Technologies 2018, 6(2), 45; https://doi.org/10.3390/technologies6020045

High Density Interconnect Microstrip Patch Antenna for 5G Base Stations with Integrated Filtering Performance

1
ELEDIA Research Center (ELEDIA@UniTN—University of Trento), Via Sommarive 9, I-38123 Trento, Italy
2
ELEDIA Research Center (ELEDIA@UC3M—Universidad Carlos III de Madrid), Avenida de la Universidad 30, 28911 Leganés, Madrid, Spain
*
Author to whom correspondence should be addressed.
Received: 10 March 2018 / Revised: 24 April 2018 / Accepted: 24 April 2018 / Published: 27 April 2018
Full-Text   |   PDF [2127 KB, uploaded 3 May 2018]   |

Abstract

The elementary radiator of a planar array for next generation millimeter-wave (mm-wave) 5G base stations is described. The antenna is designed for high density interconnect (HDI) manufacturing for yielding a compact, densely-interconnected, and highly-integrable stacked structure. The layout of the single element is determined by directly optimizing key radiation features of the whole planar arrangement according to specific application-driven requirements. In addition, thanks to the exploitation of a spline-shaped modelling of the radiator, suitable performance in terms of impedance matching, realized gain, half-power beamwidth (HPBW), polarization purity, and inter-element isolation are achieved within the 28-GHz pass-band. Moreover, integrated out-of-band filtering capabilities are obtained in selected and wide non-contiguous stop-bands without additional circuitry. View Full-Text
Keywords: 5G base station; mm-wave antenna design; high density interconnect (HDI); filtering antenna; spline shape; embedded element analysis 5G base station; mm-wave antenna design; high density interconnect (HDI); filtering antenna; spline shape; embedded element analysis
Figures

Figure 1
