid and 3 vol.% of H₂O₂ as a leaching solution for cobalt extraction was chosen. The efficiency of the cobalt extraction reached 95%. The obtained material was investigated using an X-ray diffraction analysis and the EDX and SEM methods. The electrochemical behavior of the synthesized NCM111 was analyzed and compared to the commercially available material of the same type. The material demonstrated a specific discharge capacity on the first cycle of 163.7 mAh/g. The cyclic resource of the material turned out to be unsatisfactory. In addition, perspective cathode materials, such as NCM622 and NCM811, were obtained. The synthesized materials were analyzed using XRD, SEM, EDX, charge–discharge and cycle life tests, and the CVA and EIS methods. The initial specific discharge capacities of the NCM622 and NCM811 were 168 and 187 mAh/g, respectively. On the fifth cycle, the NCM622 demonstrated an increasing capacity—to 179 mAh/g, unlike NCM811, as the capacity of this material decreased to 141 mAh/g. Full article

(This article belongs to the Special Issue Recycling and Reuse of End-of-Life Lithium-Ion Batteries: Challenges and Strategies)

► Show Figures

Figure 1

13 pages, 5849 KiB

Open AccessArticle

Electroforming as a Novel One-Step Manufacturing Method of Structured Aluminum Foil Current Collectors for Lithium-Ion Batteries

by Phillip Scherzl, Michael Kaupp, Wassima El Mofid and Timo Sörgel

Batteries 2023, 9(8), 422; https://doi.org/10.3390/batteries9080422 - 12 Aug 2023

Cited by 1 | Viewed by 1624

Abstract

Conventionally, cathode current collectors for lithium-ion batteries (LIB) consist of an aluminum foil generally manufactured by a rolling process. In the present work, a novel one-step manufacturing method of structured aluminum foil current collectors for lithium-ion batteries by electroforming is introduced. For this, [...] Read more.

Conventionally, cathode current collectors for lithium-ion batteries (LIB) consist of an aluminum foil generally manufactured by a rolling process. In the present work, a novel one-step manufacturing method of structured aluminum foil current collectors for lithium-ion batteries by electroforming is introduced. For this, a low-temperature chloride-based ionic liquid was used as an electrolyte and a rotating cylinder out of stainless steel as a temporary substrate. It was shown that the structure of the aluminum foils can be adjusted from dense and flat to three-dimensional by choosing an appropriate substrate rotation speed and current density. Scanning electron microscopy (SEM) and white light interferometry (WLI) were utilized to analyze the foils’ surface morphology, structure and topography. The SEM analysis of the aluminum foils showed that the rolling process produced a foil with small grains, while electrodeposition resulted in foils with different degrees of grain growth and seed formation. This was in total agreement with WLI results that revealed significant differences in terms of roughness parameters, including the peak-to-valley difference R_pv, the root-mean-square roughness R_q and the arithmetic mean roughness R_a. These were, respectively, equal to 6.8 µm, 0.35 µm and 0.279 µm for the state-of-the-art foil and up to 96.6 µm, 10.92 µm and 8.783 µm for the structured electroformed foil. Additionally, cyclic voltammetry (CV) of the aluminum foils was used to investigate their passivation behavior within the typical LIB cathode potential operation window. The strong decrease in the current density during the second cycle compared to the first cycle, where an anodic peak appeared between 4.0 and 4.4 V vs. Li/Li⁺, demonstrated that passivation occurs in the same manner as observed for commercial Al current collectors. Full article

► Show Figures

Figure 1

19 pages, 7216 KiB

Open AccessArticle

Synthesis, Characterization and Evaluation of the Application of CoZn Nanostructures as Anode Materials

by Ainur M. Zikirina, Assem Temirtassova, Artem L. Kozlovskiy, Inesh E. Kenzhina and Meiram Begentayev

Batteries 2023, 9(8), 421; https://doi.org/10.3390/batteries9080421 - 11 Aug 2023

Cited by 1 | Viewed by 1264

Abstract

This study aims to obtain CoZn nanostructures using the electrochemical deposition method and to estimate the applicability of the resulting nanostructures as anode materials for lithium-ion batteries. Scanning electron microscopy, energy dispersive and X-ray phase analysis were used as the main methods for [...] Read more.

This study aims to obtain CoZn nanostructures using the electrochemical deposition method and to estimate the applicability of the resulting nanostructures as anode materials for lithium-ion batteries. Scanning electron microscopy, energy dispersive and X-ray phase analysis were used as the main methods for characterizing the obtained nanostructures. A study of the morphological properties of the synthesized nanostructures revealed that the variation of the synthesis conditions results in the formation of structures with different degrees of structural ordering and morphology. During the evaluation of the phase composition of the synthesized CoZn nanostructures with variation in the applied potential differences, the phase transformations’ dynamics were established, which can be written as follows: X-ray amorphous structures → Zn/CoO₂ → Co₂Zn₁₁/Co/CoO₂ → Co₂Zn₁₁/ZnO. Using the methods of phase analysis and mapping, an isotropic distribution of phases in the composition of nanostructures was established. In such a case, the formation of the Co₂Zn₁₁ phase occurs with an elevation in the concentration of cobalt from 8.9 to 29.3–31.1 at. % leads to the partial substitution of zinc ions by cobalt ions, followed by the formation of a cubic phase. The study of the morphological properties of the synthesized CoZn nanostructures afterlife tests showed differences in the degradation processes of nanowires triggered by the phase composition alteration. Full article

► Show Figures

Graphical abstract

12 pages, 5160 KiB

Open AccessArticle

High-Rate Capability of LiNi_0.9Mn_0.1−xAl_xO₂ (NMA) (x = 0.01, 0.03, 0.05) as Cathode for Lithium-Ion Batteries

by Lukman Noerochim, Elsanti Anggraini Gunawan, Sungging Pintowantoro, Haniffudin Nurdiansah, Ariiq Dzurriat Adam and Nurul Hayati Idris

Batteries 2023, 9(8), 420; https://doi.org/10.3390/batteries9080420 - 11 Aug 2023

Cited by 1 | Viewed by 1750

Abstract

LiNi_0.9Mn_0.1−xAl_xO₂ (NMA) (x = 0.01, 0.03, 0.05) cathodes were synthesized via the co-precipitation method and continued with the calcination process in a tube furnace at 750 °C under flowing oxygen gas for 12 h. X-ray diffraction [...] Read more.

LiNi_0.9Mn_0.1−xAl_xO₂ (NMA) (x = 0.01, 0.03, 0.05) cathodes were synthesized via the co-precipitation method and continued with the calcination process in a tube furnace at 750 °C under flowing oxygen gas for 12 h. X-ray diffraction (XRD) revealed a well-formed and high-purity phase with a hexagonal structure. LiNi_0.9Mn_0.07Al_0.03O₂ (NMA 973) had the best electrochemical performance with the lowest redox peak separation, the smallest charge transfer resistance (71.58 Ω cm⁻²), the highest initial specific discharge capacity of 172 mAh g⁻¹ at 0.1C, and a capacity retention of 98% after 100 cycles. Under high current density at 1 C, NMA 973 had excellent specific discharge capacity compared to the other samples. The optimal content of Mn and Al elements is a crucial factor to obtain the best electrochemical performance of NMA. Therefore, NMA 973 is a promising candidate as a cathode for high-energy-density lithium-ion batteries. Full article

(This article belongs to the Special Issue Novel Electrode Materials and Technologies for High-Energy-Density Lithium-Ion and Lithium-Metal Battery)

► Show Figures

Figure 1

22 pages, 6773 KiB

Open AccessEditor’s ChoiceArticle

Analysis of the Energy Efficiency of a Hybrid Energy Storage System for an Electric Vehicle

by Florin Mariasiu and Edmond A. Kelemen

Batteries 2023, 9(8), 419; https://doi.org/10.3390/batteries9080419 - 11 Aug 2023

Cited by 7 | Viewed by 2761

Abstract

The large-scale introduction of electric vehicles into traffic has appeared as an immediate necessity to reduce the pollution caused by the transport sector. The major problem of replacing propulsion systems based on internal combustion engines with electric ones is the energy storage capacity [...] Read more.

The large-scale introduction of electric vehicles into traffic has appeared as an immediate necessity to reduce the pollution caused by the transport sector. The major problem of replacing propulsion systems based on internal combustion engines with electric ones is the energy storage capacity of batteries, which defines the autonomy of the electric vehicle. Furthermore, considering the high cost of the battery, it is necessary to consider the implementation of command-and-control systems that extend the life of a battery for as long as possible. The topic covered in this article refers to the analysis by modeling and simulation of the efficiency of a hybrid energy storage system (battery–supercapacitor) adapted for an electric vehicle (e-Golf). Based on the simulations carried out, considering that the operating mode corresponds to the WLTP test cycle, the major conclusion was reached that the use of such a system leads to a decrease in energy consumption by 2.95% per 100 km. Simulations of the model were also carried out to obtain the variation in electricity consumption and vehicle autonomy depending on the number of passengers. Electricity consumption if the vehicle is equipped with a hybrid energy storage system increases by 0.67% on average for each passenger (of 75 kg) added and by 0.73% on average if the vehicle is not equipped with supercapacitors. Moreover, the use of the supercapacitor’s properties leads to the reduction in the peaks in energy taken/given by the battery with a direct effect on extending its life. Full article

(This article belongs to the Special Issue Advances in Hybrid Supercapacitors: Materials, Devices, Models, Systems, and Applications)

► Show Figures

Graphical abstract

22 pages, 4440 KiB

Open AccessArticle

Economic Analysis of a Redox Flow Batteries-Based Energy Storage System for Energy Savings in Factory Energy Management System

by Seon Hyeog Kim, Yoonmee Doh, Tae-Wook Heo and Il Woo Lee

Batteries 2023, 9(8), 418; https://doi.org/10.3390/batteries9080418 - 10 Aug 2023

Viewed by 2767

Abstract

Renewable energy systems are essential for carbon neutrality and energy savings in industrial facilities. Factories use a lot of electrical and thermal energy to manufacture products, but only a small percentage is recycled. Utilizing energy storage systems in industrial facilities is being applied [...] Read more.

Renewable energy systems are essential for carbon neutrality and energy savings in industrial facilities. Factories use a lot of electrical and thermal energy to manufacture products, but only a small percentage is recycled. Utilizing energy storage systems in industrial facilities is being applied as a way to cut energy costs and reduce carbon emissions. However, lithium-based batteries, which are predominantly used in traditional industries, face challenges in terms of affordability and reliability. Redox flow batteries, on the other hand, offer high power output and reliability, and are economical to manufacture for installations with high capacity. Although redox flow batteries are difficult to use in general electrical systems due to their small volume-to-capacity ratio, they can be easily utilized as energy storage devices in industrial parks or renewable energy parks with relatively little space constraints. In addition, since factories use a lot of heat energy in addition to electricity, utilizing combined heat and power can further reduce heat energy. In this study, we analyzed the cost estimation and economic feasibility of utilizing photovoltaics, redox flow cells, and combined heat and power to save energy in a factory’s energy management system. Full article

(This article belongs to the Special Issue Recent Progress in Redox Flow Battery Research and Development)

► Show Figures

Graphical abstract

15 pages, 2963 KiB

Open AccessArticle

Implementing Reversible Swelling into the Numerical Model of a Lithium-Ion Pouch Cell for Short Circuit Prediction

by Patrick Höschele and Christian Ellersdorfer

Batteries 2023, 9(8), 417; https://doi.org/10.3390/batteries9080417 - 9 Aug 2023

Viewed by 1724

Abstract

Mechanical simulation models have become crucial for understanding Li-ion battery failure and degradation mechanisms. However, existing safety assessment models lack the implementation of SOC-dependent thickness variations referred to as reversible swelling. Reversible swelling affects the applied preload force on a constrained pouch cell, [...] Read more.

Mechanical simulation models have become crucial for understanding Li-ion battery failure and degradation mechanisms. However, existing safety assessment models lack the implementation of SOC-dependent thickness variations referred to as reversible swelling. Reversible swelling affects the applied preload force on a constrained pouch cell, potentially impacting its safety. To investigate this, a finite element RVE model was developed in LS-Dyna. Two swelling models, simplified homogenous expansion (HE) and locally resolved expansion (LE), were implemented along with a reference basis model (BM) without expansion. Six different stress- or strain-based short circuit criteria were calibrated with abuse test simulations at different SOCs and preload forces. Short circuit prognosis improved on average by 0.8% and 0.7% for the LE and HE model compared to the BM, with minimum principal stress being the most suitable criterion. The LE model exhibited a softer mechanical response than the HE model or BM, accounting for the pouch cell surface unevenness at small indentations. This study demonstrated the feasibility and usefulness of implementing an expansion model in a commercial FE solver for improved short circuit predictions. An expansion model is crucial for simulating aged battery cells with significant geometry changes strongly affecting the preload force of a constrained battery cell. Full article

(This article belongs to the Section Battery Modelling, Simulation, Management and Application)

► Show Figures

Figure 1

16 pages, 2127 KiB

Open AccessArticle

Using Reinforcement Learning to Solve a Dynamic Orienteering Problem with Random Rewards Affected by the Battery Status

by Angel A. Juan, Carolina A. Marugan, Yusef Ahsini, Rafael Fornes, Javier Panadero and Xabier A. Martin

Batteries 2023, 9(8), 416; https://doi.org/10.3390/batteries9080416 - 9 Aug 2023

Cited by 4 | Viewed by 1538

Abstract

This paper discusses an orienteering optimization problem where a vehicle using electric batteries must travel from an origin depot to a destination depot while maximizing the total reward collected along its route. The vehicle must cross several consecutive regions, with each region containing [...] Read more.

This paper discusses an orienteering optimization problem where a vehicle using electric batteries must travel from an origin depot to a destination depot while maximizing the total reward collected along its route. The vehicle must cross several consecutive regions, with each region containing different types of charging nodes. A charging node has to be selected in each region, and the reward for visiting each node—in terms of a ‘satisfactory’ charging process—is a binary random variable that depends upon dynamic factors such as the type of charging node, weather conditions, congestion, battery status, etc. To learn how to efficiently operate in this dynamic environment, a hybrid methodology combining simulation with reinforcement learning is proposed. The reinforcement learning component is able to make informed decisions at each stage, while the simulation component is employed to validate the learning process. The computational experiments show how the proposed methodology is capable of design routing plans that are significantly better than non-informed decisions, thus allowing for an efficient management of the vehicle’s battery under such dynamic conditions. Full article

(This article belongs to the Special Issue Battery Management in Electric Vehicles: Current Status and Future Trends)

► Show Figures

Graphical abstract

14 pages, 1089 KiB

Open AccessFeature PaperArticle

Multi-Cell Testing Topologies for Defect Detection Using Electrochemical Impedance Spectroscopy: A Combinatorial Experiment-Based Analysis

by Manuel Ank, Jonas Göhmann and Markus Lienkamp

Batteries 2023, 9(8), 415; https://doi.org/10.3390/batteries9080415 - 8 Aug 2023

Cited by 2 | Viewed by 2003

Abstract

Given the increasing use of lithium-ion batteries, which is driven in particular by electromobility, the characterization of cells in production and application plays a decisive role in quality assurance. The detection of defects particularly motivates the optimization and development of innovative characterization methods, [...] Read more.

Given the increasing use of lithium-ion batteries, which is driven in particular by electromobility, the characterization of cells in production and application plays a decisive role in quality assurance. The detection of defects particularly motivates the optimization and development of innovative characterization methods, with simultaneous testing of multiple cells in the context of multi-cell setups having been researched to economize on the number of cell test channels required. In this work, an experimental study is presented demonstrating the influence of a defect type in one cell on five remaining interconnected cells in eight combinatorially varied topologies using galvanostatic electrochemical impedance spectroscopy. The results show that regularities related to the interconnection position are revealed when considering the change in the specific resistance

Z_{I M, m i n}

at the transition from the charge transfer to the diffusion region between the reference and fault measurements, allowing it to function as a defect identifier in the present scenario. These results and the extensive measurement data provided can serve as a basis for the evaluation and design of multi-cell setups used for simultaneous impedance-based lithium-ion cell characterizations. Full article

► Show Figures

Figure 1

20 pages, 1257 KiB

Open AccessArticle

A Novel Sequence-to-Sequence Prediction Model for Lithium-Ion Battery Capacity Degradation Based on Improved Particle Swarm Optimization

by Dinghong Chen, Weige Zhang, Caiping Zhang, Bingxiang Sun, Haoze Chen, Sijia Yang and Xinwei Cong

Batteries 2023, 9(8), 414; https://doi.org/10.3390/batteries9080414 - 8 Aug 2023

Viewed by 1754

Abstract

The state of health (SOH) evaluation and remaining useful life (RUL) prediction for lithium-ion batteries (LIBs) are crucial for health management. This paper proposes a novel sequence-to-sequence (Seq2Seq) prediction method for LIB capacity degradation based on the gated recurrent unit (GRU) neural network [...] Read more.

The state of health (SOH) evaluation and remaining useful life (RUL) prediction for lithium-ion batteries (LIBs) are crucial for health management. This paper proposes a novel sequence-to-sequence (Seq2Seq) prediction method for LIB capacity degradation based on the gated recurrent unit (GRU) neural network with the attention mechanism. An improved particle swarm optimization (IPSO) algorithm is developed for automatic hyperparameter search of the Seq2Seq model, which speeds up parameter convergence and avoids getting stuck in local optima. Before model training, the complete ensemble empirical mode decomposition with adaptive noise (CEEMDAN) algorithm decomposes the capacity degradation sequences. And the intrinsic mode function (IMF) components with the highest correlation are employed to reconstruct the sequences, reducing the influence of noise in the original data. A real-cycle-life data set under fixed operating conditions is employed to validate the superiority and effectiveness of the method. The comparison results demonstrate that the proposed model outperforms traditional GRU and RNN models. The predicted mean absolute percent error (MAPE) in SOH evaluation and RUL prediction can be as low as 0.76% and 0.24%, respectively. Full article

(This article belongs to the Special Issue Advances in Battery Status Estimation and Prediction)

► Show Figures

Figure 1

22 pages, 3353 KiB

Open AccessArticle

Predicting the Cycle Life of Lithium-Ion Batteries Using Data-Driven Machine Learning Based on Discharge Voltage Curves

by Yinfeng Jiang and Wenxiang Song

Batteries 2023, 9(8), 413; https://doi.org/10.3390/batteries9080413 - 7 Aug 2023

Cited by 5 | Viewed by 3119

Abstract

Battery degradation is a complex nonlinear problem, and it is crucial to accurately predict the cycle life of lithium-ion batteries to optimize the usage of battery systems. However, diverse chemistries, designs, and degradation mechanisms, as well as dynamic cycle conditions, have remained significant [...] Read more.

Battery degradation is a complex nonlinear problem, and it is crucial to accurately predict the cycle life of lithium-ion batteries to optimize the usage of battery systems. However, diverse chemistries, designs, and degradation mechanisms, as well as dynamic cycle conditions, have remained significant challenges. We created 53 features from discharge voltage curves, 18 of which were newly developed. The maximum relevance minimum redundancy (MRMR) algorithm was used for feature selection. Robust linear regression (RLR) and Gaussian process regression (GPR) algorithms were deployed on three different datasets to estimate battery cycle life. The RLR and GPR algorithms achieved high performance, with a root-mean-square error of 6.90% and 6.33% in the worst case, respectively. This work highlights the potential of combining feature engineering and machine learning modeling based only on discharge voltage curves to estimate battery degradation and could be applied to onboard applications that require efficient estimation of battery cycle life in real time. Full article

(This article belongs to the Special Issue Artificial Intelligence-Based State-of-Health Estimation of Lithium-Ion Batteries)

► Show Figures

Figure 1

17 pages, 7093 KiB

Open AccessArticle

Comparison of Different Current Collector Materials for In Situ Lithium Deposition with Slurry-Based Solid Electrolyte Layers

by Tina Kreher, Fabian Heim, Julia Pross-Brakhage, Jessica Hemmerling and Kai Peter Birke

Batteries 2023, 9(8), 412; https://doi.org/10.3390/batteries9080412 - 7 Aug 2023

Cited by 3 | Viewed by 2578

Abstract

In this paper, we investigate different current collector materials for in situ deposition of lithium using a slurry-based

β

-Li₃PS₄ electrolyte layer with a focus on transferability to industrial production. Therefore, half-cells with different current collector materials (carbon-coated aluminum, stainless [...] Read more.

In this paper, we investigate different current collector materials for in situ deposition of lithium using a slurry-based

β

-Li₃PS₄ electrolyte layer with a focus on transferability to industrial production. Therefore, half-cells with different current collector materials (carbon-coated aluminum, stainless steel, aluminum, nickel) are prepared and plating/stripping tests are performed. The results are compared in terms of Coulombic efficiency (CE) and overvoltages. The stainless steel current collector shows the best performance, with a mean efficiency of

η_{mean, SST} = 98 %

; the carbon-coated aluminum reaches

η_{mean, Al + C} = 97 %

. The results for pure aluminum and nickel indicate strong side reactions. In addition, an approach is tested in which a solvate ionic liquid (SIL) is added to the solid electrolyte layer. Compared to the cell setup without SIL, this cannot further increase the CE; however, a significant reduction in overvoltages is achieved. Full article

(This article belongs to the Special Issue From Liquid to Solid, the Alternation of Generations toward Solid-State Batteries)

► Show Figures

Figure 1

22 pages, 6970 KiB

Open AccessReview

Research Progress in Thermal Runaway Vent Gas Characteristics of Li-Ion Battery

by Mingming Qiu, Jianghong Liu, Beihua Cong and Yan Cui

Batteries 2023, 9(8), 411; https://doi.org/10.3390/batteries9080411 - 7 Aug 2023

Cited by 9 | Viewed by 3668

Abstract

The wide application of lithium-ion batteries (LIBs) brings along with it various safety problems, such as fire and explosion accidents. Aiming at the thermal runaway (TR) and fire problems of LIBs, we reviewed the evolution of TR within LIB and the release of [...] Read more.

The wide application of lithium-ion batteries (LIBs) brings along with it various safety problems, such as fire and explosion accidents. Aiming at the thermal runaway (TR) and fire problems of LIBs, we reviewed the evolution of TR within LIB and the release of TR gases and their hazards, as well as the research progress in recent years in the area of fire separation of LIBs. To begin with, physical, electrical, and thermal abuse are the three main factors leading to TR and the thermal stability of aging batteries significantly deteriorates. Furthermore, the decomposition of the electrolyte and the reaction between the active materials generates CO, CO₂, H₂, HF, and a variety of hydrocarbons. These TR gases have serious toxic and explosive hazards. In addition, fire separation can effectively delay the occurrence and propagation of TR within LIB modules. As a good heat-absorbing material, phase-change materials are widely used in the thermal management system and have a great prospect of wide applications in the fire separation of LIBs. Finally, the research on the TR gases’ hazards of aging LIB and safer and more effective fire separation are prospected. Full article

► Show Figures

Graphical abstract

17 pages, 3644 KiB

Open AccessArticle

Optimal Capacity Configuration of Wind–Solar Hydrogen Storage Microgrid Based on IDW-PSO

by Ge He, Zhijie Wang, Hengke Ma and Xianli Zhou

Batteries 2023, 9(8), 410; https://doi.org/10.3390/batteries9080410 - 6 Aug 2023

Cited by 6 | Viewed by 2110

Abstract

Because the new energy is intermittent and uncertain, it has an influence on the system’s output power stability. A hydrogen energy storage system is added to the system to create a wind, light, and hydrogen integrated energy system, which increases the utilization rate [...] Read more.

Because the new energy is intermittent and uncertain, it has an influence on the system’s output power stability. A hydrogen energy storage system is added to the system to create a wind, light, and hydrogen integrated energy system, which increases the utilization rate of renewable energy while encouraging the consumption of renewable energy and lowering the rate of abandoning wind and light. Considering the system’s comprehensive operation cost economy, power fluctuation, and power shortage as the goal, considering the relationship between power generation and load, assigning charging and discharging commands to storage batteries and hydrogen energy storage, and constructing a model for optimal capacity allocation of wind–hydrogen microgrid system. The optimal configuration model of the wind, solar, and hydrogen microgrid system capacity is constructed. A particle swarm optimization with dynamic adjustment of inertial weight (IDW-PSO) is proposed to solve the optimal allocation scheme of the model in order to achieve the optimal allocation of energy storage capacity in a wind–hydrogen storage microgrid. Finally, a microgrid system in Beijing is taken as an example for simulation and solution, and the results demonstrate that the proposed approach has the characteristics to optimize the economy and improve the capacity of renewable energy consumption, realize the inhibition of the fluctuations of power, reduce system power shortage, and accelerate the convergence speed. Full article

(This article belongs to the Topic Advances in Renewable Energy and Energy Storage)

► Show Figures

Figure 1

44 pages, 4755 KiB

Open AccessReview

Redox Flow Batteries: Recent Development in Main Components, Emerging Technologies, Diagnostic Techniques, Large-Scale Applications, and Challenges and Barriers

by Abdul Ghani Olabi, Mohamed Adel Allam, Mohammad Ali Abdelkareem, T. D. Deepa, Abdul Hai Alami, Qaisar Abbas, Ammar Alkhalidi and Enas Taha Sayed

Batteries 2023, 9(8), 409; https://doi.org/10.3390/batteries9080409 - 4 Aug 2023

Cited by 16 | Viewed by 11244

Abstract

Redox flow batteries represent a captivating class of electrochemical energy systems that are gaining prominence in large-scale storage applications. These batteries offer remarkable scalability, flexible operation, extended cycling life, and moderate maintenance costs. The fundamental operation and structure of these batteries revolve around [...] Read more.

Redox flow batteries represent a captivating class of electrochemical energy systems that are gaining prominence in large-scale storage applications. These batteries offer remarkable scalability, flexible operation, extended cycling life, and moderate maintenance costs. The fundamental operation and structure of these batteries revolve around the flow of an electrolyte, which facilitates energy conversion and storage. Notably, the power and energy capacities can be independently designed, allowing for the conversion of chemical energy from input fuel into electricity at working electrodes, resembling the functioning of fuel cells. This work provides a comprehensive overview of the components, advantages, disadvantages, and challenges of redox flow batteries (RFBs). Moreover, it explores various diagnostic techniques employed in analyzing flow batteries. The discussion encompasses the utilization of RFBs for large-scale energy storage applications and summarizes the engineering design aspects related to these batteries. Additionally, this study delves into emerging technologies, applications, and challenges in the realm of redox flow batteries. Full article

(This article belongs to the Special Issue Recent Progress in Redox Flow Battery Research and Development)

► Show Figures

Graphical abstract

12 pages, 6952 KiB

Open AccessArticle

In-Situ Alloy-Modified Sodiophilic Current Collectors for Anode-Less Sodium Metal Batteries

by Xiaolong Cheng, Dongjun Li, Shen Peng, Pengcheng Shi, Huili Yu, Yu Jiang and Shikuo Li

Batteries 2023, 9(8), 408; https://doi.org/10.3390/batteries9080408 - 4 Aug 2023

Cited by 10 | Viewed by 2174

Abstract

Anode-less sodium metal batteries have drawn dramatica attention owing to their high specific energy and low cost. However, the growth of sodium dendrites and the resulting loss of active materials and serious safety concerns hinder their practical applications. In this work, a bismuth-based [...] Read more.

Anode-less sodium metal batteries have drawn dramatica attention owing to their high specific energy and low cost. However, the growth of sodium dendrites and the resulting loss of active materials and serious safety concerns hinder their practical applications. In this work, a bismuth-based modification layer with good sodiophilicity is constructed on the surface of Cu foil (denoted as Cu@Bi) to control the deposition of Na metal. The activation-derived porous Na-rich alloy phase can provide abundant nucleation sites and reduce the nucleation overpotential to induce the uniform and dense deposition of Na metal. When evaluated in half cell, the Cu@Bi current collectors can operate for 750 h at 1 mA cm⁻² and 1 mAh cm⁻², with an average coulombic efficiency (CE) of 99.5%. When the current density is improved to 2 mA cm⁻², the Cu@Bi can also stably maintain for 750 cycles, demonstrating the remarkable effect of the modification layer. When coupled with the Na₃V₂(PO₄)₃ cathode, the full cell exhibits stable cycle performance over 80 cycles. The modification strategy of alloy modification can provide fresh ideas for the research and application of anode-less and even anode-free metal batteries. Full article

(This article belongs to the Special Issue High-Performance Materials for Sodium-Ion Batteries)

► Show Figures

Graphical abstract

27 pages, 3101 KiB

Open AccessReview

Solid Electrolytes Based on NASICON-Structured Phosphates for Lithium Metal Batteries

by Irina Stenina, Svetlana Novikova, Daria Voropaeva and Andrey Yaroslavtsev

Batteries 2023, 9(8), 407; https://doi.org/10.3390/batteries9080407 - 4 Aug 2023

Cited by 8 | Viewed by 3180

Abstract

All-solid-state lithium batteries are a promising alternative to commercially available lithium-ion batteries due to their ability to achieve high energy density, safety, and compactness. Electrolytes are key components of all-solid-state batteries, as they are crucial in determining the batteries’ efficiency. Herein, the structure [...] Read more.

All-solid-state lithium batteries are a promising alternative to commercially available lithium-ion batteries due to their ability to achieve high energy density, safety, and compactness. Electrolytes are key components of all-solid-state batteries, as they are crucial in determining the batteries’ efficiency. Herein, the structure of LiM₂(PO₄)₃ (M = Ti, Ge, Zr) and lithium-ion migration mechanisms are introduced as well as different synthetic routes and doping (co-doping), and their influence on conductivity is discussed. The effective methods of reducing electrolyte/electrode interface resistance and improving ion-conducting properties are summarized. In addition, different polymer/NASICON composites are considered. The challenges and prospects of practical applications of NASICON-type lithium phosphates as electrolytes for all-solid-state batteries are discussed. Full article

(This article belongs to the Special Issue Electrolytes for Solid State Batteries)

► Show Figures

Figure 1

17 pages, 4763 KiB

Open AccessArticle

The Impact of Graphene in Na₂FeP₂O₇/C/Reduced Graphene Oxide Composite Cathode for Sodium-Ion Batteries

by Inara Nesterova, Liga Britala, Anatolijs Sarakovskis, Beate Kruze, Gunars Bajars and Gints Kucinskis

Batteries 2023, 9(8), 406; https://doi.org/10.3390/batteries9080406 - 3 Aug 2023

Cited by 4 | Viewed by 2226

Abstract

This study presents a thorough investigation of Na₂FeP₂O₇ (NFP) cathode material for sodium-ion batteries and its composites with carbon and reduced graphene oxide (rGO). Our findings demonstrate that rGO sheets improve cycling performance in NFP/C/rGO composite in the [...] Read more.

This study presents a thorough investigation of Na₂FeP₂O₇ (NFP) cathode material for sodium-ion batteries and its composites with carbon and reduced graphene oxide (rGO). Our findings demonstrate that rGO sheets improve cycling performance in NFP/C/rGO composite in the absence of solid electrolyte interphase (SEI)-stabilizing additives. However, once SEI is stabilized with the help of fluoroethylene carbonate electrolyte additive, NFP with carbon additive (NFP/C) exhibits a superior electrochemical performance when compared to NFP/rGO and NFP/C/rGO composites. The decreases in capacity and rate capability are proportional to the amount of rGO added, and lead to an increase in overvoltage and internal resistance. Based on our results, we attribute this effect to worsened sodium kinetics in the bulk of the electrode—the larger ionic radius of Na⁺ hinders charge transfer in the presence of rGO, despite the likely improved electronic conductivity. These findings provide a compelling explanation for the observed trends in electrochemical performance and suggest that the use of rGO in Na-ion battery electrodes may present challenges associated with ionic transport along and through rGO sheets. Full article

(This article belongs to the Special Issue Promising Carbon-Based Materials for Energy Storage)

► Show Figures

Graphical abstract

12 pages, 3715 KiB

Open AccessArticle

A Hollow-Shaped ZIF-8-N-Doped Porous Carbon Fiber for High-Performance Zn-Ion Hybrid Supercapacitors

by Mingqi Wei, Zhenlong Jiang, Chengcheng Yang, Tao Jiang, Linlin Zhang, Guangzhen Zhao, Guang Zhu, Lianghao Yu and Yuanyuan Zhu

Batteries 2023, 9(8), 405; https://doi.org/10.3390/batteries9080405 - 3 Aug 2023

Cited by 5 | Viewed by 1813

Abstract

The advantages of low cost, high theoretical capacity, and dependable safety of aqueous zinc ion hybrid supercapacitors (ZHSCs) enable their promising use in flexible and wearable energy storage devices. However, achieving extended cycling stability in ZHSCs is still challenged by the limited availability [...] Read more.

The advantages of low cost, high theoretical capacity, and dependable safety of aqueous zinc ion hybrid supercapacitors (ZHSCs) enable their promising use in flexible and wearable energy storage devices. However, achieving extended cycling stability in ZHSCs is still challenged by the limited availability of carbon cathode materials that can effectively pair with zinc anode materials. Here, we report a method for synthesising heteroatom-doped carbon nanofibers using electrostatic spinning and metal-organic frameworks (specifically ZIF-8). Assembled Zn//ZPCNF-1.5 ZHSCs exhibited 193 mA h g⁻¹ specific capacity at 1 A g⁻¹ and 162.6 Wh kg⁻¹ energy density at 841.2 kW kg⁻¹. Additionally, the device showed an ultra-long cycle life, maintaining 98% capacity after 20,000 cycles. Experimental analysis revealed an increase in the number of pores and active sites after adding ZIF-8 to the precursor. Furthermore, N doping effectively enhanced Zn²⁺ ions chemical adsorption and improved Zn-ion storage performance. This work provides a feasible design strategy to enhance ZHSC energy storage capability for practical applications. Full article

(This article belongs to the Special Issue Electrode Materials and Electrolyte for Rechargeable Batteries)

► Show Figures

Graphical abstract

13 pages, 2328 KiB

Open AccessArticle

Effect of External Compression on the Thermal Runaway of Lithium-Ion Battery Cells during Crush Tests: Insights for Improved Safety Assessment

by Alexander Hahn, Stefan Doose, Daniel Saathoff and Arno Kwade

Batteries 2023, 9(8), 404; https://doi.org/10.3390/batteries9080404 - 2 Aug 2023

Cited by 3 | Viewed by 2007

Abstract

To gain better understanding of the safety behavior of lithium-ion batteries under mechanical stress, crush tests are performed and reported in literature and in standards. However, many of these tests are conducted without the use of a cell clamping device, whereas external pressure [...] Read more.

To gain better understanding of the safety behavior of lithium-ion batteries under mechanical stress, crush tests are performed and reported in literature and in standards. However, many of these tests are conducted without the use of a cell clamping device, whereas external pressure is applied to the cell in a battery module in applications such as in an electric vehicle. The objective of this manuscript is to determine the effect of differing external compression on the thermal runaway of battery cells. Therefore, in this study, crush tests are performed with a hemispherical punch in a battery cell test chamber on commercially available 5 Ah pouch cells in a clamping device at four different normal stresses. The results are compared to cells that are free to expand with gas evolution. It is shown that applying compression to the cells not only results in a greater reproducibility of the experiments but that it also affects the thermal runaway process itself. With decreasing clamping stresses, the reaction time of the thermal runaway is increased by up to 19%, and the mass ejection is decreased by up to 10%, which, in turn, strongly influences the measurable gas concentrations by up to 80%. Based on this, a defined clamping compression was selected to obtain comparable results for different cell formats. Full article

(This article belongs to the Section Battery Performance, Ageing, Reliability and Safety)

► Show Figures

Figure 1

14 pages, 4508 KiB

Open AccessArticle

Facile Constructing Hierarchical Fe₃O₄@C Nanocomposites as Anode for Superior Lithium-Ion Storage

by Haichang Zhong, Wenlong Huang, Yukun Wei, Xin Yang, Chunhai Jiang, Hui Liu, Wenxian Zhang, Chu Liang, Leyang Dai and Xijun Xu

Batteries 2023, 9(8), 403; https://doi.org/10.3390/batteries9080403 - 2 Aug 2023

Cited by 2 | Viewed by 1311

Abstract

Ferroferric oxide (Fe₃O₄) is regarded to be a promising high-capacity anode material for LIBs. However, the capacity attenuates fast and the rate performance is poor due to the dramatic pulverization and sluggish charge transfer properties. To solve these problems, [...] Read more.

Ferroferric oxide (Fe₃O₄) is regarded to be a promising high-capacity anode material for LIBs. However, the capacity attenuates fast and the rate performance is poor due to the dramatic pulverization and sluggish charge transfer properties. To solve these problems, a simple in situ encapsulation and composite method was successfully developed to construct carbon nanotube/nanorod/nanosheet-supported Fe₃O₄ nanoparticles. Owing to the hierarchical architecture design, the novel structure Fe₃O₄@C nanocomposites effectively enhance the charge transfer, alleviate pulverization, avoid the agglomeration of Fe₃O₄ nanoparticles, and also provide superior kinetics toward lithium storage, thereby showing significantly improved reversibility and rate performance. The carbon nanotube/nanorod supported core-shell structure Fe₃O₄@C nanocomposite displays outstanding high rate capability and stable cycling performance (reversible capability of 1006, 552 and 423 mA h g⁻¹ at 0.2, 0.5 and 1 A g⁻¹ after running 100, 300 and 500 cycles, respectively). Full article

(This article belongs to the Special Issue Transition Metal Compound Materials for Secondary Batteries)

► Show Figures

Graphical abstract

25 pages, 8490 KiB

Open AccessArticle

Conditioning Solid-State Anode-Less Cells for the Next Generation of Batteries

by Manuela C. Baptista, Beatriz Moura Gomes, Diana Capela, Miguel F. S. Ferreira, Diana Guimarães, Nuno A. Silva, Pedro A. S. Jorge, José J. Silva and Maria Helena Braga

Batteries 2023, 9(8), 402; https://doi.org/10.3390/batteries9080402 - 2 Aug 2023

Cited by 2 | Viewed by 2647

Abstract

Anode-less batteries are a promising innovation in energy storage technology, eliminating the need for traditional anodes and offering potential improvements in efficiency and capacity. Here, we have fabricated and tested two types of anode-less pouch cells, the first using solely a copper negative [...] Read more.

Anode-less batteries are a promising innovation in energy storage technology, eliminating the need for traditional anodes and offering potential improvements in efficiency and capacity. Here, we have fabricated and tested two types of anode-less pouch cells, the first using solely a copper negative current collector and the other the same current collector but coated with a nucleation seed ZnO layer. Both types of cells used the same all-solid-state electrolyte, Li_2.99Ba_0.005ClO composite, in a cellulose matrix and a LiFePO₄ cathode. Direct and indirect methods confirmed Li metal anode plating after charging the cells. The direct methods are X-ray photoelectron spectroscopy (XPS) and laser-induced breakdown spectroscopy (LIBS), a technique not divulged in the battery world but friendly to study the surface of the negative current collector, as it detects lithium. The indirect methods used were electrochemical cycling and impedance and scanning electron microscopy (SEM). It became evident the presence of plated Li on the surface of the current collector in contact with the electrolyte upon charging, both directly and indirectly. A maximum average lithium plating thickness of 2.9 µm was charged, and 0.13 µm was discharged. The discharge initiates from a maximum potential of 3.2 V, solely possible if an anode-like high chemical potential phase, such as Li, would form while plating. Although the ratings and energy densities are minor in this study, it was concluded that a layer of ZnO, even at 25 °C, allows for higher discharge power for more hours than plain Cu. It was observed that where Li plates on ZnO, Zn is not detected or barely detected by XPS. The present anode-less cells discharge quickly initially at higher potentials but may hold a discharge potential for many hours, likely due to the ferroelectric character of the electrolyte. Full article

(This article belongs to the Special Issue Rechargeable Batteries)

► Show Figures

Figure 1

18 pages, 5183 KiB

Open AccessArticle

AlCl₃-NaCl-ZnCl₂ Secondary Electrolyte in Next-Generation ZEBRA (Na-ZnCl₂) Battery

by Sumit Kumar, Wenjin Ding, Ralf Hoffmann, Louis Sieuw, Meike V. F. Heinz, Norbert Weber and Alexander Bonk

Batteries 2023, 9(8), 401; https://doi.org/10.3390/batteries9080401 - 1 Aug 2023

Cited by 2 | Viewed by 1712

Abstract

Increasing demand to store intermittent renewable electricity from, e.g., photovoltaic and wind energy, has led to much research and development in large-scale stationary energy storage, for example, ZEBRA batteries (Na-NiCl₂ solid electrolyte batteries). Replacing Ni with abundant and low-cost Zn makes the [...] Read more.

Increasing demand to store intermittent renewable electricity from, e.g., photovoltaic and wind energy, has led to much research and development in large-scale stationary energy storage, for example, ZEBRA batteries (Na-NiCl₂ solid electrolyte batteries). Replacing Ni with abundant and low-cost Zn makes the ZEBRA battery more cost-effective. However, few studies were performed on this next-generation ZEBRA (Na-ZnCl₂) battery system, particularly on its AlCl₃-NaCl-ZnCl₂ secondary electrolyte. Its properties such as phase diagrams and vapor pressures are vital for the cell design and optimization. In our previous work, a simulation-assisted method for molten salt electrolyte selection has shown its successful application in development of molten salt batteries. The same method is used here to in-depth study the AlCl₃-NaCl-ZnCl₂ salt electrolyte in terms of its phase diagrams and vapor pressures via FactSage^TM and thermo-analytical techniques (Differential Scanning Calorimetry (DSC) and OptiMelt^TM), and their effects on battery performance such as operation safety and charging/discharging reaction mechanism. The DSC and OptiMelt results show that the experimental data such as melting temperatures and phase changes agree well with the simulated phase diagrams. Moreover, the FactSage^TM simulation shows that the salt vapor pressure increases significantly with increasing temperature and molar fraction of AlCl₃. The obtained phase diagrams and vapor pressures will be used in the secondary electrolyte selection, cell design and battery operation. Full article

(This article belongs to the Special Issue High Performance Sodium Rechargeable Batteries and Beyond)

► Show Figures

Figure 1

37 pages, 9937 KiB

Open AccessReview

Recent Progress and Prospects in Liquid Cooling Thermal Management System for Lithium-Ion Batteries

by Jiahao Liu, Hao Chen, Silu Huang, Yu Jiao and Mingyi Chen

Batteries 2023, 9(8), 400; https://doi.org/10.3390/batteries9080400 - 1 Aug 2023

Cited by 13 | Viewed by 7196

Abstract

The performance of lithium-ion batteries is closely related to temperature, and much attention has been paid to their thermal safety. With the increasing application of the lithium-ion battery, higher requirements are put forward for battery thermal management systems. Compared with other cooling methods, [...] Read more.

The performance of lithium-ion batteries is closely related to temperature, and much attention has been paid to their thermal safety. With the increasing application of the lithium-ion battery, higher requirements are put forward for battery thermal management systems. Compared with other cooling methods, liquid cooling is an efficient cooling method, which can control the maximum temperature and maximum temperature difference of the battery within an acceptable range. This article reviews the latest research in liquid cooling battery thermal management systems from the perspective of indirect and direct liquid cooling. Firstly, different coolants are compared. The indirect liquid cooling part analyzes the advantages and disadvantages of different liquid channels and system structures. Direct cooling summarizes the different systems’ differences in cooling effectiveness and energy consumption. Then, the combination of liquid cooling, air cooling, phase change materials, and heat pipes is examined. Later, the connection between the cooling and heating functions in the liquid thermal management system is considered. In addition, from a safety perspective, it is found that liquid cooling can effectively manage thermal runaway. Finally, some problems are put forward, and a summary and outlook are given. Full article

(This article belongs to the Special Issue Thermal Safety of Lithium Ion Batteries)

► Show Figures

Graphical abstract

Journal Menu

Journal Browser

Batteries, Volume 9, Issue 8 (August 2023) – 39 articles

Further Information

Guidelines

MDPI Initiatives

Follow MDPI
