Search Results (70)

Search Parameters:
Keywords = Operational Transconductance Amplifier (OTA)

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
30 pages, 5886 KB
Article
Split Capacitive Boosting Technique for High-Slew-Rate Single-Ended Amplifiers: Design and Optimization
by Francesco Gagliardi, Paolo Bruschi, Massimo Piotto and Michele Dei
Electronics 2025, 14(16), 3225; https://doi.org/10.3390/electronics14163225 - 14 Aug 2025
Viewed by 3080
Abstract
Parallel-type slew-rate enhancers (PSREs) improve the driving capability of operational transconductance amplifiers (OTAs) for large capacitive loads. While capacitive-boosting (CB) techniques enhance PSRE efficiency in fully-differential designs, their application to single-ended configurations—common in off-chip load driving—remains unexplored. This work identifies a critical limitation [...] Read more.
Parallel-type slew-rate enhancers (PSREs) improve the driving capability of operational transconductance amplifiers (OTAs) for large capacitive loads. While capacitive-boosting (CB) techniques enhance PSRE efficiency in fully-differential designs, their application to single-ended configurations—common in off-chip load driving—remains unexplored. This work identifies a critical limitation of standard CB in single-ended unity-gain buffers: severe slew-rate degradation due to large common-mode input swings. To overcome this, we propose a novel split CB (SCB) technique for single-ended PSREs that strategically divides the boosting capacitance. Simulated in a 0.18-µm CMOS process, the proposed method achieves a ×5.53 reduction in settling time compared to standard CB when driving a 1-nF load. With only 4 µA quiescent current under a 3.3-V supply, it attains a 1% settling time of 2.56 µs for 2.64-V steps, demonstrating robust performance across process-voltage-temperature variations. This technique enables low-power, high-speed interfaces for drivers of off-chip devices. Full article
(This article belongs to the Special Issue Analog/Mixed Signal Integrated Circuit Design)
Show Figures

Graphical abstract

20 pages, 2183 KB
Review
Bulk-Driven CMOS Differential Stages for Ultra-Low-Voltage Ultra-Low-Power Operational Transconductance Amplifiers: A Comparative Analysis
by Muhammad Omer Shah, Andrea Ballo and Salvatore Pennisi
Electronics 2025, 14(10), 2085; https://doi.org/10.3390/electronics14102085 - 21 May 2025
Cited by 1 | Viewed by 1089
Abstract
Energy-efficient integrated circuits require scaled-down supply voltages, posing challenges for analog design, particularly for operational transconductance amplifiers (OTAs) essential in high-accuracy CMOS feedback systems. Below 1 V, gate-driven OTAs are limited in common-mode input range and minimum supply voltage. This work investigates CMOS [...] Read more.
Energy-efficient integrated circuits require scaled-down supply voltages, posing challenges for analog design, particularly for operational transconductance amplifiers (OTAs) essential in high-accuracy CMOS feedback systems. Below 1 V, gate-driven OTAs are limited in common-mode input range and minimum supply voltage. This work investigates CMOS Bulk-Driven (BD) sub-threshold techniques as an efficient alternative for ultra-low voltage (ULV) and ultra-low power (ULP) designs. Although BD overcomes MOS threshold voltage limitations, historical challenges like lower transconductance, latch-up, and layout complexity hindered its use. Recent advancements in CMOS processes and the need for ULP solutions have revived industrial interest in BD. Through theoretical analysis and computer simulations, we explore BD topologies for ULP OTA input stages, classifying them as tailed/tail-less and class A/AB, evaluating their effectiveness for robust analog design, while offering valuable insights for circuit designers. Full article
(This article belongs to the Special Issue Advanced CMOS Technologies and Applications)
Show Figures

Figure 1

18 pages, 1818 KB
Article
Power-Efficient Recycling Folded Cascode Operational Transconductance Amplifier Based on Nested Local Feedback and Adaptive Biasing
by Chunkai Wu, Peng Cai, Jinghu Li, Jin Xie and Zhicong Luo
Sensors 2025, 25(8), 2523; https://doi.org/10.3390/s25082523 - 17 Apr 2025
Viewed by 971
Abstract
In this paper, we present a novel enhanced recycling folded cascode (ERFC) operational transconductance amplifier (OTA), which exhibits high efficiency and a fast transient response under weak inversion. Our innovative combination of adaptive biasing with nested local feedback (ABNLF) effectively enhances the input [...] Read more.
In this paper, we present a novel enhanced recycling folded cascode (ERFC) operational transconductance amplifier (OTA), which exhibits high efficiency and a fast transient response under weak inversion. Our innovative combination of adaptive biasing with nested local feedback (ABNLF) effectively enhances the input transconductance and slew rate (SR), thus improving the transient response. By incorporating coupling capacitors at the output stage, we achieve a stable operating region with large signal responses. Both the traditional RFC OTA and the proposed ERFC OTA were designed in a 0.18 μm CMOS process, operating at a power supply of 1.8 V, with quiescent currents of 8 μA and 10.4 μA, respectively. Post-layout simulations reveal a remarkable enhancement in the proposed ERFC OTA over the traditional RFC OTA, with the SR and gain–bandwidth (GBW) surging by 120- and 5.95-fold, respectively. This advancement boosts the efficiency of the traditional RFC OTA and provides an impressive figure of merit (FoM) of 130.04 (V/μs)·pF/μA. Full article
(This article belongs to the Section Electronic Sensors)
Show Figures

Figure 1

18 pages, 6465 KB
Article
0.5-V High-Order Universal Filter for Bio-Signal Processing Applications
by Montree Kumngern, Fabian Khateb, Tomasz Kulej and Somkiat Lerkvaranyu
Appl. Sci. 2025, 15(7), 3969; https://doi.org/10.3390/app15073969 - 3 Apr 2025
Cited by 1 | Viewed by 664
Abstract
In this paper, a novel multiple-input operational transconductance amplifier (MI-OTA) is proposed. The MI-OTA can be obtained by using the multiple-input bulk-driven MOS transistor (MIBD MOST) technique. The circuit structure is simple, can operate with a supply voltage of 0.5 V, and consumes [...] Read more.
In this paper, a novel multiple-input operational transconductance amplifier (MI-OTA) is proposed. The MI-OTA can be obtained by using the multiple-input bulk-driven MOS transistor (MIBD MOST) technique. The circuit structure is simple, can operate with a supply voltage of 0.5 V, and consumes 937 pW at a current setting of 625 pA. The proposed MI-OTA was used to implement a high-order multiple-input voltage-mode universal filter. The proposed filter can provide non-inverting and inverting low-pass, high-pass, band-pass, band-stop, and all-pass transfer functions to the same topology. In addition, it has a high input impedance and does not need any inverted input signals, so there is no additional buffering circuit. The proposed filter can be used for biological signal processing. The proposed MI-OTA and the second-order universal filter were simulated in Cadence using CMOS process parameters of 0.18 μm from TSMC to verify the functionality and performance of the new structures. Full article
(This article belongs to the Section Electrical, Electronics and Communications Engineering)
Show Figures

Figure 1

20 pages, 12813 KB
Article
A 48 nW, Universal, Multi-Mode Gm-C Filter with a Frequency Range Tunability
by Ali Namdari, Orazio Aiello, Mehdi Dolatshahi and Daniele D. Caviglia
Electronics 2025, 14(7), 1334; https://doi.org/10.3390/electronics14071334 - 27 Mar 2025
Viewed by 746
Abstract
This paper presents an ultra-low-power, inverter-based, universal Gm-C filter capable of operating in multiple modes: voltage, current, transconductance, and trans-resistance. The proposed filter features orthogonal tunability of the center frequency (ω0) and quality factor (Q). To achieve ultra-low power consumption, all [...] Read more.
This paper presents an ultra-low-power, inverter-based, universal Gm-C filter capable of operating in multiple modes: voltage, current, transconductance, and trans-resistance. The proposed filter features orthogonal tunability of the center frequency (ω0) and quality factor (Q). To achieve ultra-low power consumption, all transistors are biased in the subthreshold region with a supply voltage of 0.5 V. A Nauta inverter-based gm block is utilized as the operational transconductance amplifier (OTA), further enhancing power efficiency. The filter is capable of generating all filtering responses across a supply voltage ranges from 1.2 V down to 0.5 V. Moreover, the center frequency and quality factor can be tuned by adjusting capacitance values. The proposed Gm-C filter achieves a power consumption of 48 nW, with the center frequency ranging from 50.6 Hz to 1270 Hz. Full article
(This article belongs to the Special Issue Design of Low-Voltage and Low-Power Integrated Circuits)
Show Figures

Figure 1

18 pages, 1855 KB
Article
A Fully Integrated Memristive Chaotic Circuit Based on Memristor Emulator with Voltage-Controlled Oscillator
by Zhikui Duan, Jiahui Chen, Shaobo He, Xinmei Yu, Qiang Wang, Xin Zhang and Peng Xiong
Micromachines 2025, 16(3), 246; https://doi.org/10.3390/mi16030246 - 21 Feb 2025
Cited by 2 | Viewed by 1661
Abstract
This paper introduces a fully integrated memristive chaotic circuit, which is based on a voltage-controlled oscillator (VCO). The circuit employs a fully integrated architecture that offers reduced power consumption and a smaller footprint compared to the use of discrete components. Specifically, the VCO [...] Read more.
This paper introduces a fully integrated memristive chaotic circuit, which is based on a voltage-controlled oscillator (VCO). The circuit employs a fully integrated architecture that offers reduced power consumption and a smaller footprint compared to the use of discrete components. Specifically, the VCO is utilized to generate the oscillatory signal, whereas the memristor emulator circuit serves as the nonlinear element. The memristor emulator circuit is constructed using a single operational transconductance amplifier (OTA), two transistors, and a grounded capacitor. This straightforward design contributes to diminished power usage within the chip’s area. The VCO incorporates a dual delay unit and implements current compensation to enhance the oscillation frequency and to broaden the VCO’s tunable range. Fabricated using the SMIC 180 nm CMOS process, this chaotic circuit occupies a mere 0.0072 mm2 of chip area, demonstrating a design that is both efficient and compact. Simulation outcomes indicate that the proposed memristor emulator is capable of operating at a maximum frequency of 300 MHz. The memristive chaotic circuit is able to produce a chaotic oscillatory signal with an operational frequency ranging from 158 MHz to 286 MHz, powered by a supply of 0.9 V, and with a peak power consumption of 3.5553 mW. The Lyapunov exponent of the time series within the resultant chaotic signal spans from 0.2572 to 0.4341. Full article
(This article belongs to the Section E:Engineering and Technology)
Show Figures

Figure 1

23 pages, 8687 KB
Article
A Low-Voltage Low-Power Voltage-to-Current Converter with Low Temperature Coefficient Design Awareness
by Haoze Chen and Pak Kwong Chan
Sensors 2025, 25(4), 1204; https://doi.org/10.3390/s25041204 - 16 Feb 2025
Cited by 2 | Viewed by 1222
Abstract
This paper presents a low-voltage, low-power voltage-to-current converter (V-I Converter) implemented in TSMC 40 nm CMOS technology. Operating at a supply voltage of 0.45 V with an input range of 0.1 V to 0.3 V, the proposed circuit achieves a temperature coefficient of [...] Read more.
This paper presents a low-voltage, low-power voltage-to-current converter (V-I Converter) implemented in TSMC 40 nm CMOS technology. Operating at a supply voltage of 0.45 V with an input range of 0.1 V to 0.3 V, the proposed circuit achieves a temperature coefficient of 54.68 ppm/°C, which is at least 2× better than prior works, ensuring stable performance across a wide temperature range (−20 °C to 80 °C). The design employs a three-stage operational transconductance amplifier (OTA) with a Q-reduction frequency compensation technique to produce programmable output currents while maintaining a power dissipation of less than 2.76 μW. With a bandwidth of 34.45 kHz and a total harmonic distortion (THD) of −56.66 dB at 1 kHz and 0.1 VPP input signal, the circuit demonstrates high linearity and low power consumption under ultra-low voltage design scenarios. These features make the proposed V-I Converter highly suitable for energy-constrained applications such as biomedical sensors, energy harvesting systems, and IoT nodes, where low power consumption and temperature stability are critical parameters. Full article
(This article belongs to the Special Issue Advanced Interface Circuits for Sensor Systems (Volume II))
Show Figures

Figure 1

19 pages, 5465 KB
Article
Design of Shadow Filter Using Low-Voltage Multiple-Input Operational Transconductance Amplifiers
by Montree Kumngern, Fabian Khateb, Tomasz Kulej and Natchayathorn Wattikornsirikul
Appl. Sci. 2025, 15(2), 781; https://doi.org/10.3390/app15020781 - 14 Jan 2025
Cited by 4 | Viewed by 944
Abstract
This paper introduces shadow filters that employ multiple-input operational transconductance amplifiers (MI-OTAs) as the active component. Two configurations of shadow filters are proposed. The first configuration, in contrast to previous designs, enables the adjustment of the quality factor without affecting the passband gains [...] Read more.
This paper introduces shadow filters that employ multiple-input operational transconductance amplifiers (MI-OTAs) as the active component. Two configurations of shadow filters are proposed. The first configuration, in contrast to previous designs, enables the adjustment of the quality factor without affecting the passband gains of the BPF, LPF, and HPF, thus achieving optimal frequency responses for these filters. The second configuration allows for the variation of the natural frequency without impacting the passband gains of the HPF, LPF, and BPF, maintaining constant passband gains. Moreover, the natural frequency can be electronically controlled by modifying parameters of the original biquad filters, providing advantages in compensating for process, voltage, and temperature variations. The MI-OTA is designed to provide multiple-input differential terminals using the multiple-input bulk-driven MOS transistor (MIBD-MOST) technique, allowing differential input signals to be converted into current output through its transconductance gain. The OTA operates at a supply voltage of 450 mV and consumes 81 nW of power, with the MOS transistors operating in weak inversion. The OTA and shadow filters were designed and simulated using a 0.18 µm CMOS process to validate the functionality and performance of the proposed circuits. Full article
(This article belongs to the Section Electrical, Electronics and Communications Engineering)
Show Figures

Figure 1

17 pages, 5553 KB
Article
Complementary Metal Oxide Semiconductor Circuit Realization of Inverse Chebyshev Low-Pass Filter of Order (1 + α)
by Soubhagyaseetha Nettar, Shankaranarayana Kilingar, Chandrika B. Killuru and Dattaguru V. Kamath
Fractal Fract. 2024, 8(12), 712; https://doi.org/10.3390/fractalfract8120712 - 30 Nov 2024
Cited by 1 | Viewed by 1337
Abstract
This paper presents the CMOS circuit realization of a low-pass Inverse Chebyshev fractional-order filter (FOF) of order (1 + α) using the inverse-follow-the-leader feedback (IFLF) topology. A nonlinear least squares optimization routine is used to determine the coefficients of the fractional-order transfer function [...] Read more.
This paper presents the CMOS circuit realization of a low-pass Inverse Chebyshev fractional-order filter (FOF) of order (1 + α) using the inverse-follow-the-leader feedback (IFLF) topology. A nonlinear least squares optimization routine is used to determine the coefficients of the fractional-order transfer function to approximate the stop-band characteristics. The Inverse Chebyshev FOF of orders 1.3, 1.6, and 1.9 using cross-coupled operational transconductance amplifier (OTA) was designed in united microelectronics corporation (UMC) 180 nm complementary metal–oxide–semiconductor process. The MATLAB and Cadence Spectre simulations are used to validate the implementation of the fractional-order filter of orders 1.3, 1.6 and 1.9. The dynamic range (DR) of the filter is found to be 83.04 dB, 86.13 dB, and 84.71 dB, respectively, for order of 1.3, 1.6, and 1.9. The simulation results such as magnitude response, transient plot, Monte Carlo, and PVT plots, have justified the design accuracy. Full article
(This article belongs to the Section Numerical and Computational Methods)
Show Figures

Figure 1

15 pages, 2190 KB
Data Descriptor
Open and Collaborative Dataset for the Classification of Operational Transconductance Amplifiers for Switched-Capacitor Applications
by Francesco Gagliardi and Michele Dei
Data 2024, 9(10), 114; https://doi.org/10.3390/data9100114 - 3 Oct 2024
Cited by 4 | Viewed by 1801
Abstract
This study introduces a collaborative and open dataset designed to classify operational transconductance amplifiers (OTAs) in switched-capacitor applications. The dataset comprises a diverse collection of OTA designs sourced from the literature, facilitating benchmarking, analysis and innovation in analog and mixed-signal integrated circuit design. [...] Read more.
This study introduces a collaborative and open dataset designed to classify operational transconductance amplifiers (OTAs) in switched-capacitor applications. The dataset comprises a diverse collection of OTA designs sourced from the literature, facilitating benchmarking, analysis and innovation in analog and mixed-signal integrated circuit design. Various evaluation methodologies, implemented through a companion Python notebook script, are discussed to assess OTA performances across different operating conditions and specifications. Several Figures of Merit (FoMs) are utilized as performance metrics to achieve significant performance classification. This study also uncovers intriguing behaviors and correlations among FoMs, providing valuable insights into OTA design considerations. By making the dataset openly available on platforms like GitHub, this work encourages collaboration and knowledge sharing within the integrated circuit design community, thereby enhancing transparency, reproducibility and innovation in OTA design research. Full article
Show Figures

Figure 1

14 pages, 2788 KB
Review
A Review of Current Differencing Buffered Amplifiers: Performance Metrics and Technological Advances
by Shekhar Suman Borah and Prabha Sundaravadivel
Electronics 2024, 13(18), 3623; https://doi.org/10.3390/electronics13183623 - 12 Sep 2024
Cited by 4 | Viewed by 1749
Abstract
Current Differencing Buffered Amplifiers (CDBAs) are a critical class of analog circuit components capable of handling both current and voltage signals with minimal power consumption. Due to their low impedance voltage output, they play a significant role in modern electronics for developing high-performance, [...] Read more.
Current Differencing Buffered Amplifiers (CDBAs) are a critical class of analog circuit components capable of handling both current and voltage signals with minimal power consumption. Due to their low impedance voltage output, they play a significant role in modern electronics for developing high-performance, high-precision analog and mixed-signal circuits. But, designing and characterizing CDBAs pose several challenges, such as ensuring stability at high frequencies, minimizing noise impact for high-precision applications, and enhancing adaptability. Integrating CDBAs with other analog components to create multifunctional integrated circuits opens many opportunities in the analog signal-processing domain. This paper reviews the evolution and applications of CDBAs in analog signal processing. Various implementation schemes, including those using commercial Current Feedback Amplifiers (CFAs) and novel CMOS configurations, are analyzed for their performance metrics such as supply voltage, power dissipation, input/output impedances, and technology node. Future trends and challenges in advancing CDBA technology towards higher integration and lower-voltage operation are discussed, highlighting potential applications in next-generation electronics. Full article
(This article belongs to the Special Issue Feature Review Papers in Electronics)
Show Figures

Figure 1

14 pages, 2171 KB
Article
An Ultra-Low-Voltage Transconductance Stable and Enhanced OTA for ECG Signal Processing
by Yue Yin, Xinbing Zhang, Ziting Feng, Haobo Qi, Haodong Lu, Jiayu He, Chaoqi Jin and Yihao Luo
Micromachines 2024, 15(9), 1108; https://doi.org/10.3390/mi15091108 - 30 Aug 2024
Cited by 2 | Viewed by 1924
Abstract
In this paper, a rail-to-rail transconductance stable and enhanced ultra-low-voltage operational transconductance amplifier (OTA) is proposed for electrocardiogram (ECG) signal processing. The variation regularity of the bulk transconductance of pMOS and nMOS transistors and the cancellation mechanism of two types of transconductance variations [...] Read more.
In this paper, a rail-to-rail transconductance stable and enhanced ultra-low-voltage operational transconductance amplifier (OTA) is proposed for electrocardiogram (ECG) signal processing. The variation regularity of the bulk transconductance of pMOS and nMOS transistors and the cancellation mechanism of two types of transconductance variations are revealed. On this basis, a transconductance stabilization and enhancement technique is proposed. By using the “current-reused and transconductance-boosted complementary bulk-driven pseudo-differential pairs” structure, the bulk-driven pseudo-differential pair during the input common-mode range (ICMR) is stabilized and enhanced. The proposed OTA based on this technology is simulated using the TSMC 0.18 μm process in a Cadence environment. The proposed OTA consumes a power below 30 nW at a 0.4 V voltage supply with a DC gain of 54.9 dB and a gain-bandwidth product (GBW) of 14.4 kHz under a 15 pF capacitance load. The OTA has a high small signal figure-of-merit (FoM) of 7410 and excellent common-mode voltage (VCM) stability, with a transconductance variation of about 1.35%. Based on a current-scaling version of the proposed OTA, an OTA-C low-pass filter (LPF) for ECG signal processing with VCM stability is built and simulated. With a −3 dB bandwidth of 250 Hz and a power consumption of 20.23 nW, the filter achieves a FoM of 3.41 × 10−13, demonstrating good performance. Full article
(This article belongs to the Topic Advanced Integrated Circuit Design and Application)
Show Figures

Figure 1

17 pages, 6867 KB
Article
A 0.5 V, 32 nW Compact Inverter-Based All-Filtering Response Modes Gm-C Filter for Bio-Signal Processing
by Ali Namdari, Orazio Aiello and Daniele D. Caviglia
J. Low Power Electron. Appl. 2024, 14(3), 40; https://doi.org/10.3390/jlpea14030040 - 4 Aug 2024
Cited by 4 | Viewed by 2062
Abstract
A low-power, low-voltage universal multi-mode Gm-C filter using a 180 nm TSMC technology node is presented in this paper. The proposed filter employs only three transconductance operational amplifiers (OTAs) operating in the sub-threshold region with a supply voltage of 0.5 V, resulting in [...] Read more.
A low-power, low-voltage universal multi-mode Gm-C filter using a 180 nm TSMC technology node is presented in this paper. The proposed filter employs only three transconductance operational amplifiers (OTAs) operating in the sub-threshold region with a supply voltage of 0.5 V, resulting in a power consumption of 32 nW. Moreover, without additional active elements, the proposed circuit can operate various functional modes, such as voltage, current, transconductance, and trans-resistance. The filter’s frequency, centered at 462 Hz, and a compact and low-power solution showing only 93.5 µVrms input-referred noise make the proposed filter highly suitable for bio-signal processing. Full article
(This article belongs to the Special Issue Ultra-Low-Power ICs for the Internet of Things (2nd Edition))
Show Figures

Figure 1

14 pages, 706 KB
Article
An Ultra-Low-Voltage Approach to Accurately Set the Quiescent Current of Digital Standard Cells Used for Analog Design and Its Application on an Inverter-Based Operational Transconductance Amplifier
by Riccardo Della Sala, Francesco Centurelli and Giuseppe Scotti
J. Low Power Electron. Appl. 2024, 14(3), 39; https://doi.org/10.3390/jlpea14030039 - 24 Jul 2024
Cited by 1 | Viewed by 2347
Abstract
An approach to design analog building blocks based on digital standard cells is presented in this work. By ensuring that every CMOS inverter from a standard-cell library operates with a well-defined quiescent current and output voltage, the suggested method makes it possible to [...] Read more.
An approach to design analog building blocks based on digital standard cells is presented in this work. By ensuring that every CMOS inverter from a standard-cell library operates with a well-defined quiescent current and output voltage, the suggested method makes it possible to construct analog circuits that are resistant against PVT variations. The method uses the local supply voltages connected to the source terminals of the p-channel and n-channel MOS transistors of the standard-cell inverters as control inputs. It is based on adaptive supply voltage generator (ASVG) reusable blocks, which are comparable to those used in digital applications to handle process variations. All of the standard-cell inverters used for analog functions receive the local supply voltages produced by the ASVGs, which enable setting each cell’s quiescent current to a multiple of a reference current and each cell’s static output voltage to an appropriate reference voltage. Both the complete custom design of the ASVG blocks and a theoretical study of the feedback loop of the ASVG are presented. An application example through the design of a fully synthesizable two-stage operational transconductance amplifier (OTA) is also provided. The TSMC 180 nm CMOS technology has been used to implement both the OTA and the ASV generators. Simulation results have demonstrated that the proposed approach allows to accurately set the quiescent current of standard-cell inverters, dramatically reducing the effect of PVT variations on the pmain performance parameters of the standard-cell-based two-stage OTA. Full article
(This article belongs to the Special Issue Ultra-Low-Power ICs for the Internet of Things (2nd Edition))
Show Figures

Figure 1

15 pages, 12241 KB
Article
Design and Characterization of a Digitally Tunable Gm-C Filter for Multi-Standard Receivers
by Mateus S. Oliveira, Matheus B. S. Carvalho, Crístian Müller, Lucas Compassi-Severo, Paulo C. C. de Aguirre and Alessandro G. Girardi
Electronics 2024, 13(14), 2866; https://doi.org/10.3390/electronics13142866 - 20 Jul 2024
Cited by 1 | Viewed by 2938
Abstract
This paper presents the design, simulation, prototyping, and measurement results of a digitally tunable fourth order Gm-C low-pass filter (LPF) for multi-standard radio receivers. The LPF cut-off frequency can be tunned by digitally selecting the transconductance of the basic reconfigurable operational transconductance amplifiers [...] Read more.
This paper presents the design, simulation, prototyping, and measurement results of a digitally tunable fourth order Gm-C low-pass filter (LPF) for multi-standard radio receivers. The LPF cut-off frequency can be tunned by digitally selecting the transconductance of the basic reconfigurable operational transconductance amplifiers (OTAs) that compose the circuit. Four operation modes allow for control of the OTA transconductances and, consequently, the scaling of power consumption. The filter was designed and prototyped in a 1.8 V 180 nm CMOS process. The measurement results indicate that the configurability provides a cutoff frequency of 1.90/3.56/6.07/8.15 MHz with a power consumption ranging from 9.9 to 13.1 mW. The designed filter achieves an IIP3 of 8.17 dBm for a signal bandwidth of 8.15 MHz. The performance, in terms of power dissipation, noise, and cut-off frequency, is at the same order of magnitude compared to recent related works reported in the literature. The advantages are a compact area, small sensitivity to component mismatches, and low design complexity. The proposed filter presents electrical characteristics suitable for the application in radio receivers for multi-carrier WCDMA signals. Full article
Show Figures

Figure 1
