Batteries, Volume 7, Issue 3 (September 2021) – 22 articles

Cover Story (view full-size image): Mechanical expansion due to intercalation of lithium ions in graphite, as well as SEI growth and pressure rise in cylindrical battery cells, poses additional challenges for engineers designing battery modules but can also be used for battery cell state estimation due to its correlation with state of charge and state of health. However, it has been previously assumed that battery cells expand uniformly due to their cylindricity. Instead of the expected uniform expansion, the cell takes on a potato shape. The roundness of the cell decreases and bulges, and valleys form around the circumference depending on the position and orientation of the jelly roll inside the housing. View this paper
  • Issues are regarded as officially published after their release is announced to the table of contents alert mailing list.
  • You may sign up for e-mail alerts to receive table of contents of newly released issues.
  • PDF is the official format for papers published in both, html and pdf forms. To view the papers in pdf format, click on the "PDF Full-text" link, and use the free Adobe Reader to open them.
Order results
Result details
Section
Select all
Export citation of selected articles as:
28 pages, 27697 KiB
Review
Battery Crush Test Procedures in Standards and Regulation: Need for Augmentation and Harmonisation
by Bhavya Kotak, Yash Kotak, Katja Brade, Tibor Kubjatko and Hans-Georg Schweiger
Batteries 2021, 7(3), 63; https://doi.org/10.3390/batteries7030063 - 16 Sep 2021
Cited by 15 | Viewed by 14209
Abstract
Battery safety is a prominent concern for the deployment of electric vehicles (EVs). The battery powering an EV contains highly energetic active materials and flammable organic electrolytes. Usually, an EV battery catches fire due to its thermal runaway, either immediately at the time [...] Read more.
Battery safety is a prominent concern for the deployment of electric vehicles (EVs). The battery powering an EV contains highly energetic active materials and flammable organic electrolytes. Usually, an EV battery catches fire due to its thermal runaway, either immediately at the time of the accident or can take a while to gain enough heat to ignite the battery chemicals. There are numerous battery abuse testing standards and regulations available globally. Therefore, battery manufacturers are always in dilemma to choose the safest one. Henceforth, to find the optimal outcome of these two major issues, six standards (SAE J2464:2009, GB/T 31485-2015:2015, FreedomCAR:2006, ISO 12405-3:2014, IEC 62660-2:2010, and SAND2017-6295:2017) and two regulations (UN/ECE-R100.02:2013 and GTR 20:2018), that are followed by more than fifty countries in the world, are investigated in terms of their abuse battery testing conditions (crush test). This research proves that there is a need for (a) augmenting these standards and regulations as they do not consider real-life vehicle crash scenarios, and (b) one harmonised framework should be developed, which can be adopted worldwide. These outcomes will solve the battery manufacturers dilemma and will also increase the safety of EV consumers. Full article
Show Figures

Figure 1

19 pages, 3810 KiB
Article
Power and Energy Rating Considerations in Integration of Flow Battery with Solar PV and Residential Load
by Purnima Parmeshwarappa, Ravendra Gundlapalli and Sreenivas Jayanti
Batteries 2021, 7(3), 62; https://doi.org/10.3390/batteries7030062 - 8 Sep 2021
Cited by 16 | Viewed by 3691
Abstract
Integration of renewable energy sources such as solar photovoltaic (PV) generation with variable power demand systems like residential electricity consumption requires the use of a high efficiency electrical energy system such as a battery. In the present study, such integration has been studied [...] Read more.
Integration of renewable energy sources such as solar photovoltaic (PV) generation with variable power demand systems like residential electricity consumption requires the use of a high efficiency electrical energy system such as a battery. In the present study, such integration has been studied using vanadium redox flow battery (VRFB) as the energy storage system with specific focus on the sizing of the power and energy storage capacities of the system components. Experiments have been carried out with a seven-day simulated solar insolation and residential load characteristics using a 1 kW VRFB stack and variable amounts of electrolyte volume. Several scenarios have been simulated using power and energy scale factors. Battery response, in terms of its power, state of charge and efficiency, has been monitored in each run. Results show that the stack power rating should be based on peak charging characteristics while the volume of electrolyte should be based on the expected daily energy discharge through the battery. The PV source itself should be sized at about 25% more energy rating than the average daily load. The ability to design a VRFB with a high power-to-energy ratio makes it particularly attractive for PV-load integration. Full article
(This article belongs to the Special Issue Battery Systems and Energy Storage beyond 2020)
Show Figures

Figure 1

16 pages, 28445 KiB
Article
Non-Uniform Circumferential Expansion of Cylindrical Li-Ion Cells—The Potato Effect
by Jessica Hemmerling, Jajnabalkya Guhathakurta, Falk Dettinger, Alexander Fill and Kai Peter Birke
Batteries 2021, 7(3), 61; https://doi.org/10.3390/batteries7030061 - 6 Sep 2021
Cited by 16 | Viewed by 7994
Abstract
This paper presents the non-uniform change in cell thickness of cylindrical Lithium (Li)-ion cells due to the change of State of Charge (SoC). Using optical measurement methods, with the aid of a laser light band micrometer, the expansion and contraction are determined over [...] Read more.
This paper presents the non-uniform change in cell thickness of cylindrical Lithium (Li)-ion cells due to the change of State of Charge (SoC). Using optical measurement methods, with the aid of a laser light band micrometer, the expansion and contraction are determined over a complete charge and discharge cycle. The cell is rotated around its own axis by an angle of α=10° in each step, so that the different positions can be compared with each other over the circumference. The experimental data show that, contrary to the assumption based on the physical properties of electrode growth due to lithium intercalation in the graphite, the cell does not expand uniformly. Depending on the position and orientation of the cell coil, there are different zones of expansion and contraction. In order to confirm the non-uniform expansion around the circumference of the cell in 3D, X-ray computed tomography (CT) scans of the cells are performed at low and at high SoC. Comparison of the high resolution 3D reconstructed volumes clearly visualizes a sinusoidal pattern for non-uniform expansion. From the 3D volume, it can be confirmed that the thickness variation does not vary significantly over the height of the battery cell due to the observed mechanisms. However, a slight decrease in the volume change towards the poles of the battery cells due to the higher stiffness can be monitored. Full article
(This article belongs to the Special Issue Battery Systems and Energy Storage beyond 2020)
Show Figures

Figure 1

15 pages, 846 KiB
Review
Review of Achieved Purities after Li-ion Batteries Hydrometallurgical Treatment and Impurities Effects on the Cathode Performance
by Olimpia A. Nasser and Martina Petranikova
Batteries 2021, 7(3), 60; https://doi.org/10.3390/batteries7030060 - 3 Sep 2021
Cited by 27 | Viewed by 7308
Abstract
This paper is a product purity study of recycled Li-ion batteries with a focus on hydrometallurgical recycling processes. Firstly, a brief description of the current recycling status was presented based on the research data. Moreover, this work presented the influence of impurities such [...] Read more.
This paper is a product purity study of recycled Li-ion batteries with a focus on hydrometallurgical recycling processes. Firstly, a brief description of the current recycling status was presented based on the research data. Moreover, this work presented the influence of impurities such as Cu, Fe and Mg on recovered cathode materials performance. The impact of the impurities was described depending on their form (metallic or ionic) and concentration. This work also reviewed hydrometallurgical recycling processes depending on the recovered material, obtained purity and recovery methods. This purity data were obtained from both research and battery industry actors. Finally, the purity study was completed by collecting data regarding commercial battery-grade chemical compounds and active lithium cathode materials, including required purity levels and allowed impurity limitations. Full article
(This article belongs to the Special Issue Circular Battery Technologies)
Show Figures

Graphical abstract

16 pages, 947 KiB
Article
Grid-Scale Battery Energy Storage for Arbitrage Purposes: A Colombian Case
by Andrés F. Peñaranda, David Romero-Quete and Camilo A. Cortés
Batteries 2021, 7(3), 59; https://doi.org/10.3390/batteries7030059 - 3 Sep 2021
Cited by 16 | Viewed by 6277
Abstract
This study seeks to determine a suitable arbitrage strategy that allows a battery energy storage system (BESS) owner to obtain the maximum economic benefits when participating in the Colombian electricity market. A comparison of different arbitration strategies from the literature, such as seasonal, [...] Read more.
This study seeks to determine a suitable arbitrage strategy that allows a battery energy storage system (BESS) owner to obtain the maximum economic benefits when participating in the Colombian electricity market. A comparison of different arbitration strategies from the literature, such as seasonal, statistical, and neural networks-based models, is performed. To determine BESS’s optimal operation, a Mixed Integer Linear Programming (MILP) optimization problem is formulated, including a battery degradation model based on an upper piecewise linear approximation method. A financial evaluation of the different arbitrage strategies is carried out, resulting, for all the analyzed cases, in a negative net present value (NPV); thus, the results show that the income obtained from BESS when only performing energy arbitrage in the Colombian market do not compensate the investment costs. Results have also shown that strategies based on statistical and prediction models have a better performance than seasonal strategies, especially in atypical circumstances such as COVID-19. Full article
Show Figures

Figure 1

21 pages, 4716 KiB
Article
Thermal Analysis of LMO/Graphite Batteries Using Equivalent Circuit Models
by Nadjiba Mahfoudi, M’hamed Boutaous, Shihe Xin and Serge Buathier
Batteries 2021, 7(3), 58; https://doi.org/10.3390/batteries7030058 - 27 Aug 2021
Cited by 5 | Viewed by 3663
Abstract
An efficient thermal management system (TMS) of electric vehicles requires a high-fidelity battery model. The model should be able to predict the electro-thermal behavior of the battery, considering the operating conditions throughout the battery’s lifespan. In addition, the model should be easy to [...] Read more.
An efficient thermal management system (TMS) of electric vehicles requires a high-fidelity battery model. The model should be able to predict the electro-thermal behavior of the battery, considering the operating conditions throughout the battery’s lifespan. In addition, the model should be easy to handle for the online monitoring and control of the TMS. Equivalent circuit models (ECMs) are widely used because of their simplicity and suitable performance. In this paper, the electro-thermal behavior of a prismatic 50 Ah LMO/Graphite cell is investigated. A dynamic model is adopted to describe the battery voltage, current, and heat generation. The battery model parameters are identified for a single cell, considering their evolution versus the state of charge and temperature. The needed experimental data are issued from the measurements carried out, thanks to a special custom electrical bench able to impose a predefined current evolution or driving cycles, controllable by serial interface. The proposed battery parameters, functions of state of charge (SOC), and temperature (T) constitute a set of interesting and complete data, not available in the literature, and suitable for further investigations. The thermal behavior and the dynamic models are validated using the New European Driving Cycle (NEDC), with a large operating time, higher than 3 h. The measurement and model prediction exhibit a temperature difference less than 1.2 °C and a voltage deviation less than 3%, showing that the proposed model accurately predicts current, voltage, and temperature. The combined effects of temperature and SOC provides a more efficient modeling of the cell behavior. Nevertheless, the simplified model with only temperature dependency remains acceptable. Hence, the present modeling constitutes a confident prediction and a real step for an online control of the complete thermal management of electrical vehicles. Full article
(This article belongs to the Special Issue Thermoelectricity and Energy Transfer)
Show Figures

Figure 1

26 pages, 4361 KiB
Article
Life Cycle Modelling of Extraction and Processing of Battery Minerals—A Parametric Approach
by Nelson Bunyui Manjong, Lorenzo Usai, Odne Stokke Burheim and Anders Hammer Strømman
Batteries 2021, 7(3), 57; https://doi.org/10.3390/batteries7030057 - 24 Aug 2021
Cited by 34 | Viewed by 9621
Abstract
Sustainable battery production with low environmental footprints requires a systematic assessment of the entire value chain, from raw material extraction and processing to battery production and recycling. In order to explore and understand the variations observed in the reported footprints of raw battery [...] Read more.
Sustainable battery production with low environmental footprints requires a systematic assessment of the entire value chain, from raw material extraction and processing to battery production and recycling. In order to explore and understand the variations observed in the reported footprints of raw battery materials, it is vital to re-assess the footprints of these material value chains. Identifying the causes of these variations by combining engineering and environmental system analysis expands our knowledge of the footprints of these battery materials. This article disaggregates the value chains of six raw battery materials (aluminum, copper, graphite, lithium carbonate, manganese, and nickel) and identifies the sources of variabilities (levers) for each process along each value chain. We developed a parametric attributional process-based life cycle model to explore the effect of these levers on the greenhouse gas (GHG) emissions of the value chains, expressed in kg of CO2e. The parametric life cycle inventory model is used to conduct distinct life cycle assessments (LCA) for each material value chain by varying the identified levers within defined engineering ranges. 570 distinct LCAs are conducted for the aluminum value chain, 450 for copper, 170 for graphite, 39 for lithium carbonate via spodumene, 20 for lithium carbonate via brine, 260 for manganese, and 440 for nickel. Three-dimensional representations of these results for each value chain in kg of CO2e are presented as contour plots with gradient lines illustrating the intensity of lever combinations on the GHG emissions. The results of this study convey multidimensional insights into how changes in the lever settings of value chains yield variations in the overall GHG emissions of the raw materials. Parameterization of these value chains forms a flexible and high-resolution backbone, leading towards a more reliable life cycle assessment of lithium-ion batteries (LIB). Full article
(This article belongs to the Special Issue Circular Battery Technologies)
Show Figures

Figure 1

21 pages, 3566 KiB
Article
Analysis of Electrochemical Impedance Spectroscopy on Zinc-Air Batteries Using the Distribution of Relaxation Times
by Robert Franke-Lang and Julia Kowal
Batteries 2021, 7(3), 56; https://doi.org/10.3390/batteries7030056 - 18 Aug 2021
Cited by 10 | Viewed by 6355
Abstract
Zinc-air batteries could be a key technology for higher energy densities of electrochemical energy storage systems. Many questions remain unanswered, however, and new methods for analyses and quantifications are needed. In this study, the distribution of relaxation times (DRT) based on ridge regression [...] Read more.
Zinc-air batteries could be a key technology for higher energy densities of electrochemical energy storage systems. Many questions remain unanswered, however, and new methods for analyses and quantifications are needed. In this study, the distribution of relaxation times (DRT) based on ridge regression was applied to the impedance data of primary zinc-air batteries in a temperature range of 253 K and 313 K and at different State-of-Charges for the first time. Furthermore, the problem of the regularization parameter on real impedance spectroscopic measurements was addressed and a method was presented using the reconstruction of impedance data from the DRT as a quality criterion. The DRT was able to identify a so far undiscussed process and thus explain why some equivalent circuit models may fail. Full article
Show Figures

Figure 1

15 pages, 3401 KiB
Article
Carbon Monoliths with Hierarchical Porous Structure for All-Vanadium Redox Flow Batteries
by Jose Francisco Vivo-Vilches, Blagoj Karakashov, Alain Celzard, Vanessa Fierro, Ranine El Hage, Nicolas Brosse, Anthony Dufour and Mathieu Etienne
Batteries 2021, 7(3), 55; https://doi.org/10.3390/batteries7030055 - 10 Aug 2021
Cited by 8 | Viewed by 3780
Abstract
Carbon monoliths were tested as electrodes for vanadium redox batteries. The materials were synthesised by a hard-templating route, employing sucrose as carbon precursor and sodium chloride crystals as the hard template. For the preparation process, both sucrose and sodium chloride were ball-milled together [...] Read more.
Carbon monoliths were tested as electrodes for vanadium redox batteries. The materials were synthesised by a hard-templating route, employing sucrose as carbon precursor and sodium chloride crystals as the hard template. For the preparation process, both sucrose and sodium chloride were ball-milled together and molten into a paste which was hot-pressed to achieve polycondensation of sucrose into a hard monolith. The resultant material was pyrolysed in nitrogen at 750 °C, and then washed to remove the salt by dissolving it in water. Once the porosity was opened, a second pyrolysis step at 900 °C was performed for the complete conversion of the materials into carbon. The products were next characterised in terms of textural properties and composition. Changes in porosity, obtained by varying the proportions of sucrose to sodium chloride in the initial mixture, were correlated with the electrochemical performances of the samples, and a good agreement between capacitive response and microporosity was indeed observed highlighted by an increase in the cyclic voltammetry curve area when the SBET increased. In contrast, the reversibility of vanadium redox reactions measured as a function of the difference between reduction and oxidation potentials was correlated with the accessibility of the active vanadium species to the carbon surface, i.e., was correlated with the macroporosity. The latter was a critical parameter for understanding the differences of energy and voltage efficiencies among the materials, those with larger macropore volumes having the higher efficiencies. Full article
(This article belongs to the Special Issue Material Design and Development for Redox Flow Batteries II)
Show Figures

Figure 1

9 pages, 2223 KiB
Article
Layered Iron Vanadate as a High-Capacity Cathode Material for Nonaqueous Calcium-Ion Batteries
by Munseok S. Chae, Dedy Setiawan, Hyojeong J. Kim and Seung-Tae Hong
Batteries 2021, 7(3), 54; https://doi.org/10.3390/batteries7030054 - 9 Aug 2021
Cited by 23 | Viewed by 5030
Abstract
Calcium-ion batteries represent a promising alternative to the current lithium-ion batteries. Nevertheless, calcium-ion intercalating materials in nonaqueous electrolytes are scarce, probably due to the difficulties in finding suitable host materials. Considering that research into calcium-ion batteries is in its infancy, discovering and characterizing [...] Read more.
Calcium-ion batteries represent a promising alternative to the current lithium-ion batteries. Nevertheless, calcium-ion intercalating materials in nonaqueous electrolytes are scarce, probably due to the difficulties in finding suitable host materials. Considering that research into calcium-ion batteries is in its infancy, discovering and characterizing new host materials would be critical to further development. Here, we demonstrate FeV3O9∙1.2H2O as a high-performance calcium-ion battery cathode material that delivers a reversible discharge capacity of 303 mAh g−1 with a good cycling stability and an average discharge voltage of ~2.6 V (vs. Ca/Ca2+). The material was synthesized via a facile co-precipitation method. Its reversible capacity is the highest among calcium-ion battery materials, and it is the first example of a material with a capacity much larger than that of conventional lithium-ion battery cathode materials. Bulk intercalation of calcium into the host lattice contributed predominantly to the total capacity at a lower rate, but became comparable to that due to surface adsorption at a higher rate. This stimulating discovery will lead to the development of new strategies for obtaining high energy density calcium-ion batteries. Full article
Show Figures

Figure 1

36 pages, 7869 KiB
Review
In-Situ Tools Used in Vanadium Redox Flow Battery Research—Review
by Purna C. Ghimire, Arjun Bhattarai, Tuti M. Lim, Nyunt Wai, Maria Skyllas-Kazacos and Qingyu Yan
Batteries 2021, 7(3), 53; https://doi.org/10.3390/batteries7030053 - 4 Aug 2021
Cited by 31 | Viewed by 10908
Abstract
Progress in renewable energy production has directed interest in advanced developments of energy storage systems. The all-vanadium redox flow battery (VRFB) is one of the attractive technologies for large scale energy storage due to its design versatility and scalability, longevity, good round-trip efficiencies, [...] Read more.
Progress in renewable energy production has directed interest in advanced developments of energy storage systems. The all-vanadium redox flow battery (VRFB) is one of the attractive technologies for large scale energy storage due to its design versatility and scalability, longevity, good round-trip efficiencies, stable capacity and safety. Despite these advantages, the deployment of the vanadium battery has been limited due to vanadium and cell material costs, as well as supply issues. Improving stack power density can lower the cost per kW power output and therefore, intensive research and development is currently ongoing to improve cell performance by increasing electrode activity, reducing cell resistance, improving membrane selectivity and ionic conductivity, etc. In order to evaluate the cell performance arising from this intensive R&D, numerous physical, electrochemical and chemical techniques are employed, which are mostly carried out ex situ, particularly on cell characterizations. However, this approach is unable to provide in-depth insights into the changes within the cell during operation. Therefore, in situ diagnostic tools have been developed to acquire information relating to the design, operating parameters and cell materials during VRFB operation. This paper reviews in situ diagnostic tools used to realize an in-depth insight into the VRFBs. A systematic review of the previous research in the field is presented with the advantages and limitations of each technique being discussed, along with the recommendations to guide researchers to identify the most appropriate technique for specific investigations. Full article
(This article belongs to the Special Issue Redox Flow Batteries for Large-Scale Energy Storage)
Show Figures

Figure 1

23 pages, 810 KiB
Article
Combining the Distribution of Relaxation Times from EIS and Time-Domain Data for Parameterizing Equivalent Circuit Models of Lithium-Ion Batteries
by Leo Wildfeuer, Philipp Gieler and Alexander Karger
Batteries 2021, 7(3), 52; https://doi.org/10.3390/batteries7030052 - 2 Aug 2021
Cited by 32 | Viewed by 8786
Abstract
Equivalent circuit models (ECMs) are a widely used modeling approach for lithium-ion batteries in engineering applications. The RC elements, which display the dynamic loss processes of the cell, are usually parameterized by fitting the ECM to experimental data in either the time-domain or [...] Read more.
Equivalent circuit models (ECMs) are a widely used modeling approach for lithium-ion batteries in engineering applications. The RC elements, which display the dynamic loss processes of the cell, are usually parameterized by fitting the ECM to experimental data in either the time-domain or the frequency-domain. However, both types of data have limitations with regard to the observable time constants of electrochemical processes. This work proposes a method to combine time-domain and frequency-domain measurement data for parameterization of RC elements by exploiting the full potential of the distribution of relaxation times (DRT). Instead of using only partial information from the DRT to supplement a conventional fitting algorithm, we determine the parameters of an arbitrary number of RC elements directly from the DRT. The difficulties of automated deconvolution of the DRT, including regularization and the choice of an optimal regularization factor, is tackled by using the L-curve criterion for optimized calculation of the DRT via Tikhonov regularization. Three different approaches to merge time- and frequency-domain data are presented, including a novel approach where the DRT is simultaneously calculated from electrochemical impedance spectoscropy (EIS) and pulse relaxation measurements. The parameterized model for a commercial 18650 NCA cell was validated during a validation cycle consisting of constant current and real-world automotive cycling and yields a relative improvement of over 40% compared to a conventional EIS-fitting algorithm. Full article
Show Figures

Figure 1

15 pages, 2400 KiB
Article
Comparative Study of Equivalent Circuit Models Performance in Four Common Lithium-Ion Batteries: LFP, NMC, LMO, NCA
by Manh-Kien Tran, Andre DaCosta, Anosh Mevawalla, Satyam Panchal and Michael Fowler
Batteries 2021, 7(3), 51; https://doi.org/10.3390/batteries7030051 - 27 Jul 2021
Cited by 198 | Viewed by 32863
Abstract
Lithium-ion (Li-ion) batteries are an important component of energy storage systems used in various applications such as electric vehicles and portable electronics. There are many chemistries of Li-ion battery, but LFP, NMC, LMO, and NCA are four commonly used types. In order for [...] Read more.
Lithium-ion (Li-ion) batteries are an important component of energy storage systems used in various applications such as electric vehicles and portable electronics. There are many chemistries of Li-ion battery, but LFP, NMC, LMO, and NCA are four commonly used types. In order for the battery applications to operate safely and effectively, battery modeling is very important. The equivalent circuit model (ECM) is a battery model often used in the battery management system (BMS) to monitor and control Li-ion batteries. In this study, experiments were performed to investigate the performance of three different ECMs (1RC, 2RC, and 1RC with hysteresis) on four Li-ion battery chemistries (LFP, NMC, LMO, and NCA). The results indicated that all three models are usable for the four types of Li-ion chemistries, with low errors. It was also found that the ECMs tend to perform better in dynamic current profiles compared to non-dynamic ones. Overall, the best-performed model for LFP and NCA was the 1RC with hysteresis ECM, while the most suited model for NMC and LMO was the 1RC ECM. The results from this study showed that different ECMs would be suited for different Li-ion battery chemistries, which should be an important factor to be considered in real-world battery and BMS applications. Full article
(This article belongs to the Special Issue Lithium-Ion Batteries: Latest Advances and Prospects II)
Show Figures

Figure 1

12 pages, 1555 KiB
Article
Biopolimer Peptide Batteries—A New Concept for Environmentally Friendly and Safer Energy Storage
by Volodymyr Moklyak, Andrii Hrubiak, Zurab Gogitidze and Yurii Yavorskyi
Batteries 2021, 7(3), 50; https://doi.org/10.3390/batteries7030050 - 20 Jul 2021
Cited by 7 | Viewed by 4148
Abstract
The work shows a new approach to improving the performance of lithium power sources by using polypeptides as an active component of the cathode composition. Specifically, the experimental results of testing prototypes of lithium current sources with cathodes based on polypeptides, which demonstrate [...] Read more.
The work shows a new approach to improving the performance of lithium power sources by using polypeptides as an active component of the cathode composition. Specifically, the experimental results of testing prototypes of lithium current sources with cathodes based on polypeptides, which demonstrate the value of the specific discharge capacity at the level of 2000–2700 mAh/g, depending on the content of the organic component, are presented. The use of the intermittent galvanostatic titration mode during the discharge showed an increase in the specific indicators of the current sources in comparison with the continuous discharge at different specific load currents. Based on this, the effect of “relaxation recovery” of the cathode material based on polypeptides was discovered, the essence of which is a significant increase (recovery) of the open-circuit voltage when the load of the lithium current source is disconnected, which leads to an increase of the discharge capacity without external energy influences. The functionalization of the surface of thermally expanded graphite with polypeptide components made it possible to create a cathode material, the use of which in lithium current source models increased the specific discharge capacity to 19,000 mA h/g at a discharge current of 10 mA/h. Full article
Show Figures

Figure 1

18 pages, 7849 KiB
Article
Analysis and Investigation of Thermal Runaway Propagation for a Mechanically Constrained Lithium-Ion Pouch Cell Module
by Luigi Aiello, Ilie Hanzu, Gregor Gstrein, Eduard Ewert, Christian Ellersdorfer and Wolfgang Sinz
Batteries 2021, 7(3), 49; https://doi.org/10.3390/batteries7030049 - 19 Jul 2021
Cited by 12 | Viewed by 7876
Abstract
In this paper, tests and analysis of thermal runaway propagation for commercial modules consisting of four 41 Ah Li-ion pouch cells are presented. Module samples were tested at 100% state-of-charge and mechanically constrained between two steel plates to provide thermal and mechanical contact [...] Read more.
In this paper, tests and analysis of thermal runaway propagation for commercial modules consisting of four 41 Ah Li-ion pouch cells are presented. Module samples were tested at 100% state-of-charge and mechanically constrained between two steel plates to provide thermal and mechanical contact between the parts. Voltage and temperature of each cell were monitored during the whole experiment. The triggering of the exothermal reactions was obtained by overheating one cell of the stack with a flat steel heater. In preliminary studies, the melting temperature of the separator was measured (from an extracted sample) with differential scanning calorimetry and thermogravimetric analysis techniques, revealing a tri-layers separator with two melting points (≈135 °C and ≈170 °C). The tests on module level revealed 8 distinct phases observed and analyzed in the respective temperature ranges, including smoking, venting, sparkling, and massive, short circuit condition. The triggering temperature of the cells resulted to be close to the melting temperature of the separator obtained in preliminary tests, confirming that the violent exothermal reactions of thermal runaway are caused by the internal separator failure. Postmortem inspections of the modules revealed the internal electrical failure path in one cell and the propagation of the internal short circuit in its active material volume, suggesting that the expansion of the electrolyte plays a role in the short circuit propagation at the single cell level. The complete thermal runaway propagation process was repeated on 5 modules and ended on average 60 s after the first thermal runaway triggered cell reached a top temperature of 1100 °C. Full article
Show Figures

Figure 1

18 pages, 4459 KiB
Article
Identification of Degradation Mechanisms by Post-Mortem Analysis for High Power and High Energy Commercial Li-Ion Cells after Electric Vehicle Aging
by Pierre Kuntz, Olivier Raccurt, Philippe Azaïs, Karsten Richter, Thomas Waldmann, Margret Wohlfahrt-Mehrens, Michel Bardet, Anton Buzlukov and Sylvie Genies
Batteries 2021, 7(3), 48; https://doi.org/10.3390/batteries7030048 - 16 Jul 2021
Cited by 24 | Viewed by 7566
Abstract
Driven by the rise of the electric automotive industry, the Li-ion battery market is in strong expansion. This technology does not only fulfill the requirements of electric mobility, but is also found in most portable electric devices. Even though Li-ion batteries are known [...] Read more.
Driven by the rise of the electric automotive industry, the Li-ion battery market is in strong expansion. This technology does not only fulfill the requirements of electric mobility, but is also found in most portable electric devices. Even though Li-ion batteries are known for their numerous advantages, they undergo serious performance degradation during their aging, and more particularly when used in specific conditions such as at low temperature or high charging current rates. Depending on the operational conditions, different aging mechanisms are favored and can induce physical and chemical modifications of the internal components, leading to performance decay. In this article, the identification of the degradation mechanisms was carried out thanks to an in-depth ante- and post mortem study on three high power and high energy commercial 18,650 cells. Li-ion cells were aged using a battery electric vehicle (BEV) aging profile at −20 °C, 0 °C, 25 °C, and 45 °C in accordance with the international standard IEC 62-660, and in calendar aging mode at 45 °C and SOC 100%. Internal components recovered from fresh and aged cells were investigated through different electrochemical (half-coin cell), chemical (EDX, GD-OES, NMR), and topological (SEM) characterization techniques. The influence of power and energy cells’ internal design and Si content in the negative electrode on cell aging has been highlighted vis-à-vis the capacity and power fade. Full article
(This article belongs to the Special Issue Lithium-Ion Batteries Aging Mechanisms, 2nd Edition)
Show Figures

Figure 1

18 pages, 2347 KiB
Article
Versatile AC Current Control Technique for a Battery Using Power Converters
by S. M. Rakiul Islam and Sung-Yeul Park
Batteries 2021, 7(3), 47; https://doi.org/10.3390/batteries7030047 - 15 Jul 2021
Cited by 1 | Viewed by 3663
Abstract
Although a battery is a DC device, AC current is often necessary for testing, preheating, impedance spectroscopy, and advanced charging. This paper presents a versatile control technique to inject AC current to a battery. Synchronous buck and H-bridge topologies are operated in bidirectional [...] Read more.
Although a battery is a DC device, AC current is often necessary for testing, preheating, impedance spectroscopy, and advanced charging. This paper presents a versatile control technique to inject AC current to a battery. Synchronous buck and H-bridge topologies are operated in bidirectional mode and controlled by uni-polar and bi-polar pulse width modulation techniques for the AC current injection. The input and output passive circuits are specially designed considering AC current and the properties of the battery. A controller is proposed considering a small internal impedance, small AC ripple voltage, and variable DC offset voltage of a battery. The controller is capable of maintaining stable operation of AC current injection in two power quadrant within a small DC voltage boundary of a battery. The controller is comprised of a feedback compensator, a feedforward term, and an estimator. The feedback gain is designed considering the internal impedance. The feedforward gain is designed based on estimated open circuit battery voltage and input voltage. The open circuit voltage estimator is designed based on filters and battery model. For validation, AC current is injected to a Valence U-12XP battery. The battery is rated for 40 Ah nominal capacity and 13.8 V nominal voltage The controller successfully injected AC current to a battery with +10 A, 0 A and −10 A DC currents. The magnitude and frequency of the AC current was up to 5 A and 2 kHz respectively. Full article
(This article belongs to the Special Issue Battery Systems and Energy Storage beyond 2020)
Show Figures

Figure 1

13 pages, 3161 KiB
Article
Detection of Lithium Plating in Li-Ion Cell Anodes Using Realistic Automotive Fast-Charge Profiles
by Matteo Dotoli, Emanuele Milo, Mattia Giuliano, Riccardo Rocca, Carlo Nervi, Marcello Baricco, Massimiliano Ercole and Mauro Francesco Sgroi
Batteries 2021, 7(3), 46; https://doi.org/10.3390/batteries7030046 - 7 Jul 2021
Cited by 14 | Viewed by 7334
Abstract
The widespread use of electric vehicles is nowadays limited by the “range anxiety” of the customers. The drivers’ main concerns are related to the kilometric range of the vehicle and to the charging time. An optimized fast-charge profile can help to decrease the [...] Read more.
The widespread use of electric vehicles is nowadays limited by the “range anxiety” of the customers. The drivers’ main concerns are related to the kilometric range of the vehicle and to the charging time. An optimized fast-charge profile can help to decrease the charging time, without degrading the cell performance and reducing the cycle life. One of the main reasons for battery capacity fade is linked to the Lithium plating phenomenon. This work investigates two methodologies, i.e., three-electrode cell measurement and internal resistance evolution during charging, for detecting the Lithium plating conditions. From this preliminary analysis, it was possible to develop new Multi-Stage Constant-Current profiles, designed to improve the performance in terms of charging time and cells capacity retention with respect to a reference profile. Four new profiles were tested and compared to a reference. The results coming from the new profiles demonstrate a simultaneous improvement in terms of charging time and cycling life, showing the reliability of the implemented methodology in preventing Lithium plating. Full article
(This article belongs to the Special Issue Lithium-Ion Batteries Aging Mechanisms, 2nd Edition)
Show Figures

Figure 1

13 pages, 34487 KiB
Article
An ASIC-Based Miniaturized System for Online Multi-Measurand Monitoring of Lithium-Ion Batteries
by Giuseppe Manfredini, Andrea Ria, Paolo Bruschi, Luca Gerevini, Michele Vitelli, Mario Molinara and Massimo Piotto
Batteries 2021, 7(3), 45; https://doi.org/10.3390/batteries7030045 - 5 Jul 2021
Cited by 13 | Viewed by 5212
Abstract
To better asses the ageing and to reduce the hazards involved in the use of Lithium-Ion Batteries, multi-measurand monitoring units and strategies are urged. In this paper, a Cell Management Unit, based on the SENSIPLUS chip, a recently introduced multichannel, multi-mode sensor interface, [...] Read more.
To better asses the ageing and to reduce the hazards involved in the use of Lithium-Ion Batteries, multi-measurand monitoring units and strategies are urged. In this paper, a Cell Management Unit, based on the SENSIPLUS chip, a recently introduced multichannel, multi-mode sensor interface, is described. SENSIPLUS is a single System on a Chip combined with a reduced number of external components, resulting in a highly miniaturized device, built on 20 × 8 mm2 printed circuit board. Thanks to SENSIPLUS’ versatility, the proposed system is capable of performing direct measurements (EIS, cell voltage) on the cell it is applied to, and reading different kinds of sensors. The SENSIPLUS versatile digital communication interface, combined with a digital isolator, enable connection of several devices to a single bus for parallel monitoring a large number of cells connected in series. Experiments performed by connecting the proposed system to a commercial Lithium-Ion Battery and to capacitive and resistive sensors are described. In particular, the capability of measuring the cell internal impedance with a resolution of 120 μΩ is demonstrated. Full article
(This article belongs to the Special Issue Lithium-Ion Batteries Aging Mechanisms, 2nd Edition)
Show Figures

Figure 1

16 pages, 6274 KiB
Article
Investigation into the Lithium-Ion Battery Fire Resistance Testing Procedure for Commercial Use
by Daniel Darnikowski and Magdalena Mieloszyk
Batteries 2021, 7(3), 44; https://doi.org/10.3390/batteries7030044 - 30 Jun 2021
Cited by 5 | Viewed by 4325
Abstract
Lithium-ion batteries (LIBs) have many advantages (e.g., high voltage and long-life cycle) in comparison to other energy storage technologies (e.g., lead acid), resulting in their applicability in a wide variety of structures. Simultaneously, the thermal stability of LIBs is relatively poor and can [...] Read more.
Lithium-ion batteries (LIBs) have many advantages (e.g., high voltage and long-life cycle) in comparison to other energy storage technologies (e.g., lead acid), resulting in their applicability in a wide variety of structures. Simultaneously, the thermal stability of LIBs is relatively poor and can be damaged by exposure to fire. This paper presents an investigation into a fire resistance safety test for LIBs and the use of thermal sensors to evaluate exposure conditions and estimate the temperatures to which cells are subjected. Temperature distribution data and statistical analysis show significant differences of over 200 C, indicating the stochastic nature of the heating curve despite following the testing procedure requirements. We concluded that the current testing procedure is inadequate for the reliable testing of LIBs, leaving an alarming loophole in the fire safety evaluation. The observed instability is mostly related to wind speed and direction, and fire source size. Full article
Show Figures

Figure 1

1 pages, 197 KiB
Correction
Correction: Paccha-Herrera et al. Thermal Modeling Approaches for a LiCoO2 Lithium-ion Battery—A Comparative Study with Experimental Validation. Batteries 2020, 6, 40
by Edwin Paccha-Herrera, Williams R. Calderón-Muñoz, Marcos Orchard, Francisco Jaramillo and Kamal Medjaher
Batteries 2021, 7(3), 43; https://doi.org/10.3390/batteries7030043 - 25 Jun 2021
Cited by 1 | Viewed by 2207
Abstract
The authors wish to make the following corrections to their paper [...] Full article
11 pages, 1299 KiB
Article
Thermal Conductivity in Aged Li-Ion Cells under Various Compression Conditions and State-of-Charge
by Georgi Kovachev, Andrea Astner, Gregor Gstrein, Luigi Aiello, Johann Hemmer, Wolfgang Sinz and Christian Ellersdorfer
Batteries 2021, 7(3), 42; https://doi.org/10.3390/batteries7030042 - 25 Jun 2021
Cited by 15 | Viewed by 5935
Abstract
Thermal conductivity (TC) is a parameter, which significantly influences the spatial temperature gradients of lithium ion batteries in operative or abuse conditions. It affects the dissipation of the generated heat by the cell during normal operation or during thermal runaway propagation from one [...] Read more.
Thermal conductivity (TC) is a parameter, which significantly influences the spatial temperature gradients of lithium ion batteries in operative or abuse conditions. It affects the dissipation of the generated heat by the cell during normal operation or during thermal runaway propagation from one cell to the next after an external short circuit. Hence, the thermal conductivity is a parameter of great importance, which concurs to assess the safety of a Li-ion battery. In this work, an already validated, non-destructive measurement procedure was adopted for the determination of the evolution of the through-plane thermal conductivity of 41 Ah commercially available Li-ion pouch cells (LiNiMnCoO2-LiMn2O4/Graphite) as function of battery lifetime and state of charge (SOC). Results show a negative parabolic behaviour of the thermal conductivity over the battery SOC-range. In addition, an average decrease of TC in thickness direction of around 4% and 23% was measured for cells cycled at 60 °C with and without compression, respectively. It was shown that pretension force during cycling reduces battery degradation and thus minimises the effect of ageing on the thermal parameter deterioration. Nevertheless, this study highlights the need of adjustment of the battery pack cooling system due to the deterioration of thermal conductivity after certain battery lifetime with the aim of reducing the risk of battery overheating after certain product life. Full article
(This article belongs to the Special Issue Lithium-Ion Batteries Aging Mechanisms, 2nd Edition)
Show Figures

Figure 1
