Search Results (46)

This article presents an experimental study on the hydrodynamics of coolant flow within the pressure vessel of a small modular reactor (SMR) cooled with water, including areas such as the annular downcomer, bottom chamber, and core-simulating channels that are being developed for use in land-based nuclear power plants. This paper describes the experimental setup and test model, measurement techniques used, experimental conditions under which this research was conducted, and results obtained. This study was conducted at the Nizhny Novgorod State Technical University (NNSTU) using a high-pressure aerodynamic testing facility and a scale model that included structural components similar to those found in loop-type reactors. Experiments were performed with Reynolds numbers (Re) ranging from 20,000 to 50,000 in the annular downcomer space of the test model. Two independent techniques were used to simulate the non-uniform flow field in the pressure vessel: passive impurity injection (adding propane to the airflow) and hot tracer (heating one of the reactor circulation loops). The axial velocity field at the inlet to the reactor core was also investigated. This study provided information about the spatial distribution of a tracer within the coolant flow in the annular downcomer and bottom chamber of the pressure vessel. Data on the distribution of the contrasting admixture are presented in plots. The swirling nature of the coolant flow within the pressurized vessel was analyzed. It was shown that the intensity of mixing within the bottom chamber of the pressure vessel is influenced by the presence of a central vortex. Parameters associated with the mixing of admixtures within the model for the pressure vessel were estimated. Additionally, the possibility for simulating flow with different temperature mixing processes using isothermal models was observed. Full article

New energy vehicles (NEVs) rely heavily on Insulated-Gate Bipolar Transistors (IGBTs) to perform frequent battery voltage conversions for operations such as acceleration, deceleration, and hill climbing. Consequently, effective thermal management of the IGBT junction temperature is critically important. This study investigates the junction temperature of IGBT modules equipped with pin-fin heat sinks of varying spacings under diverse operating conditions. The effects of the coolant inlet flow velocity and temperature on the junction temperature were examined. Furthermore, the pin-fin heat sink structure was optimized to enhance temperature uniformity across the IGBT chips. The results indicate that (1) IGBT modules with small-spacing pin-fin heat sinks exhibit improved thermal performance and enhanced temperature uniformity under specific conditions; (2) coolant inlet flow velocity is positively correlated with both module cooling efficiency and temperature uniformity; (3) coolant inlet temperature is inversely correlated with module junction temperature and chip junction temperature uniformity; and (4) among the three optimization schemes evaluated, the dual-channel, non-uniformly spaced pin-fin heat sink delivered the optimal performance, reducing the maximum junction temperature difference between IGBT chips to approximately 0.5 °C and that between diode chips to approximately 1.0 °C. Full article

The heat exchanger in a hydropower unit plays a critical role in ensuring the stability of the unit and improving operational efficiency. This paper conducted a global flow-field/heat-transfer numerical analysis of multi-tube heat exchangers in hydropower units (with 98 tubes) and applied it to optimization research under actual operating conditions. Using a three-dimensional two-phase flow model, this work systematically analyzes the effects of different sand content and particle size on heat-transfer performance, revealing the impact of particle-flow and fluid-flow nonuniformity on heat-exchange efficiency. This research fills the gap in existing studies regarding the analysis of the impact of complex operating conditions on hydropower unit radiators. To address the issues of nonuniform flow fields and poor flow mixing in existing heat exchangers, an improved inlet/outlet structural-optimization plan is proposed. The original cylindrical inlet/outlet is replaced with a square structure, and its area is increased. The optimized structure improves flow uniformity, reduces flow losses, enhances heat-transfer performance by 7.7%, and achieves a significant reduction of 0.53 K in oil temperature. The findings of this study provide theoretical and engineering guidance for the design and optimization of heat exchangers in hydropower units and are of high value for practical applications. Full article

This study investigates the thermal performance of an oil-jet-cooled permanent magnet synchronous motor (PMSM), with a particular focus on end-winding heat dissipation. A high-fidelity numerical model that preserves the full geometric complexity of the end-winding is developed and validated against experimental temperature data, achieving average deviations below 7%. To facilitate efficient parametric analysis, a simplified equivalent model is constructed by replacing the complex geometry with a thermally equivalent annular region characterized by calibrated radial conductivity. Based on this model, the effects of key spray ring parameters—including orifice diameter, number of nozzles, inlet oil temperature, and flow rate—are systematically evaluated. The results indicate that reducing the orifice diameter from 4 mm to 2 mm lowers the maximum winding temperature from 162 °C to 153 °C but increases the pressure drop from 205 Pa to 913 Pa. An optimal nozzle number of 12 decreases the peak winding temperature to 155 °C compared with 162 °C for 8 nozzles, while increasing the oil flow rate from 2 L/min to 6 L/min reduces the peak winding temperature from 162 °C to 142 °C. Furthermore, a non-uniform spray ring configuration decreases maximum stator, winding, spray ring, and shaft temperatures by 5.6–9.2% relative to the baseline, albeit with a pressure drop increase from 907 Pa to 1410 Pa. These findings provide quantitative guidance for optimizing oil-jet cooling designs for PMSMs under engineering constraints. Full article

Based on admirable porous media performance and the popularity of additive manufacturing technology, gradient porous media are progressively being applied in increasing fields. In this study, convection heat transfer within a square vented cavity, partially occupied by two copper metal foam layers of $10$ and $20$ PPI saturated with nanofluid, was assessed numerically. The left wall was heated uniformly and non-uniformly by applying multi-frequency spatial heating following a sinusoidal function. Governing equations, including continuity, the Darcy–Brinkmann–Forchheimer model, and local thermal non-equilibrium energy equations, were adopted and solved by employing the finite volume method. The influences of relevant parameters, including nanoparticle concentrations $\left(0\%\le \phi \le 10\%\right)$, Reynolds number ($1\le Re\le 100$), inlet and outlet port aspect ratios $\left(0.1\le D/H\le 0.4\right)$, three outlet vent opening locations ($\left(S_o=0\right)$ left, ($S_o=\left(H/2-D/2\right)$) middle, and ($S_o=\left(H-D\right)$) right), sinusoidal offset temperature (${\theta }_o=0.5$, $1$), frequency ($f=1, 3, 5$), and amplitude ($A=0-1$), were examined. The results demonstrate that flow and heat transfer fields are impacted mainly by these parameters. Streamlines are more intensified at the upper-left corner when the outlet opening vent is shifted towards the right-corner upper wall. Fluid- and solid-phase Nusselt number increases $Re$, $D/H$, ${\theta }_o$, $A$, and $f$ are raised, specifically when $A\ge 0.3$. The Nusselt number remains constant when the frequency is raised from $3$ to $5$, definitely when $D/H\ge 0.25$. In uniform and non-uniform heating cases, the Nusselt number of both phases remains constant as the outlet port is shifted right for $Re\le 10$ and slightly for higher $Re$ as the outlet vent location is translated from left to right. Full article

Traditional perforated duct designs fail to resolve the energy consumption-uniformity conflict in semi-closed greenhouses. To address this, we develop a CFD-RSM-NSGA-II framework that simultaneously minimizes velocity non-uniformity (CV-v), pressure loss (ΔP), and temperature variation (CV-t). Key parameters—hole diameter (6–10 mm), spacing (30–70 mm), and inlet velocity (4–8 m/s)—are co-optimized. Model validation showed that the mean relative errors were 8.6% for velocity, 2.3% for temperature, and pressure deviations below 5 Pa, with the response surface model achieving an R² of 0.9831 (p < 0.0001). Larger hole diameters improved CV-v, while wider spacings led to a decrease in uniformity. Pressure loss followed an opposite trend. Temperature variation was mostly affected by inlet velocity. Sensitivity analysis revealed that hole diameter was the most influential factor, followed by spacing and velocity, with a significant interaction between diameter and spacing. Using entropy-weighted TOPSIS coupled with NSGA-II, the optimization identified an optimal configuration (hole diameter = 9.0 mm, spacing = 65 mm, velocity = 7.0 m/s). This solution achieved a 58.8% reduction in CV-v, a 10.8% decrease in ΔP, and a 5.2% improvement in CV-t, while stabilizing inlet static pressure at 72.8 Pa. Critically, it reduced power consumption by 17.4%—directly lowering operational costs for farmers. The “larger diameter, wider spacing” strategy resolves energy-uniformity conflicts, demonstrating how integrated multi-objective process control enables efficient greenhouse ventilation. Full article

Research on the thermal analysis of laser diode (LD) side-pumped amplifiers is a critical step in the design of high-power solid-state laser systems. Instead of adopting a standard solid modeling approach that only considers a laser rod, a fluid–structure interaction model is employed for analysis using the FLUENT 2021 R1 software. This model integrates the cooling structure, coolant, and laser rod, incorporating their relevant material parameters. By considering both uniform and non-uniform inlet velocity distributions as loading conditions, the study reveals remarkably different thermal simulation results. The correlation between thermal analysis outcomes and the total inlet flow rates is calculated, while temperature and stress distributions are obtained under a varying internal heat source. It was observed that the non-uniform inlet velocity distribution has little impact on the rod’s maximum temperature but significantly influences the maximum equivalent stress. This finding underscores the necessity of accounting for non-uniform inlet distributions during the design of laser amplifiers to achieve more accurate thermal simulation results and optimize structural reliability. Full article

Large curvature, high pre-swirl large high-speed centrifugal fans are the preferred choice for industrial gas quenching furnaces, as they need to operate under non-uniform inlet conditions for extended periods. The resulting inlet distortion disrupts the symmetric flow of the gas, leading to reduced fan stability and phenomena such as flow separation and rotational stall. This issue has become a key research focus in the field of large centrifugal fan applications. This paper introduces an eddy viscosity correction method, and compares it with experimental results from U-shaped pipe curved flow. The corrected SST k-ω model shows a maximum error of only 4.7%. Simulation results show that the fan inlet generates a positive pre-swirl inflow with a relative distortion intensity of 3.83°. The flow characteristics within the impeller passage are significantly affected by the swirl angle distribution. At the maximum swirl angle, the leakage flow at the blade tip develops into a stall vortex that spans the entire passage, with an average blockage coefficient of 0.29. At the minimum swirl angle, the downstream leakage flow at the blade tip is suppressed on the suction side by the main flow, leading to a reduced vortex structure within the passage and an average blockage coefficient of 0.21. To address the design challenges of large high-speed centrifugal fans under inlet distortion, a blade design method based on secondary flow suppression is proposed. Eleven impeller flow surfaces are selected as control parameters, and the centrifugal impeller blade profile is redesigned. Numerical simulations and experimental results of the gas quenching furnace’s flow and temperature fields indicate that the modified impeller significantly reduces the blade tip leakage flow strength, with the average blockage coefficient decreasing to 0.07 and 0.04, respectively. The standard deviation of the average flow velocity at the test section is reduced by 42.78% compared to the original, and the temperature fluctuation at the workpiece surface is reduced by 53.09%. Both the flow and temperature field uniformity are significantly improved. Full article

The rapid growth of photovoltaic (PV) installed capacity has driven advancements in photovoltaic technology, such as integrating PV panels into building envelopes. Temperature increases are known to negatively impact PV panel performance. This study investigates and optimizes the design of air-based cooling systems for PV roofs using experimental and numerical analyses, leveraging free natural convection for cooling. Experimental measurements included air inlet/outlet, PV panel, and roof surface temperatures. The primary parameters examined in Computational Fluid Dynamics (CFD) for the numerical study were the heights and widths of the air channels between the panels and the rooftop, with heights ranging from 25 mm to 75 mm and widths varying from 200 mm to 400 mm. There are good agreements between the numerical results and experimental measurements after model validation. The results reveal significant temperature non-uniformity across the surface of the PV panels, with a maximum temperature difference of 16.50 °C. The shading effect of the PV panels resulted in an average reduction in roof surface temperature by 12.90 °C. Parametric studies showed that changes in height had a more pronounced effect on cooling than in width. The optimal design was identified with a channel size of 75 mm × 400 mm, resulting in the lowest average PV panel temperature of 65.21 °C and enhanced temperature uniformity, with maximum efficiency reaching 11.54%. Full article

The energy consumption of data center cooling systems is rapidly increasing, necessitating urgent improvements in cooling system performance. This study investigates a pump-driven two-phase cooling system (PTCS) utilizing a parallel-flow heat exchanger (PFHE) as an evaporator, positioned at the rear of server cabinets. The findings indicate that enhancing the vapor quality at the PFHE outlet improves the overall cooling performance. However, airflow non-uniformity induces premature localized overheating, restricting further increases in vapor quality. For PFHEs operating with a two-phase outlet condition, inlet air temperature non-uniformity has a relatively minor impact on the cooling capacity but significantly affects the drop in pressure. Specifically, higher upstream air temperatures increase the pressure drop by 7%, whereas higher downstream air temperatures reduce it by 7.7%. The implementation of multi-pass configurations effectively mitigates localized overheating caused by airflow non-uniformity, suppresses the decline in cooling capacity, and enhances the operational vapor quality of the cooling system. Full article

The temperature gradient inside a tundish leads to the uneven density distribution of molten steel, resulting in thermal buoyancy, which has a significant impact on the motion of inclusion particles. Based on practice data and necessary assumptions, a three-dimensional model of a tundish considering non-uniform thermal transfer was established. The flow and temperature distribution were studied, and the changes in inclusion removal rate were compared with different casting speeds and temperature reduction rates using computational fluid dynamics simulation. It was observed that, when the inlet temperature is higher, the molten steel floats up under the action of thermal buoyancy, which can form a horizontal stream behind the weir. While the inlet temperature is lower, the horizontal stream cannot be maintained, resulting in a decrease in the removal rate of inclusions. Increasing the casting speed will increase the velocity of the molten steel in the tundish, make it easier to shorten the temperature difference between the inlet and outlet, and reduce the removal rate of inclusions. When formulating production processes, the impact of thermal buoyancy on the flow field should be taken into account. Full article

To enhance the performance of combustors in micro thermophotovoltaic systems, this study employs numerical simulations to investigate a planar microscale combustor featuring a counter-flow flame configuration. The analysis begins with an evaluation of the effects of (1) equivalence ratio Φ and (2) inlet flow rate V_i on key thermal and combustion parameters, including the average temperature of the combustor main wall (${\overline{T}}_w$), wall temperature non-uniformity (${\overline{R}}_{Tw}$) and radiation efficiency (${\eta }_r$). The findings indicate that increasing Φ causes these parameters to initially increase and subsequently decrease. Similarly, increasing the inlet flow rate leads to a monotonic decline in ${\eta }_r$, while the ${\overline{T}}_w$ and ${\overline{R}}_{Tw}$ exhibit a rise-then-fall trend. A comparative study between the proposed combustor and a conventional planar combustor reveals that, under identical inlet flow rate and equivalence ratio conditions, the use of the counterflow flame configuration can increase the ${\overline{T}}_w$ while reducing the ${\overline{R}}_{Tw}$. The Nusselt number analysis shows that the counter-flow flame configuration micro-combustor achieves a larger area with positive Nusselt numbers and higher average Nusselt numbers, which highlights improved heat transfer from the fluid to the solid. Furthermore, the comparison of blow-off limits shows that the combustor with counter-flow flame configuration exhibits superior flame stability and a broader flammability range. Overall, this study provides a preliminary investigation into the use of counter-flow flame configurations in microscale combustors. Full article

The temperature inside broiler houses is crucial to broiler health, welfare, and productivity. High stocking density in broiler houses can easily lead to nonuniform temperature conditions, which would cause broilers to suffer cold and heat stress. It is essential to assess the temperature distribution inside broiler houses and investigate the factors that affect temperature uniformity. Therefore, in this study, temperature, wind velocity, and differential pressure were monitored in the aisle, at the sidewall inlet, and outside the sidewalls of a commercial stacked-deck cage broiler house in Northeast China aiming to continuously monitor the temperature throughout the entire fattening period. Results show that the maximum temperature difference increased from 1.85 °C to 6.43 °C, while the daily fluctuation increased from 2.27 °C to 5.80 °C. The highest temperature was consistently recorded at the side of the exhaust fans (p < 0.001) in the longitudinal direction. In the lateral direction, the temperature difference varies periodically with solar radiation. The average temperature at the southern location (23.58 ± 1.97 °C), which faces the sun, was higher than that at the northern location (23.35 ± 1.38 °C), which is in the shade, during periods of solar radiation (p < 0.001) at the last testing period. However, without solar radiation, the northern location recorded a warmer temperature (23.19 ± 1.41 °C) compared to the southern location (22.30 ± 1.67 °C) (p < 0.001). The lateral temperature differences are strongly positively correlated with solar radiation and wind speed (p < 0.001). In conclusion, the inside temperature nonuniformity and fluctuation increased as the broiler age increased, which affected the production performance of broilers. Nonuniform solar radiation and wind speed can lead to differences in the inlet temperature and air volume between both sidewalls, thereby affecting the uniformity of the lateral temperature inside the house. Full article

Over the past two decades, double-layered microchannel heat sinks (DL-MCHs) have become increasingly popular as they provide effective performance for electronic cooling, particularly in the counterflow configuration. The cross-flow configuration, which requires much simpler headers, has seldom been considered in the scientific literature, probably due to the possible formation of a hotspot near the outlet port. The aim of this study is to show that cross-flow DL-MCHs can provide performance levels that are comparable to those attained by counterflow DL-MCHs by exploiting the nonuniform flow distribution produced by properly designed headers. Numerical simulations are performed using in-house finite element procedures to solve the parabolized Navier–Stokes equations in the microchannels and the energy equation in the entire computational domain. The analysis is carried out both for ideal linear microchannel velocity distributions and for the realistic velocity distributions induced by headers with or without baffles, as proposed by the authors in previous papers. The optimal degree of velocity nonuniformity in the microchannels yielding the best thermal performance was found to depend on the flow rate. For instance, in the case of optimal linear variations of the microchannel velocity distribution, the thermal resistance was reduced by 11.8%, 7.1%, and 4.4% compared to the case with uniform inlet velocities, and it was only 3.4%, 1.8%, and 0.3% higher than that of the counterflow configuration for average microchannel velocities equal to 0.5, 1, and 2 m/s, respectively. The main conclusion is that the cross-flow configuration, with its simple headers and piping, can achieve thermal resistance and temperature uniformity on the heated surface that are very similar to that of the counter-flow configuration through proper header design that ensures a suitable microchannel velocity distribution. Full article

Several engineering systems currently use microchannel heat sinks. In order to increase the performance of these devices, optimisation according to the first and second law of thermodynamics is employed. One way to achieve the goal is to modify the geometry of the cross-section, as is done in this paper for square ducts, having the walls at a uniform temperature which is higher than that of the bulk fluid at the inlet. The effects of both the thermal entry region of the duct and the heat generation due to viscous dissipation are considered. The resulting Graetz–Brinkman problem is solved numerically to obtain the velocity and temperature fields. It is demonstrated that non-negligible viscous heating eventually causes the heat flux to reverse (from fluid to walls), and that, only after this condition is achieved, can the flow become fully developed, which makes the entry region the only useful stretch for real-life applications. The length after which the direction of the heat flux reverses due to viscous heating in the fluid is obtained as a function of the Brinkman number and of the smoothing radius. Optimisation with performance evaluation criteria and entropy generation minimisation was carried out separately, and the results were combined into a single objective function. A comparison with published models highlights how neglecting the entry region and viscous heating yields misleading results. It turns out that smoothing the corners is always profitable in the case of the constrained heated perimeter or area of the cross-section but seldom when the characteristic length or the hydraulic diameter is fixed. With few exceptions, viscous heating amplifies the trends experienced for zero-Brinkman flows. The results are in non-dimensional form, yet they have been obtained starting from plausible dimensional values and are applicable to real-life devices. Full article
