Appl. Mech., Volume 6, Issue 3 (September 2025) – 7 articles

Crash boxes play a crucial role in automotive safety by absorbing impact energy during collisions. The advancement of additive manufacturing (AM), particularly Fused Deposition Modeling (FDM), has enabled the fabrication of geometrically complex and lightweight crash boxes. This study presents a comparative evaluation of the crashworthiness performance of five FDM materials, namely, PLA+, PLA-ST, PLA-LW, PLA-CF, and PETG, across four structural configurations: Single-Cell Circle (SCC), Multi-Cell Circle (MCC), Single-Cell Square (SCS), and Multi-Cell Square (MCS). Quasi-static axial compression tests are conducted to assess the specific energy absorption $\left(SEA\right)$ and crush force efficiency $\left(CFE\right)$ of each material–geometry combination. Among the materials, PLA-CF demonstrates superior performance, with the MCC configuration achieving an $SEA$ of 22.378 ± 0.570 J/g and a $CFE$ of 0.732 ± 0.016. Multi-cell configurations consistently outperformed single-cell designs across all materials. To statistically quantify the influence of material and geometry on crash performance, a two-factor ANOVA was performed, highlighting geometry as the most significant factor across all evaluated metrics. Additionally, a comparative test with aluminum 6063-T5 demonstrates that PLA-CF offers comparable crashworthiness, with advantages in mass reduction, reduced $PCF$, and enhanced design flexibility inherent in AM. These findings provide valuable guidance for material selection and structural optimization in FDM-based crash boxes. Full article

Unlike previous studies focusing on two-layer structures or single-parameter effects, this work systematically investigates the influence of sheet layer combination modes on the mechanical properties of three-layer AA6063-T6 self-piercing riveting (SPR) joints through a combination of experimental testing and numerical simulation. Shear and cross-tensile tests were conducted on three-layer AA6063-T6 SPR joints with three distinct sheet layer combinations: T1 (top/middle: 100 × 40 mm², bottom: 40 × 40 mm²), T2 (top/bottom: 100 × 40 mm², middle: 40 × 40 mm²), and T3 (middle/bottom: 100 × 40 mm², top: 40 × 40 mm²). Experimental results reveal significant differences in joint strength and failure modes across the three combinations. T3 joints exhibited the highest shear strength (9.16 kN) but the lowest cross-tensile strength (3.56 kN), whereas T1 joints showed the highest cross-tensile strength (4.97 kN) but moderate shear strength (8.76 kN). A high-fidelity finite element model was developed to simulate the SPR joint under varying sheet layer combinations, incorporating precise geometric details (0.25 mm mesh at critical zones) and advanced contact algorithms (friction coefficient μ = 0.2). Numerical simulations revealed the stress distribution and failure mechanisms under shear and cross-tensile loading, aligning well with experimental observations. Analysis highlights that the mechanical performance of the joint is governed by two key factors: (1) the stress redistribution in sheet layers due to combination mode variations, and (2) the interlocking strength between the rivet and sheets. These findings provide practical guidelines for optimizing sheet layer combinations in lightweight automotive structures subjected to mixed loading conditions. Full article

Properly refrigerating hard-to-cut alloys during grinding is key to achieve high quality, strict tolerances, and good surface finishing. Nonetheless, literature about the influence of cooling-lubrication conditions (CLCs) on dimensional accuracy of ground components is still scarce. Thus, this work aims to evaluate surface quality, grinding power, and dimensional accuracy of Inconel 718 workpieces after grinding with silicon carbide grinding wheel at different grinding conditions. Four different CLCs were tested: flood, minimum quantity of lubrication (MQL) without graphene, and with multilayer graphene (MG) at two distinct concentrations: 0.05 and 0.10 wt.%. Different radial depths of cut values were also tested. The results showed that the material’s removed height increased with radial depth of cut, leading to coarse tolerance (IT) grades. Machining with the MQL WG resulted in higher dimensional precision with an IT grade varying between IT6 and IT7, followed by MQL MG 0.10% (IT7), MQL MG 0.05% (IT7-IT8), and flood (IT8). The lower tolerances achieved with MG were attributed to the lowering in the friction coefficient of the workpiece material sliding through the abrasive grits with no material removal (micro-plowing mechanism), thereby reducing grinding power and the removed height in comparison to the other CLC tested. Full article

The sandwich plates in consideration are structures composed of a number of Lévy plate components laminated with viscoelastic layers, and they are seen in broad engineering applications. In vibration analysis of a sandwich plate, conventional analytical methods are limited due to the complexity of the geometric and material properties of the structure, and consequently, numerical methods are commonly used. In this paper, an innovative analytical method is proposed for vibration analysis of sandwich Lévy plates having different configurations of viscoelastic layers and using various models of viscoelastic materials. The focus of the investigation is on the determination of closed-form frequency response at any given frequencies. In the development, an s-domain state-space formulation is established by the Distributed Transfer Function Method (DTFM). With this formulation, closed-form analytical solutions of the frequency response problem of sandwich plates are obtained, without the need for spatial discretization. As one unique feature, the DTFM-based approach has consistent formulas and unified solution procedures by which analytical solutions at both low and high frequencies are obtained. The accuracy, efficiency, and versatility of the proposed analytical method are demonstrated in three numerical examples, where the DTFM-based analysis is compared with the finite element method and certain existing analytical solutions. Full article

This paper develops an analytical turbulence model for open-ended squeeze film damper (SFD) application. Prandtl’s mixing length theory is adopted to describe the momentum transfer within the damper for its thin-film turbulent flow. A novel turbulence coefficient function is developed to describe the effective fluid viscosity such that the classical Reynolds equation remains applicable. Model validation is presented by (i) comparing the damping coefficient obtained by several existing empirical formulas and (ii) correlating the rotor dynamic prediction with the experimental measurement of an integrated rotor-SFD test rig. This work provides a reduced form of turbulence coefficient for certain SFD implementations. It quantifies the turbulence effect under different operating conditions, which is valued as a practical tool to assess the significance of turbulence consequences in rotor dynamic applications. Full article

Machining Nomex honeycomb cores is essential for manufacturing components that meet the stringent requirements of industrial sectors, but the complexity of this type of structure material requires specialized techniques to minimize defects, ensure optimal surface quality and extend cutting tool life. For this reason, an innovative machining technology based on longitudinal–torsional ultrasonic vibration assistance has been integrated into a CZ10 combined cutting tool, with the aim of optimizing the efficiency of conventional machining processes. To this end, a three-dimensional numerical model based on the finite element method, developed using Abaqus/Explicit 2017 software, was used to simulate the complex interactions between the cutting tool and the thin walls of the structures to be machined. This study aimed to validate the numerical model through experimental tests, quantifying the surface condition, cutting force and tool wear, while evaluating the impact of key machining parameters, such as feed rate and wall thickness, on process performance. The obtained results reveal a substantial reduction in cutting forces, varying from 20 to 40%, as well as a notable improvement in surface finish and a significant extension of tool life. These conclusions open up new perspectives for the optimization of industrial processes, particularly in high-demand sectors such as aeronautics. Full article

This study investigates the biotribological performance of alumina–UHMWPE and alumina–PEEK hip implant couples through finite element simulation (ANSYS v24) and statistical inference (STATA v17). During gait cycle loading simulations, significant disparity in wear behaviour was observed. Alumina–UHMWPE demonstrated superior mechanical resistance, with a wear volume of 0.18481 mm³ and a wear depth of 6.93 × 10⁻⁴ mm compared to alumina–PEEK, which registered higher wear (volume: 8.4006 mm³; depth: 3.15 × 10⁻² mm). Wear distribution analysis indicated alumina–UHMWPE showed an even wear pattern in comparison to the poor, uneven alumina-PEEK high-wear patterns. Statistical comparison validated these findings, wherein alumina–UHMWPE achieved a 27.60 hip joint wear index (HCI) value, which is better than that of alumina–PEEK (35.85 HCI), particularly regarding key parameters like wear depth and volume. This computational–statistical model yields a baseline design for biomaterial choice, demonstrating the potential clinical superiority of alumina–UHMWPE in reducing implant failure risk. While this is a simulation study lacking experimental validation, the results pave the way for experimental and clinical studies for further verification and refinement. The approach enables hip arthroplasty design optimization with maximal efficiency and minimal resource-intensive testing. Full article
