A Portable Phase-Domain Magnetic Induction Tomography Transceiver with Phase-Band Auto-Tracking and Frequency-Sweep Capabilities

1
School of Electrical and Computer Engineering, Ulsan National Institute of Science and Technology, Ulsan 44919, Korea
2
School of Mechanical, Aerospace and Nuclear Engineering, Ulsan National Institute of Science and Technology, Ulsan 44919, Korea
*
Authors to whom correspondence should be addressed.
Received: 18 October 2018 / Revised: 4 November 2018 / Accepted: 5 November 2018 / Published: 7 November 2018
(This article belongs to the Section Physical Sensors)
Full-Text   |   PDF [3177 KB, uploaded 7 November 2018]   |

Abstract

This paper presents a portable magnetic induction tomography (MIT) transceiver integrated circuit to miniaturize conventional equipment-based MIT systems. The miniaturized MIT function is enabled through single-chip transceiver implementation. The proposed MIT transceiver utilizes a phase-locked loop (PLL) for frequency sweeping and a phase-domain sigma–delta modulator with phase-band auto-tracking for a full-range fine-phase resolution. The designed transceiver is fabricated and verified to achieve the measured signal to noise and distortion ratio (SNDR) of 101.7 dB. Its system-level prototype including in-house magnetic sensor coils is manufactured and functionally verified for four different material types. View Full-Text
Keywords: magnetic induction tomography; phase-domain sigma–delta modulator; phase-locked loop; transceiver integrated circuit; phase-band auto-tracking magnetic induction tomography; phase-domain sigma–delta modulator; phase-locked loop; transceiver integrated circuit; phase-band auto-tracking
Figures

Graphical abstract
