The Precise Battery—towards Digital Twins for Advanced Batteries

A special issue of Batteries (ISSN 2313-0105).

Deadline for manuscript submissions: closed (31 July 2023) | Viewed by 32062

Special Issue Editors


E-Mail Website
Guest Editor
Chair for Electrical Energy Storage Systems, Institute for Photovoltaics, University of Stuttgart, Pfaffenwaldring 47, 70569 Stuttgart, Germany
Interests: battery cell research; battery system technology; battery block building kits; modeling of battery cells and battery systems; battery state estimation (state of charge, state of health, state of function); implementation of artificial intelligence for detrmination of battery cell parameters with enhanced accuracy; digital twins for battery cells and battery systems; high boiling point safety enhanced electrolytes; double layer capacitors; pseudo 3D-capacitors; power to X (X = gas, liquid, solid)
Special Issues, Collections and Topics in MDPI journals

E-Mail Website
Guest Editor
Chair for Electrical Energy Storage Systems, Institute for Photovoltaics, University of Stuttgart, Pfaffenwaldring 47, 70569 Stuttgart, Germany
Interests: battery cell research; novel battery diagnostics; battery modeling; battery characterization; battery cell state estimation; cell-to-cell variances; local cell state imbalances
Special Issues, Collections and Topics in MDPI journals

Special Issue Information

Dear Colleagues,

Electromobility has led to high demands with respect to energy and power density, durability and safety. Thus, there have been rapid and varied developments in battery technology, especially for Li-Ion and post Li-Ion battery cells.

To meet these stringent requirements (cell, module, system) and to set new benchmarks, research efforts in various areas are in progress. On the one hand, new candidates for negative electrodes are being investigated, such as lithium metal or silicon. Research is also constantly ongoing on solid electrolytes to make said anode materials feasible. At the positive electrode, the Ni content is steadily increased to reduce the amount of cobalt and nickel. Furthermore, abundant and safe electrodes such as lithium iron phosphate (LFP) have gained enhanced interest.

In parallel to new material developments at the cellular level, the optimization of cell design and operating strategy are in focus. Important factors include the tab design, the geometric cell and battery formats, the cell size (in terms of Ah) and the energy content. The challenges o material selection and cell design are doubtless important trade-offs among different KPIs.

However, without a precise battery model and advanced calculation methods, all the aforementioned mentioned attempts fail. A precise battery model is a digital twin including electrical, thermal, mechanical and aging models as well as new approaches employing artificial intelligence. Additionally, the digital twin should show real-time ability.

Consequently, we want to promote and address a new Special Issue ‘The precise battery battery - towards digital twins for advanced batteries’.

Research on the enhancement of the accuracy of models, their smart combination and sophisticated stand-alone calculation methods in terms of materials, cells, modules and battery level are highly welcome. All these contributions are necessary to build up digital twins for batteries.

Potential topics include but are not limited to:

  • Digital twins of battery cells;
  • Digital twins for battery systems;
  • Equivalent circuit and equation-based battery modeling;
  • Electrical, thermal and mechanical battery modeling;
  • Lifetime estimation of battery cells and modules;
  • Accuracy enhancement methods for battery states and lifetime estimation;
  • Calculation-based cell size optimization for advanced Li-ion batteries;
  • Calculation aspects of battery cell and pack design;
  • Quantifying the impact of solid electrolytes;
  • Quantifying the impact of new electrode materials.

Prof. Dr. Kai Peter Birke
Dr. Alexander Fill
Guest Editors

Manuscript Submission Information

Manuscripts should be submitted online at www.mdpi.com by registering and logging in to this website. Once you are registered, click here to go to the submission form. Manuscripts can be submitted until the deadline. All submissions that pass pre-check are peer-reviewed. Accepted papers will be published continuously in the journal (as soon as accepted) and will be listed together on the special issue website. Research articles, review articles as well as short communications are invited. For planned papers, a title and short abstract (about 100 words) can be sent to the Editorial Office for announcement on this website.

Submitted manuscripts should not have been published previously, nor be under consideration for publication elsewhere (except conference proceedings papers). All manuscripts are thoroughly refereed through a single-blind peer-review process. A guide for authors and other relevant information for submission of manuscripts is available on the Instructions for Authors page. Batteries is an international peer-reviewed open access monthly journal published by MDPI.

Please visit the Instructions for Authors page before submitting a manuscript. The Article Processing Charge (APC) for publication in this open access journal is 2700 CHF (Swiss Francs). Submitted papers should be well formatted and use good English. Authors may use MDPI's English editing service prior to publication or during author revisions.

Keywords

  • battery algorithms
  • modeling of battery cells and battery systems
  • battery state estimation (state of charge, state of health, state of function)
  • electrochemical models
  • electrical models
  • thermal models
  • aging models
  • mechanical models
  • thermal propagation models
  • artificial intelligence in battery models
  • digital twins for battery cells and battery systems
  • battery management systems
