Sensors, Volume 18, Issue 11 (November 2018)

  • Issues are regarded as officially published after their release is announced to the table of contents alert mailing list.
  • You may sign up for e-mail alerts to receive table of contents of newly released issues.
  • PDF is the official format for papers published in both, html and pdf forms. To view the papers in pdf format, click on the "PDF Full-text" link, and use the free Adobe Readerexternal link to open them.
View options order results:
result details:
Displaying articles 1-426
Export citation of selected articles as:
Open AccessArticle A CMOS SPAD Imager with Collision Detection and 128 Dynamically Reallocating TDCs for Single-Photon Counting and 3D Time-of-Flight Imaging
Sensors 2018, 18(11), 4016; https://doi.org/10.3390/s18114016 (registering DOI)
Received: 5 October 2018 / Revised: 14 November 2018 / Accepted: 15 November 2018 / Published: 17 November 2018
PDF Full-text (10048 KB) | HTML Full-text | XML Full-text
Abstract
Per-pixel time-to-digital converter (TDC) architectures have been exploited by single-photon avalanche diode (SPAD) sensors to achieve high photon throughput, but at the expense of fill factor, pixel pitch and readout efficiency. In contrast, TDC sharing architecture usually features high fill factor at small
[...] Read more.
Per-pixel time-to-digital converter (TDC) architectures have been exploited by single-photon avalanche diode (SPAD) sensors to achieve high photon throughput, but at the expense of fill factor, pixel pitch and readout efficiency. In contrast, TDC sharing architecture usually features high fill factor at small pixel pitch and energy efficient event-driven readout. While the photon throughput is not necessarily lower than that of per-pixel TDC architectures, since the throughput is not only decided by the TDC number but also the readout bandwidth. In this paper, a SPAD sensor with 32 × 32 pixels fabricated with a 180 nm CMOS image sensor technology is presented, where dynamically reallocating TDCs were implemented to achieve the same photon throughput as that of per-pixel TDCs. Each 4 TDCs are shared by 32 pixels via a collision detection bus, which enables a fill factor of 28% with a pixel pitch of 28.5 μm. The TDCs were characterized, obtaining the peak-to-peak differential and integral non-linearity of −0.07/+0.08 LSB and −0.38/+0.75 LSB, respectively. The sensor was demonstrated in a scanning light-detection-and-ranging (LiDAR) system equipped with an ultra-low power laser, achieving depth imaging up to 10 m at 6 frames/s with a resolution of 64 × 64 with 50 lux background light. Full article
(This article belongs to the Special Issue The International SPAD Sensor Workshop)
Figures

Figure 1

Open AccessReview UAV IoT Framework Views and Challenges: Towards Protecting Drones as “Things”
Sensors 2018, 18(11), 4015; https://doi.org/10.3390/s18114015 (registering DOI)
Received: 20 October 2018 / Revised: 8 November 2018 / Accepted: 15 November 2018 / Published: 17 November 2018
PDF Full-text (4077 KB)
Abstract
Unmanned aerial vehicles (UAVs) have enormous potential in enabling new applications in various areas, ranging from military, security, medicine, and surveillance to traffic-monitoring applications. Lately, there has been heavy investment in the development of UAVs and multi-UAVs systems that can collaborate and complete
[...] Read more.
Unmanned aerial vehicles (UAVs) have enormous potential in enabling new applications in various areas, ranging from military, security, medicine, and surveillance to traffic-monitoring applications. Lately, there has been heavy investment in the development of UAVs and multi-UAVs systems that can collaborate and complete missions more efficiently and economically. Emerging technologies such as 4G/5G networks have significant potential on UAVs equipped with cameras, sensors, and GPS receivers in delivering Internet of Things (IoT) services from great heights, creating an airborne domain of the IoT. However, there are many issues to be resolved before the effective use of UAVs can be made, including security, privacy, and management. As such, in this paper we review new UAV application areas enabled by the IoT and 5G technologies, analyze the sensor requirements, and overview solutions for fleet management over aerial-networking, privacy, and security challenges. Finally, we propose a framework that supports and enables these technologies on UAVs. The introduced framework provisions a holistic IoT architecture that enables the protection of UAVs as “flying” things in a collaborative networked environment. Full article
(This article belongs to the Section Internet of Things)
Open AccessArticle Extended Joint Sparsity Reconstruction for Spatial and Temporal ERT Imaging
Sensors 2018, 18(11), 4014; https://doi.org/10.3390/s18114014 (registering DOI)
Received: 9 October 2018 / Revised: 6 November 2018 / Accepted: 12 November 2018 / Published: 17 November 2018
PDF Full-text (18618 KB) | HTML Full-text | XML Full-text
Abstract
Electrical resistance tomography (ERT) is an imaging technique to recover the conductivity distribution with boundary measurements via attached electrodes. There are a wide range of applications using ERT for image reconstruction or parameter calculation due to high speed data collection, low cost, and
[...] Read more.
Electrical resistance tomography (ERT) is an imaging technique to recover the conductivity distribution with boundary measurements via attached electrodes. There are a wide range of applications using ERT for image reconstruction or parameter calculation due to high speed data collection, low cost, and the advantages of being non-invasive and portable. Although ERT is considered a high temporal resolution method, a temporally regularized method can greatly enhance such a temporal resolution compared to frame-by-frame reconstruction. In some of the cases, especially in the industrial applications, dynamic movement of an object is critical. In practice, it is desirable for monitoring and controlling the dynamic process. ERT can determine the spatial conductivity distribution based on previous work, and ERT potentially shows good performance in exploiting temporal information as well. Many ERT algorithms reconstruct images frame by frame, which is not optimal and would assume that the target is static during collection of each data frame, which is inconsistent with the real case. Although spatiotemporal-based algorithms can account for the temporal effect of dynamic movement and can generate better results, there is not that much work aimed at analyzing the performance in the time domain. In this paper, we discuss the performance of a novel spatiotemporal total variation (STTV) algorithm in both the spatial and temporal domain, and Temporal One-Step Tikhonov-based algorithms were also employed for comparison. The experimental results show that the STTV has a faster response time for temporal variation of the moving object. This robust time response can contribute to a much better control process which is the main aim of the new generation of process tomography systems. Full article
(This article belongs to the Section Physical Sensors)
Figures

Figure 1

Open AccessArticle Smart Ocean: A New Fast Deconvolved Beamforming Algorithm for Multibeam Sonar
Sensors 2018, 18(11), 4013; https://doi.org/10.3390/s18114013 (registering DOI)
Received: 12 October 2018 / Revised: 12 November 2018 / Accepted: 13 November 2018 / Published: 17 November 2018
PDF Full-text (8159 KB) | HTML Full-text | XML Full-text
Abstract
A new fast deconvolved beamforming algorithm is proposed in this paper, and it can greatly reduce the computation complexity of the original Richardson–Lucy (R–L algorithm) deconvolution algorithm by utilizing the convolution theorem and the fast Fourier transform technique. This algorithm makes it possible
[...] Read more.
A new fast deconvolved beamforming algorithm is proposed in this paper, and it can greatly reduce the computation complexity of the original Richardson–Lucy (R–L algorithm) deconvolution algorithm by utilizing the convolution theorem and the fast Fourier transform technique. This algorithm makes it possible for real-time high-resolution beamforming in a multibeam sonar system. This paper applies the new fast deconvolved beamforming algorithm to a high-frequency multibeam sonar system to obtain a high bearing resolution and low side lobe. In the sounding mode, it restrains the tunnel effect and makes the topographic survey more accurate. In the 2D acoustic image mode, it can obtain clear images, more details, and can better distinguish two close targets. Detailed implementation methods of the fast deconvolved beamforming are given, its computational complexity is analyzed, and its performance is evaluated with simulated and real data. Full article
(This article belongs to the Special Issue Smart Ocean: Emerging Research Advances, Prospects and Challenges)
Figures

Figure 1

Open AccessArticle Mapping Mangrove Forests of Dongzhaigang Nature Reserve in China Using Landsat 8 and Radarsat-2 Polarimetric SAR Data
Sensors 2018, 18(11), 4012; https://doi.org/10.3390/s18114012 (registering DOI)
Received: 23 October 2018 / Revised: 14 November 2018 / Accepted: 14 November 2018 / Published: 17 November 2018
PDF Full-text (4761 KB) | HTML Full-text | XML Full-text
Abstract
Mangrove forests are distributed in intertidal regions that act as a “natural barrier” to the coast. They have enormous ecological, economic, and social value. However, the world’s mangrove forests are declining under immense pressure from anthropogenic and natural disturbances. Accurate information regarding mangrove
[...] Read more.
Mangrove forests are distributed in intertidal regions that act as a “natural barrier” to the coast. They have enormous ecological, economic, and social value. However, the world’s mangrove forests are declining under immense pressure from anthropogenic and natural disturbances. Accurate information regarding mangrove forests is essential for their protection and restoration. The main objective of this study was to develop a method to improve the classification of mangrove forests using C-band quad-pol Synthetic Aperture Radar (SAR) data (Radarsat-2) and optical data (Landsat 8), and to analyze the spectral and backscattering signatures of mangrove forests. We used a support vector machine (SVM) classification method to classify the land use in Hainan Dongzhaigang National Nature Reserve (HDNNR). The results showed that the overall accuracy using only optical information was 83.5%. Classification accuracy was improved to a varying extent by the addition of different radar data. The highest overall accuracy was 95.0% based on a combination of SAR and optical data. The area of mangrove forest in the reserve was found to be 1981.7 ha, as determined from the group with the highest classification accuracy. Combining optical data with SAR data could improve the classification accuracy and be significant for mangrove forest conservation. Full article
(This article belongs to the Section Remote Sensors)
Figures

Figure 1

Open AccessArticle A Novel Microfluidic Point-of-Care Biosensor System on Printed Circuit Board for Cytokine Detection
Sensors 2018, 18(11), 4011; https://doi.org/10.3390/s18114011 (registering DOI)
Received: 8 October 2018 / Revised: 6 November 2018 / Accepted: 12 November 2018 / Published: 17 November 2018
PDF Full-text (2395 KB) | HTML Full-text | XML Full-text
Abstract
Point of Care (PoC) diagnostics have been the subject of considerable research over the last few decades driven by the pressure to detect diseases quickly and effectively and reduce healthcare costs. Herein, we demonstrate a novel, fully integrated, microfluidic amperometric enzyme-linked immunosorbent assay
[...] Read more.
Point of Care (PoC) diagnostics have been the subject of considerable research over the last few decades driven by the pressure to detect diseases quickly and effectively and reduce healthcare costs. Herein, we demonstrate a novel, fully integrated, microfluidic amperometric enzyme-linked immunosorbent assay (ELISA) prototype using a commercial interferon gamma release assay (IGRA) as a model antibody binding system. Microfluidic assay chemistry was engineered to take place on Au-plated electrodes within an assay cell on a printed circuit board (PCB)-based biosensor system. The assay cell is linked to an electrochemical reporter cell comprising microfluidic architecture, Au working and counter electrodes and a Ag/AgCl reference electrode, all manufactured exclusively via standard commercial PCB fabrication processes. Assay chemistry has been optimised for microfluidic diffusion kinetics to function under continual flow. We characterised the electrode integrity of the developed platforms with reference to biological sampling and buffer composition and subsequently we demonstrated concentration-dependent measurements of H2O2 depletion as resolved by existing FDA-validated ELISA kits. Finally, we validated the assay technology in both buffer and serum and demonstrate limits of detection comparable to high-end commercial systems with the addition of full microfluidic assay architecture capable of returning diagnostic analyses in approximately eight minutes. Full article
(This article belongs to the Special Issue Portable Biosensing Systems for Point-of-Care Diagnostic Applications)
Figures

Figure 1

Open AccessArticle Measuring Sedentary Behavior by Means of Muscular Activity and Accelerometry
Sensors 2018, 18(11), 4010; https://doi.org/10.3390/s18114010 (registering DOI)
Received: 18 October 2018 / Revised: 6 November 2018 / Accepted: 15 November 2018 / Published: 17 November 2018
PDF Full-text (947 KB) | HTML Full-text | XML Full-text | Supplementary Files
Abstract
Sedentary Behavior (SB) is among the most frequent human behaviors and is associated with a plethora of serious chronic lifestyle diseases as well as premature death. Office workers in particular are at an increased risk due to their extensive amounts of occupational SB.
[...] Read more.
Sedentary Behavior (SB) is among the most frequent human behaviors and is associated with a plethora of serious chronic lifestyle diseases as well as premature death. Office workers in particular are at an increased risk due to their extensive amounts of occupational SB. However, we still lack an objective method to measure SB consistent with its definition. We have therefore developed a new measurement system based on muscular activity and accelerometry. The primary aim of the present study was to calibrate the new-developed 8-CH-EMG+ for measuring occupational SB against an indirect calorimeter during typical desk-based office work activities. In total, 25 volunteers performed nine office tasks at three typical workplaces. Minute-by-minute posture and activity classification was performed using subsequent decision trees developed with artificial intelligence data processing techniques. The 8-CH-EMG+ successfully identified all sitting episodes (AUC = 1.0). Furthermore, depending on the number of electromyography channels included, the device has a sensitivity of 83–98% and 74–98% to detect SB and active sitting (AUC = 0.85–0.91). The 8-CH-EMG+ advances the field of objective SB measurements by combining accelerometry with muscular activity. Future field studies should consider the use of EMG sensors to record SB in line with its definition. Full article
(This article belongs to the Section Intelligent Sensors)
Figures

Figure 1

Open AccessArticle Twisted Dual-Cycle Fiber Optic Bending Loss Characteristics for Strain Measurement
Sensors 2018, 18(11), 4009; https://doi.org/10.3390/s18114009 (registering DOI)
Received: 17 October 2018 / Revised: 9 November 2018 / Accepted: 15 November 2018 / Published: 16 November 2018
Viewed by 101 | PDF Full-text (3473 KB)
Abstract
The intensity-based fiber optic sensor (FOS) head using twisted dual-cycle bending loss is proposed and experimentally demonstrate. The bending loss characteristics depend on the steel wire radius, number, and distance. To determine the effects of these parameters, two samples in each of seven
[...] Read more.
The intensity-based fiber optic sensor (FOS) head using twisted dual-cycle bending loss is proposed and experimentally demonstrate. The bending loss characteristics depend on the steel wire radius, number, and distance. To determine the effects of these parameters, two samples in each of seven configuration cases of the proposed FOS head were bonded to fiber reinforced plastics coupons, and tensile and flexural strain tests were repeated five times for each coupon. The bending loss of the manufactured FOS heads was measured and converted to the tensile and flexural strain as a function of configuration cases. The measurement range, sensitivity, and average measurement errors of the tensile load and flexural strain were 4.5 kN and 1,760 με, 0.70 to 3.99 dB/kN and 0.930 to 6.554 dB/mm, and 57.7 N, and 42.6 με, respectively. The sensing range of FOS head were 82 to 138 mm according to configuration cases. These results indicate that it is possible to measure load, tensile strain, and flexural strain using the proposed FOS head, and demonstrate that the sensitivities, the operating ranges, and the sensing range can be adjusted depending on the deformation characteristics of the measurement target. Full article
(This article belongs to the Special Issue Fiber Optic Sensors for Structural and Geotechnical Monitoring)
Open AccessArticle Autonomous Robot-Guided Inspection System Based on Offline Programming and RGB-D Model
Sensors 2018, 18(11), 4008; https://doi.org/10.3390/s18114008 (registering DOI)
Received: 10 October 2018 / Revised: 8 November 2018 / Accepted: 14 November 2018 / Published: 16 November 2018
Viewed by 119 | PDF Full-text (15789 KB) | HTML Full-text | XML Full-text
Abstract
Automatic optical inspection (AOI) is a control process for precisely evaluating the completeness and quality of manufactured products with the help of visual information. Automatic optical inspection systems include cameras, light sources, and objects; AOI requires expert operators and time-consuming setup processes. In
[...] Read more.
Automatic optical inspection (AOI) is a control process for precisely evaluating the completeness and quality of manufactured products with the help of visual information. Automatic optical inspection systems include cameras, light sources, and objects; AOI requires expert operators and time-consuming setup processes. In this study, a novel autonomous industrial robot-guided inspection system was hypothesized and developed to expedite and ease inspection process development. The developed platform is an intuitive and interactive system that does not require a physical object to test or an industrial robot; this allows nonexpert operators to perform object inspection planning by only using scanned data. The proposed system comprises an offline programming (OLP) platform and three-dimensional/two-dimensional (3D/2D) vision module. A robot program generated from the OLP platform is mapped to an industrial manipulator to scan a 3D point-cloud model of an object by using a laser triangulation sensor. After a reconstructed 3D model is aligned with a computer-aided design model on a common coordinate system, the OLP platform allows users to efficiently fine-tune the required inspection positions on the basis of the rendered images. The arranged inspection positions can be directed to an industrial manipulator on a production line to capture real images by using the corresponding 2D camera/lens setup for AOI tasks. This innovative system can be implemented in smart factories, which are easily manageable from multiple locations. Workers can save scanned data when new inspection positions are included based on cloud data. The present system provides a new direction to cloud-based manufacturing industries and maximizes the flexibility and efficiency of the AOI setup process to increase productivity. Full article
(This article belongs to the Section Physical Sensors)
Figures

Figure 1

Open AccessArticle High Precision Position Measurement Method for Laguerre-Gaussian Beams Using a Quadrant Detector
Sensors 2018, 18(11), 4007; https://doi.org/10.3390/s18114007 (registering DOI)
Received: 27 September 2018 / Revised: 12 November 2018 / Accepted: 14 November 2018 / Published: 16 November 2018
Viewed by 101 | PDF Full-text (988 KB)
Abstract
In this paper, we propose a new method to improve the position measurement accuracy for Laguerre-Gaussian beams on a quadrant detector (QD). First, the error effects of the detector diameter and the gap size are taken into account, and the position error compensation
[...] Read more.
In this paper, we propose a new method to improve the position measurement accuracy for Laguerre-Gaussian beams on a quadrant detector (QD). First, the error effects of the detector diameter and the gap size are taken into account, and the position error compensation factor is introduced into the conventional formula. Then, in order to reduce the number of parameters, the concept of effective radius is proposed. Thus, a new analytical expression is obtained with a best fit using the least square method. It is verified by simulation that this approach can reduce the maximum error by 97.4% when the beam radius is 0.95 mm; meanwhile, the root mean square errors under different radii are all less than 0.004 mm. The results of simulation show that the new method could effectively improve the accuracy of the QD measurement for different radii. Therefore, the new method would have a good prospect in the engineering practice of beam position measurements. Full article
(This article belongs to the Special Issue Infrared Sensors and Technologies)
Open AccessArticle Dictionary Learning Phase Retrieval from Noisy Diffraction Patterns
Sensors 2018, 18(11), 4006; https://doi.org/10.3390/s18114006 (registering DOI)
Received: 15 October 2018 / Revised: 13 November 2018 / Accepted: 14 November 2018 / Published: 16 November 2018
Viewed by 105 | PDF Full-text (5082 KB)
Abstract
This paper proposes a novel algorithm for image phase retrieval, i.e., for recovering complex-valued images from the amplitudes of noisy linear combinations (often the Fourier transform) of the sought complex images. The algorithm is developed using the alternating projection framework and is aimed
[...] Read more.
This paper proposes a novel algorithm for image phase retrieval, i.e., for recovering complex-valued images from the amplitudes of noisy linear combinations (often the Fourier transform) of the sought complex images. The algorithm is developed using the alternating projection framework and is aimed to obtain high performance for heavily noisy (Poissonian or Gaussian) observations. The estimation of the target images is reformulated as a sparse regression, often termed sparse coding, in the complex domain. This is accomplished by learning a complex domain dictionary from the data it represents via matrix factorization with sparsity constraints on the code (i.e., the regression coefficients). Our algorithm, termed dictionary learning phase retrieval (DLPR), jointly learns the referred to dictionary and reconstructs the unknown target image. The effectiveness of DLPR is illustrated through experiments conducted on complex images, simulated and real, where it shows noticeable advantages over the state-of-the-art competitors. Full article
(This article belongs to the Section Physical Sensors)
Open AccessArticle A High-Sensitivity Microfluidic Sensor Based on a Substrate Integrated Waveguide Re-Entrant Cavity for Complex Permittivity Measurement of Liquids
Sensors 2018, 18(11), 4005; https://doi.org/10.3390/s18114005 (registering DOI)
Received: 19 October 2018 / Revised: 8 November 2018 / Accepted: 14 November 2018 / Published: 16 November 2018
Viewed by 104 | PDF Full-text (6072 KB) | HTML Full-text | XML Full-text
Abstract
In this study, a novel non-invasive and contactless microwave sensor using a square substrate integrated waveguide (SIW) re-entrant cavity is proposed for complex permittivity measurement of chemical solutions. The working principle of this sensor is based on cavity perturbation technique, in which the
[...] Read more.
In this study, a novel non-invasive and contactless microwave sensor using a square substrate integrated waveguide (SIW) re-entrant cavity is proposed for complex permittivity measurement of chemical solutions. The working principle of this sensor is based on cavity perturbation technique, in which the resonant properties of cavity are utilized as signatures to extract the dielectric information of liquid under test (LUT). A winding microfluidic channel is designed and embedded in the gap region of the cavity to obtain a strong interaction between the induced electric field and LUT, thus achieving a high sensitivity. Also, a mathematical predictive model which quantitatively associates the resonant properties of the sensor with the dielectric constant of LUT is developed through numerical analysis. Using this predictive model, quick and accurate extraction of the complex permittivity of LUT can be easily realized. The performance of this sensor is then experimentally validated by four pure chemicals (hexane, ethyl acetate, DMSO and water) together with a set of acetone/water mixtures in various concentrations. Experimental results demonstrate that the designed sensor is capable of characterizing the complex permittivities of various liquids with an accuracy of higher than 96.76% (compared with the theoretical values obtained by Debye relaxation equations), and it is also available for quantifying the concentration ratio of a given binary mixture. Full article
(This article belongs to the Special Issue RF Technology for Sensor Applications)
Figures

Graphical abstract

Open AccessArticle Measuring Linewidth Enhancement Factor by Relaxation Oscillation Frequency in a Laser with Optical Feedback
Sensors 2018, 18(11), 4004; https://doi.org/10.3390/s18114004 (registering DOI)
Received: 2 October 2018 / Revised: 12 November 2018 / Accepted: 15 November 2018 / Published: 16 November 2018
Viewed by 96 | PDF Full-text (666 KB)
Abstract
This paper presents a new method for measuring the linewidth enhancement factor (alpha factor) by the relaxation oscillation (RO) frequency of a laser with external optical feedback (EOF). A measurement formula for alpha is derived which shows the alpha can be determined by
[...] Read more.
This paper presents a new method for measuring the linewidth enhancement factor (alpha factor) by the relaxation oscillation (RO) frequency of a laser with external optical feedback (EOF). A measurement formula for alpha is derived which shows the alpha can be determined by only using the RO frequencies and no need to know any other parameters related to the internal or external parameters associated to the laser. Unlike the existing EOF based alpha measurement methods which require an external target has a symmetric reciprocate movement. The proposed method only needs to move the target to be in a few different positions along the light beam. Furthermore, this method also suits for the case with alpha less than 1. Both simulation and experiment are performed to verify the proposed method. Full article
(This article belongs to the Special Issue Optoelectronic and Photonic Sensors)
Open AccessArticle Quaternion-Based Local Frame Alignment between an Inertial Measurement Unit and a Motion Capture System
Sensors 2018, 18(11), 4003; https://doi.org/10.3390/s18114003 (registering DOI)
Received: 13 August 2018 / Revised: 9 November 2018 / Accepted: 15 November 2018 / Published: 16 November 2018
Viewed by 109 | PDF Full-text (1001 KB) | HTML Full-text | XML Full-text | Supplementary Files
Abstract
Local frame alignment between an inertial measurement unit (IMU) system and an optical motion capture system (MCS) is necessary to combine the two systems for motion analysis and to validate the accuracy of IMU-based motion data by using references obtained through the MCS.
[...] Read more.
Local frame alignment between an inertial measurement unit (IMU) system and an optical motion capture system (MCS) is necessary to combine the two systems for motion analysis and to validate the accuracy of IMU-based motion data by using references obtained through the MCS. In this study, we propose a new quaternion-based local frame alignment method where equations of angular velocity transformation are used to determine the frame alignment orientation in the form of quaternion. The performance of the proposed method was compared with those of three other methods by using data with different angular velocities, noises, and alignment orientations. Furthermore, the effects of the following three factors on the estimation performance were investigated for the first time: (i) transformation concept, i.e., angular velocity transformation vs. angle transformation; (ii) orientation representations, i.e., quaternion vs. direction cosine matrix (DCM); and (iii) applied solvers, i.e., nonlinear least squares method vs. least squares method through pseudoinverse. Within our limited test data, we obtained the following results: (i) the methods using angular velocity transformation were better than the method using angle transformation; (ii) the quaternion is more suitable than the DCM; and (iii) the applied solvers were not critical in general. The proposed method performed the best among the four methods. We surmise that the fewer number of components and constraints of the quaternion in the proposed method compared to the number of components and constraints of the DCM-based methods may result in better accuracy. Owing to the high accuracy and easy setup, the proposed method can be effectively used for local frame alignment between an IMU and a motion capture system. Full article
(This article belongs to the Section Physical Sensors)
Figures

Figure 1

Open AccessArticle A Portable Smartphone-Based Sensing System Using a 3D-Printed Chip for On-Site Biochemical Assays
Sensors 2018, 18(11), 4002; https://doi.org/10.3390/s18114002 (registering DOI)
Received: 15 October 2018 / Revised: 8 November 2018 / Accepted: 13 November 2018 / Published: 16 November 2018
Viewed by 106 | PDF Full-text (4496 KB) | HTML Full-text | XML Full-text | Supplementary Files
Abstract
Recently, smartphone-based chromogenic sensing with paper-based microfluidic technology has played an increasingly important role in biochemical assays. However, generally there were three defects: (i) the paper-based chips still required complicated fabrication, and the hydrophobic boundaries on the chips were not clear enough; (ii)
[...] Read more.
Recently, smartphone-based chromogenic sensing with paper-based microfluidic technology has played an increasingly important role in biochemical assays. However, generally there were three defects: (i) the paper-based chips still required complicated fabrication, and the hydrophobic boundaries on the chips were not clear enough; (ii) the chromogenic signals could not be steadily captured; (iii) the smartphone apps were restricted to the detection of specific target analytes and could not be extended for different assays unless reprogrammed. To solve these problems, in this study, a portable smartphone-based sensing system with a 3D-printed chip was developed. A 3D-printed imaging platform was designed to significantly reduce sensing errors generated during signal capture, and a brand-new strategy for signal processing in downloadable apps was established. As a proof-of-concept, the system was applied for detection of organophosphorus pesticides and multi-assay of fruit juice, showing excellent sensing performance. For different target analytes, the most efficient color channel could be selected for signal analysis, and the calibration equation could be directly set in user interface rather than programming environment, thus the developed system could be flexibly extended for other biochemical assays. Consequently, this study provides a novel methodology for smartphone-based biochemical sensing. Full article
(This article belongs to the Section Chemical Sensors)
Figures

Figure 1

Open AccessArticle Reliable Positioning and mmWave Communication via Multi-Point Connectivity
Sensors 2018, 18(11), 4001; https://doi.org/10.3390/s18114001 (registering DOI)
Received: 12 October 2018 / Revised: 6 November 2018 / Accepted: 13 November 2018 / Published: 16 November 2018
Viewed by 101 | PDF Full-text (1044 KB)
Abstract
One of the key elements of future 5G and beyond mobile technology is millimeter-wave (mmWave) communications, which is targeted to extreme high-data rate services. Furthermore, combining the possibility of a wideband signal transmission with the capability of pencil-beamforming, mmWave technology is key for
[...] Read more.
One of the key elements of future 5G and beyond mobile technology is millimeter-wave (mmWave) communications, which is targeted to extreme high-data rate services. Furthermore, combining the possibility of a wideband signal transmission with the capability of pencil-beamforming, mmWave technology is key for accurate cellular-based positioning. However, it is also well-known that at the mmWave frequency band the radio channel is very sensitive to line-of-sight blockages giving rise to unstable connectivity and inefficient communication. In this paper, we tackle the blockage problem and propose a solution to increase the communication reliability by means of a coordinated multi-point reception. We also investigate the advantage of this solution in terms of positioning quality. More specifically, we describe a robust hybrid analog–digital receive beamforming strategy to combat the unavailability of dominant links. Numerical examples are provided to validate the efficiency of our proposed method. Full article
Open AccessArticle An Efficient Algorithm for Partial Discharge Localization in High-Voltage Systems Using Received Signal Strength
Sensors 2018, 18(11), 4000; https://doi.org/10.3390/s18114000 (registering DOI)
Received: 24 October 2018 / Revised: 9 November 2018 / Accepted: 14 November 2018 / Published: 16 November 2018
Viewed by 100 | PDF Full-text (4999 KB) | HTML Full-text | XML Full-text
Abstract
The term partial discharge (PD) refers to a partial bridging of insulating material between electrodes that sustain an electric field in high-voltage (HV) systems. Long-term PD activity can lead to catastrophic failures of HV systems resulting in economic, energy and even human life
[...] Read more.
The term partial discharge (PD) refers to a partial bridging of insulating material between electrodes that sustain an electric field in high-voltage (HV) systems. Long-term PD activity can lead to catastrophic failures of HV systems resulting in economic, energy and even human life losses. Such failures and losses can be avoided by continuously monitoring PD activity. Existing techniques used for PD localization including time of arrival (TOA) and time difference of arrival (TDOA), are complicated and expensive because they require time synchronization. In this paper, a novel received signal strength (RSS) based localization algorithm is proposed. The reason that RSS is favoured in this research is that it does not require clock synchronization and it only requires the energy of the received signal rather than the PD pulse itself. A comparison was made between RSS based algorithms including a proposed algorithm, the ratio and search and the least squares algorithm to locate a PD source for nine different positions. The performance of the algorithms was evaluated by using two field scenarios based on seven and eight receiving nodes, respectively. The mean localization error calculated for two-field-trial scenarios show, respectively, 1.80 m and 1.76 m for the proposed algorithm for all nine positions, which is the lowest of the three algorithms. Full article
(This article belongs to the Special Issue UHF and RF Sensor Technology for Partial Discharge Detection)
Figures

Figure 1

Open AccessReview Location Information Quality: A Review
Sensors 2018, 18(11), 3999; https://doi.org/10.3390/s18113999 (registering DOI)
Received: 4 September 2018 / Revised: 7 November 2018 / Accepted: 9 November 2018 / Published: 16 November 2018
Viewed by 90 | PDF Full-text (850 KB)
Abstract
The quality of location information is an important factor for location-based services (LBSs). In the literature, the quality of location information has been defined in different ways based on varying sets of aspects. The objectives of this paper are to review existing literature
[...] Read more.
The quality of location information is an important factor for location-based services (LBSs). In the literature, the quality of location information has been defined in different ways based on varying sets of aspects. The objectives of this paper are to review existing literature discussing location information quality and to provide a consistent framework for describing and dealing with location information quality. In particular, we review existing literature on different aspects of location information quality and on factors that affect location sensing technologies (and thus location information quality). Based on this review, we also propose a simple model for describing location information quality and a classification of the strategies for dealing with variations in the quality of location information. Designers of location sensing systems can use this model as a standard vocabulary for describing the quality of location information. The classification of strategies can be used by developers of LBSs apps to design alternative strategies for dealing with location information quality on three levels: sensor-level, algorithm-level, and application-level, which are aligned with the Location Stack model. Full article
(This article belongs to the Section Physical Sensors)
Figures

Graphical abstract

Open AccessArticle Sensitive Hg2+ Sensing via Quenching the Fluorescence of the Complex between Polythymine and 5,10,15,20-tetrakis(N-methyl-4-pyridyl) Porphyrin (TMPyP)
Sensors 2018, 18(11), 3998; https://doi.org/10.3390/s18113998 (registering DOI)
Received: 26 October 2018 / Revised: 8 November 2018 / Accepted: 14 November 2018 / Published: 16 November 2018
Viewed by 101 | PDF Full-text (1710 KB) | HTML Full-text | XML Full-text
Abstract
The interaction between polythymine (dTn) and 5,10,15,20-tetrakis(N-methyl-4-pyridyl) porphyrin (TMPyP) was systematically studied using various techniques. dTn remarkably enhanced the fluorescence intensity of TMPyP as compared to other oligonucleotides. The enhanced fluorescence intensity and the shift of the emission peaks were ascribed to the
[...] Read more.
The interaction between polythymine (dTn) and 5,10,15,20-tetrakis(N-methyl-4-pyridyl) porphyrin (TMPyP) was systematically studied using various techniques. dTn remarkably enhanced the fluorescence intensity of TMPyP as compared to other oligonucleotides. The enhanced fluorescence intensity and the shift of the emission peaks were ascribed to the formation of a π-π complex between TMPyP and dTn. And the quenching of the dTn-enhanced fluorescence by Hg2+ through a synergistic effect occurs due to the heavy atom effect. The binding of Hg2+ to TMPyP plays an important role in the Hg-TMPyP-dT30 ternary complex formation. A TMPyP-dT30-based Hg2+ sensor was developed with a dynamic range of Hg2+ from 5 nM to 100 nM. The detection limit of 1.3 nM was low enough for Hg2+ determination. The sensor also exhibited good selectivity against other metal ions. Experiments for tap water and river water demonstrated that the detection method was applicable for Hg2+ determination in real samples. The Hg2+ sensor based on oligonucleotide dT30-enhanced TMPyP fluorescence was fast and low-cost, presenting a promising platform for practical Hg2+ determination. Full article
(This article belongs to the Section Biosensors)
Figures

Figure 1

Open AccessArticle Millimeter Wave Vehicular Channel Emulation: A Framework for Balancing Complexity and Accuracy
Sensors 2018, 18(11), 3997; https://doi.org/10.3390/s18113997 (registering DOI)
Received: 11 October 2018 / Revised: 8 November 2018 / Accepted: 13 November 2018 / Published: 16 November 2018
Viewed by 108 | PDF Full-text (4644 KB) | HTML Full-text | XML Full-text
Abstract
We propose a general framework for the specification of a sparse representation of millimeter wave vehicular propagation channels and apply this to both synthetic data and real-world observations from channel sounding experiments. The proposed framework is based on the c-LASSO (complex Least Absolute
[...] Read more.
We propose a general framework for the specification of a sparse representation of millimeter wave vehicular propagation channels and apply this to both synthetic data and real-world observations from channel sounding experiments. The proposed framework is based on the c-LASSO (complex Least Absolute Shrinkage and Selection Operator) which minimizes the mean squared error of the sparse representation for a given number of degrees of freedom. By choosing the number of degrees of freedom, we balance the numerical complexity of the representation in the channel emulation against its accuracy in terms of the mean squared error. A key ingredient is the choice of basis of the representation and we discuss two options: the Fourier basis and its projection onto a given subband. The results indicate that the subband-projected Fourier basis is a low-complexity choice with high fidelity for representing clustered channel impulse responses. Finally, a sequential estimator is formulated which enforces a consistent temporal evolution of the geometry of the interacting objects in the propagation environment. We demonstrate the performance of our approach using both synthetic data and measured 60 GHz vehicular channel traces. Full article
(This article belongs to the Special Issue Enhances in V2X Communications for Connected Autonomous Vehicles)
Figures

Figure 1

Open AccessArticle Space-Based Focal Plane Ambiguous Measurement Ballistic Target MeMber Tracking
Sensors 2018, 18(11), 3996; https://doi.org/10.3390/s18113996 (registering DOI)
Received: 21 October 2018 / Revised: 10 November 2018 / Accepted: 14 November 2018 / Published: 16 November 2018
Viewed by 99 | PDF Full-text (2531 KB) | HTML Full-text | XML Full-text
Abstract
Aimed at space-based passive detection and tracking of ballistic targets, a multi-target multi-Bernoulli (MeMber) filtering algorithm based on a focal plane ambiguous measurement model is proposed. The measurement error sources of space-based passive detection are analyzed. It is found that focal plane target
[...] Read more.
Aimed at space-based passive detection and tracking of ballistic targets, a multi-target multi-Bernoulli (MeMber) filtering algorithm based on a focal plane ambiguous measurement model is proposed. The measurement error sources of space-based passive detection are analyzed. It is found that focal plane target tracking is the basis of space target tracking in the framework of the distributed data processing structure, and the main error of focal plane measurement is pixel resolution. Based on the above analysis, the focal plane ambiguous measurement model is established to replace the traditional measurement model and the generalized likelihood function is designed. Finally, the MeMber filter is modified based on ambiguous measurement and generalized likelihood function. The simulation experiment compares the tracking effect of a MeMber filter based on ambiguous measurement and traditional measurement, respectively. The filter based on ambiguous measurement achieves better results. It shows that ambiguous measurement is closer to reality and has more application value. Full article
(This article belongs to the Special Issue Satellite and Airborne Remote Sensing for Earth Monitoring)
Figures

Figure 1

Open AccessReview A Survey of LoRaWAN for IoT: From Technology to Application
Sensors 2018, 18(11), 3995; https://doi.org/10.3390/s18113995 (registering DOI)
Received: 26 October 2018 / Revised: 12 November 2018 / Accepted: 13 November 2018 / Published: 16 November 2018
Viewed by 112 | PDF Full-text (1024 KB) | HTML Full-text | XML Full-text
Abstract
LoRaWAN is one of the low power wide area network (LPWAN) technologies that have received significant attention by the research community in the recent years. It offers low-power, low-data rate communication over a wide range of covered area. In the past years, the
[...] Read more.
LoRaWAN is one of the low power wide area network (LPWAN) technologies that have received significant attention by the research community in the recent years. It offers low-power, low-data rate communication over a wide range of covered area. In the past years, the number of publications regarding LoRa and LoRaWAN has grown tremendously. This paper provides an overview of research work that has been published from 2015 to September 2018 and that is accessible via Google Scholar and IEEE Explore databases. First, a detailed description of the technology is given, including existing security and reliability mechanisms. This literature overview is structured by categorizing papers according to the following topics: (i) physical layer aspects; (ii) network layer aspects; (iii) possible improvements; and (iv) extensions to the standard. Finally, a strengths, weaknesses, opportunities and threats (SWOT) analysis is presented along with the challenges that LoRa and LoRaWAN still face. Full article
(This article belongs to the Section Internet of Things)
Figures

Figure 1

Open AccessArticle Training-Based Methods for Comparison of Object Detection Methods for Visual Object Tracking
Sensors 2018, 18(11), 3994; https://doi.org/10.3390/s18113994 (registering DOI)
Received: 27 August 2018 / Revised: 29 October 2018 / Accepted: 4 November 2018 / Published: 16 November 2018
Viewed by 116 | PDF Full-text (6395 KB) | HTML Full-text | XML Full-text
Abstract
Object tracking in challenging videos is a hot topic in machine vision. Recently, novel training-based detectors, especially using the powerful deep learning schemes, have been proposed to detect objects in still images. However, there is still a semantic gap between the object detectors
[...] Read more.
Object tracking in challenging videos is a hot topic in machine vision. Recently, novel training-based detectors, especially using the powerful deep learning schemes, have been proposed to detect objects in still images. However, there is still a semantic gap between the object detectors and higher level applications like object tracking in videos. This paper presents a comparative study of outstanding learning-based object detectors such as ACF, Region-Based Convolutional Neural Network (RCNN), FastRCNN, FasterRCNN and You Only Look Once (YOLO) for object tracking. We use an online and offline training method for tracking. The online tracker trains the detectors with a generated synthetic set of images from the object of interest in the first frame. Then, the detectors detect the objects of interest in the next frames. The detector is updated online by using the detected objects from the last frames of the video. The offline tracker uses the detector for object detection in still images and then a tracker based on Kalman filter associates the objects among video frames. Our research is performed on a TLD dataset which contains challenging situations for tracking. Source codes and implementation details for the trackers are published to make both the reproduction of the results reported in this paper and the re-use and further development of the trackers for other researchers. The results demonstrate that ACF and YOLO trackers show more stability than the other trackers. Full article
(This article belongs to the Section Physical Sensors)
Figures

Figure 1

Open AccessArticle Computational Assessment of Facial Expression Production in ASD Children
Sensors 2018, 18(11), 3993; https://doi.org/10.3390/s18113993 (registering DOI)
Received: 4 October 2018 / Revised: 9 November 2018 / Accepted: 14 November 2018 / Published: 16 November 2018
Viewed by 112 | PDF Full-text (1423 KB) | HTML Full-text | XML Full-text
Abstract
In this paper, a computational approach is proposed and put into practice to assess the capability of children having had diagnosed Autism Spectrum Disorders (ASD) to produce facial expressions. The proposed approach is based on computer vision components working on sequence of images
[...] Read more.
In this paper, a computational approach is proposed and put into practice to assess the capability of children having had diagnosed Autism Spectrum Disorders (ASD) to produce facial expressions. The proposed approach is based on computer vision components working on sequence of images acquired by an off-the-shelf camera in unconstrained conditions. Action unit intensities are estimated by analyzing local appearance and then both temporal and geometrical relationships, learned by Convolutional Neural Networks, are exploited to regularize gathered estimates. To cope with stereotyped movements and to highlight even subtle voluntary movements of facial muscles, a personalized and contextual statistical modeling of non-emotional face is formulated and used as a reference. Experimental results demonstrate how the proposed pipeline can improve the analysis of facial expressions produced by ASD children. A comparison of system’s outputs with the evaluations performed by psychologists, on the same group of ASD children, makes evident how the performed quantitative analysis of children’s abilities helps to go beyond the traditional qualitative ASD assessment/diagnosis protocols, whose outcomes are affected by human limitations in observing and understanding multi-cues behaviors such as facial expressions. Full article
(This article belongs to the Special Issue Semantic Representations for Behavior Analysis in Robotic system)
Figures

Figure 1

Open AccessArticle M2M Communication Assessment in Energy-Harvesting and Wake-Up Radio Assisted Scenarios Using Practical Components
Sensors 2018, 18(11), 3992; https://doi.org/10.3390/s18113992 (registering DOI)
Received: 14 August 2018 / Revised: 2 November 2018 / Accepted: 12 November 2018 / Published: 16 November 2018
Viewed by 109 | PDF Full-text (585 KB) | HTML Full-text | XML Full-text
Abstract
Techniques for wireless energy harvesting (WEH) are emerging as a fascinating set of solutions to extend the lifetime of energy-constrained wireless networks, and are commonly regarded as a key functional technique for almost perpetual communications. For example, with WEH technology, wireless devices are
[...] Read more.
Techniques for wireless energy harvesting (WEH) are emerging as a fascinating set of solutions to extend the lifetime of energy-constrained wireless networks, and are commonly regarded as a key functional technique for almost perpetual communications. For example, with WEH technology, wireless devices are able to harvest energy from different light sources or Radio Frequency (RF) signals broadcast by ambient or dedicated wireless transmitters to support their operation and communications capabilities. WEH technology will have increasingly wider range of use in upcoming applications such as wireless sensor networks, Machine-to-Machine (M2M) communications, and the Internet of Things. In this paper, the usability and fundamental limits of joint RF and solar cell or photovoltaic harvesting based M2M communication systems are studied and presented. The derived theoretical bounds are in essence based on the Shannon capacity theorem, combined with selected propagation loss models, assumed additional link nonidealities, diversity processing, as well as the given energy harvesting and storage capabilities. Fundamental performance limits and available capacity of the communicating link are derived and analyzed, together with extensive numerical results evaluated in different practical scenarios, including realistic implementation losses and state-of-the-art printed supercapacitor performance figures with voltage doubler-based voltage regulator. In particular, low power sensor type communication applications using passive and semi-passive wake-up radio (WuR) are addressed in the study. The presented analysis principles and results establish clear feasibility regions and performance bounds for wireless energy harvesting based low rate M2M communications in the future IoT networks. Full article
Figures

Figure 1

Open AccessArticle Mobile Helical Capacitive Sensor for the Dynamic Identification of Obstructions in the Distribution of Solid Mineral Fertilizers
Sensors 2018, 18(11), 3991; https://doi.org/10.3390/s18113991 (registering DOI)
Received: 1 October 2018 / Revised: 26 October 2018 / Accepted: 30 October 2018 / Published: 16 November 2018
Viewed by 107 | PDF Full-text (5421 KB) | HTML Full-text | XML Full-text
Abstract
Modern agriculture uses techniques and technologies that have provided farmers with increased yield and a possible reduction in costs. Optimizing the use of inputs by applying exact and accurate doses, which match the real needs of the soil, in addition to supplying the
[...] Read more.
Modern agriculture uses techniques and technologies that have provided farmers with increased yield and a possible reduction in costs. Optimizing the use of inputs by applying exact and accurate doses, which match the real needs of the soil, in addition to supplying the necessary nutrients for the correct development of the crops, enables a reduction in costs and environmental impacts caused by the incorrect use of products such as fertilizers and pesticides. With this background, this paper presents a study on the development of a capacitive sensor to identify the absence, presence or variations in the distribution of solid mineral fertilizers. To evaluate this sensor, eight different formulations were tested in distribution analysis with an overflow dosing mechanism, both statically and dynamically, with 2% maximum moisture variation between all samples. The identification of an absence or presence of fertilizers was successful in 100% of the experiments. Tests to identify variations in the fertilizer distribution were carried out through simulated obstruction. The sensor identified a reduction in the fertilizer flow in all experiments, obtaining numeric variations above 55%. In the fertilizer formulation identification test, only the formulations 02-28-20 and 06-21-12 in experiments carried out with the overflow dosing mechanism did not differ statistically one from another, while all other formulations presented a statistically significant difference in the ANOVA analysis and the Tukey test at 5% significance. Full article
(This article belongs to the Section Remote Sensors)
Figures

Figure 1

Open AccessArticle Influence of Stainless Needle Electrodes and Silver Disk Electrodes over the Interhemispheric Cerebral Coherence Value in Vigil Dogs
Sensors 2018, 18(11), 3990; https://doi.org/10.3390/s18113990 (registering DOI)
Received: 8 October 2018 / Revised: 12 November 2018 / Accepted: 13 November 2018 / Published: 16 November 2018
Viewed by 120 | PDF Full-text (939 KB) | HTML Full-text | XML Full-text
Abstract
Electroencephalography (EEG) is an objective diagnostic tool in the evaluation of cerebral functionality, both in human and veterinary medicine. For EEG acquisition, different types of electrodes are used, as long as they have no impact on the recorded background activity. However, to date,
[...] Read more.
Electroencephalography (EEG) is an objective diagnostic tool in the evaluation of cerebral functionality, both in human and veterinary medicine. For EEG acquisition, different types of electrodes are used, as long as they have no impact on the recorded background activity. However, to date, the influence of electrode type on quantitative EEG and cerebral coherence has not been investigated. Twenty EEG traces (ten with needle electrodes and ten with disk electrodes) were recorded from ten mesocephalic vigil dogs in a monopolar montage. Values for interhemispheric coherence for each frequency band were compared between stainless needle and silver disk electrodes traces. Our results show that the values of interhemispheric coherence in vigil dogs are depending of the type of electrodes used in EEG recordings. In the frontal (FP) channel, for delta and theta frequency bands, the registered coherence is significantly higher when stainless needle electrodes are used. Our results might have important consequences in the field of canine neurology and applied neuroscience, as the frontal channel analysis is preferred in aging and behavior studies. Full article
(This article belongs to the Special Issue EEG Electrodes)
Figures

Figure 1

Open AccessArticle Label-Free Time-Gated Luminescent Detection Method for the Nucleotides with Varying Phosphate Content
Sensors 2018, 18(11), 3989; https://doi.org/10.3390/s18113989 (registering DOI)
Received: 3 October 2018 / Revised: 11 November 2018 / Accepted: 12 November 2018 / Published: 16 November 2018
Viewed by 89 | PDF Full-text (1037 KB) | HTML Full-text | XML Full-text | Supplementary Files
Abstract
A new label-free molecular probe for luminescent nucleotide detection in neutral aqueous solution is presented. Phosphate-containing molecules, such as nucleotides possess vital role in cell metabolism, energy economy, and various signaling processes. Thus, the monitoring of nucleotide concentration and nucleotide related enzymatic reactions
[...] Read more.
A new label-free molecular probe for luminescent nucleotide detection in neutral aqueous solution is presented. Phosphate-containing molecules, such as nucleotides possess vital role in cell metabolism, energy economy, and various signaling processes. Thus, the monitoring of nucleotide concentration and nucleotide related enzymatic reactions is of high importance. Two component lanthanide complex formed from Tb(III) ion carrier and light harvesting antenna, readily distinguishes nucleotides containing different number of phosphates and enable direct detection of enzymatic reactions converting nucleotide triphosphate (NTP) to nucleotide di/monophosphate or the opposite. Developed sensor enables the detection of enzymatic activity with a low nanomolar sensitivity, as highlighted with K-Ras and apyrase enzymes in their hydrolysis assays performed in a high throughput screening compatible 384-well plate format. Full article
Figures

Figure 1

Open AccessArticle Fast and Accurate Finite Transducer Analysis Method for Wireless Passive Impedance-Loaded SAW Sensors
Sensors 2018, 18(11), 3988; https://doi.org/10.3390/s18113988 (registering DOI)
Received: 29 September 2018 / Revised: 9 November 2018 / Accepted: 12 November 2018 / Published: 16 November 2018
Viewed by 89 | PDF Full-text (1969 KB) | HTML Full-text | XML Full-text
Abstract
An accurate and fast simulation tool plays an important role in the design of wireless passive impedance-loaded surface acoustic wave (SAW) sensors which have received much attention recently. This paper presents a finite transducer analysis method for wireless passive impedance-loaded SAW sensors. The
[...] Read more.
An accurate and fast simulation tool plays an important role in the design of wireless passive impedance-loaded surface acoustic wave (SAW) sensors which have received much attention recently. This paper presents a finite transducer analysis method for wireless passive impedance-loaded SAW sensors. The finite transducer analysis method uses a numerically combined finite element method-boundary element method (FEM/BEM) model to analyze non-periodic transducers. In non-periodic transducers, FEM/BEM was the most accurate analysis method until now, however this method consumes central processing unit (CPU) time. This paper presents a faster algorithm to calculate the bulk wave part of the equation coefficient which usually requires a long time. A complete non-periodic FEM/BEM model of the impedance sensors was constructed. Modifications were made to the final equations in the FEM/BEM model to adjust for the impedance variation of the sensors. Compared with the conventional method, the proposed method reduces the computation time efficiently while maintaining the same high degree of accuracy. Simulations and their comparisons with experimental results for test devices are shown to prove the effectiveness of the analysis method. Full article
(This article belongs to the Special Issue Surface Acoustic Wave Sensors)
Figures

Figure 1

Open AccessArticle Indoor Smartphone Localization Based on LOS and NLOS Identification
Sensors 2018, 18(11), 3987; https://doi.org/10.3390/s18113987 (registering DOI)
Received: 1 October 2018 / Revised: 12 November 2018 / Accepted: 14 November 2018 / Published: 16 November 2018
Viewed by 64 | PDF Full-text (2023 KB) | HTML Full-text | XML Full-text
Abstract
Accurate localization technology is essential for providing location-based services. Global positioning system (GPS) is a typical localization technology that has been used in various fields. However, various indoor localization techniques are required because GPS signals cannot be received in indoor environments. Typical indoor
[...] Read more.
Accurate localization technology is essential for providing location-based services. Global positioning system (GPS) is a typical localization technology that has been used in various fields. However, various indoor localization techniques are required because GPS signals cannot be received in indoor environments. Typical indoor localization methods use the time of arrival, angle of arrival, or the strength of the wireless communication signal to determine the location. In this paper, we propose an indoor localization scheme using signal strength that can be easily implemented in a smartphone. The proposed algorithm uses a trilateration method to estimate the position of the smartphone. The accuracy of the trilateration method depends on the distance estimation error. We first determine whether the propagation path is line-of-sight (LOS) or non-line-of-sight (NLOS), and distance estimation is performed accordingly. This LOS and NLOS identification method decreases the distance estimation error. The proposed algorithm is implemented as a smartphone application. The experimental results show that distance estimation error is significantly reduced, resulting in accurate localization. Full article
(This article belongs to the Special Issue Applications of Wireless Sensors in Localization and Tracking)
Figures

Figure 1

Back to Top
