Pneumatic Soft Actuators

A special issue of Actuators (ISSN 2076-0825).

Deadline for manuscript submissions: closed (31 October 2020) | Viewed by 95389

Special Issue Editor

Dr. Steve Davis

E-Mail Website
Guest Editor
School of Engineering, College of Engineering and Physical Sciences, University of Birmingham, Birmingham B15 2TT, UK
Interests: soft robotics; pneumatic muscles; end effectors; automation for food; healthcare robotics
