Metals, Volume 8, Issue 2 (February 2018) – 67 articles

Cover Story (view full-size image): In order to reduce rotating masses, the Presta joining process is extended to the usage of aluminum shafts. For this purpose, the manufacturing process is modelled using the finite element method and a material model of large strain viscoplasticity to provide a realistic representation of the material behavior even for large deformations. The simulation sequence includes the rolling of the shaft, which causes a local widening of the shaft, and the subsequent joining step, where a cam with an inner profile oriented parallel to the shaft axis is forced onto the widened cam seat. View the paper here.
  • Issues are regarded as officially published after their release is announced to the table of contents alert mailing list.
  • You may sign up for e-mail alerts to receive table of contents of newly released issues.
  • PDF is the official format for papers published in both, html and pdf forms. To view the papers in pdf format, click on the "PDF Full-text" link, and use the free Adobe Reader to open them.
Order results
Result details
Section
Select all
Export citation of selected articles as:
15 pages, 5777 KiB
Article
Processing Effects on the Formability of Magnesium Alloy Sheets
by Jan Bohlen, Guadalupe Cano, Daria Drozdenko, Patrik Dobron, Karl Ulrich Kainer, Sven Gall, Sören Müller and Dietmar Letzig
Metals 2018, 8(2), 147; https://doi.org/10.3390/met8020147 - 23 Feb 2018
Cited by 23 | Viewed by 5370
Abstract
As a generalized semi-finished product, the use of magnesium sheets requires addressing two major aspects of their processing: their microstructure and texture control, which are both essential for the forming behavior of such sheets during their forming to parts. Further, the processing of [...] Read more.
As a generalized semi-finished product, the use of magnesium sheets requires addressing two major aspects of their processing: their microstructure and texture control, which are both essential for the forming behavior of such sheets during their forming to parts. Further, the processing of such sheets is complex, and therefore expensive, and requires simplification. In this work, magnesium alloys AZ31, ZE10, and ME21 are investigated in the form of conventionally rolled sheets, as well as in the form of extruded sheets. Their microstructural and textural development are correlated to their mechanical and forming properties. During extrusion, strong textures develop that hinder stretch-forming operations, even in rare earth-containing alloys. Chemical composition and process parameters have a significant impact on the texture development, and enable the design of sheet materials with weak textures and potentially enhanced formability. Full article
Show Figures

Figure 1

13 pages, 9237 KiB
Article
Numerical Simulation of Transient Multiphase Flow in a Five-Strand Bloom Tundish during Ladle Change
by Hua Zhang, Ronghua Luo, Qing Fang, Hongwei Ni and Xiao Song
Metals 2018, 8(2), 146; https://doi.org/10.3390/met8020146 - 23 Feb 2018
Cited by 17 | Viewed by 4103
Abstract
The steel-slag-air multiphase flow in a bloom tundish with five strands during the transient casting of the ladle change was simulated using the Volume of Fluid (VOF) model, and the formation mechanisms of macro-inclusions and the behavior of the steel-slag-air interface during the [...] Read more.
The steel-slag-air multiphase flow in a bloom tundish with five strands during the transient casting of the ladle change was simulated using the Volume of Fluid (VOF) model, and the formation mechanisms of macro-inclusions and the behavior of the steel-slag-air interface during the filling process were investigated. Water model experiments were conducted to validate the multiphase model. The results showed that the numerical results of slag entrapment behavior and the exposed area of steel are basically consistent with the experimental results. The flow of molten steel in the tundish is weak except for the region around the stopper rods at the end of the emptying process. Strong fluctuations in liquid level were formed during the filling process, showing two wave crests in front of and behind the shroud in the impact zone, which intensified with the increase in filling time and then declined gradually. Entrapment phenomena and exposure of liquid steel could not be observed before the filling stage. While the entrapped slag droplets mostly float up and can be removed within 40 s during the filling process, the remainder enters the casting zone through the baffle. The maximum exposed area of molten steel is 252 cm2 when the filling time is 4.0 s. Full article
Show Figures

Figure 1

10 pages, 5297 KiB
Article
An Investigation on the Adiabatic Shear Bands in Depleted U-0.75 wt % Ti Alloy under Dynamic Loading
by Bo Wang, Yongxiang Dong and Guangyan Huang
Metals 2018, 8(2), 145; https://doi.org/10.3390/met8020145 - 22 Feb 2018
Cited by 8 | Viewed by 6744
Abstract
Adiabatic shear bands in uranium alloy projectiles/penetrators, during penetration, allow them to “self-sharpen,” a process that is absent in most tungsten alloy projectiles/penetrators. U-0.75 wt % Ti alloy samples have been accelerated to impact steel targets, and the distribution of adiabatic shear bands [...] Read more.
Adiabatic shear bands in uranium alloy projectiles/penetrators, during penetration, allow them to “self-sharpen,” a process that is absent in most tungsten alloy projectiles/penetrators. U-0.75 wt % Ti alloy samples have been accelerated to impact steel targets, and the distribution of adiabatic shear bands in residual samples has been studied in detail to understand the effect of self-sharpening on penetration. In our study, self-sharpening was evidenced by the distribution of the shear bands in the recovered sample. The shear bands formed during impact were observed to change direction when they crossed grain boundaries, which indicated that the grain boundaries had an influence on the adiabatic shear bands of U-0.75 wt % Ti. Micro-hardness test results showed that the Vickers micro-hardness in the adiabatic shear zone was 18% lower than that in the matrix. In the split-Hopkinson pressure bar (SHPB) experiment, a strain rate of around 2891 s−1 was the threshold strain rate that triggered the formation of adiabatic shear bands in the U-0.75 wt % Ti alloy. Full article
Show Figures

Figure 1

10 pages, 5864 KiB
Article
Microstructure, Texture Evolution and Magnetic Properties of Fe-6.5 wt. % Si and Fe-6.5 wt. % Si-0.5 wt. % Cu Alloys during Rolling and Annealing Treatment
by Zhaoyang Cheng, Jing Liu, Jiachen Zhu, Zhidong Xiang, Juan Jia and Yunjie Bi
Metals 2018, 8(2), 144; https://doi.org/10.3390/met8020144 - 22 Feb 2018
Cited by 4 | Viewed by 4148
Abstract
Sheets of Fe-6.5 wt. % Si and Fe-6.5 wt. % Si-0.5 wt. % Cu with the thickness of 0.3 mm have been produced by hot and warm rolling. The microstructure, texture evolution and magnetic properties of the two alloys were investigated. It was [...] Read more.
Sheets of Fe-6.5 wt. % Si and Fe-6.5 wt. % Si-0.5 wt. % Cu with the thickness of 0.3 mm have been produced by hot and warm rolling. The microstructure, texture evolution and magnetic properties of the two alloys were investigated. It was found that the addition of 0.5 wt. % Cu promoted the formation of shear bands during warm rolling, and enhanced the {110}<001> texture at surface layer and {111}<112> texture in the middle layer. After annealing treatment, a strong η fiber texture with a peak at {110}<001> was formed in the Fe-6.5 wt. % Si-0.5 wt. % Cu sample, while the Fe-6.5 wt. % Si sample was characterized by complex γ, η and λ fibers. The formation of dominating η fiber in the annealed Fe-6.5 wt. % Si-0.5 wt. % Cu sample is attributed to the shear bands formed in {111}<112> oriented grains. These shear bands in {111}<112> oriented grains acted as the nucleation sites of η oriented grains and promoted the growth of Goss oriented grains. The presence of strong η fiber with a peak at Goss in Fe-6.5 wt. % Si-0.5 wt. % Cu sample was the cause for the higher magnetic induction observed for this sample than for the Fe-6.5 wt. % Si sample. Full article
(This article belongs to the Special Issue Metallic Materials and Manufacturing)
Show Figures

Figure 1

11 pages, 956 KiB
Article
Particle-Reinforced Aluminum Matrix Composites (AMCs)—Selected Results of an Integrated Technology, User, and Market Analysis and Forecast
by Anja Schmidt, Steve Siebeck, Uwe Götze, Guntram Wagner and Daisy Nestler
Metals 2018, 8(2), 143; https://doi.org/10.3390/met8020143 - 22 Feb 2018
Cited by 37 | Viewed by 5371
Abstract
The research and development of new materials such as particle-reinforced aluminum matrix composites (AMCs) will only result in a successful innovation if these materials show significant advantages not only from a technological, but also from an economic point of view. Against this background, [...] Read more.
The research and development of new materials such as particle-reinforced aluminum matrix composites (AMCs) will only result in a successful innovation if these materials show significant advantages not only from a technological, but also from an economic point of view. Against this background, in the Collaborative Research Center SFB 692, the concept of an integrated technology, user, and market analysis and forecast has been developed as a means for assessing the technological and commercial potential of new materials in early life cycle stages. After briefly describing this concept, it is applied to AMCs and the potential field of manufacturing aircraft components. Results show not only technological advances, but also considerable economic potential—the latter one primarily resulting from the possible weight reduction being enabled by the increased yield strength of the new material. Full article
Show Figures

Figure 1

10 pages, 6655 KiB
Article
The Properties of Arc-Sprayed Aluminum Coatings on Armor-Grade Steel
by Marcin Adamiak, Artur Czupryński, Adam Kopyść, Zbigniew Monica, Małgorzata Olender and Aleksander Gwiazda
Metals 2018, 8(2), 142; https://doi.org/10.3390/met8020142 - 22 Feb 2018
Cited by 20 | Viewed by 6498
Abstract
This article presents the results of an examination of the properties of arc-sprayed aluminum on alloyed armor-grade steel. Thermal arc spraying was conducted with a EuTronic Arc Spray 4 wire arc sprayer. Aluminum wire 1.6 mm in diameter was used to produce dense, [...] Read more.
This article presents the results of an examination of the properties of arc-sprayed aluminum on alloyed armor-grade steel. Thermal arc spraying was conducted with a EuTronic Arc Spray 4 wire arc sprayer. Aluminum wire 1.6 mm in diameter was used to produce dense, abrasion- and erosion-resistant coatings approx. 1.0 mm thick with and without nickel/5% aluminum-buffered subcoating. Aluminum coatings were characterized in accordance with ASTM G 65-00 abrasion resistance test, ASTM G 76-95 erosion resistance tests, ASTM C 633-01 adhesion strength, HV0.1 hardness tests and metallographic analyses. Results demonstrate properties of arc-sprayed aluminum and aluminum-nickel material coatings that are especially promising in industrial applications where erosion-, abrasion- and corrosion-resistant coating properties are required. Full article
Show Figures

Figure 1

11 pages, 5160 KiB
Article
The Formation and Evolution of Shear Bands in Plane Strain Compressed Nickel-Base Superalloy
by Bin Tang, Lin Xiang, Liang Cheng, Degui Liu, Hongchao Kou and Jinshan Li
Metals 2018, 8(2), 141; https://doi.org/10.3390/met8020141 - 18 Feb 2018
Cited by 16 | Viewed by 5331
Abstract
The formation and evolution of shear bands in Inconel 718 nickel-base superalloy under plane strain compression was investigated in the present work. It is found that the propagation of shear bands under plane strain compression is more intense in comparison with conventional uniaxial [...] Read more.
The formation and evolution of shear bands in Inconel 718 nickel-base superalloy under plane strain compression was investigated in the present work. It is found that the propagation of shear bands under plane strain compression is more intense in comparison with conventional uniaxial compression. The morphology of shear bands was identified to generally fall into two categories: in “S” shape at severe conditions (low temperatures and high strain rates) and “X” shape at mild conditions (high temperatures and low strain rates). However, uniform deformation at the mesoscale without shear bands was also obtained by compressing at 1050 °C/0.001 s−1. By using the finite element method (FEM), the formation mechanism of the shear bands in the present study was explored for the special deformation mode of plane strain compression. Furthermore, the effect of processing parameters, i.e., strain rate and temperature, on the morphology and evolution of shear bands was discussed following a phenomenological approach. The plane strain compression attempt in the present work yields important information for processing parameters optimization and failure prediction under plane strain loading conditions of the Inconel 718 superalloy. Full article
Show Figures

Figure 1

15 pages, 4661 KiB
Article
Sensitivity Analysis of Oxide Scale Influence on General Carbon Steels during Hot Forging
by Bernd-Arno Behrens, Alexander Chugreev, Birgit Awiszus, Marcel Graf, Rudolf Kawalla, Madlen Ullmann, Grzegorz Korpala and Hendrik Wester
Metals 2018, 8(2), 140; https://doi.org/10.3390/met8020140 - 17 Feb 2018
Cited by 7 | Viewed by 4242
Abstract
Increasing product requirements have made numerical simulation into a vital tool for the time- and cost-efficient process design. In order to accurately model hot forging processes with finite, element-based numerical methods, reliable models are required, which take the material behaviour, surface phenomena of [...] Read more.
Increasing product requirements have made numerical simulation into a vital tool for the time- and cost-efficient process design. In order to accurately model hot forging processes with finite, element-based numerical methods, reliable models are required, which take the material behaviour, surface phenomena of die and workpiece, and machine kinematics into account. In hot forging processes, the surface properties are strongly affected by the growth of oxide scale, which influences the material flow, friction, and product quality of the finished component. The influence of different carbon contents on material behaviour is investigated by considering three different steel grades (C15, C45, and C60). For a general description of the material behaviour, an empirical approach is used to implement mathematical functions for expressing the relationship between flow stress and dominant influence variables like alloying elements, initial microstructure, and reheating mode. The deformation behaviour of oxide scale is separately modelled for each component with parameterized flow curves. The main focus of this work lies in the consideration of different materials as well as the calculation and assignment of their material properties in dependence on current process parameters by application of subroutines. The validated model is used to carry out the influence of various oxide scale parameters, like the scale thickness and the composition, on the hot forging process. Therefore, selected parameters have been varied within a numerical sensitivity analysis. The results show a strong influence of oxide scale on the friction behaviour as well as on the material flow during hot forging. Full article
(This article belongs to the Special Issue Advances in Plastic Forming of Metals)
Show Figures

Figure 1

15 pages, 4327 KiB
Article
Effect of Nitric and Oxalic Acid Addition on Hard Anodizing of AlCu4Mg1 in Sulphuric Acid
by Maximilian Sieber, Roy Morgenstern, Ingolf Scharf and Thomas Lampke
Metals 2018, 8(2), 139; https://doi.org/10.3390/met8020139 - 17 Feb 2018
Cited by 14 | Viewed by 5543
Abstract
The anodic oxidation process is an established means for the improvement of the wear and corrosion resistance of high-strength aluminum alloys. For high-strength aluminum-copper alloys of the 2000 series, both the current efficiency of the anodic oxidation process and the hardness of the [...] Read more.
The anodic oxidation process is an established means for the improvement of the wear and corrosion resistance of high-strength aluminum alloys. For high-strength aluminum-copper alloys of the 2000 series, both the current efficiency of the anodic oxidation process and the hardness of the oxide coatings are significantly reduced in comparison to unalloyed substrates. With regard to this challenge, recent investigations have indicated a beneficial effect of nitric acid addition to the commonly used sulphuric acid electrolytes both in terms of coating properties and process efficiency. The present work investigates the anodic oxidation of the AlCu4Mg1 alloy in a sulphuric acid electrolyte with additions of nitric acid as well as oxalic acid as a reference in a full-factorial design of experiments (DOE). The effect of the electrolyte composition on process efficiency, coating thickness and hardness is established by using response functions. A mechanism for the participation of the nitric acid additive during the oxide formation is proposed. The statistical significance of the results is assessed by an analysis of variance (ANOVA). Eventually, scratch testing is applied in order to evaluate the failure mechanisms and the abrasion resistance of the obtained conversion coatings. Full article
Show Figures

Figure 1

12 pages, 8053 KiB
Article
The Effect of Interlayer Materials on the Joint Properties of Diffusion-Bonded Aluminium and Magnesium
by Stefan Habisch, Marcus Böhme, Siegfried Peter, Thomas Grund and Peter Mayr
Metals 2018, 8(2), 138; https://doi.org/10.3390/met8020138 - 17 Feb 2018
Cited by 16 | Viewed by 7613
Abstract
Diffusion bonding is a well-known technology for a wide range of advanced joining applications, due to the possibility of bonding different materials within a defined temperature-time-contact pressure regime in solid state. For this study, aluminium alloys AA 6060, AA 6082, AA 7020, AA [...] Read more.
Diffusion bonding is a well-known technology for a wide range of advanced joining applications, due to the possibility of bonding different materials within a defined temperature-time-contact pressure regime in solid state. For this study, aluminium alloys AA 6060, AA 6082, AA 7020, AA 7075 and magnesium alloy AZ 31 B are used to produce dissimilar metal joints. Titanium and silver were investigated as interlayer materials. SEM and EDXS-analysis, micro-hardness measurements and tensile testing were carried out to examine the influence of the interlayers on the diffusion zone microstructures and to characterize the joint properties. The results showed that the highest joint strength of 48 N/mm2 was reached using an aluminium alloy of the 6000 series with a titanium interlayer. For both interlayer materials, intermetallic Al-Mg compounds were still formed, but the width and the level of hardness across the diffusion zone was significantly reduced compared to Al-Mg joints without interlayer. Full article
Show Figures

Figure 1

11 pages, 4404 KiB
Article
Effects of Pre-Strain on the Aging Behavior of Al 7075 Alloy for Hot-Stamping Capability
by Seon-Ho Jung, Jongsup Lee and Megumi Kawasaki
Metals 2018, 8(2), 137; https://doi.org/10.3390/met8020137 - 16 Feb 2018
Cited by 21 | Viewed by 6868
Abstract
The present study investigates the significance of pre-strain on the T6 aging behavior of an Al 7075 alloy for evaluating the applicability of hot stamping. In practice, the alloy was pre-strained up to 15% during solution heat treatment at 480 °C prior to [...] Read more.
The present study investigates the significance of pre-strain on the T6 aging behavior of an Al 7075 alloy for evaluating the applicability of hot stamping. In practice, the alloy was pre-strained up to 15% during solution heat treatment at 480 °C prior to quenching, and artificial aging was conducted at 120 °C. The peak aging time and precipitation behavior were compared with the alloy with pre-straining at room temperature after quenching but immediately before the artificial aging. The results showed that increasing amounts of pre-strain tend to reduce the aging time up to 50% for achieving peak hardness, which is consistent with the alloy at the T6 condition. There is a limitation for the maximum attainable amount of pre-strain of 10% for the homogeneous distribution of strain when the alloy is strained at room temperature (RT) due to the low formability. The pre-strained alloy as hot stamping exhibited lowering of the peak reaction temperatures for dissolution and formation of Guinier–Preston (GP)-Zones and precipitated with increasing amounts of pre-strain towards 15% through the differential scanning calorimetry analysis, thereby confirming the shortening of the peak aging time. The present study confirms the excellent potential of the hot-stamping process to extend the capability of an Al 7075 alloy. Full article
(This article belongs to the Special Issue Heat Treatment of Aluminum Alloys)
Show Figures

Graphical abstract

17 pages, 12911 KiB
Article
Finite Element Analysis of Surface Integrity in Deep Ball-Burnishing of a Biodegradable AZ31B Mg Alloy
by Mohammad Sharif Uddin, Colin Hall, Ryan Hooper, Eric Charrault, Peter Murphy and Vincent Santos
Metals 2018, 8(2), 136; https://doi.org/10.3390/met8020136 - 16 Feb 2018
Cited by 26 | Viewed by 4759
Abstract
As an effective and affordable technique, deep ball-burnishing has been applied to induce the plastic deformation of material, thus resulting in an increased surface hardness, compressive residual stress, and finish quality. Recent research shows that the fast degradation of an Mg alloy implant [...] Read more.
As an effective and affordable technique, deep ball-burnishing has been applied to induce the plastic deformation of material, thus resulting in an increased surface hardness, compressive residual stress, and finish quality. Recent research shows that the fast degradation of an Mg alloy implant is a prime limiting factor for its success in in vivo human trials. This paper presents a comprehensive investigation into deep ball-burnishing of a biodegradable AZ31B Mg alloy, in order to improve the alloy’s surface integrity. A series of experiments using an in-house built burnishing tool with a 10-mm steel ball have been conducted, with a key focus of exploring the influence of the major process parameters—e.g., burnishing force (750–2650 N), feed rate (150–500 mm/min), and step-over (0.05–0.15 mm)—on hardness and finish quality. With the aim of performing a parametric sensitivity study, a three-dimensional (3D) finite element (FE) model is developed to predict the deformation mechanics, plastic flow, hardness, and residual stress. The FE model agrees with the experiment, hence validating the reliability of the model. Results show that while burnishing significantly improves surface integrity compared to the untreated surface, burnishing force and step-over are shown to be dominant. The net material movement dictates generated residual stress (tensile or compressive), often negatively affecting the surface integrity (e.g., surface cracks), which may be responsible for the onset of corrosion. An appropriate burnishing strategy must therefore be planned, in order to achieve the intended process outcome. The resulting surface properties, enhanced by the deep ball-burnishing, are expected to potentially increase the corrosion resistance of AZ31B Mg alloy implants. Full article
Show Figures

Figure 1

12 pages, 1865 KiB
Article
Chemical Synthesis and Characterization of Pd/SiO2: The Effect of Chemical Reagent
by Aram L. Bugaev, Vladimir A. Polyakov, Andrei A. Tereshchenko, Ashura N. Isaeva, Alina A. Skorynina, Elizaveta G. Kamyshova, Andriy P. Budnyk, Tatiana A. Lastovina and Alexander V. Soldatov
Metals 2018, 8(2), 135; https://doi.org/10.3390/met8020135 - 16 Feb 2018
Cited by 12 | Viewed by 5307
Abstract
The size and shape distribution of metal nanoparticles (NPs) are important parameters that need to be tuned in order to achieve desired properties of materials for practical applications. In the current work, we present the synthesis of palladium NPs supported on silica by [...] Read more.
The size and shape distribution of metal nanoparticles (NPs) are important parameters that need to be tuned in order to achieve desired properties of materials for practical applications. In the current work, we present the synthesis of palladium NPs supported on silica by three different methods, applying reduction by sodium borohydride, hydrazine vapors, and polyethylene glycol (PEG). The synthesized materials were characterized by X-ray diffraction, X-ray fluorescence, transmission electron microscopy, surface area and porosity measurements, and thermogravimetric analysis. Similar nanoparticle sizes with narrow size distribution centered at 8 nm were obtained after reduction by sodium borohydride and hydrazine vapors, whereas the smallest particle size of about 4.8 nm was obtained after reduction by PEG. The effect of modification of the initial palladium chloride compound by ammonium hydroxide was found to lead to the formation of larger particles with average size of 15 nm and broader size distribution. In addition, the process of the reduction of palladium by PEG at different reduction stages was monitored by UV-Vis spectroscopy. CO-stripping voltammetry showed that reduction in hydrazine and in PEG allowed the preparation of Pd NPs with high electrochemically-active surface area. Such NPs are promising materials for electrocatalysis. Full article
Show Figures

Graphical abstract

19 pages, 4681 KiB
Article
Comparative Effect of Mo and Cr on Microstructure and Mechanical Properties in NbV-Microalloyed Bainitic Steels
by Andrii Kostryzhev, Navjeet Singh, Liang Chen, Chris Killmore and Elena Pereloma
Metals 2018, 8(2), 134; https://doi.org/10.3390/met8020134 - 16 Feb 2018
Cited by 29 | Viewed by 5735
Abstract
Steel product markets require the rolled stock with further increasing mechanical properties and simultaneously decreasing price. The steel cost can be reduced via decreasing the microalloying elements contents, although this decrease may undermine the mechanical properties. Multi-element microalloying with minor additions is the [...] Read more.
Steel product markets require the rolled stock with further increasing mechanical properties and simultaneously decreasing price. The steel cost can be reduced via decreasing the microalloying elements contents, although this decrease may undermine the mechanical properties. Multi-element microalloying with minor additions is the route to optimise steel composition and keep the properties high. However, this requires deep understanding of mutual effects of elements on each other’s performance with respect to the development of microstructure and mechanical properties. This knowledge is insufficient at the moment. In the present work we investigate the microstructure and mechanical properties of bainitic steels microalloyed with Cr, Mo, Nb and V. Comparison of 0.2 wt. % Mo and Cr additions has shown a more pronounced effect of Mo on precipitation than on phase balance. Superior strength of the MoNbV-steel originated from the strong solid solution strengthening effect. Superior ductility of the CrNbV-steel corresponded to the more pronounced precipitation in this steel. Nature of these mechanisms is discussed. Full article
(This article belongs to the Special Issue Advances in Microalloyed Steels)
Show Figures

Figure 1

13 pages, 9264 KiB
Article
Elastic and Plastic Behavior of the QE22 Magnesium Alloy Reinforced with Short Saffil Fibers and SiC Particles
by Josef Zapletal, Zuzanka Trojanová, Pavel Doležal, Stanislava Fintová and Michal Knapek
Metals 2018, 8(2), 133; https://doi.org/10.3390/met8020133 - 15 Feb 2018
Cited by 6 | Viewed by 4636
Abstract
Magnesium alloy QE22 (nominal composition 2 wt % Ag, 2 wt % mixture of rare earth elements, balance Mg) was reinforced with 5 vol % Saffil fibers and 15 vol % SiC particles. The hybrid composite was prepared via the squeeze cast technique. [...] Read more.
Magnesium alloy QE22 (nominal composition 2 wt % Ag, 2 wt % mixture of rare earth elements, balance Mg) was reinforced with 5 vol % Saffil fibers and 15 vol % SiC particles. The hybrid composite was prepared via the squeeze cast technique. The microstructure of the monolithic alloy and composite was analyzed using scanning electron microscopy. Elastic modulus was measured at room temperature and modeled by the Halpin–Tsai–Kardos mathematical model. The strengthening effect of fibers and particles was calculated and compared with the experimentally obtained values. The main strengthening terms were determined. Fracture surfaces were studied via scanning electron microscope. While the fracture of the matrix alloy had a mainly intercrystalline character, the failure of the hybrid composite was transcrystalline. Full article
(This article belongs to the Special Issue Metal Matrix Composites)
Show Figures

Figure 1

15 pages, 5536 KiB
Article
Microstructure and Properties of Hybrid Laser Arc Welded Joints (Laser Beam-MAG) in Thermo-Mechanical Control Processed S700MC Steel
by Jacek Górka and Sebastian Stano
Metals 2018, 8(2), 132; https://doi.org/10.3390/met8020132 - 15 Feb 2018
Cited by 31 | Viewed by 7286
Abstract
The article presents the microstructure and properties of joints welded using the Hybrid Laser Arc Welding (HLAW) method laser beam-Metal Active Gas (MAG). The joints were made of 10-mm-thick steel S700MC subjected to the Thermo-Mechanical Control Process (TMCP) and characterised by a high [...] Read more.
The article presents the microstructure and properties of joints welded using the Hybrid Laser Arc Welding (HLAW) method laser beam-Metal Active Gas (MAG). The joints were made of 10-mm-thick steel S700MC subjected to the Thermo-Mechanical Control Process (TMCP) and characterised by a high yield point. In addition, the welding process involved the use of solid wire GMn4Ni1.5CrMo having a diameter of 1.2 mm. Non-destructive tests involving the joints made it possible to classify the joints as representing quality level B in accordance with the ISO 12932 standard. Destructive tests of the joints revealed that the joints were characterised by tensile strength similar to that of the base material. The hybrid welding (laser beam-MAG) of steel S700MC enabled the obtainment of good plastic properties of welded joints. In each area of the welded joints, the toughness values satisfied the criteria related to the minimum allowed toughness value. Tests involving the use of a transmission electron microscope and performed in the weld area revealed the decay of the precipitation hardening effect (i.e., the lack of precipitates having a size of several nm) and the presence of coagulated titanium-niobium precipitates having a size of 100 nm, restricting the growth of recrystallised austenite grains, as well as of spherical stable TiO precipitates (200 nm) responsible for the nucleation of ferrite inside austenite grains (significantly improving the plastic properties of joints). The tests demonstrated that it is possible to make welded joints satisfying quality-related requirements referred to in ISO 15614-14. Full article
(This article belongs to the Special Issue Laser Welding)
Show Figures

Figure 1

16 pages, 11052 KiB
Article
Sliding Contact Wear Damage of EBM built Ti6Al4V: Influence of Process Induced Anisotropic Microstructure
by Jae Joong Ryu, Sanjay Shrestha, Guha Manogharan and Jai K. Jung
Metals 2018, 8(2), 131; https://doi.org/10.3390/met8020131 - 13 Feb 2018
Cited by 14 | Viewed by 4731
Abstract
Process-induced directional microstructure is identified as one of the key factors of anisotropic mechanical properties. This directional property significantly affects surface contact fatigue and corrosion of electron beam melting (EBM) built biomedical implants. In the current study, material removal on EBM built titanium [...] Read more.
Process-induced directional microstructure is identified as one of the key factors of anisotropic mechanical properties. This directional property significantly affects surface contact fatigue and corrosion of electron beam melting (EBM) built biomedical implants. In the current study, material removal on EBM built titanium (Ti6Al4V) subjected to reciprocating motion of commercially pure titanium spherical slider is investigated to identify the influence of the process-induced layered structure and environments on wear damage. Specimens developed by two different build orientations are mechanically stimulated using different sliding directions with nominally elastic normal load in dry, passivating, and synovial environments. It was noticed that EBM orientation significantly changes wear behavior in ambient environment. Wear resistance of mill-annealed Ti6Al4V was improved in passivating environment. Implications to improve useful life of orthopedic implants are discussed. Full article
Show Figures

Figure 1

12 pages, 6928 KiB
Article
Evaluation of Primary Water Stress Corrosion Cracking Resistance of Three Heats of Alloy 600 in 400 °C Hydrogenated Steam Condition
by Eunsub Yun, Hansub Chung and Changheui Jang
Metals 2018, 8(2), 130; https://doi.org/10.3390/met8020130 - 12 Feb 2018
Cited by 2 | Viewed by 4094
Abstract
For Alloy 600, primary water stress corrosion cracking (PWSCC) is one of the key material degradation mechanisms in pressurized water reactors (PWRs). To identify the governing factors of PWSCC resistance, a systematic investigation into the role of each factor was performed. A PWSCC [...] Read more.
For Alloy 600, primary water stress corrosion cracking (PWSCC) is one of the key material degradation mechanisms in pressurized water reactors (PWRs). To identify the governing factors of PWSCC resistance, a systematic investigation into the role of each factor was performed. A PWSCC initiation test was performed for 3 heats of Alloy 600 in the 400 °C hydrogenated steam condition. Based on the test results, the effects of known factors like chemical composition, mechanical strength, grain boundary carbide coverage, grain boundary character, and surface cold work on PWSCC resistance were discussed. In addition, surface oxide morphology and penetrative oxide depth was compared. From this study, grain boundary character was considered to be the most dominant factor affecting the PWSCC resistance. Full article
Show Figures

Figure 1

18 pages, 6756 KiB
Review
Atomistic Simulations to Predict Favored Glass-Formation Composition and Ion-Beam-Mixing of Nano-Multiple-Metal-Layers to Produce Ternary Amorphous Films
by M. H. Yang, J. H. Li, B. X. Liu and J. B. Liu
Metals 2018, 8(2), 129; https://doi.org/10.3390/met8020129 - 11 Feb 2018
Cited by 2 | Viewed by 4481
Abstract
Based on the framework of long-range empirical formulas, the interatomic potentials were constructed for the Ni-Nb-Mo (fcc-bcc-bcc) and Ni-Zr-Mo (fcc-hcp-bcc) ternary metal systems. Applying the constructed potentials, atomistic simulations were performed [...] Read more.
Based on the framework of long-range empirical formulas, the interatomic potentials were constructed for the Ni-Nb-Mo (fcc-bcc-bcc) and Ni-Zr-Mo (fcc-hcp-bcc) ternary metal systems. Applying the constructed potentials, atomistic simulations were performed to predict the energetically favored glass formation regions (GFRs) in the respective composition triangles of the systems. In addition, the amorphization driving forces (ADFs), i.e., the energy differences between the solid solutions and disordered phases, were computed and appeared to correlate with the so-called glass forming abilities. To verify the atomistic prediction, ion beam mixing with nano-multiple-metal-layers was carried out to produce ternary amorphous films. The results showed that the composition of ternary amorphous films obtained by ion beam mixing all locate inside the GFRs, supporting the predictions of atomistic simulations. Interestingly, the minimum ion dosage required for amorphization showed a negative correlation with the calculated ADF, implying that the predicted amorphization driving force could be an indicator of the glass formation ability. Full article
Show Figures

Figure 1

12 pages, 6074 KiB
Article
Finite Element Simulation of the Presta Joining Process for Assembled Camshafts: Application to Aluminum Shafts
by Robert Scherzer, Sebastian Fritsch, Ralf Landgraf, Jörn Ihlemann and Martin Franz-Xaver Wagner
Metals 2018, 8(2), 128; https://doi.org/10.3390/met8020128 - 11 Feb 2018
Cited by 7 | Viewed by 4654
Abstract
This work shows a sequence of numerical models for the simulation of the Presta joining process: a well-established industrial process for manufacturing assembled camshafts. The operation is divided into two sub-steps: the rolling of the shaft to widen the cam seat and the [...] Read more.
This work shows a sequence of numerical models for the simulation of the Presta joining process: a well-established industrial process for manufacturing assembled camshafts. The operation is divided into two sub-steps: the rolling of the shaft to widen the cam seat and the joining of the cam onto the shaft. When manufactured, the connection is tested randomly by loading it with a static torque. Subsequently, there are three numerical models using the finite element method. Additionally, a material model of finite strain viscoplasticity with nonlinear kinematic hardening is used throughout the whole simulation process, which allows a realistic representation of the material behavior even for large deformations. In addition, it enables a transfer of the deformation history and of the internal stresses between different submodels. This work also shows the required parameter identification and the associated material tests. After comparing the numerical results with experimental studies of the manufacturing process for steel-steel connections, the models are used to extend the joining process to the utilization of aluminum shafts. Full article
Show Figures

Figure 1

2 pages, 140 KiB
Editorial
Corrosion: Critical Challenge in Wider Use of Magnesium Alloys
by Raman Singh, Vijayaraghavan Venkatesh and Vinod Kumar
Metals 2018, 8(2), 127; https://doi.org/10.3390/met8020127 - 11 Feb 2018
Cited by 11 | Viewed by 3624
Abstract
Magnesium alloys, given their high strength-to-weight ratio, are very attractive materials for applications such as aerospace and automotive components.[...] Full article
(This article belongs to the Special Issue Corrosion of Magnesium Alloys)
12 pages, 3890 KiB
Article
Slurry Erosion Behavior of AlxCoCrFeNiTi0.5 High-Entropy Alloy Coatings Fabricated by Laser Cladding
by Jianhua Zhao, Aibin Ma, Xiulin Ji, Jinghua Jiang and Yayun Bao
Metals 2018, 8(2), 126; https://doi.org/10.3390/met8020126 - 11 Feb 2018
Cited by 34 | Viewed by 6581
Abstract
High-entropy alloys (HEAs) have gained extensive attention due to their excellent properties and the related scientific value in the last decade. In this work, AlxCoCrFeNiTi0.5 HEA coatings (x: molar ratio, x = 1.0, 1.5, 2.0, and 2.5) were [...] Read more.
High-entropy alloys (HEAs) have gained extensive attention due to their excellent properties and the related scientific value in the last decade. In this work, AlxCoCrFeNiTi0.5 HEA coatings (x: molar ratio, x = 1.0, 1.5, 2.0, and 2.5) were fabricated on Q345 steel substrate by laser-cladding process to develop a practical protection technology for fluid machines. The effect of Al content on their phase evolution, microstructure, and slurry erosion performance of the HEA coatings was studied. The AlxCoCrFeNiTi0.5 HEA coatings are composed of simple face-centered cubic (FCC), body-centered cubic (BCC) and their mixture phase. Slurry erosion tests were conducted on the HEA coatings with a constant velocity of 10.08 m/s and 16–40 meshs and particles at impingement angles of 15, 30, 45, 60 and 90 degrees. The effect of three parameters, namely impingement angle, sand concentration and erosion time, on the slurry erosion behavior of AlxCoCrFeNiTi0.5 HEA coatings was investigated. Experimental results show AlCoCrFeNiTi0.5 HEA coating follows a ductile erosion mode and a mixed mode (neither ductile nor brittle) for Al1.5CoCrFeNiTi0.5 HEA coating, while Al2.0CoCrFeNiTi0.5 and Al2.5CoCrFeNiTi0.5 HEA coatings mainly exhibit brittle erosion mode. AlCoCrFeNiTi0.5 HEA coating has good erosion resistance at all investigated impingement angles due to its high hardness, good plasticity, and low stacking fault energy (SFE). Full article
Show Figures

Figure 1

5 pages, 159 KiB
Editorial
Novel Research for Development of Shape Memory Alloys
by Takuo Sakon
Metals 2018, 8(2), 125; https://doi.org/10.3390/met8020125 - 11 Feb 2018
Cited by 5 | Viewed by 3754
Abstract
Shape memory alloys have attracted much attention due to their attractive properties for applications as well as their basic aspects of deformation and transformation in structural and magnetic behavior.[...] Full article
(This article belongs to the Special Issue Shape Memory Alloys 2017)
10 pages, 5785 KiB
Article
Effects of Zr Additive on Microstructure, Mechanical Properties, and Fractography of Al-Si Alloy
by Hui Qian, Degui Zhu, Chunfeng Hu and Xiaosong Jiang
Metals 2018, 8(2), 124; https://doi.org/10.3390/met8020124 - 10 Feb 2018
Cited by 19 | Viewed by 5291
Abstract
The effects of Zr additive on the microstructure, mechanical properties, and fracture behavior of Al-Si alloy were systematically investigated. The additive of Zr obviously reduced the size of Si particles and changed its morphology. Grain size refinement was promoted by the reaction between [...] Read more.
The effects of Zr additive on the microstructure, mechanical properties, and fracture behavior of Al-Si alloy were systematically investigated. The additive of Zr obviously reduced the size of Si particles and changed its morphology. Grain size refinement was promoted by the reaction between Al and Zr forming Al3Zr and ZrSi2 compounds. Compared to a Zr-free alloy, the additive enhanced the tensile strength, compressive strength, shear strength, and hardness. The optimized Zr content was 2.4 wt % corresponding to a tensile strength of 231.1 MPa, compressive strength of 343.1 MPa, shear strength of 174.9 MPa, and hardness of 85.5 HV, greater than those of the Zr-free alloy. This illustrates that fine-grain strengthening and the existence of a second phase can improve the mechanical properties of Al-Si alloy. The fracture surface of Al-Si alloy without Zr additive showed a brittle fracture mode and there were no pits on the fractured surface. In the presence of Zr addictive, a typical plastic deformation with a large amount of pits was evidenced. Full article
Show Figures

Figure 1

13 pages, 8322 KiB
Article
Evolution of Microstructure and Mechanical Properties of a CoCrFeMnNi High-Entropy Alloy during High-Pressure Torsion at Room and Cryogenic Temperatures
by Sergey Zherebtsov, Nikita Stepanov, Yulia Ivanisenko, Dmitry Shaysultanov, Nikita Yurchenko, Margarita Klimova and Gennady Salishchev
Metals 2018, 8(2), 123; https://doi.org/10.3390/met8020123 - 10 Feb 2018
Cited by 43 | Viewed by 6393
Abstract
High-pressure torsion (HPT) is applied to a face-centered cubic CoCrFeMnNi high-entropy alloy at 293 and 77 K. Processing by HPT at 293 K produced a nanostructure consisted of (sub)grains of ~50 nm after a rotation for 180°. The microstructure evolution is associated with [...] Read more.
High-pressure torsion (HPT) is applied to a face-centered cubic CoCrFeMnNi high-entropy alloy at 293 and 77 K. Processing by HPT at 293 K produced a nanostructure consisted of (sub)grains of ~50 nm after a rotation for 180°. The microstructure evolution is associated with intensive deformation-induced twinning, and substructure development resulted in a gradual microstructure refinement. Deformation at 77 K produces non-uniform structure composed of twinned and fragmented areas with higher dislocation density then after deformation at room temperature. The yield strength of the alloy increases with the angle of rotation at HPT at room temperature at the cost of reduced ductility. Cryogenic deformation results in higher strength in comparison with the room temperature HPT. The contribution of Hall–Petch hardening and substructure hardening in the strength of the alloy in different conditions is discussed. Full article
Show Figures

Figure 1

12 pages, 5128 KiB
Article
Strain Hardening Behavior and Microstructure Evolution of High-Manganese Steel Subjected to Interrupted Tensile Tests
by Adam Grajcar, Aleksandra Kozłowska and Barbara Grzegorczyk
Metals 2018, 8(2), 122; https://doi.org/10.3390/met8020122 - 10 Feb 2018
Cited by 11 | Viewed by 5588
Abstract
Strain hardening behavior and the corresponding microstructure evolution of the high-manganese steel with additions of Si and Al were investigated in this study. Thermomechanically processed and solution-heat-treated sheet steels were compared under conditions of interrupted tensile tests. Relationships between microstructure and strain hardening [...] Read more.
Strain hardening behavior and the corresponding microstructure evolution of the high-manganese steel with additions of Si and Al were investigated in this study. Thermomechanically processed and solution-heat-treated sheet steels were compared under conditions of interrupted tensile tests. Relationships between microstructure and strain hardening were assessed for different strain levels using light microscopy and scanning electron microscopy techniques. It was found that the deformation of both steels at low strain levels was dominated by dislocation glide before the occurrence of mechanical twinning. The amount of twins, slip lines, and bands was increasing gradually up to the point of necking. As the strain level increased, dislocation density within twinning areas becomes higher, which enhances the strength, the work hardening exponent, and the work hardening rate of the investigated high-manganese sheet steels. Full article
(This article belongs to the Special Issue Physical Metallurgy of High Performance Steels)
Show Figures

Figure 1

10 pages, 4016 KiB
Article
Exothermic Reaction Kinetics in High Energy Density Al-Ni with Nanoscale Multilayers Synthesized by Cryomilling
by Minseok Oh, Min Chul Oh, Deokhyun Han, Sang-Hyun Jung and Byungmin Ahn
Metals 2018, 8(2), 121; https://doi.org/10.3390/met8020121 - 9 Feb 2018
Cited by 7 | Viewed by 5192
Abstract
The Al-Ni system is known as a high energy density materials (HEDM) because of its highly exothermic nature during intermetallic compound (IMC) formation. In this study, elemental Al and Ni powder were milled to explore the effect of cryomilling atmosphere on the microstructure [...] Read more.
The Al-Ni system is known as a high energy density materials (HEDM) because of its highly exothermic nature during intermetallic compound (IMC) formation. In this study, elemental Al and Ni powder were milled to explore the effect of cryomilling atmosphere on the microstructure and exothermic behavior. Scanning electron microscope (SEM) observations show continuous structural refinement up to 8 h of cryomilling. No IMC phase was detected in the X-ray diffraction (XRD) spectrum. Differential thermal analyzer (DTA) results show two exothermic peaks for 8 h cryomilled powder as compared to that of powder milled for 1 h. The ignition temperature of prepared powder mixture also decreased due to gradual structural refinement. The activation energy was also calculated and correlated with the DTA and SEM results. The cryomilled Al-Ni powder is composed of fine Al-Ni metastable junctions which improve the reactivity at a lower exothermic reaction temperature. Full article
(This article belongs to the Special Issue Synthesis and Properties of Bulk Nanostructured Metallic Materials)
Show Figures

Figure 1

3 pages, 148 KiB
Editorial
Recent Advances in Study of Solid-Liquid Interfaces and Solidification of Metals
by Mohsen Asle Zaeem
Metals 2018, 8(2), 120; https://doi.org/10.3390/met8020120 - 9 Feb 2018
Cited by 1 | Viewed by 3296
Abstract
Solidification occurs in several material processing methods, such as in casting, welding, and laser additive manufacturing of metals, and it controls the nano- and microstructures, as well as the overall properties of the products[...] Full article
15 pages, 8597 KiB
Article
Characteristics of Metal Magnetic Memory Testing of 35CrMo Steel during Fatigue Loading
by Zhibin Hu, Jianchun Fan, Shengnan Wu, Haoyuan Dai and Shujie Liu
Metals 2018, 8(2), 119; https://doi.org/10.3390/met8020119 - 8 Feb 2018
Cited by 27 | Viewed by 5255
Abstract
The fatigue fracture of a drillstring could cause drilling disturbances and some negative impacts (e.g., economic loss) will be brought when restoring the drillstring to functionality. In order to evaluate the effects of the fatigue damage of the drillstring during drilling, a new [...] Read more.
The fatigue fracture of a drillstring could cause drilling disturbances and some negative impacts (e.g., economic loss) will be brought when restoring the drillstring to functionality. In order to evaluate the effects of the fatigue damage of the drillstring during drilling, a new apparatus, which could monitor the load level in real-time, was built to perform the four-point bending fatigue test on 35CrMo steel, a typical material of drillstrings. Such an apparatus is based on metal magnetic memory (MMM) technology and can acquire the tangential and normal components of MMM signals. Based on the analysis of the change of surface morphology and MMM signals, it was concluded that the variation of MMM signals could be divided into four stages, which are used to accurately describe the fatigue damage process of the drillstring. Additionally, the MMM signal characteristics are introduced to especially evaluate the fatigue damage of the drillstring, including crack initiation. Furthermore, the scanning electron microscopy (SEM) results demonstrated that morphologies of fatigue fracture were related to the variation of MMM signals. Linear fitting results indicated that fatigue crack length had a good linear relationship with the characteristics, so it is feasible to monitor fatigue damage and predict the residual life of a drillstring by using MMM technology. Full article
(This article belongs to the Special Issue Advanced Non-Destructive Testing in Steels)
Show Figures

Figure 1

12 pages, 14527 KiB
Article
Enhanced Compressive Property of Al Composite Foams at Elevated Temperatures via Plasma Electrolytic Oxidation
by Huamin Liu, Wenchi Pan, Fujian Si, Kuo Huang, Yan Liu and Jiaan Liu
Metals 2018, 8(2), 118; https://doi.org/10.3390/met8020118 - 8 Feb 2018
Cited by 9 | Viewed by 3583
Abstract
The present work investigates the compressive property of Al matrix composite foams at different temperatures between room temperature and 200 °C. Elevated temperature results in a decreased compressive strength and energy absorption capacity of as-received Al foams. Therefore, to maintain the compressive property, [...] Read more.
The present work investigates the compressive property of Al matrix composite foams at different temperatures between room temperature and 200 °C. Elevated temperature results in a decreased compressive strength and energy absorption capacity of as-received Al foams. Therefore, to maintain the compressive property, the Al2O3 ceramic coating was deposited on the Al struts of the foams by the plasma electrolytic oxidation (PEO) process to form Al2O3/Al composite foams. As a consequence, the composite foams exhibit a higher compressive strength and energy absorption capacity as compared with the as-received Al foams at both room temperature and elevated temperatures because of the reinforced effect of the Al2O3 ceramic on the foam strut. The related mechanisms were explained by fractography, microstructure observation and phase composition analysis using scanning electron microscopy (SEM), energy-dispersive X-ray spectroscopy (EDS) and X-ray diffraction (XRD). Full article
Show Figures

Figure 1

Previous Issue
Next Issue
Back to TopTop
