  • Proceeding Paper
  • Open Access

9 November 2022

10 Pages

Sealing Technologies for the Manufacturing of Bipolar Plates via Active and Passive Hydroforming †

,
,
,
and
Fraunhofer Institute for Machine Tools and Forming Technology, 09126 Chemnitz, Germany
*
Author to whom correspondence should be addressed.
†
Presented at the 28th Saxon Conference on Forming Technology SFU and the 7th International Conference on Accuracy in Forming Technology ICAFT, Chemnitz, Germany, 2–3 November 2022.

Abstract

Hydrogen technology is central to the process of turning away from fossil fuels. Electrolyzers and fuel cells of various sizes are needed to implement the hydrogen strategy. The cost-efficient forming of bipolar plates is key to the implementation of this strategy. Based on previous research, this paper presents active and passive hydroforming using the example of the production of bipolar plates for fuel cells. Furthermore, different systems for sealing the hydroforming pressure between tool and sheet are presented and compared with regard to their behavior in forming tests, their failure characteristics and the resulting process parameters.
