Electricity, Volume 6, Issue 1 (March 2025) – 16 articles

Shunt active power filters (SAPFs) have been around for a long time. They improve the quality of a current drawn from the grid when feeding non-linear loads formed by old-fashioned power electronic converters such as uncontrolled and controlled rectifiers. Most SAPFs are implemented using the well-known six-switch three-phase inverter (SSTPI) topology. This paper investigates the capability of adopting the four-switch three-phase inverter (FSTPI) scheme to develop low-cost SAPFs, mainly for low-power ranges. The performance of the proposed SAPF using the FSTPI topology is compared with the conventional scheme of an SAPF formed by the six-switch three-phase inverter (SSTPI) topology. Qualitative and quantitative analyses are conducted. The performance of the proposed FSTPI-based SAPF is investigated under different loading conditions. The obtained results indicate the validity and effectiveness of the FSTPI scheme in improving the quality of currents drawn from the AC grid. The SAPF scheme investigated is also feasible and results in cost reduction when the SAPF power circuit is constructed with modern WBG devices, such as SiC-based MOSFETs, which are relatively expensive (approximately three times the price of the equivalent Si IGBTs). Full article

This paper considers two dynamic load models that are widely used in industry to account for induction motor behavior: CMLD and CLOD. These models must be parametrized for the specific utility system in a general way so that they can be used in planning studies and provide a conservative but realistic representation of load behavior. This study considers a measurement-based approach to tuning both models. The load modeling study compares the response of the tuned models to generic candidate models using historical events. This study considers one area-based subsystem to simplify the modeling approach and reduce the number of models required for simulations. Additionally, because dynamic load models often produce similar results for different sets of parameters, a sensitivity study was conducted to assess the parameter impacts on the voltage response. The sensitivity study covers the parameters that are tuned using event measurements. The process to estimate the parameters uses the particle-swarm optimization algorithm. Overall, the performance of the tuned model more accurately captures recovery voltage, delayed recovery, and settling voltage than its predecessor models while not being overly tuned so that it remains general for peak summer conditions. Full article

This paper addresses the optimal conductor selection (OCS) problem in radial distribution networks, aiming to minimize the total costs associated with conductor investment and energy losses while ensuring voltage regulation and power balance as well as observing thermal limits. The problem is formulated as a mixed-integer nonlinear programming (MINLP) model and solved using a hybrid branch-and-bound (B&B), interior-point optimizer (IPO) approach within the Julia-based JuMP framework. Numerical validations on 27-, 33-, and 69-bus test feeders demonstrate cost-efficient conductor configurations. A multi-objective analysis is employed to construct the Pareto front, offering trade-offs between investment and operating costs. The impact of distributed energy resources (DERs) is also assessed, showing cost reductions when said resources provide reactive power support. The results confirm that the proposed MINLP approach outperforms conventional metaheuristics in terms of accuracy and reliability. Full article

Energy storage systems (ESSs) and active power filters (APFs) are key power electronic technologies for FACTS (Flexible AC Transmission Lines). Battery energy storage has a structure similar to a shunt active power filter, i.e., a storage element and a voltage source inverter (VSI) connected to the grid using a PWM filter and/or transformer. This similarity allows for the design of an ESS with the ability to operate as a shunt APF. One of the key milestones in ESS or APF development is the DC-link design. The proper choice of the capacitance of the DC-link capacitors and their equivalent resistance ensures the proper operation of the whole power electronic system. In this article, it is proposed to estimate the required minimum DC-link capacitance using a spectral analysis of the DC-link current for different operating modes, battery charge mode and harmonic compensation mode, for a nonlinear load. It was found that the AC component of the DC-link current is shared between the DC-link capacitors and the rest of the DC stage, including the battery. This relation is described analytically. The main advantage of the proposed approach is its universality, as it only requires calculating the harmonic spectrum using the switching functions. This approach is demonstrated for DC-link capacitor estimation in two-level and three-level NPC inverter topologies. Moreover, an analysis of the AC current component distribution between the DC-link capacitors and the other elements of the DC-link stage was carried out. This part of the analysis is especially important for battery energy storage systems. The obtained results were verified using a simulation model. Full article

In this article, a comprehensive review of electrical microgrids is presented, emphasizing their increasing importance in the context of renewable energy integration. Microgrids, capable of operating in both grid-connected and standalone modes, offer significant potential for providing energy solutions to rural and remote communities. However, the inclusion of diverse energy sources, energy storage systems (ESSs), and varying load demands introduces challenges in control and optimization. This review focuses on hybrid microgrids, analyzing their operational scenarios and exploring various optimization strategies and control approaches for efficient energy management. By synthesizing recent advancements and highlighting key trends, this article provides a detailed understanding of the current state and future directions in hybrid microgrid systems. Full article

This paper proposes the integration and operation of lithium-ion battery energy storage systems (ESS) in active distribution networks with high penetration of distributed generation based on renewable energy. The goal is to minimize total system costs, including energy purchasing at the substation node, as well as ESS integration, maintenance, and replacement costs over a 20-year planning horizon. The proposed master–slave methodology uses the Salp Swarm Optimization Algorithm to determine ESS location, technology, and daily operation schemes, combined with a successive approximation power flow to compute the objective function value and enforce constraints. This approach employs a discrete–continuous encoding, reducing processing times and increasing the likelihood of finding the global optimum. Validated on a 33-node test system adapted to Medellín, Colombia, the methodology outperformed five metaheuristic algorithms, achieving the highest annual savings (USD 16,605.77), the lowest average cost (USD 2,964,139.99), and the fastest processing time (345.71 s). The results demonstrate that the proposed methodology enables network operators to reduce distribution network costs effectively, offering high repeatability, solution quality, and computational efficiency. Full article

To tackle the challenges arising from missing real-time measurement data and dynamic changes in network topology in optimizing and controlling distribution networks, this study proposes a data-driven collaborative optimization strategy tailored for multi-area clusters. Firstly, the distribution network is clustered based on electrical distance modularity and power balance indicators. Next, a collaborative optimization model for multiple area clusters is constructed with the objectives of minimizing node voltage deviations and active power losses. Then, a locally observable Markov decision model within the clusters is developed to characterize the relationship between the temporal operating states of the distribution network and the decision-making instructions. Using the Actor–Critic framework, the cluster agents are trained while considering the changes in cluster boundaries due to topology variations. A Critic network based on an attention encoder is designed to map the dynamically changing cluster observations to a fixed-dimensional space, enabling agents to learn control strategies under topology changes. Finally, case studies show the effectiveness and superiority of the proposed method. Full article

This article presents two novel mixed-integer nonlinear programming (MINLP) formulations in the complex variable domain to address the optimal phase-balancing problem in asymmetric three-phase distribution networks. The first employs a matrix-based load connection model (M-MINLP), while the second uses a compact vector-based representation (V-MINLP). Both integrate the power flow equations through the current injection method, capturing the nonlinearities of Delta and Wye loads. These formulations, solved via an interior-point optimizer and the branch-and-cut method in the Julia software, ensure global optima and computational efficiency. Numerical validations on 8-, 25-, and 37-node feeders showed power loss reductions of 24.34%, 4.16%, and 19.26%, outperforming metaheuristic techniques and convex approximations. The M-MINLP model was 15.6 times faster in the 25-node grid and 2.5 times faster in the 37-node system when compared to the V-MINLP approach. The results demonstrate the robustness and scalability of the proposed methods, particularly in medium and large systems, where current techniques often fail to converge. These formulations advance the state of the art by combining exact mathematical modeling with efficient computation, offering precise, scalable, and practical tools for optimizing power distribution networks. The corresponding validations were performed using Julia (v1.10.2), JuMP (v1.21.1), and AmplNLWriter (v1.2.1). Full article

This paper presents a detailed fifth-order mathematical model of a three-phase induction motor, used in the WECC (Western Electricity Coordinating Council) composite load model. The main objective is to analyze the dynamic behavior of three-phase induction motors during fault-induced delayed voltage recovery (FIDVR) events, a critical phenomenon in power system voltage stability. The model is implemented in MATLAB/Simulink and validated by comparing its results with previous studies, demonstrating its ability to capture transient and subtransient responses under voltage disturbances. Different types of motors (A, B, and C) are analyzed, and variations in load and voltage disturbance magnitudes are studied. The results show that the model is accurate and robust, making it useful for voltage stability studies in systems with high induction motor penetration. However, the model has limitations, such as the lack of consideration for frequency drives and protection systems, suggesting areas for future research. Full article

In non-synchronous machine sources (N-SMSs), power sources are connected to the grid through power electronic devices, which typically exhibit a voltage-controlled current source characteristic during faults. Due to the current-limiting feature of inverters, the voltage and current demonstrate a strong nonlinearity. As a result, the short-circuit current (SCC) of N-SMSs is commonly calculated using iterative methods. For renewable energy plants, which contain a large number of N-SMSs, the calculation is often based on the single-machine multiplication method, ignoring internal discrepancies among machines. To address these issues, this paper proposes a calculation method for the SCC contributed by a renewable energy plant based on single-machine multiplication. This method is simple, does not require iteration, and ensures engineering practicability. This paper first analyzes the SCC calculation model under a low-voltage ride-through (LVRT) control strategy. Inspired by the single-machine multiplication approach, a fast initial voltage calculation method at the machine terminal is proposed, along with an active current correction method. With this approach, a more accurate SCC can be obtained, avoiding convergence issues and ensuring practical applicability in engineering. The validity of this method is verified through PSCAD/EMTDC simulations. The error in calculating SCC does not exceed 3.02%. Compared with the single-machine multiplication method, the accuracy is significantly improved, while the accuracy is roughly equivalent to that of the iterative method. Full article

Forming required AC voltage levels is currently one of the most pressing problems. Unstable voltage levels can lead to the failure of household and industrial equipment. This can lead to a pure effect on the production cycle. In this regard, the development of AC voltage regulators has become relevant. Such regulators can perform the function of voltage level asymmetry compensators in a three-phase power supply network. In turn, new topologies should be energy-efficient and reliable. This can be achieved by reducing the number of semiconductor elements, thus reducing losses and increasing efficiency. Also, AC voltage regulators have found applications as soft-start devices for motors and have become relevant to frequency converters. The power level of such devices can vary from units to tens of kilowatts. This paper presents several circuit design solutions for AC voltage regulators with fewer switches. These solutions are made according to both a single-level and two-level system, where the level refers to the number of links that increase the transmission coefficient. The schemes were analyzed, and efficiency was evaluated through their harmonic coefficients, power factor, and efficiency coefficient. For the basic scheme, a photo of the experimental layout and its results are provided. Full article

This study explores the potential for PV solar power and battery storage to reduce energy costs in a typical Malian single-family household, highlighting significant cost savings and improved energy reliability. The high solar irradiance throughout the year makes solar power viable for household energy needs. However, most electricity is consumed at night due to air conditioning, with an annual consumption of 12,504 kWh. Cost models for solar power plants and battery energy storage systems, including installation, were developed. Cost parameters were reviewed using the latest literature, distinguishing between current and future cost trends, referred to as Case I and Case II, respectively. Additionally, a feed-in tariff of $0.00 and $0.04 per injected kWh of electricity into the AC mains was considered. The annual return in USD and the return on investment were considered as economic parameters. A small solar power plant with a peak power of up to 3 kW can achieve a high ROI between 70% and 100%. Due to reduced future cost prospects, this ROI could increase to 90% to 130%. However, such a plant can only reach a maximum self-sufficiency of about 40%, as most of the electricity is consumed during nights. A 4 kW power plant can achieve a self-sufficiency of about one-third for an ROI of 57% to 82%, costing approximately $1330 to $1760. When using battery energy storage, a self-sufficiency of 95% has been targeted. With battery storage, the maximum ROI varies from 22.5% to 32.0% with an investment cost of about $9590 to $13,139. Full article

Offshore wind farms are increasingly being commissioned farther from shore, and high voltage alternating current (HVAC) transmission systems are preferred because of their maturity and reliability. However, as cable length increases, ensuring system stability becomes more challenging, making it essential to investigate shunt reactor compensation configurations and converter control strategies. This study examines three different shunt reactor compensation arrangements and two control strategies, grid-forming (GFM) and grid-following (GFL), across three cable lengths (80 km, 120 km, and 150 km). The systems were evaluated based on small-signal stability using disk margins for different active power operating points, and later for different short-circuit ratios (SCR) and X/R. The results demonstrate that the GFM is preferable for longer cables and enhanced stability. The most robust configuration includes a shunt reactor placed in the mid-cable with additional reactors at both ends of the cable, followed by an arrangement with reactors at the beginning and end. The GFM converter control maintained stability across all operating points, cable lengths, and configurations, whereas the stability of the GFL unit was highly dependent on active power injection and struggled under weaker grid conditions. Thus, for longer HVAC cables, it is necessary to employ GFM control units, and it is recommended to use shunt reactors at the cable start and end, as well as at mid-cable, for optimal stability. Full article

To enhance the utilization of emerging energy sources, the application of battery energy storage systems (BESSs) was increasingly explored by investors. However, the immature development of BESS technologies introduced supply–demand imbalances, complicating the establishment of standardized cost analysis frameworks for potential investments. To address this challenge, a hybrid optimization model for a user-side BESS was developed to maximize total net returns over the system’s entire life cycle. The model accounted for factors such as energy storage arbitrage revenue, government tariff subsidies, reductions in electricity transmission fees, delays in grid upgrades, and overall life cycle costs. Conditional value-at-risk (CVaR) was employed as a risk assessment metric to provide investment allocation recommendations across various risk scenarios. An example analysis was conducted to allocate and evaluate the net returns of different battery types. The results demonstrated that the model identified optimal investment strategies aligned with investors’ risk preferences, enabling informed decision-making that balanced returns with operational stability. This approach enhanced the resilience and economic viability of user-side energy storage configurations. Full article

In this paper, the performance of a Dual-Stator Winding Synchronous Reluctance Generator (SynRG) suitability for off-grid wind power generation is analyzed. The rotor of the SynRG has a slitted-rotor core to improve selected vital performance parameters. The SynRG with a slitted-rotor core was modeled using a two-dimensional (2D) Finite Element Method (FEM) to study the electromagnetic performance of key parameters of interest. To validate the FEA results, a prototype of the SynRG with a slitted rotor was tested in the laboratory for no-load operation and load operation for unity, lagging, and leading power factors. To evaluate the capability of the SynRG with a slitted-rotor core to operate in a wind turbine environment, the machine was modeled and simulated in Matlab/Simulink (R2023a) for dynamic responses. The FEA results reveal that the SynRG with a slitted-rotor core, compared with the conventional SynRG with the same ratings and specifications, reduces the torque ripple by 24.51%, 29.72%, and 13.13% when feeding 8 A to a load with unity, lagging, and leading power factors, respectively. The FEA results also show that the induced voltage on no-load of the SynRG with a slitted-rotor core, compared with the conventional SynRG of the same ratings and specifications, increases by 10.77% when the auxiliary winding is fed by a capacitive excitation current of 6 A. Furthermore, the same results show that with a fixed excitation capacitive current of 6 A, the effect of armature reaction of the SynRG with a slitted-rotor core is demagnetizing when operating with load currents having a lagging power factor, and magnetizing when operating with load currents having unity and leading power factors. The same patterns have been observed in the experimental results for different excitation capacitance values. The Matlab/Simulink results show that the SynRG with a slitted-rotor core has a quicker dynamic response than the conventional SynRG. However, a well-designed pitch-control mechanism for the wind turbine is necessary to account for changes in wind speeds. Full article

With the rise of renewable energy penetration in the grid, photovoltaic (PV) panels are connected to the grid via inverters to supply solar energy. Transformer-less grid-tied PV inverters are gaining popularity because of their improved efficiency, reduced size, and lower costs. However, they can induce a path for leakage currents between the PV and the grid due to the absence of galvanic isolation. This leads to serious electromagnetic interference, loss in efficiency, and safety concerns. The leakage current is primarily influenced by the nature of the common mode voltage (CMV), which is determined by the switching techniques of the inverter. In this paper, a novel inverter topology of Hysteresis Controlled H5 with Two Clamping Diodes (HCH5-D2) is derived. The HCH5-D2 topology helps decouple the AC part (Grid) and DC part (PV) during the freewheeling period to make the CMV constant, thereby reducing the leakage current. Additionally, the extra diodes help reduce voltage spikes generated during the freewheeling period and maintain the CMV at a constant value. Finally, a 2.2 kW grid-connected single-phase HCH5-D2 PV inverter system’s MATLAB simulation is presented, showing better results compared to a traditional H4 inverter. Full article
