Development and Analysis of an Exoskeleton for Upper Limb Elbow Joint Rehabilitation Using EEG Signals
by
Christian Armando Castro-Moncada, Alan Francisco Pérez-Vidal, Gerardo Ortiz-Torres, Felipe De Jesús Sorcia-Vázquez, Jesse Yoe Rumbo-Morales, José-Antonio Cervantes, Carmen Elvira Hernández-Magaña, María Dolores Figueroa-Jiménez, Jorge Aurelio Brizuela-Mendoza and Julio César Rodríguez-Cerda
Viewed by 1420
Abstract
Motor impairments significantly affect individuals’ ability to perform activities of daily living, reducing autonomy and quality of life. In response to this, robot-assisted rehabilitation has emerged as an effective and practical solution, enabling controlled limb movements and supporting functional recovery. This study presents
[...] Read more.
Motor impairments significantly affect individuals’ ability to perform activities of daily living, reducing autonomy and quality of life. In response to this, robot-assisted rehabilitation has emerged as an effective and practical solution, enabling controlled limb movements and supporting functional recovery. This study presents the development of an upper-limb exoskeleton designed to assist rehabilitation by integrating neurophysiological signal processing and real-time control strategies. The system incorporates a proportional–derivative (PD) controller to execute cyclic flexion and extension movements based on a sinusoidal reference signal, providing repeatability and precision in motion. The exoskeleton integrates a brain–computer interface (BCI) that utilizes electroencephalographic signals for therapy selection and engagement enabling user-driven interaction. The EEG data extraction was possible by using the UltraCortex Mark IV headset, with electrodes positioned according to the international 10–20 system, targeting alpha-band activity in channels O1, O2, P3, P4, Fp1, and Fp2. These channels correspond to occipital (O1, O2), parietal (P3, P4), and frontal pole (Fp1, Fp2) regions, associated with visual processing, sensorimotor integration, and attention-related activity, respectively. This approach enables a more adaptive and personalized rehabilitation experience by allowing the user to influence therapy mode selection through real-time feedback. Experimental evaluation across five subjects showed an overall mean accuracy of 86.25% in alpha wave detection for EEG-based therapy selection. The PD control strategy achieved smooth trajectory tracking with a mean angular error of approximately 1.70°, confirming both the reliability of intention detection and the mechanical precision of the exoskeleton. Also, our core contributions in this research are compared with similar studies inspired by the rehabilitation needs of stroke patients. In this research, the proposed system demonstrates the potential of integrating robotic systems, control theory, and EEG data processing to improve rehabilitation outcomes for individuals with upper-limb motor deficits, particularly post-stroke patients. By focusing the exoskeleton on a single degree of freedom and employing low-cost manufacturing through 3D printing, the system remains affordable across a wide range of economic contexts. This design choice enables deployment in diverse clinical settings, both public and private.
