Journal of Nuclear Engineering

This work investigated machine-learning algorithms for remote-control and autonomous operation of the Very-Small, Long-Life, Modular (VSLLIM) microreactor. This walk-away safe reactor can continuously generate 1.0–10 MW of thermal power for 92 and 5.6 full power years, respectively, is cooled by natural circulation of in-vessel liquid sodium, does not require on-site storage of either fresh or spent nuclear fuel, and offers redundant means of control and passive decay heat removal. The two ML algorithms investigated are Supervised Learning with Long Short-Term Memory networks (SL-LSTM) and Soft-Actor Critic with Feedforward Neural Networks (SAC-FNN). They are trained to manage the movement of the control rods in the reactor core during various transients including startup, shutdown, and to change the reactor steady state power up to 10 MW. The trained algorithms are incorporated into a Programmable Logic Controller (PLC) coupled to a digital twin dynamic model of the VSLLIM microreactor. Although the SL-LSTM algorithms demonstrate high prediction accuracy of up to 99.95%, they demonstrate inferior performance when incorporated into the PLC. Conversely, the PLC with SAC-FNN algorithm accurately adjusts the control rods positions during the reactor startup transients to within ±1.6% of target values. Full article

Growing environmental awareness has renewed interest in thorium as a nuclear fuel, underscoring the need for further studies to evaluate how reactors perform when conventional fuels are replaced with thorium-based alternatives. In this study, thermal hydraulics and solid mechanics computations were simulated using COMSOL multiphysics to investigate the safe operating conditions of a heavy water reactor with thorium-based fuel. The thermo-mechanical analysis of the fuel rod under transient heating conditions provides critical insights into strain, displacement, stress, and coolant flow behavior at elevated volumetric heat sources. After 3 s of heating, the strain distribution in the fuel exhibits a high-strain core surrounded by a low-strain rim, with peak volumetric strain increasing nearly linearly from 0.006 to 0.014 as heat generation rises. Displacement profiles confirm that radial deformation is concentrated at the outer surface, while axial elongation remains uniform and scales systematically with power. The resulting von Mises stress fields show maxima at the outer surface, increasing from ~0.06 to 0.15 GPa at the centerline with higher heat input but remaining within structural safety margins. Cladding simulations demonstrate nearly uniform axial expansion, with displacements increasing from ~0.012 mm to 0.03 mm across the investigated power range, and average strain remains negligible (≈10⁻⁴), while mean stresses increase moderately yet stay well below the yield strength of zirconium alloys, confirming safe elastic behavior. Hydrodynamic analysis shows that coolant velocity decreases smoothly along the axial direction but maintains stability, with only minor reductions under increased heat sources. Overall, the coupled thermo-mechanical and fluid-dynamic results confirm that both the fuel and cladding remain structurally stable under the studied conditions. By using COMSOL’s multiphysics capabilities, and unlike most legacy codes optimized for uranium-based fuel, this work is designed to easily incorporate non-traditional fuels such as thorium-based systems, including user-defined material properties, temperature-dependent thermal polynomial formulas, and mechanical response. Full article

Fibre Bragg grating (FBG) grid sensors are an underexplored technology with potential to benefit nuclear thermal hydraulics experiments. This paper presents a new FBG grid sensor consisting of 38 FBGs across 8 flow-crossing chords. Using this sensor, experiments determined for the first time that an FBG grid can detect large air bubbles rising in standing liquids—demonstrated in both columns of water and 20W50 automotive oil. The instrument’s sensitivity was quantified by comparing its measurements to high-speed camera recordings. Analysis of Bragg wavelength shift timings on each chord enabled the surface of a bubble to be reconstructed using the air–oil data. Finally, the increase in Bragg wavelength when bubbles interact with the FBG grid suggests a variant sensing principle different from that reported in the literature for FBG grids in flowing liquids. Full article

High concentrations of hydrogen isotopes have been observed at the ends of CANDU Zr-2.5Nb pressure tubes in the region associated with the rolled joints with 403 stainless steel end fittings. These concentrations are above current regulatory limits, causing concerns over how long pressure tubes should remain in service. This paper reviews two differing interpretations of the mechanisms for these high concentrations, leading to two conclusions. Ingress after about 30 y is attributed to pressure tube sag creating a crevice between the end fitting and the top of the tube that provides a window for hydrogen isotopes to enter from the annulus gas under reducing conditions. Small additions of oxygen should close this window. A new mechanism is suggested to explain deuteride precipitates past the rolled joint contact region after about 30 y. Surprisingly, the mechanism relies on deuterium and protium diffusing in solution at the same rate, i.e., no mass-dependent isotope effect. Full article

Although dynamic probabilistic risk assessment (PRA) techniques have advanced in their ability to represent the progression of events over time, the formulation of suitable risk importance measures for these methods still poses a substantial challenge. In particular, it is difficult to reflect the full breadth and multidimensional character of the risk information produced by dynamic PRA. In this study, we introduce a set of new importance measures derived from the risk triplet perspective: (i) Timing-Based Worth (TBW), which expresses diversity in scenario occurrence time; (ii) Frequency-Based Worth (FBW), which captures the probability of different scenarios; and (iii) Consequence-Based Worth (CBW), which characterizes scenario consequences. Formal definitions of these three indices are provided, and a conceptual scheme for integrated importance evaluation is proposed to support multidimensional analysis. As an initial demonstration, TBW and FBW are applied to a simplified reliability case using a dynamic PRA framework built on the continuous Markov chain Monte Carlo (CMMC) approach. This application is used to test their interpretability and the internal consistency of the proposed scheme. The findings suggest that TBW and FBW make it possible to conduct more holistic importance evaluations, taking into account resilience effects and temporal diversity in addition to conventional frequency-based perspectives. Such an extension is expected to increase the usefulness of dynamic PRA outputs for risk-informed decision-making. Full article

The High Temperature Gas-cooled Reactor (HTGR) is a Generation IV advanced nuclear reactor, which can realize inherent safety and prevent core melt. The Institute of Nuclear and New Energy Technology (INET) of Tsinghua University developed a commercial-scale 200 MWe High Temperature gas-cooled Reactor Pebble bed Module project (HTR-PM), which entered commercial operation on 6 December 2023. A passive Reactor Cavity Cooling System (RCCS) was designed for HTR-PM to export heat from the reactor cavity during normal operation and also in accident conditions, keeping the safety of the reactor pressure vessel (RPV) and reactor cavity. The RCCS of HTR-PM has been designed as three independent sets; the normal operation of two sets of RCCS can guarantee the safety of the PRV and reactor activity. The heat can be transferred from the RPV to the final heat sink atmosphere through thermal radiation and natural convection in the reactor cavity, and the natural circulation of water and air in the RCCS. The CAVCO code was developed by the INET to simulate the behavior of an RCCS. In this paper, assuming different RPV temperatures and different ambient temperatures, as well as assuming all or parts of the RCCS sets work, the performances of RCCS are studied by CAVCO to evaluate its operational reliability, so as to provide a reference for further optimization. The analysis results indicate that even under hypothetically extremely RPV temperatures, two sets of RCCS could effectively remove heat without causing water boiling or system failure. However, during the winter when ambient temperatures are low, particularly when the reactor operates at a lower RPV temperature, additional attention must be given to the operational safety of the system. It is crucial to prevent system failure caused by the freezing of circulating water and the potential cracking of water-cooling pipes due to freezing. Depending on the reactor status and ambient conditions, one or all three sets of RCCS may need to be taken offline. In addition, the maximum heat removal capacity of the RCCS with only two sets operational exceeds the design requirement of 1.2 MW. When the ambient temperature fluctuates significantly, it may be advisable to increase the number of available RCCS sets to mitigate the effect of abrupt changes in cooling water temperature on pipeline thermal stress. Full article

As a critical component of nuclear and thermal energy conversion systems, the long-term safe operation of a steam generator depends on the structural integrity of its tube bundles. Foreign objects introduced into the secondary side can induce flow-induced vibrations and wear, potentially causing tube wall damage and unplanned outages, thereby affecting overall system reliability. This study systematically investigates the flow-induced vibration behavior of foreign objects within steam generator tube bundles and explores the influence of object geometry through three-dimensional fluid–structure interaction (FSI) simulations. The foreign objects are modeled as single-degree-of-freedom rigid bodies, and their dynamic responses are captured using a coupled flow–motion framework. Results reveal that object geometry significantly influences flow separation, variations in lift and drag forces, and displacement characteristics. Cylindrical and irregular objects exhibit stable, low-amplitude vibrations; plate-shaped objects experience restricted motion due to large drag areas and symmetric contact constraints; whereas helical objects show the largest displacements arising from coupled axial–radial vibrations and complex vortical structures. These findings demonstrate that the interplay between aerodynamic forces and geometric complexity strongly governs the flow-induced vibration of foreign objects, offering insights into their motion behavior and potential impact on steam generator tube bundle integrity. Full article

Following the Great East Japan Earthquake in 2011, there has been an increased focus on risk assessment and the practical application of its findings to safety enhancement. In particular, dynamic probabilistic risk assessment (PRA) used in conjunction with plant dynamics analysis is being considered for accident management (AM) and operational support. Determining countermeasure priorities in AM can be challenging due to the diversity of accident scenarios. In multi-unit operations, the complexity of scenarios increases in cases of simultaneous disasters, which makes establishing response operations priorities more difficult. Dynamic PRA methods can efficiently generate and assess complex scenarios by incorporating changes in plant state. This paper introduces the continuous Markov chain Monte Carlo (CMMC) method, a dynamic PRA approach, as a tool for prioritizing countermeasures to support nuclear power plant operations. The proposed method involves three steps: (1) generating exhaustive scenarios that include events, operator actions, and system responses; (2) classifying scenarios according to countermeasure patterns; and (3) assigning priority based on risk data for each pattern. An evaluation was conducted using a simple plant model to analyze event countermeasure patterns for addressing steam generator tube rupture during single-unit operation. The generated scenario patterns included depressurization by opening a pressurizer relief valve (DP), depressurization via heat removal through the steam generator (DSG), and both operations combined (DP + DSG). The timing of the response operations varied randomly, resulting in multiple scenarios. The assessment, based on reactor pressure vessel water level and the potential for core damage, showed that the time margin to core damage depended on the countermeasure pattern. The findings indicate that the effectiveness of each countermeasure can be evaluated and that it is feasible to identify which countermeasure should be prioritized. Full article

Helically coiled tube heat exchangers (HCT) are recognized as promising solutions for steam generator applications in Small Modular Reactors (SMRs), where compactness and high thermal performance are crucial. The complex geometry of HCTs, however, substantially increases the difficulty of accurately estimating pressure drops, particularly under two-phase flow conditions. Over the last decade, several predictive correlations have been suggested, and their applicability is often limited to specific ranges of geometry and operating pressure. The present study examines correlations proposed during the previous decade, aiming to clarify their applicability limits. Validation is carried out using experimental datasets from the literature, enabling a rigorous evaluation of predictive accuracy, robustness, and generality. Full article

Compared to traditional large-scale reactors, the more heterogeneous, boron-free SMR cores create additional challenges for accurate multiphysics simulations. Therefore, advanced modelling and simulation tools should be used to create high-fidelity, high-accuracy, and computationally efficient multiphysics and multiscale solvers. These solvers can evaluate the safety and performance of SMRs and could be attractive for industrial applications if the computational power requirements were reasonably low. The first crucial step in building a computationally efficient simulation model is to define an SMR benchmark model. This model is a reference for validating the simulation results. In this paper, the benchmark model is a NuScale-like SMR, where the Serpent code has been utilized to run the neutronic simulation. The neutronic simulation was then performed again in the benchmark model, this time utilizing OpenMC code. The results of the Serpent and OpenMC codes were compared in terms of the reactivity coefficient, control rod worth and radial and axial power distribution. By comparing two different codes to validate the simulation of the NuScale-like benchmark, OpenMC will be utilized for future work, such as generating the nuclear material cross-section data for core simulators. Full article

This study presents a molecular dynamics (MD) investigation of water evaporation in copper nanochannels, with a focus on accurately modeling copper–water interactions through forcefield calibration. The TIP4P/2005 water model was coupled with the Modified Embedded Atom Method (MEAM) for copper, and the oxygen–copper Lennard–Jones (LJ) parameters were systematically tuned to match experimentally reported water contact angles (WCAs) on Cu (111) surfaces. Contact angles were extracted from simulation trajectories using a robust five-step protocol involving 2D kernel density estimation, adaptive thresholding, circle fitting, and mean squared error (MSE) validation. The optimized forcefield demonstrated strong agreement with experimental WCA values (50.2°–82.3°), enabling predictive control of wetting behavior by varying ε in the range 0.20–0.28 kcal/mol. Using this validated parameterization, we explored nanoscale evaporation in copper channels under varying thermal loads (300–600 K). The results reveal a clear temperature-dependent transition from interfacial-layer evaporation to bulk-phase vaporization, with evaporation onset and rate governed by the interplay between copper–water adhesion and thermal disruption of hydrogen bonding. These findings provide atomistically resolved insights into wetting and evaporation in metallic nanochannels, offering a calibrated framework for simulating phase-change heat transfer in advanced thermal management systems. Full article

The two-phase flow within a Boiling Water Reactor steam separator is investigated using an interface capturing method. The simulations are focused on resolving the flow around the first pickoff ring which is the highest contributor to steam carryunder phenomenon. Multiple simulations are conducted of varying levels of resolution to evaluate the capabilities of interface capturing technique for this challenging problem. First, high-resolution simulations of the flow using a simplified $30°$ wedge are conducted without a swirling velocity field present in the actual system. In order to understand the flow field generated by the separator swirler, secondary simulations of single-phase flow passing through a swirler model are conducted. Using this information, a coarse simulation of the full $360°$ model was performed, which incorporated the effect of the swirler using a custom inflow boundary condition. Instantaneous carryunder/carryover along with void fraction and film thickness are evaluated at the pickoff ring entrance. Overall, these simulations demonstrate that interface capturing simulations can be an accurate tool for studying full-scale components within nuclear power plants. Full article

Helical coiled tube (HCT) heat exchangers (HXs) are used in the nuclear industry, particularly in the residual heat removal systems of nuclear power plants (NPPs) and steam generators for small modular reactors. In this study, a single-phase CFD model was developed to investigate non-uniform circumferential distributions in the local wall heat transfer characteristics of a vertical HCT to obtain localized information critical for the safety of NPPs. In a comparison, the predicted circumferential heat transfer characteristics agreed well with the measured data. Governed by centrifugal/gravitational forces, these non-uniform distributions are clearly visible in the results, explaining the test data. We performed additional simulations of the conjugated heat transfer from the hot fluid of the shell side to the cold fluid of the tube side, confirming that the inhomogeneity of circumferential distributions in HCTs is due to the assumption of a constant heat flux boundary condition. Full article

Nuclear energy plays a critical role in global decarbonisation, but its expansion raises concerns about the proliferation risks associated with conventional fuel cycles. This study addresses this challenge by evaluating Am-241 doping as a method to enhance the intrinsic proliferation resistance of nuclear fuel. Using full-core simulations across Pressurised Water Reactors (PWRs), Boiling Water Reactors (BWRs), and Molten Salt Reactors (MSRs), the research assesses the impact of Am-241 on isotopic composition, reactor performance, and safety. The results show that Am-241 reliably increases the Pu-238 fraction in spent fuel above the 6% threshold, which significantly complicates its use in nuclear weapons. Additionally, Am-241 serves as a burnable poison, reducing the need for conventional absorbers without compromising operational margins. Economic modelling indicates that the levelised cost of electricity (LCOE) increases modestly, with the most notable impact observed in MSRs due to continuous doping requirements. The project concludes that Am-241 doping offers a passive, fuel-intrinsic safeguard that complements existing verification regimes. Adoption of this approach may require adjustments to regulatory frameworks, particularly in fuel licencing and fabrication standards, but could ultimately support the secure expansion of nuclear energy in regions with heightened proliferation concerns. Full article

The selection of suitable sites for the disposal of radioactive waste constitutes a critical component of nuclear waste management. This study presents an original methodological proposal based on the Analytic Hierarchy Process (AHP), designed to support early-stage site screening for a near-surface repository in Italy. AHP could be used to identify appropriate locations, focusing on 51 areas that have already undergone a preliminary screening phase. These areas, included in the National Map of Suitable Areas (CNAI), were selected as they fulfill all the technical requirements (geological, geomorphological, and hydraulic stability) necessary to ensure the safety performance of the engineering structures to be implemented through multiple artificial barriers, as specified in Technical Guide N. 29. The proposed methodology is applicable in cases where multiple sites listed in the CNAI have been identified as potential candidates for hosting the repository. A panel of 20 multidisciplinary experts, including engineers, environmental scientists, sociologists, and economists, evaluated two environmental, two economic, and two social criteria not included among the criteria outlined in Technical Guide N. 29. Pairwise comparisons were aggregated using the geometric mean, and consistency ratios (CRs) were calculated to ensure the coherence of expert judgements. Results show that social criteria received the highest overall weight (0.53), in particular the “degree of site acceptability”, followed by environmental (0.28) and economic (0.19) criteria. While the method does not replace detailed site investigations (which will nevertheless be carried out once the site has been chosen), it can facilitate the early identification of promising areas and guide future engagement with local communities. The approach is reproducible, adaptable to additional criteria or national requirements, and may be extended to other countries facing similar nuclear waste management challenges. Full article

The molten salt reactor (MSR) is a prominent Generation IV nuclear reactor concept that offers substantial advantages over conventional solid-fueled systems, including enhanced fuel utilization, inherent passive safety features, and significant reductions in long-lived radioactive waste. Central to its safety strategy is a reliance on natural circulation (NC) mechanisms, which eliminate the need for active pumping systems and enhance system reliability during normal and off-normal conditions. However, the challenges associated with molten salts, such as their high melting points, corrosivity, and material compatibility issues, render experimental investigations inherently complex and demanding. Therefore, the use of high-Pr-number surrogate fluids represents a practical alternative for studying molten salt behavior under safer and more accessible experimental conditions. In this study, a single-phase natural circulation loop setup at the University of Idaho’s Thermal–Hydraulics Laboratory was employed to investigate NC behavior under various operating conditions. The RELAP5-3D code was initially validated against water-based experiments before employing Therminol-66, a high-Prandtl-number surrogate for molten salts, in the natural circulation loop for the first time. The RELAP5-3D results demonstrated good agreement with both steady-state and transient experimental results, thereby confirming the code’s ability to model NC behavior in a single-phase flow regime. The results also highlighted certain experimental limitations that should be addressed to enhance the NC loop’s performance. These include increasing the insulation thickness to reduce heat losses, incorporating a dedicated mass flow measurement device for improved accuracy, and replacing the current heater with a higher-capacity unit to enable testing at elevated power levels. By identifying and addressing the main causes of these limitations and uncertainties during water-based experiments, targeted improvements can be implemented in both the RELAP5 model and the experimental setup, thereby ensuring that tests using a surrogate fluid for MSR analyses are conducted with higher accuracy and minimal uncertainty. Full article

Utilities that operate nuclear power plants are increasingly using probabilistic risk assessments (PRAs) to make day-to-day decisions on design, operations, and maintenance and to support risk-informed applications. These applications require high-quality and complete PRAs to ensure that the decisions and proposed changes are technically well-founded. Such PRAs include the modeling and quantification of PRA models for accident sequences initiated by internal floods and high-energy line breaks. To support PRA updates and upgrades for such sequences, the Electric Power Research Institute (EPRI) has sponsored ongoing research to develop and refine guidance and generic data that can be used to estimate initiating event frequencies for internal flood- and high-energy line break-induced accident sequences. In 2023, EPRI published the fifth revision of a generic database for these initiating event frequencies. This revision produced advancements in the methodology for passive component reliability, including the quantification of aging effects on pipe rupture frequencies and the capability to adjust these frequencies to account for enhancements to integrity management strategies associated with leak inspections and non-destructive examinations. The purpose of this paper is to present these enhancements and illustrate their application with selected examples. Full article

This study reviews the release potential of volatile radionuclides in the ALFRED reactor, providing data for source-term evaluations under both normal and postulated accident conditions. Using empirical Henry’s law relations and radionuclide inventories, the equilibrium partial pressures and maximum gas phase concentrations of activation and fission products were estimated. Results indicate that mercury, cadmium, and tellurium exhibit the highest volatility under normal operation, with more than 99.995% of radionuclides retained in the liquid lead. Polonium, despite its lower volatility, remains a critical safety concern due to its high radiotoxicity. Under elevated temperatures, such as those in an unprotected loss-of-flow (ULOF) scenario, increased release rates for volatile species are expected. In accident conditions involving a defective fuel assembly, fission products, including iodine, caesium, and noble gases, significantly contribute to the gas-phase radiological source term. These findings confirm the essential role of continuous cover gas monitoring and efficient purification systems in maintaining reactor safety. Full article
