Instruments, Volume 7, Issue 2

2023 June - 5 articles

Cover Story: In radiation instrumentation, there is a desire to reach a sub-10 ps FWHM timing resolution for many applications. One of the key components in a detection chain is a single-photon detector, and in recent years, the first single-photon avalanche diode (SPAD) with a sub-10 ps timing resolution was presented. This paper presents a comparison between comparators and inverters to determine which type of leading-edge discriminator can obtain the best single-photon timing resolution. Six different quenching circuits are tested with SPADs of the same architecture and in the same operation conditions. This paper reports a 6.3 ps FWHM SPTR for a SPAD read out by a comparator and a 6.8 ps FWHM SPTR for an optimized 1 V inverter using a cascode transistor for higher excess voltage. View this paper
  • Issues are regarded as officially published after their release is announced to the table of contents alert mailing list .
  • You may sign up for email alerts to receive table of contents of newly released issues.
  • PDF is the official format for papers published in both, html and pdf forms. To view the papers in pdf format, click on the "PDF Full-text" link, and use the free Adobe Reader to open them.

Articles (5)

  • Feature Paper
  • Article
  • Open Access
9 Citations
4,489 Views
20 Pages

Investigating Slit-Collimator-Produced Carbon Ion Minibeams with High-Resolution CMOS Sensors

  • Lennart Volz,
  • Claire-Anne Reidel,
  • Marco Durante,
  • Yolanda Prezado and ,
  • Christoph Schuy,
  • Uli Weber and
  • Christian Graeff
  • + 2 authors+ 0 author

Particle minibeam therapy has demonstrated the potential for better healthy tissue sparing due to spatial fractionation of the delivered dose. Especially for heavy ions, the spatial fractionation could enhance the already favorable differential biolo...

(This article belongs to the Special Issue Medical Applications of Particle Physics)
  • Article
  • Open Access
1 Citations
6,009 Views
14 Pages

Muography requires a detailed understanding of the absorption of muons in the material situated between the muon source and the detector. A large-statistics (>3 billion event) Geant4 simulation was run to simulate the absorption of muons in differ...

(This article belongs to the Special Issue Muography, Applications in Cosmic-Ray Muon Imaging)
  • Article
  • Open Access
6 Citations
4,854 Views
15 Pages

Quenching Circuit Discriminator Architecture Impact on a Sub-10 ps FWHM Single-Photon Timing Resolution SPAD

  • Frédéric Nolet,
  • Valérie Gauthier,
  • Samuel Parent,
  • Frédéric Vachon and ,
  • Nicolas Roy,
  • Nicolas St-Jean,
  • Serge A. Charlebois and
  • Jean-François Pratte
  • + 3 authors+ 0 author

In the field of radiation instrumentation, there is a desire to reach a sub-10 ps FWHM timing resolution for applications such as time-of-flight positron emission tomography, time-of-flight positron computed tomography and time-resolved calorimetry....

(This article belongs to the Special Issue Feature Papers in Instruments 2021–2022)
  • Article
  • Open Access
4,961 Views
14 Pages

Design and Manufacture of a Test Device for Radiosynthesizer Vacuum Pumps

  • Victor Amador Diaz,
  • Scott E. Snyder and
  • Amy L. Vavere

Vacuum pump wear is the most prevalent failure mode of the IBA Synthera® automated radiochemistry system. Rebuilding or replacing the pump causes equipment downtime and increases the radiation exposure of the service personnel. We built a dedicat...

  • Project Report
  • Open Access
1 Citations
2,915 Views
6 Pages

Fast Timing Detectors and Applications in Cosmic Ray Physics and Medical Science

  • Christophe Royon,
  • William d’Assignies D.,
  • Florian Gautier,
  • Tommaso Isidori and ,
  • Nicola Minafra and
  • Alexander Novikov
  • + 1 author+ 0 author

We use fast silicon detectors and the fast sampling method originally developed for high energy physics for two applications: cosmic ray measurements in collaboration with NASA and dose measurements during flash beam cancer treatment. The cosmic ray...

(This article belongs to the Special Issue Timing Detectors)
