Analog/Mixed Signal Integrated Circuit Design

A special issue of Electronics (ISSN 2079-9292). This special issue belongs to the section "Circuit and Signal Processing".

Deadline for manuscript submissions: 15 November 2025 | Viewed by 1748

Special Issue Editors

Dr. Chengying Chen

E-Mail Website
Guest Editor
School of Opto-Electronic and Communication Engineering, Xiamen University of Technology, Xiamen 966675, China
Interests: voltage controlled oscillators; analog-to-digital converter; continuous time
Dr. Xinghua Wang

E-Mail Website
Guest Editor
1. School of Integrated Circuits and Electronics, Beijing Institute of Technology, Beijing 100081, China
2. BIT Chongqing Institute of Microelectronics and Microsystems, Chongqing 401332, China
3. Yangtze Delta Region Academy of Beijing Institute of Technology, Jiaxing 314000, China
4. Advanced Technology Research Institute, Beijing Institute of Technology, Jinan 250101, China
Interests: AFE; computing-in-memory
Dr. Xiaoran Li

E-Mail Website
Guest Editor
School of Information and Electronics, Beijing Institute of Technology, Beijing 100081, China
Interests: analog; RF/MMW IC design

Special Issue Information

Dear Colleagues,

Analog/mixed-signal-integrated circuits are an essential component for the collection, reception, and processing analysis of signals from the natural world, which are crucial in key areas such as audio and video signal processing, wireless communication, high-resolution instrumentation, and power management systems. They are optimized for tasks like signal amplification, filtering, and analog-to-digital conversion, while providing excellent performance in noise cancellation and bandwidth management. These circuits are cost-effective and help to reduce the complexity of systems. To meet specific application requirements, analog/mixed-signal-integrated circuits must offer high resolution and superior linearity, which are essential for maintaining signal integrity.

This Special Issue aims to collect original research articles on analog/mixed-signal-integrated circuit design. The topics of interest for this Special Issue include, but are not limited to, the following:

  • Analog-to-digital/digital-to-analog convertor;
  • Operational amplifier;
  • Filters;
  • Oscillator;
  • RF and microwave circuit;
  • Power management circuit;
  • Interface circuit;
  • Processor;
  • Computing-in-memory.

Dr. Chengying Chen
Dr. Xinghua Wang
Dr. Xiaoran Li
Guest Editors
