This study develops and validates a finite element model for round-ended concrete-filled steel tubular (CFST) columns subjected to combined compression–bending–shear loading using ABAQUS. Based on the calibrated model, the mechanical behavior of such members is thoroughly analyzed, including lateral bearing capacity, axial force evolution, and interaction mechanisms. The influences of key parameters, such as shear-span ratio, axial load ratio, cross-sectional aspect ratio, concrete strength, and steel yield strength, on the bearing capacity are systematically investigated. Furthermore, a calculation method for predicting the ultimate bearing capacity is proposed based on the section equivalent approach. The results demonstrate that the loading direction relative to the principal axes significantly affects structural performance: long-axis loading leads to higher bearing capacity and improved ductility, whereas short-axis loading reduces the ultimate capacity by an average of 49%. As the shear-span ratio increases, the ultimate lateral capacity gradually decreases. For shear-span ratios between 1.0 and 3.0, the long-axis loaded specimens exhibit pronounced compression–bending–shear failure modes. Variations in the axial load ratio notably influence both lateral capacity and axial force distribution; both bearing capacity and ductility decrease with increasing axial load ratio, although the effect on ultimate capacity remains minor when the axial load ratio does not exceed 0.4. Full article

Lane departure can cause lateral vehicle collisions and, in severe cases, lead to vehicles running off the road. Such incidents often occur on curved sections and ramps. This study focuses on loop ramps. To quantify the impact of geometric alignment characteristics of loop ramps on lane departure behaviors, unmanned aerial vehicle (UAVs) aerial photography was used to collect operation videos of 10 loop ramps at 6 interchanges, and 762 pieces of vehicle trajectory data under free-flow conditions were extracted based on DataFromSky. Combined with the indicators of equivalent radius and trajectory design curvature difference, vehicle trajectories were systematically classified into three patterns via k-means clustering: in the direction of centrifugal force (IDCF), against the direction of centrifugal force (ADCF), and no-offset normal driving (NOND). A multinomial logistic regression model was constructed to analyze the influence of loop ramp geometric alignment characteristics on departure behaviors. The results show that for the horizontal alignment elements of loop ramps, an increase in circular curve radius, a decrease in circular curve length, and a decrease in the length of the transition curve entering the circular curve all increase the risk of IDCF; conversely, the increase in these geometric parameters tend to increase the risk of ADCF. For the vertical alignment elements, there is a significant nonlinear negative correlation between the adjacent maximum gradient difference and lane departure behaviors. For the cross-section of loop ramps, widening can significantly suppress the risk of IDCF but slightly increase the risk of ADCF. This study reveals the synergistic influence mechanism of the three-dimensional (horizontal, vertical, and cross-sectional) geometric characteristics of combined alignments on lane departure behaviors at interchange loop ramps. Full article

The accurate estimation of the fundamental period is critical for seismic design using the Equivalent Lateral Force method. This study evaluates widely used empirical period formulae from international seismic codes and previous research by comparing them with detailed finite element method (FEM) analyses. A total of 93 reinforced concrete building models were assessed. The results show that most empirical formulae, notably the American Society of Civil Engineers Standard (ASCE 7-10), the Eurocode, the National Building Code of Canada (NBCC), and the Saudi Building Code (SBC 301), systematically underestimate the fundamental period in low- and mid-rise buildings often by more than 40% under cracked conditions, while discrepancies reduce under uncracked assumptions. Equations such as those proposed by the Building Standard Law of Japan (BSLJ) and Australian Standard (AS 11407.2) show comparatively closer agreements with FEM predictions, whereas formulae developed by Goel and Chopra and by Alguhane et al. have distinct differences, especially at greater heights. Statistical parameters, including the arithmetic mean difference and the standard deviation, were employed to enhance the comparison and assess the accuracy and dispersion of the estimated fundamental periods. The results indicate that empirical formulae, although beneficial in first-design stages, are likely to yield conservative results and suggest the use of advanced numerical computation or revised models and coefficients for RC high-rise and irregular buildings. Full article

Reinforced concrete buildings with masonry-induced soft-storey irregularities exhibit extreme seismic vulnerability, a critical risk often underestimated by conventional code-based design. Standard equivalent static methods typically fail to capture the intense concentration of seismic demand at the flexible ground level, leading to unconservative designs that do not meet performance objectives. This research proposes a corrective linear–static methodology to address this deficiency. A new Equivalent Lateral Force profile (ELF_i1) was developed, derived from modal analyses of 235 representative soft-storey archetypes to accurately account for stiffness heterogeneity. This profile was integrated with a realistic response modification coefficient (R_i1 = 5.04), determined to be 37% lower than the normative R-factor (R = 8) prescribed by code. Nonlinear static analyses confirmed that conventional design resulted in “irreparable” damage (mean Global Damage Index = 0.82). In contrast, redesigning the structure using the proposed ELF_i1 and R_i1 methodology successfully mitigated damage concentration, upgrading structural performance to a “repairable” state (mean Global Damage Index = 0.52). Finally, Incremental Dynamic Analysis validated the approach; the redesigned structure satisfied FEMA P695 collapse prevention criteria, achieving an Adjusted Collapse Margin Ratio (ACMR) of 2.10. This study confirms the proposed method is a robust and practical design alternative for soft-storey mechanisms within a simplified linear framework. Full article

Continuous-flow separation of magnetically labeled cells according to surface-marker expression levels is increasingly needed to study phenotypic heterogeneity and support downstream assays. Here, we present a microfluidic platform that uses spatially engineered soft magnetic strips (SMS) to sculpt lateral magnetic deflection fields for quantitative, label-guided cell fractionation. Under a uniform bias field, the SMS generates controllable magnetic gradients within the microchannel, producing distinct lateral velocities among EpCAM-labeled tumor cells that carry different Dynabead loads, which indirectly report membrane protein expression. Multi-outlet collection converts these “race-based” trajectory differences into discrete expression-level-resolved fractions. A COMSOL–MATLAB framework and a force-equivalent metric |(H·∇)H| are used to optimize key structural parameters of the magnetic interface, including strip thickness, width, and vertical spacing from the flow channel. Three journey nodes at 1.5, 3, and 9 mm along the flow path define a three-stage cascade that partitions MDA-MB-231, Caco-2, and A549 cells into four EpCAM-related magnetic subgroups: high (H), medium (M), low (L), and near-negative (N). Experiments show that the sorted fractions follow the expected expression trends reported in the literature, while maintaining high cell recovery (>90%) and viability retention of 98.2 ± 1.3%, indicating compatibility with downstream whole-blood assays and culture. Rather than introducing a new biomarker, this work establishes a quantitative magnetic-field design strategy for continuous microfluidic sorting, in which the spatial configuration of soft magnetic elements is exploited to implement expression-level-dependent fractionation in next-generation magneto-fluidic separation systems. Full article

This study investigated the mechanical properties of a boltless hexagonal segment lining structure in TBM tunnels through a 1:10 scale similarity model test. The analysis considered the effects of burial depth and lateral pressure coefficient. A gypsum-diatomite composite simulated C50 concrete segments, and a custom loading system applied equivalent soil-water loads. The tests examined variations in bending moment, axial force and displacement. The results demonstrate that: (1) The tongue-and-groove joints behave like hinges, effectively reducing joint bending moments. (2) The unique staggered interlocking structure induces significantly higher axial forces at the joints than traditional rectangular segments, increasing susceptibility to stress concentration. (3) Increased burial depth has the most significant impact on the tunnel crown, where the bending moment, axial force, and displacement change most notably. (4) The lateral pressure coefficient (λ) alters the joint load transfer mechanism by modifying the structure’s triaxial stress state. An optimal λ of 0.6 maximizes axial force transfer efficiency, while excessively high values impair horizontal load-bearing capacity. (5) Structural failure was ductile, with a final ovality slightly exceeding 10‰. The findings of this study can provide a reference for the design and application of similar boltless hexagonal segment tunnels. Full article

We propose an integrated model predictive control (MPC) scheme for steering-robot path tracking that directly optimizes the robot voltage and embeds steering-angle limits as linear-inequality voltage constraints inside the optimizer. This avoids cascade-induced error accumulation and extra phase lag in MPC+PID while guaranteeing actuator-level feasibility. A Simulink–CarSim co-simulation evaluates two scenarios: (1) double-lane change (DLC) at 70/40 km·h⁻¹; and (2) straight-line tracking with/without sinusoidal crosswind modeled as an equivalent lateral force. Metrics include lateral-error RMS/Peak/P95 and real-time statistics (WCET, average per-update time, and utilization rate). The results show consistent gains: at 70 km·h⁻¹, RMS/Peak/P95 decrease by 22.3%/18.0%/17.7%; and, at 40 km·h⁻¹, by 17.0%/19.5%/18.9%. Real-time feasibility is met with $T$ = 10 ms, average ≈ 1.7 ms, WCET ≈ 2.1~2.3 ms, utilization ratio ≈ 0.17. Under crosswind, robustness improves over the cascaded baseline by 9.7%/35.6%/30.8% on RMS/Peak/P95. The method provides tighter tracking, stronger disturbance rejection, and strict timing for safety-critical testing. Full article

This paper analyzes the seismic performance and damage characteristics of high-rise frame-core-tube structures on soft soil, explicitly incorporating dynamic soil–pile–structure interaction (SSI). A refined 3D finite element model of a 52-storey soil–pile–structure system was developed in ABAQUS, utilizing viscous-spring boundaries and the equivalent nodal force method for seismic input. Nonlinear analyses under six seismic waves were compared to a fixed-base model neglecting SSI. Key findings demonstrate that SSI significantly alters structural response; it amplifies lateral displacements and inter-storey drift ratios throughout the structure, particularly at the top level. While total base shear decreased, frame column base shear forces substantially increased. SSI also reduced peak top-storey accelerations, diminished short-period spectral components, and prolonged the predominant period of response spectra. Analysis of member damage revealed SSI generally reduced compressive and tensile damage in core walls, floor slabs, and frame beams. Principal compressive stresses at the base of frame columns increased under SSI. These results highlight the necessity of including dynamic SSI in seismic analysis for high-rises on soft soil, specifically due to its detrimental amplification of forces in frame columns. Full article

Controlling legged robots to run at high speeds or to traverse complex terrains remains challenging due to the difficulty of handling the interaction between the robot and the ground. Impedance control and model predictive control are widely used to account for ground reaction forces (GRFs) during dynamic locomotion. This paper introduces a model predictive impedance control (MPIC) method that combines the advantages of both strategies and applies it to a quadruped robot. The proposed approach reformulates MPIC within the single rigid body model (SRBM) framework and derives linear inequality constraints for the equivalent wrench, allowing explicit consideration of GRF limits while retaining compliant behavior against ground impacts and external disturbances. Furthermore, a novel optimized gait pattern based on a simplified dynamic model is introduced to minimize the effect of GRFs on the robot. The resulting gait improves stability compared to conventional gait patterns while maintaining a similar level of energy efficiency. The proposed method is validated through various simulations under diverse conditions. The results demonstrate that it enables the quadruped robot to run at a speed of 12 m/s while maintaining stability against repeated lateral disturbances. Full article

In recent years, novel Personal Mobility Vehicles (PMVs) with a narrow width and an inward tilting mechanism, similar to motorcycles (MCs), have been proposed to prevent overturning during turns. Due to their compact size, these vehicles have inherent limitations in collision safety, making their dynamic safety and accident avoidance capabilities particularly crucial. In this study, a comparative analysis was conducted using a simulated single lane change course to evaluate obstacle avoidance performance. The results reveal that PMVs equipped with an active inward tilting mechanism exhibit superior obstacle avoidance capabilities. Based on the roll moment equilibrium conditions of these vehicles, an investigation of vehicle states during avoidance maneuvers revealed that both actual and virtual tilt angles coexist in PMVs, and their combined equivalent tilt angle effectively balances the roll moment during turning. This unique mechanism, which integrates the responsiveness of passenger cars with motorcycle-like tire lateral force characteristics, underpins the exceptional obstacle avoidance capabilities of actively inward tilting PMVs. Full article

To investigate how severe wear at No. 12 turnout frogs in an urban rail transit line operating at speeds over 120 km/h on the dynamic performance of the vehicle, a vehicle–frog coupled dynamic model was established by employing the 2021 version of SIMPACK software. Profiles of No. 12 alloy steel frogs and metro wheel rims were measured to simulate wheel–rail interactions as the vehicle traverses the turnout, using both brand-new and worn frog conditions. The experimental results indicate that increased service life deepens frog wear, raises equivalent conicity, and intensifies wheel–rail forces. When a vehicle passes through the frog serviced for over 17 months at the speed of 120 km/h, the maximum derailment coefficient, lateral acceleration of the car body, and lateral and vertical wheel–rail forces increased by 0.14, 0.17 m/s², 9.52 kN, and 105.76 kN, respectively. The maximum contact patch area grew by 35.73%, while peak contact pressure rose by 236 MPa. To prevent dynamic indicators from exceeding safety thresholds and ensure train operational safety, it is recommended that the frog maintenance cycle be limited to 12 to 16 months. Full article

This paper establishes some links between Sturm–Liouville problems and the well-known controllability property in linear dynamic systems, together with a control law design that allows any prefixed arbitrary final state finite value to be reached via feedback from any given finite initial conditions. The scheduled second-order dynamic systems are equivalent to the stated second-order differential equations, and they are used for analysis purposes. In the first study, a control law is synthesized for a forced time-invariant nominal version of the current time-varying one so that their respective two-point boundary values are coincident. Afterward, the parameter that fixes the set of eigenvalues of the Sturm–Liouville system is replaced by a time-varying parameter that is a control function to be synthesized without performing, in this case, any comparison with a nominal time-invariant version of the system. Such a control law is designed in such a way that, for given arbitrary and finite initial conditions of the differential system, prescribed final conditions along a time interval of finite length are matched by the state trajectory solution. As a result, the solution of the dynamic system, and thus that of its differential equation counterpart, is subject to prefixed two-point boundary values at the initial and at the final time instants of the time interval of finite length under study. Also, some algebraic constraints between the eigenvalues of the Sturm–Liouville system and their evolution operators are formulated later on. Those constraints are based on the fact that the solutions corresponding to each of the eigenvalues match the same two-point boundary values. Full article

In order to solve the zoom delay issue for high-magnification zoom optical systems, a voice coil motor (VCM) is used to achieve rapid zooming. In this paper, the structural design of VCMs is systematically analyzed through magnetic field numerical computations. Firstly, finite element method (FEM) is used to analyze magnetic field of single magnets, and simulations correspond to experimental results. Both FEM and equivalent magnetic charge (EMC) results confirm that increasing magnet thickness while reducing its lateral dimensions will contribute to magnetic enhancement. Furthermore, the influence of structural parameters VCM is analyzed, validating the yoke’s critical role in suppressing edge effects and optimizing magnetic circuit efficiency, and optimal yoke thickness and magnet width range are determined. Moreover, a simple EMC calculation method is proposed for rapid and accurate determination of the magnetic field distribution in the VCM air gap. Optimal structural parameters of VCM are determined for a 40× rapid zoom lens with cost and space limitations. Driving force F_drive = 5.58 N is about 5 times the demand force F_d = 1.06 N, and the prototype fabrication of the rapid zoom lens is successfully accomplished. Moving group reaches 35.4 mm destination within 0.18 s, and photographs confirm that the rapid zoom system achieves 100-ms-level short/long-focus transition. Rapid zoom lens shows great potential in applications including security surveillance, industrial visual inspection, and intelligent logistics management. Full article

The behavior of long-span concrete-filled steel tube (CFST) arch bridges during the pouring stage is complex. The coupling effect of the time-varying hydration heat and the evolution of the elastic modulus is crucial for the linear control of the structure. Most of the existing models focus on static self-weight analysis but generally ignore the above-mentioned dynamic heat–force interaction, resulting in significant prediction deviations. In response to this limitation, this paper proposes an analysis method for the injection stage considering the time-varying heat of hydration and elastic modulus of concrete inside the pipe. Firstly, based on the composite index model of the hydration heat and through the reduction of the participating materials, the heat source function of the hydration heat of the arch rib was obtained, and its accuracy was verified by using two test components. Secondly, the equivalent application method of the hydration heat temperature field of the bar system model was proposed. Combined with the modified time-varying model of the elastic modulus at the initial age, the analysis method for the pouring stage of concrete-filled steel tube arch bridges was established. Finally, the accuracy of the proposed method was verified by analysis and calculation combined with engineering examples and comparison with the measured results. The results show that the time-varying heat of hydration and the time-varying elastic modulus during the concrete pouring stage inside the pipe can lead to residual deflection after the arch rib is poured. The calculated value of the example reaches 154 mm, while the influence of the lateral displacement is relatively small and recoverable. The proposed method improves the calculation accuracy by 44.19% compared with the traditional method, which is of great significance for the actual engineering construction control. Full article

Background/Objectives: Orthoses are commonly used in the treatment of various foot and ankle injuries and deformities. An effective technology in foot orthoses is a vacuum system to improve the fit and function of the orthosis. Recently, a new technology was designed to facilitate the wearing of the foot orthoses while maintaining function without the need for vacuum suction. Methods: A plantar dynamic pressure distribution measurement was carried out in 25 healthy subjects (13 w/12 m, age 23–58 y) using capacitive measuring insoles in two differently designed inlays within the VACOpedes^® orthosis (Group A: vacuum inlay vs. Group B: XELGO^® inlay) and a regular off-the-shelf shoe (Group C, OTS). The peak plantar pressure, mean plantar pressure and maximum force were analyzed in the entire foot and in individual regions of the medial and lateral forefoot, the midfoot and the hindfoot. Finally, the wearing comfort was compared using a visual analog scale from 1 to 10 (highest comfort). Results: The peak pressure of both inlays was significantly lower than in the OTS shoe (A: 230.6 ± 44.6 kPa, B: 218.0 ± 49.7 kPa, C: 278.6 ± 50.5 kPa; p < 0.001). In a sub-analysis of the different regions, the XELGO^® inlay significantly reduced plantar pressure in the medial forefoot compared to the vacuum orthosis (A: 181.7 ± 45.7 kPa, B: 158.6 ± 51.7 kPa, p < 0.002). The wearing comfort was significantly higher with the XELGO^® inlay compared to the vacuum inlay (A: 5.68/10, B: 7.24/10; p < 0.001). Conclusions: The VACOpedes^® orthosis with a new XELGO^® inlay showed at least equivalent relief in all pressure distribution measurements analyzed and greater relief in the forefoot area than the VACOpedes^® orthosis with a vacuum inlay, as well as increased wearing comfort. Full article
