Advances in Semiconductor GaN and Applications

A special issue of Electronics (ISSN 2079-9292). This special issue belongs to the section "Semiconductor Devices".

Deadline for manuscript submissions: 15 September 2025 | Viewed by 248

Special Issue Editor

Dr. Zesheng Lv

E-Mail Website
Guest Editor
School of Electronics and Information Technology, Sun Yat-sen University, Guangzhou, China
Interests: epitaxy and characterization of Ⅲ-nitrides; UV–visible photodetectors

Special Issue Information

Dear Colleagues,

(1) With the remarkable developments of InGaN/GaN LEDs and AlGaN/GaN HEMTs, how to further enhance the performance of GaN-based electronic and optoelectronic devices as well as how to explore more application scenarios are some of the general concerns. This Special Issue aims to highlight the research progress of GaN-based semiconductors and their related applications, including the epitaxy and defect properties of GaN-based materials, structural and technological advances in electronic and optoelectronic devices, and the development of related display, communication, and circuit systems;

(2) Original research articles and reviews are welcome in this Special Issue. Research areas may include three aspects, namely materials, processing, and devices. Details include, but are not limited to, the following: the MOCVD, MBE, and HVPE of GaN and its ternary alloys, GaN-based nanostructures, defects and their suppression, high-efficiency doping in high-Al-composition AlGaN, low-resistivity ohmic contacts, dry etching and wet treatment, surface and interface properties of GaN-based heterostructures, high-power-density converters, terahertz devices, high-efficiency AlGaN (InGaN) UV (visible) LEDs and micro-LEDs, UV/visible laser diodes, high-sensitivity and high-speed UV/visible photodetectors, displays based on micro-LEDs, visible light communication systems based on GaN, and GaN-based power electronic modules. Novel explorations and applications based on GaN material systems are also encouraged, such as new understandings on defect characteristics, device construction utilizing polarization electric fields, and the heterogeneous integration of GaN materials with other materials, etc.

Dr. Zesheng Lv
Guest Editor

Manuscript Submission Information

Manuscripts should be submitted online at www.mdpi.com by registering and logging in to this website. Once you are registered, click here to go to the submission form. Manuscripts can be submitted until the deadline. All submissions that pass pre-check are peer-reviewed. Accepted papers will be published continuously in the journal (as soon as accepted) and will be listed together on the special issue website. Research articles, review articles as well as short communications are invited. For planned papers, a title and short abstract (about 100 words) can be sent to the Editorial Office for announcement on this website.

Submitted manuscripts should not have been published previously, nor be under consideration for publication elsewhere (except conference proceedings papers). All manuscripts are thoroughly refereed through a single-blind peer-review process. A guide for authors and other relevant information for submission of manuscripts is available on the Instructions for Authors page. Electronics is an international peer-reviewed open access semimonthly journal published by MDPI.

Please visit the Instructions for Authors page before submitting a manuscript. The Article Processing Charge (APC) for publication in this open access journal is 2400 CHF (Swiss Francs). Submitted papers should be well formatted and use good English. Authors may use MDPI's English editing service prior to publication or during author revisions.

Keywords

  • epitaxy of GaN materials
  • processing technologies
  • GaN-based power electronics
  • light-emitting diodes
  • laser diodes
  • UV/visible photodetectors
  • high-frequency converters
  • micro-LEDs

Benefits of Publishing in a Special Issue

  • Ease of navigation: Grouping papers by topic helps scholars navigate broad scope journals more efficiently.
  • Greater discoverability: Special Issues support the reach and impact of scientific research. Articles in Special Issues are more discoverable and cited more frequently.
  • Expansion of research network: Special Issues facilitate connections among authors, fostering scientific collaborations.
  • External promotion: Articles in Special Issues are often promoted through the journal's social media, increasing their visibility.
  • Reprint: MDPI Books provides the opportunity to republish successful Special Issues in book format, both online and in print.

Further information on MDPI's Special Issue policies can be found here.

Published Papers (1 paper)

Order results
Result details
Show export options expand_more Show export options expand_less
Select all
Export citation of selected articles as:

Research

13 pages, 1463 KiB
Article
Weak-Light-Enhanced AlGaN/GaN UV Phototransistors with a Buried p-GaN Structure
by Haiping Wang, Feiyu Zhang, Xuzhi Zhao, Haifan You, Zhan Ma, Jiandong Ye, Hai Lu, Rong Zhang, Youdou Zheng and Dunjun Chen
Electronics 2025, 14(10), 2076; https://doi.org/10.3390/electronics14102076 - 20 May 2025
Viewed by 126
Abstract
We propose a novel ultraviolet (UV) phototransistor (PT) architecture based on an AlGaN/GaN high electron mobility transistor (HEMT) with a buried p-GaN layer. In the dark, the polarization-induced two-dimensional electron gas (2DEG) at the AlGaN/GaN heterojunction interface is depleted by the buried p-GaN [...] Read more.
We propose a novel ultraviolet (UV) phototransistor (PT) architecture based on an AlGaN/GaN high electron mobility transistor (HEMT) with a buried p-GaN layer. In the dark, the polarization-induced two-dimensional electron gas (2DEG) at the AlGaN/GaN heterojunction interface is depleted by the buried p-GaN and the conduction channel is closed. Under UV illumination, the depletion region shrinks to just beneath the AlGaN/GaN interface and the 2DEG recovers. The retraction distance of the depletion region during device turn-on operation is comparable to the thickness of the AlGaN barrier layer, which is an order of magnitude smaller than that in the conventional p-GaN/AlGaN/GaN PT, whose retraction distance spans the entire GaN channel layer. Consequently, the proposed device demonstrates significantly enhanced weak-light detection capability and improved switching speed. Silvaco Atlas simulations reveal that under a weak UV intensity of 100 nW/cm2, the proposed device achieves a photocurrent density of 1.68 × 10−3 mA/mm, responsivity of 8.41 × 105 A/W, photo-to-dark-current ratio of 2.0 × 108, UV-to-visible rejection ratio exceeding 108, detectivity above 1 × 1019 cm·Hz1/2/W, and response time of 0.41/0.41 ns. The electron concentration distributions, conduction band variations, and 2DEG recovery behaviors in both the conventional and novel structures under dark and weak UV illumination are investigated in depth via simulations. Full article
(This article belongs to the Special Issue Advances in Semiconductor GaN and Applications)
