Driven by carbon neutrality and peak carbon policies, hydrogen energy, due to its zero-emission and renewable properties, is increasingly being used in hydrogen fuel cell vehicles (H-FCVs). However, the high cost and limited durability of H-FCVs hinder large-scale deployment. Hydrogen internal combustion engine hybrid electric vehicles (H-HEVs) are emerging as a viable alternative. Research on the techno-economics of H-HEVs remains limited, particularly in systematic comparisons with H-FCVs. This paper provides a comprehensive comparison of H-FCVs and H-HEVs in terms of total cost of ownership (TCO) and hydrogen consumption while proposing a multi-objective powertrain parameter optimization model. First, a quantitative model evaluates TCO from vehicle purchase to disposal. Second, a global dynamic programming method optimizes hydrogen consumption by incorporating cumulative energy costs into the TCO model. Finally, a genetic algorithm co-optimizes key design parameters to minimize TCO. Results show that with a battery capacity of 20.5 Ah and an H-FC peak power of 55 kW, H-FCV can achieve optimal fuel economy and hydrogen consumption. However, even with advanced technology, their TCO remains higher than that of H-HEVs. H-FCVs can only become cost-competitive if the unit power price of the fuel cell system is less than 4.6 times that of the hydrogen engine system, assuming negligible fuel cell degradation. In the short term, H-HEVs should be prioritized. Their adoption can also support the long-term development of H-FCVs through a complementary relationship. Full article

Polymer electrolyte membrane fuel cells (PEMFCs) are emerging as the next-generation powertrain for unmanned aerial vehicles (UAVs) due to their high energy density and long operating duration. PEMFCs are subject to icing and performance degradation problems at sub-zero temperatures, especially at high altitudes. Therefore, an effective preheating system is required to ensure stable PEMFC operation in high-altitude environments. This study aimed to mathematically model a shell-and-tube heat exchanger that utilizes waste heat recovery to prevent internal and external PEMFC damage in cold, high-altitude conditions. The waste heat from the PEMFC is estimated based on the thrust of the MQ-9 Reaper, and the proposed heat exchanger must be capable of heating air to −5 °C. As the heat exchanger utilizes only waste heat, the primary energy consumption arises from the coolant pumping process. Calculation results indicated that the proposed heat exchanger design improved the overall system efficiency by up to 15.7%, demonstrating its effectiveness in utilizing waste heat under aviation conditions. Full article

Electric vertical take-off and landing vehicles introduce challenges in powertrain design with short but high peak loads and low-load phases over longer periods of time during wing-borne flight. In this paper, three powertrain topologies are analyzed for a tilt-rotor urban air mobility vehicle with an expected entry into service after 2030. The powertrains are studied on the level of preliminary sizing for the design mission of the vehicle. The three powertrain topologies studied and compared are battery-only, fuel cell-only and a hybrid of the two energy sources. Parameter studies on the gearbox transmission ratio, the design point of the fuel cell system as well as the degree of hybridization were carried out. The combination of fuel cell and battery was found to be most beneficial in terms of mass when the fuel cell is sized for slightly more than cruise power. In flight phases with higher power requirements, the batteries would provide the additional boost. Full article

In this paper, a methodology for selecting the Energy Management Strategy (EMS) that best suits a heavy-duty Fuel Cell Electric Vehicle (FCEV) operating under specific conditions along a given driving cycle is proposed. Using a simulation model that incorporates the powertrain architecture and components of a specific FCEV—validated through a more detailed model operating at the power converter switching level—the performance of the entire system can be tested under different EMSs. The multicriteria evaluation system developed in this study enables the calculation of hydrogen and energy consumption, as well as the aging of the battery and fuel cell associated with each EMS. The proposed methodology serves as an evaluation tool for both the dimensioning of powertrain components and the selection of the EMS that best meets the operational requirements of a given FCEV. Results demonstrate that applying this methodology to a use case tailored for commercial devices and a standard driving cycle enables the identification of the most suitable EMS, minimizing hydrogen and energy consumption while reducing battery and fuel cell aging. Full article

Electric vehicle thermal management systems have in the last two decades grown to become complex systems. This development has come as a response to the unique challenges faced by electrified powertrains, particularly the driving range reduction in cold climate operation. The rapid increase in complexity makes the systems harder to design, control, and evaluate, and consequently, a need for systematic analysis and design tools has emerged. The key contribution of this work is a model-based simulation tool developed to enable the combined evaluation and control of state-of-the-art thermal management systems. To show how engineers may use the tool to solve industrially relevant problems, two simulation case studies are performed and presented. The first case study compares three thermal management system layouts of increasing complexity and shows how their performance varies as ambient temperature decreases. The second case study concerns the potential benefits of additional cooling radiators for fuel cell trucks under heavy load in hot climates. Full article

Separate DC-DC converters for each energy source are typically configured in fuel-cell hybrid vehicles. This results in a complex control structure of the powertrain system, low energy density of the converter, and high cost due to the large number of components. Conducting research on DC-DC converters with good energy flow management and high integration is a trend to solve such problems. Based on the analysis of the basic functional structure of the converter, this paper designs a buffering unit circuit with energy collection and distribution functions and appropriately connects it with the pulse unit circuit of the converter. Through device optimization reuse and power transmission path integration, a class of non-isolated four-port DC-DC converters is constructed, which consists of an auxiliary energy charging module, input energy source control module, braking energy feedback module and forward bootstrap boost circuit. This converter has two bi-directional ports, a uni-directional input and a bi-directional output, for separate connection to the power batteries, supercapacitors, fuel cells and DC bus. It can adapt to the fluctuation of the vehicle’s driving condition while achieving dynamic and flexible regulation of power flow and can flexibly allocate power according to the load current and voltage level of energy. It can realize a total of 14 operation modes, including six output power supply operation modes, five auxiliary power charging operation modes, and three braking energy regeneration operation modes. Furthermore, the mathematical model of this converter is constructed using the state-average method and the small-signal modeling method in order to achieve the responsiveness and stability of switching multiple operating modalities. The PI control parameters are optimized using the particle swarm optimization algorithm to achieve optimized control of the converter. The simulation system is set up using MATLAB R2024a to verify that the proposed converter topology and algorithm can dynamically allocate appropriate current paths to manipulate the power flow under various operating conditions, effectively improving the utilization rate and efficiency of energy. The converter has the characteristics of high gain and high power density, which is suitable for three-energy fuel cell hybrid electric vehicles. Full article

Rising greenhouse gas emissions stemming from road transport have intensified the need for efficient and environmentally friendly propulsion technologies. Hybrid and fuel cell electric vehicles have emerged as a viable solution, integrating internal combustion engines and fuel cells with electric motors to optimize fuel efficiency and reduce emissions. This article reviews and analyzes energy management strategies for the principal powertrain topologies of hybrid electric vehicles, focusing on achieving solution optimality in real-time applications. A thorough and comprehensive overview of rule-based, optimization-based, and learning-based energy management strategies is presented, highlighting their main attributes and providing a comparative analysis in terms of fuel economy improvements, real-time implementation feasibility, and computational complexity, while simultaneously identifying and uncovering areas requiring further research in the field. We found that while rule-based methods offer simplicity and real-time capability, their adaptability remains limited. Optimization-based and learning-based approaches, although often achieving near-optimal solutions, face challenges due to their high computational demands and integration complexities. Our analysis also revealed the importance of leveraging vehicle connectivity and intelligent transportation systems for future energy management developments, which will contribute to broader sustainability goals in the automotive sector. Full article

Reducing reliance on fossil fuels has driven the development of innovative technologies in recent years due to the increasing levels of greenhouse gases in the atmosphere. Since the automotive industry is one of the main contributors of high CO₂ emissions, the introduction of more sustainable solutions in this sector is fundamental. This paper presents a novel energy management system for fuel cell hybrid electric vehicles based on dynamic programming and adaptive neuro fuzzy inference system methodologies to optimize energy distribution between battery and fuel cell, therefore enhancing powertrain efficiency and reducing hydrogen consumption. Three different approaches have been considered for performance assessment through a simulation platform developed in MATLAB/Simulink 2023a. Further validation has been conducted via a rapid control prototyping device, showcasing significant improvements in hydrogen usage and operational efficiency across different drive cycles. Results manifest that the developed controllers successfully replicate the optimal control trajectory, providing a robust and computationally feasible solution for real-world applications. This research highlights the potential of combining advanced control strategies to meet performance and environmental demands of modern heavy-duty vehicles. Full article

As interest in eco-friendly work vehicles grows, research on the powertrains of eco-friendly tractors has increased, including research on the development of eco-friendly vehicles (tractors) using hydrogen fuel cell power packs and batteries. However, batteries require a long time to charge and have a short operating time due to their low energy efficiency compared with hydrogen fuel cell power packs. Therefore, recent studies have focused on the development of tractors using hydrogen fuel cell power packs; however, there is a lack of research on powertrain performance analysis considering actual working conditions. To evaluate vehicle performance, an actual load measurement during agricultural operation must be conducted. The objective of this study was to conduct an efficiency analysis of powertrains according to their power source using data measured during agricultural operations. A performance evaluation with respect to efficiency was performed through comparison and an analysis with internal combustion engine tractors of the same level. The specifications of the transmission for hydrogen fuel cell and engine tractors were used in this study. The power loss and efficiency of the transmission were calculated using ISO 14179-1 equations, as shown below. Plow tillage and rotary tillage operations were conducted for data measurement. The measurement system consists of four components. The engine data load measurement was calculated using the vehicle’s controller area network (CAN) data, the axle load was measured using an axle torque meter and proximity sensors, and fuel consumption was measured using the sensor installed on the fuel line. The calculated capacities, considering the engine’s fuel efficiency for plow and rotary tillage operations, were 131.2 and 175.1 kWh, respectively. The capacity of the required power, considering the powertrain’s efficiency for hydrogen fuel cell tractors with respect to plow and rotary tillage operations, was calculated using the efficiency of the motor, inverter, and power pack, and 51.3 and 62.9 kWh were the values obtained, respectively. Considering these factors, the engine exhibited an efficiency of about 47.9% compared with the power pack in the case of plow tillage operations, and the engine exhibited an efficiency of about 29.3% in the case of rotary tillage operations. A hydrogen fuel cell tractor is considered suitable for high-efficiency and eco-friendly vehicles because it can operate on eco-friendly power sources while providing the advantages of a motor. Full article

Given the complex powertrain of fuel cell electric vehicles (FCEVs) and diversified vehicle platooning synergy constraints, a control strategy that simultaneously considers inter-vehicle synergy control and energy economy is one of the key technologies to improve transportation efficiency and release the energy-saving potential of platooning vehicles. In this paper, an energy-oriented hybrid cooperative adaptive cruise control (eHCACC) strategy is proposed for an FCEV platoon, aiming to enhance energy-saving potential while ensuring stable car-following performance. The eHCACC employs a hybrid cooperative control architecture, consisting of a top-level centralized controller (TCC) and bottom-level distributed controllers (BDCs). The TCC integrates an eco-driving CACC (eCACC) strategy based on the minimum principle and random forest, which generates optimal reference velocity datasets by aligning the comprehensive control objectives of the platoon and addressing the car-following performance and economic efficiency of the platoon. Concurrently, to further unleash energy-saving potential, the BDCs utilize the equivalent consumption minimization strategy (ECMS) to determine optimal powertrain control inputs by combining the reference datasets with detailed optimization information and system states of the powertrain components. A series of simulation evaluations highlight the improved car-following stability and energy efficiency of the FCEV platoon. Full article

With the increasing focus on decarbonisation of the transport sector, it is imperative to consider routes to electrify vehicles beyond those achievable using lithium-ion battery technology. These include heavy goods vehicles and aerospace applications that require propulsion systems that can provide gravimetric energy densities, which are more likely to be delivered by fuel cell systems. While the discussion of light-duty vehicles is abundant in the literature, heavy goods vehicles are under-represented. This paper presents an overview of the electrochemical degradation of a proton exchange membrane fuel cell integrated into a simulated Class 8 heavy goods range-extender fuel cell hybrid electric vehicle operating in urban driving conditions. Electrochemical degradation data such as polarisation curves, cyclic voltammetry values, linear sweep voltammetry values, and electrochemical impedance spectroscopy values were collected and analysed to understand the expected degradation modes in this application. In this application, the proton exchange membrane fuel cell stack power was designed to remain constant to fulfil the mission requirements, with dynamic and peak power demands managed by lithium-ion batteries, which were incorporated into the hybridised powertrain. A single fuel cell or battery cell can either be operated at maximum or nominal power demand, allowing four operational scenarios: maximum fuel cell maximum battery, maximum fuel cell nominal battery, nominal fuel cell maximum battery, and nominal fuel cell nominal battery. Operating scenarios with maximum fuel cell operating power experienced more severe degradation after endurance testing than nominal operating power. A comparison of electrochemical degradation between these operating scenarios was analysed and discussed. By exploring the degradation effects in proton exchange membrane fuel cells, this paper offers insights that will be useful in improving the long-term performance and durability of proton exchange membrane fuel cells in heavy-duty vehicle applications and the design of hybridised powertrains. Full article

Several technological challenges delay the adoption of electrified powertrains in the heavy-duty transport sector. For fuel-cell hybrid electric trucks, key issues include slow cold start, reduced cooling power during high ambient temperatures, and uncertainties regarding durability. In addition, the engineers must handle the complexity of the system. In this article, a Matlab/Simulink library is introduced, which has been developed to aid engineers in the design and optimization of energy management systems and strategies of this complex system that consider mechanical, electrochemical, and thermal energy flows. The library is introduced through five example vehicle models, and through case studies that highlight the various kinds of analysis that can be performed using the provided models. All library code is open source, open for commercial use, and runs in Matlab/Simulink without any need for external libraries. Full article

Aiming at the demand for subjective evaluation of driveability for fuel cell vehicles, the modeling and evaluation method of driveability for fuel cell vehicles were studied in this paper. Firstly, a real-time model of the fuel cell vehicle powertrain system was established, which included the fuel cell model, power battery model, DC/DC converter model and drive motor model. Secondly, it was integrated with the vehicle dynamics model to form a virtual prototype of a fuel cell vehicle. And a virtual subjective evaluation platform for fuel cell vehicles was built by combining the virtual prototype and high-fidelity driving simulator. Thirdly, a subjective evaluation method of driveability for fuel cell vehicles was proposed, which included the starting performance, acceleration performance, uniform speed performance and tip-in/tip-out performance. Finally, the paper used the platform and method mentioned above to conduct subjective evaluations of the fuel cell vehicles. Full article

This paper presents a case study of a lithium battery and fuel cell integrated powertrain system for a renewable energy vehicle. The performance analysis includes evaluating the energy consumption of the vehicle and the efficiency of the power generation components. When driven solely by the lithium battery at average speeds of 15 km/h and 20 km/h, it was observed that speed significantly influences the travel distance of the vehicle, with higher speeds resulting in lower mileage. The energy efficiency rates were found to be 89.3% and 85.7% at speeds of 15 km/h and 20 km/h, respectively, indicating an 18.1% decrease in efficiency from low to higher speeds. When the lithium battery is solely charged by the hydrogen fuel cell, the efficiency under test conditions reaches approximately 32.5%. In the “FC + B + SC” driving mode, which combines the use of the lithium battery, fuel cell, and solar panel to power the vehicle, the travel range can be extended to 50.62 km and 42.05 km, respectively, representing an increase of over 50%, with overall efficiencies of 63.8% and 60.7%, respectively. This hybrid powertrain system exhibits rapid dynamic response, high energy and power density, and enables longer travel distances for the renewable energy vehicle. Full article

The growing awareness about climate change and environmental pollution is pushing the industrial and academic world to investigate more sustainable solutions to reduce the impact of anthropic activities. As a consequence, a process of electrification is involving all kind of vehicles with a view to gradually substitute traditional powertrains that emit several pollutants in the exhaust due to the combustion process. In this context, fuel cell powertrains are a more promising strategy, with respect to battery electric alternatives where productivity and endurance are crucial. It is important to replace internal combustion engines in those vehicles, such as the those in the sector of Non-Road Mobile Machinery. In the present paper, a preliminary analysis of a fuel cell powertrain for a telehandler is proposed. The analysis focused on performance, fuel economy, durability, applicability and environmental impact of the vehicle. Numerical models were built in MATLAB/Simulink and a simple power follower strategy was developed with the aim of reducing components degradation and to guarantee a charge sustaining operation. Simulations were carried out regarding both peak power conditions and a typical real work scenario. The simulations’ results showed that the fuel cell powertrain was able to achieve almost the same performances without excessive stress on its components. Indeed, a degradation analysis was conducted, showing that the fuel cell system can achieve satisfactory durability. Moreover, a Well-to-Wheel approach was adopted to evaluate the benefits, in terms of greenhouse gases, of adopting the fuel cell system. The results of the analysis demonstrated that, even if considering grey hydrogen to feed the fuel cell system, the proposed powertrain can reduce the equivalent ${\mathrm{CO}}_2$ emissions of 69%. This reduction can be further enhanced using hydrogen from cleaner production processes. The proposed preliminary analysis demonstrated that fuel cell powertrains can be a feasible solution to substitute traditional systems on off-road vehicles, even if a higher investment cost might be required. Full article
