Rotating machinery is essential in various industrial fields, and growing demands for high performance under harsh operating conditions have heightened interest in fault diagnosis and prognostic technologies. However, a major challenge in fault diagnosis research lies in the scarcity of data, primarily due to the inability to deliberately introduce faults into machines during actual operation. In this study, a physical model is proposed to realistically simulate the system behavior of a ship’s turbo-rotating machinery by coupling the torsional and lateral vibrations of the rotor. While previous studies employed simplified single-shaft models, the proposed model adopted gear mesh interactions to reflect the coupling behavior between shafts. Furthermore, the time-domain response of the system is analyzed through state-space transformation. The proposed model was applied to simulate imbalance and gear teeth damage conditions that may occur in marine turbo-rotating systems and the results were compared with those under normal operating conditions. The analysis confirmed that the model effectively reproduces fault-induced dynamic characteristics. By enabling rapid implementation of various fault conditions and efficient data acquisition data, the proposed model is expected to contribute to enhancing the reliability of fault diagnosis and prognostic research. Full article

Drilling oil and gas wells is a complex process that requires a combination of several parameters to dig into the ground. Inappropriate drilling parameter settings and reaction forces can lead to unwanted vibrations, which can negatively impact the drill string and cause damage to drill bits. To reduce unwanted oscillations, drilling vibration modeling is the first approach used to determine the behavior of the drill string under various conditions. Natural frequencies, one of the modal characteristics of a vibrating drill string, can be estimated by analytical or numerical models. However, as the field conditions become more complicated, analytical models become increasingly difficult to use, and alternative approaches must be adopted. The main objective of this paper is to investigate the natural frequencies of drill strings with real geometry under coupled vibration modes using both analytical and finite element methods. This study bridges the literature gap in modeling stepped drill string geometries, which are usually represented as uniform beams. This paper used analytical and finite element models to determine the drill string’s lateral, axial, and torsional natural frequencies under varying lengths of drill pipes and drill collars. To assess the reliability of finite element models under complex geometry, the drill string was approximated as a stepped beam rather than a uniform beam. Then, a comparison was made with analytical models. The results showed that the length of drill pipes has a pronounced effect on the natural frequencies of the overall drill string for the three vibrational modes, while drill collar length only has a notable impact on the torsional mode. These findings contribute to drilling systems’ reliability and efficiency in the oil and gas energy sector. Full article

The establishment of a linear seismic response analysis model that considers ground rotation effects and eccentric torsion informed the investigation of the linear response characteristics of coupled lateral–torsional vibration, considering eccentricity and ground rotation, after which the lateral–torsional coupling linear response pattern of special-shaped column structures is examined. The results show that the torsion angle of a floor is equal to the sum of the interlayer torsion angle caused by eccentric torsion and the pure torsion angle caused by ground rotation, respectively. The natural vibration frequency of the structure considering ground rotation effects is a function of relative eccentricity; the period ratio of translation to torsion caused by ground rotation; and the period ratio of translation to torsion when considering only eccentric torsion. When the translation to torsion period ratio, considering eccentric torsion, is greater than 1.0, the torsional amplitude increases remarkably, but the first-order participation mode is considerably higher under the same conditions. The natural vibration characteristics, translational response, torsional response, and seismic force distribution are obtained for special-shaped columns by conducting the shaking table test on steel-reinforced concrete (SRC) frame structures. After comparative analysis, the maximum ratio of the maximum torsional displacement of the bottom layer of the structure to the horizontal displacement in the X direction is 0.0007. The maximum ratio of the base shear force to the theoretical base shear force of the structure without considering coupling is 0.93. The maximum ratio of the measured shear force of the special-shaped column to the theoretical shear force without considering coupling is 0.65. This indicates that ground rotation has a significant amplification effect on structural response. The research results provide a reference for the seismic design of special-shaped column structures. Full article

With the growing adoption of Unmanned Aerial Vehicles (UAVs) in industrial and commercial sectors, the limitations of traditional under-actuated multirotors are becoming increasingly evident, particularly in manipulation tasks. Limited control over the thrust vector direction of the propellers, coupled with its interdependence on the vehicle’s roll, pitch, and yaw moments, significantly restricts manipulation capabilities. To address these challenges, this work presents a control framework for multirotor UAVs equipped with thrust-vectoring components, enabling enhanced control over the direction of lateral forces. The framework supports various actuator configurations by integrating fixed vertical propellers with horizontally mounted thrust-vectoring components. It is capable of handling horizontal thruster setups that generate forces in all directions along the x- and y-axes. Alternatively, it accommodates constrained configurations where the vehicle is limited to generating force in a single direction along either the x- or y-axis. The supported UAVs can follow transmitter commands, setpoints, or predefined trajectories, while the flight controller autonomously manages the propellers and thrusters to achieve the desired motion. Moment evaluations were conducted to assess the torsional capabilities of the vehicles by varying the angles of the thrusters during torsional tasks. The results demonstrate comparable torsional magnitudes to previously studied thrust-vectoring UAVs. Simulations with vehicles of varying inertia and dimensions showed that, even with large horizontal thruster offsets, the vehicles followed desired trajectories while maintaining stable horizontal orientation and smaller attitude variations compared to normal flight. Similar performance was observed with positive and negative vertical offsets, demonstrating the framework’s tolerance for thrusters outside the horizontal plane. Full article

The driving and resistance torques of some rotating machinery for industrial applications are nonstationary and affect system dynamics. Under such operating conditions, coupling between torsional and lateral vibrations may become significant for drive lines supported by hydrodynamic bearings in particular design configurations. Indeed, the occurrence of fluid–structure interactions causes a reduction in the stability threshold of the journal bearings. A hypothesis based on Hopf bifurcation theory (HBT), which justifies how the coupling phenomenon develops, is validated by means of overall experimental observations and a suitable numerical model. When the pulsating driving torque induces significant angular speed oscillation, the rotor-bearing system lateral operating response becomes more complex, and bearing instability onset is detected. Such observation proves the influence of bearings in converting torsional oscillations to lateral vibrations. Particularly, during run-up and run-down tests, localized hysteresis is observed in trends of fundamental order contents. The numerical model of the hydrodynamic bearings solves the Reynolds equation in unsteady conditions to quantify the lateral vibrations amplitude in the presence of both angular speed oscillation and dynamic perturbation. The proposed approach proves the onset of torsional–lateral vibration coupling due to hydrodynamic bearings, to a certain extent. The detected hysteresis phenomena can also be explained by the onset of journal bearing instability. Full article

When vehicles move on a bridge, the coupling effect between vehicles and bridges can affect driving safety and comfort, especially for curved bridges, therefore, choosing reasonable design parameters for curved bridges is crucial. In this article, a three-span curved continuous box-girder bridge was taken as the research object; the entire process of vehicle-bridge coupling vibration of highway curved girder bridges was conducted via numerical simulation and the vehicle-bridge coupling vibration analysis program Cmck 1.0 was developed. Then, the influence factors such as curvature radius, constraint mode, and vehicle characteristics on the vehicle-bridge coupling vibration of curved girder bridges were explored. The results showed that as the curvature radius increased, the dynamic response of the bridge offered a gradually decreasing trend and compared to the vertical dynamic response, the torsional response was more sensitive to the influence of the curvature radius. Different constraint methods significantly impacted the dynamic response of bridges, and the vertical and torsional dynamic responses of bridges under general constraint arrangement of straight bridges were increased compared to those under boundary conditions for curved beam bridges. As the axle load of the car decreases, the bridge mid-span vertical and torsional dynamic responses showed a decreasing trend. In contrast, the lateral dynamic response gradually increased. Full article

No-tillage seeding is of great significance for adjusting and improving soil structure in Northeast China. The conventional no-tillage seeder faces several issues with its row cleaner, such as a low straw cleaning rate and a high working resistance. To address these problems, this paper utilizes the bionic design method and develops a bionic elastic row cleaner inspired by the motion behavior of mole excavation. The bionic structure includes bent teeth and a torsion spring for lateral throwing. The MBD–DEM coupled simulation technology is proposed as the experimental optimization method, and it analyzes the interactions between different row cleaners, straw, and soil. The results indicate that a bionic elastic row cleaner with curved teeth and a torsion spring for lateral throwing (BA-T) had a higher straw cleaning rate and total kinetic energy of straw. It also had lower working resistance. The field test results indicate that the BA-T improved the straw cleaning rate by 13.04% and reduced the working resistance by 39.24% compared to a flat row cleaner. This outcome also validates the accuracy of the simulation experiments. This study contributes to the design of new and efficient row cleaners suitable for maize straw mulching and no-tillage conditions, thereby promoting the adoption of conservation agriculture practices. Full article

A finite element analysis (FEA) model was developed for Euler and Timoshenko curved beam elements by incorporating trigonometric displacement distribution patterns. Local polar coordinate stiffness matrices were derived based on force-displacement relations and static equilibrium conditions. By employing the kinetic energy theorem and triangular displacement functions, an expression for the consistent mass matrix of a curved beam element was obtained. A coordinate transformation matrix for the curved beam element was established by relating the local polar coordinate system to the global polar coordinate system. Calculation programs were implemented in the Fortran language to evaluate the static–dynamic performance and natural frequency characteristics of curved beam bridges. The obtained results were then compared with those obtained using ANSYS solid models and “replace curve with straight” beam element models. The comparison demonstrated a strong agreement between the results of the Euler and Timoshenko curved beam element models and those of the ANSYS solid models. However, discrepancies were observed when comparing with the results of the “replace curve with straight” beam element model, particularly in terms of lateral static displacement. This discrepancy suggests that the characteristic matrix derived in this study accurately represents the stiffness and mass distribution of the curved beam, making it suitable for mechanical performance analysis of curved beam bridges. It should be noted that the “replace curve with straight” method overlooks the initial curvature and the bending–torsion coupling effects of a curved beam, resulting in calculation deviations. On the other hand, the use of curved beam elements in numerical analysis provides a simple and practical approach, which facilitates further research in areas such as vehicle–bridge coupling vibrations and seismic analysis of curved beam bridges. Full article

Stability analysis of lateral–torsional coupled vibration is obligatory for rotating machinery, such as aero-engines. However, the state-of-the-art method may lead to stability misjudgment under different coordinate systems. The cause of this misjudgment has not yet been well explored. The purpose of this paper is to clarify the error source of the stability analysis in a more comprehensive manner. A vertical Jeffcott rotor model including torsion vibration is built, and the Lagrange approach is applied to establish the motion equations. The coordinate transformation matrix is used to transfer the motion equations into the rotating coordinate system, making the coefficients of the motion equation constants. The differences in the unstable speed regions in the two coordinate systems are captured. The limitations of the Floquet theory and Hill’s determinant analysis in the stability estimation of the lateral–torsional coupled vibration are explained. It is found that, for Hill’s method, increasing the number of the harmonic truncation cannot correct the misjudgment, and the matrix truncation is the fundamental error source. The above research provides more accurate theoretical support for the analysis of the lateral–torsional coupling instability of rotors. Full article

Diagnosis of faults in a rotor system operating in a fluid is a complex task in the field of rotating machinery. In an ideal scenario, a forced shutdown due to rotor-stator contact failure would necessitate the replacement of the rotor or stator. However, factors such as time constraints, economic considerations, and the aging of infrastructure make it imprudent to abruptly shut down machinery that can still be safe to operate. The purpose of this paper is to present an experimental study that validates the theoretical results of the dynamic behavior and friction detection using the wavelet synchrosqueezing transformation (WSST) method for recurrent rotor-stator contacts in a fluid environment, as presented in a previous study. The investigation focused on the analysis of whirl orbits, shaft deflection, and fluctuation frequency during passage through critical speeds. The WSST method was used to decompose the dynamic responses of the rotor in the supercritical speed zone into several supercomponents. The variation of the high-frequency component was studied based on the fluctuation of the instantaneous frequency (IF) technique. Additionally, the fast Fourier transform (FFT) method, in conjunction with the WSST technique, was used to calculate the variation in the amplitude of high-order frequencies in the vibration signal spectrum. The experimental study revealed that the split in resonance caused by rubbing effects is reduced when the rotor and stator interact with an inviscid fluid. However, despite the effects of elasticity and fluid boundaries generating self-excitation at low frequencies and uneven motion due to stator clearance, the experimental results were consistent with the theoretical analysis, demonstrating the effectiveness of the contact detection method based on WSST. Full article

Transversely loaded beam grillages are quite often used in industrial construction. In order to produce a safe design of such structures, it is necessary to account for the lateral torsional buckling phenomenon, which reduces load-bearing capacity. To be able to calculate the relevant reduction factor, the elastic critical load must be determined. As regards the existing design practice for such structures, simplified conditions are assumed for the mutual restraint of the component beams. However, this approach does not correspond to reality. This study discusses the results of numerical investigations and analytical calculations concerning the effect of the elastic action of simple beam grillage (SBG) joints on the critical load, which results from the lateral torsional buckling (LTB) condition. The SBG was defined as a flat system of interconnected beams, unstiffened laterally and loaded perpendicularly to the grillage plane. The analysis covered H-shaped grillages with different span ratios of component beams, in which the main (coupling) beam was decisive for instability. The effectiveness of the use of closed-section stiffeners at the grillage joints was also investigated. The grillage elastic critical resistances (ECR) were determined for two variants of joint stiffening. The computations were performed by means of FEM numerical simulations. The spatial models were discretised with the following elements: (1) solid ones in Abaqus, (2) shell ones in ConSteel, and (3) thin-walled bars in ConSteel. The LTB critical moments of the weakest beam (critical beam), elastically restrained against warping and against lateral rotation (in the LTB plane), were computed using the analytical methods developed by the authors. To this end, the methods were proposed to determine the indexes of the critical beam elastic restraint in the adjacent stiffening beams. In the study, it was demonstrated that (1) taking into account the conditions of mutual elastic restraint and interaction of the component beams provides a more accurate assessment of the grillage ECR, (2) the use of closed-section stiffeners in the grillage joints increase the ECR compared with classic flat stiffeners, (3) the grillage ECR can be estimated based on the critical moment M_cr of the weakest beam (critical beam) when the conditions of its elastic restraint in joints are accounted for. Full article

It is of practical interest to investigate the mechanical behaviors of a sidetracking tool system and to describe the sidetracking tool’s vibration mechanical response, as this can provide an important basis for evaluating and optimizing the tool structure and effectively controlling the profile of the sidetracking window. In this article, three nonlinear dynamic models with ten, six, and two degrees of freedom, respectively, are established using the Lagrange method to characterize the behavior of the sidetracking tool. It should be noted that in these models, the axial, lateral, and torsional vibration of the tool system are fully coupled. The process of the sidetracking tool mills in the casing-pipe wall is divide into three typical stages, i.e., the window mill, pilot mill, and watermelon mill grinding the casing, respectively. The dynamic response of the three stages is studied to more effectively analyze the influence of the sidetracking tool vibration deformation on the window width. The Runge–Kutta method, which is easy to implement, is applied to solve the supposed nonlinear dynamic model, and some useful findings are as follows. The effects of sidetracking tool vibrations at different stages on window widening size are illustrated quantitatively. The vibration trajectory pattern of the sidetracking tool is different from that of the conventional drilling tool due to the influence of the whipstock, which changes from the general whirling motion pattern to the X reciprocating pattern, and the vibration amplitude decreases. Due to the influence of the tool’s lateral amplitude, the window profile is widened. The widened window size of the window mill and the pilot mill are 3.30 mm and 2.74 mm, respectively, and the extended window size of the watermelon mill is 0.07 mm, while the maximum window width formed by the sidetracking tool is 374.34 mm. This work proposes, for the first time, the coupled vibration model of the sidetracking tool system, which is helpful to better understand the nonlinear dynamic effects of the sidetracking tool, laying the foundation for the optimization of the sidetracking parameters. Full article

As off-road vehicles, in addition to field transportation, another vital function of agricultural tractors is to provide power for field machinery. Therefore, the dynamic performance of the power take-off (PTO) driveline directly affects the field reliability of tractors. Firstly, a torsional vibration coupled spatial dynamics model of the power take-off driveline is proposed according to the classical machine driveline dynamics and gear dynamics theory. In the dynamics model, the interactions among the vertical, lateral, and rotational motions of the driveline parts are fully included. The coupling vibrations from internal excitations (such as tooth surface friction, gear time-varying mesh, and engine pulse) and external excitations (such as field machinery load) are also considered. Secondly, the simulation results of the model are obtained using the numerical solving algorithm ode15s. The actual experiment is carried out on the indoor Tractor PTO Test Bench. Then, the model is verified by comparing the test results with the simulation results. Finally, the dynamic characteristics of the whole driveline are revealed under different drive modes, especially strong interactions between the driveline and field machinery in low-speed and heavy-load mode. The gear mesh forces and the root mean square (RMS) values of the acceleration amplitude for the main parts generally decrease gradually with the increase in the PTO rotation speed and the decrease in PTO torque. Furthermore, the model can be applied to reliability assessment, for instance, vibration, damage, and fatigue of off-road vehicles considering gear transmissions, particularly in a field working environment. Full article

Gear dynamics analysis based on time-varying meshing stiffness (TMS) is an important means to understand the gear fault mechanism. Based on Jones bearing theory, a bearing statics model was established and introduced into a gear system. The lateral–torsion coupling vibration model of the gear shaft was built by using a Timoshenko beam element. The lumped parameter method was used to build the dynamic model of a gear pair. The dynamic model of a spur gear system was formed by integrating the component model mentioned above. The influence of rectangular and elliptical spalling on TMS was analyzed by the potential energy method (PEM). The fault feature of tooth spalling was studied by dynamic simulation and verified by experiments. It is found that the gear system will produce a periodic shock response owing to the periodic change of the number of meshing gear teeth. Due to the contact loss and the decrease of TMS, a stronger shock response will be generated when the spalling area is engaged. In the spectrum, some sidebands will appear in the resonance region. The results can provide a theoretical guide for the health monitoring and diagnosis of gear systems. Full article

Field investigation shows that most corrugations occur on the inner rail surface of curved tracks with a radius of less than 700 m. In order to explore the formation mechanism of metro corrugation, the relationship between wheel–rail stick–slip characteristics and rail corrugation is studied by combining single wheelset curving and a rigid–flexible coupling model. The numerical results illustrate that the lateral torsional stick–slip vibration of inner rail–inner wheel of the guiding wheelset on the small radius curve eventually leads to the generation of inner rail corrugation, and the lateral torsional stick–slip vibration of outer rail–outer wheel of the driven wheelset may also occur, but the intensity is weak and the probability is low. The lateral torsional stick–slip vibration of inner rail–inner wheel of the guiding wheelset on the large radius curve is also easy to cause inner rail corrugation, but the degree of inner rail corrugation is lower than that on the small radius curve; the outer rail on the large radius curve is still not easy to produce corrugation. The formation mechanism of rail corrugation on the straight track is different from that on the curve track, which is mainly related to the wheel–rail longitudinal torsional stick–slip vibration. Full article
