Photonics, Volume 10, Issue 10 (October 2023) – 112 articles

Cover Story (view full-size image): Diffractive optical elements (DOEs) enable simultaneous imaging utilizing different orders. To use this capability to full capacity, diffraction efficiency must be tailored to specific wavelengths for individual orders, which can be realized by multi-layer structures. In order to tailor wavelength selectivity, theoretical investigations of the diffraction efficiency of triple-layer double-relief DOEs were conducted using a wide range of materials, including inorganic glasses, nanocomposites, layer materials, and high-index liquids. To account for both positive and negative orders, specific material combinations featuring intersecting or touching dispersion curves were employed. A significant benefit of applying high-index liquids as an intermediate layer between two solid profiles is the option to fine-tune efficiency profiles. View this paper
  • Issues are regarded as officially published after their release is announced to the table of contents alert mailing list.
  • You may sign up for e-mail alerts to receive table of contents of newly released issues.
  • PDF is the official format for papers published in both, html and pdf forms. To view the papers in pdf format, click on the "PDF Full-text" link, and use the free Adobe Reader to open them.
Order results
Result details
Section
Select all
Export citation of selected articles as:
11 pages, 2671 KiB
Article
Numerical Aperture-Dependent Spatial Scaling of Plasma Channels in HPHT Diamond
Photonics 2023, 10(10), 1177; https://doi.org/10.3390/photonics10101177 - 23 Oct 2023
Viewed by 502
Abstract
The investigation of plasma channels induced by focused ultra-short 1030-nm laser pulses in bulk of synthetic High Pressure High Temperature (HPHT) diamond revealed strong dependence of their spatial parameters on the used numerical aperture of the lens (NA = 0.15–0.45). It was shown [...] Read more.
The investigation of plasma channels induced by focused ultra-short 1030-nm laser pulses in bulk of synthetic High Pressure High Temperature (HPHT) diamond revealed strong dependence of their spatial parameters on the used numerical aperture of the lens (NA = 0.15–0.45). It was shown that at weak focusing conditions it is possible to significantly increase the length of the plasma channel with a slight increase in pulse power, while tight focusing allows one to obtain more compact structures in the same range of used powers. Such a dependence paves the way to new possibilities in 3D processing of transparent dielectrics, allowing one, for example, to vary the spatial parameters of modified regions without changing the setup, but only by controlling the lens aperture, which seems very promising for industrial applications. Full article
Show Figures

Figure 1

13 pages, 3408 KiB
Article
Analysis of Coaxiality Error Induced by the Cube Corner Retro-Reflector Geometrical and Assembly Errors of an Acquisition, Pointing, and Tracking System
Photonics 2023, 10(10), 1176; https://doi.org/10.3390/photonics10101176 - 23 Oct 2023
Viewed by 424
Abstract
Satellite laser communication is a promising technology for the next-generation communication system. Its communication performance is subject to the APT beam-pointing accuracy. One of the most important problems is reducing the coaxiality error before the APT starts working. However, the coaxiality error is [...] Read more.
Satellite laser communication is a promising technology for the next-generation communication system. Its communication performance is subject to the APT beam-pointing accuracy. One of the most important problems is reducing the coaxiality error before the APT starts working. However, the coaxiality error is difficult to correct effectively owing to the lack of empirical guidance based on qualitative analysis. We study the inducement that will generate coaxiality errors. The mathematical model of the influence of the CCR dihedral angle error and planeness error on the spot centroid measurement are built, and an analysis is performed. The model of the beam-pointing error induced by the APT element’s assembly error is built, and the pointing error change rule is explored. Furthermore, the coaxiality performance simulation is performed in the presence of a CCR geometrical error while considering the assembly error. The results show that the coaxiality error has a nonlinear characteristic. The CCR planeness error has a greater influence on coaxiality deviation than that of dihedral angle error under certain conditions. This research is relevant to the design and test work of the APT system. Full article
(This article belongs to the Special Issue Optical Imaging and Measurements)
Show Figures

Figure 1

12 pages, 3172 KiB
Article
Photonic Hook Initiated Using an Air–Liquid Interface
Photonics 2023, 10(10), 1175; https://doi.org/10.3390/photonics10101175 - 23 Oct 2023
Viewed by 562
Abstract
In this paper, we demonstrate a novel photonic hook being initiated using an air–liquid interface (ALI). This bent light focus is produced by immersing a dielectric micro-cylinder partially at the edge of a thin liquid film whose thickness is smaller than the diameter [...] Read more.
In this paper, we demonstrate a novel photonic hook being initiated using an air–liquid interface (ALI). This bent light focus is produced by immersing a dielectric micro-cylinder partially at the edge of a thin liquid film whose thickness is smaller than the diameter of the micro-cylinder. Unlike the well-known properties of normal near-field focuses, this photonic hook propagates horizontally in the liquid along the ALI at specific depths and does not require the material processing of microscopic particles or the modulation of light irradiation for initiation. A morphological analysis indicates that the contrast in the refractive indexes of the ALI causes this phenomenon at the shadow end of the micro-cylinder with a transverse dimension smaller than the diffraction limit. Compared to previously discovered photonic hooks, the unique setup of this photonic hook can generate a force field that enables optical trapping in the region slightly beneath the ALI, and the related optical pressures have been simulated. Full article
(This article belongs to the Special Issue Sciences and Applications of Nano-Photonics)
Show Figures

Figure 1

12 pages, 1962 KiB
Communication
A Simplified Volterra Equalizer Based on System Characteristics for Direct Modulation Laser (DML)-Based Intensity Modulation and Direct Detection (IM/DD) Transmission Systems
Photonics 2023, 10(10), 1174; https://doi.org/10.3390/photonics10101174 - 21 Oct 2023
Viewed by 682
Abstract
The nonlinear Volterra equalizer has been proved to be able to solve the problem of nonlinear distortion, but it has high computational complexity and is difficult to implement. In this paper, a simplified second-order Volterra nonlinear equalizer designed for intensity modulation/direct detection systems [...] Read more.
The nonlinear Volterra equalizer has been proved to be able to solve the problem of nonlinear distortion, but it has high computational complexity and is difficult to implement. In this paper, a simplified second-order Volterra nonlinear equalizer designed for intensity modulation/direct detection systems based on direct modulated laser is proposed and demonstrated, taking into account the characteristics of the system. It has been proved that the received signal of direct modulation laser/direct detection system can be expressed in Volterra series form, but its form is too complex, and the device parameters should also be considered. We re-derived it and obtained a more concise form. At the same time, we proposed a method to simplify the second-order Volterra nonlinear equalizer without relying on device parameters. The performance of the proposed Volterra nonlinear equalizer is evaluated experimentally on a 56 Gb/s 4-ary pulse amplitude modulation link implemented by using a 1.55 µm direct modulation laser. The results show that, compared with the traditional Volterra nonlinear equalizer, the receiver sensitivity of the equalizer is only reduced by 0.2 dB at most, but the complexity can be reduced by 50%; compared with diagonally pruned Volterra nonlinear equalizers, the complexity of the equalizer is the same, but the reception sensitivity can be improved by 0.5 dB. Full article
(This article belongs to the Special Issue Optical Signal Processing)
Show Figures

Figure 1

9 pages, 1280 KiB
Article
Genetic Optimization of the Y-Shaped Photonic Crystal NOT Logic Gate
Photonics 2023, 10(10), 1173; https://doi.org/10.3390/photonics10101173 - 21 Oct 2023
Viewed by 628
Abstract
The present paper is devoted to the actual problem of photonic crystal (PhC) logic gate design. The development of components for photonic digital computing systems will provide opportunities for high-efficient information processing. The use of 2D photonic crystals is one of the most [...] Read more.
The present paper is devoted to the actual problem of photonic crystal (PhC) logic gate design. The development of components for photonic digital computing systems will provide opportunities for high-efficient information processing. The use of 2D photonic crystals is one of the most promising approaches to designing interference logic gates. Photonic crystal band gap and use of lattice defects are giving opportunities for flexible control of waveguiding light. Interference logic gates of NOT, OR, AND, and XOR types based on the Y-shaped structure are well known. However, known realizations have limited energy efficiency. Earlier, a method for minimizing energy losses at the PhC waveguide bending based on genetic optimization of the PhC waveguide topology was proposed and investigated. In this paper, the genetic algorithm for optimization of the PhC interference logic gate of the NOT type was used. Optimization of the Y-shaped topology allowed for an increase in the energy efficiency of the logic gate to 95%. A description of the developed numerical procedure as well as computer simulation results are presented. The developed procedure includes the possibility of taking into account the limitations of the technology to be used for the realization of a designed 2D PhC structure. Full article
(This article belongs to the Special Issue Recent Advances in Diffractive Optics)
Show Figures

Figure 1

15 pages, 1508 KiB
Article
One-Step Implementation of Collective Anti-Blockade in a Rydberg Ring
Photonics 2023, 10(10), 1172; https://doi.org/10.3390/photonics10101172 - 20 Oct 2023
Viewed by 485
Abstract
In contrast to Rydberg blockade, Rydberg anti-blockade allows multiple atoms to be simultaneously excited in the presence of significant nonlocal interactions and can lead to distinct phenomena and applications. This inspires us to examine here general conditions, numerical verifications, and realistic restrictions regarding [...] Read more.
In contrast to Rydberg blockade, Rydberg anti-blockade allows multiple atoms to be simultaneously excited in the presence of significant nonlocal interactions and can lead to distinct phenomena and applications. This inspires us to examine here general conditions, numerical verifications, and realistic restrictions regarding the collective anti-blockade excitations of N Rydberg atoms equally arranged along a ring. We find that by adjusting the detuning of a pump field to compensate for nonlocal interactions between one atom and all others, it is viable to realize resonant excitations of N atoms but suppress far-detuned excitations of N1 and fewer atoms under different conditions for an odd and an even number of atoms. Population dynamics of this Rydberg ring further show that one-step anti-blockade implementation can be attained at a cutoff time of the pump field, which increases quickly with the number of atoms. Hence, roughly perfect anti-blockade excitations are attainable only for a not-too-large N due to inevitable spontaneous Rydberg decay. Full article
Show Figures

Figure 1

13 pages, 3504 KiB
Article
Bimetallic Eu/Tb Complexes for Ratiometric Temperature Sensing with Unusual Enhancement of Eu Luminescence with Temperature
Photonics 2023, 10(10), 1171; https://doi.org/10.3390/photonics10101171 - 20 Oct 2023
Viewed by 553
Abstract
In this paper we describe the results of the influence of temperature in the range of 280–340 K on the luminescence of bimetallic Eu/Tb complexes with N-heterocyclic ligand L based on 2,2′-bipyridyldicarboxylic acid in acetonitrile. The experiments were carried out for systems with [...] Read more.
In this paper we describe the results of the influence of temperature in the range of 280–340 K on the luminescence of bimetallic Eu/Tb complexes with N-heterocyclic ligand L based on 2,2′-bipyridyldicarboxylic acid in acetonitrile. The experiments were carried out for systems with various Eu/Tb ratios. The stability of the complexes of the ligand L with metal M (Eu or Tb) was determined using spectrophotometric titration in acetonitrile solutions. The LM complexes’ stability constants were found to be typical for these systems; however, the stability of Eu complex is slightly higher than that for Tb. Along with rising temperature, we observed a decrease in Tb emission intensity and, at the same time, an enhancement in Eu luminescence. An explanation of Eu luminescence enhancement involves the appearance of charge transfer states, bands of which can be observed in the Eu luminescence excitation spectra as difference spectra measured with two close temperatures. The unusual Eu luminescence enhancement upon heating was observed for the first time for the complex with tetradentate O,N-type heterocyclic diamide ligand L, while an inverse phenomenon was observed with the Tb luminescence. The Eu luminescence enhancement was found earlier for various carboxylate complex salts, but not for heterocyclic coordination complexes. This allows the construction of a ratiometric luminescent thermometer in the range of 280–340 K using the ratio of luminescence intensities for Eu and Tb. The stability constants for the individual Eu and Tb complexes help us to understand the equilibrium in L:Tb:Eu complex system and shed light on plausible speciation in solution. Full article
(This article belongs to the Special Issue Fluorescence Microscopy)
Show Figures

Figure 1

16 pages, 2056 KiB
Article
Manipulation of Population Levels through Zeno-Type Measurements
Photonics 2023, 10(10), 1170; https://doi.org/10.3390/photonics10101170 - 20 Oct 2023
Viewed by 423
Abstract
We present a scheme, based on Bloch equations and Zeno-type measurements, that allows the control of the probability density evolution of the eigenstates of a V-type system. The equations are solved numerically and we present how the population in each level can be [...] Read more.
We present a scheme, based on Bloch equations and Zeno-type measurements, that allows the control of the probability density evolution of the eigenstates of a V-type system. The equations are solved numerically and we present how the population in each level can be controlled using different sequences of “pulse measurements”. The entropy between the “measurement device” and the field used to perform the measurement process is evaluated for different strengths of such field, these calculations show that the entropy is maximized when we are in the Zeno regime. The results shown here unveil different possible strategies for controlling the population levels of a V-type system and could be implemented, for example, in trapped ions or RMN qubits. Full article
Show Figures

Figure 1

12 pages, 4820 KiB
Article
A Diamond Terahertz Large Aperture Photoconductive Antenna Biased by a Longitudinal Field
Photonics 2023, 10(10), 1169; https://doi.org/10.3390/photonics10101169 - 20 Oct 2023
Viewed by 468
Abstract
The novel design of a terahertz large aperture photoconductive antenna (LAPCA) is reported. It features a longitudinal orientation of the bias electric field within the photoconductive substrate, and has the advantage of a small interelectrode gap, resulting in a higher field for the [...] Read more.
The novel design of a terahertz large aperture photoconductive antenna (LAPCA) is reported. It features a longitudinal orientation of the bias electric field within the photoconductive substrate, and has the advantage of a small interelectrode gap, resulting in a higher field for the same applied voltage. The proposed LAPCA configuration has been tested with a nitrogen-doped (∼10 ppm) synthetic monocrystalline diamond, which is a promising material for high-intensity and high-power terahertz sources. Two antennas with different high-voltage electrode realizations were assembled, pumped by a 400 nm femtosecond laser, and tested for THz emitter function. The experimental data are found to be in good correlation with the numerical simulation results. The performance of antennas with the conventional transverse E-field configuration and the novel longitudinal configuration is compared and discussed. Full article
(This article belongs to the Special Issue Ultrashort Laser Pulses)
Show Figures

Figure 1

13 pages, 6121 KiB
Article
Calculation of BaGa4Se7 OPO/OPA Output Spectrum Characteristics
Photonics 2023, 10(10), 1168; https://doi.org/10.3390/photonics10101168 - 20 Oct 2023
Viewed by 491
Abstract
Optical parametric oscillation (OPO) or optical parametric amplification (OPA) systems offer significant potential for generating high-energy, narrow-pulse laser output, finding applications across various domains. To achieve efficient amplification in cascade with amplifiers, precise frequency domain matching between OPO/OPA systems and amplifiers is imperative. [...] Read more.
Optical parametric oscillation (OPO) or optical parametric amplification (OPA) systems offer significant potential for generating high-energy, narrow-pulse laser output, finding applications across various domains. To achieve efficient amplification in cascade with amplifiers, precise frequency domain matching between OPO/OPA systems and amplifiers is imperative. Therefore, preliminary simulation and computation of the spectral characteristics of OPO/OPA systems are of paramount importance in the early stages of experimentation. Currently, the calculation of OPO/OPA output spectrum characteristics is limited to estimating the influence of pump light characteristics on output spectrum linewidth, a consideration that remains incomplete. This paper presents a comprehensive computational approach that takes into account the impact of four crucial factors on the output spectrum characteristics: pump light linewidth, pump light divergence angle, the walk-off effect, and the absorption loss of the crystal. This method finely characterizes the features of the output spectrum. The results obtained through the proposed approach align well with experimental results, underscoring its effectiveness. This study aims to obtain the output spectrum characteristics of BaGa4Se7 OPO/OPA through calculations to provide theoretical guidance for subsequent cascade amplification experiments. Full article
(This article belongs to the Special Issue Advances and Applications of Solid State Lasers)
Show Figures

Figure 1

12 pages, 3125 KiB
Article
Acousto-Optic Transfer Function Control by a Phased-Array Piezoelectric Transducer
Photonics 2023, 10(10), 1167; https://doi.org/10.3390/photonics10101167 - 19 Oct 2023
Viewed by 547
Abstract
We present analysis and numerical simulations of the acousto-optic spatial filter (AOSF) transfer function under the condition of dual-transducer operation and phase control. Based on these simulations, the AOSF crystal configuration is optimized for operation in the near-infrared wavelength region from 0.7 to [...] Read more.
We present analysis and numerical simulations of the acousto-optic spatial filter (AOSF) transfer function under the condition of dual-transducer operation and phase control. Based on these simulations, the AOSF crystal configuration is optimized for operation in the near-infrared wavelength region from 0.7 to 1.0 μm. We demonstrate that ultrasonic phase control can provide efficient tuning of the transfer function, which is independent of conventional frequency control. Thus, the application of phase control coupled with frequency control can reduce the transfer function asymmetry that is inherent to anisotropic Bragg diffraction in uniaxial crystals. Full article
Show Figures

Figure 1

14 pages, 3244 KiB
Article
Frequency-Shift Monitoring of Optical Filter Based on Optical Labels over FTN-WDM Transmission Systems
Photonics 2023, 10(10), 1166; https://doi.org/10.3390/photonics10101166 - 18 Oct 2023
Viewed by 519
Abstract
Optical network monitoring and soft failure identification such as optical filter shifting and filter tightening are increasingly significant for the complex and dynamic optical networks of the future. Center frequency shift of optical filtering devices in optical networks has a serious impact on [...] Read more.
Optical network monitoring and soft failure identification such as optical filter shifting and filter tightening are increasingly significant for the complex and dynamic optical networks of the future. Center frequency shift of optical filtering devices in optical networks has a serious impact on the performance of multi-span transmission, especially in high spectrum efficiency faster-than-Nyquist (FTN) transmission systems with various optical switching and add/drop nodes. Existing monitoring schemes generally have the problems of high cost, high complexity, and inability to realize multi-channel online monitoring, which makes it difficult for them to be applied in a wavelength division multiplexing (WDM) system with numerous nodes. In this paper, a monitoring scheme of frequency shift of optical filtering devices based on optical label (OL) is proposed and demonstrated. The signal spectrum of each channel is intentionally divided into many sub-bands with corresponding optical labels loading. The characteristics of spectrum power changing caused by frequency shift can be reflected on labels power changing of each sub-band, which are used to monitor and estimate the value of frequency shift via DSP algorithm. Simulation results show that the monitoring errors of frequency shift can be kept reasonably below 0.5 GHz after 10-span WDM transmission in FTN polarization multiplexing m-ary quadrature amplitude modulation (PM-mQAM) systems. In addition, 250 km fiber transmission experiments are also carried out, and similar results are obtained, which further verify the feasibility of our proposed scheme. The characteristics of low cost, high reliability, and efficiency make it a better candidate for practical application in future FTN-WDM networks. Full article
(This article belongs to the Special Issue Optical Communication, Sensing and Network)
Show Figures

Figure 1

9 pages, 665 KiB
Communication
Adjunct Nondamaging Focal Laser Reduces Intravitreal Injection Burden in Diabetic Macular Edema
Photonics 2023, 10(10), 1165; https://doi.org/10.3390/photonics10101165 - 18 Oct 2023
Viewed by 555
Abstract
This study aims to determine the impact of adjunct nondamaging focal laser therapy on the number of anti-vascular endothelial growth factor (anti-VEGF) injections and visual acuity (VA) and imaging in patients with diabetic macular edema (DME). A retrospective analysis of 18 eyes of [...] Read more.
This study aims to determine the impact of adjunct nondamaging focal laser therapy on the number of anti-vascular endothelial growth factor (anti-VEGF) injections and visual acuity (VA) and imaging in patients with diabetic macular edema (DME). A retrospective analysis of 18 eyes of 14 patients with DME treated with a single session of the PASCAL 532 nm Synthesis Photocoagulator with Endpoint Management was conducted. Demographic data, VA, imaging, laser parameters, and anti-VEGF injection burden six months before and after treatment were collected. Wilcoxon Signed-rank tests were used to assess changes in VA and injection burden before and after treatment. The mean number of intravitreal injections in the six-month period prior to laser treatment was 3.39 ± 2.57 injections compared to 2.33 ± 2.40 injections following laser treatment (p = 0.02). There was no significant difference between the mean VA on the day of treatment logMAR VA of 0.38 ± 0.27 (approx. Snellen equivalent 20/50) and the visual acuity on the most recent follow-up 6 months after laser logMAR VA of 0.35 ± 0.32 (approx. Snellen equivalent 20/40) (p = 0.34). There was also no significant difference in OCT central macular thickness before (311 µm) compared to 6 months after (301 µm, p = 0.64). Adjunct focal macular laser therapy is associated with a statistically and clinically significant decrease in the number of intravitreal injections required in the six-month period immediately following treatment, without compromising visual acuity or macular thickness. Nondamaging focal laser has the potential to alleviate the burden of injections for both patients and clinics. Full article
(This article belongs to the Special Issue Laser Treatment in Retinal Diseases)
Show Figures

Figure 1

14 pages, 2409 KiB
Article
Compact Diode-Pumped Solid-State Laser with Intracavity Pump-Enhanced DFG Emitting at ~3.5 Microns
Photonics 2023, 10(10), 1164; https://doi.org/10.3390/photonics10101164 - 17 Oct 2023
Viewed by 619
Abstract
We report a diode-pumped solid-state (DPSS) laser used for intracavity pump-enhanced difference frequency generation (DFG) to create a 3.5-micron laser. Using a 50 mm-long periodically poled lithium niobate (PPLN) crystal inside the cavity of an Nd:YVO4 solid-state laser at 1064 nm with [...] Read more.
We report a diode-pumped solid-state (DPSS) laser used for intracavity pump-enhanced difference frequency generation (DFG) to create a 3.5-micron laser. Using a 50 mm-long periodically poled lithium niobate (PPLN) crystal inside the cavity of an Nd:YVO4 solid-state laser at 1064 nm with 4.5 W pump power at 808 nm, and a 310 mW C-band signal at 1529 nm, up to 31 mW of mid-infrared output power at 3499 nm is obtained. The cavity requires no active stabilization and/or locking, and the entire cavity is <8 cm in length. The obtained output power corresponds to a black-box efficiency of 2.20%W−1, which is the highest value reported to date for continuous-wave DFG based on a bulk nonlinear optical crystal with no active stabilization. Potential future applications in free-space optical communication are also discussed. Full article
(This article belongs to the Special Issue Editorial Board Members' Collection Series: Nonlinear Photonics)
Show Figures

Figure 1

11 pages, 2715 KiB
Article
Wavelength-Tunable Pulsed Cylindrical Vector Beams in a 1.7-μm Mode-Locking Thulium-Doped All-Fiber Laser
Photonics 2023, 10(10), 1163; https://doi.org/10.3390/photonics10101163 - 17 Oct 2023
Viewed by 747
Abstract
Because of the special absorption peak, pulsed lasers at 1.7 μm have been rapidly developed in medical treatment, biological imaging and so on. Introducing the cylindrical vector beam (CVB) may further promote these special applications due to its unique intensity, phase and polarization [...] Read more.
Because of the special absorption peak, pulsed lasers at 1.7 μm have been rapidly developed in medical treatment, biological imaging and so on. Introducing the cylindrical vector beam (CVB) may further promote these special applications due to its unique intensity, phase and polarization characteristics. Herein, we have experimentally demonstrated the generation of wavelength-tunable pulsed CVBs at 1.7 μm based on a thulium-doped all-fiber laser. A bandpass filter with a wide bandwidth combined with nonlinear polarization rotation technology is used to obtain pulsed laser emission at 1.7 μm. By taking advantage of a home-made Lyot filter and mode selective coupler (MSC), pulsed CVBs can be obtained with a wavelength tuning range of 66 nm (1720–1786 nm). The development of wavelength-tunable pulsed CVBs at the 1.7 μm waveband has significant potential applications in deep bioimaging and laser processing. Full article
(This article belongs to the Special Issue Advances and Application of Structured Light)
Show Figures

Figure 1

24 pages, 2086 KiB
Article
Bessel–Gauss Beams of Arbitrary Integer Order: Propagation Profile, Coherence Properties, and Quality Factor
Photonics 2023, 10(10), 1162; https://doi.org/10.3390/photonics10101162 - 17 Oct 2023
Viewed by 630
Abstract
We present a novel approach to generate Bessel–Gauss modes of arbitrary integer order and well-defined optical angular momentum in a gradient index medium of transverse parabolic profile. The propagation and coherence properties, as well as the quality factor, are studied using algebraic techniques [...] Read more.
We present a novel approach to generate Bessel–Gauss modes of arbitrary integer order and well-defined optical angular momentum in a gradient index medium of transverse parabolic profile. The propagation and coherence properties, as well as the quality factor, are studied using algebraic techniques that are widely used in quantum mechanics. It is found that imposing the well-defined optical angular momentum condition, the Lie group SU(1,1) comes to light as a characteristic symmetry of the Bessel–Gauss beams. Full article
(This article belongs to the Special Issue Laser Beam Propagation and Control)
Show Figures

Figure 1

6 pages, 882 KiB
Communication
Spectrum of Terahertz Emission from Single-Color Filament Plasma under Different Laser Beam Focusing
Photonics 2023, 10(10), 1161; https://doi.org/10.3390/photonics10101161 - 16 Oct 2023
Cited by 1 | Viewed by 590
Abstract
The spectrum of terahertz radiation generated in plasma of a single-color laser filament is observed, using a new technique based on obtaining two-dimensional angular distributions at different frequencies. It is shown that the maximum of the spectrum occurs in the low-frequency region for [...] Read more.
The spectrum of terahertz radiation generated in plasma of a single-color laser filament is observed, using a new technique based on obtaining two-dimensional angular distributions at different frequencies. It is shown that the maximum of the spectrum occurs in the low-frequency region for different laser pump focusing conditions. It is demonstrated that with the initial beam numerical aperture growth the generation of terahertz radiation at high frequencies increases more intensely compared to low frequencies. Full article
(This article belongs to the Special Issue Ultrashort Laser Pulses)
Show Figures

Figure 1

12 pages, 3776 KiB
Article
Reducing the Crosstalk in Collinear Holographic Data Storage Systems Based on Random Position Orthogonal Phase-Coding Reference
Photonics 2023, 10(10), 1160; https://doi.org/10.3390/photonics10101160 - 16 Oct 2023
Viewed by 471
Abstract
Previous studies have shown that orthogonal phase-coding multiplexing performs well with low crosstalk in conventional off-axis systems. However, noticeable crosstalk occurs when applying the orthogonal phase-coding multiplexing to collinear holographic data storage systems. This paper demonstrates the crosstalk generation mechanism, features, and elimination [...] Read more.
Previous studies have shown that orthogonal phase-coding multiplexing performs well with low crosstalk in conventional off-axis systems. However, noticeable crosstalk occurs when applying the orthogonal phase-coding multiplexing to collinear holographic data storage systems. This paper demonstrates the crosstalk generation mechanism, features, and elimination methods. The crosstalk is caused by an inconsistency in the intensity reconstruction from the orthogonal phase-coded reference wave. The intensity fluctuation range was approximately 40%. Moreover, the more concentrated the distribution of pixels with the same phase key, the more pronounced the crosstalk. We propose an effective random orthogonal phase-coding reference wave method to reduce the crosstalk. The orthogonal phase-coded reference wave is randomly distributed over the entire reference wave. These disordered orthogonal phase-coded reference waves achieve consistent reconstruction intensities exhibiting the desired low-crosstalk storage effect. The average correlation coefficient between pages decreased by 73%, and the similarity decreased by 85%. This orthogonal phase-coding multiplexing method can be applied to encrypted holographic data storage. The low-crosstalk nature of this technique will make the encryption system more secure. Full article
(This article belongs to the Special Issue Holographic Information Processing)
Show Figures

Figure 1

17 pages, 6221 KiB
Communication
A High-Sensitivity Fiber Biosensor Based on PVDF-Excited Surface Plasmon Resonance in the Terahertz Band
Photonics 2023, 10(10), 1159; https://doi.org/10.3390/photonics10101159 - 16 Oct 2023
Viewed by 618
Abstract
In this paper, a D-type photonic crystal fiber (PCF) with Zeonex material as the substrate and polyvinylidene fluoride (PVDF) material as the surface plasmon resonance (SPR) excitation layer is proposed for biosensing in the terahertz (THz) band. Analyzed with a finite element method, [...] Read more.
In this paper, a D-type photonic crystal fiber (PCF) with Zeonex material as the substrate and polyvinylidene fluoride (PVDF) material as the surface plasmon resonance (SPR) excitation layer is proposed for biosensing in the terahertz (THz) band. Analyzed with a finite element method, the proposed biosensor has shown excellent sensing properties for analyte refractive indices ranging from 1.32 to 1.45. With a maximum sensor resolution of 8.40 × 10−7 refractive index unit (RIU) and a figure of merit of 39.42 RIU−1, the maximum wavelength sensitivity and amplitude sensitivity can reach 335.00 μm/RIU and −66.01 RIU−1, respectively. A ±2% fabrication tolerance analysis is also performed on the biosensor to prove its practical feasibility. We conclude that our proposed PCF biosensor utilizing PVDF-excited SPR can provide high sensitivity, and thus a compact, label-free, and convenient solution for biomedical liquid sensing in the THz band. Full article
(This article belongs to the Special Issue Terahertz Transmission and Imaging)
Show Figures

Figure 1

11 pages, 3490 KiB
Article
A 5 kW Nearly-Single-Mode Monolithic Fiber Laser Emitting at ~1050 nm Employing Asymmetric Bi-Tapered Ytterbium-Doped Fiber
Photonics 2023, 10(10), 1158; https://doi.org/10.3390/photonics10101158 - 16 Oct 2023
Viewed by 621
Abstract
Limited by stimulated Raman scattering (SRS), amplified spontaneous emission (ASE) and transverse mode instability (TMI), it is challenging to achieve high-power laser output in ytterbium-doped fiber (YDF) lasers with operating wavelengths less than 1060 nm. In high-power fiber lasers, bi-tapered YDF can provide [...] Read more.
Limited by stimulated Raman scattering (SRS), amplified spontaneous emission (ASE) and transverse mode instability (TMI), it is challenging to achieve high-power laser output in ytterbium-doped fiber (YDF) lasers with operating wavelengths less than 1060 nm. In high-power fiber lasers, bi-tapered YDF can provide a balance between the suppression of SRS and TMI. In this work, we designed and fabricated a new double-cladding asymmetric bi-tapered YDF to suppress ASE and SRS in the 1050 nm monolithic fiber laser. The asymmetric bi-tapered YDF has an input end with a core/cladding diameter of ~20/400 μm, a middle section with a core/cladding diameter of ~30/600 μm and an output end with a core/cladding diameter of ~25/500 μm. The working temperature of the non-wavelength-stabilized 976 nm laser diodes was optimized to improve the TMI threshold. An output power of over 5 kW with an efficiency of 83.1% and a beam quality factor M2 of about 1.47 were achieved. To the best of our knowledge, this represents the highest power nearly-single mode in 1050 nm fiber lasers. This work demonstrates the potential of asymmetric bi-tapered YDF for achieving a high-power laser with high beam quality in 1050 nm fiber lasers. Full article
(This article belongs to the Special Issue Specialty Optical Fibers and Their High-Power Applications)
Show Figures

Figure 1

13 pages, 2757 KiB
Article
Temperature Demodulation for an Interferometric Fiber-Optic Sensor Based on Artificial Bee Colony–Long Short-Term Memory
Photonics 2023, 10(10), 1157; https://doi.org/10.3390/photonics10101157 - 16 Oct 2023
Viewed by 527
Abstract
Demodulation methods play a critical role in achieving high-performance interferometric fiber-optic temperature sensors. However, the conventional passive 3 × 3 coupler demodulation method overlooks certain issues, such as the non-1:1:1 splitting ratio of the coupler, resulting in a non-ideal phase difference in the [...] Read more.
Demodulation methods play a critical role in achieving high-performance interferometric fiber-optic temperature sensors. However, the conventional passive 3 × 3 coupler demodulation method overlooks certain issues, such as the non-1:1:1 splitting ratio of the coupler, resulting in a non-ideal phase difference in the three output interference signals. These problems significantly impact the measurement results of interferometric temperature sensors. In this paper, we propose a novel arc-tangent method based on a 3 × 3 coupler and a demodulation algorithm combining long short-term memory (LSTM) with an artificial bee colony (ABC). The arc-tangent method is employed to enhance the input phase signal of the ABC-LSTM network model and establish a nonlinear mapping between the phase signal and temperature, effectively preventing the influence of the spectral ratio and phase difference of the 3 × 3 coupler on temperature demodulation. The proposed ABC-LSTM method achieves high-resolution measurements with an interval of 0.10 °C, and the absolute error is below 0.0040 °C within the temperature range of 25.00–25.50 °C. To demonstrate the stability and adaptability of the proposed method under long-term constant temperature conditions, we conducted measurements for approximately three hours in a controlled temperature environment set at 25.00 °C. Experimental results indicate that the maximum error of LSTM-ABC method remains around 0.0040 °C, outperforming the conventional algorithm (0.0095 °C). Furthermore, when comparing the average error values of the conventional passive 3 × 3 coupler method (0.0023 °C), LSTM model (0.0019 °C), and ABC-LSTM model (0.0014 °C), it is evident that the demodulation results of the ABC-LSTM method exhibit the highest level of stability. Therefore, the ABC-LSTM method enhances the accuracy and reliability of interferometric fiber-optic temperature-sensing systems. Full article
Show Figures

Figure 1

12 pages, 3596 KiB
Article
Interval Adjustable Dual-Wavelength Erbium-Doped Fiber Laser Based on Cascaded Two Mach-Zehnder Interferometers
Photonics 2023, 10(10), 1156; https://doi.org/10.3390/photonics10101156 - 16 Oct 2023
Viewed by 662
Abstract
An interference filter is designed by cascading two Mach-Zehnder interferometers (MZIs), which is then utilized in the construction of a wavelength interval adjustable dual-wavelength Erbium-doped fiber laser (EDFL). Each MZI consists of two 3 dB optical couplers (OCs) connected in series. The input [...] Read more.
An interference filter is designed by cascading two Mach-Zehnder interferometers (MZIs), which is then utilized in the construction of a wavelength interval adjustable dual-wavelength Erbium-doped fiber laser (EDFL). Each MZI consists of two 3 dB optical couplers (OCs) connected in series. The input light is split into two arms at the first OC and recombined at the second OC. The first MZI (MZI 1) has a smaller free spectral range (FSR) and is used for selecting the output wavelength of the laser. The second MZI (MZI 2) has a larger FSR and forms an envelope structure on the comb-like spectrum of MZI 1. By adjusting the optical path difference between the two arms of MZI 2, the FSR of the envelope can be changed, thereby altering the interval of the output wavelengths. The implemented filter is inserted into the EDFL to achieve stable dual-wavelength output. By stretching one arm of MZI 2, the interval of the dual-wavelength can be adjusted from 4.64 to 13.94 nm, with the side-mode suppression ratio of over 44 dB for all wavelengths. Full article
Show Figures

Figure 1

13 pages, 15322 KiB
Article
Robust Holographic Reconstruction by Deep Learning with One Frame
Photonics 2023, 10(10), 1155; https://doi.org/10.3390/photonics10101155 - 15 Oct 2023
Viewed by 583
Abstract
A robust method is proposed to reconstruct images with only one hologram in digital holography by introducing a deep learning (DL) network. The U-net neural network is designed according to DL principles and trained by the image data set collected using phase-shifting digital [...] Read more.
A robust method is proposed to reconstruct images with only one hologram in digital holography by introducing a deep learning (DL) network. The U-net neural network is designed according to DL principles and trained by the image data set collected using phase-shifting digital holography (PSDH). The training data set was established by collecting thousands of reconstructed images using PSDH. The proposed method can complete the holography reconstruction with only a single hologram and then benefits the space bandwidth product and relaxes the storage loads of PSDH. Compared with the results of PSDH, the results of deep learning are immune to most disturbances, including reference tilt, phase-shift errors, and speckle noise. Assisted by a GPU processor, the proposed reconstruction method can reduce the consumption time to almost one percent of the time needed by two-step PSDH. This method is expected to be capable of holography imaging with a single hologram, with high capacity, efficiently in the digital holography applications. Full article
(This article belongs to the Special Issue Holographic Information Processing)
Show Figures

Figure 1

10 pages, 8199 KiB
Article
Capture Dynamics of Dielectric Microparticles in Hollow-Core-Fiber-Based Optical Traps
Photonics 2023, 10(10), 1154; https://doi.org/10.3390/photonics10101154 - 13 Oct 2023
Viewed by 432
Abstract
Optical traps formed in hollow-core fibers (HCFs) can overcome several limitations of conventional free-space optical tweezers. One of the key issues is to load particles from free space into the hollow core with high efficiency, in which process the capture dynamics of the [...] Read more.
Optical traps formed in hollow-core fibers (HCFs) can overcome several limitations of conventional free-space optical tweezers. One of the key issues is to load particles from free space into the hollow core with high efficiency, in which process the capture dynamics of the particles in front of the HCF endface plays an important role. In this work, a comprehensive model of the trapping and capture process of the dielectric particles in front of HCF is established by taking into account the features of the fiber modes and the motional parameters of the particles. Stable capture positions are predicted based on analytical calculations of optical forces, and the dependencies of the equilibrium axial trapping position on the beam numerical aperture, the fiber core and particle diameters are provided. In addition, the trajectories and the capture dynamics of the particles are studied by solving the equation of motion for the particles under the impact of optical forces, predicting feasible parameter ranges of the initial amplitude and direction of particle launch velocity for achieving successful particle capture in front of HCF. The results can provide guidance for further improving the particle-loading efficiencies of the HCF-based optical traps, which may find applications of flying particle sensors and long-range particle binding in HCFs. Full article
(This article belongs to the Special Issue Optical Fiber Sensors with a Specialty Fiber Tip)
Show Figures

Figure 1

14 pages, 640 KiB
Article
Precision Spectroscopy of Radiation Transitions between Singlet Rydberg States of the Group IIb and Yb Atoms
Photonics 2023, 10(10), 1153; https://doi.org/10.3390/photonics10101153 - 13 Oct 2023
Viewed by 493
Abstract
The measurements of microwave (μw) and radio-frequency (RF) radiation quantitative parameters may be based on the quantum–optical approach to determine the spectral characteristics of radiation transitions between the Rydberg states of atoms. Frequencies and matrix elements are calculated for dipole transitions between opposite-parity [...] Read more.
The measurements of microwave (μw) and radio-frequency (RF) radiation quantitative parameters may be based on the quantum–optical approach to determine the spectral characteristics of radiation transitions between the Rydberg states of atoms. Frequencies and matrix elements are calculated for dipole transitions between opposite-parity Rydberg states nL 1L and nL±1 1L±1 (where n= n,n±1,n±2) of the singlet series in the alkaline–earth–metal-like atoms of group IIb (Zn, Cd, Hg) and Yb. The matrix elements determine the shifts of Rydberg-state energy levels in the field of resonance μw or RF radiation, splitting the resonance of electromagnetically induced transparency (EIT) for intensely absorbed probe radiation. Numerical computations based on the single-electron quantum defect method (QDM) and the Fues’ model potential (FMP) approach with the use of the most reliable data from the current literature on quantum defect values are performed for frequencies and matrix elements of transitions between singlet Rydberg states of 1S0-, 1P1-, 1D2-, and 1F3-series in Zn, Cd, Hg, and Yb atoms. The calculated data are approximated by polynomials in the powers of the principal quantum numbers. The polynomial coefficients are determined with the use of a standard curve-fitting interpolation polynomial procedure for numerically calculated functions. These approximation expressions provide new possibilities for accurately evaluating the frequencies and matrix elements of dipole transitions between Rydberg states over a wide range of quantum numbers n >> 1, accompanied by the emission and absorption of μw and RF photons. Full article
(This article belongs to the Special Issue Precision Atomic Spectroscopy)
Show Figures

Figure 1

14 pages, 8350 KiB
Article
Research on Adaptive Transmit Diversity Strategy for Reducing Interference in Underwater Optical Multi-Beam Non-Orthogonal Multiple Access Systems
Photonics 2023, 10(10), 1152; https://doi.org/10.3390/photonics10101152 - 13 Oct 2023
Viewed by 482
Abstract
With the rapid development of the underwater Internet of Things (IoT), the number of underwater communication nodes is rapidly increasing. The access capacity of a traditional multi-antenna communication system is limited by the number of transmitting antennas, and multi-beam communication systems using non-orthogonal [...] Read more.
With the rapid development of the underwater Internet of Things (IoT), the number of underwater communication nodes is rapidly increasing. The access capacity of a traditional multi-antenna communication system is limited by the number of transmitting antennas, and multi-beam communication systems using non-orthogonal multiple access (NOMA) technology can enhance the access capacity of the system. However, this can lead to serious inter-beam and intra-beam interference. To address the severe issues of inter-beam and intra-beam interference in underwater multi-beam NOMA systems, we propose an adaptive transmit diversity strategy. We design an algorithm for adaptive selection and merging beams based on the degree of interference between beams in space, which merges LED beams with high interference. Diversity technology is used to reduce interference between beams, and spatial multiplexing is still performed between LED groups with low interference. Within the same beam, we use an OFDM-NOMA scheme to match and group the users. Signals from different user groups are sent through different subcarriers to improve resource utilization. This enhances access capacity while reducing NOMA inter-user interference. Simulation results show that the bit error rate (BER) of users with the adaptive transmit diversity strategy satisfies the forward error correction (FEC) limits in the presence of high inter-beam interference and has a better reachable rate and BER performance compared to the multi-beam access system without interference management. We also analyze the system BER performance of the proposed strategy in the multi-user case, and the BER of all 32 access nodes are lower than the FEC threshold at a communication distance of 5 m. This demonstrates that the strategy can effectively reduce the interference of the multi-beam NOMA system. Full article
Show Figures

Figure 1

9 pages, 7188 KiB
Article
Two-Dimensional Dynamic Beam Steering by Tamm Plasmon Polariton
Photonics 2023, 10(10), 1151; https://doi.org/10.3390/photonics10101151 - 13 Oct 2023
Viewed by 561
Abstract
The dynamic steering of a beam reflected from a photonic structure supporting Tamm plasmon polariton is demonstrated. The phase and amplitude of the reflected wave are adjusted by modulating the refractive index of a transparent conductive oxide layer by applying a bias voltage. [...] Read more.
The dynamic steering of a beam reflected from a photonic structure supporting Tamm plasmon polariton is demonstrated. The phase and amplitude of the reflected wave are adjusted by modulating the refractive index of a transparent conductive oxide layer by applying a bias voltage. It is shown that the proposed design allows for two-dimensional beam steering by deflecting the light beam along the polar and azimuthal angles. Full article
Show Figures

Figure 1

12 pages, 1842 KiB
Article
Al2O3/GeO2/P2O5/F-Doped Silica Large-Mode-Area Optical Fibers for High-Power Single-Frequency Radiation Delivery
Photonics 2023, 10(10), 1150; https://doi.org/10.3390/photonics10101150 - 13 Oct 2023
Cited by 1 | Viewed by 490
Abstract
A new design of a passive optical fiber waveguide with a large mode area (LMA) and strong stimulated Brillouin scattering (SBS) suppression is proposed. The fiber core consists of two parts: a central one, doped with Al2O3 and GeO2 [...] Read more.
A new design of a passive optical fiber waveguide with a large mode area (LMA) and strong stimulated Brillouin scattering (SBS) suppression is proposed. The fiber core consists of two parts: a central one, doped with Al2O3 and GeO2, and a peripheral one, doped with P2O5 and F. The doping profiles form a gradient-increasing profile of the acoustic refractive index, which effectively implements the acoustic multimode SBS suppression method. Measurements of the SBS gain spectrum and SBS threshold power were carried out, showing an increase in the SBS threshold of no less than 11 dB compared to a conventional uniformly doped passive LMA fiber. Full article
(This article belongs to the Special Issue Optical Fiber Lasers)
Show Figures

Figure 1

2 pages, 158 KiB
Editorial
Special Issue on Fiber Laser and Their Applications
Photonics 2023, 10(10), 1149; https://doi.org/10.3390/photonics10101149 - 12 Oct 2023
Viewed by 524
Abstract
Fiber lasers have achieved significant advancements owing to their compactness, perfect beam quality, good environmental adaptability, and so on [...] Full article
(This article belongs to the Special Issue Fiber Laser and Their Applications)
10 pages, 3677 KiB
Communication
Investigation of Optical Cavity Dynamics with Raman and Ytterbium-Doped Gain Media Integration
Photonics 2023, 10(10), 1148; https://doi.org/10.3390/photonics10101148 - 12 Oct 2023
Viewed by 550
Abstract
This study delves into a comprehensive examination of an optical cavity system that integrates Raman and Yb-doped gain media, with a focus on understanding their interactions. The research implies a characterization of each gain medium within the cavity while subjecting them to diverse [...] Read more.
This study delves into a comprehensive examination of an optical cavity system that integrates Raman and Yb-doped gain media, with a focus on understanding their interactions. The research implies a characterization of each gain medium within the cavity while subjecting them to diverse co-pumping conditions with the other. When the Raman-lasing cavity is co-pumped by exciting the Yb-doped section, the resulting composite laser exhibits significant threshold reductions and there is an optimal co-pumping regime that enhances energy transfer from pump to Stokes. As for the complementary cavity, where the Yb-doped gain is influenced by the co-pumped Raman gain, at moderate pump powers a light-controlling-light behavior phenomenon arises. Within this regime, the 1064 nm signal suppresses the Yb-generated 1115 nm signal, suggesting potential applications in intracavity optical modulation. For higher pump levels, a cooperative effect emerges whereby both lasers mutually enhance each other. Minor variations in the primary 974 nm pump power, even by just a few milliwatts, result in significant capabilities for switching or modulating the Stokes signal. Under these conditions of mutual enhancement, the hybrid optical system validates notable improvements regarding energy transfer efficiency and threshold reduction. This research provides valuable insights into the intricate dynamics of optical cavity systems and reveals promising avenues for applications in advanced optical modulation technologies. Full article
Show Figures

Figure 1

Previous Issue
Next Issue
Back to TopTop
