Advanced Characterization and On-Line Process Monitoring of Additively Manufactured Materials...
share announcement

Advanced Characterization and On-Line Process Monitoring of Additively Manufactured Materials and Components

A special issue of Metals (ISSN 2075-4701). This special issue belongs to the section "Additive Manufacturing".

Deadline for manuscript submissions: closed (31 March 2022) | Viewed by 52531

Printed Edition Available!
A printed edition of this Special Issue is available here.

Special Issue Editors

Prof. Dr. Giovanni Bruno

E-Mail Website
Guest Editor
Bundesanstalt für Materialforschung und –prüfung (BAM), Berlin, Germany
Interests: neutron diffraction; residual stress; mechanical properties of materials; additive manufacturing; porous ceramics
Special Issues, Collections and Topics in MDPI journals
Dr. Christiane Maierhofer

E-Mail Website
Guest Editor
Federal Institute for Materials Research and Testing (BAM), Berlin, Germany
Interests: active thermography; additive manufacturing; welding; joint connections; composites

Special Issue Information

Dear Colleagues,

Additive manufacturing (AM) techniques have risen to prominence in many industrial sectors. This rapid success of AM is due to the freeform design, which offers enormous possibilities to the engineer, and to the reduction of waste material. Even safety-critical parts are now being produced using AM. This enthusiastic penetration of AM in our daily life is not yet paralleled by a thorough characterization and understanding of the microstructure of materials and of the internal stresses of parts. The same holds true for the understanding of the formation of defects during manufacturing. While simulation efforts are sprouting and some experimental techniques for on-line monitoring are available, still little is known about the propagation of defects throughout the life of a component (from powder to operando conditions).

This Issue aims to collect contributions about the advanced characterization of AM materials and components (especially at large-scale experimental facilities such as Synchrotron and Neutron sources), as well as efforts to liaise online process monitoring to the final product and even to the component during operation. While primarily focused on metallic materials and components, this Issue welcomes contributions dealing with all industrially relevant AM materials and components, such as (but not exhaustively) ceramic implants, polymeric parts, and geopolymers. The goal is to give an overview of advances in the understanding of the impacts of microstructure and defects on component performance and life at several length scales of both defects and parts.

Prof. Dr. Giovanni Bruno
Dr. Christiane Maierhofer
Guest Editors

Manuscript Submission Information

Manuscripts should be submitted online at www.mdpi.com by registering and logging in to this website. Once you are registered, click here to go to the submission form. Manuscripts can be submitted until the deadline. All submissions that pass pre-check are peer-reviewed. Accepted papers will be published continuously in the journal (as soon as accepted) and will be listed together on the special issue website. Research articles, review articles as well as short communications are invited. For planned papers, a title and short abstract (about 100 words) can be sent to the Editorial Office for announcement on this website.

Submitted manuscripts should not have been published previously, nor be under consideration for publication elsewhere (except conference proceedings papers). All manuscripts are thoroughly refereed through a single-blind peer-review process. A guide for authors and other relevant information for submission of manuscripts is available on the Instructions for Authors page. Metals is an international peer-reviewed open access monthly journal published by MDPI.

Please visit the Instructions for Authors page before submitting a manuscript. The Article Processing Charge (APC) for publication in this open access journal is 2600 CHF (Swiss Francs). Submitted papers should be well formatted and use good English. Authors may use MDPI's English editing service prior to publication or during author revisions.

Keywords

  • Thermography
  • Microstructure
  • Defects
  • Porosity
  • Mechanical properties
  • Computed tomography
  • Large-scale facilities
  • Residual stress

Published Papers (15 papers)
