Remote Sens., Volume 13, Issue 9 (May-1 2021) – 260 articles

Cover Story (view full-size image): Meeting the demand of food supply and environment protection in rocky desertified regions (e.g., Southeast China) is of great significance for enhancing human wellbeing. Herein, we calculated the yield gap for 6 main crop species in Guizhou Province and simulated crop yield using ensembled artificial neural networks. We also tested the influence of adjusting the quantity of local fertilization and irrigation on crop production in Guizhou Province. Results showed that the total yield of the selected crops had, on average, reached over 72.5% of the theoretical maximum yield. For most crop species, the bonus of fertilization intensification has reached the condition of “stagnation”. By contrast, increasing irrigation tended to be more consistently effective at increasing crop yield. View this paper
  • Issues are regarded as officially published after their release is announced to the table of contents alert mailing list.
  • You may sign up for e-mail alerts to receive table of contents of newly released issues.
  • PDF is the official format for papers published in both, html and pdf forms. To view the papers in pdf format, click on the "PDF Full-text" link, and use the free Adobe Readerexternal link to open them.
Order results
Result details
Select all
Export citation of selected articles as:
Article
Lifting Scheme-Based Sparse Density Feature Extraction for Remote Sensing Target Detection
Remote Sens. 2021, 13(9), 1862; https://doi.org/10.3390/rs13091862 - 10 May 2021
Viewed by 522
Abstract
The design of backbones is of great significance for enhancing the location and classification precision in the remote sensing target detection task. Recently, various approaches have been proposed on altering the feature extraction density in the backbones to enlarge the receptive field, make [...] Read more.
The design of backbones is of great significance for enhancing the location and classification precision in the remote sensing target detection task. Recently, various approaches have been proposed on altering the feature extraction density in the backbones to enlarge the receptive field, make features prominent, and reduce computational complexity, such as dilated convolution and deformable convolution. Among them, one of the most widely used methods is strided convolution, but it loses the information about adjacent feature points which leads to the omission of some useful features and the decrease of detection precision. This paper proposes a novel sparse density feature extraction method based on the relationship between the lifting scheme and convolution, which improves the detection precision while keeping the computational complexity almost the same as the strided convolution. Experimental results on remote sensing target detection indicate that our proposed method improves both detection performance and network efficiency. Full article
Show Figures

Graphical abstract

Article
Analysis of Activity in an Open-Pit Mine by Using InSAR Coherence-Based Normalized Difference Activity Index
Remote Sens. 2021, 13(9), 1861; https://doi.org/10.3390/rs13091861 - 10 May 2021
Viewed by 601
Abstract
In this study, time-series of Sentinel-1A/B Interferometric Synthetic Aperture Radar (InSAR) coherence images were used to monitor the mining activity of Musan open-pit mine, the largest iron mine in North Korea. First, the subtraction of SRTM DEM (2000) from TanDEM-X DEM (2010–2015) has [...] Read more.
In this study, time-series of Sentinel-1A/B Interferometric Synthetic Aperture Radar (InSAR) coherence images were used to monitor the mining activity of Musan open-pit mine, the largest iron mine in North Korea. First, the subtraction of SRTM DEM (2000) from TanDEM-X DEM (2010–2015) has identified two major accumulation areas, one in the east (+112.33 m) and the other in the west (+84.03 m), and a major excavation area (−42.54 m) at the center of the mine. A total of 89 high-quality coherence images with a 12-day baseline from 2015 to 2020 were converted to the normalized difference activity index (NDAI), a newly developed activity indicator robust to spatial and temporal decorrelation. An RGB composite of annually averaged NDAI maps (red for 2019, green for 2018, and blue for 2017) showed that overall activity has diminished since 2018. Dumping slopes were categorized into shrinking, expanding, or transitional, according to the color pattern. Migration and expansion of excavation sites were also found on the pit floor. Time series of 12-day NDAI graphs revealed the date of activities with monthly accuracy. It is believed that NDAI with continuous acquisition of Sentinel-1A/B data can provide detailed monitoring of various types of activities in open-pit mines especially with limited in situ data. Full article
Show Figures

Graphical abstract

Technical Note
NDFTC: A New Detection Framework of Tropical Cyclones from Meteorological Satellite Images with Deep Transfer Learning
Remote Sens. 2021, 13(9), 1860; https://doi.org/10.3390/rs13091860 - 10 May 2021
Viewed by 414
Abstract
Accurate detection of tropical cyclones (TCs) is important to prevent and mitigate natural disasters associated with TCs. Deep transfer learning methods have advantages in detection tasks, because they can further improve the stability and accuracy of the detection model. Therefore, on the basis [...] Read more.
Accurate detection of tropical cyclones (TCs) is important to prevent and mitigate natural disasters associated with TCs. Deep transfer learning methods have advantages in detection tasks, because they can further improve the stability and accuracy of the detection model. Therefore, on the basis of deep transfer learning, we propose a new detection framework of tropical cyclones (NDFTC) from meteorological satellite images by combining the deep convolutional generative adversarial networks (DCGAN) and You Only Look Once (YOLO) v3 model. The algorithm process of NDFTC consists of three major steps: data augmentation, a pre-training phase, and transfer learning. First, to improve the utilization of finite data, DCGAN is used as the data augmentation method to generate images simulated to TCs. Second, to extract the salient characteristics of TCs, the generated images obtained from DCGAN are inputted into the detection model YOLOv3 in the pre-training phase. Furthermore, based on the network-based deep transfer learning method, we train the detection model with real images of TCs and its initial weights are transferred from the YOLOv3 trained with generated images. Training with real images helps to extract universal characteristics of TCs and using transferred weights as initial weights can improve the stability and accuracy of the model. The experimental results show that the NDFTC has a better performance, with an accuracy (ACC) of 97.78% and average precision (AP) of 81.39%, in comparison to the YOLOv3, with an ACC of 93.96% and AP of 80.64%. Full article
(This article belongs to the Special Issue Deep Learning and Computer Vision in Remote Sensing)
Show Figures

Graphical abstract

Article
Canopy Parameter Estimation of Citrus grandis var. Longanyou Based on LiDAR 3D Point Clouds
Remote Sens. 2021, 13(9), 1859; https://doi.org/10.3390/rs13091859 - 10 May 2021
Viewed by 440
Abstract
The characteristic parameters of Citrus grandis var. Longanyou canopies are important when measuring yield and spraying pesticides. However, the feasibility of the canopy reconstruction method based on point clouds has not been confirmed with these canopies. Therefore, LiDAR point cloud data for C. [...] Read more.
The characteristic parameters of Citrus grandis var. Longanyou canopies are important when measuring yield and spraying pesticides. However, the feasibility of the canopy reconstruction method based on point clouds has not been confirmed with these canopies. Therefore, LiDAR point cloud data for C. grandis var. Longanyou were obtained to facilitate the management of groves of this species. Then, a cloth simulation filter and European clustering algorithm were used to realize individual canopy extraction. After calculating canopy height and width, canopy reconstruction and volume calculation were realized using six approaches: by a manual method and using five algorithms based on point clouds (convex hull, CH; convex hull by slices; voxel-based, VB; alpha-shape, AS; alpha-shape by slices, ASBS). ASBS is an innovative algorithm that combines AS with slices optimization, and can best approximate the actual canopy shape. Moreover, the CH algorithm had the shortest run time, and the R2 values of VCH, VVB, VAS, and VASBS algorithms were above 0.87. The volume with the highest accuracy was obtained from the ASBS algorithm, and the CH algorithm had the shortest computation time. In addition, a theoretical but preliminarily system suitable for the calculation of the canopy volume of C. grandis var. Longanyou was developed, which provides a theoretical reference for the efficient and accurate realization of future functional modules such as accurate plant protection, orchard obstacle avoidance, and biomass estimation. Full article
(This article belongs to the Special Issue 3D Point Clouds for Agriculture Applications)
Show Figures

Graphical abstract

Article
Optical Remote Sensing Image Denoising and Super-Resolution Reconstructing Using Optimized Generative Network in Wavelet Transform Domain
Remote Sens. 2021, 13(9), 1858; https://doi.org/10.3390/rs13091858 - 10 May 2021
Viewed by 388
Abstract
High spatial quality (HQ) optical remote sensing images are very useful for target detection, target recognition and image classification. Due to the influence of imaging equipment accuracy and atmospheric environment, HQ images are difficult to acquire, while low spatial quality (LQ) remote sensing [...] Read more.
High spatial quality (HQ) optical remote sensing images are very useful for target detection, target recognition and image classification. Due to the influence of imaging equipment accuracy and atmospheric environment, HQ images are difficult to acquire, while low spatial quality (LQ) remote sensing images are very easy to acquire. Hence, denoising and super-resolution (SR) reconstruction technology are the most important solutions to improve the quality of remote sensing images very effectively, which can lower the cost as much as possible. Most existing methods usually only employ denoising or SR technology to obtain HQ images. However, due to the complex structure and the large noise of remote sensing images, the quality of the remote sensing image obtained only by denoising method or SR method cannot meet the actual needs. To address these problems, a method of reconstructing HQ remote sensing images based on Generative Adversarial Network (GAN) named “Restoration Generative Adversarial Network with ResNet and DenseNet” (RRDGAN) is proposed, which can acquire better quality images by incorporating denoising and SR into a unified framework. The generative network is implemented by fusing Residual Neural Network (ResNet) and Dense Convolutional Network (DenseNet) in order to consider denoising and SR problems at the same time. Then, total variation (TV) regularization is used to furthermore enhance the edge details, and the idea of Relativistic GAN is explored to make the whole network converge better. Our RRDGAN is implemented in wavelet transform (WT) domain, since different frequency parts could be handled separately in the wavelet domain. The experimental results on three different remote sensing datasets shows the feasibility of our proposed method in acquiring remote sensing images. Full article
(This article belongs to the Section Remote Sensing Image Processing)
Show Figures

Figure 1

Article
Develop of New Tools for 4D Monitoring: Case Study of Cliff in Apulia Region (Italy)
Remote Sens. 2021, 13(9), 1857; https://doi.org/10.3390/rs13091857 - 10 May 2021
Viewed by 435
Abstract
The monitoring of areas at risk is one of the topics of great interest in the scientific world in order to preserve natural areas of particular environmental value. The present work aims to develop a suitable survey and analysis methodology, in order to [...] Read more.
The monitoring of areas at risk is one of the topics of great interest in the scientific world in order to preserve natural areas of particular environmental value. The present work aims to develop a suitable survey and analysis methodology, in order to optimise multi-temporal processing. In particular, the phenomenon investigated the monitoring of cliffs in southern Apulia (Italy). To achieve this objective, different algorithms were tested and implemented in an in-house software called ICV. The implementation involved the use of different calculation procedures, combined and aimed at the analysis of the phenomenon in question. The validation of the experimentation was shown through the elaboration of a series of datasets of a particular area within the investigated coastline. Full article
(This article belongs to the Section Remote Sensing in Geology, Geomorphology and Hydrology)
Show Figures

Figure 1

Article
SNR-Based Water Height Retrieval in Rivers: Application to High Amplitude Asymmetric Tides in the Garonne River
Remote Sens. 2021, 13(9), 1856; https://doi.org/10.3390/rs13091856 - 10 May 2021
Viewed by 428
Abstract
Signal-to-noise ratio (SNR) time series acquired by a geodetic antenna were analyzed to retrieve water heights during asymmetric tides on a narrow river using the Interference Pattern Technique (IPT) from Global Navigation Satellite System Reflectometry (GNSS-R). The dynamic SNR method was selected because [...] Read more.
Signal-to-noise ratio (SNR) time series acquired by a geodetic antenna were analyzed to retrieve water heights during asymmetric tides on a narrow river using the Interference Pattern Technique (IPT) from Global Navigation Satellite System Reflectometry (GNSS-R). The dynamic SNR method was selected because the elevation rate of the reflecting surface during rising tides is high in the Garonne River with macro tidal conditions. A new process was developed to filter out the noise introduced by the environmental conditions on the reflected signal due to the narrowness of the river compared to the size of the Fresnel areas, the presence of vegetation on the river banks, and the presence of boats causing multiple reflections. This process involved the removal of multipeaks in the Lomb-Scargle Periodogram (LSP) output and an iterative least square estimation (LSE) of the output heights. Evaluation of the results was performed against pressure-derived water heights. The best results were obtained using all GNSS bands (L1, L2, and L5) simultaneously: R = 0.99, ubRMSD = 0.31 m. We showed that the quality of the retrieved heights was consistent, whatever the vertical velocity of the reflecting surface, and was highly dependent on the number of satellites visible. The sampling period of our solution was 1 min with a 5-min moving window, and no tide models or fit were used in the inversion process. This highlights the potential of the dynamic SNR method to detect and monitor extreme events with GNSS-R, including those affecting inland waters such as flash floods. Full article
(This article belongs to the Special Issue Radar Based Water Level Estimation)
Show Figures

Figure 1

Article
Airborne LiDAR-Derived Digital Elevation Model for Archaeology
Remote Sens. 2021, 13(9), 1855; https://doi.org/10.3390/rs13091855 - 10 May 2021
Viewed by 525
Abstract
The use of topographic airborne LiDAR data has become an essential part of archaeological prospection, and the need for an archaeology-specific data processing workflow is well known. It is therefore surprising that little attention has been paid to the key element of processing: [...] Read more.
The use of topographic airborne LiDAR data has become an essential part of archaeological prospection, and the need for an archaeology-specific data processing workflow is well known. It is therefore surprising that little attention has been paid to the key element of processing: an archaeology-specific DEM. Accordingly, the aim of this paper is to describe an archaeology-specific DEM in detail, provide a tool for its automatic precision assessment, and determine the appropriate grid resolution. We define an archaeology-specific DEM as a subtype of DEM, which is interpolated from ground points, buildings, and four morphological types of archaeological features. We introduce a confidence map (QGIS plug-in) that assigns a confidence level to each grid cell. This is primarily used to attach a confidence level to each archaeological feature, which is useful for detecting data bias in archaeological interpretation. Confidence mapping is also an effective tool for identifying the optimal grid resolution for specific datasets. Beyond archaeological applications, the confidence map provides clear criteria for segmentation, which is one of the unsolved problems of DEM interpolation. All of these are important steps towards the general methodological maturity of airborne LiDAR in archaeology, which is our ultimate goal. Full article
(This article belongs to the Special Issue Perspectives on Digital Elevation Model Applications)
Show Figures

Figure 1

Article
Small Object Detection in Remote Sensing Images with Residual Feature Aggregation-Based Super-Resolution and Object Detector Network
Remote Sens. 2021, 13(9), 1854; https://doi.org/10.3390/rs13091854 - 10 May 2021
Viewed by 490
Abstract
This paper deals with detecting small objects in remote sensing images from satellites or any aerial vehicle by utilizing the concept of image super-resolution for image resolution enhancement using a deep-learning-based detection method. This paper provides a rationale for image super-resolution for small [...] Read more.
This paper deals with detecting small objects in remote sensing images from satellites or any aerial vehicle by utilizing the concept of image super-resolution for image resolution enhancement using a deep-learning-based detection method. This paper provides a rationale for image super-resolution for small objects by improving the current super-resolution (SR) framework by incorporating a cyclic generative adversarial network (GAN) and residual feature aggregation (RFA) to improve detection performance. The novelty of the method is threefold: first, a framework is proposed, independent of the final object detector used in research, i.e., YOLOv3 could be replaced with Faster R-CNN or any object detector to perform object detection; second, a residual feature aggregation network was used in the generator, which significantly improved the detection performance as the RFA network detected complex features; and third, the whole network was transformed into a cyclic GAN. The image super-resolution cyclic GAN with RFA and YOLO as the detection network is termed as SRCGAN-RFA-YOLO, which is compared with the detection accuracies of other methods. Rigorous experiments on both satellite images and aerial images (ISPRS Potsdam, VAID, and Draper Satellite Image Chronology datasets) were performed, and the results showed that the detection performance increased by using super-resolution methods for spatial resolution enhancement; for an IoU of 0.10, AP of 0.7867 was achieved for a scale factor of 16. Full article
(This article belongs to the Special Issue Convolutional Neural Networks for Object Detection)
Show Figures

Graphical abstract

Article
Sequence Image Datasets Construction via Deep Convolution Networks
Remote Sens. 2021, 13(9), 1853; https://doi.org/10.3390/rs13091853 - 10 May 2021
Viewed by 504
Abstract
Remote-sensing time-series datasets are significant for global change research and a better understanding of the Earth. However, remote-sensing acquisitions often provide sparse time series due to sensor resolution limitations and environmental factors such as cloud noise for optical data. Image transformation is the [...] Read more.
Remote-sensing time-series datasets are significant for global change research and a better understanding of the Earth. However, remote-sensing acquisitions often provide sparse time series due to sensor resolution limitations and environmental factors such as cloud noise for optical data. Image transformation is the method that is often used to deal with this issue. This paper considers the deep convolution networks to learn the complex mapping between sequence images, called adaptive filter generation network (AdaFG), convolution long short-term memory network (CLSTM), and cycle-consistent generative adversarial network (CyGAN) for construction of sequence image datasets. AdaFG network uses a separable 1D convolution kernel instead of 2D kernels to capture the spatial characteristics of input sequence images and then is trained end-to-end using sequence images. CLSTM network can map between different images using the state information of multiple time-series images. CyGAN network can map an image from a source domain to a target domain without additional information. Our experiments, which were performed with unmanned aerial vehicle (UAV) and Landsat-8 datasets, show that the deep convolution networks are effective to produce high-quality time-series image datasets, and the data-driven deep convolution networks can better simulate complex and diverse nonlinear data information. Full article
Show Figures

Graphical abstract

Technical Note
Day and Night Clouds Detection Using a Thermal-Infrared All-Sky-View Camera
Remote Sens. 2021, 13(9), 1852; https://doi.org/10.3390/rs13091852 - 10 May 2021
Viewed by 381
Abstract
The formation and evolution of clouds are associated with their thermodynamical and microphysical progress. Previous studies have been conducted to collect images using ground-based cloud observation equipment to provide important cloud characteristics information. However, most of this equipment cannot perform continuous observations during [...] Read more.
The formation and evolution of clouds are associated with their thermodynamical and microphysical progress. Previous studies have been conducted to collect images using ground-based cloud observation equipment to provide important cloud characteristics information. However, most of this equipment cannot perform continuous observations during the day and night, and their field of view (FOV) is also limited. To address these issues, this work proposes a day and night clouds detection approach integrated into a self-made thermal-infrared (TIR) all-sky-view camera. The TIR camera consists of a high-resolution thermal microbolometer array and a fish-eye lens with a FOV larger than 160°. In addition, a detection scheme was designed to directly subtract the contamination of the atmospheric TIR emission from the entire infrared image of such a large FOV, which was used for cloud recognition. The performance of this scheme was validated by comparing the cloud fractions retrieved from the infrared channel with those from the visible channel and manual observation. The results indicated that the current instrument could obtain accurate cloud fraction from the observed infrared image, and the TIR all-sky-view camera developed in this work exhibits good feasibility for long-term and continuous cloud observation. Full article
Show Figures

Graphical abstract

Article
Monitoring Terrestrial Water Storage Changes with the Tongji-Grace2018 Model in the Nine Major River Basins of the Chinese Mainland
Remote Sens. 2021, 13(9), 1851; https://doi.org/10.3390/rs13091851 - 10 May 2021
Viewed by 371
Abstract
Data from the Gravity Recovery and Climate Experiment (GRACE) satellite mission can be used to monitor changes in terrestrial water storage (TWS). In this study, we exploit the TWS observations from a new temporal gravity field model, Tongji-Grace2018, which was developed using an [...] Read more.
Data from the Gravity Recovery and Climate Experiment (GRACE) satellite mission can be used to monitor changes in terrestrial water storage (TWS). In this study, we exploit the TWS observations from a new temporal gravity field model, Tongji-Grace2018, which was developed using an optimized short-arc approach at Tongji University. We analyzed the changes in the TWS and groundwater storage (GWS) in each of the nine major river basins of the Chinese mainland from April 2002 to August 2016, using Tongji-Grace2018, the Global Land Data Assimilation System (GLDAS) hydrological model, in situ observations, and additional auxiliary data (such as precipitation and temperature). Our results indicate that the TWS of the Songliao, Yangtze, Pearl, and Southeastern River Basins are all increasing, with the most drastic TWS growth occurring in the Southeastern River Basin. The TWS of the Yellow, Haihe, Huaihe, and Southwestern River Basins are all decreasing, with the most drastic TWS loss occurring in the Haihe River Basin. The Continental River Basin TWS has remained largely unchanged over time. With the exception of the Songliao and Pearl River Basins, the GWS results produced by the Tongji-Grace2018 model are consistent with the in situ observations of these basins. The correlation coefficients for the Tongji-Grace2018 model results and the in situ observations for the Yellow, Huaihe, Yangtze, Southwestern, and Continental River Basins are higher than 0.710. Overall, the GWS results for the Songliao, Yellow, Haihe, Huaihe, Southwestern, and Continental River Basins all exhibit a downward trend, with the most severe groundwater loss occurring in the Haihe and Huaihe River Basins. However, the Yangtze and Southeastern River Basins both have upward-trending modeled and measured GWS values. This study demonstrates the effectiveness of the Tongji-Grace2018 model for the reliable estimation of TWS and GWS changes on the Chinese mainland, and may contribute to the management of available water resources. Full article
(This article belongs to the Special Issue Terrestrial Hydrology Using GRACE and GRACE-FO)
Show Figures

Figure 1

Article
Towards the Spectral Mapping of Plastic Debris on Beaches
Remote Sens. 2021, 13(9), 1850; https://doi.org/10.3390/rs13091850 - 10 May 2021
Viewed by 674
Abstract
Floating and washed ashore marine plastic debris (MPD) is a growing environmental challenge. It has become evident that secluded locations including the Arctic, Antarctic, and remote islands are being impacted by plastic pollution generated thousands of kilometers away. Optical remote sensing of MPD [...] Read more.
Floating and washed ashore marine plastic debris (MPD) is a growing environmental challenge. It has become evident that secluded locations including the Arctic, Antarctic, and remote islands are being impacted by plastic pollution generated thousands of kilometers away. Optical remote sensing of MPD is an emerging field that can aid in monitoring remote environments where in-person observation and data collection is not always feasible. Here we evaluate MPD spectral features in the visible to shortwave infrared regions for detecting varying quantities of MPD that have accumulated on beaches using a spectroradiometer. Measurements were taken from a range of in situ MPD accumulations ranging from 0.08% to 7.94% surface coverage. Our results suggest that spectral absorption features at 1215 nm and 1732 nm are useful for detecting varying abundance levels of MPD in a complex natural environment, however other absorption features at 931 nm, 1045 nm and 2046 nm could not detect in situ MPD. The reflectance of some in situ MPD accumulations was statistically different from samples that only contained organic debris and sand between 1.56% and 7.94% surface cover; however other samples with similar surface cover did not have reflectance that was statistically different from samples containing no MPD. Despite MPD being detectable against a background of sand and organic beach debris, a clear relationship between the surface cover of MPD and the strength of key absorption features could not be established. Additional research is needed to advance our understanding of the factors, such as type of MPD assemblage, that contribute to the bulk reflectance of MPD contaminated landscapes. Full article
(This article belongs to the Section Ocean Remote Sensing)
Show Figures

Figure 1

Article
Evaluation of Light Pollution in Global Protected Areas from 1992 to 2018
Remote Sens. 2021, 13(9), 1849; https://doi.org/10.3390/rs13091849 - 09 May 2021
Viewed by 708
Abstract
Light pollution, a phenomenon in which artificial nighttime light (NTL) changes the form of brightness and darkness in natural areas such as protected areas (PAs), has become a global concern due to its threat to global biodiversity. With ongoing global urbanization and climate [...] Read more.
Light pollution, a phenomenon in which artificial nighttime light (NTL) changes the form of brightness and darkness in natural areas such as protected areas (PAs), has become a global concern due to its threat to global biodiversity. With ongoing global urbanization and climate change, the light pollution status in global PAs deserves attention for mitigation and adaptation. In this study, we developed a framework to evaluate the light pollution status in global PAs, using the global NTL time series data. First, we classified global PAs (30,624) into three pollution categories: non-polluted (5974), continuously polluted (8141), and discontinuously polluted (16,509), according to the time of occurrence of lit pixels in/around PAs from 1992 to 2018. Then, we explored the NTL intensity (e.g., digital numbers) and its trend in those polluted PAs and identified those hotspots of PAs at the global scale with consideration of global urbanization. Our study shows that global light pollution is mainly distributed within the range of 30°N and 60°N, including Europe, north America, and East Asia. Although the temporal trend of NTL intensity in global PAs is increasing, Japan and the United States of America (USA) have opposite trends due to the implementation of well-planned ecological conservation policies and declining population growth. For most polluted PAs, the lit pixels are close to their boundaries (i.e., less than 10 km), and the NTL in/around these lit areas has become stronger over the past decades. The identified hotspots of PAs (e.g., Europe, the USA, and East Asia) help support decisions on global biodiversity conservation, particularly with global urbanization and climate change. Full article
(This article belongs to the Special Issue Light Pollution Monitoring Using Remote Sensing Data)
Show Figures

Graphical abstract

Article
Estimation of Long-Term Surface Downward Longwave Radiation over the Global Land from 2000 to 2018
Remote Sens. 2021, 13(9), 1848; https://doi.org/10.3390/rs13091848 - 09 May 2021
Viewed by 444
Abstract
It is of great importance for climate change studies to construct a worldwide, long-term surface downward longwave radiation (Ld, 4–100 μm) dataset. Although a number of global Ld datasets are available, their low accuracies and coarse spatial resolutions limit [...] Read more.
It is of great importance for climate change studies to construct a worldwide, long-term surface downward longwave radiation (Ld, 4–100 μm) dataset. Although a number of global Ld datasets are available, their low accuracies and coarse spatial resolutions limit their applications. This study generated a daily Ld dataset with a 5-km spatial resolution over the global land surface from 2000 to 2018 using atmospheric parameters, which include 2-m air temperature (Ta), relative humidity (RH) at 1000 hPa, total column water vapor (TCWV), surface downward shortwave radiation (Sd), and elevation, based on the gradient boosting regression tree (GBRT) method. The generated Ld dataset was evaluated using ground measurements collected from AmeriFlux, AsiaFlux, baseline surface radiation network (BSRN), surface radiation budget network (SURFRAD), and FLUXNET networks. The validation results showed that the root mean square error (RMSE), mean bias error (MBE), and correlation coefficient (R) values of the generated daily Ld dataset were 17.78 W m−2, 0.99 W m−2, and 0.96 (p < 0.01). Comparisons with other global land surface radiation products indicated that the generated Ld dataset performed better than the clouds and earth’s radiant energy system synoptic (CERES-SYN) edition 4.1 dataset and ERA5 reanalysis product at the selected sites. In addition, the analysis of the spatiotemporal characteristics for the generated Ld dataset showed an increasing trend of 1.8 W m−2 per decade (p < 0.01) from 2003 to 2018, which was closely related to Ta and water vapor pressure. In general, the generated Ld dataset has a higher spatial resolution and accuracy, which can contribute to perfect the existing radiation products. Full article
(This article belongs to the Special Issue Advances on Land–Ocean Heat Fluxes Using Remote Sensing)
Show Figures

Graphical abstract

Article
Comparing PlanetScope to Landsat-8 and Sentinel-2 for Sensing Water Quality in Reservoirs in Agricultural Watersheds
Remote Sens. 2021, 13(9), 1847; https://doi.org/10.3390/rs13091847 - 09 May 2021
Viewed by 808
Abstract
Agricultural runoff transports sediments and nutrients that deteriorate water quality erratically, posing a challenge to ground-based monitoring. Satellites provide data at spatial-temporal scales that can be used for water quality monitoring. PlanetScope nanosatellites have spatial (3 m) and temporal (daily) resolutions that may [...] Read more.
Agricultural runoff transports sediments and nutrients that deteriorate water quality erratically, posing a challenge to ground-based monitoring. Satellites provide data at spatial-temporal scales that can be used for water quality monitoring. PlanetScope nanosatellites have spatial (3 m) and temporal (daily) resolutions that may help improve water quality monitoring compared to coarser-resolution satellites. This work compared PlanetScope to Landsat-8 and Sentinel-2 in their ability to detect key water quality parameters. Spectral bands of each satellite were regressed against chlorophyll a, turbidity, and Secchi depth data from 13 reservoirs in Oklahoma over three years (2017–2020). We developed significant regression models for each satellite. Landsat-8 and Sentinel-2 explained more variation in chlorophyll a than PlanetScope, likely because they have more spectral bands. PlanetScope and Sentinel-2 explained relatively similar amounts of variations in turbidity and Secchi Disk data, while Landsat-8 explained less variation in these parameters. Since PlanetScope is a commercial satellite, its application may be limited to cases where the application of coarser-resolution satellites is not feasible. We identified scenarios where PS may be more beneficial than Landsat-8 and Sentinel-2. These include measuring water quality parameters that vary daily, in small ponds and narrow coves of reservoirs, and at reservoir edges. Full article
(This article belongs to the Special Issue Remote Sensing for Water Resources Assessment in Agriculture)
Show Figures

Figure 1

Article
Identifying Spatial and Temporal Variations in Concrete Bridges with Ground Penetrating Radar Attributes
Remote Sens. 2021, 13(9), 1846; https://doi.org/10.3390/rs13091846 - 09 May 2021
Viewed by 453
Abstract
Estimating variations in material properties over space and time is essential for the purposes of structural health monitoring (SHM), mandated inspection, and insurance of civil infrastructure. Properties such as compressive strength evolve over time and are reflective of the overall condition of the [...] Read more.
Estimating variations in material properties over space and time is essential for the purposes of structural health monitoring (SHM), mandated inspection, and insurance of civil infrastructure. Properties such as compressive strength evolve over time and are reflective of the overall condition of the aging infrastructure. Concrete structures pose an additional challenge due to the inherent spatial variability of material properties over large length scales. In recent years, nondestructive approaches such as rebound hammer and ultrasonic velocity have been used to determine the in situ material properties of concrete with a focus on the compressive strength. However, these methods require personnel expertise, careful data collection, and high investment. This paper presents a novel approach using ground penetrating radar (GPR) to estimate the variability of in situ material properties over time and space for assessment of concrete bridges. The results show that attributes (or features) of the GPR data such as raw average amplitudes can be used to identify differences in compressive strength across the deck of a concrete bridge. Attributes such as instantaneous amplitudes and intensity of reflected waves are useful in predicting the material properties such as compressive strength, porosity, and density. For compressive strength, one alternative approach of the Maturity Index (MI) was used to estimate the present values and compare with GPR estimated values. The results show that GPR attributes could be successfully used for identifying spatial and temporal variation of concrete properties. Finally, discussions are presented regarding their suitability and limitations for field applications. Full article
(This article belongs to the Special Issue Trends in GPR and Other NDTs for Transport Infrastructure Assessment)
Show Figures

Graphical abstract

Article
Quantifying the Response of German Forests to Drought Events via Satellite Imagery
Remote Sens. 2021, 13(9), 1845; https://doi.org/10.3390/rs13091845 - 09 May 2021
Viewed by 713
Abstract
Forest systems provide crucial ecosystem functions to our environment, such as balancing carbon stocks and influencing the local, regional and global climate. A trend towards an increasing frequency of climate change induced extreme weather events, including drought, is hereby a major challenge for [...] Read more.
Forest systems provide crucial ecosystem functions to our environment, such as balancing carbon stocks and influencing the local, regional and global climate. A trend towards an increasing frequency of climate change induced extreme weather events, including drought, is hereby a major challenge for forest management. Within this context, the application of remote sensing data provides a powerful means for fast, operational and inexpensive investigations over large spatial scales and time. This study was dedicated to explore the potential of satellite data in combination with harmonic analyses for quantifying the vegetation response to drought events in German forests. The harmonic modelling method was compared with a z-score standardization approach and correlated against both, meteorological and topographical data. Optical satellite imagery from Landsat and the Moderate Resolution Imaging Spectroradiometer (MODIS) was used in combination with three commonly applied vegetation indices. Highest correlation scores based on the harmonic modelling technique were computed for the 6th harmonic degree. MODIS imagery in combination with the Normalized Difference Vegetation Index (NDVI) generated hereby best results for measuring spectral response to drought conditions. Strongest correlation between remote sensing data and meteorological measures were observed for soil moisture and the self-calibrated Palmer Drought Severity Index (scPDSI). Furthermore, forests regions over sandy soils with pine as the dominant tree type were identified to be particularly vulnerable to drought. In addition, topographical analyses suggested mitigated drought affects along hill slopes. While the proposed approaches provide valuable information about vegetation dynamics as a response to meteorological weather conditions, standardized in-situ measurements over larger spatial scales and related to drought quantification are required for further in-depth quality assessment of the used methods and data. Full article
(This article belongs to the Section Forest Remote Sensing)
Show Figures

Graphical abstract

Article
Terrain Proxy-Based Site Classification for Seismic Zonation in North Korea within a Geospatial Data-Driven Workflow
Remote Sens. 2021, 13(9), 1844; https://doi.org/10.3390/rs13091844 - 09 May 2021
Viewed by 520
Abstract
Numerous seismic activities occur in North Korea. However, it is difficult to perform seismic hazard assessment and obtain zonal data in the Korean Peninsula, including North Korea, when applying parametric or nonparametric methods. Remote sensing can be implemented for soil characterization or spatial [...] Read more.
Numerous seismic activities occur in North Korea. However, it is difficult to perform seismic hazard assessment and obtain zonal data in the Korean Peninsula, including North Korea, when applying parametric or nonparametric methods. Remote sensing can be implemented for soil characterization or spatial zonation studies on irregular, surficial, and subsurface systems of inaccessible areas. Herein, a data-driven workflow for extracting the principal features using a digital terrain model (DTM) is proposed. In addition, geospatial grid information containing terrain features and the average shear wave velocity in the top 30 m of the subsurface (VS30) are employed using geostatistical interpolation methods; machine learning (ML)-based regression models were optimized and VS30-based seismic zonation in the test areas in North Korea were forecasted. The interrelationships between VS30 and terrain proxy (elevation, slope, and landform class) in the training area in South Korea were verified to define the input layer in regression models. The landform class represents a new proxy of VS30 and was subgrouped according to the correlation with grid-based VS30. The geospatial grid information was generated via the optimum geostatistical interpolation method (i.e., sequential Gaussian simulation (SGS)). The best-fitting model among four ML methods was determined by evaluating cost function-based prediction performance, performing uncertainty analysis for the empirical correlations of VS30, and studying spatial correspondence with the borehole-based VS30 map. Subsequently, the best-fitting regression models were designed by training the geospatial grid in South Korea. Then, DTM and its terrain features were constructed along with VS30 maps for three major cities (Pyongyang, Kaesong, and Nampo) in North Korea. A similar distribution of the VS30 grid obtained using SGS was shown in the multilayer perceptron-based VS30 map. Full article
Show Figures

Figure 1

Article
Distribution and Attribution of Terrestrial Snow Cover Phenology Changes over the Northern Hemisphere during 2001–2020
Remote Sens. 2021, 13(9), 1843; https://doi.org/10.3390/rs13091843 - 09 May 2021
Viewed by 410
Abstract
Snow cover phenology has exhibited dramatic changes in the past decades. However, the distribution and attribution of the hemispheric scale snow cover phenology anomalies remain unclear. Using satellite-retrieved snow cover products, ground observations, and reanalysis climate variables, this study explored the distribution and [...] Read more.
Snow cover phenology has exhibited dramatic changes in the past decades. However, the distribution and attribution of the hemispheric scale snow cover phenology anomalies remain unclear. Using satellite-retrieved snow cover products, ground observations, and reanalysis climate variables, this study explored the distribution and attribution of snow onset date, snow end date, and snow duration days over the Northern Hemisphere from 2001 to 2020. The latitudinal and altitudinal distributions of the 20-year averaged snow onset date, snow end date, and snow duration days are well represented by satellite-retrieved snow cover phenology matrixes. The validation results by using 850 ground snow stations demonstrated that satellite-retrieved snow cover phenology matrixes capture the spatial variability of the snow onset date, snow end date, and snow duration days at the 95% significance level during the overlapping period of 2001–2017. Moreover, a delayed snow onset date and an earlier snow end date (1.12 days decade−1, p < 0.05) are detected over the Northern Hemisphere during 2001–2020 based on the satellite-retrieved snow cover phenology matrixes. In addition, the attribution analysis indicated that snow end date dominates snow cover phenology changes and that an increased melting season temperature is the key driving factor of snow end date anomalies over the NH during 2001–2020. These results are helpful in understanding recent snow cover change and can contribute to climate projection studies. Full article
Show Figures

Figure 1

Article
Analyzing the Performance of GPS Data for Earthquake Prediction
Remote Sens. 2021, 13(9), 1842; https://doi.org/10.3390/rs13091842 - 09 May 2021
Viewed by 568
Abstract
The results of earthquake prediction largely depend on the quality of data and the methods of their joint processing. At present, for a number of regions, it is possible, in addition to data from earthquake catalogs, to use space geodesy data obtained with [...] Read more.
The results of earthquake prediction largely depend on the quality of data and the methods of their joint processing. At present, for a number of regions, it is possible, in addition to data from earthquake catalogs, to use space geodesy data obtained with the help of GPS. The purpose of our study is to evaluate the efficiency of using the time series of displacements of the Earth’s surface according to GPS data for the systematic prediction of earthquakes. The criterion of efficiency is the probability of successful prediction of an earthquake with a limited size of the alarm zone. We use a machine learning method, namely the method of the minimum area of alarm, to predict earthquakes with a magnitude greater than 6.0 and a hypocenter depth of up to 60 km, which occurred from 2016 to 2020 in Japan, and earthquakes with a magnitude greater than 5.5. and a hypocenter depth of up to 60 km, which happened from 2013 to 2020 in California. For each region, we compare the following results: random forecast of earthquakes, forecast obtained with the field of spatial density of earthquake epicenters, forecast obtained with spatio-temporal fields based on GPS data, based on seismological data, and based on combined GPS data and seismological data. The results confirm the effectiveness of using GPS data for the systematic prediction of earthquakes. Full article
Show Figures

Graphical abstract

Communication
Impact of Assimilating FY-3D MWTS-2 Upper Air Sounding Data on Forecasting Typhoon Lekima (2019)
Remote Sens. 2021, 13(9), 1841; https://doi.org/10.3390/rs13091841 - 09 May 2021
Viewed by 381
Abstract
In this study, the Fengyun-3D (FY-3D) clear-sky microwave temperature sounder-2 (MWTS-2) radiances were directly assimilated in the regional mesoscale Weather Research and Forecasting (WRF) model using the Gridpoint Statistical Interpolation (GSI) data assimilation system. The assimilation experiments were conducted to compare the track [...] Read more.
In this study, the Fengyun-3D (FY-3D) clear-sky microwave temperature sounder-2 (MWTS-2) radiances were directly assimilated in the regional mesoscale Weather Research and Forecasting (WRF) model using the Gridpoint Statistical Interpolation (GSI) data assimilation system. The assimilation experiments were conducted to compare the track errors of typhoon Lekima from uses of the Advanced Microwave Sounding Unit-A (AMSU-A) radiances (EXP_AD) with those from FY-3D MWTS-2 upper-air sounding data at channels 5–7 (EXP_AMD). The clear-sky mean bias-corrected observation-minus-background (O-B) values of FY-3D MWTS-2 channels 5, 6, and 7 are 0.27, 0.10 and 0.57 K, respectively, which are smaller than those without bias corrections. Compared with the control experiment, which was the forecast of the WRF model without use of satellite data, the assimilation of satellite radiances can improve the forecast performance and reduce the mean track error by 8.7% (~18.4 km) and 30% (~58.6 km) beyond 36 h through the EXP_AD and EXP_AMD, respectively. The direction of simulated steering flow changed from southwest in the EXP_AD to southeast in the EXP_AMD, which can be pivotal to forecasting the landfall of typhoon Lekima (2019) three days in advance. Assimilation of MWTS-2 upper-troposphere channels 5–7 has great potential to improve the track forecasts for typhoon Lekima. Full article
(This article belongs to the Section Environmental Remote Sensing)
Show Figures

Figure 1

Article
The Intra-Tidal Characteristics of Tidal Front and Their Spring–Neap Tidal and Seasonal Variations in Bungo Channel, Japan
Remote Sens. 2021, 13(9), 1840; https://doi.org/10.3390/rs13091840 - 09 May 2021
Viewed by 399
Abstract
The intra-tidal variations of a tidal front in Bungo Channel, Japan and their dependence on the spring–neap tidal cycle and month were analyzed utilizing high-resolution (~2 km) hourly sea surface temperature (SST) data obtained from a Himawari-8 geostationary satellite from April 2016 to [...] Read more.
The intra-tidal variations of a tidal front in Bungo Channel, Japan and their dependence on the spring–neap tidal cycle and month were analyzed utilizing high-resolution (~2 km) hourly sea surface temperature (SST) data obtained from a Himawari-8 geostationary satellite from April 2016 to August 2020. A gradient-based front detection method was utilized to define the position and intensity of the front. Similar to previous ship-based studies, SST data were utilized to identify tidal fronts between a well-mixed strait and its surrounding stratified area. The hourly SST data confirmed the theoretical intra-tidal movement of the tidal front, which is mainly controlled by tidal current advection. Notably, the intensity of the front increases during the ebb current phase, which carries the front toward the stratified area, but decreases during the flood current phase that drives the front in the opposite direction. Due to a strong dependence on tidal currents, the intra-tidal variations appear in a fortnight cycle, and the fortnightly variations of the front are dependent on the month in which the background stratification and residual current changes occur. Additionally, tidal current convergence and divergence are posited to cause tidal front intensification and weakening. Full article
Show Figures

Figure 1

Communication
Seasonal Trends in Movement Patterns of Birds and Insects Aloft Simultaneously Recorded by Radar
Remote Sens. 2021, 13(9), 1839; https://doi.org/10.3390/rs13091839 - 09 May 2021
Viewed by 590
Abstract
Airspace is a key but not well-understood habitat for many animal species. Enormous amounts of insects and birds use the airspace to forage, disperse, and migrate. Despite numerous studies on migration, the year-round flight activities of both birds and insects are still poorly [...] Read more.
Airspace is a key but not well-understood habitat for many animal species. Enormous amounts of insects and birds use the airspace to forage, disperse, and migrate. Despite numerous studies on migration, the year-round flight activities of both birds and insects are still poorly studied. We used a 2 year dataset from a vertical-looking radar in Central Europe and developed an iterative hypothesis-testing algorithm to investigate the general temporal pattern of migratory and local movements. We estimated at least 3 million bird and 20 million insect passages over a 1 km transect annually. Most surprisingly, peak non-directional bird movement intensities during summer were of the same magnitude as seasonal directional movement peaks. Birds showed clear peaks in seasonally directional movements during day and night, coinciding well with the main migration period documented in this region. Directional insect movements occurred throughout the year, paralleling non-directional movements. In spring and summer, insect movements were non-directional; in autumn, their movements concentrated toward the southwest, similar to birds. Notably, the nocturnal movements of insects did not appear until April, while directional movements mainly occurred in autumn. This simple monitoring reveals how little we still know about the movement of biomass through airspace. Full article
(This article belongs to the Section Ecological Remote Sensing)
Show Figures

Graphical abstract

Article
Assessing the Accuracy of ALOS/PALSAR-2 and Sentinel-1 Radar Images in Estimating the Land Subsidence of Coastal Areas: A Case Study in Alexandria City, Egypt
Remote Sens. 2021, 13(9), 1838; https://doi.org/10.3390/rs13091838 - 09 May 2021
Cited by 1 | Viewed by 1051
Abstract
Recently, the Differential Interferometric Synthetic Aperture Radar (DInSAR) technique is widely used for quantifying the land surface deformation, which is very important to assess the potential impact on social and economic activities. Radar satellites operate in different wavelengths and each provides different levels [...] Read more.
Recently, the Differential Interferometric Synthetic Aperture Radar (DInSAR) technique is widely used for quantifying the land surface deformation, which is very important to assess the potential impact on social and economic activities. Radar satellites operate in different wavelengths and each provides different levels of vertical displacement accuracy. In this study, the accuracies of Sentinel-1 (C-band) and ALOS/PALSAR-2 (L-band) were investigated in terms of estimating the land subsidence rate along the study area of Alexandria City, Egypt. A total of nine Sentinel-1 and 11 ALOS/PALSAR-2 scenes were used for such assessment. The small baseline subset (SBAS) processing scheme, which detects the land deformation with a high spatial and temporal coverage, was performed. The results show that the threshold coherence values of the generated interferograms from ALOS-2 data are highly concentrated between 0.2 and 0.3, while a higher threshold value of 0.4 shows no coherent pixels for about 80% of Alexandria’s urban area. However, the coherence values of Sentinel-1 interferograms ranged between 0.3 and 1, with most of the urban area in Alexandria showing coherent pixels at a 0.4 value. In addition, both data types produced different residual topography values of almost 0 m with a standard deviation of 13.5 m for Sentinel-1 and −20.5 m with a standard deviation of 33.24 m for ALOS-2 using the same digital elevation model (DEM) and wavelet number. Consequently, the final deformation was estimated using high coherent pixels with a threshold of 0.4 for Sentinel-1, which is comparable to a threshold of about 0.8 when using ALOS-2 data. The cumulative vertical displacement along the study area from 2017 to 2020 reached −60 mm with an average of −12.5 mm and mean displacement rate of −1.73 mm/year. Accordingly, the Alexandrian coastal plain and city center are found to be relatively stable, with land subsidence rates ranging from 0 to −5 mm/year. The maximum subsidence rate reached −20 mm/year and was found along the boundary of Mariout Lakes and former Abu Qir Lagoon. Finally, the affected buildings recorded during the field survey were plotted on the final land subsidence maps and show high consistency with the DInSAR results. For future developmental urban plans in Alexandria City, it is recommended to expand towards the western desert fringes instead of the south where the present-day ground lies on top of the former wetland areas. Full article
(This article belongs to the Special Issue ALOS-2/PALSAR-2 Calibration, Validation, Science and Applications)
Show Figures

Figure 1

Article
Towards Vine Water Status Monitoring on a Large Scale Using Sentinel-2 Images
Remote Sens. 2021, 13(9), 1837; https://doi.org/10.3390/rs13091837 - 09 May 2021
Viewed by 477
Abstract
Wine growing needs to adapt to confront climate change. In fact, the lack of water becomes more and more important in many regions. Whereas vineyards have been located in dry areas for decades, so they need special resilient varieties and/or a sufficient water [...] Read more.
Wine growing needs to adapt to confront climate change. In fact, the lack of water becomes more and more important in many regions. Whereas vineyards have been located in dry areas for decades, so they need special resilient varieties and/or a sufficient water supply at key development stages in case of severe drought. With climate change and the decrease of water availability, some vineyard regions face difficulties because of unsuitable variety, wrong vine management or due to the limited water access. Decision support tools are therefore required to optimize water use or to adapt agronomic practices. This study aimed at monitoring vine water status at a large scale with Sentinel-2 images. The goal was to provide a solution that would give spatialized and temporal information throughout the season on the water status of the vines. For this purpose, thirty six plots were monitored in total over three years (2018, 2019 and 2020). Vine water status was measured with stem water potential in field measurements from pea size to ripening stage. Simultaneously Sentinel-2 images were downloaded and processed to extract band reflectance values and compute vegetation indices. In our study, we tested five supervised regression machine learning algorithms to find possible relationships between stem water potential and data acquired from Sentinel-2 images (bands reflectance values and vegetation indices). Regression model using Red, NIR, Red-Edge and SWIR bands gave promising result to predict stem water potential (R2=0.40, RMSE=0.26). Full article
(This article belongs to the Special Issue Remote and Proximal Sensing for Precision Agriculture and Viticulture)
Show Figures

Graphical abstract

Article
Determination of Key Phenological Phases of Winter Wheat Based on the Time-Weighted Dynamic Time Warping Algorithm and MODIS Time-Series Data
Remote Sens. 2021, 13(9), 1836; https://doi.org/10.3390/rs13091836 - 08 May 2021
Viewed by 425
Abstract
Accurate determination of phenological information of crops is essential for field management and decision-making. Remote sensing time-series data are widely used for extracting phenological phases. Existing methods mainly extract phenological phases directly from individual remote sensing time-series, which are easily affected by clouds, [...] Read more.
Accurate determination of phenological information of crops is essential for field management and decision-making. Remote sensing time-series data are widely used for extracting phenological phases. Existing methods mainly extract phenological phases directly from individual remote sensing time-series, which are easily affected by clouds, noise, and mixed pixels. This paper proposes a novel method of phenological phase extraction based on the time-weighted dynamic time warping (TWDTW) algorithm using MODIS Normalized Difference Vegetation Index (NDVI) 5-day time-series data with a spatial resolution of 500 m. Firstly, based on the phenological differences between winter wheat and other land cover types, winter wheat distribution is extracted using the TWDTW classification method, and the results show that the overall classification accuracy and Kappa coefficient reach 94.74% and 0.90, respectively. Then, we extract the pure winter-wheat pixels using a method based on the coefficient of variation, and use these pixels to generate the average phenological curve. Next, the difference between each winter-wheat phenological curve and the average winter-wheat phenological curve is quantitatively calculated using the TWDTW algorithm. Finally, the key phenological phases of winter wheat in the study area, namely, the green-up date (GUD), heading date (HD), and maturity date (MD), are determined. The results show that the phenological phase extraction using the TWDTW algorithm has high accuracy. By verification using phenological station data from the Meteorological Data Sharing Service System of China, the root mean square errors (RMSEs) of the GUD, HD, and MD are found to be 9.76, 5.72, and 6.98 days, respectively. Additionally, the method proposed in this article is shown to have a better extraction performance compared with several other methods. Furthermore, it is shown that, in Hebei Province, the GUD, HD, and MD are mainly affected by latitude and accumulated temperature. As the latitude increases from south to north, the GUD, HD, and MD are delayed, and for each 1° increment in latitude, the GUD, HD, and MD are delayed by 4.84, 5.79, and 6.61 days, respectively. The higher the accumulated temperature, the earlier the phenological phases occur. However, latitude and accumulated temperature have little effect on the length of the phenological phases. Additionally, the lengths of time between GUD and HD, HD and MD, and GUD and MD are stable at 46, 41, and 87 days, respectively. Overall, the proposed TWDTW method can accurately determine the key phenological phases of winter wheat at a regional scale using remote sensing time-series data. Full article
(This article belongs to the Special Issue Remote Sensing and Decision Support for Precision Orchard Production)
Show Figures

Figure 1

Article
Multi-Dimensional Drought Assessment in Abbay/Upper Blue Nile Basin: The Importance of Shared Management and Regional Coordination Efforts for Mitigation
Remote Sens. 2021, 13(9), 1835; https://doi.org/10.3390/rs13091835 - 08 May 2021
Viewed by 386
Abstract
Drought is one of the least understood and complex natural hazards often characterized by a significant decrease in water availability for a prolonged period. It can be manifested in one or more forms as meteorological, agricultural, hydrological, and/or socio-economic drought. The overarching objective [...] Read more.
Drought is one of the least understood and complex natural hazards often characterized by a significant decrease in water availability for a prolonged period. It can be manifested in one or more forms as meteorological, agricultural, hydrological, and/or socio-economic drought. The overarching objective of this study is to demonstrate and characterize the different forms of droughts and to assess the multidimensional nature of drought in the Abbay/ Upper Blue Nile River (UBN) basin and its national and regional scale implications. In this study, multiple drought indices derived from in situ and earth observation-based hydro-climatic variables were used. The meteorological drought was characterized using the Standardized Precipitation Index (SPI) computed from the earth observation-based gridded CHIRPS (Climate Hazards Group InfraRed Precipitation with Station) rainfall data. Agricultural and hydrological droughts were characterized by using the Soil Moisture Deficit Index (SMDI) and Standardized Runoff-discharge Index (SRI), respectively. The monthly time series of SMDI was derived from model-based gridded soil moisture and SRI from observed streamflow data from 1982 to 2019. The preliminary result illustrates the good performance of the drought indices in capturing the historic severe drought events (e.g., 1984 and 2002) and the spatial extents across the basin. The results further indicated that all forms of droughts (i.e., meteorological, agricultural, and hydrological) occurred concurrently in Abbay/Upper Blue Nile basin with a Pearson correlation coefficient ranges from 0.5 to 0.85 both Kiremt and annual aggregate periods. The concurrent nature of drought is leading to a multi-dimensional socio-economic crisis as indicated by rainfall, and soil moisture deficits, and drying of small streams. Multi-dimensional drought mitigation necessitates regional cooperation and watershed management to protect both the common water sources of the Abbay/Upper Blue Nile basin and the socio-economic activities of the society in the basin. This study also underlines the need for multi-scale drought monitoring and management practices in the basin. Full article
Show Figures

Graphical abstract

Article
Predicting Height to Crown Base of Larix olgensis in Northeast China Using UAV-LiDAR Data and Nonlinear Mixed Effects Models
Remote Sens. 2021, 13(9), 1834; https://doi.org/10.3390/rs13091834 - 08 May 2021
Viewed by 307
Abstract
As a core content of forest management, the height to crown base (HCB) model can provide a theoretical basis for the study of forest growth and yield. In this study, 8364 trees of Larix olgensis within 118 sample plots from 11 sites were [...] Read more.
As a core content of forest management, the height to crown base (HCB) model can provide a theoretical basis for the study of forest growth and yield. In this study, 8364 trees of Larix olgensis within 118 sample plots from 11 sites were measured to establish a two-level nonlinear mixed effect (NLME) HCB model. All predictors were derived from an unmanned aerial vehicle light detection and ranging (UAV-LiDAR) laser scanning system, which is reliable for extensive forest measurement. The effects of the different individual trees, stand factors, and their combinations on the HCB were analyzed, and the leave-one-site-out cross-validation was utilized for model validation. The results showed that the NLME model significantly improved the prediction accuracy compared to the base model, with a mean absolute error and relative mean absolute error of 0.89% and 9.71%, respectively. In addition, both site-level and plot-level sampling strategies were simulated for NLME model calibration. According to different prediction scale and accuracy requirements, selecting 15 trees randomly per site or selecting the three largest trees and three medium-size trees per plot was considered the most favorable option, especially when both investigations cost and the model’s accuracy are primarily considered. The newly established HCB model will provide valuable tools to effectively utilize the UAV-LiDAR data for facilitating decision making in larch plantations management. Full article
(This article belongs to the Section Forest Remote Sensing)
Show Figures

Graphical abstract

Article
Coupling of Dual Channel Waveform ALS and Sonar for Investigation of Lake Bottoms and Shore Zones
Remote Sens. 2021, 13(9), 1833; https://doi.org/10.3390/rs13091833 - 08 May 2021
Viewed by 429
Abstract
In this work, we proposed to include remote sensing techniques as a part of the methodology for natural lake bottom mapping, with a focus on the littoral zone. Due to the inaccessibility of this zone caused by dense vegetation, measurements of the lake [...] Read more.
In this work, we proposed to include remote sensing techniques as a part of the methodology for natural lake bottom mapping, with a focus on the littoral zone. Due to the inaccessibility of this zone caused by dense vegetation, measurements of the lake bottom and the coastline are also difficult to perform using traditional methods. The authors of this paper present, discuss and verify the applicability of remote sensing active sensors as a tool for measurements in the shore zone of a lake. The single-beam Lowrance HDS-7 ComboGPS echosounder with an 83/200 kHz transducer and a two-beam LiDAR RIEGL VQ-1560i-DW scanner have been used for reservoir bottom measurements of two neighboring lakes, which differ in terms of water transparency. The research has found a strong correlation between both sonar and LiDAR for mapping the bottom depth in a range up to 1.6 m, and allowed LiDAR mapping of approximately 20% of the highly transparent lake, but it has not been found to be useful in water with low transparency. In the light of the conducted research, both devices, sonar and LiDAR, have potential for complementary use by fusing both methods: the sonar for mapping of the sublittoral and the pelagic zone, and the LiDAR for mapping of the littoral zone, overcoming limitation related to vegetation in the lake shore zone. Full article
(This article belongs to the Special Issue Geoinformation Technologies in Civil Engineering and the Environment)
Show Figures

Graphical abstract

Previous Issue
Next Issue
Back to TopTop
