Al-doped zinc oxide (AZO) thin films were deposited by RF magnetron sputtering using a simple doping approach: aluminum tape was placed directly on the ZnO target. The work focused on understanding how Al incorporation, annealing temperature, and annealing atmosphere affect the structural and electrical behavior of the films, particularly their baseline resistance for gas sensing applications. EDX measurements confirmed that increasing the Al-covered area on the target progressively increased the Al concentration in the deposited layers. XRD analysis showed that higher Al contents and stronger thermal treatments reduced crystallinity and promoted the formation of smaller crystallites. The electrical response changed markedly with both Al incorporation and thermal treatment. Pure ZnO films initially exhibited very high resistance, while annealing reduced it by several orders of magnitude. Further increasing the Al concentration improved conductivity due to the donor effect of Al in the ZnO lattice. Overall, the results show that RF sputtering and post-treatment strategies can provide broad control over the electrical resistance of ZnO-based thin films. This tunability makes AZO coatings attractive for adapting chemoresistive gas sensors to different sensing environments and operating regimes, and deposition and thermal treatment parameters determine the resistance range. Full article

Semiconducting metal oxides are gaining attention in thermoelectric applications, where performance is evaluated by the figure of merit (ZT), which depends on the power factor (S²σ) and thermal conductivity (κ). However, achieving high ZT values in these materials remains challenging. This study introduces a distinct strategy to enhance thermoelectric performance by infiltrating aluminum-doped zinc oxide (AZO) into poly(methyl methacrylate) (PMMA) films using the vapor-phase infiltration (VPI) technique. The resulting AZO/PMMA hybrid films exhibit a unique composite structure with AZO nanocrystals embedded within an amorphous PMMA matrix. This structure facilitates energy-dependent carrier scattering (the energy filtering effect) at the AZO/PMMA interfaces, thereby enhancing the Seebeck coefficient, while phonon scattering at the interfaces reduces thermal conductivity. By precisely controlling VPI parameters, we achieved a uniform dispersion of AZO nanocrystals within the PMMA matrix. The optimized AZO/PMMA hybrid film demonstrated a power factor of 1306 μW m⁻¹ K⁻² and a thermal conductivity of 1.02 W m⁻¹ K⁻¹, resulting in a ZT value of approximately 0.384 at 300 K, which is one of the highest reported for metal oxide thermoelectric materials near room temperature. The successful integration of AZO into the PMMA matrix via VPI opens new pathways for developing high-performance, flexible thermoelectric materials. Full article

Novel colourimetric sensors are readily devised by combining multifunctional (nano)materials with miniature optoelectronic components. The demand to detect and monitor metal ions has resulted in the invention of new colourimetric sensing schemes, especially for use at the Point-of-Need (PoN). Nonetheless, the design of fully reversible optical materials for continuous real-time ion monitoring remains a bottleneck in the practical realisation of sensors. Magnesium ion is vital to physiological and environmental processes, but monitoring can be challenging, particularly in the presence of Ca²⁺ as a cross-sensitive interferent in real samples. In this work, a chromophore molecule Hyphan I (1-(2-hydroxy-5-ß-hydroxyethylsulfonyl-phenyl-azo)-2-naphthol) has been grafted onto a cellulose matrix with a simple one-pot vinylsulfonyl process, to form a transparent, biocompatible and highly flexible thin-film colourimetric magnesium ion sensing material (Cellulose Film with Hyphan-CFH). The CFH film has a pH response time of <60 s over the pH range 4 to 9, with a pK_a1 = 5.8. The LOD and LOQ for Mg²⁺ at pH 8 are 0.089 mM and 0.318 mM, respectively, with an RSD = 0.93%. The CFH film exhibits negligible interference from alkaline and alkaline earth metals, but irreversibly binds certain transition metals (Fe³⁺, Cu²⁺ and Zn²⁺). The CFH material has a fast and fully reversible colourimetric response to pH and Mg²⁺ over physiologically relevant ranges without interference by Ca²⁺, demonstrating good potential for integration into microfluidic systems and wearable sensors for biofluid monitoring. Full article

This study investigates pristine and doped ZnO thin films fabricated via the sol-gel technique, aiming to address efficiency challenges when used as transparent conductive oxide (TCO) layers in thin-film solar cells. ZnO was first doped with aluminum (Al), and subsequently with both Al and reduced graphene oxide (rGO), to evaluate the individual and combined effects of these dopants. The optimal pH value for the ZnO structure was initially determined, with the film produced at pH 9 exhibiting the most favorable characteristics. Al doping was then optimized at a ratio of Al/(Al + Zn) = 0.2, followed by optimization of the graphene content at 1.5 wt%. In this context, the structural, optical, and electrical properties of pristine ZnO, Al-doped ZnO (AZO), and Al and graphene co-doped ZnO (Gr:AZO) thin films were systematically investigated. These films were integrated as TCO layers into Cu₂SnS₃ (CTS)-based thin-film solar cells fabricated via physical vapor deposition (PVD). The cell architecture employed an 80 nm pristine ZnO window layer, while the doped ZnO films (300 nm) served as TCO layers. To assess the influence of the chemically deposited top layers, device performance was compared against a reference cell in which all layers were fabricated entirely using PVD. As expected, the reference cell exhibited superior performance compared to the cell whose AZO layer deposited chemically; however, the incorporation of both Al and graphene significantly enhanced the efficiency of the chemically modified cell, outperforming devices using only pristine or singly doped ZnO films. These results demonstrate the promising potential of co-doped solution-processed ZnO films as an alternative TCO layer in improving the performance of thin-film solar cell technologies. Full article

Azobenzene-based hologram recording materials are well known for their rewritable and polarization-selective properties that enable polarization-multiplexed recording and high-density optical storage. High diffraction efficiency, longer retention time, and shorter response time are desirable for rewritable recording materials, but they always require a trade-off relationship. In this study, we show that by simply coating the Azobenzene-based film with multiple layers of a suitable material, these parameters can be improved simultaneously without compromise. Bilayer films and triple layer films were prepared by depositing a DNA–surfactant complex-based layer above and below the azobenzene-based poly(CACzE-MMA) copolymer layer. The hologram recording performance was evaluated in terms of the diffraction efficiency, photoresponse time, and retention behavior of the recorded gratings. Compared with monolayer copolymer films, the multilayer DNA–surfactant complex-based copolymer films exhibited enhanced diffraction efficiency and faster photoresponse. In particular, the bilayer and trilayer structures showed a marked improvement in retention time, indicating suppressed relaxation of refractive index modulation. This enhancement is attributed to molecular confinement at the DNA–surfactant complex and copolymer interfaces generated by the layered architecture. These results demonstrate that a DNA–surfactant complex-based layering approach is an effective strategy for improving hologram stability and highlight the potential of DNA–surfactant complex-derived matrices as effective alternatives to poly(methyl methacrylate) (PMMA) in holographic applications. Full article

In the presented research, aluminum-doped zinc oxide (AZO) thin films were synthesized on high-power transmission lines using the RF magnetron sputtering process. The impact of deposition power (160 W to 280 W) and deposition pressure (2 Pa to 5 Pa), on key characteristics like material composition, wettability, anti-icing behavior, and average crystal size were analyzed. The optimization of wettability and anti-icing performance was carried out using two-factor, four-level design of the Taguchi method to study the combined effects of multiple parameters rather than the effect of a single parameter. Considerable variation in the water contact angle, from 92.3° to 123.6°, has been observed, suggesting an enhancement in hydrophobic nature with optimized condition. Anti-icing tests demonstrated that the coated surface delayed ice accumulation by approximately 4.56 times compared to the uncoated surface. X-ray diffraction (XRD) analysis was carried out to confirm notable changes in the intensity of the (002) peak along the c-axis, directly correlating with grain size modification. The change in surface roughness was studied using AFM and the results were compared to establish a relationship between surface roughness and average grain size. Overall, the findings highlight the critical role of deposition parameters and their interactions in modifying the surface and structural properties of AZO thin films, which demonstrates their potential application for improving the anti-icing performance of transmission lines. Full article

An ultrathin Al layer was introduced into AZO/Cu/AZO films to further enhance the optoelectronic performance. The AZO/Al/Cu/AZO films were deposited on glass substrates by DC and RF magnetron sputtering; the microstructure and optoelectronic properties were analyzed by XRD, SEM, AFM, TEM, visible spectrophotometer, and Hall effect measurement system. The results indicated that the Al layer played a crucial role in modulating the crystallization behavior and optoelectronic properties of the films, exhibiting a distinct thickness-threshold effect. At an Al layer thickness of 1 nm, the film exhibited optimal optoelectronic performance, achieving a high F_OM of 0.71 Ω⁻¹, a high transmittance of 85%, and a low resistivity of 5.7 × 10⁻⁵ Ω·cm. However, when the Al layer thickness exceeded 1 nm, the crystallinity of the films deteriorated significantly, the grain boundary scattering and light absorption effect enhanced, leading to the deterioration of photoelectric properties. The introduction of the Al layer significantly improved the stability of the films, and the AZO/Al(2 nm)/Cu/AZO film exhibited the best temporal stability after being exposed to air for 20 months. Full article

High-quality AZO thin films were produced on a 4-inch Si substrate using large-area PLD equipment at a substrate temperature of 330 °C, with a ZnO: Al (98:2 wt.%) target. This study aims to enhance the electrical, optical, morphological and structural properties of large-area PLD-grown AZO thin films by tuning the deposition pressures. The samples were prepared under high-vacuum (HV) conditions, as well as in oxygen atmospheres of 0.005 mbar O₂, 0.01 mbar O₂, and 0.1 mbar O₂. Consequently, a bilayer AZO film was prepared in a combination of two deposition pressures (first layer prepared under HV, followed by the second layer prepared at 0.01 mbar O₂). Additionally, morphological and structural characterization revealed that high-quality columnar growth AZO thin films free of droplets, with a strong (002) orientation, were achieved on a 4-inch Si substrate. Moreover, Hall measurements in the Van der Pauw configuration were used to assess the electrical properties. A low electrical resistivity of 3.98 × 10⁻⁴ Ω cm, combined with a high carrier concentration (n) of 1.05 × 10²¹ cm⁻³ and a charge carrier mobility of 17.9 cm²/V s, was achieved at room temperature for the sample prepared under HV conditions. The optical characterization conducted through spectroscopic ellipsometry measurements showed that the large-area AZO sample exhibits an increased optical transparency in the visible (VIS) range with a near-zero extinction coefficient (k) and a wide bandgap of 3.75 eV, fulfilling the standards for materials classified as TCO. In addition, the increased thickness uniformity of the prepared AZO films over a large area represents a significant step in scaling the PLD technique for industrial applications. Full article

Multilayer and free-standing films self-assembled from water-soluble anionic azo dye acid yellow 9 (AY9) and both poly(allylamine hydrochloride) (PAH) and chitosan (CS) cationic polyelectrolytes were fabricated from water solution using a layer-by-layer (LbL) technique and characterized by UV–Vis and Raman spectroscopy. Observations were made of a strong, unexpected, and highly unusual colour change from deep red to a distinct dark blue upon exposure of the multilayer films to an acidic environment. The colour change was attributed to the multilayer films only and was not observed either for the polymer or the dye alone, or their mixture in water solution, nor when cast as free-standing films. The significant shift to blue colour of the absorption peaks was quantified with UV–Vis spectroscopy, and a proposed explanation is presented based on density functional theory (DFT) calculations exploring possible and most likely acid-base equilibria configurations of the azo dye that result from being self-assembled. Full article

This work presents a low-cost and scalable method for fabricating thin-film transistors (TFTs) using a single-step, 3D-printed shadow mask approach. Room temperature growth of both aluminum-doped zinc oxide (AZO) thin film was used as the semiconductor channel, and zirconium oxide (ZrO₂) as the high-k dielectric, and the films were never exposed to any post-annealing treatment. Structural and morphological characterization confirmed smooth, compact films with stable dielectric behavior. Electrical measurements revealed a field-effect mobility of 13.1 cm²/V·s, a threshold voltage of ~4.1 V, and an on/off ratio of ~10⁴, validating effective gate modulation and drain current saturation. The off-state current, estimated from AZO conductivity measurements, was ~10⁻¹⁰ A, while the on-state current reached ~10⁻⁶ A. Benchmarking against state-of-the-art devices shows that these transistors rival ALD-processed IGZO TFTs and significantly outperform reported indium-free ZnO/AZO devices, while avoiding scarce indium and costly high-temperature or photolithographic processing. These findings establish 3D-printed shadow masks as a practical alternative to conventional lithography for oxide TFT fabrication. The method offers high device performance with simplified, indium-free, and room-temperature processing, underscoring its potential for scalable, transparent, and flexible electronics. Full article

Bulk chalcogenides from the system (GeTe₄)_1−xIn_x, where x = 0; 5 and 10 mol%, were synthesized by a two-step melt quenching technique. New layered composite materials based on them and the azo polymer [1-4-(3-carboxy-4-hydrophenylazo) benzensulfonamido]-1,2-ethanediyl, sodium salt] has been prepared through spin coating, electrospray deposition and via vacuum-thermal evaporation of the chalcogenide and spin coating of the azo polymer onto it. Using the latter technology, a material consisting of one chalcogenide and one azo polymer film and three chalcogenide and three azo polymer films has been fabricated. The carried-out SEM analysis shows that in the materials, initially prepared as a bilayer and multilayer structure, diffusion at the chalcogenide/polymer interface occurs leading to the formation of a homogenous composite environment. Birefringence was induced at 444 nm in all the fabricated thin film materials. The highest value of the maximal induced birefringence has been measured for the material fabricated as a stack, Δn_max = 0.118. For the material prepared as a bilayer structure and the composite material obtained through electrospray deposition, the maximal induced birefringence takes values of Δn_max = 0.101 and Δn_max = 0.095, respectively. The sample prepared via spin coating of the chalcogenide/PAZO dispersion has the lowest value of the maximal induced birefringence (Δn_max = 0.066) in comparison to the pure PAZO polymer film (Δn_max = 0.083). Full article

Transparent conductive aluminum-doped zinc oxide (AZO) films were investigated as potential recombination layers for perovskite/silicon tandem solar cells, comparing the results of atomic layer deposition (ALD) and magnetron sputtering (MS) on vertically aligned silicon nanowire (SiNW) scaffolds. Conformality and thickness control were examined by cross-sectional SEM/TEM and profilometry, revealing fully conformal ALD coatings with tunable thicknesses (40–120 nm) versus tip-capped, semi-uniform MS films (100–120 nm). Optical transmission measurements on glass substrates showed that both 120 nm ALD and MS layers exhibit interference maxima near 450–500 nm and 72–89% transmission across 800–1200 nm; the thinnest ALD films reached up to 86% near-IR transparency. Four-point probe analysis demonstrated that ALD reduces surface resistance from 1150 Ω/□ at 40 nm to 245 Ω/□ at 120 nm, while MS layers achieved 317 Ω/□ at 120 nm. These results delineate the balance between conformality, transparency, and conductivity, providing design guidelines for AZO recombination interfaces in next-generation tandem photovoltaics. Full article

Transparent conductive oxides (TCOs) have become essential components in a broad range of modern devices, including smartphones, flat-panel displays, and photovoltaic cells. Currently, indium tin oxide (ITO) is used in approximately 90% of these devices. However, ITO prices continue to rise due to the limited supply of indium (In), making the development of alternative materials for TCOs indispensable. Therefore, this study highlights the latest advances in creating new, affordable materials, with a focus on aluminum-doped zinc oxide (AZO). Over the last few decades, this material has been widely studied to improve its physical properties, particularly its low electrical resistivity, which can affect the performance of various devices. Now, it is close to replacing ITO due to several advantages including cost-effectiveness, stability under hydrogen plasma, low processing temperatures, and lack of toxicity. Besides that, in comparison to other TCOs such as IZO, IGZO, or IZrO, AZO achieved a low electrical resistivity (10⁻⁵ ohm cm) while maintaining a high transparency across the visible spectrum (over 85%). Additionally, due to the increasing development of technologies utilizing such materials, it is essential to develop more effective techniques for producing TCOs on a larger scale. Additionally, due to the increasing development of technologies utilizing such materials, it is essential to develop more effective techniques for producing TCOs on a larger scale. This review emphasizes the potential of AZO as a cost-effective and scalable alternative to ITO, highlighting key advancements in deposition techniques such as pulsed laser deposition (PLD). Full article

In this paper, nanoscale graphene film electrodes were prepared using laser-induced technology, and an in situ electrochemical cell was constructed. The normalized peak areas at 2.82 ppm for the samples without the in situ electrochemical cell and with an in situ electrochemical cell are 4.02 and 4.41, respectively. Tests showed that this in situ electrochemical cell has minimal interference from the nuclear magnetic resonance (NMR) magnetic field, allowing for high-resolution in situ spectra. Using this in situ electrochemical cell and employing in situ electrochemistry combined with NMR techniques, we investigated the oxidation reaction of 0.01 M procarbazine (PCZ) in real-time. We elucidated the following oxidation mechanism for procarbazine: the oxidation of PCZ first generates azo-procarbazine, which then undergoes a double bond shift to hydrazo-procarbazine. hydrazo-procarbazine undergoes hydrolysis to yield benzaldehyde-procarbazine, and then finally oxidizes to produce N-isopropylterephthalic acid. This confirms that the combination of in situ electrochemistry and nuclear magnetic resonance technology provides chemists with an effective tool for in situ studying the reaction mechanisms of drug molecules. Full article

New bulk chalcogenides from the system (GeTe₆)_1−xCu_x, where x = 5, 10, 15 and 20 mol%, have been synthesized. The structure and composition of the materials were studied using X-ray powder diffraction (XRD) and energy-dispersive spectroscopy (EDS). Scanning electron microscopy (SEM) was applied to analyze the surface morphology of the samples. Some thermal characteristics such as the glass transition, crystallization and melting temperature and some physico-chemical properties such as the density, compactness and molar and free volumes were also determined. The XRD patterns show sharp diffraction peaks, indicating that the synthesized new bulk materials are crystalline. The following four crystal phases were determined: Te, Cu, CuTe and Cu₂GeTe₃. The results from the EDS confirmed the presence of Ge, Te and Cu in the bulk samples in concentrations in good correspondence with those theoretically determined. A layered thin-film material based on Ge₁₄Te₈₁Cu₅, which exhibits lower network compactness compared to the other synthesized new chalcogenides, and the azo polymer PAZO was fabricated, and the kinetics of the photoinduced birefringence at 444 nm was measured. The results indicated an increase in the maximal induced birefringence for the layered structure in comparison to the non-doped azo polymer film. Full article
