Micromachines, Volume 12, Issue 7 (July 2021) – 120 articles

Cover Story (view full-size image): As one of the most important prosthetic implants for amputees, commercially available prosthetic hands are too bulky, heavy, expensive, complex and inefficient. We present a study that utilizes artificial tendons to drive the motion of fingers in a biomimetic prosthetic hand. The artificial tendons are realized by combining liquid crystal elastomers (LCEs) and liquid metal (LM) heating elements. Joule-heating-induced temperature increase in the LCE tendons leads to linear contraction, which drives the fingers of the biomimetic prosthetic hand to bend in a way similar to the human hand. This biomimetic prosthetic hand is demonstrated to be able to perform complex tasks, including making different hand gestures, holding objects of different sizes and shapes, and carrying weights. View this paper.
  • Issues are regarded as officially published after their release is announced to the table of contents alert mailing list.
  • You may sign up for e-mail alerts to receive table of contents of newly released issues.
  • PDF is the official format for papers published in both, html and pdf forms. To view the papers in pdf format, click on the "PDF Full-text" link, and use the free Adobe Readerexternal link to open them.
Order results
Result details
Select all
Export citation of selected articles as:
Article
Molecular Dynamic Investigation of the Anisotropic Response of Aluminum Surface by Ions Beam Sputtering
Micromachines 2021, 12(7), 848; https://doi.org/10.3390/mi12070848 - 20 Jul 2021
Viewed by 208
Abstract
Aluminum optics are widely used in modern optical systems because of their high specific stiffness and high reflectance. With the applied optical frequency band moving to visible, traditional processing technology cannot meet the processing precision. Ion beam sputtering (IBS) provides a highly deterministic [...] Read more.
Aluminum optics are widely used in modern optical systems because of their high specific stiffness and high reflectance. With the applied optical frequency band moving to visible, traditional processing technology cannot meet the processing precision. Ion beam sputtering (IBS) provides a highly deterministic technology for high-precision aluminum optics fabrication. However, the surface quality is deteriorated after IBS. The interaction between the bombard atoms and the surface morphology evolution mechanism are not clear, and systematic research is needed. Thus, in this paper, the IBS process for single crystal aluminum with different crystallographic orientations are studied by the molecular dynamics method. The ion beam sputter process is firstly demonstrated. Then, the variation of sputter yield of the three crystal faces is analyzed. The sputter yield difference of different crystal surfaces causes the appearance of the relief structure. Then, the gravel structure generates on the single crystal surfaces and dominates the morphology evolution. The state of the atom diffusion of the specific crystal surfaces will determine the form of the gravel structure. Furthermore, the form and distribution of subsurface damage and stress distribution of three different crystal surfaces are analyzed. Although there are great differences in defect distribution, no stress concentration was found in three workpieces, which verifies that the ion beam sputter is a stress-free machining method. The process of IBS and the mechanism of morphology evolution of aluminum are revealed. The regularity and mechanism will provide a guidance for the application of IBS in aluminum optics manufacture fields. Full article
(This article belongs to the Special Issue Frontiers in Ultra-Precision Machining)
Show Figures

Figure 1

Review
Artificial Compound Eye Systems and Their Application: A Review
Micromachines 2021, 12(7), 847; https://doi.org/10.3390/mi12070847 - 20 Jul 2021
Viewed by 274
Abstract
The natural compound eye system has many outstanding properties, such as a more compact size, wider-angle view, better capacity to detect moving objects, and higher sensitivity to light intensity, compared to that of a single-aperture vision system. Thanks to the development of micro- [...] Read more.
The natural compound eye system has many outstanding properties, such as a more compact size, wider-angle view, better capacity to detect moving objects, and higher sensitivity to light intensity, compared to that of a single-aperture vision system. Thanks to the development of micro- and nano-fabrication techniques, many artificial compound eye imaging systems have been studied and fabricated to inherit fascinating optical features of the natural compound eye. This paper provides a review of artificial compound eye imaging systems. This review begins by introducing the principle of the natural compound eye, and then, the analysis of two types of artificial compound eye systems. We equally present the applications of the artificial compound eye imaging systems. Finally, we suggest our outlooks about the artificial compound eye imaging system. Full article
Show Figures

Figure 1

Article
Observation and Optimization on Garbage Collection of Flash Memories: The View in Performance Cliff
Micromachines 2021, 12(7), 846; https://doi.org/10.3390/mi12070846 - 20 Jul 2021
Viewed by 214
Abstract
The recent development of 3D flash memories has promoted the widespread application of SSDs in modern storage systems by providing large storage capacity and low cost. Garbage collection (GC) as a time-consuming but necessary operation in flash memories largely affects the performance. In [...] Read more.
The recent development of 3D flash memories has promoted the widespread application of SSDs in modern storage systems by providing large storage capacity and low cost. Garbage collection (GC) as a time-consuming but necessary operation in flash memories largely affects the performance. In this paper, we perform a comprehensive experimental study on how garbage collection impacts the performance of flash-based SSDs, in the view of performance cliff that closely relates to Quality of Service (QoS). According to the study results using real-world workloads, we first observe that GC occasionally causes response time spikes, which we call the performance cliff problem. Then, we find that 3D SSDs exacerbate the situation by inducing a much higher number of page migrations during GC. To relieve the performance cliff problem, we propose PreGC to assist normal GC. The key idea is to distribute the page migrations into the period before normal GC, thus leading to a reduction in page migrations during the GC period. Comprehensive experiments with real-world workloads have been performed on the SSDsim simulator. Experimental results show that PreGC can efficiently relieve the performance cliff by reducing the tail latency from the 90th to 99.99th percentiles while inducing a little extra write amplification. Full article
(This article belongs to the Special Issue Flash Memory Devices)
Show Figures

Figure 1

Article
Carbon Dioxide Sensor Module Based on NDIR Technology
Micromachines 2021, 12(7), 845; https://doi.org/10.3390/mi12070845 - 20 Jul 2021
Viewed by 192
Abstract
In this paper, a gas detection system with an environmental compensation algorithm based on nondispersive infrared (NDIR) technology was designed. The prepared infrared pyroelectric detector was a dual-channel type based on the lithium tantalate (LiTaO3) wafer. The design of the optical [...] Read more.
In this paper, a gas detection system with an environmental compensation algorithm based on nondispersive infrared (NDIR) technology was designed. The prepared infrared pyroelectric detector was a dual-channel type based on the lithium tantalate (LiTaO3) wafer. The design of the optical gas chamber adopted a combination of two ellipsoids and a spherical top surface, which not only enhanced the coupling efficiency of the light propagation but also facilitated the miniaturization of the sensor module. In addition to this, a temperature and humidity compensation algorithm based on the least square method was proposed to make the measurement accuracy up to ±0.9% full scale (FS). Full article
(This article belongs to the Special Issue Design, Fabrication and Reliability of Semiconductor Devices)
Show Figures

Figure 1

Article
Robust Orthogonal-View 2-D/3-D Rigid Registration for Minimally Invasive Surgery
Micromachines 2021, 12(7), 844; https://doi.org/10.3390/mi12070844 - 20 Jul 2021
Viewed by 223
Abstract
Intra-operative target pose estimation is fundamental in minimally invasive surgery (MIS) to guiding surgical robots. This task can be fulfilled by the 2-D/3-D rigid registration, which aligns the anatomical structures between intra-operative 2-D fluoroscopy and the pre-operative 3-D computed tomography (CT) with annotated [...] Read more.
Intra-operative target pose estimation is fundamental in minimally invasive surgery (MIS) to guiding surgical robots. This task can be fulfilled by the 2-D/3-D rigid registration, which aligns the anatomical structures between intra-operative 2-D fluoroscopy and the pre-operative 3-D computed tomography (CT) with annotated target information. Although this technique has been researched for decades, it is still challenging to achieve accuracy, robustness and efficiency simultaneously. In this paper, a novel orthogonal-view 2-D/3-D rigid registration framework is proposed which combines the dense reconstruction based on deep learning and the GPU-accelerated 3-D/3-D rigid registration. First, we employ the X2CT-GAN to reconstruct a target CT from two orthogonal fluoroscopy images. After that, the generated target CT and pre-operative CT are input into the 3-D/3-D rigid registration part, which potentially needs a few iterations to converge the global optima. For further efficiency improvement, we make the 3-D/3-D registration algorithm parallel and apply a GPU to accelerate this part. For evaluation, a novel tool is employed to preprocess the public head CT dataset CQ500 and a CT-DRR dataset is presented as the benchmark. The proposed method achieves 1.65 ± 1.41 mm in mean target registration error(mTRE), 20% in the gross failure rate(GFR) and 1.8 s in running time. Our method outperforms the state-of-the-art methods in most test cases. It is promising to apply the proposed method in localization and nano manipulation of micro surgical robot for highly precise MIS. Full article
(This article belongs to the Special Issue Fundamentals and Applications of Micro-nanorobotics)
Show Figures

Figure 1

Article
Effect of Optical and Morphological Control of Single-Structured LEC Device
Micromachines 2021, 12(7), 843; https://doi.org/10.3390/mi12070843 - 19 Jul 2021
Viewed by 278
Abstract
We investigated the performance of single-structured light-emitting electrochemical cell (LEC) devices with Ru(bpy)3(PF6)2 polymer composite as an emission layer by controlling thickness and heat treatment. When the thickness was smaller than 120–150 nm, the device performance decreased because [...] Read more.
We investigated the performance of single-structured light-emitting electrochemical cell (LEC) devices with Ru(bpy)3(PF6)2 polymer composite as an emission layer by controlling thickness and heat treatment. When the thickness was smaller than 120–150 nm, the device performance decreased because of the low optical properties and non-dense surface properties. On the other hand, when the thickness was over than 150 nm, the device had too high surface roughness, resulting in high-efficiency roll-off and poor device stability. With 150 nm thickness, the absorbance increased, and the surface roughness was low and dense, resulting in increased device characteristics and better stability. The heat treatment effect further improved the surface properties, thus improving the device characteristics. In particular, the external quantum efficiency (EQE) reduction rate was shallow at 100 °C, which indicates that the LEC device has stable operating characteristics. The LEC device exhibited a maximum luminance of 3532 cd/m2 and an EQE of 1.14% under 150 nm thickness and 100 °C heat treatment. Full article
(This article belongs to the Special Issue Recent Advances in Organic Electronics and Novel Applications)
Show Figures

Figure 1

Review
Progress and Challenges in the Use of a Liver-on-a-Chip for Hepatotropic Infectious Diseases
Micromachines 2021, 12(7), 842; https://doi.org/10.3390/mi12070842 - 19 Jul 2021
Viewed by 307
Abstract
The liver is a target organ of life-threatening pathogens and prominently contributes to the variation in drug responses and drug-induced liver injury among patients. Currently available drugs significantly decrease the morbidity and mortality of liver-dwelling pathogens worldwide; however, emerging clinical evidence reveals the [...] Read more.
The liver is a target organ of life-threatening pathogens and prominently contributes to the variation in drug responses and drug-induced liver injury among patients. Currently available drugs significantly decrease the morbidity and mortality of liver-dwelling pathogens worldwide; however, emerging clinical evidence reveals the importance of host factors in the design of safe and effective therapies for individuals, known as personalized medicine. Given the primary adherence of cells in conventional two-dimensional culture, the use of these one-size-fit-to-all models in preclinical drug development can lead to substantial failures in assessing therapeutic safety and efficacy. Advances in stem cell biology, bioengineering and material sciences allow us to develop a more physiologically relevant model that is capable of recapitulating the human liver. This report reviews the current use of liver-on-a-chip models of hepatotropic infectious diseases in the context of precision medicine including hepatitis virus and malaria parasites, assesses patient-specific responses to antiviral drugs, and designs personalized therapeutic treatments to address the need for a personalized liver-like model. Second, most organs-on-chips lack a monitoring system for cell functions in real time; thus, the review discusses recent advances and challenges in combining liver-on-a-chip technology with biosensors for assessing hepatocyte viability and functions. Prospectively, the biosensor-integrated liver-on-a-chip device would provide novel biological insights that could accelerate the development of novel therapeutic compounds. Full article
Show Figures

Figure 1

Article
Facile Preparation of Mesoporous MCM-48 Containing Silver Nanoparticles with Fly Ash as Raw Materials for CO Catalytic Oxidation
Micromachines 2021, 12(7), 841; https://doi.org/10.3390/mi12070841 - 19 Jul 2021
Viewed by 236
Abstract
An environmentally friendly method was proposed to prepare mesoporous Mobil Composition of Matter No.48 (MCM-48) using fly ash as the silica source. Silver nanoparticles were infiltrated on MCM-48 facilely by an in situ post-reduction method and evaluated as an effective catalyst for CO [...] Read more.
An environmentally friendly method was proposed to prepare mesoporous Mobil Composition of Matter No.48 (MCM-48) using fly ash as the silica source. Silver nanoparticles were infiltrated on MCM-48 facilely by an in situ post-reduction method and evaluated as an effective catalyst for CO oxidation. The as-prepared MCM-48 and Ag/MCM-48 nanoparticles were characterized by XRD, N2 adsorption/desorption, and TEM. Investigations by means of XPS for Ag/MCM-48 were performed in order to illuminate the surface composition of the samples. Studies revealed the strong influence of the loading of Ag nanoparticles on catalysts in the oxidation of CO. CO conversion values for Ag/MCM-48 of 10% and 100% were achieved at temperatures of 220 °C and 270 °C, respectively, indicating that the Ag-decorated MCM-48 catalyst is extremely active for CO oxidation. Full article
(This article belongs to the Special Issue Advanced Ceramic and Glass Devices)
Show Figures

Figure 1

Editorial
Editorial for the Special Issue on Micro and Nano Devices for Cell Analysis
Micromachines 2021, 12(7), 840; https://doi.org/10.3390/mi12070840 - 19 Jul 2021
Viewed by 213
Abstract
In recent years, miniaturized systems (micro- and nano-devices) called a lab-on-a-chip or micro-total analysis system (µ-TAS) have received attention as new systems for chemical and biochemical analyses [...] Full article
(This article belongs to the Special Issue Micro and Nano Devices for Cell Analysis)
Article
Encapsulated Cell Dynamics in Droplet Microfluidic Devices with Sheath Flow
Micromachines 2021, 12(7), 839; https://doi.org/10.3390/mi12070839 - 19 Jul 2021
Viewed by 234
Abstract
In this paper we study the dynamics of single cells encapsulated in water-in-oil emulsions in a microchannel. The flow field of a microfluidic channel is coupled to the internal flow field of a droplet through viscous traction at the interface, resulting in a [...] Read more.
In this paper we study the dynamics of single cells encapsulated in water-in-oil emulsions in a microchannel. The flow field of a microfluidic channel is coupled to the internal flow field of a droplet through viscous traction at the interface, resulting in a rotational flow field inside the droplet. An encapsulated single cell being subjected to this flow field responds by undergoing multiple orbits, spins, and deformations that depend on its physical properties. Monitoring the cell dynamics, using a high-speed camera, can lead to the development of new label-free methods for the detection of rare cells, based on their biomechanical properties. A sheath flow microchannel was proposed to strengthen the rotational flow field inside droplets flowing in Poiseuille flow conditions. A numerical model was developed to investigate the effect of various parameters on the rotational flow field inside a droplet. The multi-phase flow model required the tracking of the fluid–fluid interface, which deforms over time due to the applied shear stresses. Experiments confirmed the significant effect of the sheath flow rate on the cell dynamics, where the speed of cell orbiting was doubled. Doubling the cell speed can double the amount of extracted biomechanical information from the encapsulated cell, while it remains within the field of view of the camera used. Full article
(This article belongs to the Special Issue Droplet-Based Microfluidic Devices)
Show Figures

Graphical abstract

Article
ASimOV: A Framework for Simulation and Optimization of an Embedded AI Accelerator
Micromachines 2021, 12(7), 838; https://doi.org/10.3390/mi12070838 - 19 Jul 2021
Viewed by 183
Abstract
Artificial intelligence algorithms need an external computing device such as a graphics processing unit (GPU) due to computational complexity. For running artificial intelligence algorithms in an embedded device, many studies proposed light-weighted artificial intelligence algorithms and artificial intelligence accelerators. In this paper, we [...] Read more.
Artificial intelligence algorithms need an external computing device such as a graphics processing unit (GPU) due to computational complexity. For running artificial intelligence algorithms in an embedded device, many studies proposed light-weighted artificial intelligence algorithms and artificial intelligence accelerators. In this paper, we propose the ASimOV framework, which optimizes artificial intelligence algorithms and generates Verilog hardware description language (HDL) code for executing intelligence algorithms in field programmable gate array (FPGA). To verify ASimOV, we explore the performance space of k-NN algorithms and generate Verilog HDL code to demonstrate the k-NN accelerator in FPGA. Our contribution is to provide the artificial intelligence algorithm as an end-to-end pipeline and ensure that it is optimized to a specific dataset through simulation, and an artificial intelligence accelerator is generated in the end. Full article
(This article belongs to the Special Issue Smart Embedded Processors)
Show Figures

Figure 1

Review
Electrochemical Cell-Based Sensor for Detection of Food Hazards
Micromachines 2021, 12(7), 837; https://doi.org/10.3390/mi12070837 - 18 Jul 2021
Viewed by 323
Abstract
People’s health has been threatened by several common food hazards. Thus, it is very important to establish rapid and accurate methods to detect food hazards. In recent years, biosensors have inspired developments because of their specificity and sensitivity, short reaction time, low cost, [...] Read more.
People’s health has been threatened by several common food hazards. Thus, it is very important to establish rapid and accurate methods to detect food hazards. In recent years, biosensors have inspired developments because of their specificity and sensitivity, short reaction time, low cost, small size and easy operation. Owing to their high precision and non-destructive characteristics, cell-based electrochemical detection methods can reflect the damage of food hazards to organisms better. In this review, the characteristics of electrochemical cell-based biosensors and their applications in the detection of common hazards in food are reviewed. The strategies of cell immobilization and 3D culture on electrodes are discussed. The current limitations and further development prospects of cell-based electrochemical biosensors are also evaluated. Full article
(This article belongs to the Special Issue Electrochemical Sensors in Biological Applications)
Show Figures

Figure 1

Article
Flow of Non-Newtonian Fluids in a Single-Cavity Microchannel
Micromachines 2021, 12(7), 836; https://doi.org/10.3390/mi12070836 - 18 Jul 2021
Viewed by 288
Abstract
Having a basic understanding of non-Newtonian fluid flow through porous media, which usually consist of series of expansions and contractions, is of importance for enhanced oil recovery, groundwater remediation, microfluidic particle manipulation, etc. The flow in contraction and/or expansion microchannel is unbounded in [...] Read more.
Having a basic understanding of non-Newtonian fluid flow through porous media, which usually consist of series of expansions and contractions, is of importance for enhanced oil recovery, groundwater remediation, microfluidic particle manipulation, etc. The flow in contraction and/or expansion microchannel is unbounded in the primary direction and has been widely studied before. In contrast, there has been very little work on the understanding of such flow in an expansion–contraction microchannel with a confined cavity. We investigate the flow of five types of non-Newtonian fluids with distinct rheological properties and water through a planar single-cavity microchannel. All fluids are tested in a similarly wide range of flow rates, from which the observed flow regimes and vortex development are summarized in the same dimensionless parameter spaces for a unified understanding of the effects of fluid inertia, shear thinning, and elasticity as well as confinement. Our results indicate that fluid inertia is responsible for developing vortices in the expansion flow, which is trivially affected by the confinement. Fluid shear thinning causes flow separations on the contraction walls, and the interplay between the effects of shear thinning and inertia is dictated by the confinement. Fluid elasticity introduces instability and asymmetry to the contraction flow of polymers with long chains while suppressing the fluid inertia-induced expansion flow vortices. However, the formation and fluctuation of such elasto-inertial fluid vortices exhibit strong digressions from the unconfined flow pattern in a contraction–expansion microchannel of similar dimensions. Full article
(This article belongs to the Special Issue X-fluidics at the Micro/Nanoscale)
Show Figures

Figure 1

Article
Improvement of p-Type AlGaN Conductivity with an Alternating Mg-Doped/Un-Doped AlGaN Layer Structure
Micromachines 2021, 12(7), 835; https://doi.org/10.3390/mi12070835 - 18 Jul 2021
Viewed by 329
Abstract
Using molecular beam epitaxy, we prepared seven p-type AlGaN samples of ~25% in Al content, including six samples with Mg-doped/un-doped AlGaN alternating-layer structures of different layer-thickness combinations, for comparing their p-type performances. Lower sheet resistance and higher effective hole mobility are obtained in [...] Read more.
Using molecular beam epitaxy, we prepared seven p-type AlGaN samples of ~25% in Al content, including six samples with Mg-doped/un-doped AlGaN alternating-layer structures of different layer-thickness combinations, for comparing their p-type performances. Lower sheet resistance and higher effective hole mobility are obtained in a layer-structured sample, when compared with the reference sample of uniform Mg doping. The improved p-type performance in a layer-structured sample is attributed to the diffusion of holes generated in an Mg-doped layer into the neighboring un-doped layers, in which hole mobility is significantly higher because of weak ionized impurity scattering. Among the layer-structured samples, that of 6/4 nm in Mg-doped/un-doped thickness results in the lowest sheet resistance (the highest effective hole mobility), which is 4.83 times lower (4.57 times higher) when compared with the sample of uniform doping. The effects of the Mg-doped/un-doped layer structure on p-type performance in AlGaN and GaN are compared. Full article
Show Figures

Figure 1

Article
Power Dissipation of an Inductively Coupled Plasma Torch under E Mode Dominated Regime
Micromachines 2021, 12(7), 834; https://doi.org/10.3390/mi12070834 - 18 Jul 2021
Viewed by 291
Abstract
This paper focuses on the power dissipation of a plasma torch used for an optical surface fabrication process. The process utilizes an inductively coupled plasma (ICP) torch that is equipped with a De-Laval nozzle for the delivery of a highly collimated plasma jet. [...] Read more.
This paper focuses on the power dissipation of a plasma torch used for an optical surface fabrication process. The process utilizes an inductively coupled plasma (ICP) torch that is equipped with a De-Laval nozzle for the delivery of a highly collimated plasma jet. The plasma torch makes use of a self-igniting coil and an intermediate co-axial tube made of alumina. The torch has a distinctive thermal and electrical response compared to regular ICP torches. In this study, the results of the power dissipation investigation reveal the true efficiency of the torch and discern its electrical response. By systematically measuring the coolant parameters (temperature change and flow rate), the power dissipation is extrapolated. The radio frequency power supply is set to 800 W, E mode, throughout the research presented in this study. The analytical results of power dissipation, derived from the experiments, show that 15.4% and 33.3% are dissipated by the nozzle and coil coolant channels, respectively. The experiments also enable the determination of the thermal time constant of the plasma torch for the entire range of RF power. Full article
(This article belongs to the Special Issue Feature Papers of Micromachines in Materials and Processing 2021)
Show Figures

Figure 1

Article
Numerical Analysis of Space Deployable Structure Based on Shape Memory Polymers
Micromachines 2021, 12(7), 833; https://doi.org/10.3390/mi12070833 - 17 Jul 2021
Viewed by 303
Abstract
Shape memory polymers (SMPs) have been applied in aerospace engineering as deployable space structures. In this work, the coupled finite element method (FEM) was established based on the generalized Maxwell model and the time–temperature equivalence principle (TTEP). The thermodynamic behavior and shape memory [...] Read more.
Shape memory polymers (SMPs) have been applied in aerospace engineering as deployable space structures. In this work, the coupled finite element method (FEM) was established based on the generalized Maxwell model and the time–temperature equivalence principle (TTEP). The thermodynamic behavior and shape memory effects of a single-arm deployment structure (F-DS) and four-arm deployment structure (F-DS) based on SMPs were analyzed using the coupled FEM. Good consistency was obtained between the experimental data and simulation data for the tensile and S-DS recovery forces, verifying that the coupled FEM can accurately and reliably describe the thermodynamic behavior and shape memory effects of the SMP structure. The step-by-step driving structure is suitable for use as a large-scale deployment structure in space. This coupled FEM provides a new direction for future research on epoxy SMPs. Full article
Show Figures

Figure 1

Article
An In Vivo Microfluidic Study of Bacterial Load Dynamics and Absorption in the C. elegans Intestine
Micromachines 2021, 12(7), 832; https://doi.org/10.3390/mi12070832 - 17 Jul 2021
Viewed by 327
Abstract
Caenorhabditiselegans (C. elegans) has gained importance as a model for studying host-microbiota interactions and bacterial infections related to human pathogens. Assessing the fate of ingested bacteria in the worm’s intestine is therefore of great interest, in particular with respect to [...] Read more.
Caenorhabditiselegans (C. elegans) has gained importance as a model for studying host-microbiota interactions and bacterial infections related to human pathogens. Assessing the fate of ingested bacteria in the worm’s intestine is therefore of great interest, in particular with respect to normal bacterial digestion or intestinal colonization by pathogens. Here, we report an in vivo study of bacteria in the gut of C. elegans. We take advantage of a polydimethylsiloxane (PDMS) microfluidic device enabling passive immobilization of adult worms under physiological conditions. Non-pathogenic Escherichia coli (E. coli) bacteria expressing either pH-sensitive or pH-insensitive fluorescence reporters as well as fluorescently marked indigestible microbeads were used for the different assays. Dynamic fluorescence patterns of the bacterial load in the worm gut were conveniently monitored by time-lapse imaging. Cyclic motion of the bacterial load due to peristaltic activity of the gut was observed and biochemical digestion of E. coli was characterized by high-resolution fluorescence imaging of the worm’s intestine. We could discriminate between individual intact bacteria and diffuse signals related to disrupted bacteria that can be digested. From the decay of the diffuse fluorescent signal, we determined a digestion time constant of 14 ± 4 s. In order to evaluate the possibility to perform infection assays with our platform, immobilized C. elegans worms were fed pathogenic Mycobacterium marinum (M. marinum) bacteria. We analyzed bacterial fate and accumulation in the gut of N2 worms and mitochondrial stress response in a hsp-6::gfp mutant. Full article
(This article belongs to the Special Issue Organisms-on-Chips)
Show Figures

Figure 1

Article
A Miniature Four-Channel Ion Trap Array Based on Non-silicon MEMS Technology
Micromachines 2021, 12(7), 831; https://doi.org/10.3390/mi12070831 - 16 Jul 2021
Viewed by 253
Abstract
With the increasing application field, a higher requirement is put forward for the mass spectrometer. The reduction in size will inevitably cause a loss of precision; therefore, it is necessary to develop a high-performance miniature mass spectrometer. Based on the researches of rectangular [...] Read more.
With the increasing application field, a higher requirement is put forward for the mass spectrometer. The reduction in size will inevitably cause a loss of precision; therefore, it is necessary to develop a high-performance miniature mass spectrometer. Based on the researches of rectangular ion trap, the relationship between mass resolution and structural parameters of the ion trap array was analyzed by further simulation. The results indicate that, considering the balance of mass resolution and extraction efficiency, the preferable values for the field radius of exit direction y0 and ion exit slot width s0 are 1.61 mm and 200 μm, respectively. Afterwards, a miniature four-channel ion trap array (MFITA) was fabricated, by using MEMS and laser etching technology, and mass spectrometry experiments were carried out to demonstrate its performance. The mass resolution of butyl diacetate with m/z = 230 can reach 324. In addition, the consistency of four channels is verified within the error tolerance, by analyzing air samples. Our work can prove the correctness of the structural design and the feasibility of MEMS preparation for MFITA, which will bring meaningful guidance for its future development and optimization. Full article
(This article belongs to the Special Issue MEMS/NEMS Sensors: Fabrication and Application, Volume III)
Show Figures

Figure 1

Article
A Study on the Energy-Harvesting Device with a Magnetic Spring for Improved Durability in High-Speed Trains
Micromachines 2021, 12(7), 830; https://doi.org/10.3390/mi12070830 - 16 Jul 2021
Viewed by 242
Abstract
Durability is a critical issue concerning energy-harvesting devices. Despite the energy-harvesting device’s excellent performance, moving components, such as the metal spring, can be damaged during operation. To solve the durability problem of the metal spring in a vibration-energy-harvesting (VEH) device, this study applied [...] Read more.
Durability is a critical issue concerning energy-harvesting devices. Despite the energy-harvesting device’s excellent performance, moving components, such as the metal spring, can be damaged during operation. To solve the durability problem of the metal spring in a vibration-energy-harvesting (VEH) device, this study applied a non-contact magnetic spring to a VEH device using the repulsive force of permanent magnets. A laboratory experiment was conducted to determine the potential energy-harvesting power using the magnetic spring VEH device. In addition, the characteristics of the generated power were studied using the magnetic spring VEH device in a high-speed train traveling at 300 km/h. Through the high-speed train experiment, the power generated by both the metal spring VEH device and magnetic spring VEH device was measured, and the performance characteristics required for a power source for wireless sensor nodes in high-speed trains are discussed. Full article
(This article belongs to the Special Issue Advanced Energy Conversion and Storage Microdevices)
Show Figures

Figure 1

Article
In Situ Construction of ZnO/Ni2S3 Composite on Ni Foam by Combing Potentiostatic Deposition with Cyclic Voltammetric Electrodeposition
Micromachines 2021, 12(7), 829; https://doi.org/10.3390/mi12070829 - 16 Jul 2021
Viewed by 287
Abstract
The ZnO/Ni2S3 composite has been designed and in situ synthesized on Ni foam substrate by two steps of electrodeposition. ZnO was achieved on Ni foam by a traditional potentiostatic deposition, followed by cyclic voltammetric (CV) electrodeposition, to generate Ni2 [...] Read more.
The ZnO/Ni2S3 composite has been designed and in situ synthesized on Ni foam substrate by two steps of electrodeposition. ZnO was achieved on Ni foam by a traditional potentiostatic deposition, followed by cyclic voltammetric (CV) electrodeposition, to generate Ni2S3, where the introduction of ZnO provides abundant active sites for the subsequent Ni2S3 electrodeposition. The amount of deposit during CV electrodeposition can be adjusted by setting the number of sweep segment and scan rate, and the electrochemical characteristics of the products can be readily optimized. The synergistic effect between the ZnO as backbones and the deposited Ni2S3 as the shell enhances the electrochemical properties of the sample significantly, including a highly specific capacitance of 2.19 F cm−2 at 2 mA cm−2, good coulombic efficiency of 98%, and long-term cyclic stability at 82.35% (4000 cycles). Full article
Show Figures

Graphical abstract

Article
Analysis of Multi-Physics Coupling of Small Holes in GH4169 Alloy by Electrolytic Processing of Tube Electrodes
Micromachines 2021, 12(7), 828; https://doi.org/10.3390/mi12070828 - 15 Jul 2021
Viewed by 265
Abstract
This paper presents a simulation and experimental study of the structure of small holes in GH4169 alloy electrolytic ally processed by tube electrodes with different characteristic power sources. It analyzes the multi-physical field coupling relationship of flow, temperature, and electric fields within the [...] Read more.
This paper presents a simulation and experimental study of the structure of small holes in GH4169 alloy electrolytic ally processed by tube electrodes with different characteristic power sources. It analyzes the multi-physical field coupling relationship of flow, temperature, and electric fields within the interstitial space. The results indicate that the tube electrode electrolytic processing of the GH4169 alloy small hole structure with a pulsed power supply has more uniform temperature and current density distribution within the gap, which is beneficial to the processing accuracy and smoothness of the small hole structure. Meanwhile, SEM was used to analyze the microscopic morphology of the electrode end surface during short-circuiting, and it was concluded that as the processing continued, the electrode end surface gradually produced a non-metallic oxide layer, which destroyed the electric field of the gap and affected the processing stability. The use of high-frequency positive and negative pulse power can effectively avoid the generation of a non-metallic oxide layer. Through the combination of simulation analysis and experimental verification, it is concluded that increasing electrolyte pressure in stages can effectively improve machining accuracy and stability. The interstitial current increases as the feed rate of the tool electrode increases, and the diameter of the machined small hole decreases as it increases. Full article
(This article belongs to the Special Issue Electrochemical Manufacturing Processes)
Show Figures

Figure 1

Article
Simulation Analysis of Cluster Effect of High-Shear Low-Pressure Grinding with Flexible Abrasive Tools
Micromachines 2021, 12(7), 827; https://doi.org/10.3390/mi12070827 - 15 Jul 2021
Viewed by 276
Abstract
Based on the clustering effect of shear-thickening fluids (STFs), a high-shear low-pressure flexible grinding wheel has been developed. In order to explore the material removal mechanism, the coupled Eulerian—Lagrangian (CEL) method is adopted to simulate the novel grinding process. The simulation results show [...] Read more.
Based on the clustering effect of shear-thickening fluids (STFs), a high-shear low-pressure flexible grinding wheel has been developed. In order to explore the material removal mechanism, the coupled Eulerian—Lagrangian (CEL) method is adopted to simulate the novel grinding process. The simulation results show that particle clustering effects do occur at the tangential and bottom positions of the micro-convex peak when it instantaneously strikes the workpiece surface. The particle clusters drive the harder abrasive particles to resist the strong interactions of micro-convex peaks. The micro-convex peaks are removed due to the cutting effect of the harder abrasive particles. Compared with traditional grinding, the ratio of tangential force to normal force for the high-shear low-pressure flexible grinding wheel is improved. The various trends in force ratio are consistent with the experimental results, which verifies the effectiveness of high-shear low-pressure grinding. Full article
(This article belongs to the Special Issue Frontiers in Ultra-Precision Machining)
Show Figures

Figure 1

Review
Microfluidics-Based Plasmonic Biosensing System Based on Patterned Plasmonic Nanostructure Arrays
Micromachines 2021, 12(7), 826; https://doi.org/10.3390/mi12070826 - 14 Jul 2021
Viewed by 328
Abstract
This review aims to summarize the recent advances and progress of plasmonic biosensors based on patterned plasmonic nanostructure arrays that are integrated with microfluidic chips for various biomedical detection applications. The plasmonic biosensors have made rapid progress in miniaturization sensors with greatly enhanced [...] Read more.
This review aims to summarize the recent advances and progress of plasmonic biosensors based on patterned plasmonic nanostructure arrays that are integrated with microfluidic chips for various biomedical detection applications. The plasmonic biosensors have made rapid progress in miniaturization sensors with greatly enhanced performance through the continuous advances in plasmon resonance techniques such as surface plasmon resonance (SPR) and localized SPR (LSPR)-based refractive index sensing, SPR imaging (SPRi), and surface-enhanced Raman scattering (SERS). Meanwhile, microfluidic integration promotes multiplexing opportunities for the plasmonic biosensors in the simultaneous detection of multiple analytes. Particularly, different types of microfluidic-integrated plasmonic biosensor systems based on versatile patterned plasmonic nanostructured arrays were reviewed comprehensively, including their methods and relevant typical works. The microfluidics-based plasmonic biosensors provide a high-throughput platform for the biochemical molecular analysis with the advantages such as ultra-high sensitivity, label-free, and real time performance; thus, they continue to benefit the existing and emerging applications of biomedical studies, chemical analyses, and point-of-care diagnostics. Full article
(This article belongs to the Special Issue Micro-Nano Science and Engineering)
Show Figures

Figure 1

Article
Microfluidic Airborne Metal Particle Sensor Using Oil Microcirculation for Real-Time and Continuous Monitoring of Metal Particle Emission
Micromachines 2021, 12(7), 825; https://doi.org/10.3390/mi12070825 - 14 Jul 2021
Viewed by 388
Abstract
Airborne metal particles (MPs; particle size > 10 μm) in workplaces result in a loss in production yield if not detected in time. The demand for compact and cost-efficient MP sensors to monitor airborne MP generation is increasing. However, contemporary instruments and laboratory-grade [...] Read more.
Airborne metal particles (MPs; particle size > 10 μm) in workplaces result in a loss in production yield if not detected in time. The demand for compact and cost-efficient MP sensors to monitor airborne MP generation is increasing. However, contemporary instruments and laboratory-grade sensors exhibit certain limitations in real-time and on-site monitoring of airborne MPs. This paper presents a microfluidic MP detection chip to address these limitations. By combining the proposed system with microcirculation-based particle-to-liquid collection and a capacitive sensing method, the continuous detection of airborne MPs can be achieved. A few microfabrication processes were realized, resulting in a compact system, which can be easily replaced after contamination with a low-priced microfluidic chip. In our experiments, the frequency-dependent capacitive changes were characterized using MP (aluminum) samples (sizes ranging from 10 μm to 40 μm). Performance evaluation of the proposed system under test-bed conditions indicated that it is capable of real-time and continuous monitoring of airborne MPs (minimum size 10 μm) under an optimal frequency, with superior sensitivity and responsivity. Therefore, the proposed system can be used as an on-site MP sensor for unexpected airborne MP generation in precise manufacturing facilities where metal sources are used. Full article
(This article belongs to the Special Issue MEMS/NEMS Sensors and Actuators)
Show Figures

Figure 1

Article
Development of a Rotary Ultrasonic Motor with Double-Sided Staggered Teeth
Micromachines 2021, 12(7), 824; https://doi.org/10.3390/mi12070824 - 14 Jul 2021
Viewed by 317
Abstract
Based on the conventional structure of traveling wave ultrasonic motor, a rotary ultrasonic motor with double-sided staggered teeth was proposed. Both sides of the stator could be used to actuate the rotors to rotate and output torque. Moreover, the staggered teeth in the [...] Read more.
Based on the conventional structure of traveling wave ultrasonic motor, a rotary ultrasonic motor with double-sided staggered teeth was proposed. Both sides of the stator could be used to actuate the rotors to rotate and output torque. Moreover, the staggered teeth in the stator could be dedicated to accommodating the piezoelectric ceramic chips. Under the excitation of two alternating voltages with a 90° phase difference, a traveling wave could be generated in the ring-like stator. Then, a rotary motion could be realized by means of the friction between the rotors and the driving teeth of the stator. The finite element method was adopted to analyze the motion trajectories of the driving tips. Moreover, the experimental results showed that the load-free maximum speed and maximum output torque of the prototype were 99 rpm and 0.19 N·m at a voltage of 150 Vp with a frequency of 28.25 kHz. Full article
Show Figures

Figure 1

Article
Folded Heterogeneous Silicon and Lithium Niobate Mach–Zehnder Modulators with Low Drive Voltage
Micromachines 2021, 12(7), 823; https://doi.org/10.3390/mi12070823 - 14 Jul 2021
Viewed by 270
Abstract
Optical modulators were, are, and will continue to be the underpinning devices for optical transceivers at all levels of the optical networks. Recently, heterogeneously integrated silicon and lithium niobate (Si/LN) optical modulators have demonstrated attractive overall performance in terms of optical loss, drive [...] Read more.
Optical modulators were, are, and will continue to be the underpinning devices for optical transceivers at all levels of the optical networks. Recently, heterogeneously integrated silicon and lithium niobate (Si/LN) optical modulators have demonstrated attractive overall performance in terms of optical loss, drive voltage, and modulation bandwidth. However, due to the moderate Pockels coefficient of lithium niobate, the device length of the Si/LN modulator is still relatively long for low-drive-voltage operation. Here, we report a folded Si/LN Mach–Zehnder modulator consisting of meandering optical waveguides and meandering microwave transmission lines, whose device length is approximately two-fifths of the unfolded counterpart while maintaining the overall performance. The present devices feature a low half-wave voltage of 1.24 V, support data rates up to 128 gigabits per second, and show a device length of less than 9 mm. Full article
(This article belongs to the Special Issue Photonic Chips for Optical Communications)
Show Figures

Figure 1

Article
Fabrication of Stromal Cell-Derived Factor-1 Contained in Gelatin/Hyaluronate Copo006Cymer Mixed with Hydroxyapatite for Use in Traumatic Bone Defects
Micromachines 2021, 12(7), 822; https://doi.org/10.3390/mi12070822 - 14 Jul 2021
Viewed by 263
Abstract
Bone defects of orthopedic trauma remain a challenge in clinical practice. Regarding bone void fillers, besides the well-known osteoconductivity of most bone substitutes, osteoinductivity has also been gaining attention in recent years. It is known that stromal cell-derived factor-1 (SDF-1) can recruit mesenchymal [...] Read more.
Bone defects of orthopedic trauma remain a challenge in clinical practice. Regarding bone void fillers, besides the well-known osteoconductivity of most bone substitutes, osteoinductivity has also been gaining attention in recent years. It is known that stromal cell-derived factor-1 (SDF-1) can recruit mesenchymal stem cells (MSCs) in certain circumstances, which may also play an important role in bone regeneration. In this study, we fabricated a gelatin/hyaluronate (Gel/HA) copolymer mixed with hydroxyapatite (HAP) and SDF-1 to try and enhance bone regeneration in a bone defect model. After material characterization, these Gel/HA–HAP and Gel/HA–HAP–SDF-1 composites were tested for their biocompatibility and ability to recruit MSCs in vitro. A femoral condyle bone defect model of rats was used for in vivo studies. For the assessment of bone healing, micro-CT analysis, second harmonic generation (SHG) imaging, and histology studies were performed. As a result, the Gel/HA–HAP composites showed no systemic toxicity to rats. Gel/HA–HAP composite groups both showed better bone generation compared with the control group in an animal study, and the composite with the SDF-1 group even showed a trend of faster bone growth compared with the composite without SDF-1 group. In conclusion, in the management of traumatic bone defects, Gel/HA–HAP–SDF-1 composites can be a feasible material for use as bone void fillers. Full article
(This article belongs to the Special Issue 3D In Vitro Tissue and Organ Models)
Show Figures

Figure 1

Article
A Flexible a-SiC-Based Neural Interface Utilizing Pyrolyzed-Photoresist Film (C) Active Sites
Micromachines 2021, 12(7), 821; https://doi.org/10.3390/mi12070821 - 13 Jul 2021
Viewed by 407
Abstract
Carbon containing materials, such as graphene, carbon-nanotubes (CNT), and graphene oxide, have gained prominence as possible electrodes in implantable neural interfaces due to their excellent conductive properties. While carbon is a promising electrochemical interface, many fabrication processes are difficult to perform, leading to [...] Read more.
Carbon containing materials, such as graphene, carbon-nanotubes (CNT), and graphene oxide, have gained prominence as possible electrodes in implantable neural interfaces due to their excellent conductive properties. While carbon is a promising electrochemical interface, many fabrication processes are difficult to perform, leading to issues with large scale device production and overall repeatability. Here we demonstrate that carbon electrodes and traces constructed from pyrolyzed-photoresist-film (PPF) when combined with amorphous silicon carbide (a-SiC) insulation could be fabricated with repeatable processes which use tools easily available in most semiconductor facilities. Directly forming PPF on a-SiC simplified the fabrication process which eliminates noble metal evaporation/sputtering and lift-off processes on small features. PPF electrodes in oxygenated phosphate buffered solution at pH 7.4 demonstrated excellent electrochemical charge storage capacity (CSC) of 14.16 C/cm2, an impedance of 24.8 ± 0.4 kΩ, and phase angle of −35.9 ± 0.6° at 1 kHz with a 1.9 kµm2 recording site area. Full article
(This article belongs to the Special Issue Implantable Neural Interfaces)
Show Figures

Figure 1

Review
Membrane Fouling Phenomena in Microfluidic Systems: From Technical Challenges to Scientific Opportunities
Micromachines 2021, 12(7), 820; https://doi.org/10.3390/mi12070820 - 13 Jul 2021
Viewed by 426
Abstract
The almost ubiquitous, though undesired, deposition and accumulation of suspended/dissolved matter on solid surfaces, known as fouling, represents a crucial issue strongly affecting the efficiency and sustainability of micro-scale reactors. Fouling becomes even more detrimental for all the applications that require the use [...] Read more.
The almost ubiquitous, though undesired, deposition and accumulation of suspended/dissolved matter on solid surfaces, known as fouling, represents a crucial issue strongly affecting the efficiency and sustainability of micro-scale reactors. Fouling becomes even more detrimental for all the applications that require the use of membrane separation units. As a matter of fact, membrane technology is a key route towards process intensification, having the potential to replace conventional separation procedures, with significant energy savings and reduced environmental impact, in a broad range of applications, from water purification to food and pharmaceutical industries. Despite all the research efforts so far, fouling still represents an unsolved problem. The complex interplay of physical and chemical mechanisms governing its evolution is indeed yet to be fully unraveled and the role played by foulants’ properties or operating conditions is an area of active research where microfluidics can play a fundamental role. The aim of this review is to explore fouling through microfluidic systems, assessing the fundamental interactions involved and how microfluidics enables the comprehension of the mechanisms characterizing the process. The main mathematical models describing the fouling stages will also be reviewed and their limitations discussed. Finally, the principal dynamic investigation techniques in which microfluidics represents a key tool will be discussed, analyzing their employment to study fouling. Full article
(This article belongs to the Special Issue Micro-Reaction Engineering)
Show Figures

Figure 1

Review
A Survey on Battery-Less RFID-Based Wireless Sensors
Micromachines 2021, 12(7), 819; https://doi.org/10.3390/mi12070819 - 13 Jul 2021
Viewed by 394
Abstract
We present a survey on battery-less Radio Frequency Identification (RFID-based wireless sensors that have emerged in the past several years. We discuss the evolution of RFID turning into wireless sensors. Moreover, we talk about different components of these battery-less RFID-based wireless sensors, five [...] Read more.
We present a survey on battery-less Radio Frequency Identification (RFID-based wireless sensors that have emerged in the past several years. We discuss the evolution of RFID turning into wireless sensors. Moreover, we talk about different components of these battery-less RFID-based wireless sensors, five main topologies that transform a simple RFID chip into a battery-less wireless sensor, and state-of-the-art implementations of these topologies. In battery-less wireless sensors, the read range is of key importance. Hence, we discuss how each component of the sensor plays its role in determining the read range and how each topology exploits these components to optimize read range, complexity, and/or cost. Additionally, we discuss potential future directions that can help provide improvements in RFID-based wireless sensor technology. Full article
(This article belongs to the Special Issue Next Generation RFID Transponders)
Show Figures

Figure 1

Previous Issue
Next Issue
Back to TopTop
