Sensors, Volume 24, Issue 5 (March-1 2024) – 363 articles

Cover Story (view full-size image): Silicon PhotoMultipliers (SiPMs) are pixelated photo-detectors operating in Geiger mode for single photon detection. They are commonly used in applications requiring high spatial resolution like high-energy physics and medical imaging, as well as for their high photo-detection efficiency in astrophysics, space detectors, and LIDAR systems. SiPMs have a non-linear detection range from one to several thousand photons. We have devised a method to correct the non-linear response of SiPMs using only SiPM measurements, independent of light source knowledge or linearity. The method involves uniformly illuminating the SiPM surface with two tunable light sources, LED and laser, of varying amplitude and arrival time. Through this technique, we can effectively correct the SiPMs' non-linear response and expand the linear dynamic range by over tenfold. View this paper
  • Issues are regarded as officially published after their release is announced to the table of contents alert mailing list.
  • You may sign up for e-mail alerts to receive table of contents of newly released issues.
  • PDF is the official format for papers published in both, html and pdf forms. To view the papers in pdf format, click on the "PDF Full-text" link, and use the free Adobe Reader to open them.
Order results
Result details
Section
Select all
Export citation of selected articles as:
10 pages, 3706 KiB
Communication
Correction of 2π Phase Jumps for Silicon Photonic Sensors Based on Mach Zehnder Interferometers with Application in Gas and Biosensing
by Loic Laplatine, Sonia Messaoudene, Nicolas Gaignebet, Cyril Herrier and Thierry Livache
Sensors 2024, 24(5), 1712; https://doi.org/10.3390/s24051712 - 06 Mar 2024
Viewed by 743
Abstract
Silicon photonic sensors based on Mach Zehnder Interferometers (MZIs) have applications spanning from biological and olfactory sensors to temperature and ultrasound sensors. Although a coherent detection scheme can solve the issues of sensitivity fading and ambiguity in phase direction, the measured phase remains [...] Read more.
Silicon photonic sensors based on Mach Zehnder Interferometers (MZIs) have applications spanning from biological and olfactory sensors to temperature and ultrasound sensors. Although a coherent detection scheme can solve the issues of sensitivity fading and ambiguity in phase direction, the measured phase remains 2π periodic. This implies that the acquisition frequency should ensure a phase shift lower than π between each measurement point to prevent 2π phase jumps. Here, we describe and experimentally characterize two methods based on reference MZIs with lower sensitivities to alleviate this drawback. These solutions improve the measurement robustness and allow the lowering of the acquisition frequency. The first method is based on the phase derivative sign comparison. When a discrepancy is detected, the reference MZI is used to choose whether 2π should be added or removed from the nominal MZI. It can correct 2π phase jumps regardless of the sensitivity ratio, so that a single reference MZI can be used to correct multiple nominal MZIs. This first method relaxes the acquisition frequency requirement by a factor of almost two. However, it cannot correct phase jumps of 4π, 6π or higher between two measurement points. The second method is based on the comparison between the measured phase from the nominal MZI and the phase expected from the reference MZI. It can correct multiple 2π phase jumps but requires at least one reference MZI per biofunctionalization. It will also constrain the corrected phase to lie in a limited interval of [π, +π] around the expected value, and might fail to correct phase shifts above a few tens of radians depending on the disparity of the nominal sensors responses. Nonetheless, for phase shift lower than typically 20 radians, this method allows the lowering of the acquisition frequency almost arbitrarily. Full article
(This article belongs to the Special Issue Eurosensors 2023 Selected Papers)
Show Figures

Figure 1

22 pages, 10115 KiB
Article
The Rise of Passive RFID RTLS Solutions in Industry 5.0
by Ygal Bendavid, Samad Rostampour, Yacine Berrabah, Nasour Bagheri and Masoumeh Safkhani
Sensors 2024, 24(5), 1711; https://doi.org/10.3390/s24051711 - 06 Mar 2024
Viewed by 755
Abstract
In today’s competitive landscape, manufacturing companies must embrace digital transformation. This study asserts that integrating Internet of Things (IoT) technologies for the deployment of real-time location systems (RTLS) is crucial for better monitoring of critical assets. Despite the challenge of selecting the right [...] Read more.
In today’s competitive landscape, manufacturing companies must embrace digital transformation. This study asserts that integrating Internet of Things (IoT) technologies for the deployment of real-time location systems (RTLS) is crucial for better monitoring of critical assets. Despite the challenge of selecting the right technology for specific needs from a wide range of indoor RTLS options, this study provides a solution to assist manufacturing companies in exploring and implementing IoT technologies for their RTLS needs. The current academic literature has not adequately addressed this industrial reality. This paper assesses the potential of Passive UHF RFID-RTLS in Industry 5.0, addressing the confusion caused by the emergence of new ’passive’ RFID solutions that compete with established ’active’ solutions. Our research aims to clarify the real-world performance of passive RTLS solutions and propose an updated classification of RTLS systems in the academic literature. We have thoroughly reviewed both the academic and industry literature to remain up to date with the latest market advancements. Passive UHF RFID has been proven to be a valuable addition to the RTLS domain, capable of addressing certain challenges. This has been demonstrated through the successful implementation in two industrial sites, each with different types of tagged objects. Full article
(This article belongs to the Special Issue RFID-Enabled Sensor Design and Applications)
Show Figures

Figure 1

18 pages, 6117 KiB
Article
Research on a Visual/Ultra-Wideband Tightly Coupled Fusion Localization Algorithm
by Pin Jiang, Chen Hu, Tingting Wang, Ke Lv, Tingfeng Guo, Jinxuan Jiang and Wenwu Hu
Sensors 2024, 24(5), 1710; https://doi.org/10.3390/s24051710 - 06 Mar 2024
Viewed by 543
Abstract
In the autonomous navigation of mobile robots, precise positioning is crucial. In forest environments with weak satellite signals or in sites disturbed by complex environments, satellite positioning accuracy has difficulty in meeting the requirements of autonomous navigation positioning accuracy for robots. This article [...] Read more.
In the autonomous navigation of mobile robots, precise positioning is crucial. In forest environments with weak satellite signals or in sites disturbed by complex environments, satellite positioning accuracy has difficulty in meeting the requirements of autonomous navigation positioning accuracy for robots. This article proposes a vision SLAM/UWB tightly coupled localization method and designs a UWB non-line-of-sight error identification method using the displacement increment of the visual odometer. It utilizes the displacement increment of visual output and UWB ranging information as measurement values and applies the extended Kalman filtering algorithm for data fusion. This study utilized the constructed experimental platform to collect images and ultra-wideband ranging data in outdoor environments and experimentally validated the combined positioning method. The experimental results show that the algorithm outperforms individual UWB or loosely coupled combination positioning methods in terms of positioning accuracy. It effectively eliminates non-line-of-sight errors in UWB, improving the accuracy and stability of the combined positioning system. Full article
(This article belongs to the Section Navigation and Positioning)
Show Figures

Figure 1

22 pages, 7518 KiB
Article
Omni-OTPE: Omnidirectional Optimal Real-Time Ground Target Position Estimation System for Moving Lightweight Unmanned Aerial Vehicle
by Yi Ding, Jiaxing Che, Zhiming Zhou and Jingyuan Bian
Sensors 2024, 24(5), 1709; https://doi.org/10.3390/s24051709 - 06 Mar 2024
Viewed by 433
Abstract
Ground target detection and positioning systems based on lightweight unmanned aerial vehicles (UAVs) are increasing in value for aerial reconnaissance and surveillance. However, the current method for estimating the target’s position is limited by the field of view angle, rendering it challenging to [...] Read more.
Ground target detection and positioning systems based on lightweight unmanned aerial vehicles (UAVs) are increasing in value for aerial reconnaissance and surveillance. However, the current method for estimating the target’s position is limited by the field of view angle, rendering it challenging to fulfill the demands of a real-time omnidirectional reconnaissance operation. To address this issue, we propose an Omnidirectional Optimal Real-Time Ground Target Position Estimation System (Omni-OTPE) that utilizes a fisheye camera and LiDAR sensors. The object of interest is first identified in the fisheye image, and then, the image-based target position is obtained by solving using the fisheye projection model and the target center extraction algorithm based on the detected edge information. Next, the LiDAR’s real-time point cloud data are filtered based on position–direction constraints using the image-based target position information. This step allows for the determination of point cloud clusters that are relevant to the characterization of the target’s position information. Finally, the target positions obtained from the two methods are fused using an optimal Kalman fuser to obtain the optimal target position information. In order to evaluate the positioning accuracy, we designed a hardware and software setup, mounted on a lightweight UAV, and tested it in a real scenario. The experimental results validate that our method exhibits significant advantages over traditional methods and achieves a real-time high-performance ground target position estimation function. Full article
Show Figures

Figure 1

31 pages, 3474 KiB
Review
A Survey of Deep Learning Road Extraction Algorithms Using High-Resolution Remote Sensing Images
by Shaoyi Mo, Yufeng Shi, Qi Yuan and Mingyue Li
Sensors 2024, 24(5), 1708; https://doi.org/10.3390/s24051708 - 06 Mar 2024
Viewed by 795
Abstract
Roads are the fundamental elements of transportation, connecting cities and rural areas, as well as people’s lives and work. They play a significant role in various areas such as map updates, economic development, tourism, and disaster management. The automatic extraction of road features [...] Read more.
Roads are the fundamental elements of transportation, connecting cities and rural areas, as well as people’s lives and work. They play a significant role in various areas such as map updates, economic development, tourism, and disaster management. The automatic extraction of road features from high-resolution remote sensing images has always been a hot and challenging topic in the field of remote sensing, and deep learning network models are widely used to extract roads from remote sensing images in recent years. In light of this, this paper systematically reviews and summarizes the deep-learning-based techniques for automatic road extraction from high-resolution remote sensing images. It reviews the application of deep learning network models in road extraction tasks and classifies these models into fully supervised learning, semi-supervised learning, and weakly supervised learning based on their use of labels. Finally, a summary and outlook of the current development of deep learning techniques in road extraction are provided. Full article
Show Figures

Figure 1

20 pages, 18265 KiB
Article
Temperature-Automated Calibration Methods for a Large-Area Blackbody Radiation Source
by Wenhang Yang, Chen Cao, Pujiang Huang, Jindong Bai, Bangjian Zhao, Shouzheng Zhu, Haijun Jin, Ke Jin, Xin He, Chunlai Li, Jianyu Wang, Shijie Liu and Hongxing Qi
Sensors 2024, 24(5), 1707; https://doi.org/10.3390/s24051707 - 06 Mar 2024
Viewed by 494
Abstract
High-precision temperature control of large-area blackbodies has a pivotal role in temperature calibration and thermal imaging correction. Meanwhile, it is necessary to correct the temperature difference between the radiating (surface of use) and back surfaces (where the temperature sensor is installed) of the [...] Read more.
High-precision temperature control of large-area blackbodies has a pivotal role in temperature calibration and thermal imaging correction. Meanwhile, it is necessary to correct the temperature difference between the radiating (surface of use) and back surfaces (where the temperature sensor is installed) of the blackbody during the testing phase. Moreover, large-area blackbodies are usually composed of multiple temperature control channels, and manual correction in this scenario is error-prone and inefficient. At present, there is no method that can achieve temperature-automated calibration for a large-area blackbody radiation source. Therefore, this article is dedicated to achieving temperature-automated calibration for a large-area blackbody radiation source. First, utilizing two calibrated infrared thermometers, the optimal temperature measurement location was determined using a focusing algorithm. Then, a three-axis movement system was used to obtain the true temperature at the same measurement location on a large-area blackbody surface from different channels. This temperature was subtracted from the blackbody’s back surface. The temperature difference was calculated employing a weighted algorithm to derive the parameters for calibration. Finally, regarding experimental verification, the consistency error of the temperature measurement point was reduced by 85.4%, the temperature uniformity of the surface source was improved by 40.4%, and the average temperature measurement deviation decreased by 43.8%. In addition, this system demonstrated the characteristics of strong environmental adaptability that was able to perform temperature calibration under the working conditions of a blackbody surface temperature from 100 K to 573 K, which decreased the calibration time by 9.82 times. Full article
(This article belongs to the Section Physical Sensors)
Show Figures

Figure 1

14 pages, 7580 KiB
Article
Flying Target Detection Technology Based on GNSS Multipath Signals
by Pengfei Zhu, Qinglin Zhu, Xiang Dong and Mingchen Sun
Sensors 2024, 24(5), 1706; https://doi.org/10.3390/s24051706 - 06 Mar 2024
Viewed by 420
Abstract
In this study, a passive radar system that detects flying targets is developed in order to solve the problems associated with traditional flying target detection systems (i.e., their large size, high power consumption, complex systems, and poor battlefield survivability). On the basis of [...] Read more.
In this study, a passive radar system that detects flying targets is developed in order to solve the problems associated with traditional flying target detection systems (i.e., their large size, high power consumption, complex systems, and poor battlefield survivability). On the basis of target detection, the system uses the multipath signal (which is usually eliminated as an error term in navigation and positioning), enhances it by supporting information, and utilizes the multi-source characteristics of ordinary omnidirectional global navigation satellite system (GNSS) signals. The results of a validation experiment showed that the system is able to locate a passenger airplane and obtain its flight trajectory using only one GNSS receiving antenna. The system is characterized by its light weight (less than 5 kg), low power consumption, simple system, good portability, low cost, and 24/7 and all-weather work. It can be installed in large quantities and has good prospects for development. Full article
(This article belongs to the Section Radar Sensors)
Show Figures

Figure 1

16 pages, 4179 KiB
Article
Fluorescence Spectra of Prototropic Forms of Fluorescein and Some Derivatives and Their Potential Use for Calibration-Free pH Sensing
by Bernard Gauthier-Manuel, Chafia Benmouhoub and Bruno Wacogne
Sensors 2024, 24(5), 1705; https://doi.org/10.3390/s24051705 - 06 Mar 2024
Viewed by 440
Abstract
Fluorescence pH sensing has proven to be efficient but with the drawback that molecules photobleach, requiring frequent calibrations. Double-emission peak molecules allow ratiometric measurements and theoretically avoid calibration. However, they are often expensive and fragile and usually have very low quantum yields. Single [...] Read more.
Fluorescence pH sensing has proven to be efficient but with the drawback that molecules photobleach, requiring frequent calibrations. Double-emission peak molecules allow ratiometric measurements and theoretically avoid calibration. However, they are often expensive and fragile and usually have very low quantum yields. Single emission peaks such as fluorescein and derivatives are inexpensive and have very high quantum yields. Because they are single emission peaks, the pH is assumed to be derived from the ratio of emitted intensities at measured pH and at high pH values, i.e., they require frequent calibration. However, the shape of their single emitted peak evolves slightly with pH. In this paper, we first demonstrate a simple method to calculate the emission spectrum shape of each prototropic form of fluorescein (and derivatives) as well as the values of the pKas. A complete model of the evolution of the emission spectrum shape with pH is then constructed. Second, we evaluate the potential of these molecules for pH sensing by fitting the experimental spectra with the complete emission model. The method is applied to fluorescein, FITC and FAM. Depending on the molecule, pH can be measured from pH 1.9 to pH 7.3 with standard deviations between 0.06 and 0.08 pH units. Estimating pH and pKas from shape instead of intensity allows calibration-free measurements even with single-emission peak molecules. Full article
(This article belongs to the Special Issue Optical Spectroscopy for Sensing, Monitoring and Analysis)
Show Figures

Figure 1

12 pages, 5568 KiB
Article
Influence of Flexible and Textile Substrates on Frequency-Selective Surfaces (FSS)
by Olga Rac-Rumijowska, Piotr Pokryszka, Tomasz Rybicki, Patrycja Suchorska-Woźniak, Maksymilian Woźniak, Katarzyna Kaczkowska and Iwona Karbownik
Sensors 2024, 24(5), 1704; https://doi.org/10.3390/s24051704 - 06 Mar 2024
Viewed by 627
Abstract
Frequency-selective surfaces (FSS) are two-dimensional geometric structures made of conductive materials that selectively transmit or reflect electromagnetic waves. In this paper, flexible FSS made on textile and film substrates is presented and compared to show the effect of the texture associated with the [...] Read more.
Frequency-selective surfaces (FSS) are two-dimensional geometric structures made of conductive materials that selectively transmit or reflect electromagnetic waves. In this paper, flexible FSS made on textile and film substrates is presented and compared to show the effect of the texture associated with the type of substrate on the shielding properties. Three geometries of patterns of squares in the border, inversion of squares in the border, and circles with a border were used, and the patterns were made by the silver paste screen printing technique. Microscopic analysis (SEM and optical) was performed to determine the degree of substrate coverage and the actual geometry of the pattern. The resistance per square of the obtained patterns was about 50 mΩ/□. The shielding properties of FSS were simulated in Comsol Multiphysics 6.2 software and then measured by the antenna method. Selective textile filters were obtained, depending on the pattern used, with one or two modals with a transmission attenuation of about 15 dB. The paper analyzes the effect of the substrate and the screen printing technique used on the shielding properties of the flexible FSS. Full article
(This article belongs to the Special Issue RFID-Enabled Sensor Design and Applications)
Show Figures

Figure 1

29 pages, 3153 KiB
Article
Ultra-Wideband Ranging Error Mitigation with Novel Channel Impulse Response Feature Parameters and Two-Step Non-Line-of-Sight Identification
by Hongchao Yang, Yunjia Wang, Shenglei Xu, Jingxue Bi, Haonan Jia and Cheekiat Seow
Sensors 2024, 24(5), 1703; https://doi.org/10.3390/s24051703 - 06 Mar 2024
Viewed by 536
Abstract
The effective identification and mitigation of non-line-of-sight (NLOS) ranging errors are essential for achieving high-precision positioning and navigation with ultra-wideband (UWB) technology in harsh indoor environments. In this paper, an efficient UWB ranging-error mitigation strategy that uses novel channel impulse response parameters based [...] Read more.
The effective identification and mitigation of non-line-of-sight (NLOS) ranging errors are essential for achieving high-precision positioning and navigation with ultra-wideband (UWB) technology in harsh indoor environments. In this paper, an efficient UWB ranging-error mitigation strategy that uses novel channel impulse response parameters based on the results of a two-step NLOS identification, composed of a decision tree and feedforward neural network, is proposed to realize indoor locations. NLOS ranging errors are classified into three types, and corresponding mitigation strategies and recall mechanisms are developed, which are also extended to partial line-of-sight (LOS) errors. Extensive experiments involving three obstacles (humans, walls, and glass) and two sites show an average NLOS identification accuracy of 95.05%, with LOS/NLOS recall rates of 95.72%/94.15%. The mitigated LOS errors are reduced by 50.4%, while the average improvement in the accuracy of the three types of NLOS ranging errors is 61.8%, reaching up to 76.84%. Overall, this method achieves a reduction in LOS and NLOS ranging errors of 25.19% and 69.85%, respectively, resulting in a 54.46% enhancement in positioning accuracy. This performance surpasses that of state-of-the-art techniques, such as the convolutional neural network (CNN), long short-term memory–extended Kalman filter (LSTM-EKF), least-squares–support vector machine (LS-SVM), and k-nearest neighbor (K-NN) algorithms. Full article
Show Figures

Figure 1

19 pages, 2478 KiB
Article
A Comprehensive Evaluation Algorithm of Multi-Point Relay Based on Link-State Awareness for UANETs
by Rencheng Jin, Xinyuan Zhang, Jiajun Liu, Guangxu Wang and Di Zhang
Sensors 2024, 24(5), 1702; https://doi.org/10.3390/s24051702 - 06 Mar 2024
Viewed by 436
Abstract
The Multi-Point Relay (MPR) is one of the core technologies for Optimizing Link State Routing (OLSR) protocols, offering significant advantages in reducing network overhead, enhancing throughput, maintaining network scalability, and adaptability. However, due to the restriction that only MPR nodes can forward control [...] Read more.
The Multi-Point Relay (MPR) is one of the core technologies for Optimizing Link State Routing (OLSR) protocols, offering significant advantages in reducing network overhead, enhancing throughput, maintaining network scalability, and adaptability. However, due to the restriction that only MPR nodes can forward control messages in the network, the current evaluation criteria for selecting MPR nodes are relatively limited, making it challenging to flexibly choose MPR nodes based on current link states in dynamic networks. Therefore, the selection of MPR nodes is crucial in dynamic networks. To address issues such as unstable links, poor transmission accuracy, and lack of real-time performance caused by mobility in dynamic networks, we propose a comprehensive evaluation algorithm of MPR based on link-state awareness. This algorithm defines five state evaluation parameters from the perspectives of node mobility and load. Subsequently, we use the entropy weight method to determine weight coefficients and employing the method of Technique for Order Preference by Similarity to Ideal Solution (TOPSIS) for comprehensive evaluation to select MPR nodes. Finally, the Comprehensive Evaluation based on Link-state awareness of OLSR (CEL-OLSR) protocol is proposed, and simulated experiments are conducted using NS-3. The results indicate that, compared to PM-OLSR, ML-OLSR, LD-OLSR, and OLSR, CEL-OLSR significantly improves network performance in terms of packet delivery rate, average end-to-end delay, network throughput, and control overhead. Full article
(This article belongs to the Section Sensor Networks)
Show Figures

Figure 1

26 pages, 32597 KiB
Article
Weakly Supervised Depth Estimation for 3D Imaging with Single Camera Fringe Projection Profilometry
by Chunqian Tan and Wanzhong Song
Sensors 2024, 24(5), 1701; https://doi.org/10.3390/s24051701 - 06 Mar 2024
Viewed by 477
Abstract
Fringe projection profilometry (FPP) is widely used for high-accuracy 3D imaging. However, employing multiple sets of fringe patterns ensures 3D reconstruction accuracy while inevitably constraining the measurement speed. Conventional dual-frequency FPP reduces the number of fringe patterns for one reconstruction to six or [...] Read more.
Fringe projection profilometry (FPP) is widely used for high-accuracy 3D imaging. However, employing multiple sets of fringe patterns ensures 3D reconstruction accuracy while inevitably constraining the measurement speed. Conventional dual-frequency FPP reduces the number of fringe patterns for one reconstruction to six or fewer, but the highest period-number of fringe patterns generally is limited because of phase errors. Deep learning makes depth estimation from fringe images possible. Inspired by unsupervised monocular depth estimation, this paper proposes a novel, weakly supervised method of depth estimation for single-camera FPP. The trained network can estimate the depth from three frames of 64-period fringe images. The proposed method is more efficient in terms of fringe pattern efficiency by at least 50% compared to conventional FPP. The experimental results show that the method achieves competitive accuracy compared to the supervised method and is significantly superior to the conventional dual-frequency methods. Full article
(This article belongs to the Section Sensing and Imaging)
Show Figures

Figure 1

17 pages, 1952 KiB
Article
Building Individual Player Performance Profiles According to Pre-Game Expectations and Goal Difference in Soccer
by Arian Skoki, Boris Gašparović, Stefan Ivić, Jonatan Lerga and Ivan Štajduhar
Sensors 2024, 24(5), 1700; https://doi.org/10.3390/s24051700 - 06 Mar 2024
Viewed by 600
Abstract
Soccer player performance is influenced by multiple unpredictable factors. During a game, score changes and pre-game expectations affect the effort exerted by players. This study used GPS wearable sensors to track players’ energy expenditure in 5-min intervals, alongside recording the goal timings and [...] Read more.
Soccer player performance is influenced by multiple unpredictable factors. During a game, score changes and pre-game expectations affect the effort exerted by players. This study used GPS wearable sensors to track players’ energy expenditure in 5-min intervals, alongside recording the goal timings and the win and lose probabilities from betting sites. A mathematical model was developed that considers pre-game expectations (e.g., favorite, non-favorite), endurance, and goal difference (GD) dynamics on player effort. Particle Swarm and Nelder–Mead optimization methods were used to construct these models, both consistently converging to similar cost function values. The model outperformed baselines relying solely on mean and median power per GD. This improvement is underscored by the mean absolute error (MAE) of 396.87±61.42 and root mean squared error (RMSE) of 520.69±88.66 achieved by our model, as opposed to the B1 MAE of 429.04±84.87 and RMSE of 581.34±185.84, and B2 MAE of 421.57±95.96 and RMSE of 613.47±300.11 observed across all players in the dataset. This research offers an enhancement to the current approaches for assessing players’ responses to contextual factors, particularly GD. By utilizing wearable data and contextual factors, the proposed methods have the potential to improve decision-making and deepen the understanding of individual player characteristics. Full article
(This article belongs to the Special Issue Applications of Body Worn Sensors and Wearables)
Show Figures

Figure 1

13 pages, 5726 KiB
Article
Sensor-Based Measurement Method to Support the Assessment of Robot-Assisted Radiofrequency Ablation
by Hilda Zsanett Marton, Pálma Emese Inczeffy, Zsuzsanna Kis, Attila Kardos and Tamás Haidegger
Sensors 2024, 24(5), 1699; https://doi.org/10.3390/s24051699 - 06 Mar 2024
Viewed by 955
Abstract
Digital surgery technologies, such as interventional robotics and sensor systems, not only improve patient care but also aid in the development and optimization of traditional invasive treatments and methods. Atrial Fibrillation (AF) is the most common cardiac arrhythmia with critical clinical relevance today. [...] Read more.
Digital surgery technologies, such as interventional robotics and sensor systems, not only improve patient care but also aid in the development and optimization of traditional invasive treatments and methods. Atrial Fibrillation (AF) is the most common cardiac arrhythmia with critical clinical relevance today. Delayed intervention can lead to heart failure, stroke, or sudden cardiac death. Although many advances have been made in the field of radiofrequency (RF) catheter ablation (CA), it can be further developed by incorporating sensor technology to improve its efficacy and safety. Automation can be utilized to shorten the duration of RF ablation, provided that the interactions between the tissue and the RF tools are well understood and adequately modeled. Further research is needed to develop the optimal catheter design. This paper describes the systematic methodology developed to support robot-assisted RF CA characterization measurements. The article describes the custom instruments developed for the experiments, particularly the contact force limiter, the measurement procedure, and the evaluation of the results, as enablers for new results. The aim was to establish an objective, repeatable, robust measurement method and adjacent procedure. Full article
(This article belongs to the Section Physical Sensors)
Show Figures

Figure 1

23 pages, 4802 KiB
Article
QRS Detector Performance Evaluation Aware of Temporal Accuracy and Presence of Noise
by Wojciech Reklewski, Marek Miśkowicz and Piotr Augustyniak
Sensors 2024, 24(5), 1698; https://doi.org/10.3390/s24051698 - 06 Mar 2024
Viewed by 531
Abstract
Algorithms for QRS detection are fundamental in the ECG interpretive processing chain. They must meet several challenges, such as high reliability, high temporal accuracy, high immunity to noise, and low computational complexity. Unfortunately, the accuracy expressed by missed or redundant events statistics is [...] Read more.
Algorithms for QRS detection are fundamental in the ECG interpretive processing chain. They must meet several challenges, such as high reliability, high temporal accuracy, high immunity to noise, and low computational complexity. Unfortunately, the accuracy expressed by missed or redundant events statistics is often the only parameter used to evaluate the detector’s performance. In this paper, we first notice that statistics of true positive detections rely on researchers’ arbitrary selection of time tolerance between QRS detector output and the database reference. Next, we propose a multidimensional algorithm evaluation method and present its use on four example QRS detectors. The dimensions are (a) influence of detection temporal tolerance, tested for values between 8.33 and 164 ms; (b) noise immunity, tested with an ECG signal with an added muscular noise pattern and signal-to-noise ratio to the effect of “no added noise”, 15, 7, 3 dB; and (c) influence of QRS morphology, tested on the six most frequently represented morphology types in the MIT-BIH Arrhythmia Database. The multidimensional evaluation, as proposed in this paper, allows an in-depth comparison of QRS detection algorithms removing the limitations of existing one-dimensional methods. The method enables the assessment of the QRS detection algorithms according to the medical device application area and corresponding requirements of temporal accuracy, immunity to noise, and QRS morphology types. The analysis shows also that, for some algorithms, adding muscular noise to the ECG signal improves algorithm accuracy results. Full article
(This article belongs to the Section Biomedical Sensors)
Show Figures

Figure 1

20 pages, 14330 KiB
Article
Unmanned Surface Vehicle Thruster Fault Diagnosis via Vibration Signal Wavelet Transform and Vision Transformer under Varying Rotational Speed Conditions
by Hyunjoon Cho, Jung-Hyeun Park, Ki-Beom Choo, Myungjun Kim, Dae-Hyeong Ji and Hyeung-Sik Choi
Sensors 2024, 24(5), 1697; https://doi.org/10.3390/s24051697 - 06 Mar 2024
Viewed by 468
Abstract
Among unmanned surface vehicle (USV) components, underwater thrusters are pivotal in their mission execution integrity. Yet, these thrusters directly interact with marine environments, making them perpetually susceptible to malfunctions. To diagnose thruster faults, a non-invasive and cost-effective vibration-based methodology that does not require [...] Read more.
Among unmanned surface vehicle (USV) components, underwater thrusters are pivotal in their mission execution integrity. Yet, these thrusters directly interact with marine environments, making them perpetually susceptible to malfunctions. To diagnose thruster faults, a non-invasive and cost-effective vibration-based methodology that does not require altering existing systems is employed. However, the vibration data collected within the hull is influenced by propeller-fluid interactions, hull damping, and structural resonant frequencies, resulting in noise and unpredictability. Furthermore, to differentiate faults not only at fixed rotational speeds but also over the entire range of a thruster’s rotational speeds, traditional frequency analysis based on the Fourier transform cannot be utilized. Hence, Continuous Wavelet Transform (CWT), known for attributions encapsulating physical characteristics in both time-frequency domain nuances, was applied to address these complications and transform vibration data into a scalogram. CWT results are diagnosed using a Vision Transformer (ViT) classifier known for its global context awareness in image processing. The effectiveness of this diagnosis approach was verified through experiments using a USV designed for field experiments. Seven cases with different fault types and severity were diagnosed and yielded average accuracy of 0.9855 and 0.9908 at different vibration points, respectively. Full article
(This article belongs to the Section Sensors and Robotics)
Show Figures

Figure 1

12 pages, 6133 KiB
Article
Passive Biotelemetric Detection of Tibial Debonding in Wireless Battery-Free Smart Knee Implants
by Thomas A. G. Hall, Frederic Cegla and Richard J. van Arkel
Sensors 2024, 24(5), 1696; https://doi.org/10.3390/s24051696 - 06 Mar 2024
Viewed by 517
Abstract
Aseptic loosening is the dominant failure mechanism in contemporary knee replacement surgery, but diagnostic techniques are poorly sensitive to the early stages of loosening and poorly specific in delineating aseptic cases from infections. Smart implants have been proposed as a solution, but incorporating [...] Read more.
Aseptic loosening is the dominant failure mechanism in contemporary knee replacement surgery, but diagnostic techniques are poorly sensitive to the early stages of loosening and poorly specific in delineating aseptic cases from infections. Smart implants have been proposed as a solution, but incorporating components for sensing, powering, processing, and communication increases device cost, size, and risk; hence, minimising onboard instrumentation is desirable. In this study, two wireless, battery-free smart implants were developed that used passive biotelemetry to measure fixation at the implant–cement interface of the tibial components. The sensing system comprised of a piezoelectric transducer and coil, with the transducer affixed to the superior surface of the tibial trays of both partial (PKR) and total knee replacement (TKR) systems. Fixation was measured via pulse-echo responses elicited via a three-coil inductive link. The instrumented systems could detect loss of fixation when the implants were partially debonded (+7.1% PKA, +32.6% TKA, both p < 0.001) and fully debonded in situ (+6.3% PKA, +32.5% TKA, both p < 0.001). Measurements were robust to variations in positioning of the external reader, soft tissue, and the femoral component. With low cost and small form factor, the smart implant concept could be adopted for clinical use, particularly for generating an understanding of uncertain aseptic loosening mechanisms. Full article
(This article belongs to the Special Issue Novel Implantable Sensors and Biomedical Applications)
Show Figures

Figure 1

17 pages, 51092 KiB
Article
A Connector for Integrating NGSI-LD Data into Open Data Portals
by Laura Martín, Jorge Lanza, Víctor González, Juan Ramón Santana, Pablo Sotres and Luis Sánchez
Sensors 2024, 24(5), 1695; https://doi.org/10.3390/s24051695 - 06 Mar 2024
Viewed by 461
Abstract
Nowadays, there are plenty of data sources generating massive amounts of information that, combined with novel data analytics frameworks, are meant to support optimisation in many application domains. Nonetheless, there are still shortcomings in terms of data discoverability, accessibility and interoperability. Open Data [...] Read more.
Nowadays, there are plenty of data sources generating massive amounts of information that, combined with novel data analytics frameworks, are meant to support optimisation in many application domains. Nonetheless, there are still shortcomings in terms of data discoverability, accessibility and interoperability. Open Data portals have emerged as a shift towards openness and discoverability. However, they do not impose any condition to the data itself, just stipulate how datasets have to be described. Alternatively, the NGSI-LD standard pursues harmonisation in terms of data modelling and accessibility. This paper presents a solution that bridges these two domains (i.e., Open Data portals and NGSI-LD-based data) in order to keep benefiting from the structured description of datasets offered by Open Data portals, while ensuring the interoperability provided by the NGSI-LD standard. Our solution aggregates the data into coherent datasets and generate high-quality descriptions, ensuring comprehensiveness, interoperability and accessibility. The proposed solution has been validated through a real-world implementation that exposes IoT data in NGSI-LD format through the European Data Portal (EDP). Moreover, the results from the Metadata Quality Assessment that the EDP implements, show that the datasets’ descriptions generated achieve excellent ranking in terms of the Findability, Accessibility, Interoperability and Reusability (FAIR) data principles. Full article
(This article belongs to the Special Issue Data Engineering in the Internet of Things)
Show Figures

Figure 1

5 pages, 163 KiB
Editorial
Sensors Data Processing Using Machine Learning
by Patrik Kamencay, Peter Hockicko and Robert Hudec
Sensors 2024, 24(5), 1694; https://doi.org/10.3390/s24051694 - 06 Mar 2024
Viewed by 535
Abstract
Various sensors utilize computational models to estimate measured variables, and the generated data require processing [...] Full article
(This article belongs to the Special Issue Sensors Data Processing Using Machine Learning)
17 pages, 4444 KiB
Article
Research on SPAD Estimation Model for Spring Wheat Booting Stage Based on Hyperspectral Analysis
by Hongwei Cui, Haolei Zhang, Hao Ma and Jiangtao Ji
Sensors 2024, 24(5), 1693; https://doi.org/10.3390/s24051693 - 06 Mar 2024
Viewed by 412
Abstract
With the rapid progression of agricultural informatization technology, the methodologies of crop monitoring based on spectral technology are constantly upgraded. In order to carry out the efficient, precise and nondestructive detection of relative chlorophyll (SPAD) during the booting stage, we acquired hyperspectral reflectance [...] Read more.
With the rapid progression of agricultural informatization technology, the methodologies of crop monitoring based on spectral technology are constantly upgraded. In order to carry out the efficient, precise and nondestructive detection of relative chlorophyll (SPAD) during the booting stage, we acquired hyperspectral reflectance data about spring wheat vertical distribution and adopted the fractional-order differential to transform the raw spectral data. After that, based on correlation analysis, fractional differential spectra and fractional differential spectral indices with strong correlation with SPAD were screened and fused. Then, the least-squares support vector machine (LSSSVM) and the least-squares support vector machine (SMA-LSSSVM) optimized on the slime mold algorithm were applied to construct the estimation models of SPAD, and the model accuracy was assessed to screen the optimal estimation models. The results showed that the 0.4 order fractional-order differential spectra had the highest correlation with SPAD, which was 9.3% higher than the maximum correlation coefficient of the original spectra; the constructed two-band differential spectral indices were more sensitive to SPAD than the single differential spectra, in which the correlation reached the highest level of 0.724. The SMA-LSSSVM model constructed based on the two-band fractional-order differential spectral indices was better than the single differential spectra and the integration of both, which realized the assessment of wheat SPAD. Full article
(This article belongs to the Section Optical Sensors)
Show Figures

Figure 1

20 pages, 7599 KiB
Article
A Capacitive Particle-Analyzing Smoke Detector for Very Early Fire Detection
by Boqiang Wang, Xuezeng Zhao, Yiyong Zhang, Zigang Song and Zhuogang Wang
Sensors 2024, 24(5), 1692; https://doi.org/10.3390/s24051692 - 06 Mar 2024
Viewed by 486
Abstract
Smoke detectors face the challenges of increasing accuracy, sensitivity, and high reliability in complex use environments to ensure the timeliness, accuracy, and reliability of very early fire detection. The improvement in and innovation of the principle and algorithm of smoke particle concentration detection [...] Read more.
Smoke detectors face the challenges of increasing accuracy, sensitivity, and high reliability in complex use environments to ensure the timeliness, accuracy, and reliability of very early fire detection. The improvement in and innovation of the principle and algorithm of smoke particle concentration detection provide an opportunity for the performance improvement in the detector. This study is a new refinement of the smoke concentration detection principle based on capacitive detection of cell structures, and detection signals are processed by a multiscale smoke particle concentration detection algorithm to calculate particle concentration. Through experiments, it is found that the detector provides effective detection of smoke particle concentrations ranging from 0 to 10% obs/m; moreover, the detector can detect smoke particles at parts per million (PPM) concentration levels (at 2 and 5 PPM), and the accuracy of the detector can reach at least the 0.5 PPM level. Furthermore, the detector can detect smoke particle concentrations at better than 1 PPM accuracy even in an environment with 6% obs/m oil gas particles, 7% obs/m large dust interference particles, or 8% obs/m small dust interference particles. Full article
(This article belongs to the Section Intelligent Sensors)
Show Figures

Figure 1

12 pages, 4919 KiB
Article
Fabrication of a Fully Printed Ammonia Gas Sensor Based on ZnO/rGO Using Ultraviolet–Ozone Treatment
by Mijin Won, Jaeho Sim, Gyeongseok Oh, Minhun Jung, Snigdha Paramita Mantry and Dong-soo Kim
Sensors 2024, 24(5), 1691; https://doi.org/10.3390/s24051691 - 06 Mar 2024
Viewed by 478
Abstract
In this study, a room-temperature ammonia gas sensor using a ZnO and reduced graphene oxide (rGO) composite is developed. The sensor fabrication involved the innovative application of reverse offset and electrostatic spray deposition (ESD) techniques to create a ZnO/rGO sensing platform. The structural [...] Read more.
In this study, a room-temperature ammonia gas sensor using a ZnO and reduced graphene oxide (rGO) composite is developed. The sensor fabrication involved the innovative application of reverse offset and electrostatic spray deposition (ESD) techniques to create a ZnO/rGO sensing platform. The structural and chemical characteristics of the resulting material were comprehensively analyzed using XRD, FT-IR, FESEM, EDS, and XPS, and rGO reduction was achieved via UV–ozone treatment. Electrical properties were assessed through I–V curves, demonstrating enhanced conductivity due to UV–ozone treatment and improved charge mobility from the formation of a ZnO–rGO heterojunction. Exposure to ammonia gas resulted in increased sensor responsiveness, with longer UV–ozone treatment durations yielding superior sensitivity. Furthermore, response and recovery times were measured, with the 10 min UV–ozone-treated sensor displaying optimal responsiveness. Performance evaluation revealed linear responsiveness to ammonia concentration with a high R2 value. The sensor also exhibited exceptional selectivity for ammonia compared to acetone and CO gases, making it a promising candidate for ammonia gas detection. This study shows the outstanding performance and potential applications of the ZnO/rGO-based ammonia gas sensor, promising significant contributions to the field of gas detection. Full article
(This article belongs to the Section Chemical Sensors)
Show Figures

Figure 1

14 pages, 4291 KiB
Article
Assessing the Role of Yarn Placement in Plated Knit Strain Sensors: A Detailed Study of Their Electromechanical Properties and Applicability in Bending Cycle Monitoring
by Youn-Hee Kim, Juwon Jun, You-Kyung Oh, Hee-Ji Choi, Mi-Jung Lee, Kyeong-Sik Min, Sung-Hyon Kim, Hyunseung Lee, Ho-Seok Nam, Son Singh, Byoung-Joon Kim and Jaegab Lee
Sensors 2024, 24(5), 1690; https://doi.org/10.3390/s24051690 - 06 Mar 2024
Viewed by 469
Abstract
In this study, we explore how the strategic positioning of conductive yarns influences the performance of plated knit strain sensors fabricated using commercial knitting machines with both conductive and non-conductive yarns. Our study reveals that sensors with conductive yarns located at the rear, [...] Read more.
In this study, we explore how the strategic positioning of conductive yarns influences the performance of plated knit strain sensors fabricated using commercial knitting machines with both conductive and non-conductive yarns. Our study reveals that sensors with conductive yarns located at the rear, referred to as ‘purl plated sensors’, exhibit superior performance in comparison to those with conductive yarns at the front, or ‘knit plated sensors’. Specifically, purl plated sensors demonstrate a higher sensitivity, evidenced by a gauge factor ranging from 3 to 18, and a minimized strain delay, indicated by a 1% strain in their electromechanical response. To elucidate the mechanisms behind these observations, we developed an equivalent circuit model. This model examines the role of contact resistance within varying yarn configurations on the sensors’ sensitivity, highlighting the critical influence of contact resistance in conductive yarns subjected to wale-wise stretching on sensor responsiveness. Furthermore, our findings illustrate that the purl plated sensors benefit from the vertical movement of non-conductive yarns, which promotes enhanced contact between adjacent conductive yarns, thereby improving both the stability and sensitivity of the sensors. The practicality of these sensors is confirmed through bending cycle tests with an in situ monitoring system, showcasing the purl plated sensors’ exceptional reproducibility, with a standard deviation of 0.015 across 1000 cycles, and their superior sensitivity, making them ideal for wearable devices designed for real-time joint movement monitoring. This research highlights the critical importance of conductive yarn placement in sensor efficacy, providing valuable guidance for crafting advanced textile-based strain sensors. Full article
(This article belongs to the Section Wearables)
Show Figures

Figure 1

17 pages, 10836 KiB
Article
Design of Mantis-Shrimp-Inspired Multifunctional Imaging Sensors with Simultaneous Spectrum and Polarization Detection Capability at a Wide Waveband
by Tianxin Wang, Shuai Wang, Bo Gao, Chenxi Li and Weixing Yu
Sensors 2024, 24(5), 1689; https://doi.org/10.3390/s24051689 - 06 Mar 2024
Viewed by 447
Abstract
The remarkable light perception abilities of the mantis shrimp, which span a broad spectrum ranging from 300 nm to 720 nm and include the detection of polarized light, serve as the inspiration for our exploration. Drawing insights from the mantis shrimp’s unique visual [...] Read more.
The remarkable light perception abilities of the mantis shrimp, which span a broad spectrum ranging from 300 nm to 720 nm and include the detection of polarized light, serve as the inspiration for our exploration. Drawing insights from the mantis shrimp’s unique visual system, we propose the design of a multifunctional imaging sensor capable of concurrently detecting spectrum and polarization across a wide waveband. This sensor is able to show spectral imaging capability through the utilization of a 16-channel multi-waveband Fabry–Pérot (FP) resonator filter array. The design incorporates a composite thin film structure comprising metal and dielectric layers as the reflector of the resonant cavity. The resulting metal–dielectric composite film FP resonator extends the operating bandwidth to cover both visible and infrared regions, specifically spanning a broader range from 450 nm to 900 nm. Furthermore, within this operational bandwidth, the metal–dielectric composite film FP resonator demonstrates an average peak transmittance exceeding 60%, representing a notable improvement over the metallic resonator. Additionally, aluminum-based metallic grating arrays are incorporated beneath the FP filter array to capture polarization information. This innovative approach enables the simultaneous acquisition of spectrum and polarization information using a single sensor device. The outcomes of this research hold promise for advancing the development of high-performance, multifunctional optical sensors, thereby unlocking new possibilities in the field of optical information acquisition. Full article
(This article belongs to the Special Issue Nature Inspired Engineering: Biomimetic Sensors)
Show Figures

Figure 1

13 pages, 2581 KiB
Article
Two-Layer Inkjet-Printed Microwave Split-Ring Resonators for Detecting Analyte Binding to the Gold Surface
by Matthias Paul, Harald Kühnel, Rudolf Oberpertinger, Christoph Mehofer, Doris Pollhammer and Markus Wellenzohn
Sensors 2024, 24(5), 1688; https://doi.org/10.3390/s24051688 - 06 Mar 2024
Cited by 1 | Viewed by 596
Abstract
This work focuses on demonstrating the working principle of inkjet-printed Au nanoparticle (NP) two-layer Gigahertz (2.6 GHz) microwave split-ring resonators (SRRs) as a novel platform for the detection of analytes on flexible substrates. In contrast to the standard fabrication of split-ring resonator biosensors [...] Read more.
This work focuses on demonstrating the working principle of inkjet-printed Au nanoparticle (NP) two-layer Gigahertz (2.6 GHz) microwave split-ring resonators (SRRs) as a novel platform for the detection of analytes on flexible substrates. In contrast to the standard fabrication of split-ring resonator biosensors using printed circuit board technology, which results in a seven-layer system, the resonators in this work were fabricated using a two-layer system. A ground plane is embedded in the SRR measurement setup. In this method, a microwave electromagnetic wave is coupled into the Au SRR via an inkjet-printed Cu-NP stripline that is photonically sintered. This coupling mechanism facilitates the detection of analytes by inducing resonance shifts in the SRR. In this study, the functionality of the printed sensors was demonstrated using two different Au functionalization processes, firstly, with HS-PEG7500-COOH, and, secondly, with protein G with an N-terminal cysteine residue. The sensing capabilities of the printed structures are shown by the attachment of biomolecules to the SRR and the measurement of the resulting resonance shift. The experiments show a clear shift of the resonance frequency in the range of 20–30 MHz for both approaches. These results demonstrate the functionality of the simplified printed two-layer microwave split-ring resonator for use as a biosensor. Full article
(This article belongs to the Section Biosensors)
Show Figures

Figure 1

20 pages, 4228 KiB
Article
Enhancing Robot Task Planning and Execution through Multi-Layer Large Language Models
by Zhirong Luan, Yujun Lai, Rundong Huang, Shuanghao Bai, Yuedi Zhang, Haoran Zhang and Qian Wang
Sensors 2024, 24(5), 1687; https://doi.org/10.3390/s24051687 - 06 Mar 2024
Viewed by 879
Abstract
Large language models have found utility in the domain of robot task planning and task decomposition. Nevertheless, the direct application of these models for instructing robots in task execution is not without its challenges. Limitations arise in handling more intricate tasks, encountering difficulties [...] Read more.
Large language models have found utility in the domain of robot task planning and task decomposition. Nevertheless, the direct application of these models for instructing robots in task execution is not without its challenges. Limitations arise in handling more intricate tasks, encountering difficulties in effective interaction with the environment, and facing constraints in the practical executability of machine control instructions directly generated by such models. In response to these challenges, this research advocates for the implementation of a multi-layer large language model to augment a robot’s proficiency in handling complex tasks. The proposed model facilitates a meticulous layer-by-layer decomposition of tasks through the integration of multiple large language models, with the overarching goal of enhancing the accuracy of task planning. Within the task decomposition process, a visual language model is introduced as a sensor for environment perception. The outcomes of this perception process are subsequently assimilated into the large language model, thereby amalgamating the task objectives with environmental information. This integration, in turn, results in the generation of robot motion planning tailored to the specific characteristics of the current environment. Furthermore, to enhance the executability of task planning outputs from the large language model, a semantic alignment method is introduced. This method aligns task planning descriptions with the functional requirements of robot motion, thereby refining the overall compatibility and coherence of the generated instructions. To validate the efficacy of the proposed approach, an experimental platform is established utilizing an intelligent unmanned vehicle. This platform serves as a means to empirically verify the proficiency of the multi-layer large language model in addressing the intricate challenges associated with both robot task planning and execution. Full article
(This article belongs to the Special Issue Mobile Robots: Navigation, Control and Sensing)
Show Figures

Figure 1

19 pages, 8194 KiB
Article
Efficient Vertical Structure Correlation and Power Line Inference
by Paul Flanigen, Ella Atkins and Nadine Sarter
Sensors 2024, 24(5), 1686; https://doi.org/10.3390/s24051686 - 05 Mar 2024
Viewed by 488
Abstract
High-resolution three-dimensional data from sensors such as LiDAR are sufficient to find power line towers and poles but do not reliably map relatively thin power lines. In addition, repeated detections of the same object can lead to confusion while data gaps ignore known [...] Read more.
High-resolution three-dimensional data from sensors such as LiDAR are sufficient to find power line towers and poles but do not reliably map relatively thin power lines. In addition, repeated detections of the same object can lead to confusion while data gaps ignore known obstacles. The slow or failed detection of low-salience vertical obstacles and associated wires is one of today’s leading causes of fatal helicopter accidents. This article presents a method to efficiently correlate vertical structure observations with existing databases and infer the presence of power lines. The method uses a spatial hash key which compares an observed tower location to potential existing tower locations using nested hash tables. When an observed tower is in the vicinity of an existing entry, the method correlates or distinguishes objects based on height and position. When applied to Delaware’s Digital Obstacle File, the average horizontal uncertainty decreased from 206 to 56 ft. The power line presence is inferred by automatically comparing the proportional spacing, height, and angle of tower sets based on the more accurate database. Over 87% of electrical transmission towers were correctly identified with no false negatives. Full article
(This article belongs to the Section Physical Sensors)
Show Figures

Figure 1

15 pages, 4018 KiB
Article
Measurement of 3D Wrist Angles by Combining Textile Stretch Sensors and AI Algorithm
by Jae-Ha Kim, Bon-Hak Koo, Sang-Un Kim and Joo-Yong Kim
Sensors 2024, 24(5), 1685; https://doi.org/10.3390/s24051685 - 05 Mar 2024
Viewed by 493
Abstract
The wrist is one of the most complex joints in our body, composed of eight bones. Therefore, measuring the angles of this intricate wrist movement can prove valuable in various fields such as sports analysis and rehabilitation. Textile stretch sensors can be easily [...] Read more.
The wrist is one of the most complex joints in our body, composed of eight bones. Therefore, measuring the angles of this intricate wrist movement can prove valuable in various fields such as sports analysis and rehabilitation. Textile stretch sensors can be easily produced by immersing an E-band in a SWCNT solution. The lightweight, cost-effective, and reproducible nature of textile stretch sensors makes them well suited for practical applications in clothing. In this paper, wrist angles were measured by attaching textile stretch sensors to an arm sleeve. Three sensors were utilized to measure all three axes of the wrist. Additionally, sensor precision was heightened through the utilization of the Multi-Layer Perceptron (MLP) technique, a subtype of deep learning. Rather than fixing the measurement values of each sensor to specific axes, we created an algorithm utilizing the coupling between sensors, allowing the measurement of wrist angles in three dimensions. Using this algorithm, the error angle of wrist angles measured with textile stretch sensors could be measured at less than 4.5°. This demonstrated higher accuracy compared to other soft sensors available for measuring wrist angles. Full article
(This article belongs to the Collection Sensors and AI for Movement Analysis)
Show Figures

Figure 1

20 pages, 7676 KiB
Article
Condition Monitoring of Railway Bridges Using Vehicle Pitch to Detect Scour
by Claire McGeown, David Hester, Eugene J. OBrien, Chul-Woo Kim, Paul Fitzgerald and Vikram Pakrashi
Sensors 2024, 24(5), 1684; https://doi.org/10.3390/s24051684 - 05 Mar 2024
Viewed by 644
Abstract
This study proposes the new condition monitoring concept of using features in the measured rotation, or ‘pitch’ signal, of a crossing vehicle as an indicator of the presence of foundation scour in a bridge. The concept is explored through two-dimensional vehicle–bridge interaction modelling, [...] Read more.
This study proposes the new condition monitoring concept of using features in the measured rotation, or ‘pitch’ signal, of a crossing vehicle as an indicator of the presence of foundation scour in a bridge. The concept is explored through two-dimensional vehicle–bridge interaction modelling, with a reduction in stiffness under a pier used to represent the effects of scour. A train consisting of three 10-degree-of-freedom carriages cross the model on a profiled train track, each train varying slightly in terms of mass and velocity. An analysis of the pitch of the train carriages can clearly identify when scour is present. The concept is further tested in a scaled laboratory experiment consisting of a tractor–trailer crossing a four-span simply supported bridge on piers. The foundation support is represented by four springs under each pier, which can be replaced with springs of a reduced stiffness to mimic the effect of scour. The laboratory model also consistently shows a divergence in vehicle pitch between healthy and scoured bridge states. Full article
(This article belongs to the Section Fault Diagnosis & Sensors)
Show Figures

Figure 1

23 pages, 19263 KiB
Article
Indication Variability of the Particulate Matter Sensors Dependent on Their Location
by Alicja Wiora, Józef Wiora and Jerzy Kasprzyk
Sensors 2024, 24(5), 1683; https://doi.org/10.3390/s24051683 - 05 Mar 2024
Viewed by 504
Abstract
Particulate matter (PM) suspended in the air significantly impacts human health. Those of anthropogenic origin are particularly hazardous. Poland is one of the countries where the air quality during the heating season is the worst in Europe. Air quality in small towns and [...] Read more.
Particulate matter (PM) suspended in the air significantly impacts human health. Those of anthropogenic origin are particularly hazardous. Poland is one of the countries where the air quality during the heating season is the worst in Europe. Air quality in small towns and villages far from state monitoring stations is often much worse than in larger cities where they are located. Their residents inhale the air containing smoke produced mainly by coal-fired stoves. In the frame of this project, an air quality monitoring network was built. It comprises low-cost PMS7003 PM sensors and ESP8266 microcontrollers with integrated Wi-Fi communication modules. This article presents research results on the influence of the PM sensor location on their indications. It has been shown that the indications from sensors several dozen meters away from each other can differ by up to tenfold, depending on weather conditions and the source of smoke. Therefore, measurements performed by a network of sensors, even of worse quality, are much more representative than those conducted in one spot. The results also indicated the method of detecting a sudden increase in air pollutants. In the case of smokiness, the difference between the mean and median indications of the PM sensor increases even up to 400 µg/m3 over a 5 min time window. Information from this comparison suggests a sudden deterioration in air quality and can allow for quick intervention to protect people’s health. This method can be used in protection systems where fast detection of anomalies is necessary. Full article
Show Figures

Figure 1

Previous Issue
Next Issue
Back to TopTop
